Contents

Manual 2

<46> M4300
Listen to voice mail Menu-4-7
This menu provides you with a quick way of accessing
your voice mailbox (if provided by your network).
Before using this feature, you must enter the voice
centre number obtained from your network operator.
When new voice message is received, the symbol
will be displayed on the screen. Please check with
your network provider for details of their service in
order to configure the handset correctly.
Info message
(Network dependent) Menu-4-8
Info service messages are text messages sent by the
network to mobile phone users. They provide general
information such as weather reports or traffic condi-
tions. Each type of information has the number; there-
fore, you can contact the service provider as long as
you have input the certain number for the information.
When you receive an info service message, a popup
message will indicate a new message receipt or the
info service message will be displayed directly. The
following options are available when viewing info serv-
ice messages.
Read (Menu-4-8-1)
1. Select Read to view the message, it will be displayed
on the screen.
2. The message will be shown until another
message is reached.
Topics (Network dependent) (Menu-4-8-2)
• Add new: You can add a new info service message
number with its nickname in the phone or in the SIM (if
the SIM is available).
• View list: You can view the list of all the info service
message numbers. Press the left soft key [Options] to
edit or delete the info message category.
• Active list: You can set whether you will receive each
info service message or not using the left soft key
[On/Off] in this list.
Messages
M4300 <47>
Messages
Templates Menu-4-9
There are pre-defined messages in the list. You can
view and edit the template messages or create new
messages. Two types of templates are available: Text
and Multimedia.
Text template (Menu-4-9-1)
• Please call me back.
• I’m late. I will be there at...
• Where are you now?
• I am on the way.
• Top urgent. Please contact.
• I love you.
The following options are available.
] View: You can view the selected template.
] Delete: Deletes the selected template.
] Add new: Use this to create new template.
] Send via:
] Edit: Use this to write a new message or edit the
selected template message from the text template
list.
] Delete all: Deletes all the text templates.
Multimedia template (Menu-4-9-2)
You can create a multimedia template after pressing
the left soft key [Add new]. And the multimedia tem-
plates you saved as a template while creating a multi-
media message in the Write multimedia message.
] Preview: Select this option to check out the multime-
dia message you've created. Each slide is sequen-
tially played back automatically. You can also move
to another slide from the currently played slide using
the left/right navigation keys. To replay the message,
press the left soft key [Replay].
] Save: Saves the message in drafts or as a template.
] Edit subject:
] Add slide: Add a slide before or after the current
slide.
] Move to slide: Select this option to move to another
slide from the current slide.
] Delete slide: Deletes the current slide.
] Set slide format: You can set the following slide for-
mat.
- Set timer: Enter the timer in each field using the
numeric keypad.
<48> M4300
] T9 dictionary: Select the T9 language for T9 input
mode. You can also deactivate the T9 input mode by
selecting T9 off.
] Exit: Exits from the Write multimedia message menu.
Settings
Menu-4-0
Text message (Menu-4-0-1)
This menu lets you set up default SMS information.
] Message types: Set the default message type (Text,
Voice, Fax, Natl. Paging, X.400, E-mail, ERMES). The
network can convert the messages into the selected
format.
] Validity period: Set the length of time for which your
text messages will be saved at the SMS center while
attempts are made to deliver them to the recipient.
Possible values are 30 minutes, 1 hour, 6 hours, 12
hours, 1 day, 1 week and the maximum authorised by
your network operator.
] Delivery report: Select whether to activate or deac-
tivate the report function. When this function is acti-
vated, the network informs you whether or not your
message has been delivered.
] Reply charging: Allows the recipient of your SMS
message to send you a reply via your message cen-
tre, if the service is provided by the network.
] SMS centre: Saves or changes the number of your
SMS centre when sending text messages. You must
obtain this number from your service provider.
Multimedia message (Menu-4-0-2)
Via this menu, you can set up the default multimedia
message information.
The following options are available.
] Priority: Set the priority for the multimedia messages
you will send.
] Validity period: Set the length of time for which your
multimedia messages will be saved in the network
server while attempts are made to deliver them to
the recipient. Possible values are 1 hour, 12 hours,
1 day, 1 week and the maximum authorised by your
network operator.
