GW550 User Manual HTML Version

Users Manual

GW550 User Guide

- English

This document is the user guide for the LG GW550 Windows Mobile

Smartphone. All rights for this document are reserved by LG Electronics.

Copying, modifying and distributing this document without the consent of

LG Electronics are prohibited.

Part 15.21 statement

" Change or Modifications that are not expressly approved by the manufacturer could void

the user's authority to operate the equipment. “

Part 15.105 statement

This equipment has been tested and found to comply with the limits for a class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful interference or

television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

This device is not intended for sale in the USA.

Part 15 Class B Compliance

This device and its accessories comply with part15 of FCC rules.

Operation is subject to the following two conditions:

(1) This device & its accessories may not cause harmful interference.

(2) This device & its accessories must accept any interference received,

including interference that may cause undesired operation.

Body-worn Operation

This device has been tested for typical body-worn operations

with the distance of 0.79inches (2.0cm) from the user’s body.

To comply with FCC RF exposure requirements, a minimum separation distance

of 0.79inches(2.0cm) must be maintained from the user's body.

Additionally, Belt clips, holsters & other body-worn accessories may not contain

metallic components.

Introduction

Congratulations on your purchase of this LG GW550 Windows Mobile Smartphone.

This user guide contains information on the use and operation of this phone. Please read

all the information carefully for optimal performance and to prevent damage or misuse of

the phone. Any changes or modiﬁ cations not expressly approved in this user guide could

void your warranty for this equipment.

Phone Components

GW550 Features

1. Phone button

2. Proximity Sensor

3. Display screen

4. Home key

5. Left soft key

6. Call key

7. Enter key

8. Messaging key

9. Microphone

12. Earpiece

13. Camera

14. Navigation key

15. Right soft key

16. End key

17. Back key

18. Keyboard

19. Smart E-mail key

20. Smart Contacts key

21. Smart Applications

key

10. Speakers

11. microSD Card Holder

22. Camera

23. Battery

Compartment

24. SIM Card Holder

GW550 Features

Keys and Parts Functions

1. Phone button

b Long press to turn the phone on or off.

b Short press to display Quick List. Quick

List allows you to turn off or lock the

keyboard of your device, provides shortcut

access to Task Manager or Wireless

Manager, or allows you to change proﬁ les.

2. Proximity Sensor

3. Display screen

4. Home key: Press to return to the Today

screen.

5. Left soft key: Press to perform the

function indicated by the text on the

display above it.

6. Send key: Press to place or answer

incoming calls. In standby mode, press

to access the dialer and view the most

recent incoming, outgoing and missed

calls.

7. Enter key: Press to conﬁ rm a selection.

8. Messaging key: Press to access

Messaging.

9. Microphone

10. Speakers

11. microSD Card Holder

12. Earpiece

13. Camera: Use for video calls.

14. Navigation key: Use as directional keys

to move up, down, left, or right.

15. Right soft key: Press to perform the

function indicated by the text on the

display above it.

16. End key: Press to end or reject a call.

17. Back key: Press to go back to the

previous screen or back out of menus

one level at a time. When entering text,

press to delete single characters; press

and hold to delete entire words.

18. Keyboard

19. Smart E-mail key: Press to access

Smart E-mail. Smart E-mail is a

shortcut application to send and receive

e-mails.

20. Smart Contacts key: Press to access

Smart Contacts. Smart Contacts allows

you to add your favorite contacts or

phone numbers to the Smart Contacts

list.

21. Smart Applications key: Press to

access Smart Applications. Smart

Application allows you to add your

favorite applications to the Smart

Applications list for easy access.

22. Camera: Use to take photos or videos.

23. Battery Compartment

24. SIM Card Holder

GW550 Features

How to hold your phone

In order to allow better RF antenna sensitivity, LG suggests that you hold

the handset as depicted in the ﬁ

gure below.

Please do not cover the RF antenna area with your hand during a call and

using a bluetooth connection. It may degrade speech quality.

Volume Keys

bWhen the screen

is idle, press to adjust

system volume.

bDuring a call, press to

adjust the in-call volume.

USB Connector

Use to connect the

charger, earphone, or USB

cable to synchronize with

a computer.

Camera Key

Press to activate the

camera and take photos

or videos.

Getting Started

Installing the SIM card and

Battery

Always turn off your phone and disconnect

it from the charger and other accessories

before installing or replacing the SIM card,

microSD card, and battery.

To remove the back cover

1. Use both thumbs to push and slide the

back cover down until it disengage.

2. Lift to remove the back cover.

Battery

Your phone comes with a rechargeable Li-ion

battery.

To remove the battery

1. Turn the phone off.

2. Remove the back cover.

3. Insert your ﬁ nger in the battery’s ﬁ nger

grip, then gently push down the battery

towards the direction of the arrow to

release and remove the battery.

SIM Card

Your SIM card contains your phone number,

subscription details, and contacts and must

be inserted into your handset.

To install the SIM card

Insert the SIM card with the metal contacts

facing down and the cut-off corner on the

top-right side.

Getting Started

To remove the SIM card

1. Remove the battery if it is installed.

2. Slide the SIM card out the slot.

Note

The SIM card and its contacts can be

easily damaged by scratching and bending

the card. Be careful when installing and

removing the card. Refer to the instructions

supplied with the SIM card.

To install the battery

1. Remove the back cover.

2. Insert the battery. Align the contacts of the

battery with the corresponding connectors

on the battery compartment and insert in

the direction of the arrow (A) then push

the battery into place (B).

3. Replace the back cover.

To replace the back cover

1. Align the back cover (A).

2. Push the back cover to lock into place (B).

Getting Started

Charging the Battery

1. Make sure the battery is installed inside

the battery compartment.

2. Plug the power adaptor into a wall outlet.

3. Flip open the USB connector’s cover of

the phone.

4. Connect the power adaptor into the USB

connector of your phone.

Battery Indicators

When the phone is turned on...

b The icon indicates that the battery

is charging.

b When the battery is fully charged, the

icon is displayed.

When the phone is turned off...

b A charging animation is displayed on the

screen.

b When the battery is fully charged, the

animation stops and the screen turns

blank.

Note

When you charge a fully discharged battery,

it may take over a minute for the display

to respond. It is not a malfunction but

completely normal.

CAUTION!

b Do not remove the battery or the SIM

card while charging.

b There is a risk of explosion if battery

is replaced by an incorrect type.

Replace only with batteries approved

by the manufacturer.

b Dispose of used batteries according

to the local regulations in your area.

b Do not force the mini USB connector

as this may damage the phone or

the cable.

Getting Started

WARNING!

• Unplug the charger from the mains and

phone during lightning storms to avoid

electric shock or ﬁ re.

• Make sure that no sharp-edged items,

such as nails, come into contact with the

battery. There is a risk of causing ﬁ re.

microSD Card

For additional storage space for your photos,

videos, music and ﬁ les, install a microSD

card into your phone.

To install the microSD card

1. Push the microSD card slot towards the

direction of the arrow (A) to release lock,

then ﬂ ip up the slot (B).

2. Slide the microSD card into the slot with

the gold contact area facing up (C).

3. Flip down (D) then push the slot towards

the direction of the arrow (E) to lock.

Getting Started

To remove the microSD card

1. Turn the phone off.

2. Push the microSD card slot to release

lock.

3. Flip up the slot.

4. Slide out the microSD card from the slot.

5. Flip down then push the slot to lock.

Info!

The microSD card is an optional

accessory and is not included in your

package. Contact your retailer to

purchase one.

b Avoid using the microSD card when the

battery is low.

b The card is designed to ﬁ t easily into

the slot.

b Do not bend the card or force it into

the slot.

b Do not insert any memory cards other

than microSD.

Turn the Device On and Off

To turn on the device, press and hold the

Power button located on top of the device.

To turn off the device:

Press the Power button and select

Power off.

Press and hold the Power button.

Lock the Keyboard

To lock the keyboard, press and hold the

End key.

To unlock keyboard, select Unlock, then

press *.

Getting Started

Getting Started gives you step-by-step

instructions on how to set up the basic

functions of your device. From the Today

screen, do either of the following to access

Getting Started:

b Scroll down to select the Getting Started

shortcut menu, then scroll left or right and

select a speciﬁ c topic.

b Select Start > Getting Started, then

select the topic to view.

•

Getting Started

Adjust Volume

Your device has two types of volume:

b System Volume: Adjust the system

volume to change the volume level of

system sounds and notiﬁ cations like

alarm, ringer, keypad, audio and video

playback.

To adjust the system volume:

When the device is in idle mode, press

the volume keys up or down to increase

or decrease volume.

b In-Call Volume: Adjusts the volume level

of the phone conversation.

To adjust the in-call volume:

During a call, press the volume keys

up or down to increase or decrease

volume.

•

Getting Started

Screen Information

The Today Screen

From the home screen, you can quickly check your schedule, and see at a glance any missed

calls or new messages.

Default Today Screen

To Customize the Today Screen

You can change the layout, background image, color scheme and the time out of the Today

screen.

4To customize settings of the Today screen, go to Start > Settings > Home Screen.

Service Provider’s Name

Wi-Fi Status

Shortcut menu

Scroll down to view more

shortcut menu. Highlight

a menu to expand to more

shortcuts. Start menu

(Left soft key function)

b Press the left soft key

to access.

Contacts

(Right soft key function)

b Press the right soft key

to access Contacts.

Status Indicators

Alarm Indicator

Date and Time

Status Indicators

The following are some of the status icons

that you may see on your device.

Icon Description

Indicates maximum signal

strength

Searching for signal

No phone service

Indicates battery level

Battery low

Battery charging

Silent mode enabled

Vibrate mode enabled

WCDMA (3G) available

HSDPA available

GPRS (General Packet Radio

Services) available

3G network in use

GPRS network in use

HSDPA network in use

New message received

Missed call or rejected call

Call in progress

Call on hold

Bluetooth active

Wireless network available

Wireless network connecting

Wireless network connected

Screen Information

Shortcut Menu

The shortcut menu displays notiﬁ cations or other information of each menu item.

By default the following applications are displayed:

Menu Description

Clock and Alarm Displays the date and time. To adjust date and time press the

Enter key.

Calls and Messages

Notiﬁ cation

Displays notiﬁ cations about recent voice and video calls,

voicemail, and other messages. To access a submenu, use the

navigation keys to scroll, then press the Enter key.

Appointments Displays upcoming schedules and allows you to set appointments.

Getting Started Select an item to view its help information.

Favorites Displays and allows you to add your favorite web pages for easy

access.

Settings Displays and allows you to easily adjust basic device settings.

b To access a shortcut menu, use the navigation keys, then press the Enter key.

b To add shortcuts of media applications, go to Start > Settings > Home Screen> Home

Screen Layout > Sliding Panel Media.

Screen Information

Start Menu

The Start menu contains all the programs

installed on your device.

