GS390 User Manual HTML Version

Users Manual

ns or

rranty

ate to

fax

es:

026

824

ABOVE

d for

aims.

GS390GS390 User Guide

Some of the contents in this

manual may differ from your phone

depending on the software of the

phone or your service provider.

Part 15.21 statement

" Change or Modifications that are not expressly approved by the manufacturer could void

the user's authority to operate the equipment. “

Part 15.105 statement

This equipment has been tested and found to comply with the limits for a class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful interference or

television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

Part 15 Class B Compliance

This device and its accessories comply with part15 of FCC rules.

Operation is subject to the following two conditions:

(1) This device & its accessories may not cause harmful interference.

(2) This device & its accessories must accept any interference received,

including interference that may cause undesired operation.

Body-worn Operation

This device has been tested for typical body-worn operations

with the distance of 0.79inches (2.0cm) from the user’s body.

To comply with FCC RF exposure requirements, a minimum separation distance

of 0.79inches(2.0cm) must be maintained from the user's body.

Additionally, Belt clips, holsters & other body-worn accessories may not contain

metallic components.

LG GS390 | User Guide

Your Phone

Phone Components

1. Handsfree or Stereo earphone

connector

2. Earpiece: Lets you hear the caller

and automated prompts.

Rea

Exte

lens

SIM

Batt

3. Main LCD: Displays phone status

icons, menu items, web items,

web information, pictures and

other party is ready to use the

3. To

(Li

Note

auto

free d

head

• Live

with

• Rec

vide

that

176

4. If

In-Call Menu

a 3G

both

vice

ese

all]

will

Video Share service. If the Audio

alert in the Video Share setting

(See Application Setting) is set to

, audio alert will sound along

with the prompt.

3. To Share Video with another party,

touch the Video icon or press the

Camera key and select Video Type

(Live or Recorded).

Note : The Speakerphone will be

automatically activated when a Video

Share session begins, unless a hands-

free device (Bluetooth

or stereo

headset) is connected.

• Live: Share a real-time video stream

with the other party.

• Recorded: Share a pre-recorded

video clip with the other party. (Note

that H.263 & Mpeg4 video formats in

176x144 size is supported)

4. If the other party accepts the

Video Share invitation, the Video

Share session will begin. (After

accepting, it may take several

seconds before the actual Video

Share starts.)

During a Video Share call, you can

do the following by touching the

icons below:

• : You can turn on/off the

Speakerphone.

• : You can mute/unmute the

microphone.

• : You can stop a Video

Share Call and proceed to a Voice

Call.

You can choose from the following:

• Brightness: You can adjust the

brightness of the screen by

selecting Brightness.

• Zoom: You can zoom in/out the

video by selecting Zoom.

• Audio to Bluetooth

/Audio to

Phone: When Audio to Bluetooth

is selected, you can have a

conversation using Bluetooth

When Audio to Phone is selected,

you can have a conversation using

either speakerphone or headset.

• Record Video Share/Stop

Recording: You can start recording

the live video by selecting

‘Record Video Share’. Once you

are recording the video, you can

stop recording by selecting ‘Stop

Recording’.

LG GS390 | User Guide

• End Call: You can end the phone

call by selecting ‘End Call’. (Note:

Video Share will stop as well)

• Hold Call: You can hold the phone

call by selecting ‘Hold Call’. (Note:

Video Share will stop when you

select ‘Hold Call’)

During the Video Share session, turn

the speakerphone on/off using the

‘Spk. off’ / ‘Spk. on’ key.

Note : Recorded video clip will be

saved in [My stuff ] - [More].

5.1. Stop a Video Share call and

proceed to a voice call by

1. Touching [Stop] Icon

5.2. End a voice call along with the

Video Share call by

1. Pressing [END] Key

2. Selecting > [End Call•

Note

1. A Video Share Call will be

terminated in the following cases:

• When trying to make a conference

call/second call during a Video

Share Call.

• When the voice call is placed on

hold.

• When the voice call is

disconnected.

• When moving out of an AT&T 3G

service area.

• When the network connection is

poor.

2. A Video Share Call will be unavailable

in the following cases (“Video Share

Ready” message will not appear).

• When trying to make a conference

call/second call during a Video

Share Call.

• When the voice call is placed on

hold.

• When moving out of an AT&T 3G

service area.

Answering a Video Share Call

1. Touch [Accept• when you receive

a prompt asking “The other party

wants to share Video Share with

you” appears, to start the Video

Share Call. Touch [Decline• to

decline the Video Share call. (Note

that after accepting the call, it may

take several seconds before the

Video Share session starts.)

You can choose from the following:

• Landscape mode: When Landscape

mode is selected you can watch

shared video in landscape mode.

• Aud

Pho

is se

con

you

eith

Note

auto

rever

when

Mak

from

Mod

Whe

can e

a pe

1. S

• I

Note

3G co

capa

Note

Video

ordin

In-Call Menu

able

are

ence

Call

rty

ote

may

ng:

cape

• Audio to Bluetooth

/Audio to

Phone: When Audio to Bluetooth

is selected, you can have a

conversation using Bluetooth

When Audio to Phone is selected,

you can have a conversation using

either speakerphone or headset.

Note : The speakerphone will be

automatically turned on when a Video

Share Call begins, and automatically

reverts back to the previous mode

when a Video Share Call ends.

Making a Video Share Call

from the Video Recording

Mode or Video

When you are Recording Video, you

can easily make a Video Share Call to

a person in your Contact List.

1. Start Video Share call as follows:

• In Record Video Mode, Touch .

• In Video Gallery, touch and

choose Video Share Call.

Note : This menu item is active only in

3G coverage areas and on Video Share

capable devices.

Note : If the other party is not ready for

Video Share, the call will proceed to an

ordinary voice call.

Saving your Video Share

The sender can record video during

the Video Share session by

1. Selecting [Option] > [Record

Video Share] during a live Video

Share call.

2. Setting Auto Record to ‘ON’

(See Application Settings).

Sender can save the recorded

video by

1. Selecting [Option] > [Stop

Recording] during a live Video

Share call.

2. Ending Video Share call.

Recorded video will be saved in [My

Stuff] > [Videos] folder in the phone.

Conference Calls

The conference service provides

you with the ability to have a

simultaneous conversation with

more than one caller. The conference

call feature can be used only if your

network service provider supports

this feature.

Once a conference call is set up,

calls may be added, disconnected or

separated (that is, removed from the

conference call but still connected to

LG GS390 | User Guide

you) by the person who set up the

conference call. These options are all

available from the In-Call menu.

The maximum number of callers in a

conference call is five. Once started,

you are in control of the conference

call, and only you can add calls to

the conference call.

Making a Second Call

You can make a second call while

currently on a call simply by

accessing the Dial Pad, from the

In-Call Menu, entering the second

number and pressing the

[SEND] key. When the second

call is connected, the first call is

automatically placed on hold. You

can swap between calls by pressing

the [SEND] key.

Setting Up a Conference Call

To set up a conference call, place

the first call. Once that is connected,

follow the steps above to make a

second call. You can then join the

two separate calls by touching

and select the Join Calls from the

Conference Call menu.

Activate the Conference Call

on Hold

To activate a conference call on hold,

press the key.

Adding Calls to the

Conference Call

To add a call to an existing

conference call, touch and

then select the Join Calls from the

Conference Call option.

Private Call in a Conference

Call

To have a private call with one caller

from a conference call, touch

and select Private Call from the

Conference Call option. When the

numbers of the callers are displayed,

select the one you wish to speak in

private with. Only the person who

initiates the Conference Call can

initiate a Private Call.

Ending a Conference Call

The currently active conference call

can be disconnected by pressing the

key.

In-Call Menu Yo

From

optio

the s

man

Tou

The

place

touc

To se

accu

to vi

you’v

To sc

item

the s

• The

tou

pick

• Use

the

not

all

hold,

aller

yed,

call

the

Your Standby Screen

From here you can access all menu

options, make a quick call and view

the status of your phone - as well as

many other things.

Touch Screen Tips

The standby screen is also a great

place to get accustomed to the

touch screen.

To select an item, touch the icon

accurately. Your LG GS390 can be set

to vibrate slightly when it recognises

you’ve touched an option.

To scroll through lists, touch the last

item visible and slide your finger up

the screen. The list will move up so

more items are visible.

• There’s no need to press hard, the

touchscreen is sensitive enough to

pick up on a light yet firm touch.

• Use the tip of your finger to touch

the option you require. Be careful

not to touch any other keys.

• When the screen light is off, press

the key on the right hand

side twice to restore the standby

screen.

• Don’t cover the phone with a

case or cover as the touch screen

will not work with any material

covering it.

LG GS390 | User Guide

The Quick Keys

The quick keys on your standby screen provide easy, one-touch access to

your most used functions.

Touch to bring up the

touch dialling pad to

make a call. Input the

number as you would

using a normal key pad

and touch or

press the hard

key.

Touch to open your

contacts and search for

the number you want to

call. You can also create

new contacts and edit

existing ones.

Touch to access the

Messaging options

menu. From here

you can create a new

outgoing Message.

Touch to open the

full Top menu which

is separated into four

sub-menus. Touch the

vertical tabs to view

further options.

