User Manual 1 of 2
AAss aann EENNEERRGGYY SSTTAARR
PPaarrttnneerr LLGGEE UU..SS..AA..,,
IInncc.. hhaass ddeetteerrmmiinneedd
tthhaatt tthhiiss pprroodduucctt
mmeeeettss tthhee EENNEERRGGYY
SSTTAARR gguuiiddeelliinneess ffoorr
eenneerrggyy eeffffiicciieennccyy..
Please read this manual carefully before operating your set.
Retain it for future reference.
Record model number and serial number of the set.
See the label attached on the back cover and quote this
information to your dealer when you require service.
LCD TV
OWNER’S MANUAL
LCD TV MODELS
3322LLBB99DD
4477LLCC77DDFF
EENNEERRGGYY SSTTAARR iiss aa sseett ooff ppoowweerr--ssaavviinngg
gguuiiddeelliinneess iissssuueedd bbyy tthhee UU..SS..
EEnnvviirroonnmmeennttaall PPrrootteeccttiioonn AAggeennccyy((EEPPAA))..
wwwwww..llgguussaa..ccoomm // wwwwww..llgg..ccaa
PLASMA TV MODELS
6600PPYY33DD
PLASMA TV
is a trademark of SRS Labs, Inc.
TruSurround XT technology is incorporated under
license from SRS Labs, Inc.
LG TV with this logo displays Full HD(high-defini-
tion) 1080p native resolution by receiving and pro-
cessing a Full HD 1080p signal.
LG TV with this logo can play MP3 music from a
MP3 player, such as iPOD, and JPEG images from a
digital camera through the USB unit.
With HDMI CEC support of LG’s audio/video device
connected to the HDMI (high-definition multimedia
interface), LG TV with this logo works easily with one
remote control.
It has three HDMI ports that connect audio and
video devices with one cable and produces the high-
est quality digital images and sound.
R
TruSurround XT
Manufactured under license from Dolby Laboratories.
“
Dolby
“and the double-D symbol are trademarks of
Dolby Laboratories.
High-definition television. High-resolution digital
television broadcast and playback system composed
of roughly a million or more pixels, 16:9 aspect-ratio
screens, and AC3 digital audio. A subset of digital
television, HDTV formats include 1080i and 720p
resolutions.
HDMITM, the HDMI logo and High-Definition
Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing."
LG's own special digital image generator, consisting
of a full digital image processor, six different main
picture quality factors.
R
TruSurround XT
1
WARNING / CAUTION
WARNING / CAUTION
To prevent fire or shock hazards, do not expose
this product to rain or moisture.
FCC NOTICE
Class B digital device
This equipment has been tested and found to com-
ply with the limits for a Class B digital device, pur-
suant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio fre-
quency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not
occur in a particular installation. If this equipment
does cause harmful interference to radio or televi-
sion reception, which can be determined by turning
the equipment off and on, the user is encouraged to
try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment
and receiver.
- Connect the equipment to an outlet on a circuit
different from that to which the receiver is con-
nected.
- Consult the dealer or an experienced radio/TV
technician for help.
Any changes or modifications not expressly
approved by the party responsible for compliance
could void the user’s authority to operate the
equipment.
CAUTION
Do not attempt to modify this product in any way
without written authorization from LG Electronics.
Unauthorized modification could void the user’s
authority to operate this product
The lightning flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of elec-
tric shock to persons.
The exclamation point within an equi-
lateral triangle is intended to alert the
user to the presence of important
operating and maintenance (servicing) instruc-
tions in the literature accompanying the
appliance.
TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER TO
QUALIFIED SERVICE PERSONNEL.
WARNING/CAUTION
TO REDUCE THE RISK OF FIRE AND ELEC-
TRIC SHOCK, DO NOT EXPOSE THIS PRO-
DUCT TO RAIN OR MOISTURE.
NOTE TO CABLE/TV INSTALLER
This reminder is provided to call the CATV sys-
tem installer’s attention to Article 820-40 of the
National Electric Code (U.S.A.). The code pro-
vides guidelines for proper grounding and, in
particular, specifies that the cable ground shall
be connected to the grounding system of the
building, as close to the point of the cable entry
as practical.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water
Clean only with dry cloth.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
Do not install near any heat sources such as
radiators, heat registers, stoves, or other appa-
ratus (including amplifiers)that produce heat.
Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong, The wide blade
or the third prong are provided for your safe-
ty. If the provided plug does not fit into your
outlet, consult an electrician for replacement
of the obsolete outlet.
Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
Only use attachments/accessories specified
by the manufacturer.
2
IMPORTANT SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
Important safety instructions shall be provided with each apparatus. This information shall be given in a se-
parate booklet or sheet, or be located before any operating instructions in an instruction for installation for
use and supplied with the apparatus.
