LG Electronics USA 9QKE40450 VCR/DVD Recorder User Manual RC69225M AA1ULL 0609

LG Electronics USA VCR/DVD Recorder RC69225M AA1ULL 0609

users manual

VCR / DVD Recorder
OWNER’S MANUAL
MODEL: RC68225M
LGXBR446
Before connecting, operating or adjusting this product,
please read this owner’s manual carefully and completely.
CD-R/RW
Call us and we will
guide you through
your first recording,
for free.
11--880000--224433--00000000
©Copyright 2004, LG Electronics U.S.A., Inc.
2
Safety Precautions
This lightning flash with arrowhead symbol within an
equilateral triangle is intended to alert the user to
the presence of uninsulated dangerous voltage
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
product.
WARNING: Do not install this equipment in a confined space
such as a bookcase or similar unit.
NOTE TO CABLE/TV INSTALLER: This reminder is provided to
call the cable TV system installer’s attention to Article 820-40 of
the National Electric Code (U.S.A.). The code provides guidelines
for proper grounding and, in particular, specifies that the cable
ground shall be connected to the grounding system of the
building, as close to the point of the cable entry as practical.
CAUTION:
This VCR/DVD Recorder employs a Laser System.
To ensure proper use of this product, please read this owner’s
manual carefully and retain for future reference. Should the
unit require maintenance, contact an authorized service
center.
Use of controls, adjustments, or the performance of proce-
dures other than those specified herein may result in haz-
ardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open
the enclosure. Visible laser radiation when open. DO NOT
STARE INTO BEAM.
CAUTION: The apparatus should not be exposed to water
(dripping or splashing) and no objects filled with liquids, such
as vases, should be placed on the apparatus.
FCC WARNING: This equipment may generate or use radio
frequency energy. Changes or modifications to this
equipment may cause harmful interference unless the modifi-
cations are expressly approved in the instruction manual. The
user could lose the authority to operate this equipment if an
unauthorized change or modification is made.
REGULATORY INFORMATION: FCC Part 15
This product has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the product is
operated in a residential installation. This product generates,
uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur
in a particular installation. If this product does cause harmful
interference to radio or television reception, which can be
determined by turning the product off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the product and
receiver.
Connect the product into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
FCC COMPLIANCE: The responsible party for this product’s
compliance is:
LG Electronics U.S.A., Inc.,1000 Sylvan Avenue,
Englewood Cliffs, NJ.
Phone: 1-201-816-2000.
SERIAL NUMBER: The serial number is found on the back of
this unit. This number is for this unit only. You should record
requested information here and retain this guide as a perma-
nent record of your purchase.
Model No. ___________________________________
Serial No. ___________________________________
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE
DANS LA BORNE CORRESPONDANTE DE LA PRISE ET
POUSSER JUSQU’AU FOND.
WARNING: TO REDUCE THE RISK OF FIRE OR ELEC-
TRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO
RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK
OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
INTRODUCTION
3
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions. - All these safety and oper-
ating instructions should be read before the product is
operated.
2. Keep these instructions. - The safety, operating and
use instructions should be retained for future refer-
ence.
3. Heed all warnings. - All warnings on the product and
in the operating instructions should be adhered to.
4. Follow all instructions. - All operating and use
instructions should be followed.
5. Do not use this product near water. – For example:
near a bath tub, wash bowl, kitchen sink, laundry tub,
in a wet basement; or near a swimming pool; and
other areas located near water.
6. Clean only with dry cloth. – Unplug this product from
the wall outlet before cleaning. Do not use liquid
cleaners.
7.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions. -
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the
product and to protect it from over- heating. The open-
ings should never be blocked by placing the product
on a bed, sofa, rug or other similar surface. This prod-
uct should not be placed in a built-in installation such
as a bookcase or rack unless proper ventilation is pro-
vided or the manufacturer’s instructions have been
adhered to.
8. Do not install near any heat sources such as radi-
ators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9.
Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A ground-
ing
type plug has two blades and a third ground-
ing prong. The wide blade or the third prong are
provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the product.
11. Only use attachments/accessories specified by
the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
apparatus. When a cart is used, use caution
when moving the cart/product combination to
avoid injury from tip-over.
13. Unplug this product during lightning storms or
when unused for long periods of time.
14.
Refer all servicing to qualified service personnel.
Servicing is required when the product has been
damaged in any way, such as power-supply cord
or plug is damaged, liquid has been spilled or
objects have fallen into the product, the product
has been exposed to rain or moisture, does not
operate normally, or has been dropped.
CAUTION:
PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS OWNER’S MANUAL.
AND THOSE MARKED ON THE PRODUCT. RETAIN THIS MANUAL FOR FUTURE REFERENCE.
This product has been designed and manufactured to assure personal safety. Improper use can result in electric
shock or fire hazard. The safeguards incorporated in this product will protect you if you observe the following proce-
dures for installation, use, and servicing.
This product does not contain any parts that can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
4
Table of Contents
INTRODUCTION
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . 2
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . 3
Table of Contents . . . . . . . . . . . . . . . . . . . . . . 4-5
LGXBR342 Overview. . . . . . . . . . . . . . . . . . . . 6-9
Recordable Discs . . . . . . . . . . . . . . . . . . . . . . . 6
Playable Discs . . . . . . . . . . . . . . . . . . . . . . . . . 6
Disc-related terms . . . . . . . . . . . . . . . . . . . . . . 6
Types of video CDs . . . . . . . . . . . . . . . . . . . . . 6
About DVD-R and DVD-RW disc. . . . . . . . . . . . 7
•What are “Recording modes”? . . . . . . . . . . 7
•Is editing a DVD like editing a video tape? . 7
•About word ‘Original’ and ‘Playlist’ . . . . . . . 7
About DVD recording. . . . . . . . . . . . . . . . . . . 7-8
•Disc types and recording formats, modes,
and settings . . . . . . . . . . . . . . . . . . . . . . . . 7
•Notes for recording. . . . . . . . . . . . . . . . . . . 8
•Recording TV audio channels. . . . . . . . . . . 8
•Restrictions on video recording. . . . . . . . . . 8
•What is ‘CPRM’? . . . . . . . . . . . . . . . . . . . . 8
•Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
•Handling the unit . . . . . . . . . . . . . . . . . . . . 9
•Cleaning the unit . . . . . . . . . . . . . . . . . . . . 9
•Remote Control Operation Range. . . . . . . . 9
•Remote Control Battery Installation . . . . . . 9
Notes on Discs . . . . . . . . . . . . . . . . . . . . . . . . . 9
•Handling discs . . . . . . . . . . . . . . . . . . . . . . 9
•Storing discs . . . . . . . . . . . . . . . . . . . . . . . 9
•Cleaning discs . . . . . . . . . . . . . . . . . . . . . . 9
About Symbols . . . . . . . . . . . . . . . . . . . . . . . . . 9
•About the symbol display . . . . . . . . . . . . 9
•About the disc symbols for instructions. . . . 9
Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Function Display Window . . . . . . . . . . . . . . . . 11
Remote Control Overview . . . . . . . . . . . . . . . . 12
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
DVR HOOKUP
Connections . . . . . . . . . . . . . . . . . . . . . . . . 14-17
Connecting Antenna/Cable TV to
VCR/DVD Recorder . . . . . . . . . . . . . . . . . . . . 14
Connecting to a TV. . . . . . . . . . . . . . . . . . . . . 15
Connecting to Optional Equipment . . . . . . . . . 16
Accessory Audio/Video (A/V) Connections
to VCR/DVD Recorder . . . . . . . . . . . . . . . . . . 17
Connecting a Digital Camcorder . . . . . . . . . . . 17
Before Operation. . . . . . . . . . . . . . . . . . . . . 18-29
Initial Settings . . . . . . . . . . . . . . . . . . . . . . . . . 18
•General Operation . . . . . . . . . . . . . . . . . . 18
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . 18-20
•Tuning Band Select . . . . . . . . . . . . . . . . . 18
•Auto Channel Set. . . . . . . . . . . . . . . . . . . 18
•To Add or Erase Channels from Memory . 19
•Auto Clock Set . . . . . . . . . . . . . . . . . . . . . 19
•Manual Clock Set. . . . . . . . . . . . . . . . . . . 19
•TV Aspect Ratio . . . . . . . . . . . . . . . . . . . . 20
•Progressive Scan . . . . . . . . . . . . . . . . . . . 20
•Factory Setting. . . . . . . . . . . . . . . . . . . . . 20
LANGUAGE . . . . . . . . . . . . . . . . . . . . . . . . . . 20
•Display Menu . . . . . . . . . . . . . . . . . . . . . . 20
•Disc Language . . . . . . . . . . . . . . . . . . . . . 20
AUDIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
•Dolby Digital. . . . . . . . . . . . . . . . . . . . . . . 21
•DTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
•MPEG . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
•Sampling Freq. (Frequency) . . . . . . . . . . . 21
•DRC (Dynamic Range Control) . . . . . . . . 21
•Vocal . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
LOCK (Parental Control) . . . . . . . . . . . . . . 22-23
•Movie Rating . . . . . . . . . . . . . . . . . . . . . . 22
•Set Password. . . . . . . . . . . . . . . . . . . . . . 22
•Country Code. . . . . . . . . . . . . . . . . . . . . . 23
RECORD. . . . . . . . . . . . . . . . . . . . . . . . . . 23-24
•DISC Record Mode . . . . . . . . . . . . . . . . . 23
•VCR Record Mode . . . . . . . . . . . . . . . . . . 23
•DV Record Audio . . . . . . . . . . . . . . . . . . . 24
•Auto Chapter . . . . . . . . . . . . . . . . . . . . . . 24
DISC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-25
•DISC Initialize . . . . . . . . . . . . . . . . . . . . . 24
•DISC Finalize. . . . . . . . . . . . . . . . . . . . . . 25
•DISC Protect . . . . . . . . . . . . . . . . . . . . . . 25
•PBC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
•DISC Name . . . . . . . . . . . . . . . . . . . . . . . 26
General Explanation of On-Screen Display . . . 27
•Displaying Information on-screen . . . . . . . 27
•Displaying OSD While Watching TV . . . . . 27
•Changing TV Channels . . . . . . . . . . . . . . 27
•Changing TV Audio Channel. . . . . . . . . . . 27
OSD Menu Options by Media Type . . . . . . 28-29
•DVD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
•VR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
•Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
•VCD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
•VHS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Table of Contents
PLAYBACK
Operation with DVD and Video CD. . . . . . . 30-33
Playing a DVD or Video CD . . . . . . . . . . . . 30-33
•Moving to another TITLEs . . . . . . . . . . . . 30
•Moving to another CHAPTER/TRACKs. . . 30
•Slow Motion . . . . . . . . . . . . . . . . . . . . . . . 30
•
Still Picture and Frame-by-Frame Playback
. 31
•Search . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
•Random . . . . . . . . . . . . . . . . . . . . . . . . . . 31
•Repeat . . . . . . . . . . . . . . . . . . . . . . . . . . 31
•Repeat A-B . . . . . . . . . . . . . . . . . . . . . . . 31
•Time Search. . . . . . . . . . . . . . . . . . . . . . . 32
•Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
•Marker Search . . . . . . . . . . . . . . . . . . . . 32
•Disc Menu . . . . . . . . . . . . . . . . . . . . . . . . 32
•Title Menu . . . . . . . . . . . . . . . . . . . . . . . . 32
•Camera Angle . . . . . . . . . . . . . . . . . . . . . 33
•Changing the Audio Language . . . . . . . . . 33
•Changing the Audio Channel . . . . . . . . . . 33
•3D Surround . . . . . . . . . . . . . . . . . . . . . . 33
•Subtitles. . . . . . . . . . . . . . . . . . . . . . . . . . 33
•Finding Locations on a Disc . . . . . . . . . . . 33
•Last Condition Memory. . . . . . . . . . . . . . . 33
Audio CD and MP3 Operation. . . . . . . . . . . 34-35
Playing an Audio CD or MP3 Disc. . . . . . . . . . 34
Notes on MP3 Recordings . . . . . . . . . . . . . . . 34
•Pause . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
•Moving to Another Track. . . . . . . . . . . . . . 35
•Repeat. . . . . . . . . . . . . . . . . . . . . . . . . . . 35
•Random . . . . . . . . . . . . . . . . . . . . . . . . . . 35
•Search . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
•Repeat A-B . . . . . . . . . . . . . . . . . . . . . . . 35
Programmed Playback with Audio CD and MP3
. 36
•Repeat Programmed Tracks . . . . . . . . . . 36
•Erasing a Track from the Program List . . . 36
•Erasing the multi tracks
on the Program List . . . . . . . . . . . . . . . . . 36
•Changing the order of Program List . . . . . 36
Photo Disc Operation
. . . . . . . . . . . . . . . . . . . . . 37
Viewing a Photo Disc . . . . . . . . . . . . . . . . . . . 37
•Selecting other Files. . . . . . . . . . . . . . . . . 37
•To rotate the picture . . . . . . . . . . . . . . . . . 37
•To view Slide Show . . . . . . . . . . . . . . . . . 37
•Notes on JPEG Files . . . . . . . . . . . . . . . . 37
VCR Mode Tape Playback . . . . . . . . . . . . . . . . 38
Preparation. . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Normal Playback . . . . . . . . . . . . . . . . . . . . . . 38
•Tracking Control. . . . . . . . . . . . . . . . . . . . 38
Special Effect Playback. . . . . . . . . . . . . . . . . . 38
•Search . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
•Still Picture and
Frame-by-Frame Playback . . . . . . . . . . . . 38
•Slow Motion . . . . . . . . . . . . . . . . . . . . . . . 38
•Counter Memory Function . . . . . . . . . . . . 38
RECORDING
Basic Recording . . . . . . . . . . . . . . . . . . . . . 39-40
Basic Recording from a TV . . . . . . . . . . . . . . . 39
Instant Timer Recording . . . . . . . . . . . . . . . . . 39
Copying from DVD to VCR . . . . . . . . . . . . . . . 40
Copying from VCR to DVD . . . . . . . . . . . . . . . 40
Timer Recording . . . . . . . . . . . . . . . . . . . . . . . 41
Checking Timer Recording Details . . . . . . . . . 41
Canceling a Timer Recording . . . . . . . . . . . . . 41
Stopping a Timer Recording in Progress . . . . . 41
Timer Recording Troubleshooting . . . . . . . . . . 41
Recording from an External Input . . . . . . . 42-43
Recording from External Components. . . . . . . 42
Recording from a Digital Camcorder . . . . . . . . 42
Playing Recordings on Other DVD players
. . . . . 42
•Finalizing a Disc. . . . . . . . . . . . . . . . . . . . 42
What is DV? . . . . . . . . . . . . . . . . . . . . . . . . . . 43
•DV-Related Messages . . . . . . . . . . . . . . . 43
•Troubleshooting . . . . . . . . . . . . . . . . . . . . 43
EDITING
VR Mode: Original and Playlist Editing . . . 44-50
Titles, Chapters and Parts. . . . . . . . . . . . . . . . 44
Adding Chapter Markers . . . . . . . . . . . . . . . . . 44
Changing Title or Chapter Thumbnails . . . . . . 44
Using the Original (Title) menu . . . . . . . . . . . . 45
Using the Original (Chapter) menu . . . . . . . . . 45
Using the Playlist (Title) menu. . . . . . . . . . . . . 46
Using the Playlist (Chapter) menu. . . . . . . . . . 46
Naming a Title . . . . . . . . . . . . . . . . . . . . . . . . 47
Deleting an Original or Playlist Title/Chapter . . 47
Making a New Playlist. . . . . . . . . . . . . . . . . . . 48
Adding Titles/Chapters to the Playlist . . . . . . . 48
Combining Two Chapters Into One . . . . . . . . . 49
Moving a Playlist Chapter . . . . . . . . . . . . . . . . 49
Deleting a Part . . . . . . . . . . . . . . . . . . . . . . . . 50
Video Mode: Original editing . . . . . . . . . . . . . . 51
Using the Title List . . . . . . . . . . . . . . . . . . . . . 51
Deleting a Title . . . . . . . . . . . . . . . . . . . . . . . . 51
If the disc has already been finalized . . . . . . . 51
REFERENCE
Controlling Your TV
with the Supplied Remote . . . . . . . . . . . . . . . . 52
Language Code List. . . . . . . . . . . . . . . . . . . . . 53
Country Code List . . . . . . . . . . . . . . . . . . . . . . 54
Troubleshooting . . . . . . . . . . . . . . . . . . . . . 55-56
Specifications . . . . . . . . . . . . . . . . . . . . . . . 57-58
About the symbols for instructions
Indicates hazards likely to cause harm to the unit
itself or other material damage.
Indicates special operating features of this unit.
Indicates tips and hints for making the task easier.
INTRODUCTION
5
6
LGXBR342 Overview
Recordable Discs
12cm/8cm, single-sided, single layer disc
Approx. max. recording time (LP mode):
240 minutes (4.7GB), 80 minutes (1.46GB)
12cm/8cm, single-sided, single layer disc
Approx. max. recording time (LP mode):
240 minutes (4.7GB), 80 minutes (1.46GB)
otes
–This recorder cannot record CD-R or CD-RW discs.
–DVD-R/RW and CD-R/RW discs recorded using a
personal computer or a DVD or CD recorder may not
play if the disc is damaged or dirty, or if there is dirt of
condensation on the recorder’s lens.
–If you record a disc using a personal computer, even
if it is recorded in a compatible format, there are
cases in which it may not play because of the settings
of the application software used to create the disc.
(Check with the software publisher for more detailed
information.)
Playable Discs
DVD
(8 cm/12 cm disc)
Video CD (VCD)
(8 cm / 12 cm disc)
Audio CD
(8 cm/12 cm disc)
In addition, the VCR/DVD Recorder can play
DVD±R/DVD±RW discs, CD-R/CD-RW discs that
contain audio titles, MP3 files, SVCD file or JPEG files
and Kodak Picture CDs.
otes
–Depending on the conditions of the recording equip-
ment or the CD-R/RW (or DVD±R/±RW) disc itself,
some CD-R/RW (or DVD±R/±RW) discs cannot be
played on the unit.
–Do not attach any seal or label to either side (the
labeled side or the recorded side) of a disc.
–
Do not use irregularly shaped CDs (e.g., heart-shaped
or octagonal). Doing so may result in malfunctions.
Regional code of the VCR/DVD Recorder and DVDs
This VCR/DVD Recorder is designed and manu-
factured for playback of Region 1 encoded DVD
software. The region code on the labels of some
DVD discs indicates which type of VCR/DVD
Recorder can play those discs. This unit can play only
DVD discs labeled 1 or ALL. If you try to play any other
discs, the message “Incorrect region code. Can’t play-
back” will appear on the TV screen. Some DVD discs
may not have a region code label even though their play-
back is prohibited by area limits.
otes on DVDs and Video CDs
Some playback operations of DVDs and Video CDs
may be intentionally fixed by software manufacturers.
As this unit plays DVDs and Video CDs according to
disc content designed by the software manufacturer,
some playback features of the unit may not be available
or other functions may be added.
Refer also to the instructions supplied with the DVDs
and Video CDs. Some DVDs made for business pur-
poses may not be played on the unit.
Disc-related terms
Title (DVD only)
The main film content or accompanying feature content
or music album.
Each title is assigned a title reference number enabling
you to locate it easily.
Chapter (DVD only)
Sections of a picture or a musical piece that are smaller
than titles. A title is composed of one or several chap-
ters. Each chapter is assigned a chapter number to
enable you to locate the chapter you want. Depending
on the disc, chapters may not be labeled.
Track (Video CD and audio CD only)
Sections of a picture or a musical piece on a video CD
or an audio CD. Each track is assigned a track number,
enabling you to locate the track you want.
Scene
On a video CD with PBC (Playback Control), movies
and pictures are divided into “Scenes”. Each scene is
displayed on a menu and assigned a number, enabling
you to quickly locate the scene you want. A scene may
be composed of one or several tracks.
Types of video CDs
There are two types of video CDs:
Video CDs equipped with PBC (Version 2.0)
PBC (Playback control) allows you to interact with the
contents of a Video CD using menus, search functions,
and other special operations. High resolution pictures
can be displayed if they are included on the disc.
