LG Electronics USA HBS800 Bluetooth Stereo Headset User Manual
LG Electronics USA Bluetooth Stereo Headset
User manual
English
Español
Rev 1.0 US
All rights reserved.
LG Electronics Inc., 2013
Note: Please read all information carefully prior to
using HBS-800 in order to prevent damages to the
product and to enjoy the best performance.
WARNING :
This product contains chemicals known to the State
of California to cause cancer and birth defects or
reproductive harm.
Wash hands after handling.
HBS-800 User Manual
BLUETOOTH® Stereo Headset
2
ENG
Introduction 3
- Included in the package 3
Description of Parts 3
How to Use 4
- Charging 4
- Low Battery 4
- Battery Status Alert 4
- Power On / Power Off 4
- Pairing 4
- NFC - Near Field Communication 5
- ANC - Ambient Noise Cancelling 6
- Multi-connection 7
- Auto Reconnect 8
- Audio Streaming Controls 8
- Equalizer 9
- aptX
®
9
- Volume Control 9
- Calling 9
- SMS reader 10
Summary of Button Functions 11
LED Indicator 12
Troubleshooting 12
Specification 13
Precautions 13
Declaration of Confirmation 14
Additional Information 14
Limited Warranty 17
Important Safety Information 17
Table of Contents
3
ENG
Included in the Package
Headset
The LG TONE+TM (HBS-800) is a light weight wireless headset that uses Bluetooth®
technology.
This product can be used as an audio accessory for devices supporting either the
A2DP or Hands-Free Bluetooth
Earbuds
(2 Sets)
Charger User Manual Warranty Card
Introduction
Description of Parts
HBS-800
VOLUME UP Button
REWIND Button
ANC Switch
FAST FORWARD Button
PLAY / PAUSE / STOP Button
Earphone (R)
Charging Port
LED Indicator
Power Switch
VOLUME DOWN Button
CALL Button
Microphone
Earphone (L)
Memory Flex Neck Strap
4
ENG
Charging
- When the charger is connected, with the power switched on or off, the headset
will turn off.
- While charging, the LED indicator will show a solid red light.
- When charging is complete, the LED indicator will turn off.
Low Battery
- A low battery alert will play once every 2 minutes.
- If the battery is not charged, the headset will turn off.
Power On / Power Off
- Slide the power switch to the ‘ON’ or ‘OFF’ position.
Pairing
device.
- There are 2 pairing mode methods with the HBS-800.
1) Easy Pairing
a) Slide the power switch to the “ON” position.
If it has been paired but no paired device is in range it will enter pairing mode
after 10 seconds.
How to Use
Battery Status Alert
- Press and hold the VOLUME DOWN button for 1 second to check the battery
status of the HBS-800. The audible battery status alert will inform you of the
battery level. There are 3 levels of battery power:
1. Battery High
2. Battery Medium
3. Battery Low
- An HBS-800 battery status indicator will appear on the iPhone screen.
5
ENG
devices.
d) Select “LG HBS800 H01 S01” from the list of devices.
e) If asked for a Password/Pin Code enter 0000 (4 Zeros).
f) Once the devices are paired, you will hear “Headset paired”.
2) Manual Pairing (pairing with another phone or re-pairing)
a) With the power off, press the CALL button and slide the power switch to the
‘ON’ position. Hold the CALL button for about 2 seconds.
b) When the headset enters Pairing Mode, the LED indicator will show a solid
blue light. After the procedure repeat Easy Pairing steps “c)” through “f)”.
NFC - Near Field Communication
Near Field Communication is short-range wireless technology.
It helps you to pair/connect Bluetooth easily.
Note : If your phone does not support NFC, pair the headset manually. (See the
Pairing method on page 4,5). For details on NFC, see the user guide of your phone.
NFC
1) NFC Pairing & connection
a) Turn on NFC and Bluetooth on the phone you want to pair with the HBS-800.
b) Turn the HBS-800 on.
c) Touch the NFC area of HBS-800 with the NFC area of phone.
d) The HBS-800 will connect to the NFC and Bluetooth enabled phone automatically.
2) Connect & disconnect
Touch HBS-800 to connect or disconnect with NFC and Bluetooth activated phone.
Touch the NFC area of the HBS-800 and phone to disconnect/connect.
How to Use
6
ENG
How to Use
ANC - Ambient Noise Cancelling
Ambient Noise Cancelling is new technology that reduces ambient noise in a
noisy environment. It provides a better listening experience to you.
1) Performance
Ambient Noise Cancelling reduces more than 95% of ambient noise on buses,
trains, and airplanes. Its effect may depend on the noisy environment.
2) Activating / deactivating
a) Slide the ANC switch to the “ON” position.
b) The LED indicator will show a solid violet light and you will hear “ ANC On”.
c) Slide the ANC switch to the “OFF” position to deactivate the Ambient Noise
Cancelling feature. You will hear “ANC off”.
d) Noise Cancelling available Headset off status.
