LG Electronics USA M1740AB 17” LCD Monitor User Manual Microsoft PowerPoint F User s Manual
LG Electronics USA 17” LCD Monitor Microsoft PowerPoint F User s Manual
Users Manual
FCC ID : BEJM1740AB
APPENDIX F :
USER’S MANUAL
1 / 50
1
FCC Compliance Statement
This equipment has been tested and found to comply within
the limits of a Class B digital device pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses, and can radiate radio
frequency energy and if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio
or television reception (which can be determined by turning
the equipment on and off), the user is encouraged to try to
correct the interference by using one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the
receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV
technician for help.
Caution: Changes or modifications not expressly approved
by the party responsible for compliance could void the
user's (or your) authority to operate the equipment. Only
peripherals (digital input/output devices, terminals, printers,
etc.) certified to comply with the Class B limits may be
attached to this monitor. Operation with non-certified
peripherals is likely to result in interference to radio and TV
reception.
Only shielded signal cables may be used with this System.
Canadian DOC Notice
This Class B digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les
exigences du Règlement sur le matériel brouilleur du
Canada.
CE Conformity Notice (for Europe)
Products with the “CE” Marking comply with the EMC
Directive(89/336/EEC) and LOW VOLTAGE Directive
(73/23/EEC) issued by the Commission of the European
Community.
Compiance with these directives implies conformity to the
following European Norms :
• EN 55022:1998 ; Radio Frequency Interference
• EN 55024:1998 ; Electromagnetic Immunity
• EN 61000-3-2 ; Power Line Harmonics
• EN 61000-3-3 ; Voltage Fluctuations
• EN 60950 ; Product Safety
Low Radiation Compliance (MPR II)
This monitor meets one of the strictest guidelines available
today for low radiation emissions, offering the user extra
shielding and an antistatic screen coating. These
guidelines, set forth by a government agency in Sweden,
limit the amount of emission allowed in the Extremely Low
Frequency (ELF) and Very Low Frequency (VLF)
electromagnetic range.
TCO95
Congratulations!
You have just purchased a TCO’95 approved and labelled
product! Your choice has provided you with a product
developed for professional use. Your purchase has also
contributed to reducing the burden on the environment and
to the further development of environmentally-adapted
electronic products.
Why do we have environmentally labelled computers?
In many countries, environmental labelling has become an
established method for encouraging the adaptation of
goods and services to the environment. The main problem
as far as computers and other electronic equipment are
concerned is that environmentally harmful substances are
used both in the products and during their manufacture.
Since it has not been possible so far for the majority of
electronic equipment to be recycled in a satisfactory way,
most of these potentially damaging substances sooner or
later enter Nature.
There are also other characteristics of a computer, such as
energy consumption levels, that are important from both the
working and natural environment viewpoints. Since all
types of conventional electricity generation have a negative
effect on the environment (acidic- and climatic-influencing
emissions, radioactive waste, etc.), it is vital to conserve
energy. Electronic equipment in offices consumes as
enormous amount of energy, since it is often routinely left
running continuously.
What does the environmenal labelling involve?
This product meets the requirements for the TCO’95
Regulatory Information
NOTICE
The regulations are applied only to the products with the
ID LABEL indicating specific requirements.
NOTICE
The regulations are applied only to the products with the
ID LABEL indicating specific requirements.
NOTICE
The regulations are applied only to the products with the
ID LABEL indicating specific requirements.
2
Regulatory Information cont.
NUTEK
Naturskydds
föreningen
Närings- och teknikutvecklingsverket
SEMKO
scheme, which provides for international environmental
labelling of personal computers. The labelling scheme was
developed as a joint effort by the TCO (The Swedish
Confederation of Professional Employees),
Naturckyddsföreningen (The Swedish Society for Nature
Conservation), and NUTEK (The National Board for
Industrial and Technical Development in Sweden), and
SEMKO AB (an international certification agency).
The requirements cover a wide range of issues:
environment, ergonomics, usability, emission of electrical
and magnetic fields, energy consumption and electrical and
fire safety.
The environmental demands concern, among other things,
restriction on the presence and use of heavy metals,
brominated and chlorinated flame retardants, CFCs
(freons), and chlorinated solvents. The product must be
prepared for recycling, and the manufacturer is obliged to
have an environmental plan, which must be adhered to in
each country where the company implements its
operational policy.
The energy requirements include a demand that the
computer and/or display, after a certain period of inactivity,
shall reduce its power consumption to a lower level, in one
or more stages. The length of time to reactivate the
computer shall be reasonable for the user.
Labelled products must meet strict environmental
demands, for example, in respect of the reduction of electric
and magnetic fields, along with physical and visual
ergonomics and good usability.
The following is a brief summary of the environmental
requirements met by this product. The complete
environmental criteria document may be ordered from:
TCO Development Unit
Linnegatan 14, S-11494 Stockholm, Sweden
FAX +46-8 782 92 07
E-mail (Internet): development@tco.se
Current information regarding TCO’95 approved and
labelled products may also be obtained on the Internet
using the address: http://www.tco-info.com/
TCO’95 is a co-operative project between:
Environmental requirements
Brominated flame retardants are present in printed circuit
boards, cabling, casings, and housings, and are added to
delay the spread of fire. Up to 30% of the plastic in a
computer casing can consist of flame-retardant substances.
These are related to another group of environmental toxins,
PCBs, and are suspected of giving rise to similar harm,
including reproductive damage in fish-eating birds and
mammals. Flame retardants have been found in human
blood, and researchers fear that they can disturb fetus
development.
Bio-accumulative1TCO’95 demands require that plastic
components weighing more than 25 grams must not
contain flame retardants with organically bound chlorine or
bromine.
Lead can be found in picture tubes, display screens, solder,
and capacitors. Lead damages the nervous system and in
higher doses causes lead poisoning. The relevant bio-
accumulative TCO’95 requirement permits the inclusion of
lead, as no replacement has yet been developed.
Cadmium is present in rechargeable batteries and in the
color-generating layers of certain computer displays.
Cadmium damages the nervous system and is toxic in high
doses. The relevant bio-accumulative TCO’95 requirement
states that batteries may not contain more than 25 ppm
(parts per million) of cadmium. The color-generating layers
of display screens must not contain any cadmium.
Mercury is sometimes found in batteries, relays and
switches. Mercury damages the nervous system and is
toxic in high doses. The relevant bio-accumulative TCO’95
requirement states that batteries may not contain more than
25 ppm of mercury and that no mercury is present in any of
the electrical or electronic components concerned with the
display unit.
CFCs (freons) are sometimes used for washing printed
circuit boards and in the manufacture of expanded foam for
packaging. CFCs break down ozone and thereby damage
the ozone layer in the atmosphere, causing increased
reception on Earth of ultra-violet light with consequent
increased risks of skin cancer (malignant melanoma). The
relevant TCO’95 requirement: Neither CFCs nor HCFCs
may be used during the manufacture of the product or its
packaging.
1Bio-accumulative means that the substance accumulates
within living organisms.
Shipping Package
The packaging material can be recycled, or you can save it
to return the monitor to a service center for repair or
disposal.
CFC Compounds in Distribution Packaging
Cushioning material used for shipping finished monitors are
not manufactured with nor do they contain any CFC
compounds.
Design for Disassembly/Recycling
These monitors have been designed for easy end-of-life
disassembly and recycling. Fasteners are generally of the
same type for efficient disassembly. Components made of
different materials can be easily separated and plastics
have been identified using intermational symbols to aid in
recycling.
Monitor Disposal
WARNING
If you need to dispose of a monitor, ask a qualified service
representative for the proper procedure. Improper disposal
could result in personal injury from implosion.
3
TCO99
Congratulations!
You have just purchased a TCO’99 approved and
labelled product! Your choice has provided you with
a product developed for professional use. Your
purchase has also contributed to reducing the
burden on the environment and also to the further
development of environmentally adapted electronics
products.