Video CDs not equipped with PBC (Version 1.1)
Video CDs without PBC are similar to audio CDs,
except they allow playback of video as well as sound.
1
INTRODUCTION
7
LGXBR342 Overview (Continued)
About DVD-R and DVD-RW disc
How are DVD-R and DVD-RW discs different?
The essential difference between DVD-R and DVD-RW
is that DVD-R is a record-once medium, while DVD-RW
is a re-recordable/erasable medium. You can re-record/
erase a DVD-RW disc approximately 1,000 times.
Can I play my recordable discs in a regular DVD
player?
Generally, DVD-R discs and DVD-RW discs recorded in
Video mode are playable in a regular DVD player, but
they must be ‘finalized’ first. This process fixes the con-
tents of the disc to make them readable to other DVD
players as DVD-Video discs.
DVD-RW discs recorded in VR (Video Recording) mode
are playable in some players.
This indicates a product feature that is capa-
ble of playing DVD-RW discs recorded with
Video Recording (VR) format.
What are “Recording modes”?
There are two recording modes available using this
recorder: VR mode and Video mode. When recording to
a DVD-R disc, recordings are always in Video mode.
DVD-RW discs can be formatted for VR mode recording
or Video mode recording.
VR mode recording
•3 different picture quality/recording time settings avail-
able (SP, LP, XP)
•Not playable on regular DVD players
•Recordings can be extensively edited
Video mode recording
•3 different picture quality/recording time settings avail-
able (SP, LP, XP)
•Playable on regular DVD players (after finalizing)
•Limited editing features
Many functions of this recorder are dependent on the
recording mode. One or more of the symbols
( , ) appears by each function explained
in this manual so that you can see at a glance whether
it’s relevant for the disc loaded.
You can find more information on disc formats and
recording modes on next page.
ote
DVD-Video Format (Video mode) is a new format for
recording on DVD-R/RW discs that was approved by
the DVD Forum in 2000. You may therefore experience
problems playing recordable DVD discs in some play-
ers. Symptoms include video artifacts, audio and/or
video dropouts and playback suddenly stopping.
Our company cannot take responsibility for problems
playing discs recorded on this VCR/DVD Recorder in
other players.
Is editing a DVD like editing a video tape?
No. When you edit a video tape you need one video
deck to play the original tape and another to record the
edits. With DVD, you edit by making a ‘Playlist’ of what
to play and when to play it. On playback, the VCR/DVD
Recorder plays the disc according to the Playlist.
About word ‘Original’ and ‘Playlist’
Throughout this manual, you will often see the words
Original and Playlist to refer to the actual content and
the edited version.
•Original: content refers to what’s actually recorded
on the disc.
•Playlist: content refers to the edited version of the
disc — how the Original content is to be played.
About DVD recording
otes
•This recorder cannot make recordings on CD-R or
CD-RW discs.
•Our company takes no responsibility for recording fail-
ure due to power cuts, defective discs, or damage to
the recorder.
•Fingerprints and small scratches on a disc can affect
playback and/or recording performance. Please take
proper care of your discs.
Disc types and recording formats, modes,
and settings
This recorder can play three different kinds of DVD disc:
pre-recorded DVD-Video discs, DVD-RW and DVD-R
discs. The disc format for DVD-R discs is always “Video
format”—the same as pre-recorded DVD-Video discs.
This means that once finalized, you can play a DVD-R
in a regular DVD player.
The recording mode is closely related to the disc for-
mat. If the disc format is Video Recording format, then
the recording mode is VR mode; if the disc format is
Video mode, then the recording mode is Video mode
(except for DVD-Video, which is not recordable, and so
does not have a recording mode).
Within the recording modes (which are fixed for the
whole disc) are the record settings. These can be
changed as required for each recording and determine
the picture quality and how much space the recording
will take up on the disc.
VR
Video
LGXBR342 Overview (Continued)
Notes for recording
•The recording times shown are not exact because the
VCR/DVD Recorder uses variable bit-rate video com-
pression. This means that the exact recording time
will depend on the material being recorded.
•When recording a TV broadcast, if the reception is
poor or the picture contains interference, the record-
ing times may be shorter.
•If you record still pictures or audio only, the recording
time may be longer.
•The displayed times for recording and time remaining
may not always add up to exactly the length of the
disc.
•The recording time available may decrease if you
heavily edit a disc.
•If using a DVD-RW disc, make sure you change the
recording format (Video mode or VR mode) before
you record anything on the disc. See page 24 (DISC
Initialize) for how to do this.
•When using a DVD-R disc, you can keep recording
until the disc is full, or until you finalize the disc.
Before you start a recording session, check the
amount of recording time left on the disc.
•When using a DVD-RW disc in Video mode, recording
time available will only increase if you erase the last
title recorded on the disc.
•The Erase Title option in the Original (Title) menu only
hides the title, it does not actually erase the title from
the disc and increase the recording time available
(except for the last recorded title on a DVD-RW disc
in Video mode).
Recording TV audio channels
This recorder can record one or two channel audio. For
TV broadcasts, this usually means mono or stereo, but
some programs are broadcast with a main and a SAP
(Secondary Audio Program) audio channel.
If you’re recording in Video mode (or in VR mode), you
can record either the main audio or the SAP audio.
Restrictions on video recording
•You cannot record copy-protected video using this
recorder. Copy-protected video includes DVD-Video
discs and some satellite broadcasts. If copy-protected
material is encountered during a recording, recording
will pause or stop automatically and an error message
will be displayed on-screen.
•Video that is ‘copy-once only’ can only be recorded
using a DVD-RW disc in VR mode with CPRM (see
below).
What is ‘CPRM’?
CPRM is a copy protection system (with scramble sys-
tem) only allowing the recording of ‘copy once’ broad-
cast programs. CPRM stands for Content Protection for
Recordable Media.
This recorder is CPRM compatible, which means that
you can record copy-once broadcast programs, but you
cannot then make a copy of those recordings. CPRM
recordings can only be made on DVD-RW discs format-
ted in VR mode, and CPRM recordings can only be
played on players that are specifically compatible with
CPRM.
Copyright
•Audio and video recordings you make using this
recorder are for your personal use only. You may not
sell, lend or rent them to other people.
•This product incorporates copyright protection tech-
nology that is protected by method claims of certain
U.S.patents and other intellectual property rights
owned by Macrovision Corporation and other rights
owners. Use of this copyright protection technology
must be authorized by Macrovision Corporation, and
is intended for home and other limited viewing uses
only unless otherwise authorized by Macrovision cor-
poration. Reverse engineering or disassembly is pro-
hibited.
8
Disc type Disc format Recording mode Functions
DVD-Video Video format n/a Playback only
DVD-RW Video Recording VR mode Playback, recording, Original/Playlist editing
format (default)
Video format Video mode Playback, limited recording, limited editing
DVD-R Video format Video mode Playback, limited recording, limited editing
DVD+R Video format n/a Playback only
DVD+RW Video format n/a Playback only
INTRODUCTION
9
LGXBR342 Overview (Continued)
Precautions
Handling the unit
When shipping the unit
The original shipping carton and packing materials
come in handy. For maximum protection, re-pack the
unit as it was originally packaged at the factory.
When setting up the unit
The picture and sound of a nearby TV, VCR, or radio
may be distorted during playback. In this case, position
the unit away from the TV, VCR, or radio, or turn off the
unit after removing the disc.
To keep the surface clean
Do not use volatile liquids, such as insecticide spray,
near the unit. Do not leave rubber or plastic products in
contact with the unit for a long period of time. They will
leave marks on the surface.
Cleaning the unit
To clean the cabinet
Use a soft, dry cloth. If the surfaces are extremely dirty,
use a soft cloth lightly moistened with a mild detergent
solution. Do not use strong solvents such as alcohol,
benzine, or thinner, as these might damage the surface
of the unit.
To obtain a clear picture
The VCR/DVD Recorder is a high-tech, precision
device. If the optical pick-up lens and disc drive parts
are dirty or worn, the picture quality will be poor.
Regular inspection and maintenance are recommended
after every 1,000 hours of use. (This depends on the
operating environment.)
For details, please contact your nearest dealer.
Remote Control Operation Range
Point the remote control at the remote sensor and press
the buttons.
Distance: About 23 ft (7 m) from the front of the
remote sensor.
Angle: About 30° in each direction of the front of the
remote sensor.
Remote Control Battery Installation
Detach the battery cover on the rear of
the remote control, and insert two AAA
batteries with and aligned cor-
rectly.
Caution
Do not mix old and new batteries. Never mix different
types of batteries (standard, alkaline, etc.).
Notes on Discs
Handling discs
Do not touch the playback side of the disc. Hold the
disc by the edges so that fingerprints will not get on the
surface. Do not stick paper or tape on the disc.
Storing discs
After playing, store the disc in its case.
Do not expose the disc to direct sunlight or sources of
heat, or leave it in a parked car exposed to direct sun-
light, as there may be a considerable temperature
increase inside the car.
Cleaning discs
Fingerprints and dust on the disc can cause poor pic-
ture quality and sound distortion. Before playing, clean
the disc with a clean cloth. Wipe the disc from the cen-
ter outward.
Do not use strong solvents such as alcohol, benzine,
thinner, commercially available cleaners, or anti-static
spray intended for older vinyl records.
About Symbols
About the symbol display
“ ” may appear on the TV screen during operation.
This icon means the function explained in this owner’s
manual is not available on that specific disc.
About the disc symbols for instructions
Asection whose title has one of the following symbols are
applicable only to those discs represented by the symbol.
DVD-R/RW with Video recording mode
DVD-RW with VR recording mode
DVD-Video disc
Video CDs.
Audio CDs.
MP3 Discs.
JPEG Discs.
VHS Tape.
VHS
JPEG
MP3
CD
VCD
DVD
VR
Video
NoYes
10
Front Panel
REC (z) button
Starts recording. Press
repeatedly to set the
recording time.
CHANNEL (v/ V)
Scans up or down
through memorized
channels.
PLAY (N)
To play back a disc or tape.
OPEN/CLOSE (Z)
Opens or closes the disc tray.
AV2 IN (VIDEO / AUDIO (Left/Right))
Connect the audio/video output of an external source
(Audio system, TV/ Monitor, VCR, Camcorder, etc.).
S-VIDEO IN
Connect the S-Video output of an external source
(TV/ Monitor, VCR, Camcorder, etc.).
DV INPUT
Connect the DV output of a
digital camcorder.
PAUSE/STEP (X/C)
Pause playback or recording
temporarily/press repeatedly for
frame-by-frame playback.
Disc Tray (DVD deck)
Insert a disc here.
POWER button and indicator
Switches the VCR/DVD Recorder ON and OFF.
Lights green when the VCR/DVD Recorder is turned on.
STOP (x)
Stops playback.
COPY
Press to copy DVD to VCR
(or VCR to DVD).
Cassette Compartment (VCR deck)
Insert a video cassette here.
EJECT
Ejects the tape in the VCR deck.
DVD/VCR
Toggles control between the DVD
deck and the VCR deck.
FORWARD (M/>)
DVD: Go to NEXT chapter/track. Press and hold for two seconds for a fast forward search.
VCR: Advances the tape during the STOP mode or for fast forward picture search.
BACKWARD (./m)
DVD: Go to beginning of current chapter/track or to previous chapter/track.
Press and hold for a fast reverse search.
VCR: Rewinds the tape during the STOP mode or for fast reverse picture search.
Display window
Shows the current status of
the VCR/DVD Recorder.
Remote Sensor
Point the VCR/DVD Recorder
remote control here.
11
INTRODUCTION
Function Display Window
DVD
PRG TTL VR TRK CHP TV SAP COPY
Hi-Fi ST
XP SP S LP
SVCD
AB
-R W
REC
ST Indicates a stereo broadcast is
being received.
Disc type indicators
Indicates the type of disc loaded.
Hi-Fi Indicates when the VCR/DVD Recorder is playing
or recording a tape in Hi-Fi.
COPY Indicates that a DVD to VCR (or VCR to DVD)
copy is in progress.
SAP Indicates when a SAP BILINGUAL broadcast is being received.
Character indicators
Indicates clock, total playing time, elapsed time, remaining
time, title number, chapter/track number, channel, etc.
REPEAT Indicates repeat mode.
REC The recorder is
recording.
Indicates when the recorder
is in timer recording or a timer
recording is programmed.
SP, SLP, LP, XP
Indicates the current Recording mode.
PRG Programmed playback active
TTL Indicates current title.
Adisc is inserted in the DVD deck.
AVHS tape is inserted in the VCR deck.
Indicates a DVD-RW disc (VR mode only) is inserted in the
DVD deck.
CHP/TRK Indicates current chapter or track number
TV The unit’s functions are available and channels
are selected at TV.
Indicates when the VCR/DVD Recorder is Locked.
12
Remote Control Overview
POWER
Turns VCR/DVD Recorder ON and OFF.
DVD
Select the VCR/DVD Recorder’s func-
tion mode to DVD.
VCR
Select the VCR/DVD Recorder’s func-
tion mode to VCR.
INPUT
Changes the input to use for recording
(Tuner, AV1, AV2, or DV IN).
0-9 numerical buttons
Selects numbered options in a menu.
Selects TV’s channel.
TV/VCR
To view channels selected by the VCR
tuner or by the TV tuner.
BACKWARD / FORWARD (m/M)
-
DVD: Search backward or forward.
- VCR: Rewinds/Advances the tape dur-
ing the STOP mode, for fast reverse/
forward picture search.
SKIP (./ >)
Go to next chapter or track. Returns to
beginning of current chapter or track or
go to previous chapter or track.
PAUSE/STEP (X)
Pause playback or recording temporari-
ly, press again to exit pause mode.
press repeatedly for frame-by-frame
playback.
N(PLAY)
Starts playback.
STOP (x)
Stops playback or recording.
AUDIO
Selects an audio language (DVD).
SUBTITLE
Selects a subtitle language.
ANGLE
Selects a DVD camera angle,
if available.
ZOOM
Enlarges DVD video image.
REPEAT
Repeat chapter, track, title or all.
A-B
Repeats sequence between two points
(A and B)
RANDOM
Plays tracks in random order.
LOCK
Locks/unlocks front panel buttons.
EJECT, OPEN/CLOSE
- Opens and closes the disc tray.
- Ejects the tape in the VCR deck.
TV Control Buttons
-POWER: Switches TV ON and OFF.
-INPUT: Selects the TV’s source.
-CH +/–: Selects TV’s channel.
-VOL +/–: Adjusts TV’s volume.
-MUTE: Turns on or off TV sound.
REC (z)
Starts recording. Press repeatedly to set
the recording time.
TIMER REC
Displays Timer Record menu.
REC MODE
Selects the recording mode:
- DVD : SP, LP, or XP.
- VCR : SP or SLP.
MARKER
Marks any point during playback.
SEARCH
Displays Marker Search menu.
COPY
Press to copy DVD to VCR (or VCR to
DVD).
LIST / DISC MENU
Accesses menu on a DVD disc.
Switches between Original and Playlist
editing in VR mode.
SETUP
Accesses or removes the Setup menu.
DISPLAY
Accesses On-Screen Display.
Displays information while viewing a TV
program.
RETURN (O)
-Removes the menu.
bBvV(left/right/up/down)
Selects menu options.
CH/TRK(v/V): Selects a program.
Adjusts manually the tape’s picture
onscreen.
ENTER
Confirms menu selections.
TITLE
Displays the disc’s Title menu, if
available.
CHP ADD
Inserts a chapter marker when playing/
recording a DVD-RW disc in VR mode.
THUMBNAIL
Selects a thumbnail picture for the
current title for use in the Original (Title).
CLEAR
Removes a mark on the Marker Search
menu.
LOCK
The Lock feature disables the
front panel buttons to prevent
children from tampering with
the VCR/DVD Recorder.
Simply press LOCK on the
remote control to toggle this
feature on and off.
INTRODUCTION
13
Rear Panel
Caution
Do not touch the inner pins of the jacks on the rear
panel. Electrostatic discharge may cause permanent
damage to the unit.
ANT.IN
Connect the VHF/UHF/CATV antenna to this terminal.
COAXIAL (DIGITAL AUDIO OUT jack)
Connect to digital (coaxial) audio equipment.
AUDIO OUT (Left/Right)
Connect to a TV or other equipment with audio
inputs.
A/V OUT (VIDEO OUT/AUDIO OUT (Left/Right))
Connect to a TV with video and audio inputs.
COMPONENT/PROGRESSIVE SCAN VIDEO OUT
(Y Pb Pr)
Connect to a TV with Y Pb Pr inputs.
AV 1 IN (VIDEO IN /AUDIO IN (Left/Right))
Connect the audio/video output of an external source
(Audio system, TV/Monitor, VCR, Camcorder).
AC Power Cord
Plug into the
power source.
S-VIDEO OUT
Connect to a S-Video Input on TV.
OPTICAL (Digital audio out jack)
Connect to digital (optical) audio equipment.
RF. OUT (DVD/VCR OUT)
Connect to a TV with RF coaxial inputs.
Connections
ips
Depending on your TV and other equipment you wish
to connect, there are various ways you could connect
the VCR/DVD Recorder. Use only one of the connec-
tions described below.
Please refer to the manuals of your TV, VCR, Stereo
System or other devices as necessary to make the
best connections.
For better sound reproduction, connect the recorder’s
AUDIO OUT jacks to the audio in jacks of your
amplifier, receiver, stereo or audio/video equipment.
See “Connecting to Optional Equipment” on page 16.
Caution
Make sure the VCR/DVD Recorder is connected
directly to the TV. Tune the TV to the correct video
input channel.
Do not connect the VCR/DVD Recorder’s AUDIO
OUT jack to the phono in jack (record deck) of your
audio system.
Do not connect your VCR/DVD Recorder via your
VCR. The DVD image could be distorted by the copy
protection system.
Connecting Antenna/Cable TV to
VCR/DVD Recorder
11
Disconnect the antenna leads from the rear of the
TV.
22
Identify the type of cable from your antenna. If it is
a round cable as illustrated, it is a 75 ohm coaxial
antenna cable. This cable will connect directly to
the jack marked ANT.IN on your Recorder.
ip
If your antenna lead wire is a flat type antenna cable,
connect it to an Antenna Adapter (300-ohm to 75-ohm)
(not supplied) and slip the Adapter onto the ANT.IN
jack. The Adapter does not screw on to the VCR/DVD
Recorder, it just slips over the jack.
Cable Service Without Cable Box
If your cable wire is connected to your TV without a converter
or descrambler box, unscrew the wire from your TV and attach
it to the ANT.IN jack on the VCR/DVD Recorder. Use the
supplied round coaxial cable to connect between the
VCR/DVD Recorder’s OUT TO TV jack and the 75 ohm anten-
na input jack on the TV. With this connection, you can receive
all midband, super band, and hyperband channels. (All cable
channels.)
Cable Service With Cable Box
If a converter is required in your cable system, follow the
instruction below:
The cable hookup permits both TV and VCR/DVD Recorder
operation.
To view or record a CATV channel
1
Tune the TV to the correct video input channel.
2Set the VCR/DVD Recorder channel selector to the output
channel of the Cable Converter box using CH (v/ V) or
number (0-9) of your VCR/DVD Recorder. (Example: CH3)
3Select the channel to view at the Cable Converter Box.
ote
If you are using a cable box to tune channels, it is not neces-
sary to do Auto Channel Set as indicated on page 18.
14
Antenna Antenna
Flat Wire
(300 ohm)
300/75 ohm
Adaptor
(Not supplied)
Cable TV
Wall Jack
OR OR
Rear of VCR/DVD Recorder
Cable TV
Wall Jack
Back Panel of
Typical Cable Box
Rear of VCR/DVD Recorder
DVR HOOKUP
15
Connections (Continued)
Connecting to a TV
Make one of the following connections, depending on
the capabilities of your existing equipment.
RF coaxial connection
Connect the RF.OUT jack on the VCR/DVD Recorder to
the antenna in jack on the TV using the 75-ohm Coaxial
Cable supplied (R).
ote
If you use this connection, tune the TV to the VCR/DVD
Recorder’s RF output channel (CH 3 or 4).