Hom

Allow

add

• Clic

• Dra

will

• You

che

set

from

Hom

• Clic

Scre

Your Standby Screen

t to

Home Screen

Allows you to use Widgets and even

add them to your Home screen.

• Click to open the Home Screen.

• Drag a Widget from the roll-out

Menu onto the Home screen. This

will enable you to use Widgets.

• You can play songs, add memos,

check the calendar, play slide show,

set an alarm or add events directly

from the standby screen using

Home Screen.

• Click again to close the Home

Screen.

LG GS390 | User Guide

Touch in the standby screen to open a Top menu.

Menu Tree

Phone

AT&T Social Net

Messaging

Recent History

Mobile Web

AppCenter

AT&T Music

Address Book

Mobile Email

My Sutff

Audio

Memory Card

Other Files

Pictures

Tools

Video

Games and Apps

Games

Applications

SETTINGS

Audio & Ringtones

Phone settings

Display

Touch

Call

Connection

Memory

Application Settings

Phone Information

M e

This

to SM

MMS

voice

servi

New

1. In

2. To

Note

audio

mess

up to

activ

time

you w

mess

Edit

The f

whe

• Sym

ran

and

wan

scro

sym

Messaging

This menu includes functions related

to SMS (Short Message Service),

MMS (Multimedia Message Service),

voice mail as well as the network's

service messages.

New Message

1. In the standby screen, select .

2. Touch Create Message.

Note : If you attach a graphic or an

audio file while writing a multimedia

message, the file loading time can take

up to 5 seconds. You will not be able to

activate any key during the file loading

time. When the file loading is complete,

you will be able to write a multimedia

message.

Editing a message

The following options are available

when Editing a Message.

• Symbol: You can insert symbols

ranging from sentence notes to

emoticons. Touching the twice,

and you can select the symbols you

want. You can use and to

scroll through the various pages of

symbols.

Inserting Multimedia files in

outgoing messages is easy. Press the

button and select an option

from below:

• Picture: You can preview

the selected picture. Touch

to insert the

selected picture.

• Audio: You can insert from your

saved Audio files.

• Video: You can insert from your

saved Video clips.

• New Picture: You can insert a new

image taken from the camera by

touching [Capture].

Note : Refer to page 77 for camera

options.

LG GS390 | User Guide

• New Audio: You can record a new

audio clip by touching .

• Record Mode: MMS mode

record time is about 6 minutes

and the General mode

provides a longer recording

time.

• Quality: Set the audio quality

to Fine, Normal or Economy.

• Select Storage Defaults: You

can assign the default storage

to Phone Memory or Memory

Card.

• New Video: You can record a new

video. The options are similar to

those when inserting a New Picture.

• Template

- Text: You can easily insert

frequently used sentences in the

text message.

- Multimedia: Preset multimedia

templates are available.

- Signature: Input your own

created signature. For further

details, see page 52.

• More: Allows you to insert Subject,

vCard, vCalendar, vNote, vTask or

Contact.

Note : vCard, vCalendar, vNote, vTask

and Contact are created by the Address

Book, Calendar, Notepad and Tasks

functions. Go to the corresponding

sections for more detailed information.

Using Options

Touch to use the options below.

• Text Entry Settings

- Text Entry Language: Allows you

to set the text entry language

to English, Français, Español or

Korean.

- Show/Hide Candidate List: When

in T9 Entry Mode, you can see the

word candidates as you type.

- Show/Hide Next Word

- T9 Dictionary: Here you can add/

delete/reset/modify words to the

T9 Dictionary.

• Delivery Options

- Delivery Receipt: If this is set to

On in this menu, you can check

whether your message was sent

successfully.

- Read Receipt: You can set this to

On or Off.

Messaging

• Sav

• Wri

Fon

Lar

• Can

the

inp

Send

Afte

the I

send

• Ent

can

- En

- C

- R

- D

dress

ion.

ow.

you

hen

the

dd/

the

t to

eck

ent

is to

• Save to Drafts: Saves the selected

message to Drafts.

• Writing Font Size: Set the writing

Font size to Small, Medium and

Large.

• Cancel Message: Allows you to exit

the Message without saving your

input message.

Sending a Message

After completing a message using

the Insert/Options, select Send To to

send a message.

• Enter the recipient(s). From , you

can choose an option item below.

- Enter Number: You can input the

recipient(s) number using the

Touch keypad or Qwerty keypad.

- Enter Email: You can enter an

Email address instead of a phone

number.

- Caller Groups: Displays Contact

Groups.

- Recent Messages: Choose a

contact from recent messages.

- Recent Calls: Choose a contact

from recent calls.

- Delivery Options: Options of

Delivery Receipt, Read Receipt,

Add Cc, and Add Bcc.

- Edit Message: Go back to the

message editing mode.

- Save to Drafts: Saves the selected

message to Drafts.

- Text Entry Settings: This menu

allows you to set the text entry

Language. It also allows you to

Show/Hide Candidate, Show/

Hide Next Word and access the

T9 Dictionary to delete/add/

modify words.

- Cancel Message: You can cancel

the message.

Message folders

The folder structure on your LG

GS390 was designed to be fast and

easy to use.

• Inbox: All the messsages you

receive are placed into your Inbox.

• Drafts: If you don’t have time to

finish writing a message, you can

save what you’ve done so far here.

• Outbox: This is a temporary storage

folder where messages are stored

while being sent.

Note : If you see the message “No space

for USIM messages”, then you should

delete some messages from your Inbox.

If you see the message “No space for

LG GS390 | User Guide

messages”, then you can delete either

messages or saved files to create space.

Inbox

You will be alerted when you receive

a message. They will be stored in the

Inbox. In the Inbox, you can identify

each message by icons. To reach

the Inbox, from the Standby screen,

touch and touch Inbox.

The following options are available

when you select a message and

touch .

Conversation View

This mode allows you to view all

messages with each contact in

conversational order.

Choose to see messages

in detail or choose for the

simple view.

Standard View

The following options are available

in standard view:

• Add to Address Book: You can save

the sender's phone number in the

Contact List.

• Select Slide: If the multimedia

message has more than one slide,

you can select and move to the

desired slide.

• Extract Data: You can make a voice

call or send a message. You can

save the number As New contact or

Updating Existing.

• Message Details: You can view

information about received

messages; message Type, Subject,

Sender's address, and message

Time.

The following Options are available

in Inbox folder.

• Delete: You can pick a message and

delete it.

• Standard/Conversation View:

You can select between the two

viewing modes.

• Sort By: You can sort all messages

by Name, Title, Date and Read/

Unread.

• Delete All Read Messages: You can

delete all read messages.

Drafts

You can view the messages saved as

drafts. To see the Drafts folder, touch

the . Quick key from the Standby

screen, then touch Drafts.

Messaging

Out

Outb

for m

Whe

key,

num

the s

If the

Outb

alert

Failu

attem

the f

unsu

will n

In or

that

Afte

attem

Send

tryin

the m

Send

Outb

send

sent

avail

• Del

cho

oice

ct or

ct,

ble

and

can

d as

uch

dby

Outbox

Outbox is a temporary storage place

for messages waiting to be sent.

When you press the [SEND]

key, you can make a call to the

number of the recipient number of

the selected message.

If the message is not sent from the

Outbox, you will receive a sound

alert along with a Message Sending

Failure notice on the screen. Another

attempt will be made to send

the failed message and after two

unsuccessful attempts, the message

will no longer be sent automatically.

In order to send the message

that has failed, you must touch

to resend the message.

After the maximum number of Send

attempts has been reached, the

Send function has failed. If you were

trying to send a text message, open

the message and check that the

Sending options are correct.

Outbox list will display messages in

sending failed, sending or waiting,

sent order. Touch to use options

available from Outbox list.

• Delete: Deletes a message you

choose.

• Sort by: Sorts by name, title and

date.

• Delete All: Delete all messages.

Those options are available when

you choose a message in Outbox.

• View Status: Shows message status

as failed, sent or error.

• Edit: Allows you to edit the selected

message.

• Select slide: If the multimedia

message has more than one slide,

you can select and move to the

desired slide.

• View Attachment: View attachment

of the message.

• Message Details: Allows you

to view the information on the

message.

Voicemail

This menu provides you with a quick

way of accessing your voice mailbox

(if provided by your network).

Note : Please check with your network

service provider for details of their

service in order to configure the

handset accordingly.

LG GS390 | User Guide

Message Settings

To configure Messaging settings,

touch the Quick key from the

Standby screen, then touch Message

Settings.

Message Alert

You can set the Sounds and Alert

Type here.

Save to

Choose between Phone and SIM

Card to save message.

Signature

This feature allows you to create your

Text signature. You can use symbols,

templates and contacts as part of

the signature.

Text Message

• Text Template

There are 6 predefined messages

in the list. You can view and edit

the template messages or create

new ones.

The following options are available

when you touch .

- Add New: Allows you to create a

new template.

- Delete: Allows you to delete the

selected template message.

- Delete All: Deletes all messages

in the folder.

To edit an existing Template, touch

it (to open) then touch the text.

The Edit Template screen will

automatically open.