] Subject:
Messages
M4300 <49>
Messages
] Delivery report: Select whether to activate or deac-
tivate the report function. When this function is acti-
vated, the network informs you whether or not your
message has been delivered.
] Read reply:
] Auto download
-
On: If you select this, messages are downloaded
automatically on receipt.
-
Off: Requires you to confirm you want to download
the message.
- Home network only: If you select this, messages
are downloaded automatically on receipt in your
home network area. And outside your home service
area, it requires you to confirm you to download
the message.
-
Reject: If you select this, every message will be
rejected on receipt.
] Network settings: If you select the multimedia mes-
sage server, you can set the URL for multimedia
message server.
] Permitted types: Set the permitted type. Possible val-
ues are Personal, Advertisements and Information.
1. Hold down key in standby mode.
2. You can check the following submenus.
• Home: You can listen to voice mails by selecting
Home.
• Roaming: Even when you are abroad, you can listen
to voice mails if roaming service is supported.
Email (Menu-4-0-3)
To send the email, you should set up the email account.
Refer to Email at page 48 first.
]
Message edit
1. Select Email from the Write Message menu.
2. You can input up to 20 addresses in the To, Cc fields
and You can input up to 10 addresses in the Bcc
field.
n Note To input @, select the key [Symbol], and then
press 9 numeric key pad to input or press video
call key.
3. Input the title of the mail to be sent in the Subject
field.
<50> M4300
Messages
4. Input the content of the mail to be sent in the
Message field.
5. Specify up to 4 files to attach in the Attach field.
6. When you have finished writing a message, press
the key. You can send the message by selecting
Send now from the popup list and you can save
the message by selecting Save as draft. You can
also preview the message by selecting Preview from
the popup list.
Voice mail centre (Menu-4-0-4)
You can receive the voicemail if this feature is sup-
ported by your network service provider. When a new
voicemail is arrived, the symbol will be displayed on
the screen. Please check with your network service
provider for details of their service in order to config-
ure the phone accordingly.
Info message (Menu-4-0-5)
Info service messages are text messages delivered by
the network to GSM. They provide general information
such as weather reports, traffic news, taxis, pharma-
cies, and stock prices. Each type of information has the
number; therefore, you can contact service provider
as long as you have input the certain number for the
information. When you have received an info service
message, you can see the popup message to show you
that you have received a message or the info service
message is directly displayed. The following options
are available.
] Receive: If you select Yes, your phone will receive
Info service messages. Otherwise, it will not receive
Info service messages any more.
] Alert: If you select Yes, your phone will beep when
you have received Info service message numbers.
Otherwise, it will not beep even though you have
received info service messages.
] Languages: You can select the language you want
by pressing [On/Off]. Then, the info service message
will be shown in the language that you selected.
Push message (Menu-4-0-6)
You can order push messages from WAP service pro-
viders. Push messages are notifications of, for exam-
ple, news headlines and they can contain a text mes-
sage or the address of a WAP service. For availability
and subscription, contact your WAP service provider.
In this menu, you can set the push message receive
option.
] Receive on/off: If you select Receive on, all push
messages will be accepted irrespective of the origi-
nation.
M4300 <51>
] Auto download: Will only accept the push messages
from T-Mobile.
After selecting a push message, the following menus
are available.
• Information: Shows the information of the current
push message.
•
Load: Connects to a specific site using the informa-
tion in the current push message.
• Delete: Deletes the current push message.
• Delete All: Deletes all the messages in inbox (includ-
ing SMS, MMS, etc.).
Push SMSC server (Menu-4-0-7)
Messages
Icon Description
Read Push Message
Unread Push Message
<52> M4300
How to access t-zones
You can use your phone for so much more than just
texting and talking. t-zones provides information you
need such as news, weather forecast, information on
sports or traffic when you need it. In addition, t-zones
provides superior multimedia services such as the lat-
est ring tones, wallpapers or games for your interest.
Press the menu key ( ) and select t-zones using
navigation keys. You can also access t-zones by press-
ing key in standby mode.
n Note The additional cost for services may be depend-
ent on the network.
t-zones/Contacts
You can save phone numbers and their corresponding
names in the memory of your SIM card. In addition,
you can save up to 200 numbers and names in the
phone memory.
Press the left soft key [Menu] in standby mode, then
select Contacts.
