GM730 User Manual HTML Version

Users Manual

This document is the user guide for the GM730

Windows Mobile Pocket PC. All rights for this document are reserved by

LG Electronics. Copying, modifying and distributing this document without

the consent of LG Electronics are prohibited.

GM 730 User Guide

- English

This device is not intended for sale in the USA.

Part 15.21 statement

" Change or Modifications that are not expressly approved by the manufacturer could void

the user's authority to operate the equipment. “

Part 15.105 statement

This equipment has been tested and found to comply with the limits for a class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful interference or

television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

Part 15 Class B Compliance

This device and its accessories comply with part15 of FCC rules.

Operation is subject to the following two conditions:

(1) This device & its accessories may not cause harmful interference.

(2) This device & its accessories must accept any interference received,

including interference that may cause undesired operation.

Body-worn Operation

This device has been tested for typical body-worn operations

with the distance of 0.79inches (2.0cm) from the user’s body.

To comply with FCC RF exposure requirements, a minimum separation distance

of 0.79inches(2.0cm) must be maintained from the user's body.

Additionally, Belt clips, holsters & other body-worn accessories may not contain

metallic components.

Getting Started

Installing the SIM Card and Battery

1. Installing the SIM card.

Your SIM card contains your phone number, service details and contacts and must be inserted into your

handset. If your SIM card is removed then your handset becomes unusable (except for emergency calls

depending on which Country you are in at the time) until a valid one is inserted. Always disconnect the

charger and other accessories from your handset before inserting and removing your SIM card. Slide the

SIM card into the SIM card holder. Make sure that the SIM card is properly inserted and the gold contact

area on the card is facing downwards. To remove the SIM card, press down lightly and pull it in the

reverse direction.

Note

v The metal contact of the SIM card can easily be damaged by scratches. Pay special attention to the SIM

card while handling. Follow the instructions supplied with the SIM card.

Installing the battery.

Insert the Battery into the battery compartment as the metal contacts meet in the middle of the phone.

Push down the top of the battery until it snaps into place. Place the battery cover to the phone as shown.

Charging the Battery

Before connecting the charger to the phone you must first check the battery is installed.

Getting Started

When you recharge your phone after device switch off, the phone displays a charging animation.

When the phone is fully charged, the animation displays “Battery Charging Complete”.

When the battery is fully discharged, animation is not displayed.

During the animation displays “ Battery is too low”, you cannot power on the phone to get sufficient

power for booting.

As soon as charged power reach 1% (need 1 or 2 minutes), charging animation is displayed. And you

can power on the phone.

If you press and hold the power button for approx. 2 seconds in charging mode, the phone is turned on.

CAUTION!

• When you charge a fully discharged battery, it may take over a minute for the display to respond.

This is not a malfunction but completely normal.

(If using a USB cable, it may take over 10 minutes.)

• Do not force the connector as this may damage the phone and/or the charger.

• If you use the charger out of your own country, use an attachment plug adaptor for the proper

configuration.

• Do not remove your battery or the SIM card while charging.

• There is risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries

according to the maker's instructions.

WARNNING

• Unplug the charger from the mains and phone during lightning storms to avoid electric shock or fire.

• Make sure that no sharp-edged items such as animal teeth or nails come into contact with the

battery. There is a risk of this causing a fire.

Getting Started

Disconnecting the Charger

Disconnect the travel adapter from the phone as shown in the diagram. Make sure you pull by the plug,

not the cord.

How to Use a MicroSD Memory Card (Optional)

Lift the plastic cover which protects the microSD slot.

Insert the memory card into the slot with the metal contacts facing down. Do not force the memory

card into the slot, if the card does not slide in easily, please check that the card is being inserted the

correct way or if there is a foreign object in the slot.

Once inserted, push the memory card until you hear a

Click

, meaning that the microSD has been

correctly engaged.

Close the plastic slot protection.

Do not remove the memory card when reading/writing the memory card.

Attention:

v Avoid using the microSD memory card when the battery is low.

v When writing to the card, wait for the operation to complete before

removing the card.

v The card is designed to fit easily into the system one way only.

v Do not bend the card or force it into the slot.

v Do not insert any memory cards other than microSD.

Supports up to 32GB microSD. For more information on the microSD, please

refer to the memory card instruction manual.

Memory Card Formatting

Before you start to use the memory card you have to format it. A message will pop up after you insert the

memory card notifying you to format the memory card.

Note

v Usually the microSD has already been formatted.

Turn the Device On and Off

To turn on the device, press the button. When you turn on the device for the first time, you are

asked to complete a calibration process. For more information, see “Calibrate the device” on next page.

To turn off the device, press again.

Getting Started

Reset the Device

Occasionally you may need to reset your device. A normal (or soft) reset of your device clears all active

program memory and shuts down all active programs. This can be useful when the device is running

slower than normal, or a program is not performing properly. A soft reset is also necessary after the

installation of some programs. If a soft reset is performed when programs are running, unsaved work will

be lost.

You can also perform a hard reset (also known as a full reset). A hard reset should be performed only if

a normal reset does not solve a system problem. After a hard reset, the device is restored to its default

settings—the way it was when you first purchased it and turned it on. Any programs you installed, data

you entered, and settings you customized on the device will be lost.

To perform a soft reset

• Find out Soft reset key which is small hole at the left side of your device shown enclosed by circles in

the picture below.

Use the stylus to press the reset key and hold it for a while. Your device may shut down. Press the

POWER button, the device restarts and displays the Today screen.

A soft reset of your device clears all active program memory and shuts down all active programs. This

can be useful when your device is running slower than normal, or a program is not performing properly.

A soft reset is also necessary after the installation of some programs. If a soft reset is performed when

programs are running, unsaved work will be lost.

To perform a hard reset

• A Hard Reset should only be performed after all other trouble shooting options have been exhausted.

After a hard reset, the device is restored to its default settings - the way it was when you first

purchased it and turned it on. Any programs you installed, data you entered, and settings you

customized on your device will be lost.

Power the device ON

Tap

Start

Settings

System

tab >

Clear Storage

Enter 1234 for the password twice.

Press Enter.

Select what to reset.

You have to enter your password and confirm again for hard reset. However when you forget your

password, the only way to hard reset the device is via the hard key sequence.

Power the device OFF.

Press and hold the following hard keys in sequence.

+ +

Keep pressing keys until your LCD screen turns on.

Align screen will appear if you success hard key reset.

Calibrate the Device

Calibrating the device screen involves tapping with the stylus the center of a cross as it moves around the

screen. This process ensures that when you tap the screen with your stylus, the tapped item is activated.

If your device does not accurately respond to screen taps, follow these steps to re-calibrate it:

Tap

Start

Settings

System

tab >

Screen

On the

Genera

l tab, tap

Align Screen

, and follow the instructions on the screen. After calibration is

completed, Align screen reappears. Click OK on upper right corner to return to setting mode.

Getting Started

Manage Screen Settings

The device touch screen has three orientation modes: Portrait, Landscape (right-handed), and Landscape

(left-handed). Portrait mode allows you to get a better view or a better operation of certain programs on

your device, while Landscape mode may be optimal for viewing longer text files.

v To change the orientation, tap

Start

Settings

System

tab >

Screen

General

tab, and select the

orientation you want.

If Accelerometer Sensor is turned on (check (

LG Menu

) >

Settings

Sensor

Accelerometer

Sensor

), rotation sensor automatically perceive the orientation of your device and decide to direction

of screen display when the orientation for device is changed.

v To smooth the edges of screen fonts for many programs, on the

ClearType

tab(tap

Start

Settings

System

tab >

Screen

), select the

Enable ClearType

check box.

v To increase the readability or to see more content on the screen, on the

Text Size

tab

(tap

Start

Settings

System

tab >

Screen

), adjust the text size by moving the slider.

Screen information

The Today Screen

Customising the Today screen

The Today screen displays important information, such as upcoming appointments and status indicators.

You can tap a section on the screen to open the associated program.

v To access the Today screen, tap (

LG Menu

)

Settings

Today

Items

tab.

You can select the item you want to appear on the Today screen. To change its position, tap

Move up

Move Down

. If you want to customise the further task and appointment information by tapping

Options

Check the

Today timeout

select the number of hours from the drop down list. If you don't use your phone

after the specified length of time has elapsed, the screen switches to the Today screen.

v To synchronise the Today screen display, including the background image, tap (

LG Menu

)

Settings

Today

Appearance

tab.

You can select the desired theme for the background. If you use your own background image, tap the

Use

this picture as the background

and tap

Browse

to locate the file you want.

Screen information

Default MS Today Screen

On the Today screen, you can see important and recent information for the day.

Start button:

Shows the Start menu that you can use directly.

LGdatetime:

Shows today's date and current time. Tap to select the clock type.

Phone information:

Wireless Manager / Bluetooth phone on or off.

Service provider name:

Shows your service provider name.

Unread message:

You can see the unread message from Inbox account.

6. Get Xpress Mail:

You can install Xpress Mail application.

Upcoming Appointments:

You can see the upcoming schedule.

No new missed calls:

You can see the missed call history.

9. IM:

Go to Instant Message program menu.

10.

Indicators:

Connectivity, SIM card, Volume and Battery indicator.

11. Weather:

You can check today's weather. Tap to see more detail weather forecast.

12. Calendar:

Link to Calendar

13. Contacts:

Link for Contacts list

Indicators

Following are some of the status icons that you may see on your device.

Icon Description

Bluetooth Hands-Free connection established

Bluetooth Hands-Free channel opened

Bluetooth High Quality Audio channel opened

Indicates the remained battery power .

Indicates the battery is very low.

Battery charging.

Sound on.

Sound off.

Ringer in vibration mode.

Connection is active.

Connection is not active.

Synchronization in progress.

Synchronization error.

Indicates maximum signal strength.

No signal.

Indecates Bluetooth service.

No phone service.

Searching for phone service.

Voice call in progress.

Screen information

Icon Description

Calls are forwarded.

Call on hold.

Missed call or rejected call.

GPRS (General Packet Radio Services) available

EDGE (Enhanced Data Rates For Global Evolution) available

WCDMA or HSDPA available

New e-mail or text messages.

New voice mail

There are more notifications. Tap the icon to view all.

SIM is not inserted. You can not use Network service without SIM.

Shows the list of running Applications by tapping this indicator.

Using the Start Menu

The Start menu, located at the top left corner of the Today screen, displays a list of programs. It lets you

open a screen and switch from one program to another. You can start a program by scrolling through the

programs list and tap a program.

Editing the Today Screen

Tap to open the Today screen.

Tap to start a program. The items displayed in Start menu can be synchronised by tapping

Start

Settings

Personal

tab >

Menus

Tap to start a recently-used program.

Tap to view and select more programs that are installed in your device.

Tap to change device settings.

Tap to see a Help topic for the current screen.

Program Indicators

Following are some of the icons for the programs that are already

installed on your device.

Icon Name (Path) Description

Apps

(Tap

LG Menu

Multimedia

Apps

) Use pre-installed applications.

AT&T GPS

(Tap

LG Menu

Applications

AT&T GPS

)

Helps you get around town by providing

voice guided turn-by-turn GPS driving directions with real time traffic based navigation.

AT&T Music

(Tap

LG Menu

Multimedia

AT&T Music

) Shop for music, songs, music videos,

streaming media, and access AT&T's 1 music player.

Games (Tap LG Menu > Multimedia > Games)

Play pre-installed games: Block Breaker Deluxe,

Bubble Breaker, MsPac-Man, Solitaire and Sudoku.

MEdia Mall

(Tap

LG Menu

Multimedia

MEdia Mall

)

Shop for games, musics, graphics,

multimedia, tones, videos and other applications.

Messaging

(Tap

LG Menu

Communication

Messaging

)

Sends and receives e-mail and text

messages.

Tools

(Tap

LG Menu

Applications

Tools

) Access some array of tools and utilities on your

mobile device.

File Explorer, GPS Utility, Java, etc..

Active Sync

(Tap

LG Menu

Communication

ActiveSync

)

Synchronizes information

between your device and a PC.

Browser

(Tap

LG Menu

Applications

Browser

)

Browses Web and WAP sites, and

downloads new programs and files from the Internet.

Cellular Video

(Tap

LG Menu

Multimedia

Cellular Video

)

Watch news, sports, weather,

and entertainment clips via AT&T’s high-speed data network while on the go.

Internet Sharing

(Tap

LG Menu

Applications

Internet Sharing

)

Use your device as a

internet sharing device.

MEdia Net

(Tap

LG Menu

Multimedia

MEdia Net

)

Browses to access your favorite content

(weather, news, etc.) and download ringtones or other personalization items.

Modem Link (Tab Start > Programs)

Use your mobile device as a modem.

Notes

(Tap

LG Menu

Applications

Notes

)

Creates handwritten or typed notes, drawings,

and recordings

Pictures & Videos

(Tap

LG Menu

Multimedia

Pictures & Videos

)

Collects, organizes, and

sorts picture and video files in the My Pictures folder of your device or on a storage card.

Screen information

Icon Name (Path) Description

Stopwatch

(Tap

LG Menu

Applications

Stopwatch

)

Allows you to record the elapsed

time of an event. The duration of an individual lap time (up to 99 times) and the total time can be

displayed.

Task Manager

(Tap

LG Menu

Settings

Task Manager

)

Check activating task information.

Tasks

(Tap

LG Menu

Communication

Tasks

)

Keeps track of your tasks.

Windows Media

(Tap

LG Menu

Multimedia

Windows Media

)

Enables the multimedia function

on your device.

Settings

You can adjust the device settings to suit the way you work. To see all available settings, tap

Start

Settings

, then tap the

Personal

System

, and

Connections

tabs located at the bottom of the screen.

Personal tab

Icon Description

Buttons

Assign a program or function to a hardware button.

Clock Style & Weather

Select clock style. Weather also be set specified information.

Gesture

Enable to recognize your flicking gesture. Adjusting click sensitivity and select

exclusive programs.

Input

Set options for each of the input methods.

Lock

Set a password for your device.

