LG Electronics USA 9QKE40250 VCR / DVD/CD/MP3 Player AM/FM Receiver User Manual DT 587M OM Zenith
LG Electronics USA VCR / DVD/CD/MP3 Player AM/FM Receiver DT 587M OM Zenith
users manual
© Copyright 2002, Zenith Electronics Corporation
Installation and Operating Guide | Warranty
Model Number | XBS245 | Combi Home Theater System
2
Safety Precautions
This lightning flash with arrowhead symbol within an
equilateral triangle is intended to alert the user to
the presence of uninsulated dangerous voltage
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
product.
WARNING: Do not install this equipment in a confined space
such as a bookcase or similar unit.
NOTE TO CABLE/TV INSTALLER: This reminder is provided to
call the cable TV system installer’s attention to Article 820-40 of
the National Electric Code (U.S.A.). The code provides guidelines
for proper grounding and, in particular, specifies that the cable
ground shall be connected to the grounding system of the
building, as close to the point of the cable entry as practical.
CAUTION:
This DVD+VCR employs a Laser System.
To ensure proper use of this product, please read this owner’s
manual carefully and retain for future reference. Should the
unit require maintenance, contact an authorized service
location.
Use of controls, adjustments, or the performance of proce-
dures other than those specified herein may result in haz-
ardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open
the enclosure. Visible laser radiation when open. DO NOT
STARE INTO BEAM.
CAUTION: The apparatus should not be exposed to water
(dripping or splashing) and no objects filled with liquids, such
as vases, should be placed on the apparatus.
FCC WARNING: This equipment may generate or use radio
frequency energy. Changes or modifications to this
equipment may cause harmful interference unless the modifi-
cations are expressly approved in the instruction manual. The
user could lose the authority to operate this equipment if an
unauthorized change or modification is made.
REGULATORY INFORMATION: FCC Part 15
This product has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the product is
operated in a residential installation. This product generates,
uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur
in a particular installation. If this product does cause harmful
interference to radio or television reception, which can be
determined by turning the product off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the product and
receiver.
Connect the product into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
FCC COMPLIANCE: The responsible party for this product’s
compliance is: Zenith Electronics Corporation, 2000 Millbrook
Drive, Lincolnshire, IL 60069, USA.
Phone: 1-847-941-8000
NOTES ON COPYRIGHTS:
It is forbidden by law to copy, broadcast, show, broadcast
via cable, play in public, or rent copyrighted material without
permission.
This product features the copy protection function developed
by Macrovision. Copy protection signals are recorded on some
discs. When recording and playing the pictures of these discs
on a VCR, picture noise will appear.
This product incorporates copyright protection technology that
is protected by method claims of certain U.S. patents and other
intellectual property rights owned by Macrovision Corporation
and other rights owners. Use of this copyright protection tech-
nology must be authorized by Macrovision Corporation, and is
intended for home and other limited viewing uses only unless
otherwise authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited.
SERIAL NUMBER: The serial number is found on the back of
this unit. This number is unique to this unit and not available to
others. You should record requested information here and
retain this guide as a permanent record of your purchase.
Model No. ___________________________________
Serial No. ___________________________________
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE
DANS LA BORNE CORRESPONDANTE DE LA PRISE ET
POUSSER JUSQU’AU FOND.
WARNING: TO REDUCE THE RISK OF FIRE OR ELEC-
TRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO
RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK
OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
INTRODUCTION
3
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions. - All these safety and oper-
ating instructions should be read before the product is
operated.
2. Keep these instructions. - The safety, operating and
use instructions should be retained for future refer-
ence.
3. Heed all warnings. - All warnings on the product and
in the operating instructions should be adhered to.
4. Follow all instructions. - All operating and use
instructions should be followed.
5. Do not use this product near water. – For example:
near a bath tub, wash bowl, kitchen sink, laundry tub,
in a wet basement; or near a swimming pool; and
other areas located near water.
6. Clean only with dry cloth. – Unplug this product from
the wall outlet before cleaning. Do not use liquid
cleaners.
7.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions. -
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the
product and to protect it from over- heating. The open-
ings should never be blocked by placing the product
on a bed, sofa, rug or other similar surface. This prod-
uct should not be placed in a built-in installation such
as a bookcase or rack unless proper ventilation is pro-
vided or the manufacturer’s instructions have been
adhered to.
8. Do not install near any heat sources such as radi-
ators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9.
Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A ground-
ing
type plug has two blades and a third ground-
ing prong. The wide blade or the third prong are
provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the product.
11. Only use attachments/accessories specified by
the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
apparatus. When a cart is used, use caution
when moving the cart/product combination to
avoid injury from tip-over.
13. Unplug this product during lightning storms or
when unused for long periods of time.
14.
Refer all servicing to qualified service personnel.
Servicing is required when the product has been
damaged in any way, such as power-supply cord
or plug is damaged, liquid has been spilled or
objects have fallen into the product, the product
has been exposed to rain or moisture, does not
operate normally, or has been dropped.
CAUTION:
PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS OWNER’S MANUAL.
AND THOSE MARKED ON THE PRODUCT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE.
This product has been designed and manufactured to assure personal safety. Improper use can result in electric
shock or fire hazard. The safeguards incorporated in this product will protect you if you observe the following proce-
dures for installation, use, and servicing.
This product does not contain any parts that can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
4
Table of Contents
Introduction
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . 2
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . 3
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Before Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Playable Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Notes on Discs . . . . . . . . . . . . . . . . . . . . . . . . . . 6
About Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Display Window. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Preparation
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-14
Connecting Antenna/Cable TV to a DVD+VCR . . 11
Basic TV Connections . . . . . . . . . . . . . . . . . . . . 12
Optional TV Connections . . . . . . . . . . . . . . . . . . 12
Speaker System Connections . . . . . . . . . . . . . . 13
Speaker Positioning . . . . . . . . . . . . . . . . . . . . . . 13
Radio Antenna Connections . . . . . . . . . . . . . . . . 14
Accessory Audio/Video (A/V) Connections to
DVD+VCR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Degital Device Connections . . . . . . . . . . . . . . . . 14
Before Operation - Amplifier Part . . . . . . . . . . 15-17
Mini Glossary for Sound Mode . . . . . . . . . . . . . . 15
Sound Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Sound Level. . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Test Tone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Delay Time Setting. . . . . . . . . . . . . . . . . . . . . . . 17
Before Operation - VCR Part . . . . . . . . . . . . . . 18-20
On-Screen Display. . . . . . . . . . . . . . . . . . . . . . . 18
Setting the On-Screen Display . . . . . . . . . . . . . . 18
Setting the VCR Setup Menu . . . . . . . . . . . . . . . 19
Channel Selection . . . . . . . . . . . . . . . . . . . . . . . 19
Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . 20
Before Operation - DVD Part . . . . . . . . . . . . . . 21-23
General Explanation. . . . . . . . . . . . . . . . . . . . . . 21
On-Screen Display. . . . . . . . . . . . . . . . . . . . . . . 21
Initial Settings . . . . . . . . . . . . . . . . . . . . . . . . 22-23
Initial Settings General Operation . . . . . . . . . 22
Language . . . . . . . . . . . . . . . . . . . . . . . . . . 22
PBC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Parental Control. . . . . . . . . . . . . . . . . . . . . . 23
Operation
Operation with tape - VCR Part . . . . . . . . . . . . 24-29
Normal Playback . . . . . . . . . . . . . . . . . . . . . . . . 24
Special Effect Playbacks . . . . . . . . . . . . . . . . . . 24
Search. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Still Picture and Frame-by-Frame Playback . 24
Slow Motion . . . . . . . . . . . . . . . . . . . . . . . . . 24
CM SKIP (Commercial Skip) . . . . . . . . . . . . 24
Normal Recording . . . . . . . . . . . . . . . . . . . . . . . 25
Timer Recording . . . . . . . . . . . . . . . . . . . . . . 25-26
Instant Timer Recording . . . . . . . . . . . . . . . . . . . 27
Dubbing and Editing. . . . . . . . . . . . . . . . . . . . . . 27
Copying from DVD to VCR. . . . . . . . . . . . . . . . . 27
VHS Hi-Fi Stereo System/MTS Broadcast . . . . . 28
Tape Counter Memory Feature. . . . . . . . . . . . . . 29
Additional Information . . . . . . . . . . . . . . . . . . . . 29
Operation with DVD and Video CD - DVD Part
. . 30-35
Playing DVD and Video CD . . . . . . . . . . . . . . . . 30
General Features. . . . . . . . . . . . . . . . . . . . . . . . 30
Moving to another TITLE . . . . . . . . . . . . . . . 30
Moving to another CHAPTER/TRACK . . . . . 30
Slow Motion . . . . . . . . . . . . . . . . . . . . . . . . . 30
Still Picture and Frame-by-Frame Playback . 31
Search. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Random. . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Repeat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Repeat A-B . . . . . . . . . . . . . . . . . . . . . . . . . 29
Time Search . . . . . . . . . . . . . . . . . . . . . . . . 31
3D Surround . . . . . . . . . . . . . . . . . . . . . . . . 31
Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Marker Search . . . . . . . . . . . . . . . . . . . . . . . 32
Special DVD Features . . . . . . . . . . . . . . . . . . . . 32
Checking the contents of DVD Video discs: Menus
. 32
Title Menu . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Disc Menu . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Camera Angle . . . . . . . . . . . . . . . . . . . . . . . 32
Changing the Audio Language . . . . . . . . . . . 32
Changing the Audio Channel . . . . . . . . . . . . 32
Subtitle . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Operation with Audio CD and MP3 Discs - DVD Part . .
33
Playing an Audio CD and MP3 Discs . . . . . . . . . 33
Pause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Moving to another Track . . . . . . . . . . . . . . . 33
Repeat Track/ All/ Off. . . . . . . . . . . . . . . . . . 33
Search. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Random . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Repeat A-B . . . . . . . . . . . . . . . . . . . . . . . . . 33
3D Surround . . . . . . . . . . . . . . . . . . . . . . . . 33
Changing the Audio Channel . . . . . . . . . . . . 33
Programmed Playback - DVD Part . . . . . . . . . . . . 34
Programmed Playback with Audio CD
and MP3 Discs . . . . . . . . . . . . . . . . . . . . . . . . . 34
Programmed Playback with Video CD . . . . . . . . 34
Repeat Programmed Tracks . . . . . . . . . . . . 34
Erasing a Track from Program List . . . . . . . . 34
Erasing the Complete Program List . . . . . . . 34
Additional Information - DVD Part . . . . . . . . . . . . 35
Last Condition Memory . . . . . . . . . . . . . . . . . . . 35
Screen Saver. . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Video Mode Setting . . . . . . . . . . . . . . . . . . . . . . 35
Notes on MP3 Discs . . . . . . . . . . . . . . . . . . . . . 35
Operation with Radio . . . . . . . . . . . . . . . . . . . . . . 36
Presetting Radio Stations. . . . . . . . . . . . . . . . . . 36
Listening to the Radio . . . . . . . . . . . . . . . . . . . . 36
Reference
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 37-38
Language Code List . . . . . . . . . . . . . . . . . . . . . . . 39
Country Code List . . . . . . . . . . . . . . . . . . . . . . . . . 40
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . 41-42
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . Rear Cover
About the symbols for instructions
Indicates hazards likely to cause harm to the unit
itself or other material damage.
Indicates special operating features of this unit.
Indicates tips and hints for making the task easier.
INTRODUCTION
5
Before Use
Playable Discs
DVD
(8 cm/12 cm disc)
Audio CD
(8 cm/12 cm disc)
In addition, this unit can play a CD-R or CD-RW that
contains audio titles or MP3 files.
Notes
– Depending on the conditions of the recording equip-
ment or the CD-R/RW disc itself, some CD-R/RW
discs cannot be played on the unit.
– The unit cannot play discs that contain data other
than MP3 and CD-DA data.
– Do not attach any seal or label to either side (the
labeled side or the recorded side) of a disc.
– Do not use irregularly shaped CDs (e.g., heart-
shaped or octagonal). It may result in malfunctions.
Notes on DVDs
Some playback operations of DVDs may be intentionally
fixed by software manufacturers. As this unit plays
DVDs according to disc content designed by the soft-
ware manufacturer, some playback features of the unit
may not be available or other functions may be added.
Refer also to the instructions supplied with the DVDs.
Some DVDs made for business purposes may not be
played on the unit.
Regional code of the DVD+VCR and DVDs
This DVD+VCR is designed and manufactured
for playback of Region 1 encoded DVD software.
The region code on the labels of some DVD discs indi-
cates which type of DVD+VCR can play those discs. This
unit can play only DVD discs labeled 1 or ALL. If you try
to play any other discs, the message “Check Regional
Code” will appear on the TV screen. Some DVD discs
may not have a region code label even though their play-
back is prohibited by area limits.
Note on DTS-encoded CDs
When playing DTS-encoded CDs, excessive noise may
be exhibited from the analog stereo output. To avoid
possible damage to the audio system, turn down the
volume before playing back such discs, adjust the vol-
ume gradually, and keep the volume level low. To enjoy
DTS Digital SurroundTM playback, an external 5.1 chan-
nel DTS Digital SurroundTM decoder system must be
connected to the digital output of the unit.
Disc-related terms
Title (DVD only)
The main film content or accompanying feature content
or music album.
Each title is assigned a title reference number enabling
you to locate it easily.
Chapter (DVD only)
Sections of a picture or a musical piece that are smaller
than titles. A title is composed of one or several chap-
ters. Each chapter is assigned a chapter number to
enable you to locate the chapter you want. Depending
on the disc, chapters may not be labelled.
Track (audio CD only)
Sections of a musical piece on an audio CD. Each track
is assigned a track number, enabling you to locate the
track you want.
Remote control battery installation
Detach the battery cover on the rear of the
remote control, and insert two R03 (size
AAA) batteries with and aligned
correctly.
Caution
Do not mix old and new batteries. Never mix different
types of batteries (standard, alkaline, etc.).
Remote Control Operation Range
Point the remote control at the remote sensor and press
the buttons.
Distance: About 23 ft (7 m) from the front of the
remote sensor
Angle: About 30° in each direction of the front of the
remote sensor
1
AAA
AAA
IMPORTANT NOTE:
SPENT OR DISCHARGED BATTERIES MUST BE
RECYCLED OR DISPOSED OF IN A SAFE MANNER
IN COMPLIANCE WITH ALL APPLICABLE LAWS.
FOR DETAILED INFORMATION, CONTACT YOUR
LOCAL COUNTY SOLID WASTE AUTHORITY.
6
Before Use (Continued)
Precautions
Handling the unit
When shipping the unit
The original shipping carton and packing materials
come in handy. For maximum protection, re-pack the
unit as it was originally packaged at the factory.
When setting up the unit
The picture and sound of a nearby TV, VCR, or radio
may be distorted during playback. In this case, position
the unit away from the TV, VCR, or radio, or turn off the
unit after removing the disc.
To keep the surface clean
Do not use volatile liquids, such as insecticide spray,
near the unit. Do not leave rubber or plastic products in
contact with the unit for a long period of time. They will
leave marks on the surface.
Cleaning the unit
To clean the cabinet
Use a soft, dry cloth. If the surfaces are extremely dirty,
use a soft cloth lightly moistened with a mild detergent
solution. Do not use strong solvents such as alcohol,
benzine, or thinner, as these might damage the surface
of the unit.
To obtain a clear picture
The DVD+VCR is a high-tech, precision device. If the
optical pick-up lens and disc drive parts are dirty or
worn, the picture quality will be poor.
Regular inspection and maintenance are recommended
after every 1,000 hours of use. (This depends on the
operating environment.)
For details, please contact your nearest dealer.
Notes on Discs
Handling discs
Do not touch the playback side of the disc.
Hold the disc by the edges so that fingerprints will not
get on the surface.
Do not stick paper or tape on the disc.
Storing discs
After playing, store the disc in its case.
Do not expose the disc to direct sunlight or sources of
heat, or leave it in a parked car exposed to direct sun-
light, as there may be a considerable temperature
increase inside the car.
Cleaning discs
Fingerprints and dust on the disc can cause poor pic-
ture quality and sound distortion. Before playing, clean
the disc with a clean cloth. Wipe the disc from the cen-
ter outward.