• Message Subject: You can enter

SMS Subject when this menu is

ON. You can switch between

to by dragging it from left

to right.

• Insert Signature: Insert signature

you created.

Multimedia Message

• Multimedia Templates: Multimedia

templates are available and can be

created here.

• Priority: You can choose to set the

priority of the message.

• Message Subject: You can enter

the MMS Subject when this option

is .

You can switch between to

by dragging it from left to

right.

• Validity Period: This network

service allows you to decide how

Messaging

lon

• Sen

to s

for

• Sen

sen

• Dow

- D

• Me

ont

Voic

This

voice

featu

chec

servi

hand

edia

the

ion

long your multimedia messages will

be stored at the message center.

• Send Delivery Receipt: Allows you

to send a delivery confirmation mail

for a Multimedia Message.

• Send Read Receipt: Allows you to

send a message read confirmation

mail for a Multimedia Message.

• Download Options

- Download Without Ask: Allows

Multimedia Messages to be

downloaded automatically.

- Ask Always: You can download a

multimedia message manually.

- Discard: Used when the

user rejects download of the

Multimedia Message.

• Message Center: The details for the

Multimedia gateway are pre-loaded

onto your handset and should not

be changed.

Voicemail Number

This menu allows you to set the

voicemail center number if this

feature is supported by AT&T. Please

check with AT&T for details of their

service in order to configure the

handset correctly.

Service Message

You can set the Service option to

determine whether or not you will

receive service messages.

Offline Menu

This allows users to login by filling in

the User ID and Password.

Note :Once the User ID and Password

are saved, you will not be required to

type them in again during the Login

process. This feature is optional.

Saved Conversations

This is where a user can view saved

conversations.

• Offline Conversations: This is

where a user can view offline

conversations.

Settings/Preferences

• Set Sound: Allows you to turn

alerts

On/Off for a Contact when they

have activity on their session.

• Network: You may check your

Network Profiles or Server Address

information.

LG GS390 | User Guide

IM Information

This displays the Instant Messaging

Client Information such as Client

Name and Version Number.

Online Menu /

1-to-1 conversation

After a successful Login, a list of

contacts with Screen Names will

appear on the screen. Touch and

hold each item, it will show various

menu pop up.

General Options

Touch .

• My Status: Allows you to set your

status to Available, Busy or Invisible.

• Add a Contact: This adds a new

contact to the selected contacts

list; contacts are searched on the

basis of Email Address. First Name

or Last Name.

• Send Message to: Allows you to

send a message to someone by

inputting an email address.

• Block List: Displays the list of all

blocked Contacts.

• Saved Conversations: This is

where a user can view saved

conversations.

Messaging

• Set

- D

- M

- O

- Se

- A

Touc

• End

the

unk

tha

ible.

• Settings:

- Display Name

- My Status: Allows you to set

your status to Available, Busy or

Invisible

- Offline Contacts

- Set Sound: Allows you to turn

on/off an alert for the Contact

when they have activity on their

session

- Auto Sign In

Touch and hold a conversation.

• End Conversation: This closes

the selected conversation. If an

unknown contact was selected,

that contact is deleted.

• Block/Unblock Contact: This allows

you to block/unblock the selected

Conversations Contact.

• Contact Info: This allows you to

view the User ID and Status Text

information.

Touch and hold the contact List.

• Refresh: This refreshes the current

information on the contacts within

the list.

LG GS390 | User Guide

Touch and hold a contact.

• Delete Contact: This deletes the

selected Contact.

• Move Contact: Allows you to move

a Contact to another Contact List.

• Block/Unblock Contact: This

allows you to block/unblock a

conversation with the selected

Contact.

• Contact Info: This allows you to

view information. It provides User

ID, Status Text.

Menu options available in the

Conversation screen

• Insert: You can insert a Symbol,

Template and emoticons in the

conversation screen. This feature

is accessed by pressing the left

soft key.

• Back to Contacts: This brings the

screen back to the contacts.

• My Communities: Displays the list

of Email providers.

• Block/Unblock Contact: This

allows you to block/unblock a

conversation with the selected

Contact.

• Add to Contact List: Allows you to

add the person you are currently

having a conversation with to a

Contact List.

• Save Conversation: Stores the

currently active conversation.

• End Conversation: This ends the

active conversation and clears the

conversation buffer.

Messaging

• Set

- D

- M

- O

- Se

- A

• Tex

inp

T9 a

• Tex

sele

Lan

you

to a

Ent

• Min

win

• Sig

pro

the

list

• Settings:

- Display Name

- My Status: Allows you to set

your status to Available, Busy or

Invisible.

- Offline Contacts

- Set Sound: Allows you to turn

on/off an alert for the Contact

when they have activity on their

session.

- Auto Sign In

• Text Entry Mode: Sets the text

input mode such as abc, Abc, ABC,

T9 abc, T9 Abc, T9 ABC and 123.

• Text Entry Mode Settings: This

selects the T9 predictive mode

Language. This feature also allows

you to turn T9 mode on or off, and

to access the T9 Dictionary, Text

Entry Language.

• Minimize: Minimizes the IM

window and returns to standby

mode.

• Sign Out: This begins the logout

process.

Note

• In the conversation window, you can

use the up/down Qwerty keys to scroll

through the conversation.

• The maximum number of characters

supported by a message is 800

characters, for receiving, and 127

characters for sending.

• The current information might not

update in real time so the "Refresh

List"/"Refresh Contact” option can be

used for the most up to date status.

Mobile Email

Mobile Email allows you to access

your Yahoo! Mail, AOL Mail, AIM Mail,

Windows Live Hotmail, AT&T Yahoo!,

BellSouth Mail and Other providers

accounts on your phone. So, now

you can quickly and easily check

your email while you are away from

your computer.

LG GS390 | User Guide

To Set Up Mobile Email

• Open Mobile Email: From the

standby screen, Touch , and

touch .

• Select an Email Provider: Touch the

email provider you wish to use.

• Read and Accept the Terms of Use

• Log In

1. Highlight the ID entry field,

touch and then type in your

existing email ID.

2. Touch the Password field, to

highlight it, and enter your

password.

Quick Tip: Your password is case

sensitive. Press the button

on the keypad to change to lower

case or upper case.

3. To save your password scroll

down to Remember Me and

press down on the select to

check the box.

4. Select Sign In.

• Opening an Email: Just scroll down

and press on the subject line to

highlight the message you want to

open, then press again to open the

message. When the email is open,

select Options to reply, forward

or delete.

• Deleting an Email: Scroll down to

the email you want to delete, touch

the subject line to highlight it, press

Options, and then Delete.

Messaging Mo

This

the h

in th

defa

hom

This

the I

brow

MEd

prov

acce

do w

Note

servi

netw

prov

use. S

you i

servi

Pleas

open

To la

mod

choo

Touc

Once

disp

time

own

t to

the

en,

ouch

press

Mobile Web

This browser connects you to

the homepage, which is defined

in the activated account. The

default account connects to AT&T’s

homepage.

This menu shows how to access

the Internet by launching the WAP

browser.

MEdia Net is one of the services

provided by AT&T and it gives you

access to all the cool things you can

do with your wireless phone.

Note : Check the availability of WAP

services, pricing and tariffs with your

network operator and/or the service

provider whose service you wish to

use. Service providers will also give

you instructions on how to use their

services.

Please contact your service provider to

open an Internet account.

To launch the browser in Standby

mode, touch the Quick key then

choose the tab .

Touch .

Once connected, the homepage is

displayed. To exit the browser at any

time, press the key.

Menus for the Browser

You can surf the Internet using either

the touch screen or the qwertykey

pads.

Using the WAP Browser Menu

Using the Browser Tool Bar

Bookmark

Zoom

Refresh/Stop

Back

Forward

• Back : Moves to the previous

page.

• Forward : Moves to the next

page.

• Refresh/Stop : Loads the current

page again. When a page is loading,

press to stop loading the current

page.

LG GS390 | User Guide

• Bookmarks : Takes you to your

Bookmark menu. Holding down

this key will add the current page to

your saved Bookmarks.

• Zoom : Displays the Zoom bar

to Zoom in and out while browsing.

Once you are connected to the

Internet, the following menu options

are available as buttons or through

the Options menu :

Note : If you are browsing the Internet

in Landscape mode, you can access

the Options Menu by tapping any part

of the browser screen that does not

contain a link.

• Home: Moves to the initial

homepage.

• Windows: Create, manage or view

different browser windows. This

allows you to access multiple web

pages simultaneously.

• EnterURL: Connects to the specific

URL after editing.

• Bookmarks: You can add or save

the current page to Bookmark

or view the list saved under

Bookmark.

• View Full Screen/View Normal

Screen: Hold your phone

horizontally and you can view

full screen, If you hold the phone

vertically, you can view normal

screen.

• Search Text: You can search the text

what you want to find.

• Recent Pages: You can manage

the list of the Internet pages you

visited.

• Settings: Allows you to set options

such as Full Screen View, Cache,

Cookie and other Browser Settings.

• Help: Help for browser menu and

options

• Exit: Exit browser

To la

Stan

key

touc

Rin

This

ringt

Note

when

AT&T

Gam

This

gam

user

gam

Note

when

AT&T

Col

This

grap

Note

when

AT&T

Mobile Web

text

ons

ngs.