Lock Key

Enables or disables the handset's Keypad Lock key.

Menus

Set what programs will appear in the Start menu.

Owner Information

Enter your personal information on your device.

Phone

Customize phone settings such as ring tone, set a PIN number for your SIM card, and more.

Sounds & Notifications

Enable sounds for events, notifications, and more, and set the type of

notification for different events.

Today

Customize the appearance and the information to be displayed on the Today screen.

TTY

Enable TTY (Teletypewriter) support for your device.

Screen information

Icon Description

Voice Command

Enable to use Voice Command function. Select the items where are voice

command is enabled.

System tab

Icon Description

About

This is where you can see basic information such as the Windows Mobile® version and

type of processor used on your device. You can also specify a name for your device.

Backlight

Set the backlight timeout and adjust brightness.

Certificates

See information about certificates that are installed on your device.

Clear Storage

Tap this icon only when you need to remove all your data and files from the

memory and reset your device to factory default settings.

Clock & Alarms

Set the device clock to the date and time of your locale or to a visiting time

zone when you’re traveling. Alarms can also be set at specified days and times of a week.

Customer Feedback

You can participate the Customer Experience Improvement Program by

sending your feedback to Microsoft.

Encryption

Allow files on your storage card to be encrypted. Encrypted files will be readable

only on your device.

Error Reporting

Enable or disable error reporting when errors are occured on your device.

External GPS

Set the appropriate GPS communication ports, if required. You may need to do this

when there are programs on your device that access GPS data or you have connected a GPS receiver to

your device. See Help for details.

LG X Button

Stop running programs and set the "X" button to end programs immediately when you tap

the button.

Managed Programs

This is where you can see installation history of your device.

Memory

Check the device memory allocation status and memory card information. You can also

stop currently running programs.

Power

Check the remaining battery power. You can also set the timeout for turning off the

display (switching device to Sleep mode) to conserve battery power.

Regional Settings

Set the regional configuration to use, including the format for displaying

numbers, currency, date, and time on your device.

Remove Programs

Remove programs that you installed on your device.

Screen information

Icon Description

Screen

Change the screen orientation, re-calibrate the screen, and change the screen text size.

Sensor

Set your Auto Luminous Control and Proximity sensor to use or not.

System information

Check your system information and storage information.

Task Manager

Shows the executing application list.

Time Auto update

If Auto update sets On, current city time will follow the network time.

Video Share

You can change the Video share default settings.

Windows Update

Link to Microsoft's Web site and update Windows Mobile® on your device

with the latest security patches or fixes.

Connections tab

Icon Description

Bluetooth

This is where you can see basic information such as the Windows Mobile® version

and type of processor used on your device. You can also specify a name for your device.

Connections

Set up one or more types of modem connections for your device, such as phone

dial-up, GPRS, and more, so that your device can connect to the Internet or a private local network.

Domain

Enroll Connect your device with company resources.

GPRS Setting

Set the GPRS authentication method.

USB to PC

Enhances the connection between the device and the computer, in situations when

ActiveSync on the computer is unable to detect the device.

Wi-Fi

Allows you to customize Wi-Fi settings.

Wireless LAN

Shows information about the active wireless network.

Wireless Manager

Allows you to manage all of wireless settings such as Wi-Fi, Bluetooth and

Phone.

Screen information

Entering and Searching Information

You are available to the various input methods on the screen, including

Keyboard

LGJavaKey

Trnscriber

, and

XT9 Keypad

. The Input Panel icon appears on the menu bar to indicate which input

method is currently selected. The Input Selector arrow (shown at the right side of the Input Panel icon)

opens a list of available input methods.

Overview of Input Panel

To change the input method, tap the Input Selector arrow.

Icon Indicates the selected input method is

The on-screen keyboard.

Transcriber.

LGJavaKey

XT9 Keypad

Using the Keyboard

To enter text, symbols, and numbers, you can either type using the QWERTY Keyboard to type ABC

charanters or the standard on-screen

Keyboard

Using the standard on-screen Keyboard

The on-screen Keyboard is available when text entry is possible. You can enter text by tapping keys on

the keyboard that are displayed on the screen.

Enter text using the on-screen keyboard

v The on-screen keyboard is available when text entry is possible.

v To make the keys larger, tap the Input Selector arrow, and then

Options

. In the

Input method

list,

select

Keyboard

, and then tap

Large Keys

v General rule for entering text is same as MS based PC.

Entering and Searching Information

Using the LGJavaKey

v You can use as navigation keys (left/right/up/down/center) when your Java applications are

launched.

v You can move the cursor and select menu on out of Java application.

XT9 Keypad

With XT9 keypad, you can enter text by tapping keys displayed on the screen. This is the most common

way to enter text with word prediction function in 20 Qwerty of portrait screen.

v XT9 Keypad is available when text entry is possible.

v Enter letters by tapping the keys labelled with the required letters.

v There are four input modes and you can change by tapping Fn, T9/123 and abc/123. You can turn

on and off XT9 prediction function by tapping Fn and T9/123 or abc/123 successively. If you tap just

T9/123 or abc/123, you can enter 123 mode. If you tap just Fn, you can enter symbol mode.

XT9 mode

If you turn on XT9 mode by tapping Fn and T9/123 successively, you can enter words with only one

keystroke per letter. The XT9 mode automatically compares your keystrokes with an internal dictionary to

determine the correct word, thus requiring far fewer keystrokes than the traditional multitap mode.

This is sometimes known as predictive text. This feature is supported only in portrait screen.

ABC mode

If you turn off XT9 mode by tapping Fn and abc/123 successively, you can enter letters by tapping the key

labeled with the required letter once or twice until the correct letter is displayed. Tap once for the first

letters and twice for the second letters. This mode is known as multitap mode.

Entering and Searching Information

123 mode

If you tap T9/123(abc/123), you can enter 123 mode. Type numbers using one keystroke per number.

You can also enter additional symbols in 123 mode.

Symbol mode

Short press of FN key gives symbol for one key press, and long press of FN locks symbol mode.

The symbol mode enables you to enter various symbols or special characters.

You can enter extra symbols by tapping Sym key in full qwerty.

CAPS

Short press switches to uppercase for one keypress, long press switches to caps lock mode.

Portrait mode:

Tap this key for entering Symbols or turning XT9 on and off.

Landscape mode:

Tap this key for entering Symbols and numbers.

Touch for switching to symbol keypad. Switch to letter keypad again after one key input. If you want to

lock symbol keypad, press and hold the icon.

Arrow key in full qwerty

Pressing the arrow key will hide the menu bar and show the bigger text area.

Using Transcriber

Transcriber

is a handwriting recognition program that allows you to write in cursive, print, or a

combination of both. Transcriber works transparently in the background of programs, recognizing words

with its integrated dictionary. When Transcriber is turned on, it interprets stylus movement anywhere on

the screen as handwriting input. For more information about using Transcriber, see Help on your device.

To start Transcriber

Start a program that accepts user input, such as Word Mobile.

Tap the Input Selector arrow, and tap Transcriber. The Transcriber introductory screen appears.

To write using Transcriber

In a program, position the cursor where you want text to appear.

Use the stylus to write anywhere on the screen. The handwriting will be converted to text shortly after

you lift the stylus from the screen.

To enter punctuation and symbols

Transcriber comes with an on-screen keyboard that provides an easy way to add punctuation or a special

symbol to existing text.

v From a program, tap on the Transcriber toolbar. The keyboard remains visible until you tap the

button again.

Note

v To reposition the keyboard, tap and hold the title bar, then drag to the desired location.

When no text is selected, you can also open the keyboard by doing the gesture.

To edit text

In a program, draw a line across the text you want to edit.

After you lift the stylus from the screen, the line will disappear and the selected text will be

highlighted.

Do either of the following:

v Rewrite the text.

v Use gestures to capitalize letters, insert a space, and so on.

Entering and Searching Information

Transcriber Gestures

Use quick strokes of the stylus to edit your text or to insert returns, spaces, or tabs.

Do To

Insert a paragraph return at the cursor.

The horizontal portion of the gesture must be at least two times longer than the vertical

portion.

Insert a space at the cursor.

The horizontal portion of the gesture must be at least two times longer than the vertical

portion.

Move the cursor one space back and erase any text.

Do the gesture by drawing a line from right to left.

Open the menu of alternate words if a word is selected or the onscreen Transcriber keyboard

if no text is selected.

Do the gesture by drawing a line straight down and back up.

Change the capitalization of a selected letter, word, or block of text.

Do the gesture by drawing a line straight up.

Undo the last action.

Do the gesture by drawing a line straight up and back down.

Copy the selected text.

Do the gesture by drawing a line from left to right and back.

Cut the selected text.

Do the gesture by drawing a line from right to left and back.

Paste copied or cut text.

Do the gesture by drawing a line from the lower left of the screen diagonally up toward the right

and back down to the right.

Insert a tab.

The horizontal portion of the gesture must be at least two times longer than the vertical portion.

Entering and Searching Information

Note

v You can also use the Enter, Space, and Backspace buttons on the Transcriber toolbar.

The Transcriber toolbar

Tap To

You can set the transcriber options such as writing direction, text and shorthand.

You can set the shape of letters as your handwriting.

You can enter numbers, punctuation and symbols.

You can change text input methods.

• a mode. This is the default for optimum handwriting recognition.

• 123 mode. Numbers and some letters are allowed and the calculator is activated.

• A mode. All letters are automatically capitalized.

If you are in A or 123 mode, recognition returns automatically to the default mode once

you lift the stylus.

You can insert a space at the cursor.

You can insert a paragraph return at the cursor.

You can insert the cursor one space to the left.

You can move the cursor one space to the right.

Back and erase any text.

Help

Entering and Searching Information

Drawing and Writing on the Screen

You can draw directly on the screen, or write on the screen and save notes in your own handwriting. To do

this, you must set the input mode in Notes to

Writing

If you prefer to use handwriting or frequently add drawings to your notes, you may find it helpful to set

Writing as the default input mode. If you prefer typed text, set

Typing

as the default input mode.

To set the input mode for Notes

Tap (

LG Menu

)

Applications

Notes

In the note list, tap

Options

In the

Default mode

box, tap one of the following:

Writing

if you want to draw or enter handwritten text in a note.

Typing

if you want to create a typed note.

Tap

To write a note

Tap (

LG Menu

)

Applications

Notes

In the note list, tap

New

Write your text on the screen.

When finished, tap

to return to the note list.

Note

v To select handwritten text, tap and hold next to the writing. As soon as dots appear, and before they

form a complete circle, quickly drag across the writing.

If a letter crosses three ruled lines, it is treated as a drawing rather than text.

Entering and Searching Information

To draw in a note

Tap (

LG Menu

)

Applications

Notes

In the note list, tap

New

To draw on the screen, use the stylus like a pen.

A selection box appears around your drawing.

When finished, tap

to return to the note list.

Note

v To select a drawing (for example, to copy or delete it), tap and hold the drawing briefly. When you lift the

stylus, the drawing is selected.

Picsel Viewer Pan and Zoom Mode

The document you wish to see is often larger than the space available on the screen. There are two ways

to see more of it. To pan (or ‘scroll’) to a different part of the document, simply stroke your pen across the

screen in the direction you would like the page to move.

To pan the page up, touch and hold your pen somewhere near the middle of the screen and draw a line

towards the top, then take your pen off the screen. You can do this repeatedly so that you can view any

size of document. Further, you can ‘throw’ the document across the screen, and it will continue moving

after you have released the pen. This gives you time to start another stroke. This inertia can be used to

save time while you pan around the document.

You can also zoom the size of the document, so that more or less of it is visible at a different size. The

tap-and-stroke gesture for this is to tap your pen briefly near the middle of the screen then touch and

hold it again in the same place (a “double-tap”). Now, stroke your pen up to zoom in, or down to zoom

out. Release your pen when you reach the scale you like. Using this, you can view small print details on

diagrams, or can get an overview of a whole page.

Entering and Searching Information

Thumbnail

While viewing a page, a thumbnail can be displayed to:

- Give an overview of the current page

- Show the position of the current visible screen on the page

Currently, there are two modes that can be used. For document map mode, the visible area of the

document is the same, and the thumbnail is superimposed at the bottom of the screen, on a transparent

panel. A red transparent box on top of this thumbnail shows the current screen position and size.

For magnify mode, the screen is split in two. A magnifying glass icon can be used to navigate the

thumbnail at the top, and the bottom portion shows the zoomed document.

Find text in a PDF

You can search a word or words in a PDF file. The Find menu searches the currently open PDF

1. Select Search > Find menu. Then search dialog is shown.

2. Type the text you want to search.

3. Press OK.

* This viewer doesn’t use exact case match.

Quick reference

Search > Find Find the word in this document

Search > Find prev Find the word before current focused word

Search > Find next Find the word after current focused word

Search > Snap to result Move to current focused word

Search > Cancel Cancel finding the word

Thumbnail > Off Off the thumbnail

Thumbnail > Document map View the document map

Thumbnail > Magnify View the document through magnifying glass

Goto > Page Go to page where you want

Goto > First Jump to the first page

Goto > Prev Go to the previous page

Goto > Next Go to the next page

Goto > Last Jump to the last page

Entering and Searching Information

Recording a Note

You can create a stand-alone recording (voice note) or you can add a recording to a note.

To create a voice note

Tap (

LG Menu

)

Applications

Notes

Do one of the following:

v To create a stand-alone recording, record from the note list.

v To add a recording to a note, create or open a note.

If you do not see the Recording toolbar, tap

View Recording Toolbar

Hold your device’s microphone near your mouth or other source of sound. Press the recording button

from the Recording Toolbar.

If you adding a recording to a note, tap OK to return to the note list when finished.

If you are recording in an open note, an icon will appear in the note.

If you are creating a stand-alone recording, the recording will appear in the note list.

To change recording formats

Tap

Start

Settings

Personal

tab >

Input

Tap the

Options

tab, and in the

Voice recording format

list, tap the format you want.

Tap

Note

v You can also change recording formats from within Notes. In the note list, tap Menu > Options > Global

Input Options link (at the bottom of the page).