You can see the solid violet lighting but it’s not play Voice Prompt - “ANC
On” and “ANC Off”HBS-800 will enter pairing mode.
Status ANC On ANC Off
LED Indicator Voice Prompt LED Indicator Voice Prompt
Power on
Violet “ANC On” Blue “ANC Off”
Power off Violet X X
X
3) Precautions when using Ambient Noise Cancelling
a) The Ambient Noise Cancelling feature optimizes noisy environments, such
as buses, trains, and airplanes. There is no need to use this feature in a
quiet environment.
b) Be extra cautious while walking, bicycling, or driving. You may not hear
warning signals or alarms.
c) The ANC performance might vary depending on how the headset is placed
into the ear.
7
ENG
Multi-connection
Advanced Multipoint
The HBS-800 is capable of having two devices connected to the headset at the
same time. This will give you the freedom of using call waiting between calls on
both of your connected phones.
Connection
1. Pair the headset with one of your Bluetooth-enabled phones. (per the pairing
instructions on page 6).
2. Turn the headset off and use the Manual Pairing method as described on page
5 to enter Pairing Mode.
3. Now, pair and connect the headset with your other Bluetooth-enabled phone.
(this will be your primary phone).
4. Once this phone is paired and connected, go back and connect the originally
paired phone to the headset. This will now be your secondary phone.
* NOTE: When the HBS-800 is connected to two phones at the same
time(Multipoint), the headset calling functions will work with the primary phone.
* NOTE: In case of failure to connect to the primary phone through Easy Pairing,
HBS-800 will enter pairing mode.
Calling Function
- Voice Dialing and Last Number Redial features work with the primary phone (or
phone which made the last outgoing call).
Call Waiting
- While speaking on an active call, press and hold the CALL button for 1 second to
switch to an incoming call.
- To switch between 2 active calls, press and hold the CALL button for 1 second.
- If both phones are receiving an incoming call, the headset will default to the
primary device.
How to Use
8
ENG
How to Use
Auto Reconnect
- If the HBS-800 is turned off (either accidentally or intentionally) while connected
to a phone, the headset and phone will disconnect. The phone and phone will
automatically reconnect when the HBS-800 is turned back on while in range.
- The secondary phone will need to be connected manually. Select “LG HBS-800”
from the list of devices in the Bluetooth menu and pair.
Out of Range
- If the paired devices are separated by a range of 33 feet (10 meters) or more,
the headset and phone will disconnect and the HBS800 will vibrate to alert you.
- If the headset and phone do not automatically reconnect when they are back within
manually.
- While in multi-connection and streaming, the inactive paired device, which is out
of range, will be disconnected. The HBS-800 will alert you once with no attempt to
reconnect.
Audio Streaming Controls
Play
Pause
Stop
- While playing music, press and hold the PLAY/PAUSE/STOP button for 1
second.
Next song
Previous song
Fast Forward
- Press and hold the Fast Forward button.
Rewind
- Press and hold the REWIND button.
9
ENG
Volume Control
- Press the VOLUME UP or VOLUME DOWN button to adjust the speaker volume.
- There are eight levels of speaker volume in Hands-Free mode.
- There are eight levels of speaker volume in Audio Streaming mode.
aptX®
- The HBS-800 features aptX® technology that ensures audio content transmitted
over Bluetooth is instant and crystal-clear.
- aptX® is automatically enabled as long as the source device supports it.
Calling
Answering a Call
- When there is an incoming call, the headset will ring and vibrate.
Transferring a Call
- If you make a call from the phone, the call will (depending on the phone settings)
automatically transfer to the headset. If the call is not automatically transferred, you can
manually transfer the call to, or from, the headset by pressing and holding VOLUME
UP button for 3 seconds on the HBS-800 (phone and headset must be paired).
Voice Dialing
record the voice dialing tag through your headset.
NOTE: If your phone does not support voice dialing, this action may activate Last
Number Redial.
Last Number Redial
- Press and hold the CALL button for 1 second to activate “Last Number Redial”.
The headset will beep and then call the last number dialed.
Equalizer
- While playing music, press and hold the VOLUME UP and VOLUME
DOWN buttons simultaneously for 1 second to switch between EQ’s (Bass
Boost(Default) J Normal J Treble Boost).
- The bass coming from the speakers can vary as a result of the size of the earbud
that is being used.
How to Use
10
ENG
Ending a Call
Call Waiting
CALL button for 1 second. Press and hold the CALL button for 1 second to return
to the original call.
Rejecting a Call
- Activate call reject by pressing and holding the CALL button for 1 second when
the phone rings.
* These functions may only be used if your phone supports them. For further
information about using these features, please consult your phone’s user manual.
