LG Electronics USA L03F USB Modem with Multi-band GPRS and WCDMA User Manual
LG Electronics MobileComm USA, Inc. USB Modem with Multi-band GPRS and WCDMA
Users Manual
Don't forget your mobile phone … or your manners!
○ When using your mobile phone in a public place, don't forget to show common courtesy and consideration for others around you.
■From DOCOMO mobile phones
(In Japanese only)
* Unavailable from land-line phones, etc.
General Inquiries
<docomo Information Center>
Loss or theft of this terminal or payment of
cumulative cost overseas
<docomo Information Center> (available 24 hours a day)
From land-line phones
<Universal number>
-81-3-6832-6600*(toll free)
International call access code for
the country you stay
* You are charged a call fee to Japan when calling from a land-line phone, etc.
-8000120-0151*
*
You might be charged a domestic call fee according to the call rate for the country you stay.
Repairs
Failures encountered overseas
<Network Support and Operation Center> (available 24 hours a day)
From land-line phones
<Universal number>
-81-3-6718-1414*(toll free)
International call access code for
the country you stay
* You are charged a call fee to Japan when calling from a land-line phone, etc.
From DOCOMO mobile phones
-8005931-8600*
*
You might be charged a domestic call fee according to the call rate for the country you stay.
※For international call access codes for major countries and universal number international
prefix, refer to DOCOMO International Services website.
* Unavailable from land-line phones, etc.
■From DOCOMO mobile phones
(In Japanese only)
■From land-line phones
(In Japanese only)
* Unavailable from part of IP phones.
* Service available in: English, Portuguese, Chinese, Spanish, Korean.
* Unavailable from part of IP phones.
From DOCOMO mobile phones
NTT DOCOMO website http://www.nttdocomo.co.jp/english/
※For international call access codes for major countries and universal number international
prefix, refer to DOCOMO International Services website.
●If you lose your terminal or have it stolen, immediately take the steps necessary for suspending the use of this terminal.
●If your terminal is damaged, bring your terminal to a repair counter specified by DOCOMO after returning to Japan.
(Business hours: 24 hours. (open all year round))
■From land-line phones
(In Japanese only)
* Unavailable from part of IP phones.
(toll free)
0120-800-000
0120-800-000 (toll free)
0120-005-250 (toll free)
(Business hours: 9:00 a.m. to 8:00 p.m.)
(Business hours: 9:00 a.m. to 8:00 p.m. (open all year round))
L-03F
Contents/Precautions
Before Using this Terminal
Setting Up
L-03F Connection Manager
Mobile Broadband
Conguring Network Manually
Overseas Use
Appendix/Troubleshooting
‘14.x
L-03F
Introduction
Thank You for Purchasing the "L-03F"
Before using your terminal, or when necessary, read this
manual to ensure safe use and handling.
Before Using this Terminal
•L-03F supports LTE, W-CDMA, GSM/GPRS.
•Because this terminal uses radio waves, it may not function in
locations where it is difficult for radio waves to penetrate, such
as tunnels, underground passages, and some buildings in
areas where radio wave signals are weak or out of the Xi/FOMA
service area. Even when you are on a higher floor of a tall
building or condominium and nothing blocks your view outside,
this terminal may not be able to receive or transmit signals.
Also communication may be interrupted even when the
Antenna Indication Lamp on this terminal lights indicating a
strong signal reception with 3 antenna indication bar.
•This terminal communicates via radio waves by converting
voices into digital signals. If you move into an area where signal
reception is poor, the digital signals may not be accurately
decoded and what you hear may differ slightly from what was
actually said.
•DOCOMO is not responsible for any economic losses incurred
through lost communication opportunities caused by external
factors such as malfunction or electrical outage.
•This terminal can be operated in Xi area, FOMA Plus-Areas and
FOMA HIGH-SPEED Areas.
•This terminal does not support i-mode functions (i-mode mail,
connection to i-mode sites (program) or i-αppli, etc.).
SIM unlock
This terminal supports SIM unlock. If you release SIM lock,
you can use SIM by a carrier other than NTT DOCOMO.
•The SIM unlock service is provided at a docomo Shop.
•A SIM unlock charge is separately required.
•Note that it takes several days for SIM unlock.
•If you use a SIM other than by DOCOMO, LTE system is
unavailable. And available services and functions will be limited.
DOCOMO is not liable to any failures or malfunctions.
•For details of SIM unlock, refer to NTT DOCOMO website.
The latest information of this manual can be downloaded from
the DOCOMO website.
■ The URL of PDF for INSTRUCTION MANUAL
http://www.nttdocomo.co.jp/english/support/trouble/
manual/download/index.html
※ The URL and the information contained in the manual are
subject to change without prior notice.
1
Basic Package
■ L-03F Terminal (With Back cover L30, Warranty)
■ L-03F INSTRUCTION MANUAL for Connection Guide
■ USB Extension Cable (Sample)
2
How to Read this Manual
Contents
L-03F Manual is composed of "L-03F INSTRUCTION MANUAL for Connection Guide" and "L-03F INSTRUCTION MANUAL"
(this manual).
■ "L-03F INSTRUCTION MANUAL for Connection Guide"
The following contents such as connection to computer, troubleshooting, specifications of L-03F are described.
•Contents/Precautions
•Before Using this Terminal
•Setting Up
•Appendix/Troubleshooting
■ "L-03F INSTRUCTION MANUAL" (this manual)
Besides the above contents described in "L-03F INSTRUCTION MANUAL for Connection Guide", the contents of
configuring communication through special application are also written.
This manual is supplied with PDF. To view this manual, Adobe Reader (Version 6.0 or later is recommended) is necessary.
•L-03F Connection Manager
•Mobile Broadband
•Configuring Network Manually
•Overseas Use
•Please understand that in "L-03F INSTRUCTION MANUAL", "this terminal" refers to "L-03F".
•Note that in "L-03F INSTRUCTION MANUAL", "PC" refers to both "Windows PC" and "Mac".
•Operation procedures and images may differ depending on environment.
•Reprinting all or parts of this manual is prohibited.
•Information contained in this manual is subject to change without prior notice.
3
Contents/Precautions
Contents
Basic Package ･･････････････････････････････････････ 1
How to Read this Manual････････････････････････････ 2
Contents ････････････････････････････････････････････ 3
Features of the L-03F ･･･････････････････････････････ 4
Safety Precautions (ALWAYS FOLLOW THESE
PRECAUTIONS) ･････････････････････････････････････ 5
Handling and Care･････････････････････････････････ 11
Before Using
this Terminal
13
Names of Parts and Functions
Using UIM
Available Communications
Connecting this Terminal to a PC
Setting Up
27
Setting Up
Windows Version
Mac Version
L-03F
Connection
Manager
49
L-03F Connection Manager
Using Packet Communication
Settings
Mobile
Broadband
63
Mobile Broadband
Connecting through Mobile Broad
-
band
Disconnecting Mobile Broadband
Changing APN Settings
Setting UIM
Configuring
Network
Manually
69
Windows Version
Overseas
Use
89
International Roaming Service
(WORLD WING)
Services Available Overseas
Before Using Overseas
Setting the Searching Method for
Available Networks
Configuring Network
Appendix/
Trouble-
shooting
95
AT Commands
AT Command List
Options and related devices
Troubleshooting
Error Messages
Warranty and After-Sales Service
Updating Software
Main Specifications
Export Administration Regulations
Intellectual Property Rights
Index
4Contents/Precautions
Features of the L-03F
"Xi" is a service of DOCOMO supported by LTE (Long Term Evolution) which is the international communication standard.
FOMA (Freedom Of Mobile multimedia Access) is the name of a service provided by DOCOMO based on the W-CDMA
system, which is certified as one of the global standards of 3rd generation mobile communication systems (IMT-2000).
■ Supported Xi data communication
The terminal supports data communication at a speed
of up to 75Mbps for downloading and up to 25Mbps for
sending.
※ Within a part of the Xi area.
•Refer to DOCOMO website for detailed supporting areas.
Communication speed is theoretical values when sending
and receiving data which does not show the actual ones.
The actual communication speed depends on
communication environment and network congestion.
•The FOMA area which is out of Xi area is also available.
■ Correspondence with the FOMA HIGH-SPEED Area
You can enjoy high speed communication (Best effort
system) at a maximum of 14Mbps for receiving and
5.7Mbps for sending.
•Communication speed is theoretical values when sending
and receiving data which does not show the actual ones.
The actual communication speed depends on
communication environment and network congestion.
•For details of areas supporting a maximum of 5.7Mbps
for sending, view DOCOMO website.
•Sending and receiving data may become 384kbps even
in the FOMA HIGH-SPEED area.
•Sending and receiving data become 384kbps in FOMA
area out of FOMA HIGH-SPEED area.
■ International Roaming Service
Data communications from a PC are available through
using 3G network or GPRS network in foreign
countries. P90
※ "WORLD WING" is usually applied along with the
contract of this terminal. Please contact a docomo
shop or a docomo Information Center to confirm the
details.
5
Contents/Precautions
Safety Precautions (ALWAYS
FOLLOW THESE PRECAUTIONS)
■ Before using this terminal, read these "Safety
Precautions" carefully so that you can use it properly.
After reading the safety precautions, keep this manual in
a safe place for later reference.
■ These precautions are intended to protect you and
others around you. Read and follow them carefully to
avoid injury, damage to the product or damage to
property.
■ The signs below indicate the levels of danger or damage
that may occur if the particular precautions are not
observed.
■ The following symbols indicate special warnings
regarding product usage.
■ "Safety Precautions" are explained in the following
4 sections.
General Precautions for this Terminal and UIM ………… 6
Precautions for this Terminal………………………………… 7
Precautions for the UIM ……………………………………… 9
Notes on Using near Electronic Medical Equipment ……… 9
This sign indicates that
incorrect handling has a
high possibility of
causing death or serious
injury.
This sign indicates that
incorrect handling poses
a risk of causing death or
serious injury.
This sign indicates that
incorrect handling poses
a risk of causing slight
injury or damage to the
product or property.
DANGER
WARNING
CAUTION
Denotes things not to do (prohibition).
Denotes not to disassemble.
Denotes not to use where it could get
wet.
Denotes mandatory instructions
(matters that must be complied with).
Not disassembly
Not liquids
6Contents/Precautions
General Precautions for this Terminal
and UIM
DANGER
Do not use, store or leave the terminal in
hot places (e.g. by the fire, near a heater,
under a kotatsu, in direct sunlight, in a car
in the hot sun).
Fire, burns, or injury may result.
Do not put this terminal or UIM in heating
appliances such as microwaves or high
pressure containers.
Fire, burns, injury, or electric shock may
result.
Do not disassemble or remodel this
terminal and its accessories.
Fire, burns, injury, or electric shock may
result.
Do not get this terminal and its
accessories wet with water, drinking
water, pet urine, etc.
Fire, burns, injury, or electric shock may
result.
WARNING
Do not subject this terminal and its
accessories to strong force, severe
shocks, or throw them.
Fire, burns, injury, or electric shock may
result.
Keep conductive foreign objects (metal,
pencil lead, etc.) away from the USB
connector. Do not insert such objects
inside this terminal.
Fire, burns, injury, or electric shock may
result.
Do not cover or wrap this terminal or its
accessories with bedding, etc. while using.
Fire or burns may result.
Make sure to turn off the computer which
is connected with this terminal before you
go near a flammable gas such as gasoline
fumes.
Catching fire may result.
Not disassembly
Not liquids
7
Contents/Precautions
CAUTION
Do not place this terminal or UIM on
unstable locations such as wobbly tables
or slanted locations.
This terminal or UIM may fall, resulting in
injury.
Do not store this terminal or UIM in humid
or dusty places, or in hot areas.
Fire, burns, or electric shock may result.
If children use this terminal or UIM, a
guardian should explain the precautions
and correct operations. The guardian
should also make sure that the
instructions are followed during use.
Injury may result.
Keep out of reach of babies and infants.
Accidental swallowing or injury may result.
Precautions for this Terminal
WARNING
Do not get liquids such as water or foreign
objects such as metal pieces or
flammable materials into the UIM slot of
this terminal.
Fire, burns, injury, or electric shock may
result.
Turn off this terminal in places where use
is prohibited such as airplanes or
hospitals.
Electronic devices or electronic medical
devices may be adversely affected. Follow
the instructions when using inside medical
facilities.
If you wear any implanted electronic
medical devices, contact the
manufacturer or dealer of the electronic
medical device to ask about the effect
from radio waves.
Electronic medical devices may be
adversely affected.
8Contents/Precautions
Remove this terminal from USB port in
places near high-precision electronic
devices or devices using weak electronic
signals.
Electronic devices may be adversely
affected by reasons such as malfunction.
※ Electronic devices that may be affected
Hearing aids, implanted cardiac pacemakers,
implanted defibrillators, other medical
electronic devices, fire alarms, automatic
doors and other automatically controlled
devices.
If you are using an implanted cardiac pace
maker, implanted defibrillator or any other
electronic medical device, consult the
manufacturer or retailer of the device for
advice regarding possible effects from radio
waves.
CAUTION
Do not use the broken terminal.
Fire, burns, injury, or electric shock may
result.
If you use this terminal in a car, contact
the car manufacturer or dealer to ask
about the effect from radio waves.
Depending on the type of a car, in-car
electronic devices could be adversely
affected. In this case, stop using this
terminal immediately.
Itching, rash or eczema may be caused
depending on your physical conditions or
predisposition. If an abnormality occurs,
stop using this terminal immediately, and
then seek medical attention.
For the material of each part →P10
"Material List"
Be careful not to get your finger caught in
the parts when you close or open this
terminal.
Injury or other accidents may result.
9
Contents/Precautions
Precautions for the UIM
CAUTION
Be careful not to touch the edge of UIM
when removing it.
Injury may result.
Notes on Using near Electronic Medical
Equipment
■The description below meets "Guideline on the
Use of Radio-communication Equipment such as
Cellular Telephones - Safeguards for Electronic
Medical Equipment" by the Electromagnetic
Compatibility Conference.
WARNING
Be sure to adhere to the following
regulations inside medical facilities.
●Keep this terminal out of operating
rooms, intensive care units (ICUs) or
coronary care units (CCUs).
●Turn off the PC in hospital wards.
●Turn off the PC in hospital lobbies and
corridors if electrical medical devices
could be nearby.
●If the medical facility has specific zones
where use or possession of mobile
terminals is prohibited, follow those
regulations.
Turn off the PC in crowded trains or other
public places where implanted cardiac
pacemaker or defibrillator wearers could
be nearby.
Operation of an implanted cardiac
pacemaker or implanted defibrillator may
be adversely affected by radio waves.
10 Contents/Precautions
If you use medical equipment such as an
implanted cardiac pacemaker or implanted
defibrillator, use the mobile terminal 22cm
or more away from the implanted cardiac
pacemaker or implanted defibrillator.
Operation of medical equipment may be
adversely affected by radio waves.
Patients using electronic medical
equipment other than implanted cardiac
pacemakers or implanted defibrillators
(using outside medical facilities for
treatment at home, etc.) should check the
influence of radio waves upon the
equipment by consulting the
manufacturer.
Operations of electronic medical
equipment may be adversely affected by
radio waves.
Material List
Part Material/Surface
treatment
Exterior case (Front part) PC
Exterior case (Back part : Back cover) PC
Frame PC+GF30%
Communication Status Lamp Transparent PC
USB Connector/Bracket PC
USB Connector SUS
11
Contents/Precautions
Handling and Care
General Usage Guidelines
■Keep this terminal away from water.
This terminal and UIM are not waterproof. Do not
use the terminal in places with high humidity such
as a bath or where rain may get it wet. If you carry
the card close to your body, moisture from sweat
may corrode the internal parts causing a
malfunction. Note that malfunctions deemed to
be caused by water are not covered by the
warranty, and may be impossible to repair. Since
these malfunctions are not under warranty, even
when repair is possible, it will be done at the
user's expense.