Entering and Searching Information

Searching Information

You can search for files and other items stored on your device in the My Documents folder or on a storage

card. You can search by file name or by words located in the item. For example, you can search in e-mail

messages, notes, appointments, contacts, and tasks, as well as in online Help.

To search for a file or an item

Tap (

LG Menu

)

Applications

Search.

Search for

, enter the file name, word, or other information you want to search for.

If you have looked for this item before, tap the

Search for

arrow and select the item from the list.

Type

, select a data type to help narrow your search.

Tap

The

My Documents

folder and subfolders are searched.

In the

Results

list, tap the item you want to open.

Entering and Searching Information

Adjust the Device Volume

You can set the volume of System and Ringtone, which can be set the volume On or Vibrate state or Off.

System volume :

You can change the volume for sounds, such as the sound you hear when you tap

program names and menu options.

Ringer volume :

You can set the volume of Ringtone.

Note

To adjust the conversation phone volume, you must do it during a call. Adjusting the volume at another

time will affect the ring, notification, and MP3 sound levels.

When you activate Vibrate mode, sound will automatically be muted and the device will vibrate when

an incoming call is received. The Vibrate icon (

) will appear in the title bar to indicate that Vibrate

mode is activated.

Making a Call

You can make a call from

Phone

Contacts

, and

Speed Dial

Make a call from Phone

v On the Phone screen, tap the desired phone number, and tap the button.

Note

If you tap a wrong number, tap the Back arrow ( ) to erase individual numbers one at a time. To

delete all the numbers, tap and hold the Back arrow.

General functions

Make a call from Contacts

v Tap (

LG Menu

) >

Communication

Contacts

v Tap the desired contact, and tap

Call

v You can also tap the desired contact in the contacts list, and tap the phone number that you want to

call. Or, tap and hold the desired contact, and on the shortcut menu, tap

Call Work

Call Home

, or

Call Mobile

Make a call from Speed Dial

Use Speed Dial to call frequently-used numbers with a single tap. For example, if you assign a contact to

the location 2 in Speed Dial, you can simply tap and hold on the Phone screen to dial the contact’s

number. Before you can create a Speed Dial entry, the number must already exist in Contacts.

To create speed dial entry

On the Phone screen, tap

Speed Dial

Tap

New

Tap a contact. Tap the phone number for which you want to create a Speed Dial.

In the

Location

box, select an available location for the new Speed Dial.

Note

Location 1 is generally reserved for your voice mail, and Speed Dial will designate the next available

location by default. If you want to place a number in a position that is already occupied, the new

number will replace the number that is already there.

To create a Speed Dial entry from Contacts, tap and hold the contact name, tap Add to Speed Dial

through the menu, and select an available location for the new Speed Dial.

To delete a Speed Dial entry, in the Speed Dial list, tap and hold the desired entry, and tap Delete.

General functions

Receiving a Call

When you receive a phone call, a message will appear, giving you the option to either answer or ignore

the incoming call.

To answer or reject an incoming call

v To answer the call, tap

Answer

, or press on the device.

v To reject the call, tap

Ignore

, or press on the device.

To end a call

Once an incoming or outgoing call is in progress, you can tap

End

or press on the device to hang

up.

In-call Options

To put a call on hold

v Tap

Hold

To switch between two calls

v Tap

Swap

General functions

To set up a conference call

Either put a call on hold, and dial a second number; or, accept a second incoming call when you already

have one in progress.

Tap

Conference

Note

Not all service providers support conference calling. Contact your service provider for details.

To Turn the Speakerphone On and Off

The built-in Speakerphone on your device allows you to talk hands-free or lets other people listen to the

conversation.

v During a call, tap

Speaker On

. The General functions speakerphone icon (

) appears in the title bar.

v To turn off the speakerphone, tap

Speaker Off

WARNING

To avoid damage to your hearing, do not hold your device against your ear when the Speakerphone is

turned on.

To mute a call

You can turn off the microphone during a call, so that you can hear the caller but the caller cannot hear

you.

v During a call, tap

Mute

v When the microphone is turned off, the mute icon ( ) appears on the screen. Tap

Unmute

to turn on

the microphone again.

General functions

Additional Dialing Information

Make an emergency call

v Enter the international emergency number for your locale, and tap Talk.

Note

Additional emergency numbers may be included in your SIM card. Contact your service provider for

details.

Communication

Call

You can use easily with smart dial feature. If you press a number on the keypad, the screen displays the

phone number in Call History, Starting with the number you enter, and the names in Contacts or Call

History, starting with the characters you enter.

You can select you want to call number.

You can also make an international call or emergency call.

Note

You can find your phone number by tapping (

LG Menu

) >

Settings

Phone.

Making a Voice Call

1. On the Home screen tap .

2. Type the desired phone number using the Phone keypad.

3. Press the Send button or tap .

4. To end the call, press End button or tap End button call on the screen.

Making a Call from History

On the Home screen, tap . Then tap , you can choose and call.

When you tap the call you want to view, the screen shows the time and date you received or made a call

and the duration of a call.

You can personalize the settings of your phone, the services you have, and the network to which you are

connected.

Communication

Sharing a Video during your Phone Call

You can initiate to send or start to receive video with those who has a Video Share capable phone. During

a voice call, the phone will let you know whenever you can share video by showing the “Video Share

Ready” button.

Note

This service is only available in AT&T 3G coverage with below conditions.

Subscribed on the Video Share service.

The service option in the Video Share settings should be ON as default.

Presence of square-shaped indication such as ‘3G’ at the top of your signal strength icon.

“Media Net” should be selected for internet usage (Media Net is set as default)

Initiating a Video Share Session

Once the voice call has been established, after a few seconds you can see the

Video Share Ready

the screen, provided that the other party’s phone is also Video Share capable. Then, you are ready to

start sharing your video with the other party.

To suggest Live Video Share session to the other party, simply tap

Video Share Ready

on the screen

or the camera key on the right side.

Note

If you set

Initial Notification

(Tap

Start

Settings

System

tab >

Video Share

) as

(default set is OFF),

a notification message window will be popped-up automatically.

As soon as you tap the

, the phone will start establishing Live Video Share.

There are options to select the type of Video Share between Live and Recorded. You can choose one of

the sharing types after selecting

Video Share

on the

Live:

You can share a real-time video stream with the other party while having a conversation.

Recorded:

You can share a pre-recorded video clip with the other party while having a conversation.

Communication

Note

Only video files that recorded on resolution 176 * 144 are enable to be shared.

If the other party accepts your request, a video share session begins.

(It can take a few seconds for the other party to accept your invitation and start the Video Share Call.)

Note

The Speakerphone will be automatically activated when a Video Share session begins, unless a hands-free

device (Bluetooth or stereo headset) is connected.

Select the

STOP

menu item at any time when you want to quit sending video, or press the to

finish both the voice call and the video share session.

Note

1. The Video Share Call will be terminated in the following cases:

When you accept a 3rd party, Conference Call, or a 2nd incoming call during a Video Sharing.

When the voice call is placed on hold.

When the voice call is disconnected.

When moving out of a AT&T 3G service area.

When the network connection is in poor status.

2. The Video Sharing will not be available in the following cases (“Video Share Ready” button will be

grayed out).

When trying to make a conference call/second call during a call.

When the voice call is placed on hold.

When moving out of a AT&T 3G service area.

Receiving a Video Share Session

1. If you get the Video Share invitation pop-up, tap

to allow the other party to send video stream.

If you don’t want to accept the request, tap Decline.

Communication

Note

The speakerphone will be automatically turned on when a Video Share session gets started, and

automatically back to the previous mode when a Video Share session ends.

When a Hands-free device (Bluetooth or stereo headset) is connected, Speakerphone will not be turned

on automatically.

Additional Ways to Initiate a Video Share Call

From

Contacts

Recent Calls

and

Camera

preview, you can make a Video Share session followed by a

successful voice call setup.

Note

If the other party is not available for a Video Share Call, then the call will remain as a normal voice call.

From Camera preview, initiating a Video Share Call

When you see scenery through the camera preview screen, you may want to share. Then you can initiate

the video share call with who has a video share capable phone.

Tap icon on the right top of the camera preview screen, and then select the

Video Share Call

This Dialer screen provides you with two options to make a Video Share Call:

a. Enter a number directly. Or

b. Select a number from Contact.

After a successful call setup and check the other party’s capability of Video Share, Video share

invitation will be automatically requested

Communication

From Contacts, initiating a Video Share Call

You can also initiate Video Share Call from Contact.

After selecting a number on the Contact screen

Tap the

Video Share

and you can choose the sharing type between

Live

and

Recorded

After a successful call setup and checking the other party’s capability of Video Share, Video share

invitation will be automatically requested

From Recent Calls, initiating a Video Share Call

You can also initiate Video Share Call from Recent Calls.

After selecting a number on the Recent Call list

Tap the

Video Share

and you can choose the sharing type between

Live

and

Recorded

After a successful call setup and checking the other party’s capability of Video Share, Video share

invitation will be automatically requested

Saving your Video Share

Video Sender can record video stream as a clip during a Live Video Share session. There will be a prompt

asking if you would like to save or discard the video at the end of a recording. If you choose to save the

video, it will be saved in the

My Pictures

under

My Documents

folder in your phone.

Contacts

Contacts is your address book and information storage for the people and business you communicate

with. Store phone numbers, e-mail addresses, home addresses, and any other information that relates to

a contact, such as a birthday or an anniversary date. You can also add a picture or assign a ring tone to a

contact.

From the contact list, you can quickly communicate with people. Tap a contact in the list for a summary of

contact information. From there, you can call or send a message.

If you use Outlook on your PC, you can synchronise contacts between your device and PC.

Communication

Overview of Contacts

Contacts is your address book and information storage for the people and business you communicate

with. Store phone numbers, e-mail addresses, home addresses, and any other information that relates to

a contact, such as a birthday or an anniversary date. You can also add a picture or assign a ring tone to a

contact.

To Create a Contact

Tap (

LG Menu

) >

Communication

Contacts

Tap

New

and enter the contact information.

Select

Outlook Contact

SIM Contact

, and enter contact detail.

When finished, tap

Tip

If someone who is not in your list of contacts calls you or sends you a message, you can create a

contact from Call History by tapping

Save to Contacts

or from the message by tapping

received phone number.

You can add a picture or assign a ring tone to a contact in details tab of the contact.

To Change Contact Information

Tap (

LG Menu

) >

Communication

Contacts

Tap the contact.

Tap

Edit

and enter the changes.

When finished, tap

To Work with the Contact List

There are several ways to use and synchronise the contact list. Here are a few tips:

Tap (

LG Menu

) >

Communication

Contacts

In the contact list, do any of the following:

Communication

v In Name view, you can search for a contact by entering a name or by using the alphabetical index. To

switch to Name view, tap

View By

Name

v To see a summary of information about a contact, tap the contact. From there you can also make a call

or send a message.

v To see a list of available actions for a contact, tap and hold the contact.

v To see a list of contacts employed by a specific company, tap

View By

Company

. Then, tap

the company name.

To Copy SIM Contact to Contacts

If you have saved contacts on your SIM card, you can copy them into Contacts on your device several or

all.

Tap (

LG Menu

) >

Communication

Contacts

Tap

Select Contacts

Several or All

Tap

Copy Contacts

To Contacts

Or similarly you can copy Contacts on your device to your SIM card several or All, by selecting Copy

Contact

To SIM

To Find a Contact

There are several ways to find a contact when your contact list is long.

Tap (

LG Menu

) >

Communication

Contacts

If you are not in Name view, tap

View By

Name

Do one of the following:

v Begin entering a name in the provided text box until the contact you want is displayed. To show all

contacts again, tap the text box and clear the text.

v Use the alphabetical index displayed at the top of the contact list. When you tap the alphabetical

index, the selection highlight moves to the first item beginning with that alphabet.

v Filter the list by categories. In the contact list, tap

Filter

. Then, tap a category you’ve assigned

to a contact. To show all contacts again, select

All Contacts

Communication

v You can also find a contact tap (

LG Menu

) >

Applications

Recent Calls

You can view the recently missed, received and dialed calls.

You can make a call, send text message, multimedia message and save to contacts.

You can delete the number selected or all at once.

Save to Contacts

You can add the contact info from a communication event to your Contacts.

View Note

To view detailed information about the communication event.

Delete

You can delete the selected call list.

Send Text Message...

After you have found the number you want, you can send a text message.

Send MMS

After you have found the number you want, you can send multimedia message.

Communication

Filter

All Calls:

Allows you to view the missed, received, and dialled call records. You can make a call, or

send a message to the number you have selected from the records. You can also save the number in

Contacts.

Missed:

Allows you to view the last 20 phone numbers from which someone unsuccessfully tried to

reach you.

Outgoing:

Allows you to view the last 20 phone numbers that you have called or tried to call.

Incoming:

Allows you to view the last 20 phone numbers that you have answered.

Delete All Calls

You can delete all calls.

Call Timers...

You can view the duration of calls to and from your phone.

Video Share

You can initiate a Video Share Call to that number designated here. For more information, please refer to

From Recent Calls

initiating a Video Share Call

" in Page 60.

Communication

Messaging

This menu includes functions related to text messages, MMS, e-mail. You can send and receive text

messages, MMS, Outlook E-mail and Internet E-mail through an Internet service provider(ISP). You can

also access e-mail from work using a VPN connection.

To Set up an E-mail Account

You need to set up an e-mail account that you have with an Internet service provider (ISP) or an account

that you access using a VPN server connection (typically a work account) before you can send and receive

e-mail.

Tap (

LG Menu

)

> Communication > Messaging

Tap

Setup E-mail

Enter your E-mail address,

Password

, and tab

Auto configuration

attempts to download necessary e-mail server settings so that you do not need to

enter them manually.

Note

Select the Save Password check box if you want to save your password so that you do not need to

enter it again.

Once

Auto configuration

has finished, tap Next.