Accessing the Start menu

b From the Home screen, press the left soft

key Start to access the Start menu.

b By default, the Recent Programs screen is

displayed. To view other programs, press

the left soft key All Programs.

b To go to the next screen display, press the

left soft key More.

b To go back to the previous screen, press

the Back key .

b To access a menu, use the

navigation keys to highlight the

item, then press the Enter key.

Programs

The following programs are installed on your device.

Icon Program Description

Ofﬁ ce Mobile

Excel Mobile Create new and edit Excel workbooks.

Word Mobile Create new and edit Word documents.

PowerPoint

Mobile View and setup slide shows.

OneNote Mobile Create notes with pictures and recordings.

Screen Information

Icon Program Description

Messaging Send and receive e-mail and text messages.

Calendar Schedule appointments and set alarm notiﬁ cations.

Contacts Lets you store names, phone numbers, e-mail and other

information.

Internet Explorer Browse the web and download ﬁ les from the Internet.

Tasks Keeps track of your tasks.

Active Sync Synchronizes information between your device and a

computer.

Call History Displays the list of missed, received or placed calls.

Games Play pre-installed games on your device: Bubble Breaker and

Solitaire.

Voice Notes Record voice notes.

Pictures & Videos Collects, organizes, and sorts photo and video ﬁ les in the My

Picture folder of your device or the storage card.

Getting Started Learn the basics on how to operate your device.

Internet Sharing Use your device as an Internet sharing device.

File Explorer Browse ﬁ les and folders saved on your device or the storage

card.

Marketplace Purchase and download applications on the web.

Screen Information

Icon Program Description

Microsoft My

Phone

Synchronizes information on your device with your My Phone

account at http://myphone.microsoft.com.

Adobe Reader LE View *.pdf ﬁ les on your device.

AGPS Settings Enable Assisted Global Positioning System.

Backlight Control the level of brightness when using the battery or

external power.

Bluetooth

Manager Connect with other Bluetooth devices and create a network.

Camera Capture photos and record videos.

FM Radio Connect the earphones and tune in to the FM radio.

GPSExtra Download GPS data.

Java Download and install Java applications on your device.

Remote Desktop Set up and connect to your computer to access ﬁ les and

programs from your device.

Windows Media Mobile version of Windows Media Player. Tune in and watch

your favorite music videos.

RSS Viewer View RSS or RDF-compatible newsfeeds.

Stopwatch Functions as a timer.

Screen Information

Icon Program Description

Windows Live Mobile version of Windows Live™.

Clock & Alarm Allows you to set the date and time and set alarms.

MSN Money Access MSN Money to view stocks.

MSN Weather View the weather forecast via MSN Weather.

Search Widget Provides access to Live Search.

Speed Dial Allows you to add phone numbers for speed dial.

XT9 Settings

Allows you to set the language of the dictionary and enable

functions such as word completion, next word prediction and

others.

Entering Information

Using the Keyboard

Your device comes with a full keyboard

for text entry and other shortcut button

functions.

QWERTY Keyboard

QWERTY keyboard is activated whenever

an alphanumeric text entry is required. This

functions just like a standard computer

keyboard.

b To switch between the different letter

cases, press CAPS .

To type all in upper case letters, press

and hold CAPS then press the corresponding

keys. To switch back to lower case entry,

press CAPS again.

b To enter a single symbol or number

printed at the top of keys, press Fn then

press the corresponding key.

To enter various symbols or numbers,

press and hold Fn then press the

corresponding keys.

To switch back to text mode, press Fn

again. To enter the symbols that are not

shown on the keypad, press

Sym then

select the desired symbol.

b Press to go to the next line.

b Press

DEL to erase a character.

The following icons are displayed on the

status indicator area:

Icon Description

Enter text in lower case letter

Enter one character in upper

case and the rest in lower case

Enter all text in upper case letter

Enter a number or symbol

Enter all numbers or symbols

Entering Information

Numeric Keypad

QWERTY Keyboard

Entering Information

XT9 Mode

By default, the QWERTY keyboard is set to

XT9 mode. XT9 predicts words and suggests

spellings as you type the ﬁ rst few characters,

so you can just select the word you want.

To activate XT9 mode, press Fn + spacebar

and select XT9 English.

To enter text using XT9

1. Type the ﬁ rst few characters of the word.

2. As you type, the dictionary displays

predicted words below the word you are

typing.

3. Scroll left or right to highlight the word

then press the Enter key to select.

The following icons are displayed on the

status indicator area:

Icon Description

Enter the ﬁ rst character in

upper case and the rest in

lower case

Enter text in lower case letter

Numeric Keypad

The numeric keypad functions just like a

standard phone keypad. It is automatically

activated whenever numeric entries are

required, such as in setting the time.

Recording a Note

You can create a stand-alone recording

(voice note) or you can add a recording to

a note.

To create a voice note

1. Select Start > Voice Notes.

2. Hold your device’s microphone near your

mouth or other sound sources.

3. Select Record to start recording.

4. Select Stop to stop recording.

To add a recording to a note

1. Select Start > Ofﬁ ce Mobile > OneNote

Mobile.

2. Create or open a note.

3. Select Menu > Insert Recording.

3. Hold your device’s microphone near your

mouth or other sound sources.

3. Select Record to start recording.

4. Select Stop to stop recording.

Contacts

Contacts is your address book and

information storage for the people you

communicate with. You can store phone

numbers, e-mail addresses, home

addresses, and other information that relates

to a contact. You can also add a picture or

assign a ringtone to a contact.

Your device supports two types of contacts:

Outlook and SIM Contacts.

Outlook Contact

Contacts are stored in the device memory.

If you use Outlook on your PC, you can

synchronize contacts between your device

and the PC.

SIM Contact

Contacts are stored in the SIM card memory.

You can only store a name and a phone

number per entry.

To Create a Contact

1. From the Today screen, select Contacts.

2. Select New.

3. Select Outlook Contact or SIM Contact,

then enter the contact details.

4. When ﬁ nished, select Done.

TIP!

b You can create a contact from Call

History list, select Menu > Save to

Contacts.

b To add the sender of a message

to Contacts, select the received

message and the number, then press

the Enter key.

To Find a Contact

There are several ways to ﬁ nd a contact

when your contact list is long.

1. From the Today screen, select Contacts.

2. If you are not in Name view, tap Menu >

View By > Name.

3. Do one of the following:

b Enter the ﬁ rst character of a name. Scroll

down to select the desired name from

the the list. The next character you enter

continues to narrow the search.

b Filter the list by category. In the contact

list, select Menu > Filter. Then, select

a category you’ve assigned to a contact.

To show all contacts again, select No

Categories.

Contacts

To Work with the Contact List

There are several ways to use and

synchronise the contact list. Here are a

few tips:

1. From the Today screen, select Contacts.

2. In the contact list, do any of the following:

b In Name view, you can search for a

contact by entering a name or by using

the alphabetical index. To switch to Name

view, select Menu > View By > Name.

b To see a summary of information about

a contact, select the contact. From there

you can also make a call or send a

message.

b To see a list of contacts employed by

a speciﬁ c company, select Menu >

View By > Company. Then, select the

company name.

To Change Contact Information

1. From the Today screen, select Contacts.

2. Select the contact.

3. Select Menu > Edit and enter the

changes.

4. When ﬁ nished, select Done.

To Delete a Contact

1. From the Today screen, select Contacts.

2. Select the contact.

3. Select Menu > Delete.

4. Select Yes to conﬁ rm delete.

To Copy Contacts

To copy saved Contacts from SIM card to

your device or from your device to SIM card:

1. From the Today screen, select Contacts.

2. Select Menu > Select Contacts >

Several or All.

3. Select Menu > Copy Contacts > To

Contacts or To SIM.

Call

Making a Voice Call

Calling is easy with the smart dial feature.

If you press a number on the keypad, the

screen displays the phone numbers in your

Call History, starting with the number you

enter.

You can then select the number you want

to call.

Make a Call from Phone

To make a call, enter the phone number you

wish to call, including the area code, and

press the Call key .

For international calls, press and hold “0”

to add the + character that replaces the

international access code.

To end the call, press the End key .

Note

If you enter the wrong number, press

to delete a number. To delete all the

numbers, press and hold .

Make a Call from Contacts

1. From the Today screen, select Contacts.

2. Select the desired contact.

3. Press the Call key to place the call.

Make a Call from Call History

1. From the Today screen, press the Call key

to view your call history.

2. Select the desired number or name from

the list.

3. Press the Call key to place the call.

Speed Dial

Use speed dial to call a number by pressing

and holding a number key when in the home

screen. Before you can create a speed dial

entry, the number must already exists in

Contacts list.

Call

To Create a Speed Dial Entry

1. From the Today screen, select Contacts.

2. Highlight the contact, then press the

Enter key.

3. Select Menu > Add to Speed Dial.

4. In the Keypad Assignment box, select the

desired number.

5. Select Done to save.

Note

b Key 1 is generally assigned to your

voice mail, and Speed Dial will

designate the next available key by

default. If you want to save a number

to a key that has already been

assigned, the new number will replace

the current one.

b To delete a Speed Dial entry, in the

Speed Dial list, select the desired entry

then select Menu > Delete.

Receiving a Call

When you receive an incoming call, a

message will appear and the device will ring

if the ring volume is turned on.

To Answer or Reject a Call

b To answer the call, select Answer or

press the Call key .

b To reject the call, press the End key

b To reject the call and send a text

message, select Menu > Respond with

text message.

To End a Call

b To end an incoming or outgoing call, press

the End key .

In-call Options

To Put a Call on Hold

b Select Menu > Hold.

b To unhold a call, select Menu > Unhold.

To Set Up a Conference Call

1. Either put the current call on hold, and dial

a second number; or accept an incoming

call when you are already having a call

conversation.

2. Select Menu > Conference.

Call

Note

Not all service providers support

conference call. Contact your service

provider for details.

To Turn the Speakerhone On or Off

The speakerphone allows users to talk

hands-free or allows other people to listen to

the conversation.

b During a conversation, select Menu >

Speakerphone On. The speakerphone

icon appear on the status indicators

area.

b To turn off the speakerphone, select Menu

> Speakerphone Off.

WARNING!

To avoid damage to your ear, do

not hold out your device when the

speakerphone is turned Off.

To Mute a Call

You can turn off the microphone during a

call. When the phone is muted, you can hear

the caller but the caller cannot hear you

b During a conversation, select Menu

> Mute. The microphone off icon

appears on the screen.

b To turn on the microphone, select

Unmute.

Video Calls

You can see a real-time, two-way video

between you and the caller who has a

compatible mobile phone.

Note

A 3G network coverage is required to

enabled Video Call functions. You can

send or start to receive video from

a caller whose phone has Video Call

capabilities. Contact your service provider

for details.