How to set the VCR/DVD Recorder’s RF output
channel
When the
VCR/DVD Recorder
is turned off,
press and
hold CH (v/V) on the front panel for about five
seconds to change the RF output channel (CH 03 or
CH 04). “RF 03” or “RF 04” appears in the display win-
dow.
Audio/Video connection
11
Connect the VIDEO OUT jack on the VCR/DVD
Recorder to the video in jack on the TV using the
video cable (V).
22
Connect the Left and Right AUDIO OUT jacks from
the VCR/DVD Recorder to the audio left/right in
jacks from the TV using the audio cables (A).
S-Video connection
11
Connect the S-VIDEO OUT jack on the VCR/DVD
Recorder to the S-Video in jack on the TV using the
S-Video cable (S).
22
Connect the Left and Right AUDIO OUT jacks from
the VCR/DVD Recorder to the audio left/right in
jacks on the TV using the audio cables (A).
Component Video (Color Stream®) connection
11
Connect the COMPONENT/PROGRESSIVE SCAN
VIDEO OUT jacks on the VCR/DVD Recorder to
the corresponding in jacks on the TV using an Y Pb
Pr cable (C).
22
Connect the Left and Right AUDIO OUT jacks from
the VCR/DVD Recorder to the audio left/right in
jacks on the TV using the audio cables (A).
Progressive Scan (ColorStream®pro) connection
If your television is a high-definition or “digital ready”
television, you may take advantage of the VCR/DVD
Recorder’s progressive scan output for the highest
video resolution possible.
If your TV does not accept the Progressive Scan for-
mat, the picture will appear scrambled if you try
Progressive Scan on the VCR/DVD Recorder.
11
Connect the COMPONENT/PROGRESSIVE SCAN
VIDEO OUT jacks on the VCR/DVD Recorder to
the corresponding in jacks on the TV using an
optional Y Pb Pr cable (C).
22
Connect the Left and Right AUDIO OUT jacks from
the VCR/DVD Recorder to the audio left/right in
jacks on the TV using the supplied audio cables
(A).
otes
–Set Progressive Scan option to “ON” in the General
menu, see page 20.
–Progressive Scan does not work with the RF,
Audio/Video or S-Video connections.
ANTENNA
INPUT
L
R
Y
Pb
Pr
COMPONENT/PROGRESSIVE VIDEO INPUT
AUDIO INPUT
VIDEO
INPUT
S-VIDEO
INPUT
R
Rear of TV
Rear of VCR/DVD Recorder
S AV C
Connections (Continued)
16
Connecting to Optional Equipment
Connecting to an amplifier equipped with two
channel analog stereo or Dolby Pro Logic ll/
Pro Logic
Connect the Left and Right AUDIO OUT jacks on the
VCR/DVD Recorder to the audio left and right in jacks
on your amplifier, receiver, or stereo system, using the
audio cables (A).
Connecting to an amplifier equipped with two
channel digital stereo (PCM) or to an Audio/
Video receiver equipped with a multi-channel
decoder (Dolby Digital™, MPEG 2, or DTS)
11
Connect one of the VCR/DVD Recorder’s DIGITAL
AUDIO OUT jacks (OPTICAL Oor COAXIAL X) to
the corresponding in jack on your amplifier. Use an
optional digital (optical Oor coaxial X) audio cable.
22
You will need to activate the VCR/DVD Recorder’s
digital output. (See “AUDIO” on page 21).
Digital Multi-channel sound
Adigital multi-channel connection provides the best
sound quality. For this you need a multi-channel
Audio/Video receiver that supports one or more of the
audio formats supported by your VCR/DVD Recorder
(MPEG 2, Dolby Digital and DTS). Check the receiver
manual and the logos on the front of the receiver.
Caution:
Due to the DTS Licensing agreement, the digital output
will be in DTS digital out when DTS audio stream is
selected.
otes
–
If the audio format of the digital output does not match
the capabilities of your receiver, the receiver will
produce a strong, distorted sound or no sound at all.
–Six Channel Digital Surround Sound via digital con-
nection can only be obtained if your receiver is
equipped with a Digital Multi-channel decoder.
–To see the audio format of the current DVD in the on-
screen display, press AUDIO.
ote
This VCR/DVD Recorder does not perform internal (2
channel) decoding of a DTS sound track. To enjoy DTS
multi channel surround, you must connect this
VCR/DVD Recorder to a DTS compatible receiver via
one of this VCR/DVD Recorder’s digital audio outputs.
Amplifier (Receiver)
Rear of VCR/DVD Recorder
A XO
R
L
AUDIO INPUT DIGITAL INPUT
COAXIAL
DIGITAL INPUT
OPTICAL
DVR HOOKUP
17
Accessory Audio/Video (A/V)
Connections to VCR/DVD Recorder
Connect the AV 1 IN or AV 2 IN jacks on the VCR/DVD
Recorder to the audio/video out jacks on your accesso-
ry component, using optional audio/video cables.
ote
If you use the S-VIDEO IN jack on the front panel, the
VIDEO jack on the front panel is not available.
Connecting a Digital Camcorder
Using the front panel DV IN jack, it is possible to con-
nect a DV digital camcorder or video deck or
DVD-R/RW recorder and digitally transfer DV tapes or
DVD-R/RW discs to DVD-R/RW.
Use a DV cable (not supplied) to connect the DV in/out
jack of your DV Digital Camcorder to the front panel DV
IN jack of this VCR/DVD Recorder.
ote
This jack is for connection to DV equipment only. It is
not compatible with digital satellite tuners or D-VHS
video decks.
Connections (Continued)
DV Digital Camcorder
Front of VCR/DVD Recorder
DV
IN/OUT
18
Initial Settings
In this menu system, there are several ways to cus-
tomize the settings provided. Most menus consist of
three levels to set up the options, but some require
greater depth for the variety of settings. If you press
SETUP, only the first and second level of the menu sys-
tem will appear on the TV screen. The third level can be
displayed by pressing B. For navigating the menu lev-
els, you will see “B” on the right side of the menu label
to help you go to the next level.
To bring up and exit the Menu:
Press SETUP to bring up the menu. A second press of
SETUP will take you back to initial screen.
To go to the next level:
Press Bon the remote control.
To go back to the previous level:
Press bon the remote control.
General Operation
11
Press SETUP.
The Setup menu appears.
22
Use v/ Vto select the desired option.
33
While the desired item is selected, press Bto
move to the second level.
44
Use v/ Vto select the second desired option.
55
Press Bto move to the third level.
66
Use v/ Vto select the desired setting then
press ENTER to confirm your selection.
Some items require additional steps.
77
Press SETUP to exit the Setup menu.
GENERAL
Tuning Band Select
11
Press SETUP.
The Setup menu appears.
22
Use v/ Vto select the GENERAL option.
33
While the GENERAL option is selected, press B
to move to the second level.
44
Use v/ Vto select the Tuning Band option.
55
Press Bto move to the third level.
66
Use v/ Vto select the tuning band option (TV
or CATV) then press ENTER.
TV: If you are using a standard antenna to receive channels.
CATV: If you are using basic cable to receive channels.
Auto Channel Set
This VCR/DVD Recorder is equipped with a frequency
synthesized tuner capable of receiving up to 181
channels. These include VHF channels 2-13, UHF
channels 14-69 and CATV channels 1-125.
Preparation:
Connect the VCR/DVD Recorder to the desired type of
antenna or cable TV system, as shown in “Connecting
Antenna/Cable TV to VCR/DVD Recorder” on page 14
11
Press SETUP.
The Setup menu appears.
22
Use v/ Vto select the GENERAL option.
33
While the GENERAL option is selected, press B
to move to the second level.
44
Use v/ Vto select the Auto Channel Set option.
55
Press Bto move to the third level.
Start icon is highlighted.
66
Press ENTER to begin the channel search.
The tuner will automatically cycle through all
available channels in the area and place them in
the tuner’s memory.
ote
After the Auto Channel Set proceeding is complete,
make sure the Tuning Band is set appropriately (TV or
CATV) on tuning band, follow steps 1~6 as shown pre-
vious (Tuning Band Select) to choose the correct Tuning
Band (TV or CATV).
Before Operation
Tuning Band
Auto Channel Set
CH. Add/Del
Clock
TV Aspect Ratio
Progressive Scan
Factory Setting
Prev. Select
TV
CATV
Tuning Band
Auto Channel Set
CH. Add/Del
Clock
TV Aspect Ratio
Progressive Scan
Factory Setting
11%
Stop
Prev. Select
DVR HOOKUP
19
Before Operation (Continued)
To Add or Erase Channels from Memory
This feature allows you to add to or erase channels
from memory manually.
11
Follow steps 1-3 as shown above to the previ-
ous page (Auto Channel Set).
22
Use v/ Vto select the CH. Add/Del option.
33
Press Bto move to the third level.
Edit icon is highlighted.
44
Press ENTER.
The Channel Edit menu appears.
55
Use v/ Vor number buttons to select a channel
to add or delete then press ENTER.
Add or Delete icon is highlighted.
66
Press ENTER to confirm your setting.
77
Repeat steps 5-6 to add or erase additional
channels.
Auto Clock Set
The VCR/DVD Recorder gives you two ways to set the
time and date: the Auto Clock Feature or manually. The
Auto Clock Feature enables the VCR/DVD Recorder to
set up the clock when the VCR/DVD Recorder is turned
off.
The Clock Set feature is set to Auto at the factory. In the
“Auto” setting, the VCR/DVD Recorder looks for a chan-
nel carrying XDS (Extended Data Services) information.
XDS updates the clock using the Coordinated Universal
Time.
11
Press SETUP.
The Setup menu appears.
22
Use v/ Vto select the GENERAL menu.
33
While the GENERAL menu is selected, press B
to move to the second level.
44
Use v/ Vto select the Clock option.
55
Press Bto move to the third level.
66
Use v/ Vto select the Auto option then press
ENTER.
The Auto option is set at the factory. In the Auto option,
the VCR/DVD Recorder looks for a channel carrying XDS
(Extended Data Services) information. XDS updates the
clock using the Coordinated Universal Time.
77
Use v/ Vto choose your Time Zone.
You can set your local Time Zone manually. When
Timezone is set to Auto, the VCR/DVD Recorder will use
XDS information to determine the proper setting.
88
Use Bto choose the Daylight Savings option.
Use v/ Vto choose Auto, On, or Off.
You can turn Daylight Savings On or Off manually. When
it is set to Auto, the VCR/DVD Recorder will use XDS
information to determine the proper setting.
99
Press ENTER to confirm your setting, then
press SETUP to exit the Setup menu.
ote
If your local TV station does not send date and time informa-
tion, or sends incorrect information, you can
set the clock man-
ually.
Manual Clock Set
11
Follow steps 1-5 as shown above to the left
(Auto Clock Set).
22
Use v/ Vto select the Manual option then
press ENTER.
33
Enter the necessary information for date and
time.
b/ B(left/right): Moves the cursor to the previous
or next column.
v/ V(up/down): Changes the setting at the current
cursor position.
44
Press ENTER to confirm your setting, then
press SETUP to exit the Setup menu.
Tuning Band
Auto Channel Set
CH. Add/Del
Clock
TV Aspect Ratio
Progressive Scan
Factory Setting Time Zone
Manual
Auto
Auto
Daylight
Savings
Auto
Prev. Select
Tuning Band
Auto Channel Set
CH. Add/Del
Clock
TV Aspect Ratio
Progressive Scan
Factory Setting
AM
Manual
Auto
Year
Date
Time
Select
12
2003
00
11
/
:
Ch. 2 Delete
Add
0-9 Input Return
20
Before Operation (Continued)
TV Aspect Ratio
4:3 Letter Box: Select when a standard 4:3 TV is con-
nected. Displays theatrical images with masking bars
above and below the picture.
4:3 Pan Scan: Select when a standard 4:3 TV is con-
nected. Displays pictures cropped to fill your TV screen.
Both sides of the picture are cut off.
16:9 Wide: Select when a 16:9 wide TV is connected.
Progressive Scan
Progressive Scan Video provides the highest quality
pictures with less flickering.
•If you are using the COMPONENT/PROGRESSIVE
SCAN VIDEO OUT jacks, but are connecting the
VCR/DVD Recorder to a standard (analog) televi-
sion, set Progressive Scan to OFF.
•If you are using the COMPONENT/PROGRESSIVE
SCAN VIDEO OUT jacks for connection to a TV or
monitor that is compatible with a progressive scan
signal, set Progressive Scan to ON.
Caution
Once the setting for Progressive Scan output is entered,
an image will only be visible on a Progressive Scan
compatible TV or monitor. If you set Progressive Scan
to ON in error, you must reset the VCR/DVD Recorder.
First, remove the disc in the VCR/DVD Recorder. Next,
press STOP (x) and hold it for five seconds before
releasing it. The video output will be restored to the
standard setting, and a picture will once again be visible
on a conventional analog TV or monitor.
Factory Setting
If you wish, you can reset the VCR/DVD Recorder to its
original factory settings. Select “SET” then press
ENTER.
The Initialize menu will appear. Use the b B buttons to
select “Yes” and press ENTER.
ote
Some options cannot be reset. (Movie Rating, Password and
Country Code)
LANGUAGE
Display Menu
Select a language for the Setup menu and on-screen
display.
Disc Language
Select a language for the disc’s Menu, Audio, and Subtitle.
Original : The original language set for the disc is selected.
Other : To select another language, select Other option then
press ENTER. Use the numbered buttons to key-in the corre-
sponding 4-digit number according to the language code list on
page 53. If you enter the wrong number, press brepeatedly to
delete one by one and correct it.
Tuning Band
Auto Channel Set
CH. Add/Del
Clock
TV Aspect Ratio
Progressive Scan
Factory Setting ON
OFF
Prev. Select
Tuning Band
Auto Channel Set
CH. Add/Del
Clock
TV Aspect Ratio
Progressive Scan
Factory Setting
4:3 Letter Box
4:3 Pan Scan
16:9 Wide
Prev. Select
Tuning Band
Auto Channel Set
CH. Add/Del
Clock
TV Aspect Ratio
Progressive Scan
Factory Setting SET
Prev. Select
Display Menu
DISC Menu
DISC Audio
DISC Subtitle
English
Prev. Select
Display Menu
DISC Menu
DISC Audio
DISC Subtitle
English
French
Spanish
Italian
Japanese
Chinese
Other - - - -
Original
Prev. Select
21
DVR HOOKUP
Before Operation (Continued)
AUDIO
Each DVD disc has a variety of audio output options.
Set the
VCR/DVD Recorder’s
Audio Output according to
the type of audio system you use.
Dolby Digital
PCM: Select when connected to a 2-channel digital stereo
amplifier. The VCR/DVD Recorder’s digital audio outputs
sounds in the PCM 2ch format when you play a DVD video
disc recorded on the Dolby Digital recording system.
Bitstream: Select
when connected to a
Dolby Digital
decoder (or an amplifier or other equipment with a
Dolby Digital decoder).
DTS
OFF: The DTS signal will not be output from the DIGI-
TAL AUDIO OUT jack.
Bitstream: Select when connected to a DTS decoder
(or an amplifier or other equipment with a DTS
decoder).
MPEG
PCM: Select when connected to a 2-channel digital
stereo amplifier. The VCR/DVD Recorder’s digital audio
outputs sounds in the PCM 2ch format when you play a
DVD video disc recorded on the MPEG1, or MPEG2
recording system.
Bitstream: Select
when connected to a
n MPEG decoder
(or an amplifier or other equipment with an MPEG
decoder).
Sampling Freq. (Frequency)
If your receiver or amplifier is NOT capable of handling
96 kHz signals, select 48 kHz. When this choice is
made, this VCR/DVD Recorder will automatically con-
vert any 96 kHz signals to 48 kHz so your system can
decode them.
If your receiver or amplifier is capable of handling
96 kHz signals, select 96 kHz. When this choice is
made, this unit will pass each type of signal through
without any further processing.
DRC (Dynamic Range Control)
With the DVD format, you can hear a program’s sound-
track in the most accurate and realistic presentation
possible, thanks to digital audio technology. However,
you may wish to compress the dynamic range of the
audio output (the difference between the loudest sounds
and the quietest ones). Then, you may listen to a movie
at a lower volume without losing clarity of sound. Set
DRC to ON for this effect.
Vocal
Set Vocal to ON only when a multi-channel karaoke
DVD is playing. The karaoke channels on the disc will
mix into normal stereo sound.
Dolby Digital
DTS
MPEG
Sampling Freq.
DRC
Vocal
Bitstream
OFF
Prev. Select
Dolby Digital
DTS
MPEG
Sampling Freq.
DRC
Vocal
96KHz
48KHz
Prev. Select
Dolby Digital
DTS
MPEG
Sampling Freq.
DRC
Vocal
ON
OFF
Prev. Select
Dolby Digital
DTS
MPEG
Sampling Freq.
DRC
Vocal ON
OFF
Prev. Select
Dolby Digital
DTS
MPEG
Sampling Freq.
DRC
Vocal
Bitstream
PCM
Prev. Select
Dolby Digital
DTS
MPEG
Sampling Freq.
DRC
Vocal
Bitstream
PCM
Prev. Select
Before Operation (Continued)
LOCK (Parental Control)
Movie Rating
Movies on DVDs may contain scenes not suitable for
children. Therefore, discs may contain Parental Control
information that applies to the complete disc or to
certain scenes on the disc. These scenes are rated
from Level 1 to 8, and alternatively, more suitable
scenes are available for selection on some discs.
Ratings are country-dependent. The Parental Control
feature allows you to prevent discs from being played
by your children or to have certain discs played with
alternative scenes.
11
Press SETUP.
The Setup menu appears.
22
Use v/ Vto select the LOCK option.
33
While the LOCK option is selected, press Bto
move to the second level.
44
Use v/ Vto select the Movie Rating option.
55
Press Bto move to the third level.
66
When you have not entered a password yet.
Enter a 4-digit password using the numbered but-
tons to create a personal 4-digit security password.
Enter the 4-digit password again to confirm.
When you have already entered a password;
Enter a 4-digit password using the numbered but-
tons to confirm the personal 4-digit security pass-
word.
ip
If you enter the wrong number, press brepeatedly to
delete password numbers one by one then correct it.
77
Select a rating from 1 to 8 using the v/ Vbut-
tons. One (1) has the least playback restrictions.
Eight (8) has the most playback restrictions.
Unlock: If you select Unlock, Parental Control is
not active. The disc will play in full.
Level 1 to 8: Some discs contain scenes not suit-
able for children. If you set a rating for the recorder,
all disc scenes with the same rating or lower will be
played. Higher rated scenes will not be played
unless an alternative scene is available on the disc.
The alternative must have the same rating or a
lower one. If no suitable alternative is found, play-
back will stop. You must enter the 4-digit password
or change the rating level in order to play the disc.
88
Press ENTER to confirm your rating selection,
then press SETUP to exit the menu.
Set Password
Changing the 4-digit code
11
Follow steps 1-3 as shown above to the left
(Movie Rating).
22
Use v/ Vto select the Password option.
33
Press Bto move to the third level.
44
Follow step 6 as shown above to the left (Movie
Rating).
55
While “Change” is selected, press ENTER.
If you select “Delete” then press ENTER. The pass-
word is deleted.
66
Enter a 4-digit password using the numbered
buttons to create a personal 4-digit security
password.
77
Enter the 4-digit password again.
ip
If you enter the wrong number, press brepeatedly to
delete password numbers one by one then correct it.
If you forget your 4-digit code
If you forget your password, to clear the current pass-
word, follow the procedure below.
1Press SETUP to display the Setup menu.
2Use the Number buttons to enter the 5-digit number
“21019”.
The message appears on the TV screen.
3Select “Yes” then press ENTER. The 4-digit pass-
word is cleared. Enter a new code as shown above.
