APPENDIX F
FCC ID : BEJL1530TMM
USER’S MANUAL
Make sure to read the Safety Precautions before using the product.
Keep the User's Guide(CD) in an accessible place for furture reference.
See the label attached on the back cover and quote this information to your
dealer when you require service.
L1530TM
User’s Guide
1
FCC Compliance Statement
This equipment has been tested and found to comply within
the limits of a Class B digital device pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses, and can radiate radio
frequency energy and if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio
or television reception (which can be determined by turning
the equipment on and off), the user is encouraged to try to
correct the interference by using one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the
receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV
technician for help.
Caution: Changes or modifications not expressly approved
by the party responsible for compliance could void the
user's (or your) authority to operate the equipment. Only
peripherals (digital input/output devices, terminals, printers,
etc.) certified to comply with the Class B limits may be
attached to this monitor. Operation with non-certified
peripherals is likely to result in interference to radio and TV
reception.
Only shielded signal cables may be used with this System.
Canadian DOC Notice
This Class B digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les
exigences du Règlement sur le matériel brouilleur du
Canada.
CE Conformity Notice (for Europe)
Products with the “CE” Marking comply with the EMC
Directive(89/336/EEC) and LOW VOLTAGE Directive
(73/23/EEC) issued by the Commission of the European
Community.
Compiance with these directives implies conformity to the
following European Norms :
• EN 55022:1998 ; Radio Frequency Interference
• EN 55024:1998 ; Electromagnetic Immunity
• EN 61000-3-2 ; Power Line Harmonics
• EN 61000-3-3 ; Voltage Fluctuations
• EN 60950 ; Product Safety
Low Radiation Compliance (MPR II)
This monitor meets one of the strictest guidelines available
today for low radiation emissions, offering the user extra
shielding and an antistatic screen coating. These
guidelines, set forth by a government agency in Sweden,
limit the amount of emission allowed in the Extremely Low
Frequency (ELF) and Very Low Frequency (VLF)
electromagnetic range.
TCO95
Congratulations!
You have just purchased a TCO’95 approved and labelled
product! Your choice has provided you with a product
developed for professional use. Your purchase has also
contributed to reducing the burden on the environment and
to the further development of environmentally-adapted
electronic products.
Why do we have environmentally labelled computers?
In many countries, environmental labelling has become an
established method for encouraging the adaptation of
goods and services to the environment. The main problem
as far as computers and other electronic equipment are
concerned is that environmentally harmful substances are
used both in the products and during their manufacture.
Since it has not been possible so far for the majority of
electronic equipment to be recycled in a satisfactory way,
most of these potentially damaging substances sooner or
later enter Nature.
There are also other characteristics of a computer, such as
energy consumption levels, that are important from both the
working and natural environment viewpoints. Since all
types of conventional electricity generation have a negative
effect on the environment (acidic- and climatic-influencing
emissions, radioactive waste, etc.), it is vital to conserve
energy. Electronic equipment in offices consumes as
enormous amount of energy, since it is often routinely left
running continuously.
What does the environmenal labelling involve?
This product meets the requirements for the TCO’95
Regulatory Information
NOTICE
The regulations are applied only to the products with the
ID LABEL indicating specific requirements.
NOTICE
The regulations are applied only to the products with the
ID LABEL indicating specific requirements.
NOTICE
The regulations are applied only to the products with the
ID LABEL indicating specific requirements.
2
Regulatory Information cont.
NUTEK
Naturskydds
föreningen
Närings- och teknikutvecklingsverket
SEMKO
scheme, which provides for international environmental
labelling of personal computers. The labelling scheme was
developed as a joint effort by the TCO (The Swedish
Confederation of Professional Employees),
Naturckyddsföreningen (The Swedish Society for Nature
Conservation), and NUTEK (The National Board for
Industrial and Technical Development in Sweden), and
SEMKO AB (an international certification agency).
The requirements cover a wide range of issues:
environment, ergonomics, usability, emission of electrical
and magnetic fields, energy consumption and electrical and
fire safety.
The environmental demands concern, among other things,
restriction on the presence and use of heavy metals,
brominated and chlorinated flame retardants, CFCs
(freons), and chlorinated solvents. The product must be
prepared for recycling, and the manufacturer is obliged to
have an environmental plan, which must be adhered to in
each country where the company implements its
operational policy.
The energy requirements include a demand that the
computer and/or display, after a certain period of inactivity,
shall reduce its power consumption to a lower level, in one
or more stages. The length of time to reactivate the
computer shall be reasonable for the user.
Labelled products must meet strict environmental
demands, for example, in respect of the reduction of electric
and magnetic fields, along with physical and visual
ergonomics and good usability.
The following is a brief summary of the environmental
requirements met by this product. The complete
environmental criteria document may be ordered from:
TCO Development Unit
Linnegatan 14, S-11494 Stockholm, Sweden
FAX +46-8 782 92 07
E-mail (Internet): development@tco.se
Current information regarding TCO’95 approved and
labelled products may also be obtained on the Internet
using the address: http://www.tco-info.com/
TCO’95 is a co-operative project between:
Environmental requirements
Brominated flame retardants are present in printed circuit
boards, cabling, casings, and housings, and are added to
delay the spread of fire. Up to 30% of the plastic in a
computer casing can consist of flame-retardant substances.
These are related to another group of environmental toxins,
PCBs, and are suspected of giving rise to similar harm,
including reproductive damage in fish-eating birds and
mammals. Flame retardants have been found in human
blood, and researchers fear that they can disturb fetus
development.
Bio-accumulative1TCO’95 demands require that plastic
components weighing more than 25 grams must not
contain flame retardants with organically bound chlorine or
bromine.
