User manual
www.lg.com
OWNER’S MANUAL
LED LCD TV
Please read this manual carefully before operating your set and retain it
for future reference.
32LS5700
42LS5700
47LS5700
55LS5700
P/NO : MFL67468101 (1111-REV00)
32LS5750
42LS5750
47LS5750
55LS5750
42LM6200
47LM6200
55LM6200
65LM6200
42LM6250
47LM6250
55LM6250
42LM6700
47LM6700
55LM6700
47LM7600
55LM7600
2
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
Always comply with the following precautions to avoid dangerous situations and ensure peak performance
of your product.
TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR
BACK). NO USER SERVICEABLE PARTS
INSIDE. REFER TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be
of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature accompanying
the appliance.
- TO REDUCE THE RISK OF FIRE AND
ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
WARNING/CAUTION
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
y Do not use this apparatus near water.
y Clean only with a dry cloth.
y Do not block any ventilation openings. Install
in accordance with the manufacturer’s
instructions.
y Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
y Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong are provided for your safety.
If the provided plug does not fit into your
outlet, consult an electrician for replacement
of the obsolete outlet (Can differ by country).
3
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
y Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
y Only use attachments/accessories specified
by the manufacturer.
y Use only with a cart, stand, tripod, bracket,
or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
y Unplug this apparatus during lightning
storms or when unused for long periods of
time.
y Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.
y Never touch this apparatus or antenna during
a thunder or lightning storm.
y When mounting a TV on the wall, make sure
not to install the TV by hanging the power
and signal cables on the back of the TV.
y Do not allow an impact shock or any objects
to fall into the product, and do not drop
anything onto the screen.
y CAUTION concerning the Power Cord
(Can differ by country):
It is recommended that appliances be
placed upon a dedicated circuit; that is, a
single outlet circuit which powers only that
appliance and has no additional outlets or
branch circuits. Check the specification page
of this owner’s manual to be certain. Do not
connect too many appliances to the same
AC power outlet as this could result in fire or
electric shock. Do not overload wall outlets.
Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power
cords, or damaged or cracked wire insulation
are dangerous. Any of these conditions could
result in electric shock or fire. Periodically
examine the cord of your appliance, and
if its appearance indicates damage or
deterioration, unplug it, discontinue use of
the appliance, and have the cord replaced
with an exact replacement part by an
authorized service. Protect the power cord
from physical or mechanical abuse, such as
being twisted, kinked, pinched, closed in a
door, or walked upon. Pay particular attention
to plugs, wall outlets, and the point where
the cord exits the appliance. Do not move
the TV with the power cord plugged in. Do
not use a damaged or loose power cord. Be
sure do grasp the plug when unplugging the
power cord. Do not pull on the power cord
to unplug the TV.
y Warning - To reduce the risk of fire or
electrical shock, do not expose this product
to rain, moisture or other liquids. Do not
touch the TV with wet hands. Do not install
this product near flammable objects such
as gasoline or candles, or expose the TV to
direct air conditioning.
4
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
y Do not expose to dripping or splashing and
do not place objects filled with liquids, such
as vases, cups, etc. on or over the apparatus
(e.g. on shelves above the unit).
y Grounding
Ensure that you connect the earth ground
wire to prevent possible electric shock
(i.e. a TV with a three-prong grounded AC
plug must be connected to a three-prong
grounded AC outlet). If grounding methods
are not possible, have a qualified electrician
install a separate circuit breaker. Do not try to
ground the unit by connecting it to telephone
wires, lightening rods, or gas pipes.
Short-circuit Breaker
Power Supply
y DISCONNECTING DEVICE FROM THE MAIN
POWER
The power outlet must remain readily
accessed in the event the device needs to
be unplugged.
y As long as this unit is connected to the AC
wall outlet, it is not disconnected from the
AC power source even if the unit is turned
off.
y Do not attempt to modify this product in any
way without written authorization from LG
Electronics. Unauthorized modification could
void the user’s authority to operate this
product.
y ANTENNAS Outdoor antenna grounding
(Can differ by country):
If an outdoor antenna is installed, follow
the precautions below. An outdoor antenna
system should not be located in the vicinity
of overhead power lines or other electric light
or power circuits, or where it can come in
contact with such power lines or circuits as
death or serious injury can occur. Be sure the
antenna system is grounded so as to provide
some protection against voltage surges
and built-up static charges. Section 810 of
the National Electrical Code (NEC) in the
U.S.A. provides information with respect to
proper grounding of the mast and supporting
structure, grounding of the lead-in wire to
an antenna discharge unit, size of grounding
conductors, location of antenna discharge
unit, connection to grounding electrodes and
requirements for the grounding electrode.
Antenna grounding according to the National
Electrical Code, ANSI/NFPA 70
NEC: National Electrical Code
Ground Clamp
Antenna Lead in Wire
Antenna Discharge Unit
(NEC Section 810-20)
Grounding Conductor
(NEC Section 810-21)
Power Service Grounding
Electrode System
(NEC Art 250, Part H)
Electric Service
Equipment
Ground Clamp
y Cleaning
When cleaning, unplug the power cord and
wipe gently with a soft cloth to prevent
scratching. Do not spray water or other
liquids directly on the TV as electric shock
may occur. Do not clean with chemicals
such as alcohol, thinners or benzine.
y Moving
Make sure the product is turned off,
unplugged and all cables have been
removed. It may take 2 or more people to
carry larger TVs. Do not press or put stress
on the front panel of the TV.
y Ventilation
Install your TV where there is proper
ventilation. Do not install in a confined
space such as a bookcase. Do not cover the
product with cloth or other materials while
plugged. Do not install in excessively dusty
places.
y If you smell smoke or other odours coming
from the TV, unplug the power cord contact
an authorized service center.
y Do not press strongly upon the panel with
hand or sharp object such as nail, pencil or
pen, or make a scratch on it.
y Keep the product away from direct sunlight.
5
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
y Dot Defect
The Plasma or LCD panel is a high
technology product with resolution of two
million to six million pixels. In a very few
cases, you could see fine dots on the screen
while you’re viewing the TV. Those dots
are deactivated pixels and do not affect the
performance and reliability of the TV.
y Generated Sound
“Cracking” noise: A cracking noise that
occurs when watching or turning off the TV
is generated by plastic thermal contraction
due to temperature and humidity. This noise
is common for products where thermal
deformation is required.
