Specifications

General Specification
Product Name: WLAN Adapter Card
Model Number: WN8522D2
Current Consumption 5VDC
Operating Temperature 0~60℃ ambient
Storage Temperature -20~60℃ ambient
Frequency Band 2400MHz ~ 2483.5MHz、5150MHz ~ 5250MHz
5725MHz ~ 5850MHz
Frequency Range
802.11b/g/n-HT20: 2412MHz ~ 2462MHz
802.11n-HT40: 2422MHz ~ 2452MHz
5755MHz ~ 5795MHz
5190MHz ~ 5230MHz
802.11a/HT20: 5745MHz ~ 5825MHz
5180MHz ~ 5240MHz
Radio Technology 802.11b: DSSS Modulation (DBPSK/DQPSK/CCK)
802.11a/g/n-HT20/n-HT40: OFDM Modulation
(BPSK/QPSK/16QAM/64QAM)
Data Transfer Rate
802.11b: 1/2/5.5/11Mbps
802.11a/g: 6/9/12/18/24/48/54Mbps
802.11n: up to 300Mbps
Output Power
2400MHz ~ 2483.5MHz:21.68dBm
5150MHz ~ 5250MHz:13.37dBm
5725MHz ~ 5850MHz:24.24dBm
Antenna Information
Peak Gain W/ Cable loss (dBi)
Antenna Part
Number Manufacture Antenna
Type Frequency (MHz) Max Gain (dBi)
2.4GHz 0.97dBi (peak)
2.45GHz 1.25dBi (peak)
2.5GHz 0.94dBi (peak)
5.15GHz 1.73dBi (peak)
5.25GHz 1.89dBi (peak)
5.725GHz 1.54dBi (peak)
5.825GHz 1.44dBi (peak)
Ant_L
Ant./120800003400J arcadyan MIFA
Antenna
5.85GHz 1.45dBi (peak)
2.4GHz 1.24dBi (peak)
2.45GHz 1.35dBi (peak)
2.5GHz 1.64dBi (peak)
5.15GHz 1.19dBi (peak)
5.25GHz 1.78dBi (peak)
5.725GHz 0.91dBi (peak)
5.825GHz 1.62dBi (peak)
Inner
Ant./120800003600J arcadyan MIFA
Antenna
5.85GHz 1.27dBi (peak)