AppCenter

MEdia Mall

To launch MEdia Mall while in the

Standby screen, touch the Quick

key , touch tab and then

touch .

Ringtones

This menu option connects to AT&T’s

ringtone download site.

Note : Additional charges may incur

when downloading ringtones. Contact

AT&T for additional information.

Games

This menu option connects to AT&T’s

game download site. This allows

users to download the various

games by connecting to the Internet.

Note :Additional charges may incur

when downloading games. Contact

AT&T for additional information.

Color Graphics

This menu option connects to AT&T’s

graphics download site.

Note: Additional charges may incur

when downloading graphics. Contact

AT&T for additional information.

Multimedia Store

This allows you to connect to AT&T’s

multimedia download site.

Note : Additional charges may incur

when downloading multimedia

contents. Contact AT&T for additional

information.

Cool Tools/Apps

This menu option connects to AT&T’s

application download site. This

allows users to download the various

applications by connecting to the

Internet.

Note : Additional charges may incur

when downloading applications.

Contact AT&T for additional

information.

Videos

This menu option connects to AT&T’s

video download site.

Note : Additional charges may incur

when downloading applications.

Contact AT&T for additional

information.

LG GS390 | User Guide

MEdia Net Home

This connects to the homepage,

which is defined in the activated

account. The default account

connects to AT&T’s homepage.

To la

Stan

key

touc

• All

son

• Pla

play

• Art

all t

and

cho

• Alb

of a

libr

a ch

• Gen

all t

and

gen

• Shu

son

shu

Note

prote

prop

adhe

of m

or co

AppCenter

AT&T Music

Music Player

To launch AT&T Music while in

Standby mode, touch the Quick

key , touch tab and then

touch .

• All Songs: You can view all the

songs in your music library.

• Playlists: You can make your own

playlists.

• Artists: Shows the list of artists of

all the songs in your music library,

and shows all the songs by a

chosen artist.

• Albums: Shows the list of albums

of all the songs in your music

library, and shows all the songs on

a chosen album.

• Genres: Shows the list of genres of

all the songs in your music library,

and shows all songs of a specific

genre.

• Shuffle songs: You can view all the

songs in your music library with

shuffle.

Note : Copyrights of music files may be

protected by copyright and intellectual

property laws. Please ensure that you

adhere to the applicable Terms of Use

of materials laws prior to downloading

or copying files.

Playing Music

To listen to music in your phone or

the external memory, follow these

quick easy steps:

1. From the Standby screen, touch

then open the Multimedia

tab by touching .

2. Then touch .

3. Select Music Player to view your

options. You can select from All

Songs, Playlists, Artists, Albums,

Genres and Shuffle songs to select

your Music. The Now Playing

menu will be only available when

music is playing.

• Touch the song you wish to play.

LG GS390 | User Guide

• Touch to pause the selected

song. While playing, touch to

adjust the volume. Touch and

to skip to the next song or

previous song.

• Touch to Minimize the music

player and access other phone

functions while music is playing.

Note :Files under 300kb may not be

displayed in this function and may be

categorized as Ringtones.

Adding Music To Your

Handset

Music files can be added to your

handset by using one or more of the

following methods:

• Download music and ringtones

over the AT&T network directly to

your device via the Shop Music link

in the AT&T Music Folder or the

Ringtones link in the AT&T MEdia

Mall folder.

• From your existing digital media

collection on your PC via Windows

Media

Player and/or Windows

Explorer.

• From your PC using other music

subscription services, such as

Napster or eMusic.

Purchasing and downloading

Music directly to your Device

1. Touch then touch .

2. Touch .

3. Select Shop Music.

4. Navigate the Shop Music page to

download today’s hottest music,

ringtones and other personalized

content directly to your phone.

Note : Some sites are data intensive

(i.e. previews via streaming) so the user

should be enrolled in an unlimited data

plan before using these services to

avoid per-use data charges.

Note : Additional charges may apply

when downloading music, ringtones

etc.

Note : mid, wav, mp3, aac, imy files

under 300 kb can be set as ringtone.

Tran

you

Befo

To tr

to yo

follo

• Win

abo

Nap

• A m

(sup

• USB

* mic

sol

wir

Note

with

AT&T Music

ing

ice

e to

sic,

zed

user

data

Transferring Music using

your PC

Before You Get Started

To transfer music from your PC

to your device, you will need the

following:

• Windows Media

Player 10 (or

above) or other digital music

management software such as

Napster or eMusic

• A microSD™ card*

(supports up to 16GB cards)

• USB data cable*

* microSD™ card and USB data cable

sold separately; go to att.com/

wireless for details.

Note : This device is not compatible

with iTunes and/or iTunes files.

Transferring Music from the

Digital Music Service

1. Using your computer, open your

preferred PC music management

client.

2. Download the selected song to

your library.

3. Make sure the microSD™ card

is inserted properly into the

handset.

4. Use the USB adapter cable to

connect the handset to the PC.

When you try to connect handset

on your PC, the handset displays

“Connecting as Music Sync...”.

5. Once the USB connection has

been established, the handset

displays “Connected as Music Sync

Mode. Do not disconnect during

transfer.“ and the computer screen

then shows the LG GS390 device.

If the detection does not occur,

skip to Changing USB Connection

Settings section on page 71.

6. Follow the instruction in the

program to transfer music to your

handset.

Note : If you have a USB hub, connect

the handset directly to your computer

rather than through the hub.

LG GS390 | User Guide

Transferring Music using

Windows Media Player

1. Open Windows Media

Player on

your computer (version 10.0 or

higher).

2. Use the USB adapter cable to

connect the handset to the PC.

When you try to connect handset

on your PC, the handset displays

“Connecting as Music Sync...”.

3. Once the USB connection has

been established, the handset

displays “Connected as Music Sync

Mode. Do not disconnect during

transfer.“ and the computer screen

then shows the LG GS390 device.

Note : If the target computer does not

detect the newly connected handset or

provide an MTP Player dialog window

on the PC screen, skip to Changing

USB Connection Settings section on

page 71.

4. From within the Windows Media

Player application, click on the

Sync tab. Previously downloaded

songs are then listed on the left

side of the application.

5. Choose the destination location

for the media files. The LG GS390

Music Sync Player appears in a

drop-down list on the right side of

the screen.

Note : If there are no items present in

the playlist, click the Edit Playlist button

and begin adding the music files from

among the various media categories.

6. Click on the checkmark boxes

(to the left of the song entry)

to select the song you want to

synchronize to your handset.

7. Click the Start Sync button to

download the selected songs to

your handset.

A “synchronization in progress”

message appears on the

application. Do not unplug the

handset during this process. Once

complete, the progress bar will

disappear.

8. It is now safe to unplug the USB

connector from the handset.

Drag

LG G

Dev

1. M

2. Co

3. A

“F

4. Ac

5. Th

Note

a driv

7. Fi

8. D

9. D

10. A

AT&T Music

de of

utton

es.

”

Once

Drag and Drop Music Using

LG GS390 As A Mass Storage

Device

1. Make sure the microSD™ card

is inserted properly into the

headset.

2. Connect the device to a PC using

a LG GS390 USB data cable.

3. A bubble may appear on the PC,

“Found New Hardware LG USB

Modem”.

4. Access My Computer on the PC.

5. The phone’s memory card will

be listed under “Devices with

Removable Storage” in the same

location as an optical drive.

Note : The PC will automatically assign

a drive letter.

7. File explore in a new window for

desired music files.

8. Drag and drop the desired music

content from the PC window to

the “Storage Card” window.

9. Disconnect the device from the

cable.

10. Access the Music Player on the

phone.

Note : If the target computer does not

detect the newly connected handset

as Mass Storage, skip to Changing USB

Connection Settings section below.

Changing USB Connection

Settings

1. Touch and touch the tab .

2. Touch .

3. Select Connection.

4. Touch USB Connection Mode.

5. Touch Music Sync (if using

Windows Media

Player or other

Digital Music Services) or Mass

Storage (if you are going to drag

or drop files).

6. Reconnect the device to a PC.

Deleting Music Files

The following are the three options

available to delete Music from your

Phone:

1. Delete a file using Mass Storage,

but not using Music sync function.

2. Delete a file by directly inserting

the microSD™ external memory

onto the PC.

3. Delete a file using delete function

on the phone.

LG GS390 | User Guide

Note : If you delete a playlist from the

phone, the songs in the playlist will not

be removed and remain in All songs

folder.

Do your file operations like Delete,

Move and Copy using Music Sync.

Note : Be aware that all of the existing

data will be erased on microSD™ card if

you use the below process.

• Use the Settings > Phone > Reset

Settings > Master Clear > Memory

Card function in the Settings menu.

• Format external memory using Mass

Storage.

Additional Music Services

There may be other AT&T music

applications preloaded or available

for your phone that allow you to:

• Identify the name, artist and album

to a song from a song sample.

• Listen to the latest Hip Hop, R&B,

Rock, Jazz, or Country streaming

commercial-free radio channels,

anywhere you go.

• View the latest music videos.

• View music news and information.

• Cut custom-made ringtones from

the favorite parts of your favorite

songs, etc.