■Clean this terminal with a dry, soft cloth (Lens
cleaning cloth).
If this terminal is wiped with alcohol, paint thinner,
benzine or detergent, the printing may disappear
or color may fade.
■Keep the connector contacts clean with a dry
cotton swab.
Clean the connector contacts with a dry cotton swab
to prevent contacts from getting dirty which can
result in intermittent connections. Be careful when
cleaning the connector contacts.
■Do not place the equipment near air conditioner
outlets.
Condensation may form due to rapid changes in
temperature, and this may corrode internal parts
and cause malfunction.
■Do not place this terminal where excessive force
will be applied to it.
If this terminal is inserted to a full bag, or placed
in a pocket and sat on, its internal PCBs may be
damaged or malfunction. Such damage is not
covered by warranty.
■Read the individual manual attached to this
terminal.
This Terminal
■Avoid using in extremely high or low temperatures.
This terminal should be used within a temperature
range from 5 C to 35 C and a humidity range
from 45 % to 85 %.
■This terminal may adversely affect fixed phones,
televisions or radios in use nearby. Use as far as
possible from such appliances.
■Keep a separate record of any information stored
on this terminal and store the copies in a safe
location.
DOCOMO assumes no responsibility for the loss
of any of your data.
■Do not drop this terminal or subject it to shocks.
Damage or malfunction may result.
12 Contents/Precautions
■Do not insert a USB connector to PC crookedly
or do not pull it when it is inserted.
Damage or malfunction may result.
■Remove this terminal from the PC when
transporting.
Malfunction or damage may result.
■It is normal for this terminal to become warm
during use. You can continue to use it even when
it is warm.
UIM
■Do not put excessive force on the UIM when
inserting or removing it into this terminal.
■Note that DOCOMO assumes no responsibility for
malfunctions occurring as the result of inserting
and using UIM with another IC card reader/writer.
■Always keep the IC portion of the UIM clean.
■Clean the UIM with a soft, dry cloth (Lens
cleaning cloth).
■Be sure to keep a separate note of the
information registered to this terminal.
DOCOMO assumes no responsibility for the loss
of any of your data.
■Visit docomo Shop to return the UIM for the
environmental purpose.
■Do not scratch, touch carelessly or short circuit
the IC portion.
Data loss or malfunction may result.
■Do not drop or give shock to the UIM .
Malfunction may result.
■Do not bend or put heavy things on the UIM.
Malfunction may result.
■Do not insert UIM into this terminal with labels or
stickers attached on.
Malfunction may result.
CAUTION
■Do not use the modified this terminal. Using
modified this terminal result in violating the law of
Electromagnetic Compatibility.
This terminal has been complied with technical
standard of wireless equipment stipulated by law
of Electromagnetic Compatibility. As a proof,
"Technical standard compliance mark " is
indicated in the inscription seal. If this terminal is
modified by turning the screw to the left to
disassemble, technical standard compliance
becomes invalid.
Please do not use this terminal during the time
when technical standard compliance is being
invalid, since you are in violation of the law of
Electromagnetic Compatibility.
■Do not alter the basic software.
Repairs may be refused as a modification of
software.
■Keep this terminal 15mm or more away from your
body while communicating.
14 Before Using this Terminal
Names of Parts and Functions
aUSB Connector
A connection terminal used to connect
with PC
bCommunication Status Lamp→
P15
Indicates status of this terminal
cXi antenna Part
The antenna is built in this terminal.
dBack cover
Cover to protect UIM attaching part
Pulling out a:
※ Use the USB connector pulling out up to 180
degrees (90+90 degrees) from the terminal.
Note that trying to pull out over 180 degrees
may cause damage.
Example 1: Example 2:
※ The tip of the USB connector can be rotated up to 180 degrees
(90+90 degrees). Note that it can be rotated in the same
direction. Rotating in the opposite direction or over 180 degrees
by force may cause damage.
15
Before Using this Terminal
Mode Indication Lamp
※ A long period with no sent or received data.
Using UIM
A UIM is an IC card that stores personal information such as
your phone number. Without the UIM installed in this terminal,
you cannot use data communication. For detailed information,
refer to UIM Manual.
Inserting/Removing
Inserting
Insert a UIM holding the terminal with both hands.
aPress the back cover in the direction a to slide
it in the direction b. Then pull it up in the
direction c to remove
Status Status Lamp
While
communicating
LTE Blue
W-CDMA (3G) Green
HSDPA Magenta
HSUPA Magenta
GPRS Cyan
During packet
communication (no
data sent or received)
※
White
Out of service Yellow
PIN1
PIN1 lock ON Red
Waiting to unlock
PIN1 Red
Communication
Status Lamp
You can use the terminal only with UIM. Exchange your
docomo mini UIM card or FOMA card at a docomo Shop.
Back cover
16 Before Using this Terminal
bInsert a UIM under the card slot in the
direction of arrow with the IC chip side down
cFit the back cover to the ditch of this terminal
at approximately 1mm. While pushing in the
direction of a, slide the back cover in the
direction of b until it clicks
Removing
Remove a UIM holding the terminal with both hands.
aPress the back cover in the direction a to slide
it in the direction b. Then pull it up in the
direction c to remove
bSlide the UIM in the direction of arrow to
remove
UIM slot guide
Notch
UIM
IC
Approx.
1mm
Back cover
UIM
17
Before Using this Terminal
cFit the back cover to the ditch of this terminal
at approximately 1mm. While pushing in the
direction of a, slide the back cover in the
direction of b until it clicks
Security Code
You can set PIN1 code (Personal Identification Number)
for UIM. The default setting for the PIN1 code is [0000].
The PIN1 code is a 4 to 8-digit security code to be entered
every time this terminal is turned on for user verification to
prevent any unauthorized use by others.
■ Changing PIN1 Code
You can change the PIN1 code to any number. To
prevent unauthorized use by third parties, change it to
your own number. If you improperly enter the PIN1 code 3
times in a row, PIN1 code is locked automatically (PIN
Lock), so be sure to keep a separate note of the numbers
you set.
•"Changing PIN1 Code" (→P57)
■ Unblocking PIN Code
The unblocking PIN code is the number in 8 digits used
to unblock the PIN1 code, which cannot be changed by
yourself. If you improperly enter the unblocking PIN code
for 10 times in a row, the UIM is locked automatically.
Note
•Do not lose the removed UIM.
•Make sure to both sides of the UIM.
•Be careful not to scratch the UIM IC tip.
•Inserting a UIM in the reversed direction may cause
malfunction.
•Inserting or removing the UIM with an excessive force may
cause damage to your UIM.
•Do not remove the UIM while this terminal is inserted to a
PC, it may cause damage to your UIM.
•Do not transfer the UIM to others.
•Do not get the UIM scratched or transformed. The data
stored in UIM will disappear or be changed.
Approx.
1mm
IC
If your UIM is set to require a PIN1 code, data
communication cannot be performed until the PIN1
code is entered. Use UIM after verifying the PIN1 code,
or set (→P57) UIM not to verify the PIN1 code in
advance.
18 Before Using this Terminal
Caution
•Do not set PIN1 code to numbers that can easily make a
guess, such as "birth date", "part of your phone number",
"numbers from address or room number", "1111" "1234",
etc. Also memo your PIN1 code and keep it well.
•Keep your PIN1 code away from being known by other
people. DOCOMO assumes no responsibility for the loss of
any of your data results from abuse of PIN1 code.
•If you forgot your PIN1 code, you (if you are the
covenanter) are required to bring your ID (driving license,
etc.) and UIM to a docomo shop.
For details, please contact "docomo Information Center" on
the back cover of this manual.
•Unblocking PIN code is written on the proposal form
handed in at time of contract in docomo shop. For
covenanter who signed the contract other than docomo
shop are required to bring your ID (driving license, etc.) and
UIM to a docomo shop, or contact "docomo Information
Center" on the back cover of this manual.
Activate L-03F Connection Manager
PIN1 code Verification screen appears
Enter PIN1 Code
Incorrect entry 3 times in a row
Enter Unblocking PIN Code
OK Incorrect entry 10 times in a row
Available to set a new
PIN1 code Contact a docomo Shop
19
Before Using this Terminal
Available Communications
Xi Data Communication/FOMA Packet
Communication
Fees for this communication method are based on the
amount of exchanged data. You can perform data
communication at a speed of up to 75Mbps for receiving
data and up to 25Mbps for sending data by using a
connection that allows Xi data communication or FOMA
packet communication such as "mopera U", one of
DOCOMO's Internet connection services.
※ Communication speed is theoretical values when sending
and receiving data which does not show the actual ones.
The actual communication speed depends on
communication environment and network congestion.
•Depending on bandwidth, communication speed for receiving is
theoretically 100/100/75/37.5Mbps (with bandwidth of [20/
15/10/5MHz]), and for sending is 50/37.5/25/12.5Mbps
(with bandwidth of [20/15/10/5MHz]).
•For the FOMA HIGH-SPEED areas outside Xi area, the
maximum speed for receiving data is 14Mbps and for sending
is 5.7Mbps (best effort).
•Sending and receiving data become 384kbps in FOMA area
out of Xi area and FOMA HIGH-SPEED area.
•The communication speed varies depending on the access
point and radio wave status.
•The communication speed varies depending on the overseas
carrier or network when using overseas.
Note
•Communication fees become high when performing
communications with large amount of data such as
browsing websites with many graphics or downloading
data.
•Data communication may take more time or become
difficult to connect depending on the network congestion.
For customers who use a large amount of data
communication (Approximate 1Gbytes data or more is
used within the last three days including the current day),
it may have difficulties in sending and receiving data on
time. Also, data communication may get disconnected in
the following cases such as when a large amount of data
communication occurs at a time or within a certain period
of time, when being connected for a long time, or when
connecting several times in a row within a certain period of
time.
•This terminal does not support 64K data communication.
•This terminal does not support Remote Wakeup.
•This terminal does not support FAX communication.
20 Before Using this Terminal
Usage Notes
■ Internet service provider (ISP) fees
Fees to an ISP may be required to connect to the
Internet. These fees are added to the Xi service fees and
are paid to your ISP directly. For details on connection
fees, contact your ISP.
You can subscribe to such as "mopera U", one of
DOCOMO's Internet connection services. Charge for
subscribing "mopera U" is required.
For service and connection settings of "mopera U", visit
the "mopera U" website.
http://www.mopera.net/ (Japanese only)
■ User authentication to access networks
Depending on the access point, user authentication (ID
and password) may be required to connect. If required,
enter the ID and password from communication software
or dial-up network. The ID and password will be provided
by the network administrator of your ISP or the access
point. For details, contact your ISP or network
administrator.
■ Requirements for communication
The following conditions must be met to perform
communications using this terminal. However, a
connection may not be established if traffic is heavy at
the base station or if radio signals are weak.
•This terminal must be in Xi network, FOMA network or
DOCOMO's roaming service area.
•The access point corresponds to the Xi data
communication or FOMA packet communication.
Connecting this Terminal to a PC
When connecting this terminal with a PC for the first time,
it is required to install L-03F Connection Manager
(including a driver). For installing L-03F Connection
Manager, refer to the following.
•For Windows: "Preparation before using L-03F" (→P32)
•For Mac: "Preparation before using L-03F" (→P41)
Inserting
aTurn on a PC
bConnect this terminal with the PC
■When using the USB extension cable (Sample)
aPut your fingertip on the lug of the USB connector to
pull out 180 degrees
Lug
21
Before Using this Terminal
bHold the connector part of the USB extension cable and
insert into the USB connector of this terminal in
direction of arrow
* Firmly insert into the USB connector.
cHold the connector part of the USB cable and insert it
into PC's USB port in direction of arrow with inscription
of the USB side up
USB connector
USB extension
cable
USB port USB extension cable
Inscription of USB
22 Before Using this Terminal
■When connecting with a PC directly
•
The tip of the USB connector on the terminal can be
rotated 90 degrees according to the orientation of your PC.
aPut your fingertip on the lug of the USB connector to
pull out 90 degrees
bRotate the tip of the USB connector 90 degrees with
the engraved side up
※ The connector can be rotated 90 degrees more (up to
a total of 180 degrees). Note that trying to rotate over
180 degrees by force may cause damage.
cInsert the USB connector of this terminal into the PC's
USB port
•In Step b, you can insert the USB connector as is without
rotating 90 degrees to use.
※ Do not rotate the USB connector inserted to the PC's
USB port. Malfunction or damage may result when
subject this terminal to severe force or shocks due to
carelessness.
USB Connector
Lug
USB
Connector
USB Connector
USB port
USB port
23
Before Using this Terminal
cStart communication connection
•Using "L-03F Connection Manager" (→P49)
•Using "Mobile Broadband" (→P63)
•Configuring manually (→P69)
Removing
aDisconnect data communication
If the L-03F Connection Manager is running, or L-03F APN
Tool is running, close it first. Make sure the data connection
is disconnected.
bRemove this terminal
■When using the USB extension cable (Sample)
aHold the connector part of the USB extension cable and
pull out this terminal from PC's USB port in direction of
arrow
Note
•Check that the color of Communication Status Lamp is
blue, magenta, cyan or green.
•Keep the PC away from entering conditions such as sleep
(standby) or power off. Operations may become abnormal.
In that case, remove this terminal first before the PC turns
to sleep (standby) or power off.
Communication
Status Lamp
USB port USB extension cable
24 Before Using this Terminal
bHold the connector part of the USB extension cable and
pull out from the USB connector in direction of arrow
cPlace the USB connector into this terminal
※ Place the USB connector with the lug shown at the
front.
■When connecting to a PC directly
aHold the USB connector part of this terminal and pull
out this terminal straight from PC's USB port
USB extension
cable
USB connector
Lug
USB Connector
USB connector
USB port
25
Before Using this Terminal
bRotate the tip of the USB connector 90 degrees as
shown
cPlace the USB connector into this terminal
Caution
•If you force to remove this terminal or try to pull out the
USB connector, malfunction may result.
•Removing this terminal from the PC during data
communication may suspend data communication and
result malfunction or data loss.
USB
Connector
USB Connector
28 Setting Up
Setting Up
■ Data communication via L-03F
"Communication configuration file (Driver)" is required to install on a PC to recognize this terminal.
In L-03F Setup, not only "Communication configuration file (Driver)", the data communication software of "L-03F
Connection Manager" and "L-03F APN Tool" (Windows only) will be installed as well.
Data communication is available with only L-03F Connection Manager, if necessary using Mobile Broadband (Windows 7
only) is also available.
For PC with Windows OS in it, data communication is also available based on configuring manually after installing L-03F
Connection Manager.
■ Installation of L-03F Connection Manager
Since L-03F has "Zero installation", when connecting this terminal to a PC for the first time, "L-03F Connection Manager"
installation screen appears automatically. "Zero installation" is supported by PC with Windows OS in it.
Mac does not support "Zero installation", clicking the CD-ROM icon displayed when connecting this terminal to a PC
continues installation.
The procedure of setting up is described on the next page.
29
Setting Up
Work Flow of Setting Up
Connecting this terminal with a PC
・ Windows VersionP32
・ Mac VersionP41
Installing L-03F Connection Manager, Communication configuration file (Driver),
L-03F APN Tool (Windows only) (Standard installation/Custom installation)
Confirmation after Setup
・ Windows VersionP36/・ Mac VersionP45
Configuring L-03F Connection
ManagerP54
Communication connection
via L-03F Connection
ManagerP50
Communication connection
through Mobile Broadband
P65
Configuring Communication manually
・ Windows Version P70
Communication connection manually via OS
・ Windows VersionP86
Using L-03F
Connection
Manager
Using Mobile
Broadband of
Windows 7
Without using
L-03F Connection
Manager
30 Setting Up
Operating Environments
Using this terminal under the following operational
environments.
※1 Operations on upgraded OS or added/modified
environment are not guaranteed.
※2 Only Mac with CPU made by Intel Corporation is available.
※3 Required memory or available hard disk space may vary
depending on the system environment of a PC.