Lead can be found in picture tubes, display screens, solder,
and capacitors. Lead damages the nervous system and in
higher doses causes lead poisoning. The relevant bio-
accumulative TCO’95 requirement permits the inclusion of
lead, as no replacement has yet been developed.
Cadmium is present in rechargeable batteries and in the
color-generating layers of certain computer displays.
Cadmium damages the nervous system and is toxic in high
doses. The relevant bio-accumulative TCO’95 requirement
states that batteries may not contain more than 25 ppm
(parts per million) of cadmium. The color-generating layers
of display screens must not contain any cadmium.
Mercury is sometimes found in batteries, relays and
switches. Mercury damages the nervous system and is
toxic in high doses. The relevant bio-accumulative TCO’95
requirement states that batteries may not contain more than
25 ppm of mercury and that no mercury is present in any of
the electrical or electronic components concerned with the
display unit.
CFCs (freons) are sometimes used for washing printed
circuit boards and in the manufacture of expanded foam for
packaging. CFCs break down ozone and thereby damage
the ozone layer in the atmosphere, causing increased
reception on Earth of ultra-violet light with consequent
increased risks of skin cancer (malignant melanoma). The
relevant TCO’95 requirement: Neither CFCs nor HCFCs
may be used during the manufacture of the product or its
packaging.
1Bio-accumulative means that the substance accumulates
within living organisms.
Shipping Package
The packaging material can be recycled, or you can save it
to return the monitor to a service center for repair or
disposal.
CFC Compounds in Distribution Packaging
Cushioning material used for shipping finished monitors are
not manufactured with nor do they contain any CFC
compounds.
Design for Disassembly/Recycling
These monitors have been designed for easy end-of-life
disassembly and recycling. Fasteners are generally of the
same type for efficient disassembly. Components made of
different materials can be easily separated and plastics
have been identified using intermational symbols to aid in
recycling.
Monitor Disposal
WARNING
If you need to dispose of a monitor, ask a qualified service
representative for the proper procedure. Improper disposal
could result in personal injury from implosion.
3
TCO99
Congratulations!
You have just purchased a TCO’99 approved and
labelled product! Your choice has provided you with
a product developed for professional use. Your
purchase has also contributed to reducing the
burden on the environment and also to the further
development of environmentally adapted electronics
products.
Why do we have environmentally labelled
computers?
In many countries, environmental labelling has
become an established method for encouraging the
adaptation of goods and services to the environment.
The main problem, as far as computers and other
electronics equipment are concerned, is that
environmentally harmful substances are used both in
the products and during their manufacture. Since it is
not so far possible to satisfactorily recycle the
majority of electronics equipment, most of these
potentially damaging substances sooner or later
enter nature.
There are also other characteristics of a computer,
such as energy consumption levels, that are
important from the viewpoints of both the work
(internal) and natural (external) environments. Since
all methods of electricity generation have a negative
effect on the environment (e.g. acidic and climate-
influencing emissions, radioactive waste), it is vital to
save energy. Electronics equipment in offices is
often left running continuously and thereby
consumes a lot of energy.
What does labelling involve?
This product meets the requirements for the TCO’99
scheme which provides for international and
environmental labelling of personal computers. The
labelling scheme was developed as a joint effort by
the TCO (The Swedish Confederation of
Professional Employees), Svenska
Naturskyddsforeningen (The Swedish Society for
Nature Conservation) and Statens Energimyndighet
(The Swedish National Energy Administration).
Approval requirements cover a wide range of issues:
environment, ergonomics, usability, emission of
electric and magnetic fields, energy consumption
and electrical and fire safety.
The environmental demands impose restrictions on
the presence and use of heavy metals, brominated
and chlorinated flame retardants, CFCs (freons) and
chlorinated solvents, among other things. The
product must be prepared for recycling and the
manufacturer is obliged to have an environmental
policy which must be adhered to in each country
where the company implements its operational
policy.
The energy requirements include a demand that the
computer and/or display, after a certain period of
inactivity, shall reduce its power consumption to a
lower level in one or more stages. The length of time
to reactivate the computer shall be reasonable for
the user.
Labelled products must meet strict environmental
demands, for example, in respect of the reduction of
electric and magnetic fields, physical and visual
ergonomics and good usability.
Below you will find a brief summary of the
environmental requirements met by this product. The
complete environmental criteria document may be
ordered from:
TCO Development
SE-114 94 Stockholm, Sweden
Fax: +46 8 782 92 07
Email (Internet): development@tco.se
Current information regarding TCO’99 approved and
labelled products may also be obtained via the Internet,
using the address: http://www.tco-info.com/
Environmental requirements
Flame retardants
Flame retardants are present in printed circuit
boards, cables, wires, casings and housings. Their
purpose is to prevent, or at least to delay the spread
of fire. Up to 30% of the plastic in a computer casing
can consist of flame retardant substances. Most
flame retardants contain bromine or chloride, and
those flame retardants are chemically related to
another group of environmental toxins, PCBs. Both
the flame retardants containing bromine or chloride
and the PCBs are suspected of giving rise to severe
health effects, including reproductive damage in
fish-eating birds and mammals, due to the bio-
accumulative* processes. Flame retardants have
been found in human blood and researchers fear
that disturbances in foetus development may occur.
The relevant TCO’99 demand requires that plastic
components weighing more than 25 grams must not
contain flame retardants with organically bound
bromine or chlorine. Flame retardants are allowed in
the printed circuit boards since no substitutes are
available.
Cadmium**
Cadmium is present in rechargeable batteries and in
the colour-generating layers of certain computer
displays. Cadmium damages the nervous system
and is toxic in high doses. The relevant TCO’99
requirement states that batteries, the colour-
generating layers of display screens and the
electrical or electronics components must not contain
any cadmium.
Regulatory Information cont.
4
Regulatory Information cont.
