LG Electronics USA LG410G Cellular/PCS GSM Phone User Manual LG410G 1010
LG Electronics USA Cellular/PCS GSM Phone LG410G 1010
Users Manual
LG410G User Guide
- ENGLISH
Part 15.21 statement
" Change or Modifications that are not expressly approved by the manufacturer could void
the user's authority to operate the equipment. "
Part 15.105 statement
This equipment has been tested and found to comply with the limits for a class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. if this
equipment does cause harmful interference or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected
- Consult the dealer or an experienced radio/TV technician for help.
8
For Your Safety
Important Information
This user guide contains important information on the use and
operation of this phone. Please read all the information
carefully for optimal performance and to prevent any damage
to or misuse of the phone. Any changes or modifications not
expressly approved in this user guide could void your warranty
for this equipment.
Before You Start
Safety Instructions
WARNING! To reduce the possibility of electric shock, do not
expose your phone to high humidity areas, such as the
bathroom, swimming pool, etc.
Always store your phone away from heat. Never store your
phone in settings that may expose it to temperatures less than
32°F or greater than 104°F, such as outside during extreme
weather conditions or in your car on a hot day. Exposure to
excessive cold or heat will result in malfunction, damage
and/or catastrophic failure.
Be careful when using your phone near other electronic
devices. RF emissions from your mobile phone may affect
nearby in adequately shielded electronic equipment. You
should consult with manufacturers of any personal medical
devices such as pacemakers and hearing aides to determine if
they are susceptible to interference from your mobile phone.
Turn off your phone in a medical facility or at a gas station.
Never place your phone in a microwave oven as this will
cause the battery to explode.
IMPORTANT! Please read the TIA SAFETY INFORMATION on
page 78 before using your phone.
Safety Information
Read these simple guidelines. Breaking the rules may be
dangerous or illegal. Further detailed information is given in this
user guide.
]Never use an unapproved battery since this could damage
the phone and/or battery and could cause the battery to
explode.
]Never place your phone in a microwave oven as it will
cause the battery to explode.
]Do not dispose of your battery by fire or with hazardous or
flammable materials.
]Make sure that no sharp-edged items come into contact
with the battery. There is a risk of this causing a fire.
]Store the battery in a place out of reach of children.
]Be careful that children do not swallow any parts such as
rubber plugs (earphone, connection parts of the phone,
etc.). This could cause asphyxiation or suffocation.
9
For Your Safety
]Unplug the power cord and charger during lightning storms
to avoid electric shock or fire.
]When riding in a car, do not leave your phone or set up the
hands-free kit near to the air bag. If wireless equipment is
improperly installed and the air bag is activated, you may be
seriously injured.
]Do not use a hand-held phone while driving.
]Do not use the phone in areas where its use is prohibited.
(For example: aircraft).
]Do not expose the battery charger or adapter to direct
sunlight or use it in places with high humidity, such as a
bathroom.
]Never store your phone in temperatures less than- 4°F or
greater than 122°F.
]Do not use harsh chemicals (such as alcohol, benzene,
thinners, etc.) or detergents to clean your phone. There is a
risk of this causing a fire.
]Do not drop, strike, or shake your phone severely. Such
actions may harm the internal circuit boards of the phone.
]Do not use your phone in high explosive areas as the phone
may generate sparks.
]Do not damage the power cord by bending, twisting, pulling,
or heating. Do not use the plug if it is loose as it may cause
a fire or electric shock.
]Do not place any heavy items on the power cord. Do not
allow the power cord to be crimped as it may cause fire or
electric shock.
]Do not handle the phone with wet hands while it is being
charged. It may cause an electric shock or seriously
damage your phone.
]Do not disassemble the phone.
]Do not place or answer calls while charging the phone as it
may short-circuit the phone and/or cause electric shock or
fire.
]Only use the batteries, antennas, and chargers provided by
LG. The warranty will not be applied to products provided by
other suppliers.
]Only authorized personnel should service the phone and its
accessories. Faulty installation or service may result in
accidents and consequently invalidate the warranty.
]Do not hold or let the antenna come in contact with your
body during a call.
]An emergency call can be made only within a service area.
For an emergency call, make sure that you are within a
service area and that the phone is turned on.
10
For Your Safety
FCC RF Exposure Information
WARNING! Read this information before operating the phone.
In August 1996, the Federal Communications (FCC) of he United
States, with its action in Report and Order FCC 96-326, adopted
an updated safety standard for human exposure to radio
frequency (RF) electromagnetic energy emitted by FCC
regulated transmitters. Those guidelines are consistent with
the safety standard previously set by both U.S. and
international standards bodies.
The design of this phone complies with the FCC guidelines and
these international standards.
CAUTION
Use only the supplied and approved antenna. Use of
unauthorized antennas or modifications could impair call
quality, damage the phone, void your warranty and/or result in
violation of FCC regulations. Do not use the phone with a
damaged antenna. If a damaged antenna comes into contact
with skin, a minor burn may result. Contact your local dealer
for a replacement antenna.
Body-worn Operation
This device was tested for typical body-worn operations with
the back of the phone kept 0.79 inches (2cm) between the
user’s body and the back of the phone. To comply with FCC RF
exposure requirements, a minimum separation distance of 0.79
inches(2cm) must be maintained between the user's body
and the back of the phone. Third-party belt-clips, holsters, and
similar accessories containing metallic components should not
be used. Body-worn accessories that cannot maintain 0.79
inches(2cm) separation distance between the user's body
and the back of the phone, and have not been tested for typical
body-worn operations may not comply with FCC RF exposure
limits and should be avoided.