Electrical circuit humming/panel buzzing: A
low level noise is generated from a high-
speed switching circuit, which supplies a
large amount of current to operate a product.
It varies depending on the product.
This generated sound does not affect the
performance and reliability of the product.
y Take care not to touch the ventilation
openings. When watching the TV for a long
period, the ventilation openings may become
hot. This does not affect the performance of
the product or cause defects in the product.
y Viewing 3D Imaging (For 3D TV)
- The vision of young children may still be
developing. 3D contents should not be
viewed by children under the age of 5. All
other children’s viewing of 3D content should
be supervised by a responsible adult.
- Some viewers may experience symptoms of
discomfort such as nausea, eye strain, fatigue
and dizziness when viewing 3D content. All
viewers should take regular breaks to help
avoid these symptoms. If you experience any
symptoms of discomfort, discontinue viewing
and take a break until the symptoms go away.
If symptoms continue, consult a doctor.
- Following the guideline below may lessen the
likelihood of experiencing such discomfort:
· Viewing angle: watch 3D contents at the
eye level of the center of the TV screen.
· Viewing distance: watch 3D contents from
the minimum distance of 2 times the
diagonal size of the TV screen.
y If the TV feels cold to the touch, there may
be a small “flicker” when it is turned on. This
is normal, there is nothing wrong with TV.
Some minute dot defects may be visible on
the screen, appearing as tiny red, green, or
blue spots. However, they have no adverse
effect on the TV’s performance. Avoid
touching the LCD screen or holding your
finger(s) against it for long periods of time.
Doing so may produce some temporary
distortion effects on the screen.
DISPOSAL (Hg lamp only used in LCD TVs)
The fluorescent lamp used in this product contains
a small amount of mercury. Do not dispose of this
product with general household waste. Disposal of
this product must be carried out in accordance to
the regulations of your local authority.
Preventing “Image burn” or “Burn-in” on your TV screen
y If a fixed image displays on the TV screen for
a long period of time, it will be imprinted and
become a permanent disfigurement on the
screen. This is “image burn” or “burn-in” and
not covered by the warranty.
y If the aspect ratio of the TV is set to 4:3 for a
long period of time, image burn may occur on
the letterboxed area of the screen.
y Avoid displaying a fixed image on the TV screen
for a long period of time (2 or more hours for
LCD, 1 or more hours for the Plasma TV) to
prevent image burn.
For USA and Canada
NOTE TO CABLE/TV INSTALLER
This reminder is provided to call the CATV system
installer’s attention to Article 820-40 of the
National Electric Code (U.S.A.). The code provides
guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected
to the grounding system of the building, as close
to the point of the cable entry as practical.
F
T
s
t
p
i
n
s
t
e
ḫ
O
I
6
ENG
ENGLISH
TABLE OF CONTENTS
TABLE OF CONTENTS
2 IMPORTANT SAFETY INSTRUCTIONS
6 TABLE OF CONTENTS
7 INSTALLATION PROCEDURE
7 ASSEMBLING AND PREPARING
7 Unpacking
9 Optional Extras
10 Parts and buttons
11 Lifting and moving the TV
12 Setting up the TV
12 - Attaching the stand
13 - Mounting on a table
14 - Mounting on a wall
15 - Tidying cables
16 MAKING CONNECTIONS
16 Connecting to an antenna or cable
17 Connecting to a HD receiver, DVD, or VCR
player
17 - HDMI Connection
18 - DVI to HDMI Connection
19 - Component Connection
20 - Composite Connection
21 Connecting to a PC
21 - HDMI Connection, DVI to HDMI Connec-
tion or RGB Connection
23 Connecting to an Audio System
23 - Digital Optical Audio Connection
24 Connecting to a USB
25 REMOTE CONTROL
25 Magic Remote Control Functions
26 - Registering Magic Remote Control
26 - How to use Magic Remote Control
26 - Precautions to Take when Using the
Magic Remote Control
27 WATCHING TV
27 Turning the TV on for the first time
27 USING THE USER GUIDE
28 ENTERTAINMENT
28 Network Connection
28 - Connecting to a wired network
30 - Connecting to a wireless network
31 TROUBLESHOOTING
31 OPEN SOURCE SOFTWARE NOTICE
32 SPECIFICATIONS
35 MAINTENANCE
35 Cleaning Your TV
35 - Screen and frame
35 - Cabinet and stand
35 - Power cord
NOTE
y Image shown may differ from your TV.
y Your TV’s OSD (On Screen Display) may
differ slightly from that shown in this manual.
y The available menus and options may differ
from the input source or product model that
you are using.
y New features may be added to this TV in the
future.
7
ENG
ENGLISH
ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual
product and item.
INSTALLATION PROCEDURE
1 Open the package and make sure all the accessories are included.
2 Attach the stand to the TV set.
3 Connect an external device to the TV set.
4 Make sure the network connection is available.
You can use the TV functions only when the network connection is made.
NOTE
y The items supplied with your product may vary depending on the model.
y Product specifications or contents of this manual may be changed without prior notice due to
upgrade of product functions.
y For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm (0.39
inches) thick and 18 mm (0.7 inches) width.
y Use an extension cable that supports USB 2.0 if the USB cable or USB memory stick does not fit
into your TV's USB port.
B
AA
B
*A 10 mm (0.39 inches)
*B 18 mm (0.7 inches)
CAUTION
y Do not use any unapproved items to ensure the safety and product life span.
y Any damages or injuries by using unapproved items are not covered by the warranty.
y In case of some model, the thin film on screen is a part of TV, So don’t take it off.
8
ENG
ENGLISH
ASSEMBLING AND PREPARING
Magic Remote Control,
Batteries (AA)
(See p.25)
Owner’s manual Cable holder
(See p.15)
Screws for assembly
8 EA, M4 x 20
(See p.12)
Screw for fixing
(Except 55LM6700)
(See p.13)
Ring spacers
4 EA
(See p.15)
Power Cord Composite gender cable
(See p.19, 20)
Component gender cable
(See p.19)
Cinema 3D Glasses
(Except LS5700, LS5750
series)
The number of 3D glasses
may differ depending on the
model or country.
Polishing cloth
(Depending on model)
Gently wipe the spots on the
cabinet with the polishing
cloth.
9
ENG
ENGLISH
ASSEMBLING AND PREPARING
AG-F2**
Cinema 3D Glasses
The model name or design
may be changed depending
on the upgrade of product
functions, manufacturer’s
circumstances or policies.