This information shall be given in a language acceptable to the country where the apparatus is intended to
be used.
The important safety instructions shall be entitled “Important Safety Instructions”. The following safety
instructions shall be included where applicable, and, when used, shall be verbatim as follows. Additional safe-
ty information may be included by adding statements after the end of the following safety instruction list. At
the manufacturer’s option, a picture or drawing that illustrates the intent of a specific safety instruction may
be placed immediately adjacent to that safety instruction :
Owner Manual
Owner ManualOwner Manual
Owner Manual
Owner Manual
Owner Manual
Owner Manual
Owner Manual
Owner Manual
Owner Manual
Owner Manual
Owner Manual
3
Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.
Unplug this apparatus during lightning storms
or when unused for long periods of time.
Refer all servicing to qualified service person-
nel. Servicing is required when the apparatus
has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the
apparatus, the apparatus has exposed to rain
or moisture, does not operate normally, or has
been dropped.
CAUTION concerning the Power Cord :
Most appliances recommend they be placed
upon a dedicated circuit; that is, a single out-
let circuit which powers only that appliance
and has no additional outlets or branch cir-
cuits. Check the specification page of this
owner's manual to be certain.
Do not overload wall outlets. Overloaded wall
outlets, loose or damaged wall outlets, exten-
sion cords, frayed power cords, or damaged
or cracked wire insulation are dangerous. Any
of these conditions could result in electric
shock or fire. Periodically examine the cord of
your appliance, and if its appearance indicates
damage or deterioration, unplug it, disconti-
nue use of the appliance, and have the cord
replaced with an exact replacement part by an
authorized servicer. Protect the power cord
from physical or mechanical abuse, such as
being twisted, kinked, pinched, closed in a
door, or walked upon. Pay particular attention
to plugs, wall outlets, and the point where the
cord exits the appliance.
Outdoor Use Marking :
WARNING - To Reduce The Risk Of Fire Or
Electric Shock, Do Not Expose This Appliance
To Rain Or Moisture
Wet Location Marking : Apparatus shall not be
exposed to dripping or splashing and no
objects filled with liquids, such as vases, shall
be placed on or over apparatus.
GROUNDING
Ensure that you connect the earth ground
wire to prevent possible electric shock. If
grounding methods are not possible, have a
qualified electrician install a separate circuit
breaker.
Do not try to ground the unit by connecting
it to telephone wires, lightening rods, or gas
pipes.
DISCONNECTING DEVICE FROM MAINS
Main plug is the disconnecting device. The
plug must remain readily operable.
Owner Manual
Owner Manual
Owner Manual
Owner Manual
Owner Manual
Owner Manual
Owner Manual
Owner Manual
Owner Manual
Power Supply
Short-circuit Breaker
4
CONTENTS
WARNING / CAUTION
. . . . . . . . . . . . . . . . . . . . . . . . . . .
1
SAFETY INSTRUCTIONS
. . . . . . . . . . . . . . . . . . . . . . . . . . 2
FEATURES OF THIS TV . . . . . . . . . . . . . . . . 6
PREPARATION
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . 8
Back Panel Information . . . . . . . . . . . . . . . . . . . 10
Attaching the TV to a Wall . . . . . . . . . . . . . . . . . 12
Stand Installation . . . . . . . . . . . . . . . . . . . . . . . . 13
Back Cover for Wire Arrangement . . . . . . . . . . . 14
Desktop Pedestal Installation . . . . . . . . . . . . . . . 17
Vesa Wall Mounting . . . . . . . . . . . . . . . . . . . . . . . 17
Swivel Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Antenna or Cable Connection . . . . . . . . . . . . . . 19
EXTERNAL EQUIPMENT SETUP
HD Receiver Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
DVD Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
VCR Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Other A/V Source Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
PC Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
USB In Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Audio Out Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
WATCHING TV / CHANNEL CONTROL
Remote Control Functions . . . . . . . . . . . . . . . . . .36
Turning on TV . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Channel Selection . . . . . . . . . . . . . . . . . . . . . . . 39
Volume Adjustment . . . . . . . . . . . . . . . . . . . . . . 40
On-Screen Menus Selection . . . . . . . . . . . . . . . . 41
Channel Setup
- Auto Scan ( Auto Tuning) . . . . . . . . . . . . . . 42
- Add / Delete Channel ( Manual Tuning) . . 43
- Channel Editing . . . . . . . . . . . . . . . . . . . . . . .44
Input List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