Search Menu-6-1
1. Select Search. You are asked to enter a name.
2. Enter the start of the name that you wish to find and
press left soft key [Search].
] You can access the Contacts directly by pressing
the up navigation key ( ) in standby mode.
n Note You can also scroll through the Contacts from
the beginning, by pressing the left soft key [List]
directly.
3. After finding the desired contact, you can make a
call to the number by pressing the key. Or press
the left soft key [Option] to use the following options.
] Edit: You can edit the name and number.
] Write text message: Use this to write a text message
to the contact.
] Write multimedia message: Use this to write a multi-
media message to the contact.
M4300 <53>
] Copy: Use this to copy the contact entry from SIM to
the phone memory or vice versa.
] Main number: Select which number will be the main
number. The main number will be displayed first
] Delete: Deletes the contact.
Add new Menu-6-2
You can add a contact entry using this function.
There are 2 memories: Phone memory and SIM memo-
ry. To select the memory, go to Set memory [Menu-6-5-1].
The phone memory capacity is 200 entries. You can
enter up to 20 characters in each name in the phone
memory. The SIM card memory capacity depends on
the SIM card.
1. Press the Menu key and select Contacts → Add
new.
2. You can add new contact entries to the SIM memory
or the phone memory. To select the memory, go to
Set memory [Menu-6-5-1]. (Refer to page 65.)
• Adding new entries into SIM memory
You can enter a name and number, and select the
required group. (Depends on the SIM)
• Adding new entries into the phone memory
You can enter a name, numbers, E-mail address and
memo, and select the required group. And select
which number will be the main number.
Caller groups Menu-6-3
You can list up to 20 contacts per group. There are 7
pre-defined groups, where you can create lists.
1. Select Caller groups. All group lists will be dis-
played: Family, Friends, Colleague, VIP, Group 1,
Group 2, and Group 3.
2. Select the group name that you want to manage by
pressing the left soft key [Option]. The following sub-
menus will be displayed.
] Member list: Displays the member list in the group.
] Group ringtone: Use this to select the ring tone to
be used when you receive a voice phone call from a
person in the group.
] Group icon: Use this to select the graphic icon to be
displayed when you receive a call from a person in
the group.
] Add member: Add a member to the group. You can
add up to 20 members per group.
] Remove member: Removes the member from the
group member list. The contact entry still remains in
Contacts.
] Rename: Assigns a new name to the group.
] Remove all : Allows you to delete all the members in
the group.
t-zones/Contacts
<54> M4300
Speed dial Menu-6-4
You can assign any of the keys to with a
name list entry.
You can call directly by pressing this key for 2-3 sec-
onds.
1. Open Contacts first by pressing the right soft key
[Contacts] in standby mode.
2. Scroll to Speed dial, then press [Select].
3. To add a number to Speed dial, select (Empty). Then,
you can search the name through Contacts.
4. You can change or delete a speed dial number, make
a call or send a message by pressing the left soft
key [Option].
Settings Menu-6-5
Default memory (Menu-6-5-1)
You can select the memory for the Contacts feature
between the SIM and the phone.
View options (Menu-6-5-3)
You can set the Contact display option.
] Names only: When you search Contacts, the list dis-
plays only names.
] Name and number: When you search Contacts, the
list displays names and numbers.
] With picture: When you search Contacts, the list
displays names and corresponding pictures.
Copy all Menu-6-6
You can copy/move entries from the SIM card memory
to the phone memory and vice versa.
] SIM to Handset: Use this to copy the entry from the
SIM Card to the Phone memory.
] Handset to SIM: Use this to copy the entry from the
Phone memory to the SIM Card.
The following options are available.
• Keep original: When copying, the original dial
numbers are kept.
• Delete original: When copying, the original dial num-
bers will be erased.
Contacts
M4300 <55>
Delete all Menu-6-7
You can delete all entries in the SIM and/or phone.
This function requires the security code.
Press to return to standby mode.
Information Menu-6-8
] Service dial number (SIM dependent): Use this to
view the list of Service Dialling Numbers (SDN)
assigned by your network operator (if supported by
the SIM card). Such numbers include the emergen-
cy, directory enquiries and voice mail numbers.
1. Select the Service dial number option.
2. The names of the available services will be shown.
3. Use the up/down navigation keys to select a
service. Press .
] Memory status: You can check the current memory
status of the SIM card or the phone memory.