Enter Your name (the name you want displayed when you send e-mail), Account display name; tap

Note

Auto configuration

is successful, the

Account display name

and the addresses of the incoming

and outgoing e-mail servers automatically get populated.

Auto configuration

is unsuccessful or you have an account that you access using a VPN server

connection, contact your ISP or network administrator for the following information and enter it

manually.

Communication

Select Automatic Send/Receive Interval.

Finish to complete setting up your account, or tap Options to access additional settings.

Managing Messages

v On Select an Account screen, you can view Messages, Outlook E-mail folders.

v Tap the folder and you can select message box.

Deleted Items:

You can view the deleted items.

Drafts:

You can view saved messages. Select a message and you can edit the message.

Inbox:

You can view received messaged. Select a message and view.

Tip

Windows Mobile 6.1 manages your inbox messages by address. You

can check the conversation history with the address that you send

the message to or you get the message from by tapping the threaded

message. Create a new message on the text message composer

which is bottom of the conversation history screen. You can send the

new message by tapping Send.

Outbox:

The Outbox is temporary storage place for messages waiting to be sent. Failed messages are

also placed in Outbox.

Sent Items:

Show the messages you sent (Message/e-mail).

Note

You tap the upper right bar and then you can sort messages by Message Type, From, Reveived,

Subject.

Communication

Downloading Messages

The manner in which you download messages depends on the type of account you have:

• To send and receive e-mail for an Outlook E-mail account, begin synchronization with Exchange Server

through ActiveSync.

• To send and receive e-mail messages for an e-mail account that you have with an Internet Service

Provider (ISP) or that you access using a VPN server connection (typically a work account), download

messages through a remote e-mail server.

• Text messages are automatically received when your phone is turned on. When your phone is turned

off, messages are held by your service provider until the next time your phone is turned on.

To Reply to or Forward a Message

Open the message and tap

, or

Reply or Reply All

Forward.

Enter your response. To quickly add common messages, tap

Menu > My Text

and tap a desired

message.

To check the spelling, tap

Menu > Spell Check

Tap

Send

Tip

To see more header information.

Note

v You will be alerted when you have received messages. They will be stored in the Inbox.

v In the Inbox, you can identify each message by icons.

v If the phone shows ‘No space for SIM message’, you have to delete some messages from the

Inbox.

v If the phone displays ‘No space for message’, you can make space of each repository by deleting

messages, media and applications.

Communication

SIM message

SIM message means the message stored in SIM card. You can copy this message to the phone.

Calendar

To Add an Event to your Calendar

Tap (

LG Menu

) >

Communication

Calendar

Select the date you would like to add an event to.

Tap

New Appointment

Type in the subject and location of the event and check the date and enter time you would like your

event to begin.

Check other information below.

If you would like to add some note to your event, tap

Notes

tab and type in.

After you finish writing your note, press

To Change your Default Calendar View.

Tap (

LG Menu

) >

Communication

Calendar

Tap

Day

Week

Month

Year

Agenda

Communication

The Instant Messaging feature can only be used with the support of the network operator or communities

such as AIM, Windows Live and Yahoo! Messenger.

For Instant Messaging users, a valid User ID and Password will be required in order to login and exchange

messages as well as checking the online status.

The menu items below might not appear since not all IM communities support the various options. Also

the menu strings may appear differently based on the selected IM communities. The keywords such as

User ID, Login and Contact will be used as general terms in IM menus according to the currently selected

communities such as AIM, Windows Live and Yahoo! Messenger.

Select the community.

Type your user name and password. For Windows Live messenger, you will also need to enter the

respective domain name. e.g.: xyz@hotmail.com

Note

If you do not have a community user name, you will need to create one on the community website

using your desktop internet browser.

Tap sign in.

Note

To avoid typing your username and password each time you log in, select the Save Password check

box. To set your device to sign in to the community automatically each time you start the device,

select Auto Sign In.

Communication

Switching between Communities

You can Sign-in to all the communities at the same time.

All the enabled communities are displayed on the top as tabs.

Change Status

Tap

on the Contact List screen, choose the option My Status and then select the desired status

Busy/Away/Offline (This can change depending on your IM provider.

Contact List

The Contact list displays your individual contacts/buddies in a tree list view. The online contacts are

displayed under their respective group names and all the offline contacts are displayed under a separate

group called Offline.

To collapse or expand a group, select the group using the navigation keys and press the left softkey

Collapse/Expand

Add a Contact:

On the Contact list screen click the right softkey

and choose

Add Contact

. On

the next screen enter the User ID of the desired contact and click the left softkey

Add

Block:

On the Contact list screen, highlight a contact and click the the right softkey

and choose

Block. A confirmation screen will be displayed, select the Yes softkey to confirm the action. (Block

option is only available for Windows Live and AIM)

Delete:

Select the contact, click the right softkey

and choose the option

Delete

Refresh Contact List:

To get the updated presence information, click on the right softkey

and

choose the

Refresh Contact List

option.

Contact info:

Select the contact using the kdys, click the right softkey

and choose the option

Contact Info

Communication

Conversations

Conversations for each community appear under the conversation group (the first group) on the Contact

list screen.

To start a new conversation, select the desired contact on the Contact list screen and press the right

softkey

Send

. A conversation screen would open, type the message and press Enter or click the left

softkey Send to send the message.

To end a conversation, press the left softkey Menu on the conversation screen and choose

End

Conversation

option. To close a conversation without ending it, choose the

Back

option from the same

menu.

IM Settings

To get to IM Settings, tab IM from home screen.

Community Settings

Auto Save Conversations:

Select this checkbox to save the conversation without asking.

Global Settings

Enable Sound:

Select this checkbox to play the community default sound notification when a new

IM arrives.

Start Automatically on PowerOn:

Select this checkbox if you wish to automatically start the

application when the phone is powered on.

Enable Tips:

Select/Unselect this checkbox to enable/disable help tips that appear on login.

Enable BackGround IM Alerts:

Select/Unselect this checkbox to enable/disable the new IM

notifications when the application is in the background.

Communication

Closing the Application

To sign out; press the right softkey

on the Contact list screen and choose

Sign Out

To Exit the application without signing out; select the left softkey Exit from the Grid screen.

Note

Exiting the application will not sign you out and you will continue to receive messages. You will be

notified of new message through a pop up.

Tasks

Use Tasks to keep track of things you need to do. A task can occur once or repeatedly (recurring). You can

set reminders for your tasks and you can organize them using categories.

Your tasks are displayed in a task list. Overdue tasks are displayed in red.

To Create a Task

Tap (

LG Menu

) >

Communication

Tasks

Tap

New Task

Enter a subject for the task, and fill in information such as start and due dates, priority, and so on.

When finished, tap

Note

You can easily create a short, to-do-type task. Simply tap the

Tap here to add a new task box

enter a subject. If the task entry box is not available, tap

Options

and select the

Show

Tasks entry bar

check box.

Communication

To Change the Priority of a Task

Before you can sort tasks by priority, you need to specify a priority level for each task.

Tap (

LG Menu

) >

Communication

Tasks

Tap the task you want to change the priority for.

Tap

Edit

and in the Priority box, tap a priority level.

Tap

to return to the task list.

Note

All new tasks are assigned a Normal priority by default.

To Set a Default reminder for all New Tasks

You can have a reminder automatically turned on for all new tasks you create.

Tap (

LG Menu

) >

Communication

Tasks

Tap

Options

Select the

Set reminders for new items

check box.

Tap

to return to the task list.

Note

The new tasks must have due dates set in order for the reminder to take effect.

To Show Start and Due Dates in the Task List

Tap (

LG Menu

) >

Communication

Tasks

Tap

Options

Select the

Show start and due dates

check box.

Tap

To Locate a Task

When your list of tasks is long, you can display a subset of the tasks or sort the list to quickly find a

specific task.

Tap

(

LG Menu

) >

Communication

Tasks

In the task list, do one of the following:

v Sort the list. Tap

Sort by

, and tap a sort option.

v Filter the list by category. Tap

Filter

, and tap the category you want displayed.

Note

To filter your tasks further, tap

Filter

Active Tasks

Completed Tasks

PSNotes

PSNote is a multimedia input editor with handwriting recognition for Pocket PC. You can enter

handwritten text (in English, French, German, Italian or Spanish, depending on the installation) in various

styles (that is immediately converted into digital text), drawings, images, video, or sound and send it via

e-mail, SMS or MMS. From home screen mode, go to

Communication

PS Notes

• The contents of the toolbar change depending on whether you are working on:

- a text document: - or a drawing: - or a multimedia item:

New Document

v Tap

File

New

, to create a new document.

v You can write down on the note and tap

File

Save or File

Save as

(You can select the

Microsoft Word or RTF document format.)to save the document.

Communication

Writing Text

There are 6 different input modes for different handwriting styles.

v Tap

Insert

Text

> and set the input type on the toolbar.

To Change the Font or Insert Time/Date

v Tap

Options

Advanced tab

v To use a new font, open the drop-down list and choose the new font.

v To insert the current date and time automatically into your document,

tap Menu

Insert

Time/Date

Making Drawings

You can draw in the writing zone or over the top of an inserted image.

v Tap

Insert

Drawing

v To select a color that has been used in a drawing, tap the pen color icon on the toolbar.

Inserting Images

Tap

Insert


, to insert an image as a drawing background.

Inserting Multimedia

Tap

Insert

Movies

, open the options on the input type tool to insert a multimedia item from a

file.

Note

Multimedia items can be sent by e-mail or MMS.

Tap

Insert

Audio

, to insert a sound file.

Communication

To Cut/Copy an Entire Area

v To cut/copy a portion of text or part of a drawing, select that part (double-click or drag for text, for

drawings). Then from the menu icon, select

Edit

to choose from

Cut/Copy/Paste/Paste before/Paste

after/Delete

To Change the Zoom Level

v Tap

Zoom

or zoom tool. You can set the zoom level (from 25% to 200%).

To Use the Personal Dictionary

v Tap

Options

> the

Dictionary tab

v Type the word you wish to enter into the Word text box.

v Tap the Add button to enter that word in your personal dictionary.

The word will then appear in the Dictionary list.

Note

Once your writing is recognized, the input zone is cleared automatically. It need to write clearly. Space

letters and words comfortably, avoiding very cramped words, or large spaces within words.

Communication

Activesync

ActiveSync synchronizes information on your device with information on your PC, such as Outlook

content. ActiveSync can also synchronize over a cellular network with Microsoft Exchange Server, if your

company or service provider is running Microsoft Exchange Server with Exchange ActiveSync. When you

synchronize, ActiveSync compares the information on your device with the information on your PC and/or

Exchange Server and updates all locations with the most recent information.

With ActiveSync, you can:

v Synchronize information, such as Outlook E-mail, Contacts, Calendar, or Tasks information on your

device with your PC, as well as pictures, video, and music.

v Synchronize Outlook E-mail, Contacts, Calendar appointments, and Tasks on your device directly with

Exchange Server so that you can stay up to date even when your PC is turned off.

v Exchange files between your device and your PC without synchronizing.

v Select which types of information are synchronized and specify how much information is

synchronized. For example, you can choose how many weeks of past Calendar appointments to

synchronize.

Before you can synchronize information with a PC, first, you must install ActiveSync on your PC.

And then you create a synchronization relationship between your device and the PC.

You can install ActiveSync from the Getting Started disc that comes.

Once you have installed ActiveSync and set up a synchronization relationship, ActiveSync on the PC

recognizes your device when you connect it, and automatically transfers the synchronization settings you

specified on your device.

You may be able to synchronize your device with Exchange Server through your company or wireless

service provider. If you plan to do so, obtain e-mail address, Exchange Server address, user name,

password, and domain name from your administrator before starting the Sync Setup Wizard.

Communication

Setting up Windows Vista™

Microsoft Windows Mobile® Device Center is the replacement for Microsoft® ActiveSync® on Windows

Vista™.

Note

Some versions of Windows Vista come with Windows Mobile Device Center already installed. If

Windows Mobile Device Center is not available on your Windows Vista, you can install it from the

Getting Started Disc that came with your device.

Set up synchronization in Windows Mobile Device Center

When you connect your device to your PC and start Windows Mobile Device Center for the first time, you

are asked to create a Windows Mobile partnership with your device. Follow the steps below to create a

partnership.

v Connect your device to your PC. Windows Mobile Device Center configures itself and then opens.

v On the license agreement screen, click

v On the Windows Mobile Device Center’s Home screen, click

Set up your device

Note

Choose

Connect without setting up your device

if you only want to transfer media files, check for

updates, and explore your device but not sync Outlook information.

v Select the items you want to synchronize, then click

v Enter a device name and click

Set Up

. When you finish the setup wizard, Windows Mobile Device

Center synchronizes your device automatically. Notice that Outlook e-mails and other information will

appear on your device after synchronization.

Communication

Use Windows Mobile Device Center

To open Windows Mobile Device Center, click

Start > All Programs > Windows Mobile Device Center

on your Windows Vista computer. On Windows Mobile Device Center, you can do the following:

v Click

Mobile Device Settings

to change synchronization settings.

v When you click

Pictures, Music and

Video

> ___

new pictures/video clips

are

available for

import

, a wizard guides you to tag and transfer photos from your device to the Photo Gallery on your

Windows Vista PC.

v Click

Pictures, Music and Video

Add media to your device from Windows Media Player

to synchronize music and video files using Windows Media™ Player. For more information, see

“Windows Media® Player Mobile” in Chapter

11.

v Click

File Management

Browse the contents of your device

to view documents and files from

your device.

Setting up Windows XP

If you are using Windows XP the Getting Started CD that comes with your device contains Microsoft

ActiveSync 4.5 or later. Follow the steps below to install and set up ActiveSync on Windows XP.

v Insert the Getting Started CD into the CD drive of your PC.

v Select

Setup and Installation

and follow the on-screen instructions to install ActiveSync.

v After installation is completed, connect your device to your PC using the sync cable.

- Connect the smaller end of the USB cable to your GM730.