SimpLink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Input Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Entry Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Photo List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Music List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
PICTURE CONTROL
Picture Size (Aspect Ratio) Control . . . . . . . . . .56
Preset Picture Settings
- Picture Mode - Preset . . . . . . . . . . . . . . . . 57
- Color Tone - Preset . . . . . . . . . . . . . . . . . . .58
Manual Picture Adjustment
- Picture Mode - User Mode . . . . . . . . . . . . 59
- Color Tone - User Mode. . . . . . . . . . . . . . .60
XD - Picture Improvement Technology . . . . . . . . . . . 61
Advanced - Cinema 3:2 Pulldown Mode . . . . . . 62
Advanced - Black( Darkness) Level . . . . . . . . . . 63
Advanced - TruM . . . . . . . . . . . . . . . . . . . . . . . . 64
Picture Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Image Sticking Minimization( ISM) Method . . . . . . . 66
Low-Power Picture Mode . . . . . . . . . . . . . . . . . . 67
SOUND & LANGUAGE CONTROL
Auto Volume Leveler ( Auto Volume) . . . . . . . . . 68
Preset Sound Settings( Sound Mode) . . . . . . . . 69
Sound Setting Adjustment - User Mode . . . . . . . . 70
Balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Stereo / SAP Broadcast Setup . . . . . . . . . . . . . . 73
TV Speakers On/ Off Setup . . . . . . . . . . . . . . . . 74
Audio Language . . . . . . . . . . . . . . . . . . . . . . . . . 75
On-Screen Menus Language Selection . . . . . . . 76
Caption Mode
- Analog Broadcasting System Captions . . . . 77
- Digital Broadcasting System Captions . . .79
- Caption Option . . . . . . . . . . . . . . . . . . . . .80
MEDIAMEDIAMEDIA
HOST HOST HOST
MEDIA
HOST
5
TIME SETTING
Clock Setting
- Auto Clock Setup . . . . . . . . . . . . . . . . . . . 81
- Manual Clock Setup . . . . . . . . . . . . . . . . . .82
Auto On/ Off Time Setting . . . . . . . . . . . . . . . . .83
Sleep Time Setting . . . . . . . . . . . . . . . . . . . . . . . .84
Auto Shut-off Setting . . . . . . . . . . . . . . . . . . . . . 85
PARENTAL CONTROL / RATINGS
Set Password & Lock System . . . . . . . . . . . . . . . 86
Channel Blocking . . . . . . . . . . . . . . . . . . . . . . . . 88
Movie & TV Rating . . . . . . . . . . . . . . . . . . . . . . . 89
External Input Blocking . . . . . . . . . . . . . . . . . . . .92
Key Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
APPENDIX
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . .93
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . .95
Product Specifications . . . . . . . . . . . . . . . . . . . . 96
Programming the Remote Control . . . . . . . . . . 97
IR Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
External Control through RS-232C . . . . . . . . . 103
6
FEATURES OF THIS TV
What is a Plasma TV ?
Using plasma is the best way to achieve flat panel
displays with excellent image quality and large screen
sizes that are easily viewable. The Plasma TV can be
thought of as a descendant of the neon lamp and or
a series of fluorescent lamps.
How does it work?
Plasma TV is an array of cells, known as pixels, which
are comprised of three sub-pixels, corresponding to
the colors red, green, and blue. Gas in a plasma state
is used to react with phosphors in each sub-pixel to
produce colored light (red, green, or blue). These
phosphors are the same types used in Cathode Ray
Tube (CRT) devices such as televisions and common
computer monitors.
Plasma TV offers a rich, dynamic display because
each sub-pixel is individually controlled by advanced
electronics to produce over 16 million different col-
ors. This means that you get perfect images that are
easily viewable in a display that is fewer than five
inches thick.
160° - Wide angle range of vision
Your flat panel plasma screen offers an exceptionally
broad viewing angle of over 160 degrees. This means
that the display is clear and visible to viewers any-
where in the room.
Wide Screen
The wide screen offers a theater-like experience in
your own home.
Multimedia
Connect your plasma display to a PC and use it for
conferencing, games, and Internet browsing. The
Picture-in-Picture feature allows you to view your PC
and video images simultaneously.
Versatile
The light weight and thin size makes it easy to install
your plasma display in a variety of locations where
conventional TVs do not fit.
The Plasma TV Manufacturing Process: a few
minute colored dots may be present on the
Plasma TV screen
The Plasma TV is composed of 0.9 to 2.2 million
cells. A few cell defects will normally occur in the
Plasma TV manufacturing process. Several tiny,
minute colored dots visible on the screen should be
acceptable. This also occurs in other Plasma TV
manufacturers' products. The tiny dots appearing
does not mean that this Plasma TV is defective. Thus
a few cell defects are not sufficient cause for the
Plasma TV to be exchanged or returned. Our pro-
duction technology minimizes these cell defects dur-
ing the manufacture and operation of this product.
Cooling Fan Noise (This feature is not available for all models.)