Make a Video Call

To Make a Video Call From Phone

1. Enter the phone number or select the

name from Contacts or Call History.

2. Select Menu > Make VT Call or Menu >

Video Call from Contacts to place the call.

Call

To End a Video Call

b To end an incoming or outgoing video call,

press the End key .

Notes

1. Video call service is only available in 3G

coverage areas.

2. The video call will be terminated in the

following cases:

When you accept a 3rd party, Conference

Call, or a 2nd incoming call.

When the voice call is placed on hold.

When the voice call is disconnected.

When moving out of a 3G service area.

When the network connection is in poor

state.

Using Call History

From the Today screen, do either of the

following to open the Call History screen:

b Highlight Calls and Messages Notiﬁ cation

shortcut, then select View.

b Select Start > Call History.

You can view the recently missed, received,

and dialed calls.

You can make a call, send a text or

multimedia message, and save a number

to Contacts.

You can delete a selected number or select

and delete all at one time.

Find Contact

If the number is saved in your Contacts, you

can view the contact details by selecting

Menu > Find Contact.

Send Text Message

1. Select the number you want from the list.

2. Select Menu > Send Text Message to

send a text message.

E-mail

If the selected number has an e-mail

address saved in your Contacts, you can

send an email by selecting Menu > E-mail.

View Timers

To view the approximate duration of all calls

made on your device, select Menu > View

Timers.

b To reset timer, select Menu > Reset

Timers.

Delete

1. Select the desired number.

2. Select Menu > Delete.

3. Select Yes to conﬁ rm.

Call

Delete List

To empty the call history list, select Menu >

Delete List.

Filter

b No Filter: Allows you to view missed,

received, and dialed call records.

b Missed Calls: Allows you to view the

calls which you have not answered.

b Incoming Calls: Allows you to view the

calls that you have answered.

b Outgoing Calls: Allows you to view the

calls that you have dialed.

Video Call

1. Select the number to make a video call

from the list.

2. Select Menu > Video Call.

Call

Messaging

To Open the Messaging screen

b From the Today screen, select Start >

Messaging.

You can send and receive text messages,

multimedia messages, audio messages, and

email messagse.

Text Message

You can write, edit, and view the text

messages.

To create an SMS message

1. From the Messaging screen, select Text

Message.

2. Select Menu > New > SMS.

3. On the To ﬁ eld, enter the recipient’s

phone number or add a recipient from

Contacts.

TIP!

b To add a recipient from Contacts,

select Menu > Add Recipient. Then

select the name.

b Repeat the same procedure to add

more recipients.

4. Compose your message.

TIP!

b To use a template, select Menu >

My Text, the text and Insert.

5. When ﬁ nished, select Send.

To create an MMS message

1. From the Messaging screen, select Text

Message.

2. Select Menu > New > MMS.

3. On the To ﬁ eld, enter the recipient’s

phone number.

4. Enter the Subject for the message.

5. Select Insert Text to enter the text of the

message, and select Insert Picture/

Video or Insert Audio to add media

objects. To capture a new image or record

a new sound clip for the message, select

Menu > Capture.

Messaging

6. To preview a multimedia message before

sending it, select Menu > Preview

Message.

7. When ﬁ nished, select Send.

To reply or forward a text message

Highlight the message then select Reply or

Menu > Reply/Forward > Reply, Reply all

or Forward.

E-mail

You can send and receive Outlook and

Internet e-mail trhough an Internet Service

Provider (ISP). You can access e-mail from

work using VPN connection.

Your device can send and receive e-mails

just as you do with a PC. You can set up the

following e-mail accounts:

Outlook E-mail

This e-mail account can be synchronized

with your computer through Microsoft

Outlook® or Exchange Server®.

Internet E-mail

This is an e-mail account provided by an

Internet Service Provider (ISP) or a web-based

e-mail such as Hotmail, Yahoo!Mail, etc.

To Set up an E-mail Accont

1. From the Today screen, select Start >

Messaging.

2. Select Setup E-mail.

3. Enter your E-mail address and Password

then select Next.

Note

Select the Save Password box to allow

the phone to remember your password so

you do not have to enter it again.

4. Auto setup attempts to download

necessary e-mail server settings so that

you do not have to set them manually.

Once ﬁ nished, select Next.

5. Enter Your Name (name to display when

you send e-mail), Account display name

(name for this account on your device),

then select Next.

Messaging

Note

b Auto setup is successful, the Account

display name and the address of the

incoming and outgoing e-mail servers

are populated.

b Auto setup is unsuccessful or you

have an account that you access using

VPN server connection, contact your

ISP or network administrator for the

required information.

6. Select Automatic Send/Receive option.

7. Select Finish to complete setup.

To create and send a new e-mail

1. From the Messaging screen, select the

e-mail account.

2. Select Menu > New.

3. On To, enter the recipient’s e-mail

address.

TIP!

b To add Bcc and Cc recipients, use

the navigation key up to view and

scroll the screen’s the top page.

4. Enter the Subject.

5. Compose your message.

6. When ﬁ nished, select Send.

To reply or forward an e-mail

1. Highlight the message then select Menu

> Reply/Forward > Reply, Reply all or

Forward.

2. Compose your response.

b To quickly add common messages, select

Menu > My Text and select a desired

message.

b To add an attachment, select Menu >

Insert > Picture, Voice Note or File.

3. When ﬁ nished, select Send.

Note

b You will be alerted when you have

received messages.

b Received messages are stored in

the Inbox.

b If the device shows “No space for SIM

message”, delete some messages

from the Inbox.

b If the device shows “No space for

messages”, make space of each

repository by deleting messages,

media, and applications.

Messaging

Receiving Messages

The manner in which you receive messages

depends on the type of the account you

have:

• To send and receive e-mail for an Outlook

E-mail account, begin synchronization with

Exchange Server through ActiveSync.

• To send and receive an Internet e-mail

account, download messages through a

remote e-mail server.

• Text messages are automatically received

when your phone is turned on. When your

phone is off, your service provider holds

the messages until the next time your

phone is turned on.

Managing Messages

On the Messaging screen, select the

message account to open. By default, when

you open the account, its Inbox is displayed.

To view and manage account folders, select

Menu > Folders.

b Deleted Items: View deleted items.

b Drafts: View saved messages. Select a

message to edit message.

b Inbox: View received messages. Select a

message to view message.

TIP!

Windows Mobile 6.1 manages your

Inbox messages by address. You can

check the conversation history with

the address that you sent a message

to or view the message by selecting

the threaded message. Create a

new message on the text message

composer which is on the bottom of the

conversation history screen. You can

send the new message by selecting

Send.

b Outbox: The outbox is a temporary

storage for messages waiting to be sent.

Failed messages are also placed in the

Outbox.

b Sent Items: View the messages you sent.

Messaging

Multimedia

Camera

Taking a Photo

1. Select Start > Camera or press the

Camera key to activate the camera

capture mode.

2. Press the Enter key or the Camera key to

capture an image.

3. The captured image is displayed on the

screen. Do either of the following:

b To capture more images, select Back.

b To view the images in the folder, select

Menu > View.

b To send the image via MMS or e-mail,

select Menu > Send.

b To delete the image, select Menu >

Delete.

3. The captured image is automatically

saved in the My Pictures folder. To

view images in the folder, select Start >

Pictures & Videos.

4. To close the camera, select Menu > Exit.

Recording Video

1. Select Start > Camera or press the

Camera key to activate the camera

capture mode.

2. Select Options > Video.

3. Press the Enter key or the Camera key

to start recording; press again to stop

recording.

White Balance

Zoom Remaining shots

Photo Mode

Memory

Resolution

Multimedia

4. Do either of the following:

b To capture more images, select Back.

b To play the video, select Menu > Play.

b To send the video via MMS, select Menu

> Send.

b To delete the video, select Menu >

Delete.

3. The recorded video is automatically saved

in the My Videos folder. To play videos in

the folder, select Start > File Explorer >

My Videos, then select the desired video

ﬁ le to play. Videos are played using the

Windows Media Player application.

4. To close the camera, select Menu > Exit.

Camera Settings

Before taking a photo or recording video, you

can change the camera settings by selecting

Menu > Settings. Available settings are

as follows:

b Timer: Allows you to select the delay time

(5 sec., 10 sec.)

b Burst: Set the number of shots to take

when burst mode is enabled. (3 pics,

5 pics)

b Storage: Select the memory to save your

pictures and videos.

b Shutter Sound: Enable or disable shutter

sound when the Camera or Enter key is

pressd.

b Video Format: Allows you to select the

video ﬁ le format.

b Video Voice: Enable or disable audio

during video recording.

b Flicker: Allows you to select ﬂ icker

setting. (50Hz, 60Hz)

b Time Stamp: Enable or disable time

stamp on captured images.

b Photo Quality: Allows you to select the

photo quality. (Normal, Fine, Super Fine)

b Panorama: Allows you to select the

panoramic view. (Horzontal, Vertical)

Multimedia

Capture Mode Settings

On the capture screen, select Options to

view and adjust capture mode settings.

Choosing Capture Mode Type

Use the navigation up and down keys then

Enter key to select a capture mode type:

b Photo: Select to capture still images. This

is the default capture mode.

b Timer: Select to enable timer mode.

b Burst: Select to capture three or ﬁ ve

continuous shots.

b Frame: Select to choose from the

predeﬁ ned frames and add it to your

images.

b PMK: Select to capture image in vivid

colors.

b Smile: When capturing an image in this

mode, the focus is set on the smiling

subject.

b Video: Select to record a standard video.

b MMS Video: Select to capture video

suitable to send via MMS.

Use the navigation left and right keys then

Enter to adjust other capture settings such

as:

b Brightness: Adjusts brightness.

b White Balance: Auto / Incandescent /

Fluorescent / Daylight / Cloudy

b Effect: Normal / Black & White / Negative

/ Solarize / Sepia / Aqua

b Resolution: Available options depend on

the selected capture mode type.

Multimedia

Pictures & Videos

The Pictures & Videos application collects,

organizes, and sorts images and video clips

in the following formats on your device.

You can view the pictures as a slide show,

beam or send them via e-mail, edit them, or

set them as the background on the Today

screen.

To Copy a Picture or Video Clip to Your

Device

You can copy pictures from your PC and view

them on your device.

b Copy the pictures from your PC or a

storage card to the My Pictures folder on

your device.

Note

b You can also copy pictures to your

PC from your device using a memory

card. Insert the memory card into the

memory card slot on your device, then

copy the pictures from your device to

the folder you created on the memory

card.

To View Pictures

1. From the Today screen, select Menu >

Pictures & Videos. The images in the

My Pictures folder appear as thumbnails

by default.

TIP!

b If you are not in the My Pictures

folder, select Menu > Folders > My

Pictures.

b To go to other folders, select Menu

> Folders > My Device, then select

your desired folder.