Mercury**
Mercury is sometimes found in batteries, relays and
switches. It damages the nervous system and is
toxic in high doses. The relevant TCO’99
requirement states that batteries may not contain
any mercury. It also demands that mercury is not
present in any of the electrical or electronics
components associated with the labelled unit.
CFCs (freons)
The relevant TCO’99 requirement states that neither
CFCs nor HCFCs may be used during the
manufacture and assembly of the product. CFCs
(freons) are sometimes used for washing printed
circuit boards. CFCs break down ozone and thereby
damage the ozone layer in the stratosphere, causing
increased reception on earth of ultraviolet light with
e.g. increased risks of skin cancer (malignant
melanoma) as a consequence.
Lead**
Lead can be found in picture tubes, display screens,
solders and capacitors. Lead damages the nervous
system and in higher doses, causes lead poisoning.
The relevant TCO’99 requirement permits the
inclusion of lead since no replacement has yet been
developed.
* Bio-accumulative is defined as substances which
accumulate within living organisms
** Lead, Cadmium and Mercury are heavy metals which are
Bio-accumulative.
EPA (U.S.A only)
ENERGYSATR is a set of power-saving guidelines
issued by the U.S. Environmental Protection
Agency(EPA).
NOM MARK (Mexico only)
GOST MARK
EPA POLLUTION PREVENTER
As an ENERGY STAR Partner LG
Electronics U.S.A.,Inc. has
determined that this product meets the
ENERGY STAR guidelines for
energy efficiency.
BZ03
Internet Address:http://www.lg.ru
»ÌÙÓχˆËÓÌ̇ˇ ÒÎÛÊ·‡ LG
Electronics (095)742-77-77
i
Safety Precautions
K1
Accessories K4
Major Monitor Features K5
How to Use a Stand K6
Connecting to a PC K8
Using a Tablet Monitor K10
Installing USB Tablet Manager (tablet running driver) K10
Using a Pen K12
Tablet Application Software K13
Screen Selection and Adjustment K15
Adjustment on the OSD (On Screen Display) Screen K17
OSD(On Screen Display) Screen Adjustment
K19
Adjusting Screen Picture/Color/Position K20
Track/Factury Reset/Setup K21
Lightview K22
Troubleshooting K23
Product Specifications K26
Installation
and
Connection
Input
Selection
and Tracking
Miscellaneous
Table of Contents
A1
Please read these safety precautions carefully before using the monitor.
Precautions in installing the Monitor
If you ignore the caution message, you may be slightly injured or the product may be damaged
If you ignore the warning message, you may be seriously injured or there is a possibility of
accident or death.
Keep away from heat sources like electrical heaters.
- Electrical shock, fire, malfunction or deformation may occur.
Keep the packing anti-moisture material or vinyl packing out of the reach of children.
- Anti-moisture material is harmful if swallowed. If swallowed by mistake, force the patient to vomit and visit the
nearest hospital. Additionally, vinyl packing can cause suffocation. Keep it out of the reach of children.
Do not put heavy objects on the monitor or sit upon it.
- If the monitor collapses or is dropped, you may be injured. Children must pay particular attention.
Do not leave the power or signal cable unattended on the pathway.
- The passerby can falter, which can cause electrical shock, fire, product breakdown or injury.
Install the monitor in a neat and dry place.
- Dust or moisture can cause electrical shock, fire or product damage.
If you can smell smoke or other odors or hear a strange sound unplug the power cord and contact the
service center.
- If you continue to use without taking proper measures, electrical shock or fire can occur.
If you dropped the monitor or the case is broken, turn off the monitor and unplug the power cord.
- If you continue to use without taking proper measures, electrical shock or fire can occur. Contact the service
center.
Do not drop metallic objects such as coins, hair pins, chopsticks or wire into the monitor, or inflammable
objects such as paper and matches. Children must pay particular attention.
- Electrical shock, fire or injury can occur. If a foreign object is dropped into the monitor, unplug the power cord and
contact the service center.
Make sure the monitor ventilation hole is not blocked. Install the monitor in a suitably wide place (more
than 10cm from the wall)
- If you install the monitor too close to the wall, it may be deformed or fire can break out due to internal heat.
Do not block the ventilation hole of the monitor by a tablecloth or curtain.
- The monitor can be deformed or fire can break out due to overheating inside the monitor.
Install the monitor on a flat and stable place that has no risk of dropping the monitor.
- If the monitor is dropped, you may be injured or the monitor may be broken.
Install the monitor where no EMI occurs.
Keep the monitor away from direct sunlight.
- The monitor can be damaged.
Safety Precautions
Warning
Warning
Caution
Caution
A2A2
Electrical Power Related Precautions
Make sure to connect the power cable to the grounded current.
- You may be electrocuted or injured.
Use the rated voltage only.
- The monitor can be damaged, or you may be electrocuted.
During a thunder or lightning storm, unplug the power cable or signal cable.
- You may be electrocuted or a fire can break out.
Do not connect several extension cords, electrical appliances or electrical heaters to a single outlet. Use a
power bar with a grounding terminal designed for exclusive use with the computer.
- A fire can break out due to overheating.
Do not touch the power plug with wet hands. Additionally, it the cord pin is wet or covered with dust, dry
the power plug completely or wipe dust off.
- You may be electrocuted due to excess moisture.
If you don’t intend to use the monitor for a long time, unplug the power cable from the monitor.
- Covering dust can cause a fire, or insulation deterioration can cause electric leakage, electric shock or fire.
Fix the power cable completely.
- If the power cable is not fixed completely, a fire can break out.
Hold the plug when pulling out the power cable. Do not bend the power cord with excessive force or put
heavy objects on the power cord.
- The power line can be damaged, which may cause electric shock or fire.
Do not insert a conductor (like a metal chopstick) into one end of the power cable while the other end is
connected to the input terminal on the wall. Additionally, do not touch the power cable right after
plugging into the wall input terminal.