Why do we have environmentally labelled
computers?
In many countries, environmental labelling has
become an established method for encouraging the
adaptation of goods and services to the environment.
The main problem, as far as computers and other
electronics equipment are concerned, is that
environmentally harmful substances are used both in
the products and during their manufacture. Since it is
not so far possible to satisfactorily recycle the
majority of electronics equipment, most of these
potentially damaging substances sooner or later
enter nature.
There are also other characteristics of a computer,
such as energy consumption levels, that are
important from the viewpoints of both the work
(internal) and natural (external) environments. Since
all methods of electricity generation have a negative
effect on the environment (e.g. acidic and climate-
influencing emissions, radioactive waste), it is vital to
save energy. Electronics equipment in offices is
often left running continuously and thereby
consumes a lot of energy.
What does labelling involve?
This product meets the requirements for the TCO’99
scheme which provides for international and
environmental labelling of personal computers. The
labelling scheme was developed as a joint effort by
the TCO (The Swedish Confederation of
Professional Employees), Svenska
Naturskyddsforeningen (The Swedish Society for
Nature Conservation) and Statens Energimyndighet
(The Swedish National Energy Administration).
Approval requirements cover a wide range of issues:
environment, ergonomics, usability, emission of
electric and magnetic fields, energy consumption
and electrical and fire safety.
The environmental demands impose restrictions on
the presence and use of heavy metals, brominated
and chlorinated flame retardants, CFCs (freons) and
chlorinated solvents, among other things. The
product must be prepared for recycling and the
manufacturer is obliged to have an environmental
policy which must be adhered to in each country
where the company implements its operational
policy.
The energy requirements include a demand that the
computer and/or display, after a certain period of
inactivity, shall reduce its power consumption to a
lower level in one or more stages. The length of time
to reactivate the computer shall be reasonable for
the user.
Labelled products must meet strict environmental
demands, for example, in respect of the reduction of
electric and magnetic fields, physical and visual
ergonomics and good usability.
Below you will find a brief summary of the
environmental requirements met by this product. The
complete environmental criteria document may be
ordered from:
TCO Development
SE-114 94 Stockholm, Sweden
Fax: +46 8 782 92 07
Email (Internet): development@tco.se
Current information regarding TCO’99 approved and
labelled products may also be obtained via the Internet,
using the address: http://www.tco-info.com/
Environmental requirements
Flame retardants
Flame retardants are present in printed circuit
boards, cables, wires, casings and housings. Their
purpose is to prevent, or at least to delay the spread
of fire. Up to 30% of the plastic in a computer casing
can consist of flame retardant substances. Most
flame retardants contain bromine or chloride, and
those flame retardants are chemically related to
another group of environmental toxins, PCBs. Both
the flame retardants containing bromine or chloride
and the PCBs are suspected of giving rise to severe
health effects, including reproductive damage in
fish-eating birds and mammals, due to the bio-
accumulative* processes. Flame retardants have
been found in human blood and researchers fear
that disturbances in foetus development may occur.
The relevant TCO’99 demand requires that plastic
components weighing more than 25 grams must not
contain flame retardants with organically bound
bromine or chlorine. Flame retardants are allowed in
the printed circuit boards since no substitutes are
available.
Cadmium**
Cadmium is present in rechargeable batteries and in
the colour-generating layers of certain computer
displays. Cadmium damages the nervous system
and is toxic in high doses. The relevant TCO’99
requirement states that batteries, the colour-
generating layers of display screens and the
electrical or electronics components must not contain
any cadmium.
Regulatory Information cont.
4
Regulatory Information cont.
Mercury**
Mercury is sometimes found in batteries, relays and
switches. It damages the nervous system and is
toxic in high doses. The relevant TCO’99
requirement states that batteries may not contain
any mercury. It also demands that mercury is not
present in any of the electrical or electronics
components associated with the labelled unit.
CFCs (freons)
The relevant TCO’99 requirement states that neither
CFCs nor HCFCs may be used during the
manufacture and assembly of the product. CFCs
(freons) are sometimes used for washing printed
circuit boards. CFCs break down ozone and thereby
damage the ozone layer in the stratosphere, causing
increased reception on earth of ultraviolet light with
e.g. increased risks of skin cancer (malignant
melanoma) as a consequence.
Lead**
Lead can be found in picture tubes, display screens,
solders and capacitors. Lead damages the nervous
system and in higher doses, causes lead poisoning.
The relevant TCO’99 requirement permits the
inclusion of lead since no replacement has yet been
developed.
* Bio-accumulative is defined as substances which
accumulate within living organisms
** Lead, Cadmium and Mercury are heavy metals which are
Bio-accumulative.
EPA (U.S.A only)
ENERGYSATR is a set of power-saving guidelines
issued by the U.S. Environmental Protection
Agency(EPA).
NOM MARK (Mexico only)
GOST MARK
EPA POLLUTION PREVENTER
As an ENERGY STAR Partner LG
Electronics U.S.A.,Inc. has
determined that this product meets the
ENERGY STAR guidelines for
energy efficiency.
BZ03
Internet Address:http://www.lg.ru
»ÌÙÓχˆËÓÌ̇ˇ ÒÎÛÊ·‡ LG
Electronics (095)742-77-77
M1740A/M1940A/M2040A
User's Guide
P/NO. : 3828TUL289S(0412-REV00)
Printed in Korea
http://www.lge.com
Please read this manual
carefully before operating your set.
Retain it for future reference.
Record model number and serial number of the set.
See the label attached on the back cover and quote
this information to your dealer when you require service.
i
A1
A4
A5
A9
A11
A11
A13
A14
Safety Precautions
Accessories
Before Connecting to the PC
Name and Function of the Parts
Connecting to External Devices
Connecting to your PC
Watching Video
Watching TV
A31
A34
Selecting and Adjusting the Screen
OSD (On Screen Display) Scree
n Tracking Order
Set/Selects the channel when using the TV
Adjusting Screen Color
Adjusting the audio function
Adjusting the timer function
Selecting the options
Setting a password
To adjust the CAPTION&VCHIP function
Closed Captions
Adjusting Screen CLOCK/PHASE and Position
(only PC)
A15
A18
A19
A21
A22
A23
A24
A26
A27
A29
A30
Troubleshooting
Specifications
Installation
and
Connection
Input
Selection
and Tracking
Miscellaneous
Table of Contents
ENGLISH
A1
Please read these safety precautions carefully before using
Precautions in installing the Monitor
If you ignore the caution message, you may be slightly injured or the product may be damaged
If you ignore the warning message, you may be seriously injured or there is a possibility of
accident or death.
Keep away from heat sources like electrical heaters.
- Electrical shock, fire, malfunction or deformation may occur.
Keep the packing anti-moisture material or vinyl packing out of the reach of children.
- Anti-moisture material is harmful if swallowed. If swallowed by mistake, force the patient to vomit and visit the
nearest hospital. Additionally, vinyl packing can cause suffocation. Keep it out of the reach of children.
Do not put heavy objects on the monitor or sit upon it.
- If the monitor collapses or is dropped, you may be injured. Children must pay particular attention.
Do not leave the power or signal cable unattended on the pathway.
- The passerby can falter, which can cause electrical shock, fire, product breakdown or injury.
Install the monitor in a neat and dry place.
- Dust or moisture can cause electrical shock, fire or product damage.
If you can smell smoke or other odors or hear a strange sound unplug the power cord and contact the
service center.
- If you continue to use without taking proper measures, electrical shock or fire can occur.
If you dropped the monitor or the case is broken, turn off the monitor and unplug the power cord.
- If you continue to use without taking proper measures, electrical shock or fire can occur. Contact the service
center.
Do not drop metallic objects such as coins, hair pins, chopsticks or wire into the monitor, or inflammable
objects such as paper and matches. Children must pay particular attention.
- Electrical shock, fire or injury can occur. If a foreign object is dropped into the monitor, unplug the power cord and
contact the service center.
