L600i User Guide
English
2
User Guide
Introduction ............................................................................... 5
Guidelines ................................................................................. 6
Installing the USIM card ....................................................... 11
Charging the Battery .............................................................. 14
Disconnecting the charger ................................................... 15
Part of the Phone .................................................................... 16
Key functions .......................................................................... 17
Display information ............................................................... 18
Main Menu .............................................................................. 26
1. i-appli ................................................................................... 29
1.1 Software list ................................................................... 29
1.2 i-appli settings ............................................................... 29
1.3 Display history ............................................................... 29
2. i-mode .................................................................................. 30
3. NW service .......................................................................... 31
3.1 Voice mail ....................................................................... 31
3.2 Call waiting ..................................................................... 31
3.3 Call forwarding .............................................................. 31
3.4 Nuisance call barring ................................................... 32
3.5 Caller ID notification ..................................................... 34
3.6 Caller ID request ........................................................... 34
3.7 Set arrival act ................................................................ 34
3.8 Arrival call act ............................................................... 34
3.9 Others .............................................................................. 34
4. Messaging ........................................................................... 35
4.1 Inbox ................................................................................ 35
4.2 Compose new mail ........................................................ 35
4.3 Sent ................................................................................. 36
4.4 Draft ................................................................................. 36
4.5 Check new mail ............................................................. 36
4.6 SMS ................................................................................. 38
4.7 Read template ................................................................ 38
4.8 Settings ........................................................................... 39
5. My stuff ................................................................................ 42
5.1 Image .............................................................................. 42
5.2 i-motion ........................................................................... 42
5.3 Melody ............................................................................ 42
5.4 External memory ........................................................... 42
Contents
User Guide
3
6. Multimedia .......................................................................... 43
6.1 Camera ............................................................................ 43
6.2 Camcorder ...................................................................... 44
7. Organiser ............................................................................. 45
7.1 Schedule ......................................................................... 45
7.2 Memo .............................................................................. 45
7.3 Date finder ...................................................................... 45
7.4 Date counter .................................................................. 45
7.5 Settings ........................................................................... 45
8. Phonebook ........................................................................... 46
8.1 Add to Phonebook ......................................................... 46
8.2 Search to Phonebook ................................................... 46
8.3 No. of phonebook .......................................................... 46
8.4 Phonebook settings ...................................................... 46
8.5 Group settings ............................................................... 47
8.6 Own number ................................................................... 47
9. Tools ..................................................................................... 48
9.1 Alarm clock .................................................................... 48
9.2 Data exchange .............................................................. 48
9.3 Calculator ....................................................................... 48
9.4 Unit converter ................................................................ 49
9.5 World time ...................................................................... 50
9.6 Stop watch ..................................................................... 51
9.7 SIM service .................................................................... 51
9.8 Mini SD card .................................................................. 51
10. Sound .................................................................................. 52
10.1 Ring tone volume ......................................................... 52
10.2 Effect tone volume ...................................................... 52
10.3 Select ring tone ........................................................... 52
10.4 Select effect tone ........................................................ 52
10.5 Vibration ....................................................................... 52
10.6 Manner setting ............................................................ 52
10.7 Mail ring duration ........................................................ 52
10.8 Set mute second ......................................................... 52
10.9 Hold/On hold tone ....................................................... 52
11. Display ............................................................................... 53
11.1 Main display ................................................................. 53
11.2 Front display ................................................................. 53
11.3 Font ................................................................................ 53
Contents
4
User Guide
11.4 Backlight ....................................................................... 54
11.5 Contrast ........................................................................ 54
11.6 Colour scheme ............................................................. 54
12. Settings .............................................................................. 55
12.1 Call / Answer ................................................................ 55
12.2 Call feature ................................................................... 57
12.3 Video phone ................................................................. 57
12.4 Date & Time ................................................................. 57
12.5 Network ........................................................................ 58
12.6 Access points .............................................................. 59
12.7 Security ......................................................................... 60
12.8 Character input ............................................................ 62
12.9 Power on / off time ...................................................... 62
12.10 Languages .................................................................. 62
12.11 Others .......................................................................... 62
Troubleshooting ..................................................................... 63
Accessories ............................................................................ 65
Contents
User Guide
5
Contents
Introduction
Congratulations on your purchase of the advanced and
compact L600i cellular phone, designed to operate
with the latest digital mobile communication
technology.
This user’s guide contains important information on
the use and operation of this phone. Please read all
the information carefully for optimal performance
and to prevent any damage to or misuse of the
phone. Any changes or modifications not expressly
approved in this user’s guide could void your
warranty for this equipment.
6
User Guide
Read these simple guidelines. Breaking the rules may
be dangerous or illegal. Further detailed information is
given in this manual.
FCC information
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
nNote
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for
help.
Exposure to radio frequency energy
Radio wave exposure and Specific Absorption Rate
(SAR) information
This mobile phone model L600i has been designed to
comply with applicable safety requirement for
exposure to radio waves. This requirement is based on
scientific guidelines that include safety margins
designed to assure this safety of all persons,
regardless of age and health.
• The radio wave exposure guidelines employ a unit of
measurement known as the Specific Absorption Rate,
or SAR. Tests for SAR are conducted using
standardized method with the phone transmitting at
its highest certified power level in all used frequency
bands.
• While there may be differences between the SAR
levels of various LG phone models, they are all
designed to meet the relevant guidelines for
Guidelines
User Guide
7
Guidelines
exposure to radio waves.
• The SAR limit recommended by the international
Commission on Non-Ionizing Radiation Protection
(ICNIRP), which is 2W/kg averaged over ten (10) gram
of tissue.
• The highest SAR value for this model phone tested by
DASY3 for use at the ear is GSM 900:0.782/DCS
1,800:0.256 W/kg (10g).
• SAR data information for residents in
countries/regions that have adopted the SAR limit
recommended by the Institute of Electrical and
Electronics Engineers (IEEE), which is 1.6 W/kg
averaged over one (1) gram of tissue (for example
USA, Canada, Australia and Taiwan).
Product care and maintenance
Warning: Use only batteries, charger and accessories
approved for use with this particular phone model.
The use of any other types may invalidate any
approval or warranty applying to the phone, and may
be dangerous.
• Do not disassemble this unit. Take it to a qualified
service technician when repair work is required.
• Keep away from electrical appliance such as a TV,
radio or personal computer.
• The unit should be kept away from heat sources such
as radiators or cookers.
• Do not drop.
• Do not subject this unit to mechanical vibration or
shock.
• The coating of the phone may be damaged if covered
with wrap or vinyl wrapper.
• Use dry cloth to clean the exterior of the unit.
(Do not use solvent such as benzene, thinner or
alcohol.)
• Do not subject this unit to excessive smoke or dust.
• Do not keep the phone next to credit cards or
transport tickets; it can affect the information on the
magnetic strips.
• Do not tap the screen with a sharp object; otherwise,
it may damage the phone.
• Do not expose the phone to liquid or moisture.
• Use the accessories like an earphone cautiously.
Do not touch the antenna unnecessarily.
Efficient phone operation
To enjoy optimum performance with minimum power
consumption please:
• Hold the phone as you speak to any other telephone.
While speaking directly into the microphone, angle
the antenna in a direction up and over your shoulder.
If the antenna is extendable/ retractable, it should be
extended during a call.
• Do not hold the antenna when the phone is in use. If
you hold it, it can affect call quality, it also may cause
the phone to operate as a higher power level that
needed and shorten talk and standby times.
• If your mobile phone supports infrared, never direct
the infrared ray at anyone's eye.
Electronics devices
All mobile phones may get interference, which could
affect performance.
• Do not use your mobile phone near medical
equipment without requesting permission. Avoid
placing the phone over the pacemaker, i.e. in your
breast pocket.
• Some hearing aids might be disturbed by mobile
phones.
• Minor interference may affect TVs, radios, PCs, etc.
Road safety
Check the laws and regulations on the use of mobile
phones in the areas when you drive.
• Do not use a hand-held phone while driving.
• Give full attention to driving.
• Use a hands-free kit, if available.
• Pull off the road and park before making or
answering a call if driving conditions so require.
• RF energy may affect some electronic systems in your
motor vehicle such as car stereo, safety equipment.
• When your vehicle is equipped with an air bag, do not
obstruct with installed or portable wireless
equipment. It can cause serious injury due to
improper performance.
8
User Guide
Guidelines
User Guide
9
Guidelines
Blasting area
Do not use the phone where blasting is in progress.
Observe restrictions, and follow any regulations or
rules.
Potentially explosive atmospheres
• Do not use the phone at a refueling point. Don't use
near fuel or chemicals.