Note : Some sites are data intensive

(i.e. previews via streaming) so the user

should be enrolled in an unlimited data

plan before using these services to

avoid per-use data charges.

Note : Additional charges may apply for

downloading content or use of these

services.

The

only

netw

such

Yaho

Mess

Passw

to lo

well

To ac

1. To

2. Yo

AT&T Music

user

data

y for

The Instant Messaging feature can

only be used with the support of the

network operator or communities

such as AIM

, Windows Live™ and

Yahoo!

Messenger. For Instant

Messaging users, a valid User ID and

Password will be required in order

to login and exchange messages as

well as checking the online status.

To access the IM feature

1. Touch and touch .

2. You can see available IM clients.

The menu items below might not

appear as not all IM communities

support the various options. In

addition, the menu strings may

appear differently. This depends

on the selected IM communities.

The keywords such as User ID,

as general terms in IM menus

according to the currently

selected communities such as

AIM

, Windows Live™ and Yahoo!

Messenger

LG GS390 | User Guide

Multimedia

Camera

Touch , then choose tab.

Touch .

Take Photo

Using the camera module built into

your phone, you can take pictures of

people or events while on the move.

Additionally, you can send photos to

other people in a picture message.

Press to go to camera mode

directly. Or choose from the

tab.

Gett

Getting to know the viewfinder

Settings: Touch this icon to

open the settings menu. See

Using the advanced settings

on page 78 for details.

Camera mode: Camera

mode is selected.

Flash status

Image Size

Back: Touch here to return to

the previous screen.

Flash

Album

Capture: Take the picture

Video camera mode: Toggle

between camera to video

camera mode.

Zoom Bar: Allows you to

zoom in and out when

taking a picture. This option

is only available when taking

pictures in the 640*480 or

320*240 resolution.

Note! The shortcut options disappear after a few seconds automatically.

To recall the options, touch the screen again.

LG GS390 | User Guide

Settings Menu

Preview tab

• View Mode: Choose between Full

Image and Full Screen.

• Image Size: The resolution of

the image can be captured in

1600*1200 / 1280*960 / 640*480

/ 320*240.

• Brightness: Adjust brightness by

adjusting slider.

• Color Effects: Includes options of

Color/Mono/Sepia/Negative/Blue.

• White Balance: Set the White

Balance as Auto/Daylight/Cloudy/

Illuminate/Indoors.

• Night Mode: This is useful to take a

photo at dark place.

• Timer: Set the Timer can be set

to Off/3 Seconds/5 Seconds/

10 Seconds.

• Image Quality: Set the image

quality as Super Fine/Fine/Normal.

• Continuous Shot: This is great for

taking photos of moving objects

or at sporting events. Allows you

to set 3 shots, 6 shots or 9 shots

continuously.

Others tab

• Video Share: You can make a Video

Share Call. For more details, refer to

Video Share Calling (page 29).

• Save to: Choose to save a photo to

Phone or Memory Card.

• Shutter Tones: Can be set to

Tone 1/Tone 2/Tone 3/Off.

• Reset Settings: Allows you to set to

the default settings.

Note : In Take Photo mode, you can

adjust the zoom scale by moving the

slider. The maximum zoom levels

depend on the resolution as follows.

Resolution Zoom scale

1600*1200 Level 1

1280*960 Level 1

640*480 Level 1 ~ Level 10

320*240 Level 1 ~ Level 10

Rec

Whe

takin

Gett

Multimedia

deo

er to

o to

et to

Record Video

When recording video, you have many of the same Settings options as with

taking a photo. One additional option is using Video Share:

Getting to know the viewfinder

Settings: Touch this icon to

open the settings menu.

Video mode: Video mode is

selected.

Flash status

Video Size

Back: Touch here to return

to the standby screen.

Flash

Album

Recording start

Zoom: Touch to zoom

in or to zoom out.

Alternatively you can use

the side volume keys.

Camera mode: Change

from video camera to

camera mode.

Video Share: You can make

a Video Share Call. For more

details, refer to Video Share

Calling (page 29).

LG GS390 | User Guide

Settings Menu

Preview Tab

• Video Size: Sets the size of video to

320*240 or 176*144. The selected

size appears on the capture screen.

• Brightness: Adjust brightness by

adjusting slider.

• Color Effects: Includes options of

Color/Mono/Sepia/Negative/Blue.

• White Balance: Set the White

Balance as Auto/Daylight/Cloudy/

Illuminate/Indoors.

• Night Mode: This is useful to take a

photo at dark place.

• Video Quality: Determines the

quality of a video clip. Includes

options for Super Fine/Fine/Normal.

• Type: Use one of the recording

duration presets, made for different

purposes. General/Video Share/

MMS Mode.

Others Tab

• Save to: Choose to save a video clip

to Phone or Memory Card.

• Voice: Mute or unmute the voice.

• Recording Tones: Set Recording

Tones On or Off.

• Reset Settings: Allows you to set to

the default settings.

Note : In Video Record mode, you

can adjust the zoom scale by moving

the slider. The maximum zoom levels

depend on the resolution as follows.

Resolution Zoom scale

320*240 Level 1 ~ Level 10

176*144 Level 1 ~ Level 10

Alb

You

your

avail

One

Show

Touc

touc

RSS

With

and

with

avail

• Upd

fee

• Upd

fee

• New

fee

• Mo

fold

• Del

sele

Multimedia

clip

et to

els

Album

You can view the Album containing

your Pictures and Videos. For more

available options, touch .

One by One View/Sort by/Send/

Print via Bluetooth/Delete/Slide

Show/Delete All.

Web Pages

Touch then choose tab and

touch .

RSS Reader

With this function, you can open

and view files created in the format

with RSS. The following options are

available with the menu.

• Update: You can update one RSS

feed if you can access the network.

• Update all: You can update RSS

feeds with just one click.

• New RSS Feed: You can add an RSS

feed manually.

• Move: Move a RSS feed to another

folder which you added manually.

• Delete: Allows you to erase the

selected RSS feed.

• Send URL: Allows the RSS

information to be sent via SMS to

another person.

• New Folder: Add a new folder

manually.

• Update schedule: You can change

the schedule for updating RSS

feeds.

• Delete All: Delete all RSS feed.

Bookmarks

This function allows you to store and

edit frequently accessed sites.

The following options are available

with the menu.

• New Bookmark: Add a new

bookmark manually.

• Send URL: Allows the bookmark

information to be sent via SMS to

another person.

LG GS390 | User Guide

• New Folder: Allows you to add a

new folder, manually.

• List View: You can view the preset

bookmarks list.

< Portrait View >

Note : Pre-installed bookmarks cannot

be deleted or edited by users.

In order to change the text input mode

for symbol input, please refer to the

General Functions section.

Saved Pages

This saves the page on display as an

offline file. A maximum of 20 pages

can be saved.

Recent Pages

You can view a list of some of the

pages recently visited.

My Stuff

Aud

Touc

choo

• Sho

con

dow

• Ans

sho

rela

• Voi

you

• You

the

Pict

Touc

choo

This

whe

•

AT&

•

can

sele

• You

the

Audio

Touch and the tab, then

choose .

• Shop Tones: This menu option

connects to AT&T’s ringtone

download site.

• Answer Tones: This menu option

shows the list of the sites which is

related with AT&T’s answer tone.

• Voice Recorder: You can record

your own audio by touching

• You can view the audio files in

the list.

Pictures

Touch and the tab, then

choose .

This allows you to view pictures

when browsing.

• Shop Graphics: Connects to

AT&T’s graphic download site.

• Take Photo: It takes you to

move to the camera mode.

• Make GIF Animated file: You

can make an animation file with the

selected images in the list.

• You can view the graphic files in

the list.

Tools

From the Standby screen, touch ,

and the tab, then choose .

Video

Touch and the tab, then

choose .

• Shop Videos: You can

download videos.

• Record Video: You can record

your own video.

• You can view the video files in

the list.

Note : DRM sometimes restricts some

functions, such as send and edit.

LG GS390 | User Guide

Voice Recorder

Use the Voice Recorder to record

voice memos or other sounds.

• Settings

• Record Mode: MMS record

mode shortens the time so

that the recording can fit in

an MMS and General mode

provides longer recording

time.

• Quality: Set the audio's quality

to Fine, Normal or Economy.

• Select Storage Defaults: You

can assign the default storage

to Phone Memory or Memory

Card.

• Touch to start recording.

Touch to pause recording.

To continue recording, touch

again. To stop recording,

touch . The recording will

be saved automatically.

• To start a new recording, touch

To play the recording, touch .

To send the recording by Message

or Bluetooth, touch . To delete

the recording, touch and

confirm Yes.

Voic

Voice

whe

reco

voice

requ

user

func

com

Liste

mess

1. Ca

fro

My Stuff

ng.

ill

ete

Voice Command

Voice command is the function

whereby your phone’s voice

recognition engine identifies the

voice of the user and carries out the

requested commands. When the

user operates the voice command

function, there are five possible

commands, call <name or number>,

Listen to voicemail, missed calls,

messages and time and date.

1. Call <Name or Number>: This

function is activated only when

the user says the command "Call"

followed by the name stored in

the Address Book or specified

phone number. The voice engine

inside the handset recognizes

the user's utterance and displays

name lists or phone numbers

from the phone's Address Book.