Make sure the monitor ventilation hole is not blocked. Install the monitor in a suitably wide place (more
than 10cm from the wall)
- If you install the monitor too close to the wall, it may be deformed or fire can break out due to internal heat.
Do not block the ventilation hole of the monitor by a tablecloth or curtain.
- The monitor can be deformed or fire can break out due to overheating inside the monitor.
Install the monitor on a flat and stable place that has no risk of dropping the monitor.
- If the monitor is dropped, you may be injured or the monitor may be broken.
Install the monitor where no EMI occurs.
Keep the monitor away from direct sunlight.
- The monitor can be damaged.
Safety Precautions
Warning
Warning
Caution
Caution
A2A2
Electrical Power Related Precautions
Make sure to connect the power cable to the grounded current.
- You may be electrocuted or injured.
Use the rated voltage only.
- The monitor can be damaged, or you may be electrocuted.
During a thunder or lightning storm, unplug the power cable or signal cable.
- You may be electrocuted or a fire can break out.
Do not connect several extension cords, electrical appliances or electrical heaters to a single outlet. Use a
power bar with a grounding terminal designed for exclusive use with the computer.
- A fire can break out due to overheating.
Do not touch the power plug with wet hands. Additionally, it the cord pin is wet or covered with dust, dry
the power plug completely or wipe dust off.
- You may be electrocuted due to excess moisture.
If you don’t intend to use the monitor for a long time, unplug the power cable from the monitor.
- Covering dust can cause a fire, or insulation deterioration can cause electric leakage, electric shock or fire.
Fix the power cable completely.
- If the power cable is not fixed completely, a fire can break out.
Hold the plug when pulling out the power cable. Do not bend the power cord with excessive force or put
heavy objects on the power cord.
- The power line can be damaged, which may cause electric shock or fire.
Do not insert a conductor (like a metal chopstick) into one end of the power cable while the other end is
connected to the input terminal on the wall. Additionally, do not touch the power cable right after
plugging into the wall input terminal.
- You may be electrocuted.
Do not unplug the power cord while the monitor is in use.
- Electrical shock can damage the monitor.
Warning
Caution
ENGLISH
Precautions in Moving the Monitor
Warning
Make sure to turn off the monitor.
- You may be electrocuted or the monitor can be damaged.
Make sure to remove all cables before moving the monitor.
- You may be electrocuted or the monitor can be damaged.
A3
Safety Precautions
Caution
Precautions in Using the Monitor
Warning
Do not put or store inflammable substances near the monitor.
- There is a danger of explosion or fire due careless handling of the inflammable substances.
When cleaning the brown tube surface, unplug the power cord and scrub with soft cloth to prevent
scratching. Do not clean with a wet cloth.
- The water can sink into the monitor, which can cause electric shock or serious malfunction.
Take a rest from time to time to protect your vision.
Keep the monitor clean at all times.
Take a comfortable and natural position when working with a monitor to relax the muscles.
Take a regular break when working with a monitor for a long time.
Do not press strongly upon the panel with a hand or sharp object such as nail, pencil or pen, or make a
scratch on it.
Keep the proper distance from the monitor.
- Your vision may be impaired if you look at the monitor too closely.
Set the appropriate resolution and clock by referring to the User’s Manual.
- Your vision can be impaired.
Use authorized detergent only when cleaning the monitor. (Do not use benzene, thinner or alcohol.)
- Monitor can be deformed.
Caution
Do not shock the monitor when moving it.
- You may be electrocuted or the monitor can be damaged
Do not dispose the product-packing box. Use it when you move.
Make the panel face forward and hold it with both hands to move.
- If you drop the monitor, the damaged monitor can cause electric shock or fire. Contact with the service center for
repair.
Do not disassemble, repair or modify the monitor at your own discretion.
- Fire or electric shock accident can occur.
- Contact the service center for check, calibration or repair.
Do not spray water on the monitor or scrub with an inflammable substance (thinner or benzene). Fire or
electric shock accident can occur
Keep the monitor away from water.
- Fire or electric shock accident can occur.
A4A4
Please check the accessories in the product package.
* The monitor and the accessories can be different from the figures shown here.
ENGLISH
Accessories
1. Take out the battery cap.
2. Insert the battery with correct polarity (+/-).
3. Close the battery cap.
• You can use a remote controller 7 meter distance
and 30 degree (left/right) within the receiving unit
scope.
• Dispose of used batteries in the recycle bin to
prevent environmental pollution.
Inserting batteries into remote controller.
Remote Control
/Batteries (AAA x 2) Power Cord
Audio Cable (PC)
D-SUB Signal Cable DVI-D Signal Cable
Back cap
User’s Manual/
Cards/Driver Diskette
A5
Before Connecting to the PC
Before setting up the monitor, ensure that the power to the monitor, the computer
system, and other attached devices is turned off.
Unfolding the stand base
Place the product with its front facing downward on a cushion or soft cloth.
Hold down the release button inside the stand and strongly pull out the stand with
your two hands.
The stand won't move if you don't
press release button.
A6
ENGLISH
Note
To arrange the cables
ANT IN
PC
Audio
D
Audio
R
L
Pr
Pb
Y
Back Cap
ANT IN
Aud
D
Audio
R
L
Pr
Pb
Y
Cable Holder
For remove the back cap,
Pull it shown in the following
figure.
After connecting the cables neatly, arrange the cables to the Cable Holder as shown in
the following figure.
Push the back cap shown in the following figure.
A7
A7
Name and Function of the Parts
Power On/Off Button
Channel Up/Down Button
•
Input Select Button
•
TV/AV Button
(See next page)
Sleep Button
When watching AV//TV
-
The monitor will be automatically turned
off after a certain period of time.
Press this button repetitively to select an
appropriate time duration
PSM Button
When watching AV/HDTV/TV
- Automatically adjusts the image.
Press this button repetitively to set
the intended screen. (See A27)
CAPTION Button
(See A33)
•
Menu Button
•
Exit Button
Auto Channel Button
TV: Automatic TV channel setup
PC: Automatic adjustment function
(Operational for the analog signal only)
Channel Number Select
Button
Operational at the TV mode only
Set Button
Sound Mode Select
Select the sound mode
: MONO/STEREO/SAP
Video Operation Button
Applicable for LG products only
Volume Button
Mute button
Name of the Remote Controller Buttons
A8
ENGLISH
1. PIP (Picture in Picture) Button
The sub-screen moves to the next mode whenever you press this button.
: Small -> Medium -> Large -> Off
2. POP (Picture out Picture) Button
The sub-screen moves to the next mode whenever you press this button.
: POP ON -> PBP(FULL) -> PBP(4:3) -> OFF
If you press the button once,
the following Input Signal
Window will appear. Select
the signal type you want
using the button.
This button will be enabled only
when you selected the TV/AV
signal. The signal type will be
changed with the following order.
Set the signal type you want.
POP ON PBP (FULL) PBP (4:3)
•
Input Select Button
•
TV/AV Button
TV AV S-Video Component
INPUT SELECT
TV
AV
S-Video
Component
RGB
DVI
A9
SWAP
SWAP
When 'Input Signal 1' comes on in the main screen, only 'Input Signal 2' can be displayed on the sub-screen. On
the contrary, if the main screen displays 'Input Signal 2', the sub-screen can display 'Input Signal 1' only. You can
swap 'Input Signal 1' and 'Input Signal 2' using the SWAP button.
1. Take out the battery cap.
2. Insert the battery with correct polarity (+/-).
3. Close the battery cap.
• You can use a remote controller 7 meter distance and 30 degree (left/right)
within the receiving unit scope.
• Dispose of used batteries in the recycle bin to prevent environmental pollution.
Inserting batteries into remote controller.
3. Swap Button
You can swap the main screen and the sub-screen when the PIP/POP/PBP function is used..