In the same way that a fan is used in a PC computer
to keep the CPU (Central Processing Unit) cool, the
Plasma TV is equipped with cooling fans to cool the
Monitor and improve its reliability. Therefore, a cer-
tain level of noise could occur while the fans are
operating and cooling the Plasma TV.
The fan noise doesn't have any negative effect on
the Plasma TV's efficiency or reliability. The noise
from these fans is normal during the operation of
this product. We hope you understand that a certain
level of noise from the cooling fans is acceptable and
is not sufficient cause for the Plasma TV to be
exchanged or returned.
FOR LCD TV
If the TV feels cold to the touch, there may be a
small “flicker” when it is turned on. This is normal,
there is nothing wrong with TV.
Some minute dot defects may be visible on the
screen, appearing as tiny red, green, or blue spots.
However, they have no adverse effect on the moni-
tor's performance.
Avoid touching the LCD screen or holding your fin-
ger(s) against it for long periods of time. Doing so
may produce some temporary distortion effects on
the screen.
OOnn DDiissppoossaall
a. The fluorescent lamp used in this product con-
tains a small amount of mercury.
b. Do not dispose of this product with general
household waste.
c. Disposal of this product must be carried out in
accordance to the regulations of your local
authority.
PREPARATION
7
ACCESSORIES
Owner's Manual
1.5V 1.5V
Owner’s Manual Batteries
75ΩRound Cable
Remote Control
Cable Management
2- TV Bracket Bolts 2- TV Brackets,
2- Wall Brackets
Twist Holder
Arrange the wires with the twist holder.
Ensure that the following accessories are included with your plasma display. If an accessory is missing, please
contact the dealer where you purchased the product.
User must use shielded signal interface cables (D-sub 15 pin cable) with ferrite cores to maintain standard
compliance for the product.
APM
CC
AUTO DEMO
M/C EJECT
TV INPUT
TV INPUT
STB
STB
MENU
BRIGHT +
BRIGHT -
TIMER
RATIO
SIMPLINK
BACK
BACK
4-bolts for stand assembly
Refer to p. 13
3322LLBB99DD oonnllyy
■Slightly wipe stained spot on the exterior only with the polishing
cloth for the product exterior if there is stain or fingerprint on
surface of the exterior.
■Do not wipe roughly when removing stain. Please be cautions of
that excessive power may cause scratch or discoloration.
Polishing Cloth
OOppttiioonn EExxttrraass
D-sub 15 pin Cable
Power Cord
CD Manual
LCD TV PLASMA TV
Owner's Manual
http://www.lgusa.com
www.lg.ca
Copyright© 2007 LGE,
All Rights Reserved.
PREPARATION
FFoorr LLCCDD TTVV mmooddeellss
PREPARATION
8
PREPARATION
FRONT PANEL CONTROLS
■
Here shown may be somewhat different from your TV.
■
If your TV stand has a protection film, remove it attached to the stand. Then wipe the stand with polishing
cloth.
Remote Control Sensor
60PY3D
ENTER
ENTER
.
.
ENTER
VOLUME
(FF,GG)
Buttons
CHANNEL
(EE,DD)
Buttons
ENTER
Button
MENU
Button
INPUT
Button
POWER
Button
Power Standby Indicator
• illuminates red in standby
mode.
• illuminates green when
the set is switched on.
Program Display Touch Pad
PREPARATION
9
CH
VOL
32LB9D
47LC7DF
Remote Control Sensor
CH
VOL
ENTER
MENU
INPUT
/I
CHANNEL
(EE,DD) Buttons
VOLUME
(FF,GG) Buttons
ENTER Button
MENU Button
INPUT Button
POWER Button
Intelligent Eye
Adjusts picture
according to the
surrounding con-
ditions.
Power/Standby Indicator
• illuminates red in standby mode.
• illuminates green when the set is switched on.
CH VOL
ENTER
MENU INPUT
/I
CH
VOL
CHANNEL
(EE,DD) Buttons
VOLUME
(FF,GG) Buttons
ENTER Button
MENU Button
INPUT Button
POWER Button
Remote Control
Sensor
Intelligent Eye
Adjusts picture
according to the
surrounding con-
ditions.
Power/Standby Indicator
• illuminates red in standby mode.
• illuminates green when the set is switched on.
PREPARATION
10
PREPARATION
BACK PANEL INFORMATION
USB Input
S-VIDEO Input
Connect S-Video out from an S-
VIDEO device.
AUDIO/VIDEO Input
Connect audio/video output from
an external device to these jacks.
AV IN 2
L/
MONO
R
AUDIO
A
VIDEO
S-VIDEO
USB IN
47LC7DF
■
Here shown may be somewhat different from your TV.