For latest information of operation environment, visit NTT
DOCOMO website.
Item Requirement
PC Main
Unit
•PC/AT compatible and Mac.
•USB port (standard of Universal Serial Bus
Specification Rev2.0)
•Do not operate via USB hub (including USB port
on monitor and keyboard).
•Display resolution of 800×600 pixels, 16-bit
Color (65,536) or higher is recommended.
OS※1 Windows XP SP3 (Japanese/English version)
Windows Vista SP2 (Japanese/English version)
Windows 7 SP1 (Japanese/English version)
Mac OS X 10.6.8/10.7.2 (Japanese/English
version)※2
Required
Memory※3
Windows XP: 256Mbytes or more
Windows Vista: 512Mbytes or more
Windows 7: 1Gbytes or more(32bit), 2Gbytes or
more (64bit)
Mac OS X 10.6.8: 1Gbytes or more
Mac OS X 10.7.2: 2Gbytes or more
Hard Disk
Space※3 50Mbytes or more available space
Note
•The software may not work depending on your operating
system environment and type of machine. DOCOMO does
not guarantee any operation other than the operation
environment described in the table on the left side.
31
Setting Up
Windows Version
Installation of L-03F Connection Manager is only required
when connecting this terminal to your PC for the first time.
※The following procedures or screen images are all based on
the example of Windows 7.
Note
•When installing, insert this terminal into USB port after OS
is activated.
•Do not remove this terminal while installing.
•Installation may take several minutes depending on the PC.
•Do not install or uninstall during data communication.
•End all the applications before installing. Also end
programs on Windows including virus check software.
•When installing, make sure to install from the account with
PC supervisor privileges. An error will occur during
installation if you install from the account without privileges.
•For details on setting up PC supervisor privileges, contact
your computer manufacturer or Microsoft Corporation.
•When connecting this terminal to a PC for the first time,
you are required to enter PIN1 code to use UIM. →P58
■ If CD/DVD playback and written software is installed
into a PC
Depending on the CD/DVD playback or writing application
installed in a PC, this terminal may not be recognized
normally even if the terminal is connected while the
application software residents※ or is activated.
Refer to "Troubleshooting" for proper solutions. →P113
※Including the case in which its icon stays on the taskbar.
32 Setting Up
Preparation before Using L-03F
Setting Zero Installation (Auto)
aTurn on a PC and activate OS
bConnect this terminal with the PC
The device driver which connects this terminal to a PC is
automatically installed by zero installation. When the
installation finishes, the message, "Device driver software
installed successfully." appears, then L-03F Connection
Manager setup screen appears.
"AutoPlay" screen will be displayed depending on settings of
the PC. If the screen is displayed, check "Always do this for
software and games:" and select "Run L03FLauncher.exe".
np
cClick [Yes] on "User Account Control" screen
■For Windows Vista
•Click [Continue] on "User Account Control" screen.
■For Windows XP
•"User Account Control" screen is not displayed. Follow
the next step.
dSelect "English (United States)" in the
"Choose Setup Language" screen, then click
[Next]
33
Setting Up
eClick [Next]
fConfirm the contents of "License Agreement".
When agree with the contents, select "I
accept the terms of the license agreement"
and click [Next]
gSelect "Standard installation (recommended)"
on the "Select the installation method"
screen, then click [Next]
Installation starts. Then installation of L-03F communication
configuration file (Driver) continues.
※It may take time to move to the next procedure depending
on your PC.
■Custom installation
aOn the "Select the installation method" screen, select
"Custom installation" and click [Next]
bSelect "Install all of L-03F Connection Manager, L-03F
APN Tool, and L-03F USB Driver. (Recommended)" or
"Install L-03F USB driver only", then click [Next]
34 Setting Up
•To install all, also set "Profile setting" "Automatic
connection setting".
•If you install L-03F USB driver only and make packet
communications, connect in the manner in Mobile
Broadband (→P65) or Configuring Network Manually
(→P69).
•For Windows XP, the "Setting optimized
communication" screen appears. When the setting is
made, click [Next] to proceed the next step.
hConfirm that this terminal is recognized by
the PC
On the right side of the taskbar, "Installing device driver
software" appears, and this terminal is recognized
automatically.
※To recognize this terminal automatically, "L-03F is not
recognized" may appear on L-03F Connection Manager
temporarily. After a while, this terminal will be recognized.
If this terminal is recognized properly, "Your device is ready to
use" will appear.
■For Windows Vista
• On the right side of the taskbar, a message of
"Installing device driver software" appears, this terminal
will be recognized automatically.
• If this terminal is recognized normally, a message of
"Your devices are ready to use" will appear.
35
Setting Up
■For Windows XP
• On the right side of the taskbar, "Found New Hardware"
appears, and this terminal is recognized automatically.
• If this terminal is recognized properly, "Your new
hardware is installed and ready to use." will appear.
iClick [Finish]
•If you optimize communication settings (W-TCP setting)
under Windows XP, click [Finish] on the setup wizard
screen to restart.
■Installing Flash Player
If Flash Player is installed into your PC, screen shown in
"Confirming L-03F Connection Manager" (→P36) appears
and setup finishes.
If not, a message appears. Install Flash Player by the
following procedures.
aClick [OK]
bRead the content of "License Agreement", check "I
have read and agree to the terms of the Flash Player
License Agreement." and click [INSTALL]
36 Setting Up
cClick [DONE]
Installation finishes.
Confirming after Installation
Confirming L-03F Connection Manager
aDouble click L-03F Connection Manager icon
(blue) displayed on the desktop
When the following screen is displayed, the confirmation of
installation finishes.
Note
•Alternatively, remove this terminal from the PC, and then
reconnect to check.
•For Windows 7, L-03F Connection Manager cannot be
activated due to the setting of mobile broadband auto
connection. Set to "Never connect automatically". →P65
37
Setting Up
Confirming the Installed L-03F Communication
Configuration File (Drivers)
Confirm whether L-03F Communication Configuration File
(Drivers) is set in a PC.
aClick (Start) "Control Panel" "System
and Security"
■For Windows Vista
•Click (Start) "Control Panel" "System and
Maintenance".
■For Windows XP
•Click [start] "Control Panel" "Performance and
Maintenance" "System".
bClick "Device Manager"
■For Windows Vista
•Click "Device Manager" [Continue].
■For Windows XP
•Click "Hardware" tab [Device Manager].
cClick each device display to confirm the driver
name installed
•Confirm whether the driver name is displayed below
"Network adapters", "Ports (COM & LPT)", "Modems",
"Universal Serial Bus controllers".
38 Setting Up
•COM port number differs depending on user and PC.
OS Device name Driver name
Windows
7
Network adapters docomo L03F USB NDIS
Driver
Ports (COM & LPT) docomo L03F NMEA
Serial Port
docomo L03F USB Serial
Port
Modems docomo L03F Modem
Driver
Universal Serial
Bus controllers
USB Composite Device
Windows
Vista
Network adapters docomo L03F USB NDIS
Driver
Ports (COM & LPT) docomo L03F NMEA
Serial Port
docomo L03F USB Serial
Port
Modems docomo L03F Modem
Driver
Universal Serial
Bus controllers
USB Composite Device
Windows
XP
Network adapters docomo L03F USB NDIS
Driver
Ports (COM & LPT) docomo L03F NMEA
Serial Port
docomo L03F USB Serial
Port
Modems docomo L03F Modem
Driver
Universal Serial
Bus controllers
USB Composite Device
Note
•After inserting this terminal into the PC USB port, if this
terminal is not recognized, try with another USB port.
Depending on PC, this terminal may not be recognized with
certain USB port.
•When communicating data with L-03F Connection
Manager, configuring with L-03F Connection Manager is
required.→P54
•When using mobile broadband of Windows 7 to
communicate data, set in mobile broadband. →P65
•When communicating data with neither L-03F Connection
Manager nor Mobile broadband of Windows 7, configure it
manually.→P70
OS Device name Driver name
39
Setting Up
Uninstalling L-03F Connection Manager
(including a driver)
•Before uninstalling, remove this terminal from the PC.
•When uninstalling, make sure to install from the account with
PC supervisor privileges.
aClick (Start) "All Programs" "L-03F
Connection Manager" "Uninstall L-03F
Connection Manager"
■For Windows Vista
•Click (Start) "All Programs" "L-03F Connection
Manager" "Uninstall L-03F Connection Manager".
■For Windows XP
•Click [start] "All Programs" "L-03F Connection
Manager" "Uninstall L-03F Connection Manager".
bClick [Yes] on "User Account Control" screen
Click [No] to stop uninstalling.
■For Windows Vista
•Click [Continue] on "User Account Control" screen.
■For Windows XP
•"User Account Control" screen is not displayed, follow
the next procedure.
cClick [Yes] on the confirmation of deleting
application screen
dClick [Yes] on the "Confirm delete userdata"
screen to delete user data
Click [No] if you do not want to delete user data.
•Even if you click [Yes], APN information is not deleted.
40 Setting Up
■For Windows XP
•Mark "Clear communication settings (W-TCP setting)
(Recommended)" on the "Delete communication
settings" screen, then click [Next] to display the screen
in Step 4.
eClick [Finish]
Uninstallation finishes.
•If communication settings (W-TCP setting) is deleted
under Windows XP, restarting is required.
Installing L-03F USB driver only
a (Start) Click "Control Panel"
"Programs" "Uninstall a program"
"docomo L03F", then click "Uninstall"
■For Windows XP
•[start] Click "Control Panel" "Add or Remove
Programs" "docomo L03F", then click [Remove].
bClick [Yes] on the confirmation of deleting
application screen
cClick [Finish]
■For Windows XP
•Click [Finish] on the setup wizard screen. If
communication setting (W-TCP setting) is unmarked,
restarting is required.
•If the "Delete communication settings" screen appears,
select "Clear communication settings (W-TCP setting)
(recommended)" then click [Next].
41
Setting Up
Mac Version
Installation of L-03F Connection Manager is only required
to install when connect this terminal to your PC for the
first time.
※The following images are the examples of "Mac OS X 10.6.8".
Images may differ for "Mac OS X 10.7.2".
Preparation before Using L-03F
Setting via this Terminal
aTurn on the PC and activate OS
bConnect this terminal with the PC
CD-ROM icon is displayed on the desktop.
■For Mac OS X 10.7.2
CD-ROM icon does not appear by default. Make
settings to display CD-ROM icon in the following
steps.
•Finder in the menu bar "Preferences..." Mark "CDs,
DVDs, and iPods" checkbox.
cDouble click the CD-ROM icon
Note
•When installing, insert this terminal into USB port after OS
is activated.
•Do not remove this terminal while installing.
•End all the applications before installing. Also end
programs on Mac OS including virus check software.
•When installing, make sure to log in with PC supervisor
privileges.
•When connecting this terminal to a PC for the first time,
you are required to enter PIN1 code to use UIM. →P58
42 Setting Up
dDouble click "Installer.mpkg"
eClick [Continue]
fClick [Continue]
gRead "Software License Agreement" and click
"Agree" if you agree to continue installation
43
Setting Up
hClick [Install]
■If a selection screen for installation destination
appears
•Select an installation destination, click [Continue]
[Install].
■To change installation destination
•Click [Change Install Location...], then specify
installation destination.
iEnter administrator password Click [OK]
jClick [Continue Installation]
kSelect "Standard installation
(recommended)", click [Continue]
44 Setting Up
■Custom installation
aSelect "Custom installation", click [Continue]
bMake settings on the "Profile setting" screen, then click
[Continue]
cSelect "ON (recommended)" or "OFF" on the "Automatic
connection setting" screen, then click [Continue]
lClick [Restart]
The PC restarts. Installation finishes.
Remove this terminal from the PC temporarily.
45
Setting Up
Confirming after Installation
Confirming L-03F Connection Manager
aConnect this terminal with the PC
bDrag the CD-ROM icon displayed on the
desktop into trash bin
This terminal will be recognized as a modem.
cClick [Network Preferences...]
■For Mac OS X 10.7.2
•Proceed to Step 6.
dSelect "docomo L03F" and click [Apply]
eClose "Network" screen
46 Setting Up
f
Double click to launch Finder
"Applications"
"L-03F_Connection_Manager"
When the following screen is displayed, the confirmation of
installation finishes.
■Installing Flash Player
A message appears when activating the L-03F
Connection Manager for the first time if Flash Player is not
installed in your PC. Install Flash Player following the
procedures below.
aDouble click to launch Finder "Applications"
"L-03F_Connection_Manager"
bClick [OK]
cConfirm the content of the License Agreement, check
"I have read and agree to the terms of the Flash Player
License Agreement." and click [INSTALL]
47
Setting Up
dEnter administrator password and click [OK]
eClick [DONE]
Installation finishes.
Uninstalling L-03F Connection Manager
(including a driver)
•When uninstalling, make sure to log in with PC supervisor
privileges.
aConnect to a PC
CD-ROM icon is displayed on the desktop.
bDouble click the CD-ROM icon
cDouble click "Uninstaller"
dClick [Uninstall]
Note
•When communicating data via L-03F Connection Manager,
settings of L-03F Connection Manager is required.→P54
48 Setting Up
eEnter administrator password Click [OK]
fClick [Restart]
gRemove this terminal from the PC
Uninstallation finishes.
49
L-03F Connection Manager
L-03F Connection Manager ･･････････････････････ 50
Using Packet Communication ･･･････････････････ 52
Settings ･････････････････････････････････････････ 54
L-03F Connection Manager is available on either Windows or Mac. Despite the display images of Windows version and
Mac version may differ, icons on screen and available functions are the same. Please note that the descriptions in this
chapter are based on screen images of Windows.
50 L-03F Connection Manager
L-03F Connection Manager
The L-03F Connection Manager allows you to use packet
communication.
Launching/Exiting Connection Manager
■ For Windows
aConnect to a PC
•L-03F Connection Manager starts automatically and the
Home screen appears. (→P51）
■Exiting
•Click on the top of Home screen.
■ For Mac
aConnect to a PC
•When connected to a PC, the L-03F is recognized as a CD-
ROM first and a CD-ROM icon appears on the desktop.
Drag the CD-ROM icon into trash bin to have the L-03F
recognized as a modem.
b
Start Finder
Click "Applications"
"L-03F_Connection_Manager"
•L-03F Connection Manager starts automatically and the
Home screen appears.（→P51）
■Exiting
•Click "L-03F Connection Manager" on the menu bar
Quit L-03F Connection Manager.
•Using Packet Communication→P52
Enables to use packet communication easily.
•Configuration→P54, P92
Enables to confirm packet usage, set profile, set PIN1 lock for
UIM, set network (only during international roaming),
automatically connect, set language, check latest software,
reset this terminal, etc.
Note
•L-03F Connection Manager cannot be activated while
L-03F APN Tool is being operated.
•
"Access point name (APN)" on L-03F Connection Manager
does not go with "APN (Access Point No.)" on L-03F APN Tool.
•For Windows 7, L-03F Connection Manager may not be
activated depending on the setting of mobile broadband
auto connection. Set to "Never connect automatically".
•If use L-03F Connection Manager, do not connect with
wired or wireless LAN.
•Packet communication via L-03F Connection Manager is
high speed NDIS type (similar to wireless LAN type). Dial-up
connection is also available. →P73
Mac supports only NDIS type.
•L-03F Connection Manager and dial-up connection cannot
be conducted at the same time.
Note
•It may take some time before L-03F Connection Manager
activates when this terminal is connected to the PC.
51
L-03F Connection Manager
Home Screen
■ Home screen during packet communication
aVersion information button
•Click to display version information of L03F Connection
Manager.
•Latest software can be checked. (→P60)
bOperation tabs
•Tabs for Home screen and settings are functioning.
cThis terminal status area
※1 Antenna bars for showing receiving sensitivity are only
displayed during packet communication.
※2 A long period with no sent or received data.
※3 "W-CDMA (3G)"
A third generation mobile communication network complying
with 3GPP Global standards. 3GPP means 3rd Generation
Partnership Project. The local standardization organization
established for the development of common technical
specifications related to 3rd Generation Mobile
Communication Systems (IMT-2000).