<Table of PIP/POP/PBP Function Support>
DVI
DVI
RGB
RGB
TV
TV
AV1
AV1
AV2
AV2
S-Video
S-Video
Name and Function of the Parts
A10
ENGLISH
ANT IN PC
Audio
D
Audio
RL PbYPr
Audio
R
Audio
L
S-Video
ANT IN PC
Audio
D
Audio
RL
Pb
Y
Pr
Rear View
Theft prevention locking device
Power Cord Connector : Connect the power cord
AV Input Terminal
TV Tuner Jack: Connect the antenna.
DVI Signal Connector
D-SUB Analogue Signal Connector
Audio Jack :Connect to the jack in the PC sound
card.
A11
Name and Function of the Parts
•
Make sure to check the sound card connection terminal in the PC before connecting to the monitor.
If the PC sound card supports both Speaker Out and Line Out, change it to Line Out by setting the jumper or
the PC application. (For more details, refer to the sound card user’s manual.)
- Speaker Out : The terminal connected to the speaker that is not equipped with an amplifier.
- *Line Out : The terminal connected to the speaker equipped with an amplifier.
If Audio Out in the PC sound card has only Speaker Out, reduce the PC volume. This monitor is integrated
with an amplifier.
AV Input Terminal
Connecting the sound card output terminal
Audio
R
Audio
L
S-Video
AV(CVBS) Input Terminal(Audio)
AV(CVBS) Input Terminal(Video)
S-Video Input Terminal
Headphone/Earphone Connection
Terminal
A12
ENGLISH
ANT IN
PC
Audio
ANT IN PC
Audio
D
ud o
Audio
L
S-Video
Audio
RL
PrPb
Y
When Connecting to your PC
First of all, see if the computer, product and the peripherals are turned off. Then,
connect the signal input cable.
When connecting with the DVI signal input cable.
When connecting with the D-SUB signal input cable. (IBM compatible PC)
When connecting with the D-SUB signal input cable. (Macintosh)
PC
Rear side of the product
ANT IN PC
Audio
D
Audio
R
Audio
L
S-Video
Rear side of the product
* When connecting to a
wall outlet.
Connecting to External Devices
Connect the power cord.
B
A
B
A
MAC
Macintosh Adapter (Optional)
Use the standard Macintosh adapter since an incompatible
adaptor is available in the market. (Different signaling system)
C
C
A13A13
Connecting to External Devices
When connecting with a DVI signal input cable.
• Select DVI
When connecting with a D-SUB signal input cable.
• Select
RGB
Turn on power by touching the Power On/Off sensor on the product.
Turn on the PC.
Select an input signal.
Press the Input Select button on the remote controller to select the input signal.
Or, press the SOURCE button at the front side of the monitor.
B
A
•
How to connect to two computers.
Connect the signal cables (DVI and D-Sub) to each computer.
Press the SOURCE button in a remote controller to select the computer to use.
•
Directly connect to a grounded power outlet on the wall or a power bar with a ground
wire.
Note
Power On/Off sensor
INPUT SELECT
TV
AV
S-Video
Component
RGB
DVI
A14
ENGLISH
Audio
R
Audio
L
S-Video
AUDIO
OUT
VIDEO
OUT
When watching VCR
When connecting with an RCA cable.
•
Connect the input terminal with a proper color match. (Video – Yellow, Sound (left) –
White, Sound (right) – Red)
A
Red
White
Yellow RCA Cable
(Not included)
R
W
Y
Side of the Product
VCR
Connect the video cable as shown in the below figure and then connect the power cord
(See page A12).
When connecting with an S-Video cable.
•
Connect to the S-Video input terminal to watch high image quality movies.
Audio
R
Audio
L
S-Video
AUDIO
OUT
VIDEO
OUT
Red
White
RCA Cable
(Not included)
S-Video Cable
(Not included)
VCR
Side of the Product
B
R
W
When connecting with a RCA cable.
•
Select AV
When connecting with a S-Video cable.
•
Select S-Video
Select an input signal.
Press the SOURCE button on the remote controller to select the input
signal. Or, press the SOURCE button at the front side of the monitor.
B
A
INPUT SELECT
TV
AV
S-Video
Component
RGB
DVI
A15
Connecting to External Devices
Audio
RL
PrPb
Y
When watching DVD
When connecting with an Comonent cable.
•
Connect the input terminal with a proper color match.
A
Back of the Product
DVD
Connect the video/audio cable as shown in the below figure and then, connect the power
cord (See page A12).
When connecting with an S-Video cable.
•
Connect to the S-Video input terminal to watch high image quality movies.
Audio
R
Audio
L
S-Video
AUDIO
OUT
VIDEO
OUT
Red
White
RCA Cable
(Not included)
S-Video Cable
(Not included)
DVD
Side of the Product
B
R
W
When connecting with a Component cable.
•
Select Component
When connecting with a S-Video cable.
•
Select S-Video
Select an input signal.
Press the SOURCE button on the remote controller to select the input
signal. Or, press the SOURCE button at the front side of the monitor.
B
A
INPUT SELECT
TV
AV
S-Video
Component
RGB
DVI
Audio Cable
(optional)
Video Cable
(optional)
Red
White
Red
Blue
Green
A16
ENGLISH
ANT IN
PC
Audio
ANT IN PC
Audio
D
Audio
R
Audio
L
S-Video
Audio
RL
PrPb
Y
Audio
RL
PrPb
Y
Rear side of the Product
Antenna Cable
(Not Included)
•
Select TV
Select an input signal.
Press the SOURCE button on the remote controller to select the input
signal. Or, press the SOURCE button at the front side of the product.
See if the antenna cable is connected at the rear side of the monitor and
then, connect the power cord .
When watching TV
INPUT SELECT
TV
AV
S-Video
Component
RGB
DVI
A17
Selecting and Adjusting the Screen
Name of the Buttons in the Screen Adjustment Unit
• Touch the button to turn on the power. Touch the button again to turn it off.
• This indicator lights up blue when the display operates normally. If the
display is in DPM (Energy Saving) mode, this indicator color changes to
amber.
• Adjust the volume.
•Use
these buttons
to directly control
brightness and contrast of the PC signal
(RGB, DVI)
•Use
these buttons
to control the channel
for the TV signal.
• Use this button to show/hide the OSD (On Screen Display) menu screen.
•
Use these buttons to select an icon or adjust the setting in the OSD screen.
<
<
< >
Power LED
Power On/Off
sensor
MENU Button
OSD Select /
Adjust Button
SOURCE MENU < VOL > AUTO/SELECTPR
<
<
CH
A18
ENGLISH
Name of the Buttons in the Screen Adjustment Unit
[For PC Analogue signal-RGB]
[For TV]
[Other signals]
•The current signal and mode information will be displayed.
AUTO/SELECT Button
TV Television
AV Composite video
S-Video Separate Video
Component Component signal
RGB D-SUB analog signal
DVI DVI digital signal
• Select the input signal
SOURCE Button
•The unit that receives the signal from the remote controller.
<
<
Auto In progress
Auto In progress
0 ----- 50%
INPUT SELECT
TV
AV
S-Video
Component
RGB
DVI
A19
Selecting and Adjusting the Screen
OSD Menu
Icon Function Description
STATION
SOUND
TIMER
Adjusts the timer function.
Adjusts the screen video.
Adjusts the audio function.
Adjusts screen brightness, contrast and color that you prefer.
Set/Selects the channel.
SPECIAL
Adjusts the screen status according to the circumstances.
PIP/POP/PBP
Adjusts PIP/POP/PBP mode function.
SCREEN
Note
OSD(On Screen Display)
The OSD function enables you to adjust the screen status conveniently since it provides
graphical presentation.
A20
ENGLISH
How to adjust the OSD (On Screen Display) screen.
•
Use the remote controller to adjust the OSD screen.
How to adjust the screen automatically.
You need to adjust the screen display when connecting the product to a
new computer or changing the mode. Refer to the following section to
set an optimal product screen.
Press the AUTO/SELECT button (AUTO button in a remote controller)
in the PC analog signal. Then, an optimal screen status will be selected
that fits into the current mode.