However, interfering noise might

cause a problem displaying

candidates. Additionally, the user

has the option to superimpose a

number type at the end, such as

"mobile", "home" or "office".

2. Listen Voicemail: this command

is activated when the user says

the words "Listen Voicemail". The

user will then be automatically

connected to voicemail.

3. Missed Calls: this command is

activated when the user says the

words "Missed Calls". The mobile

phone presents missed call lists.

• commands available to user

- yes: make the phone call

- no: moves to the next missed

call list

- cancel: go back to the main voice

command menu

- exit: terminate voice command

4. Messages: this command is

activated when the user says

the word "Messages". The phone

displays details of unread SMS or

MMS messages.

LG GS390 | User Guide

• commands available to user

- yes: make the phone call

- no: moves to the next unread

message

- cancel: go back to the main voice

command menu

- exit: terminate voice command

5. Time & Date: this command is

activated when the user says the

words "time and date". The phone

displays the current local time

and date.

The Voice Command function also

has options accessible by pressing

when in the Voice Command

screen. They are:

• Mode

- Speed: voice command is

abbreviated

- Normal: voice command is played

normally

• Best match

- 1 Match: the most likely match

will be displayed, finding a

number from the Address Book

- 4 Matches: the four most likely

matched names will be displayed,

finding names from the Address

Book

• Sensitivity

- High: Operation and performance

of the voice recognition engine

is rarely affected by the user's

voice command and surrounding

sound.

- Medium: Operation of voice

recognition engine is normally

affected by user's voice command

and surrounding sound.

- Low: Operation of voice

recognition engine is strongly

affected by user's voice command

and surrounding sound.

• Spe

- A

• Cal

- R

- N

Note

You

30 m

1. To

2. To

My Stuff

yed,

ess

ance

ding

mand

• Speakerphone Mode

- Automatic On: When this option

is selected, sound is loud enough

so you can hear the output when

the phone is away from the ear, at

a distance.

- Off: When this option is selected,

sound is quieter, and can only be

heard through the Earpiece.

• Call Alert

- Ring only: Ring repeatedly when

you receive a call.

- Ring After Name: Tells name of

the contact you saved once and

then ring repeatedly when you

receive a call.

- Name Repeat: Tells name of the

contact you saved repeatedly

when you receive a call.

Notepad

You can create up to a maximum of

30 memos.

1. Touch and choose . Touch

and choose Notepad.

2. To create a new Note, touch New

Note, input the memo and touch

to save.

World Clock

The World clock function provides

time information for major cities

worldwide.

Note : The first time you use this

function, you will be asked to enter the

name of your current City.

1. To add a new City from where you

can see the local time, touch

and select New City.

2. Touch the City in the red box, a list

of available cities (in different time

zones) will display. From there you

can select what time zone to add.

• To make it easier, touch and

It will show the Globe. Touch the

continent and choose city you want

to know the time.

LG GS390 | User Guide

• You will see its date and time of

that city on the bottom side of

the screen. Touch and touch

Tasks

This feature allows you to save and

manage a task.

1. Touch .

2. Input Due Date, Note and Priority

for the new Task.

3. Touch to save the

Task item.

The following options are available

by pressing in the main Tasks

menu:

• New Task: Allows you to create a

new task.

• Delete: Opens the menu from

where you can select Tasks to

delete.

• Selective Delete: Allows you to

delete tasks for All Completed/All

Past Tasks selectively.

• Send Task Via: Enables the selected

task to be sent via Text Message/

Multimedia Message/Bluetooth

• View Calendar: The calendar

window will display, from there you

will be able to create New Tasks.

Stop

This

the e

dura

(up t

can a

• New

1. T

2. D

3. Y

4. T

• Sav

reco

• Sho

tak

My Stuff

rity

ble

All

cted

you

Stopwatch

This menu allows you to record

the elapsed time of an event. The

duration of an individual lap time

(up to 20 times) and the total time

can also be displayed.

• New Time

1. To start timing, touch

The running time is displayed as

HH.MM.SS.hh (hours, minutes,

seconds, hundredths of a

second).

2. During the timing, you can

record an individual lap time by

touching . Up to 20 lap

times can be recorded.

3. You can stop timing by touching

or restart by touching

4. To reset the stop watch, touch

• Saved Times: You can see the saved

recorded times.

• Show Last: Displays the last time

taken with the Stop Watch.

Tip Calculator

This feature allows you to quickly

and easily calculate the tip amount

based on the total bill as well as the

split of the total bill based on the

number of people.

Unit Converter

This function converts any

measurement into a unit you want.

There are 6 types of units that can

be converted: Area, Length, Weight,

Temperature, Volume and Velocity.

To input decimal number, touch .

LG GS390 | User Guide

Calendar

When you enter this menu, a

calendar will be displayed. The red

square cursor is used to locate a

particular day. The bottom bar on

the calendar indicates schedule(s)

for that day. This function helps to

remind you of the schedule. The

phone will sound an alarm tone if it

has been set for a specific schedule

item.

The following options are available

when you open the Calendar

function and touch the menu.

• New Schedule: Allows you to add

a new schedule on the date you

select.

• Search: Allows you to search the

saved schedule(s).

• Send Schedule Via: Send your

schedule via text message,

multimedia message or bluetooth.

• Set Holiday: Allows you to set your

personal holiday for the selected

date.

• View All: Allows you to view all

saved schedules.

• Week View: Allows you to change

Calendar view mode from Monthly

View to Week View.

• Go to Date: Allows you to jump to a

specific date.

• Selective Delete: Allows you

to delete Old Schedules or All

Schedules selectively.

• Settings: Allows you set Default

View and Weekly Begin day.

Alarm Clock

The alarm function allows you to set

up multiple separate alarms. You can

also set the time, repetition interval

and alarm sound. Select your desired

alarm setting to configure from the

alarm list. If there is no alarm setting,

• Tim

des

the

is in

to s

tou

• Rep

• Ala

to u

Cen

• Me

• Sno

sno

Min

I Ho

sav

Calc

The

you

divid

oper

Use t

num

My Stuff

thly

to a

set

can

val

sired

ting,

• Time: Select the desired set time

mode using the select. Input your

desired alarm time by specifying

the hour and minutes. If the time

is in the 12 hour format, you have

to select either or by

touching it.

• Repeat: Select the desired repeat

mode using the select.

• Alarm Tone: Select the alarm sound

to use for the alarm using the

Center key.

• Memo: Input alarm name.

• Snooze Interval: You can set the

snooze interval at 5 Minutes, 15

Minutes, 30 Minutes, 45 Minutes or

I Hour. Now, Touch to

save your new Alarm.

Calculator

The calculator function allows

you to add, subtract, multiply and

divide. You can input numbers and

operators using the touch key pad.

Use the touch key to delete

numbers.

Other Files

When you receive files of an

undefined format (such as .vcs, .vcf,

etc.) via email, the files are saved in

this folder.

The following options are available

by touching the menu.

• Send: Send the selected file via

Bluetooth

or MMS.

• Delete: Allows you to delete the

selected file.

• Move To: You can move selected

files to the Phone Memory or

Memory Card

(if applicable).

• Copy To: You can copy selected files

to the Phone Memory or Memory

Card

(if applicable).

• Rename: You can edit the name of

the selected file.

• New Folder: Allows you to make a

new folder.

LG GS390 | User Guide

• Sort by: You can sort the folders by

name, date and type.

• Delete All: You can delete all files

and folders.

• Used Space: You can view internal

and external memory status.

Memory Card

This function shows the files in the

external microSD™ card memory.

Gam

Acce

or Br

avail

ones

To la

Stan

Note

form

the J

inclu

the n

can v

from

Warn

Editio

phon

J2SE

prog

envir

• Sho

con

site

You

dow

GaMy Stuff

Applications

To launch Applications while in the

Standby screen, touch the Quick

key , touch tab and then

touch .

This menu displays the list of Java

programs downloaded using WAP.

All previously downloaded programs

can be selected, deleted or viewed in

detail within the Application menu.

Shop Applications

This menu option connects to AT&T’s

application download site. This

allows users to download the various

applications by connecting to the

Internet.

Games

Access Games on your LG GS390

or Browse the catalog of games

available to buy and download new

ones.

To launch Games while in the

Standby screen, touch the Quick key

, touch and then touch .

Note : The JAR file is a compressed

format of the Java program and

the JAD file is a description file that

includes all detailed information. From

the network, prior to download, you

can view all detailed file descriptions

from the JAD file.

Warning : Only J2ME (Java 2 Micro

Edition) based programs will run in a

phone environment.

J2SE (Java 2 Standard Edition) based

programs will only run in a PC

environment.

• Shop Games: This menu option

connects to AT&T’s game download

site.

You can see the default and

downloaded games in the list.

Games and Apps

LG GS390 | User Guide

Mobile Banking

This application provides easy

access to your banking account from

your phone where you can view

your account balances and history,

transfer funds, receive and pay bills

and more.

If your banking institution doesn’t

currently participate, check back

frequently as new banks are joining

all the time.

My-Cast Weather

Allows you to search quickly weather

forecast.