• Do not transport or store flammable gas, liquid, or
explosives in the compartment of your vehicle, which
contains your mobile phone and accessories.
In aircraft
Wireless devices can cause interference in aircraft.
• Turn off your mobile phone before boarding any
aircraft.
• Do not use it on the ground without crew permission.
Children
Keep the phone in a safe place out of children's reach.
It includes small parts which if detached may cause a
choking hazard.
Emergency calls
Emergency calls may not be available under all cellular
networks. Therefore, you should never depend solely
on the phone for emergency calls. Check with your
local service provider.
Battery information and care
• You do not need to completely discharge the battery
before recharging. Unlike other battery systems,
there is no memory effect that could compromise the
battery's performance.
• Use only LG batteries and chargers. LG chargers are
designed to maximize the battery life.
• Do not disassemble or short-circuit the battery pack.
• Keep the metal contacts of the battery pack clean.
• Replace the battery when it no longer provides
acceptable performance. The battery pack may be
recharged hundreds of times until it needs replacing.
• Recharge the battery if it has not been used for a long
time to maximize usability.
• Do not expose the battery charger to direct sunlight
or use it in high humidity, such as the bathroom.
10
User Guide
• Do not leave the battery in hot or cold places, this
may deteriorate the battery performance.
Information to user
The users manual or instruction manual for an
intentional or unintentional radiator shall caution the
user that changes or modifications not expressly
approved by the party responsible for compliance
could void the user's authority to operate the
equipment.
Guidelines
User Guide
11
Installing the USIM card
Your USIM card contains your phone number, service
details and contacts and must be inserted into your
handset.
If your USIM card is removed then your handset
becomes unusable until a valid one is inserted. Always
disconnect the charger and other accessories from
your handset before inserting and removing your USIM
card.
Your USIM card may only be used in handsets which
are enabled for 3 services. Any attempt to use the
USIM card in other handsets may result in serious
damage to the handset and may prevent you from
being able to use it, including the making of emergency
calls.
12
User Guide
nNotice
Before installing always make sure that the phone is switched
off and remove the battery.
The metal contact of the USIM card can be easily damaged by
scratches. Pay special attention to the USIM card while
handling and installing. Follow the instructions supplied with the
USIM card.
Installing the USIM card
User Guide
13
Installing the USIM card
Memory card
M4410 is equipped on the side with SD memory card
with a maximum of 128MB capacity. You can use this
card to save data files such as photos, video, audio,
contact point, schedule.
nNote
Always insert/remove the memory card with the handset power
off.
Inserting the memory card
Insert the momory card into the slot until the memory
card is fully inserted into the slot, as shown in the fig-
ure below:
Open the memory card slot Insert the memory card
Removing the memory card
1. Push in memory card with the tip of your finger into
the slot.
2. Carefully pull the memory card out of slot.
Remove the memory card
14
User Guide
To connect the travel adapter to the phone, you must
have installed the battery.
1. With the arrow facing you as shown in the diagram
push the plug on the battery adapter into the socket
on the bottom of the phone until it clicks into place.
2. Connect the other end of the travel adapter to the
mains socket.
Use only the included packing charger.
nWarning
Do not force the connector as this may damage the phone
and/or the travel adapter.
Charging the Battery
User Guide
15
Disconnecting the charger
Disconnect the travel adapter from the phone by
pressing its side buttons as shown in the diagram.
nNote
• Ensure the battery is fully charged before using the phone.
• Do not remove your battery or the USIM card while charging.
• The moving bars of battery icon will stop after charging is
complete.
• If the battery is completely discharged, the charge could take
some minutes before starting.
nNote
If the battery does not charge,
• switch the phone off.
• ensure the battery is correctly fit.
16
User Guide
Sub LCD
Flash
Camera
USIM card
socket
Battery terminals
Cable connector/
Battery charging connector
Stereo
headset jack
Volume keys
Camera key External
Memory
Side of handset Keys
Battery cover
Battery
Part of the Phone
User Guide
17
Key functions
Main LCD
Camera
Send key
Left soft key
activates the prompts displayed
on screen in the left soft box.
Video call key
Speaker
End key On/Off
OK key+4-way
navigation key
Right soft key
activates the prompts displayed
on screen in the right soft box.
Clear key
Microphone
18
User Guide
No Sim Idle Screen
This is the initial screen of the phone that appears
when there is no Sim card installed in the phone, or the
installed Sim card is invalid. In this screen, users can
only make emergency calls, and turn the phone off. To
turn off the phone, press and hold the End key for a
while.
Screen Structure
If there is no Sim card installed, an animation telling
you to insert a Sim card appears. If the Sim card
inserted into the phone is invalid, an animation telling
you that the Sim card is locked appears.
Emergency Call Function
The left soft key is represented by “SOS” on the
screen. Key in your desired emergency call number
using the number keys, and then press the OK key to
make an emergency call.
Idle Screen
The idle screen appears when you have installed a
proper Sim card and turned the phone on.
Screen Structure
Idle screen consists of the operator’s name, indicators,
date, and time on a background image. You can
configure the background Display >Main display >
Home Screen >Wallpaper.
Key Functions
The functions of the keys in the idle screen status are
described below.
Display information
User Guide
19
Display information
Numbering Screen
The numbering screen appears when a number key is
pressed in the idle screen.
Screen Structure
The numbering screen consists of status indicators,
dialled number, and soft menu. Status indicators are
the same as that of the idle screen. The dialled number
is displayed in the size and colour configured in
Display >Font. You can make a call while dialling a
phone number by pressing the Send or Video Call key.
The numbering screen appears when a number key is
pressed in the idle screen.
Soft Key
You can use the soft keys for several functions while
dialling a number. Using the left most soft key, you can
send a message to the current dialled number, you can
search for numbers in addressbook, and using
the key, you can input hyphen, manual hold, or
time hold characters within the number.Using the
middle soft key, you can save the current dialled
number to the electronic organiser. Using the right
most soft key, you can search the current dialled
number in the electronic organiser.
Phone Lock Screen
When the phone lock function is selected, you can
only make an emergency call, release the lock, and
turn off the phone in this screen. As always, you can
turn the phone off by pressing and holding the End key
for a while.
Screen Structure
The screen structure of the Phone Lock screen is the
same as that of the idle screen, except that the lock
message appears instead of the idle screen banner.
Emergency Call Function
You can make an emergency call using the left soft
key. Like the No USIM Idle screen, the emergency
numbers are displayed.
Unlock Function
If you press the OK key, a popup screen appears
asking you to input the PIN code to unlock the phone.
The PIN code is configured by selecting Settings >
Security >Change codes. If you key in an incorrect
PIN code, the phone will remain in phone lock status.
20
User Guide
If you key in the correct PIN code, the phone will be
unlocked, and the idle screen will be displayed. If you
have turned the phone off in the phone lock status, you
will find the phone remains in phone lock status when
you turn it on.
Turning your handset on
Ensure that your USIM card is in your handset and the
battery is charged.
Press and hold the key until power is on.
Enter the USIM PIN code that was supplied with your
USIM card if PIN code setting is on.
After a few seconds you will be registered on the
network.
Turning your handset off
Press and hold the key until power is off.
There may be some delay while the handset powers
down.
Do not re-power the handset during this time.
Access Codes
You can use the access codes described in this
section to avoid unauthorized use of your phone.
The access codes (except PUK and PUK2 codes) can
be changed by using the Change codes feature
[Menu 12.4.3].
PIN code (4 to 8 digits)
The PIN (Personal Identification Number) code
protects your USIM card against unauthorized use.
The PIN code is usually supplied with the USIM card.
When the PIN Code Request is set to Enable, your
phone will request the PIN code every time it is
switched on. When the PIN Code Request is set to
Disable, your phone connects to the network directly
without the PIN code.
PIN2 code (4 to 8 digits)
The PIN2 code, supplied with some USIM cards, is
required to access functions such as Fixed Dial
Number. These functions are only available if
supported by your USIM card.
Display information
User Guide
21
PUK code (4 to 8 digits)
The PUK (PIN Unblocking Key) code is required to
unlock a blocked PIN code. The PUK code may be
supplied with the USIM card. If not, contact Telefonica
Movistar Customer Service for the code.
If you lose the code, contact Telefonica Movistar
Customer Service.
PUK2 code (4 to 8 digits)
The PUK2 code, supplied with some USIM cards, is
required to unlock a blocked PIN2 code. If you lose the
code, contact Telefonica Movistar Customer Service.
Security code (4 to 8 digits)
The security code protects the unauthorized use of
your phone. The default security code is set to ‘0000’
and the security code is required to delete all phone
entries and to restore the handset to factory setting.
Barring Password
The barring password is required when you use the
call barring function. The password is obtained from
the Telefonica Movistar Customer Services when you
subscribe to this function.