If adjustment is not satisfactory, you need to adjust screen position,
clock and phase in the OSD menu.
Pops up the
menu screen
Move where
you want to
adjust
Select a menu icon Adjust the status Save/Select
adjustment Exit from the
menu screen.
Press the MENU Button, then the main menu of the OSD appears.
To access a control, use the
DD/ EE
Buttons.
When the icon you want becomes highlighted, press the SET Button.
Use the
DD/ EE/ FF / GG
Buttons to adjust the item to the desired level.
Accept the changes by pressing the SET Button.
Exit the OSD by pressing the EXIT Button.
1
2
3
4
5
6
Auto In progress
A21
Selecting and Adjusting the Screen
Set/Selects the channel when using the TV
EZ Scan
Manual Prog.
Press
G
button to start automatic programming. all available TV channels are searched
and stored automatically.
To stop auto CH progess, press the MENU button.
• Wait for auto CH progess to complete the channel search cycle before choosing a
channel. The TV scans for over-the-air channels and then channels provided by a cable
service.
To S
tart
To automatically search the available
TV channels.
Press
G button and then use F / G button to select the channel.
User can do manual channel selection and store or erase individual channels. Press DD / EE
button and then use G button to select a channel you want to add to memory or erase. Press
the E button and then use F / G button to select Memory(add) or Erase(delete).
Channel
Memory /
Erase
STATION
MENU Prev
EZ Scan
Manual Prog
STATION
MENU Prev
EZ Scan G
Manual Prog To start
STATION
MENU Prev
EZ Scan
Manual Prog GCH 3
Memory
A22
ENGLISH
Adjusting the picture function
EZ Video
MENU Prev
EZ Video
ACC
Contrast 66
Brightness 80
Color 55
Sharpness 54
Tint
MENU Prev
EZ Video G
ACC
Dynamic
Standard
Mild
Game
User
<
MENU Prev
EZ Video
ACC GWarm
Normal
Cool
<
Dynamic
Standard
Mild
Game
UserG
<
Contrast
To adjust the contrast of the screen.
Brightness
To adjust the brightness of the screen.
Color
To adjust the color to desired level.
Sharpness
To adjust the cleaness of the screen.
Tint
To adjust the tint to desired level. (only
60Hz signal)
TV/AV1/AV2/S-Video input only
The EZ Video function automatically adjusts the screen image quality
depending on the AV/TV usage environment.
• Dynamic : Select this option to display with a sharp image.
• Standard : The most general and natural screen display status.
• Mild : Select this option to display with a mild image.
• Game : Select this option to enjoy dynamic image when playing a game.
• User : Select this option to use the user-defined settings.
ACC
Note
If the input is RGB PC(D-Sub analogue)/DVI PC(DVI Digital), the adjustable items in the
ACC function are color temp (9300K / 6500K).
If the PSM' setting in the Picture menu is set to Dynamic, Standard, Mild or Game
the subsequent menus will be automatically set.
Selecting a factory setting color set.
• Warm : Slightly reddish white.
• Normal : Slightly bluish white.
• Cool : Slightly purplish white.
A23
Adjusting the picture function
Selecting and Adjusting the Screen
MENU Prev
EZ Video
ACC G6500K
9300K
User
<
CSM
MENU Prev
EZ Video
ACC G
Contrast 72
Brightness 58
Red 99
Green 100
Blue 100
•Contrast
To adjust the contrast of the screen.
•Brightness
To adjust the brightness of the screen.
•Red / Green / Blue
Set your own color levels.
RGB PC / DVI PC input only
• 6500K/9300K
Selecting a factory setting color set.
6500K: Slightly reddish white.
9300K: Slightly bluish white.
• User : Select this option to use
the user-defined settings.
6500K
9300K
User
<
A24
ENGLISH
SOUND
MENU Prev
EZ Audio G
Balance
AVL
SRS WOW
Flat
Music
Movie
Speech
User
<
SOUND
MENU Prev
EZ Audio
Balance
AVL
SRS WOW
Flat
Music
Movie
Speech
User G
Equalizer
0.1 0.5 1.5 5.0 10.0
kHz
<
The best sound tone quality will be selected automatically
depending on the video type that you're currently watching.
EZ Audio
Adjusting the sound function
Note
When connected to your computer and the 'EZ Audio' setting in the audio menu is one of
Flat, Movie, Music or Speech, the available menus are Balance, SRS WOW .
Use this function to balance sound from the left and right speakers.
To adjust uneven sound volumes across all channels or signals automatically to the most
appropriate level. To use this feature, select ON. (It is adjustble to the TV input signal only.)
Set the SRS WOW menu on.
The SRS WOW function plays back the mono or stereo sound input with the dynamic surround
effects. It will provide rich and profound sound tone. If you set the SRS WOW on, user audio
setting can not be adjusted.
Balance
AVL
SRS WOW
• Flat
The most commanding and natural audio.
• Music
Select this option to enjoy the original
sound when listening to the music.
• Movie
Select this option to enjoy sublime sound.
• Speech
Select this option to watch sports broadcasting.
1) Press the MENU button and then use DD / EEbutton to select the SOUND menu.
2) Press the GGbutton and then use DD / EEbutton to select the EZ Audio menu.
3) Press GGbutton and then use DD / EEbutton to select User.
3) Press GGbutton and then use
F / G
button to select the band. Then press the
DD / EEbutton to adjust the band level.
Equalizer
A25
Selecting and Adjusting the Screen
Clock
Adjusting the timer function
The off timer automatically switches the set to Off Mode at the pre-set time.
1) Press the MENU button and then use DD / EEbutton to select the TIMER menu.
2) Press the GG button and then use DD / EEbutton to select Off Timer or On Timer.
3) Press the GG button and then use DD / EEbutton to set the hour(01~12).
4) Press the GG button and then use DD / EEbutton to set the minutes(00~59).
5) Press GGbutton and then use DD / EEbutton to set the morning(AM) or afternoon(PM).
6) Press the GG button and then use DD / EEbutton to select On or Off.
7) Only ON Timer function; Press the GG button and then DD / EEbutton to adjust volume level and channel
number.
8) Press the SET/MENU button to save.
Off / On Timer
Auto Off
(TV input only)
You must set the time correctly before using on/off timer function.
1) Press the MENU button and then use DD / EEbutton to select the TIMER menu.
2) Press the GGbutton and then use DD / EEbutton to select the Clock menu.
3) Press GGbutton and then use DD / EEbutton to select Manual.
3) Press GGbutton and then use DD / EEbutton to set the hour(01~12).
4) Press GGbutton and then use DD / EEbutton to set the minutes(00~59).
5) Press GGbutton and then use DD / EEbutton to set the morning(AM) or afternoon(PM).
6) The default value is __:__.
If Auto Off is active and there is no input signal, the TV swithchs to off mode automatically after 10 minutes.
1) Press the MENU button and then useDD / EE button to select the Auto Off menu.
2) Press the GG button and then useDD / EE button to select On or Off.
3) Press the SET/MENU button to save .
In the event of power interruption (disconnection or power failure), the clock must be reset.
Two hours after the set is switched on by the on time function it will automatically switch
back to off mode unless a button has been pressed.
Once the on or off time is set, these functions operate daily at the preset time.
Off Timer function overrides On Timer function if they are set to the same time.
The set must be in Off Mode mode for the On timer to work.
Note
This function is used to set up of current time.
You must set the time correctly before using on/off timer function.
1) Press the MENU button and then use DD / EEbutton to select the
TIMER menu.
2) Press the GGbutton and then use DD / EEbutton to select the Clock menu.
3) Press GGbutton and then use DD / EEbutton to select Auto.
4) Press GGbutton and then use FF / GG button to select the time zone
for your viewing area. Your choices are : AUTO, E.S.T(Eastern
Standard Time), C.S.T(Central Standard Time), M.S.T(Mountain
Standard Time), P.S.M(Pacific Standard Time), Alaska and Hawaii.