11
For Your Safety
Vehicle Mounted External Antenna
(optional, if available)
A minimum separation distance of 8 inches (20cm) must be
maintained between the user/bystander and the vehicle
mounted external antenna to satisfy FCC RF exposure
requirements. For more information about RF exposure, visit
the FCC website at www.fcc.gov
FCC Part 15 Class B Compliance
This device and its accessories comply with part 15 of FCC
rules. Operation is subject to the following two conditions:
(1) This device and its accessories may not cause harmful
interference, and (2) this device and its accessories must
accept any interference received, including interference that
may cause undesired operation.
Cautions for Battery
]Do not disassemble.
]Do not short-circuit.
]Do not expose to high temperature: 60°C (140°F).]
]Do not incinerate.
Battery Disposal
]Please dispose of your battery properly or bring to your
local wireless carrier for recycling.
]Do not dispose in fire or with hazardous or flammable
materials.
Adapter (Charger) Cautions
]Using the wrong battery charger could damage your phone
and void your warranty.
]The adapter or battery charger is intended for indoor use
only.
Do not expose the adapter or battery charger to direct sunlight
or use it in places with high humidity, such as the bathroom.
General Functions
Making a Call
1. Make sure your phone is powered
on.
2. Enter a phone number including
the area code. To edit a number on
the display screen, simply press the
Clear key to erase one digit at a
time.
]Press and hold the Clear key to
erase the entire number and return
to the idle screen.
3. Press the [SEND] key or left soft
key to call the number.
4. When finished, press the
[PWR/END] key.
Making a Call by Send Key
2. Press the [SEND] key, and the
most recent incoming, outgoing
and missed phone numbers will be
displayed.
2. Use , to highlight a
number.
3. Press [SEND] key to call the
highlighted number.
Making International Calls
1. Press and hold the key and
the international access character
‘+’ will appear.
2. Enter the country code, area code,
and the phone number.
3. Press the [SEND] key.
Ending a Call
When you have finished a call, press
the [PWR/END] key.
Making a Call From the
Contact List
You can store names and phone
numbers in the SIM, as well as in the
phone memory from the Contacts
menu. (Menu 2.2)
You can dial a number by simply
selecting a name in the contacts and
pressing the [SEND] key.
12
Adjusting the Volume
During a call, if you want to adjust the
earpiece volume, use the up/down
navigation key of the phone.
Answering a Call
When you receive a call, the phone
rings or vibrates, and the LED blinks
until the call is answered. If the caller
can be identified, the caller's phone
number (or name if stored in your
Contacts) is displayed on the screen.
1. Press the [SEND] key or the
Left Soft Key Accept to answer an
incoming call. If the answer mode
has been set to Any Key (Menu
9.4.1), any key press will answer a
call except for the [PWR/END]
Key or the Right Soft Key Silent.
2. End the call by closing the phone or
pressing the [PWR/END] key.
Vibrate Mode (Quick)
Vibrate Mode can be activated by
pressing and holding down the
[Star] key.
Signal Strength
If you are inside a building, being near
a window may give you better
reception. You can see the strength of
your signal by the signal indicator on
your phone’s display screen.
Entering Text
You can enter alphanumeric characters
by using the phone’s keypad. For
example, storing names in the Address
Book, writing a message, or creating
scheduling events in the Calendar all
require entering text.
The following text input methods are
available in the phone.
Notice
You can answer a call while using the
Contacts or other menu features.
General Functions
General Functions
13
T9 Mode
This mode allows you to enter words
with only one keystroke per letter.
Each key on the keypad has more than
one letter. The T9 mode automatically
compares your keystrokes with an
internal linguistic dictionary to
determine the correct word, thus
requiring far fewer keystrokes than the
traditional ABC mode. You can set T9
input mode to On or Off by selecting
Right Soft Key Options, then 3 Set T9
from the text message window screen.
ABC Mode
This mode allows you to enter letters
by pressing the key labeled with the
required letter once, twice, three or
four times until the letter is displayed.
123 Mode (Numbers Mode)
Type numbers using one keystroke per
number. To change to 123 mode in a
text entry field, press key until 123
mode is displayed.
Symbol Mode
This mode allows you to enter special
characters. Press [Star] Key to
access Symbols.
Changing the Text Input
Mode
Change the text input mode by
pressing . You can check the
current text input mode in the upper
right corner of the screen.
Using the T9 Mode
The T9 predictive text input mode
allows you to enter words easily with a
minimum number of key presses. As
you press each key, the phone begins
to display the characters that it thinks
you are typing based on a built-in
dictionary. As new letters are added,
the word changes to reflect the most
likely candidate from the dictionary.
Notice
T9 Mode is set to Off by default.
General Functions
14
1. When you are in the T9 predictive
text input mode, start entering a
word by pressing keys
to .
]The word changes as letters are
typed - ignore what’s on the
screen until the word is typed
completely.
]If the word is still incorrect after
typing it completely, press the
,keys to cycle through
the other word options.
Example: To type the word
"Cook", press 2, 6, 6, 5.
Press , until the word
"Cook" is displayed.
]If the desired word is missing from
the word choices list, add it by
using the ABC mode.
2. Enter the whole word before
editing or deleting any keystrokes.
3. Complete each word with a space
by pressing the key or the right
navigation key.