AN-WF100
Wi-Fi dongle
AN-MR300
Magic Remote Control
Optional Extras
Optional extras can be changed or modified for quality improvement without any notification.
Contact your dealer for buying these items.
These device only works with compatible LG TV.
Compatibility LS5700
LS5750
LM6200
LM6250 LM6700 LM7600
AG-F2** Cinema 3D Glasses
AN-WF100 Wi-Fi Dongle
AN-MR300 Magic Remote Control
10
ENG
ENGLISH
ASSEMBLING AND PREPARING
Parts and buttons
SETTINGS
INPUT
OK
Speakers
Screen
1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.
2 All of the buttons are touch sensitive and can be operated through simple touch with your finger.
Touch buttons2
Power indicator
Remote control and
intelligent1 sensors
Touch Button Description
v ^
Scrolls through the saved channels.
- + Adjusts the volume level.
OK ٜSelects the highlighted menu option or confirms an input.
SETTINGS Accesses the main menu, or saves your input and exits the menus.
INPUT Changes the input source.
/ ITurns the power on or off.
NOTE
y You can set the power indicator light to on or off by selecting OPTION in the main menus.
11
ENG
ENGLISH
ASSEMBLING AND PREPARING
Lifting and moving the TV
When moving or lifting the TV, read the following
to prevent the TV from being scratched or
damaged and for safe transportation regardless of
its type and size.
CAUTION
y Avoid touching the screen at all times, as
this may result in damage to the screen.
y It is recommended to move the TV in the
box or packing material that the TV originally
came in.
y Before moving or lifting the TV, disconnect
the power cord and all cables.
y When holding the TV, the screen should face
away from you to avoid damage.
y Hold the top and bottom of the TV frame
firmly. Make sure not to hold the transparent
part, speaker, or speaker grill area.
y When transporting a large TV, there should
be at least 2 people.
y When transporting the TV by hand, hold the
TV as shown in the following illustration.
y When transporting the TV, do not expose the
TV to jolts or excessive vibration.
y When transporting the TV, keep the TV
upright, never turn the TV on its side or tilt
towards the left or right.
12
ENG
ENGLISH
ASSEMBLING AND PREPARING
Setting up the TV
Put your TV on a pedestal stand and mount the TV on a table or wall.
Attaching the stand
If you are not mounting the TV to a wall, use the following instructions to attach the stand.
CAUTION
y Tighten the screws firmly to prevent
the TV from tilting forward. Do not over
tighten.
1
3
2
CAUTION
y When attaching the stand to the TV
set, place the screen facing down on a
cushioned table or flat surface to protect
the screen from scratches.
NOTE
y Remove the stand before installing the TV
on a wall mount by performing the stand
attachment in reverse.
M4 x 20
4 EA
Front
M4 x 20
4 EA
Top View
13
ENG
ENGLISH
ASSEMBLING AND PREPARING
Mounting on a table
1 Lift and tilt the TV into its upright position on a
table.
- Leave a 10 cm (4 inches) (minimum) space
from the wall for proper ventilation.
10 cm
10 cm
10 cm
10 cm
(4 inches)
2 Connect the power cord to a wall outlet.
CAUTION
y Do not place the TV near or on sources
of heat, as this may result in fire or other
damage.
NOTE
y Swivel 20 degrees to the left or right and
adjust the angle of the TV to suit your view.
y When adjusting the angle of the TV, watch
out for your fingers.
2020
Securing the TV to a table
(Except 55LM6700)
Fix the TV to a table to prevent from tilting
forward, damage, and potential injury.
Mount the TV on a table, and then insert and
tighten the supplied screw on the rear of the
stand.
WARNING
y To prevent TV from falling over, the TV
should be securely attached to the floor/wall
per installation instructions. Tipping, shaking,
or rocking the TV may cause injury.
14
ENG
ENGLISH
ASSEMBLING AND PREPARING
Securing the TV to a wall (optional)
1 Insert and tighten the eye-bolts, or TV brackets
and bolts on the back of the TV.
- If there are bolts inserted at the eye-bolts
position, remove the bolts first.
2 Mount the wall brackets with the bolts to the
wall.
Match the location of the wall bracket and the
eye-bolts on the rear of the TV.
3 Connect the eye-bolts and wall brackets tightly
with a sturdy rope.
Make sure to keep the rope horizontal with the
flat surface.
CAUTION
y Make sure that children do not climb on or
hang on the TV.
NOTE
y Use a platform or cabinet that is strong and
large enough to support the TV securely.
y Brackets, bolts and ropes are optional. You
can obtain additional accessories from your
local dealer.
Mounting on a wall
Attach an optional wall mount bracket at the rear
of the TV carefully and install the wall mount
bracket on a solid wall perpendicular to the
floor. When you attach the TV to other building
materials, please contact qualified personnel.
LG recommends that wall mounting be performed
by a qualified professional installer.
10 cm
10 cm
10 cm
10 cm
(4 inches)
Make sure to use screws and wall mount
bracket that meet the VESA standard. Standard
dimensions for the wall mount kits are described
in the following table.
Model 32LS5700
42LS5700
32LS5750
42LS5750
42LM6200
42LM6250
42LM6700
47LS5700
55LS5700
47LS5750
55LS5750
47LM6200
55LM6200
65LM6200
47LM6250
55LM6250
47LM6700
55LM6700
47LM7600
55LM7600
VESA 200 x 200 400 x 400
Standard screw M6 M6
Number of screws 44
Wall mount bracket
(optional)
LSW200BX,
LSW200BXG
LSW400BX,
LSW400BXG
15
ENG
ENGLISH
ASSEMBLING AND PREPARING
CAUTION
y Disconnect the power first, and then move
or install the TV. Otherwise electric shock
may occur.
y If you install the TV on a ceiling or slanted
wall, it may fall and result in severe injury.
Use an authorized LG wall mount and contact
the local dealer or qualified personnel.
y Do not over tighten the screws as this may
cause damage to the TV and void your
warranty.
y Use the screws and wall mounts that meet
the VESA standard. Any damages or injuries
by misuse or using an improper accessory
are not covered by the warranty.
NOTE
y Use the screws that are listed on the VESA
standard screw specifications.
y The wall mount kit includes an installation
manual and necessary parts.
y The wall mount bracket is optional. You can
obtain additional accessories from your local
dealer.
y The length of screws may differ depending
on the wall mount. Make sure to use the
proper length.
y For more information, refer to the manual
supplied with the wall mount.