Making and Answering calls
Ensure you tell the other party before recording a
voice call.
Making and Answering a video call
You can make/answer a video call to a 3G video phone
the other party must have a 3G video phone and be in a
video service area.
To make/answer a video call, do the following.
1. Input the phone number using the keypad, or select
the phone number from the calls made/received
lists.
nNote
To correct mistakes, press the key briefly to delete the last
number, or press and hold the key to delete all numbers.
2. If you do not want to use the speakerphone, ensure
you have the headset plugged in.
3. To start the video function, press .
nNote
You will be notified that you will need to close other applications
to make the video call.
Display information
22
User Guide
nNote
The video call may take some time to connect. Please be
patient. The connection time will also depend on how quickly
the other party answers the call. While the video call is
connecting, you will see your own images; after the other party
has answered, their image will be displayed on screen.
4. Adjust the camera position if necessary.
5. Press the end key to finish the call, or close the
handset.
Making a voice call
1. Make sure your handset is powered on.
2. Enter the number including the full area code.
]To delete a digit press the key.
To delete all digits press and hold the key.
3. Press the key to make the call.
4. Press the key to finish the call, or close the
handset.
nNote
To activate the speakerphone during a call, you have to press
and hold the key for at least 2 secs.
Making a voice/video call from Contacts
It is easy to call anyone whose number you have
stored in your Contacts.
Press the down navigation key to access contact list.
Scroll to your chosen contact and press the key.
To make a voice call press the key.
To make a video call press the key. Press the
key to finish the call.
Making International Calls
1. Press and hold the key for the international
prefix. The ‘+’ character can be replaced with the
international access code.
2. Enter the country code, area code, and the phone
number.
3. Press the key.
Adjusting the Volume
During a call, if you want to adjust the earpiece
volume, use the side keys of the handset. In idle mode
with the flip cover open, you can adjust the key volume
using the side keys.
Display information
User Guide
23
Display information
Answering a Call
When you receive a call, the phone rings and the
flashing phone icon appears on the screen. If the
caller can be identified, the caller’s phone number (or
name if stored in your Contacts) is displayed.
1. Open the flip and press the key to answer an
incoming call.
If the Press any key menu option has been set to
key, Press any key will answer a call except for the
key.
nNote
• To reject an incoming call, press the key or the right
soft key twice.
• If you set “Answer mode” as “On flip open” (Menu 2.9.4), you
can answer the call simply by opening the flip.
2. End the call by closing the handset or pressing the
key.
nNote
You can answer a call while using the Contacts or other menu
features.
Signal Strength
If you are inside a building, being near a window
may give you better reception. You can see the
strength of your signal by the signal indicator see the
strength ( ) on your handset's display screen.
Entering Text
You can enter alphanumeric characters using the
keypad.
For example, storing names in the Contacts, writing a
message, creating a personal greeting or scheduling
events in the calendar all require entering text.
Following text input methods are available in the
handset.
Changing the Text Input Mode
1. When you are in a field that allows characters to be
entered, you will notice the text input mode indicator
in the upper right corner of the display.
2. Short pressing the key cycles between ,
, and . A long press changes mode
to .
24
User Guide
Using the T9 Mode
The T9 predictive text input mode allows you to enter
words easily with a minimum number of key presses.
As you press each key, the handset begins to display
the characters that it thinks you are typing based on a
built-in dictionary. As new letters are added, the word
changes to reflect the most likely candidate from the
dictionary.
1. When you are in the T9 predictive text input mode,
start entering a word by pressing keys to
. Press one key per letter.
]The word changes as letters are typed - ignore
what’s on the screen until the word is typed
completely.
]If the word is still incorrect after typing completely,
press the key once or more to cycle through
the other word options.
Using the ABC Mode
Use the to keys to enter your text.
1. Press the key labeled with the required letter:
]Once for the first letter
]Twice for the second letter
]And so on
2. To insert a space, press the key once.To delete
letters, press the key. Press and hold down
the key to clear the display.
Using the 123 (Number) Mode
The 123 Mode enables you to enter numbers in a text
message (a telephone number, for example).
Press the keys corresponding to the required digits
before manually switching back to the appropriate text
entry mode.
Using the Symbol Mode
The symbol mode enables you to enter various
symbols or special characters.
To enter a symbol, press the center soft key [Symbol].
Use the navigation and numeric keys to select the
desired symbol and press the key.
Display information
User Guide
25
Display information
Key description
Each key can be used for several symbols. There are
shown below.
Characters in the order display
Lower case Upper case
. , ? ! 1 . , ? ! 1
a b c 2 à á â ã ä å æ ç A B C 2 À Á Â Ã Ä Å ÆÇ
d e f 3 è é ê ë D E F 3 È É Ê Ë
g h i 4 ì í î ï G H I 4 Ì Í Î Ï
j k l 5 £ J K L 5 £
m n o 6 ñ ò ó ô õ ö ø œ M N O 6 Ñ Ò Ó Ô Õ Ö Ø Œ
p q r s 7 ß $ P Q R S 7 ß $
t u v 8 ù ú û ü T U V 8 Ù Ú Û Ü
w x y z 9 W X Y Z 9
Space 0 Space 0
1
2
3
4
5
6
7
8
9
0
Key
26
User Guide
You can launch a menu by pressing the Menu key over numeric key 2 in the idle screen.
Move to a desired item and press the OK key to go into the sub menu.
You can also go into a submenu by directly pressing the corresponding numeric key as follows.
The main menu consists of the following high-level and sub menus.
1 i-appli
Software list
i-appli settings
Display history
2 i-mode
3 NW service
Voice mail
Call waiting
Call forwarding
Nuisance call barring
Caller ID notification
Caller ID request
Set arrival act
Arrival call act
Others
4 Messaging
Inbox
Compose new mail
Sent
Draft
Check new Mail
SMS
Read template
Settings
Main Menu
User Guide
27
Main Menu
5 My stuff
i-motion
Melody
External memory
6 Multimedia
Camera
Camcorder
7 Organiser
Schedule
Memo
Date finder
Date counter
Settings
8 Phonebook
Add to Phonebook
Search to Phonebook
No. of phonebook
Phonebook settings
Group settings
Own number
9 Tools
Alarm clock
Data exchange
Calculator
Unit converter
World time
Stop watch
SIM service
Mini SD card
28
User Guide
10 Sound
Ring tone volume
Effect tone volume
Select ring tone
Select effect tone
Vibration
Manner setting
Mail ring duration
Set mute second
Hold/On hold tone
11 Display
Main display
Front display
Font
Backlight
Contrast
Colour scheme
12 Settings
Call / Answer
Call feature
Video phone
Date & Time
Network
Access points
Security
Character input
Power on / off time
Languages
Others
Main Menu
User Guide
29
i-appli [Menu 1]
You can check the latest weather information, stock
prices, and the games without conneting network. You
can dowmload all sorts of software applications from
sites and saving them on your i-mode handset. Please
refer to FOMA i-mode user's manual.
Software list [Menu 1-1]
If you select My folder menu, you can check the
downloaded software list.
i-appli settings [Menu 1-2]
i-appli can be set as a standby mode, and you can
receive mail and make calls while the i-appli is
avtivated. You can make your standby mode even more
usuful by displaying the latest news and weather, or by
setting favorite characters to inform you of incoming
mail and appointments.
Display history [Menu 1-3]
You can view the list of connecting i-appli.
30
User Guide
i-mode offers various sites, enabling you to view
information you need by accessing your favrite sites.
i-mode [Menu 2]
User Guide
31
NW service [Menu 3]
Voice mail [Menu 3-1]
Once this menu has been selected, simply press the
left soft key [OK] to listen to voice mail. You can also
hold down key in standby mode to listen to voice
mail.
Call waiting [Menu 3-2]
This menu consists of All calls, Video call, Voice call.
If you select one, activate/deactivate/view status
menu list appears.
1. Activate Call waiting: Activates waiting service.
Selecting this item, displays requesting message
and animation. When the network answers, the
result of the operation is displayed.
2. Deactivate Call waiting: Deactivates Call waiting
service. Selecting this item displays requesting
message and animation. When the network
answers, the result of the operation is displayed.
3. Call waiting status request: Displays activated Call
waiting service group item of the network. Selecting
this item displays requesting message and
animation. When the network answers, the result of
the operation is displayed.
Call forwarding [Menu 3-3]
The Call divert service allows you to divert incoming
voice calls, fax calls, and data calls to another number.
For details, contact your service provider.
All voice calls
Diverts voice calls unconditionally.
If busy
Diverts voice calls when the phone is in use.
If no reply
Diverts voice calls which you do not answer.