Do not use strong solvents such as alcohol, benzine,
thinner, commercially available cleaners, or anti-static
spray intended for older vinyl records.
About Symbols
About the symbol display
“ ” may appear on the TV screen during operation.
This icon means the function explained in this owner’s
manual is not available on that specific DVD video disc.
About the disc symbols for instructions
A section whose title has one of the following symbols are
applicable only to those discs represented by the symbol.
DVD
Audio CDs.
MP3 Discs.
MP3
CD
DVD
No
Yes
Setting the Output Source
You must select one of your output sources (DVD or
VCR) to view on the TV screen.
•If you want to view output from the DVD deck:
Press DVD on the remote or DVD/VCR on the front panel
until DVD indicator on the front panel lights and output from
the DVD deck is viewed on the TV screen.
•If you want to view from the VCR deck:
Press VCR on the remote or DVD/VCR on the front panel
until VCR indicator on the front panel lights and output from
the VCR deck is viewed on the TV screen.
•If you use OUTPUT SELECT button on the remote con-
trol to select output source:
Cycles through the 3 main output views: DVD, Tuner and VCR.
DVD: To view the current DVD deck status. (disc playback,
DVD menu or setup menu, etc)
Tuner: To view TV programs through TV tuner.
VCR: To view the current VCR deck status (tape playback,
VCR programming or viewing TV programs through
the VCR tuner, etc).
7
INTRODUCTION
Front Panel
FORWARD (>>/MM)
DVD: Go to NEXT chapter/track. Press and hold for two seconds for a fast forward search.
VCR: Advances the tape during the STOP mode or for fast forward picture search.
PAUSE/STEP (XX)
Pause playback or recording
temporarily/press repeatedly for
frame-by-frame playback.
OPEN/CLOSE
Opens or closes
the disc tray.
Remote Sensor
Point the DVD+VCR remote control
here.
Display window
Shows the current
status of the
DVD+VCR.
Disc Tray (DVD deck)
Insert a disc here.
POWER
Switches the DVD+VCR ON and OFF.
COPY/MEMORY
Press to copy a DVD
in the DVD deck to a
VCR tape in the VCR
deck.
Memories a frequen-
cy of radio.
TUNNIING (vv/VV)
Scans an available channel in
the area.
BACKWARD (../mm)
DVD: Go to beginning of current chapter/track or to previous chapter/track.
Press and hold for a fast reverse search.
VCR: Rewinds the tape during the STOP mode or for fast reverse picture search.
PLAY (HH)
To play back a recorded tape.
STOP (xx)
Stops playback.
REC/ITR (zz)
To record normally or
to activate Instant
Timer Recording.
CH/PRESET (vv/VV)
To scan up or down through
memorized channels or radio fre-
quency.
RADIO
Selects operation
mode to radio.
VIDEO IN/AUDIO IN (Left/Right)
Connect the audio/video output of an
external source (Audio system, TV/ Monitor,
Another VCR).
Cassette Compartment
(VCR deck)
Insert a video cassette here.
EJECT
Ejects the tape in the VCR deck.
VOLUME
Adjusts volume of speakers.
DVD/VCR
Toggles control
between the DVD deck
and the VCR deck.
8
Display Window
STEREO Indicates a stereo broadcast is being received.
SAP Indicates when a SAP BILINGUAL broadcast is being received.
DVD DVD inserted.
CD Audio CD inserted.
MP3 MP3 disc inserted
Indicates repeat mode
ANGLE active
RAND RANDOM playback active
A cassette is in the VCR deck.
SP LP EP Displays the recording
and playback speed.
HI-FI Indicates the unit is playing back
a tape recorded in Hi-Fi.
OPT Indicates source of DVD+VCR is
DIGITAL AUDIO IN.
Indicates clock, total playing time, elapsed time, remaining time, title number,
chapter/track number, channel, frequency, level, volume, channel or current
deck status (Playback, Pause, etc).
VCR DVD+VCR functions are available and
channels are selected at DVD+VCR.
TIMER DVD+VCR is in timer recording or a timer
recording is programmed.
REC DVD+VCR is Recording.
PROG. Programmed playback active.
Indicates current encoding method of the disc.
COPY DVD to VCR copy is in progress.
Indicates sound mode is
PROLOGIC II.
9
INTRODUCTION
Remote Control
OPEN/CLOSE, EJECT (ZZ)
- Opens and closes the disc tray.
- Ejects the tape in the VCR deck.
AUX/DVD/VCR/RADIO
select buttons
Select the output source (DVD,VCR, AUX
or RADIO) to view on the TV screen.
LEVEL
Sets the sound leve of each speakerl.
DELAY
Sets the delay time of each speaker.
TEST TONE
A hiss noise comes out for 2 seconds
from each speakers.
MUTE
Turn off speaker sound.
0-9 numerical buttons
Selects numbered options in a menu.
PROGRAM
Accesses or removes Program menu.
MARKER
Marks any point during playback.
SEARCH
Displays MARKER SEARCH menu.
INPUT
To select the VCR deck’s source (Tuner,
LINE 1, or LINE 2).
OUTPUT SELECT
Cycles through the 3 main output views:
DVD, Tuner and VCR.
VOLUME (+/–)
Adjusts volume of speaker.
RETURN
Removes the setup menu.
STOP (xx)
Stops playback.
PAUSE/STEP (XX)
Pause playback or recording
temporarily/press repeatedly for frame-
by-frame playback.
PLAY (HH)
Starts playback.
REC/ITR (zz)
Records normally or activates Instant
Timer Recording.
A-B, SPEED
- Repeats sequence.
- Selects recording speed
REPEAT
Repeat chapter, track, title, all.
RANDOM, CM SKIP
- Plays tracks in random order.
- Fast forwards picture search through
30 seconds of recording.
POWER
Switches DVD+VCR ON and OFF.
SOUND EFFECT
Selects sound mode.
PLOROGIC II
Selects sound mode of PROLOGIC II.
BY PASS
Sets PRO LOGIC II mode to Off
CLEAR
Removes a track number on the
program menu or a mark on the
MARKER SEARCH menu.
AUDIO
Selects an audio language (DVD) or an
audio channel (VCD/CD).
ZOOM
Enlarges DVD video image.
ANGLE
Selects a DVD camera angle if
available.
SUBTITLE
Selects a subtitle language.
TITLE
Displays the disc’s Title menu, if
available.
DISPLAY, CLK/CNT
Accesses On-Screen display.
Switches among the clock, tape counter
and tape remaining modes on the display.
SETUP, MENU
Accesses or removes DVD setup menu
and VCR menu.
b/B/v/V(left/right/up/down)
- Selects an option in the menu
-
CH/TRK (v/V): Selects channel of VCR.
Adjusts manually the tape’s picture
onscreen.
DISC MENU
Accesses menu on a DVD disc.
TV/VCR
To view channels selected by the VCR
tuner or by the TV tuner.
SELECT/ENTER
- Acknowledges menu selection.
- Displays functions on the TV screen.
FORWARD (>>)
Search forward*/go to next chapter or
track (DVD). Advances the tape during
the STOP mode or for fast forward pic-
ture search. (VCR)
BACKWARD (..)
Search backward*/go to beginning of
current chapter or track or go to previ-
ous chapter or track (DVD). Rewinds the
tape during the STOP mode or for fast
reverse picture search. (VCR)
* Press and hold button for about two
seconds.
Note
This remote control use the
same buttons for VCR or DVD
functions (ex. PLAY).
When using a VCR, first press
the VCR button.
When using a DVD, first press
the DVD button.
Rear Panel
Do not touch the inner pins of the jacks on the rear
panel. Electrostatic discharge may cause permanent
damage to the unit.
VCR IN LINE 1 (VIDEO IN/AUDIO IN (Left/Right))
Connect the audio/video output of an external source
(Audio system, TV/Monitor, Another VCR).
ANT.IN
Connect the VHF/UHF/CATV antenna to
this terminal.
DVD/VCR OUT (VIDEO/AUDIO (Left/Right))
Connect to a TV with video and audio inputs.
AC Power Cord
Plug into the power source.
S-VIDEO OUT (DVD OUT)
Connect to a S-Video Input on TV.
DIGITAL AUDIO IN (OPTICAL)
Connect to a digital audio output on a digital device.
COMPONENT VIDEO OUT (Y Pb Pr) (DVD OUT)
Connect to a TV with Y Pb Pr inputs.
RF OUT (DVD/VCR OUT)
Connect to a TV with RF coaxial inputs.
VIDEO OUTPUT Switch
Select either S-VIDEO OUT or COMPONENT VIDEO OUT/PROGRESSIVE
SCAN, depending on how you connected the DVD+VCR to the TV.
AM Antenna Connectors
Connect the AM antenna to this terminal.
FM Antenna Connector
Connect the FM antenna to this terminal.
SPEAKER Connectors
Connect the FM antenna to this terminal.
Dust Protection Cap
Remove the dust protection cap from the
OPTICAL DIGITAL IN jack and connect the
optical digital cable (not supplied) securely
so that the configurations of both the cable
and the connector match. Keep the dust
protection cap and always reattach the cap
when not using the connector to protect
against dust intrusion.
10
PREPARATION
11
Connections
Tips
Depending on your TV and other equipment you wish to
connect, there are various ways you could connect the
DVD+VCR. Use connections described on pages 11-14.
Please refer to the manuals of your TV, VCR, Stereo
System or other devices as necessary to make the best
connections.
Caution
Make sure the DVD+VCR is connected directly to the TV.
Tune the TV to the correct video input channel.
Do not connect the DVD+VCR’s DVD/VCR AUDIO OUT
jack to the phono in jack (record deck) of your audio
system.
Do not connect your DVD+VCR via your VCR. The DVD
image could be distorted by the copy protection system.
Connecting Antenna/Cable TV to
DVD+VCR
11
Disconnect the antenna leads from the rear of the
TV.
22
Identify the type of cable from your antenna. If it is
a round cable as illustrated, it is a 75 ohm coaxial
antenna cable. This cable will connect directly to
the jack marked ANT.IN on your DVD+VCR.
Tip
If your antenna lead wire is a flat type antenna cable,
connect it to an Antenna Adaptor (300-ohm to 75-ohm)
(not supplied) and slip the Adaptor onto the ANT.IN
jack. The Adaptor does not screw on to the DVD+VCR,
it just slips over the jack.
Without Cable Box
If your cable wire is connected to your TV without a converter
or descrambler box, unscrew the wire from your TV and attach
it to the ANT.IN jack on the DVD+VCR. Use the supplied round
coaxial cable to connect between the DVD+VCR’s RF.OUT
jack and the 75 ohm antenna input jack on the TV. With this
connection, you can receive all midband, super band, and
hyperband channels.
With Cable Box
If a converter is required in your cable system, follow the
instruction below:
The cable hookup permits both TV and DVD+VCR operation.
To view or record CATV channel
1Tune the TV to the DVD+VCR output channel (CH 3 or 4).
2Set the DVD+VCR channel selector to the output channel of
the Cable Converter box by pressing the CH/TRK (v/V) or
number (0-9) of your DVD+VCR. (Example: CH3)
3Select the channel to view at the Cable Converter Box.
Notes
With this connection, you CANNOT record one program
while viewing another.
If you are using a cable box to tune channels, it is not nec-
essary to do Auto Channel Programming, (Auto Channel
Search) as indicated on page 19.
Antenna Antenna
Flat Wire
(300 ohm)
300/75 ohm
Adaptor
(Not supplied)
Cable TV
Wall Jack
OR OR
Rear of DVD+VCR
Cable TV
Wall Jack
Back Panel of
Typical Cable Box
Rear of DVD+VCR
Connections (Continued)
12
Basic TV Connections
Make one of the following connections, depending on
the capabilities of your existing equipment.
RF coaxial connection
Connect the RF.OUT jack on the DVD+VCR to the
antenna in jack on the TV using the 75-ohm Coaxial
Cable supplied (R).
Note
If you use this connection, tune the TV to the
DVD+VCR’s RF output channel (CH 3 or 4).
How to set the DVD+VCR’s RF output channel
When the DVD+VCR is turned off,
press and hold
CHANNEL (v/V) on the front panel for about five
seconds to change the RF output channel (CH 03 or
CH 04). “RF 03” or “RF 04” appears in the display
window.
Audio/Video connection
11
Connect the DVD/VCR VIDEO OUT jack on the
DVD+VCR to the video in jack on the TV using the
video cable supplied (V).
22
Connect the Left and Right DVD/VCR AUDIO OUT
jacks on the DVD+VCR to the audio left/right in
jacks on the TV (A) using the supplied audio
cables.
Note
If you use this connection, set the TV’s source selector
to VIDEO.
Optional TV Connections
Notes
DVD playback can ONLY be done using the S-VIDEO
OUT and COMPONENT VIDEO OUT/PROGRESSIVE
SCAN connection options below.
The tuner and VCR
will still output through the RF.OUT (R) or DVD/VCR
OUT (A, V) jack. (See left)
When using the COMPONENT VIDEO OUT/PRO-
GRESSIVE SCAN jacks, set the VIDEO OUTPUT
switch to COMPONENT/PROGRESSIVE. When
using the S-VIDEO OUT jack, set the VIDEO OUT-
PUT switch to S-VIDEO.
S-Video connection
11
Connect the S-VIDEO OUT jack on the DVD+VCR
to the S-Video in jack on the TV using the supplied
S-Video cable (S).
22
Connect the Left and Right AUDIO OUT jacks of the
DVD+VCR to the audio left/right in jacks on the TV
using the supplied audio cables (A).
Component Video (Color Stream®) connection
11
Connect the COMPONENT VIDEO OUT jacks on
the DVD+VCR to the corresponding in jacks on the
TV using user-supplied Y Pb Pr cables (C).
22
Connect the Left and Right AUDIO OUT jacks of
the DVD+VCR to the audio left/right in jacks on the
TV (A) using the supplied audio cables.
Progressive Scan (ColorStream®pro) connection
If your television is a high-definition or “digital ready”
television, you may take advantage of the
DVD+VCR’s progressive scan output for the highest
video resolution possible.
If your TV does not accept the Progressive Scan for-
mat, the picture will appear scrambled if you try
Progressive Scan on the DVD+VCR.
11
Connect the COMPONENT VIDEO OUT/
PROGRESSIVE SCAN jacks on the DVD+VCR to
the corresponding in jacks on the TV using an
optional Y Pb Pr cable (C).
22
Connect the Left and Right AUDIO OUT jacks of
the DVD+VCR to the audio left/right in jacks on the
TV (A) using the supplied audio cables.
Notes
–Set the Progressive to “On” on the setup menu for
progressive signal, see page 22.
–Progressive scan does not work with the analog video
connections (yellow VIDEO OUT jack).
ANTENNA
INPUT
R
L
R
Y
Pb
Pr
COMPONENT VIDEO INPUT
AUDIO INPUT
L
VIDEO
INPUT
S-VIDEO
INPUT
Rear of TV
Rear of DVD+VCR
SA V C
PREPARATION
13
Speaker System Connections
Connect the speakers using the supplied speaker cords
by matching the colors of the terminals and those of the
cords. To obtain the best possible surround sound,
adjust the speaker parameters (distance, level, etc.).
Note
Be sure to match the speaker cord to the appropriate
terminal on the components: + to + and – to –. If the
cords are reversed, the sound will be distorted and
lack bass.
If you use front speakers with low maximum input rat-
ing, adjust the volume carefully to avoid excessive
volume output to the speakers.
Do not disassemble the front covers of supplied
speakers.
Speaker Positioning
In the case of normal position use the 6 speakers
(2 front speakers, center speaker, 2 rear speakers and
subwoofer).
If you want to hear deeper bass sound, DTS digital sur-
round or Dolby Digital surround, you should connect an
optional active subwoofer (has its own built-in amplifier).
•Front speakers
According to your listening position set up the speak-
ers for equal distance. And by hearing position set up
the interval between speakers at 45 degree.
•Center speaker
It is ideal that the center speakers and front speakers
are same height. But normally place it above or below
the television as shown below.
•Rear speakers
Place left and right behind the listening area. These
speakers recreate sound motion and atmosphere
required for surround playback. For best results, do
not install the rear speakers too far behind the listen-
ing position, install them at or above the level of the
listener’s ears. It is also effective to direct the rear
speakers towards a wall or ceiling to further disperse
the sound.