2. Highlight a picture and select View.

3. To zoom the image, select Menu > Zoom,

then select zoom options (Zoom In / Zoom

Out / Fit to Screen / Actual Size).

Multimedia

To View Slide Show

b From the My Pictures folder screen or

while viewing a picture, select Menu >

Play Slide Show.

b To stop slide show, press the back key

To Play Videos with Audio

1. Select Menu > Folders > My Device >

My Documents > My Videos to open

the default folder for videos. By default,

the video ﬁ les appear as thumbnails with

a media icon.

2. Highlight the video and select Play to play

it with the built-in Windows Media Player.

To Delete a Picture or Video Clip

1. From the Today screen, select Start >

Pictures & Videos.

2. Highlight a picture or video clip then

select Menu > Delete.

3. Select Yes to conﬁ rm the deletion.

To Edit a Picture

You can rotate, crop, and adjust the

brightness and color contrast of your

pictures.

1. From the Today screen, select Start >

Pictures & Videos.

2. Select the picture you want to edit.

3. Select Menu > Edit. The Edit screen

appears.

4. Select Menu, then any of the following:

b Rotate: To rotate the picture 90º

clockwise.

b Crop: To crop the picture. Use the

navigation and Enter keys to select the

position of the ﬁ rst and second corners.

Select Done to complete cropping.

Multimedia

bAuto Correct: To adjust the brightness

and contrast levels of the picture.

Note

b To undo an edit, select Menu > Undo.

b To cancel all unsaved edits you made

to the picture, press then select

Yes to conﬁ rm.

5. When ﬁ nished, select Done.

To Set a Picture as the Today Screen

Background

You can use a picture as the background on

the Today screen.

1. From the Today screen, select Start >

Pictures & Videos.

2. Select the picture you want to set as

background.

3. Select Menu > Use as Home Screen.

4. Adjust the transparency level, select a

higher percentage for a more transparent

picture, or a lower percentage for a more

opaque picture.

5. Select Finish to complete.

Multimedia

To Send Pictures and Video Clips via

E-mail or MMS

You can send pictures and video clips to

other devices via e-mail.

1. First, set up Messaging to send and

receive e-mail messages.

2. From the Today screen, select Start >

Pictures & Videos.

3. Highlight the picture or video clip you

want to send.

4. Select Menu > Send, then select the

messaging account (such as Outlook

E-mail or MMS) to send the attached item.

5. A new message is created with the item

attached.

6. Enter the recipient name and subject, then

select Send. The message will be sent the

next time you synchronize your device.

Note

b Pictures and video clips are saved

automatically before they are sent.

To Assign Pictures to Contacts

You can assign a picture to a contact so that

you can easily identify the contact at any

point of time.

1. From the Today screen, select Start >

Pictures & Videos.

2. Highlight a picture then select Menu >

Save to Contact.

3. Select the desired contact from the

Contacts list then Select to conﬁ rm.

To Save a Picture as Another File

1. From the Today screen, select Start >

Pictures & Videos.

2. Select the picture you want to save as

another ﬁ le.

3. Select Menu > Save > Save As.

4. Enter the new ﬁ lename, then select Done.

Multimedia

To Use Advance Options

1. From the Today screen, select Start >

Pictures & Videos.

2. Select the picture for which you want to

conﬁ gure settings.

3. Select Menu > Options. The Options

screen appears, allow you to:

b Resize a picture so that you can send it

faster via e-mail.

b Conﬁ gure the rotation setting.

b Conﬁ gure the view settings during slide

shows.

Windows Media

Use Microsoft Windows Media Player 10

Mobile for Pocket PC to play digital audio

and video ﬁ les that are stored on your device

or on a network, such as on a web site. The

following ﬁ le formats are supported by this

application: WAV, WMA, WMV, MP3, MIDI,

SP-MIDI, SMAF, AAC, AMR, 3GP, MP4, etc.

To Open Windows Media

Access Windows Media by any of the

following options:

b From the Today screen, select Start >

Windows Media to open the application.

b Open an audio or video ﬁ le from File

Explorer or Pictures & Videos.

Windows Media Player has three primary

screens: Playback, Now Playing and Library.

From the Playback screen, select Now

Playing or Menu > Library to switch to Now

Playing or Library screen.

Multimedia

Playback Screen

This is the default screen that displays the

playback controls, the album art window,

and the video window. You can change the

appearance of this screen by choosing a

different skin.

When you are viewing the Playback screen,

the following commands appear on the

Menu.

b Library: Displays the Library screen so

you can choose a ﬁ le to play.

b Play/Pause: Starts or pauses playback.

b Stop: Stops playback.

b Shufﬂ e/Repeat: Plays the items in the

Now Playing playlist randomly/repeatedly.

b Full Screen: When a video is playing,

displays it by using the entire screen.

b Options: Lets you adjust various Windows

Media Player options, including network,

skin, and hardware button options.

b Properties: Displays information about

the currently playing ﬁ le.

b About: Displays information about the

Windows Media Player, such as the

version number.

Playback Controls

During playback, use the following keys to

play, pause, skip titles/tracks, and adjust

the volume.

b To start or pause playback, press the

Enter key.

b To go to the previous title/track, press the

left navigation key.

b To go to the next title/track, press the right

navigation key.

b To increase or decrease the volume, press

the up or down navigation keys.

Multimedia

Now Playing Screen

The screen that displays the Now Playing

playlist. This special playlist indicates the

currently playing ﬁ le and any ﬁ les that are

“queued up” to play next.

When you are viewing the Now Playing

screen, the following commands appear on

the Menu.

b Library: Displays the Library screen so

you can choose a ﬁ le to play.

b Move Up/ Down: Moves the selected

item up/down in the playlist order.

b Remove from Playlist: Deletes the

selected item from the playlist.

b Shufﬂ e/Repeat: Plays the items in the

Now Playing playlist randomly/repeatedly.

b Save Playlist: Saves the current playlist.

b Clear Now Playing: Deletes all items

from the Now Playing playlist.

b Error Details: Displays error information

about the selected item (an exclamation

mark appears before the item name if

error details are available).

b Properties: Displays information about

the selected ﬁ

le.

Library Screen

The Library screen lets you quickly ﬁ nd

your audio ﬁ les, video ﬁ les, and playlists. It

contains categories such as My Music, My

Video, My TV, My Playlists and Now Playing.

Multimedia

When you are viewing the Library screen, the

following commands appear on the Menu.

b Queue Up: Adds the selected item to the

end of the current Now Playing playlist.

b Delete from Library: Deletes the selected

item from the library.

b Now Playing: Displays the Now Playing

screen.

b Library: Displays the Library screen so

you can choose a ﬁ le to play.

b Update Library: Adds new items to

the library by searching your device or

storage card.

b Open File: Lets you ﬁ

nd and play ﬁ les

that are stored on your device or storage

card but that are not in the library.

b Open URL: Lets you play a ﬁ

le on a

network, such as the Internet.

b Properties: Displays information about

the selected ﬁ

le.

FM Radio

You can search for your favorite radio

stations and enjoy listening to the radio.

Note

b You must connect the supplied

earphones or use Bluetooth headsets

to use the FM Radio.

1. From the Today screen, select Menu >

FM Radio.

2. Press the navigation left and right keys to

select the radio station to listen to.

TIP!

Press and hold the navigation left and

right keys to ﬁ nd stations.

Multimedia

3. Select Channel to tune in to a preset

station. When no preset channel is

available, execute Auto Scan. The FM

radio will scan for channels, when it

stopped at an intercepted station, do any

of the following:

b Select Set to save the station to a

channel.

b Press the Enter key to skip that station

and continue scan.

b Select Stop to stop scan.

4. To close radio, select Menu > Exit.

To Use Radio Options

From the FM Radio screen, select Menu and

choose any of the following options:

b Listen Via: Allows you to select to listen

to the radio via Wired HeadSet, Speaker,

or Bluetooth Headset.

b Edit: Allows you to edit the station set on

a channel.

b Add New: Allows you to add a new

channel.

b Station Info On / Off: Enable or disable

station information display.

b AF Off / On: Enable or disable Alternate

Frequency (AF).

b Alarm: Allows you to set radio alarm.

Multimedia

Applications

Internet Explorer

With Internet Explorer you can view web sites

and surf the Internet on your device just like

you do on a computer.

From the Today screen, select Start >

Internet Explorer.

In the address bar, enter the web address

you want to visit or choose from previously

entered addresses from Favorites or History.

Press the left or right soft key to display the

function bar.

You can do the following by selecting Menu.

b Favorites: You can view and select from

the list of your favorite web sites.

b Add to Favorites: Select to add the

currently displayed web site to your

Favorites.

b Go to Web Address: Select to place

cursor on the address bar and enter

the web address that you want to visit

manually.

b Home Page: Select to visit the home

page.

b History: Select to view the history list of

recently visited web pages.

b Forward: Select to go to the next page.

b Refresh: Select to refresh the current

web page.

b View: Select the view options.

• Text Size: Select the font size for the

page you are viewing.

• Enable ActiveX Controls: Select this

option to enable ActiveX Controls.

• Mobile: Select this option to view the

page in mobile format.

• Desktop: Select this option to view the

page in desktop format.

b Tools: Select to change browser options

such as Speed Link, Properties and other

options.

b Copy/Paste: Allows you to use copy and

paste functions.

b Exit: Select to exit the browser.

Applications

To zoom the page

b Select Zoom then use the up and down

navigation keys to zoom in or out the

web page.

Note

b Browsing the internet may incur

additional charges. Charges vary

depending on the type of connection

(i.e. GPRS, ActiveSync, or WiFi). Please

contact your network operator for

further information.

Windows Live™

With the pre-installed Windows Live™ on

your device, you can access Hotmail, search

the web and synchronize your Contacts.

To Set Up Windows Live™

1. From the Today screen, select Start >

Windows Live.

2. Select Sign in to Windows Live.

3. Read the license agreement then select

Accept.

TIP!

b To avoid typing your name and

password each time you log in, select

the Save Password box.

4. Enter your e-mail address and password

then select Next.

5. Select what you want to sync on your

device then select Next.

6. When ﬁ nished, select Done.

Using Hotmail

1. From the Today screen, select Start >

Windows Live.

2. Select Hotmail.

3. To synchronize e-mail, select Menu >

Send/Receive.53

Applications

Windows Live™ Contacts

After setting up Windows Live™, you can

synchronize Contacts to your device.

To add Windows Live™ contacts

1. From the Today screen, select Contacts

> New.

2. Select Windows Live.

3. Enter the contact information, in the E-

mail ﬁ eld, enter the e-mail address.

4. When ﬁ nished, select Done.

Using Windows Live™ Search

1. From the Today screen, select Start >

Windows Live.

2. Enter the word(s) to search on the search

bar, then press the Enter key.

3. Internet Browser opens and displays the

search results.