- Connect the larger end of the USB cable to the USB port on your computer.

v The Synchronization Setup Wizard automatically starts and guides you to create a synchronization

relationship. Click

to proceed.

v To synchronize your device with your computer, clear the Synchronize directly with a server running

Microsoft Exchange Server check box, and then click

v Select the information types that you want to synchronize, and then click

Click Finish.

When you finish the wizard, ActiveSync synchronizes your device automatically.

Synchronizing Information

When you connect your device to the PC using a USB or a Bluetooth connection, ActiveSync will

immediately synchronize. While the device is connected, ActiveSync synchronizes every time you make a

change on either the PC or the device.

Synchronizing Outlook information

If you have set up a synchronization relationship between your device and the PC, synchronization

keeps Outlook information up-to-date on both computers. ActiveSync synchronizes a limited amount of

information by default to save storage space on your device. You can change the amount of information

synchronized for a given information type in Settings for the information type.

You can set up your device to synchronize with more than one PC or with a combination of one or more

PCs and Exchange Server. When synchronizing with multiple computers, the items that you synchronize

will appear on all of the computers with which they are synchronized.

For example, if you have set up synchronization with two PCs (PC1 and PC2), which have different items,

and you synchronize Contacts and Calendar on the device with both computers, the result is as follows:

Location New state

PC1

All Outlook contacts and calendar appointments that were on PC2 are now also on PC1.

PC2

All Outlook contacts and calendar appointments that were on PC1 are now also on PC2.

Device

All Outlook contacts and calendar appointments from both PC1 and PC2 are on the

device.

Communication

To start and stop synchronization

v To synchronize Outlook information and other local information on the PC, including media files,

connect your device to the PC using Bluetooth or a cable.

v If you are synchronizing directly with Exchange Server, you can use the PC connection to the network

that is "Desktop Pass-through", or you can synchronize without connecting to the PC over a cellular

network.

v In ActiveSync, tap

Sync

. To end synchronization before it completes, tap Stop. To change which

information is synchronized

In ActiveSync on the device, tap

Options

Do one or both of the following:

v Select the check box for any items you want to synchronize. If you cannot select a check box, you

might have to clear the check box for the same information type elsewhere in the list.

v Clear the check box for any items you want to stop synchronizing.

To stop synchronizing with one PC completely, tap the PC and tap Delete.

Note

Outlook e-mail can be synchronized with only one computer. To change available synchronization settings,

select the type of information and tap Settings.

To synchronize directly with Exchange Server

You can set up synchronization with Exchange Server on your device, if it is available to you through your

company or wireless service provider. However, you should first ask your administrator for the following

information and then carry on with the steps: e-mail address, Exchange Server address, user name,

password, and domain name.

Communication

In ActiveSync on the device, tap

Configure Server

. If you have not yet set up synchronization

with Exchange Server, this will say

Add Server Source

Enter e-mail address, and tap

In Server address, enter the address of the server running Exchange Server, select the check box if this

Server requires an encrypted (SSL) connection. And tap

Enter user name, password, and domain, and tap

. To change the rules for resolving

synchronization conflicts, tap Advanced.

Select the check boxes for the types of information items that you want to synchronize with Exchange

Server.

To change available synchronization settings, select the type of information, and tap

Settings

Tap

Finish

Synchronizing via Bluetooth

You can connect your device to the PC to synchronize using Bluetooth.

To synchronize with a PC via Bluetooth

Firstly, check "Allow connections to one of the following" of the ActiveSync connections Settings menu

on your PC.

Select the proper COM port.

If there is not available connections, then you should first make a Bluetooth pairing.

Select the ActiveSync via Bluetooth item in Bluetooth connection wizard(Bluetooth Settings

-> Bluetooth Manager -> new -> ActiveSync via Bluetooth).

Communication

Synchronizing Music, Video, and Pictures

If you want to carry your music or other digital media with you along while you travel, ActiveSync works

with Windows Media Player to synchronise music, video, and pictures.

Other than selecting the Media information type in ActiveSync to be synchronised, all media

synchronization settings must be set in Windows Media Player. Before media can be synchronised, you

must do the following:

v Install Windows Media Player Version 10 on the PC.

v Connect your device to the PC with a USB cable. If the device is currently connected using Bluetooth,

you must end that connection before media can be synchronised.

v Insert a storage card into your device (32MB or larger is recommended).

v Set up a sync partnership between the storage card and Windows Media Player.

Change Media synchronization settings

Once you select the Media information type in ActiveSync to be synchronised, any of your favorite music,

video, and picture files in Windows Media Player playlists can be synchronised. All you have to do is set

up synchronization in Windows Media Player for those media files.

To set up a sync relationship with a storage card

Open Windows Media Player.

Click the

Sync

tab.

Select the storage card.

Click

Set up Sync

For information about using Windows Media Player on the device, see Chapter

Communication

New Message

New Text Messages

You can write, edit and view the text messages.

v Tap on the home screen to access Messaging menu directly.

v Enter the e-mail address or text message address of one or more recipients, separating them with a

semicolon. To access addresses and phone numbers from Contacts, tap

v Enter your message. To quickly add common messages, tap

My Text

and tap a desired

message.

v To check the spelling, tap

Spell Check

v Tap

Send

New MMS Messages

You can configure Multimedia message using the device camera to capture photos and video clips while

composing a new MMS message, and send them along with your message.

Note

You can also send an MMS message directly from the

Pictures & Videos

or Camera programs.

Select a picture from My Pictures, and tap

Send

Capture a photo or an MMS video clip using the camera, and tap

Message

icon >

Send MMS

and put the recipients address in the To field and then tab

Send

Communication

To start MMS message

You can compose MMS messages in a combination of various slides, where each slide can consist of a

photo, audio or video clip, and/or text.

v From home screen, tap

LGMenu

Messaging

Message

New

MMS

v In

, enter the recipient’s phone number or e-mail address directly, or tap

Add Recipient

choose a phone number or an e-mail address from

Contacts

v Enter a subject for your message.

v Tap to select and insert a media file by tapping the respective areas.

v Enter text.

v Tap

Send

to send the message.

Get Xpress Mail

You can easily access to your personal or work E-mail from your mobile by installing Xpress Mail

application.

Xpress Mail makes it fast and easy to set up your personal E-mail from providers such as Yahoo! Mail,

Comcast, EarthLink, and many others.

The key features that Xpress Mail include are not only read, reply, forward and delete messages but also

automatic push mail and full attachment E-mail.

Download Xpress Mail client from the web site to your GM730 and install the program.

Tap Get Xpress Mail which is on the home screen.

Tap

Install Now

to launch the Xpress Mail download site.

Tap

Download Now

on the download page.

Tap

Yes

(Open file after download should be checked) and them tap

Yes

again to continue.

Tap

to accept the license agreement.

Confirm your 10 digit phone number and tap

Select Portal or ISP and tap

Choose your provider and tap

. If your e-mail provider is not listed, tap

to view an additional

list of personal e-mail providers.

Tap

to agree to the ISP terms of use, if applicable.

Communication

10.

Enter your User Name and Password and Tap

to continue.

11.

Tap

and wait for the registration process to complete.

12.

When the process is complete, tap

when the message appears telling you the device has been

successfully registered. Tap

to go to your settings.

13.

After successfully registering, your device will automatically display the Xpress Mail Settings screen.

Communication

Multimedia

MEdia Mall

Note

Additional charges may accrue when you download new content. Contact AT&T for more

information.

Shop Tones

This menu option connects to AT&T’s ringtone download site.

AT&T Starter Packs

This menu option allows users to download free trials of mobile applications and games.

Shop Games

This menu option connects to AT&T’s game download site. This allows users to download the various

games by connecting to the Internet.

Shop Graphics

This menu option connects to AT&T’s graphic download site.

Shop Multimedia

This allows you to connect to AT&T's multimedia download site.

Shop Applications

This menu option connects to AT&T’s application download site. This allows users to download the

various applications by connecting to the Internet.

Multimedia

Shop Videos

This menu option connects to AT&T’s video download site. This allows users to download the various

videos by connecting to the Internet.

Shop Music

This menu option connects to AT&T’s music download site. This allows users to download music from the

Internet.

MEdia Net Home

This menu option connects to AT&T’s branded web portal that can be customized to display your favorite

information.

MEdia Net

MEdia Net is AT&T’s branded web portal that can be customized to display your favorite information.

Note

May require an AT&T data plan. Please contact your AT&T wireless representative for more

information.

Multimedia

AT&T Music

Music Player

Allows you to use Windows Media Player. You can play digital audio and video files that are stored on

your device or on a network.

Adding Music to your Handset

Before You Get Started

To transfer music from your PC to your device, you will need the following:

• Windows Media Player 10 or above

• Windows XP Service Pack 2

• Music on your PC in one of these formats: MP3, .AAC, AAC+ or WMA

• A MicroSD card

• USB data cable

*MicroSD card is optional.

Transferring Music from the Digital Music Stores

Transferring Music from the Digital Music Strores. In order to download music from the computer to your

GM730, handset and microSD card are required. These items are sold separately;

go to http://www.wireless.att.com/.

Using your computer, open your preferred WMDRM PC music management client.

Download the selected song to your library.

Insert the microSD card into the handset.

Use the USB adapter cable to connect the handset to the target PC.

Mobile Device will be shown on the computer screen.

Highlight the song you wish to download to the handset.

Using your right mouse button, click on the highlighted song and select Transfer Track(s) to Portable

Multimedia

Device from the dropdown menu. This step begins the download process.

Adding Music to your Handset

Music files can be added to your handset by using one or more of the

following methods:

• Download music and ringtones over the AT&T network directly to your device by using the shopping for

music feature.

• From your existing digital media collection through Windows Media Player®.

• From music stores through the applicable music client.

Transferring Music using Windows Media Player

A USB cable, microSD card, and a current version of the Windows Media Player are required for this

procedure.

Open Windows Media Player on your computer (version 10.0 or higher).

Use the USB adapter cable to connect the handset to the target PC.

Mobile Device will be shown on the computer screen.

From within the Windows Media Player application, click on the Sync tab. Previously downloaded

songs are then listed on the left side of the application in case that Window Media Player 11 is

installed.

Choose the destination location for the media files.

Note

If there are no items present in the playlist, click the Edit Playlist button and begin adding the music files

from among the various media categories.

Select the songs to be highlighted and right click to add to 'Sync List' to synchronize to your handset.

Tap the Start Sync at the lower right corner of the application to download the selected songs to your

handset. Do not unplug the handset during this process.

It is now safe to unplug the USB connector from the handset.

Multimedia

Transferring a Playlist to the handset

Open Windows Media Player on your computer (version 10.0 or higher).

Use the USB adapter cable to connect the handset to the target PC.

Mobile Device will be shown on the computer screen.

From within the Windows Media Player application, click on the Library tab.

From the left side of the Library tab, click on All Music. The right side of the page is then populated with

all of the songs which the player has previously found.

Right click on the song entry and select, Add to.. > Additional Playlists.

From the Add to Playlist dialog, click the New button and type in a unique playlist name.

Click OK when you are done entering the new playlist name. The new Windows Media playlist is then

displayed within the My Playlist section of the Library tab (left side).

Drag and drop the newly created playlist from the My playlist section to the phone Music Sync Player

listed just above it. Click "Start Sync".

Note

If there are no items present in the playlist, click the Edit Playlist button and begin adding the music files

from among the various media categories.

10.

It is now safe to unplug the USB connector from the handset.

Multimedia

Note

If you connect handset with specific USB Hub on your PC, above Music Sync service can not be work.

So we recommend direct USB Connection on your PC not using HUB.

Do not disconnect during transfer. Check if your PC is running Windows XP and Windows Media Player

10 or later. If your PC is running Windows XP and Windows Media Player 9, please download WMP10 or

WMP11 by visiting Microsoft site.

If you have connected your handset to PC, and trying to send file using Music Sync, but the

function is not working properly, please check the below lists.

A. Check whether the file length you are transmitting is not too long.

B. Check whether license of the file you are transmitting is not expired.

C. Check whether the file you are transmitting is a right format for your phone (MP3, WMA, AAC).

If you transfer files as shown below, the transferred files will not show in a third party application

or in Windows Media Player.

A. Transmitted a file by directly inserting external memory on PC.

When you have transferred files with Music Sync feature and you want to delete them from your

phone, you should connect the phone to your PC again with Music Sync to delete them. Even if you

have deleted files transferred with Music Sync feature as shown below, delete them again with

Music Sync. Otherwise you will not be able to transfer files identical to the deleted files again.

A. Deleted a file using Windows Explorer on PC.

B. Deleted a file by directly inserting external memory on PC.

C. Deleted a file using delete function on the phone.

Multimedia

Play Media

Use the library on Windows Media Player Mobile to find and play songs, videos, and playlists that are

stored on your device or removable storage card.

To update the Library

If you are not on the Library screen, tap

Library

On the Library screen, tap the Library arrow (near the top of the screen), then tap the media storage

that you want use, for example, Storage Card.

In most cases, Windows Media Player Mobile automatically updates the library. However, you can

manually update the library to ensure that it contains new files that you recently copied to your device

or storage card. Tap

Update Library

to manually update the library list.

To play video and audio files on your device

Select a category (for example, My Music or My Playlists).

Tap the item that you want to play (such as a genre, album, or artist name), then tap Play.

Note

To play a media file that is stored on your device but is not in a library, on the Library screen, tap

Open File

. Tap and hold the item that you want to play (such as a file or a folder), then tap Play.

To play a media file from the Internet or a network server, tap

Library

then tap

Open

URL

Playlists

A playlist is a list of digital media files that play in a specified order. By using playlists, you can group

audio and video files together for convenient playback.

In Windows Media Player on your PC, you can create playlists and synchronize them with your device.

In Windows Media Player Mobile on your device, you can create a new playlist by saving the current

Now Playing playlist and giving it a new name.

Multimedia

To save a new playlist

If you are not on the Library screen, tap

Library

Tap to select a category (for example, My Music or My Playlists).

Select a media file that you want, then tap

Queue Up

. This adds the file to the Now Playing

list.

Repeat this step until you have added all desired media files to the Now Playing list.

Note

You cannot select multiple files simultaneously.