If out of reach
Diverts voice calls when the phone is switched off or
out of coverage.
All data calls
Diverts to a number with a PC connection
unconditionally.
All fax calls
Diverts to a number with a fax connection
unconditionally.
Cancel all
Cancels all call divert service.
32
User Guide
The submenus
Call divert menus have the submenus shown below.
• Activate
Activate the corresponding service.
To voice mail centre
Forwards to message centre. This function is not
shown at All data calls and All fax calls menus.
To other number
Inputs the number for diverting.
To favourite number
You can check recent 5 diverted numbers.
• Cancel
Deactivate the corresponding service.
• View status
View the status of the corresponding service.
Nuisance call barring [Menu 3-4]
Call barring menus for All calls ,video, voice are
provided.
However, available menus are determined by the SIM
supporting CPHS.
The menu consists of All calls ,Video, Voice.
The All calls menu provides menus to barring all calls
and the Video menu provides menus to barring video
calls. the Voice menu provides menus to barring voice
calls. The All call,Video and Voice menus have the
following submenus.
If you select All calls, Outgoing calls, International
calls, International except home country, Incoming
calls, and Incoming calls when abroad submenus.
menu list appears.
The Call barring menu consists of Outgoing calls,
International calls, International except home country,
Incoming calls, and Incoming calls when abroad
submenus. However, the menus available depend on
whether the SIM suppors CPHS. The Outgoing calls
menu bars dialing outgoing calls, the International
calls menu bars dialing outgoing international calls,
the International except home country menu bars
dialing outgoing international calls except for the
NW service
User Guide
33
Home PLMN country, Incoming calls rejects incoming
calls, and the Incoming calls when abroad menu
rejects incoming calls in roaming.
3.4.1 All calls
3.4.2 Video call2.7.3 Voice call
All outgoing
1. When OK button is selected – Receives Barring
password from user, and activates barring service
on the network. Requesting message and animation
appears. When the network answers, the result of
the operation is displayed.
2. When Options menu is selected – It activates
Outgoing calls menu. Select options menu from the
soft menus on the lowest menu. Then, Activate,
Deactivate, Deactivate all, View status, and Barring
password menu appear. Select Activate menu to
receive Barring Password from user and activates
the barring service on the network. Deactivate menu
deactivates barring service after Barring Password
input of user. Deactivate all menu deactivates all
barring service configured in the network after
Barring Password input of user. View status menu
enables users to view the current network
configuration. Selecting View status menu displays
Requesting message with animation and the result
of the operation when the network answers. Barring
password menu enables users to change current
barring password.
Outgoing international
1. When OK button is selected . It operates the same to
Outgoing calls menu.
2. When Options menu is selected – It activates and
operates International calls menu. It operates the
same to Outgoing calls menu.
Outgoing international calls except home country
1. When OK button is selected It operates the same to
Outgoing calls menu.
2. When Options menu is selected – It activates and
operates International except home country menu. It
operates the same to Outgoing calls menu.
All incoming
1. OK button select It operates the same to Outgoing
calls menu.
2. When Options menu is selected – It activates and
operates Incoming calls menu. It operates the same
to Outgoing calls menu.
NW service
34
User Guide
Incoming calls when roaming
1. OK button select. It operates the same to Outgoing
calls menu.
2. When Options menu is selected – It activates and
operates Incoming calls when abroad menu. It
operates the same to Outgoing calls menu.
Caller ID notification [Menu 3-5]
On
You can send your phone number to another party.
Your phone number will be shown on the receiver’s
phone.
Off
Your phone number will not be shown.
Set by network
If you select this, you can send your phone number
depending on two line service such as line 1 or line 2.
Caller ID request [Menu 3-6]
When you receive a call, you can check the number of
the other party.
Set arrival act [Menu 3-7]
During a call, you can receive or reject a call
depending on setting.
Arrival call act [Menu 3-8]
When you select this menu, you can forward or reject
a call during a call or making a data call.
Others [Menu 3-9]
You can use various supplementary services as below:
USSD, Record reply message, English guideline,
Service Dialing Number.
NW service
User Guide
35
Inbox [Menu 4-1]
1. You can view saved messages. Select a message
and then press the OK key to view the message.
2. You can view the previous or next message by using
the left and right keys.
3. To view an MMS Noti message, select Retrieve in
the message view screen. Then the file is
transmitted, and you can view the file when the
transmission is complete.
4. You can use the following functions by using
[Option] key.
[For a normal message]
1. Reply: You can create a reply to the selected
message.
2. Forward: Forwards the selected message. (Not
supported for MMSNoti message)
3. Open: You can view the message.
4. New message: You can write a new message.
5. Mark / Unmark: You can delete more than selected
message or all messages.
6. Filter: Displays messages by desired message types.
7. Delete: Deletes a selected message.
8. Info: Shows message info. . (Not supported for text
message)
[For WAP push message]
1. Open: Opens a selected message.
2. Mark/Unmark: Using the Mark function, you can
delete multiple files.
3. Filter: Displays messages by desired message types.
4. Delete: Deletes the marked messages.
5. Memory info: Shows how much memory the phone
has left.
Compose new mail [Menu 4-2]
You can send the text of up to 10,000 half-size
characters for the main text as well as attach melody
and image files. In addition, when sending mail to oan
i-mode handset, you only need to enter the part of the
address before. The maximum number of characters
depends on the data volume of melody or image
attachments.
Sent [Menu 4-3]
Show the messages you sent (Text message / Picture
Messaging [Menu 4]
36
User Guide
message / Email)
[Options]
- Forward: Forwards the selected message. (Text
message / Picture message / Email)
- Open: Open the selected message.
- Edit: Edits the selected message.
- New message: Creates a new message. (Text
message / Picture message / Email)
- Mark / Unmark: (Un)Mark / (Un)Mark all
- Filter : All messages / Text messages / Picture
messages / Email / Service messages
- Delete: you can delete the selected message
Draft [Menu 4-4]
1. You can edit saved messages. Select a message and
then press the OK key to edit the message.
2. You can use the following functions by using the
[Option] key.
- Edit: You can edit selected message
- New message: You can write a new message.
- Mark / Unmark: You can delete more than selected
message or all messages.
- Filter: Displays messages by desired message types.
- Delete: Deletes a selected message.
Check new mail [Menu 4-5]
4.5.1 Allow reply email
You can choose whether or not you allow reply email.
4.5.2 Auto retrieve
You can configure Auto retrieve to retrieve e-mails
automatically from the incoming mail server. When a
new mail arrives, an icon appears at the top of the idle
screen. You can select that auto receiving time slot
have None, 1, 3, 6 and 12 hours.
4.5.3 Text signature
You can configure a signature text to be attached to
the end of an e-mail. The configured signature text is
automatically attached to the end the e-mail when it is
sent.
4.5.4 Email accounts
1. You can create or configure an e-mail account
including the e-mail server and user ID.
Messaging
User Guide
37
2. You can edit a selected e-mail account by pressing
the Edit key.
3. You can select an e-mail account to be used to send
an e-mail using the OK key.
Creating a new e-mail account
1. Select Add new from the E-mail account menu
options.
2. By moving the cursor to a desired item, you can edit
the item to create an e-mail account.
3. Move the cursor to the Title field and enter a title.
4. Move the cursor to the User name field and enter
the user name of the e-mail account.
5. Move the cursor to the Password field and configure
e-mail account password.
6. Move the cursor to the e-mail address field and
configure the e-mail address for outgoing mail.
7. Move the cursor to the Reply e-mail address field and
configure the e-mail address to reply to your e-mail.
8. Move the cursor to the Outgoing mail server field
and configure the outgoing e-mail server.
9. Move the cursor to the Incoming mail server field
and configure the incoming e-mail server.
10. Move the cursor to the Outgoing server port field
and configure the mail server port number. In
general, the outgoing mail server port number
(SMTP) is 25.
11. Move the cursor to the Incoming server port field
and configure the mail server port number. In
general, the incoming mail server port number
(POP3) is 110.
12. Move the cursor to Maximum receive size and
configure the maximum e-mail size. The permissible
maximum receive size is no more than 500KB.
13. Move the cursor the Email inbox type and select
the email inbox type. You can select one between
POP3 and IMAP4.
14. Move the cursor to Save to server and determine
whether to leave a copy of messages on the
incoming server or not. You can select Yes or No
using the List key.
15. Move the cursor to the Access point field to select
an access point to connect to the Internet. You can
select a configured access point using the List key.
16. Move the cursor to the auto retrieve item and
decide a auto receiving E-mail message as a fixed
time slot, You can select on/off using the List key. If
Messaging
38
User Guide
you want to utilize this function, there is selected
auto retrieve in E-mail setting. But auto retrieve is
not selected, you can select auto retrieve in Option.