Active Sync

ActiveSync synchronizes information on your

device with information on your PC, such

as Outlook content. ActiveSync can also

synchronize over a cellular network with

Microsoft Exchange Server, if your company

or service provider is running Microsoft

Exchange Server with Exchange ActiveSync.

When you synchronize, ActiveSync compares

the information on your device with the

information on your PC and/or Exchange

Server and updates all locations with the

most recent information.

With ActiveSync, you can:

b Synchronize information, such as Outlook

E-mail, Contacts, Calendar, or Tasks

information on your device with your PC,

as well as pictures, video, and music.

b Synchronize Outlook E-mail, Contacts,

Calendar appointments, and Tasks on your

device directly with Exchange Server so

that you can stay up to date even when

your PC is turned off.

b Exchange ﬁ les between your device and

your PC without synchronizing.

Applications

b Select which types of information are

synchronized and specify how much

information is synchronized. For example,

you can choose how many weeks of past

Calendar appointments to synchronize.

Install ActiveSync on your PC. Once

ActiveSync is installed, you can synchronize

your device with the PC. You can download

ActiveSync from the Microsoft’s website

(http://www.microsoft.com) and install it on

your PC. Once you have installed ActiveSync

and set up a synchronization relationship,

ActiveSync on the PC recognizes your device

when you connect it, and automatically

transfers the synchronization settings you

speciﬁ ed on your device.

You may be able to synchronize your device

with Exchange Server through your company

or wireless service provider. If you plan to do

so, obtain e-mail address, Exchange Server

address, user name, password, and domain

name from your administrator before starting

the Sync Setup Wizard.

Setting up Windows Vista™

Instead of ActiveSync, Windows Vista™ uses

the Microsoft Windows Mobile™ Device

Center.

Note

b Some versions of Windows Vista come

with Windows Mobile Device Center

already installed. If Windows Mobile

Device center is not available on your

Windows Vista, you can download it

from Microsoft’s website (http://www.

microsoft.com) and install it on your

PC.

Set up synchronization in Windows

Mobile Device Center

When you connect your device to your PC

and start Windows Mobile Device Center

for the ﬁ rst time, you are asked to create

a Windows Mobile partnership with your

device. Follow the steps below to create a

partnership.

b Connect your device to your PC. Windows

Mobile Device Center conﬁ gures itself and

then opens.

b On the license agreement screen, click

Accept.

b On the Windows Mobile Device Center’s

Home screen, click Set up your device.

Applications

Note

b Choose Connect without setting

up your device if you only want

to transfer media ﬁ les, check for

updates, and explore your device but

not sync Outlook information.

b Select the items you want to synchronize,

then click Next.

b Enter a device name and click Set

Up. When you ﬁ nish the setup wizard,

Windows Mobile Device Center

synchronizes your device automatically.

Notice that Outlook e-mails and other

information will appear on your device

after synchronization.

Use Windows Mobile Device Center

To open Windows Mobile Device Center, click

Start > All Programs > Windows Mobile

Device Center on your Windows Vista

computer. On Windows Mobile Device Center,

you can do the following:

b Click Mobile Device Settings to change

synchronization settings.

b When you click Pictures, Music and

Video > ___ new pictures/video clips

are available for import, a wizard guides

you to tag and transfer photos from

your device to the Photo Gallery on your

Windows Vista PC.

b Click Pictures, Music and Video > Add

media to your device from Windows

Media Player to synchronize music and

video ﬁ les using Windows Media™ Player.

For more information, see “Windows

Media® Player Mobile” in page 112.

b Click File Management > Browse

the contents of your device to view

documents and ﬁ les from your device.

Setting up Windows XP

If you are using Windows XP, download

ActiveSync from Microsoft’s website

(http://www.microsoft.com) then follow the

steps below to install and set up ActiveSync

on your PC.

b Follow the on-screen instructions to install

ActiveSync.

b After installation is completed, connect

your device to your PC using the sync

cable.

- Connect the smaller end of the USB

cable to your LG GW550 device.

Applications

- Connect the larger end of the USB cable

to the USB port on your computer.

b The Synchronization Setup Wizard

automatically starts and guides you to

create a synchronization relationship. Click

Next to proceed.

b To synchronize your device with your

computer, clear the Synchronize directly

with a server running Microsoft Exchange

Server check box, and then click Next.

b Select the information types that you want

to synchronize, and then click Next.

b Click Finish.

When you ﬁ nish the wizard, ActiveSync

synchronizes your device automatically.

Sychronizing Information

When you connect your device to the PC

using a USB or a Bluetooth connection,

ActiveSync will immediately synchronize.

While the device is connected, ActiveSync

synchronizes every time you make a change

on either the PC or the device.

Synchronizing Outlook information

If you have set up a synchronization

relationship between your device and the PC,

synchronization keeps Outlook information

up-to-date on both computers.

ActiveSync synchronizes a limited amount

of information by default to save storage

space on your device. You can change the

amount of information synchronized for a

given information type in Settings for the

information type.

You can set up your device to synchronize

with more than one PC or with a combination

of one or more PCs and Exchange Server.

When synchronizing with multiple computers,

the items that you synchronize will appear

on all of the computers with which they are

synchronized.

For example, if you have set up

synchronization with two PCs (PC1 and

PC2), which have different items, and you

synchronize Contacts and Calendar on the

device with both computers, the result is

as follows:

Applications

Location New state

PC1 All Outlook contacts and

calendar appointments that

were on PC2 are now also

on PC1.

PC2 All Outlook contacts and

calendar appointments that

were on PC1 are now also

on PC2.

Device All Outlook contacts and

calendar appointments

from both PC1 and PC2

are on the device.

To start and stop synchronization

b To synchronize Outlook information

and other local information on the PC,

including media ﬁ les, connect your device

to the PC using Bluetooth or a cable.

b If you are synchronizing directly with the

Exchange Server, you can use the PC

connection to the network that is “Desktop

Pass-through”, or you can synchronize

without connecting to the PC over a

cellular network.

b In ActiveSync, select Sync. To end

synchronization before it completes,

select Stop.

b To change which information is

synchronized

1. In ActiveSync on the device, select

Menu > Options.

2. Do one or both of the following:

b Select the check box for any items

you want to synchronize. If you cannot

select a check box, you might have

to clear the check box for the same

information type elsewhere in the list.

b Clear the check box for any items you

want to stop synchronizing.

3. To stop synchronizing with one PC

completely, select the PC and select

Delete.

Note

b Outlook e-mail can be synchronized

with only one computer. To change

available synchronization settings,

select the type of information and

select Settings.

Applications

To synchronize directly with Exchange

Server

You can set up synchronization with

Exchange Server on your device, if it is

available to you through your company or

wireless service provider. However, you

should ﬁ rst ask your administrator for the

following information and then carry on

with the steps: e-mail address, Exchange

Server address, user name, password, and

domain name.

1. In ActiveSync on the device, select Menu

> Conﬁ gure Server. If you have not yet

set up synchronization with Exchange

Server, this will say Add Server Source.

2. Enter e-mail address, and select Next.

3. In the Server address, enter the address

of the running Exchange Server, check the

box if this Server requires an encrypted

(SSL) connection, and select Next.

4. Enter your user name, password, and

domain, then select Next. To change

the rules for resolving synchronization

conﬂ icts, select Advanced.

5. Select the check boxes for the types of

items that you want to synchronize with

the Exchange Server.

6. To change available synchronization

settings, select the settings desired and

select Settings.

7. Select Finish.

Synchronizing via Bluetooth

You can connect your device to the PC to

synchronize using Bluetooth.

To synchronize with a PC via Bluetooth

1. First, check “Allow connections to one

of the following” of the ActiveSync

connection Settings menu on your PC.

Select the proper COM port.

If there is not an available connection,

then you should make a Bluetooth pairing.

2. Select the Menu > Connect via

Bluetooth.

Applications

Synchronizing Music, Video, and

Pictures

If you want to carry your music or other

digital media with you along while you travel,

ActiveSync works with Windows Media

Player to synchronize music, video, and

pictures.

Other than selecting the Media information

type in ActiveSync to be synchronized, all

media synchronization settings must be set

in Windows Media Player. Before media can

be synchronized, you must do the following:

b Install Windows Media Player Version 10

on the PC.

b Connect your device to the PC with a

USB cable. If the device is currently

connected using Bluetooth, you must

end that connection before media can be

synchronized.

b Insert a storage card into your device

(32MB or larger is recommended).

b Set up a sync partnership between the

storage card and Windows Media Player.

Change Media synchronization

settings

Once you select the Media information type

in ActiveSync to be synchronized, any of

your favorite music, video, and picture ﬁ les

in Windows Media Player playlists can be

synchronised. All you have to do is set up

synchronization in Windows Media Player for

those media ﬁ les.

To set up a sync relationship with a storage

card:

1. Open Windows Media Player.

2. Click the Sync tab.

3. Select the storage card.

4. Click Set up Sync.

For information about using Windows Media

Player on the device, see “Windows Media

Player on page 59.

Applications

Internet Sharing

You can set up your PC to connect to the

Internet using the Internet connection on

your device.

Note

b ActiveSync software version 4.5 or

higher is required.

1. Connect the USB cable to the PC.

2. From the Today screen, select Start >

Internet Sharing.

3. Set PC Connection to USB or Bluetooth

PAN.

4. Set the Network Connection to a proper

APN.

5. Select Connect.

6. A data connection indicator ( /

/) is displayed when PDP activation is

performed successfully.

Note

b The operating system of your PC

must be Windows XP, Service Pack 2

or higher.

Bluetooth Manager

Bluetooth enables compatible mobile

devices, peripherals and computers that are

in close proximity to communicate directly

with each other without wires. Your device

supports built-in Bluetooth connectivity,

which makes it possible to connect it with

compatible Bluetooth headsets, computer

applications and so on.

To Set the Bluetooth Conﬁ guration

1. From the Today screen, select Start >

Bluetooth Manager.

2. Select Yes to turn on Bluetooth. The

Bluetooth Manager Settings page is

displayed.

Applications

Note

b If you use a PC Sync via Bluetooth, you

can exchange data within Contacts.

b When you receive data from another

Bluetooth device, the device requests

a conﬁ rmation. After conﬁ rming the

transfer, the ﬁ le will be copied to you

device.

b You can set the shared folder in

Settings > Advanced... > File

Transfer.

To Make Your Device Discoverable

1. From the Settings page, highlight Not

Discoverable then press the Enter key.

2. Select visibility option (Always Visible,

Visible for 60 seconds, Not Visible).

3. Select Done.

Bluetooth Partnership

A Bluetooth partnership is a relationship

that you create between your device

and another Bluetooth-enabled device in

order to exchange information in a secure

manner. Creating a partnership between two

devices involves entering the same personal

identiﬁ cation number (PIN) or Passkey

on both devices. Creating a partnership

between two devices is a one-time process.