After adding the media files, tap

Now Playing.

On the Now Playing screen, tap

Save Playlist

Enter the playlist name then tap Done.

To play back the playlist you created, tap

My Playlists

in the Library, select your playlist, then tap

Play

Shop Music

Selecting Shop Music from the AT&T Music sub menu launches the browser to a music landing page

from which you can purchase music from 3rd party stores and personalization content from AT&T.

Music ID

MusicID is an application which uses the onboard microphone to analyze a song sample and then

compare it to a remote database of songs. Once the application completes the analysis of the song

sample, it then provides you with the name of the song, artist and album art as well as opportunities to

buy related content.

ID song!:

Allows you to find out information of unknown music by sending the sound of the unknown

music to the web. If the web identifies the song, it returns with relevant information of the song.

Manage IDs:

Once a song has been identified through the MusicID, you can see the list of songs in

this folder.

XM Radio

Selecting XM Radio from the AT&T Music sub menu launches a preinstalled application. The application

allows the user to listen to dozens of channels of digital radio on your mobile phone. Get unlimited access

to commercial-free music, the latest Hip Hop, R&B, Rock, Jazz, Country anywhere you go.

WARNING!

This product will use a large amount of data and you are responsible for all data charges

incurred.

Music Videos

Selecting Music Videos from the AT&T Music sub menu launches a browser which takes you directly

into the Music Video section of Cellular Video. From this menu, you will have access to music videos from

the latest artist as well as programming from AT&T, MTV,VH1, and CMT among others. Simply click on a

video and begin watching!

Pandora

Selecting Pandora from the AT&T Music sub menu launches the browser to discover new music and

enjoy it. Pandora is an automated music recommendation and Internet radio service created by the

Music Genome Project. Users enter a song or artist that they enjoy, and the service responds by playing

selections that are musically similar. Users provide feedback on the individual song choices approval or

disapproval which Pandora takes into account for future selections.

Community

Selecting Community from the AT&T Music sub menu launches the browser to either one or more of the

hot user communities. The application allows the user to interact with their friends and the community as

well as review artist fan sites.

Music Apps

Selecting Music Apps from the AT&T Music sub menu launches the browser to an area where the user

can purchase music related applications for download.

Multimedia

Note

Additional charges may accrue when you download content. Contact AT&T for further information.

Cellular Video (CV)

CV brings you quick, on-demand access to news, sports, weather and entertainment video clips. Catch

up on TV’s hottest shows, funniest comedians, biggest headlines and latest sports scores. You can even

personalize your homepage for quick access to your favorites. In addition, the CV service automatically

streams localized weather information to your personalized “News & Weather” page each and every day.

Games

In the Games submenu of Menu, Java games(Block Breaker Deluxe and Sudoku) and Windows games

(Bubble Breaker, MsPac-Man, Solitaire) have been added. You can download the full versions of these

games from the internet except for Bubble Breaker, Solitaire.

To play, tap the game that you want to enjoy.

Apps

In the Apps submenu of Menu, Java apps(Mobile Banking, My-Cast 5 Weather and People) have been

added.

Multimedia

Pictures & Videos

The Pictures and Videos program collects, organizes, and sorts images and video clips in the following

formats on your device.

File Type File Extensions

Image *.bmp, *.jpg

Video *.avi, *.wmv, *.mp4, *.3gp

Audio *.aac, *.wma, *.mp3, *.wav, *.midi

You can view the pictures as a slide show, bean them, send them via e-mail, edit them, or set them as the

background on the Today screen.

To Copy a Picture or Video Clip to Your device

You can copy pictures from your PC and view them on your device.

Copy the pictures from your PC or a storage card to the My Pictures folder on your device.

Note

You can also copy pictures from your PC to your device using a memory card. Insert the memory card

into the memory card slot on your device, then copy the pictures from your PC to the folder you created

on the memory card.

To View Pictures

Tap (

LG Menu

) >

Multimedia

Pictures & Videos

. The images in the My Pictures folder appear as

thumbnails by default.

Select a picture and tap

View

. If you cannot find a picture in the default My Pictures folder, go to

another folder by tapping the Down arrow.

Zoom :

Allows the panel buttons to zoom in or out of the area highlighted by the red box.

Multimedia

To Play Videos with Audio

Tap (

LG Menu

) >

Multimedia

Pictures & Videos

The video files in the My Pictures folder appear as thumbnails

by default, which appear with a media icon.

Select a video and tap

the thumbnail

to play it with the built-in Windows Media Player.

To Sort Pictures and Video Clips

If you store a large number of pictures or video clips on your device, you may find it helpful to sort them to

quickly find a specific picture or clip. You can sort by name, date, and size.

Tap (

LG Menu

) >

Multimedia

Pictures & Videos

Tap the sort list (the top right side of the screen and labeled Date by default), and select the item you

want to sort by.

To Delete a Picture or Video Clip

Do any of the following to remove a picture or a video clip:

Select a picture or video clip on the Pictures & Videos screen, and tap

Delete

. Tap

Yes

confirm the deletion.

Tap and hold the thumbnail of the picture you want to delete, then tap

Delete

To Edit a Picture or Video Clip

You can rotate, crop, and adjust the brightness and color contrast of your pictures.

Tap (

LG Menu

) >

Multimedia

Pictures & Videos

Tap the picture you want to edit.

Tap

Edit

, and do any of the following:

To rotate a picture 90 degrees counterclockwise, tap

Rotate

To crop a picture, tap

Crop

. Then, tap and drag to select the area to crop. Tap outside the box to

stop cropping.

To adjust the brightness and contrast levels of a picture, tap

AutoCorrect

Multimedia

Note

To undo an edit, tap

Menu > Undo

. To cancel all unsaved edits you made to the picture, tap

Revert

Saved

To Set a Picture as the Today Screen Background

You can use a picture as the background on the Today screen.

Tap (

LG Menu

) >

Multimedia

Pictures & Videos

Select the picture you want to set as the background.

Tap

Set as Today Background

Transparency level

, select a higher percentage for a more transparent picture, or a lower

percentage for a more opaque picture.

Tap

To Send Pictures and Video Clips via E-mail

You can send pictures and video clips to other devices via e-mail.

First, set up Messaging to send and receive messages.

From the program, select the picture or video clip you want to send.

Tap

Send

, and select one account (such as Outlook E-mail or MMS) to send the attached item.

A new message is created with the item attached.

Enter the recipient name and subject, and tap Send. The message will be sent the next time you

synchronize your device.

Note

Pictures and video clips are saved automatically before they are sent.

Multimedia

To Assign Pictures to Contacts

You can assign a picture to a contact so that you can easily identify the contact at any point of time.

Tap (

LG Menu

) >

Multimedia

Pictures & Videos

Select the picture you want to assign to a contact.

Tap

Save

Save to Contact

Tap the contact, or navigate and tap

Select

to choose the contact from your Contacts list.

. Tab

To Use Advance Options

Tap (

LG Menu

) >

Multimedia

Pictures & Videos

Select the picture for which you want to configure further settings.

Tap

Options

. The Options screen appears, allowing you to:

Resize a picture so that you can send it faster to someone using your e-mails.

Configure the view settings during slide shows and activate screensaver options.

Configure your device camera and camcorder settings.

Send:

You can send the selected image via Message, E-mail but some files which are protected by

Digital Rights Management (DRM) cannot send.

Zoom:

You can zoom in or out the picture.

Play Slide Show:

You can view the images as a slide show.

Set as Today Background...:

You can set the image as screen background.

Save to Contact:

You can set the image of selected entry in contacts. When you receive an incoming

call, the image saved in contact is displayed.

Save as:

You can save as file name.

Edit:

You can crop or rotate the image.

Properties:

You can preserve the image.

Options...:

When sending pictures in e-mail, pictures can be resized so that they transfer faster. Use

this picture size: Large(640x480)/Medium(320x240)/Small(160x120)

Send to HP's Snapfish:

Sends the selected file to

Snapfish

Multimedia

Weather

You can check today's weather and the weather forecast of the city that you chose. Just tap the icon of

weather from your home screen.

To Change the City and State

Tap

Start

Settings

Personal

tab >

Clock Style & Weather

. Or you can simply tab the clock from

home screen.

Tap

Weather

tab.

Select the

Region

Country

State

and

City

where you want to get weather data.

To Set Options

Tap

Start

Settings

Personal

tab >

Clock Style & Weather

Tap

Weather

tab

Select

for

Display on the Today screen

if you want to check the weather on the

Today

screen

Check

Automatic Download

box if you want to download weather data automatically.

Note

This function may incur additional data transfer fees from your provider.

You can check today's weather of the city that you chose on home screen also.

Multimedia

FM Radio

You can search radio stations and enjoy listening to the radio.

Note

To improve the radio reception, extend the headset cord which functions as the FM antenna.

You cannot use the FM radio without the headset.

In order to save/ add a station, tap the bottom middle bar then tap

and tap add.

After presetting the radio channels, you can listen to all the preset channels by tapping the left or right

arrow.

You can access the following option menus tapping

Scan:

If you tap Scan, it automatically sets the radio channels. If you want to save current channel,

then stop->Menu->save preset.

Save preset:

You can set the channel that you use frequently. It can be found in preset list.

Options:

Allows to Enable RDS and Alternative Frequency Switching

Note

Enable RDS:

On the screen displays the received data message from radio station.

Multimedia

Camera

Press the

1 2abc 3def

4 5jkl 6mno

ghi

7 8tuv 9wxyz

pqrs

0 #

key to enter camera capture mode directly. Or, tap the Multimedia icon, and then select

Camera menu.

The picture and filename will be shown after the picture taken. You can automatically save the picture

and return to preview by pressing

1 2abc 3def

4 5jkl 6mno

ghi

7 8tuv 9wxyz

pqrs

0 #

or tap the button. To delete it and return to preview, tap the

button.

The photo is saved in the

My Pictures

folder. You can access to folder by tapping

Pictures & Videos

Before taking a picture, you can try QFL (Quick Functions List) on the right side of display, or change

settings by tapping the indicator icon or menu pop-up. The settings you can change are as follows:

Goto:

Video/Picture & Video Gallery/Video Share Call

Tip

For more information about Video Share Call, please refer to "

From Camera preview

, initiating a

Video

Share Call

" in Page 59.

Mode:

Normal shot / Continuous shot / Panorama / Frame shot

Full View:

Change preview display to 400X240. The snapshot resolution wouldn't be changed

Brightness:

Change brightness of preview & snapshot

Image size:

320X240, 640X480, 1024X768, 1600X1200, 2048X1536

Color Effect:

Off / Negative / Sepia / Black & White / Aqua

White Balance:

Auto / Incandescent / Sunny / Fluorescent / Cloudy

Timer:

Allows you to select the delay time(Off, 3 Seconds, 5 Seconds, 10 Seconds).

Then the picure is being taken after the specified time.

Image Quality:

Normal / Fine / Super Fine

Memory in Use:

Handset / External

Shutter Sound:

Allows you to select various shutter sound(Sound 1, Sound 2, Sound 3, Off). You can

play the sound by touching the specified row. But only 'Multi shot' mode use specific sound.

Reset setting:

Reset all the settings to default.

Multimedia

Choosing a Shot Type

Normal shot:

This is the default shot type, the photo will be taken in the normal way.

Continuous shot:

Continuous shot enables you to take three, six, or nine shots automatically in very

quick succession.

Panorama:

This shot type is great for taking a photo of a large group of people or for capturing a

panoramic view.

Frame shot:

Choose from one of the fun frames to transform your friend into a pirate or just decorate

their surroundings.

Video Camera

To start recording press

1 2abc 3def

4 5jkl 6mno

ghi

7 8tuv 9wxyz

pqrs

0 #

. On camera capture mode, press and select ' Video' row to change

mode to video camera.

As soon as it starts to record a timer wil be displayed.

Settings for video camera are same as camera except of

Video Size

Voice

Record mode

Video Size:

128X96, 176X144, 320X240, 400X240

Voice:

Mute / Unmute

Record mode:

MMS / No Limit / Video Share Call

Press the hotkey or touch button to end the recording and this will now be saved.

Multimedia

Windows Media

You can use Microsoft Windows Media Player 10 Mobile for Pocket PC to play digital audio and video

files that are stored on your device or on a network, such as on a Web site.

Using Windows Media Player, you can play both audio and video files. These are the following file

formats that are supported by this version of Windows Media Player (WAV, WMA, WMV, MP3, MIDI,SP-

MIDI, SMAF, AAC,AMR,3GP,MP4 etc).

Windows Media Player has three primary screens:

Playback Screen

The default screen that displays the playback controls (such as Play, Pause, Next, Previous, and Volume),

the album art window, and the video window. You can change the appearance of this screen by choosing

a different skin.

When you are viewing the Playback screen, the following commands appear on

Library:

Displays the Library screen so you can choose a file to play.

Play/Pause:

Starts or pauses playback.

Stop:

Stops playback.

Shuffle /Repeat:

Plays the items in the Now Playing playlist randomly/ repeatedly.

Full Screen:

When a video is playing, displays it by using the entire screen.

Options:

Lets you adjust various Windows Media Player options, including network, skin, and

hardware button options.

Properties:

Displays information about the currently playing file.

About:

Displays information about Windows Media Player, such as the version number.About the

screens and menus

Multimedia

Icon Description

Plays/Pauses a file.

Increases the volume level.

Decreases the volume level.

Skips to the beginning of the current file or to the previous file.

Skips to the next file.

Adjusts the playback progress of a selected file.

Turns the sound on or off.

Displays a video by using the entire screen (full screen).

Displays a Web site where you can find music and videos to play.

Now Playing Screen

The screen that displays the

Now Playing

playlist. This special playlist indicates the currently playing

file and any files that are “queued up” to play next.

When you are viewing the Now Playing screen, the following commands appear on

Library:

Displays the Library screen so you can choose a file to play.

Move Up/ Down:

Moves the selected item up/down in the playlist order.

Remove from Playlist:

Deletes the selected item from the playlist.