※4 "HSDPA" (Short for High Speed Downlink Packet Access)
"HSUPA" (Short for High Speed Uplink Packet Access)
A high speed type of W-CDMA data communication. It is called
"3.5G" since it is the improvement version of 3rd generation
(3G) cell phone, "W-CDMA".
※5 "LTE" (short for Long Term Evolution) is a technology level
between 3rd generation (3G) and 4th generation (4G) mobile
phone. It is known as "3.9G".
※6 "GPRS" (Short for General Packet Radio Service)
GPRS is the 2.5 generation mobile communication system
that enables high speed packet communication using GSM.
Home screen (→P51)
Setting screen (→P54)
Signal bar
Strong ← → Weak
Not connected※1/during packet communication
(with no sent or received data)※2
(Out of service) Out of service area/In the area
with no signal
Network type
W-CDMA※3, HSDPA※4,
HSUPA※4, LTE※5, GPRS※6
52 L-03F Connection Manager
dConnection status display area
•Connection status (Connected/Disconnected) is shown. If
no data communication is performed for a long time while
being connected, "Connecting (no data transmission)"
appears.
eConnect/disconnect Internet button
•Click to connect or disconnect Internet.
fMinimize button
•The minimized window residents on Windows taskbar. To
reopen the minimized window, click on taskbar.
gQuit button
•Exit L-03F Connection Manager.
hCarrier display area
•The name of the connected carrier is displayed.
•
While international roaming, the name of the connected
carrier is displayed if "Operator name display" is set to
"Show".
(→P92)
iAPN name area
•Current APN name is displayed.
jOwn phone number area
•Own phone number is displayed.
Using Packet Communication
If Automatic connection setting is ON in the Setting
screen (→P59), connecting this terminal to a PC activates
L-03F Connection Manager and enables packet
communication. On Mac OS, activating L-03F Connection
Manager while Automatic connection setting is ON enables
packet communication.
※ Since Automatic connection setting is ON by default, packet
communication becomes available if L-03F Connection
Manager is activated.
Starting Packet Communication
When Automatic connection setting is ON
aConnect this terminal with a PC
•For Windows, L-03F Connection Manager is activated
automatically.
For Mac, activate L-03F Connection Manager manually.
•"Connected" appears for Connection status.
53
L-03F Connection Manager
When Automatic connection setting is OFF
•Set auto connection to OFF beforehand.
aConnect this terminal with a PC
•For Windows, L-03F Connection Manager is activated
automatically.
For Mac, activate L-03F Connection Manager manually.
bClick in Home screen
•"Connected" appears for Connection status.
Note
•The default setting of APN is "mopera.net". Set Profile
setting to change APN. →P55
•A message of "Failed to connect. Do you want to try
again?" appears when connection fails. Check APN and
connect again.
•If the PC goes to sleep or turns off while this terminal is
connected via packet communication, connection may not
be established after resume. Disconnect packet
communication and remove the terminal from the PC
before the PC goes to sleep or turns off.
•Clicking with Automatic connection setting
ON does not reconnect automatically. To execute packet
communication again, click .
•For Mac OS, when L-03F communication device is not set,
a message "The "docomo L03F" network interface has not
been set up. To set up this interface, use Network
Preferences." appears. Click [Network Preferences...] on
the screen. When "Network" screen appears, check
"docomo L03F" is displayed and click [Apply]. Clicking
[Cancel] in the message box exits L-03F Connection
Manager. Activate L-03F Connection Manager again.
•"User name", "Password", "Authentication method" for the
Profile setting (→P55) and Automatic connection setting
(→P59) are managed by user account.
54 L-03F Connection Manager
Disconnecting Packet Communication
aClick in Home screen
•Packet communication will be disconnected.
Settings
Setting screen appears if clicking in Home
screen.
•The Setting screen cannot be displayed during packet
communication. Disconnect packet communication to make
the settings.
Note
•Clicking does not turn off Automatic
connection setting. Set Automatic connection setting to
OFF not to connect automatically.
•Packet communication may automatically be disconnected
depending on the network condition or location.
•In packet communication, fees apply on the amount of
sent/received data. Note that the communication fees may
become high if you perform heavy communication such as
browsing websites which include large multi-media
contents or downloading a large size of data.
•Depending on the auto connection setting of mobile
broadband of Windows 7, communication via mobile
broadband may start when L-03F Connection Manager is
closed. Not to connect automatically, set to "Never
connect automatically" in auto connection setting of
mobile broadband. →P65
Setting item Description Page
Used amount Confirm packet usage. P55
Profile setting Set basic items for packet
communication.
P55
DOCOMO UIM card
setting
"Lock PIN1", "Unlock PIN1",
and "Change the PIN1
code" are available.
P56
Network setting Settings for overseas use
such as roaming can be
made.
P92
Automatic
connection setting
Set whether to
automatically connect to
the Internet.
P59
Language setting Set language displayed on
the screen.
P59
Check latest SW
setting
Set whether to
automatically check the
latest software.
P60
Reset L-03F Reset this terminal. P61
55
L-03F Connection Manager
Confirming Packet Usage
•Check the amount of sending and receiving data.
aClick "Used amount" in Setting screen
Packet usage is displayed.
Total use amount:
Accumulated total data usage
Use amount of this month:
Usage from 1st of this month to current
Previous use amount
:
Data usage of current session
：Reset "Total use amount" and "Use amount of
this month", respectively.
：Click to reset all the amount.
Setting Profile
•Set basic items for packet communication.
aClick "Profile setting" in Setting screen
bPerform the following operations
Access point name (APN): APN for packet communication
User name: ID supplied by your provider
Password: Supplied by your provider
Authentication method: To enable to use this terminal
：Click to change settings.
： Click to return to default setting.
cClick [Set]
A message to confirm is displayed.
dClick [Yes]
eClick [OK]
Note
•The data usage displayed on the screen may differ from the
actual volume of packet communication.
56 L-03F Connection Manager
Setting a UIM
•"Lock PIN1", "Unlock PIN1" and "Change PIN1 code" are
available.
aClick "DOCOMO UIM card setting" in Setting
screen
DOCOMO UIM card setting screen is displayed.
Locking PIN1
•Set security to UIM.
aSelect "Lock PIN1" in DOCOMO UIM card
setting screen
Entering PIN1 code screen is displayed.
bEnter the PIN1 code set in UIM
cClick [OK]
dClick [OK]
Note
•"Connection type" is set according to the IPv4, IPv6 IP
address setting by network settings in the OS.
•Click [Set] to renew the settings. Always remember to click
when changing settings.
•If ID or password is wrong, Internet connection cannot be
made.
•Set the content of each profile according to the values
specified by each provider or network administrator.
Connection does not correctly perform with wrong
settings.
•You can connect to "mopera U" even if "User name" and
"Password" are in blank.
Note
•If you lock PIN1 then remove and insert this terminal, PIN1
code entry screen appears when L-03F Connection
Manager restarts. Enter a correct PIN1 code to use this
terminal.
57
L-03F Connection Manager
Unlocking PIN1
aSelect "Unlock PIN1" in DOCOMO UIM card
setting screen
Entering PIN1 code screen is displayed.
bEnter the PIN1 code set in UIM
cClick [OK]
dClick [OK]
Changing PIN1 Code
•Set the password required when unlocking or locking PIN1.
•Changing PIN1 code is only available when PIN1 is locked.
aClick [Change PIN1 code] in the DOCOMO
UIM card setting screen
bEnter the current PIN1 code set in UIM in
"PIN1 code" field
cEnter new PIN1 code in "New PIN1 code"
Enter a 4- to 8- digit PIN1 code.
dIn "Confirm new PIN1 code", enter the PIN1
code that has been entered in "New PIN1
code" code again
eClick [Set]
fClick [OK]
Note
•If PIN1 is unlocked, you can use UIM information from this
terminal without verifying PIN1 code.
58 L-03F Connection Manager
Entering PIN1 Code
•When L-03F Connection Manager is started after setting PIN1
lock or it is restarted to reset this terminal, PIN1 code input
screen will appear.
aEnter PIN1 code
Enter the 4- to 8- digit PIN1 code.
bClick [OK]
cConfirm the result after entering PIN1 code
Ex.1： When PIN1 code is entered correctly
Home screen of L-03F Connection Manager is displayed.
Ex.2： When PIN1 code is entered incorrectly
Ex.3： When PIN1 code is entered incorrectly for 3
times in a row.
•If you improperly enter the PIN1 code 3 times in a row,
the unblocking PIN code entry screen will be displayed.
■Unblocking PIN code setting
aEnter the unblocking PIN code set your UIM to "PIN
unlocking code"
bEnter a new PIN1 code in "New PIN1 code"
cIn "Confirm new PIN1 code", enter the PIN1 code that
has been entered in "New PIN1 code" code again
dClick [Set]
59
L-03F Connection Manager
Making Automatic connection setting
•Set whether to automatically connect to the Internet when
L-03F Connection Manager is activated.
•Automatic connection setting is not available during
international roaming.
aClick "Automatic connection setting" in
Setting screen
bSelect "ON (Recommended)" or "OFF"
cClick [Set]
dClick [OK]
Setting language
•Select Japanese or English as a display language for L-03F
Connection Manager.
aClick "Language setting" in Setting screen
bSelect "English" or "Japanese"
cClick [Set]
dClick [OK]
Caution
•If you select Japanese on an OS other than Japanese
version, specified settings or installations may be required.
For details on settings, contact your computer
manufacturer or Microsoft Corporation.
60 L-03F Connection Manager
Setting to check the latest software
•Set whether to automatically check the latest software each
time L-03F Connection Manager is activated.
aClick "Check latest SW setting" in Setting
screen
bSelect "ON" or "OFF"
ON： Check the latest software each time L-03F
Connection Manager is activated.
OFF：Check the latest software by clicking
on the information screen of
L-03F Connection Manager.
cClick [Set]
dClick [OK]
Checking the version information
Click on the title bar in the L-03F Connection Manager
screen to display information about L-03F Connection
Manager software.
：Click to check updates.
Note
•For information on how to update the software, see
"Updating Software". →P118
•Software update is not available on Mac OS. Update
software on Windows.
61
L-03F Connection Manager
Resetting this terminal
Reset this terminal if it does not work properly.
aClick in Setting screen
bClick
This terminal starts resetting. After the reset finishes, it will
return to the Home screen.
•A message "L-03F is not recognized" may temporarily be
displayed. This terminal will be detected after a while.
64 Mobile Broadband
Mobile Broadband
Use the mobile broadband installed in Windows 7 to
communicate packet. Only Windows 7 supports mobile
broadband.
In this manual, operations such as connecting/
disconnecting mobile broadband, changing APN or setting
PIN lock are described.
Visit Microsoft website for detailed information.
For connecting this terminal with Internet, agreement with
the ISP (mopera U etc.) supporting service and data
communication is required.
Visit DOCOMO website for detailed information (Japanese
only).
※ For the following procedures, description will be based on
the installation via only Communication Configuration File
(Driver).
•If you use mobile broadband, install the communication
configuration file (Driver) only.
Viewing Screen
■ APN screen
aCurrent APN
•While connecting mobile broadband, the current APN will
be displayed.
bAPN list
•If click APN, "Connect" button/"Disconnect" button will be
displayed.
65
Mobile Broadband
■ Property screen for setting each item
aSetting tabs on Property screen
Subscription：Display provider details, own number, etc.
Profile：Set APN or auto connection. (→P66)
Roaming※：Select a network to use while roaming.
Security：When connecting mobile broadband, set PIN
authentication. (→P67)
※ Display only during international roaming.
Connecting through Mobile
Broadband
aConnect this terminal with a PC
■When connecting for the first time
aClick ( if network connection is not made) or in
the task tray displayed on the bottom right
bRight click "DOCOMO" and click "Connect"
cSet each item Click "Continue"
•Enter APN in "APN" field.
•Enter the settings specified by your provider or
network administrator in "User name" and "Password".
•If connect to "mopera U", connection is available with
"User name" and "Password" blank.
dSet auto connection Click "Continue"
•Select from "Connect automatically except when
roaming", "Always connect automatically" or "Never
connect automatically" in pull-down menu.
bFollow the auto connection setting on profile
tab to connect
■Connect automatically except when roaming
•Connect automatically while using in Japan. While
roaming, operations are the same as "■ Never connect
automatically".
■Always connect automatically
•Connect automatically after connecting with this
terminal.
■ Never connect automatically
aClick ( if network connection is not made) or in
the task tray displayed on the bottom right
bSelect "DOCOMO" Click [Connect]
66 Mobile Broadband
Disconnecting Mobile
Broadband
aClick or in the task tray on the bottom
right
bSelect "DOCOMO" Click [Disconnect]
Changing APN Settings
aConnect this terminal with a PC
b
Click ( if network connection is not made)
or in the task tray on the bottom right
cRight click "DOCOMO" and click "Properties"
dClick "Profile" tab Set each item
•Enter APN in "APN" field.
•Enter the specified settings by provider or network
administrator in "User name", "Password" field.
•If connect to "mopera U", connection is available even if
"User name" and "Password" are in blank.
•In "Autoconnect" field, select from "Connect automatically
except when roaming", "Always connect automatically" and
"Never connect automatically".
•If a PC accesses Internet via LAN, check the check box of
"Autoconnect only if no alternate Internet connection is
available" not to connect automatically on Windows.
eClick [OK]
Note
•A screen to confirm PIN1 code appears according to the
setting. Enter PIN1 code after the screen appears.
•When mobile broadband is used to connect data
communication, L-03F Connection Manager and dial-up
connection are not available.
"Disconnect" the mobile broadband or set auto connection
setting to "Never connect automatically" to enable to use
L-03F Connection Manager or dial-up connection.
•If select "Always connect automatically", the amount of
packet transmission may go huge due to the long time
connection. Note that hefty fee may result.
•Note that communication fees may become high when
"Always connect automatically" is set during overseas use.
67
Mobile Broadband
Setting UIM
•[Enable PIN...], [Disable PIN...] and [Change PIN...] can be
performed on UIM.
aConnect this terminal with a PC
bClick ( if network connection is not
made) or in the task tray on the bottom
right
cRight click "DOCOMO" and click "Properties"
dClick "Security" tab Set each item
•Set PIN1 lock in [Enable PIN...].
•Unlock PIN1 in [Disable PIN...].
•Change PIN1 in [Change PIN...].
Note
•If connect mobile broadband under PIN validation, PIN1
code entry screen is displayed. In this case, this terminal
cannot normally function with wrong PIN1 code.
•If entering PIN1 code is failed 3 times in a row, PIN code
will be locked. In that case, enter unblocking PIN code.
•If entering unblocking PIN code is failed 10 times in a row,
UIM will be locked automatically. In that case, contact a
docomo Shop.
•If set to PIN invalidation, mobile broadband connection is
available without confirming PIN1 code.
70 Configuring Network Manually
Windows Version
Setting APN Using L-03F APN Tool
Set the settings required when connecting dial up manually
through L-03F APN Tool.
Set the access point (APN) in packet communication of
dial-up connection. Up to 10 APN can be set up and they
are managed with cid's.
•While L-03F Connection Manager is activated, L-03F APN Tool
cannot be activated.
•The registration number (cid) 1 is pre-installed to mopera.net.
Use cid2 to cid10 to set another APN.
•For APNs other than "mopera U", contact your ISP or network
administrator.
aConnect this terminal with a PC
bDouble click L-03F APN Tool icon (purple)
on the desktop
L-03F APN Tool is launched.
cSelect "CID No." field to set Click [Add/Edit]
■Deleting APN
aSelect "CID No." field to delete
bClick [Remove]
cClick [Yes]
dClick [Save]
eClick [OK]
■Initializing APN
aClick [APN Reset]
bClick [Yes]
cClick [Save]
dClick [OK]
71
Configuring Network Manually
dEnter the APN in "APN" field Click [Set]
eClick [Save]
Confirmation screen appears.
fClick [OK]
The setting of APN finishes.