17. Move the cursor to the SMTP authentication field
and decide whether the outgoing mail server
requires authentication.
You can select Yes or No using the List key.
Editing an e-mail account
1. Select a desired e-mail account from the e-mail
account list and press the Edit key.
2. You can edit desired fields by moving the cursor up
and down.
3. When configuration is complete, press the Save key
to complete the e-mail account configuration.
SMS [Menu 4-6]
Compose SMS
You can create new message.
Received SMS
You can check the received message.
Sent SMS
You can check the sent message.
SMS Settings
You can set the font type, the status of delivery, the
duration for message in SMS center, SMSC, address
and type of number.
Read template [Menu 4-7]
You can add, edit, and delete frequently-used useful
phrases. You can save frequently-used phrases in the
input window in advance. You can save these useful
phrases using the Options menu.
- Depending on your service provider, the useful
phrases such asthe following examples are saved as
a default.
• I'm at home. Please call.
Messaging
User Guide
39
• I'm at work. Please call.
• I'm in a meeting, please call me later.
• I'm in a meeting, I'll call you later.
• I'm running late. I'll be there at.
• I love you.
• Hi. How are you?
• Sorry, I can't help you on this.
• Good to see you. My phone number is
• Call me. I'm ready for you.
Settings [Menu 4-8]
4.8.1 General
4.8.1.1 Message display
• Display after confirm: When new message arrived,
you can choose to read now or later on the popup.
• Only notification: When new message arrived, show
you only indicate image on the indicator area.
4.8.1.2 Message alert
• None / Once / Every 1 min / Every 2 mins /
Every 5 mins / Every 10 mins
You can select how often alert new message.
4.8.1.3 Message tone
• If you set your phone to Vibration or silent, it’s not
available.
Melody 1 ~ Melody 10
4.8.1.4 Save sent messages
• You can select whether save sent messages or not.
4.8.2 Text message
4.8.2.1 Text message centre
• Select text message centre
• Add new / Edit / Set as default centre / Delete
4.8.2.2 Character encoding
• Auto / Default alphabet / Unicode
4.8.2.3 Delivery report
• Yes / No
Messaging
40
User Guide
4.8.2.4 Validity period
• 1 hour / 6 hours / 12 hours / 1 day / 2 days / 1 week /
Maximum
4.8.2.5 Pages per sending
• 1 ~ 7 pages
4.8.3 Picture message
4.8.3.1 Picture msg. Centre
This menu allows you to configure network information
such as MMSC, and WAP gateway, to send an MMS
message.
In the Option menu, you can create or delete
Telefonica Movistar MMS only.
A profile name selected in a Checkbox is the current
configured value. You can view and edit the contents
of the profile in the edit mode by pressing the Edit key
at the option menu. The edit screen also appears when
creating a new profile under Options. The meanings of
the items are given below.
- Title: Profile name
- MMSC URL: Enter the MMS center URL
- IP address: Enter the WAP gateway IP address
- Port number: Enter the WAP gateway port number
- Connection mode: Specify the UDP(CO/CL), the TCP
with proxy, the TCP without proxy
- Primary access point: Specify the access point name
(see WAP connection settings.)
- Secondary access point: Specify the access point
name (see WAP connection settings.)
Press the Done key to save the changes and complete
MMS setting.
4.8.3.2 Message size
You can configure the size of a message for MMS
message
4.8.3.3 Priority
You can configure the priority of a message for MMS
message transmission.
4.8.3.4 Delivery report
This menu allows you to determine whether to request
a delivery confirmation mail to a recipient, and
whether to allow sending delivery confirmation mail to
a sender.
Messaging
User Guide
41
4.8.3.5 Validity period
This menu allows you to configure the term of validity
for a message when transmitting an MMS message.
The message would be saved in the MMS server only
for the configured term.
4.8.3.6 Multimedia reception
1. Only in home net 2. Always on 3. Off
4.8.3.7 Auto retrieve
This menu allows you to determine whether to
automatically download an MMS message when an
MMS notification message arrives.
4.8.3.8 Report sending?
1. Yes 2. No
4.8.4 Video mail
• Select video message centre
• Add new / Edit / Set as default centre / Delete
4.8.5 Voice mail
• Select voice message centre
• Add new / Edit / Set as default centre / Delete
4.8.6 Service message
• Never: Do not receive service message
• With confirmation: Receive service message
• Without confirmation: In the case of SL message.
Ask on the popup "Connect to internet ?"
Messaging
42
User Guide
In this menu, you can manage graphics, i-motion, and
tones which are downloaded from network. These files
are arranged in folders. You can create, edit the delete
the folder. Furthermore, you can copy, move and
delete the file in folder.
Image [Menu 5-1]
i-motion [Menu 5-2]
Melody [Menu 5-3]
External memory [Menu 5-4]
My stuff [Menu5]
User Guide
43
Camera [Menu 6-1]
Taking a Picture (Still picture)
1. Select Camera or press the numeric key (#1) from
the Media album menu.
2. Environment Setting.
- Select the [Options] key.
- Size: Select ‘Size’ and choose one from 1280x1024,
640x480, 320x240, Wallpaper size and Address book
size.
- Quality: You can select the desired quality of
picture by selecting either Super fine, Fine or
Normal.
- Flash: Select either Auto(around brightness),
Always on(always use flash), When taking(only
when taking a picture) or Off (do not use flash).
- Multishot: You can take 3/6/9 photos consecutively
(the Picture size is fixed to 320x240).
- Zoom: You can select zoom level according to the
picture size And preview size, and the range of
zoom level is 1 to 10. For pictures with 1280x1024,
only zoom level 1(1:1) is supported.
- Brightness: You can select a level from –2.0 to 2.0
with step size 0.5. The higher the level, the more
brighter the screen.
- White balance: Using this function you can adjust
the tone of the background picture according to
the weather by selecting either Auto, Daylight,
Cloudy, Shade or Fluorescent.
- Night mode: You can take better pictures at night.
- Frame shot: You can apply 10 kinds of frame effects
when taking a picture.
- Delay timer: Using this function you can delay the
camera shutter time by selecting either None, 3
seconds, 5 seconds or 10 seconds.
- Effect: Using this menu you can select special
camera effect by selecting either None,
Black & White, Negative, Sepia.
- Shutter sound: You can select the camera shutter
sound by selecting either No sound, Sound1 or
Sound2.
- Memory In use: You can choose the internal
(Phone) flash memory or the external flash
memory.
My stuff
3. Taking a Picture
- Adjust the camera position so that object is in the
center of the screen, and then press the Take key
to take a picture of the object. A taken picture
saved in the internal (phone)flash memory or the
external flash memory. To view existing taken
pictures, select album soft menu. Then the Picture
album is launched, and displays existing pictures
as thumbnails. Move to a desired picture to view,
and select [View: View] to view the picture. You
can also send a selected picture to the other party
through the MMS or Email service by pressing the
Send key in the thumbnail list screen.
Camcorder [Menu 6-2]
1. This function is selected when you select 2.
Camcorder from the Multimedia album keys in 1
Camera mode.
2. Environment Settings
- Press the [Options] key.
- Quality: You can select the desired quality of video by
selecting either Super fine, Fine or Normal (just as you
can in Camera)
- Flash: Select either Always on (always use flash), When
recording (only when recording a picture) and Off (do
not use flash).
- Zoom: Same as Camera
- Brightness: Same as Camera
- White balance: Using this function you can adjust the
tone of the background picture according to the weather
by selecting either Auto, Daylight, Cloudy, Shade or
Fluorescent.
- Night mode: You can take better video images at night.
- Effect: Same as Camera
- Recording time: You can select recording times of 30
seconds, 1 minute, 2 minutes, 5 minutes, Unlimited.
- Memory In use: You can choose the internal (Phone)
flash memory or the external flash memory.
3. Recording a video
Put the camcorder where you want it and press the
“Rec.” key to start recording. Press the “Stop” key
again to stop recording.
The recorded video is saved in the gallery. To view
the recorded video, select [List], select a desired
video thumbnail from the video list and press “Play”.
44
User Guide
Multimedia [Menu 6]
User Guide
45
Schedule [Menu 7-1]
Memo [Menu 7-2]
Date finder [Menu 7-3]
Date counter [Menu 7-4]
Settings [Menu 7-5]
Organiser [Menu 7]
This is a addressbook function to record and manage
contact addresses. Using the Addressbook
Management menu, you can register new contact
addresses, or can search for desired addresses by
name, phone number, or groups.
Add to Phonebook [Menu 8-1]
You can register a new contact address.
