TEST PAD
Test all your models on this test pad.
This is the starting point on the pad.
LEGO® BRICKS
72
LABELS
Use these labels to decorate your robots.
You can use these labels to stick around
both ends of a cable, to make sure the
cable is connected to the right port.
LEGO® BRICKS
73
TROUBLESHOOTING
Resetting the NXT
If the running icon stops spinning, your NXT has frozen
and you will need to reset it. Follow these steps to reset your NXT:
Make sure that your NXT is turned on.
Push the reset button that is located on the back of
your NXT in the LEGO® Technic hole in the upper left
corner. Use, for example, an unfolded paperclip to
press the button.
If you press the reset button for more than 4 seconds
you will need to update the fi rmware [see below].
Updating the fi rmware in the NXT from your computer
Go to Tools > Update NXT Firmware.
Make sure that your NXT is turned on.
Note! If you have just reset your NXT (see above)
the display will not show anything. A ticking sound
will tell whether it is turned on or not.
Make sure that your NXT and computer are connected
with the USB cable.
Go to the Tools pull-down menu in the software’s
menu bar and select Update NXT Firmware.
USEFUL INFORMATION
74
FCC approval:
Model: MINDSTORMS NXT FCC ID:NPI53788
This device complies with part 15 of the FCC Rules. Operation is subject to the following 2 conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received including interference that may cause undesired operation.
Warning:
Changes or modifi cations to this unit not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class 8 digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses an can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off an on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Hereby LEGO Company declares that MINDSTORMS NXT (8527) is in compliance with the essential requirements and other relevant
provisions of Directive 199/5/E.
Select the fi rmware you want to update.
Click download. (Note! The Windows ‘Found new
hardware wizard’ will pop up the fi rst time you
update your fi rmware. Complete the wizard by
following the on-screen instruction before you
continue).
For other types of troubleshooting, go to www.MINDSTORMS.com/support
USEFUL INFORMATION
75
1:1
1:1
Advanced Build
Profi modelle
Construction avancée
Costruzione avanzata
Geavanceerd bouwen
Construcción avanzada
Byg avanceret
Taitavalle rakentajalle
Bygg avancerat
Construção Avançada
Profi knak
Quick Build
Schnellbaumodelle
Construction rapide
Costruzione rapida
Snel bouwen
Construcción rápida
Byg hurtigt
Nopeaan rakentamiseen
Bygg snabbt
Construção Rápida
Kísérletezöknek
Experienced Build
Könnermodelle
Construction normale
Costruzione esperta
Bouwen voor gevorderden
Construcción experta
Byg videre
Kokeneelle rakentajalle
Bygg mer
Construção para Experimentados
Haladóknak
BLUETOOTH is a trademark owned by Bluetooth SIG, Inc. and licensed to the LEGO Group.
LEGO, the LEGO logo and MINDSTORMS are trademarks of the LEGO Group.
©2006 The LEGO Group. 4499268
Other product and company names listed are trademarks or trade names of their respective companies
