Contents

User manual 2of 3

Adding a group
1. Touch > > > .
2. Enter the new group name and an icon to
identify the group, as shown below and
then touch .
The new group is added as shown below.
Note
The icon identifies all places located in this
group, as displayed on the map.
Deleting the group
1. Touch > .
2. Touch a group you want to delete and
then touch > .
3. Touch .
The selected group is deleted.
Changing the group name
1. Touch > .
2. Touch the group you want to edit and then
touch > .
3. Change the group name or the group icon.
4. Touch .
The selected group is changed.
Alerting
The unit can sound the alert when the dis-
tance you set is closer than destination.
1. Touch > .
2. Touch > Change the “Set Alert dis-
tances” using the / > .
Note
The distance of “2nd Alert” is set closer than
that of “1st Alert”.
Navigation menu
21
Setting the destination
You can show, edit or delete the place in the
“My Places” list.
1. Touch > .
2. Touch a group you want and then touch
.
3. Touch and then touch the desired
items.
:
You can search the selected place on the
map.
Touch on the screen. And then drive
in accordance with the screen and voice
prompts.
:
You can change the name, comment, or
the group of selected destination.
:
You can delete selected place.
If you touch , the selected place is
deleted.
Points Of Interest (POI)
The POI list is a collection of hundreds of
interesting or useful places organized by
easy-to-find categories. For example, you can
use the unit to guide you to a shopping cen-
ter, hotel, restaurant, or gas station.
Finding a place in the “POI” list
1. Touch on the map screen and then
touch .
2. Touch one of “POI” you want from the list.
Note
You can view additional “POI” list , if you
touch .
3. Select the “POI CATEGORY”,
“SUBCATEGORY” and “LOCATION” you
want to search and then touch .
4. Touch to find the destination.
Drive in accordance with the screen and
voice prompts.
Note
The “POI” list may not be shown on the “POI
CATEGORY” and “SUBCATEGORY” menu.
Navigation menu
22
Setting the destination
You can show and add the place in the “POI”
list. And you can sort the place in alphabetical
and distance order. You can store in “My
places” menu the places in the “POI” list.
1. Touch in the “LOCATION” list.
2. Touch the desired items.
:
You can search for the selected place on
the map.
Touch on the screen. And then drive
in accordance with the screen and voice
prompts.
:
You can store the place in the “My Place”
menu.
Set the group you want to store by
touching / and then touch .
The place is stored in the “My Places”
menu. (Page 20)
:
You can sort the place in alphabetical
order.
Finding a destination with near place
You can find a place you want by searching a
near place.
1. Touch in the “POI CATEGORY” or
“SUBCATEGORY” list.
2. Touch the desired items.
:
You can search the place near the current
location.
:
You can search the place near the
destination when you set the destination.
:
You can search the POI near the address
when you set the address.
Follow the steps 2-5 of “Address” on the
page 19.
:
You can search for the POI within the
radius you set.
Navigation menu
23
Route Manager
You can set the route you wish to use when
you navigate a destination.
Route Playback
You can record your route while you’re driving
and view the recorded route.
1. Touch > > > .
The recording starts.
2. Touch >> >
>to stop recording.
3. Select the data file to play the recording
and then touch .
The navigator plays the recorded route on
the main map screen.
4. Touch >> >
to
stop the playback .
Route Playback Options
Touch on the “Route Playback” menu
and then touch the desired items.
:
Deletes a selected recording.
:
Deletes all recordings.
:
Adjust the playback speed. The range is
from 100% to 300%.
Turn by Turn
1. Touch > > . And
then touch the list you want.
2. Touch the desired item.
:
You can view the entire route on the
screen.
:
You can only view the turn you select.
You can also view the previous or next
turn by touching / .
:
You can avoid the selected turn in the
turn-by-turn list. The new route is recalcu-
lated automatically.
Route Summary
You can view an overview of your complete
route on the map screen, the total driving
distance to your destination, the estimated
travel time, and the complete destination
address.
1. Touch > > .
Note
Touch on the screen to move to the
previous screen.
Navigation menu
24
Multistop planner
You can plan a route with up to 5 stops.