22
Level 8(Adult)
Level 7
Level 6
Level 5
Level 4
Level 3
Level 2
Level 1(Kid Safe)
Unlock
Movie Rating
Password
Country Code
Prev. Select
Change
Delete
Movie Rating
Password
Country Code
New
Password
0-9 Input
Prev. Select
Before Operation (Continued)
Country Code
Enter the code of a country/area whose standards were
used to rate the DVD video disc, referring to the list
(See “Country Code List”, page 54.).
11
Press SETUP.
The Setup menu appears.
22
Use v/ Vto select the LOCK option.
33
While the LOCK option is selected, press Bto
move to the second level.
44
Use v/ Vto select the Country Code option.
55
Press Bto move to the third level.
66
When you have not entered a password yet.
Enter a 4-digit password using the numbered but-
tons to create a personal 4-digit security password.
Enter the 4-digit password again.
When you have already entered a password;
Enter a 4-digit password using the numbered but-
tons to confirm the personal 4-digit security pass-
word.
ip
If you enter the wrong number, press brepeatedly to
delete password numbers one by one then correct it.
77
Select the first character using the v/ V
buttons.
88
Shift the cursor using Bbuttons and select the
second character using v/ Vbuttons.
99
Press ENTER to confirm your country code
selection, then press SETUP to exit the menu.
RECORD
DISC Record Mode
You can set the picture quality for DVD recording; SP
(Standard quality), LP (Low quality), XP (High quality).
11
Press SETUP.
The Setup menu appears.
22
Use v/ Vto select the RECORD option.
33
While the RECORD option is selected, press B
to move to the second level.
44
Use v/ Vto select the DISC Record Mode Set
option.
55
Press Bto move to the third level.
66
Use b /B to select the VR Mode or Video Mode.
77
Use v/ Vto select a desired DISC Record Mode
(SP, LP, or XP)
88
Press ENTER to confirm your selection, then
press SETUP to exit the menu.
VCR Record Mode
You can set the picture quality for VCR recording; SP
(Standard Play), SLP (Super Long Play).
DVR HOOKUP
23
Movie Rating
Password
Country Code
US
Prev. Select
Video Mode
VR Mode
SP
SP
DISC Record Mode
VCR Record Mode
DV Record Audio
Auto Chapter
SLP
SP
DISC Record Mode
VCR Record Mode
DV Record Audio
Auto Chapter
Prev. Select
DV Record Audio
You need to set this if you have a camcorder using
32kHz/12-bit sound connected to the front panel DV IN
jack.
Some digital camcorders have two stereo tracks for
audio. One is recorded at the time of shooting; the other
is for overdubbing after shooting.
On the Audio 1 setting, the sound that was recorded
while shooting is used.
On the Audio 2 setting, the overdubbed sound is used.
Auto Chapter
During recording (Video mode only), chapter markers
are added automatically at fixed intervals. You can set
this interval to 3 minutes, 5 minutes or 10 minutes. To
turn off automatic chapter marking, select “Not Use”.
DISC
DISC Initialize
•If you load a blank DVD-R disc, it will always be ini-
tialized in Video mode, which allows the disc to be
played in most standard DVD players.
•If you load a blank DVD-RW disc, you will be prompt-
ed to initialize the disc in Video mode (for maximum
compatibility) or VR mode (to enable advanced edit-
ing features).
•If you load a DVD-RW that has already been used,
you can change between Video mode and VR mode
by erasing the disc using the DISC Initialize feature.
11
Press SETUP.
The Setup menu appears.
22
Use v/ Vto select the DISC option.
33
While the DISC option is selected, press Bto
move to the second level.
44
Use v/ Vto select the DISC Initialize option.
55
Press Bto move to the third level.
Start icon is highlighted.
66
Press ENTER.
Disc Initialize menu appears.
77
Use b/ Bto select a desired DISC Initialize
Mode (VR Mode or Video Mode) then press
ENTER.
88
Use b/ Bto select OK, and press ENTER.
It takes a few moments to initialize the disc.
99
Press ENTER.
Caution
If you want to change the disc format, everything
recorded on the disc will be erased.
24
Before Operation (Continued)
Audio 2
Audio 1
DISC Record Mode
VCR Record Mode
DV Record Audio
Auto Chapter
Prev. Select
5 Min
10 Min
Not Use
3 Min
DISC Record Mode
VCR Record Mode
DV Record Audio
Auto Chapter
Prev. Select
Start
DISC Initialize
DISC Finalize
DISC Name
DISC Protect
PBC
Prev. Select
Video Mode
Select mode.
Disc Initialize
VR Mode
Before Operation (Continued)
DISC Finalize
Finalizing ‘fixes’ the recordings in place so that the disc
can be played on a regular DVD player or computer
equipped with a suitable DVD-ROM drive.
Finalizing a Video mode disc creates a menu screen for
navigating the disc. This is accessed by pressing DISC
MENU or TITLE.
Caution
Once you have finalized a DVD-R disc, you cannot
edit or record anything else on that disc.
However, you can record and edit a DVD-RW disc
by choosing Unfinalize.
11
Follow steps 1-3 as shown on page 24 (DISC
Initialize).
22
Use v/ Vto select the DISC Finalize option.
33
Press Bto move to the third level.
Finalize is highlighted.
44
Press ENTER.
Finalize menu appears.
55
Use b/ Bto select OK then press ENTER.
The VCR/DVD Recorder starts finalizing the disc.
ote
Finalization can take up to 3-4 minutes depending on
the type of disc, how much is recorded on the disc, and
the number of titles on the disc.
ips
If you load a DVD-RW that has already been finalized
on a different DVD Recorder, you can ‘Unfinalize’ it by
choosing Unfinalize from the Finalize menu. After
doing this, you can edit and re-record onto the disc.
You cannot unfinalize a DVD-R disc.
DISC Protect
When recording in VR mode, set to ON to prevent acci-
dental recording, editing or erasing of the disc loaded. If
you need to unlock the disc to make edits, select OFF.
PBC
PBC stands for Playback Control and refers to special
menus and navigation features that are available on
some Video CDs.
- ON: Video CDs are played according to the PBC, if
available.
- OFF: Video CDs are played the same way as Audio
CDs.
DVR HOOKUP
25
DISC Initialize
DISC Finalize
DISC Name
DISC Protect
PBC
Unfinalize
Finalize
Prev. Select
OK
Do you want to finalize the disc?
Finalize
Cancel
DISC Initialize
DISC Finalize
DISC Name
DISC Protect
PBC ON
OFF
Prev. Select
DISC Initialize
DISC Finalize
DISC Name
DISC Protect
PBC
ON
OFF
Prev. Select
Before Operation (Continued)
DISC Name
Use the DISC Name feature to enter a name for the
disc. This name appears when you load the disc and
when you display disc information on-screen.
•The disc name can be up to 32 characters long.
•For discs formatted on a different DVD Recorder, you
will see only a limited character set.
11
Follow steps 1-3 as shown DISC Initialize on
page 24.
22
Use v/ Vto select the DISC Name option.
33
Press Bto move to the third level.
Edit icon is highlighted.
44
Press ENTER.
Keyboard menu appears.
55
Enter a name for the disc. Use vVbBto select
a character then press ENTER to confirm your
selection.
•English/Latin Capital: Selects a keyboard with
uppercase characters.
•English/Latin Lowercase: Selects a keyboard
with lowercase characters .
•Symbols: Selects a keyboard with all symbols.
•OK: Confirms the name you have entered.
•Cancel: Deletes all characters and exits the
Keyboard menu.
•Space: Inserts a space at the cursor position.
•Delete: Deletes the character to the left of the
cursor.
•b/ B:Moves the cursor left or right.
You can also use the remote control to
enter DISC Names:
SKIP (./ >): Moves the cursor left or right.
PLAY (N): Inserts a space at the cursor position.
PAUSE/STEP (X): Deletes the character to the right
of the cursor position.
STOP (x), CLEAR: Deletes the character to the left
of the cursor position.
0-9: Enters the character corresponding to the
selected column.
DISC MENU/LIST, DISPLAY: Switches the keyboard
type (English/Latin Capital, English/Latin
Lowercase, Symbols).
66
Choose OK then press ENTER to set the name
and return to the DISC menu.
77
Press SETUP to exit the menu.
26
DISC Initialize
DISC Finalize
DISC Name
DISC Protect
PBC
Edit
Prev. Select
0123456789
ABCDEFGH I J
KLMNOPQRST
UVWXYZ
DVD-VR
English/Latin CapitalLanguage
OK Cancel
Space Delete
DVR HOOKUP
27
Before Operation (Continued)
General Explanation of
On-Screen Display
This manual gives basic instructions for operating the
VCR/DVD Recorder. Some DVDs require specific oper-
ation or allow only limited operation during playback.
When this occurs, the symbol appears on the TV
screen, indicating that the operation is not permitted by
the VCR/DVD Recorder or is not available on the disc.
Displaying Information on-screen
You can display various information about the disc or
tape loaded on-screen.
On-screen display operation
11
Press DISPLAY repeatedly to display/change the
information displayed on-screen.
22
To remove the on-screen display, press DIS-
PLAY or RETURN (O) repeatedly until it disap-
pears.
See the descriptions on pages 28 and 29 for
detailed explanations of on-screen displays for each
media type.
otes
Some discs may not provide all the features shown in
the on-screen display examples.
The on-screen display disappears automatically if no
button is pressed for seven seconds.
Temporary Feedback Icons
Resume play from this point
Action prohibited or not available
Displaying OSD While Watching TV
While watching TV, press DISPLAY to display/
remove the on-screen display.
For example, when a DVD-RW in VR mode is inserted,
you would see a screen similar to the following:
Changing TV Channels
If no disc is playing, you can change TV channels using
the number or CH/TRK (v/V) buttons on the remote
control, or the CH (v/V) buttons on the front panel.
ote
Antenna channels are numbered 2 through 69. Cable
channels are numbered 1 through 125.
Changing TV Audio Channel
Some TV programs are broadcast with both a main and
a Secondary Audio Program (SAP). You can change the
TV audio using the AUDIO button.
Press AUDIO repeatedly to change the TV audio,
according to Broadcast audio signal as shown
below.
•STEREO+SAP Audio Signal
Stereo →SAP →Mono →Stereo
•STEREO Audio Signal
Stereo →L→R →Mono Stereo
•SAP Audio Signal
Mono →SAP →Mono
•MONO Audio Signal
Mono
The current audio channel is displayed on-screen.
•If SAP is selected, but there is no SAP channel being
broadcast, you will still hear the main audio (Mono or
STEREO) channel.
•If the sound is poor quality when set to Stereo, you
can often improve it by changing to Mono.
•When an external input is selected, the audio channel
can be switched only to Stereo.
DVD-VR
VR Mode SP 01H 32M Free
10/8/2003Mono 11:35 AM
MONO
DVD
Ch. 6
Indicates disc type. Indicates channel
number and
audio input
signal received
by the tuner.
Indicates the Recording mode,
free space, and elapsed time
progress bar.
Indicates current date and time.
Indicates output audio signal.
28
Before Operation (Continued)
Menu Options
Title Number
Chapter Number
Time search
Audio language
and Digital Audio
Output mode
Subtitle language
Angle
Sound
Function (Use v/ Vto select desired option)
Shows the current title number and total number of
titles, and skips to the desired title number.
Shows the current chapter number and total number of
chapters, and skips to the desired chapter number.
Shows the elapsed playing time, and
searches the point by the elapsed time directly.
Shows the current audio soundtrack language,
encoding method, and channel number, and
changes the setting.
Shows the current subtitles language, and
changes the setting.
Shows the current angle number and total number of
angles, and changes the angle number.
Shows the current sound mode, and
changes the setting.
Selection Method
b
/
B
,or
Numbers, ENTER
b
/
B
,or
Numbers, ENTER
Numbers, ENTER
b
/
B
b
/
B
b
/
B
b
/
B
1/6
4/26
- : -- : --
ABC
OFF
NORMAL
1/3
5.1CH
1. ENG
DVD
Title: 1/4
Chapter: 3/28 0:06:32 / 2:12:10
DVD
Shows the current
title/chapter number and
total number of
titles/chapters
Shows the Current
mode
Shows the elapsed playing time
and total time.
Menu Options
Title Number
Chapter Number
Time search
Sound
Function (Use v/ Vto select desired option)
Shows the current title number and total number of
titles, and skips to the desired title number.
Shows the current chapter number and total number of
chapters, and skips to the desired chapter number.
Shows the elapsed playing time, and
searches the point by the elapsed time directly.
Shows the current sound mode, and
changes the setting.
Selection Method
b
/
B
,or
Numbers, ENTER
b
/
B
,or
Numbers, ENTER
Numbers, ENTER
b
/
B
1/6
1/1
- : -- : --
VR
LPORG
Title 1
01/02/03 0:06:32 / 2:12:10
DVD
Shows the title name,
recording date,
recording mode, etc.
ORG: Original
PLS: Playlist
Shows the Current
mode
Shows the elapsed playing time
and total time.
OSD Menu Options by Media Type
DVR HOOKUP
29
Menu Options
Track Number
Time
Audio Channel
Sound
Function (Use v/ Vto select desired option)
Shows the current track number and total number of tracks
or PBC On mode, and skip to the desired track number.
Shows the elapsed playing time (Display only).
Shows the current audio channel, and
changes the audio channel.
Shows the current sound mode, and
changes the setting.
Selection Method
b
/
B
,or
Numbers, ENTER
–
b
/
B
b
/
B
VCD
1/4
0:10:30
NORMAL
Track : 1/1
0:06:32 / 2:12:10
DVD
Shows the current track
number and total number of
tracks, or shows PBC On
mode.
Shows the current
mode
Shows the elapsed playing time
and total time.
Before Operation (Continued)
Video
0:06:32 / 2:12:10
DVD
LPORG
Title 1
01/02/03
Shows the title name,
recording date,
recording mode, etc.
ORG: Original
PLS: Playlist
Shows the Current
mode.
Shows the elapsed playing time
and total time.
Menu Options
Title Number
Chapter Number
Time search
Sound
Function (Use v/ Vto select desired option)
Shows the current title number and total number of
titles, and skips to the desired title number.
Shows the current chapter number and total number of
chapters, and skips to the desired chapter number.
Shows the elapsed playing time, and
searches the point by the elapsed time directly.
Shows the current sound mode, and
changes the setting.
Selection Method
b
/
B
,or
Numbers, ENTER
b
/
B
,or
Numbers, ENTER
Numbers, ENTER
b
/
B
1/6
1/1
- : -- : --
NORMAL
OSD Menu Options by Media Type (Continued)
Menu Options
Time
Audio Channel
Function (Use v/ Vto select desired option)
S
hows the elapsed playing time (Display only).
Shows the audio channel, and
changes the audio channel.
Selection Method
–
b
/
B
0:00:20
HIFI
VCR
SP
Shows playing speed,
recording tape information
and the elapsed playing
progress bar.
Shows the Current
mode
VHS
30
Operation with DVD and Video CD
Playing a DVD or Video CD
Playback Setup
Before using the remote control, press the DVD but-
ton to select the device to be operated.
Turn the TV on and select the video input source con-
nected to the VCR/DVD Recorder.
Audio system: Turn the audio system on and select
the input source connected to the VCR/DVD
Recorder.
11
Press OPEN/CLOSE to open the disc tray.
22
Load your chosen disc in the tray, with the
playback side down.
33
Press OPEN/CLOSE to close the tray.
READING appears on the display window, and
playback starts automatically. If playback does not
start, press PLAY.
In some cases, the disc menu might appear
instead.
ip
If a menu screen is displayed
The menu screen may be displayed first after loading a
DVD or Video CD which contains a menu.
Use the bBvVbuttons to select the title/chapter you
want to view, then press ENTER to start playback.
Press TITLE or DISC MENU to return to the menu
screen.
Use the number buttons to select the track you want
to view.
Press RETURN to return to the menu screen.
Menu settings and the exact operating procedures for
using the menu may differ depending on the disc.
Follow the instructions on each menu screen.
You may also set PBC to OFF under the DISC
Settings menu. See page 25.
otes
If Parental Control is set and the disc is not within the
Movie Rating settings (not authorized), the 4-digit
code must be entered and/or the disc must be author-
ized (see “Movie Rating”, on page 22).
DVDs may have a Region Code.
Your VCR/DVD Recorder will not play discs that have
a region code different from your VCR/DVD Recorder.
The region code for this VCR/DVD Recorder is 1
(one).
ote
Unless stated otherwise, all operations described use
the remote control. Some features may also be avail-
able on the Setup menu.
Moving to another TITLEs
When a disc has more than one title, you can move to
another title as follows:
Press DISPLAY twice and use v/ Vto select the title
icon. Then, press the appropriate numbered button
(0-9) or b/ Bto select a title number and press
ENTER to confirm.
Moving to another CHAPTER/TRACKs
When a title on a disc has more than one chapter/track,
you can move to another chapter/track as follows:
Press SKIP (.or >) briefly during playback to
select the next chapter/track or to return to the begin-
ning of the current chapter/track.
Press SKIP (.) twice briefly to step back to the
previous chapter/track.
To go directly to any chapter/track during playback,
press DISPLAY twice. Then, use v/ Vto select chap-
ter icon (or for a Video CD, select the track icon).
Then, enter the chapter/track number using the num-
bered buttons (0-9) or press b/ Band press ENTER.
ote
On a Video CD with PBC, you must set PBC to OFF in
the DISC menu to use this function. See page 25.
Slow Motion
1Press BACKWARD (m) or FORWARD (M)
during pause mode.
The VCR/DVD Recorder will enter SLOW mode.
2Use the BACKWARD (m) or FORWARD (M) to
select the required speed: t 1/16, t 1/8, t 1/4,
t 1/2, or T1/16, T1/8, T1/4, T1/2.
With a Video CD, the Slow speed changes to : T
1/8, T1/4 or T1/2 (forward).
3To exit Slow Motion mode, press PLAY.
ote
Slow motion playback in reverse is not possible with
Video CDs.
VCDVR
Video
DVD
1/4
4/26
VCDVR
Video
DVD
1/6
VR
Video
DVD
VCD
DVD
PLAYBACK
31
Operation with DVD and Video CD (Continued)
Playing a DVD or Video CD (continued)
Still Picture and Frame-by-Frame Playback
1Press PAUSE/STEP (X) during playback.
The recorder will now go into PAUSE mode.
2You can advance or back up the picture frame-by-
frame by pressing b/B repeatedly during PAUSE
mode.
ote
Frame-by-frame reverse playback is not available on
Video CDs.
Search
1Press BACKWARD (m) or FORWARD (M) during
playback.
The recorder will now go into SEARCH mode.
2Press BACKWARD or FORWARD to select the
required speed: mX2, mX4, mX8, mX16,
mX100, n(backward) or MX2, MX4, MX8,
MX16, MX100, N (forward).
With a Video CD, the Search speed changes to:
mX2, mX4, mX8 (backward) or MX2, MX4,
MX8 (forward).
3To exit SEARCH mode, press PLAY (N).
ote
When you press BACKWARD or FORWARD during
Search mode to go to normal speed, search mode is
canceled.
Random
1Press RANDOM during playback or in Stop mode.
The unit automatically begins Random Playback and
“RANDOM” appears on the TV screen.
2To return to normal playback, press RANDOM until
“NORMAL” appears on the TV screen.
ip
By pressing SKIP (>) during Random playback, the
VCR/DVD Recorder selects another title (track) and
resumes Random playback.
ote
This function only works with DVD Karaoke discs or
video CDs without PBC.
On a Video CD with PBC, you must set PBC to OFF
in the DISC menu to use the Random function. See
page 25.
Repeat
DVD Video Discs - Repeat Chapter/Title/Off
1To repeat the currently playing chapter, press
REPEAT.
The REPEAT CHAPTER appears on the TV screen.
2To repeat the title currently playing, press REPEAT a
second time.
The REPEAT TITLE appears on the TV screen.
3To exit Repeat mode, press REPEAT a third time.
The REPEAT OFF icon appears on the TV screen.
Video CDs - Repeat Track/All/Off
1To repeat the track currently playing, press REPEAT.
The REPEAT TRACK icon appears on the TV screen.
2To repeat the disc currently playing, press REPEAT a
second time.
The REPEAT ALL icon appears on the TV screen.
