KingBoard Technology KF-100 FM transmitter User Manual Model No
Shenzhen KingBoard Technology Co., Ltd. FM transmitter Model No
User manual
Model No. : KF-100 REV: A 20151216
Kingboard technology Co.,ltd
Shenzhen KingBoard Technology Co., Ltd.
Item: FM transmitter
Description:
KF-100 it is the FM transmitter with a 3.5mm Jack, connected with cellphone or other
MP3 player.
Remark:
1. keep out of reach of children!
2.Pls use the original accessories
3.If unit have problem ,pls contact with the seller.Disassemble the unit by User is not
allown
4.Keep good ventilated environment when charge the unit, do not keep near
inflammables , oxidizers and explosive
Model No. : KF-100 REV: A 20151216
Kingboard technology Co.,ltd
B. Specification:
1. Size：--- mm
6. Charge port: Micro USB
2. Weight：-- g
7. connection jack：3.5MM
3. Battery output：DC3.7 ~ 4.2V
8. FM Frequency range ：
87.5-108.0Mhz
4. Charge input：DC 5V-1000mAh
5. Battery capactity：110mAh
Operation guide
A:“
Short press：Decrease 0.1 Mhz
Long press：Decrease the volume
B:“
Short press：Increase 0.1 Mhz
Long press：Increase the volume
C. “ON/OFF”
Switch to on, to turn on.
Switch to on, to turn off.
Model No. : KF-100 REV: A 20151216
Kingboard technology Co.,ltd
USER’S GUIDE:
connect KF-100’s audio plug to the headphone jack of your music device,
cellphone or other MP3 player.
Turn KF-100 “ON”
Start playing a song on your music device at medium level volume.
Turn on your FM radio and find a station (frequency) that is not being used,
for example: 88.1 MHz.
Use the FWD and BACK scan buttons on KF-100 to match the radio station
you found, for example: 88.1MHz.
Note: Now both KF-100 and your radio should be on the same station, and
you should hear your music playing.
Adjust the volume on your music device and/or FM radio as necessary.
FCC Statement:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modications to this device not explicitly approved
by manufacturer could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