To delete letters, press the [Clear]
key. Press and hold down the
[Clear] key to erase the letters
continuously.
To switch between English and
Spanish while in T9 Mode, hold down
the [Star] Key for 2 seconds.
Using the ABC Mode
Use the alphanumeric keypad to enter
your text.
1. Press the key labeled with the
required letter:
]Once for the first letter
]Twice for the second letter
]And so on
2. To insert a space, press the key
once. To delete letters, press the
[Clear] key. Press and hold
down the [Clear] key to erase
the letters continuously.
Notice
Refer to the table below for more
information on the characters
available using the keys.
General Functions
15
Using the 123 (Numbers)
Mode
The 123 Mode enables you to enter
numbers in a text message (a
telephone number, for example) more
quickly.
Press the keys corresponding to the
required digits before manually
switching back to the appropriate text
entry mode.
Using the Symbol Mode
The Symbol Mode enables you to
enter various symbols or special
characters.
To enter a symbol, press the key.
Use to highlight the desired
symbol, and press Left Soft Key OK.
T9 dictionary
The T9 dictionary is a feature that
allows the user to add any unique or
personal words to the T9 standard
language database. To add a word to
the T9 Dictionary:
1. Type the word you wish to add while
in T9 mode.
2. Select Left Soft Key Spell.
3. Type the word again, and press Left
Soft Key Save.
OK
Key Characters in Display Order
Upper Case Lower Case
1. , - ? ! ' @ : 1 . , - ? ! ' @ : 1
2A B C 2 a b c 2
3D E F 3 d e f 3
4G H I 4 g h i 4
5J K L 5 j k l 5
6M N O 6 m n o 6
7P Q R S 7 p q r s 7
8T U V 8 t u v 8
9W X Y Z 9 w x y z 9
0Space Key, Space Key,
0 (Long press) 0 (Long press)
16
In-Call Menu
Your phone provides a number of
control functions that you can use
during a call. To access these functions
during a call, press the right soft key
[Options].
During a Call
The menu displayed on the phone's
screen during a call is different than
the default main menu displayed
when in idle screen, and the options
are described below.
Making a Second Call
You can select a number you wish to
dial from the Contacts to make a
second call. Press the right soft key
[Options] then select Contact List.
Use , to highlight the contact
you wish to call, then press .
Swapping Between Two Calls
To switch between two calls, press the
[SEND] key.
Answering an Incoming Call
To answer an incoming call when the
phone is ringing, simply press the
[SEND] key. The phone is also able to
warn you of an incoming call while you
are already on a call. A tone sounds in
the earpiece, and the display will show
that a second call is waiting. This
feature, known as Call Waiting, is only
available if your network supports it.
If Call Waiting is on, you can put the
first call on hold and answer the
second call, by pressing the
[SEND] key.
Rejecting an Incoming Call
You can reject an incoming call by
pressing , or by pressing
Silent, then Reject.
During a call, you can reject an
incoming call by pressing , or
Reject.
Muting the Microphone
You can mute the microphone during
a call by pressing the left soft key
[Mute]. The phone can be unmuted by
pressing the left soft key [Unmute].
When the phone is muted, the caller
cannot hear you, but you can still hear
the caller.
Using the Speakerphone
You can use the integrated
Speakerphone during a call by
pressing the right soft key [Options]
then select Speaker On. The
speakerphone indicator [ ] will
display on the display screen. The
loudspeaker is automatically
deactivated when you end the call.
Conference Calls
The conference service provides you
with the ability to have a simultaneous
conversation with more than one
caller. The conference call feature can
be used only if your network service
provider supports this feature. The
conference call can only be set up
when you have one call active and one
call on hold, meaning both calls must
have been answered. Once a
conference call is set up, calls may be
added, disconnected or separated
(that is, removed from the conference
call but still connected to you) by the
person who set up the conference call.
These options are all available from the
In-Call menu. The maximum number
of callers in a conference call is five.
Once started, you are in control of the
conference call, and only you can add
calls to the conference call.
Warning
Because of the higher volume level,
don’t place the phone too close your
ear while the speakerphone is
enabled.
In-Call Menu
18
In-Call Menu
Making a Second Call
You can make a second call while
currently on a call simply by entering
the second number and pressing
the [SEND] key. When the second
call is connected, the first call is
automatically placed on hold. You can
swap between calls, by pressing
the [SEND] key.
Setting Up a Conference Call
To set up a conference call, place one
call on hold, conference in the second
active call by pressing the right soft key
and select the Join Calls sub menu
option from the Conference Call menu.
Activate the Conference Call
on Hold
To activate a conference call on hold,
press the [SEND] key.
Adding Calls to the
Conference Call
To add a call to an existing conference
call, press the right soft key, and then
select the Join Calls sub menu from the
Conference Call option.
Private Call in a Conference
Call
To have a private call with one caller
from a conference call, press the right
soft key and select the Private Menu
from the Conference Call option. When
the numbers of the callers are
displayed, select the one you wish to
speak in private.
Ending a Conference Call
Currently active conference call can be
disconnected by pressing the
[PWR/END] key.
Menu Tree
19
The following illustration shows the available menu structure and indicates
the:
]
Number assigned to each menu option.
]
Page where you can find the feature description.