Once a partnership is created, the devices

can recognize the partnership and exchange

information without entering a PIN again.

Make sure the two devices are within a

range of 10 meters from one another, and

Bluetooth is turned on and in discoverable

mode.

Applications

To create a Bluetooth Partnership

1. From the Settings page, select Add a

device.

2. To limit the search, select the type of

device you want to establish connection

with.

Note

b Make sure the other device and its

Bluetooth function is turned on and

discoverable.

3. Select Continue. Your device searches for

the other device.

4. Highlight the device, then select Select.

5. Enter a passkey, then select OK.

Note

b The passkey you enter must also be

the same passkey to be entered on

the other device.

b The passkey must be 1 to 16

characters.

To Accept a Bluetooth Partnership

1. Ensure that the Bluetooth is turned on.

2. When prompted, enter a passkey (the

same passkey that is entered on the

device requesting the partnership) to

establish a secure connection.

3. Select OK.

Services

After establishing connection with a

Bluetooth device, you can activate and set

the conﬁ guration of each Bluetooth proﬁ le.

Select Menu > Update. A list of services

is shown.

b Serial Port: Connect to a wireless serial

port on the device.

b Synchronization: Synchronize contacts

and other PIM items.

b Bluetooth Networking: Share

information or connect to the Internet.

Applications

Settings Page

From the Settings page, the following

options are available:

b Add a Device: Select to set up a new

Bluetooth partnership.

b Disable Bluetooth: Turns Bluetooth off.

b LG-Times: The default device name as

seen by other Bluetooth devices. Select

this option to change the name.

b Not Discoverable/Discoverable: Select

this option to set visibility status of your

device.

b Advanced:

• Connectivity: Select to set the devices

to allow connection.

• Serial Ports: Select to view Bluetooth

serial ports.

• File Transfer: Allows you to conﬁ gure

ﬁ le transfer settings.

• Audio: Allows you to conﬁ gure hands-

free related settings.

• Object Exchange: Allows you to

conﬁ gure Object Push settings.

Accessories Page

The following options are available:

b Networking Manager: Allows you to

network with other Bluetooth devices

(Create a Private Network, Share Internet

Connection, Access Internet through

remote device).

b Business Card Exchange: Allows you

to send and receive business cards from

other devices.

b BT Send Object: Allows you to send

an object, such as an item or items in

Contacts, Outlook E-mail, Calendar, Audio,

Ring Tones, Images, and Videos.

My Devices Page

This page lists all Bluetooth devices that you

have established partnership with.

b To add more devices, select Menu >

Add Device.

b To delete a selected device, select Menu

> Delete.

b To update services, select Menu >

Update.

Applications

Ofﬁ ce Mobile

Excel Mobile

Excel Mobile makes it easy for you to open

and edit Excel workbooks and templates

created on your PC.

To open an Excel ﬁ le

1. From the Today screen, select Start >

Ofﬁ ce Mobile > Excel Mobile.

2. Locate the Excel ﬁ le, then select Select.

To change view options, select View.

For other functions, select Menu.

b Close File: Select to close the ﬁ le and

exit Excel Mobile.

b Edit: Select this option to edit the opened

ﬁ le.

b File: Allows you to save the ﬁ le (Save As),

or send the ﬁ le via e-mail.

b Go to: Allows you to go to a particular cell

or reference name.

b Find: Allows you to ﬁ nd matching word(s)

in the ﬁ le.

b About: View software version.

Unsupported features in Excel Mobile

Excel Mobile does not fully support

some features such as formulas and cell

comments. Some data and formatting may

be lost when you save the workbook on

your device. Note the following Excel Mobile

formatting considerations:

b Alignment. Horizontal, vertical, and

wrap-text attributes remain the same, but

vertical text appears horizontal.

b Borders. Appear as a single line.

b Cell patterns. Patterns applied to cells

are removed.

b Fonts and font sizes. Fonts not supported

by your device are mapped to the closest

font available. The original font is listed

on your device. When the workbook is

opened in Excel on your PC again, the

data is displayed in the original font.

b Number formats. Numbers formatted

using the Microsoft Excel 2007 Version

6.1 conditional formatting feature are

displayed in Number format.

Applications

b Formulas and functions. If an Excel ﬁ le

contains a function that is not supported

by Excel Mobile, the function is removed,

and only the returned value of the

function appears. The following formulas

are also converted to values: formulas

entered as an array or containing an array

argument, for example, =SUM({1;2;3;4});

formulas containing external link

references or an intersection range

reference; and formulas containing

references past row 16384 are replaced

with #REF!

b Protection settings. Most worksheet and

workbook protection features are disabled

but not removed. However, support for

password protection has been removed.

Workbooks that are password-protected

or workbooks in which one or more

worksheets are password-protected

cannot be opened. You must remove the

password protection in Excel on the PC

and then synchronise to open the ﬁ le on

the device.

b Zoom settings. Are not retained. Excel

supports a per worksheet zoom setting,

while the Excel Mobile zoom setting is

applied to the entire workbook.

b Worksheet names. Names that reference

worksheets within the same workbook are

displayed accurately, but names that refer

to other workbooks, arrays, for example,

={1;2;3;4}, array formulas, or intersection

ranges are removed from the name list. If

a name is removed from the list, it is left

in formulas and functions, causing those

formulas to be resolved as “#NAME?”. All

hidden names are not hidden.

b AutoFilter settings. Are removed. However,

you can use the AutoFilter command in

Excel Mobile to perform similar functions.

If you have an AutoFilter applied to a

worksheet that causes rows to be hidden,

the rows remain hidden when the ﬁ le is

opened in Excel Mobile. Use the Unhide

command to display the hidden rows.

b Chart formatting. All charts will be

saved the way they are shown in Excel

Mobile. Unsupported chart types are

changed to one of these supported types:

Column, Bar, Line, Pie, Scatter, and

Area. Background colors, gridlines, data

labels, trend lines, shadows, 3D effects,

secondary axes, and logarithmic scales

are turned off.

b Worksheet features. The following

features are not supported in Excel Mobile

and are removed or modiﬁ ed when a

workbook is opened on the device: hidden

sheets are not hidden; VBA modules,

Applications

macro sheets, and dialog sheets are

removed and replaced with a place

holder sheet; text boxes, drawing objects,

pictures, lists, conditional formats, and

controls are removed; pivot table data is

converted to values.

OneNote Mobile

OneNote Mobile allows you to create notes

with added pictures and recordings.

To create a new note

1. From the Today screen, select Start >

Ofﬁ ce Mobile > OneNote Mobile.

2. Select New.

3. Compose your note.

4. When ﬁ nished, select Done.

For other functions, select Menu.

b Format: Select font style.

b List: Allows you to add or clear bullets

and numbers.

b Take Picture: Select this option to

capture an image and insert to note.

b Insert Picture: Allows you to add a

picture that is saved on your device.

b Insert Recording: Allows you to record

a voice note.

PowerPoint Mobile

With PowerPoint Mobile, you can open

and view slide show presentations created

on your PC in *.ppt and *.pps format with

PowerPoint ‘97 and later.

Many presentation elements built into the

slide shows such as slide transitions and

animations will play back on the device.

If the presentation is set up as a timed

slide show, one slide will advance to the

next automatically. Links to URLs are also

supported.

PowerPoint features not supported on the

device include:

b Notes. Notes written for slides will not

be visible.

b Rearranging or editing slides. PowerPoint

Mobile is a viewer only.

b File formats. Files created in *.ppt format

earlier than PowerPoint ‘97 and HTML

ﬁ les in *.htm and *.mht formats are not

supported.

Applications

To start a slide show presentation

1. From the Today screen, select Start >

Ofﬁ ce Mobile > PowerPoint Mobile.

2. Locate the the slide show you want to

view, then select Select.

If the presentation is set up as a timed slide

show, slides will advance automatically.

To stop a slide show

• In a PowerPoint Mobile presentation,

select End.

To navigate between slides

You can advance to the next slide if a

presentation is not set up as a timed slide

show, return to the previous slide, or go to

any slide out of sequence.

1. From the Today screen, select Start >

Ofﬁ ce Mobile > PowerPoint Mobile.

2. Open the desired presentation.

3. Select Menu > Next or Previous, or Go

to Slide then select the desired slide.

TIP!

b Simply press the left or right

navigation keys to advance to the

next slide or return to the previous

slide.

To zoom the slide show

1. From the Today screen, select Start >

Ofﬁ ce Mobile > PowerPoint Mobile.

2. Open the presentation.

3. Select Menu > Zoom In or Zoom Out.

Word Mobile

Word Mobile is a streamlined version of

Microsoft Word. Word documents created on

your PC can be opened and edited on your

device and save them as *.doc, *.rtf, *.txt,

and *.dot ﬁ les.

You can have only one document open at a

time. To open another document, you have to

close the ﬁ rst one.

When you close a document, the device

will automatically prompt you to save the

document. If you selected to save, you can

rename the document with your preferred

name and move it to another folder or a

storage card.

Word Mobile does not fully support some

features of Microsoft Word such as revision

marks and password protection. Some data

and formatting may be lost when you save

the document on your device.

The following features are not supported in

Word Mobile.

Applications

• Backgrounds

• Shapes and text boxes

• Artistic page borders

• Smart tags

• Metaﬁ les

b Bi-directional text. While Word

Mobile will open documents containing

bi-directional text, the indentations and

alignment may be displayed and saved

incorrectly.

b Password-protected ﬁ les. Word Mobile

does not support opening password-

protected documents. You must ﬁ rst

remove the password protection in

Word on the PC if you want to view the

document on the device.

b Document protection. Word Mobile does

not support displaying ﬁ les that have been

protected in Word on the PC.

The following features are partially supported

in Word Mobile.

b Picture bullets

b Revision marks. When you open a

document that has revision marks in

Word Mobile, the document appears as if

all revision marks were accepted. When

you save the document in Word Mobile,

revision marks are lost.

b Table styles. When you save a document

in Word Mobile, some or all the formatting

that is deﬁ ned in the table style is lost.

b Underline styles. Underline styles not

supported by Word Mobile are mapped to

one of the four supported styles: regular,

dotted, wavy, or thick/bold/wide.

b Legacy Pocket Word ﬁ les. You can open

*.psw ﬁ les in Word Mobile; however, if you

edit a ﬁ le, you will need to save it in *.doc,

*.rtf, *.txt, or *.dot format.

The following features are not supported on

the device; however, they are retained in the

ﬁ le so that when a ﬁ le is opened on the PC

again, they appear as expected.

b Footnotes, endnotes, headers, footers.

b Page breaks: Word Mobile does not

display breaks between pages. However,

all page breaks except for breaks at the

end of a document are retained in the

document.

b Lists: When you open the document on

the computer again, indented lists are

displayed in the original form.

b Fonts and font sizes. Fonts not supported

by the device are mapped to the closest

font available, although the original font

will be listed on the device.