Pho

Touc

choo

Lan

You

the d

chan

Inpu

Aut

This

of tim

auto

Games and Apps

Settings

Phone Settings

Touch , and the tab, then

choose .

Languages

You can change the language for

the display text on your phone. This

change will also affect the Language

Input mode.

Auto Screen Lock

This allows you to set the amount

of time before your screen locks

automatically.

If you set When slider is closed

, the screen will be locked

automatically when you slide down

the phone.

Set Flight Mode

This allows you to use only the

phone's features that do not require

the use of the wireless network

when you are in an airplane or in

places where the wireless network

is prohibited. If you set the flight

mode ,

you will be prompted to confirm

your selection. After you confirm it

by touching the Flight mode

icon will be displayed on the screen

instead of the network signal icon.

LG GS390 | User Guide

• : You cannot make (or receive)

any calls, including emergency calls

or use other features that require

network coverage.

• : Deactivates Flight Mode

and re-establishes your wireless

connections.

Security

Various codes and passwords are

used to protect the features and

settings of your phone. They are

described in the following sections.

• Phone lock: You can use a security

code to avoid unauthorized use of

the phone. If you set phone lock

to When Power On, the phone will

request a security code whenever

you switch the phone on. If you

set the phone lock to When SIM

Changed, your phone will request

a security code only when you

change your SIM Card. If you set

the phone lock to Lock Phone Now,

your phone will lock immediately.

• PIN Code Request: When the PIN

code request feature is set to

, you must enter your PIN each

time you switch the phone on.

Consequently, any person who

does not have your PIN cannot use

your phone without your approval.

Note : Before setting the PIN code

request feature to Off, you must enter

your PIN.

The following options are available:

• : You must enter the PIN each

time the phone is switched on.

• : The phone connects directly

to the network when you switch

it on.

• Fixed Dial Number: This allows

you to restrict your outgoing calls

to selected phone numbers, if this

function is supported by your SIM

Card. The PIN2 code is required.

• FD

ent

Note

If you

optio

• Cha

feat

cur

bef

You

for:

Aut

Selec

phon

you

from

Pleas

alwa

func

Settings

use

val.

ter

tly

lls

his

• FDN On/Off

- : You can only call phone

numbers stored in the FDN List.

You must enter your PIN2.

- : You can call any number.

• FDN List: You can enter new FDN

entry.

Note : Not all SIM Cards have a PIN2.

If your SIM Card does not, this menu

option is not displayed.

• Change Codes: The Change codes

feature allows you to change your

current password to a new one. You

must enter the current password

before you can specify a new one.

You can change the access codes

for: Security Code, PIN1, PIN2

Auto Rotation

Select whether or not you want the

phone to rotate automatically when

you rotate the phone (for example,

from Portrait to Landscape Mode).

Please note that the phone may not

always rotate, depending on what

function may be currently running.

Reset Settings

This function allows you to restore

factory settings. To do this, you need

the security code.

• Master Reset: Restores the settings

(e.g.: Audio, Display, Language,

Date & Time, Bluetooth

Settings)

stored in the handset memory to

default values.

• Master Clear: Deletes downloaded/

user created contents (e.g.: images,

videos) from Handset content and

the External Memory card.

• Phone

- Deletes all downloaded/user

created Images, Videos & Sounds

from the Handset Memory.

- Deletes Personal Information

stored in the handset memory

(e.g.: address book, messages,

tasks, alarm, Calendar schedules)

to default values.

- Restores the settings stored in the

handset memory to the default

values.

• Memory Card: Deletes all contents

from the External Memory Card.

LG GS390 | User Guide

Display

Touch , and the tab, then

choose .

Get New Graphics

Connects to AT&T’s graphics

download site.

Wallpapers

From this menu you can select to

have a picture for a background or

no background at all.

Fonts

You can configure the font size and

color of the numbers which appear

in the Dialing screen when you

make a call.

Brightness

You can set the brightness of the

display screen.

Backlight Timer

Use this to set the duration of the

touch screen backlight and keypad.

Themes

You can change the whole look of

display. Touch the screen and drag it

from right to left and touch

to change display theme from Black

to White or vice versa.

Tou

Touc

choo

You

setti

Feed

Soun

Also

and

set S

type

and

Settings

ad.

ag it

ack

Touch

Touch , and the tab, then

choose .

You can customize the Touch

settings and change Touchscreen

Feedback types such as Vibration,

Sound, Vibration & Sound and Silent.

Also you can choose Vibration type

and adjust its intensity. When you

set Sound as Touchscreen Feedback

type, you can choose sound type

and adjust its volume.

Call

Touch and the tab, then

choose .

Call Forwarding

When this network service is

activated, you can direct your

incoming calls to another number,

for example, to your voice mailbox

number. For details, contact AT&T.

Select one of the divert options,

for example, select If Busy to divert

voice calls when your number is

busy or when you reject an incoming

call.

The following options are available:

• All Voice Calls: Diverts voice calls

unconditionally.

• If Busy: Diverts voice calls when the

phone is in use.

• If No Answer: Diverts voice calls

which you do not answer.

• If Out of Reach: Diverts voice calls

when the phone is switched off or

out of coverage.

• Deactivate All: Turns Off all call

forwarding options so that all

incoming calls are received by your

handset.

LG GS390 | User Guide

Send My Number

This network service allows you

to set your phone number to be

displayed On or hidden Off from the

person you are calling. You can select

Set by Network if you prefer to have

different settings for different service

providers.

Auto Redial

Select On, your phone redials the

number you're trying to call up to

10 times after you hear a quick, busy

signal. Press to stop the call

attempts.

This feature attempts to redial

numbers that are engaged due to

the wireless network. It does not

redial numbers to an engaged party.

Note : There will be no alert indicating

the call has been connected. You must

stay on the line to hear when the call

is connected.

Answer Mode

This allows you to determine how to

answer the phone.

• Any Key: You can answer an

incoming call by touching the

or the multitasking key.

• Send Key Only: You can only

answer an incoming call by

pressing the key.

Minute Minder

This option allows you to specify

whether the phone will beep every

minute during a call to keep you

informed of the length of the call.

Call Waiting

The network will notify you of a new

incoming call while you have a call in

progress. Select Activate to request

the network to activate call waiting,

or select Deactivate to request the

network to deactivate call waiting or

View Status, to check if the function

is active or not.

Call

This

Off C

num

• Cal

allo

reje

spe

Rej

inco

to V

you

num

List

• Cal

to t

[Co

Cal

num

by s

Con

Settings

w to

ey.

ery

new

all in

est

ng,

g or

ion

Call Reject

This menu allows you to turn On or

Off Call Reject for all numbers or the

numbers in the Call Reject List.

• Call Reject On/Off: This feature

allows you to choose whether to

reject incoming calls, or calls from

specific phone numbers. When the

Reject All Calls option is set, all

incoming calls are routed directly

to Voicemail. Reject on List allows

you to enable Call Reject for the

numbers saved on your Call Reject

List.

• Call Reject List: After touching

, you can add

to the call reject list by selecting

[Contact List• or [New Number•.

When you add a number to the

Call Reject list, you can add the

number by entering it directly or

by searching for the number in the

Contact List.

Send DTMF Tones

Select from / .

TTY

Select from TTY Full/TTY Talk/TTY

Hear/TTY Off.

Time & Cost

You can check Call Duration and

Data Counter.

Date & Time

Touch , and the tab, then

choose .

• Set Date: This allows you to enter

the day, month and year. You can

change the date format via the

Date Format menu option.

ddd, MMM DD (day, month date)

MM/DD/YYYY (month/date/year)

DD/MM/YYYY (date/month/year)

YYYY/MM/DD (year/month/date)

LG GS390 | User Guide

• Set Time: This allows you to enter

the current time. You can choose

the time format via the Time

Format menu option, which are 12

Hours and 24 Hours.

Also you can set Daylight Saving

Time for 1 Hour or 2 Hours.

• Auto Update: Select to set

the phone to automatically update

the time and date according to the

current local time zone.

Sound

Touch , and the tab, then

choose .

Shop Tones

Connects to AT&T Ringtone Shops.

Volume

This menu controls Ringtone &

Alerts, Multimedia, Call and Keypad

volume.

Ringtone

• Sounds: Shows and plays ring

tones. You can select your preferred

Ringtone by touching the ringtone

listed.

• Alert Type: Supports 3 ring alert

types. Ring, Ring & Vibrate and Ring

after Vibration.

• Increasing Ringtone: Allows you to

select an Increasing Ringtone type

which is played when you receive

an incoming call. You can elect to

turn this and .

Message Tone

• Sounds: Shows and plays message

tones. You can select your preferred

Ringtone by touching the ringtone

listed.

• Alert Type: Supports 6 message

alert types: Ring Once, Ring Every

2 Min., Ring Every 15 Min., Ring &

Vibrate, Vibrate and Silent.

Note : Full length music tracks cannot

be set as either ringtones or message

tones.

Aler

• Sou

of a

typ

• Ale

Ale

Key

This

selec

whe

an o

Pow

You

Tone

Settings

rred

one

Ring

u to

ype

age

rred

one

not

Alert Tone

• Sounds: Allows you to select a set

of alert tones. Supports 2 alert tone

types, Alert Tone 1 and Alert Tone 2.