Setting APN Without Using L-03F APN
Tool
Describe how to set an APN by using "Hyper Terminal"
attached on standard Windows XP.
•Windows 7 and Vista do not support "Hyper Terminal". Setting
with software compatible with each OS is required. For setting
instructions, refer to the instructions for each OS.
aConnect this terminal with a PC
bClick [start] "All Programs"
"Accessories" "Communications" "Hyper
Terminal"
Hyper Terminal starts.
cEnter a connection name in "Name" field
Click [OK]
dEnter a number does not exist (like "0") in
"Phone number" field Check that "docomo
L03F Modem Driver" is displayed in "Connect
using" Click [OK]
•If two or more modem names are displayed in the "Connect
using" field, check this terminal modem name and select a
proper one. (→P38)
72 Configuring Network Manually
eClick [Cancel] on connection screen
The Hyper Terminal screen opens.
fEnter the APN in the following format
Press
Enter AT+CGDCONT=<cid>,"<PDP type>","<APN>"
Enter the following information in the corresponding <cid>,
<PDP type> and <APN> sections.
If "OK" appears after you enter the information, the APN has
been setup.
•If the entered characters do not appear, enter ATE1 .
■To reset the specified cid APN settings
Enter AT+CGDCONT=<cid>
■To view the registered APN
Enter AT+CGDCONT?
gConfirm if "OK" is displayed
hClick "File" "Exit"
iClick [Yes] on confirming disconnection
screen Click [No] on the confirming to save
screen
Hyper Terminal quits, and the settings of the APN complete.
cid ： Enter any number from 2 to 10.
※ Keep in mind that the old setting
information will be overwritten if you select
a cid number which has been set.
PDP type ： Enter a connection method. Enter IP enclosed
in quotation marks " ".
APN ： Enter an (APN) enclose it in quotation marks
" ".
Note
•The APN information is saved in this terminal. If you
connect a different terminal, save the APN information
again.
•If you want to use the APN information registered on the
PC, register the same APN in the same cid of this terminal.
•When setting connection through PDP type, enter the
specified content by each provider or network
administrator.
73
Configuring Network Manually
Configuring Dial-up Network Manually
Set up the dial-up network on the PC.
•For setting up a connection to other than "mopera U", contact
your ISP or network administrator.
Example: Connecting to the DOCOMO Internet connection
service "mopera U", which is registered to <cid>=1
For Windows 7
aClick (Start) "Control Panel" "Network
and Internet" "Network and Sharing Center"
bClick "Set up a new connection or network"
cSelect "Set up a dial-up connection" Click
[Next]
74 Configuring Network Manually
dWhen the modem selection screen appears,
click "docomo L03F Modem Driver"
The modem selection screen opens only if two or more
modems are connected to a PC.
eConfigure each setting, then click [Connect]
•Enter *99***<cid># in the "Dial-up phone number". Enter
the registration number of an APN set in <cid>. (→P70)
•Enter the user name and password specified by your ISP or
network administrator in the "User name" and "Password"
fields.
•You can leave the "User name" and "Password" fields
unfilled when connecting to "mopera U".
•Enter a connection name in the "Connection name" field.
75
Configuring Network Manually
fClick "Skip" on the "Connecting to (APN)..."
screen
The connection test will not be performed. Only the settings
will be checked.
gClick [Close]
hClick (Start) "Control Panel" "Network
and Internet" "Network and Sharing Center"
i"Change adapter settings" Select the
created dial-up icon Right click the icon and
select "Properties"
jCheck the settings on the "General" tab
window
If two or more modems are connected to a PC, enable only
"Modem - docomo L03F Modem Driver" in the "Connect using"
field.
•Disable "Use dialing rules".
76 Configuring Network Manually
kClick "Networking" tab Configure each
setting
The settings for "QoS Packet Scheduler" in "This connection
uses the following items" field should follow your ISP or
network administrator. Do not change the other items.
•When the IP and DNS information settings are requested
by your ISP, etc., select "Internet Protocol Version 6 (TCP/
IPv6)" or "Internet Protocol Version 4 (TCP/IPv4)", then
click "Properties" to make the settings. For setting details,
contact your ISP or network administrator.
lClick the "Options" tab Click [PPP
Settings...]
mRemove check marks from all items Click
[OK]
nOn the "Options" tab window, click [OK]
77
Configuring Network Manually
For Windows Vista
aClick (Start) "Connect to"
bClick "Set up a connection or network"
cSelect "Set up a dial-up connection" Click
[Next]
78 Configuring Network Manually
dWhen the modem selection screen appears,
click "docomo L03F Modem Driver"
The modem selection screen opens only if two or more
modems are connected to a PC.
eConfigure each setting, then click [Connect]
•Enter *99***<cid># in the "Dial-up phone number". Enter
the registration number of an APN set in <cid>. (→P70)
•Enter the user name and password specified by your ISP or
network administrator in the "User name" and "Password"
fields.
•You can leave the user name and password fields unfilled
when connecting to "mopera U".
•Enter a connection name in the "Connection name" field.
79
Configuring Network Manually
fClick [Skip] on the "Connecting to (APN)..."
screen
The connection test will not be performed. Only the settings
will be checked.
•If you do not click [Skip], the connection to the Internet will
be established.
gClick "Set up the connection anyway"
[Close]
hClick (Start) "Connect to"
iSelect the created dial-up connection icon
Right click "Properties"
80 Configuring Network Manually
jCheck the settings on the "General" tab
window
If two or more modems are connected to a PC, enable only
"Modem - docomo L03F Modem Driver" in the "Connect using"
field.
•Disable "Use dialing rules".
kClick "Networking" tab Configure each item
The settings for "QoS Packet Scheduler" in "This connection
uses the following items" field should follow your ISP or
network administrator. Do not change the other items.
•When the IP and DNS information settings are requested
by your ISP, etc., select "Internet Protocol Version 6 (TCP/
IPv6)" or "Internet Protocol Version 4 (TCP/IPv4)", then
click "Properties" to make the settings. For setting details,
contact your ISP or network administrator.
81
Configuring Network Manually
lClick the "Options" tab Click [PPP
Settings...]
mRemove check marks in all items Click [OK]
nOn the "Options" tab window, click [OK]
For Windows XP
aClick [start] "All Programs"
"Accessories" "Communications" "New
Connection Wizard"
bOn the "New Connection Wizard" screen, click
[Next]
82 Configuring Network Manually
cSelect "Connect to the Internet" Click
[Next]
dSelect "Set up my connection manually"
Click [Next]
eSelect "Connect using a dial-up modem"
Click [Next]
fIf "Select a Device" screen appears, check in
"Modem - docomo L03F Modem Driver" check
box Click [Next]
The "Select a Device" screen appears only if two or more
modems are connected to a PC.
83
Configuring Network Manually
gEnter a name in the "ISP Name" field Click
[Next]
hEnter the APN number in the "Phone number"
field Click [Next]
•Enter "*99***<cid>#". Enter the registered number of APN
in <cid>. (→P70)
iSelect the connection usage range Click
[Next]
Select a user.
•Depending on the PC settings, this screen may not
appear.
jFill in the "User name", "Password", and
"Confirm password" fields Click [Next]
Enter the information provided by your ISP or network
administrator.
•Enter "User name" and "Password" correctly according to
the instruction from the provider. Pay attention to the
capital characters.
•For "mopera U", connection is available with "User name"
and "Password" blank.
84 Configuring Network Manually
kClick [Finish]
lClick [start] "All Programs"
"Accessories" "Communications"
"Network Connections"
mSelect the created dial-up connection icon
Right click Click "Properties"
85
Configuring Network Manually
nCheck the settings on the "General" tab
window
•If two or more modems are connected to a PC, enable only
"Modem - docomo L03F Modem Driver" in the "Connect
using" field.
•Disable "Use dialing rules".
oClick the "Networking" tab Confirm each
item
•Select "PPP: Windows 95/98/NT4/2000, Internet" in the
"Type of dial-up server I am calling" field.
•Do not change the settings in "This connection uses the
following items" field.
•When connecting to a provider, to confirm the TCP/IP
settings contact the provider or network administrator.
86 Configuring Network Manually
pClick [Settings]
qRemove check marks from all items Click
[OK]
rClick [OK] on the "Networking" tab window
Communicating (Connecting by Dial-up)
This section describes steps to start and terminate
communication without using L-03F Connection Manager
or Mobile Broadband.
•Check whether this terminal and the PC are connected properly
before starting communication. (→P20)
•When performing communication, connect this terminal you
used to configure the settings. If a different terminal is
connected, L-03F Connection Manager (including a drivers)
may need to be reinstalled.
•When set PIN1 lock using L-03F Connection Manager, start
after unlocking PIN1.
aClick (Start) "Control Panel" "Network
and Internet" "Network and Sharing Center"
"Change adapter settings" Double click
the set APN icon
■For Windows Vista
•Click (Start) "Connect to" Select the set APN
Click [Connect].
■For Windows XP
•Click [start] "All Programs" "Accessories"
"Communications" "Network connections" Double
click the set APN icon.
87
Configuring Network Manually
bEnter "User name" and "Password" Click
[Dial]
The APN will be connected.
•To connect to "mopera U", you can leave the " User name"
and "Password" fields unfilled and click [Dial]. If another ISP
or dialup connection is selected, fill in the "User name" and
"Password" fields and click [Dial].
•You can save the user name and password or just the
password to skip entering them next time.
•Depending on the operating system, a connection
completion screen may appear when the dial-up
connection is established. However, the connection
completion screen does not appear if you previously set
the completion message not to appear.
Disconnecting Communication
Exiting the Internet browser may not terminate the
connection. Perform the following steps to terminate the
connection securely.
aClick (dial-up icon) on the task tray of a PC
A screen indicating the connection status appears.
bSelect an APN Click [Disconnect]
Communication is disconnected.
■For Windows Vista
•Click "Connect or disconnect..." "Disconnect".
■For Window XP
•Click [Disconnect].
Note
•The communication speed shown on the PC screen may be
different from the actual communication speed.
89
Overseas Use
International Roaming Service (WORLD WING) ･･ 90
Services Available Overseas ････････････････････ 90
Before Using Overseas ･･････････････････････････ 91
Setting the Searching Method for Available
Networks ･･････････････････････････････････････ 92
Configuring Network･･･････････････････････････ 92
90 Overseas Use
International Roaming Service
(WORLD WING)
International roaming service enables you to use this
terminal domestically in a service area of international
carrier associated with DOCOMO.
■ Available area
This terminal can be used in 3G network and
GPRS network service areas. Also, it can be used in the
countries and areas that support 3G850MHz. Check
available areas.
•Before using this terminal overseas, see the following items.
- "Mobile Phone User's Guide [International Services]"
- DOCOMO International Services website
•For areas out of Xi area such as overseas, connect to 3G or
GPRS network.
Services Available Overseas
Service Description
Data Communication Available for data communication
using packets communication.
Note
•For details on available communication services while
using international roaming, refer to Mobile Phone User's
Guide [International Services] or visit DOCOMO
"International Service Website".
•L-03F does not support voice call or video telephony
features.
91
Overseas Use
Before Using Overseas
STEP1：Before Leaving Japan
STEP2：While Overseas
STEP3：After Coming Back to Japan
Before Leaving Japan
■ Subscription
•"WORLD WING" is always applied together with your
subscription. Contact My docomo, docomo Shop or docomo
Information Center for details.
•A UIM made available for "WORLD WING" must be inserted
in this terminal.
■ Power source and voltage in the country or region of
stay
•Countries and regions may have different power sources,
voltages or power outlet shapes. Check these in the
INSTRUCTION MANUAL for your PC or websites of the PC
manufacturer in advance.
■ Network setup
•You can change network setup from overseas. (→P92)
■ Usage charge
•The charge for usage (bill for packet communication)
abroad is different from the charge in Japan.
■ Internet access
•For overseas access points or settings for using the
Internet overseas, contact your ISP.
•If you subscribe to mopera U, visit the mopera U website.
http://www.mopera.net/ (Japanese only)
■ Automatic connection for Mobile Broadband
•Note that if you use packet communication overseas using
Windows 7 mobile broadband with the automatic connect
setting to "Always connect automatically", (→P65)
communication fees may become extremely high.
While Overseas
■ Switching networks
Available networks are detected automatically by default.
■ Home screen
The name of the connected carrier is displayed if
"Operator name display" is set to "Show". (→P92)
Also the information of the Internet being connected is
displayed. (→P51)
Inquiries overseas
If your UIM is lost or stolen overseas, contact DOCOMO
immediately and temporarily suspend your subscription.
For inquiry information, see "docomo Information Center"
on the back of this manual. Call or data communication
charge will still on you after the terminal was lost or stolen.
Note
•You can manually switch networks if you want to connect
to a particular network. See Step 3 of "Configuring
Network". →P93
92 Overseas Use
After Coming Back to Japan
After coming back to Japan, you can use within Xi area or
FOMA area.
■ If connection cannot be established
Set "3G/GPRS switching" in "Network setting" (→ P92) to
"Automatic" and "Network discovery method" to
"Automatic search".
Setting the Searching Method
for Available Networks
Switching Carriers Manually
This terminal is set to automatically find and switch to an
available network in the country of stay by default.
However, if you have a preferred network in the area or
network cannot be found automatically, you can set to a
network manually. For details, see Step 3 of "Configuring
Network". (→P93)
Configuring Network
•Allow you to configure network by L-03F Connection Manager.
•Available if you come back to Japan with international roaming
set or "Manual search" for "Network discovery method" selected
during international roaming.
aClick "Network setting" in Setting screen
(→P54)
bSpecify a network to connect under "3G/
GPRS switching"
93
Overseas Use
cSpecify a search method from "Network
search method"
■[Automatic search]
Network can be searched automatically.
■[Manual search]※
•Connect to the listed networks manually.
•How to manually configure network
- Select [Manual search].
- Click [Yes].
- The available network list will be displayed after searching.
- Select one from the available networks.
- Click .
- Click [Yes].
※ If you manually select a network overseas, reset to
"Automatic search" after coming back to Japan.
dSpecify whether to show or hide the network
information in "Operator name display"
■[Show]
•The name of the network receiving current service is
displayed on the screen.
■[Hide]
•The name of the network receiving current service is
not displayed on the screen.
eClick the applicable
•The information entered will not be set without clicking the
applicable .
fClick [Yes]
gClick [Close]
( ○ ): Available, (×): Unavailable are shown after
the detected network operators name.
Note
•Connecting to Internet may not be able to operate properly
when network settings are changed manually.
94 Overseas Use
Note
•While using overseas
- If "Network search method" is set to "Automatic search",
this terminal will search the available carrier
automatically and connect again if move to an area out
of service.
- Some communication services may not be available
depending on the overseas carrier or network.
- If you set only "Internet Protocol Version 6 (TCP/IPv6)"
under Windows 7 or Windows Vista, you may not
connect to the Internet overseas. If a message
notifying unavailability of Internet connection, mark
"Internet Protocol Version 4 (TCP/IPv4)" on the
properties screen for "Mobile Broadband connection" or
"Local area Connection" in "docomo L03F USB NDIS
Driver", the device name for network settings, to change
the setting.
95
Appendix/Troubleshooting
AT Commands ･･･････････････････････････････････ 96
AT Command List････････････････････････････････ 97
Options and related devices ･････････････････････ 112
Troubleshooting ･････････････････････････････････ 113
Error Messages･･････････････････････････････････ 116
Warranty and After-Sales Service ･･･････････････ 117
Updating Software ･･･････････････････････････････ 118
Main Specifications ･･････････････････････････････ 119
Export Administration Regulations ･･････････････ 121
Intellectual Property Rights ･････････････････････ 123
Index･････････････････････････････････････････････ 125
96 Appendix/Troubleshooting
AT Commands
AT commands are used to check this terminal function
settings or status by using a PC. Usually, the
communication software issues AT commands so you do
not need to be concerned about them. Use AT commands if
you want to control this terminal in your own way.