When you touch the “Go”button, the route is
calculated in each stage, from the departure
point to the first stop. When you reach the first
stop, the next route is calculated to the sec-
ond stop, and so on.
Setting stops along the route
1. From the “Select/Add Multistop Route”
screen, touch the “Add” button to add a
stop by Address, POI, My Favorites, or
Recent Locations.
2. Select one of these options, specify a
location, and touch the “OK” button.
(If you touch , follow the
steps 2-5 of “Address” on the page 19.)
3. The “Select/Add Multistop Route” screen
appears with the selected location.
:
Use the “Up” or “Down” buttons to change the
order of your itinerary.
:
Use the “Edit” button to show or delete a high-
lighted entry.
:
Use the “Distance” button to organize your
entries from closest to farthest distance from
your current location.
Cancel route
If you no longer need to travel to your destina-
tion or if you want to change your destination.
Touch > > .
Route options
You can use Route options to determine what
road categories to avoid or allow and to set
the default route type when navigation calcu-
lates your selected destination.
1. Touch > > . And then
touch the desired items.
Avoid roads
Toll, Motorway, and Ferry route sections
are avoided or allowed as determined by
whether they are selected, when navigator
calculates a route.
You cannot allow or avoid specific toll
roads or ferry routes.
Route condition
Fastest:
This option selects the route that takes the
least amount of time.
Fastest is the default value.
Shortest:
This option selects the route that is the
shortest distance. Remember, the shortest
route may not always be the quickest, as
you are able to travel faster on some roads
than on others.
2. Touch .
Note
Route generation excludes any detours, stops
or delays along the route.
Navigation menu
25
TMC (Traffic Information)
What is Traffic Message Channel (TMC)
The Traffic Message Channel (TMC) is a spe-
cific application of the FM Radio Data System
(RDS) used for broadcasting real-time traffic
and weather information. Data messages are
received silently, decoded, and delivered to a
TMC enabled navigation system that can offer
dynamic route guidance alerting the driver of
a problem on the planned route and calculat-
ing an alternative route to avoid the incident.
Connect your TMC antenna
The car charger plays the part of the TMC
antenna.
Connect the car charger on the unit.
Disclaimer
The developer is not responsible for any dam-
age caused by an accident due to unreliable
TMC radio transmissions by national, region-
al, or local broadcasters caused by TMC serv-
ice restrictions, or by natural and man-made
conditions that prevent real-time traffic and
weather information from being delivered to
the TMC-enabled navigation system.
The developer is not responsible for the quali-
ty or accuracy of the events broadcasted and
the method they are displayed.
Service Information
When you are in an FM TMC service area,
your Navigator receives traffic signals as soon
as you connect the TMC module to your
Navigator. You need to be in range of an FM
station transmitting TMC (Traffic Message
Channel) data to receive traffic information.
Traffic Message Alerts
Traffic (TMC) messages are national and
regional public radio FM transmissions that
are used to inform drivers of traffic, weather,
and other driving conditions.
The traffic messages are displayed in the
TMC Inbox screen, which can be opened by
tapping the traffic info. button in menu
1. From the Navigation menu, select the
“Traffic Info” button, which opens the TMC
inbox, and displays traffic reports.
2. You can select a traffic report and touch
“OK” to show a map of the affected road.
If you click the “Avoid” button, the
Navigation recalculates your route.
Note
• If the event was avoided, the Show Map
screen
displays the “Allow” button to recalculate to
that previously avoided route section.
• All TMC messages are delivered to the TMC
Inbox, but only messages relating the direct
route and 200 meter radius are displayed.
The radius is set to 160 kilometers when no
route has been selected.
Navigation menu
26
Traffic Info Options
You can touch the “Options” button, the
“Options” dialog box is displayed, as shown
below.
These options have already been preconfig-
ured for the best performance. It’s not advis-
able to change them. However, you can
change the Traffic Info. Option configurations
by selecting the following settings:
Dynamic Rerouting
ON - The navigation device automatically
recalculates the route to avoid a road with
adverse traffic conditions – traffic jam or acci-
dent only.