AV IN 2
L/MONO
R
AUDIO
VIDEO
S-VIDEO
USB IN
AV IN 2
V IN 2
L/
L/
MONO
MONO
R
AUDIO
AUDIO
VIDEO
VIDEO
S-VIDEO
USB IN
USB IN
USB Input port
S-VIDEO Input
Connect S-Video out from an
S-VIDEO device.
AUDIO/VIDEO Input
Connect audio/video output from
an external device to these jacks.
60PY3D
PREPARATION
11
AV IN 4
L/MONO
R
AUDIO
VIDEO
32LB9D
■
Here shown may be somewhat different from your TV.
HDMI/DVI IN
Connect a HDMI signal to 1, 2 or 3.
Or DVI (VIDEO)signal to the 1, 2 or 3 port
with a DVI to HDMI cable.
COMPONENT IN
Connect a component video/audio device to
these jacks.
RGB(PC)
AUDIO (RGB/DVI)
Connect the monitor output from a PC to the
appropriate input port.
RS-232C IN (CONTROL & SERVICE) PORT
Connect to the RS-232C port on a PC.
REMOTE CONTROL PORT
Connect your wired remote control.
AV (Audio/Video) IN 1
Connect audio/video output from an external
device to these jacks.
S-VIDEO
Connect S-Video out from an S-VIDEO device.
AUDIO OUT
Connect analog audio to various types of
equipment.
DIGITAL AUDIO OUT
Connect digital audio to various types of
equipment.
Note: In standby mode, these ports do not work.
ANTENNA/CABLE IN
Connect over-the air signals to this jack.
Connect cable signals to this jack.
Power Cord Socket
For operation with AC power.
Caution :
Never attempt to operate the TV on DC power.
AV IN 2
L/MONO
R
AUDIO
VIDEO
S-VIDEO
USB IN
RGB
/DVI
ANTENNA/
CABLE IN
AV IN 4
V IN 4
L/
L/
MONO
MONO
R
AUDIO
AUDIO
VIDEO
VIDEO
USB Input port
AUDIO/VIDEO Input
Connect audio/video output from
an external device to these jacks.
PREPARATION
12
PREPARATION
ATTACHING THE TV TO A WALL
47LC7DF
We recommend that you set up the TV close to a wall so it cannot fall over if pushed backwards.
Additionally, we recommend that the TV be attached to a wall so it cannot be pulled in a forward direction,
potentially causing injury or damaging the product.
Caution: Please make sure that children don’t climb on or hang from the TV.
■Insert the eye-bolts (or TV brackets and bolts) to tighten the product to the wall as shown in the picture.
*Insert the eye-bolts and tighten them securely in the upper holes.
Secure the wall brackets with the bolts (not provided as parts of the product, must purchase separately ) to
the wall. Match the height of the bracket that is mounted on the wall to the holes in the product.
Ensure the eye-bolts or brackets are tightened securely.
■Use a sturdy rope (not provided as parts of the
product, must purchase separately) to tie the
product. It is safer to tie the rope so it becomes
horizontal between the wall and the product.
■
Here shown may be somewhat different from your TV.
60PY3D
32LB9D
PREPARATION
13
STAND INSTALLATION (Only 32LB9D model)
1
2
3
Carefully place the product screen side down on
a cushioned surface that will protect product and
screen from damage.
Assemble the product stand with the product as
shown.
Install the 4 bolts securely, in the back of the
product in the holes provided.
PREPARATION
14
PREPARATION
Hold the CABLE MANAGEMENT with both hands and pull it as shown.
Connect the cables as necessary.
To connect an additional equipment, see the External equipment Connections section.
1
2
Install the CABLE MANAGEMENT as shown.
3
CABLE MANAGEMENT
60PY3D
45
°
BACK COVER FOR WIRE ARRANGEMENT
■
Here shown may be somewhat different from your TV.
PREPARATION
15
■
Here shown may be somewhat different from your TV.
47LC7DF
Connect the cables as necessary.
To connect an additional equipment, see the
EExxtteerrnnaall eeqquuiippmmeennttCCoonnnneeccttiioonnss section.
Install the CCAABBLLEE MMAANNAAGGEEMMEENNTTas shown.
Bundle the cables using the supplied twist
holder.
Hold the CCAABBLLEE MMAANNAAGGEEMMEENNTTwith both
hands and pull it upward.
NOTE
GG Do not hold the CABLE MANAGEMENT when moving the product.
- If the product is dropped, you may be injured or the product may be broken.
How to remove the cable management
CABLE MANAGEMENT
TWIST HOLDER
1
2
3
PREPARATION
16
PREPARATION
■
Here shown may be somewhat different from your TV.
32LB9D
Connect the cables as necessary.