NOTE
y Place the ring spacers on the set before
installing the wall mounting bracket so that
the inclination of the backside of the set can
be adjusted perpendicularly.
Ring spacers
Tidying cables
1 Gather and bind the cables with the cable
holder.
Cable holder
CAUTION
y Do not move the TV by holding the cable
holder, as the cable holders may break, and
injuries and damage to the TV may occur.
16
ENG
ENGLISH
MAKING CONNECTIONS
Connecting to an antenna or cable
Connect an antenna, cable, or cable box to watch TV while referring to the following. The illustrations may
differ from the actual items and a RF cable is optional.
NOTE
y Use a signal splitter to use more than 2 TVs.
y Visit http://lgknowledgebase.com for more
information about the antenna and cable
connection. Search for antenna.
CAUTION
y Make sure not to bend the copper wire of
the RF cable.
Copper wire
y Complete all connections between devices,
and then connect the power cord to the
power outlet to prevent damage to your TV.
ANTENNA / CABLE
VHF Antenna
UHF Antenna
Antenna
Terminal
Coaxial (75Ω)
MAKING CONNECTIONS
Connect various external devices to the TV and switch input modes to select an external device. For more
information on external device’s connection, refer to the manual provided with each device.
Available external devices are: HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC,
gaming devices, and other external devices.
NOTE
y If you record a TV program on a DVD recorder or VCR, make sure to connect the TV signal input cable
to the TV through a DVD recorder or VCR. For more information on recording, refer to the manual
provided with the connected device.
y The external device connection may differ from the model.
y Connect external devices to the TV regardless of the order of the TV port.
y If you connect a gaming device to the TV, use the cable supplied with the gaming device.
y Refer to the external equipment’s manual for operating instructions.
17
ENG
ENGLISH
MAKING CONNECTIONS
Q
Connecting to a HD receiver, DVD, or VCR player
Connect a HD receiver, DVD, or VCR player to the TV and select an appropriate input mode.
HDMI Connection
HDMI is the best way to connect a device.
Transmits the digital video and audio signals from an external device to the TV. Connect the external device
and the TV with the HDMI cable as shown in the following illustration.
NOTE
y Use the latest High Speed HDMI™ Cable with CEC (Customer Electronics Control) function.
y High Speed HDMI™ Cables are tested to carry an HD signal up to 1080p and higher.
ARC (Audio Return Channel)
y Dq#h{whuqdo#dxglr#ghylfh#wkdw#vxssruwv#
VLPSOLQN#dqg#DUF#pxvw#eh#frqqhfwhg#
xvlqj#KGPL#lqsxw#4#+DUF,#sruw1
y Zkhq#frqqhfwhg#zlwk#d#kljk0vshhg#
KGPL#fdeoh/#wkh#h{whuqdo#dxglr#ghylfh#
wkdw#vxssruwv#DUF#rxwsxwv#rswlfdo#
VSGLI#zlwkrxw#dgglwlrqdo#rswlfdo#dxglr#
fdeoh#dqg#vxssruwv#wkh#VLPSOLQN#
ixqfwlrq1
HDMI
2 3 1
(ARC)
4
(PC)
IN
DVD/ Blu-Ray / HD Cable Box / HD STB
Choose any HDMI input port to connect.
It does not matter which port you use.
(*Not Provided)
NOTE
y DTV Audio Supported Codec: MPEG, Dolby
Digital
y HDMI Audio Supporeted Format: Dolby
Digital, PCM (Up to 192 KHz, 32k/44.1k/48k/
88k/96k/176k/192k) -> Not supported DTS.
18
ENG
ENGLISH
MAKING CONNECTIONS
AUDIO OUT
DVI OUT
4
(PC)
IN
(RGB/HDMI-PC)
AUDIO
(RGB/HDMI-PC)
AUDIO
DVI to HDMI Connection
Transmits the digital video signal from an external device to the TV. Connect the external device and the
TV with the DVI-HDMI cable as shown in the following illustration. To transmit an audio signal, connect an
audio cable.
(*Not Provided)
(*Not Provided)
DVD/ Blu-Ray / HD Cable Box
19
ENG
ENGLISH
MAKING CONNECTIONS
VIDEO
AUDIO
LR
IN
COMPONENT
AV
PRPBY
AUDIO
VIDEO
Component Connection
Transmits the analog video and audio signals from an external device to the TV. Connect the external
device and the TV with the component cable as shown in the following illustration.
NOTE
y If cables are installed incorrectly, it could case the image to display in black and white or with
distorted color.
y Check to ensure the cable are matched with the corresponding color connection.
DVD/ Blu-Ray / HD Cable Box
(*Not Provided)
(*Not Provided)
(Use the composite gender cable provided.) (Use the component gender cable provided.)
GREEN
RED
BLUE
GREEN
RED
BLUE
GREEN
RED
BLUE
WHITE
RED
YELLOW
WHITE
RED
WHITE
RED
20
ENG
ENGLISH
MAKING CONNECTIONS
Composite Connection
Transmits the analog video and audio signals from an external device to the TV. Connect the external
device and the TV with the composite cable as shown in the following illustration.
NOTE
y If you have a mono VCR, connect the audio cable from the VCR to the AUDIO L/MONO jack of the TV.
y Check to ensure the cable are matched with the corresponding color connection.
VIDEO
MONO
( )
AUDIOLR
IN
COMPONENT
AV
PRPBY
AUDIO
VIDEO
VCR / DVD/ Blu-Ray / HD Cable Box
(*Not Provided)
YELLOW
WHITE
RED
YELLOW
WHITE
RED
YELLOW
WHITE
RED
(Use the composite gender cable provided.)
21
ENG
ENGLISH
MAKING CONNECTIONS
HDMI
2 3 1
(ARC)
4
(PC)
IN
Connecting to a PC
NOTE
y It is recommended to use the TV with the HDMI connection for the best image quality.
y Depending on the graphics card, DOS mode may not work if a HDMI to DVI Cable is in use.
y In PC mode, there may be noise associated with the resolution, vertical pattern, contrast or
brightness. If noise is present, change the PC output to another resolution, change the refresh rate to
another rate or adjust the brightness and contrast on the PICTURE menu until the picture is clear.
y The synchronization input form for Horizontal and Vertical frequencies is separate.
y Depending on the graphics card, some resolution settings may not allow the image to be positioned
on the screen properly.
