L and Y Audio SIR200 Bluetooth Speaker User Manual
Shenzhen L&Y; Audio Co., LTD Bluetooth Speaker
User Manual
Power: 5W RMS
CSR4.0+EDR, A2DP AVRCP
NET Weight: 200g/0.2kg/0.44 lb/7.05 oz
Dimensions:102 x 95 x 43 mm/3.94 x 3.70 x 1.81 inch
2" full range driver
360° omnidirectional sound
IPX5 Splashproof
Warranty card X 1
User Manual X 1 AUX cable X 1
Charging cable X 1
GENIE X 1
USER GUIDE
GENIE
LINE IN 5V
Smart Voice-control to activate Siri/Google Now
Short press to Turn On/Off;
long press for 3 seconds for Bluetooth pairing.
“ ”
Music That Moves
Charging Indicator:
Charging - Solid Red ,
Charging complete - Slight Red.
Status Indication
Hands-Free
AUX-IN
LINE IN 5V
1.800mAh Rechargeable Li-Polymer Battery
Play time: Up to 10 Hours
(5 Hours at Max Bolume, Full Bass Status)
LINE IN 5V
MIC
HFC (Hands Free Calling)
Specifications
Voice control is capable based on:
1. Your phone is Siri or Google Now compatible;
2. Your phone's internet service is available.
Power /Bluetooth
Voice Control /Volume
Blue light: Connected via Bluetooth
Red light: Connected via Line-in
* GENIE will remember the previous Bluetooth connection and pair
back automatically the next time turn it on. To pair with another
device instead, long press the power button for 3 seconds,
after a "Dong" tone and the Blue LED quick flash, repeat the normal
Bluetooth connection procedure.
Volume up
Volume down
1.Rotation for the bluetooth music, voice, the volume to add and subtract
2. Short press - Pause/Play/pick up phone calls
3. Long press for 3 seconds to activate voice control
Could not activate Siri or Google Now
1.Is your phone connected with GENIE properly?
2.Is the Internet Service available on your phone?
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
Caution: Any changes or modifications to this device not
explicitly approved by manufacturer could void your
authority to operate this equipment.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
The device has been evaluated to meet general RF exposure
requirement. The device can be used in portable exposure condition
without restriction.
Shenzhen L&Y Audio Co., LTD
Genie
Bluetooth Speaker