] Own number (SIM dependent): Use this to display
your phone number in the SIM card.
] Business card: This option helps you to make your
own name card. Key in the name, mobile phone
number, home number, office number, Fax number,
and E-mail address. After creating the name card,
you can access the following options using the left
soft key [Options].
•
Edit: You can edit the business card.
• Send via Bluetooth: Allows you to send the business-
card via bluetooth
•
Delete: Deletes the selected business card.
Contacts
<56> M4300
Press the menu key ( ) and select Organiser.
Alarm clock Menu-7-1
There are 5 alarm clocks available. Set the alarm to
ring at a specific time.
After selecting an alarm clock using the left soft key
[Select],
1. Alarm on/off: Select On using the left/right navi-
gation key. To deactivate the alarm function, select
Off.
2. Alarm time: Enter the alarm time using the
numeric keys
3. Repeat: Select the desired one from Once,
Mon~Fri, Mon~Sat, and Everyday using the left/right
navigation key.
4. Alarm melody: Select the desired alarm melody
using the left/right navigation key.
5. Press the left soft key [OK].
6. You can edit the alarm clock name. After keying in
the name, press the left soft key [OK].
When an alarm function is activated, “ ” is shown
in standby mode.
When the alarm time is reached, it sounds the alarm
melody.
] To turn off the alarm, press the right soft key [Quit].
Calendar Menu-7-2
When you enter this menu, a calendar appears. A
square cursor is located on the current date. You can
move the cursor to another date using navigation keys. On
the calendar, you can use the following keys.
You can enter a schedule or memo in the scheduler by
pressing the left soft key [Options].
] Add new: Select this to enter a new schedule or a
memo. After a schedule note or memo is entered on
a date, the date is shown in a different colour and
“ ” (schedule), “ ” (memo) appears on the
right bottom of the screen. This function reminds you
of your schedule. And the phone will sound an alarm
tone if you set the phone to do so.
] View daily schedules: Shows the schedule note
or memo for the chosen day. Press the left soft key
[Options] to edit or delete the note you selected.
Organiser
skips back a year.
skips forward a year.
skips back a month.
Each press of
skips forward a month.
M4300 <57>
] Delete past: Select this to delete the expired sched-
ule notes that have already been notified. You are
asked to confirm this action.
] Delete all: Select this to delete all the schedule
notes and memos. You are asked to confirm this
action.
] Go to date: Typing a date, you can go to the date
directly.
] Set alarm tone
Press the menu key ( ) and select Tools using the
navigation keys.
Memo Menu-7-3
You can make up to maximum 10 memos.
1. Select a memo pad you would edit.
2. If being a (Empty), Add new by pressing the left soft
key [Select].
3. Input the memo and then press the left soft key [OK].
Calculator Menu-7-4
Using this feature, you can use the phone as a cal-
culator. The calculator provides the basic arithmetic
functions: addition, subtraction, multiplication and divi-
sion. (You can enter numbers up to the second decimal
place).
Using the Calculator
1. Enter the first number using the numeric keys.
2. Press the corresponding navigation key to select a
mathematical function.
n Note To erase any mistakes or clear the display, press
the key.
To include a decimal point, press the key.
To include a minus sign, press the key.
3. To calculate the result, press OK key.
4. After calculation, press the left soft key [Reset] to
return to the menu.
Organiser
<58> M4300
Unit converter Menu-7-5
This converts any measurement from one unit to
another.
There are 7 types that can be converted into units:
Currency, Surface, Length, Weight, Temparature,
Volume and Velocity.
1. Select one of four unit types by pressing the
left soft key [Unit].
2. Move to the current unit section by pressing the
down navigation key.
3. Select the unit you want to convert using the left/
right navigation keys.
4. Move to the Convert unit section by pressing the
down navigation key.
5. Select the unit you want to convert to, using the left/
right navigation keys.
6. Input numbers using the numeric keys. Conversion is
calculated automatically.
n Note You can input a decimal number by pressing the
key.
World time Menu-7-6
You can check the current time of Greenwich Mean
Time (GMT) and major cities around the world, using
the left/right navigation keys.
The screen shows the city name, current date and
time.
To select the time zone in which you are located, pro-
ceed as follows:
1. Select the city corresponding to your time zone by
pressing the left/right navigation keys. The local date
and time are displayed.