You can input the name, phone numbers, Email
addresses, assign it to groups, include memo,
company / party, position / occupation, home address,
office address, home page URL, ring tone, and avatar
or image (photograph) in the contact address
information. You can input and manage contact
addresses depending on the memory usage.
Search to Phonebook [Menu 8-2]
Performs the contact address search function. The
search operation is performed based on a name as a
default. The current search method and results found
are displayed in the Search window. On the right side
of the screen, an image or avatar registered to the
selected contact address appears. You can make a
phone call or send a message to the selected phone
number. An address search can be performed based
on the phone number, the Email address or group
information.
No. of phonebook [Menu 8-3]
Phonebook settings [Menu 8-4]
8.4.1 Display data
Determines where phone book data is stored. You can
select mobile phone memory, USIM (SIM) card, or both
of them. Handset & SIM is the default setting. You can
change the setting by using the up and down keys.
8.4.2 Copy all
You can copy contact address information from the
phone memory to the USIM (SIM) or from USIM (SIM)
to the phone memory. You can copy just selected items
or all of them.
46
User Guide
Phonebook [Menu 8]
User Guide
47
8.4.3 Move all
You can move contact address information from the
phone memory to the USIM (SIM) or from the USIM
(SIM) to the phone memory. You can move just
selected items or all of them.
8.4.4 Clear all address book
Clears contact address information. You can delete a
contact address saved in the mobile phone memory as
well as in the USIM (SIM) card.
8.4.5 Show image/avatar
You can select whether checking only name or name
with image on the list of search or contacts.
- On: name with image on the list of search or contacts
- Off: only name on the list of search or contacts
Group settings [Menu 8-5]
Using this menu you can manage group information.
There are 4 default groups: Family, Friends,
Colleagues and School.
You can add, edit and delete groups. You can also
assign an image and a ring tone for each group.
When a bell for a number is not specified, a call from
the number sounds the group ring tone assigned to the
number for the group.
Own number [Menu 8-6]
You can save up to 3 own numbers being used in the
USIM card, and send the number to another person
through Card.
Phonebook
48
User Guide
Alarm clock [Menu 9-1]
If you set up alarm, [Alarm icon] appears on the
Indicator bar. The specified alarm sounds at the
scheduled time. Press the [OK] key to stop the alarm,
and the alarm is released. Press the [Right key] or
[Snooze], choose the snooze interval, the alarm sound
is stopped and resumed after selected Snooze
duration. You can configure up to 5 alarms.
1. Select your desired alarm to configure in the alarm
list. If there is no alarm, press the right soft key [Add]
to add a new alarm.
2. Set/Cancel alarm: Set or cancel the alarm using the
options for specifying the alarm off or by choosing
the alarm time.
3. Input alarm time: Input your desired alarm time by
specifying Hour and Minute. Choose either ‘AM’ or
‘PM’ visible if 12 hour format is specified for the
phone.
4. Select repeat mode: Select desired repeat mode
using the left and right direction keys or from the list
pressing the center key.
5. Select bell: Select the bell to ring at the alarm time,
using the left addright direction keys or from the
pressing the center key.
6. Input memo: Input alarm name.
7. Select the Power off: Select the Power off option to
enable or disable the alarm at Phone Power off.
When you have completed configuration, press the
[ ] key [Done] to save the changed alarm
configuration.
Data exchange [Menu 9-2]
Calculator [Menu 9-3]
You have a calculator function that provides 4
calculations of addition, subtraction, multiplication and
division.
You can input numbers using the number keys, and
operators using the up, down, left, and right direction
key. You can input a decimal point by pressing the left
soft key. Whenever you press the Clear key,
characters are sequentially deleted in reverse
direction.
When calculation is completed and the result is
displayed on the screen, pressing a number or decimal
point (.) clears the previous result and the calculator
Tools [Menu 9]
User Guide
49
waits for new input, even though you did not press AC
key. When calculation is completed and the result is
displayed on the screen, pressing a symbol saves the
result into the symbol, and continues calculation.
Unit converter [Menu 9-4]
Using this menu, users can convert the unit of 7
weights and measures of currency, surface, length,
weight, temperature, volume and velocity.
9.4.1 Currency
1. Select the Currency menu.
2. Users can set a currency exchange rate using
[Rate].
3. Input currency rates for upto 5 currencies equivalent
to USD and then press [Save]. Then you can convert
to one currency to another.
4. You can view the value of between 5 currency units
5. Press [Reset] to clear the current input filed.
6. To exit currency conversion function, press the
[Back] key.
9.4.2 Surface
1. Select Surface menu.
2. Select desired unit to convert using [Unit].
3. Input standard unit and view converted value.
4. Press [Reset] to clear the current input filed, and
locate the cursor in the input field.
5. To exit Surface conversion function, press [Back]
key.
9.4.3 Length
1. Select length menu.
2. Select the desired unit to convert using [Unit].
3. Input the standard unit and view your converted
value.
4. Press [Input again] to clear the current input filed.
5. To exit length conversion function, press [Back] key.
9.4.4 Weight
1. Select Weight menu.
2. Select desired unit to convert using [Unit].
3. Input standard unit and view converted value.
Tools
50
User Guide
4. Press [Reset] to clear the current input filed, and
locate the cursor in the input field.
5. To exit Weight conversion function, press [Back]
key.
9.4.5 Temperature
1. Select Temperature menu.
2. Position the cursor in desired unit by using up or
down arrow key.
3. Input standard unit and view converted value.
4. Press [Reset] to clear the current input field.
5. To exit Temperature conversion function, press
[Back] key.
9.4.6 Volume
1. Select Volume menu.
2. Select desired unit to convert using [Unit].
3. Input standard unit and view converted value.
4. Press [Reset] to clear the current input filed.
5. To exit volume conversion function, press [Back]
key.
9.4.7 Velocity
1. Select Velocity menu.
2. Select desired unit to convert using [Unit]
3. Input standard unit and view converted value.
4. Press [Reset] to clear the current input field
5. To exit Velocity conversion function, press [Back]
key.
World time [Menu 9-5]
The World time function provides time information on
major cities worldwide.
1. You can view the time of desired country or city
using the left and right key.
2. You can select a desired city as a base using
[Home].
3. The home city selected in world time is the base for
daylight saving calculation for time.
Tools
User Guide
51
Stop watch [Menu 9-6]
StopWatch allows to count the no of seconds elapsed
after an event started.
1. Press [Go] to start the stopwatch.
2. Press [Stop] to stop the stopwatch and view the
measured duration of time.
3. Press [Go] to resume the stopwatch.
4. Press [Lap] during operation to record the duration
of time at the moment, and continue the stopwatch.
5. Users can save up to 20 time records by pressing
[Lap]. If the number of recorded time exceeds 20, the
oldest one is deleted.
6. Press Details to see recorded Lap timings. Press
[Reset] to initialise the stopwatch.
SIM service [Menu 9-7]
This menu depends on SIM and the network service.
Mini SD card [Menu 9-8]
This menu allows you to view Photos, Pictures, Sounds
and Music in the SD card. If the external memory is not
available, a pop up message “Please insert external
memory” is dis-played.
Tools
52
User Guide
In Sound menu, you can adjust and customise the ring
tone for different events, situations or caller groups.
Ring tone volume [Menu 10-1]
This menu allows to select the desired ring tone from
the list. You can set the various ring tone depending on
call and message types.
Effect tone volume [Menu 10-2]
This menu allows to set the volume of effect tone.
Select ring tone [Menu 10-3]
This menu allows to select the desired ring tone from
the list. You can set the various ring tone depending on
call and message types.
Select effect tone [Menu 10-4]
This menu allows to select the desired effect tone from
the list. You can adjust the tone when you switch on/
off the phone, press the keypad, or open/ close the flip.
Vibration [Menu 10-5]
This menu allows to set the vibration mode when you
receive a call or a message.
Manner setting [Menu 10-6]
This menu allows to set manner mode.
Mail ring duration [Menu 10-7]
This menu allows to set the ring tone duration when
you receive the mail.
Set mute second [Menu 10-8]
Hold/On hold tone [Menu 10-9]
Sound [Menu 10]
User Guide
53
In this menu, you can configure screen display options
including LCD settings andtheme.
Main display [Menu 11-1]
You can configure the Main LCD background by theme
selection.
11.1.1 Home screen
You can select an Main LCD background to display in
idle mode. You can also select the clock and calendar
type to appear in idle mode.You can also configure the
font size and color of the clock displayed on the Main
LCD idle screen.
11.1.2 Incoming call
You can select an Main LCD background to display
when an incoming call arrives. The configuration is
applied to both voice and video calls.
11.1.3 Outgoing call
You can select an Main LCD background to display
when dialling a call. The configuration is applied to
both voice and video calls.