3To exit Repeat mode, press REPEAT a third time.
The REPEAT OFF icon appears on the TV screen.
ote
On a Video CD with PBC, you must set PBC to OFF in the
DISC menu to use the Repeat function. See page 25.
Repeat A-B
To repeat a sequence in a title:
1Press A-B at your chosen starting point.
REPEAT A- appears on the TV screen.
2Press A-B again at your chosen end point.
REPEAT A-B appears briefly on the TV screen, and the repeat
sequence begins.
3To cancel the sequence, press A-B repeatedly to
select REPEAT OFF.
REPEAT
A - B
VCDVR
Video
DVD
REPEAT
CHAPTER
VCDVR
Video
DVD
VCDKaraoke DVD
VCDVR
Video
DVD
VCDVR
Video
DVD
Operation with DVD and Video CD (Continued)
Playing a DVD or Video CD (Continued)
Time Search
The Time Search function allows you to start playing at
any chosen time on the disc.
1Press DISPLAY twice during playback. The on-screen
display appears on the TV screen.
The Time Search box shows the elapsed playing time of the
current disc.
2Within 7 seconds, use v/ Vto select the Time
Search icon in the on-screen display.
The “-:--:--” appears in the Time Search box.
3Within 7 seconds, use the number buttons to enter
the required start time. Enter hours, minutes, and sec-
onds from left to right in the box.
You can not enter an invalid time.
If you enter the wrong numbers, press b
/
Bto move the
under bar (_) to the wrong number. Then reenter the correct
numbers.
4Within 7 seconds, press ENTER to confirm the start
time.
Playback starts from the selected time on the disc.
Zoom
The Zoom function allows you to enlarge the video
image and to move through the enlarged image.
1Press ZOOM during playback or still playback to acti-
vate the Zoom function.
The square frame will be displayed in the right bottom of the
picture. If no button is pressed for more than 5 seconds, the
square frame will disappear.
Each press of the ZOOM button changes the TV screen in
the sequence shown below.
X1(normal size) →X2 size →X4 size →X1(normal size)
2Use the bBvVbuttons to move through the
zoomed picture.
3To resume normal playback, press CLEAR or press
ZOOM repeatedly until the normal picture appears.
ote
The zoom function may not work for some DVDs.
Marker Search
You can start playback from a memorized point. Up to
six points can be memorized.
To enter a mark, follow these steps.
1During disc playback, press MARKER when
playback reaches the spot that you want to
memorize.
The Marker icon will appear on the TV screen briefly.
2Repeat step 1 to enter up to six Marker points on a
disc.
To Recall a Marked Scene
1During disc playback, press SEARCH.
The Marker Search menu will appear on the TV screen.
2Use the bBvVbuttons to select a Marked scene
that you want to recall.
3Press ENTER.
Playback will start from the Marked scene.
4To remove the Marker Search menu,
press RETURN (O)
To clear a Marked Scene
1During disc playback, press SEARCH.
The Marker Search menu will appear on the TV screen.
2Use bBvVto select the Marked scene that you
want to erase.
3Press CLEAR.
“Delete selected marker. Continue?” message appears.
4Use b/ Bto select “Yes” then press ENTER.
5Repeat steps 2-4 to erase additional Marked scene.
6To remove the Marker Search menu,
press RETURN (O).
Disc Menus
Many DVDs contain Disc menus that allow you to
access special features. To open a Disc menu, press
DISC MENU. Then use the 0-9 buttons to directly select
the desired option, or use the bBvVbuttons to high-
light your selection and press ENTER.
1Press DISC MENU.
The Disc menu is displayed.
2To exit the Disc menu, press STOP (x).
Title Menus
1Press TITLE.
If the current title has a menu, the Title menu will appear on
the TV screen. Otherwise, the Disc menu may appear.
2The Title menu may contain camera angles, spoken
languages and subtitle options, as well as the chap-
ters for the title.
DVD
DVD
MARKER
1 / 6
VCDVR
Video
DVD
VCDVR
Video
DVD
- : -- : --
VR
Video
DVD
Delete
CLEAR
CloseSelect
Marker Search
Marker Search
Move
32
PLAYBACK
33
Operation with DVD and Video CD (Continued)
Playing a DVD or Video CD (Continued)
Camera Angle
If the disc contains scenes recorded at different camera
angles, you can change to a different camera angle
during playback.
Press ANGLE then press b/ Brepeatedly during
playback to select a desired angle.
The number of the current angle appears on the TV screen.
ip
The Camera Angle icon is displayed on the TV screen when
alternate angles are available.
Changing the Audio Language
Press AUDIO then press b/ Brepeatedly during play-
back to hear a different audio language or audio track.
Changing the Audio Channel
With a Video CD, press AUDIO then press b/ B
repeatedly during playback to hear a different audio
channel (STEREO, LEFT or RIGHT).
3D Surround
This unit can produce a 3D Surround effect, which
simulates multi-channel audio playback from two
conventional stereo speakers, instead of the five or
more speakers normally required to listen to multi-
channel audio from a home theater system.
1Press DISPLAY twice then use v/ Vto select the
sound icon. Then, use b/ Bto select “3D SUR.”.
2To turn off the 3D Surround effect, select “NORMAL”.
Subtitles
Press SUBTITLE then press b/ Brepeatedly during
playback to see the different subtitle languages.
Finding Locations on a Disc
You can directly access any point on a video CD using
this function within 95%. Use this function only while a
video CD is playing. Playback jumps to the point speci-
fied.
1Press SEARCH during playback.
The progress bar appears on the TV screen.
2Use b/ Bto find the desired starting position for
playback.
3Press ENTER to confirm the selected position.
Playback starts from the selected position.
ote
This function will not work if any bookmarks have been
set; see page 32.
Last Condition Memory
This VCR/DVD Recorder memorizes the user settings
for the last disc that you have viewed. Settings remain
in memory even if you remove the disc from the
VCR/DVD Recorder or switch off the VCR/DVD
Recorder. If you load a disc that had its settings memo-
rized, the latest stop position is automatically recalled.
otes
Settings are stored in memory for use any time.
This VCR/DVD Recorder does not memorize settings
of a disc if you switch off the VCR/DVD Recorder
before commencing to play it.
The Last Condition Memory function may not work
on some DVDs.
DVD
VCD
ABC
OFF
DVD
NORMAL
VCDVR
Video
DVD
STEREO
VCD
5.1CH
1. ENG
DVD
1/3
DVD
33%PBC
33%
TRK 1
34
Audio CD and MP3 Operation
Playing an Audio CD or MP3 Disc
The VCR/DVD Recorder can play audio CDs and MP3
files on CD-ROM, CD-R or CD-RW discs. Before play-
ing MP3 files, read “Notes on MP3 Recordings” at right.
11
Insert a disc and close the tray.
AUDIO CD or MP3 CD menu appears on the TV
screen.
AUDIO CD Menu MP3 CD Menu
22
Use v/Vto select a track then press PLAY (NN).
Playback starts.
During playback, the current track’s elapsed playing
time will appear on the display window and menu.
Playback will stop at the end of the disc.
ips
On the MP3 CD menu, you can display the folders on
the disc. Use vVbBto select the “Folder” icon on the
MP3 CD menu then press ENTER twice.
Also, you can display only tracks in the folders.
Use vVbBto select a folder then press ENTER.
If audio tracks and MP3 files are mixed on the disc, you
can switch between the AUDIO CD menu and MP3 CD
menu by pressing TITLE repeatedly in Stop mode.
If you select a track and press DISPLAY, the file infor-
mations are displayed.
If you select a folder and press DISPLAY, the number of
subfolders and number of MP3 files in the folder are
displayed.
If you are in a file list and want to return to the Folder
list, use the v/Vto highlight and press ENTER to
return to the previous menu screen.
You can view TV channel or video input source by
pressing RETURN. If you want to return to the MP3 or
AUDIO CD menu, press DISC MENU/LIST.
33
To stop playback at any time, press STOP (xx).
Notes on MP3 Recordings
About MP3
An MP3 file is audio data compressed by using the
MPEG1 audio layer-3 file-coding scheme. We call
files that have the “.mp3” file extension “MP3 files”.
The VCR/DVD Recorder can not read an MP3 file
that has a file extension other than “.mp3”.
MP3 Disc compatibility with this recorder is
limited as follows:
1. CD-R/RW physical format should be “ISO 9660” and
“JOLIET”.
2. If you record MP3 files using the software which
cannot create a FILE SYSTEM, for example “Direct-
CD” etc., it is impossible to playback MP3 files. We
recommend that you use “Easy-CD Creator”, which
creates an ISO9660 or JOLIET file system.
3. The total number of files and folders on the disc are
free but the total number of files and folders on the
folder should be less than 1999.
This VCR/DVD Recorder requires discs/recordings to
meet certain technical standards in order to achieve
optimal playback quality. Pre-recorded DVDs are auto-
matically set to these standards. There are many differ-
ent types of recordable disc formats (including CD-R
containing MP3 files) that require certain pre-existing
conditions (see above) to insure compatible playback.
Customers should also note that permission is
required in order to download MP3 files and music
from the Internet. Our company has no right to
grant such permission. Permission should always
be sought from the copyright owner.
MP3
CD
Audio CD
52:16
Title Duration
Track 1 04:47
Track 2 04:01
03:01
03:30
04:24
05:01
03:48
04:09
05:10
04:11
Track 3
Track 4
Track 5
Track 6
Track 7
Track 8
Track 9
Track 10
Program
Close
Mark
MARKER
Select LIST
MP3 CD
00:00
ROOT 152 Items
FOLDER 01
FILE 2.mp3
FILE 3.mp3
FILE 4.mp3
FILE 5.mp3
FILE 6.mp3
FILE 7.mp3
FILE 8.mp3
FILE 9.mp3
FILE 10.mp3
Program
Close
Mark
MARKER
Select LIST
PLAYBACK
35
Audio CD and MP3 Operation (Continued)
Pause
1Press PAUSE/STEP during playback.
2To return to playback, press PAUSE/STEP again.
Moving to Another Track
Press SKIP .or >briefly during
playback to go to the next track or to return to the
beginning of the current track.
Press SKIP .twice briefly to step back to the pre-
vious track.
On an Audio CD, to go directly to any track, enter the
track number using the numbered buttons (0-9) dur-
ing playback.
Repeat
Press REPEAT to select a desired repeat mode.
•Audio CD
- TRACK: Repeats the current track.
- ALL: Repeats all the tracks on a disc.
- OFF: Does not play repeatedly (no display).
•MP3 Disc
- TRACK: Repeats the current track.
- FOLDER: Repeats all the tracks on a folder of a disc.
- OFF: Does not play repeatedly (no display).
Random
1Press RANDOM during playback or when playback
has stopped.
The VCR/DVD Recorder automatically begins
Random Playback and RANDOM appears on the left
side of menu screen.
2To return to normal playback, press RANDOM again,
then RANDOM disappears from the menu screen.
Search
1Press BACKWARD (m) or FORWARD (M) during
playback.
The recorder will now go into SEARCH mode.
2Press BACKWARD or FORWARD to select the
required speed: mX2, mX4, mX8 (backward) or
MX2, MX4, MX8 (forward).
Search speed and direction are indicated on the menu
screen.
3To exit SEARCH mode, press PLAY (N).
Repeat A-B
To repeat a sequence in a title:
1Press A-B at your chosen start point.
Repeat icon and “A-” appears on the menu screen.
2Press A-B again at your chosen end point.
The Repeat icon and “A - B” appears on the left side of
menu screen, and the repeat sequence begins.
3To exit the sequence and return to normal play, press
A-B again.
The Repeat icon disappears from the menu screen.
CD
CD
MP3
CD
MP3
CD
MP3
CD
MP3
CD
36
Programmed Playback with Audio CD and MP3
The Program function enables you to store your favorite
tracks from any disc in the recorder memory.
Program can contain 99 tracks (Audio CD) or 256
tracks (MP3).
11
Insert an Audio CD or MP3 disc.
Audio CD or MP3 CD menu will appear.
22
Use vVto select a track or fold on the List then
press ENTER.
The options appears on the left side of the menu.
otes
Press and hold V for fast to move to the next
track or folder.
Press and hold vfor fast to move to the previ-
ous track or folder.
33
Use vVto highlight the “Program Add”icon
then press ENTER.
The selected track is added to the Program List.
44
Repeat steps 2-3 to place additional tracks on
the Program list.
ip
You can add multi tracks on the List to the Program List.
1. Select a track then press MARKER.
2. Repeat step 1 to mark additional tracks.
3. Select any track then press ENTER.
The options appears on the left side of the menu.
4. Use v/ Vto highlight the “Program Add” icon then
press ENTER.
The all marked tracks are added to the Program List.
otes
Use the CLEAR button to select all tracks, or cancel
all marked tracks.
If you select folder for Programmed Playback, all
tracks in the folder are added to the program list.
55
Use Bto move the tracks to the Program list.
The programmed track you selected last is highlighted on
the program list.
66
Use v/ Vto select the track you want to start
playing.
77
Press PLAY (N)to start.
Playback begins in the order in which you programmed
the tracks and “PRG” indicator appears on the display
window.
Playback stops after playing the last programmed track on
the program list.
88
To resume normal playback from pro-
grammed playback, select a track on the
List then press PLAY (NN).
“PRG” indicator disappears from the display window.
Repeat Programmed Tracks
Press REPEAT to select a desired Repeat mode.
• TRACK : Repeats the current track.
• ALL : Repeats all the tracks on a disc.
• OFF : Does not play repeatedly (no display).
Erasing a Track from the Program List
1Select the track that you wish to erase from the
Program List then press ENTER.
The options appears on the left side of the menu.
2Select the Delete icon then press ENTER.
The selected track is deleted on the Program List.
3Repeat steps 1-2 to delete additional tracks on the
Program List.
Erasing the multi tracks on the
Program List
1. Select a track on the Program List then press
MARKER.
2. Repeat step 1 to mark additional tracks.
3. Select any track then press ENTER.
The options appears on the left side of the menu.
4. Use v/ Vto highlight the “Delete” icon then press
ENTER.
The all marked tracks are deleted from the Program
List.
Changing the order of Program List
1Select the track you wish to move on the Program
List then press ENTER.
The options appear on the left side of the menu.
2Select Move then press ENTER.
Ayellow bar appears in the Program List.
3Use v/Vto move the yellow bar to the desired loca-
tion, then press ENTER.
The selected track is moved.
4If you wish to move other tracks repeat stages 1 - 3.
ip
Use MARKER to move multiple tracks.
05/12
Track 5
Track 1
Track 2
Track 3
Track 4
Track 5
Track 6
Track 7
Track 8
Track 9
Track 10
Track 5
Track 2
Track 8
Track 4
Audio CD
00:42
Title Program List
Program
Close
Mark
MARKER
Select LIST
MP3 CD
9/152
02:13
FILE 9.mp3
ROOT Program List
FILE 1.mp3
FILE 2.mp3
FILE 3.mp3
FILE 4.mp3
FILE 5.mp3
FILE 6.mp3
FILE 6.mp3
FILE 7.mp3
FILE 8.mp3
FILE 9.mp3
FILE 2.mp3
FILE 4.mp3
FILE 9.mp3
FILE 10.mp3
Program
Close
Mark
MARKER
Select LIST
PLAYBACK
37
Viewing a Photo Disc
This VCR/DVD Recorder can play discs with JPEG
files. Before playing JPEG files, read the notes on
JPEG files on right.
1
Insert a disc and close the tray.
The Photo menu appears on the TV screen.
22
Use vVbB to select a folder, and ENTER.
Open icon is highlighted on the left side of the
menu.
33
Press ENTER.
Alist of files in the folder appears.
ote
If the icon displays in a JPEG file list, it means you
cannot see those JPEG files.
44
Use vVbB to select a file, then press ENTER.
The options appear on the left side of the menu.
ip
If you are in a file list and want to return to the Folder
list, use the v/ Vbuttons on the remote to highlight the
icon and press ENTER.
55
Use v/ Vto select the Full Screen option then
press ENTER.
66
To stop viewing at any other time, press STOP
or RETURN (O).
The Photo menu appears.
Selecting other Files
While viewing a picture, press SKIP (./>) or bB
once to advance to the next file or return to the previous
file.
To rotate the picture
Use v/ Vwhile showing a picture to flip the
picture clockwise or counterclockwise.
To view Slide Show
1. Select Slide Show option on the menu.
2. Press ENTER.
Slide Show menu appears.
3. Use vVbB to set the options.
Object: All files or Selected file.
Speed: Selects Slide Show speed (Slow, Normal,
Fast).
4. Select START icon then press ENTER to start slide
show.
5. Press STOP to stop the Slide Show and return to the
Photo menu.
ote
Use the MARKER button to select multiple files.
Notes on JPEG Files
Depending on the size and number of the JPEG files,
it could take a long time for the DVD player to read
the disc’s content. If you don’t see an on-screen dis-
play after several minutes, some of the files are too
big — reduce the resolution of the JPEG files to less
than 4 megapixels and burn another disc.
The total number of files and folders on the disc are
free but the total number of files and folders on the
folder should be less than 1999.
Some discs may be incompatible due to different
recording format or condition of the disc.
When you are using software such as “Easy CD
Creator” to burn jpeg files on a CD-R, ensure that all
the selected files have the “.jpg” extension before
copying into the CD layout.
If the files have “.jpe” or “.jpeg” extensions, please
rename them as “.jpg” files.
File names without “.jpg” extension will not be able to
be read by this VCR/DVD Recorder, even though the
files are shown as JPEG image files in Windows
Explorer.
On CDs with mixed content (audio tracks, MP3 files
and JPEG files), you can select among the AUDIO
CD menu, MP3 CD menu, and Photo CD menu by
pressing TITLE repeatedly in Stop mode.
JPEG
Photo Disc Operation
MP3
Select
MARKER
TITLE
Mark
JPEG Folder 01 Folder 02
Folder 03 Folder 04 Folder 05
Folder 08
Folder 06 Folder 07
Start
Object
Speed
Slide Show
Cancel
All
Normal
JPEG
MP3
Select
MARKER
TITLE
Mark
4/20 90 90 Stop HidePrev Next
File 03.jpg
VCR Mode Tape Playback
38
Preparation
Before using the remote control, press the VCR but-
ton to select the device to be operated.
Turn the TV on and select the video input source con-
nected to the VCR/DVD Recorder.
Audio system: Turn the audio system on and select
the input source connected to the VCR/DVD
Recorder.
Normal Playback
11
Insert a prerecorded video cassette.
The indicator will light and the VCR/DVD Recorder
will power-up automatically.
Make sure that the TIMER indicator in the display
window is not lighted. If it is, press POWER once.
If a tape without a safety tab is inserted, the VCR/DVD
Recorder will start playback automatically.
22
Press PLAY (N) once.
PLAY icon appears on the TV screen.
It is not necessary to select the tape speed for play-
back. It will be automatically selected by the VCR/DVD
Recorder.
In playback, the TV/VCR selector switches to VCR
mode automatically.
33
Press STOP (x) to stop playback.
STOP icon appears on the TV screen.
If the tape reaches the end before STOP (x) is pressed,
the VCR/DVD Recorder will automatically stop, rewind
and eject the tape, and turn itself off.
Tracking Control
Auto Tracking
The automatic tracking function adjusts the picture to
remove snow or streaks.
The AUTO TRACKING function works in the following
cases:
Atape is played back for the first time.
Tape speed (SP, LP, SLP) changes.
Streaks or snow appear because of scratches on the tape.
Manual Tracking
If noise appears on the screen during playback, press
either
CH/TRK (v/V)
on the remote control or
CH (v/V) on the front panel until the noise on the
screen is reduced.
In case of vertical jitter, adjust these controls very carefully.
Tracking is automatically reset to normal when the tape is
ejected or the power cord is unplugged for more than 3 sec-
onds.
Special Effect Playback
Special effects playback notes
Horizontal lines (noise bars) will appear on the TV screen.
This is normal.
The audio is automatically muted during special effect modes,
so there is no sound during search.
During the high-speed picture search modes, a short time is
needed to stabilize tape speed when re-entering the PLAY
mode. Slight interference may be observed during this time.