Mic Mute
- Press and hold the VOLUME UP and VOLUME DOWN buttons simultaneously
for 1 second to mute/unmute the mic during conversation.
SMS Reader
The HBS-800 Bluetooth headset supports SMS reading on Android TM based devices.
Search the Google Play™ Store for the LG ‘BT Reader’ application and install on
your device to use this function.
* The QR code shown below helps you download the LG ‘BT Reader’ application
from the Google Play™ Store. Google Play is a trademark of Google, Inc.
How to Use
11
ENG
Function
HBS-800 Status
Action
Power on Power off Slide the power switch to the ‘ON’ position.
Power off Power on Slide the power switch to the ‘OFF’ position.
ANC on
ANC off Power on/off Slide the ANC switch to the “On” position.
Slide the ANC Switch to the “ Off” position.
Volume up Talking/Playing music
Volume down Talking/Playing music
Transferring a call Talking Press and hold VOLUME UP button for 3 seconds.
Answering a call Ringing
Stop incoming call
vibration alerting Ringing
Ending a call Talking
Call waiting Talking Press and hold CALL button for 1 second.
Last number redial Idle Press and hold CALL button for 1 second.
Voice dialing
(phone must support) Idle
Call reject Ringing Press and hold the CALL button for 1 second.
Mic mute on/off Talking Press and hold the VOLUME UP and VOLUME DOWN
buttons simultaneously for 1 second.
Pairing mode (Manual) Power off Press the CALL button and slide the power switch to the
‘ON’ side. Hold the CALL button for abou 2 seconds.
Battery status check Idle Press and hold the VOLUME DOWN button for
1 second.
Play Power on
Pause Playing music
Stop Playing music Press and hold the PLAY/PAUSE/STOP button for
1 second.
Next song Playing music
Previous song Playing music
Fast forward Playing music Press and hold the Fast Forward button.
Rewind Playing music Press and hold the REWIND button.
Equalizer settings Playing music Press and hold the VOLUME UP and VOLUME DOWN
buttons simultaneously for 1 second.
Pairing/Connect/
Disconnect Power on Tough the each NFC area of the HBS-800 and phone.
Summary of Button Functions
12
Function HBS-800 Status Action
Operating
Power on
Power off
turns off.
ANC on
The solid violet LED light stays on.
Pairing mode The solid blue LED light stays on.
Headset / hands-free
seconds.
Call connected
seconds.
Charging Charging The red LED stays on.
Charging complete
LED turns off.
Issue Possible problem Resolution
Does not turn on Check whether the battery of
the HBS-800 is fully charged. Charge the battery.
Unable to
communicate with
the LG Bluetooth
®
Headset HBS-800
Check whether the phone
supports the headset or
Determine whether your phone
supports the headset or hands-
Check whether the battery of
the HBS-800 is low.
Charge the battery.
Unable to pair the
HBS-800 with the
Bluetooth
®
device
Check and make sure the
headset is on.
Slide the power switch to the ‘ON’
position to turn on the headset.
Check and make sure the
headset is placed in pairing
mode.
With the power off, press the
CALL button and slide the power
switch to the ‘ON’ side. Hold the
CALL button for about 2 seconds
to manually place the headset in
pairing mode.
Low sound (speaker) Check the speaker volume. lncrease the volume level.
ENG
LED Indicator
Troubleshooting
13
ENG
Item Description
Bluetooth
®
Battery
Battery 3.7V / 195mAh Li-Polymer
Talk Time Up to 10Hrs
Music play time Up to 10Hrs
Standby time Up to 400Hrs
ANC time Up to 12Hrs
Charging time < 2.0Hrs
Operation temperature 14°F ~ 140°F (-10°C ~ 60°C)
Dimension / weight 135.6mm(W) X 160mm(L) X 14mm(T) / 30g
Do not drop the device.
Do not modify, repair, or disassemble.
Do not expose directly to water, alcohol, benzene, etc for cleaning.
Keep the device away from excessive humidity and dust.
Do not place heavy objects on the device.
Only charge the headset with an original LG charger, otherwise it may be damaged.
compliance could void the user’s authority to operate the equipment.
strap repeatedly is not recommended.
Precautions
14
1. Radio frequency exposure
This Bluetooth® Stereo Headset HBS-800, is a radio transmitter and receiver.
When in operation it communicates with a Bluetooth® equipped mobile device
(microwaves) in the frequency range 2.4 to 2.4835 GHz. The output power of the
radio transmitter is low. Your Bluetooth® Headset is designed to
operate in compliance with the RF exposure guidelines and limits set by national
authorities and international health agencies when used any compatible LG
Electronics mobile phone.