2. If you want to change the time display in standby
mode to the selected time, press the left soft key
[Set].
n Note The time zone setting of each city in World time
menu may be affected by network condition.
Voice recorder Menu-7-7
You can record a memo. You can record up to 10 voice
memos up to a maximum of 20 seconds each.
You can play or delete the recorded memo or record
new voice memo using the left soft key [Options] key.
Organiser
M4300 <59>
n Note In standby mode, you can go directly to the Voice
recorder menu by pressing the down navigation
key.
Record
1. Press and hold down key in standby mode.
2. Once recording is started, the message ‘Recording...’
and the remaining time is displayed.
3. When you finish recording, press left soft key
[Save].
n Note If all memo locations are full, you must delete an old
memo before recording a new one.
View list
The phone shows the voice memo title which you have
recorded by pressing in standby mode. You can
play back or delete the recorded voice memo.
] Playback: Allows you to play back all memos record-
ed, starting with the most recent memo.
] Write multimedia message: You can write multime-
dia messages using the voice memo.
] Delete: Deletes the voice memo.
] Delete all: Allows you to delete all the memos. Press
the left soft key[Yes] to confirm.
Settings
] Duration: You can set the Voice recorder duration
as 30 secs and 1 minute.
Memory status Menu-7-8
You can check the current memory status of each
repository:
Free memory, Text message, Multimedia message,
Inbox, Outbox, Drafts, Multimedia templates, Messages
in SIM, Push message, Voice memo, Photos, Pictures,
Sounds, Games & more.
And you can go to each repository to manage it.
SW version Menu-7-9
You can check the current Model code, Country code,
software version, and network code of your phone.
Organiser
<60> M4300
With the M4300 phone, you can takes pictures and
save them. After taking a picture, you can also send it
via MMS (Multimedia Messaging Service) right away.
Take photo Menu-8-1
Press the Menu key and select Camera → Take photo
using navigation keys. Or, you can directly open the
camera module by a press of the Camera key in stand-
by mode. The camera module opens and you’ll see the
view to be captured.
Before shooting, you can set the following options
n Note If the battery is too low, you may not be able tot
use the Camera feature.
1. Center the desired option menu using the left/right
navigation keys.
2. Select the desired value with the up/down
navigation keys.
3. After finishing all the setting, focus on the subject to
capture and press the Camera key or OK key. With a
click, the image is captured and the following menu
bar appears.
n Note If Auto save [Menu-8-4-1] is set to On, the cap-
tured image is automatically saved without dis-
playing this menu bar. (Refer to page 76.)
4. To save the image, center the ( ) and press . If you
don’t want to save the image, center the ( ) and
press . You can immediately access My photos
by pressing the left soft key [My photos].
You can also send the image via multimedia mes-
sage by selecting ( ). For further information
regarding multimedia message writing, refer to page
49.
preview option
menu bar
Back
1. Size : Home screen, Contact, Front home,
640X480, 320X240
2. Quality ( ): Standard( )/ Super fine
( )/Fine ( )
3. Flash ( ):Always off, Always on, When taking
4. Multishot ( ): 1, 3. 6. 9
5. Zoom:( ): X1
6. Brightness ( ) : 2.0, -1.5, -1.0, 0.0, +0.5, +1,
+1.5, +2.0
7. WB White balance ( ): Auto, Fluorescent,
Cloudy, Daylight.
8. Nightmode ( ): On/Off
Cancel
Save
Send via multimedia
message
Camera
M4300 <61>
Fun frames Menu-8-2
You can enjoy taking pictures in diverse preset frames.
7 preset frames are available. Press the Menu key and
select Camera → Take in modes using navigation keys.
Before shooting, you can set the following options.
1. Center the desired option menu using the left/right
navigation keys.
2. Select the desired value with the up/down naviga-
tion keys.
3. After finishing all the setting, focus on the subject to
capture and press the Camera key or OK key. With a
click, the image is captured and the following menu
bar appears.
n Note If Auto save [Menu-8-4-1] is set to On, the cap-
tured image is automatically saved without dis-
playing this menu bar. (Refer to page 76.)
To save the image, center the ( ) and
press . If you don’t want to save the image,
center the ( ) and press .