5) Press EE button and then use FF / GG button to set PBS channel.
6) Press EE button and then use FF / GG button to set D.ST (Daylight
Savings Time) Auto, off or On, depending in whether or not your
viewing area observes Daylight Savings Time.
7) Press SET button to save.
Auto Clock Setup
Manual Clock Setup
TIMER
MENU Prev
Clock
Off timer
On timer
Auto off
A26
ENGLISH
To choose the language in which the control names are displayed.
Use the DD / EEbuttons to select ON or OFF. It can be set up so that it can only be used
with the remote control. This feature can prevent unauthorized viewing.
In order to lock the OSD screen adjustment, set the Key lock tab to the 'on' position.
In order to unlock it, do the following :
1) Push the MENU button on the remote control and set Key lock to the 'off' position.
Adjusting the special function
Use this function to set the power indicator on the front side of the monitor to ON or OFF.
If you set OFF, it will go off after 15 seconds when the power is turned on. If you set ON
at any time, the power indicator will automatically be turned on.
Use this function to adjust the transparency of the OSD menu screen.
SPECIAL
MENU Prev
Input G
Key lock
language
Power indicator
Transparency
Zoom
Reset
TV
Video
S-Video
Component
RGB
DVI
<
SPECIAL
MENU Prev
Input
Key lock
language
Power indicator
Transparency
Zoom G
Reset
Zoom 0
H Position 0
V Position 0
Use this function to zoom in
the screen. When you turn
the product off and on again,
the default screen size will be
restored.
Press the
GG
button to
display the submenu for
Zoom.
* If the zooming value is set to
'0', vertical and horizontal
positioning cannot be
adjusted.
If you press the ?? button
once, the following Input
Signal Window will appear.
Select the signal type you
want using the DD / EEbutton.
key lock
Language
Power Indicator
Transparency
Use this function to reset the monitor to the factory default. However, language selection
and Volume will not be initialized.
Reset
Zoom
E
E
A27
Selecting and Adjusting the Screen
[Remote Control]
Press the CC button repeatedly to display the caption option as shown below. Press the SET
button to select the caption option.
Use the DD / EE buttons to select captions.
Captions
(only TV mode)
Use the DD / EE buttons to select caption mode.
Text services give a wide variety of information on all kind of subjects(ex. captioned
program lists, weather forecasts, stock exchange topics, news for hearing-impaired....) on
up to half of the TV screen. But not all stations offer text services, even though they might
offer captioning.
In the event you are receiving a poor signal, an empty black box may appear and disappear,
even when the text mode is selected. This is a normal when receiving a poor signal.
This TV is programmed to remember the CAPTION / TEXT mode it was last set to, when
you turn the power off.
Caption / Text
If sound is on, the caption will be off. On the contrary, if sound is off, the caption will be on.
* EZ Mute
Closed Captions
Closed captioning is a process which converts the audio portion of a television program into written words
which then appear as subtitles on the television screen. Closed captions allow viewers to read the dialogue
and narration of television programs.
Using Closed Captions
Captions are the subtitles of the dialogue and narration of television programs. For prerecorded programs,
program dialogue can be arranged into captions in advance. It is possible to caption a live program by using
a process called real-time captioning, which creates captions instantly. Real-time captioning is normally done
by professional reporters using a machine shorthand system and computer for translation into English.
Captioning is an effective system for the hearing-impaired, and it can also aid in teaching language skills.
Caption Tips
1. Not all TV broadcasts include closed caption signals.
2. Sometimes TV stations broadcasts four different caption signals on the same channel. By selecting From
CC1 ~ CC4, TEXT1 ~ TEXT4 you can choose which signal you view CC1 is usually the signal with the
captions, while Another mode might show demonstration or programmimg information.
3. Your TV might not receive caption signals normally in the following situations.
Poor reception conditions are encountered :
- IGNITION :
Picture may flutter, drift, suffer from black spots, or horizontal streaking. Usually caused by interference
from automobile ignition systems, neon lamps, electrical drills, and other electrical appliances.
- GHOSTS :
Ghosts are caused when the TV signal splits and follows two paths. One is the direct path and the other
is reflected off tall buildings, hills or other objects. Changing the direction or position of the antenna may
improve reception.
- SNOW :
If your receiver is located at the weak, fringe area of a TV signal, your picture may be marred by small
dots. It may be necessary to install a special antenna to improve the picture.
An old, bad or illegally recorded tape is playing.
Strong, random signals from a car or airplane interfere with the TV signal.
The signal from the antenna is weak.
The program wasn't captioned when it was produced, transmitted, or taped.
Off On EZ Mute
A28
ENGLISH
V-CHIP rating and categories
- Rating guidelines are provided by broadcast station. Most television programs and television
movies can be blocked by TV rating and/or individual categories. Movies that have been shown
at the theaters or direct-to-video movies use the Movies Rating System(MPAA) only.
PARENTAL
MENU Prev
MPAA G
Age block
Content block
Set password
Lock on/off
Canadian
Unblocked
G & above
PG & above
PG-13 & above
R & above
NC-17 & above
X
<
PARENTAL
MENU Prev
MPAA
Age block G
Content block
Set password
Lock on/off
Canadian
General
Children
<
PARENTAL
MENU Prev
MPAA
Age block
Content block G
Set password
Lock on/off
Canadian
Dialoge
Language
Sex scene
Violence
F Violence
No rating
<
For movies previously shown in theaters.
MPAA
MOVIE Ratings :
- Unblocked
- G&above : General audience
- PG&above : Parental guidance suggested
- PG-13&above : 13 years and up
- R&above : Restricted
- NC-17&above : 17 years and up
- X : Adult
If you set PG-13&above, G and PG movies will
be available : PG-13, R, NC-17, and X will be
blocked.
GENERAL TV Rating :
- Unblocked
- TV-G&above : General audience / Individual
categories do not apply.
- TV-PG&above : Parental guidance suggested
- TV-14&above : 14 years and up
- TV-MA : Mature audience
CHILDREN TV Rating :
- Unblocked
- TV-Y&above : Youth/Individual content
categories do not apply.
- TV-Y7 : Youth, 7 years and up.
Age Block
CONTENT Categories :
- Dialogue(sexual dialogue)
: Applies to TV-PG&above, TV-14.
- Language(adult language)
: Applies to TV-PG&above, TV-14&above, TV-MA.
- Sex (sexual situations)
: Applies to TV-PG&above, TV-14&above, TV-MA.
- Violence
: Applies to TV-PG&above, TV-14&above, TV-MA.
- F Violence(fantasy violence)
: Applies only to TV-PG&above.
Content Block
A29
Selecting the options
(To adjust the CAPTION & VCHIP function)
Selecting and Adjusting the Screen
1. Open the OSD. -> Press the DD / EEbuttons to select the Special menu, then press the GG button to open
the menu. -> Press the DD / EEbuttons to select the Parental sub-menu, then press the GG button to open
the sub-menu.
2. Use the number pad to enter your password when prompted.
If you have not set a passwod, enter 0000.
If you are unable to correct the problem yourself, contact the service center.
You control access to the parental controls with a password. The default password is '0000'. You can change
the password to any four-digit number.
3. Press the DD / EEbuttons to select the Set Password sub-menu,
then press the GG button to change the setting. Use the number button
pad to enter a new four-digit password when prompted.
4. Re-enter the new four-digit password when prompted.
Setting a password
Set Password
This menu is to be used to change password.
Once the correct current password is entered
using the number panel in a remote control, the
window for new password will appear. Enter
your choice of new four-digit password.
Lock On/Off
To select the VCHIP function ON/OFF.