FCC NOTICE TO USERS:
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
IMPORTANT NOTE:
To comply with the FCC RF exposure compliance requirements, no change to
the antenna or the device is permitted. Any change to the antenna or the device
could result in the device exceeding the RF exposure requirements and void
user’s authority to operate the device.
CE NOTICE TO USERS:
Hereby, LG Electronics Inc. declares that this HBS-800 is in compliance with
the essential requirements and other relevant provisions of Directive 1999/5/
EC.
FCC ID: BEJHBS800
1177
ENG
Additional Information
15
ENG
2. Potentially explosive atmosphere
Turn off your electronic device when in any area with a potentially explosive
atmosphere. Although this is uncommon, your electronic device could generate
injury or even death. Areas with a potentially explosive atmosphere are often, but
not always, clearly marked.
3.Emergency calls
IMPORTANT!
This Bluetooth® headset and the electronic device connected to the headset
operate using radio signals, mobile and landline networks as well as user
- programmed functions, which cannot guarantee connection under all conditions.
Therefore you should never rely solely upon any electronic device for essential
communications (e.g. medical emergencies). Remember, in order to make or
receive calls, the headset and the electronic device connected to the headset
must be switched on and in a service area with adequate mobile signal strength.
Emergency calls may not be possible on all mobile phone networks or when
certain network services and/or phone features are in use. Check with your local
service provider.
4. Battery information
A rechargeable battery has a long service life if treated properly. A new battery
or one that has not been used for a long period of time could have reduced
temperatures, never above +60°C(+140°F) or under -20°C(-4°F). For maximum
battery capacity, use the battery at room temperature. If the battery is used in
low temperatures, the battery capacity will be reduced. The battery can only be
charged in temperatures between +10°C(+50°F) and +45°C (+113°F). For your
safety, do not remove the battery incorperated in the product. If you need to
replace the battery, take it to the nearest authorised LG Electronics service point
or dealer for assistance.
5. Recycling the battery in your Bluetooth® headset
The battery in your Bluetooth® Headset must be disposed of properly and should
never be placed in municipal waste. The LG Electronics service partner who
removes the battery will dispose of it according to local regulations.
Additional Information
16
6. Conditions
- The warranty is valid only if the original receipt issued to the original
purchaser by the dealer, specifying the date of purchase and serial number,
is presented with the product to be repaired or replaced. LG Electronics
reserves the right to refuse warranty service if this information has been
removed or changed after the original purchase of the product from the dealer.
- If LG Electronics repairs or replaces the product, the repaired or replaced
product shall be warranted for the remaining time of the original warranty
period or for ninety (90) days from the date of repair, whichever is longer.
Repair or replacement may involve the use of functionally equivalent
reconditioned units. Replaced parts or components will become the property
of LG Electronics.
- This Warranty does not cover any failure of the product due to normal wear
and tear, or due to misuse, including but not limited to use in other than the
normal and customary manner, in accordance with instructions for use and
maintenance of the product. Nor does this warranty cover any failure of the
resulting from liquid.
- This warranty does not cover product failures due to improper repair
authorised person. Tampering with any of the seals on the product will void
the warranty.
- THERE ARE NO EXPRESS WARRANTIES, WHETHER WRITTEN OR
ORAL, OTHER THAN THIS PRINTED INCLUDING WITHOUT LIMITATION
THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY. IN NO EVENT SHALL LG ELECTRONICS OR ITS
VENDORS BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES
OF ANY NATURE WHATSOEVER, INCLUDING BUT NOT LIMITED TO
LOST PROFITS OR COMMERCIAL LOSS, TO THE FULL EXTENT THOSE
DAMAGES CAN BE DISCLAIMED BY LAW.
consequential damages, or limitation of the duration of implied warranties, so
the preceding limitations or exclusions may not apply to you. The warranty
provided does not affect the consumer’s statutory rights under applicable
national legislation in force, nor the consumer’s rights against the dealer
arising from their sales/purchase contract.
Additional Information
ENG
17
Subject to the conditions of this Limited Warranty, LG Electronics warrants this
product to be free from defects in design, material and workmanship at the time
of its original purchase by a consumer, and for a subsequent period of one (1)
year. Should your product need warranty service, please return it to the dealer
from whom it was purchased or contact your local LG Electronics contact centre
to get further information.
Avoiding hearing damage
Permanent hearing loss may occur if you use your headset at a high volume.
Set the volume to a safe level. Over time you can become accustomed to a
higher volume that may sound normal but can be damaging to your hearing.
your hearing checked. The louder the volume, the less time is required before
your hearing could be affected.
Hearing experts suggest that to protect your hearing:
Using Headsets safely
Use of headsets to listen to music while operating a vehicle is not recommended
and is illegal in some areas. Be careful and attentive whilst driving. Stop using
vehicle or performing any other activity that requires your full attention.
ENG
Limited Warranty
Important Safety Information