You can also send the image via multimedia message
by selecting ( )
1. Fun frame ( ): Select the desired one from
5 preset frames.
2. Quality ( ): Standard/ Super fine/ Fine.
3. Flash ( )
4. Zoom ( ): x1
5. Brightness ( ): -2.0, -1.5, -1.0, 0.0, +0.5, +1,
+1.5, +2.0
6. WB White balance ( ): Auto( )/
Fluorescent( )/ Cloudy ( )/Daylight.
7. Nightmode ( ): On/Off
8. Effect: Normal/ Sepia/ Black and white.
9. Memory ( ): Shows the current
memory status of the phone or SD card..
Back n Note If the memory is full, “Memory full” message
is popped up and you cannot save a photo.
Create space by eleting old photos in My
photos.
preview option
menu bar
Camera
Cancel
Save
Send via multimedia
message
<62> M4300
My photos Menu-8-3
Press the Menu key and select Camera → My photos
using navigation keys. All the photos taken in the Take
photo and Take in modes are stored in this menu. The
latest taken picture comes first.
The photos are classified into General photos, Mode
photos, and Phonebook photos. And in All photos, you
can view all the photos. With pictures, you can do the
following by pressing the left soft key [Options].
] Delete: Deletes the selected photo.
n Note To clear up the My photos, go to Camera →
Settings → Delete all photos [Menu-8-4-2].
] Send via MMS: You can also send the image via mul-
timedia message by selecting this menu. For further
information regarding multimedia message writing,
refer to page 49.
] Set as wallpaper: You can set the photo as
wallpaper.
] Rename: You can change the name of the
selected photo.
] Information: You can check the name, resolution,
size, and date and time of the selected photo.
Settings Menu-8-4
Press the Menu key and select Camera → Settings
using navigation keys.
Auto save: If you set this On, the captured images are
automatically saved without displaying the Save menu
bar.
Delete all photos: Use this menu to delete all the pho-
tos.
You are asked to confirm this action.
Memory status Menu-8-5
Press the Menu key and select Camera → Memory
status using navigation keys.
Camera
M4300 <63>
Profiles Menu-9-1
In Profiles, you can adjust and customise the phone
tones for different events, environments, or caller
groups.
There are six preset profiles: Vibrate Only, Silent,
General, Loud, Headset and Car. Each profile can be
personalised.
Press the menu key ( ) and select Profiles using
navigation keys.
Activate - Changing the profile (Menu-9-1-1)
1. A list of profiles is displayed.
2. In the Profile list, scroll to the profile you want to
activate and press the left soft key [Select] or OK
key ( ).
3. Then, select Activate.
Personalise - Customising profiles
(Menu-9-1-2)
Scroll to the desired profile in the Profile list and select
Personalise. The profile setting option opens. Set the
option as required.
1. Call alert type: Set the alert type for incoming
calls.
2. Ringtone: Select the desired ringtone from the list.
Scroll through the list using up/down navigation
keys. You can hear the desired tone prior to making
a selection.
3. Ring volume: Set the volume of the ringing tone.
4. Message alert type: Select the alert type for receiv-
ing a message.
5. Message tone: Select the alert tone for receiving
a message.
6. Keypad tone: Select the desired keypad tone.
7. Keypad volume: Set the volume of keypad tone.
8. Effect sound volume: Set the volume of effect
sound.
9. Power on/off volume: Set the volume of the ringing
tone when switching the phone on/off.
Rename - Customising profiles
(Menu-9-1-3)
You can rename a profile and give it any name you
want.
Vibrate only, Headset and Car profiles cannot renamed.
Settings
<64> M4300
1. To change the name of a profile, scroll to the profile
in the profile list and select Rename.
2. Key in the desired name and press the OK key or the
left soft key [OK].
Press the menu key ( ) and select Settings using
the navigation keys.
Date & Time Menu-9-2
This option lets you change the current time and date
displayed.
The following options are available.
Set date (Menu-9-2-1)
• Set date
Use this to enter the day, month and year. You can
change the date format via the Date Format menu
option.
• Date Format
MM/DD/YYYY (month/day/year)
YYYY/MM/DD (year/month/day)
DD/MM/YYYY (day/month/year)
Set time (Menu-9-2-2)
•
Set Time
Use this to enter the current time. You can choose
the time format via the Time format menu option.