OFF - You can manually select the TMC event
from the inbox and tap the “Avoid” button from
the Show Map screen.
Test TMC
When you tap this button, The Navigation
expands the search radius for to the "whole
map" for one minute and switches automati-
cally to the TMC Inbox screen and displays
one test message called "Testing TMC
Service". After one minute, navigation device
reverts to the route and the 200 meter radius.”
If you do not receive any message after
touching this button, please check in the fol-
lowing order:
1. If you see the tuner scanning but not lock-
ing on a TMC station, try to change your
position and check that you have put your
antenna vertically upright.
2. Depending on your location, you may not
have TMC coverage.
3. Check that you are using the map of the
country that you are currently traveling in.
Note
Please make sure your navigation unit
acquires the GPS signal before starting Traffic
service free trial or subscription.
(Current position icon will turn green when
GPS signal is acquired)
If you complete traffic service free trial without
acquiring GPS signal, the unit may not display
the accurate expiration date.
However, if the unit acquires GPS signal after
completing traffic service free trial or subscrip-
tion, the expiration date will be automatically
adjusted and displayed correctly on the
screen.
Navigation menu
27
Setup
You can make various adjustments to items
by using the setup menu.
1. Touch > .
2. Touch the desired items.
For details, refer to the pages 26-30.
Note
• Touch on the screen to move to
the previous screen.
• Touch on the screen to move to the
map screen.
Display
1. Touch > > .
2. Touch the desired items.
:
The 2D and 3D Mode buttons lets you
display the map view in 2-dimensional or
3-dimensional views for either day or night
driving.
:
The Day and Night Mode buttons lets you
display the map view for either day or
night driving.
The Auto button automatically adjusts the
map view for day or night driving by GPS
time.
:
The Pedestrian Mode button lets you tog-
gle between travelling as a pedestrian or
in a vehicle.
When in Pedestrian Mode, you can gener-
ate a route up to ten kilometers and you
are not limited by vehicle constraints, such
as one way streets.
When creating a pedestrian route, the
navigator avoids motorways or other roads
where pedestrians would not travel.
Voice prompts are deactivated in this
mode.
3. Touch .
Navigation menu
28
Setup
Display
Units & Time
Language
Guidance
GPS Status
Map Setup
Tutorial
Help
Start Demo
Select Map
Initialise
Speed
Cameras
Units & Time
You can specify units of measure and adjust
the time as displayed on your Navigator.
1. Touch > > .
2. Touch the desired items.
:
: Displays and announces in
kilometers.
: Displays and announces in miles.
:
You will see the current values of GMT,
and use one time zone, Greenwich Mean
Time (GMT).
Language
1. Touch > > .
2. Touch the desired items.
:
You can select the language text.
:
You can select voice travel messages and
driving directions. You can hear the voice
of language through speakers while
driving.
3. Touch .
Guidance
You can select the types of voice and visual
notifications that you would like to use while
navigating as follows.
1. Touch > > .
2. Touch the desired items.
:
Warns you when your car exceeds the
speed limit. This prompt is not active by
default.
:
Activated when the Navigator recalculates
a new route.
This prompt is not active by default.
Note
Languages noted with (TTS) are text-to-
speeches, which have an extensive
vocabulary and pronunce the street names
as you approach turns, the pre recorded
voices have a limited vocabulary.
:
Warns that the GPS signal is too low and
unreliable for navigation.
This prompt is active by default.
:
Reminder at the start of each journey.
This prompt is active by default.
:
You can set the type of the guidance
name that you will use to navigate the
route.
3. Touch .
Navigation menu
29
GPS Status
The Navigator uses the GPS receiver to
pinpoint your location. GPS signals are
automatically acquired and your vehicle's
location and position are constantly updated.
The GPS receiver may take a few minutes to
find its initial location.
For best results, ensure that the GPS receiver
has a clear vertical view of the sky.
1. Touch > > .
The following GPS information is displayed:
The angular distance east or west
on the earth's surface.
The location of a place north or
south on the earth's surface.
The rate of movement, as expressed
by kilometers or miles per hour.
The height above sea level.
You can check reception
signals from the GPS
satellite.