Shuffle/Repeat:

Plays the items in the Now Playing playlist randomly/ repeatedly.

Clear Now Playing:

Deletes all items from the Now Playing playlist.

Error Details:

Displays error information about the selected item (an exclamation mark appears before

the item name if error details are available).

Properties:

Displays information about the selected file.

Multimedia

Library Screen

The screen that lets you quickly find your audio files, video files, and playlists. It contains categories such

My Music

My Video

My TV

, and

My Playlists

When you are viewing the Library screen, the following commands appear on

Queue Up:

Adds the selected item to the end of the current

Now Playing

playlist.

Delete from Library:

Deletes the selected item from the library.

Now Playing:

Displays the

Now Playing

screen.

Library:

Displays the

Library

screen so you can choose a file to play.

Update Library:

Adds new items to the library by searching your device or storage card.

Open File:

Lets you find and play files that are stored on your device or storage card but that are not in

the library.

Open URL:

Lets you play a file on a network, such as the Internet.

Properties:

Displays information about the selected file.

At the bottom of each screen is a menu called Menu. The commands on this menu change depending

upon which screen you are viewing.

Multimedia

Applications

AT&T GPS

The AT&T Navigator™ application on your device uses GPS position determination technology and

access to your carrier’s data network to provide you with driving directions and a host of other services,

including:

GPS navigation that gives you turn-by-turn directions to any destination address in the continental

United States. If you miss a turn or get off-track, AT&T Navigator will calculate a new route for you. You

can enter a destination address by using AT&T Navigator’s automatic voice recognition system or by

typing on the device’s keypad.

Audio and visual traffic alerts while driving or viewing maps, as well as traffic re-routing capabilities to

minimize delays on your trip.

A Search feature that allows you to find businesses or points of interest near your current location,

an airport, a waypoint, or any other entered address. You can read ratings and reviews for businesses

and easily call the business that you have found to check on the availability of an item or to make a

reservation. You can navigate to the business location now or save the address for later use.

Maps of the area around your current location, around a marked waypoint, or around an address that

you had previously entered. You can pan the map (adjust left, right, up, or down) and zoom in or out.

You can also mark a point under the cursor as a waypoint.

A compass-like indicator presenting your direction of travel, location, and speed.

The ability to personalize your application preferences by selecting U.S. customary or metric distance

units, the language for audible guidance, and so on.

You can also use many of AT&T Navigator’s features on the TeleNav website, such as getting driving

directions (Route Planning) and using the Search function to find businesses, churches, schools, and

government offices. You can also use the TeleNav website to add an address to your My Favorites list,

manage your My Favorites and Recent Places lists, and shop at the TeleNav Store.

Applications

Note

v In order to improve GPS antenna sensitivity, do not cover the GPS antenna area with your hand.

Please hold the handset as depicted in the figure below.

owever, if you hold your handset as in the picture shown above your RF antenna sensitivity might be

decreased.

v Will not be able to obtain a GPS location as a result of being in a restricted GPS

signal area such as in a building, underground or location surrounded by

metal or concrete.

v Use near from the window indoor for better GPS antenna sensitivity.

v Use windshield holder on your car.

v For battery durability, use vehicle power adapter on your car.

v It could take 2~3 minute to get your GPS position depends on the condition of environment or network.

How to Install AT&T Navigator.

Tap (

LG Menu

) >

Applications

AT&T GPS

Tap

Get AT&T Navigator

Browser will be launched and download page will be appeared. You can download and install AT&T

Navigator.

Applications

Launching AT&T Navigator

Tap (

LG Menu

) >

Applications

AT&T GPS

Tap

Tap AT&T Navigator

After launching AT&T Navigator, Login screen will appear. Your phone number is automatically

generated. Your phone number MUST be the same as your carrier phone number beginning with area

code so that when you call the Voice Address Input System, you will not need to type it in. Correct the

number if it is not accurate.

Type in your first and last name and click

If you have already signed up for the TeleNav service, then the next Login screen will prompt you to type

in the 4-digit PIN you provided when registering for TeleNav services at www.telenav.com.

Warning Screen

This next screen presents a warning for usage safety. If you agree to the conditions, click

Product Tour

If you choose to continue, a pop-up screen will offer to give you a brief tour of AT&T Navigator. Choose

Yes

to view a tour of AT&T Navigator’s key features. To go directly to the application, choose

Note

The product tour is only displayed the first time you log into AT&T Navigator and does not appear for

subsequent logins. You can always access the Product Tour again in the Tools/Extras menu.

Applications

AT&T Navigator Menu Overview

This section gives you a brief overview of the AT&T Navigator menus.

Main Menu

The AT&T Navigator Main Menu options are:

• Drive To

• Directory

• Maps

• Extras

Drive To Menu

Use Drive To and select from a variety of ways to navigate to a chosen address. The Drive To Menu

options are:

•

My Favorites

- Places that you have found and saved in the past so you can quickly access them.

•

Recent Places

- AT&T Navigator automatically saves all of the places that you:

) Found in a Directory

(Business) search,

) Viewed as a map, or

) Located using a street address, intersection, city, or

airport.

•

Business

- Search the directory and find the addresses and phone numbers of businesses. Sort

businesses by average star rating and read user reviews. Once you find what you are looking for, you

can get audible and visual driving or walking directions, place a call, view a map, or save it to your My

Favorites list.

•

Address

- Enter a street address by typing or speaking. You can leave the address field blank and type

in a city name to get directions to the center of the city.

•

Intersection

- Enter an intersection by typing or speaking.

•

Airport

- Quickly find airports by typing in the name or 3-letter code. For more information about using

the Drive To Menu.

100

Applications

Directory Menu

The Directory menu provides you with a few different ways to find the addresses and phone numbers of

businesses such as restaurants, motels, gas stations, churches, schools, government offices, and police

and fire stations.

You have the following options in the Directory menu:

•

Spell Name

– Type in a keyword for the search.

•

Recent Searches

– Access a list of the businesses you have recently viewed.

•

Food/Coffee

– Search from a variety of categorized restaurants.

•

Gas Stations

– Search for nearby gas stations.

•

Gas By Price

– Find the cheapest gas in your area.

•

Bank/ATM

– Search for nearby banks.

•

Hotels/Motels

– Search for nearby hotels and motels.

•

Parking

– Search for nearby parking facilities.

•

Other

– Search the Directory by categories. Press the plus (+) sign to expand a category and the minus

sign (-) to collapse it.

Maps Menu

You can use the Maps menu to view a map and traffic information for one of the following:

• Your Current Location

• A Favorite Place

• A Recent Place

• A Business (this is the same as the Search menu option)

• An Address

• An Intersection

• An Airport

101

Applications

Extras Menu

The Extras menu gives you options for setting your preferences and other features.

The Extras Menu options are:

•

Share Address

– Share an address with friends on their mobile device.

•

Record Location

– Record your current location via GPS. This option is useful when you do not know

your exact current address or if you would like to mark an area without a street address.

•

My Favorites

– Manage your Favorites list by renaming or deleting the items.

•

My Contacts

– Manage your contacts by organizing them into categories or editing contact

information.

•

Refer a Friend

– Invite another person to try the AT&T Navigator service.

•

Preferences

– Set your preferred options for the AT&T Navigator application.

•

Compass

– View a compass of your current directional heading.

•

About

- View information such as your AT&T Navigator version number, the Customer Support phone

number, and your account information. You can also take a Product Tour.

Note

v Please press x button or Exit menu button to halt AT&T Navigator. If you press End key, AT&T Navigator

disappers, but it is still running in the background, so unwanted battery consumption can happens.

Removing AT&T Navigator

Do the following steps to remove the AT&T Navigator application from your device.

Go to Start Menu and choose “Settings.”

In the System tab, choose “Remove Programs” (you may need to scroll

down to see this item).

In the list, highlight “AT&T Navigator" and click Remove.

102

Applications

Click Yes on the Delete Application warning message.

Verify that the application is no longer available on the handset menu.

Browser

With

Access Browser

, your mobile device can display web site like PC. Default browser for your device

is set to

Access Browser

In the address bar, enter the web address you want to visit and then tap . Tap the down arrow in the

address bar to choose one from previously entered addresses.

You can check following menus by tapping

Window:

You can open multiple windows at a time and display those by switching.

Up to 5 windows can be displayed.

View Setting:

You can view and set browser functions.

File:

You can check the list of page files.

View:

Full Screen:

You can view in full screen mode. Indicator area and menu bar area is disappeared.

Toolbars:

You can edit tool bar menu.

Text Size:

You can select the font size of the page.

Encoding:

You can change the character code of the web site displayed.

Show Images:

If you do not check this menu, all images on the web site are not displayed.

Enable Animations:

If you do not check this menu, all animations on the web site are not displayed.

Browsing Mode:

You can select the mode of browsing. Full browsing display web site as same as PC

browser. Text Browsing display only text of the web site.

Display Mode:

Change display mode of the web sites.

Zoom:

Set zoom factor for the web site display.

Virtual Canvas:

You can select size of the virtual canvas.

Edit:

You can Cut/ Copy/ Paste and Select All the text on the web site.

Tools:

You can change browser options.

103

Applications

Exit:

You can exit Access Browser.

You can check following menus by tapping

Operation

Back:

Go to web site accessed previously.

Forward:

When displaying web sites backwards, display next page of the currently displayed web site.

Reload:

Reload the currently displayed web site.

Stop:

Stop loading current web site.

Home:

Display a web site which URL is set as Home.

Bookmark:

Note

When "Page cannot be displayed." is appeared on the screen when you try to access web pages

with ActiveSync or Wi-Fi connection, please disable the Proxy setting on the device by going to

(

LG Menu

) >

Applications

Tools

Proxy Manager

To disable the Proxy setting, select 'Disable Proxy' and tap 'OK' on the Proxy Manager.

You should enable the Proxy setting again in order to access web pages with GPRS connection.

To enable the Proxy setting, select 'Restore Proxy' and tap 'OK' on the Proxy Manager.

The charge about browser usage can be different according to base connection(i.e. GPRS,

ActiveSync, or WiFi). Please contact your network operator for further information.

104

Applications

Calculator

The calculator function allows you to add, subtract, multiply and divide. You can input numbers using the

number keys, and input operators using button keys.

Voice Command

Voice command is the function whereby your phone’s voice recognition engine identifies the voice of the

user and carries out the requested commands. When the user operates the voice command function,

there are five possible commands, call <name or number>, Listen voicemail, missed calls, messages and

time and date.

Call <Name or Number>: This function is activated only when if user says command “Call” and name

stored in address book or specified phone number. Handset, voice engine inside recognize users

utterance handset, displays name lists from your phone’s address book or phone number, however

noise might caused to display candidates. Additionally user can superimpose number type at the end

optionally, such as “mobile”, “home” or “office”.

Listen Voicemail: this command is activated when the user says the words “Listen voicemail”. You will

be automatically connected to your voicemail.

Missed Calls: this command is activated when the user says the words “Missed calls”. The mobile

phone presents missed call lists.

•

commands available to user

yes:

make phone call

no:

moves next missed call list

cancel:

go back to main voice command menu

exit:

terminate voice command

105

Applications

Messages:

this command is activated when the user says the word “messages”. Mobile phone

displays details of unread SMS or MMS messages.

•

commands available to user

yes:

make phone call

no:

moves next unread messages

cancel:

go back to main voice command menu

exit:

terminate voice command

Time & Date:

this command is activated when the user says the words “time and date”. The phone

displays the current local time and date.

The Voice Command also has Menu Options

•

mode

speed:

voice command is abbreviated

normal:

voice command is played normally

•

train

answer:

enables the user train for answers used via voice command

number:

enables the user train for numbers used via voice command

•

best match

1 match:

when the user tries to find a number from the address book via the call someone function,

the most likely match will be displayed

4 matches:

when the user tries to find a name from the address book via the call someone function,

the four most likely matched names will be displayed

•

speaker phone mode

automatic on:

when this option is selected, sound is loud enough so you can hear in a distant place

off:

when this option is selected, sound is not loud enough so you can hear in a distant place

106

Applications

You can search for files and other items stored on your device in the My Documents folder or on a storage

card. You can search by file name or by words located in the item. For example, you can search in e-mail

messages, notes, appointments, contacts, and tasks, as well as in online Help.

To search for a file or an item

Tap (

LG Menu

)

Applications

Search for

, enter the file name, word, or other information you want to search for.

If you have looked for this item before, tap the

Search for

arrow and select the item from the list.

Type

, select a data type to help narrow your search.

Tap

The

My Documents

folder and subfolders are searched.

In the

Results

list, tap the item you want to open.

Stop Watch

This menu allows you to record the elapsed time of an event. The duration of an individual lap time (up to

20 times) and the total time can be displayed.

New Time

To start timing, tap

Start

. The running time is displayed as HH.MM.SS.hh (hours, minutes, seconds,

hundredths of a second).

During the timing, you can record an individual lap time by tapping

Lap

. Up to 99 lap times can be

recorded.

You can stop or restart timing by tapping

Stop

Reset

To reset the stopwatch, tap the key.

Saved Times:

You can see the saved recorded times which are in the lap time list.

107

Applications

Sprite Backup

Backup

Sprite Backup

allows to backup to SD Card, Main Memory, PC and FTP. For instructions on using the

PC and FTP options, please view these sections.

Tap (

LG Menu

) >

Applications

Sprite Backup

Tap

Backup

From the

Backup Data Selection

screen you can customized the backup. You can add/remove items

by simply enabling the the check boxes.

Press on the Next button to continue with the operation and open the

Save As

screen.

In the Save As screen you can add a name for the backup and also select the location to save the file.

After entering a name and selecting a location, press the

button to continue.

Once the backup index is completed,

Sprite Backup

will soft reset your device and display the

progress screen.

Once the operation is started do not start any applications on the device until the operation is

completed.

When the operation is completed, press next,

Sprite Backup

will automatically soft reset the device

and display the notification message.

10.

To view the report file, select

View Report

to close the notification message.

Note

The report file will display information about the Backup operation. You can also view the operation

report from the history option of the application. For more information view the Options-History.