1.1 Add Airtime
1.2 Buy Airtime
1.3 My Phone Number
1.4 Airtime Info.
1.5 Airtime Display
1.6 Serial Number
1.7 SIM Number
1.8 Code Entry Mode
1. Prepaid
2.1 Contact List
2.2 New Contact
2.3 Speed Dial List
2.4 Caller Groups
2.5 Copy All Contacts
2.6 Delete All Contacts
2.7 Information
2. Contacts
3. Games
4. Alarm Clock
Menu Tree
20
5.1 New Message
5.2 Inbox
5.3 Drafts
5.4 Outbox
5.5 Sent
5.6 Voicemail
5.7 Templates
5.8 Message Settings
5.9 Check Memory
6.1 Missed Calls
6.2 Dialed Calls
6.3 Received Calls
6.4 All Calls
6.5 Call Duration
5. Messaging
6. Recent Calls
7.1 Games
7.2 Audio & Ringtones
7.3 Graphics
8.1 Alarm Clock
8.2 Calendar
8.3 Record Voice
8.4 Notepad
8.5 Calculator
8.6 Tip Calculator
8.7 World Clock
8.8 Stop Watch
8.9 Unit Converter
8.0 SIM App.
7. My Stuff
8. Tools
Menu Tree
21
9.1 Audio & Ringtones
9.2 Display
9.3 Date & Time
9.4 Call
9.5 Security
9.6 Power Save
9.7 Phone Information
9.8 Reset Default
9. Settings
Prepaid
22
With prepaid service, you buy wireless
network services in advance. Your
phone works the same way it did
before, with some additional features.
You can check your prepaid balance,
add money to your account, and call
customer service.
Prepaid service may not be available
from your wireless service provider.
Contact your service provider for
availability and more information.
In the Prepaid menu, you can activate
and deactivate prepaid service,
replenish your prepaid credits, and
provide other information requested
by the prepaid service provider.
Add Airtime
Menu 1.1
Add Airtime allows you to start an
over-the-air request for additional
airtime.
Buy Airtime
Menu 1.2
Buy Airtime allows you to start an over-
the-air request to purchase additional
airtime.
My Phone Number
Menu 1.3
My Phone Number displays the SIM's
own number.
Airtime Info.
Menu 1.4
Airtime Info displays the amount of
airtime currently available on your
phone, and the due date of your next
payment.
Airtime Display
Menu 1.5
Airtime Display allows your phone to
display your airtime information on the
idle screen. This feature can be turned
on or off.
Serial Number
Menu 1.6
Serial Number displays the Phone's
Serial Number.
Prepaid
23
SIM Number
Menu 1.7
SIM Number displays the SIM Card's
Serial Number.
Code Entry Mode
Menu 1.8
Code Entry Mode will allow the phone
to accept Service Provider - Related
codes in order to add airtime, modify
specific data, and troubleshoot any
issues with the phone. While using
Code Entry Mode, you cannot receive
incoming calls or use event alerts.
Contacts
24
Contact List
Menu 2.1
This menu allows you to save and
manage contact address information.
The Contact List functions allow you to
add a new address or search saved
contact addresses by name.
New Contact
Menu 2.2
This menu allows you to add a new
contact address. You can input contact
address information including name,
phone numbers, email addresses,
group information items, and memos.
Speed Dial List
Menu 2.3
This menu allows you to configure the
speed dial numbers. You can select a
number as a speed dial from 2 to 9.
You can configure speed dial numbers
for any of the 8 numbers for a specific
contact address.
Caller Groups
Menu 2.4
1. Every Group list will be displayed:
Family, VIP, Friends, Colleague,
Group 1, Group 2, No Group.
2. Select the Group name that you
want to manage by pressing the
right soft key [Options].
3. You will see the following submenus
under the predefined groups except
for the No Group group.
• Group Ringtone: Allows you to
select the ringtone to be used when
you receive a voice phone call from
a person in the group.
• Group Icon: Allows you to select
the graphic icon to be displayed on
the group of Group List.
• Add Member: Allows you to add
the member to the group.
• Remove Member:Allows you to
delete the member in the group.
• Rename: Allows you to assign a
name to the group.
Contacts
25
Copy All Contacts
Menu 2.5
This menu allows you to copy all of the
information from your SIM (e.g. name,
phone number, etc.) to your phone,
and vice versa. If a name is duplicated
during the copying process, the
information is also duplicated.
]SIM to Phone:You can copy the
entry from the SIM card to the phone
memory.
]Phone to SIM: You can copy the
entry from the phone memory to the
SIM card (not all the data will be
copied).
Delete All Contacts Menu 2.6
You can delete all entries in the SIM
and the Phone.
Information
Menu 2.7
Check Memory
(Menu 2.7.1)
You can check how many names and
numbers are stored in the Address
Book (SIM card and phone memories).
My Numbers
(Menu 2.7.2)
Allows you to display your phone
number in the SIM card.
You can play the games that are pre-
installed on the phone.
Games
26
Alarm Clock
27
Set the alarm to ring at a specific time.
In the Set Alarm Clock menu, the
following options are available:
1.Navigate to the Alarm Clock menu.
2.Select [On] by pressing the right/left
navigation keys.
3.If you want to set the time for
activating the alarm, press the down
navigation key.
4.Enter the desired time, and press
.
5.Set the repeat frequency. The
following options are available:
• Once: The alarm rings only once
and is then deactivated.
• Daily: The alarm rings every day at
the set time.
• Mon ~ Fri: The alarm rings every
weekday (Monday - Friday) at the
set time.
• Sat ~ Sun:The alarm rings every
Saturday and Sunday at the set
time.