• Alert Type: You can elect to turn

Alert Tones to Ring or Silent.

Keypad Tone

This menu option allows you to

select a tone that the phone sounds

when a key is pressed. You can select

an option between Beep and Voice.

Power On/Off Tones

You can elect to turn Power On/Off

Tones to Ring or Silent.

Bluetooth®

Touch , and the tab, then

choose .

Your phone has built-in Bluetooth

wireless technology, which makes

it possible for you to connect your

phone wirelessly to other Bluetooth

devices such as a hands-free device,

PC, PDA, a remote screen or other

phones. The devices registered in

your phone can only be connected

one at a time. (To make a connection

to the same type of device or change

Bluetooth

preferences, disconnect

the existing device first.)

You can have a conversation via

a cordless Bluetooth

hands-free

phone or browse the Internet,

wirelessly connected, via a mobile

phone.

You can also exchange, for example,

business cards, calendar items and

pictures.

XMRadio or Music Playing is

supported through a Bluetooth

headset.

LG GS390 | User Guide

Hands-free profile

This icon appears when the

hands-free profile is used

between the hands-free device.

This allows you to call using a

Bluetooth

connection.

A2DP profile

This icon appears when the

A2DP profile is used between

the stereo headset device and

the phone. This allows you to

listen to an audio clip. A2DP is

the Advanced Audio Distribution

Profile, which provides support

for streaming either mono or

stereo audio using Bluetooth

Hands-free + A2DP profile

This icon appears when both

profiles of the hands-free and

the A2DP are used between

the compatible device and the

phone. This allows you to call

and listen to an audio clip using

a Bluetooth

connection.

When using each device, see the

manual that comes with the device.

Note : We recommend that your

phone and the Bluetooth

device you

are communicating with should be

no more than 10 meters apart. The

connection may be improved if there

are no solid objects between your

phone and the other Bluetooth

device.

• Bluetooth

: This menu sets the

Bluetooth

or .

• My Visibility

- Selecting the option exposes

your phone to other Bluetooth

devices.

- Selecting shows your phone

to already-paired devices only.

• Search New Device: This function

allows you to search for and add

new devices.

• My Devices: This function allows

you to view the list of all devices

that are paired with your phone.

Settings

ce.

vice.

oses

one

1. Touch to

search for the device that can

be connected, and which is also

within range.

2. If you want to stop searching,

touch .

3. All of the devices found are

displayed.

Touch the desired device and enter

the password. If you would like to

search again, touch .

• My Bluetooth

Info: This menu

allows you to configure the profile

for Bluetooth

- My Device Name: Allows you to

change the handset's name, this

can be seen by other Bluetooth

devices.

- Supported Services: Shows you

all services that the handset

supports.

- Primary Storage: Select from

Handset and Memory Card to

save data you received using

Bluetooth.

Touch , and the tab, then

choose .

LG GS390 | User Guide

Connection

USB Connection Mode

You can transfer files from a

compatible PC to the memory in

your phone using the Mass Storage.

When you connect the phone to

a PC using the USB cable, this will

be displayed as a removable disk

through Windows Explorer.

The USB Connection Mode

determines how your Phone will

communicate with other USB

devices when they are connected

with a USB cable.

Internet Profiles

This menu shows the Internet

Profiles. You can add, delete and

edit Internet Profiles by using the

Menu. However, you cannot

delete or edit default configurations

provided by AT&T.

Access Points

This menu shows the Access Points.

You can register, delete and edit

by using the Menu. However,

you cannot delete or edit default

configurations provided by AT&T.

Start Up Guide

This menu will start the animated

guide. This guide will help you, using

animated visuals, quickly learn some

of the functions of your LG GS390.

For the complete list of Guides in this

menu, see page 15.

Touch Calibration

This menu option will allow you to

calibrate your touch screen. Follow

the instructions on the screen to

complete this task.

Memory

Used Space

This function shows the status of the

user memory of the handset.

• Phone Common: This will display

the memory currently used up in

your phone and will categorize it by

types of files using the memory.

• Memory Card: If your phone has

a multimedia memory card in the

card slot, you can save images,

sounds and videos on the memory

card. You can check the current

status of the external memory card

in the Memory status menu.

• Pho

sho

Con

• SIM

the

Set S

You

case

from

Blue

Phon

You

or ch

Defa

App

This

setti

the p

Vide

• Aud

aler

• Aut

aut

Sha

Settings

sing

ome

this

fthe

it by

ory

card

• Phone Reserved: This function

shows the status of the reserved

memory for the user (Text Message,

Contacts, Calendar, Tasks, Memo).

• SIM Card: This function shows

the status of the SIM Card user

memory.

Set Storage Defaults

You can set Storage default for each

case. When you need to save files

from Camera, Internet Download,

Bluetooth and Voice Recorder, set

Phone Memory or Memory card.

You can set each case separately

or choose All and set the Storage

Default all the same.

Applications Settings

This Menu allows you to adjust the

settings to the following features on

the phone:

Video Share

• Audio Alert: Enable/Disable audio

alert when Video Share is available.

• Auto Record: Enable/Disable

automatic recording of live Video

Share.

Messaging

To set the message settings

from standby screen, touch .

Touch Message Settings.

For more information regarding

Message Settings, please refer to

page 50.

Browser

This menu allows you to customize

your Browsing experience by giving

you the option of changing the

following settings:

Accounts

This includes the network

information used to connect the

browser to the Internet. Select the

desired account by tapping the

screen.

This will activate the account that

will be used for future connections.

MEdia Net is the predefined account

that is set as default.

LG GS390 | User Guide

The following options will be

available when you touch :

• Delete: Allows you to delete the

account.

• Delete all

Note : You cannot edit and delete pre-

installed accounts. In order to create a

new account, please fill in the network

information.

1. Account Name: Name associated

with new account.

2. Homepage: Homepage URL.

3. Internet Profile: You can choose one

from the Internet profiles.

Note

1. AT&T has provided default settings

regarding account information.

2. Creating or editing an account

requires caution. The browser cannot

connect to the Internet if the account

information is incorrect.

Appearance

You can choose the settings of the

browser appearance (Text size,

Encoding, Show Image, Java Script).

Cache

The web pages you have accessed

are stored in the memory of the

phone.

• Clear Cache: Remove all cached

data in the memory.

Note : A cache is a buffer memory,

which is used to store data temporarily,

especially when it is online.

Cook

The

acce

a Co

Rend

You

Stan

Secu

A list

show

• Cer

cer

• Cle

ses

Secu

You

indic

Settings

nnot

ount

pt).

arily,

The information of services you have

accessed are stored in what is called

a Cookie.

Rendering

You can set the Rendering mode to

Standard or Text Only.

Security

A list of the available certificates is

shown.

• Certificates: You can see the list of

certificates and view them in detail.

• Clear Session: Removes the secure

session.

Secure Popup

You can control the pop-up which

indicates a secure page or not.

Shortcut

If this is set to On, you can use

the browser more quickly and

conveniently with the Qwerty key

pad in the phone. If Shortcut is on,

the following Shortcut keys are

available:

Enter URL This page

View

Bookmarks

Page

Overview

Full Screen Normal Screen

Page up Recent Pages

Zoom In Search Text

Page Down Zoom Out

Voice Command

• Mode

- Speed: voice command is

abbreviated

- Normal: voice command is played

normally

• Best Match

- 1 Match: the most likely match

will be displayed, finding a

number from the address book

- 4 Matches: the four most likely

matched names will be displayed,

finding a name from the address

book

LG GS390 | User Guide

• Sensitivity

- High: Operation and performance

of the voice recognition engine

is rarely affected by the user's

voice command and surrounding

sound.

- Medium: Operation of voice

recognition engine is normally

affected by user's voice command

and surrounding sound.

- Low: Operation of voice

recognition engine is strongly

affected by user's voice command

and surrounding sound.

• Speakerphone Mode

- Automatic On: When this option

is selected, sound is loud enough

so you can hear the output when

the phone is away from the ear, at

a distance

- Off: When this option is selected,

sound is quieter, and cannot be

heard when the phone is away

from the ear, at a distance

- Call Alert: Allows you to select

an alert type between Ring Only,

Ring After Name and Name

Repeat.

Software Update

If new software exists, the AT&T

server notifies devices using a WAP

push message. Before updating

new software after downloading

it from the AT&T server, users can

decide whether they would like to

postpone the operation. When the

time is up, users are prompted again

or users can resume the postponed

operation using this menu at any

time.

Phone Information

This menu is used to view My

Numbers, Manufacturer, Model

Name, Device ID, Hardware Version,

Software Version, Language and DM

Client Version.

Pleas

are d

callin

Q H

A Pr

Q W

A W

Q W

A W

Settings

HAC T-Coil Information

LG Electronics USA GS390 Cellular/PCS GSM/EDGE Phone with Bluetooth User Manual GS390 Open Eng Cover indd

LG Electronics USA Cellular/PCS GSM/EDGE Phone with Bluetooth GS390 Open Eng Cover indd

Users Manual

Navigation menu

Namespaces

Views

Navigation