In the case of a smaller room size, if the audience is
near to the rear wall set the rear speakers opposite
each other, and set the rear speakers 60 - 90 cm
above the listener’s ears.
•Subwoofer
This can be placed in any front position.
Front speaker
(Right)
Left speaker
(Left surround)
Front speaker
(Left)
Subwoofer
Center speaker
Rear speaker
(Right surround)
Rear of
DVD+VCR
Connections (Continued)
Center Speaker
Front
Speaker
(Left)
Speaker Positioning Example
Rear
Speaker
(Left)
Rear
Speaker
(Right)
Front
Speaker
(Right)
Subwoofer
14
Radio Antenna Connections
Connect the supplied FM/AM antennas for listening to
the radio.
11
Connect the AM loop antenna to the AM antenna
connector.
22
Connector the FM wire antenna to the FM 300Ω
antenna connector.
Note
To prevent noise pickup, keep the AM loop antenna
away from the DVD Receiver and other components.
Be sure to fully extend the FM wire antenna.
After connecting the FM wire antenna, keep it as hori-
zontal as possible.
Accessory Audio/Video (A/V)
Connections to DVD+VCR
Connect the VCR IN LINE1 or LINE2 jacks on the
DVD+VCR to the audio/video out jacks on your
accessory component, using optional audio/video
cables.
Digital Device Connections
Connect the DIGITAL AUDIO IN (OPTICAL) jacks on
the DVD+VCR to the digital audio out (optical) jacks on
your digital device (DVD Player, etc.), using optional
optical audio cables.
To select source of DVD+VCR to OPTICAL IN, press
AUX on the remote control.
ote
If the audio format of the digital output does not
match the capabilities of your DVD+VCR, the
DVD+VCR will produce a strong, distorted sound or
no sound at all.
The Optical input function is available only when the
other unit’s Sampling Frequency is 32 - 48kHz.
Rear of DVD+VCR
AM loop antenna (supplied)
FM wire antenna (supplied)
Rear of DVD+VCR
HDTV ReceiverGame Devive
OR
Connections (Continued)
L
R
VIDEO
OUTPUT
AUDIO
OUTPUT
Jack panel of Accessory Component
(VCR, Camcorder, etc.)
Rear of DVD+VCR Front of DVD+VCR
OR
PREPARATION
15
Before Operation - Amplfier Part
Mini Glossary for Sound Mode
Allows you to enjoy 5.1(or 6) discrete channels of high quality digital audio from DTS program sources bearing the
trademark such as discs, DVD and compact discs, etc. DTS Digital Surround delivers up to 6 channels of transpar-
ent audio(which means identical to the original masters) and results in exceptional clarity throughout a true 360
degree sound field. The term DTS is a trademark of DTS Technology, LLC. Manufactured under license from DTS
Technology, LLC.
The Dolby Digital surround format lets you enjoy up to 5.1 channels of digital surround sound from a Dolby Digital
program source. If you play DVDs with “” mark, you can enjoy even better sound quality, greater spatial
accuracy, and improved dynamic range.
When playing recordings of live music and classic, this mode provides a feeling similar to actually being in a small
concert hall.
When playing recordings of live music and classic, this mode provides a feeling similar to actually being in a large
concert hall.
This mode provides a three dimensional effect similar to that of movie theater.
(II)
Dolby Pro Logic II creates five full-bandwidth output channels from two-channel sources. This is done using an
advanced, high-purity matrix surround decoder that extracts the spatial properties of the original recording without
adding any new sounds or tonal colorations.
PROLOGIC mode:
The Pro Logic Emulation mode offers users the same robust surround processing as original Pro Logic, in case
the source content is not of optimum quality, or if there is a desire to hear the program more “as it used to be.”
When this mode is used, it is called Pro Logic, as before. There is no “Pro Logic I” mode. The Pro Logic emula-
tion mode is optional. Dolby does not require PLII products to use the original Pro Logic decoding algorithm.
However, if the DSP contains the original Pro Logic code, and if the product maker would like to use it, this is
quite acceptable and even encouraged. A product must not offer both original Pro Logic and the Pro Logic emula-
tion mode.
MOVIE mode:
The Movie mode is for use with stereo television shows and all programs encoded in Dolby Surround. The result
is enhanced soundfield directionality that approaches the quality of discrete 5.1-channel sound.
MUSIC mode:
The Music mode is for use with any stereo music recordings, and provides a wide and deep sound space. The
Music mode includes controls that allow the sound to be tailored to individual listening tastes.
VIRTUAL mode:
The Virtual mode is usually used when Pro Logic II is connected to a virtual process for speaker use. However,
there might be some virtualizers for which this mode does not produce the intended result. For those virtualizers,
Movie mode may give the best surround effect. Virtual mode is designed to be used with the virtual process
developed by Dolby Laboratories. The Pro Logic II mode should be called only “Pro Logic II” so the Virtual name
can be reserved to describe the speaker virtualization process itself.
MATRIX mode:
The Matrix mode is the same as the Music mode except that the directional enhancement logic is turned off. It
may be used to enhance mono signals by making them seem “larger.” The Matrix mode may also find use in auto
systems, where the fluctuations from poor FM stereo reception can otherwise cause disturbing surround signals
from a logic decoder. The ultimate “cure” for poor FM stereo reception may be simply to force the audio to mono.
SURROUND OFF (2CH STEREO)
Outputs the sound from the front left and right speakers and subwoofer. Standard two channel (stereo) sources
completely bypass the sound field processing. This allows you to play any source using only the front left and right
speakers and subwoofer. You can select SURROUND OFF by pressing BY-PASS on the remote control.
16
Before Operation - Amplfier Part (Continued)
Sound Mode
You can enjoy surround sound simply by selecting one
of the pre-programmed sound fields according to the
program you want to listen to.
Each time you press SOUND EFFECT button, the
sound mode is changed as the following order;
PROLOGIC →HALL 1 →HALL 2 →THEATER
Note
For the DVD, you can select only when PCM indicator is
shown in the display window.
Each time you press button, the sound mode of Pro
Logic II is changed as the following order;
PROLOGIC →MOVIE →MUSIC →VIRTUAL → MATRIX
Tip
You can select SURROUND OFF (2CH STEREO) mode by
pressing BY-PASS button.
When DVD is inserted.
You can change the sound mode of DVD (Dolby Digital, DTS,
PRO LOGIC, etc) by pressing the AUDIO button on the remote
during playback.
Although the DVD contents differ from disc to disc, the follow-
ing explains the basic operation when this feature is used.
Each time you press AUDIO button, the sound mode of DVD is
changed as the following order;
→→and
When DVD is inserted and PROLOGIC II
indicator lights.
Each time you press button, the sound mode of Pro
Logic II is changed as the following order;
PROLOGIC →MOVIE →MUSIC →VIRTUAL → MATRIX
Tip
You can set PRO LOGIC II mode to Off (2CH STEREO) by
pressing BY PASS button and the PROLOGIC II indicator dis-
appears.
For your reference
•
The DVD Receiver memorizes the last mode set-
tings for each source individually.
•
You can identify the encoding format of program
software by looking at its packaging.
- Dolby Digital discs are labeled with the logo.
- Dolby Surround encoded programs are labeled with
the logo.
- DTS Digital Surround discs are marked with DTS.
Note
When you play sound tracks with 96kHz sampling frequency,
the output signals will be converted to 48kHz (sampling fre-
quency).
Sound Level
You can
set the sound level of the desired channel.
11
Press LEVEL.
The level indicator will appear in the display window.
22
Press bb/BBto select a desired speaker to set.
Each time you press the b/Bbutton, it is changed as the
following order;
FL (Front Left) →C (Center) →FR (Front Right) →
SR (Surround Right) →SL (Surround Left) →
SW (Subwoofer) →FL (Front Left)
•On the 2 channel stereo mode, you can only select
the SW (Subwoofer).
33
Press vv/VVto adjust the sound level of the
selected channel. (-6dB ~ +6dB)
44
Repeat step 2-3 and adjust the sound level of
the other channels.
55
If setting is complete, press LEVEL.
Test Tone
This function allows you can easily adjust the sound
balance of the speakers from the listener's position.
11
Select the test tone mode by pressing TEST
TONE.
•A hiss noise comes out for 2 seconds from each speak-
ers in the following order;
FL (Front Left) →C (Center) →FR (Front Right) →
SR (Surround Right) →SL (Surround Left) →
SW (Subwoofer) →FL (Front Left)
22
You can adjust the sound level during operating
the test tone, first press LEVEL then press vv/VV
buttons, so that all speaker’s sound level is
same from the listener’s position.
•During operating the test tone, if you adjust the sound
level, it will be paused in the current speaker channel.
33
If setting is complete, press TEST TONE.
PREPARATION
17
Before Operation (Cont’d)
Delay Time Setting
In Dolby Digital or Dolby Pro Logic mode it is assumed
that the distance from the listener to each of the speak-
ers is equal. If not then setting the delay times of the
center or rear speakers the sound will be heard simulta-
neously by the listener.
The interval from the speakers to the listener. If the dis-
tance from the listener to each speakers is same, in the
Dolby Digital and Dolby Pro Logic mode the delay time
of each speakers is as following.
In Dolby Digital mode
Center delay time : 0ms
Rear delay time: 5ms
In Dolby Pro Logic mode
Center delay time : cannot setting
Rear delay time : 15-30ms
If the rear delay time is set in Dolby Digital mode, in the
Dolby Pro Logic mode the delay time will be automatical-
ly set.
The delay time is 1 msec per 30 cm.
If the center and rear speakers are further than the front
speakers from the listener, the delay time will be at min-
imum.
Surround delay time setting
If the distance of DSis equal to or longer than the DFin
the left figure, set the Surround Delay Time as 0ms.
Otherwise, change the setting according to the below.
Ex) If the distance from front speakers to the listener is
3 m and from rear speakers from the listener is 1.5 m,
in the Dolby Digital mode the rear delay time is 5 msec.
3m (DF) - 1.5m (DS) = 1.5m (B)
1.5m (B) = 150cm / 30cm = 5msec
In Dolby Pro Logic II (Surround delay time):
PROROGIC: 10 ~ 25msec
MOVIE: 10 ~ 25msec
MUSIC: 0 ~ 15msec
VIRTUAL: cannot setting
MATRIX: 0 ~ 15msec
Center delay time setting (Dolby Digital mode only)
If the distance of DF is equal to the distance of DC in
the left figure, set the Center Delay Time as 0ms.
Otherwise, change the setting according to the table
below.
Ex) If the distance from the front speakers to the listen-
er is 3m and from the center speaker to the listener is
2.4m, the center delay time is 2msec.
3m (DF) - 2.4m (DC) = 60cm (A)
60cm (A) / 30cm = 2msec
Setting the delay time in the Dolby
Digital and Dolby Pro Logic (II) mode
11
Press DELAY.
The current surround delay time appears in the dis-
play window.
You can select center delay time by pressing b/Bin
the Dolby Digital mode only.
22
Press vv/VVto change the delay time.
33
If setting is complete, press DELAY.
Notes
You can adjust the center delay time only in the Dolby Digital
mode and its delay time appears.
Center Width (MUSIC mode of Dolby Pro Logic II only)
This control allows center-channel sounds to be posi-
tioned between the center speaker and the left/right
speakers over a range of eight steps. Step “3” uses a
combination of all three front speakers to give the best
vocal imaging and most seamless soundstage presen-
tation, and is recommended for most recordings. Step
“0” places all center sound in the center speaker. Step
“7” places all center sound equally in the left/right
speakers, just as in conventional stereo.
DIMENSE (MUSIC mode of Dolby Pro Logic II only)
This control allows the user to gradually adjust the
soundfield either towards the front or the rear. This can
be useful to help achieve the desired balance from all
the speakers with certain recordings that may contain
either too much or too little spatial effect. Step “0” is the
recommended setting, which has no effect on the
sound. Steps 1, 2, and 3 gradually move the sound for-
ward, and steps –1, –2, and –3 move the sound
towards the surrounds.
PANORAMA (MUSIC mode of Dolby Pro Logic II only)
This control extends the front stereo image to include
the surround speakers for an exciting “wraparound”
effect with side-wall imaging. It is particularly effective
for recordings which have strong left- or right-channel
elements in the mix, as these are detected and accen-
tuated by the Panorama process.
L
SL SR
R
C
DCDF
DS
(A)
(B)
SW
18
On-Screen Display (OSD)
Some of these functions will be displayed every time the
VCR is operated.
❶❷❸ ❹ ❺
❻❼
❶TAPE SPEED DISPLAY
Shows the current tape speed.
❷FUNCTION DISPLAY
Indicates the function in progress.
❸HI-FI DISPLAY
Indicates when this unit is playing back tape recorded with
Hi-Fi.
❹CHANNEL DISPLAY
I
ndicates the selected channel (or LINE1, LINE2).
❺STEREO/SAP DISPLAY (MONO is not displayed)
Shows the type of audio signal received by the VCR tuner.
❻DATE DISPLAY
Shows the current date. (Month/Date/Day of the week
format)
❼CLOCK/COUNT/REMAIN DISPLAY
Shows the current time, the tape counter and remaining time
on the tape.
Each press of the SELECT/ENTER changes the TV
screen in the following sequence.
Notes
The function displays can be seen displayed on the TV
screen for 3 seconds.
The clock (or tape counter, tape remaining) mode will contin-
ue until you press SELECT/ENTER.
The tape counter and the remaining tape length indicator
appear only when a cassette is inserted. Also, the remaining
tape length indicator appears after any tape operation.
Setting the On-Screen Display
The SETUP, clock setting, and timer recordings are
accessed conveniently with On-Screen Menu Displays
that lead you through each step. The following pages
describe the On-screen selections to be set.
Menu Selection
Your VCR allows remote control adjustment of several
features.
11
Press MENU and the MAIN menu will appear.
22
Select the desired menu with v/Vbutton and
then press SELECT/ENTER.
Note
Menus remain on-screen for 3 minutes.
Before Operation - VCR Part
SET CLOCK (page 20)
TIMER RECORD (page 25)
CHANNEL SETUP (page 19)
VCR SETUP (page 19)
PLAY HI-FI CH 4
SP STEREO
JUL 5 , FRI 2:15 PM
MAIN MENU
MONTH : JANUARY
DAY : 1 TUE
YEAR : 2002
TIME : 12 : 00 AM
AUTO CLOCK SET: ON
PBS CH. : 2 TV
SELECT
TO EXIT PRESS ADJUST
SELECT
TO EXIT PRESS ENTER
SET CLOCK
TIMER RECORD
CHANNEL SETUP
VCR SETUP
PROGRAM 1
MONTH :
DAY :
START :
STOP :
CHANNEL :
SPEED :
REPEAT :
SELECT
TO EXIT PRESS ADJUST
AUTO CHANNEL SEARCH
CHANNEL SOURCE:
ADD/DEL CH:
INPUT SLECT:
SELECT
TO EXIT PRESS ADJUST
SCREEN DISPLAY: ON
LANGUAGE:
AUDIO MODE:
BROADCAST TYPE:
AUDIO OUTPUT:
One press Two presses Three presses
STOP CH 4
SP
JUL 05 , FRI 2:15 PM
STOP CH 4
SP
REM 1:56
STOP CH 4
SP
M 0:35:40
2:15 PM
After 3 seconds
REM 1:56
After 3 seconds
After 3 seconds
Press
SELECT/ENTER
Press
SELECT/ENTER
Press
SELECT/ENTER
All indicators are turned off.
M 0:35:40
19
PREPARATION
Before Operation - VCR Part (Continued)
Setting the VCR Setup Menu
11
Press MENU and the MAIN menu will appear.
22
Press vv/VVto select the VCR SETUP menu, then
press SELECT/ENTER.
The VCR SETUP menu will appear.
33
Press vv/VVto choose a desired option on the
VCR SETUP menu. Then press bb/BBto choose a
desired setting.
SCREEN DISPLAY
The on-screen display of this DVD+VCR can be turned on or off.
SCREEN DISPLAY can be switched between ON and OFF
by pressing b/B.
LANGUAGE
The on-screen programming of this DVD+VCR can be
displayed in English, Spanish, or French.
LANGUAGE can be switched among ENGLISH, SPANISH
and FRENCH by pressing b/B.