- You may be electrocuted.
Do not unplug the power cord while the monitor is in use.
- Electrical shock can damage the monitor.
Warning
Caution
Precautions in Moving the Monitor
Warning
Make sure to turn off the monitor.
- You may be electrocuted or the monitor can be damaged.
Make sure to remove all cables before moving the monitor.
- You may be electrocuted or the monitor can be damaged.
A3
Safety Precautions
Caution
Precautions in Using the Monitor
Warning
Do not put or store inflammable substances near the monitor.
- There is a danger of explosion or fire due careless handling of the inflammable substances.
When cleaning the brown tube surface, unplug the power cord and scrub with soft cloth to prevent
scratching. Do not clean with a wet cloth.
- The water can sink into the monitor, which can cause electric shock or serious malfunction.
Take a rest from time to time to protect your vision.
Keep the monitor clean at all times.
Take a comfortable and natural position when working with a monitor to relax the muscles.
Take a regular break when working with a monitor for a long time.
Do not press strongly upon the panel with a hand or sharp object such as nail, pencil or pen, or make a
scratch on it.
Keep the proper distance from the monitor.
- Your vision may be impaired if you look at the monitor too closely.
Set the appropriate resolution and clock by referring to the User’s Manual.
- Your vision can be impaired.
Use authorized detergent only when cleaning the monitor. (Do not use benzene, thinner or alcohol.)
- Monitor can be deformed.
Caution
Do not shock the monitor when moving it.
- You may be electrocuted or the monitor can be damaged
Do not dispose the product-packing box. Use it when you move.
Make the panel face forward and hold it with both hands to move.
- If you drop the monitor, the damaged monitor can cause electric shock or fire. Contact with the service center for
repair.
Do not disassemble, repair or modify the monitor at your own discretion.
- Fire or electric shock accident can occur.
- Contact the service center for check, calibration or repair.
Do not spray water on the monitor or scrub with an inflammable substance (thinner or benzene). Fire or
electric shock accident can occur
Keep the monitor away from water.
- Fire or electric shock accident can occur.
A4A4
Accessories
Pen/Pen Content (2 ea.)/
Battery (1 ea.)
Pen Holder
User’s Manual
CD/Cards/Software CD
Power Cord/Adapter
Monitor
Please check all accessories are included in the monitor.
* The actual monitor and accessories may look differently than shown in this
manual.
15-pin D-Sub Signal
Cable
USB Cable
DVI-D Signal Cable
A5
Tablet Function
The monitor’s tablet function enables you to write down a letter or draw a picture on the
screen, using the electronic pen writing recognition software with a touch screen.
Handwriting can also be saved as an image file, which allows intuitive use of the
computer.
Extending the handwriting recognition function, you can directly add a letter or a picture
on the various document types including MS Word or PDF. Therefore, you can
communicate with others while maintaining the current document format.
Stand Angle Adjustment Function
A stand can be conveniently separated or adjusted to various angles according to your
needs. Refer to the next page for details of the stand adjustment method.file, which
allows intuitive use of the computer.
Major Monitor Features
A6
Basic connection – using a stand
How to Use a Stand
You can adjust a stand angle by taking the following steps. Set your preferences. Make sure
to hold the monitor panel with both hands when adjusting the stand angle.
Lift up the monitor panel to face upwards.
* Maximum tilt angle: 20˚
Pull out and hold down the monitor
Hold down the monitor until it reaches to a
stand and the bottom.
* Maximum tilt angle: 113°
If necessary, you can adjust the monitor
panel only while folding the monitor.
Cautions
Do not force the monitor panel up with excessive force.
It may do damage to the monitor.
XX
113˚
1
2
20˚
1
A7
How to Use a Stand
You can separate a stand according to your own requirements.
To separate a stand
1. Make the front side face downward and lay the monitor on a
cushion or soft cloth.
2. Press down the ( ) button at the rear of the monitor until
you can hear a click and then, pull down the stand down to
separate it.
1. Make the front side face downward and lay the monitor on a
cushion or soft cloth.
2. Hold down the stand with both hands and fix the lower stand hooks
into the lower monitor holes. Then, push the stand upward. You will
hear a click when it is in place.
To attach a stand
Rear Side of the
Monitor
Stand Hook
2
A8
A8
Connect the signal input cable first and then, power cord and USB cable .
First, open the back door at the rear side of the
monitor. Make sure that the computer monitor
and peripheral power are off. Then, connect the
monitor as described below.
Back Door
When connecting with a D-Sub signal input cable/For IBM.
When connecting with a D-Sub signal input cable/For Macintosh.
When connecting with a DVI signal input cable.
Basic connection – connecting a signal input cable/power cord
A
B
C
Macintosh adapter(Adapter)
The adapter available in the market may not be compatible with this monitor (if the signaling
system is different). Please use the standard Macintosh adapter or the one provided by LG.
* When
connecting to
a wall consent
* When connecting to a PC
AC adapter
PC
MAC
PC
Power cord
USB
DVI-D D-SUB
1
2
3
A
B
C
Connecting to a PC
1
2
3
2
1
A9
Connecting to a PC
Press the Power button on the front side of the monitor to turn it on.
When the power is on, “Self Image Setting Function” function will start
automatically. (Supported for the analog signal only.)
Close the back door when the connection is complete
Please refer to the following figure to tie up the cables.
Once the cable is connected up as shown in the figure, it will be arranged properly,
which facilitates stand angle adjustment.
Connect the cables as described below !
PROCESSING SELF
IMAGE SETTING
What is the “
Self Image Setting Function
”function?
This function provides the optimal screen state for the user. When you connect the monitor for
the first time, automatic screen adjustment will begin for each type of signal. If you want to
adjust the screen while it is in use or execute this function manually, press the AUTO button at
the front side of the monitor.