6.Set the alarm melody by using the
right/left navigation keys.
7.Press the left soft key [Save].
Off: Cancel the alarm setting.
Notice
If this option is set to On, the alarm
will ring at the specified time, even
when the phone is switched off.
To stop the alarm when it rings, press
the right soft key[Quit].
New Message
Menu 5.1
You can write and edit text messages
of up to 913 characters.
1. Type in a message using key
presses. For details on how to enter
text, refer to page 19 (Entering
Text).
2. After completing the message
select the desired option by
pressing the right soft key
[Options].
The following options are available.
]Insert
• Symbol: You can insert symbols
ranging from sentence notes to
emoticons. Use the navigation keys
to highlight a symbol, then press
OK or the left soft key OK.
• Text Template: You can easily
insert frequently used sentences in
the text message.
• Contact: You can browse one of
your contacts and place their
information within the body of the
text message.
• Business Card: Input your own
business card created in (Menu
5.7.2). For further details, see page
40.
]Save to Drafts: Saves the selected
message as a draft.
]Set T9: You can turn T9 Mode on or
off.
]Clear Text: Deletes the written
message.
]Cancel: Exit the text editor.
]Left Soft Key SEND: Enter the
recipient's phone number or select
the number from your contact list.
Messaging
28
Messaging
29
Inbox
Menu 5.2
You will be alerted when you receive a
message. They will be stored in the
Inbox.
In the Inbox, you can identify each
message by icons.
Press Options. Choose from the
following options:
]Delete: Deletes the selected
message from the Inbox.
]Reply:Allows you to reply to the
sender of the selected message.
]Forward: Forwards a received
message to other recipients. After
recipients are entered, the message
can be forwarded.
]Return call: Call back the sender.
]Delete All Read: Deletes all
messages that you have read in the
list.
]Delete All Unread: Deletes all the
messages that you have not read.
]Delete All: Deletes all messages in
the list.
]Left Soft Key View: You can
view the received messages.
Press the left soft key [Reply]:
Allows you to reply to the sender of
the selected message.
Drafts
Menu 5.3
You can view the messages you have
saved as drafts. The draft messages are
listed with the dates and times of
when they were saved.
Press Options. Choose from the
following options:
]Delete: Deletes the highlighted
message.
]Delete all: Deletes all messages in
the folder.
Press View. While viewing the
message, press Edit to edit the
message.
When you are finished editing the
message, press Send to send the
message to a recipient.
Outbox
Menu 5.4
If the message transmission fails, you
can save the message in the Outbox.
The following [Options] are available in
the Outbox list.
]Delete: Deletes the message you
choose.
]Delete All: Deletes all messages in
the folder.
Press the left soft key [View]
]View: View the message you choose.
]Edit: Allows you to edit the selected
message.
Sent
Menu 5.5
This menu allows you to save the
messages you have sent successfully.
You can also view the delivery status.
Press Options. Choose from the
following options:
]Delete: Deletes the selected
message from the Sent list.
]Forward: Forwards the current
message to other recipients.
]Delete all: Deletes all messages in
the folder.
]Left Soft Key View: View the
selected message from the Sent list.
While viewing the selected sent
message, press Options. Select
Delete to delete the message.
Press Send to send the message to
a recipient.
Voicemail
Menu 5.6
This menu provides you with a quick
way of accessing your voice mailbox (if
provided by your network).
Before using this feature, you must
enter the voice server number
obtained from your service provider.
This may already be available; to check
the voicemail, press and hold the
key.
When new voicemail is received, the
symbol will be displayed on the
screen.
Messaging
30
Messaging
31
Templates
Menu 5.7
There are 6 predefined messages in
the list. You can view and edit the
template messages or create new
messages.
Text Templates
(Menu 5.7.1)
• Please call me back
• I’m late. I will be there at
• Where are you now?
• I’m on the way.
• Urgent! Please contact.
• I love you
Press Options. Choose from the
following options:
]Edit: Allows you to write a new
message or edit the selected
template message.
]Send Via Text Message: Allows you
to send the selected template
message via SMS.
]Delete: Allows you to delete the
selected template message.
]New Template:Use this to create a
new template.
]Delete All: Deletes all messages in
the folder.
]Left Soft Key View: Allows you
to view the the selected template
message.
Note
Please check with your network
service provider for details of their
service in order to configure the
phone accordingly.
Business Card
(Menu 5.7.2)
This feature allows you to create your
own name card. You can key in the
Name, Mobile number, Office number,
Fax number and E-mail address.
]Send Via Text Message: Sends the
selected name card by SMS.
]Delete: Allows you to delete the
selected name card.
Press the left soft key [Edit]
]Edit: Allows you to write a new
message or edit the selected name
card.
Message settings
Menu 5.8
Text Message
(Menu 5.8.1)
]Message Center Number:If you
want to send a text message, you can
receive the address of the SMS center
through this menu.
]Email Gateway: You can send the
text message to an Email Address via
this gateway.
]Subject: You can enter the SMS
Subject when this menu is on.
Voicemail Number
(Menu 5.8.2)
Allows you to change the voicemail
server number, if necessary.
Check Memory
Menu 5.9
You can check the current used and
available text message memory.
Note
Voice Mail is a network feature.
Please contact your service provider
for further details.
Messaging
32
Recent Calls
33
You can check the record of missed,
received, and dialed calls only if the
network supports the Calling Line
Identification (CLI) within the service
area.
