Contents

User Manual 1 2

17
Available resolution according to the resolution setting
Notes:
•Depending on your display, some of the resolution settings may result in
the picture disappearing or an abnormal picture appearing. In this case,
press HOME then RESOLUTION repeatedly until the picture re-appear.
•This player supports simultaneous output of all video out jacks. The
resolution of the HDMI output will not be the same as the resolution
output on the component video output.
HDMI OUT connection
•For the 480i resolution setting, real output resolution of HDMI OUT will
change to 480p.
•If you select a resolution manually and then connect the HDMI jack to
TV and your TV does not accept it, the resolution setting is set to [Auto].
•If you select a resolution that your TV does not accept, the warning
message will appear. After resolution change, if you cannot see the
screen, please wait 20 seconds and the resolution will automatically
revert back to the previous resolution.
•The 1080p video output frame rate may be automatically set to either
24Hz or 60Hz depending both on the capability and preference of the
connected TV and based on the native video frame rate of the content
on the BD-ROM disc.
COMPONENT VIDEO OUT connection
•For the 1080p resolution setting with unprotected media, real output
resolution of COMPONENT VIDEO OUT will change to 1080i.
•For the 720p, 1080i, 1080p resolution setting with protected media, real
output resolution of COMPONENT VIDEO OUT will change to 480i or
480p depending on the connectivity of HDMI cable.
•BD, DVD or Netflix video stream could prevent up-scaling on analog
output.
VIDEO OUT connection
The resolution of the MONITOR OUTPUT jack is always outputted at 480i
resolution.
• When the non-copy protected media is playing back
Video Output HDMI OUT COMPONENT VIDEO OUT
Resolution Setting
480i 480p 480i
480p 480p 480p
720p 720p 720p
1080i 1080i 1080i
1080p / 24Hz 1080p / 24Hz 480i 1080i
1080p / 60Hz 1080p / 60Hz 480i 1080i
• When the copy protected media is playing back
Video Output HDMI OUT COMPONENT VIDEO OUT
Resolution Setting
480i 480p 480i
480p 480p 480p
720p 720p 480i 480p
1080i 1080i 480i 480p
1080p / 24Hz 1080p / 24Hz 480i 480p
1080p / 60Hz 1080p / 60Hz 480i 480p
HDMI connected HDMI disconnected
HDMI connected HDMI disconnected
HB954PA-AD.954SA-AP.BUSALL_ENG 12/18/08 5:31 PM Page 17
18
Internet connection
This player can be connected to a local area network (LAN) via the LAN
port on the rear panel.
After making the physical connection the player needs to be set up for
network communication. This is done from the [Setup] menu — see
“[NETWORK] Menu” on page 26 for detailed instructions.
Connect the player’s LAN port to the corresponding port on your Modem or
Router using a LAN cable.
Use a commercially available straight LAN cable (Category 5/CAT5 or bet-
ter with RJ45 connector).
By connecting the unit to broadband Internet, you can use a disc that
offers BD-Live function.
Cautions:
•When plugging or unplugging the LAN cable, hold the plug portion of the
cable. When unplugging, do not pull on the LAN cable but unplug while
pressing down on the lock.
•Do not connect a modular phone cable to the LAN port.
•Since there are various connection configurations, please follow the
specifications of your telecommunication carrier or internet service
provider.
Notes:
•Depending on the internet service provider (ISP), the number of devices
that can receive internet service may be limited by the applicable terms
of service. For details, contact your ISP.
•Our company is not responsible for any malfunction of the player and/or
the internet connection feature due to communication errors/malfunc-
tions associated with your broadband internet connection, or other con-
nected equipment.
•Our company is not responsible for any trouble in your internet connec-
tion.
•The features of BD-ROM discs made available through the Internet
Connection feature are not created or provided by our company, and our
company is not responsible for their functionality or continued availabili-
ty. Some disc related material available by the Internet Connection may
not be compatible with this player. If you have questions about such
content, please contact the producer of the disc.
•Some internet contents may require a higher bandwidth connection.
•Even if the player is properly connected and configured, some internet
contents may not operate properly because of internet congestion, the
quality or bandwidth of your internet service, or problems at the provider
of the content.
•Some internet connection operations may not be possible due to certain
restrictions set by the Internet service provider (ISP) supplying your
broadband Internet connection.
•Any fees charged by an ISP including, without limitation, connection
charges are your responsibility.
•A10 Base-T or 100 Base-TX LAN port is required for connection to this
player. If your internet service does not allow for such a connection, you
will not be able to connect the player.
•You must use a Router to use xDSL service.
Broadband
Service
Router
BD player
HB954PA-AD.954SA-AP.BUSALL_ENG 12/18/08 5:31 PM Page 18