PARENTAL
MENU Prev
MPAA
Age block
Content block
Set password G
Lock on/off
Canadian
Enter code
- - - -
PARENTAL
MENU Prev
MPAA
Age block
Content block
Set password
Lock on/off G
Canadian
Enter code
- - - -
Enter new code
- - - -
Enter new code
- - - -
Re-enter code
- - - -
Off
On
<
A30
ENGLISH
MOVIE Ratings :
- Unblocked
- C&Above : Under 8 years
- C8&Above : 8 years and up
- G&Above : General audience
- PG&Above : Parental guidance suggested
- 14+&Above : 14 years and up
- 18+ : Adult
English
MOVIE Ratings :
- Unblocked
- G&Above : General audience
- 8 ans + : 8 years and up
- 13 ans + : 13 years and up
- 16 ans + : 16 years and up
- 18 ans + : 18 years and up
Français
V-CHIP rating and categories (Optional) - Canadian Rating System
- Rating guidelines are provided by broadcast station. Most television programs and television
movies can be blocked by TV rating and/or individual categories.
Canadian
Selecting the options
(To adjust the CAPTION & VCHIP function - Canadian Only)
PARENTAL
MENU Prev
MPAA
Age block
Content block
Set password
Lock on/off
Canadian GEnglish
Français
<
A31
Selecting and Adjusting the Screen
Adjusting Screen CLOCK/PHASE and Position(only PC)
SCREEN
ARC
Auto-configure
Clock
Phase
Position
SCREEN
MENU Prev
ARC G
Auto-configure
Clock
Phase
Position
Auto
Full
4:3
Spectacle
Zoom1
Zoom2
<
SCREEN
MENU Prev
ARC
Auto-configure
Clock
Phase
Position G
Horizontal 40
Vertical 53
D
E
F G
To adjust position of the screen.
Press the
GG
button to display the submenu for position.
FF
Left
GG
Right Moving the screen position horizontally.
DD
Up
EE
Down Moving the screen position vertically.
To select the image size of
the screen.
Full / 4:3 / 16:9 / Zoom In
only TV/AV1/AV2/S-Video
4:3 aspect ratios is not
available in 20 inches
model.
FULL/1:1 in DVI/RGB
ARC
This function is suitable for analoge singnal input only. This button is for the automatic
adjustment of the screen position, clock and phase.
Auto-
Configure
To minimize any vertical bars or stripes visible on the screen background. The horizontal
screen size will also change.
Clock
To minimize any vertical bars or stripes visible on the screen background. The horizontal
screen size will also change.
Phase
Position
A32
ENGLISH
PIP/POP/PBP Mode (Multiple Screen) Functions
After selecting PIP/POP/PBP in the PIP On/Off
menu, the following menu items can be adjusted.
PIP
Source
Size
To select an input signal for PIP/POP/PBP.
To adjust the size of the PIP/POP/PBP screen. (PIP : Small, Medium, Large / PBP : Full, 4:3)
To adjust the image of the PIP/POP/PBP screen; Press the Gbutton to display the
submenu for PIP/POP/PBP image. Use the F / Gbuttons to adjust the item to the desired
level. The items of the sub-menu may vary depending on the type of the source.
Contrast
Adjust PIP/POP/PBP screen contrast.
Brightness
Adjust PIP/POP/PBP screen brightness.
Colour
Adjust the PIP/POP/PBP screen colour.
* The sub-menu can differ according to the type of the
input signal.
After selecting PIP/POP/PBP in the POP On/Off
menu, the following menu items can be adjusted.
POP
After selecting PIP/POP/PBP in the PBP On/Off
menu, the following menu items can be adjusted.
PBP
On/Off
To turn the PIP/POP/PBP sound on/off.
Sound
PIP/POP/PBP
MENU Prev
On/Off G
Source
Size
Sound
Position
Swap
Off
PIP
POP
PBP
<
PIP/POP/PBP
MENU Prev
On/Off
Source
Size
Image G
Sound
Position
Swap
Contrast 30
Brightness 50
Color 50
A33
To adjust the position to
PIP screen.
Position
PIP/POP/PBP Mode (Multiple Screen) Functions
SWAP
SWAP
PIP
POP
PBP
To switch the main-
screen and sub-screen
in PIP/POP/PBP mode.
Swap
PIP/POP/PBP
MENU Prev
On/Off
Source
Size
Sound
Position
Swap G
PIP/POP/PBP
MENU Prev
On/Off
Source
Size
Sound
Position G
Swap
<
Off
On
<
Selecting and Adjusting the Screen
A34
ENGLISH
• Install the product driver, which is provided with
the product, or download it from the web site.
(http://www.lge.com)
• See if the plug&play function is supported by
referring to the video card user manual.
Did you install the driver?
'Unknown Product' message appears when the product is connected.
• See if the power cord is properly connected to the
outlet.
• See if the power switch is turned on.
• Adjust brightness ( ) and contrast ( ) again.
• If the product is in power saving mode, move the
mouse or press any key.
• The signal from the PC (video card) is out of the
vertical or horizontal frequency range of the
product. Adjust the frequency range by referring
to the Specifications in this manual.
* Maximum resolution
17, 19 inches : 1280 x 1024 @75Hz
20.1 inches : 1600 x 1200 @60Hz
• The signal cable between PC and product is not
connected. Check the signal cable.
• Press the 'SOURCE' button in the remote
controller to check the input signal.
Is the product power cord
connected?
Does the power LED is turned on?
Power is on, power LED is green but
the screen appears extremely dark.
Does the power LED look amber?
Does the 'Out of Range' message
appear?
Does the 'Check Signal Cable'
message appear?
No image is displayed
Note
• The control locking function prevents unintentional
OSD setting change due to careless usage. To
unlock the controls.(You can only set this function
using the remote controller.)
The “Controls locked” message
appears when pressing local key.
'Controls Locked' message appears.
* Vertical frequency: To enable the user to watch the product display, screen image should be changed tens of times
every second like a fluorescent lamp. The vertical frequency or refresh rate is the times of image display per second.
The unit is Hz.
* Horizontal frequency: The horizontal interval is the time to display one vertical line. When the 1 is divided by
horizontal interval, the number of horizontal lines displayed every second can be tabulated as the horizontal
frequency. The unit is kHz.
Troubleshooting
A35
The screen image looks abnormal.
• D-SUB analog signal – Press the “AUTO” button
in the remote controller to automatically select the
optimal screen status that fits into the current
mode. If adjustment is not satisfactory, use the
Position menu in OSD .
• See if the video card resolution and frequency are
supported by the product. If the frequency is out of
range, set to the recommended resolution in the
Control Panel – Display – Setting menu.
• D-SUB analog signal – Press the “AUTO” button
in the remote controller to automatically select an
optimal screen status that fits into the current
mode. If adjustment is not satisfactory, use the
Clock menu in OSD.
• D-SUB analog signal – Press the “AUTO” button
in the remote controller to automatically select an
optimal screen status that fits into the current
mode. If adjustment is not satisfactory, use the
Phase menu in OSD.
• See if the Zoom value is set to 0. If it is, you
cannot adjust the H/V Position value.
• If the screen size is not full when connected to the
PC, execute the PIP/POP/PBP to change to full
screen mode.
• See if the TV sound is set to mono. If it is, the
sound will not be displayed.
• You cannot adjust brightness in the PIP/POP/PBP
Screen menu for the sub-screen among
PIP/POP/PBP menus. Therefore, brightness can
be different for the sub-screen.
• The proper input signal is not connected to the
signal port. Connect the signal cable that matches
with the source input signal.
• See if the TV sound is set to mono. if it is, the
sound will not be displayed.
Is the screen position wrong?
Do thin lines appear on the
background screen?
Horizontal noise appears or the
characters look blurred.
Unable to adjust the horizontal /
vertical position in the Zoom menu.
Screen size is automatically adjusted
when connected to the PC.
No sound appears in the TV channel
display window.
Brightness differs in the main and
sub screen when connected to the
PC.
The screen is displayed abnormally.
No sound appears in the TV channel
display window.
Troubleshooting
A36
ENGLISH
• Set the number of colors to more than 24 bits (true
color)
Select Control Panel – Display – Settings
– Color Table menu in Windows.