To connect an additional equipment, see the
EExxtteerrnnaall eeqquuiippmmeennttCCoonnnneeccttiioonnss section.
Install the CCAABBLLEE MMAANNAAGGEEMMEENNTTas shown.
Bundle the cables using the supplied twist
holder.
Hold the CCAABBLLEE MMAANNAAGGEEMMEENNTTwith both
hands and pull it upward.
NOTE
GG Do not hold the CABLE MANAGEMENT when moving the product.
- If the product is dropped, you may be injured or the product may be broken.
How to remove the cable management
CABLE MANAGEMENT
TWIST HOLDER
1
2
3
PREPARATION
17
DESKTOP PEDESTAL INSTALLATION
For proper ventilation, allow a clearance of 4 in. on each side and the top, 2.36 in. on the bottom, and 4 in.
from the wall.
4 inches
4 inches
47LC7DF
4 inches
4 inches
4 inches
4 inches
60PY3D
4 inches
4 inches
4 inches
4 inches
32LB9D
4 inches
4 inches
VESA WALL MOUNTING
This product accepts a VESA-compliant mounting interface pad. (optional)
There 4 threaded holes are available for attaching the bracket.
GGScrew length needed depends on the wall mount used. For further information, refer to the VESA
Wall Mounting Instruction Guide.
NOTE
47LC7DF 32LB9D
AV IN 4
L/ MONO
R
AUDIO
VIDEO
100mm
400mm
200mm
600mm
60PY3D
AV IN 2
L/ MONO
R
AUDIO
VIDEO
S-VIDEO
USB IN
400mm
600mm
PREPARATION
18
PREPARATION
SWIVEL STAND (Only
60PY3D
model)
After installing the TV, you can adjust the the TV set manually to the left or right direction by 20 degrees to
suit your viewing position.
NOTE
GG Before adjusting the angle, you must remove the cable
management and loosen (to the left) the shaft bolt on
the middle of stand’s back. And when stand be level
with TV, you must close (to the right) the shaft bolt to
set the hole.
PREPARATION
19
1. Antenna (analog or digital)
Wall Antenna Socket or Outdoor Antenna without a
Cable Box Connections. For optimum picture quality,
adjust antenna direction if needed.
2. Cable
ANTENNA/
CABLE IN
ANTENNA/
CABLE IN
Wall
Antenna
Socket
Outdoor
Antenna
(VHF, UHF)
Cable TV
Wall Jack
Multi-family Dwellings/Apartments
(Connect to wall antenna socket)
RF Coaxial Wire (75 ohm)
RF Coaxial Wire (75 ohm)
Single-family Dwellings /Houses
(Connect to wall jack for outdoor antenna)
Be careful not to bend the bronze wire
when connecting the antenna.
Copper Wire
The TV will let you know when the analog, cable, and digital channel scans are complete.
NOTE
ANTENNA/
CABLE IN
■To improve the picture quality in a poor signal area, please purchase a signal amplifier and install properly.
■If the antenna needs to be split for two TV’s, install a 2-Way Signal Splitter.
■If the antenna is not installed properly, contact your dealer for assistance.
Antenna
UHF
Signal
Amplifier
VHF
3. Using both cable and antenna
Cable TV
Wall Jack
Antenna
RF Coaxial Wire (75 ohm)
RF Coaxial Wire (75 ohm)
Diplexer
(Signal
Combinner)
ANTENNA/
CABLE IN
ANTENNA OR CABLE CONNECTION
AV IN 2
L/MONO
R
AUDIO
VIDEO
S-VIDEO
USB IN
AV IN 4
L/ MONO
R
AUDIO
VIDEO
HD RECEIVER SETUP
This TV can receive Digital Over-the-air/Cable signals without an external digital set-top box. However, if you
do receive digital signals from a digital set-top box or other digital external device, refer to the figure as
shown below.
This TV supports HDCP (High-bandwidth Digital Contents Protection)protocol for Digital Contents.
(DVI)
Y L RPBPR
(DVI)
RGB
When connecting Component cable
1. How to connect
Connect the video outputs (Y, PB, PR)of the digital set
top box to the CCOOMMPPOONNEENNTT IINN VVIIDDEEOO 11jacks on
the set. Match the jack colors
(Y = green, PB= blue, and PR= red).
Connect the audio output of the digital set-top box to
the CCOOMMPPOONNEENNTT IINN AAUUDDIIOO 11jacks on the set.
2. How to use
■Turn on the digital set-top box.
(Refer to the owner’s manual for the digital set-top box.)
■Select CCOOMMPPOONNEENNTT 11input source with using the IINNPPUUTT
button on the remote control.
■If connected to CCOOMMPPOONNEENNTT IINN 22input, select CCOOMMPPOO--
NNEENNTT 22input source.