Alternatively, execute the “Preset Mode” menu in the OSD menu. However, note that all other
menus except the language menu will be initialized at the same time if you execute the “Preset
Mode” menu.
To connect to two PCs
Connect the signal cables (DVI and D-Sub) to each computer respectively.
You can select the computer to use using the SOURCE button on the front of the monitor.
Directly connect to the multi tab integrated with a conductor, or an earthed wall power outlet.
You cannot use tablet drive and application software on Macintosh.
3
4
Note
A10
Using a Tablet Monitor
First, see if the signal input cable, power cord and USB cable are connected properly.
Then, install the driver as described below.
The main window will be automatically displayed when you insert the software CD into
your CD-ROM driver, which is included in the User’s Manual. Install the “USB Tablet
Manager” driver first and set your preferred options.
You should install the tablet running driver before using the tablet function.
Installing USB Tablet Manager (tablet running driver)
Exit
1
2
USB Tablet Manager
About
- Click the USB Tablet Manager icon and follow the driver installation instructions. Then, restart
your computer. When installation is completed, the USB Tablet icon( ) will appear on the
Windows Task Bar. Click the icon. When you install the tablet monitor for the first time, the pen
touch position may be different from that of the cursor. To adjust the touching position, click the
Calibration button and take the following steps.
Click it again with a pen nib.Click the intersection point of a
cross with a pen nib.
Click
A11
Buttons
(1) Side button
: You can set the function of the pen side button. By
default, the upper side of the side button (Side
Button 2) triggers a double click event, whereas
the lower side (Side Button 1) triggers a right
mouse click event.
(2) Pen offset value
: The tablet monitor detects the power (pressure)
when you touch the screen with a pen. If the
pressure sensitivity is not appropriate due to pen
replacement or computer restart-up, calibrate the
pen offset value appropriately.
- Auto Setting: If you click on this check box, the pen offset value will be automatically
adjusted.
- Adjust: You can adjust pen pressure (sensitivity) manually.
When you un-check the Auto Setting check box and click the Adjust button, the
following message will be displayed. Touch the screen with a pen. Then, pressure
(sensitivity) sensed by the screen will be set. Once touching is detected, the “Adjusting,
please wait” message will be changed to the “OK” message.
Press the button to complete the value setting.
(3) Click Pressure
: You can set “click pressure” from 0% to 30%. You can easily select pressure sensitivity
among pre-set values in the USB tablet drive. Weaker pressure will be applied as the
value decreases.
(3) Test
: You can test the settings. Click the Test button to pop up the window where you can
test pen pressure (sensitivity)
(4) Default
: Click this button to return to the default setting values.
Using a Tablet Monitor
A12
Name and Function of the Parts
Using a Pen
Using a Pen
[When Using a Pen][Inserting a Battery]
[Using a Pen]
ON/OFF Button
Side Button (Upper)
Side Button (Lower)
Pen Content
[When Keeping a Pen]
Pen Cab
Pen Holder
Open the pen cab and insert the provided battery into it. Hold the pen as if you’re holding a
normal pen or pencil. Press the side button using your thumb or index finger.
1. ON/OFF button.
2. Side Button: You can set the right/left mouse button or double click function. Refer to
“How to Use USB Tablet Manager” (Page K12) on the details of function setting.
3. Pen Content: When the pen content is worn out, replace it with new one, which is included
in the product.
1. Pointing: The screen point moves when you move a pen nib on the tablet screen, not
touching it but moving just over it.
2. Click: Clicking the screen with a pen has the same effect as that of a mouse.
3. Double Click: Rapidly click the same screen position with a pen twice to imitate a mouse
double click. Or press the upper side button.
4. Drag: Drag the pen while holding the pen on the screen.
Replacing a Pen Content
1. Taking out the pen content: Hold the pen nib and extract it using a pincette or tweezers
(optional).
2. Inserting new pen content: Push the replacement in softly until it is blocked.
To use the pen side button as a right mouse button, click the side button while not touching
the pen on the screen.
Note
A13
Using a Tablet Monitor
Tablet Application Software
Art Dabbler
Art Dabbler from Corel, the specialized graphic tool vendor, allows you
to present the graphics with rich texture selection and modification as
well as various types of pens and colors. Its text input function enables
you to enter the description on the picture, if necessary.
The presented graphic can be saved with various formats. You can also
create a simple animation using Art Dabbler.
[Example of Using Art Dabbler]
[Example of Using Free Notes]
[Example of Using Office Ink]
Install the provided software to use a tablet monitor more usefully and in
various ways.
Insert the software CD-ROM included in this manual into the PC DC-ROM drive.
Then, the main window will be automatically populated. Click the icon of the software
to install and follow the instructions displayed on the screen.
1
Free Notes
Free Notes is an exclusive document handling program that enables
you to import the picture like a general word processor and modify a
picture or a handwritten document, using various modes displayed at
the bottom of the window. The composed document or picture can be
saved with the file extension of “*.fns" or “*.jpg”. The file saved with the
“*.fns" extension can be opened and modified by “FreeNotes” program
installed in other PC.
You can send a composed picture or a text as an e-mail attachment or
print out.
Office Ink
Office Ink is the bundle software include in Free Notes. Unlike Free
Notes, you can input a picture or handwrite letters on the background
screen freely using the pen with various pen touch techniques and
colors. However, Office Ink is designed for instant pen touch and the
file saving function is provided like Free Notes.
However, you can use this program usefully to highlight a lecturing
item or add a comment, instead of a pen.