The number and name (if available) are
displayed together with the date and
time of the call. You can also view call
times.
Missed Calls
Menu 6.1
• View the number, if available, and call
it or save it in the Contacts
• Enter a new name for the number
and save both in the Contacts
• Send a message to this number
• Delete the call from the list
Dialed Calls
Menu 6.2
• View the number, if available, and call
it or save it in the Contacts
• Enter new name for the number and
save both in the Contacts
• Send a message to this number
• Delete the call from the list
Received Calls
Menu 6.3
• View the number, if available, and call
it or save it in the Contacts
• Enter a new name for the number
and save both in the Contacts
• Send a message to this number
• Delete the call from the list
All Calls
Menu 6.4
Allows you to view all of missed,
received, and dialed call records.
Call Duration
Menu 6.5
This allows you to view the duration of
the incoming and outgoing calls. You
can also reset the call times. The
following timers are available:
Last Call
(Menu 6.5.1)
Duration of the last call.
Dialed Calls
(Menu 6.5.2)
Duration of the outgoing calls.
Received Calls
(Menu 6.5.3)
Duration of the incoming calls.
All Calls
(Menu 6.5.4)
Total duration of all incoming and
outgoing calls since the timer was last
reset.
Recent Calls
34
My Stuff
35
Games
Menu 7.1
You can play the games that are pre-
installed on the phone.
Audio & Ringtones
Menu 7.2
The right soft key [Options] will bring
up the following options.
]Set as Ringtone: Allows you to set
the selected audio file as your
phone's ringtone.
Graphics
Menu 7.3
The right soft key [Options] will bring
up the following options.
]Set as Wallpaper: Currently selected
picture can be set as a Wallpaper.
]List/Icon View: You can configure
the graphic files to List style or Icon
style.
]Left Soft Key View: You can
view the currently selected image.
Note
Pictures supplied as default can only
be used under the Set as Wallpaper
mode.
Note
Sounds supplied as default can only
be used under the Set as Ringtone
mode.
Alarm Clock
Menu 8.1
For further details, see page 35.
Calendar
Menu 8.2
When you enter this menu a calendar
will be displayed. The square cursor is
used to locate a particular day. An
orange colored date indicates
schedule entries for that day. This
function helps remind you of entries
you have input in the calendar. The
phone will sound an alarm tone if it has
been set for a specific schedule item.
For changing the day, month, and year.
]Left Soft Key View: Allows you
to view the selected schedule.
]Delete: Allows you to delete the
selected schedule entry.
]New Schedule: You can enter a
maximum of 30 characters and
create up to 30 notes.
]Edit: Allows you to edit the selected
schedule.
]Calendar:Allows you to view the
calendar.
]Scheduler Tone:The phone can
sound an alarm tone when the
scheduled date for an event has
been reached.
]All Schedules: Shows the notes that
are set for all days. Use the up/down
navigation keys to browse through
the note lists. You can view
additional options by pressing the
right soft key [Options].
]Go to Date: Allows you to jump to a
specific date.
]Delete Old: Delete past schedule
events.
]Delete All: Delete all schedule
entries. You are asked to confirm
your action.
Tools
36
Key Description
up/down navigation key Weekly
left/right navigation key Daily
key / key Yearly
key/ key
Monthly
Tools
37
Record Voice
Menu 8.3
Allows you to record a memo. You can
record up to 3 voice messages with
each message up to 30 seconds.
You can use the Voice Memo feature
to:
• Play the recorded voice memos
• Delete one or all voice memos
1.Once recording is started, the
message ‘ Recording... ’ and the
remaining time is displayed.
2.If you want to finish recording, press
the left soft key [Save].
]Play: Allows you to play back all
memos recorded, starting with the
most recent memo. The screen
displays the date and time when the
memo was recorded.
]Delete: Allows you to delete a
specific memo.
]Record New:Allows you to record a
memo.
]Delete All: Allows you to delete all
memos.
Notepad
Menu 8.4
You can create up to a maximum of 20
memos.
1. Select a memo pad to edit.
2. Press the left soft key [New] to create
a new memo.
3. Input the memo and press the left
soft key [Save] to save.
Calculator
Menu 8.5
Using this feature, you can use the
phone as a calculator. The calculator
provides the basic arithmetic
functions: addition, subtraction,
multiplication and division.
Note
If all memo locations are full, you
must delete an old memo before
recording a new one.
Tools
38
Using the Calculator
1.Enter the first number using the
numeric keys.
2.Use the navigation keys to select a
sign for calculation.
3.To calculate the result, press OK key.
4. To erase your calculation, press
Reset.
Tip Calculator
Menu 8.6
Allows you to quickly and easily
estimate the tip and total amount of a
bill by inputting the bill amount before
tip, the tip percentage, and dividing it
by the number of people paying.
World Clock
Menu 8.7
Allows you to check the current
Greenwich Mean Time(GMT) and
major cities around the world, using
the left/right navigation keys.
The screen shows the city name,
current date and time.
To select the time zone in which you
are located, proceed as follows:
1. Select the city corresponding to
your time zone by pressing the
left/right navigation keys one or
more times. The local date and time
are displayed.
2. If you want to set the selected city's
time to your phone, press the left
soft key [Set].
3. If you want to set Daylight Savings,
press the right soft key [DST].
Note
The time zone setting of each city in
World time menu may be affected by
network condition.
Note
To input a decimal point, press the
key.
Tools
39
Stop Watch
Menu 8.8
1.Press [Start] to start the timer, and
record lap times by pressing [Lap].