HDMI Connection, DVI to HDMI Connection or RGB Connection
Choose method A, B, or C to make connection.
Method A: HDMI Connection
(*Not Provided)
SF
Choose any HDMI input port to connect.
It does not matter which port you use.
22
ENG
ENGLISH
MAKING CONNECTIONS
Method B: DVI to HDMI Connection
Method C: RGB Connection
RGB OUT (PC) AUDIO OUT
(PC)
RGB
(RGB/HDMI-PC)
AUDIO
(PC)
RGB
(RGB/HDMI-PC)
AUDIO
(*Not Provided)
(*Not Provided)
SF
AUDIO OUT DVI OUT
4
(PC)
IN
(RGB/HDMI-PC)
AUDIO
(RGB/HDMI-PC)
AUDIO
(*Not Provided)
SF
(*Not Provided)
23
ENG
ENGLISH
MAKING CONNECTIONS
Connecting to an Audio System
Use an optional external audio system instead of the built-in speaker.
NOTE
y If you use an optional external audio device instead of the built-in speaker, set the TV speaker feature
to off.
Digital Optical Audio Connection
Transmits the digital audio signal from the TV to an external device. Connect the external device and the
TV with the optical audio cable as shown in the following illustration.
NOTE
y Do not look into the optical output port. Looking at the laser beam may damage your vision.
y Audio with ACP (Audio Copy Protection) function may block digital audio output.
Digital Audio System
(*Not Provided)
OPTICAL AUDIO IN
OUT
OPTICAL
DIGITAL
AUDIO
24
ENG
ENGLISH
MAKING CONNECTIONS
Connecting to a USB
Connect a USB storage device such as a USB flash memory, external hard drive, or a USB memory card
reader to the TV and access the Smart Share menu to use various multimedia files.
NOTE
y To store apps in the USB storage device, make sure that it is connected to the USB IN 3 USB Apps
port.
y To use USB Hub device, make sure that it is connected to the USB IN 2 USB Hub port.
USB Hub USB Apps
HDD IN
123
USB IN
USB
(*Not Provided)
Choose any USB input port to connect.
It does not matter which port you use.
25
ENG
ENGLISH
REMOTE CONTROL
REMOTE CONTROL
Magic Remote Control Functions
Please read this manual carefully and use the TV correctly.
When the message “Magic remote control battery is low. Change the battery.” is
displayed, replace the battery.
To replace batteries, open the battery cover, replace batteries (1.5 V AA) matching
and ends to the label inside the compartment, and close the battery cover. Be
sure to point the remote control at the remote control sensor on the TV.
To remove the batteries, perform the installation actions in reverse.
y Do not mix old and new batteries, as this may damage the remote control.
CAUTION
Make sure to point the remote control at the remote control sensor on the TV.
HOMEBACK
VOL CH
MY APPS
(POWER)
Turns the TV on or off.
Pointer (RF & Bluetooth transmitter)
Blinks the light when operating.
Home
Accesses the Home menu.
Navigation buttons (up/down/left/right)
Scrolls through menus or options.
BACK
Returns to the previous level.
+ VOL -
Adjusts the volume level.
^ CH v
Scrolls through the saved channels.
(MUTE)
Mutes all sounds.
MY APPS
Sees MY APPS.
(User Guide)
Sees User Guide.
(Wheel)
Selects menus or options and confirms
your input.
If you press the navigation button while
moving the pointer on the screen,
the pointer disappears, and the Magic
remote control works as a regular
remote control.
To display the pointer again, shake the
Magic remote control from side to side.
1
If you press (Wheel) on the Magic remote
control, the following screen appears.
Views the information of the current program
and screen.
2
If you press (Wheel) on the Magic remote
control, the following screen appears.
Set the channel you want.
You can press the CH button on the remote
control to set the channel.
3If you move the Magic remote control on the
bottom of the screen.
You can selcet Quick Menu.
%ULHI,QIR7LWOH7HVW ,QIR
᱈
$0
79 L
12
3
26
ENG
ENGLISH
REMOTE CONTROL
Registering Magic Remote Control
The Magic Remote Control operates by pairing
with your TV.
Register the Magic Remote Control to use it.
How to register the Magic Remote Control
To register the remote control,
press the (Wheel) button on
the remote control while aiming it
at your TV.
How to Re-register the Magic Remote Control
after Registration Failure
BACK
HOME
Reset the remote control by
pressing and holding both the
BACK and HOME buttons
for 5 seconds. (Once the reset is
complete, the light on the Pointer
blinks.) Then repeat the above
procedure to register the remote
control.
How to use Magic Remote
Control
1Press (Wheel) button if
there is no pointer on your TV
screen. The pointer will then
appear on the screen.
» If the pointer has not been
used for a certain period of
time, it will disappear.
2You can move the pointer by
aiming the Pointer Receiver of
the remote control at your TV
then move it left, right, up or
down.
» If the pointer does not work
properly after clicking the
(Wheel) button, leave
the remote control for 10
seconds then use it again.
Precautions to Take when Using
the Magic Remote Control
y Use the remote control within the maximum
communication distance (10 m, 32.8ft).
Using the remote control beyond this
distance, or with an object obstructing it,
may cause a communication failure.
y A communication failure may occur due to
nearby devices. Electrical devices such as
a microwave oven or wireless LAN product
may cause interference, as this will use the
same bandwidth (2.4 GHz) as the Magic
Remote Control.
y The Magic Remote Control may be damaged
or may malfunction if it is dropped or
receives a heavy impact.
y Take care not to bump into nearby furniture
or other people when using the Magic
Remote Control.
y Manufacturer and installer cannot provide
service related to human safety as the
applicable wireless device has possibility of
electric wave interference.
y It is recommended that an Access Point (AP)
be located more than 1 m (3.28 ft) away
from the TV. If the AP is installed closer than
1 m (3.28 ft), the magic remote control may
not perform as expected due to frequency
interference.
27
ENG
ENGLISH
WATCHING TV
NOTE
y To display images in the best quality for
your home environment, select Home*.
y Store* is suitable for the retail
environment.
y If you select Store*, the any customized
settings will switch back to the default
settings of Store* in 5 minutes.
y Power Indicator feature is disabled in
Store Demo mode.
4 When the basic settings are complete,
press (Wheel).
NOTE
y If you do not complete the Initial setting,
it will appear whenever the TV turns on.
y Disconnect the power cord from the
power outlet when you do not use the
TV for a long period of time.