2
1
2
3
4
A14
[Example of Using Power Presenter RE]
Power Presenter RE
Power Presenter RE is a program designed to be used with PowerPoint
presentations. It enables you to highlight the section to emphasize, or provide
supplementary description using a whiteboard or blackboard. The presented
picture or text can be saved as “*.jpg”, or sent to other person as an e-mail
attachment. The recording function can be used conveniently for repetitive
training or presentation. Since Power Presenter RE is solely designed for
presentation, instead of a picture or other purposes, only the limited number of
colors is provided.
You can use Power Presenter RE with MS PowerPoint or other application
programs.
When the application program is successfully installed, the AP Manager icon ( )
will appear on the Task Bar. Click the icon to pop up the AP Manager window. When
the program is running, the icon can be used as a shortcut key. Click once to start the
program.
3
Acrobat Reader
User’s manuals of the application programs are provided as a PDF file. Please install Acrobat Reader to
retrieve the user’s manual.
You can retrieve the user’s manual by selecting Windows Start -> Programs.
4
Art Dabbler Free Notes Office Ink Power Presenter RE
A15
Screen Selection and Adjustment
Name of the Buttons on the Screen Adjustment Unit
Buttons at the rear side
of the monitor
Screen at the front side
of the monitor
A green LED will be displayed in a normal operation mode, or an
orange LED will be displayed in a power saving mode.
Press the POWER button to turn the power on. Press the button again
Shows or hides the OSD (On Screen Display) menu.
Lock/Unlock OSD – Locks or unlocks the OSD adjustment function.
To lock the OSD menu, press the MENU button for 5 seconds. The “OSD Locked” message
will be displayed and the screen will be locked. To release OSD menu locking, press the
MENU button for 5 seconds again. The “OSD Unlocked” message will appear and the OSD
menu will be unlocked.
OSD Locked OSD Unlocked
MENU/EXIT button
OSD LOCKED OSD UNLOCKED
Power LED
Power button
A16
Use this button to select the icon or make an adjustment in the OSD (On Screen Display) menu.
When two computers are connected, use this button to select the input signal for the
destination computer.
If only one computer is connected, it will be recognized automatically.
Use this button to select the optimized image conditions, depending on the surrounding
environment (brightness, type of the image). See the page K24 for more details.
Select the icon to adjust in the OSD screen.
*Automatic screen adjustment function - The screen will be automatically adjusted
when you press the AUTO/SET button. (See the page K19)
> <
button
AUTO/SET button
Lightview <
button
LIGHT VIEW
DAY TEXT
1 2
PROCESSING AUTO
IMAGE ADJUSTMENT
SOURCE >
button
A17
Adjustment on the OSD (On Screen Display) Screen
You need to adjust the screen if you connect the monitor to the new
computer or change the mode.
Refer to the following description to keep the screen in an optimal state.
Press the AUTO/SET button to carry out automatic screen adjustment that best fits into the current screen
mode. If adjustment is found to be unsatisfactory, you may need to adjust screen position, frequency or
brightness manually in the OSD menu. (Supported only for the analog signal only.)
PROCESSING AUTO
IMAGE ADJUSTMENT
Screen Selection and Adjustment
Selects the
menu icon
Selects the icon Adjusts the status
Selects the
adjustment
value/Closes the
OSD screen
Press the MENU button to open the OSD screen.
Adjust the OSD menu item using the > < button.
When the menu icon is selected, press the AUTO/SET button
Adjust the item values using the > < button. To move down to the sub-menu or other menu, press the
AUTO/SET button to move.
To select other functions or to return to the previous screen, press the MENU button again.
Press the MENU button twice to close the OSD screen.
Automatic Saving Function
When you select another menu or close the OSD screen after changing the value while the OSD screen is
open, the adjusted value will be automatically saved. Even though you don’t close the screen after
adjustment, the OSD will disappear automatically and the adjusted values will be saved accordingly.
1
2
3
4
OSD(On Screen Display)
The OSD screen provides graphical presentation of the screen adjustment state so that you can
change the setting visually.
[Note] The language displayed in the monitor may differ from the one in the User’s Manual.
Pops up the
OSD screen
Adjusts the OSD screen easily and automatically…
Note
A18
OSD Adjustment Menu
The icon layout can be different for each model. (K21 ~ K24)
When you set the menu in the “Light View”menu, the “Picture” and “Color” menus are
automatically set. If you select the “Picture” or “Color” menu in the “Light View” menu mode, the
Light View menu mode will be automatically released and changed to the “normal” mode.
You can adjust screen contrast and
brightness
COLOR
POSITION
TRACKING
FACTORY
RESET
SETUP
LIGHTVIEW
Main Menu Sub-menu A D Function Description
PRESET
RED
GREEN
BLUE
You can adjust screen position
You can restore the initial monitor
settings
You can set the preferred screen
color
You can adjust the screen to the
circumstances
You can select or adjust the image
conditions according to the
environment
You can adjust screen clock and
phase
Brightness
Contrast
Gamma
H POSITION
V POSITION
CLOCK
PHASE
FACTORY RESET
WHITE BALANCE
LANGUAGE
OSD H POSITION
OSD V POSITION
DAY
TEXT/MOVIE/PHOTO
NIGHT
TEXT/MOVIE/PHOTO
USER1/2
NORMAL
: Adjustable items
A : Analog signal
D : Digital signal
Note
A19
Screen Selection and Adjustment
Menu Name
Icons
Sub-menus
50
50
0
MENU : Exit
<>
: Adjust (
Decrease
/
Increase)
SET : Enter
: Select another sub-menu
Button Tip
OSD(On Screen Display) Screen Adjustment
You were introduced to the procedure of selecting and adjusting an item
using the OSD system. Listed below are the icons, icon names, and icon
descriptions of the all items shown on the Menu.
Press the MENU Button, then the main menu of the OSD appears.
OSD (On Screen Display) menu languages on the monitor may differ from the manual.
Note
A20
COLOR
BRIGHTNESS
50
50
0
To adjust the brightness of the screen.