Search
This function lets you visually search forward and back-
ward for a desired scene on your tape.
1Press BACKWARD (m) or FORWARD (M)
during playback.
The VCR/DVD Recorder will be activated in the
SEARCH mode.
If the VCR/DVD Recorder is left in the SEARCH mode for
more than 3 minutes, the VCR/DVD Recorder will auto-
matically enter the PLAY mode, to protect the tape and
video heads.
2To return to playback, press PLAY (N).
Still Picture and Frame-by-Frame Playback
1Press PAUSE/STEP (X) during playback.
Astill picture appears on the TV screen.
If a still picture vibrates vertically, stabilize it by using
CH/TRK (v/V)
on the remote control.
If the VCR/DVD Recorder is left in the STILL mode for
more than 5 minutes, the VCR/DVD Recorder will auto-
matically enter the STOP mode to protect the tape and
video heads.
2Press PAUSE/STEP (X) repeatedly to advance the
video picture one frame at a time while viewing a still
picture.
3To return to playback, press PLAY (N).
Slow Motion
1While in still mode, press FORWARD (M).
The tape will be played back at a speed 1/19 times
slower than the normal speed.
During slow playback, use CH/TRK (v/V) on the Remote
Control to minimize noise bands.
If slow motion mode continues for more than 3 minutes,
the VCR/DVD Recorder will automatically change to nor-
mal play mode.
2To return to playback, press PLAY (N).
Counter Memory Function
This is useful if there is a section of tape you want to
view immediately after recording or if you want to return
to the same point several times.
1Begin recording or playing a tape.
2Press DISPLAY repeatedly to display the real-time
counter on the TV screen.
3At the point you want to locate later, reset the real-
time counter to 0:00:00 by pressing CLEAR.
Continue to play or record.
4Press STOP when recording or playback finishes.
5Press RETURN (O).
The tape automatically stops when the tape counter
returns to about “0:00:00”.
VHS
VHS
VHS
RECORDING
39
Basic Recording
Basic Recording from a TV
Follow the instructions below to record a TV program.
Recording starts immediately and continues until the disc or
tape is full or you stop the recording.
11
Switch on the VCR/DVD Recorder, select the
device (VCR or DVD) for Recording and load a
recordable disc or tape.
Also make sure that the TV input is set to this recorder.
If you load a completely blank DVD-RW disc, Disc initial-
ize menu will appear, to select a desired Recording Mode
to initialize the disc (See page 24).
22
Set a recording mode as necessary by pressing
REC MODE repeatedly.
DVD: SP (Standard quality), LP (Low quality),
XP(High quality)
VCR: SP (Standard Play), SLP (Super Long Play)
33
Use CH (v/V) on the front panel or CH/TRK(v/V)
on the remote control to select the TV channel
to record.
44
Use AUDIO to select the audio channel to
record.
The table below shows what will be recorded on the differ-
ent settings for different types of broadcast. The last col-
umn (Monitor Audio) shows what you’ll hear as it is
recording.
•If you set the audio channel to SAP, but there is no
SAP channel being broadcast, the main audio (mono or
stereo) will be recorded.
55
Press REC (z) once.
Recording will start. (The REC indicator lights in the
display window.)
Recording continues until you press STOP (x) or the
disc (or tape) is full.
To record for a fixed length of time, see Instant Timer
Recording on right.
66
Press STOP (x) to stop recording.
ote
The available recording DVD title number is 99.
If the VCR/DVD Recorder is powered off during DVD
recording, the recording will not be saved.
Instant Timer Recording
Instant Timer Recording allows you to make a recording
easily of a preset length without using the program
timer.
11
Follow steps 1-4 as shown left (Basic Recording
from a TV).
22
Press REC (z) repeatedly to select the record-
ing time length.
Recording starts after the first press.
DVD: Each subsequent press increases the recording
time by 10 minutes (maximum 240 minutes) within free
space.
VCR: Each subsequent press increases the recording
time by 30 minutes (maximum 540 minutes). Please con-
firm the VHS tape has enough remaining time to be
recorded before recording.
Instant Timer Record Menu
Checking the Recording Time
Press REC (z) or DISPLAY once to check the record-
ing time. The recalled setting will automatically return to
the TV screen for a moment.
Also, remaining time of recording is shown in the dis-
play window.
To Extend the Recording Time
The recording time can be extended anytime by press-
ing REC (z).
Each subsequent press increases the recording time by
10 minutes (DVD) within free space or 30 minutes
(VCR) .
To Pause the Recording
1Press PAUSE/STEP (X) to pause the disc during
recording.
2When you want to continue recording, press
PAUSE/STEP (X) or REC (z).
otes
•If you press PAUSE/STEP (X) during the Instant
Timer Recording, it will be canceled.
•The VCR/DVD Recorder will automatically power off
when the Instant Timer Recording ends.
To record one TV program while watching another
1
Press TV/VCR to select the TV mode during recording.
The TV indicator appears.
2Using the TV, select the channel to be viewed.
ips (VCR mode only)
Always use PAUSE/STEP (X) for best results when making
changes during recording .
For example: To change channels during recording, first press
PAUSE/STEP (X) to put the unit in pause mode. Then select
the desired channel on the VCR/DVD Recorder, and press
PAUSE/STEP (X) again to resume recording.
TV Broadcast Selected Audio Broadcast Audio Monitor
LChR Ch Audio
MONO MONO MONO MONO MONO
STEREO STEREO L R STEREO
Left L L Left
Right L R Right
MONO MONO MONO MONO
MONO+SAP MONO MONO MONO MONO
SAP SAP SAP SAP
STEREO+SAP STEREO L R STEREO
SAP SAP SAP SAP
MONO MONO MONO MONO
VCR
120min Rec
DVD
00:09:05
30min Rec
MONO
Input: Ch. 6
00:17:32
SP
MONO
Input: Ch. 6
02H 01M Free
SP
Copying from DVD to VCR
You can copy the contents of a DVD to a VHS tape
using the COPY button.
ote
If the DVD (or Discs) you are attempting to copy is copy
protected, you will not be able to copy the disc. It is not
permitted to copy Macrovision encoded DVDs (or
Discs). “Copy-protected. Cannot record.” is displayed on
the TV screen.
11
Insert a Disc
Insert the disc you wish to copy in the DVD deck
and close the disc tray.
22
Insert a VHS Tape
Insert a blank VHS videotape into the VCR deck.
33
Select DVD mode by pressing DVD on the
remote control or pressing DVD/VCR on the
front panel.
44
Find the place on the DVD (or Disc) from which
you want to start recording using the PLAY and
PAUSE functions.
For best results, pause playback at the point from which
you want to record.
55
Press the COPY button on the remote control or
front panel.
The Copy to VCR menu appears.
66
Use vv /VV /bb /BBto select the desired Record
Mode:
• SP (Standard Play)
• SLP (Super Long Play, 3 times SP).
77
Select Copy then press ENTER or COPY to start
copying.
ip
If you press PAUSE during Copy mode, both the DVD and
VCR decks go into Pause mode and the “COPY” indicator
blinks on the front panel display. While in Pause mode,
you can adjust the DVD playback position using PLAY,
REW, FF, PAUSE/STEP, etc. The VCR deck will remain in
Pause mode. To resume copying, press the COPY button
twice.
88
Stop the Copy Process
To stop copying at any other time, press STOP (x).
You must stop the Copy process manually when the
DVD movie ends, or the unit may replay and record
over and over again.
Copying from VCR to DVD
You can copy the contents of a VHS tape to a DVD-R
or DVD-RW using the COPY button. This allows you to
archive your old VHS tapes to DVD.
ote
If the VHS video tape you are attempting to copy is
copy protected, you will not be able to copy the tape. It
is not permitted to copy Macrovision encoded tapes.
11
Insert a VHS Tape
Insert the VHS video tape you wish to copy into the
VCR deck.
22
Insert a DVD-R or DVD-RW disc.
Insert a blank DVD-R or DVD-RW disc in the DVD
deck and close the disc tray.
ote
When using a DVD-RW disc, you must initialize
before copying; see page 24.
33
Select VCR mode by pressing VCR on the
remote control or pressing DVD/VCR on the
front panel.
44
Find the place on the VHS tape from which you
want to start recording using the PLAY, FF, REW
and PAUSE functions.
For best results, pause playback at the point from which
you want to record.
55
Press the COPY button on the remote control or
front panel.
The Copy to DVD menu appears.
66
Use vv /VV /bb /BBto select the desired Record
Mode:
• LP (Low Quality)
• SP (Standard Quality)
• XP (High Quality)
77
Select Copy then press ENTER or COPY to start
copying.
ip
If you press PAUSE during Copy mode, both the DVD and
VCR decks go into Pause mode and the “COPY” indicator
blinks on the front panel display. While in Pause mode,
you can adjust the VCR playback position using PLAY,
REW, FF, PAUSE/STEP, etc. The DVD deck will remain in
Pause mode. To resume copying, press the COPY button
twice.
88
Stop the Copy Process
To stop copying at any other time, press STOP (x).
Copying will stop automatically when the VHS tape
ends.
40
Basic Recording (Continued)
Free Space
Rec. Mode
Copy to VCR
- - %
SP
Copy Stop
Copy
Free Space
Rec. Mode
Copy to DVD
01:54M
SP
Stop
Timer Recording
RECORDING
41
The Timer Recording function allows you to record up to
8 programs within a period of one month.
11
Press TIMER REC.
The Timer Record menu will appear.
•Media – Choose a media (DVD or VCR).
•Ch. – Choose a channel (2-69 or 1-125 for anten-
na or cable channels respectively, excluding skip
channels), or one of the external inputs from
which to record (AV1 or AV2).
•Date – Choose a date up to
1 month
in advance,
or select a daily or weekly program.
•Start Time – Set the recording start time.
•End Time – Set the recording end time.
•Mode – Choose a record mode.
DVD: SP, LP, XP, or AT (Auto)
VCR: SP, SLP, AT (Auto)
AUTO mode determines how much time is avail-
able on the disc or tape and switches record
mode, if necessary, to complete recording the
program.
22
Enter the necessary information for your timer
recording(s).
•b /B (left/right) – Move the cursor left/right
•v /V (up/down) – Change the setting at the cur-
rent cursor position
•Press RETURN (O)to exit the Timer Record
menu.
•Press ENTER after filling in all the program infor-
mation.
•Press TIMER REC to display Timer Record List.
33
Press ENTER to save the program.
The Timer Record List will appear.
44
Press RETURN (O) to exit the Timer Record
List.
55
Be sure to load a recordable disc or tape.
ote
•The Timer indicator lights on the front panel display.
•If the Disc and Tape indicator are blinking, either no disc
or tape is loaded, or the loaded disc is not recordable.
•The VCR/DVD Recorder will record the audio according
to the current TV tuner setting (Stereo, Mono or SAP).
Use the AUDIO button to set the audio before switching
the VCR/DVD Recorder to Standby mode.
•You must press STOP to stop the Timer Recording.
•The VCR/DVD Recorder will automatically power off
when the Timer Recording ends.
•There is a short delay when a timer recording finishes to
confirm the recorded program. If two timer recordings are
set to record sequentially (one right after the other), the
very beginning of the later program may not be recorded.
Checking Timer Recording Details
Programming can be checked whenever the VCR/DVD
Recorder is turned on. Press TIMER REC twice.
•Use v/ Vto select a timer recording.
•Press ENTER to edit the selected program.
Timer Record menu appears.
•Press CLEAR to delete the selected program
from the Timer Record List.
Canceling a Timer Recording
You can clear a timer setting anytime before the record-
ing actually starts.
•Use v/ Vto select a program you want to erase on
the Timer Recorder List. If you want to erase the
program, press CLEAR.
Stopping a Timer Recording in Progress
After a timer recording has started, you can still cancel
the program.
•Press STOP.
Timer Recording Troubleshooting
Even though the timer is set, the recorder will not
record when:
•There is no disc (or tape) loaded.
•Anon-recordable disc (or tape) is loaded.
•Disc Protect is set to ON in the Disc menu
(see page 25).
•There are already 99 titles recorded on the disc.
You cannot enter a timer program when:
•Arecording is already underway.
•The time you’re trying to set has already passed.
•There are already 8 timer programs set.
If two or more timer programs overlap:
•The earlier program takes priority.
•When the earlier program finishes, the later program
starts.
•If two programs are set to start at exactly the same
time, the program entered first takes priority.
Confirmation is not possible when:
•Disc Protect setting is set to ON.
•There are already 99 titles recorded on the disc.
If the disc is damaged, the recording may not complete
successfully. In this case even though the Check field
shows “Rec. OK”, it may not be.
TIMER REC
Media Ch. Date Start Time End Time Mode
Timer Record
OK Timer Rec List Close
198 min Free
Ch.11DVD 10/16 Thu 10:07 AM 11:00 AM SP
SP
Media Start Time DurationDateCh. Mode Check
Timer Record List
Edit CloseDelete
CLEAR
10/19 SunCh.11 18:07 AM 30min SP Rec. OK
Timer Rec
TIMER REC
Recording from an External Input
42
Recording from External Components
You can record from an external component, such as a
camcorder or VCR, connected to any of the VCR/DVD
Recorder’s external inputs.
11
Make sure that the component you want to
record from is connected properly to the
VCR/DVD Recorder. See page 17.
22
Press INPUT repeatedly to select the external
input to record from.
•AV1: Audio/Video Input mounted on back panel
•AV2 (AV2 COMP): Audio/Video Input mounted on front
panel
•DV: DV Input mounted on front panel
ote
Check that the Audio In settings DV Rec Audio are as
you want them. See page 24.
33
Load a recordable disc or tape.
44
Set a recording mode as necessary by pressing
REC MODE repeatedly.
DVD: SP (Standard Quality), LP (Low Quality),
XP(High Quality)
VCR: SP (Standard Play), SLP (Super Long Play)
55
Press REC (z) once.
Recording will start. (The REC indicator lights in the
display window.)
Recording continues until you press STOP (x) or the
disc is full.
To record for a fixed length of time, see Instant Timer
Recording on page 39.
66
Press STOP (x) to stop recording.
ote
If your source is copy-protected using CopyGuard, you will not
be able to record it using this recorder. See Copyright on page
8 for more details.
Recording from a Digital Camcorder
You can record from a digital camcorder connected to
the DV IN jack on the front panel of this VCR/DVD
Recorder. You can use the VCR/DVD Recorder’s
remote to control both the camcorder and the VCR/DVD
Recorder. Before recording, make sure that the audio
input for the DV IN jack is set up (see page 24).
ips
•The source signal must be DVC-SD format.
•Some camcorders cannot be controlled using the
VCR/DVD Recorder remote.
•If you connect a second DVD recorder using a DV
cable, you cannot control the second recorder from
this one.
•You cannot control the VCR/DVD Recorder remotely
from a component connected to the DV IN jack.
•You cannot record date and time information from a
DV cassette.
11
Make sure your digital camcorder is connected
to the front panel DV IN jack. See page 17.
22
Check that the DV audio input is as you require.
You can choose between Audio 1 (original audio) and
Audio 2 (overdubbed audio).
•DV Input is set from the DV Rec Audio in sub-menu of
the General menu. See DV Rec Audio on page 24 for
more information.
33
Press INPUT repeatedly to select the DV input.
DV appears in the display window.
44
Find the place on the camcorder tape from
which you want to start recording.
For best results, pause playback at the point from which
you want to record.
•Depending on your camcorder, you can use this
VCR/DVD Recorder’s remote control to control the
camcorder using the STOP, PLAY and PAUSE func-
tions.
55
Press REC (z) once to start recording.
•Recording is automatically stopped if the recorder
detects no signal.
•You can pause or stop the recording by pressing
PAUSE/STEP or STOP. You cannot control the cam-
corder from this remote control during recording.
•In Video mode, the final frame of the recording may
remain displayed on screen for a while after recording
stops.
Playing Recordings on Other DVD
Players
Most regular DVD players can play finalized discs
recorded in Video mode. A small number of players
can also play DVD-RW discs recorded in VR mode,
finalized or not. Check the manual that came with the
other player to check what kinds of discs it will play.
Finalizing a Disc
Finalizing ‘fixes’ the recordings in place so that the
disc can be played on a regular DVD player or com-
puter equipped with a suitable DVD-ROM drive.
Finalizing a Video mode disc creates a menu screen
for navigating the disc. This is accessed by pressing
DISC MENU or TITLE. To finalize a disc, refer to
“DISC Finalize”on page 25.
RECORDING
43
Recording from an External Input (Continued)
What is DV?
Using DV, also known as i.LINK, you can connect a
DV-equipped camcorder to this recorder using a single
DV cable for input and output of audio, video, data and
control signals.
The i.LINK interface is also known as IEEE 1394-1995.
“i.LINK” and the “i.LINK” logo are trademarks.
•This recorder is only compatible with DV-format
(DVC-SD) camcorders. Digital satellite tuners and
Digital VHS video recorders are not compatible.
•You cannot connect more than one DV camcorder at
a time to this recorder.
•You cannot control this recorder from external equip-
ment connected via the DV IN jack (including two
DVD Recorders).
•It may not always be possible to control the connect-
ed camcorder via the DV IN jack.
•Digital camcorders can usually record audio as stereo
16-bit/48kHz, or twin stereo tracks of 12-bit/32kHz.
The VCR/DVD Recorder can only record one stereo
audio track. Set DV Record Audio to Audio 1 or Audio
2 as necessary (see page 24).
•Audio input to the DV IN jack should be 32 or 48kHz
(not 44.1kHz).
•Picture disturbance on the recording may occur if the
source component pauses playback or plays an
unrecorded section of tape, or if the power fails in the
source component, or the DV cable becomes discon-
nected.
•If DV Rec Audio is set to Audio 2, but no Audio 2 sig-
nal is present, DV Audio will be reset to Audio 1 auto-
matically.
DV-Related Messages
You may see the following messages appear on your
TV screen when using the DV IN jack.
Camcorder not connected
The camcorder is not connected properly, or the cam-
corder is switched off.
Too many devices connected
The DV jack on this recorder supports connection to
just one camcorder.
Check tape
There is no cassette loaded into the connected equip-
ment.
Uncontrollable device
The VCR/DVD Recorder cannot control the camcorder.
Updating device information
Camcorder is updating information for DV.
Camera Mode
Camcorder is set to camera mode.
Troubleshooting
If you cannot get a picture and/or audio through the DV
IN jack, check the following:
•Make sure the DV cable is properly connected.
•Try switching off the connected equipment, then
switch it back on.
•Try switching the audio input.
ote
Depending on the connected camcorder, you may not
be able to control it using the remote control supplied
with this VCR/DVD Recorder.
VR Mode: Original and Playlist Editing
44
Edits you make to the Original content changes the
actual content of the disc. For example, if you delete a
title or chapter from the Original content (Title or
Chapter), that title or chapter is deleted from the disc,
freeing up extra recording time.
When you edit the Playlist, on the other hand, you are
not changing the content of the disc. For example,
when you delete a title from the Playlist, you are just
telling the recorder not to play that title; nothing is actu-
ally deleted from the disc.
Titles, Chapters and Parts
Titles in the disc’s original content contain one or more
chapters. When you insert a title into the Playlist, all the
chapters within that title also appear. In other words,
chapters in the Playlist behave exactly as chapters on a
DVD-Video disc do. Parts are sections of Original or
Playlist titles. From the Original and Playlist menu you
can add or delete parts. Adding a chapter or title to the
Playlist creates a new title made up of a section (ie.,
chapter) of an Original title. Deleting a part removes
part of a title from the Original or Playlist menu.
Caution
•When editing using the Delete, Add and Move func-
tions, the start and end frames may not be exactly as
set in the start and end point display.
•During Playlist playback, you may notice a momen-
tary pause between edits. This is not a malfunction.
Adding Chapter Markers
You can put a chapter marker anywhere in a Playlist or
Original title during recording or playback.
Once the chapter is marked, you can use the Chapter
Search feature, as well as Erase, combine and move
chapters in the Original (Chapter) or Playlist (Chapter)
menu.
You can insert up to 999 chapter markers in both the
Original and Playlist contents.