5 To turn the TV off, press the power button on
the remote control.
USING THE USER
GUIDE
User Guide allows you to more easily access the
detailed TV information.
1 Move the Magic remote control on the bottom
of the screen.
2 Select
SETTINGS and press (Wheel).
3 Move the Magic remote control, select
SUPPORT and press (Wheel).
4 Move the Magic remote control, selectUser
Guide and press (Wheel).
NOTE
y You can also access the User Guide by
pressing (User Guide) in the remote
control.
WATCHING TV
Turning the TV on for the first
time
When you turn the TV on for the first time, the
Initial setting screen appears. Select a language
and customize the basic settings.
1 Connect the power cord to a power outlet.
2 In Standby mode, press the power button on
the remote control to turn the TV on.
The Initial setting screen appears if you turn
the TV on for the first time.
NOTE
y You can also access Initial Setting by
accessing OPTION in the main menu.
3 Follow the on-screen instructions to customize
your TV settings according to your preferences.
Language Selection* Selects a language to
display.
Ø
Using the Magic remote
control
Sets the Magic remote
contol.
Ø
Enviroment Selection Selects Home* for the
home environment.
Ø
Network Connection Sets your network to
enable network-related
feature on the TV.
Ø
Time Zone Setting Selects the time zone
and daylight saving.
Ø
Auto Tuning Scans and saves available
channels automatically.
Ø
Auto Energy Saving
mode Setting
Selects Auto Energy
Saving mode.
Ø
3D-On-Start Setting Selects 3D-On-Start
option. (For 3D TV)
Ø
Setting is complere. Confirms the setting
options.
28
ENG
ENGLISH
ENTERTAINMENT
ENTERTAINMENT
Network Connection
Connecting to a wired network
Connect the TV to a local area network (LAN) via
the LAN port as shown in the following illustration
and set up the network settings.
After making a physical connection, a small
number of home networks may require the TV
network settings to be adjusted. For most home
networks, the TV will connect to automatically
without any adjustments.
For detail information, contact your internet
provider or router manual.
LAN
External modem / Wall outlet / PC
(*Not Provided)
1
&RQQHFWLQJZLUHGQHWZRUN
2
CAUTION
y Do not connect a modular phone cable to the
LAN port.
y Since there are various connection methods,
please follow the specifications of your
telecommunication carrier or internet service
provider.
y After connecting the LAN port, use the
Premium or LG Apps menu.
29
ENG
ENGLISH
ENTERTAINMENT
To set up the network settings: (Even if your TV
has already connected automatically, running
setup again will not harm anything)
1 Press
SETTINGS to access the Home menu.
2 Press the Navigation buttons to scroll to
NETWORK.
3 Press the Navigation buttons to select
Network Connection and press (Wheel).
4 Press the Navigation buttons to select IP Auto
Setting or IP Manual Setting and press
(Wheel).
1HWZRUN6HWWLQJ
,QVHUWWKH,3DGGUHVV
,30RGH ܁,30DQXDO6HWWLQJ۽
ᯘ,3$GGUHVV
ᯘ6XEQHW0DVN
ᯘ*DWHZD\
'160RGH
,30DQXDO6HWWLQJ
ᯘ'166HUYHU
(QWHU
ᰳ3UHYLRXV ᯙ1H[W
- If selecting IP Manual Setting, press the
Navigation and Number buttons. IP addresses
will need to be input manually.
- IP Auto Setting: Select this if there is a DHCP
server (Router) on the local area network
(LAN) via wired connection, the TV will
automatically be allocated an IP address. If
you’re using a broadband router or broadband
modem that has a DHCP (Dynamic Host
Configuration Protocol) server function. The
IP address will automatically be determined.
- IP Manual Setting: Select if there is no DHCP
server on the network or you want to set the
IP address manually.
4 When you are finished, press Enter.
#NOTE
y If the network setting screen do not
appear automatically, press SETTINGS 䮫
NETWORK 䮫 Network Connection.
y If the network settings are not set correctly,
the functions or services that require the
network connection may not work properly.
y If the options in Network Connection are not
set properly, check your Internet connection
and contact your Internet service provider.
y To use Internet on TV, you must have active
broadband Internet connection at all times.
y If you cannot access the Internet, check the
network status of your computer.
y If the auto IP setting of the router
expires, when using IP Auto Setting,
you may experience temporary network
disconnection. Refer to the owner's manual
of the router for details.
30
ENG
ENGLISH
ENTERTAINMENT
Connecting to a wireless network
The LG Wireless LAN for Broadband/DLNA
Adaptor allows the TV to connect to a wireless
LAN network.
The network configuration and connection method
may vary depending on the equipment in use
and the network environment. Refer to the setup
instructions supplied with your access point or
wireless router for detailed connection steps and
network settings.
Setting up the AP (Access Point) or the wireless
router is required before connecting the TV to the
network. The easiest method is the WPS button
method (Third method in this section).
Wireless line sharer
NOTE
y For enjoying pictures, music, or video stored
on a PC using the router, a wired connection
is recommended.
y When the wireless port of the router is used,
there may be restrictions on some functions.
y It is recommended that an Access Point (AP)
be located more than 1 m (3.28 ft) away
from the TV. If the AP is installed closer than
1 m, the magic motion remote control may
not perform as expected due to frequency
interference.
31
ENG
ENGLISH
TROUBLESHOOTING
TROUBLESHOOTING
General
Problem Resolution
Cannot control the TV with the
remote control.
y Check the remote control sensor on the product and try again.
y Check if there is any obstacle between the product and the remote control.
y Check if the batteries are still working and properly installed ( to , to ).
No image display and no sound is
produced.
y Check if the product is turned on.
y Check if the power cord is connected to a wall outlet.
y Check if there is a problem in the wall outlet by connecting other products.
The TV turns off suddenly. y Check the power control settings. The power supply may be interrupted.
y Check if the Auto sleep feature is activated in the Time settings.
y If there is no signal while the TV is on, the TV will turn off automatically after
15 minutes of inactivity.
OPEN SOURCE SOFTWARE NOTICE
To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this
product, please visit http://opensource.lge.com.
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are
available for download.
32
ENG
ENGLISH
SPECIFICATIONS
SPECIFICATIONS
Product specifications may be changed without prior notice due to upgrade of product functions.