AUDIO MODE
The DVD+VCR has two separate audio playback systems, the
high quality VHS Hi-Fi system and standard NORMAL mono
system. The same audio is generally recorded on both
systems. The VHS Hi-Fi system plays on separate (left and
right) channels, and the NORMAL system plays monaural
sound. The normal track is always played so the cassette can
be played on a DVD+VCR that does not have VHS Hi-Fi.
AUDIO MODE can be switched between HI-FI and
NORMAL by pressing b/B.
BROADCAST TYPE (STEREO/SAP/MONO)
Multichannel Television Sound (MTS) carries stereo and/or
Second Audio Program (SAP) bilingual signals. Set this display to
the desired position when both MTS stereo and SAP signals are
received. When only one of the MTS signal is received, the
DVD+VCR automatically selects the corresponding receiving
mode (Stereo or SAP) regardless of the selected position. For
normal operation, the display should be in the STEREO position.
The DVD+VCR will then record a STEREO program when available,
and record a mono program IF the program is NOT IN STEREO.
For weak STEREO and/or SAP broadcasts, changing the dis-
play to mono may give clearer sound.
BROADCAST TYPE can be switched among STEREO, SAP,
and MONO by pressing b/B.
AUDIO OUTPUT (STEREO/LEFT/RIGHT)
Used during playback [when AUDIO MODE (HI-FI/NORMAL) is
in HI-FI position] for selecting the audio output signals from the
AUDIO OUT terminals (L ch and R ch), and RF.OUT.
This display setting should normally be left in the stereo posi-
tion, so that when a stereo tape is played, the stereo sound will
be heard through the left and right channels. If a mono tape is
played and the audio output is set to stereo, the same mono
sound will be heard from both left and right channels.
AUDIO OUTPUT can be switched among STEREO, LEFT,
and RIGHT by pressing b/B.
Channel Selection
This DVD+VCR is equipped with a frequency
synthesized tuner capable of receiving up to 181
channels. These include VHF channels 2-13, UHF
channels 14-69 and CATV channels 1-125.
Preparation:
Connect the DVD+VCR to the desired type of antenna or
cable TV system, as shown in Connecting Antenna/Cable TV
to DVD+VCR on page 11.
AUTO CHANNEL PROGRAMMING
11
Press MENU and the MAIN menu will appear.
22
Press vv/VVto select the CHANNEL SETUP menu,
then press SELECT/ENTER.
The CHANNEL SETUP menu will appear.
33
Press VVto choose the INPUT SELECT option,
then press bb/BBto select TUNER.
Press b/Brepeatedly to switch among TUNER, LINE1
and LINE2.
44
Press vv/VVto choose the AUTO CHANNEL SEARCH
option, then press bb/BBto find channels.
The tuner will automatically cycle through all
available channels in the area and place them in
the tuner’s memory.
55
After the AUTO CHANNEL SEARCH PROCEED-
ING is complete, make sure the CHANNEL
SOURCE is set appropriately (TV or CATV) by
pressing vv/VVand choosing the correct CHAN-
NEL SOURCE (TV or CATV) by pressing bb/BB
using the CHANNEL SETUP menu.
Remember, TV is for the air antenna reception,
CATV is for cable or wireless cable connection.
66
Press MENU to return to the TV screen.
77
Use CH/TRK (vv/VV) or CHANNEL (vv/VV) on the
front panel to cycle the DVD+VCR through the
channels in memory.
TO ADD OR ERASE CHANNELS FROM MEMORY
This feature allows you to add or erase channels from
memory manually.
1Press VVto choose the ADD/DEL CH option on the
CHANNEL SETUP menu. Press b/Bto select a
channel to add or erase.
2Press SELECT/ENTER to add or erase the channel.
Repeat steps 1 and 2 to add or erase channels.
3Press MENU to return to the TV screen.
SELECT
TO EXIT PRESS ENTER
SET CLOCK
TIMER RECORD
CHANNEL SETUP
VCR SETUP
SELECT
TO EXIT PRESS ADJUST
SCREEN DISPLAY: ON
LANGUAGE:
AUDIO MODE:
BROADCAST TYPE:
AUDIO OUTPUT:
SET CLOCK
TIMER RECORD
CHANNEL SETUP
VCR SETUP
SELECT
TO EXIT PRESS ENTER
AUTO CHANNEL SEARCH
CHANNEL SOURCE:
ADD/DEL CH:
INPUT SLECT:
20
Before Operation - VCR Part (Continued)
Setting the Clock
The DVD+VCR gives you two ways to set the time and
date: the Auto Clock Feature or manually. The Auto
Clock Feature enables the DVD+VCR to set up the clock
when the DVD+VCR is turned off.
Auto Clock Set
The Auto Clock Set feature is set to ON at the factory. In the
ON setting, the DVD+VCR looks for a channel carrying XDS
(Extended Data Services) information. XDS updates the clock
using the Coordinated Universal Time.
The Auto Clock Feature enables the DVD+VCR to set up
the clock when the DVD+VCR is turned off.
11
Press MENU and the MAIN menu will appear.
22
Press vv/VVto choose the SET CLOCK menu.
Press SELECT/ENTER and the SET CLOCK
menu will appear.
33
Press VVto choose the AUTO CLOCK SET
option.
Press bb/BBto choose ON.
The Auto Clock Set feature is set to ON at the factory. In
the ON setting, the DVD+VCR looks for a channel
carrying XDS (Extended Data Services) information. XDS
updates the clock using the Coordinated Universal Time.
44
Press VVto choose the PBS CH. option.
Press bb/BBto choose channel of PBS
broadcast.
55
Press MENU when finished.
Note
There are cases where the TV station does not send, or sends
wrong date and/or time information and the DVD+VCR sets the
incorrect time.
If this happens, we recommend that you set the clock manually.
Manual Clock Set
Example: July 5, 2002 ; 2:15 AM
11
Press MENU and the MAIN menu will appear.
22
Press vv/VVto choose the SET CLOCK menu.
Press SELECT/ENTER and the SET CLOCK
menu will appear.
33
Press bb/BBto choose the month.
44
Press VVto choose the DAY option.
Use bb/BBto choose the day.
The day of the week will display automatically.
55
Press VVto choose the YEAR option.
Use bb/BBto choose the year.
66
Press VVto choose the TIME option.
Use bb/BBto choose the time.
77
Press MENU when finished.
Note
If setting the clock manually, “AUTO CLOCK SET” must
set to “OFF”.
If set to “ON”, an incorrect date and/or time will be
entered again when the DVD+VCR is turned off.
The clock uses the 12-hour system. (Be sure to set AM
and PM correctly.)
The initial Clock Setting is JANUARY 1, 2002, 12:00 AM.
Things to know before starting
SELECT
TO EXIT PRESS ENTER
SET CLOCK
TIMER RECORD
CHANNEL SETUP
VCR SETUP
MONTH : JANUARY
DAY : 1 TUE
YEAR : 2002
TIME : 12 : 00 AM
AUTO CLOCK SET: ON
PBS CH. : 2 TV
SELECT
TO EXIT PRESS ADJUST
SELECT
TO EXIT PRESS ENTER
SET CLOCK
TIMER RECORD
CHANNEL SETUP
VCR SETUP
MONTH : JANUARY
DAY : 1 TUE
YEAR : 2002
TIME : 12 : 00 AM
AUTO CLOCK SET: ON
PBS CH. : 2 TV
SELECT
TO EXIT PRESS ADJUST
PREPARATION
21
Before Operation - DVD Part
Items
Title Number
Chapter Number
Time search
Audio language
and Digital Audio
Output mode
Subtitle language
Angle
Sound
Function (Press 33
/
44to select desired item)
Shows the current title number and total number of
titles, and skips to the desired title number.
Shows the current chapter number and total number of
chapters, and skips to the desired chapter number.
Shows the elapsed playing time, and
searches the point by the elapsed time directly.
Shows the current audio soundtrack language,
encoding method, and channel number, and
changes the setting.
Shows the current subtitles language, and
changes the setting.
Shows the current angle number and total number of
angles, and changes the angle number.
Shows the current sound mode, and
changes the setting.
Selection Method
11
/
22
,or
Numbers, SELECT/ENTER
11
/
22
,or
Numbers , SELECT/ENTER
Numbers , SELECT/ENTER
11
/
22
11
/
22
11
/
22
11
/
22
1/3
1/12
0:16:57
1 ENG
D
6 CH
OFF
1/1
NORM.
Items
Track Number
Time
Audio Channel
Sound
Function (Press 33
/
44to select desired item)
Shows the current track number, total number of tracks
and PBC On mode, and skip to the desired track number.
Shows the elapsed playing time (Display only)
Shows the audio channel, and
changes the audio channel.
Shows the current sound mode, and
changes the setting.
Selection Method
11
/
22
,or
Numeric, SELECT/ENTER
–
11
/
22
11
/
22
1/4
0:16:57
STER.
NORM.
VCD2.0 VCD1.1
DVD
Caution:
Before using the remote control, press the DVD or TV
button to select the device to be operated.
General Explanation
This manual gives basic instructions for operating the
DVD+VCR. Some DVDs require specific operation or
allow only limited operation during playback. When this
occurs, the symbol appears on the TV screen, indi-
cating that the operation is not permitted by the
DVD+VCR or is not available on the disc.
On-Screen Display
General playback status can be displayed on the TV
screen. Some items can be changed on the menu.
On-screen display operation
11
Press DISPLAY during playback.
22
Press 33or 44to select an item.
The selected item will be highlighted.
33
Press 11or 22to change the setting of an item.
The number buttons can be also be used for setting
numbers (e.g., title number). For some functions,
press SELECT/ENTER to execute the setting.
Temporary Feedback Field Icons
Repeat Title
Repeat Chapter
Repeat Track (non-PBC Video CDs only)
Repeat All Tracks (non-PBC Video CDs only)
Repeat A-B
Repeat Off
Resume play from this point
Action prohibited or not available
Notes
Some discs may not provide all of the features on the
on-screen display example shown below.
If no button is pressed for 10 seconds, the on-screen
display disappears.
OFF
A B
ALL
TRACK
CHAPT
TITLE
22
Before Operation - DVD Part (Continued)
Initial Settings
You can set your own Personal Preferences on the
player.
Initial Settings General Operation
11
Press SETUP.
The setup menu appears.
22
Press 33/44to select the desired item.
The screen will show the current setting for the
selected item, as well as alternate setting(s).
33
While the desired item is selected, press 22, then
33/44to select the desired setting.
44
Press SELECT/ENTER to confirm your selection.
Some items require additional steps.
55
Press SETUP, RETURN, or PLAY (HH) to exit the
setup menu.
Language
Disc Language
Select a language for the disc’s Menu, Audio, and Subtitle.
Original : The original language set for the disc is selected.
Other : To select another language, press number buttons to
enter the corresponding 4-digit number according to the lan-
guage code list on page 39. If you enter the wrong language
code, press CLEAR.
Menu Language
Select a language for the setup menu. This is the menu
you see when you press SETUP.
PBC
Set Playback Control (PBC) to On or Off.
On: Video CDs with PBC are played according to the PBC.
Off: Video CDs with PBC are played the same way as Audio
CDs.
TV Aspect
4:3 Letterbox: Select when a standard 4:3 TV is con-
nected. Displays theatrical images with masking bars
above and below the picture.
4:3 Panscan: Select when a standard 4:3 TV is con-
nected. Displays pictures cropped to fill your TV screen.
Both sides of the picture are cut off.
16:9 Wide: Select when a 16:9 wide TV is connected.
Progressive Scan
Progressive Scan Video provides the highest quality
pictures with less flickering.
If you are using the COMPONENT VIDEO OUT/
PROGRESSIVE SCAN jacks, but are connecting the
DVD Player to a standard (analog) television, set
Progressive Scan to Off.
If you are using the Component Video jacks for
connection to a TV or monitor that is compatible with a
progressive scan signal, set Progressive Scan to On.
Notes
–Progressive Scan only works when the VIDEO OUT-
PUT switch on the rear panel is set to COMPO-
NENT/PROGRESSIVE SCAN.
Caution
Once the setting for progressive scan output is entered,
an image will only be visible on a progressive scan
compatible TV or monitor. If you set Progressive Scan
to On in error, you must reset the unit. Press STOP (x)
to stop any disc that is playing. Next, press STOP (x)
again and hold it for five seconds before releasing it.
The video output will be restored to the standard set-
ting, and a picture will once again be visible on a con-
ventional analog TV or monitor.
DVD
DVD
DVD
Disc Subtitle
Disc Menu
Rating
Country Code
TV Aspect
Menu Language
Progressive Scan
PBC
Disc Audio Original
Spanish
English
Chinese
Polish
Hungarian
Russian
French
German
Italian
Other — — — —
Disc Subtitle
Disc Menu
Rating
Country Code
TV Aspect
Menu Language
Disc Audio English
Spanish
French
Disc Subtitle
Disc Menu
Rating
Country Code
TV Aspect
Disc Audio 4:3 Letterbox
4:3 Panscan
16:9 Wide
Disc Subtitle
Disc Menu
Rating
Country Code
TV Aspect
Menu Language
Progressive Scan
Disc Audio Off
On
Disc Subtitle
Disc Menu
Rating
Country Code
TV Aspect
Menu Language
Progressive Scan
PBC
Disc Audio Off
On
PREPARATION
23
Before Operation - DVD Part (Continued)
Parental Control
Rating
Movies on DVDs may contain scenes not suitable for
children. Therefore, discs may contain Parental Control
information that applies to the complete disc or to
certain scenes on the disc. These scenes are rated
from 1 to 8, and alternatively, more suitable scenes are
available for selection on some discs. Ratings are
country-dependent. The Parental Control feature allows
you to prevent discs from being played by your children
or to have certain discs played with alternative scenes.
11
Select “Rating” on the Setup menu using the
33 and 44buttons.
22
While “Rating” is selected, press 22.
33
When you have not entered a password yet.
Enter a 4-digit password using the numbered but-
tons to create a personal 4-digit security password,
then press SELECT/ENTER. Enter the 4-digit pass-
word again and press SELECT/ENTER to verify.
When you have already entered a password;
Enter a 4-digit password using the numbered but-
tons to confirm the personal 4-digit security pass-
word, then press SELECT/ENTER.
If you make a mistake before pressing SELECT/ENTER,
press CLEAR and enter 4-digit security password again.
44
Select a rating from 1 to 8 using the 33/44but-
tons. One (1) has the least playback restrictions.
Eight (8) has the most playback restrictions.
Unlock: If you select Unlock, Parental Control is
not active. The disc will play in full.
Ratings 1 to 8: Some discs contain scenes not
suitable for children. If you set a rating for the play-
er, all disc scenes with the same rating or lower will
be played. Higher rated scenes will not be played
unless an alternative scene is available on the disc.
The alternative must have the same rating or a
lower one. If no suitable alternative is found, play-
back will stop. You must enter the 4-digit password
or change the rating level in order to play the disc.
55
Press SELECT/ENTER to confirm your rating
selection, then press SETUP to exit the menu.
Country Code
Enter the code of a country/area whose standards were
used to rate the DVD video disc, referring to the list
(See “Country Code List”, page 40.).
11
Select Country Code using the 33/44buttons on
the setup menu.
22
While Country Code is selected, press 2.
33
Follow step 3 of “Rating” on left.
44
Select the first character using the 33/44buttons.
55
Shift the cursor using 11/2buttons and select
the second character using 33/44buttons.
66
Press SELECT/ENTER to confirm your country
code selection, then press SETUP to exit the
menu.
Note
Confirmation of the 4-digit password is necessary when
the code is changed (see “Changing the 4-digit code”
below ).
Changing the 4-digit code
1Follow Steps 1-2 as shown above to the left (Rating).
2Enter the old code, then press SELECT/ENTER.
3Select Change using the 33/44buttons then press
SELECT/ENTER.
4Enter the new 4-digit code, then press
SELECT/ENTER.
5Enter exactly the same code a second time and veri-
fy by pressing SELECT/ENTER.
6Press SETUP to exit the menu.
If you forget your 4-digit code
If you forget your password, to clear the current pass-
word, follow the procedure below.
1Press SETUP to display the setup menu.
2Use the Number buttons to enter the 6-digit number
“210499”.