Note
If GPS signal can not be detected for a long
time, please restart whole navigation system
by pressing .
GPS not found
When you first start the navigator you will
hear the message “Signal too low”. This mes-
sage means that your navigation device has-
n’t yet located a reliable GPS signal. Check
that your device is connected to the cigarette
lighter and has a clear view of the sky.
The “GPS not found” message means that
there is no GPS antenna or the antenna is not
properly installed.
Please check that:
•The GPS antenna has a clear view of the
sky for uninterrupted GPS reception. The
navigator cannot calculate the route if there
is no GPS reception (for example, in a tun-
nel).
•The navigation device is charged or con-
nected to the cigarette lighter.
Map Setup
You can tap the “Map Setup” button to cus-
tomize your map display.
1. Touch > > .
2. Touch the desired items.
:
When this option is selected, the zoom is
speed dependent. The map zooms out at
higher speeds, displaying a larger map
area, and zooms in at slower speeds, dis-
playing a smaller map area.
If you manually change the zoom, the
Automatic Zoom returns to a system
defined zoom level after several seconds
of inactivity.
:
This option increases the size of street
names to make the text easier to read.
3. Touch .
Navigation menu
30
Tutorial
When you first start the Navigator, a message
box appears prompting you to open the
Navigator Guided Tour program.
The Guided Tour is an excellent way of
becoming familiar with the different navigation
features available. You can also start the
Navigator Guided Tour any time, by touching
the “Tutorial” button from the “Extras” menu.
1. Touch > > > .
2. Touch the desired items.
Help
You can display Navigator technical support
information.
Touch > > > .
Start Demo
This lets the Navigator display a
simulated route. Many of the navigation fea-
tures are disabled when the Demo is running.
Touch > > > .
Touch >to end the Demo.
Note
The demo route is set, and depending on the
current map data, the demo function may dif-
fer somewhat from the map data.
Select Map
This feature lets you change the currently
selected map to another map saved on built-
in memory.
1. Touch > > > .
You can touch the “Select Map” button to dis-
play the maps saved on your built in memory.
The Select Map screen displays map details
and version numbers. The map currently used
appears at the top of the list.
:Lets you refresh the screen when a
new memory card is inserted into the
device.
:Lets you permanently remove a
selected map.
Note
You cannot delete the current map.
Select lets you designate a selected map as
the current map.
Initialise
1. Touch > > > .
:
You can delete all list from the memory.
:
You can set all the function to their factory
settings.
2. Touch .
Navigation menu
31
Speed Cameras
You should agree with developer's policy to
use the speed camera warning function.
If you agree with the provider's policy, you can
be informed on the location and also the type
of camera.
Touch > > > .
Dynamic database of the speed cameras
You are offered support for Dynamic updates.
The content in this database may not be fully
accurate or up-to-date. It is provided as an
indication only. The software and/or data
providers will bear no responsibility in your
acting on this content. This software does not
incite you or anyone to break any laws. The
operating of speed cameras are permitted in
some countries.The operation is at one's own
risk.
Condition for operating is a PC with internet-
connection. For daily updates of your
Cameras database please visit www.safety-
camsam.com (additional charges apply)."
LG does not guarantee the accuracy of the
data which offered on updating website
(www.safetycamsam.com), and users are all
responsible for use and update of the speed
camera data.
Easy updates using PC Portal
PC Portal makes the update, supports
mass storage device & SD card reader. For
more information, see “Import Speed Camera
Alerts” on page 43 and “Importing Favorite
Locations” on page 44.
Playing music
Playing the files in “All Music” folder
1. Touch > > .
The “Music List” screen appears.
There are two kinds of music list: All
Music, My Music
2. Touch the folder or file you want to play.
Playing the files in “My Music” folder
1. Touch during playback.
The mark indicates playing music file.
2. Touch in the left position of the screen.
The mark appears and the file you
touch is stored in “My Music” folder.
To cancel it, touch .
Navigation menu/Music player
32
3. Touch and then touch the
desired file to play music in “My Music”
folder.
•Touch / on the screen to move to the
previous/next page.