Form of AT Commands
AT commands should be entered on the Terminal Mode
screen of the communication software. Use only single-
byte alphanumeric characters.
<Example>
•An AT command must be entered on a single line including
parameters (numbers and symbols) following the command. On
the Terminal Mode screen of the communication software,"one
line" is from the first character to the character before .
Note
•In the Terminal mode, a PC functions as a communication
terminal. Characters entered from the keyboard are sent to
a line connected to a communication port.
ATD ＊ 99 ＊＊＊ 1#
Hard Return
Parameter: Content
Command Name
97
Appendix/Troubleshooting
AT Command List
The following AT commands can be used on the "L-03F" modem port.
•[&F]：A command to initialize settings used as AT&F command.
•[?][=?]：The current settings appear when adding "?" at the end of the command, and the effective range of the current
settings appears when adding "=?" at the end of the command.
Command Overview Parameters/Description Examples of
Commands
AT OK is displayed. - AT
OK
AT&C<n>
[&F]
Select the operating conditions of
the circuit CD signal for TE.
n=0: Always keeps CD signal ON
n=1 (default): CD changes depending on the
other party's modem status.
AT&C1
OK
AT&D<n>
[&F]
Select the operation when receiving
circuit ER signal from TE.
n=0 : Same as n=2
n=1 : Same as n=2
n=2 (default) : If ER signal is changed from
ON to OFF, line will be disconnected and
become offline command.
AT&D1
OK
AT&F<n> Reset the settings on this terminal
with the nonvolatile memory
contents. If performed during a
communication, the line is
disconnected.
Only n=0 can be set (Skippable) AT&F
OK
AT+CEER Set up error report is displayed. - AT+CEER
+CEER: 36
OK
98 Appendix/Troubleshooting
AT+CEREG=<n>
[&F]
[?] [=?]
Set if notify EPS network
registration.
＜n＞： Set if send unsolicited result code
n=0： Do not send unsolicited result code
(default)
n=1： Send network registration status as
unsolicited result code
n=2： Send network registration status and
location information as unsolicited result
code
＜stat＞：Packet data exchange network
registration status
stat=0：Outside area and not searching
stat=1： Within area (HOME)
stat=2： Outside area and Attach or searching
stat=3： Registration is refused
stat=4： Unclear (other)
stat=5： Within area (while roaming)
＜lac＞：Location area code
This parameter is string parameter. It will be
surrounded by "". Notation as a hex of 2byte.
＜ci＞：Cell ID
This parameter is string parameter. It will be
surrounded by "". Notation as a hex of 4byte.
＜AcT＞： Within area
AcT=0：GSM
AcT=2：3G (FOMA)
AcT=7：LTE (Xi)
＜rac＞： Routing area code
This parameter is string parameter, it will be
surrounded by "". Notation as a hex of 1byte.
AT+CEREG?
+CEREG:
2,1,"00C3","01","00
00C4D1",7
OK
AT+CGDCONT
[?] [=?]
Set APN when sending Packet
communication.
Refer to P111 Refer to P111
Command Overview Parameters/Description Examples of
Commands
99
Appendix/Troubleshooting
AT+CGEQMIN
[?] [=?]
Register criteria value for
determining if QoS (Quality of
Service) sent from network when
PPP Packet communication is
established is acceptable or not.
Refer to P111 Refer to P111
AT+CGEQREQ
[?] [=?]
Set QoS(Quality of Service) to
request for the network when PPP
Packet communication starts.
Refer to P111 Refer to P111
AT+CGMR Display IMEISV value of this
terminal.
- AT+CGMR
1234512345123
456
OK
Command Overview Parameters/Description Examples of
Commands
100 Appendix/Troubleshooting
AT+CGREG=<n>
[&F]
[?] [=?]
Set if notify GPRS network
registration.
＜n＞: Set if send unsolicited result code
n=0：Do not send unsolicited result code
(default)
n=1：Send network registration status as
unsolicited result code
n=2：Send network registration status and
location information as unsolicited result
code
＜stat＞：Packet data exchange network
registration status
stat=0：Outside area and not searching
stat=1：Within area (HOME)
stat=2：Outside area and Attach or
searching
stat=3：Registration is refused
stat=4：Unclear (Other)
stat=5：Within area (while roaming)
＜lac＞：Location area code
This parameter is string parameter. It will be
surrounded by "". Notation as a hex of 2byte.
＜ci＞：Cell ID
This parameter is string parameter. It will be
surrounded by "". Notation as a hex of 4byte.
＜AcT＞：Within area
AcT=0：GSM
AcT=2：3G (FOMA)
AcT=7：LTE (Xi)
＜rac＞：Routing area code
This parameter is string parameter. It will be
surrounded by "". Notation as a hex of 1byte.
AT+CGREG?
+CGREG:
2,1,"00C3","0000C
4D1",2,"01"
OK
AT+CGSN Display the serial number of this
terminal.
- AT+CGSN
12345678901
2345
OK
Command Overview Parameters/Description Examples of
Commands
101
Appendix/Troubleshooting
AT+CIND
[?] [=?]
The signal status of this terminal is
displayed. Execute "AT+CIND=?",
then appears as
"+CIND:<battchg>,<signal>,<servi
ce>".
<battchg>
battchg=0∼5 : Battery charge level
* Not supportive.
<signal>
signal=1 : 0 or 1 bar of antenna is displayed
signal=3 : 2 bars of antenna are displayed
signal=5 : 3 bars of antenna are displayed
<service>
service=0 : Out of area
service=1 : Within area
AT+CIND?
+CIND:5,5,1
OK
AT+CIND=?
+CIND:("battchg",(0
-5)),("signal",(0-
5)),("service",(0,1))
OK
AT+CLCK=<fac>,<mod
e>[,<passwd>]
[=?]
Change PIN lock setting and inquire
the setting items.
<fac>: Lock type
fac="SC" : Operation of setting UIM PIN lock
<mode>: Lock control
mode=0 : Unlock PIN lock
mode=1 : Set PIN lock
mode=2 : Status of PIN lock
<passwd>: PIN code
Execute "AT+CLCK="SC",2", then appears as
"+CLCK:<state>".
<state>: Lock status
0 : PIN is unlocked
1 : PIN is locked
AT+CLCK="SC",0,"0
000"
OK
AT+CLCK="SC",2
+CLCK:1
OK
Command Overview Parameters/Description Examples of
Commands
102 Appendix/Troubleshooting
AT+CMEE=<n>
[&F]
[?] [=?]
Set the error report form of this
terminal.
n=0: Display "ERROR". (default)
n=1: Display in the form of "+CMEE ERROR:
xxxx" (where xxxx are numbers)
n=2: Display in the form of "+CMEE ERROR:
xxxx" (where xxxx are text)
※ If using ATZ or AT&F command to default,
"0" is setup.
Note that when connecting L-03F to
power, the value of ATZ or AT&F
command differs.
AT+CMEE=0
OK
AT+CMEE?
+CMEE:0
OK
AT+CMEE=?
+CMEE:(0-2)
OK
AT+ CNUM Display the own number of this
terminal.
Executing "AT+CNUM" displays in the form of
"+CNUM: <number>, <type>".
number: phone number
type=129: Excluding the international
access code+
type=145: Including the international
access code+
AT+CNUM
+CNUM:
,"09012345678",1
29
OK
Command Overview Parameters/Description Examples of
Commands
103
Appendix/Troubleshooting
AT+COPS=
〔<mode>〔,<format>
〔,<oper>〔,<AcT>
〕〕〕〕
[?] [=?]
Select network operator and set. ＜mode＞ Parameter is supporting 0-4.
＜format＞ Parameter is only supporting
2(default).
＜oper＞ MCC+MNC
For example, if PLMN Number is 440 (MCC)
10 (MNC), ＜oper＞="44010".
＜stat＞ Parameter is supporting the
followings.
stat=0：unknown
stat=1：available
stat=2：current
stat=3：forbidden
＜AcT＞: Within area
AcT=0：GSM
AcT=2：3G (FOMA)
AcT=7：LTE (Xi)
AT+COPS=0
OK
AT+COPS?
+COPS:0
OK
AT+COPS=1,2,"44
010",7
OK
Command Overview Parameters/Description Examples of
Commands
104 Appendix/Troubleshooting
AT+CPAS
[=?]
Display this terminal state. Displays in the form of "+CPAS : <n>".
n=0: Available
n=1: Unavailable
n=2: Unclear
n=3: Available and while incoming call
receiving
n=4: Available and communicating
AT+CPAS
+CPAS:0
OK
AT+CPIN="PIN"/
AT+CPIN="PUK" , "PIN"
[?]
Command to enter the PIN1 code or
unblocking PIN code for UIM.
Enter the PIN1 code for "PIN", and enter
unblocking PIN code for "PUK".
Executing "AT+CPIN?" displays "+CPIN:
<n>".
n=READY: Authenticated
n=SIM PIN: Waiting for entry
n=SIM PUK: Waiting for
unblocking PIN code entry
n=ERROR: Locked
(+CPIN:SIM PIN
status)
AT+CPIN="1234"
OK
(+CPIN:SIM PUK
status)
AT+CPIN="123456
78", "1234"
OK
AT+CPWD=<fac>,<old
pwd>,<newpwd>
[=?]
Change password of PIN1 code. <fac>
fac="SC" : Change PIN1 code of UIM
<oldpwd><newpwd>means enter the
current PIN code and new PIN code.
Execute "AT+CPWD=?", then appears
as"+CPWD:("SC",<pwdlength>)".
<pwdlength> displays maximum character
number of PIN.
AT+CPWD="SC",
"0000", "1111"
OK
Command Overview Parameters/Description Examples of
Commands
105
Appendix/Troubleshooting
AT+CR=<mode>
[&F]
[?] [=?]
Set if display service report. <mode>
0 : Do not return report (default).
1 : Return report.
AT+CR=0
OK
AT+CR?
+CR:0
OK
AT+CREG=<n>
[&F]
[?] [=?]
Set if notify EPS network
registration and make an inquiry.
＜n＞: Set if send unsolicited result code
n=0 : Do not send unsolicited result code
(default)
n=1 : Send network registration status as
unsolicited result code
n=2 : Send network registration status and
location information as unsolicited result
code
＜stat＞：Packet exchange network
registration status
n=0 : Outside area and not searching
AT+CREG=0
OK
AT+CREG?
+CREG:0,0
OK
AT+CSQ
[=?]
Display the wireless quality of this
terminal.
Execute "AT+CSQ", then appears as
"+CSQ:<rssi>,<ber>".
<rssi>
rssi=0 : Under -113dBm
rssi=1 : -111dBm
rssi=2∼30 : -109dBm∼-53dBm
rssi=31 : Over -51dBm
rssi=99 : Unclear or not detected
<ber>
ber=0∼7 : Bit Error Rate, RXQUAL
ber=99 : Unclear or not detected
AT+CSQ
+CSQ:31,7
OK
Command Overview Parameters/Description Examples of
Commands
106 Appendix/Troubleshooting
AT+GCAP Display the capability list of this
terminal.
- AT+GCAP
+GCAP: +CGSM,+W
OK
AT+GMI Display the manufacturer of this
terminal.
-AT+GMI
LG Electronics Inc
OK
AT+GMM Display the name of this terminal. - AT+GMM
docomo L03F
OK
AT+GMR Display the S/W version of this
terminal.
-AT+GMR
L03F-MDM9200-
VXXX-XXX-XX-
XXXX-DCM-JP
OK
AT+IFC=<n>,<m>
[&F]
[?] [=?]
Set the local flow control method
between the PC and this terminal.
n : DCE by DTE control
n=0 : No flow control.
n=1 : Perform XON/XOFF flow control.
n=2 (default): Perform RS/CS (RTS/CTS)
flow control.
m : DTE by DCE control
m=0: No flow control
m=1: Perform XON/XOFF flow control.
m=2(default) : Perform RS/CS (RTS/CTS)
flow control
AT+IFC=2,2
OK
AT+IFC=1,1
OK
AT+IFC=0,0
OK
Command Overview Parameters/Description Examples of
Commands
107
Appendix/Troubleshooting
AT+WS46=<n>
[?] [=?]
Set the wireless network to be used
by this terminal when dialing.
n=12 : 3GPP Systems
*For AT+WS46？ , the answer is only 25.
AT+WS46=12
OK
AT+WS46?
25
OK
A/ Retry a command just before
performing.
is not needed after entering command. A/
OK
ATA Display NO CARRIER under offline
command mode.
-ATA
NO CARRIER
ATD Send packet. Sending packet：ATD*99***<cid>#
<cid>1∼10： + Display the APN that
configured +CGDCONT
ATD*99#
CONNECT
ATE<n>
[&F]
Set whether to echo back the text
sent from a PC.
n=0 : Not echo back.
n=1(default) : Echo back.
ATE0
OK
ATE1
OK
ATH<n> The line is disconnected. Only n=0 (default) can be specified. ATH
OK
Command Overview Parameters/Description Examples of
Commands
108 Appendix/Troubleshooting
ATI<n> Display the recognition code. n=0 : Display [NTT DOCOMO, INC.]
n=1 : Display the name of this terminal
(Same as +GMM).
n=2 : Display this terminal version (same as
+GMR).
n=3 : Display OK.
n=4 : Display the details of communication
functions of this terminal.
ATI
NTT DOCOMO, INC.
OK
ATI0
NTT DOCOMO, INC.
OK
ATI1
docomo L03F
OK
ATI2
L03F-MDM9200-
VXXX-XXX-XX-
XXXX-DCM-JP
OK
ATI3
OK
ATI4
4
OK
ATS0=<n>
[&F] [?]
Set the RING value while receiving
automatically.
n=0 (default) : Cannot receive automatically.
n=1∼255 : Receive automatically by
specified RING value.
ATS0=0
OK
ATS0?
000
OK
Command Overview Parameters/Description Examples of
Commands
109
Appendix/Troubleshooting
ATS3=<n>
[&F] [?]
Set the return character (CR) to
recognize the end of AT command
text string.
Only n=13 (default) can be specified. ATS3=13
OK
ATS4=<n>
[&F] [?]
Set the line feed (LF) character. It is
positioned next to the return
character (CR) if displaying the
result code in English characters.
Only n=10 (default) can be specified. ATS4=10
OK
ATS5=<n>
[&F] [?]
Set the back space (BS) character
to delete the last character in the
input buffer while AT commands are
entered.
Only n=8 (default) can be specified. ATS5=8
OK
ATS6=<n>
[&F] [?]
Set pause duration (seconds) till
dial.
This command can be set but is not
functional.
ATS6=5
OK
ATS8=<n>
[&F] [?]
Set pause duration (seconds) of
comma dial.
This command can be set but is not
functional.
ATS8=3
OK
ATS8?
003
OK
ATS10=<n>
[&F] [?]
Set delay duration of auto
disconnection (1/10 seconds).
This command can be set but is not
functional.
ATS10=1
OK
ATS10?
001
OK
ATQ<n>
[&F]
Set if display result code. n=0 (default) : Display result code.
n=1 : Not display result code.
ATQ0
OK
ATV<n>
[&F]
Set the display method of the result
code.
n=0 :Display in numeric characters.
n=1(default): Display in text.
ATV1
OK
Command Overview Parameters/Description Examples of
Commands
110 Appendix/Troubleshooting
ATX<n>
[&F]
Set if detect dial tone. n=0 : No busy tone detected, no dial tone
detected, no speed display
n=1 : No busy tone detected, no dial tone
detected, speed display detected
n=2 : No busy tone detected, dial tone
detected, speed display detected
n=3 : Busy tone detected, no dial tone
detected, speed display detected
n=4 (default) : Busy tone detected, dial tone
detected, speed display detected
ATX1
OK
ATZ Reset the settings on this terminal
with the nonvolatile memory
contents. If performed during a
communication, the line is
disconnected.