Signal Component 1/2
Yes
Yes
Yes
Yes
Yes
HDMI/DVI1, 2 or 3
No
Yes
Yes
Yes
Yes
2
1
EXTERNAL EQUIPMENT SETUP
20
12
480i
480p
720p
108 0 i
108 0 p
EXTERNAL EQUIPMENT SETUP
When connecting D-sub 15pin cable
(DVI)
(DVI)
RGB
L R
RGB OUTPUT
(DVI)
(DVI)VI)
HDMI-DTV OUTPUT
RGB
Connect the RGB output of the digital set-top box to
the RRGGBB ((PPCC))jack on the set.
Connect the audio outputs of the set-top box to the
AAUUDDIIOO ((RRGGBB//DDVVII))jack on the set.
1. How to connect
2. How to use
■Turn on the PC and the set.
■Select RRGGBB--PPCCinput source with using the IINNPPUUTTbutton
on the remote control.
When connecting HDMI cable
Connect the digital set-top box to HHDDMMII//DDVVII IINN11,
22 or 33 jack on the set.
No separated audio connection is necessary.
1. How to connect
2. How to use
■Turn on the digital set-top box.
(Refer to the owner’s manual for the digital set-top box.)
■Select HHDDMMII11,HHDDMMII22 or HHDDMMII33input source with using
the IINNPPUUTTbutton on the remote control.
■If the digital set-top box player does not support Auto HDMI,
you need to set the output resolution appropriately.
2
1
2
1
EXTERNAL EQUIPMENT SETUP
21
12
1
EXTERNAL EQUIPMENT SETUP
22
EXTERNAL EQUIPMENT SETUP
When connecting HDMI to DVI cable
L R
DVI-DTV OUTPUT
RGB
RGB
3
Connect the DVI output of the digital set-top box to the HHDDMMII//DDVVII IINN11, 22 or 33 jack on the set.
Connect the audio output of the digital set-top box to the AAUUDDIIOO((RRGGBB//DDVVII))jack on the set.
1. How to connect
■Turn on the digital set-top box. (Refer to the owner’s manual for the digital set-top box.)
■Select HHDDMMII11,HHDDMMII22 or HHDDMMII33input source with using the IINNPPUUTTbutton on the remote control.
2. How to use
2
1
12
EXTERNAL EQUIPMENT SETUP
23
DVD SETUP
Component Input ports
To get better picture quality, connect a DVD player to the component input ports as shown below.
Component ports on the TV
YP
BPR
Video output ports
on DVD player
Y
Y
Y
Y
PB
Pb
B-Y
Cb
PR
Pr
R-Y
Cr
Y L RPBPR
When connecting Component cable
Connect the video outputs (Y, PB, PR)of the DVD to
the CCOOMMPPOONNEENNTT IINN VVIIDDEEOO11jacks on the set.
Match the jack colors
(Y = green, PB= blue, and PR= red).
Connect the audio outputs of the DVD to the
CCOOMMPPOONNEENNTT IINN AAUUDDIIOO11jacks on the set.
1. How to connect
2. How to use
■Turn on the DVD player, insert a DVD.
■Select CCOOMMPPOONNEENNTT 11input source with using the
IINNPPUUTTbutton on the remote control.
■If connected to CCOOMMPPOONNEENNTT IINN 22input, select CCOOMM--
PPOONNEENNTT 22input source.
■Refer to the DVD player's manual for operating instruc-
tions.
2
1
1 2
When connecting with an S-Video cable
HDMI-DVD OUTPUT
L R
S-VIDEO
AUDIO
Connect the S-VIDEO output of the DVD to the
SS--VVIIDDEEOOinput on the set.
Connect the audio outputs of the DVD to the AAUUDDIIOO
input jacks on the set.
1. How to connect
2. How to use
■Turn on the DVD player, insert a DVD.
■Select AAVV11input source with using the IINNPPUUTTbutton on
the remote control.
■If connected to AAVV IINN 22, select AAVV22input source.
■Refer to the DVD player's manual for operating instructions.
When connecting HDMI cable
Connect the HDMI output of the DVD to the
HHDDMMII//DDVVII IINN11, 22 or 33jack on the set.
No separated audio connection is necessary.
1. How to connect
2. How to use
■Select HHDDMMII11,HHDDMMII22 or HHDDMMII33input source with using
the IINNPPUUTTbutton on the remote control.
■Refer to the DVD player's manual for operating instruc-
tions.
■If the DVD does not support Auto HDMI, you need to set
the output resolution appropriately.