•Touch on the screen to move to the
upper folder.
•Touch on the screen to move to the
previous screen.
Note
If there is no supported file, an error message
is displayed on the screen and the next music
file will be played.
Pause
1. Touch during playback.
2. To return to playback, touch again.
Skip the next music
Touch briefly to move to the next music.
Skip the previous music
Touch briefly to move to the previous
music.
Search
Touch and hold the or during play-
back and then release at the point you want.
You can use the slide bar to search for the
music.
Repeat
You can set the repeat playback mode by
touching or .
: Plays repeatedly the current selected file.
: Plays repeatedly all music files in your
device.
Shuffle
You can set the random playback mode by
touching or .
: Returns to the normal playback.
: Plays randomly all the files in your
device.
Viewing the information of
music file
1. Touch during playback.
The information of music file appears.
(If you touch the information screen, it
moves to the previous screen.)
If there is no information of music file,
appears.
Adjusting the Volume/Brightness
1. Touch during playback.
The “Handy Setup” screen appears.
2. Set the volume ( ) and brightness ( )
by touching / and then touch .
Mute
Touch on the “Handy Setup” screen to
mute the sound .To cancel it, touch again.
Music player
33
Viewing photo
1. Turn the unit on.
The map screen appears.
2. Touch > > .
The “Photo List” screen appears.
3. Touch the folder or file you want to play
and then touch .
The slide show starts automatically.
Browse an image
1. Touch the screen during slide show and
then touch .
2. Touch the folder icon to display its sub-
folders and thumbnail images.
•Touch / on the screen to move to the
previous/next page.
•Touch on the screen to move to the
upper folder.
•Touch on the screen to move to the
previous screen.
Pause
1. Touch the screen during slide show.
2. Touch to pause slide show.
2. To return to slide show, touch again.
Skip to the next photo
Touch to move to the next photo in the
selected folder.
Skip to the previous photo
Touch to move to the previous photo in
the selected folder.
Repeat
You can set the repeat playback mode by
touching or .
: Plays repeatedly all photo files in your
device.
: Plays repeatedly all the photos within
folder.
Rotation
Press repeatedly to rotate the photo
clockwise.
Adjusting the Volume/Brightness
1. Touch during playback.
The “Handy Setup” screen appears.
2. Set the volume ( ) and brightness ( )
by touching / and then touch .
Photo viewer
34
Bluetooth wireless technology
If you have a phone with Bluetooth wireless
technology and it is compatible with your
device (Please refer to the list of available
phones on the page 48-49), you can use the
following features in your device: Hands-free
Calling, Audio streaming for mp3, and
Phonebook sync and edit.
Hands free feature is to make or receive a
phone call using microphone and speaker
built in your device. Audio streaming feature is
to enable to listen to music (especially, mp3
file) in your stereo headset and to enable to
handle playing music such as play, pause, or
skip. Lastly, phonebook sync and edit feature
is to transfer your phonebook in your phone to
your device, and to add and edit new phone
numbers on your device. These features on
your device are only available if your phone
supports these features using Bluetooth wire-
less technology. To use these features, you
must connect your phone with your device.
You may initiate this connection from your
phone or from your device. Please refer to
phone’s guidebook for more information.
Connecting your unit and blue-
tooth phone
To connect using the unit settings
1. Press POWER ( ) briefly in power on sta-
tus. The “Handy Setup” screen appears.
2. Touch .
3. Touch .
4. Touch .
The “Searching for available devices.”
pop-up screen appears on the screen.
It will take about 30-60 seconds, to contin-
ue the process.
To cancel, touch .
5. Touch a bluetooth phone you desire from
the “Search Results” screen.
The “Please enter the below PIN code in
your phone” pop-up screen appears.
6. Input the PIN code (0000) in your phone
when the pop-up screen is displayed on
the screen.
When it is successfully connected, the
mark is displayed in the "Handsfree -
available devices" screen.
When it is not connected, the connection
failure message appears.
Note
Before connecting, check the PIN code set-
tings. Refer to “Setting the Bluetooth” on the
page 36.
Bluetooth
35
Map/Photo mode Music mode

Navigation menu