-ATZ
OK
Command Overview Parameters/Description Examples of
Commands
111
Appendix/Troubleshooting
Supplementary Explanation of AT
Commands
■ Command name：+CGDCONT
•Overview
Set APN when sending packet connection.
•Form
+CGDCONT=[<cid>[,"<PDP type>"[,"<APN>"]]]
•Parameter descriptions
Set the destination (APN) when sending packets. See
the following examples for command operations.
<cid>※1：1 to 10
<PDP type>※2：IP
<APN>※3：Optional
※1 <cid> is the number used to control the destination
(APN) for the packet communication to be registered in
this terminal. 1 to 10 can be registered.
The default value of <cid>=1 is "mopera.net". Set cid
number from 2 to 10.
※2 <PDP type> is a protocol for packet communication.
The pre-installed <PDP type>=IP is set to <cid>=1 as
default.
※3 <APN> is optional string that indicates each destination.
•Command examples
Command to register an APN with the name of abc
(When PDP type is IP, cid is 2)
AT+CGDCONT=2,"IP","abc"
OK
•Operations without a parameter
AT+CGDCONT= : Clear all the settings of <cid>.
However, the setting of <cid>=1 is reset to the value
when purchasing.
AT+CGDCONT?：Display the current settings.
■ Command name: +CGEQMIN=[Parameter]
•Overview
Register the threshold to accept the QoS (Quality of
Service) sent from the network when packet
communication is established.
LTE data communication is not supported.
•Format
+CGEQMIN=[<cid>[,,<Maximum bitrate UL>[,<Maximum
bitrate DL>]]]
•Parameter description
<cid>※1：1 to 10
<Maximum bitrate UL>※2：None (default)
<Maximum bitrate DL>※2：None (default)
※1 <cid> is a number used to manage the access point
(APN) for the packet communication registered in this
terminal.
※2 <Maximum bitrate UL> and <Maximum bitrate
DL>indicate the minimum communication speed [kbps] of
upload and download traffic respectively between this
terminal and the base station. If these are set to None
(default), all speeds are permissible. Be aware that a
packet communication may not be established because
any other speed than this is not permissible.
•Command examples
(1) Command to permit all speeds for both upload and
download (When cid=2)
AT+CGEQMIN=2
OK
(2) Command to permit only 5,760kbps for upload and
7,232kbps for download (When cid=2)
AT+CGEQMIN=2,,5760,7232
OK
(3) Command to permit 5,760kbps for upload and all speeds
for download (When cid=2)
AT+CGEQMIN=2,,5760
OK
112 Appendix/Troubleshooting
(4) Command to permit all speeds for upload and only
7,232kbps for download (When cid=4)
AT+CGEQMIN=4,,,7232
OK
■ Command name: +CGEQREQ=[Parameter]
•Overview
Set the QoS (Quality of Service) requested to the
network when packet communication is dialed.
•Format
+CGEQREQ=[<cid>[,,<Maximum bitrate UL>[,<Maximum
bitrate DL>]]]
•Parameter description
<cid>※1：1 to 10
<Maximum bitrate UL>※2：None (default)
<Maximum bitrate DL>※2：None (default)
※1 <cid> is a number used to manage the access point
(APN) for the packet communication registered in this
terminal.
※2 <Maximum bitrate UL> and <Maximum bitrate
DL>indicate the minimum communication speed [kbps] of
upload and download traffic respectively between this
terminal and the base station. If these are set to None
(default), Qos of network is not required.
•Command example
Command to require 5,760kbps for upload and
7,232kbps for download (When cid=2)
AT+CGEQREQ=2,2,5760,7232
OK
Result Codes
■ List of result codes
Options and related devices
Combining this terminal with optional accessories
supports a wide variety of uses from personal use to
business use. Some merchandise are not available in some
regions.
For details, contact a docomo Shop. For details about the
optional devices, refer to the instruction manual for each
device.
•Back Cover L30
Note
•This command, (+CGDCONT, +CGEQMIN, + CGEQREQ) is
not reset by [&F] and [Z], either.
Numeric
display Text display Description
0 OK Operation performed properly
1 CONNECT Connected to other party
3 NO CARRIER Line disconnected
4 ERROR Unable to accept command
100 RESTRICTION Network restriction display
113
Appendix/Troubleshooting
Troubleshooting
First, check whether software is required to update.
Update software if necessary. (Updating Software⇒P118)
Contact General Inquiries specified by DOCOMO located in
"Repairs" (Japanese only) at the last page of the manual if
the symptom is not improved after confirming the item to
check.
■ This terminal is not recognized
Symptom Check
This terminal is
not recognized
Insert the USB port firmly into this terminal.
Verify the L-03F Communication
Configuration Files (Drivers) for this terminal
functioning properly.→P31, P41
This terminal may not be recognized correctly
when activating the PC with this terminal
being connected, during restarting or after
retrieving from the states of standby
(sleeping)/stopping during packet
communication. Remove this terminal from
the PC and insert again after restarting the
PC.
Delete the driver of this terminal on device
manager when "!" appears in this terminal
device. Only install the driver again.
The UIM will not be able to use if PIN1 unlock
code is wrongly entered 10 times in a row. For
further information, visit docomo Shop.
This terminal is
not recognized
■If CD/DVD playback and written software is
installed into a PC
Depending on the CD/DVD playback or
writing application installed in a PC, this
terminal may not be recognized normally
even if the terminal is connected while the
application software residents※ or is
activated.
Try the following methods in that case.
■To recognize after finishing the running
application
aRemove this terminal from the PC
bFinish CD/DVD playback and the
executants of written application
software
cConnect this terminal to the PC
■To recognize via icon
●For Windows 7
• (Start) Double click icon of
"Computer".
●For Windows Vista
• (Start) Double click icon of
"Computer".
●For Windows XP
•[start] Double click icon of "My
computer".
※Including the case in which its icon stays
on the taskbar.
Symptom Check
114 Appendix/Troubleshooting
■ Communication problems ■ Problems with AT Commands
■ Zero installation fails
Symptom Check
Communications
are not possible
Verify if signals are received in the service
area.
Check if you set the UIM setting to "Unlock
PIN1". →P57
If it is set to "Lock PIN1", launch the L-03F
Connection Manager, then enter PIN1 code.
→P58
Check the setting of this terminal and the
APN registration.
When connecting manually by L-03F is not
available, open the property of dial-up
connection and make sure that only
"docomo L03F Modem Driver" has check
mark in "Connect using".
(If the modem inside PC or other modems
have check marks, packet connection may
be incorrect.)
Even if Auto connection setting is set to
"ON", auto connection may not be available
depending on the PC or network. In that
case, remove this terminal and insert it into
the PC again.
When using Internet by this terminal, make
sure that wired/wireless LAN or other
communication devices are disconnected.
Symptom Check
"ERROR"
appears when
AT command is
entered
Verify if you entered a correct AT command.
Check the properties of the terminal
software to see whether a device other than
this terminal is selected.
"OK" does not
appear after an
AT command is
entered
Check the L-03F Communication
Configuration Files (Drivers) have been
installed and functioned properly.
Verify if the commands start with "AT" or "at".
Symptom Check
New hardware
detection
screen
appears
If the L-03F setup screen does not appear,
and the input of driver is required, cancel it
temporarily. Remove this terminal from the
USB port of PC and insert again.
Do not start zero installation during OS
activation. It may take several minutes
depending on the PC. Make sure to start the
installation after the PC runs normally.
115
Appendix/Troubleshooting
■ Other problems
Symptom Check
The terminal
suddenly
stopped working
Verify that the UIM is properly inserted to
this terminal.→P15
Your PC operating environments may have
changed because a new peripheral or
software was installed. Make a confirmation
with your manufacturer of accessory or
software.
This terminal is
not detected if it
is inserted into a
USB port of PC
after installing
the L-03F
Communication
Configuration
Files (Drivers)
Please confirm the following.
•Whether the PC or OS you are using is in
the latest condition?
(If required, apply revision program of OS
provided from manufacturer.)
•Whether this terminal recognizes normally
when other USB devices are inserted into
the USB port of PC?
•Whether this terminal operates normally
when being inserted into another PC?
•Whether this terminal operates normally
when PC is reset to its default?
※For inquiries related to OS or PC, contact
Microsoft or PC manufactures.
Internet
connection
speed
decreased
significantly
If this terminal is connected to a PC directly,
use the supplied "USB extension cable
(Sample)" to keep away from PC.
Speed may turn slow in unsteady areas such
as LTE/W-CDMA/HSDPA/HSUPA/GPRS
service environment. Move it to another
place and connect again.
116 Appendix/Troubleshooting
Error Messages
Error Messages Description
Out of service area You are out of service area or available network.
Failed to connect. Do you want to try
again?
A network error may occur if you are out of service area or available network area. Make
network setting again.
Failed to reset L-03F. This terminal failed in resetting. Check if this terminal is inserted correctly in PC and if
it is recognized by PC.
Settings cannot be changed while
connected. Please disconnect to change
the settings.
You cannot customize setting during data communication. Set again after closing data
communication.
The confirmed PIN1 code doesn't match
the changed PIN1 code. Please input
again.
Two of new PIN1 code are not identical each other. New PIN1 code you want to change
is not matched to the PIN1 code you entered for verification purpose. Enter correct PIN1
code.
Please check whether the DOCOMO UIM
card is inserted properly.
Make sure to insert UIM into this terminal before inserting to a PC.
L-03F is not recognized Do not remove this terminal from the PC while using. If this terminal cannot be correctly
detected, try to reboot the PC as a remedy.
Failed to input PIN1 code for three times.
Please input PIN unlock code.
An incorrect PIN1 code was improperly entered 3 times in a row. Available functions will
be limited. Enter unblocking PIN code to unlock.
Incorrect PIN1 code entered. Please try
again. (Retry ○/3)
An incorrect PIN1 code has been entered. Enter the correct PIN1 code again.
PIN1 code is 4∼8 characters. Valid PIN1 code is 4- to 8-digit number.
Please lock PIN1 code.
To change the PIN1 code, PIN1 must be locked. Switch PIN1 unblocking to PIN1 blocking.
Incorrect PIN1 unlock code entered.
Please try again. (Retry ○/10)
An incorrect unblocking PIN code was entered. Please enter the correct unblocking PIN
code.
L-03F is locked because the user failed to
input the correct PIN unlocking code 10
times. Please contact DOCOMO service
center.
You are no longer able to use UIM that unblocking PIN code has been improperly entered
10 times in a row. Please contact docomo Shop.
117
Appendix/Troubleshooting
Warranty and After-Sales
Service
Warranty
•A written warranty is provided with every terminal. Make sure
that you receive it. Store the warranty in a safe place after you
read it and verified that it contains the "Shop name/date" you
purchased the product. If the written warranty does not contain
the necessary information, contact the Shop where you
purchased the product. The warranty is valid for a period of one
year from the date of purchase.
•This product and all accessories are subject to change, in part
or whole, for the sake of improvement without prior notice.
After-Sales Service
If Problems Occur
•Before requesting service, read the "Troubleshooting"
section in this manual. If the problem still persists,
contact one of the numbers listed in "Repairs" (Japanese
only) on the back of this manual.
For Inquiries Result or When Repair is Required
•Take this terminal to a service center designated by
DOCOMO. Be sure to check the operating hours of the
service center. You must present the warranty.
Please note that depending on malfunctions, it may take
more than a day to repair.
■ In the warranty period
•This terminal will be repaired at no charge subject to the
conditions of the warranty.
•The warranty must be presented to receive warranty
service. The subscriber will be charged for the repair of
items not covered in the warranty or repairs of defects
resulting from misuse, accident or neglect even during the
warranty period.
•The subscriber is charged even during the warranty period
for the repair of failures caused by the use of devices or
consumable items that are not DOCOMO specified.
■ Repairs may not be possible in the following cases
•When DOCOMO Repairs judges that this terminal is
exposed to water. (Ex: the sticker is reacted to water)
•Repair is not possible when corrosion due exposure to
moisture, condensation or perspiration is detected in a
moisture seal reaction or test, or if any of the internal
boards are damaged or deformed.
※ Since these conditions are outside the scope of the
warranty, any repairs, if at all possible, will be
charged.
■ After expiration of the warranty
All repairs that are requested are charged.
118 Appendix/Troubleshooting
■ Replacement parts
Basically, replacement parts (parts required to maintain
product function) will be kept in stock for at least 4 years
after termination of production. Please note that the
product may not be repaired even during this period,
depending on the malfunctioning parts due to a shortage
of those parts. Depending on the nature of the required
repairs, it may still be possible to repair your terminal
even after this period. Contact "Repairs" (Japanese only)
listed on the back of this manual.
Pay attention
•Do not modify this terminal or its accessories.
- Fire, injury or damage may result.
- If this terminal is modified (part replacement, modification,
painting, etc.), it will be repaired only after the modified parts
have been restored to the condition at the time of purchase.
However, repair may be refused depending on the nature of
modification.
Things like following cases will be regarded as modification of
this terminal.
･ Using sticker to decorate this terminal
･ Exchanging the packing with those other than DOCOMO
product
- Repair of failures or damage caused by modification are
charged even during the warranty period.
•Do not remove any inscription stickers attached to this
terminal. The inscription stickers certify that this terminal
satisfies specific technical standards. If stickers are removed
intentionally or are reattached in such a way that confirmation
of the sticker's contents is impossible, repair or servicing may
be refused because confirmation of whether or not the device
conforms to relevant technical standards cannot be made.
•Information of settings for each function may possibly be
cleared (reset) due to the malfunction, repair or other
treatment of this terminal.
•Take this terminal to the service center when the inner of this
terminal is exposed to water or moisture. However, repairs may
not be available for some conditions depending on this
terminal.
Updating Software
Download the modification file of this terminal from
download site on the Internet and then update the
software. If software update is necessary, you will be
informed at the NTT DOCOMO website with "お知らせ
(Information)".
aConnect to a PC
The following screen appears if the latest software to be
downloaded.
■When Check latest SW setting (→P60) is set to
"OFF"
•Connect this terminal to the PC Click on the title
bar
119
Appendix/Troubleshooting
bClick [Yes]
•Update software following the onscreen instructions from
here. For details, refer to Software Update procedure on
the NTT DOCOMO website.
Main Specifications
■ Operating system
Windows XP Japanese/English version (Service Pack 3)
Windows Vista 32bit/64bit Japanese/English version
(Service Pack 2)
Windows 7 32bit/64bit Japanese/English version
(Service Pack 1)
Mac OS X 10.6.8 32bit/64bit Japanese/English version
Mac OS X 10.7.2 32bit/64bit Japanese/English version
Note
•Do not unplug this terminal with the computer during
software update.
•Software update (downloading and rewriting) may take a
while.
•If software update fails, all operations become unavailable.
In this case, bring this terminal to a DOCOMO service
center.
120 Appendix/Troubleshooting
■ Communication Speed
Up to 75Mbps for receiving data
Up to 25Mbps for sending data
※ Communication speed is theoretical value when sending
and receiving data which does not show the actual ones.
The actual communication speed depends on
communication environment and network congestion.
※ Depending on the bandwidth of Xi area, the theoretical
value is 100/100/75/37.5Mbps for receiving speed
(bandwidth [20/15/10/5MHz]) and 50/37.5/25/
12.5Mbps for sending speed (bandwidth [20/15/10/
5MHz)
※ Refer to NTT DOCOMO website for detailed areas that
support Xi.
※ Receiving data up to 14Mbps, sending data up to
5.7Mbps in FOMA HIGH-SPEED area out of Xi area.
※ Sending and receiving data speed may become up to
384kbps in the FOMA HIGH-SPEED area.
※ Sending and receiving data speed becomes up to
384kbps in FOMA area out of Xi area and FOMA HIGH-
SPEED area.