The 4-digit password is cleared. “P CLr” appears on the dis-
play. The message will appear if the disc tray is closed. It
will be on the display until you try another feature.
3
Enter a new code as shown above to the left (Rating).
DVD
DVD
Disc Subtitle
Disc Menu
Rating
Country Code
TV Aspect
Menu Language
Progressive Scan
Digital Audio Output
5.1 Speaker Setup
Others
Disc Audio Code Set
U S
Disc Subtitle
Disc Menu
Rating
Country Code
TV Aspect
Menu Language
Progressive Scan
Digital Audio Output
5.1 Speaker Setup
Others
Disc Audio 8
7
6
5
4
3
2
1
Unlock
Change
24
Operation with tape - VCR Part
Normal Playback
Preparation:
Turn on the TV.
Tune the TV to the DVD+VCR output channel (CH 3 or 4) or
set the TV’s source selector to VIDEO.
If a direct VIDEO/AUDIO connection is made between the
DVD+VCR and the TV, set the TV’s source selector to VIDEO.
Set the Output Source to VCR as shown in Setting the
Output Source on page 6.
11
Insert a prerecorded video cassette.
The indicator will light and the DVD+VCR will
power-up automatically.
Make sure that the TIMER indicator in the display
window is not lighted. If it is, press POWER once.
If a tape without a safety tab is inserted, the unit will
start playback automatically.
22
Press PLAY (HH) once.
PLAY appears on the TV screen .
It is not necessary to select the tape speed for play-
back. It will be automatically selected by the DVD+VCR.
In playback, the TV/VCR selector switches to VCR
mode automatically.
33
Press STOP (xx) to stop playback.
STOP appears on the TV screen.
If the tape reaches the end before STOP (x) is
pressed, the DVD+VCR will automatically stop, rewind,
eject, and it will turn itself off.
Tracking Control
Auto Tracking
The automatic tracking function adjusts the picture to
remove snow or streaks.
The AUTO TRACKING function works in the following
cases:
A tape is played back for the first time.
Tape speed (SP, LP, EP) changes.
Streaks or snow appear because of scratches on the tape.
Manual Tracking
If noise appears on the screen during playback, press
either
CH/TRK (vv/VV)
on the remote control or
CHANNEL (vv/VV) on the front panel until the noise on
the screen is reduced.
In case of vertical jitter, adjust these controls very carefully.
Tracking is automatically reset to normal when the tape is
ejected or the power cord is unplugged for more than 3 sec-
onds.
Special Effect Playbacks
Special effects playback notes
Horizontal lines (noise bars) will appear on the TV screen. This
is normal.
The audio is automatically muted during special effect modes,
so there is no sound during search.
During the high-speed picture search modes, a short period is
needed to stabilize tape speed when re-entering the PLAY
mode. Slight interference may be observed during this period.
Search
This function lets you quickly and visually search for a
desired tape section in either direction: forward and
reverse.
1Press BACKWARD (.) or FORWARD (>)
during playback.
The DVD+VCR will be activated in the SEARCH
mode.
If the DVD+VCR is left in the SEARCH mode for more
than 3 minutes, the DVD+VCR will automatically enter the
PLAY mode, to protect the tape and video heads.
2To return to playback, press PLAY (H).
Still Picture and Frame-by-Frame Playback
1Press PAUSE/STEP (X) during playback.
Still picture will appear on the TV screen.
If a still picture vibrates vertically, stabilize it by pressing
CH/TRK (v/V)
on the remote control.
If the DVD+VCR is left in the STILL mode for more than 5
minutes, the DVD+VCR will automatically enter the STOP
mode to protect the tape and video heads.
2Press PAUSE/STEP (X) repeatedly to advance the
video picture one frame at a time while viewing a still
picture.
3To return to playback, press PLAY (H).
Slow Motion
1While in still mode, press FORWARD (>).
The tape will be played back at a speed 1/19 times
slower than the normal speed.
During slow playback, use CH/TRK (v/V) on the Remote
Control to minimize noise bands.
If slow motion mode continues for more than 30 seconds,
the DVD+VCR will automatically change to playback
mode.
2To return to playback, press PLAY (H).
CM SKIP (Commercial Skip)
This is useful for skipping commercials or short program
segments.
1Press CM SKIP during the playback mode.
The tape will fast forward picture search through 30
seconds of recording.
The skipping time can be extended by pressing CM SKIP.
Subsequent presses result in advancing the fast forward
picture search time by 30-second increments (maximum 2
minutes).
2When the search is completed, the DVD+VCR will go
into playback mode automatically.
OPERATION
25
Operation with tape - VCR Part (Continued)
Normal Recording
Preparation:
Turn on the power of both the DVD+VCR and TV.
Tune the TV to the DVD+VCR output channel (CH 3 or 4) or
set the TV’s source selector to VIDEO.
If a direct VIDEO/AUDIO connection is made between the
DVD+VCR and the TV, set the TV’s source selector to
VIDEO.
11
Insert a video cassette that the safety tab intact.
22
Select the desired channel by using CH/TRK
(vv/VV).
If you are recording from another source via audio/video
input jacks (at the Rear or Front panel), select the
LINE1 or LINE2 by pressing INPUT.
33
Set the desired recording speed (SP or EP) by
pressing SPEED.
This DVD+VCR is not designed to record in LP mode.
44
Set the MTS mode as desired (See page 19, 28).
55
Press REC/ITR (zz) once.
Recording will start. (The REC indicator will light in
the display window.)
If a cassette with no safety tab is loaded, the cassette
will be ejected automatically.
66
Press STOP (xx) to stop recording.
If the tape reaches the end before STOP (x) is pressed,
the DVD+VCR will automatically stop, rewind, eject, and
turn itself off.
To pause the recording
1Press PAUSE/STEP (X) to pause the tape during
recording.
The REC indicator will flash in the display window.
2When you want to continue recording, press
PAUSE/STEP (X) or press REC/ITR (zz).
After 5 minutes in pause mode, the tape will be stopped
automatically to protect the tape and the video heads.
To record one TV program while
watching another
1Press TV/VCR to select the TV mode during record-
ing.
The VCR indicator disappears.
2Using the TV, select the channel to be viewed.
Tips
Always use PAUSE/STEP (X) for best results when making
changes during recording.
For example: To change channels during recording, first press
PAUSE/STEP (X) to put the unit in pause mode. Then select
the desired channel on the DVD+VCR, and press
PAUSE/STEP (X) again to resume recording.
Timer Recording
This DVD+VCR can be programmed to record up to 8
programs within a period of 1 year. For unattended
recording, the timer needs to know the channels to be
recorded and the starting and ending times.
Preparation:
Turn on the power of both the DVD+VCR and the TV.
Be sure the TV is set to the DVD+VCR output channel (3 or 4).
Make sure the CHANNEL SOURCE in the CHANNEL
SETUP menu is set appropriately (TV or CATV).
11
Press MENU and the MAIN menu will appear.
22
Use vv/VVto choose the TIMER RECORD menu.
33
Press SELECT/ENTER to go to the TIMER
RECORD menu.
The TIMER RECORD menu will appear.
If all programs have already been entered, MAX
NUMBER OF EVENTS SCHEDULED message will
appear for a moment and then PROGRAM 1 will
appear on the TV screen.
44
Use bb/BBto choose the PROGRAM No. (1-8).
55
Use VVto choose the MONTH option.
Use bb/BBto choose the desired month.
66
Use VVto choose the DAY option.
Use bb/BBto choose the desired day.
77
Use VVto choose the START option.
Use bb/BBto choose the desired start time.
88
Use VVto choose the STOP option.
Use bb/BBto choose the desired stop time.
99
Use VVto choose the CHANNEL option.
Use bb/BBto choose the desired channel
(Channel, LINE1 or LINE2).
Cable Users: If you have CABLE TV and used Cable Box
in Connecting Antenna/Cable TV to DVD+VCR (page 11),
using a cable box converter, you must set the channel in
this step to match the cable box output channel (usually
CH 3 or 4). Change channels on the cable box instead of
with the DVD+VCR.
SELECT
TO EXIT PRESS ENTER
SET CLOCK
TIMER RECORD
CHANNEL SETUP
VCR SETUP
PROGRAM 1
MONTH :
DAY :
START :
STOP :
CHANNEL :
SPEED :
REPEAT :
SELECT
TO EXIT PRESS ADJUST
If you try to set the program timer before setting the clock,
PLEASE SET THE CLOCK appears for a moment and
then SET CLOCK menu appears on the TV screen. Set the
time and date before proceeding.
Make sure a tape is in the DVD+VCR and the safety tab is
in place or the tape will be automatically ejected.
Things to know before starting
26
Operation with tape - VCR Part (Continued)
1100
Use VVto choose theSPEED option.
Use bb/BBto choose the desired recording
speed (AUTO, SP or EP).
AUTO mode determines how much tape is left and
switches speed from SP to EP, if necessary, to com-
plete recording the program. There will be some pic-
ture and sound distortion at the point of the speed
change.
1111
Use VVto choose the REPEAT option.
Use bb/BBto choose the desired repeat (ONCE,
WEEKLY, or DAILY).
ONCE event....for recording up to 8 programs on a
single day or over the days within a period of 1 year.
WEEKLY event....for recording up to 8 programs on a
certain day of every week.
DAILY event....for recording up to 8 programs at the
same time(s) Monday through Friday.
Tip
If the input data is wrong, use vvto select the data
and correct it using bb/BB.
1122
Press MENU, the program will be memorized
at the DVD+VCR.
If the program preset time is past, the EVENT
SCHEDULED IN THE PAST message will appear on
the TV screen. Return to the incorrect program and
program it with the correct time.
If you enter a past date, the timer recording will be
performed on that date of the next year.
Additional programs may be entered by repeating
steps 1-12.
Cable Users: If your cable hookup is via a TV convert-
er box, you can program multiple recordings only on
the converter box output channel. This is because the
converter determines what channel you view through
your DVD+VCR.
1133
Turn the DVD+VCR off for timer recording to
take place.
Tip
If you are finished programming and you want to set the
DVD+VCR to record the programs you have entered.
A) MAKE SURE YOU HAVE INSERTED A TAPE INTO THE
DVD+VCR. B) YOU MUST TURN OFF THE DVD+VCR
BEFORE IT WILL RECORD ANY TIMER PROGRAMS.
(TIMER indicator lights). The DVD+VCR is now set to record
the preset programs.
Note
If the power fails or the DVD+VCR is unplugged from the AC
outlet, the correct clock time and timer settings are kept in
memory for approximately 3 seconds. After 3 seconds, the
clock and program timer must be reset when power is
restored. Reset the clock according to instructions.
Checking (Erasing) the Timer Program
Programming can be checked whenever the DVD+VCR
is turned on.
1Press MENU and the MAIN menu will appear.
2Use v/Vto choose the TIMER RECORD menu.
Press SELECT/ENTER and the PROGRAM menu
will appear.
3Use b/Bto select a program you want to check or
erase. If you want to erase the program, press
CLEAR.
4Press MENU to return to the TV screen.
Program Priority
If the recording start and end
times of preset programs
overlap on the same day
(see the example and dia-
gram left), program number 2
will not be recorded until pro-
gram number 1 is finished.
The first part of program number 2 will not be recorded.
The same thing will happen to program number 3.
PROGRAM 1
MONTH : JULY
DAY : 6 SAT
START : 6 : 00 PM
STOP : 7 : 30 PM
CHANNEL : 4 TV
SPEED : SP
REPEAT : ONCE
SELECT
TO EXIT PRESS ADJUST
SELECT
TO EXIT PRESS ENTER
SET CLOCK
TIMER RECORD
CHANNEL SETUP
VCR SETUP
PROGRAM 1
MONTH : JULY
DAY : 6 SAT
START : 6 : 00 PM
STOP : 7 : 30 PM
CHANNEL : 4 TV
SPEED : SP
REPEAT : ONCE
TO EXIT PRESS
TO ERASE PRESS
OPERATION
27
Operation with tape - VCR Part (Continued)
Instant Timer Recording (One-Touch Record)
Instant Timer Recording allows you to make a recording
easily of a preset length without using the program
timer.
Preparation:
Turn on the power of both the DVD+VCR and the TV.
Be sure the TV is tuned to the DVD+VCR output channel (3 or 4).
If a direct VIDEO/AUDIO connection is made between the
DVD+VCR and the TV, set the TV’s source selector to VIDEO.
11
Insert a video cassette with the safety tab intact.
22
Select the desired channel by using CH/TRK
(vv/VV) or number (0-9).
The channel number appears on the TV screen.
If you are recording from another source via audio/video
input jacks (at the Rear or Front panel), select the
LINE1 or LINE2.
33
Set the desired recording speed (SP or EP) by
pressing SPEED.
The tape speed will appear on the TV screen.
44
Press REC/ITR (zz) twice.
The menu as illustrated, will appear on the TV screen.
Recording will start. (The TIMER indicator will light)
55
Press REC/ITR (zz) repeatedly to select the
recording time length.
At the end of the recording, the DVD+VCR will stop
recording and shut off.
During Instant Timer Recording, changing the channel
on the DVD+VCR will not be possible.
You can stop the recording by pressing STOP (x).
INSTANT TIMER RECORD (ONE-TOUCH RECORD) MENU
Checking the Recording Time
Press REC/ITR (z) once to check the recording time.
The recalled setting will automatically return to the TV
screen after 6 seconds.
To extend the Recording Time
The recording time can be extended anytime by press-
ing REC/ITR (z).
Subsequent presses result in advancing the recording
time by 30-minute increments.
Notes
If you press PAUSE/STEP (X) during instant timer record-
ing, the DVD+VCR will enter the recording pause mode.
Instant timer recording is cancelled.
If the DVD+VCR is set to “0H00M”, the DVD+VCR goes to
normal recording mode.
Dubbing and Editing
If you wish to edit or dub your camcorder (or another
VCR) recordings to this DVD+VCR, the rear (or Front)
panel mounted Audio and Video (A/V) input jacks
make the connections quick and easy. These direct
A/V jacks will also provide better picture results than
using the RF jack on the rear panel.
11
Connect the camcorder’s (or another VCR’s) A/V
outputs to your DVD+VCR as illustrated on page 14.
22
Set the input channel “LINE2”. (press INPUT
twice to select LINE2.)
If you have connected your DVD+VCR to the A/V input
jacks on the rear of DVD+VCR, you should select the
input channel LINE1 by pressing INPUT.
33
Play the tape in the camcorder (or another
VCR). If you have a TV attached to your
DVD+VCR, you can see the video playing.
44
When you desire recording to begin, press
DVD+VCR’s REC/ITR (zz) once to start.
Note
Before recording, please confirm the recording start position.
Copying from DVD to VCR
This unit allows you to copy the contents of a DVD to a
VHS tape with a press of the COPY button.
Note
If the DVD you are attempting to copy is copy protect-
ed, you will not be able to copy the disc. It is not per-
mitted to copy Macrovision encoded DVDs. “LOCK” is
displayed in the display window.
11
Insert Disc
Insert the disc you wish to copy in the DVD deck
and close the disc tray.
22
Insert VHS Tape
Insert a blank VHS video tape into the VCR deck.
33
Press the COPY button on the unit front panel.
The DVD will go into Play mode and the VCR will
go into Record mode.
If the DVD disc menu appears, you may need to press
PLAY (HH) manually to begin copying.
44
Stop the Copy Process
When the DVD is finished playing, press the VCR
on the remote control and then press STOP (x) to
end the copy.
You must stop the Copy process manually when the
DVD movie ends, or the unit may replay and record
over and over again.
Note
When you stop the DVD playback during copying, the record-
ing on VCR is stopped automatically.
ONE-TOUCH RECORD
CHANNEL 2
SPEED SP
START NOW
LENGTH 0H30M
0H30M ..... 9H00M ➝0H00M
Length Display
(each additional press of
REC/ITR (zz) increases recording
time 30 minutes)
28
Operation with tape - VCR Part (Continued)
VHS Hi-Fi Stereo System/
MTS Broadcast
This DVD+VCR is equipped with the VHS Hi-Fi audio
sound system for recording and playback. The informa-
tion below gives a brief description of Hi-Fi audio and
how to record and play a tape in the Hi-Fi audio mode.