11
Play the title (Original or Playlist).
22
At the point you want to start a new chapter,
press CHP ADD.
Achapter marker icon appears on the TV screen.
•You can also put chapter markers during recording.
Changing Title or Chapter Thumbnails
Each title and chapter displayed in the Original or
Playlist menu is represented by a thumbnail picture
taken from the start of that title or chapter.
If you prefer, select a different still picture from within a
title.
11
Play the title (Original or Playlist).
22
Press THUMBNAIL to make the currently dis-
played picture the one that appears in the
Original or Playlist menu.
The still picture that you choose appears in both the
Original or Playlist menu.
ip
You can also change the thumbnail picture of the title on
the Original (Chapter) or Playlist (Chapter) menu. Select
a chapter on the Original (Chapter) or Playlist (Chapter)
menu then press THUMBNAIL. The thumbnail picture of
the title that includes the chapter is changed.
Thumb.
VR
Chapter
VR
VR
VR Mode: Original and Playlist Editing (Continued)
U
sing
the
Original (Title) menu
The Original (Title) is where you build and edit your
Playlist, and where you can delete titles and make other
changes to the Original content of the disc. You can
also play individual titles directly from the Original (Title)
menu.
11
Press DISC MENU/LIST repeatedly to display
the Original (Title) menu.
•Use the v/Vbuttons to display the previous/next
page if there are more than 6 titles or chapters.
•To exit the menu, press RETURN (O).
ote
To switch between the Original (Title) and Playlist
(Title) menu, press DISC MENU/LIST repeatedly.
The Original and Playlist heading at the top of the
screen indicate which mode you are in.
22
To view Original (Title) options, select the title
you want then press ENTER.
Original (Title) options appears on the left side of
the Original (Title) display.
33
Use v/ Vto select an option then press ENTER
to confirm.
Play: Start playback of the
selected title.
View Chap.: Shows the
Original (Chapter) menu of the
title (Refer to right column on
this page).
Rename: Edits the title name.
(page 47)
Delete: Deletes the title from the
Original (Title) menu. (see page
47)
Playlist Add: Adds the title to
the Playlist. (see page 48)
Delete Part: Deletes a part of
the Title. (see page 50)
Copy to VCR: Copys the title to
a VHS tape.
44
Press RETURN (O) repeatedly to exit the
Original (Title) menu.
ip
Press DISPLAY to display more detailed title information
for selected title.
Using the Original (Chapter) menu
11
Press DISC MENU/LIST repeatedly to display
Original (Title) menu.
22
Use vVbBto choose the title you want to
view Original (Chapter) menu then press
ENTER.
Original (Title) options appears on the left side of
the Original (Title) menu.
33
Use v/ Vto select “View Chap.” from Original
(Title) options then press ENTER.
Original (Chapter) menu appears on the TV screen.
44
To view Original (Chapter) options, select the
chapter you want then press ENTER.
Original (Chapter) options appears on the left side
of the Original (Chapter) menu.
55
Use v/ Vto select an option then press ENTER
to confirm.
Play: Starts playback of the
selected chapter.
View Title: Shows the Original
(Title) menu (refer to left on this
page)
Delete: Deletes the chapter
from the Original (Chapter)
menu. (page 47)
Merge: Merges two chapters
into one. (page 49)
Playlist Add: Adds the chapter
to the Playlist. (page 48)
66
Press RETURN (O) repeatedly to exit Original
(Chapter) menu.
VRVR
EDITING
45
Original
-Title
DVD-VR
1hour 57min
Playlist
LIST
Free
SP
Close
Info.
DISPLAY
Select
TITLE 1
10/12 0:25:20
TITLE 2
10/14 0:5:12
TITLE 3
10/16 0:2:34
1/4
TITLE 4
10/17 0:6:06
Play
View Chap.
Rename
Delete
Playlist Add
Delete Part
Copy to VCR
Original
-Chapter
TITLE 1
10/12/2003 Wed 0:25:20 TV 11
1/3
Playlist
LIST
Close
Select
Play
View Title
Delete
Merge
Playlist Add
VR Mode: Original and Playlist Editing (Continued)
Using the Playlist (Title) Menu
11
Press DISC MENU/LIST repeatedly to display
the Playlist (Title) menu.
•Use the v/Vbuttons to display the previous/next
page if there are more than 6 titles or chapters.
•To exit the Playlist (Title), press RETURN (O).
22
To view Playlist (Title) options, select the title
you want then press ENTER.
Playlist (Title) options appears on the left side of the
Playlist (Title) menu.
33
Use v/ Vto select an option then press ENTER
to confirm.
Play: Start playback the select-
ed title.
View Chap.: Shows the Playlist
(Chapter) menu of the title
(Refer to right on this page).
Rename: Edits the title name.
(page 47)
Delete: Deletes the title from the
Playlist (Title) menu. (page 47)
Delete Part: Deletes a part of
the Title. (page 50)
Copy to VCR: Copys the title to
a VHS tape.
44
Press RETURN (O) repeatedly to exit Playlist
(Title) menu.
Using the Playlist (Chapter) Menu
11
Press DISC MENU/LIST repeatedly to display the
Playlist (Title) menu.
22
Use vVbBto choose the title you want to
view Playlist (Title) menu then press ENTER.
Playlist (Title) options appears on the left side of the
Playlist (Title) menu.
33
Use v/ Vto select ‘View Chap.’ from Playlist
(Title) options then press ENTER.
Playlist (Chapter) menu appears on the TV screen.
44
To view Playlist (Chapter) options, select the
chapter you want then press ENTER.
Playlist (Chapter) options appears on the left side of
the Playlist (Chapter) menu.
55
Use v/ Vto select an option then press ENTER
to confirm.
Play: Starts playback of the
selected chapter.
View Title: Shows the Playlist
(Title) menu (Refer to left on
this page).
Delete: Deletes the chapter from
the Playlist (Chapter) menu
(page 47).
Move: Moves a chapter of
Playlist (Chapter) to a position
on the Playlist (Chapter) menu
(page 49).
Merge: Merges two chapters
into one (page 49).
66
Press RETURN (O) repeatedly to exit Playlist
(Chapter) menu.
VRVR
46
Playlist
-Title
TITLE 1
10/12 0:25:20
TITLE 2
10/14 0:5:12
1/2
Original
LIST
Close
Select
Play
View Chap.
Rename
Delete
Delete Part
Copy to VCR
Playlist
-Chapter
Original
LIST
Close
Select
TITLE 1
10/12/2003 Wed 0:25:20 TV 11
1/3
Play
View Title
Delete
Move
Merge
EDITING
47
VR Mode: Original and Playlist Editing (Continued)
Naming a Title
You can name Original and Playlist titles independently.
Names can be up to 32 characters long.
11
Press DISC MENU/LIST repeatedly to display
Original (Title) or Playlist (Title) menu.
22
Use vVbBto choose the title you want to
name then press ENTER.
Options appears on the left side of the menu.
Original (Title) Playlist (Title)
33
Use v/Vto select ‘Rename’ option then press
ENTER.
The Keyboard menu appears.
44
Enter a name for the title. Use vVbBto select
a character then press ENTER to confirm your
selection. Refer step 5 as shown on page 26
(DISC Name).
55
Choose OK then press ENTER to save the name
and return to the previous menu screen.
66
Press RETURN (OO) repeatedly to exit the
menu.
ote
For discs formatted on a different DVD Recorder, you
will see only a limited character set.
Deleting an Original or Playlist
Title/Chapter
When you erase a title or chapter from the Playlist
menu, you only remove it from the Playlist; the
title/chapter remains in the Original menu.
If you choose to delete a title or chapter from the
Original (title/chapter) menu, the title or chapter is actu-
ally deleted from the disc and the remaining time avail-
able for recording increases. Titles/chapters deleted
from the Original are also removed from the Playlist.
ote
It may not be possible to delete chapters that are less
than 3 seconds long.
11
Press DISC MENU/LIST repeatedly to display
Original (Title) or Playlist (Title) menu.
If you want to display the Original (Chapter) or
Playlist (Chapter) menu, refer to “Using Original
(Chapter) menu” or “Using Playlist (Chapter) menu”
on pages 45-46.
22
Use vVbBto choose a chapter or title you
want to delete then press ENTER.
Options appears on the left side of the screen.
33
Select ‘Delete’ on the menu.
e.g., If you select “Delete” on Original (Title) menu.
44
Press ENTER to confirm.
The confirm message for deleting will appear.
55
Use b/ Bto select ‘Yes’then press ENTER.
The selected chapter or title is deleted.
After pressing ENTER, the new, updated menu is
displayed.
66
Repeat steps 2 - 5 to continue to delete from the
menu.
77
Press RETURN (OO) repeatedly to exit the
menu.
VR
VR
0123456789
ABCDEFGH I J
KLMNOPQRST
UVWXYZ
TITLE 2
English/Latin CapitalLanguage
OK Cancel
Space Delete
Play
View Chap.
Rename
Delete
Playlist Add
Delete Part
Copy to VCR
Play
View Chap.
Rename
Delete
Delete Part
Copy to VCR
Play
View Chap.
Rename
Delete
Playlist Add
Delete Part
Copy to VCR
Making a New Playlist
Use this function to add an Original title or chapter to
the Playlist. When you do this, the whole title is put into
the Playlist (you can delete bits you don’t need later —
see Deleting an Original or Playlist Title/Chapter on
page 48).
The title appears in the Playlist complete with the chap-
ter markers that appear in the Original. However, if you
add more chapter markers to the Original later, these
are not automatically copied over into the Playlist title.
You can add up to 999 chapters to one disc . If you only
want to add a chapter of a title, use the Adding a
title/chapter to the Playlist on this page.
11
Press DISC MENU/LIST repeatedly to display
Original (Title) menu.
If you want to display the Original (Chapter) menu,
refer to “Using the Original (Chapter) menu” on
page 45.
22
Choose a title or chapter on the Original menu
to put into the Playlist, then press ENTER.
Original (Title or Chapter) options appears on the
left side of the Original (Title or Chapter) menu.
Original (Title) Original (Chapter)
33
Use v/ Vto select ‘Playlist Add’ from from the
Original (Title or Chapter) options then press
ENTER.
44
Select ‘New Playlist’ then press ENTER.
The new title appears in the updated Playlist. All
chapters of the title are added to the Playlist.
Adding Titles/Chapters to the Playlist
You can add an Original title or chapter to add to a
Playlist title even if it is already registered.
11
Press DISC MENU/LIST repeatedly to display
Original (Title) menu.
If you want to show the Original (Chapter) menu,
refer to “Using the Original (Chapter)” on page 45.
22
Choose an Original title or chapter to put into
the Playlist, then press ENTER.
The Original (Title) or Original (Chapter) options
appear on the left side of the screen.
Original (Title) Original (Chapter)
33
Use v/ Vto select ‘Playlist Add’ from the
Original (Title) or Original (Chapter) options
then press ENTER.
44
Choose a Playlist title that is already registered
to insert a title, then press ENTER.
The title appears in the updated Playlist menu.
55
Repeat steps 1-4 to continue adding to the
Playlist.
66
Press RETURN (OO) to exit, or DISC MENU/LIST
to go back to the Original (Title) menu.
VR
VR
VR Mode: Original and Playlist Editing (Continued)
48
New Playlist
Select Playlist.
TITLE 1
Play
View Chap.
Rename
Delete
Playlist Add
Delete Part
Copy to VCR
Play
View Title
Delete
Merge
Playlist Add
New Playlist
Select Playlist.
Play
View Chap.
Rename
Delete
Playlist Add
Delete Part
Copy to VCR
Play
View Title
Delete
Merge
Playlist Add
Playlist
-Title
TITLE 1
10/12 0:25:20
TITLE 2
10/14 0:5:12
3/3
TITLE 3
10/19 0:17:23
Original
LIST
Close
Select
VR Mode: Original and Playlist Editing (Continued)
EDITING
49
Combining Two Chapters Into One
Use this function to combine two adjacent Playlist or
Original chapters into one.
11
Press DISC MENU/LIST repeatedly to display
Original (Title) or Playlist (Title) menu.
If you want to display the Original (Chapter) or
Playlist (Chapter) menu, refer to “Using the Original
(Chapter)” and “Using the Playlist (Chapter)” on
page 45-46.
22
First, select the second chapter of the two chap-
ters you want to combine then press ENTER on
the Original (Chapter) or playlist (Chapter)
menu.
Playlist (Chapter) or Original (Chapter) options
appears on the left side of the screen.
Original (Chapter) Playlist (Chapter)
33
Use v/ Vto select ‘Merge’ option then press
ENTER.
The confirm message for combining will appear.
44
Use b/ Bto select ‘Yes’then press ENTER.
After pressing ENTER, the new, updated menu is
displayed.
55
Repeat steps 2 - 5 to continue to merge from
the menu.
66
Press RETURN (OO) repeatedly to exit the
menu.
ote
This function cannot operate listed below;
•If there is only one chapter within the title.
•If two chapters created by erasing a part from an
original title.
•If two chapters created from different titles.
•If two chapters created by moving an order from an
original title.
Moving a Playlist Chapter
Use this function to re-arrange the playing order of
Playlist chapters on the Playlist (Title) menu.
11
Press DISC MENU/LIST repeatedly to display
Playlist (Title) menu.
To display the Playlist (Chapter) menu, refer to
“Using the Playlist (Chapter)” on page 46.
ote
This function is not available if there is only one chapter.
22
Select a chapter from the Playlist (Chapter)
menu.
33
Press ENTER.
Playlist (Chapter) options appears on the left side of
the screen.
44
Use v/ Vto select ‘Move’ from Playlist
options then press ENTER.
55
Use vVbBto choose the place you want to
move the chapter to then press ENTER.
The confirm message for moving will appear.
66
Use b/ Bto select ‘Yes’then press ENTER.
After pressing ENTER, the new, updated menu is
displayed.
77
Repeat steps 2 - 6 to continue to move from the
menu.
88
Press RETURN (O) repeatedly to exit the
menu.
VR
VR
Play
View Title
Delete
Move
Merge
Play
View Title
Delete
Merge
Playlist Add
Play
View Title
Delete
Move
Merge
Playlist
-Chapter
Original
LIST
Close
Select
TITLE 1
10/12/2003 Wed 0:25:20 TV 11
1/3
VR Mode: Original and Playlist Editing (Continued)
Deleting a Part
You can delete a part which you do not want in the title.
11
Press DISC MENU/LIST repeatedly to display
Original (Title) or Playlist (Title) menu.
22
Use vVbBto choose a title you want to
delete then press ENTER.
The options appears on the left side of the menu.
Original (Title) Playlist (Title)
33
Use v/ Vto select ‘Delete Part’ then press
ENTER.
The Title Edit menu appears on the TV screen and
the VCR/DVD Recorder goes into Pause mode.
The Start Point option is highlighted.
44
Use PLAY, PAUSE/STEP, FF, REW, and Slow
Motion playback to find the starting point.
The segment is indicated in yellow on the Progress
Bar.
55
Press ENTER at the starting point of the seg-
ment you want to erase.
The End Point option is selected.
66
Use PLAY, PAUSE/STEP, FF, REW, and Slow
Motion playback to find the ending point.
77
Press ENTER at the ending point of the section
you want to edit.
The Done option is selected.
To cancel the Edit mode, select Cancel using v/V
then press ENTER.
88
Press ENTER to delete the selected part.
When the confirm menu appears, select “Yes” using
b/ B then press ENTER.
To erase additional segments, repeat steps 4-8.
99
When finished editing, press RETURN (O).
The Original (Title) or Playlist (Title) menu appears.
ote
If you select Cancel then press ENTER, the VCR/DVD
Recorder will go to previous option and into Pause
mode.
VR
50
Play
View Chap.
Rename
Delete
Playlist Add
Delete Part
Copy to VCR
Play
View Chap.
Rename
Delete
Delete Part
Copy to VCR
Title Edit
Move Point
Select
Start Point
Play & Select the Start Point
-Delete Part
End Point
Cancel
Done
00:00:00
Start
End
TITLE 2
10/14 0:34:12
Close
Video Mode: Original Editing
Using the Title List
From the Title List display you can play, name and
erase titles.
Once a Video mode disc is finalized, the Title List
screen changes its appearance and all you can do is
select titles to play.
11
Press DISC MENU/LIST to display the Title List.
22
Use v/ Vto choose a title then press ENTER.
Title List options appears on the left side of the Title
List display.
If you get more information, press Display
33
Use v/ Vto select an option then press ENTER
to confirm.
Play: Start playback the select-
ed title.
Rename: Edits the title name
(page 47).
Delete: Deletes the title from the
Title List.
Copy to VCR: Copys the title to
a VHS tape.
44
Press RETURN (O) repeatedly to exit Title List.
Deleting a Title
Before a disc is finalized, you can erase titles recorded
on the disc.
Caution
•If you erase a title from a DVD-R disc,the title will dis-
appear from the Title List, but the available recording
time will not increase.
•When erasing a title from a DVD-RW disc, the
remaining time available for recording will only
increase if it is the last title on the disc.
11
Press DISC MENU/LIST to display Title List
22
Use vVbBto choose a title you want to erase
then press ENTER.
Title List options appears on the left side of the Title
List screen.
33
Use v/ Vto select ‘Delete’ then press ENTER to
confirm.
The confirm message for deleting will appear.
44
Use b/ Bto select ‘Yes’then press ENTER.
The selected chapter or title is deleted.
After pressing ENTER, the new, updated menu is
displayed.
55
Repeat steps 2 - 4 to continue to delete from the
menu.
66
Press RETURN (OO) to exit the menu.
If the disc has already been finalized
You will see a screen as shown below:
VideoVideo
EDITING
51
Play
Rename
Delete
Copy to VCR
Play
Rename
Delete
Copy to VCR
Title List
DVD VIDEO
TITLE 1 1/ 3 0:02:01
TITLE 2 1/ 3 0:06:21
TITLE 3 4/ 12 0:52:31
1/3
1hour 57min
Free
SP
Title DurationDate
Close
Info.
DISPLAY
Select
DVD VIDEO 1/1
PAGE
UP
PAGE
DOWN
EXIT
1 TITLE 1 1/03 0:02:01
2 TITLE 2 1/03 0:24:12
3 TITLE 3 1/03 0:36:30
Disc name
Title list
Exits the Title List screen.
Moves to the next or
previous page
Indicates total and current page number
Controlling Your TV with the Supplied Remote
52
You can control the sound level, input source, and
power switch of your LG TV with the supplied remote.
You can control your TV using the buttons below.
By pressing You can
POWER Turn the TV on or off.
INPUT Switch the TV’s input source
between the TV and other input
sources.
CH +/– Scans up or down through
memorized channels.
VOL +/– Adjust the volume of the TV.
MUTE Turns on or off TV sound.
ote
Depending on the unit being connected, you may not be
able to control your TV using some of the buttons.
Controlling other TVs with the remote
You can control the sound level, input source, and
power switch of non-LG TVs as well. If your TV is listed
in the table below, set the appropriate manufacturer
code.
1. While holding down TV POWER button, press
the number buttons to select the manufacturer
code for your TV (see the table below).
2. Release TV POWER button.
Code numbers of controllable TVs
If more than one code number is listed, try entering
them one at a time until you find the one that works with
your TV.
Manufacturer Code Number
LG / GoldStar 1 (Default), 2
Zenith 1, 3, 4
Samsung 6, 7
Sony 8, 9
Hitachi 4
otes
Depending on your TV, some or all buttons may not
function on the TV, even after entering the correct
manufacturer code.
If you enter a new code number, the code number
previously entered will be erased.
When you replace the batteries of the remote, the
code number you have set may be reset to the
default setting. Set the appropriate code number
again.