2.Press[Stop] to ascertain the record
of lap time.
3.Press [Reset] to set the timer back to
0.
Unit Converter
Menu 8.9
This feature allows you to convert units
of measurement.
There are 4 types of units of
measurement that can be converted:
Length, Surface, Weight and
Volume.
1. You can select one of four unit types
by pressing the left soft key [Unit].
2. Select the standard value by using
the left/right navigation keys.
3. Select the unit you want to convert
by pressing the up/down navigation
keys.
4. You can check the converted value
for the unit you want. Also, you can
input a decimal number by pressing
the key.
SIM App.
Menu 8.0
This feature is dependent on your
service provider. Please contact the
customer call center of your service
provider for more information.
Settings
40
Audio & Ringtones
Menu 9.1
Pressing and holding while on the
idle screen will switch between Normal
mode and Vibrate mode.
Ringtones
(Menu 9.1.1)
Shows and plays ringtones.
Volume
(Menu 9.1.2)
This menu controls Ringtone, Key
Tone, Earpiece and Headset volume.
There are 5 volume levels available.
Ring Alert Type
(Menu 9.1.3)
Supports 3 ring alert types. Ring, Ring
and Vibrate, and Vibrate then Ring.
Message Alert Tones
(Menu 9.1.4)
Allows you to select an alert tone
which is played when a message is
received.
Increasing Ringtone
(Menu 9.1.5)
Allows you to set an Increasing
Ringtone which will play when
receiving an incoming call. You can set
this feature to On or Off.
Power On/Off Tones
(Menu 9.1.6)
Allows you to set a Power On/Off tone.
You can set this feature to On or Off.
Display
Menu 9.2
Wallpapers
(Menu 9.2.1)
This option allows you to change the
background image (wallpaper) to be
displayed in idle mode.
1. Scroll through the list by pressing
the navigation keys.
You have various preset images
available. You can also select any
images downloaded from the Internet.
2. Press the left soft key [View] when
the desired image is highlighted.
3. Press the left soft key [Set], then the
selected image will be displayed in
idle mode.
Settings
41
Backlight Timer
(Menu 9.2.2)
This option allows you to set the
duration of the Display and Keypad
backlighting.
Contrast
(Menu 9.2.3)
This option allows you to adjust the
contrast of the LCD screen by pressing
the navigation key.
Languages
(Menu 9.2.4)
This option allows you to change the
display text language on your phone.
You can also change the Input
Language.
Date & Time
Menu 9.3
Date Format
(Menu 9.3.1)
YYYY/MM/DD(year/month/day)
DD/MM/YYYY(day/month/year)
MM/DD/YYYY(month/day/year)
Time Format
(Menu 9.3.2)
24 Hours/12 Hours
Call
Menu 9.4
Call Forwarding
(Menu 9.4.1)
When this network service is activated,
you can direct your incoming calls to
another number, for example, to your
voice mailbox number. For details,
contact your service provider. Select
one of the divert options, for example,
select If busyto divert voice calls when
your number is busy or when you
reject incoming calls.
The following options are available:
]All Voice Calls: Diverts voice calls
unconditionally.
]If Busy:Diverts voice calls when the
phone is in use.
]If No Reply:Diverts voice calls which
you do not answer.
]If Out Of Reach:Divert voice calls
when the phone is turned off or out
of the coverage area.
]Cancel All: Cancels all Call
Forwarding settings.
Settings
42
Answer Mode
(Menu 9.4.2)
This allows you to determine how you
would like to answer your phone.
]Flip Open: When the phone rings,
you can answer a call simply by
opening the flip.
]Any Key: You can answer an
incoming call by pressing any key,
except the [PWR/END] key or
the right soft key Silent/Reject.
]SEND Key Only: You can only
answer an incoming call by pressing
the [SEND] key.
Send My Number
(Menu 9.4.3)
This network service allows you to set
your phone number to be displayed
On or hidden Offfrom the person to
whom you are calling. You can select
Set by Networkif you prefer to have
different settings for different service
provider.
Call Waiting
(Menu 9.4.4)
The network will notify you of a new
incoming call while you have a call in
progress. Select Activate to request
the network to activate call waiting,
Cancel to request the network to
deactivate call waiting, or View Status,
to check if the function is active or not.
Minute Minder
(Menu 9.4.5)
This option allows you to specify
whether the phone must beep every
minute during an outgoing call to keep
you informed of the length of the call.
Auto Redial
(Menu 9.4.6)
When set to On, your phone redials the
number you are trying to call up to 10
times after you hear a quick busy
signal. Press [PWR/END] key to
stop the call attempts.
This feature attempts to redial
numbers that are busy due to the
wireless network. It does not redial
numbers to a busy party.
Note
If this network service is not
activated, this menu option will not
appear on your phone. Contact your
service provider for details.
Settings
43
TTY
(Menu 9.4.7)
Allows you to attach a TTY device
enabling you to communicate with
parties also using a TTY device.
A phone with TTY support is able to
translate typed characters to voice.
Voice can also be translated into
characters and then displayed on the
TTY.
Send DTMF Tones
(Menu 9.4.8)
You can send the DTMF (dual tone
multi-frequency) tones of the number
on the display during a call.
This option is helpful for entering a
password or account number when
you call an automated system, like a
banking service.
Security
Menu 9.5
Various codes and passwords are used
to protect the features of your phone.