Playback with Hi-Fi Stereo Audio Sound
A stereo TV with AUDIO/VIDEO input jacks or a stereo
audio system is required for true stereo playback. To
experience the full and rich stereo sound available with
Hi-Fi recorded tapes, we recommend the connection of
this unit to a home stereo audio system.
11
Set the AUDIO MODE option to HI-FI on the VCR
SETUP menu .
22
Set the AUDIO OUTPUT option to STEREO
position.
(STEREO) POSITION: The left channel sound (L) is
heard from the left speaker and the right channel sound
(R) is heard from the right speaker.
(LEFT) POSITION: The left channel sound (L) is heard
from both speakers.
(RIGHT) POSITION: The right channel sound (R) is heard
from both speakers.
33
Insert a cassette and press PLAY (HH).
Adjust volume at your stereo system.
MTS (Multi-Channel TV Sound)
This DVD+VCR will decode MTS stereo and bilingual
(SAP) off-the-air broadcast sound signals. It also
decodes stereo TV sound from local cable companies,
as long as they operate on assigned cable frequencies
and use the EIA-recommended MTS stereo/bilingual TV
sound system.
Multichannel TV Sound Indicator (MTS)
Shows Onscreen as illustrated below when
SELECT/ENTER is pressed.
One or both of the indicators will light, depending on the
MTS broadcast.
If only STEREO appears on the TV screen.
The DVD+VCR can record in stereo onto the VHS Hi-Fi audio
tracks when the BROADCAST TYPE option is in the STEREO
position. The DVD+VCR will also record mono audio onto the
mono audio track.
If only SAP appears on the TV screen.
Set the BROADCAST TYPE option to SAP.
If STEREO/SAP appears on the TV screen
Use the BROADCAST TYPE option to select the desired
recording mode (STEREO or SAP).
SAP (Second Audio Program) Recording
Some stations transmit a Second Audio Program, which
is used for a second language or additional information.
When the station broadcasts a Second Audio Program,
follow the procedure below to record the SAP.
11
Insert a video cassette with the safety tab intact.
22
Set the BROADCAST TYPE option to SAP (VCR
SETUP menu).
Do this if only the SAP appears on the TV screen or you
know the program will use the SAP.
33
Set the desired recording speed (SP or EP) by
pressing SPEED.
44
Select the desired channel. The SAP should
appear on the TV screen.
55
Press REC/ITR (zz) once
You are now recording the program you see and hear on the
TV.
66
Press STOP (xx) to stop recording.
SELECT
TO EXIT PRESS ADJUST
SCREEN DISPLAY:
LANGUAGE:
AUDIO MODE: HI-FI
BROADCAST TYPE:
AUDIO OUTPUT:
SELECT
TO EXIT PRESS ADJUST
SCREEN DISPLAY:
LANGUAGE:
AUDIO MODE:
BROADCAST TYPE:
AUDIO OUTPUT: STEREO
SELECT
TO EXIT PRESS ADJUST
SCREEN DISPLAY:
LANGUAGE:
AUDIO MODE:
BROADCAST TYPE: SAP
AUDIO OUTPUT:
STEREO
Lights up when a stereo broadcast
is being received.
SAP
Lights up when a SAP BILINGUAL
broadcast is being received.
TV screen
CH 4
STEREO/SAP
OPERATION
29
Operation with tape - VCR Part (Continued)
Tape Counter Memory Feature
Real-Time Counter
Shows length of tape run in hours, minutes, and sec-
onds. Press CLK/CNT to select the real-time counter
display.
Every press of CLK/CNT changes the TV screen as
illustrated below.
Counter changes to “M 0:00:00” when the cassette is
ejected.
The real-time counter does not operate if nothing is record-
ed on the tape.
The real-time counter will not work unless a tape is
inserted.
Counter Memory Function
This is useful if there is a section of tape you want to
view immediately after recording or if you want to return
to the same point several times.
11
Begin recording or playing a tape.
22
Press CLK/CNT repeatedly to display the real-
time counter on the TV screen.
33
At the point that you want to locate later, reset
the real-time counter to “M 0:00:00” by pressing
CLEAR.
44
Continue to play or record.
55
Press STOP (xx) when recording or playback fin-
ishes.
66
Press BACKWARD (..).
The tape automatically stops when the tape counter
returns to about “M 0:00:00”.
Tape Remaining
This function allows the time of the remaining tape to be
displayed during recording or playback.
Press CLK/CNT until the REM indicator displays on the
TV screen during recording or playback.
Note
The remaining tape length indicator may not be displayed
correctly depending on the condition of the tape and the kind of
the tape (T-140, T-160, or T-210 etc)
Additional Information
In manual recording, Timer recording, Instant Timer
Recording, playback, or fast forward modes, the DVD+VCR
automatically starts rewinding the tape at the end of the
tape. The cassette will stop at the beginning of the tape and
be ejected, and the DVD+VCR will turn itself off.
After you have finished using the DVD+VCR, rewind, eject,
and remove the cassette. Place the cassette in its protec-
tive sleeve to protect it from dust. It is not necessary to
rewind the cassette before removing it, but if you do, it will
be ready to play or record the next time you use it.
Be sure the DVD+VCR Channel Selector is on the correct
channel you wish to record. The channel that is being
recorded can always be checked by setting the television
on the DVD+VCR channel (3 or 4) and pressing the
TV/VCR selector to turn the DVD+VCR’s VCR indicator on.
Do not attempt to hook up more than one television set to
the DVD+VCR for either recording or playback.
Auto Play System
This DVD+VCR features automatic playback.
Load a cassette (with the safety tab removed).
The power turns on automatically and playback begins.
At the end of the tape, the DVD+VCR stops, then rewinds.
The cassette is ejected after rewinding and the unit turns
itself off automatically.
2:15 AM M 0:05:25 REM 1:07
CLOCK COUNTER REMAINING TIME
LOAD
TAPE
AUTO
REWIND
AUTO
POWER
OFF
AUTO
EJECT
AUTO
PLAY
30
Operation with DVD and Video CD
Playing a DVD and Video CD
Playback Setup
Turn on the TV and select the video input source con-
nected to the DVD player.
Audio system: Turn on the audio system
and select the input source connected to the
DVD player.
11
Press OPEN/CLOSE to open the disc tray.
22
Load your chosen disc in the tray, with the label
facing up.
When a double-sided DVD is inserted, make sure
the side you want to play is facing up.
33
Press OPEN/CLOSE to close the tray.
READING appears on the TV screen, and playback
starts automatically. If playback does not start,
press PLAY.
In some cases, the disc menu might appear
instead.
If a menu screen is displayed
The menu screen may be displayed first after loading a
DVD or Video CD which contains a menu.
Use the 11 22 33 44 buttons to select the title/chapter
you want to view, then press SELECT/ENTER to start
playback.
Press TITLE or MENU to return to the menu screen.
Use the number buttons to select the track you want
to view.
Press RETURN to return to the menu screen.
Menu setting and the exact operating procedures for
using the menu may differ depending on the disc.
Follow the instructions on the each menu screen.
You also may set PBC to Off under setup. See page
22.
Notes
–If Parental Control is set and the disc is not within the
Rating settings (not authorized), the 4-digit code must
be entered and/or the disc must be authorized (see
“Parental Control”, on page 23).
–DVDs may have a region code.
–Your player will not play discs that have a region code
different from your player. The region code for this
player is 1 (one).
General Features
Note
Unless stated otherwise, all operations
described use the remote control. Some
features may also be available on the Setup menu.
Moving to another TITLE
When a disc has more than one title, you can move to
another title as follows:
Press DISPLAY when playback is stopped, then
press the appropriate numbered button (0-9) to
select a title number.
Moving to another CHAPTER/TRACK
When a title on a disc has more than one chapter or a
disc has more than one track, you can move to another
chapter/track as follows:
Press SKIP/SCAN .or >briefly during
playback to select the next chapter/track or to return
to the beginning of the current chapter/track.
Press .twice briefly to step back to the previous
chapter/track.
To go directly to any chapter during DVD playback,
press DISPLAY. Then, press 33/44to select C
(chapter) (or for a Video CD, select T for track). Then,
enter the chapter/track number using the numbered
buttons (0-9).
Note
For two-digit numbers, press the buttons in rapid
succession.
Slow Motion
1Press SLOW tor Tduring playback.
The player will enter SLOW mode.
2Use the SLOW tor Tto select the required speed:
t 1/16, t 1/8, t 1/4 or t 1/2 (backward), or T
1/16, T1/8, T1/4 or T1/2 (forward).
3To exit slow motion mode, press PLAY.
Note
Slow motion playback in reverse is not applicable for
Video CD.
VCD1.1VCD2.0
DVD
1/3
1/12
VCD1.1
DVD
1/3
DVD
VCD2.0
DVD
VCD1.1VCD2.0
DVD
31
Operation with DVD and Video CD - DVD Part
General Features (continued)
Still Picture and Frame-by-frame playback
1Press PAUSE/STEP (X) during playback.
The player will now go into PAUSE mode.
2
You can advance the picture frame-by-frame by pressing
PAUSE/STEP (X)
repeatedly on the remote control.
Search
1Press and hold BACKWARD (.) or FORWARD
(>) for about two seconds during playback.
The player will now go into SEARCH mode.
2Press and hold BACKWARD (.) or FORWARD
(>) repeatedly to select the required speed: mX2,
mX4, mX16, mX100 (backward) or MX2,
MX4, MX16, MX100 (forward).
With a Video CD, the Search speed changes: mX2,
mX4, mX8 (backward) or MX2, MX4, MX8
(forward).
3To exit SEARCH mode, press PLAY (H).
Random
1Press RANDOM during playback or in stop mode.
The unit automatically begins Random Playback and
“RAND.” appears on the display window.
2To return to normal playback, press RANDOM until
“RAND.” disappears on the display window.
Tips
By pressing BACKWARD (.) or FORWARD (>)
during Random playback, the unit selects another title
(track) and resumes Random playback.
Note
This function only works with DVD Karaoke discs and
video CD without PBC.
Repeat
DVD Video Discs - Repeat Chapter/Title/Off
1To repeat the currently playing chapter, press
REPEAT.
The Repeat Chapter icon appears on the TV screen.
2To repeat the title currently playing, press REPEAT a
second time.
The Repeat Title icon appears on the TV screen.
3To exit Repeat mode, press REPEAT a third time.
The Repeat Off icon appears on the TV screen.
Video CDs - Repeat Track/All/Off
1To repeat the track currently playing, press REPEAT.
The Repeat Track icon appears on the TV screen.
2To repeat the disc currently playing, press REPEAT a
second time.
The Repeat All icon appears on the TV screen.
3To exit Repeat mode, press REPEAT a third time.
The Repeat Off icon appears on the TV screen.
Note
On a Video CD with PBC, you must set PBC to Off on the
setup menu to use the Repeat function. See page 22.
Repeat A-B
To repeat a sequence in a title:
1Press A-B at your chosen starting point.
A- appears briefly on the TV screen.
2Press A-B again at your chosen end point.
A-B appears briefly on the TV screen, and the repeat sequence
begins (a-b repeat appears on the player’s display).
3To cancel the sequence, press A-B.
Time Search
The Time Search function allows you to start playing at
any chosen time on the disc.
1Press DISPLAY during playback. The on-screen dis-
play appears on the screen.
The Time Search box shows the elapsed playing time of the
current disc.
2Within 10 seconds, press 33/44to select the Time
Search icon in the on-screen display.
The “-:--:--” appears in the Time Search box.
3Within 10 seconds, use the number buttons to enter
the required start time. Enter hours, minutes, and sec-
onds from left to right in the box.
If you enter the wrong numbers, press CLEAR to remove the
numbers you entered. Then enter the correct numbers.
4Within 10 seconds, press SELECT/ENTER to confirm
the start time.
Playback starts from the selected time on the disc. If you enter
an invalid time, playback will continue from the current point.
3D Surround
This unit can produce a 3D Surround effect, which
simulates multi-channel audio playback from two
conventional stereo speakers, instead of the five or
more speakers normally required to listen to multi-
channel audio from a home theater system.
1Press SOUND to select “3D SUR” during playback.
2To turn off the 3D Surround effect, press SOUND
again to select “NORM”.
3D SUR
NORM.
DVD
-:--:--
0:16:57
DVD
OFF
A B
A *
VCD1.1VCD2.0
DVD
OFF
ALL
TRACK
TITLE
CHAPT
VCD1.1VCD2.0
DVD
VCD1.1
Karaoke DVD
VCD1.1VCD2.0
DVD
VCD1.1VCD2.0
DVD
OPERATION
32
Operation with DVD and Video CD - DVD Part (Continued)
General Features (continued)
Zoom
The Zoom function allows you to enlarge the video
image and to move through the enlarged image.
1Press ZOOM during playback or still playback to acti-
vate the Zoom function.
If you press ZOOM repeatedly, the magnification level
increases up to six times.
2Use the 11223344buttons to move through the
zoomed picture.
3Press CLEAR to resume normal playback or return to
the paused image.
Note
The zoom function may not work for some DVDs.
The zoom function may not work on multi-angle
scenes.
Marker Search
You can start playback from a memorized point. Up to
nine points can be memorized.
To enter a mark, follow these steps.
1During disc playback, press MARKER when
playback reaches the spot that you want to
memorize.
The Marker icon will appear on the TV screen briefly.
2Repeat step 1 to enter up to nine Marker points on a
disc.
To Recall a Marked Scene
1During disc playback, press SEARCH.
The MARKER SEARCH menu will appear on the screen.
2Within 10 seconds, press 1/2to select a Marker num-
ber that you want to recall.
3Press SELECT/ENTER.
Playback will start from the Marked scene.
4To remove the MARKER SEARCH menu, press
SEARCH.
To clear a Marked Scene
1During disc playback, press SEARCH.
The MARKER SEARCH menu will appear on the screen.
2Press 1/2to select the Marker number that you want
to erase.
3Press CLEAR.
The Marker number will be erased from the list.
4Repeat steps 2 and 3 to erase additional Marker
numbers.
5To remove the MARKER SEARCH menu, press
SEARCH.
Special DVD Features
Checking the contents of DVD Video
discs: Menus
DVDs may contain menus that allow you to access spe-
cial features. To use the disc menu, press MENU. Then,
press the appropriate number button to select an option.
Or, use the 1/2/3/4buttons to highlight your selection,
then press SELECT/ENTER.
Title Menu
1Press TITLE.
If the current title has a menu, the menu will appear on the
screen. Otherwise, the disc menu may appear.
2The menu can list camera angles, spoken language
and subtitle options, and chapters for the title.
3To remove the title menu, press TITLE again.
Disc Menu
1Press MENU.
The disc menu is displayed.
2To remove the disc menu, press MENU again.
Camera Angle
If the disc contains scenes recorded at different camera
angles, you can change to a different camera angle
during playback.
Press ANGLE repeatedly during playback to select a
desired angle.
The number of the current angle appears on the display.
Changing the Audio Language
Press AUDIO repeatedly during playback to hear a dif-
ferent audio language or audio track.
Subtitles
Press SUBTITLE repeatedly during playback to see the
different subtitle languages.
Note
If appears, the feature is not available on the disc.
1 ENG
DVD
1 ENG
D
6 CH
DVD
1/1
DVD
DVD
DVD
DVD
MARKER SEARCH
1/9
VCD1.1VCD2.0
DVD
VCD1.1VCD2.0
DVD
33
Operation with Audio CD and MP3 Discs - DVD Part (Continued)
Playing an Audio CD and MP3 discs
The DVD+VCR can play MP3 formatted recordings on
CD-ROM, CD-R, or CD-RW discs.
Before playing MP3 recordings, read the notes on MP3
Recordings on page 35.
11
Insert a disc and close the tray.
The menu appears on the TV screen.
Audio CD menu MP3 menu
22
Press 33/44to select a track then press
PLAY (HH).
Playback starts.
During playback, the current track’s elapsed playing
time will appear on the display.
Playback will stop at the end of the disc.
33
To stop playback at any other time,
press STOP (xx).
Pause
1Press PAUSE/STEP (X) during playback.
2To return to playback, press PLAY (H) or press
PAUSE/STEP (X) again.
Moving to another Track
Press BACKWARD (.) or FORWARD (>) briefly
during playback to go to the next track or to return to
the beginning of the current track.
Press BACKWARD (.) twice briefly to step back to
the previous track.