2
1
2
1
24
EXTERNAL EQUIPMENT SETUP
EXTERNAL EQUIPMENT SETUP
EXTERNAL EQUIPMENT SETUP
1 2
1
VCR SETUP
When connecting with an antenna
■To avoid picture noise (interference), leave an adequate distance between the VCR and TV
■Use the ISM feature in the Option menu to avoid having a fixed image remain on the screen for a long pe-
riod of time. If the 4:3 picture format is used; the fixed images on the sides of the screen may remain visible
on the screen.
L R
S-VIDEO VIDEO
OUTPUT
SWITCH
ANT IN
ANT OUT
ANTENNA/ANTENNA/
CABLE INCABLE IN
Wall Jack
Antenna
Connect the RF antenna out socket of the VCR to the AAnntteennnnaasocket on the set.
Connect the antenna cable to the RF antenna in socket of the VCR.
1. How to connect
■Set VCR output switch to 3 or 4 and then tune TV to the same channel number.
■Insert a video tape into the VCR and press PLAY on the VCR. (Refer to the VCR owner’s manual.)
2. How to use
2
1
25
EXTERNAL EQUIPMENT SETUP
1
2
EXTERNAL EQUIPMENT SETUP
26
EXTERNAL EQUIPMENT SETUP
When connecting with a RCA cable
Do not connect to both Video
and S-Video at the same time.
CAUTION
L R S-VIDEOVIDEO
OUTPUT
SWITCH
ANT IN
ANT OUT
ANTENNA/
CABLE IN
L R
S-VIDEO VIDEO
OUTPUT
SWITCH
ANT IN
ANT OUT
ANTENNA/
CABLE IN
Connect the AAUUDDIIOO/VVIIDDEEOOjacks between TV and
VCR. Match the jack colors(Video = yellow, Audio Left =
white,and Audio Right = red)
1. How to connect
2. How to use
■Insert a video tape into the VCR and press PLAY on the
VCR. (Refer to the VCR owner’s manual.)
■Select AAVV11input source with using the IINNPPUUTTbutton on
the remote control.
■If connected to AAVV IINN 22, select AAVV22input source.
If you have a mono VCR, con-
nect the audio cable from the
VCR to the AAUUDDIIOO
LL//MMOONNOOjack of the set.
NOTE
When connecting with an S-Video cable
Connect the S-VIDEO output of the VCR to the SS--
VVIIDDEEOOinput on the set. The picture quality is
improved; compared to normal composite (RCA cable)
input.
Connect the audio outputs of the VCR to the AAUUDDIIOO
input jacks on the set.
1. How to connect
2. How to use
■Insert a video tape into the VCR and press PLAY on the VCR.
(Refer to the VCR owner’s manual.)
■Select AAVV11input source with using the IINNPPUUTTbutton on the
remote control.
■If connected to AAVV IINN 22, select AAVV22input source.
1
2
1
1
12
EXTERNAL EQUIPMENT SETUP
27
OTHER A/V SOURCE SETUP
Camcorder
Video Game Set
Connect the AAUUDDIIOO/VVIIDDEEOOjacks between TV and
external equipment. Match the jack colors
.
(Video = yellow, Audio Left = white, and Audio Right = red)
1. How to connect
2. How to use
■Select AAVV22input source with using the IINNPPUUTTbutton on
the remote control.
■If connected to AAVV IINN 11input, select AAVV11input source.
■Operate the corresponding external equipment.
1
AV IN 2
L/
MONO
R
AUDIO
A
VIDEO
S-VIDEO
USB IN
L R
VIDEO
L R
VIDEO
AV IN 4
AV IN 4
L/
MONO
R
AUDIO
A
VIDEO
1
Camcorder
Video Game Set
32LB9D
60PY3D, 47LC7DF
1
EXTERNAL EQUIPMENT SETUP
28
EXTERNAL EQUIPMENT SETUP
PC SETUP
This TV provides Plug and Play capability, meaning that the PC adjusts automatically to the TV's settings.
GGCheck the image on your TV. There may be noise associated
with the resolution, vertical pattern, contrast or brightness in
PC mode. If noise is present, change the PC output to another
resolution, change the refresh rate to another rate or adjust
the brightness and contrast on the VIDEO menu until the
picture is clear. If the refresh rate of the PC graphic card can
not be changed, change the PC graphic card or consult the
manufacturer of the PC graphic card.
NOTE
RGBRGB
RGB OUTPUT AUDIO
RGB
When connecting D-sub 15 pin cable
Connect the RGB output of the PC to the RRGGBB
((PPCC)) jack on the set.
Connect the PC audio output to the AAUUDDIIOO
((RRGGBB//DDVVII))jack on the set.
1. How to connect
2. How to use
■Turn on the PC and the set.
■Select RRGGBB--PPCCinput source with using the IINNPPUUTTbutton
on the remote control.
2
1
1 2