• Check the connection status of the signal cable.
Or, re-insert the PC video card.
• Several pixels (red, green, white or black color)
may appear on the screen, which can be
attributable to the unique characteristics of the
LCD panel. It is not a malfunction of the LCD.
Screen has poor color resolution (16
colors).
Screen color is unstable or mono-
colored.
Do black spots appear on the
screen?
Screen color is abnormal.
• See if the audio cable is connected properly.
• Adjust the volume.
• See if the sound is set properly.
• See if the sound is set to On in the PIP/POP/PBP
menu.
• Select the appropriate equalize sound.
• Adjust the volume.
No sound?
No sound is available when the
PIP/POP/PBP mode is engaged.
Sound is too dull.
Sound is too low.
The audio function does not work.
• See if you have selected the proper channel
mode.
• Use the automatic channel setup function.
• See if the TV antenna is properly connected.
The TV signal is not being received.
The TV function does not work.
• If you use a fixed image for a long time, the pixels
may be damaged quickly. Use the screensaver
function.
After-image appears when the
product is turned off.
After-image appears on the product.
A37
Specifications
Screen Type 17 inches (431.8mm) TFT (Thin Film Transistor)
LCD (Liquid Crystal Display) Panel
Visible diagonal size: 431.8mm
Pixel Pitch 0.264mm
Max. Resolution 1280X1024 @75Hz
Recommended Resolution
1280X1024 @60Hz
Horizontal Frequency D-SUB : 30 - 83 kHz
DVI-D : 30 - 71 kHz
Vertical Frequency 56 - 75 Hz
Synchronization Type Separate/Composite/SOG (Sync On Green)/Digital
15-pin D-Sub type, DVI-D (digital), S-Video,
composite video, Scart
Rated Voltage AC 100-240V~ 50/60Hz 1.0A
Power Consumption Normal operation: 55W
Power saving preparation state: ≤4W
Power saving state: ≤4W
Power switch off: ≤2W
Tilt Range -5˚~25˚
Tilt Stand Attached
Size (WxLxH) 501.5mm x 158.2 mm x 500.3 mm
Weight (excl. package) 6.65 kg (14.66 lbs)
Operational Condition Temperature: 10˚C ~ 35˚C , Humidity: 10% ~ 80%
Storage Condition Temperature: -20˚C ~ 60˚C , Humidity: 5% ~ 95%
LCD Panel
Video Signal
Input Connector
Power
Tilt
Dimension/Weight
Environmental Conditions
[17 inches]
A38
ENGLISH
Screen Type 19 inches (482.6mm) TFT (Thin Film Transistor)
LCD (Liquid Crystal Display) Panel
Visible diagonal size: 482.6mm
Pixel Pitch 0.294mm
Max. Resolution 1280X1024 @75Hz
Recommended Resolution
1280X1024 @60Hz
Horizontal Frequency D-SUB : 30 - 83 kHz
DVI-D : 30 - 71 kHz
Vertical Frequency 56 - 75 Hz
Synchronization Type Separate/Composite/SOG (Sync On Green)/Digital
15-pin D-Sub type, DVI-D (digital), S-Video,
composite video, Scart
Rated Voltage AC 100-240V~ 50/60Hz 1.0A
Power Consumption Normal operation: 60W
Power saving preparation state: ≤4W
Power saving state: ≤4W
Power switch off: ≤2W
Tilt Range -5˚~25˚
Tilt Stand Attached
Size (WxLxH) 542.5mm x 222.8 mm x 541.4 mm
Weight (excl. package) 7.75 kg (17.09 lbs)
Operational Condition Temperature: 10˚C ~ 35˚C , Humidity: 10% ~ 80%
Storage Condition Temperature: -20˚C ~ 60˚C , Humidity: 5% ~ 95%
LCD Panel
Video Signal
Input Connector
Power
Tilt
Dimension/Weight
Environmental Conditions
[19 inches]
A39
Specifications
Screen Type 20.1 inches (510mm) TFT (Thin Film Transistor)
LCD (Liquid Crystal Display) Panel
Visible diagonal size: 510mm
Pixel Pitch 0.2805mm
Max. Resolution 1600X1200 @60Hz
Recommended Resolution
1600X1200 @60Hz
Horizontal Frequency D-SUB : 30 - 92 kHz
DVI-D : 30 - 80 kHz
Vertical Frequency 56 - 85 Hz
Synchronization Type Separate/Composite/SOG (Sync On Green)/Digital
15-pin D-Sub type, DVI-D (digital), S-Video,
composite video, Scart
Rated Voltage AC 100-240V~ 50/60Hz 1.2A
Power Consumption Normal operation: 70W
Power saving preparation state: ≤4W
Power saving state: ≤4W
Power switch off: ≤2W
Tilt Range -5˚~25˚
Tilt Stand Attached
Size (WxLxH) 575.1mm x 221.1 mm x 557.5 mm
Weight (excl. package) 8.7 kg (19.18 lbs)
Operational Condition Temperature: 10˚C ~ 35˚C , Humidity: 10% ~ 80%
Storage Condition Temperature: -20˚C ~ 60˚C , Humidity: 5% ~ 95%
LCD Panel
Video Signal
Input Connector
Power
Tilt
Dimension/Weight
Environmental Conditions
[20.1 inches]
A40
ENGLISH
Mode 18 : Analogue only
Mode 19 : Digital only
PC Mode – Preset Mode
Power LED
Mode Product
Normal Operation
Pre-power Saving State
Power Saving State
Power Switch Off
Blue
Amber
Amber
-
Preset mode
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Preset mode
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
1
2
3
4
5
6
7
8
9
10
640 x 350
640 x 480
640 x 480
640 x 480
720 x 400
800 x 600
800 x 600
800 x 600
832 x 624
1024 x 768
31.469
31.469
37.500
43.270
31.469
37.880
46.880
53.670
49.720
48.360
70
60
75
85
70
60
75
85
75
60
VGA
VGA
VGA
VGA
VGA
VESA
VESA
VESA
MAC
VESA
11
12
13
14
15
16
17
18
19
1024 x 768
1024 x 768
1152 x 870
1152 x 900
1280 x 1024
1280 x 1024
1600 x 1024
1600 x 1200
1600 x 1200
60.020
68.680
68.680
61.800
63.980
79.980
62.110
75.000
73.530
VESA
VESA
MAC
MAC
VESA
VESA
VESA
VESA
VESA
75
85
75
66
60
75
60
60
60
[17, 19 inches]
[20.1 inches]
Preset mode
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Preset mode
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
1
2
3
4
5
6
7
640 x 350
720 x 400
640 x 480
640 x 480
800 x 600
800 x 600
832 x 624
31.469
31.468
31.469
37.500
37.879
46.875
49.725
70
70
60
75
60
75
75
VGA
VGA
VGA
VESA
VESA
VESA
MAC
8
9
10
11
12
13
1024 x 768
1024 x 768
1152 x 870
1152 x 900
1280 x 1024
1280 x 1024
48.363
60.123
68.681
61.805
63.981
79.980
VESA
VESA
MAC
MAC
VESA
VESA
60
75
75
66
60
75
A41
Specifications
ANT IN PC
Audio
D
Audio
R
Audio
L
S-Video
Locking Device
Use this locking cable (optional) to
prevent theft.
VESA wall mounting
Connected to another object (stand type and wall-mounted type.
This monitor accepts a VESA-compliant mounting interfacepad.optional)
For further information, refer to the VESA Wall Mounting Instruction Guide.
VESA wall mounting
Theft prevention locking device
A42
ENGLISH
M1740A/M1940A/M2040A
User's Guide
P/NO. : 3828TUL289S(0412-REV00)
Printed in Korea
http://www.lge.com
Please read this manual
carefully before operating your set.
Retain it for future reference.
Record model number and serial number of the set.
See the label attached on the back cover and quote
this information to your dealer when you require service.