Power requirement USA, Canada, Mexico: AC 120 V ~ 50 / 60 Hz
Other Country: AC 100 - 240 V ~ 50 / 60 Hz
Television System NTSC-M, ATSC, 64 & 256 QAM
Program Coverage VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135
External Antenna Impedance 75 Ω
Environment
condition
Operating
Temperature
0 - 40 °C
Operating Humidity Less than 80 %
Storage Temperature -20 - 60 °C
Storage Humidity Less than 85 %
MODELS
32LS5700
(32LS5700-UA)
42LS5700
(42LS5700-UA)
32LS5750
(32LS5750-UA)
42LS5750
(42LS5750-UA)
Dimensions
(Width x Height x
Depth)
With stand
1171.9 mm x 770.9 mm x 289.8 mm
(46.1 inch x 30.3 inch x 11.4 inch)
979.0 mm x 660.0 mm x 269.0 mm
(38.5 inch x 25.9 inch x 10.5 inch)
Without stand
1171.9 mm x 712.2 mm x 52.5 mm
(46.1 inch x 28.0 inch x 2.0 inch)
979.0 mm x 593.0 mm x 35.5 mm
(
38.5
inch x 23.3 inch x 1.3 inch)
Weight With stand 29.8 kg (65.6 lbs) 15.1 kg (33.2 lbs)
Without stand 27.5 kg (60.6 lbs) 12.7 kg (27.9 lbs)
Current Value / Power consumption 0.7 A / 70 W 1.1 A / 110 W
MODELS
47LS5700
(47LS5700-UA)
55LS5700
(55LS5700-UA)
47LS5750
(47LS5750-UA)
55LS5750
(55LS5750-UA)
Dimensions
(Width x Height x
Depth)
With stand
1089.0 mm x 720.0 mm x 269.0 mm
(42.8 inch x 28.3 inch x 10.5 inch)
1171.9 mm x 770.9 mm x 289.8 mm
(46.1 inch x 30.3 inch x 11.4 inch)
Without stand
1089.0 mm x 655.0 mm x 35.5 mm
(42.8 inch x 25.7 inch x 1.3 inch)
1171.9 mm x 712.2 mm x 52.5 mm
(46.1 inch x 28.0 inch x 2.0 inch)
Weight With stand 17.8 kg (39.2 lbs) 29.8 kg (65.6 lbs)
Without stand 15.4 kg (33.9 lbs) 27.5 kg (60.6 lbs)
Current Value / Power consumption 1.4 A / 140 W 1.6 A / 160 W
33
ENG
ENGLISH
SPECIFICATIONS
MODELS
42LM6200
(42LM6200-UA)
47LM6200
(47LM6200-UA)
42LM6250
(42LM6250-UA)
47LM6250
(47LM6250-UA)
Dimensions
(Width x Height x
Depth)
With stand
1171.9 mm x 770.9 mm x 289.8 mm
(46.1 inch x 30.3 inch x 11.4 inch)
1171.9 mm x 770.9 mm x 289.8 mm
(46.1 inch x 30.3 inch x 11.4 inch)
Without stand
1171.9 mm x 712.2 mm x 52.5 mm
(46.1 inch x 28.0 inch x 2.0 inch)
1171.9 mm x 712.2 mm x 52.5 mm
(46.1 inch x 28.0 inch x 2.0 inch)
Weight With stand 29.8 kg (65.6 lbs) 29.8 kg (65.6 lbs)
Without stand 27.5 kg (60.6 lbs) 27.5 kg (60.6 lbs)
Current Value / Power consumption 1.1 A / 110 W 1.4 A / 140 W
MODELS
55LM6200
(55LM6200-UA) 65LM6200
(65LM6200-UA)
55LM6250
(55LM6250-UA)
Dimensions
(Width x Height x
Depth)
With stand
1390.8 mm x 905.2 mm x 334.7
mm
(54.7 inch x 35.6 inch x 13.1 inch)
1171.9 mm x 770.9 mm x 289.8 mm
(46.1 inch x 30.3 inch x 11.4 inch)
Without stand
1390.8 mm x 835.5 mm x 52.5 mm
(54.7 inch x 32.8 inch x 2.0 inch)
1171.9 mm x 712.2 mm x 52.5 mm
(46.1 inch x 28.0 inch x 2.0 inch)
Weight With stand 42.6 kg (93.9 lbs) 29.8 kg (65.6 lbs)
Without stand 38.5 kg (84.8 lbs) 27.5 kg (60.6 lbs)
Current Value / Power consumption 1.6 A / 160 W 1.7 A / 170 W
MODELS 42LM6700
(42LM6700-UA)
47LM6700
(47LM6700-UA)
Dimensions
(Width x Height x
Depth)
With stand
1171.9 mm x 770.9 mm x 289.8 mm
(46.1 inch x 30.3 inch x 11.4 inch)
1171.9 mm x 770.9 mm x 289.8 mm
(46.1 inch x 30.3 inch x 11.4 inch)
Without stand
1171.9 mm x 712.2 mm x 52.5 mm
(46.1 inch x 28.0 inch x 2.0 inch)
1171.9 mm x 712.2 mm x 52.5 mm
(46.1 inch x 28.0 inch x 2.0 inch)
Weight With stand 29.8 kg (65.6 lbs) 29.8 kg (65.6 lbs)
Without stand 27.5 kg (60.6 lbs) 27.5 kg (60.6 lbs)
Current Value / Power consumption 1.1 A / 110 W 1.4 A / 140 W
MODELS 55LM6700
(55LM6700-UA)
Dimensions
(Width x Height x
Depth)
With stand 1232.0 mm x 795.0 mm x 54.5 mm
(48.5 inch x 31.2 inch x 2.1 inch)
Without stand 1232.0 mm x 716.0 mm x 54.5 mm
(48.5 inch x 28.1 inch x 2.1 inch)
Weight With stand 25.0 kg (55.1 lbs)
Without stand 21.3 kg (46.9 lbs)
Current Value / Power consumption 1.6 A / 160 W
MODELS 47LM7600
(47LM7600-UA)
55LM7600
(55LM7600-UA)
Dimensions
(Width x Height x
Depth)
With stand
1171.9 mm x 770.9 mm x 289.8 mm
(46.1 inch x 30.3 inch x 11.4 inch)
1171.9 mm x 770.9 mm x 289.8 mm
(46.1 inch x 30.3 inch x 11.4 inch)
Without stand
1171.9 mm x 712.2 mm x 52.5 mm
(46.1 inch x 28.0 inch x 2.0 inch)
1171.9 mm x 712.2 mm x 52.5 mm
(46.1 inch x 28.0 inch x 2.0 inch)
Weight With stand 29.8 kg (65.6 lbs) 29.8 kg (65.6 lbs)
Without stand 27.5 kg (60.6 lbs) 27.5 kg (60.6 lbs)
Current Value / Power consumption 1.4 A / 140 W 1.6 A / 160 W
34
ENG
ENGLISH
SPECIFICATIONS
Wireless LAN for Broadband/DLNA Adaptor SPEC
This device only works with compatible LG TV.