• Time Format
12-hours
24-hours
Favourites Menu-9-3
This option allows you to add your own favourites to
the list already provided. Once you create your own
menu, you can access the desired function quickly in
the idle screen by pressing the right soft key.
Phone settings Menu-9-4
Many features of your phone can be customised to suit
your preferences. All of these features are accessed
via the Phone settings menu.
Display settings (Menu-9-4-1)
] Wallpaper: Use this to set up the display on the LCD
screen in standby mode.
Settings
M4300 <65>
] Menu colour: Your phone provides you with 4 menu
colour themes. Set the menu colour by scrolling and
pressing the left soft key [Select].
] Greeting note: If you select On, you can edit the text
which will be displayed in standby mode.
] Backlight: Use this to select whether or not the
phone uses the backlight. A small increase in stand-
by/talk time can be achieved by turning the backlight
off.
] Information window: You can preview the current
state of the selected menu before opening the menu.
The state is shown on the bottom of the screen.
Languages (Menu-9-4-2)
You can select the display language. When the lan-
guage option is set to Automatic, the language is auto-
matically selected according to the language of the
SIM card used. English will be set if the language on
the SIM card is not supported by the phone.
Call settings Menu-9-5
To change the settings for call diverting.
Call divert (Menu-9-5-1)
When this network service is activated, you can direct
your incoming calls to another number, for example, to
your voice mailbox number. For details, contact your
network operator. Select one of the divert options, for
example, select If busy to divert voice calls when your
number is busy or when you reject incoming calls.
The following options are available.
All voice calls: Diverts all voice calls unconditionally.
If busy: Diverts voice calls when the phone is in use.
If no reply: Diverts voice calls which you do not
answer.
If out of reach: Diverts voice calls when the phone is
switched off or out of coverage.
All data calls: Diverts to a number with a PC connec-
tion unconditionally.
All fax calls: Diverts to a number with a fax connection
unconditionally.
Each option has the following menu:
Settings
<66> M4300
] Activate: Activates the corresponding service.
- To voice mail centre: Forwards to message centre.
This function does not apply to All data calls and
All fax calls menus.
- To other number: Input the number for call divert-
ing.
- To favourite number: After entering up to 5 fre-
quently used phone numbers, you can divert calls
to them.
] Cancel: Cancels the selected call divert.
] View status: You can check the status of the service.
Answer mode (Menu-9-5-2)
Select the desired mode to answer a call.
] Flip open: When the phone rings, you can answer a
call simply by opening the folder.
] Any key: When the phone rings, you can answer a
call by pressing any key except
the key and the right soft key ( ).
] SEND key only: You can answer a call only by
pressing the send key.
Send my number (Menu-9-5-3)
This network service lets you decide whether your
phone number is displayed (On) or hidden (Off) from
the person you are calling. Select Set by network to
reset the phone to the setting that you have agreed
upon with your service provider.
Call waiting (Menu-9-5-4)
The network will notify you of a new incoming call
while you have a call in progress. Select Activate to
request the network to activate call waiting, Cancel to
request the network to deactivate call
waiting, or View status, to check if the function is
active or not.
Minute minder (Menu-9-5-5)
When set to On, the phone will beep every minute dur-
ing an outgoing call to keep you informed of the length
of the call.
Auto redial (Menu-9-5-6)
Select On, and your phone will make a maximum of
four attempts to connect the call after an unsuccessful
call attempt.
Settings
M4300 <67>
Closed user group (Network dependent)
(Menu-9-5-7)
Restricts usage of the phone with numbers that belong
to certain user groups. When this function is used,
every outgoing call is associated with a group index.
If a group index is specified, it is used for all outgo-
ing calls. If no group index is specified, the network
will use the preferential index (a specific index that is
stored in the network).
] Default: Activates the default group agreed on with
the network operator.
] Set: Select this to activate the selected CUG Index.
] Edit: You can edit the CUG name and CUG Index.
] Delete: Delets the selected CUG.
] Delete all: Delets all CUG.
Security settings Menu-9-6
Various passwords are used to protect certain fea-
tures of your phone. Refer to page 24-25 for the various
passwords.
n Note Before disabling the PIN code request feature,
you must enter your PIN.