To adjust the contrast of the screen.
Set your own gamma value. : -50/0/50
On the monitor, high gamma values display
whitish images and low gamma values display
high contrast images.
BRIGHTNESS
CONTRAST
GAMMA
Main menu Sub menu Description
MENU : Exit <: Decrease >: Increase SET : Select another sub-menu
PRESET
50
50
50
6500K 9300K
Select the screen color.
... 6500K : Slightly bluish white.
... 9300K : 9300K: Slightly bluish white.
Set your own red color levels.
Set your own green color levels.
Set your own blue color levels.
PRESET
RED
GREEN
BLUE
POSITION
POSITION
50
50
To move image left and right.
To move image up and down.
H POSITION
V POSITION
A21
TRACKING
FACTORY RESET
TRACKING
50
50
To minimize any vertical bars or stripes visible
on the screen background.The horizontal
screen size will also change.
To adjust the focus of the display. This item
allows you to remove any horizontal noise
and clear or sharpen the image of characters.
CLOCK
PHASE
Main menu Sub menu Description
FACTORY RESET
NO
NO
PRESET MODE
1024 x 768 60Hz
ANALOG
Restore all factory default settings except
"LANGUAGE."
If the output of the video card is different the required
specifications, the color level may deteriorate due to
video signal distortion. Using this function, the signal
level is adjusted to fit into the standard output level of
the video card in order to provide the optimal image.
Activate this function when white and black colors are
present in the screen.
For example
FACTORY
RESET
WHITE
BALANCE
SETUP
SET UP
ENGLISH
50
50
To choose the language in which the control
names are displayed.
To adjust horizontal position of the OSD window
on the screen.
To adjust vertical position of the OSD window on
the screen.
LANGUAGE
OSD
H POSITION
OSD
V POSITION
Screen Selection and Adjustment
MENU : Exit <: Decrease >: Increase SET : Select another sub-menu
A22
LIGHTVIEW
LIGHT VIEW
DAY TEXT
1 2
This feature lets you easily select the best desired
image condition optimized to the environment
(ambient illumination, image types etc).
DAY : Bright ambient illumination
NIGHT : Dark ambient illumination
TEXT : For text images (Word processing etc.)
MOVIE : For animation images in videos
or movies
PHOTO : For pictures or drawings
DAY
NIGHT
Main menu Sub menu Description
LIGHT VIEW
USER1
1 2
BRIGHTNESS
50
50
0
6500K 9300K
NO
User can preset the BRIGHTNESS,
CONTRAST, GAMMA, and PRESET levels
and save them for later use.
Select the sub-menu using the SET
button and save the YES value using the -/+
buttons.
USER 1
USER 2
To adjust the USER1/USER2
sub-menu function, Press the
SET Button
LIGHT VIEW
NORMAL
1 2
This is under normal operating conditions.NORMAL
Press the LIGHTVIEW(
<
) Button, then the main menu of the OSD appears.
MENU : Exit <: Decrease >: Increase SET : Select another sub-menu
A23
Make sure to connect the power cord to the monitor.
See if the power switch is on.
Adjust brightness ( ) and contrast ( ) again.
If the monitor is in the power saving mode, move the
mouse or press any key to activate the screen again.
The signal from the PC (video card) is out of the
horizontal or vertical frequency range supported by
the monitor. Adjust the frequency again by referring
to the “Product Specification” in this manual.
*Maximum resolution
D-Sub: 1024x768@75 Hz
DVI-D: 1024x768@75 Hz
The signaling cable connecting PC and monitor is
not connected. See if the signal cable is firmly
connected.
Power cord is properly connected to the
monitor?
Power LED is on?
The power is on, the power LED is green,
and the screen is extremely dark?
Power LED is orange?
“Out of Range” message appears?
“Check Signal Cable” message appears?
Troubleshooting
The monitor is not working
Vertical frequency : Tens of images should be replaced within a second on the monitor to make you to see
images on the screen. The rate of changing the images within a second is called by “vertical frequency” or “refresh
rate” with the unit of Hz.
Horizontal frequency : The horizontal period is a time needed to display one horizontal line. When the horizontal
period is divided by one, the number of horizontal lines can be figured out that can be displayed for a second,
which is called by “horizontal frequency” with the unit of kHz.
The OSD locking function prevents unintentional
change of the OSD settings. Press the MENU button
for about 5 seconds to unlock then, the “OSD
Unlocked” message appears.
The “OSD Locked” message appears
when you press the MENU button?
“OSD Locked” message appears
If you use the same specific screen for a long time,
the monitor pixel can be damaged quickly. To use
the monitor longer, use the screen saver program.
Afterimage appears when the monitor is
turned off?
Afterimage appears
Note
A24
• Press the AUTO/SET button to adjust the screen
automatically with the optimal state that fits into the
currently selected mode.
If you’re not satisfied with the adjusted screen, use the
“Position” OSD menu to manually adjust the screen
position.
• See if the resolution or the frequency of the video card
is set within the range supported by the monitor. If not,
set to the recommended resolution at “Control Panel”
–> “Display” –> “Setting” menu.
• Press the AUTO/SET button to adjust the screen
automatically with the optimal state that fits into the
currently selected mode.
If you’re not satisfied with the adjusted screen, use the
“Clock” OSD menu to manually remove the vertical
lines.
• Press the AUTO/SET button to adjust the screen
automatically with the optimal state that fits into the
currently selected mode.
If you’re not satisfied with the adjusted screen, use the
“Phase” OSD menu to manually adjust it.
Screen position is wrong?
Vertical slim lines appear on the
background screen?
Horizontal noise appears or letters are
blurred?
Screen image is displayed abnormally
• Change the number of colors to 24 bits (true color) or
better.
: Windows Control Panel –> Display –> Setting –>
Color Table.