In case of audio CD, to go directly to any track, enter
the track number using the numbered buttons (0-9)
during playback.
Repeat Track/All/Off
1To repeat the track currently playing, press REPEAT.
The Repeat Track icon appears on the menu screen.
2To repeat all tracks on a disc, press REPEAT a sec-
ond time.
The Repeat All icon appears on the menu screen.
3To cancel Repeat mode, press REPEAT a third time.
The Repeat Off icon appears on the menu screen.
Search
1Press and hold BACKWARD (.) or FORWARD
(>) for about two seconds during playback.
The player will now go into SEARCH mode.
2Press and hold BACKWARD (.) or FORWARD
(>) repeatedly to select the required speed: mX2,
mX4, mX8 (backward) or MX2, MX4, MX8
(forward).
3Search speed and direction are indicated on the
menu screen.
4To exit SEARCH mode, press PLAY (H).
Random
1Press RANDOM during playback or when playback is
stopped.
The unit automatically begins Random Playback and
RANDOM or “RAND.” appears on the display window
and menu screen.
2To return to normal playback, press RANDOM repeat-
edly until RANDOM or “RAND.” disappears on the
display window and menu screen.
Repeat A-B
To repeat a sequence.
1During disc playback, press A-B at your chosen start-
ing point.
The Repeat icon and “A-” appears on the menu screen.
2Press A-B again at your chosen end point.
The Repeat icon and “AB” appears on the menu screen,
and the sequence begins to play repeatedly.
3To exit the sequence and return to normal play, press
A-B again.
The Repeat icon and “OFF” appear on the menu screen.
3D Surround
This unit can produce a 3D Surround effect, which
simulates multi-channel audio playback from two
conventional stereo speakers, instead of the five or
more speakers normally required to listen to multi-
channel audio from a home theater system.
1Press SOUND to select “3D SUR” during playback.
2To turn off the 3D Surround effect, press SOUND
again to select “NORM”.
Changing the Audio Channel
Press AUDIO repeatedly during playback to hear a dif-
ferent audio channel (STEREO, LEFT, or RIGHT).
CD
CD
CD
CD
CD
MP3CD
MP3CD
MP3CD
ProgramCD
Clear All
TRACK 1
TRACK 2
TRACK 3
TRACK 4
TRACK 5
TRACK 6
TRACK 7
TRACK 8
0:56:35 STER. NORM.
ProgramMP3
Clear All
TRACK 1.MP3
TRACK 2.MP3
TRACK 3.MP3
TRACK 4.MP3
TRACK 5.MP3
TRACK 6.MP3
TRACK 7.MP3
TRACK 8.MP3
00:00 1 OFF
OPERATION
34
Programmed Playback - DVD Part (Continued)
VCD1.1VCD2.0
MP3CD
Programmed Playback with Audio CD
and MP3 Discs
Program allows you to store your favorite tracks for a
particular disc in the player memory.
Program can contain 32 tracks (Audio CD) or 60 tracks
(MP3 disc).
11
Insert the disc and close the tray.
The menu is displayed on the TV screen.
22
Press PROGRAM during playback or in the stop
mode to enter the Program Edit mode.
The mark will appear to the right of the word Program
on the right side of the menu screen.
Note
Press PROGRAM to exit the Program Edit mode;
the mark will disappear.
33
Press 33/44to select a track, then press
SELECT/ENTER to place the selected track on
the Program list.
44
Repeat step 3 to place additional tracks on the
Program list.
Audio CD menu MP3 menu
55
Press 2.
The programmed track you selected last is highlighted on
the program list.
66
Press 33/44to select the track you want to start
playing.
Press TITLE to move to the next page.
Press MENU to move to the previous page.
77
Press PLAY (HH) to start.
Playback begins in the order in which you programmed
the tracks and “PROG.” appears on the menu screen.
Playback stops after playing the last programmed track on
the program list.
Programmed Playback with Video CD
Note
On a Video CD with PBC, you must set PBC to Off on the
setup menu to use the Program function. See page 22.
11
Insert Video CD and close the tray.
22
Press PROGRAM while playback is stopped.
The VCD Program menu will appear.
Note
Press RETURN or PROGRAM to exit the Program menu.
33
Follow steps 3-7 of “Programmed Playback with
Audio CD and MP3 Disc” on left.
Repeat Programmed Tracks
To repeat the track currently playing, press REPEAT.
The Repeat Track icon appears on the menu screen.
To repeat all tracks on the program list, press
REPEAT a second time.
The Repeat All icon appears on the menu screen.
To cancel Repeat mode, press REPEAT a third time.
The Repeat Off icon appears on the menu screen.
Erasing a Track from Program List
1Press PROGRAM during playback or in the stop
mode to enter the Program Edit mode.
The mark will appear.
2Press 2to move to the Program list.
3Use 33/44to select the track that you wish to erase
from the Program list.
4Press CLEAR.
The track will be erased from the Program list.
Erasing the Complete Program List
1Follow steps 1-2 of “Erasing a Track from Program
List” as above.
2Use 33/44to select “Clear All”, then press
SELECT/ENTER.
The complete Program for the disc will be erased.
The programs are also cleared when the disc is removed.
To resume normal playback from programmed
playback
Press and hold PROGRAM for 3 seconds until “PROG.”
indicator disappears in the display window.
E
E
E
ProgramCD
Clear All
TRACK 1
TRACK 2
TRACK 3
TRACK 4
TRACK 12
TRACK 8
TRACK 10
TRACK 3
TRACK 5
TRACK 6
TRACK 7
TRACK 8
STER. NORM.
E
0:56:35
ProgramMP3
Clear All
TRACK 1.MP3
TRACK 2.MP3
TRACK 3.MP3
TRACK 4.MP3
TRACK 8.MP3
TRACK 2.MP3
TRACK 4.MP3
TRACK 3.MP3
TRACK 5.MP3
TRACK 6.MP3
TRACK 7.MP3
TRACK 8.MP3
00:00 1 OFF
E
VCD
Clear All
TRACK 1
TRACK 2
TRACK 3
TRACK 4
TRACK 5
TRACK 6
TRACK 7
TRACK 8
Program
E
35
Additional Information - DVD Part
Last Condition Memory
This player memorizes the last condition for the last
disc you have watched. Settings remain in memory
even if you remove the disc from the player or switch off
the player. If you load a disc that has its settings memo-
rized, the latest stop position is automatically recalled.
Notes
–Settings are stored in memory for use any time.
–This player does not memorize settings of a disc if
you switch off the player before commencing to play
it.
Screen Saver
The screen saver picture appears when you leave the
DVD+VCR in stop mode for about five minutes.
After the Screen Saver has been engaged for about five
minutes, the DVD+VCR will automatically turn itself off.
Video Mode Setting
With certain discs, the playback picture may be flick-
ering or Dot Crawl is shown on straight lines. That
means Vertical interpolation or De-interlace is not
perfectly matched with the disc. In this case, the
picture quality may be improved by changing the
video mode.
To change the video mode, press and hold DISPLAY
about 3 seconds during disc playback. The new video
mode number selected is displayed on the TV screen.
Check whether the video quality has improved. If not,
repeat the above procedure until picture quality is
improved.
Video mode change sequence:
MODE1 → MODE2 →MODE3 →MODE4 →
MODE5 → MODE1
If you turn off the power, the video mode will be back
to initial state (MODE1).
Notes on MP3 Discs
About MP3
An MP3 file is audio data compressed by using
MPEG1, the audio layer-3 file-coding scheme. We call
files that have the “.mp3” file extension “MP3 files”.
The player can not read an MP3 file that has a file
extension other than “.mp3”.
The player can not read a fake MP3 file that has a
file extension “.mp3”.
MP3 Disc compatibility with this player is limit-
ed as follows:
1. Sampling Frequency / only at 44.1kHz
2. Bit rate/ within 32 - 320kbps
3. CD-R physical format should be “ISO 9660”
4. If you record MP3 files using the software which
cannot create a FILE SYSTEM, for example “Direct-
CD” etc., it is impossible to playback MP3 files. We
therefore recommend that you use “Easy-CD
Creator”, which creates an ISO9660 file system.
5. A single session disc requires MP3 files in the first
track. If there is no MP3 file in the 1st track, it can-
not playback MP3 files. If you wish to playback MP3
files, format all the data in the disc or use a new
one.
6. We do not recommend using CD-RW discs. Please
use finished CD-R discs only.
7. File names should be named using 8 letters or less
and must incorporate the “.mp3” extension
e.g. “********.MP3”.
8. Do not use special characters such as
“_?!><+*}{`[@ ]:;\/.,” etc.
9. Total number of files on the disc should be less than
200.
10. Use 74 minute CD-R discs (650M), do not use 80
minute CD-R (700M) software.
This DVD+VCR requires discs/recordings to meet
certain technical standards in order to achieve optimal
playback quality. Pre-recorded DVDs are automatically
set to these standards. There are many different types
of recordable disc formats (including CD-R containing
MP3 files).
Customers should also note that permission is
required in order to download MP3 files and music
from the Internet. Our company has no right to
grant such permission. Permission should always
be sought from the copyright owner.
VCD1.1VCD2.0
DVD
VCD1.1
CDDVD
OPERATION
36
Operation with Radio
Presetting Radio Stations
You can preset 30 stations for FM and AM. Before tun-
ing, make sure that you have turned down the volume
to the minimum.
11
Press FUNCTION on the front panel repeatedly
or FM/AM on the remote control until FM or AM
appear in the display window.
22
And then every time you press FM/AM, FM and
AM change alternately.
33
Press and hold TUNING (vv/VV) on the front panel
for about two seconds until the frequency indi-
cation starts to change, then release.
Scanning stops when the DVD Receiver tunes in a
station. “TUNED” and “STEREO”(for stereo program)
appear in the display window.
ote
“Tuned” only appears when the signal is FM and
stereo.
44
Press MEMORY.
A preset number will flash in the display window.
55
Press TUNING (vv/VV) on the front panel to select
the preset number.
66
Press MEMORY again.
The station is stored.
77
Repeat steps 3 to 6 to store other stations.
To tune in a station with a weak signal
Press TUNING (v/V) repeatedly in step 3 to tune in the
station manually.
To clear all the memorized stations
Press and hold MEMORY for about three seconds and
“CLEAR ALL” appears in the display window and then
press MEMORY again, the stations are cleared.
ote
If all stations have already been entered, FULL mes-
sage will appear in the display window for a moment
and then a preset number will flash. To change the pre-
set number, follow the steps 5-6 as above.
Listening to the Radio
Preset radio stations in the DVD+VCR’s memory first
(see “Presetting radio stations” on the left side).
11
Press FM/AM until AM or FM appears in the dis-
play window.
The last received station is tuned in.
22
Press PRESET (vv/VV) repeatedly to select a pre-
set station.
Each time you press the button, the DVD+VCR tunes in
one preset station at a time.
33
Adjust the volume by rotating VOLUME on the
front panel or by pressing VOLUME + or - on the
remote control repeatedly.
To turn off the radio
Press POWER to turn the DVD+VCR off or select
another function mode (DVD/CD, VIDEO 1 or VIDEO 2).
To listen to non-preset radio stations
Use manual or automatic tuning in step 2.
For manual tuning, press TUNING (v/V) on the front
panel repeatedly.
For automatic tuning, press and hold TUNING (v/V)
for about two seconds on the front panel.
For your reference
If an FM program is noisy
Press MONO/ST. on the front panel so that
“STEREO” disappears in the display window. There
will be no stereo effect, but the reception will
improve. Press the button again to restore the stereo
effect.
To improve reception
Realign the antenna.
37
Symptom
No power.
The power is on, but
the DVD+VCR does not
work.
No picture.
No sound.
The playback picture is
poor.
The DVD+VCR does
not start playback.
The remote control
does not work properly.
Cause
The power cord is disconnected.
No disc is inserted.
No tape is inserted.
The TV is not set to receive DVD+VCR
signal output.
TV/VCR mode for DVD+VCR is set to
TV.
The video cable is not connected
securely.
The connected TV power is turned off.
The equipment connected with the
audio cable is not set to receive
DVD+VCR signal output.
The audio cables are not connected
securely.
The power of the equipment connected
with the audio cable is turned off.
The Digital Audio Output is set to the
wrong position.
The disc is dirty.
Tape heads are dirty.
Tape is a rental or was recorded on
another VCR.
No disc is inserted.
No tape is inserted.
An unplayable disc is inserted.
The disc is placed upside down.
The disc is not placed within the guide.
The disc is dirty.
The Rating level is set.
The remote control is not pointed at the
remote sensor of the DVD+VCR.
The remote control is too far from the
DVD+VCR.
There is an obstacle in the path of the
remote control and the DVD+VCR.
The batteries in the remote control are
exhausted.
This remote control has same buttons
between VCR and DVD (ex. PLAY).
Correction
Plug the power cord into the wall outlet
securely.
Insert a disc or tape. (Check that the
disc or tape indicator in the display
window is lit.)
Select the appropriate video input mode
on the TV so the picture from the
DVD+VCR appears on the TV screen.
Press the TV/VCR button on the remote
control repeatedly to choose VCR
mode. VCR indicator light appears in
the display window.
Connect the video cable securely.
Turn on the TV.
Select the correct input mode of the
audio receiver so you can listen to the
sound from the DVD+VCR.
Connect the audio cable securely.
Turn on the equipment connected with
the audio cable.
Set the Digital Audio Output to the
correct position, then turn on the
DVD+VCR again by pressing POWER.
Clean the disc.
Clean video heads.
Use
CH/TRK (v/V)
for manual tracking
adjustment while tape is playing.
Insert a disc or tape. (Check that the
disc or tape indicator in the display
window is lit.)
Insert a playable disc. (Check the disc
type, color system, and Regional code.)
Place the disc with the playback side down.
Place the disc on the disc tray correctly
inside the guide.
Clean the disc.
Cancel the Rating function or change
the rating level.
Point the remote control at the remote
sensor of the DVD+VCR.
Operate the remote control within 23 ft
(7 m).
Remove the obstacle.
Replace the batteries with new ones.
When using a VCR, first press the VCR
button. When using a DVD, first press
the DVD button.
Troubleshooting
Check the following guide for the possible cause of a problem before contacting service.
REFERENCE
38
Troubleshooting (Continued)
Symptom
Some channels are
skipped over when
using
CH/TRK (v/V)
Picture and sound of
broadcasting channel
are weak or missing.
Camcorder image is not
shown.
Camcorder image via
A/V input to DVD+VCR
is not shown on TV
screen.
Timer recording is not
possible.
TIMER indicator light
appears after DVD+VCR
is turned off.
Stereo Audio Record
and/or Playback is not
present.
Cause
Those channels were deleted with the
ADD/DEL CH. option.
Antenna or cables are loose.
Wrong CHANNEL SOURCE option is
being used.
Camcorder is off.
DVD+VCR INPUT SELECT is not set to
LINE1 or LINE2.
Clock in DVD+VCR is not set to correct
time.
DVD+VCR is on which disables timer.
Timer has been programmed
incorrectly.
TIMER indicator light does not appear
after programming timer.
DVD+VCR is in Timer Recording mode.
TV is not Stereo-compatible.
Broadcast program is not in stereo for-
mat.
DVD+VCR A/V Out jacks are not con-
nected to TV A/V In jacks.
DVD+VCR Audio/Video Out is not
selected for viewing at the TV.
DVD+VCR BROADCAST TYPE mode is
set to SAP or MONO.
Correction
Use ADD/DEL CH. to restore channels.
See “Channel Selection” on page 19.
Tighten connections or replace cable.
Try all CHANNEL SOURCE options.
See “Channel Selection” on page 19 for
details.
Turn camcorder on and operate
properly.
Press INPUT to select LINE input chan-
nel (LINE1 or LINE2).
Set clock to correct time. See “Setting
the Clock” on page 20.
Turn DVD+VCR off to enable timer.
TIMER indicator light appears in the
display window.
Reprogram Timer. See “Timer
Recording” on pages 25 and 26.
Reprogram Timer and turn DVD+VCR
off to enable timer.
This is the normal indication that the
DVD+VCR is in TIMER mode.
No action is possible.
No action is possible.
Make A/V connections. Stereo is
available only via A/V output from
DVD+VCR.