108

Applications

Restore

Sprite Backup

allows to Restore from Internal storage such as SD Card, Main Memory, PC and FTP.

Tap (

LG Menu

) >

Applications

Sprite Backup

Tap

Restore

Sprite Backup will search for all available backup files and display them in

Open File

screen.

From the

Open File

screen, select the location from the drop down list. For PC and FTP locations you

must have an Activesync or Network connection active.

After selecting the location you can select the backup file that you wish to use to restore.

Once you have selected the backup file, press the

button to continue with the operation and

display the

Restore Data Selection

screen.

From the

Restore Data Selection

screen you can customized the restore operation. You can add/

remove items by simply enabling the the check boxes.

Press the

button to continue with the operation. Before initiating the restore operation Sprite

Backup will perform a soft reset. If a soft reset is performed when programs are running, unsaved work

will be lost.

After the Soft Reset the

Restore Progress

screen will be displayed.

10.

Do not open any applications or perform any task on the device while the restore operation is being

performed.

11.

When the operation is completed the device will soft reset and the restore operation notification will

be displayed.

12.

Select

View Report

to view the operation report or

to close the notification message.

Note

Depending on the size of the backup file that you are using to restore the operation can take few

minutes. We recommend not to use the device while the operation is being perform. When you are

performing a restore operation, please be aware that once the operation is completed

Sprite Backup

will perform a soft reset. If the soft reset occurs while you in a phone call your phone call will be

terminated.

109

Applications

Schedule

Sprite Backup

allows to Schedule Backup operations to different storage locations such as

SD Card, Main Memory, PC and FTP.

Tap (

LG Menu

) >

Applications

Sprite Backup

Tap

Schedule

Press the Next button to open the Backup Schedule screen.

Select a Frequency and enter a valid Date and/or Time for the backup or backups.

- 'Once':

will start a backup at the designated time and date.

- 'Daily':

will start a backup at the designated time each day.

- 'Weekly':

will start at the designated time and day each week, starting with the selected date.

Press the

to continue and to open the

Save As

screen.

In the

Save As

screen, you will need to enter a file name and select the location for the backup file.

Optionally enter a description for the backup file.

Press

to complete the setup.

Press the

button to confirm the changes and go back to Sprite Backup main screen.

Note

If you are using PIN Lock you will have the choice of using the background Mode that causes

Sprite Backup

to perform the operation without the need to unlock the device to continue.

The selected backup location must be available for scheduled backups to proceed. If the location

is not accessible, the backup will not proceed.

110

Applications

Options

Sprite Backup provides a number of options to help you manage your backup requirements.

Backup

Provides a number of options to help you manage your backup requirements.

Restore

Provides different restore options, these options are used to maximized the restore operation. In most

cases you will get the best result by using the default option but depending on how complicated is the

restore operation sometimes you will need to change these options to get the best result.

- General Restore Options:

Are used for standard restore operations. (Restore operations to the same

device or similar device with identical hardware and OS versions.

- Upgrade Mode Options:

Are used when restoring between different devices (Hardware types) or

devices with different OS versions (AKU and AKU2). We are constantly working on improving our

upgrade mode restore operation but due to constant development and changes to the Windows Mobile

platform ‘

Upgrade Mode

’ may not always restore your device to a desired state.)

Networking

Supports backup and restore operations between your mobile device and a PC or FTP site. This section

outlines how to configure and check these connections.

Security

Allows you to control Encryption, SIM Lock and the General security options.

History

Provides a list of the dates and times of the previous backups, with the most recent at the top of the list.

Backup reports occupy very little storage space, but can be manually deleted.

Sprite Backup

will begin

automatically deleting old backup reports after 30 have been created.

Help

Allows you to perform a number of tasks such as registration, authorization, provides version information

and access to the help file.

111

Applications

Internet Sharing

Note

ActiveSync software version 4.5 or higher is required.

Connect the USB cable to the PC.

Tap (

LG Menu

)

Applications

Internet Share

Set PC Connection to USB or Bluetooth PAN

Set Network Connection to proper APN

Tap Connect in the bottom line

Data connection indicator (G/ E/ 3G) is displayed when PDP activation is performed successfully.

Note

Operating System on your PC is required Windows XP SP2 or later.

112

Applications

Office Mobile

Excel Mobile

Excel Mobile makes it easy for you to open and edit Excel workbooks and templates created on your PC.

You can also can create new workbooks and templates on your device.

Note

Work in full-screen mode to see as much of your workbook as possible.

Tap View > Zoom and select a percentage so that you can easily read the worksheet.

Unsupported features in Excel Mobile

Excel Mobile does not fully support some features such as formulas and cell comments. Some data and

formatting may be lost when you save the workbook on your device. Note the following Excel Mobile

formatting considerations:

Alignment. Horizontal, vertical, and wrap-text attributes remain the same, but vertical text appears

horizontal.

Borders. Appear as a single line.

Cell patterns. Patterns applied to cells are removed.

Fonts and font sizes. Fonts not supported by your device are mapped to the closest font available. The

original font is listed on your device. When the workbook is opened in Excel on your PC again, the data

is displayed in the original font.

Number formats. Numbers formatted using the Microsoft Excel 2007 Version

1 conditional

formatting feature are displayed in Number format.

113

Applications

Formulas and functions. If an Excel file contains a function that is not supported by Excel Mobile, the

function is removed, and only the returned value of the function appears. The following formulas are

also converted to values: formulas entered as an array or containing an array argument, for example,

=SUM({1;2;3;4}); formulas containing external link references or an intersection range reference; and

formulas containing references past row 16384 are replaced with #REF!

Protection settings. Most worksheet and workbook protection features are disabled but not removed.

However, support for password protection has been removed. Workbooks that are password-protected

or workbooks in which one or more worksheets are password-protected cannot be opened. You must

remove the password protection in Excel on the PC and then synchronise to open the file on the device.

Zoom settings. Are not retained. Excel supports a per worksheet zoom setting, while the Excel Mobile

zoom setting is applied to the entire workbook.

Worksheet names. Names that reference worksheets within the same workbook are displayed

accurately, but names that refer to other workbooks, arrays, for example, ={1;2;3;4}, array formulas,

or intersection ranges are removed from the name list. If a name is removed from the list, it is left in

formulas and functions, causing those formulas to be resolved as “#NAME?” All hidden names are not

hidden.

AutoFilter settings. Are removed. However, you can use the AutoFilter command in Excel Mobile to

perform similar functions.

If you have an AutoFilter applied to a worksheet that causes rows to be hidden, the rows remain hidden

when the file is opened in Excel Mobile. Use the Unhide command to display the hidden rows.

Chart formatting. All charts will be saved the way they are shown in Excel Mobile. Unsupported

chart types are changed to one of these supported types: Column, Bar, Line, Pie, Scatter, and Area.

Background colors, gridlines, data labels, trend lines, shadows, 3D effects, secondary axes, and

logarithmic scales are turned off.

Worksheet features. The following features are not supported in Excel Mobile and are removed or

modified when a workbook is opened on the device: hidden sheets are not hidden; VBA modules,

macro sheets, and dialog sheets are removed and replaced with a place holder sheet; text boxes,

drawing objects, pictures, lists, conditional formats, and controls are removed; pivot table data is

converted to values.

114

Applications

PowerPoint Mobile

With PowerPoint Mobile, you can open and view slide show presentations created on your PC in *.ppt

and *.pps format with PowerPoint '97 and later.

Many presentation elements built into the slide shows such as slide transitions and animations will play

back on the device. If the presentation is set up as a timed slide show, one slide will advance to the next

automatically. Links to URLs are also supported.

PowerPoint features not supported on the device include:

Notes. Notes written for slides will not be visible.

Rearranging or editing slides. PowerPoint Mobile is a viewer only.

File formats. Files created in *.ppt format earlier than PowerPoint '97 and HTML files in *.htm and

*.mht formats are not supported.

To start a slide show presentation

Tap (

LG Menu

) >

Applications

Office Mobile

PowerPoint Mobile

In the presentation list, tap the slide show you want to view.

Tap the current slide to advance to the next slide.

If the presentation is set up as a timed slide show, slides will advance automatically.

To stop a slide show

• In a PowerPoint Mobile presentation, tap > End Show.

To navigate between slides

You can advance to the next slide if a presentation is not set up as a timed slide show, return to the

previous slide, or go to any slide out of sequence.

Tap (

LG Menu

) >

Applications

Office Mobile

PowerPoint Mobile

Open the presentation you want to view.

Tap > Next or Previous, or tap Go to Slide and tap the the slide you want to view.

115

Applications

Tip

Simply tap the current slide to go to the next one.

If you have zoomed in to see a slide in more detail, you cannot navigate to another slide until

you zoom out. Tapping Next or Previous may play an animation on a slide rather than navigate to

another slide.

Word Mobile

is a streamlined version of Microsoft Word. Word documents created on your PC can

be opened and edited on your device. You can also create and edit documents and templates in Word

Mobile and save them as *.doc, *.rtf, *.txt, and *.dot files.

You can have only one document open at a time. When you open a second document, the first one is

saved and closed automatically.

When you close a newly created document, it is automatically named after the first several words in the

document and placed in the Word Mobile document list. You can easily rename the document with a

more meaningful name and move it to another folder or a storage card.

To create a file

Tap (

LG Menu

)

Applications

Office Mobile

Word Mobile

In Word Mobile, tap New.

You’ll see either a blank document or template, depending on what you’ve selected as the default

template.

Enter text as desired.

When finished, tap OK to save the file.

116

Applications

Word Mobile does not fully support some features of Microsoft Word such as revision marks and

password protection. Some data and formatting may be lost when you save the document on your device.

The following features are not supported in Word Mobile.

• Backgrounds

• Shapes and text boxes

• Artistic page borders

• Smart tags

• Metafiles

Bi-directional text

. While Word Mobile will open documents containing bi-directional text, the

indentations and alignment may be displayed and saved incorrectly.

Password-protected files.

Word Mobile does not support opening password-protected documents.

You must first remove the password protection in Word on the PC if you want to view the document on

the device.

Document protection.

Word Mobile does not support displaying files that have been protected in

Word on the PC.

The following features are partially supported in Word Mobile.

Picture bullets

Revision marks:

When you open a document that has revision marks in Word Mobile, the document

appears as if all revision marks were accepted. When you save the document in Word Mobile, revision

marks are lost.

Table styles:

When you save a document in Word Mobile, some or all the formatting that is defined in

the table style is lost.

Underline styles. Underline styles not supported by Word Mobile are mapped to one of the four

supported styles: regular, dotted, wavy, or thick/bold/wide.

Legacy Pocket Word files. You can open *.psw files in Word Mobile; however, if you edit a file, you will

need to save it in *.doc, *.rtf, *.txt, or *.dot format.

117

Applications

The following features are not supported on the device; however, they are retained in the file so that

when a file is opened on the PC again, they appear as expected.

Footnotes, endnotes, headers, footers

Page breaks:

Word Mobile does not display breaks between pages. However, all page breaks except

for breaks at the end of a document are retained in the document.

Lists:

When you open the document on the computer again, indented lists are displayed in the original

form.

Fonts and font sizes. Fonts not supported by the device are mapped to the closest font available,

although the original font will be listed on the device.

To get more help about Word Mobile

• When in Word Mobile, tap

Start

Help

118

Applications

Notes

Notes helps you to quickly capture thoughts, questions, reminders, to-do lists, and meeting notes. You

can create handwritten and typed notes, record voice notes, convert handwritten notes to text for easy

readability, and send notes to others.

Entering Information in Notes

You can enter typed text by using the on-screen keyboard or handwriting recognition software. You can

also use the stylus to write or draw directly on the screen. On devices that support recording, you can

create a standalone recording or embed a recording in a note.

To Set the Default Input Mode for Notes

If you frequently add drawings to your notes, you may find it helpful to

set Writing as the default input mode. If you prefer typed text, select Typing.

Tap (

LG Menu

)

Applications

Notes

In the note list, tap

Options

In the Default mode box, tap one of the following:

Writing if you want to draw or enter handwritten text in a note.

Typing if you want to create a typed note.

Tap

119

Applications

To Create a Note

Tap (

LG Menu

)

Applications

Notes.

In the note list, tap

New

Drawing mode is displayed. Tab the Input Method icon if you want to type the note.

You can record the voice by checking

View Recording Toolbar

from

When finished, tap

to return to the note list.

Tools

File Explorer

The File Explorer application allows you to open an explorer window similar to a desktop Windows based

system. The explorer window allows you to navigate through your phone to locate desired folders and

files.

You can also quickly manage, delete, copy, or edit any files and folders on your phone. You can create

new folders.

If you want to see the files or folders in the

My device

Storage Card

folder, tap either of the two.

To view the files or folders in the phone’s memory, tap .

To open a file on a network, tap . Enter the file path and tap

Tap the folder category (labelled

My Documents

by default) and then the folder that you want to view.

GPS Utility

Show your location and speed information from the satellite signal.

120

Java

GM730 supports Java and hence you can easily download java games and other java applications from

the internet.

Mobile Java has 2 subfolders : Games and Applications. Each folder has an embedded link for

downloading Games or Applications from the internet .

Please note that additional costs may be incurred when using online services.

Mobile Zip

Mobile Zip is a comprehensive archiving tool for viewing and extracting of a wide range of archiving

formats.

Main Features of Mobile Zip

• Multi-tab user interface

• Open and browse a wide range of archive formats

• Extremely easy to use with user friendly interface

• Single-handed operation with extensive softkeys and navigation buttons supports

• Two folder views that enable user to copy, move, extract and add to archive from one to the other in a

breeze

• Extract-View-Edit cycle supported. Open an item in the archive, edit it and have it inserted back to the

LG Electronics USA GM730 Cellular/PCS GSM/EDGE/WCDMA Phone with WLAN and Bluetooth User Manual

LG Electronics USA Cellular/PCS GSM/EDGE/WCDMA Phone with WLAN and Bluetooth Users Manual

Users Manual

Navigation menu

Namespaces

Views

Navigation
