LG ELECTRONICS BTS1 Bluetooth Stereo Headset User Manual II
LG Electronics Inc. Bluetooth Stereo Headset II
Contents
- 1. User Manual
- 2. User Manual II
User Manual II
LED Indications and voice information
Power LED indicator Voice information
On Blue / Blinks four times. Power on
O Red / Blinks four times. Power o
Performance LED indicator Voice information
Ready to pair Blue / Turned on. Discovering
Connected Violet / Blinks twice. Your devies is connected
Battery LED indicator Voice information
High (more than 60%) Blue / Blinks. Batterty high
Medium (more than 20%) Violet / Blinks. Batterty medium
Low (less than 20%) Red / Blinks. Batterty low
Charging Red / Turned on. -
Charged Blue / Turned on. -
Product Overview
Mode selsection switch
: On the mobile mode this
device does not connect TV.
: On the TV mode this device
does not connect Bluetooth
device.
Press and hold to turn on (2
sec.) or o (3 sec.)
LED
Previous /
Next
Clip
Charging
yPlug the USB cable into the USB port at the
bottom of the unit. And connect the adapter
to charge.
yLED lights on red while charging and turns
into blue when charged.
MIC
Micro USB port
Basic operation
TV Connection
1
4
23
Select “LG BTS-1” on your
Bluetooth device.
Press and hold 1 button for
2 seconds and wait 5 seconds.
Additional Information
yKeep the distance less than 10 m between
Bluetooth device and the device.
yTV connecting time is approx. 10 ~ 20 seconds.
yDepending on the Bluetooth device, you need to
enter the PIN code “0000”.
Handsfree
This device supports a handsfree function via Bluetooth.
Before using this function, pair the device with your Bluetooth device.
yReceiving/Finishing a call: Press button to accept an incoming call. Press
button to hang up the call.
yRejecting a call: Press and hold button to ignore an incoming call.
ySwitching the voice output: Press and hold obutton for more than 3 seconds during a call.
Additional Information
yThis device may not work properly depending on the manufacturer or device.
yRefer to LG Electronics homepage for more information about handsfree function.
(www. lge.com)
Bluetooth Connection
This device can be paired with LG smart TV. You can listen to the TV sound comfortably via
Bluetooth using this device. TV connection has available only if your smart TV has LG sound sync
function.
1
4
23
Slide down to
TV mode.
Slide up to
mobile mode.
Press and hold 1 button for 2
seconds and wait 5 seconds.
LG smart TV [SETTING] menu /
[SOUND] / select [Sound out]
[LG Sound Sync. (Wireless)]
/ select “LG BTS1”
Refer to the LG smart TV manual for more information.
Quick Guide
TV & MOBILE STEREO HEADSET
BTS1
Rev 1.0 US
Please read this manual carefully before operating your set and
retain it for future reference.
Adapter
is not
supplied.
Precautions
In the Box
Device Earphone /Two sets of ear tips USB cable
Trubleshooting
Symptom Cause & Solution
No power.
yThe battery is discharged. Recharge the battery.
Bluetooth pairing does
not work well.
yCheck ı selection switch.
yInitialize the paring list by pressing 1 button and
button for more than 3 seconds at the same time, and then
reconnect to Bluetooth device.
yBe sure your Bluetooth device is on.
yRemove the obstacle in the path of the Bluetooth device
and the device.
yDepending on the type of the Bluetooth device or
surrounding environment, your device may not be paired
with the device.
No sound or sound
distortion.
yBe sure your Bluetooth device is on.
yThe volume of this device or your Bluetooth device is set to
minimum.
yWhen you use the other device at high volume, the sound
quality may distorted. Lower the volume of the devices.
yIf you use this device for purposes other than listening to
music, the sound quality may be lowered or the unit may
not work properly.
Can not connect a call
with the device.
yMake sure your phone supports the Bluetooth® prole.
yCheck the battery status by pressing 1 button twice.
The device does not
operate normally.
yPlease contact customer service.
Specifications
General
Power Supply 5 V 0 2.0 A (USB cable) / Built-in rechargeable battery.
Earphone jack Ø 3.5 mm
Communication
yBluetooth® V 3.0
yRange of Frequency: 2.402 GHz — 2.480 GHz
Operating time
yStand by: Up to 10 days.
yTalk and Music play: Up to 8 hrs.
Charging time Less than 2 hrs.
Dimensions (W x H x D) Approx. 35.9 mm x 50.2 mm x 19.2 mm
Net Weight (Approx.) 18.4 g
Operating temperature 5 °C — 45 °C
Operating humidity Less than 65 %
yDesign and specications are subject to change without notice.
Safety Information
Declaration of Confirmation
FCC Notice to Users:
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
Important Note:
To comply with the FCC RF exposure compliance requirements, no change to the antenna or the
device is permitted. Any change to the antenna or the device could result in the device exceeding
the RF exposure requirements and void user’s authority to operate the device.
Federal Communication Commission Interference Statement.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
yReorient or relocate the receiving antenna.
yIncrease the separation between the equipment and receiver.
yConnect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
yConsult the dealer or an experienced radio/TV technician for help.
CE Notice to Users:
Hereby, LG Electronics Inc. declares that this device is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC.
FCC ID: SSNBTS1