Front display [Menu 11-2]
You can select an Front LCD background to display
when an incoming call arrives. The configuration is
applied to both voice and video calls.
11.2.1 Home screen
You can select an Front LCD background to display in
idle mode.
11.2.2 Incoming call
You can select an Front LCD background to display
when an incoming call arrives. The configuration is
applied to both voice and video calls.
Font [Menu 11-3]
When number keys are pressed for call connection in
idle state, the size and color of displayed number can
be configured.
Display [Menu 11]
54
User Guide
Backlight [Menu 11-4]
It allows the user to configure the backlight duration
settings for Main LCD, Sub LCD and Keypad.Default
settings:
- Main LCD duration 10 seconds
- Sub LCD duration 10 seconds
- Keypad backlight duration 10 seconds
Contrast [Menu 11-5]
This menu allows to set the LCD contrast.
Colour scheme [Menu 11-6]
1. It allows the user to configure the handset color
theme like menus, list , soft menu, Input boxes.
2. User can also preview the colour theme.
Display
User Guide
55
Call / Answer [Menu 12-1]
12.1.1 Call history
You can check the record of missed, received, and
dialled calls only if the network supports the Calling
Line Identification (CLI) within the service area.
The number and name (if available) are displayed
together with the date and time at which the call was
made. You can also view call times.
12.1.1.1 Missed calls
This option lets you view the last 10 unanswered calls.
You can also:
• View the number if available and call it, or save it in
the Address Book
• Enter a new name for the number and save both in
the Address Book
• Send a message by this number
• Delete the call from the list
12.1.1.2 Received calls
This option lets you view the last 10 incoming calls.
You can also:
• View the number if available and call it, or save it in
the Address Book
• Enter a new name for the number and save both in
the Address Book
• Send a message by this number
• Delete the call from the list
12.1.1.3 Dialled calls
This option lets you view the last 20 outgoing calls
(called or attempted).
You can also:
• View the number if available and call it or save it in
the Address Book
• Enter new name for the number and save both in the
Address Book
• Send a message by this number
• Delete the call from the list
12.1.1.4 Delete recent calls
Allows you to delete Missed calls and Received calls
lists. You can delete Dialled calls and All calls lists at
one time.
Settings [Menu 12]
56
User Guide
12.1.2 Call duration
Allows you to view the duration of your incoming and
outgoing calls. You can also reset the call times. The
following timers are available:
• Last call: Length of the last call.
• All calls: Total length of all calls made and incoming
calls since the timer was last reset.
• Received calls: Length of the incoming calls.
• Dialled calls: Length of the outgoing calls.
• Reset all: Allows you to clear the length of all calls by
pressing the left soft key [Yes].
12.1.3 Anonymous caller
12.1.4 Auto answer
This function will be activated only when your phone is
connected to the headset.
• Off: The phone will not answer automatically.
• After 5 secs: After 5 seconds, the phone will answer
automatically.
• After 10 secs: After 10 seconds, the phone will
answer automatically.
12.1.5 Reject / Accept call
This menu allows to accept or reject a call depending
on the condition.
12.1.6 Memory reject call
This menu allows to reject a call numbers which are
not saved in phonebook memory.
12.1.7 Answer mode setting
You can set the anwer mode when you try to receive a
call.
12.1.8 Auto redial
On
When this function is activated, the phone will
automatically try to redial in the case of failure to
connect a call.
Off
Your phone will not make any attempts to redial when
the original call has not connected.
Settings
User Guide
57
Call feature [Menu 12-2]
12.2.1 Reconnect alarm
12.2.2 Quality alarm
12.2.3 Minute minder
If you select On, you can check the call duration by
deep sound every minute during a call.
12.2.4 Prefix dialing
You can restrict your outgoing calls to selected phone
numbers. The numbers are protected by your PIN2
code.
• Activate
You can restrict your outgoing calls to selected phone
numbers.
• Cancel
You can cancel fixed dialling function.
• Number list
You can view the number list saved as Fixed dial
number.
12.2.5 Auto assist setting
[Menu 12-2-5]
This menu is related to World call of NTT DoCoMo. If
you activate this function, you can make a world call of
NTT DoCoMo without inputting +.
Video phone [Menu 12-3]
Date & Time [Menu 12-4]
Although the current time is automatically configured
when the phone is registered to the network, users
can configure time and date directly using ‘Date &
Time’ menu. The time configured by user is valid only
while the phone is turned on.
12.4.1 Time
Scroll down to select the hour indication format Off,
Cuckoo clock or Chime bell.
Settings
1. Select the ‘Time’ item from the Date & Time list, and
then press [OK] [Select].
2. Move to your desired field, ‘Hour’, ‘Minute’,
'Second', or ‘AM’/‘PM’ field using the navigation
keys.
3. Input ‘Hour’, ‘Minutes’ and 'Second' using the
number keys.
4. Press the [OK] or [Confirm] key to set the time with
the specified value.
12.4.2 Date
1. Select ‘Date’ item from the Date & Time list, and then
press [OK] [Select].
2. Select date format using Left and Right navigation
keys.
3. Input ‘Year’, ‘Month’, and ‘Day’ using the number
keys.
4. Press [Done] [Confirm] to set the date with the
specified value.
12.4.3 Auto update data/time
When Auto Update is configured to On, the time and
date are automatically updated according to the
current location. If Confirm first is selected, time and
date update are confirmed before the automatic
update.
When Auto update is Off, the option selected in
daylight saving will not make any effect.
12.4.4 Daylight saving
Configuring Daylight saving to On Applies daylight
saving time for the currently selected home city in
world time. If the home city does not support summer
time, Daylight saving can not be set to On.
Network [Menu 12-5]
12.5.1 Network selection
1. If you select Network selection you can select either
Automatic or Manual.
2. If you select Automatic, connection continues
according to the Automatic network selection
procedures.
3. If you configure the Network mode to GSM-
preferred, UMTS-preferred or Automatic, all the
currently available PLMN lists are found, and you
can select one item from the list for registration.
If you configure the Network mode to GSM only, the
58
User Guide
Settings
User Guide
59
currently available UMTS PLMN list is found, and
you can select one item from the list for registration.
If you configure the Network mode to UMTS only,
the currently available GSM PLMN list is found, and
you can select one item
12.5.2 Preferred lists
1. Select Preferred lists to display the preferred list
saved in the current SIM card.
2. You can edit and save a preferred list in the SIM
card by selecting the menu when the preferred list is
displayed.
- Add new: Adds an item selected from the popup list to
the preferred list.
- Delete: Deletes the value of the preferred list item.
- Move down: Moves the preferred list item down.
Access points [Menu 12-6]
This menu shows the access point list. You can
register, delete and edit by using the Option Menu.
However, you cannot delete or edit default
configurations provided by Telefonica Movistar .
You can edit the following configuration items by
selecting the right soft key.
Connection title Access Point profile name
Bearer Choose the bearer from the list.
(Default is “Packet Switching”)
Authentication Choose the authentication from the
list. (Default is “No auth”)
Username Information provided by Service
Provider.
Password Information provided by Service
Provider.
APN APN name to access network.
Information provided by service
provider.
Traffic Class Choose the Traffic Class from the
list. (Default is “Subscribed”)
Connection title Access Point profile name
Settings
60
User Guide
- Press “Save” key to save any configuration changes.
Security [Menu 12-7]
You can activate a PIN code. When it is activated, a
window asking you to enter the PIN code appears
when you turn on the phone so as to prevent
unauthorized use of the phone.
12.7.1 PIN code request
You can activate a PIN (Personal Identification
Numeric). You can check the current status of
configuration from the status bar.
PIN request and release procedures
1. Select ‘PIN request’ item from the list, and press
[OK]. Then a window allowing you to select ‘On’ or
‘Off’ appears.
- Select ‘On’/‘Off’ from the list, press [OK], and input the
current PIN code to set the PIN request. If ‘PIN request’
is already On/Off, an “Already activated”/“Already
cancelled” message will be displayed.
2. 3 incorrect PIN code entries in the PIN code input
window would invalidate the PIN code. In this case,
you have to input the PUK (PIN Unblock Key) code to
configure the PIN code again.
3. The maximum allowed numeric of attempts of PUK
input is 10 times. 10 occasions of incorrect PUK
entries would limit the mobile phone use.
Press the Back key in the PIN code input window to
return to the previous step.
12.7.2 Handset lock
You can lock your mobile phone to prevent it being
used by other people. The following 4 lock functions
are provided.
- When switching on: Whenever the mobile phone is
turned on.
Req. Max UL Bitrate Choose the Request Maximum
Upload Bitrate from the list. (Default
is “Subscribed”)
Req. Max DL Bitrate Choose the Request Maximum
Download Bitrate from the
list.(Default is “Subscribed”)
Item Description
Enable PIN Request You have to input the PIN code each
time the mobile phone is turned on.