Standard IEEE802.11a/b/g/n
Frequency Range
2402 to 2483 MHz
5150 to 5250 MHz
5725 to 5850 MHz
Modulation CCK / OFDM / MIMO
Output Power (Typical)
802.11a: 14 dBm
802.11b: 17 dBm
802.11g: 14 dBm
802.11n: 13 dBm
Data rate
802.11a/g: 54 Mbps
802.11b: 11 Mbps
802.11n: 300 Mbps
Antenna Gain (Typical)
2402 to 2483 MHz: 1.17 dBi
5150 to 5250 MHz: 4.67 dBi
5725 to 5850 MHz: 3.30 dBi
Occupied bandwidth 802.11a/b/g: HT20
802.11n: HT20/40
Because band channel used by the country could be different, the user can not change or adjust the
operating frequency and this product is set for the regional frequency table.
y FCC ID of Wi-Fi module inside TV
FCC ID: BEJTWFMB003D
RF module (BM-LDS302) specification
For TV By using a 2.4 GHz bandwidth radio frequency(RF).
y Output: 10 dBm or lower
y Maximum Communication Distance: Line of Open Sight approx. 10 m (30 ft)
y Bandwidth: 2.4 GHz (2.400 GHz ~ 2.4835 GHz)
y Transfer Rate: 3 Mbps
y FCC ID of RF module inside TV
FCC ID: BEJLDS302
35
ENG
ENGLISH
MAINTENANCE
MAINTENANCE
Update and clean your TV regularly to keep the
best performance and to extend the product
lifespan.
Cleaning Your TV
CAUTION
y Make sure to turn the power off and
disconnect the power cord and all other
cables first.
y When the TV is left unattended and unused
for a long time, disconnect the power cord
from the wall outlet to prevent possible
damage from lightning or power surges.
Screen and frame
To remove dust or light dirt, wipe the surface with
a dry, clean, and soft cloth.
To remove major dirt, wipe the surface with a
soft cloth dampened in clean water or a diluted
mild detergent. Then wipe immediately with a dry
cloth.
CAUTION
y Do not push, rub, or hit the surface with
your fingernail or a sharp object, as this may
result in scratches on the screen and image
distortions.
y Do not use any chemicals, such as waxes,
benzene, alcohol, thinners, insecticides, air
fresheners, lubricants, as these may damage
the screen’s finish and cause discoloration.
Cabinet and stand
To remove dust or light dirt, wipe the cabinet with
a dry, clean, and soft cloth.
To remove major dirt, wipe the cabinet with a
soft cloth dampened in a clean water or water
containing a small amount of mild detergent. Then
wipe immediately with a dry cloth.
CAUTION
y Do not spray liquid onto the surface. If water
enters the TV, it may result in fire, electric
shock, or malfunction.
y Do not use any chemicals as this may
deteriorate the surface.
Power cord
Remove the accumulated dust or dirt on the
power cord regularly.
ederal Communications Commission(FCC) Statement) Federal Communications Commission(FCC) Statement
You are cautioned that changes or modifications not expressly approved by You are cautioned that changes or modifications not expressly approved by
the part responsiblethe part responsible
for compliance could void the user
’
s authority to operate the equipmentfor compliance could void the user
’
s authority to operate the equipment
for
compliance
could
void
the
user s
authority
to
operate
the
equipment
.
for
compliance
could
void
the
user s
authority
to
operate
the
equipment
.
This equipment has been tested and found to comply with the limits for a This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC rules.Class B digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful These limits are designed to provide reasonable protection against harmful
it f i id tili tlltiit f i id tili tllti
i
n
t
er
f
erence
i
n a res
id
en
ti
a
l
i
ns
t
a
ll
a
ti
on.
i
n
t
er
f
erence
i
n a res
id
en
ti
a
l
i
ns
t
a
ll
a
ti
on.
This equipment generates, uses and can radiate radio frequency energy This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a However, there is no guarantee that interference will not occur in a
particular installationparticular installation
particular
installation
.
particular
installation
.
If this equipment does cause harmful interference to radio or television If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the the user is encouraged to try to correct the
interference by one or more of the following measures:interference by one or more of the following measures:
--. Reorient or relocate the receiving antenna.. Reorient or relocate the receiving antenna.
--. Increase the separation between the equipment and receiver.. Increase the separation between the equipment and receiver.
--. Connect the equipment into an outlet on a circuit different from that to . Connect the equipment into an outlet on a circuit different from that to
which the receiver is connectedwhich the receiver is connected
which
the
receiver
is
connectedwhich
the
receiver
is
connected
--. Consult the dealer or an experienced radio/TV technician for help.. Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules.This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:Operation is subject to the following two conditions:
1) this device may not cause harmful interference, and1) this device may not cause harmful interference, and
2) this device must accept any interference received, including interference 2) this device must accept any interference received, including interference
that may cause undesired operation of the device.that may cause undesired operation of the device.
Id lId l
I
n
d
oor use on
lyI
n
d
oor use on
ly
FCC Caution: Any changes or modifications not expressly approved by the FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate party responsible for compliance could void the user's authority to operate
this equipment.this equipment.
The model and serial number of the TV is
located on the back and/or one side of the TV.
Record it below should you ever need service.
MODEL
SERIAL
This product qualifies for ENERGY STAR in the
“factory default (Home Use)” setting.
Changing the factory default settings or enabling other
features may increase power consumption that could
exceed the limits necessary to quality for ENERGY STAR.
1-800-243-0000
1-888-865-3026
1-888-542-2623
USA, Consumer User
USA, Commercial User
CANADA
Register your product Online!
LG Customer Information Center
For inquires or comments, visit www.lg.com or call;
(For LS5700/LM6700/LM7600 series,
42/47/55LS5750, 42/47/55LM6200 USA, Canada, Mexico)
www.lg.com