TV Control
Buttons
Language Code List
REFERENCE
53
Code Language
6566 Abkhazian
6565 Afar
6570 Afrikaans
8381 Albanian
6577 Amharic
6582 Arabic
7289 Armenian
6583 Assamese
6588 Aymara
6590 Azerbaijani
6665 Bashkir
6985 Basque
6678 Bengali; Bangla
6890 Bhutani
6672 Bihari
6682 Breton
6671 Bulgarian
7789 Burmese
6669 Byelorussian
7577 Cambodian
6765 Catalan
9072 Chinese
6779 Corsican
7282 Croatian
6783 Czech
6865 Danish
7876 Dutch
6978 English
6979 Esperanto
6984 Estonian
7079 Faeroese
Code Language
7074 Fiji
7073 Finnish
7082 French
7089 Frisian
7176 Galician
7565 Georgian
6869 German
6976 Greek
7576 Greenlandic
7178 Guarani
7185 Gujarati
7265 Hausa
7387 Hebrew
7273 Hindi
7285 Hungarian
7383 Icelandic
7378 Indonesian
7365 Interlingua
7165 Irish
7384 Italian
7465 Japanese
7487 Javanese
7578 Kannada
7583 Kashmiri
7575 Kazakh
7589 Kirghiz
7579 Korean
7585 Kurdish
7679 Laothian
7665 Latin
7686 Latvian, Lettish
Code Language
7678 Lingala
7684 Lithuanian
7775 Macedonian
7771 Malagasy
7783 Malay
7776 Malayalam
7784 Maltese
7773 Maori
7782 Marathi
7779 Moldavian
7778 Mongolian
7865 Nauru
7869 Nepali
7879 Norwegian
7982 Oriya
8065 Panjabi
8083 Pashto, Pushto
7065 Persian
8076 Polish
8084 Portuguese
8185 Quechua
8277 Rhaeto-Romance
8279 Romanian
8285 Russian
8377 Samoan
8365 Sanskrit
7168 Scots Gaelic
8382 Serbian
8372 Serbo-Croatian
8378 Shona
8368 Sindhi
Code Language
8373 Singhalese
8375 Slovak
8376 Slovenian
8379 Somali
6983 Spanish
8385 Sudanese
8387 Swahili
8386 Swedish
8476 Tagalog
8471 Tajik
8465 Tamil
8484 Tatar
8469 Telugu
8472 Thai
6679 Tibetan
8473 Tigrinya
8479 Tonga
8482 Turkish
8475 Turkmen
8487 Twi
8575 Ukrainian
8582 Urdu
8590 Uzbek
8673 Vietnamese
8679 Volapük
6789 Welsh
8779 Wolof
8872 Xhosa
7473 Yiddish
8979 Yoruba
9085 Zulu
Enter the appropriate code number for the initial settings “Disc Audio”, “Disc Subtitle” and/or “Disc Menu”
(See page 20).
Country Code List
54
Code Country
AD Andorra
AE United Arab Emirates
AF Afghanistan
AG Antigua and Barbuda
AI Anguilla
AL Albania
AM Armenia
AN Netherlands Antilles
AO Angola
AQ Antarctica
AR Argentina
AS American Samoa
AT Austria
AU Australia
AW Aruba
AZ Azerbaidjan
BA Bosnia-Herzegovina
BB Barbados
BD Bangladesh
BE Belgium
BF Burkina Faso
BG Bulgaria
BH Bahrain
BI Burundi
BJ Benin
BM Bermuda
BN Brunei Darussalam
BO Bolivia
BR Brazil
BS Bahamas
BT Bhutan
BV Bouvet Island
BW Botswana
BY Belarus
BZ Belize
CA Canada
CC Cocos (Keeling) Islands
CF Central African Republic
CG Congo
CH Switzerland
CI Ivory Coast
CK Cook Islands
CL Chile
CM Cameroon
CN China
CO Colombia
CR Costa Rica
CS Former Czechoslovakia
CU Cuba
CV Cape Verde
CX Christmas Island
CY Cyprus
CZ Czech Republic
DE Germany
DJ Djibouti
DK Denmark
DM Dominica
DO Dominican Republic
DZ Algeria
EC Ecuador
EE Estonia
EG Egypt
EH Western Sahara
Code Country
ER Eritrea
ES Spain
ET Ethiopia
FI Finland
FJ Fiji
FK Falkland Islands
FM Micronesia
FO Faroe Islands
FR France
FX France (European
Territory)
GA Gabon
GB Great Britain
GD Grenada
GE Georgia
GF French Guyana
GH Ghana
GI Gibraltar
GL Greenland
GM Gambia
GN Guinea
GP Guadeloupe (French)
GQ Equatorial Guinea
GR Greece
GS S. Georgia & S. Sandwich
Isls.
GT Guatemala
GU Guam (USA)
GW Guinea Bissau
GY Guyana
HK Hong Kong
HM Heard and McDonald
Islands
HN Honduras
HR Croatia
HT Haiti
HU Hungary
ID Indonesia
IE Ireland
IL Israel
IN India
IO British Indian Ocean
Territory
IQ Iraq
IR Iran
IS Iceland
IT Italy
JM Jamaica
JO Jordan
JP Japan
KE Kenya
KG Kyrgyzstan
KH Cambodia6
KI Kiribati
KM Comoros
KN
Saint Kitts & Nevis Anguilla
KP North Korea
KR South Korea
KW Kuwait
KY Cayman Islands
KZ Kazakhstan
LA Laos
LB Lebanon
Code Country
LC Saint Lucia
LI Liechtenstein
LK Sri Lanka
LR Liberia
LS Lesotho
LT Lithuania
LU Luxembourg
LV Latvia
LY Libya
MA Morocco
MC Monaco
MD Moldavia
MG Madagascar
MH Marshall Islands
MK Macedonia
ML Mali
MM Myanmar
MN Mongolia
MO Macau
MP Northern Mariana Islands
MQ Martinique (French)
MR Mauritania
MS Montserrat
MT Malta
MU Mauritius
MV Maldives
MW Malawi
MX Mexico
MY Malaysia
MZ Mozambique
AN Namibia
NC New Caledonia (French)
NE Niger
NF Norfolk Island
NG Nigeria
NI Nicaragua
NL Netherlands
NO Norway
NP Nepal
NR Nauru
NU Niue
NZ New Zealand
OM Oman
PA Panama
PE Peru
PF Polynesia (French)
PG Papua New Guinea
PH Philippines
PK Pakistan
PL Poland
PM Saint Pierre and Miquelon
PN Pitcairn Island
PR Puerto Rico
PT Portugal
PW Palau
PY Paraguay
QA Qatar
RE Reunion (French)
RO Romania
RU Russian Federation
RW Rwanda
SA Saudi Arabia
SB Solomon Islands
Code Country
SC Seychelles
SD Sudan
SE Sweden
SG Singapore
SH Saint Helena
SI Slovenia
SJ Svalbard and Jan Mayen
Islands
SK Slovak Republic
SL Sierra Leone
SM San Marino
SN Senegal
SO Somalia
SR Suriname
ST Saint Tome and Principe
SU Former USSR
SV El Salvador
SY Syria
SZ Swaziland
TC Turks and Caicos Islands
TD Chad
TF French Southern
Territories
TG Togo
TH Thailand
TJ Tadjikistan
TK Tokelau
TM Turkmenistan
TN Tunisia
TO Tonga
TP East Timor
TR Turkey
TT Trinidad and Tobago
TV Tuvalu
TW Taiwan
TZ Tanzania
UA Ukraine
UG Uganda
UK United Kingdom
UM USA Minor Outlying
Islands
US United States
UY Uruguay
UZ Uzbekistan
VA Vatican City State
VC Saint Vincent &
Grenadines
VE Venezuela
VG Virgin Islands (British)
VI Virgin Islands (USA)
VN Vietnam
VU Vanuatu
WF Wallis and Futuna Islands
WS Samoa
YE Yemen
YT Mayotte
YU Yugoslavia
ZA South Africa
ZM Zambia
ZR Zaire
ZW Zimbabwe
Enter the appropriate code number for the initial setting “Country Code” (See page 23).
REFERENCE
55
Troubleshooting
Check the following guide for the possible cause of a problem before contacting service.
Symptom
No power.
No picture.
No sound.
Playback picture is poor.
VCR/DVD Recorder does
not start playback.
Picture from external input
is distorted
Some channels are
skipped over when using
CH (v/ V)
Picture or sound of
broadcasting channel is
weak or missing.
Camcorder image not
shown.
Camcorder image via A/V
input or DV IN to
VCR/DVD Recorder is not
shown on TV screen.
Can’t play disc recorded
on this VCR/DVD
Recorder on another DVD
player.
Cause
The power cord is disconnected.
The TV is not set to receive VCR/DVD
Recorder signal output.
The video cable is not connected securely.
The TV power is turned off.
The equipment connected with the audio
cable is not set to receive VCR/DVD
Recorder signal output.
The audio cables are not connected securely.
The power of the equipment connected with
the audio cable is turned off.
The audio connecting cord is damaged.
The disc is dirty.
Tape heads are dirty.
Tape is a rental or was recorded on another
VCR.
No disc is inserted.
No tape is inserted.
An unplayable disc is inserted.
The disc is placed upside down.
The disc is not placed within the guide.
The disc is dirty.
The Movie Rating level is set.
The video signal from the external compo-
nent is copy-protected.
The skipped channels were deleted with the
CH. Add/Del feature.
Antenna or cables are loose.
Wrong Tuning Band is selected in the
VCR/DVD Recorder Setup menu.
Camcorder is off.
VCR/DVD Recorder’s source is not set to
AV1, AV2 (AV2 COMP) or DV IN.
The disc was recorded in Video mode.
Some players will not play even a finalized
disc recorded in Video mode.
The disc was recorded in VR mode.
Discs recorded with copy-once material can-
not be played on other players.
Solution
Plug the power cord into the wall outlet
securely.
Select the appropriate video input on the TV
so the picture from the VCR/DVD Recorder
appears on the TV screen.
Connect the video cable securely.
Turn on the TV.
Select the correct input mode on the audio
receiver so you can listen to the sound from
the VCR/DVD Recorder.
Connect the audio cable securely.
Turn on the equipment connected with the
audio cable.
Replace it with a new one.
Clean the disc.
Clean video heads.
Use v/Vfor manual tracking adjustment while
tape is playing.
Insert a disc or tape. (Check that the disc
indicator on the front panel display is lit.)
Insert a playable disc. (Check the disc type,
color system, and regional code.)
Place the disc with the playback side down.
Place the disc on the disc tray correctly inside
the guide.
Clean the disc.
Cancel the Movie Rating function or change
the rating level.
You cannot connect via the VCR/DVD
Recorder. Connect the component directly to
your TV.
Use the CH. Add/Del feature to restore chan-
nels. See “To Add or Erase Channels from
Memory” on page 19.
Tighten connections or replace cable.
Try “Tuning Band Select” options; see page
18 for details.
Turn camcorder on and operate
properly.
Use INPUT to select AV input channel (AV1,
AV2 (AV2 COMP) or DV IN).
Finalize the disc; see page 25.
No solution.
The other player must be RW compatible in
order to play it.
No solution.
Troubleshooting (Continued)
56
Symptom
Cannot record or did not
record successfully.
Timer Recording not possi-
ble.
Stereo Audio Record
and/or Playback not pres-
ent.
Remote control does not
work properly.
Cause
The remaining blank space on the disc is
insufficient.
The source you are trying to record is copy-
protected.
When setting the recording channel, the
channel is tuned on the TV’s own tuner.
When recording to a Video mode disc, pro-
grams that are copy-once protected cannot
be recorded.
Clock in VCR/DVD Recorder is not set to
correct time.
Timer has been programmed
incorrectly.
TIMER indicator light does not appear after
programming timer.
TV is not Stereo-compatible.
Broadcast program is not in stereo format.
VCR/DVD Recorder A/V Out jacks are not
connected to TV A/V In jacks.
VCR/DVD Recorder Audio/Video Out is not
selected for viewing at the TV.
VCR/DVD Recorder’s TV audio channel is
set to SAP or MONO.
The remote control is not pointed at the
remote sensor of the VCR/DVD Recorder.
The remote control is too far from the
VCR/DVD Recorder.
There is an obstacle in the path of the
remote control and the VCR/DVD Recorder.
The batteries in the remote control are
exhausted.
Solution
Use another disc.
You cannot record the source.
Select the channel on the VCR/DVD
Recorder’s built-in TV tuner.
Use a VR mode formatted disc for copy-once
material.
Set clock to correct time. See “Auto Clock
Set” or “Manual Clock Set” on page 19.
Reprogram Timer. See “Timer Recording” on
page 41.
Reprogram Timer.
No solution.
No solution.
Make A/V connections. Stereo is available
only via A/V output from
VCR/DVD Recorder
.
Select AUX or A/V source as TV input.
Set TV audio channel mode to Stereo. See
“Changing TV Audio Channel” on page 27.
Point the remote control at the remote sensor
of the VCR/DVD Recorder.
Operate the remote control within 23 ft (7 m).
Remove the obstacle.
Replace the batteries with new ones.
Moisture Condensation
Moisture condensation can occur:
•When the VCR/DVD Recorder is moved from a cold
place to a warm place.
•Under extremely humid conditions.
In locations where moisture condensation may occur:
•
Keep the
VCR/DVD Recorder
plugged into an AC power
outlet with POWER On. This will help prevent conden-
sation.
•When condensation has occurred, wait a few hours
for the VCR/DVD Recorder to dry before using it.
Reset the VCR/DVD Recorder
If you observe any of the following symptoms...
When the VCR/DVD Recorder is plugged in, but the power will not turn on or off.
When the display window does not working.
When the VCR/DVD Recorder does not operate normally.
You can reset the VCR/DVD Recorder as follows :
Press and hold the POWER button for more than five seconds. This will force the VCR/DVD Recorder to power off. .
Press the POWER button again to turn the VCR/DVD Recorder back on.
Unplug the power cord and then plug the power cord again after more than five seconds.
Specifications
REFERENCE
57
General
Power requirements AC 120V, 60 Hz
Power consumption 35W
Dimensions (approx.) 430 X 83.5 X 360 mm (16.9 x 3.25 x 14.2 inches) (w x h x d)
Mass (approx.) 6.8 kg (14.9 lbs)
Operating temperature 5˚C to 35˚C (41˚F to 95˚F)
Operating humidity 5 % to 90 %
Signal system NTSC
Recording
Recording format DVD VideoRecording, DVD-VIDEO
Recordable discs DVD-ReRecordable, DVD-Recordable
Recordable time DVD ; Approx. 1 hour (XP mode), 2 hours (SP mode), 4 hours (LP mode)
VCR ; SP: 2 HOURS (T-120), SLP: 6 HOURS (T-120)/8 HOURS (T-160)
Video recording format
Sampling frequency 27MHz
Compression format MPEG 2
Audio recording format
Sampling frequency 48kHz
Compression format Dolby Digital
VCR Specifications
Head system Four head helical scan azimuth system
Timer 12-hour display type with AM, PM
Tape speed SP: 33.35 mm/sec, LP: 16.67 mm/sec, SLP: 11.12 mm/sec
Tape width 12.7 mm
Rewind time About 65 seconds (T-120)
Antenna 75 ohms (VHF/UHF)
VHF output signal Channel 3 or 4 (Switchable)
Channel coverage VHF: 2-13, UHF: 14-69, CATV: 1-125 (4A, A-W, W+1 - W+84, A-5 - A-1)
Frequency range 20Hz to 20kHz
Signal-to-noise ratio 43dB
Dynamic range 88 dB
Channel separation 60 dB
DVD Specifications
Laser system Semiconductor laser, wavelength 650 nm
Frequency response DVD (PCM 48 kHz): 8 Hz to 22 kHz, CD: 8 Hz to 20 kHz
Signal-to-noise ratio More than 95dB
Harmonic distortion Less than 0.008%
Dynamic range More than 90 dB
Inputs
ANTENNA IN Antenna or CATV input, 75 ohms
VIDEO IN (AV1,2) 1.0 Vp-p 75 ohms, sync negative, RCA jack x 2
AUDIO IN (AV1,2) -6 dBm more than 47 kohms, RCA jack (L, R) x 2
DV IN 4 pin (i.LINK/IEEE 1394 standard)
Specifications (Continued)
58
Outputs
VIDEO OUT 1 Vp-p 75 Ω, sync negative, RCA jack x 1
S-VIDEO OUT (Y) 1.0 V (p-p), 75 Ω, negative sync, Mini DIN 4-pin x 1
(C) 0.286 V (p-p) 75 Ω
COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 Ω, negative sync, RCA jack x 1
(PROGRESSIVE SCAN) (Pb)/(Pr) 0.7 V (p-p), 75 Ω, RCA jack x 2
Audio output (digital audio) 0.5 V (p-p), 75 Ω, RCA jack x 1
Audio output (optical audio) Optical connector x 1
Audio output (analog audio) 1.1 Vrms (1 kHz, -6 dB), 600 Ω, RCA jack (L, R) x 2
RF OUT Channel 3 or 4 (Switchable)
Accessory:
Video cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Audio cable . . . . . . . . . . . . . . . . . . . . .1
RF 75-ohm Coaxial Cable . . . . . . . . . . . . . . . . . .1 Remote control . . . . . . . . . . . . . . . . . .1
Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Design and specifications are subject to change without notice.
Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby
Laboratories.
DTS and DTS Digital Out are registered trademarks of Digital Theater Systems, Inc.
This LG Electronics product, will be repaired or replaced, at LG’s option, if it proves to be defective in material or
workmanship, under normal use, during the warranty period (“Warranty Period”) listed below, effective from the date
(“Date of Purchase”) of original consumer purchase of the product. This warranty is good only to the original pur-
chaser of the product and effective only when used in the United States, excluding U.S. Territories.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION,
ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TO THE EXTENT ANY IMPLIED
WARRANTY IS REQUIRED BY LAW, IT IS LIMITED IN DURATION TO THE EXPRESS WARRANTY PERIOD ABOVE. LG ELEC-
TRONICS WILL NOT BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL OR PUNITIVE DAMAGES
OF ANY NATURE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, INCLUDING WITHOUT LIMITATION, LOST
REVENUES OR PROFITS, LOST OR CORRUPTED PROGRAMMING OR DATA, OR ANY OTHER DAMAGE WHETHER BASED
IN CONTRACT, TORT OR OTHERWISE. Some states do not allow the exclusion or limitation of incidental or consequential dam-
ages or limitation on how long an implied warranty lasts, so the above exclusion or limitation may not apply to you. This warranty
gives you specific legal rights and you may also have other rights that may vary from state to state.
THIS LIMITED WARRANTY DOES NOT APPLY TO:
•Damages or operating problems that result from shipping, installation, adjustment of user controls, calibration,
maintenance or failure to maintain, or separate system components; and
•Damages or operating problems that result from normal wear and tear, misuse, abuse, operation outside
environmental specifications or contrary to the requirements or precautions in the Operating Guide, accident,
lightning strikes or other natural causes, unauthorized modification or alteration, incorrect electrical current or
voltage, reception problem caused by inadequate home antenna or faulty antenna connections, computer
software, institutional or commercial use, or other causes not arising out of defect in material or workmanship.
Therefore, the cost of repair or replacement of such defective product shall be borne by the consumer.
CUSTOMER INTER-ACTIVE CENTER NUMBERS:
WARRANTY PERIOD:
LABOR: 90 days from the Date of Purchase.
PARTS: One Year from the Date of Purchase.
*Parts replaced are warranted for the remaining portion
of the original warranty period.
HOW SERVICE IS HANDLED:
Call 1-800-243-0000 for instructions on getting the
defective unit repaired or replaced.
Please retain dated sales receipt and your box to
return the unit to LG for repair or replacement.
Shipping both ways will be paid by LG during the
Warranty Period. After the Warranty Period, you pay
inbound shipping charges and LG pays return shipping
charges.
Visit our website at: http://www.lgservice.com
For nearest Authorized Service Center, Where to buy,
Product Assistance, or Customer Assistance
Call 1-800-243-0000 (24 hours a day, 365 days per year)
and select appropriate options from the menu.
Or visit our website at http://www.lgservice.com
LG Electronics, Inc.
VCR/DVD Recorder -LGXBR446
Limited Warranty - USA
LG ELECTRONICS U.S.A., INC.
1000 SYLVAN AVENUE
ENGLEWOOD CLIFFS, NJ
P/N : 3835RV0002G
Issue O
Printed in Korea

Navigation menu