They are described in the following
sections (see page 17)
PIN Code Request
(Menu 9.5.1)
When the PIN code request feature is
set to ‘Enable’, you must enter your PIN
each time you switch the phone on.
Consequently, any person who does
not have your PIN cannot use your
phone without your approval.
The following options are available:
]Enable: You must enter the PIN each
time the phone is switched on.
]Disable: The phone connects
directly to the network when you
switch it on.
Note
Before disabling the PIN code request
feature, you must enter your PIN.
Fixed Dial Number
(Menu 9.5.2)
Allows you to restrict your outgoing
calls to selected phone numbers, if this
function is supported by your SIM card.
The PIN2 code is required.
The following options are available:
]Enable: You can only call phone
numbers stored in the phonebook.
You must enter your PIN2.
]Disable: You can call any number.
]Number list:You can view the
number list saved as fixed dial
number.
Change Codes
(Menu 9.5.3)
The Change codes feature allows you
to change your current password to a
new one. You must enter the current
password before you can specify a new
one.
You can change the access codes for:
Security Code, PIN1 Code, PIN2 Code
Power Save
Menu 9.6
You can save the power when you
don't use the phone.
Phone Information
Menu 9.7
This menu is used to view My Number,
Manufacturer and Model Name, etc.
Note
PIN: Personal Identification Number.
Note
Not all SIM cards have a PIN2. If your
SIM card does not, this menu option
is not displayed.
Settings
44
Settings
45
Reset Default
Menu 9.8
You can easily reset your phone to its
default configuration. To do so:
1. Select the Reset Settings menu
option.
2. Enter the 8-digit phone password.
Note
The password is preset to 00000000.
QHow do I view the list of outgoing
calls, incoming calls and missed
calls?
APress the [SEND] key.
QHow do I view all numbers stored in
memory?
APress the down navigation key.
QWhy is the connection inconsistent
or not audible in certain areas?
AWhen frequency environment is
unstable in a certain area,
connection may be inconsistent and
not audible. Relocate to another area
and try again.
QWhy is the connection not
consistent and abruptly disconnects,
even when established?
AWhen frequency is unstable or weak
or if there are too many users,
connection may be cut off even after
it was established. Please try again
later or attempt after relocating to
other areas.
QWhy does the LCD not turn on?
ARemove the battery and turn on the
power after placing it back on. If
there is no change, fully charge the
battery and try again.
QWhy is there an echo when a
connection is made with certain
telephones in a certain area?
AThis is called the "Echo
Phenomenon", which occurs if
connection volume is too high, or by
Q&A
46
Please check to see if any problems you have encountered with the phone are
described in this section before taking the phone in for service or calling a service
engineer.
Q&A
47
special properties (semi electronic
telephone exchange) of the
equipment on the other end.
QWhy does the phone heat up?
AThe phone may get hot when there
is a very long call duration or when
games are played for a long time.
This has no effect upon the life of the
product or performance.
QWhy does the battery life get shorter
in standby mode?
AThe battery is worn out. As time
passes, the battery life gradually
becomes shorter. If the battery lasts
about half the amount of time as
when first purchased, it’s time to
purchase a new battery.
QWhy does the battery run out so
quickly during normal use?
AIt is due to the user's environment, a
large number of calls, or a weak
signal.
QWhy is no number dialed when you
recall a Contacts entry?
ACheck that the number has been
stored correctly by using the Contact
List feature. Re-store them, if
necessary.
QI cannot find the lock, PIN, or PUK
code. What is my password?
AThe default lock code is ‘0000’. If you
forget or lose the lock code, contact
your phone dealer. If you forget or
lose a PIN or PUK code, or if you have
not received such a code, contact
your network service provider.
Safety Guidelines
Hearing Aid Compatibility
(HAC) with Mobile Phones
When some mobile phones are used near
some hearing devices (hearing aids and
cochlear implants),users may detect a buzzing,
humming, or whining noise. Some hearing
devices are more immune than others to this
interference noise, and phones also vary in
the amount of interference they generate. The
wireless telephone industry has developed
ratings for some of their mobile phones, to
assist hearing device users in finding phones
that may be compatible with their hearing
devices. Not all phones have been rated.
Phones that are rated have the rating on their
box or a label on the box. The ratings are not
guarantees. Results will vary depending on
the user’s hearing device and hearing loss. If
your hearing device happens to be vulnerable
to interference, you may not be able to use a
rated phone successfully. Trying out the phone
with your hearing device is the best way to
evaluate it for your personal needs.
M-Ratings: Phones rated M3 or M4 meet FCC
requirements and are likely to generate less
interference to hearing devices than phones
that are not labeled. M4 is the better/higher of
the two ratings.
T-Ratings:
Phones rated T3 or T4 meet FCC
requirements and are likely to be more usable
with a hearing device’s telecoil (“T Switch” or
“Telephone Switch”) than unrated phones. T4 is
the better/higher of the two ratings. (Note that
not all hearing devices have telecoils in them.)
T-coil statement for CF360
Achieve optimal antenna performance of the
phone by sliding the phone open to make or
receive a call.
Hearing devices may also be measured for
immunity to this type of interference. Your
hearing device manufacturer or hearing health
professional may help you find results for your
hearing device. The more immune your hearing
aid is, the less likely you are to experience
interference noise from mobile phones.
To ensure that the Hearing Aid Compatibility
rating for your phone is maintained, secondary
transmitters such as Bluetooth and WLAN
components must be disabled during a call.