■ Operating environments
Temperature：5℃ to 35℃
Humidity：45% to 85%
■ Power source
Power voltage
DC5V (Supplied from PC)
Max Current consumption※
Max Current consumption while communicating
LTE: Approx. xxxmA or lower
3G: Approx. xxxmA or lower
GPRS: Approx. xxxmA or lower
Average Current consumption while communicating
LTE: Approx. xxxmA or lower
3G: Approx. xxxmA or lower
GPRS: Approx. xxxmA or lower
Average Current consumption while Standby:
LTE: Approx. xxxmA or lower
3G: Approx. xxxmA or lower
GPRS: Approx. xxxmA or lower
※ Depending on the usage, power consumption fluctuates.
■ Form factor
USB connection type
■ Dimensions
Height: Approx. xxmm
Width: Approx. xxmm
Depth: Approx. xxmm
■Weight
Approx. xxg
----------------------------------------------------------------
■ JATE certification number
AD11-0386001
121
Appendix/Troubleshooting
Export Administration
Regulations
This product and its accessories are under coverage of the
Export Administration Regulations of Japan ("Foreign
Exchange and Foreign Trade Control Laws" and the related
laws and regulations). When exporting this product and its
accessories, take necessary procedures on your
responsibility and expense. For details, contact Ministry of
Economy, Trade and Industry.
Declaration of Conformity
The product "L-03F" is declared to conform with the
essential requirements of European Union Directive 1999/
5/EC Radio and Telecommunications Terminal Equipment
Directive 3.1(a), 3.1(b) and 3.2.
This wireless portable device complies with the EU
requirements for exposure to radio waves.
Your wireless portable device is a radio transceiver and
receiver. It is designed not to exceed the SAR* (Specific
Absorption Rate) limits** for exposure to radiofrequency
(RF) energy by European Union Directives. The Max. SAR*
value is 0.640W/kg (10 g) when it is worn on the body. To
comply with the RF Exposure limits a distance of greater
than 1.5 cm must be maintained from the user's body.
While there may be differences between the SAR* levels of
various wireless portable devices and at various positions,
they all meet*** the EU requirements for RF exposure.
*The exposure standard for wireless portable devices
employs a unit of measurement known as the Specific
Absorption Rate, or SAR.
** The SAR limit recommended by the International
Commission on Non-Ionizing Radiation Protection (ICNIRP)
is 2W/kg averaged over 10g of tissue.
*** Tests for SAR have been conducted using standard
operating positions with the transmitting at its highest
certified power level in all tested frequency bands. Although
the SAR is determined at the highest certified power level,
the actual SAR level of the wireless portable device while
operating can be well below the maximum value. This is
because the wireless portable device is designed to operate
at multiple power levels so as to use only the power required
to reach the network.
In general, the closer you are to a base station antenna, the
lower the power output.
European Union Directives Conformance
Statement
Hereby, LG Electronics, Inc. declares that this
product is in compliance with:
•The essential requirements and other relevant
provisions of Directive 1999/5/EC
•All other relevant EU Directives
The above gives an example of a
typical Product Approval Number.
0168
122 Appendix/Troubleshooting
FCC Regulations
Statement
This equipment has been tested and found to comply with
the limits for a class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for
help.
Change or Modifications that are not expressly approved
by the manufacturer could void the user's authority to
operate the equipment.
Class B Compliance
This device and its accessories comply with part15 of FCC
rules.
Operation is subject to the following two conditions:
•This device & its accessories may not cause harmful
interference.
•This device & its accessories must accept any interference
received, including interference that may cause undesired
operation.
Normal Operation
This device has been tested in normal operating positions
of 0.19inches (0.5cm)
from the user's body.
To comply with FCC RF exposure requirements, a minimum
separation distance of 0.19inches (0.5cm) must be
maintained from the user's body.
Consumer Information on SAR (Specific Absorption
Rate)
THIS DEVICE MEETS THE GOVERNMENT'S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless device is a radio transmitter and receiver. It
is designed and manufactured not to exceed the emission
limits for exposure to radio frequency (RF) energy set by
the Federal Communications Commission of the U.S.
Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for
the general population. The guidelines are based on
standards that were developed by independent scientific
organizations through periodic and thorough evaluation of
scientific studies.
as defined in the Manual at a distance
123
Appendix/Troubleshooting
The standards include a substantial safety margin
designed to assure the safety of all persons, regardless of
age and health. The exposure standard for wireless
devices employs a unit of measurement known as the
Specific Absorption Rate, or SAR.
The SAR limit set by the FCC is 1.6W/kg.
※Tests for SAR are conducted using standard operating
positions specified by the FCC with the device
transmitting at its highest certified power level, the actual
SAR level of the device while operating can be well below
the maximum value. This is because the device is
designed to operate at multiple power levels so as to use
only the power required to reach the network. In general,
the closer you are to a wireless base station antenna, the
lower the power output.
Before a device is available for sale to the public, it must be
tested and certified to the FCC that it does not exceed the
limit established by the government-adopted requirement
for safe exposure. The tests are performed in positions and
locations as required by the FCC for each model.
The FCC has granted an Equipment Authorization for this
device with all reported SAR levels evaluated as in
compliance with the FCC RF emission guidelines. SAR
information on this device is on file with the FCC and can
be found under the Display Gant section of http://
www.fcc.gov/oet/ea/fccid/ after searching on FCC ID
xxxxxxx. Additional information about Specific Absorption
Rates (SAR) can be found on the Cellular
Telecommunications Industry Association (CTIA) website
at http://www.ctia.org/.
Intellectual Property Rights
Copyrights and Rights of Portrait
Without permission of the copyright owner you may not
duplicate, modify, transmit over public communication
lines, etc. any document, image, music, software, or other
content owned by a third party that you have used this
product to download from an Internet website, etc., except
for private uses such as duplication and indexing that are
allowed by copyright law.
Trademarks
•"FOMA" "i-mode" "i-αppli" "mopera U" "WORLD WING" "Xi"and "Xi"
logo are trademarks or registered trademarks of NTT
DOCOMO, INC.
•Microsoft®, Windows®, Windows Vista® are trademarks or
registered trademarks of Microsoft Corporation in United
States and/or other countries.
•In this manual, each OS (Japanese version) is described in the
following short form.
- Windows 7 is short for Microsoft® Windows® 7(Starter, Home
Basic, Home Premium, Professional, Enterprise, Ultimate).
- Windows Vista is short for Windows Vista®(Home Basic,
Home Premium, Business, Enterprise, Ultimate).
- Windows XP is short for Microsoft® Windows® XP
Professional operating system or Microsoft® Windows® XP
Home Edition operating system.
•OS may be written abbreviated such as Windows 7, Vista, XP.
ZNFL03F. Additional information about Specific Absorption
124 Appendix/Troubleshooting
•Apple, Apple logo, Mac, Mac OS, Macintosh are registered
trademark of Apple Inc. of US and other countries.
•Adobe, Adobe Flash Player and Adobe Reader are either
registered trademarks or trademarks of Adobe Systems
Incorporated in the United States and/or other countries.
•Other company names or product names mentioned in this
work are the trademarks or registered trademarks of their
respective owners.
125
Appendix/Troubleshooting
Index
A
Antenna . . . . . . . . . . . . . . . . . . . . . . .14
AT Command List . . . . . . . . . . . . . . .97
AT Commands . . . . . . . . . . . . . . . . . .96
Available Communications. . . . . . . .19
B
Back Cover . . . . . . . . . . . . . . . . . . . . .14
C
CE . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Communication Speed . . . . . . . . . 120
Communication Status Lamp . . . . .14
Configuring Dial-up Network Manually
For Windows . . . . . . . . . . . . . . . . . .73
Configuring Network . . . . . . . . . . . . .92
Connecting this Terminal to a PC. .20
E
Error Messages . . . . . . . . . . . . . . . 116
European Union Directives
Conformance Statement . . . . . 121
Export Administration Regulations . . .
121
F
FCC Regulations . . . . . . . . . . . . . . 122
Flash Player . . . . . . . . . . . . . . . . 35, 46
Form factor . . . . . . . . . . . . . . . . . . . 120
G
GPRS. . . . . . . . . . . . . . . . . . . . . . . . . 51
H
Home screen . . . . . . . . . . . . . . . . . . 51
HSDPA . . . . . . . . . . . . . . . . . . . . . . . 51
HSUPA . . . . . . . . . . . . . . . . . . . . . . . 51
Hyper Terminal . . . . . . . . . . . . . . . . . 71
I
Install
Flash Player on Mac . . . . . . . . . . 46
Flash Player on Windows . . . . . . 35
L-03F Connection Manager on Mac
(including a driver) . . . . . . . . . . 41
L-03F Connection Manager on
Windows (including a driver) . . 31
L
LTE . . . . . . . . . . . . . . . . . . . . . . . . . . 51
L-03F APN Tool
Setting manually (Windows) . . . . 70
L-03F Connection Manager (including
a driver)
Automatic connection setting . . 59
Check latest SW setting . . . . . . . 60
Configuring network . . . . . . . . . . . 92
Confirming after installation .36, 45
Confirming use amount of packet
communication . . . . . . . . . . . . . 55
Language setting . . . . . . . . . . . . . 59
Launching/Exiting (for Mac) . . . . 50
Launching/Exiting (for Windows) 50
Resetting this terminal . . . . . . . . 61
Set security. . . . . . . . . . . . . . . . . . 56
Setting a UIM . . . . . . . . . . . . . . . . 56
Setting Profile . . . . . . . . . . . . . . . . 55
Settings . . . . . . . . . . . . . . . . . . . . . 54
M
Main specifications . . . . . . . . . . . . 119
Mobile Broadband . . . . . . . . . . . . . . 64
Mode Indication Lamp . . . . . . . . . . . 15
N
Names of Parts and Functions . . . 14
Network type . . . . . . . . . . . . . . . . . . 51
O
Operating Environments . . . . 30, 120
Operation system. . . . . . . . . . . . . . 119
Operation tabs . . . . . . . . . . . . . . . . . 51
Overseas Use
126 Appendix/Troubleshooting
Before Using Overseas. . . . . . . . .91
Configuring Network . . . . . . . . . . .92
Setting the Searching Method for
Available Networks. . . . . . . . . . .92
Own phone number . . . . . . . . . . . . . .52
P
Packet Communication
Confirming the packet
communication volume . . . . . . .55
Disconnecting to packet
communication . . . . . . . . . . . . . .54
Requirements for packet
communication . . . . . . . . . . . . . .20
Start packet communication . . . .52
Power source. . . . . . . . . . . . . . . . . 120
R
Resetting this terminal . . . . . . . . . .61
Result Codes . . . . . . . . . . . . . . . . . 112
S
Security Code . . . . . . . . . . . . . . . . . .17
Set security . . . . . . . . . . . . . . . . . . . .56
Setting
APN settings . . . . . . . . . . . . . 55, 70
Configuring Dial-up Network
Manually. . . . . . . . . . . . . . . . . . . .73
Configuring Network . . . . . . . . . . .92
Configuring Network Manually . . .70
Environment Configuration . . . . . .54
Security settings . . . . . . . . . . . . . .56
Setting a UIM . . . . . . . . . . . . . . . . .56
Setting APN . . . . . . . . . . . . . . . . . . . 55
Setting screen . . . . . . . . . . . . . . . . . 54
Setting up. . . . . . . . . . . . . . . . . . . . . 28
T
Trademarks. . . . . . . . . . . . . . . . . . . 123
Troubleshooting. . . . . . . . . . . . . . . 113
U
UIM
Changing PIN1 Code . . . . . . . . . . 57
Entering PIN1 Code . . . . . . . . . . . 58
Inserting/Removing . . . . . . . . . . . 15
Locking PIN1 . . . . . . . . . . . . . . . . 56
Unblocking PIN code setting . . . 58
Unlocking PIN1. . . . . . . . . . . . . . . 57
Uninstall
L-03F Connection Manager on Mac
(including a driver) . . . . . . . . . . 47
L-03F Connection Manager on
Windows (including a driver) . . 39
Updating Software . . . . . . . . . . . . 118
USB Connector . . . . . . . . . . . . . . . . 14
V
Version information . . . . . . . . . . . . . 51
W
Warranty and After-Sales Service 117
W-CDMA (3G). . . . . . . . . . . . . . . . . . 51
WORLD WING. . . . . . . . . . . . . . . . . . 90
Z
Zero installation . . . . . . . . . . . . . . . . 28
マナーもいっしょに携帯しましょう
Don't forget your terminal… or your manners!
When using this terminal, be considerate and do not disturb people around you.
◎The following cases, be certain to turn off your PC in which this terminal is inserted.
■ Where use is prohibited
There are some places which this terminal can not be used. Be sure to turn off your PC in which this terminal is inserted.
※ Persons with electronic medical equipment are in places other than the actual wards. Make sure you have the power
switched off even if you are in a lobby or waiting room.
■ While driving
Using this terminal interferes with safe driving and may be dangerous.
■ When in crowded places such as packed trains, where you could be near a person with an implanted cardiac
pacemaker or implanted defibrillator
The implanted cardiac pacemaker or implanted defibrillator operation can be adversely affected.
■ When in theaters, movie theaters, museums, and similar venues
If you use this terminal where you are supposed to be quiet, you may disturb those around you.
You can register a confirmation/change of contracts, or request information material at the DOCOMO online.
From a PC My docomo（http://www.mydocomo.com/）⇒ 各種お申込・お手続き (Subscriptions/Procedures)(Japanese only)
※"docomo ID/Password" is required if you access the site from a PC.
※If you do not have or remember the "docomo ID/Password", contact the "docomo Information Center" listed on the back of this manual.
※Some contracts may not be available for using.
※ You may not be able to use online service due to system maintenance, etc.
We collect old phones, etc. regardless of brands and manufacturers. Bring them to your nearest docomo Shop.
※ Items to be collected: mobile phones, PHS, battery packs, chargers, desktop holders (regardless of brands
and manufacturers)
'14.x (1.0 Edition)
MFLxxxxxxxx
Don't forget your mobile phone … or your manners!
○ When using your mobile phone in a public place, don't forget to show common courtesy and consideration for others around you.
■From DOCOMO mobile phones
(In Japanese only)
* Unavailable from land-line phones, etc.
General Inquiries
<docomo Information Center>
Loss or theft of this terminal or payment of
cumulative cost overseas
<docomo Information Center> (available 24 hours a day)
From land-line phones
<Universal number>
-81-3-6832-6600*(toll free)
International call access code for
the country you stay
* You are charged a call fee to Japan when calling from a land-line phone, etc.
-8000120-0151*
*
You might be charged a domestic call fee according to the call rate for the country you stay.
Repairs
Failures encountered overseas
<Network Support and Operation Center> (available 24 hours a day)
From land-line phones
<Universal number>
-81-3-6718-1414*(toll free)
International call access code for
the country you stay
* You are charged a call fee to Japan when calling from a land-line phone, etc.
From DOCOMO mobile phones
-8005931-8600*
*
You might be charged a domestic call fee according to the call rate for the country you stay.
※For international call access codes for major countries and universal number international
prefix, refer to DOCOMO International Services website.
* Unavailable from land-line phones, etc.
■From DOCOMO mobile phones
(In Japanese only)
■From land-line phones
(In Japanese only)
* Unavailable from part of IP phones.
* Service available in: English, Portuguese, Chinese, Spanish, Korean.
* Unavailable from part of IP phones.
From DOCOMO mobile phones
NTT DOCOMO website http://www.nttdocomo.co.jp/english/
※For international call access codes for major countries and universal number international
prefix, refer to DOCOMO International Services website.
●If you lose your terminal or have it stolen, immediately take the steps necessary for suspending the use of this terminal.
●If your terminal is damaged, bring your terminal to a repair counter specified by DOCOMO after returning to Japan.
(Business hours: 24 hours. (open all year round))
■From land-line phones
(In Japanese only)
* Unavailable from part of IP phones.
(toll free)
0120-800-000
0120-800-000 (toll free)
0120-005-250 (toll free)
(Business hours: 9:00 a.m. to 8:00 p.m.)
(Business hours: 9:00 a.m. to 8:00 p.m. (open all year round))
’14.x
L-03F