Disable PIN Request You do not have to input the PIN code
when the mobile phone is turned on.
Settings
User Guide
61
- If SIM Changed: When the mobile phone’s SIM card
has been changed.
- Immediate: Locks the phone immediately.
- None: Cancels lock function.
12.7.3 Change codes
You can change PIN, PIN2, the mobile phone
password and the call barring password.
12.7.3.1 PIN code
PIN is the abbreviation of Personal Identification
Numeric, and is used to restrict the use of an
unauthenticated user.
PIN Password Change Procedure
1. Select ‘PIN’ from the ‘Change code’ list and then
press [Select].
2. Input the current PIN,and press [Select].
3. Input the new PIN,and press [Select].
4. Input the new PIN once again,and press [Select ].
- If the PIN is different from that of step 3, the procedure is
restarted from step 3.
5. When the PIN is properly changed, a “Successfully
Changed” message as well as new PIN code
appears. With an incorrect PIN input in step 2, the
procedure is restarted from step 2, and the
remaining allowed numeric of input attempts is
decreased by 1.
6. Press the Back key in the PIN code input window to
return to the previous step.
* 3 incorrect PIN code entries in the PIN code input
window would invalidate the PIN code. In this case,
you have to input the PUK (PIN Unblock Key) code to
configure the PIN code again. The maximum allowed
numeric of attempts of PUK input is 10 times. 10
occasions of incorrect PUK entries would limit the
mobile phone use.
12.7.3.2 PIN2 code
PIN2 is the abbreviation of Personal Identification
Numeric 2, and is used to restrict the use of
unauthenticated users like PIN. PIN2 numeric change
procedure is the same to that of PIN. 3 incorrect PIN2
code entries would invalidate the PIN2 code. In this
case, you have to input PUK2 to use the PIN2 code
again. The maximum allowed numeric of attempts of
PUK2 input is 10 times, like PUK1. 10 incorrect PUK2
entries would invalidate the PUK2.
12.7.3.3 Security code
Settings
62
User Guide
Character input [Menu 12-8]
Power on / off time [Menu 12-9]
If you set this menu, the phone will switch on/ off
automatically depending on setting the time.
Languages [Menu 12-10]
This function changes the language used in the phone.
Automatic
English
Français
Nederlands
Deutsch
Italiano
Español
Others [Menu 12-11]
Settings
User Guide
63
QHow do I view the list of outgoing calls, incoming
calls and missed calls?
APress .
QHow do I clear all call history?
APress the left soft key and then .
QHow do I view all numbers saved in the memory?
APress the right soft key and then .
Qdoes not disappear from the screen.
ACheck whether you are in a service area. If you
continue to
see , turn off the power and wait for
approximately 2 minutes before turning it back on. If
there is no change, relocate to another area and
check again.
QConnection is poor or is not audible in certain areas.
AIn certain areas, signal strength can vary
dramatically.
Try moving to a different location. Heavy network
traffic may affect the ability to connect, or the
stability of the call.
QConnection is poor even when established.
AIn certain areas, signal strength can vary
dramatically.
Try moving to a different location. Heavy network
traffic my affect the ability to connect, or the
stability of the call.
QLCD does not turn on.
ARemove and replace the battery and turn on the
power. If the phone still does not turn on, charge the
battery and try again.
Please check to see if any problem which you may have with your phone is described here before taking it for
service or calling a service engineer.
Troubleshooting
QAn echo can be heard during connection with a
certain telephone in a certain area.
AIt is called ‘Echo Phenomenon’. It occurs if the
volume is too high or caused by special properties
(semi electronic telephone exchange) of the
machine on the other end.
QThe phone gets warm.
ADuring long calls, or if games/Internet are used for a
long time, the phone may become hot. This is
perfectly normal and has no effect upon the life of
the product or performance.
QThe bell does not ring, or lamp or LCD blinks only.
AThe phone is set to ‘Vibrate’or ‘Silent’ in the Profiles
menu. Please select ‘General’ or ‘Loud’
QStandby duration of the phone gradually becomes
shorter.
ABatteries have a limited life. When the battery lasts
for half its original time, it requires replacement.
Only use authorised replacement parts.
QUsage time of battery becomes shorter.
AIf the battery time is short, it may be due to the user
environment, or large volume of calls, or weak
signals.
QNo number is dialled when you recall a phonebook
entry.
ACheck that the numbers have been saved correctly,
by using the phonebook Search feature. Resave
them, if necessary.
QYou cannot be contacted.
AIs your phone switched on ( pressed for more
than three seconds)? Are you accessing the right
cellular network? Have you set an incoming call
barring option?
QI cannot find the lock, PIN, or PUK code, or
password?
AThe default lock code is ‘0000’. If you forget or lose the
lock code, contact your phone dealer. If you forget or
lose a PIN or PUK code, or if you have not received
such a code, contact your network service provider.
64
User Guide
Troubleshooting
User Guide
65
Supplied adapter
This adapter lets you charge
the while at home or in the
office.
Battery
Standard battery is available.
Headset
Allows hands-free operation.
Includes earpiece and
microphone.
Data cable kit
Connects your phone to a PC.
On the CD-Rom, there are
programs like:
* When installing, make sure to connect to the PC after
your phone and the cable have been connected.
Otherwise, your PC may problem.
There are a variety of accessories available for your mobile phone. You can select these according to your personal
communication requirements. Consult your local dealer for availability.
Accessories
66
User Guide
nNote
The programs listed above may vary depending on the version
of the CD and the market.
nNote
• Always use genuine LG accessories. Failure to do this may
invalidate your warranty.
• Accessories may be different in different regions; please
check with our regional service company or agent for further
enquiries.
Accessories
Appendix. RF Exposure Statement
WARNING! Read this information before operating the phone.
In August 1996, the Federal Communications (FCC) of the United States, with its action in Report
and Order FCC 96-326, adopted an updated safety standard for human exposure to radio
frequency(RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines
are consistent with the safety standard previously set by both U.S. and international standards
bodies.
The design of this phone complies with the FCC guidelines and these international standards.
CAUTION
Use only the supplied and approved antenna. Use of unauthorized antennas or modifications could
impair call quality, damage the phone, void your warranty and/or result in violation of FCC
regulations.
Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with skin,
a minor burn may result. Contact your local dealer for a replacement of antenna.
Body Worn Operation
This device was tested for typical body-worn operations with the back of the phone kept 1.5
cm from the body. To comply with FCC RF exposure requirements, a minimum separation
distance of 1.5 cm must be maintained between the user’s body and the back of the phone,
including the antenna, whether extended or retracted. The use of belt-clips, holsters, and
similar accessories should not containing metallic components in its assembly. The use of
accessories that do not satisfy these requirements may not comply with FCC RF exposure
requirements, and should be avoided.
For Your Safety FCC Part 15 Class B Compliance
This device and its accessories comply with part 15 of FCC rules. Operation is subject to the
following two conditions: (1) This device and its accessories may not cause harmful
interference, and (2) this device and its accessories must accept any interference received,
including interference that may cause undesired operation.
Appendix 2. Consumer Information on SAR
(Specific Absorption Rate)
This Model Phone Meets the Government’s Requirements for Exposure to Radio Waves. Your
wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed
the emission limits for exposure to radio frequency (RF) energy set by the Federal
Communications Commission of the U.S. Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for the general population. The guidelines
are based on standards that were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The standards include a substantial safety
margin designed to assure the safety of all persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of measurement known as the
Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are
conducted using standard operating positions specified by the FCC with the phone transmitting at
its highest certified power level in all tested frequency bands. Although SAR is determined at the
highest certified power level, the actual SAR level of the phone while operating can be well below
the maximum value. Because the phone is designed to operate at multiple power levels to use only
the power required to reach the network, in general, the closer you are to a wireless base station
antenna, the lower the power output.
Before a phone model is available for sale to the public, it must be tested and certified to the FCC
that it does not exceed the limit established by the government-adopted requirement for safe
exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the
body) as required by the FCC for each model.
The highest SAR value for this model phone when tested for use at the ear is 0.28W/kg and
when worn on the body, as described in this user guide, is 0.524 W/kg (body-worn measurements
differ among phone models, depending upon available accessories and FCC requirements). While
there may be differences between SAR levels of various phones and at various positions, they all
meet the government requirement for safe exposure.
The FCC has granted an Equipment Authorization for this model phone with all reported SAR
levels evaluated as in compliance with the FCC RF emission guidelines. SAR information on this
model phone is on file with the FCC and can be found under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on FCC ID BEJL600i.