Select AUX or A/V source as TV input.
Set BROADCAST TYPE mode to
STEREO. See “Setting the VCR Setup
Menu” on page 19.
Moisture Condensation
Moisture condensation can occur:
•When the DVD+VCR is moved from a cold place to a
warm place.
•Under extremely humid conditions.
In locations where moisture condensation may occur:
•
Keep the DVD+VCR plugged into an AC power outlet
with POWER On. This will help prevent condensation.
•When condensation has occurred, wait a few hours
for the DVD+VCR to dry before using it.
39
Language Code List
Code Language
6566 Abkhazian
6565 Afar
6570 Afrikaans
8381 Albanian
6577 Amharic
6582 Arabic
7289 Armenian
6583 Assamese
6588 Aymara
6590 Azerbaijani
6665 Bashkir
6985 Basque
6678 Bengali; Bangla
6890 Bhutani
6672 Bihari
6682 Breton
6671 Bulgarian
7789 Burmese
6669 Byelorussian
7577 Cambodian
6765 Catalan
9072 Chinese
6779 Corsican
7282 Croatian
6783 Czech
6865 Danish
7876 Dutch
6978 English
6979 Esperanto
6984 Estonian
7079 Faeroese
Code Language
7074 Fiji
7073 Finnish
7082 French
7089 Frisian
7176 Galician
7565 Georgian
6869 German
6976 Greek
7576 Greenlandic
7178 Guarani
7185 Gujarati
7265 Hausa
7387 Hebrew
7273 Hindi
7285 Hungarian
7383 Icelandic
7378 Indonesian
7365 Interlingua
7165 Irish
7384 Italian
7465 Japanese
7487 Javanese
7578 Kannada
7583 Kashmiri
7575 Kazakh
7589 Kirghiz
7579 Korean
7585 Kurdish
7679 Laothian
7665 Latin
7686 Latvian, Lettish
Code Language
7678 Lingala
7684 Lithuanian
7775 Macedonian
7771 Malagasy
7783 Malay
7776 Malayalam
7784 Maltese
7773 Maori
7782 Marathi
7779 Moldavian
7778 Mongolian
7865 Nauru
7869 Nepali
7879 Norwegian
7982 Oriya
8065 Panjabi
8083 Pashto, Pushto
7065 Persian
8076 Polish
8084 Portuguese
8185 Quechua
8277 Rhaeto-Romance
8279 Romanian
8285 Russian
8377 Samoan
8365 Sanskrit
7168 Scots Gaelic
8382 Serbian
8372 Serbo-Croatian
8378 Shona
8368 Sindhi
Code Language
8373 Singhalese
8375 Slovak
8376 Slovenian
8379 Somali
6983 Spanish
8385 Sudanese
8387 Swahili
8386 Swedish
8476 Tagalog
8471 Tajik
8465 Tamil
8484 Tatar
8469 Telugu
8472 Thai
6679 Tibetan
8473 Tigrinya
8479 Tonga
8482 Turkish
8475 Turkmen
8487 Twi
8575 Ukrainian
8582 Urdu
8590 Uzbek
8673 Vietnamese
8679 Volapük
6789 Welsh
8779 Wolof
8872 Xhosa
7473 Yiddish
8979 Yoruba
9085 Zulu
Enter the appropriate code number for the initial settings “Disc Audio”, “Disc Subtitle” and/or “Disc Menu”
(See page 22).
REFERENCE
40
Code Country
AD Andorra
AE United Arab Emirates
AF Afghanistan
AG Antigua and Barbuda
AI Anguilla
AL Albania
AM Armenia
AN Netherlands Antilles
AO Angola
AQ Antarctica
AR Argentina
AS American Samoa
AT Austria
AU Australia
AW Aruba
AZ Azerbaidjan
BA Bosnia-Herzegovina
BB Barbados
BD Bangladesh
BE Belgium
BF Burkina Faso
BG Bulgaria
BH Bahrain
BI Burundi
BJ Benin
BM Bermuda
BN Brunei Darussalam
BO Bolivia
BR Brazil
BS Bahamas
BT Bhutan
BV Bouvet Island
BW Botswana
BY Belarus
BZ Belize
CA Canada
CC Cocos (Keeling) Islands
CF Central African Republic
CG Congo
CH Switzerland
CI Ivory Coast
CK Cook Islands
CL Chile
CM Cameroon
CN China
CO Colombia
CR Costa Rica
CS Former Czechoslovakia
CU Cuba
CV Cape Verde
CX Christmas Island
CY Cyprus
CZ Czech Republic
DE Germany
DJ Djibouti
DK Denmark
DM Dominica
DO Dominican Republic
DZ Algeria
EC Ecuador
EE Estonia
EG Egypt
EH Western Sahara
Code Country
ER Eritrea
ES Spain
ET Ethiopia
FI Finland
FJ Fiji
FK Falkland Islands
FM Micronesia
FO Faroe Islands
FR France
FX France (European
Territory)
GA Gabon
GB Great Britain
GD Grenada
GE Georgia
GF French Guyana
GH Ghana
GI Gibraltar
GL Greenland
GM Gambia
GN Guinea
GP Guadeloupe (French)
GQ Equatorial Guinea
GR Greece
GS S. Georgia & S. Sandwich
Isls.
GT Guatemala
GU Guam (USA)
GW Guinea Bissau
GY Guyana
HK Hong Kong
HM Heard and McDonald
Islands
HN Honduras
HR Croatia
HT Haiti
HU Hungary
ID Indonesia
IE Ireland
IL Israel
IN India
IO British Indian Ocean
Territory
IQ Iraq
IR Iran
IS Iceland
IT Italy
JM Jamaica
JO Jordan
JP Japan
KE Kenya
KG Kyrgyzstan
KH Cambodia6
KI Kiribati
KM Comoros
KN
Saint Kitts & Nevis Anguilla
KP North Korea
KR South Korea
KW Kuwait
KY Cayman Islands
KZ Kazakhstan
LA Laos
LB Lebanon
Code Country
LC Saint Lucia
LI Liechtenstein
LK Sri Lanka
LR Liberia
LS Lesotho
LT Lithuania
LU Luxembourg
LV Latvia
LY Libya
MA Morocco
MC Monaco
MD Moldavia
MG Madagascar
MH Marshall Islands
MK Macedonia
ML Mali
MM Myanmar
MN Mongolia
MO Macau
MP Northern Mariana Islands
MQ Martinique (French)
MR Mauritania
MS Montserrat
MT Malta
MU Mauritius
MV Maldives
MW Malawi
MX Mexico
MY Malaysia
MZ Mozambique
NA Namibia
NC New Caledonia (French)
NE Niger
NF Norfolk Island
NG Nigeria
NI Nicaragua
NL Netherlands
NO Norway
NP Nepal
NR Nauru
NU Niue
NZ New Zealand
OM Oman
PA Panama
PE Peru
PF Polynesia (French)
PG Papua New Guinea
PH Philippines
PK Pakistan
PL Poland
PM Saint Pierre and Miquelon
PN Pitcairn Island
PR Puerto Rico
PT Portugal
PW Palau
PY Paraguay
QA Qatar
RE Reunion (French)
RO Romania
RU Russian Federation
RW Rwanda
SA Saudi Arabia
SB Solomon Islands
Code Country
SC Seychelles
SD Sudan
SE Sweden
SG Singapore
SH Saint Helena
SI Slovenia
SJ Svalbard and Jan Mayen
Islands
SK Slovak Republic
SL Sierra Leone
SM San Marino
SN Senegal
SO Somalia
SR Suriname
ST Saint Tome and Principe
SU Former USSR
SV El Salvador
SY Syria
SZ Swaziland
TC Turks and Caicos Islands
TD Chad
TF French Southern
Territories
TG Togo
TH Thailand
TJ Tadjikistan
TK Tokelau
TM Turkmenistan
TN Tunisia
TO Tonga
TP East Timor
TR Turkey
TT Trinidad and Tobago
TV Tuvalu
TW Taiwan
TZ Tanzania
UA Ukraine
UG Uganda
UK United Kingdom
UM USA Minor Outlying
Islands
US United States
UY Uruguay
UZ Uzbekistan
VA Vatican City State
VC Saint Vincent &
Grenadines
VE Venezuela
VG Virgin Islands (British)
VI Virgin Islands (USA)
VN Vietnam
VU Vanuatu
WF Wallis and Futuna Islands
WS Samoa
YE Yemen
YT Mayotte
YU Yugoslavia
ZA South Africa
ZM Zambia
ZR Zaire
ZW Zimbabwe
Country Code List
Enter the appropriate code number for the initial setting “Country Code” (See page 23).
41
Specifications
General
Power requirements AC 120V, 60 Hz
Power consumption 80W
Dimensions (approx.) 430 X 97.5 X 360 mm (16.9 x 3.9 x 14.2 inches) (w x h x d)
Mass (approx.) 7 kg (15.4 lbs)
Operating temperature 5˚C to 40˚C (41˚F to 104˚F)
Operating humidity 5 % to 90 %
Signal system NTSC
Inputs
ANTENNA IN Antenna or CATV input, 75 ohms
VCR VIDEO IN 1 Vp-p 75 ohms, sync negative, RCA jack x 1
VCR AUDIO IN -6.0 dBm more than 47 kohms, RCA jack (L, R) x 1
FM ANTENNA IN FM antenna input, 300 ohms
AM ANTENNA IN AM antenna input, 300 ohms
DIIGTAL AUDIO IN 5 V (p-p), 75 Ω, Optical connector x 1
Outputs
VIDEO OUT 1 Vp-p 75 ohms, sync negative
S-VIDEO OUT (Y) 1.0 V (p-p), 75 ohms, negative sync, Mini DIN 4-pin x 1
(C) 0.3 V (p-p) 75 ohms
COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 ohms, negative sync, RCA jack x 1
(PROGRESSIVE SCAN) (Pb)/(Pr) 0.7 V (p-p), 75 ohms, RCA jack x 2
Audio output (analog audio) 2.0 Vrms (1 KHz, 0 dB), 330 ohms, RCA jack (L, R) x 1
RF OUT Channel 3 or 4 (Switchable)
VCR Specifications
Head system Four head helical scan azimuth system
Timer 12-hour display type with AM, FM
Tape speed SP: 33.35 mm/sec, LP: 16.67 mm/sec, EP: 11.12 mm/sec
Tape width 12.7 mm
Maximum recording time SP: 2 HOURS (T-120), EP: 6 HOURS (T-120)/8 HOURS (T-160)
Rewind time About 3 minutes (T-120)
Antenna 75 ohms (VHF/UHF)
Channel coverage VHF: 2-13, UHF: 14-69, CATV: 1-125 (4A, A-W, W+1 - W+84, A-5 - A-1)
Frequency range 20Hz to 20kHz
Signal-to-noise ratio More than 43dB
Dynamic range More than 83 dB
Channel separation More than 55 dB
DVD Specifications
Laser system Semiconductor laser, wavelength 650 nm
Frequency response DVD (PCM 48 kHz): 8 Hz to 22 kHz, CD: 8 Hz to 20 kHz
Signal-to-noise ratio More than 100dB (ANALOG OUT jacks only)
Harmonic distortion Less than 0.008%
Dynamic range More than 95 dB
Specifications (Continued)
Radio Tuner
Tuning Range 87.5 - 108 MHz
Intermediate Frequency 10.7 MHz
Signal-to Noise Ratio 60 dB
Frequency Response 150 - 10,000 Hz
Tuning Range 530 - 1,720 kHz
Intermediate Frequency 450 kHz
Amplifier
Stereo mode 50W + 50W (8 Ωat 1 kHz, THD 10 %)
Surround mode Front: 50W + 50W (THD 10 %)
Center*: 50W
Surround*: 50W + 50W (8Ωat 1 kHz, THD 10 %)
Subwoofer*: 80W (4Ωat 30 Hz, THD 10 %)
*
Depending on the sound mode settings and the source, there may be no sound output.
Inputs LINE 1, LINE 2, OPTICAL AUDIO
Speakers
Satellite Speaker Passive Subwoofer
Type 2 Way 2 Speaker 1 Way 1 Speaker
Impedance 8 Ω4 Ω
Frequency Response 110 - 40,000 Hz 40 - 1,500 Hz
Sound Pressure Level 83 dB/W (1m) 82 dB/W (1m)
Rated Input Power 50W 100 W
Max. Input Power 100 W 200 W
Net Dimensions (W x H x D) 100 x 147 x 127.5 mm 200 x 425 x 381 mm
Net Weight 0.92 kg 7.06kg
Accessory:
S-Video cable . . . . . . . . . . . . . .1
Video cable . . . . . . . . . . . . . . .1
Audio cable . . . . . . . . . . . . . . .1
RF 75-ohm Coaxial Cable . . . .1
Speakers . . . . . . . . . . . . . . . . .6
Speaker cables . . . . . . . . . . . .5
AM loop antenna . . . . . . . . . . .1
FM antenna . . . . . . . . . . . . . . .1
Remote control . . . . . . . . . . . . .1
Batteries . . . . . . . . . . . . . . . . . .2
Design and specifications are subject to change without notice.
REFERENCE
42
Manufactured under license from Dolby Laboratories. Dolby
and the double-D symbol are trademarks of Dolby
Laboratories. Confidential unpublished works. Copyright
1992-1997 Dolby Laboratories. All rights reserved.
DTS and DTS Digital Surround are registered trademarks of
Digital Theater Systems, Inc.
ZENITH ELECTRONICS CORPORATION Zenith Part No. 206-3792
2000 MILLBROOK DRIVE GS# 3835RM0053J
LINCOLNSHIRE, IL 60069 Printed in China
Issue O
ZENITH ELECTRONICS CORPORATION
LIMITED WARRANTY (USA)
Zenith will repair or replace your product, at Zenith’s option, if it proves to be defective in material or
workmanship under normal use during the warranty period listed below from the date of original
consumer purchase. This warranty is good only to the original purchaser of the product during the
warranty period as long as it is in the United States, excluding US Territories.
WARRANTY PERIOD
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESSED OR IMPLIED,
INCLUDING WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. TO THE EXTENT ANY IMPLIED WARRANTY IS
REQUIRED BY LAW, IT IS LIMITED IN DURATION TO THE EXPRESSED WARRANTY
PERIOD ABOVE. ZENITH WILL NOT BE LIABLE FOR ANY INCIDENTAL, CONSEQUEN-
TIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY NATURE, INCLUDING
WITHOUT LIMITATION LOST PROFITS, LOST OR CORRUPTED PROGRAMMING OR DATA,
OR ANY OTHER DAMAGE WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE
.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on
how long an implied warranty lasts, so these limitations or exclusions may not apply to you. This warranty
gives you specific legal rights and you may also have other rights that vary from state to state.
THE ABOVE WARRANTY DOES NOT APPLY TO:
1. To damages or problems that result from shipping, installation, calibration, maintenance, or separate
system components.
2. To damages or problems that result from misuse, abuse, operation outside environmental specifica-
tions or contrary to the requirements and precautions in the Operating Guide, accident, lightning
strikes or other natural causes, modification or alteration, incorrect electrical current or voltage, signal
reception or input, software not licensed directly by Zenith, software errors that do not disable func-
tionality, operating and software protocols adopted after date of manufacturer or for outside the US,
or institutional or commercial use.
Therefore, the cost of repair or replacement is borne by the customer.
CUSTOMER ASSISTANCE NUMBERS:
WARRANTY PERIOD
Labor: 90 Days from date of purchase
Parts: One Year from the date of purchase
HOW SERVICE IS HANDLED
Carry-in service. Please retain your bill of sale for proof of
warranty.
Please call 1-877-9ZENITH (1-877-993-6484) to locate
your nearest Zenith Authorized Service Center. Please
see below for further information.
To Prove Warranty Coverage: →→
To Obtain Where-To-Buy, nearest
Authorized Service Center, Product
Assistance, or Customer Assistance:
→→
Retain your Sales Receipt to prove date of purchase.
A copy of your Sales Receipt must be submitted at the time
warranty service is provided.
Call 1-877-9ZENITH (1-877-993-6484) and choose the
appropriate prompt.
(Mon. ~ Fri. 7 a.m. ~ 8 p.m. and Sat. 8 a.m. to 5:00 p.m. CT)
or visit our website at
http://www.zenithservice.com