Applications

Adobe Reader LE

Adobe Reader® LE is an application for

viewing PDF (Portable Document Format)

ﬁ les on your device.

To open a PDF ﬁ le

1. From the Today screen, select Start >

Adobe Reader LE.

2. Browse for the PDF ﬁ le you want to open,

then select Open.

3. To zoom the ﬁ le, select Tools > Zoom.

4. To close the application, select Menu

> Exit.

Task Manager

In most cases, programs automatically close

to free up needed memory, however, you

can close programs manually using Task

Manager.

1. From the Today screen, select Start >

Accessories > Task Manager.

2. You can check the list of running

programs, memory and CPU information.

3. You can end the programs manually by

highlighting a program and selecting

End Task.

4. To close all running programs, select

Menu > End All Tasks.

5. You can change the way programs are

viewed or ordered by selecting Menu >

View or Sort by.

6. To close Task Manager, select Menu

> Exit.

MSN Money

Allows you have quick access to MSN

Money and view the latest stocks exchange

information on your device.

Note

b Before accessing MSN Money, make

sure your device has a GPRS SIM card

installed.

b Additional costs may be incurred when

using this service.

Applications

MSN Weather

Allows you to connect to the Internet and

view the latest weather forecast from MSN

Weather.

Note

b Before accessing MSN Weather, make

sure your device has a GPRS SIM card

installed.

b Additional costs may be incurred when

using this service.

GPSExtra

Allows you to download GPS data and to

enhance GPS peroformance.

Note

b Before accessing GPSExtra, make

sure your device has a GPRS SIM card

installed.

b Additional costs may be incurred when

using this service.

Java

Your device supports Java and hence you

can easily download java games and other

java applications from the internet.

Note

b Additional costs may be incurred when

using this service.

Marketplace

Windows® Marketplace for mobile is a new

marketplace that will provide direct-to-phone

mobile applications and can be accessed

from both the phone and the Web.

b From the Today screen, select Start >

Marketplace.

Note

b Before accessing Marketplace, make

sure your device has a GPRS SIM card

installed.

b Additional costs may be incurred when

using this service.

Applications

Microsoft My Phone

Microsoft® My Phone synchronizes your

phone’s contacts, calendar, tasks, text

messages, music, photos, videos, and other

documents with your My Phone account at

http://myphone.microsoft.com.

To Conﬁ gure My Phone

1. From the Today screen, select Start >

Microsoft My Phone.

2. Select Next.

3. Read the license, then select Accept.

4. Sign in your Windows Live ID, then select

5. Select synchronization method: Manual or

Automatic, then select Next.

6. Select Finish to start synchronization.

Note

b Before accessing Microsoft My Phone,

make sure your device has a GPRS

SIM card installed.

Remote Desktop

Remote Desktop provides remote access

to the desktop of your computer running

Windows XP Professional, from your device.

Using Remote Desktop you can, for example,

connect to your ofﬁ ce computer from home

and access all your applications, ﬁ les, and

network resources as though you were in

front of your computer at the ofﬁ ce.

b From the Today screen, select Start >

Remote Desktop.

RSS Viewer

RSS Viewer is an application that allows you

to subscribe to RSS feeds and view them on

your device.

To Subscribe to RSS Feeds

1. From the Today screen, select Start >

RSS Viewer.

2. Select Menu > Add Channel.

3. Enter the URL and Channel name and set

folder location, select Done.

Applications

To Update RSS Feeds

1. Highlight the folder or channel then press

the Enter key. A check mark appears on

the folder / channel box.

2. Select Menu > Update to start updating.

To View RSS Feeds

1. Highlight the channel then select View.

2. Highlight the news feed you want to view

from the list.

3. Press the Enter key to view the rest of

the story.

4. You can view the next or previous news

feed on the list by selecting Menu > Next

or Previous.

5. If you wish to view the news feed with

Internet Explorer, select Menu > Open

with IE.

6. To refresh page, select Menu > ReLoad.

7. To return to list view, select List View.

Note

b Additional costs may be incurred when

using this service.

Search Widget

Search Widget allows you to search the

Internet using Live Search. With just a click

of a button, you can launch Live Search in a

standalone window.

b From the Today screen, select Start >

Search Widget.

Note

b Before accessing Microsoft My Phone,

make sure your device has a GPRS

SIM card installed.

b Additional costs may be incurred when

using this service.

File Explorer

The File Explorer application allows you to

open an explorer window similar to a desktop

Windows based system. The explorer window

allows you to navigate through your phone to

locate desired folders and ﬁ les.

You can also quickly manage, delete, copy,

or edit any ﬁ les and folders on your phone

and create new folders.

To access File Explorer, from the Today

screen, select Start > File Explorer.

Applications

b If you want to see the ﬁ les or folders in

the My device or Storage Card folder,

select either of the two.

b To view the ﬁ les or folders in the phone’s

memory, highlight the ﬁ les or folders

that you want to view, then press the

Enter key.

b Select the folder category (labelled My

Documents by default) and then the folder

that you want to view.

Voice Notes

Voice Notes allows you to record your voice

notes.

To create a new voice note

1. From the Today screen, select Start >

Voice Notes.

2. Select Record to start recording.

3. Select Stop to stop recording. The

recording is automatically saved with a

default ﬁ le name.

4. To close voice notes, press .

To listen to the voice note

1. From the Today screen, select Start >

Voice Notes.

2. Select Menu > Play to playback

recording.

To rename the ﬁ le

1. From the Today screen, select Start >

Voice Notes.

2. Highlight the recording from the list.

3. Select Menu > Rename to rename

the ﬁ le.

4. Enter the new name, then select Done.

To set recording as ringtone

1. From the Today screen, select Start >

Voice Notes.

2. Select Menu > Set as ringtone.

To delete recording

1. From the Today screen, select Start >

Voice Notes.

2. Highlight the recording that you want to

delete from the list.

3. Select Menu > Delete.

Applications

Calendar

To Add an Event to your Calendar

1. From the Today screen, select Start >

Calendar.

2. Select the desired date.

3. Select Menu > New Appointment.

4. Type in the subject and location of the

event and check the date and enter time

you would like your event to begin.

5. Check other information below.

6. When ﬁ nished writing your note, select

Done.

To Change your Default Calendar View

1. From the Today screen, select Start >

Calendar.

2. Select Menu > Day View / Week View /

Month View / Agenda View.

Tasks

Use Tasks to keep track of things you need

to do. A task can occur once or repeatedly

(recurring). You can set reminders for your

tasks and you can organize them using

categories.

Your tasks are displayed in a task list.

Overdue tasks are displayed in red.

To Create a Task

1. From the Today screen, select Start >

Tasks.

2. Select Menu > New Task.

3. Enter a subject for the task, and ﬁ ll in

information such as start and due dates,

priority, and so on.

4. When ﬁ nished, select Done.

Note

b You can easily create a short, to-do-

type task. Simply enter the text on the

Enter new task here bar.

To Change the Priority of a Task

Before you can sort tasks by priority, you

need to specify a priority level for each task.

1. From the Today screen, select Start >

Tasks.

2. Select the desired task, then select Edit.

3. In the Priority box, select a priority level.

4. Select Done to return to the task list.

Note

b All new tasks are assigned with

Normal priority by default.

Applications

To Set a Default reminder for all New

Tasks

You can have a reminder automatically

turned on for all new tasks you create.

1. From the Today screen, select Start >

Tasks.

2. Select Menu > Options.

3. Check the Set reminders for new

items box.

4. Select Done to return to the task list.

Note

b The new tasks must have due dates

set in order for the reminder to take

effect.

To Show Start and Due Dates in the

Task List

1. From the Today screen, select Start >

Tasks.

2. Select Menu > Options.

3. Check the Show start and due dates

box.

4. Select Done to return to the task list.

To Locate a Task

When your list of tasks is long, you can sort

the list to quickly ﬁ nd a speciﬁ c task.

1. From the Today screen, select Start >

Tasks.

2. In the task list, do one of the following:

b Sort the list. Select Menu > Sort by,

then select the sort option.

b Filter the list by category. Select Menu

> Filter, then select the category you

want displayed.

Note

b To ﬁ lter your tasks further, select

Menu > Filter > Active Tasks or

Completed Tasks.

Calculator

The calculator function allows you to add,

subtract, multiply and divide. You can input

numbers using the number keys, and input

operators using button keys.

b From the Today screen, select Start >

Accessories > Calculator.

Applications

Stop Watch

Stop watch allows you to start and stop time

for exact timing.

1. From the Today screen, select Start >

Stop Watch.

2. To start timing, select Start. The running

time is displayed as HH.MM.SS.hh

(hours, minutes, seconds, hundredths of

a second).

3. During the timing, you can record an

individual lap time by selecting Lap. The

lap times are listed on screen. Up to 99

lap times can be recorded.

4. To stop timer, select Stop.

5. You can either resume or reset the

stopwatch by selecting Resume or Reset.

Games

In the Games submenu, Windows games

like Bubble Breaker and Solitaire, have been

already been pre-installed on your device.

b From the Today screen, select Start >

Games, then select the desired game.

XT9 Dictionaries

The XT9 Dictionaries allows you to add your

own words into the My Words XT9 dictionary.

It also allows you to conﬁ gure automatic

substitution.

To add a word in XT9

1. From the Today screen, select Start >

XT9 Options > XT9 Dictionaries.

2. Select My Words XT9, then press the

Enter key.

3. Select Add.

4. Type the word to add in the dictionary,

then select Done.

5. To close My Words function, select Menu

> Exit.

To edit a word in XT9

1. From the Today screen, select Start >

XT9 Options > XT9 Dictionaries.

2. Select My Words XT9, then press the

Enter key.

3. Highlight the word you want to edit, then

select Menu > Edit.

4. Type the word to add in the dictionary,

then select Done.

Applications

To delete a word in XT9

1. From the Today screen, select Start >

XT9 Options > XT9 Dictionaries.

2. Select My Words XT9, then press the

Enter key.

3. Highlight the word you want to delete,

then select Menu > Delete.

4. To delete all the words in the My Words

list, select Menu > Delete All. Select Yes

to conﬁ rm.

To add auto-substitution shortcut

1. From the Today screen, select Start >

XT9 Options > XT9 Dictionaries.

2. Select Auto-Substitution XT9, then press

the Enter key.

3. To add a shortcut, select Add.

4. Type the shortcut word and the word to

substitute, then select Done.

To edit auto-substitution shortcut

1. From the Today screen, select Start >

XT9 Options > XT9 Dictionaries.

2. Select Auto-Substitution XT9, then press

the Enter key.

3. Highlight the word to edit, then select

Menu > Edit.

4. Type the shortcut word and the word to

substitute, then select Done.

