LG Electronics USA 9QKE40210 Video Cassette Recorder User Manual EC970CM 470CM O M Zenith
LG Electronics USA Video Cassette Recorder EC970CM 470CM O M Zenith
users manual
© Copyright 2001, Zenith Electronics Corporation
Installation and Operating Guide | Warranty
Model Numbers | VRE4122 • VRE4222 | Video Cassette Recorders
Safety Precautions
This lightning flash with arrowhead symbol
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
dangerous voltage within the product’s enclo-
sure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and mainte-
nance (servicing) instructions in the literature
accompanying the product.
NOTE TO CABLE/TV INSTALLER: This reminder is provided
to call the cable TV system installer’s attention to Article
820-40 of the National Electric Code (U.S.A.). The code
provides guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of
the cable entry as practical.
REGULATORY INFORMATION:
FCC Part 15
This product has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the product is operated in a residential installation. This
product generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to
radio communications. However, there is no guarantee
that interference will not occur in a particular installa-
tion. If this product does cause harmful interference to
radio or television reception, which can be determined by
turning the product off and on, the user is encouraged to
try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the product and
receiver.
• Connect the product into an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV techni-
cian for help.
FCC WARNING: This equipment may generate or use radio
frequency energy. Changes or modifications to this
equipment may cause harmful interference unless the
modifications are expressly approved in the instruction
manual. The user could lose the authority to operate this
equipment if an unauthorized change or modification is
made.
FCC COMPLIANCE: The responsible party for this product’s
compliance is:
Zenith Electronics Corporation, 2000 Millbrook Drive,
Lincolnshire, IL 60069, USA
Phone: 1-847-391-7000.
IMPORTANT COPYRIGHT INFORMATION: Many television
programs and films are copyrighted. In certain circum-
stances copyright law may apply to private in-home video
taping of copyrighted materials.
WARNING
2
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS
LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER
JUSQU’AU FOND.
WARNING: Do not drop the tying band of the power
cord into the unit. Doing so might cause a fire or an
electrical shock. (See page 11.)
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR
MOISTURE.
MOISTURE CONDENSATION
If you pour a cold liquid into a glass, water vapor in the
air will condense on the surface of the glass. This is
moisture condensation. Moisture condensation on the
head drum, one of the most crucial parts of the unit,
will cause damage to the tape. When the VCR is exposed
to a rapid temperature change from cold to warm, some
condensation will occur. Under this condition, connect
the power cord to the AC line, press POWER on and
allow at least two hours for the VCR to dry out.
WARNING: TO REDUCE THE RISK
OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
SERIAL NUMBER: The serial number is found on the back
of this unit. This number is unique to this unit and not
available to others. You should record requested informa-
tion here and retain this guide as a permanent record of
your purchase.
Model No. ___________________________
Serial No. ___________________________
3
CONTENTSFEATURES
INTRODUCTION
Features/Contents/Accessories . . . . . . . . . . . . . . . . . .3
Important Safety Instructions . . . . . . . . . . . . . . . . . .4-5
PREPARATION
VCR Feature Chart . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Connections for Your VCR . . . . . . . . . . . . . . . . . . . .7-8
Control Names and Locations . . . . . . . . . . . . . . . . .9-11
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . .12-13
Onscreen Display (OSD) . . . . . . . . . . . . . . . . . . . . . .14
Setting the Onscreen Display . . . . . . . . . . . . . . . . . .15
Setting the Setup Menu . . . . . . . . . . . . . . . . . . . . . . .16
Channel Selection . . . . . . . . . . . . . . . . . . . . . . . .17-18
Viewing TV Only . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Video Cassette Tapes . . . . . . . . . . . . . . . . . . . . . . . .19
Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . .20-21
PLAYBACK
Normal Playback . . . . . . . . . . . . . . . . . . . . . . . . .22-23
Special Effects Playback . . . . . . . . . . . . . . . . . . .24-25
RECORDING
Normal Recording . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Timer Recording . . . . . . . . . . . . . . . . . . . . . . . . . .27-29
Instant Timer Recording . . . . . . . . . . . . . . . . . . . . . .30
Dubbing and Editing . . . . . . . . . . . . . . . . . . . . . . . . .31
ADDITIONAL INFORMATION
EZ Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
VHS Hi-Fi Stereo System/MTS Broadcast . . . . . .33-34
Tape Counter Memory Feature . . . . . . . . . . . . . . . . .35
Editing a Recording . . . . . . . . . . . . . . . . . . . . . . . . . .36
Operating Hints . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Video Head Cleaning . . . . . . . . . . . . . . . . . . . . . . . .36
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
• Auto Clock Set System
• Energy Save Function
• Easy Operations
• MTS Hi-Fi Stereo
• 1Year/8 Event Timer with
DAILY and WEEKLY Function
• Auto Power and Playback
Functions
• Instant Timer Recording
• Real-Time Tape Counter,
Tape Remaining Time
• Clean Still, Slow, Frame
Advance, Commercial Skip
• Auto Tracking Function/Auto
Head Cleaner
• Onscreen Display of Function
• Trilingual Onscreen
Programming
(English/Spanish/French)
Check to make sure that all accessories listed left have been
included with your VCR.
•
Depending on your antenna system, you may need a different
type of Combiner (Mixer) and Separator (Splitter). You can pur-
chase them at most electronics stores. For further details, ask
your nearest authorized service center.
eject
power
menu clear
sp / slptv / vcr
stop
rew play ff
cm skip
EZ review
pause a rec / itr
ch/trk
adj
enter
ch/trk
adj
Remote Control RF Coaxial Cable
ACCESSORIES
INTRODUCTION PREPARATION PLAYBACK RECORDING ADDITIONAL INFORMATION
4