• Check signaling cable connection. If not properly
connected, connect it again. Or, plug in the PC video
card firmly.
• You may see several pixel dots (red, green, white or
black) while using the monitor due to the characteristics
of the LCD panel. It is not related with monitor
performance and is not a malfunction.
Screen is de-colored (16 colors)?
Screen color is unstable or mono-color?
Dots appear on the screen?
Screen color is displayed abnormally
• Install the provided monitor driver again or download
the driver from the LG Electronics web site
(http://www.lge.co.kr).
See if the plug & play function is supported by the
video card by referring to the video card user’s
manual.
Monitor driver is installed?
When the monitor is connected, the “Unknown Monitor” message appears
A25
Troubleshooting
The tablet driver is not recognized properly.
Plug out the USB cable and plug it in again. If you meet
up with the same symptom, remove the driver and install
it again.
Adjust the position again using the About – Calibration
menu in the USB Tablet Manager. (See the page K12)
Tablet pen touch position deviates
from the cursor position by more than
5cm?
Pen touch position does not match
with the cursor position?
Pen touch position does not match with the cursor position
• See if the tablet driver (USB Tablet Manager) is properly
installed. (See the page K12)
• See if the USB cable is connected properly.
If you have connected the USB cable again, wait until the
USB tablet icon appears on the Windows Task Bar
before using the pen. The icon appears after 3 – 4
seconds after connecting the USB cable.
• See if the battery is inserted into the pen, or the battery is
not flat. If it is flat, replace with new one.
• See if the battery polarity is correct (+/-).
Tablet pen is not working?
• You should apply a certain amount of pressure to the pen to
draw a picture or write a letter. If it is inconvenient for you to
apply excessive force, adjust pressure (sensitivity) by setting
“Pen Offset Value” or “Click Pressure” by referring to the
page K13.
I cannot draw a picture or write a
letter when I move the tablet pen.
• Clicking will be disabled in the drawing menu of “Office
Ink” or “Power Presenter RE” – tablet application
software.
1) When running Office Ink: Click the Cancel button in
the toolbar, or exit from the program.
2) When running Power Presenter RE: Select the mouse
icon in the toolbar window to activate the pen mouse
function.
I cannot click the icon on the
background screen with a tablet pen.
• You should double click on the precise position quickly.
If it is not working, use the upper pen side button. Or, set
the side button function manually by referring to the
page K13.
I cannot double click the icon
properly on the background screen
with a tablet pen
Tablet pen is not working normally
A26
Type 15 inch (38.0 cm) TFT (Thin Film Transistor) LCD
(Liquid Crystal Display) Panel
Size of Visible Diagonal Line: 38.0cm
Pixel Pitch 0.297mm
Max. Resolution Digital/Analog: 1024x768 @ 75 Hz
Recommended Resolution
1024x768 @ 60 Hz
Horizontal Frequency Digital/Analog: 30 ~ 63 kHz
Vertical Frequency 56 ~ 75 Hz
Synchronization Type Separate/Composite/SOG (Sync On Green)/
Digital
15 pin D-Sub Type/DVI-D (Digital)
Rated Voltage DC 12V 3A
Power Consumption Normal Operation : 35W
Power-saving Preparation Mode ≤3W
Power-saving Mode ≤3W
Monitor Dimension (W x L x H)
385.5x211.1x354.5mm
Weight (excl. packaging materials)
5.85kg
Stand Adjustment Angle
Operational Temperature 10 C ~ 35 C Humidity 10% ~ 80%
Storage Temperature -20 C ~ 60 C Humidity 5% ~ 95%
Product specification is subject to change without a prior notice to improve the product.
LCD Panel
Video Signal
Input Connector
Power
Dimension/Weight
Environmental Conditions
Product Specification
113˚
20˚
A27
Product Specification
PC Mode – Preset Mode
Power LED
Locking Device - Check the locking device by opening the back door at the rear of the
monitor.
Mode LED
Normal Operation
Power-saving Preparation Mode
Power-saving Mode
Green
Orange
Orange
Locking Device
You can use the locking
device to prevent theft by
connecting it to the locking
cable (optional).
Preset mode
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
1
2
3
4
5
6
7
8
9
10
11
*12
13
14
640 x 350
720 x 400
640 x 480
640 x 480
640 x 480
640 x 480
800 x 600
800 x 600
800 x 600
800 x 600
832 x 624
1024 x 768
1024 x 768
1024 x 768
31.468
31.468
31.469
35.000
37.861
37.500
35.156
37.879
48.077
46.875
49.725
48.363
56.476
60.023
70
70
60
66.67
72.8
75
56.25
60
72
75
75
60
70
75
VGA
VGA
VGA
VESA
VESA
VESA
VESA
VESA
VESA
VESA
MAC
VESA
VESA
VESA
*
Recommended Resolution
A28
DVI-D
T.M.D.S.(Transition Minimized Differential Signaling)
Number Signal
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
T.M.D.S. Data 2-
T.M.D.S. Data 2+
T.M.D.S. Data 2/4 Shield
T.M.D.S. Data 4-
T.M.D.S. Data 4+
DDC Clock
DDC Data
Analog Vertical Synchronization
T.M.D.S. Data 1-
T.M.D.S. Data 1+
T.M.D.S. Data 1/3 Shield
T.M.D.S. Data 3-
T.M.D.S. Data 3+
+5V Power
Groundings (return for +5V, horizontal and vertical synchronization)
Hot Plug Detect
T.M.D.S. Data 0-
T.M.D.S. Data 0+
T.M.D.S. Data 0/5 Shield
T.M.D.S. Data 5-
T.M.D.S. Data 5+
T.M.D.S. Clock Shield
T.M.D.S. Clock+
T.M.D.S. Clock-
A29
MEMO