To delete auto-substitution shortcut

1. From the Today screen, select Start >

XT9 Options > XT9 Dictionaries.

2. Select Auto-Substitution XT9, then press

the Enter key.

3. Highlight the word to delete, select Menu

> Delete.

Settings XT9

Use XT9 Settings to select the dictionary

language and other word prediction settings.

1. From the Today screen, select Start >

XT9 Options > Settings XT9.

2. In the Language list, select the desired

language. Options are: English,

Portuguese, Spanish, French, Italian, and

German.

3. In the Word Completion Point list, select

how many typed letters do you want the

dictionary to start word completion.

4. To enable other options, check their

corresponding boxes.

5. When ﬁ nished, select Done.

Settings

To conﬁ gure the settings on your device,

from the Today screen, select Start >

Settings, then select the settings category.

Phone

You can edit the general settings related to

making and receiving calls.

Auto Answer

Set how quickly calls are automatically

answered during hands-free operation. This

setting does not apply when the ring type

is Silent.

Band Switch

You can change the settings related to

Network.

Call Barring

You can set restrictions for the following

calls:

b Block incoming calls: All calls/When

roaming/Off.

b Block outgoing calls: All calls/

International/International except to home

country/Off.

To edit mobile call barring settings, you need

a password. You obtain the barring password

from your service provider upon subscription

to this network service.

Call barring affects all voice and data calls,

except emergency calls.

Call Forwarding

Allows you to forward your incoming calls to

another phone number.

Call Options

You can conﬁ gure the following options:

b Any key answer: Check the box to

answer a call by pressing any key.

b Show SIM contacts: Check the box to

display your contacts saved in the SIM

card.

b Voice mail number: Call the voice mail

number to listen to your voice messages.

Voice mail number is automatically

conﬁ gured upon receiving network service

from your service provider.

b Text messages service center: Service

center number for all text messages. The

service center number is automatically

conﬁ gured upon receiving network service

from your service provider.

b Country code: Enter the country code in

your location.

b Area code: Enter the area code in your

location.

Settings

Call Waiting

To be notiﬁ ed of incoming calls while you

have a call in progress, check Provide call

waiting notiﬁ cations, then select Done.

Caller ID

To display your phone number to the person

you are calling, select Everyone. Select No

one to hide it.

Channels

Allows you to receive cell broadcast

messages.

Fixed Dialing

Allows you to limit outgoing calls in certain

formats.

Networks

Displays the current network and allows you

to select the manner of selecting networks.

Current network

The current network displays in the Current

network ﬁ eld.

Network selection

Deﬁ ne how to choose between different

available networks when travelling, for

example.

b Manual: You can select the network

yourself.

b Automatic: To have the network selected

automatically.

Preferred network

To select other networks, from the Networks

page, select Menu > Preferred network

(retrieving settings may take a few minutes).

Select a network and re-order the priorities

for network usage by selecting Menu >

Move Up or Move Down.

Pre-Deﬁ ned Text Messages

Your device has pre-deﬁ ned text messages

that you can send a caller when you cannot

answer a call.

To edit pre-deﬁ ned text message

1. Highlight the pre-deﬁ ned text message,

then select Select.

2. Edit the message.

3. When ﬁ nished, select Save.

Ringer Output

Sounds

b Ring tone: You can select the ringtone for

incoming voice calls.

b Reminders: You can select the alert tone

for reminder.

Settings

b New e-mail: You can select the alert

tone that sounds when a new e-mail is

received.

b New text message: You can select the

alert tone that sounds when a new text

message is received.

b New voice message: You can select the

alert tone that sounds when a new voice

message is received.

b New instant message: You can select

the alert tone that sounds when a new

instant message is received.

b New channel message: You can select

the alert tone that sounds when a new

channel message is received.

b SIM toolkit messages: You can select

the alert tone that sounds when SIM

toolkit messages are received.

b Exclamation: You can select the alert

tone that sounds when the device pops up

information.

b Question: You can select the alert tone

that sounds when the device prompts the

user with a question.

b Warnings: You can select the alert tone

that sounds when the device displays a

warning message.

b Keypad control: You can set the key tone

when keys are pressed.

Proﬁ les

Your device comes with ﬁ ve pre-set proﬁ les.

You can adjust and customise the ringing

tones, alert tones, and other device tones

for different events, environments, or caller

groups.

To edit the proﬁ le

1. Highlight the proﬁ le.

2. Select Menu > Edit.

3. Enter the name and select your desired

ringer and alert settings.

4. When ﬁ nished, select Done.

To change the active proﬁ le

Highlight the proﬁ le and press the Enter key.

The checked proﬁ le name indicates the

current proﬁ le in use.

Home Screen

You can change how you want the Today

screen to look. The Today screen can show

your upcoming appointments, active tasks,

and information about calls and messages.

Settings

To Select Information Shown On

Screen

1. From the Today screen, select Start >

Settings > Home Screen.

2. On Home screen layout, select your

desired layout option:

b Sliding Panel: This is the default screen.

b Sliding Panel Media: Select to display

media application shortcuts on the screen.

b Windows Simple

b Windows Default

b Large Font

b Windows Basic

b Windows Live Default: Select to include

Windows Live search bar and other

Windows Live feature shortcuts on screen.

3. To display the recently opened programs

when Start is selected, check Show

Recent Programs.

4. When ﬁ nished, select Done.

To Add Own Background Image

You can use one of your own pictures as the

background image on the Today screen.

1. From the Today screen, select Start >

Settings > Home Screen.

2. In the Background image box, use the

navigation keys to select an image to use

as background.

3. When ﬁ nished, select Done.

To Set Screen Timeout

To deﬁ ne how long the backlight remains on:

1. From the Today screen, select Start >

Settings > Home Screen.

2. In the Time out box, use the navigation

keys to select a time out option.

3. When ﬁ nished, select Done.

Clock & Alarm

Clock & Alarm can accessed by either of the

following:

b From the Today screen, select Start >

Clock & Alarm.

b From the Today screen, select Start >

Settings > Clock & Alarm.

Settings

Date and Time

You can view the time, day of the week

and date.

1. From the Clock & Alarm screen, highlight

Date and Time, then press the Enter key.

2. Select the Time zone. Set the date and

time.

3. To update the time, date, and time zone

information automatically, check Sync to

current time zone.

4. When ﬁ nished, select Done.

Alarm

1. From the Clock & Alarm screen, highlight

Alarm 1 or 2, then press the Enter key.

2. Set the alarm time, frequency, sound, type,

and volume.

3. When ﬁ nished, select Done.

Connections

The Connections menu allows you to setup

various types of connections such as Wi-Fi,

Bluetooth, Dial-Up, GPRS, and others.

Wireless Manager

Wireless Manager provides shortcuts

to access Wi-Fi, Bluetooth, and Phone

connection settings.

Note

b The charge between using a data

plan to access the internet and using

Wi-Fi is different. Please contact

your network operator for further

information.

Wi-Fi

1. From the Today screen, select Start >

Settings > Connections > Wireless

Manager.

2. To turn on, highlight the Wi-Fi bar, then

press the Enter key.

3. The device prompts you whether you

want to view available networks in range,

select Yes.

4. Select the network and select “Internet”

for the type of connection.

5. When ﬁ nished, select Connect.

Settings

Note

b If your Wi-Fi service provider or

network administrator sets WEP

encryption for network security, you

should ﬁ ll in WEP key in the pop-up

window. If WEP encryption is not set,

this pop-up window is not shown.If

you don’t know the key, you need to

ask it to your Wi-Fi service provider or

network administrator.

6. Enter the required network key, then

select Done.

7. If Wi-Fi connection is established, you can

see the connection name (SSID) in the

Wireless Manager.

8. To turn off Wi-Fi, select Wi-Fi in the

Wireless Manager again.

Conﬁ guring Wi-Fi Connection

Settings

Note

b Before you set the WLAN conﬁ guration,

you need to ask your WLAN service

provider or your network administrator

for the IP settings.

1. From the Today screen, select Start >

Settings > Connections > Wireless

Manager.

2. Select Menu > Wi-Fi Settings > Menu

> Advanced.

3. Enter the necessary network information

and connection preferences.

4. When ﬁ nished, select Done.

To check WLAN status

1. From the Today screen, select Start >

Settings > Connections > Wireless

Manager.

2. Select Menu > Wi-Fi Settings. The list

of available Wi-Fi connections and their

status are displayed.

b To add a new Wi-Fi connection, select

Menu > Add.

b To edit a Wi-Fi connection conﬁ guration,

select Menu > Edit.

Settings

Bluetooth

1. From the Today screen, select Start >

Settings > Connections > Wireless

Manager.

2. To turn on/off, highlight the Bluetooth bar,

then press the Enter key.

3. To conﬁ gure settings, select Menu >

Bluetooth Settings. The Bluetooth

Manager program launches, see

“Bluetooth Manager” on page 75.

Phone

1. From the Today screen, select Start >

Settings > Connections > Wireless

Manager.

2. To turn on/off, highlight the Phone bar,

then press the Enter key.

3. To conﬁ gure phone settings, select Menu

> Phone Settings.

Security

Device Lock

You can keep your data more secure by

requiring a password every time the device

is turned on or when waking up from idle

mode.

1. From the Today screen, select Start >

Settings > More > Security > Device

Lock.

2. Check the Prompt if phone unused for

box, then select the idle time.

3. Set the password type and enter your

desired password.

4. Re-enter the password to conﬁ rm.

5. When ﬁ nished, select Done.

Note

b When the device locks, you will be

prompted to enter the password to

unlock.

Settings

To Protect your Phone with a PIN

You can protect your phone from

unauthorized use by assigning a type of

password called a PIN (personal identiﬁ cation

number). Obtain the PIN from your wireless

service provider; you can change the PIN at

a later time.

b From the Today screen, select Start >

Settings > More > Security > Enable

SIM PIN.

To Change your Password

b From the Today screen, select Start >

Settings > More > Owner Information.

To Enter Owner Information

Saving your contact information on your

device allows for easy identiﬁ cation of the

device in case it is lost.

b From the Today screen, select Start >

Settings > More > Owner Information.

Remove Programs

To free up space on your device’s memory,

remove unnecessary programs which are not

pre-installed on your device.

b From the Today screen, select Start >

Settings > More > Remove Programs.

Power Management

Use Power Management to see current

battery status and conﬁ gure battery usage to

save on power.

1. From the Today screen, select Start >

Settings > More > Power Management.

2. Set the backlight and display time out.

3. When ﬁ nished, select Done.

LG Electronics USA GW550 Cellular/PCS WCDMA/GSM/EDGE Phone with WLAN and Bluetooth User Manual GW550 0813 indd

LG Electronics USA Cellular/PCS WCDMA/GSM/EDGE Phone with WLAN and Bluetooth GW550 0813 indd

Users Manual

Navigation menu

Namespaces

Views

Navigation