PIN code request (Menu-9-6-1)
When the PIN code request feature is enabled, you
must enter your PIN each time you switch the phone
on. Consequently, any person who does not have your
PIN cannot use your phone without your approval.
The following options are available:
•
On: You must enter the PIN each time the phone is
switched on.
• Off: The phone connects directly to the network when
you switch it on.
Handset lock (Menu-9-6-2)
When the Handset lock feature is enabled, the phone
is locked and you must enter the phone password
each time the phone is switched on.
The password is factory set to 0000. To change the
phone password, refer to the Change codes–Security
code menu option (Menu-9-5-5-1). Once the correct
password has been entered, you can use the phone
until you switch it off.
The following options are available:
• When switch on
Settings
<68> M4300
] Off: You do not need to enter the phone password
when you switch the phone on.
] Always on: You are required to enter the phone
password when you switch the phone on.
] When SIM changed: Your phone will request secu-
rity code only when you change your SIM card.
• Immediately
] After entering the correct security code, the phone
will lock after going into the idle state. If you want
to disable this phone lock, you should enter the right
security code after pressing the right soft key. If you
power off in the phone lock state, when the phone is
next powered on, the phone is in the lock state.
Call barring (Network dependent)
(Menu-9-6-3)
Call barring lets you restrict the making and receiving
of calls with your phone. For this function, you need the
barring password, which you can obtain from your
service provider.
The following options are available:
] All outgoing calls: No call can be made.
] Outgoing international: International calls cannot be
made.
] O/G international except home country: When
abroad, calls can be made only to numbers within the
current country and to your home country, the coun-
try where your home network provider is located.
] All incoming: No call can be received.
] Incoming when abroad: Calls cannot be received
when you are using your phone outside your home
country.
] Cancel all barrings: All call barring settings are
deactivated; calls can be made and received normally.
] Change password: Use this to set and change the
call barring password obtained from your service
provider using this option. You must enter the current
password before you can specify a new one. Once
you have entered a new password, you are asked to
confirm it by entering it again.
n Note To use Call barring service, you must input the
network password. When calls are barred, calls
may be possible to certain emergency numbers
on some networks.
Settings
M4300 <69>
Fixed dial number (FDN)
(SIM dependent) (Menu-9-6-4)
Use this to restrict your outgoing calls to selected
phone numbers, if this function is supported by your
SIM card. The PIN2 code is required.
The following options are available:
] Enable: Use this to only call phone numbers saved in
the phonebook. You must enter your PIN2 code.
] Disable: Allows you to call any number.
] Number list: Use this to view the numbers saved as
fixed dial numbers.
n Note Not all SIM cards have a PIN2. If your SIM card
does not, this menu option is not displayed.
Change codes (Menu-9-6-5)
The Change codes feature lets you change your cur-
rent password to a new one. You must enter the cur-
rent password before you can specify a new one.
Use this to change the access codes: Security code,
PIN1 code and PIN2 code.
n Note PIN: Personal Identification Number
Connectivity Menu-9-7
The Network settings feature enables you to indicate
whether the network used when roaming (outside your
home area) is selected automatically, manually or pref-
erably.
n Note You can select a network other than your home
network only if it has a valid roaming agreement
with your home network.
Bluetooth (Menu-9-7-1)
Bluetooth enables compatible mobile devices, periph-
erals and computers that are in close proximity to
communicate directly with each other without wires.
This handset supports built-in Bluetooth connectivity,
which makes it possible to connect them with compat-
ible Bluetooth headsets, computer applications and so
on.
] My devices : You can view all devices which are
compatible with bluetooth phone.
] Handsfree devices : You can view the list of hands-
free devices which are compatible with bluetooth
phone.
] Settings : You can register a new device which is
compatible with bluetooth. If you already have added
the device, you can search it after entering a pass-
word.
Settings
<70> M4300
] Set bluetooth : You can activate or cancel bluetooth
function.
] My phone’s visibility : Select whether to let your
phone be shown to other Bluetooth devices or hid-
den.
] My phone’s name : You can set the name of blue-
tooth device. The default name is F2400.
SyncML (Menu-9-7-2)
The Server sync function synchronises the data in
a phone and the data on a server such as contact
address information, schedule items, etc. via a wire-
less network.
• Connect
Select Server sync from the Connectivity menu and
then press the key.
Select the Connect item and then press the key.
Connect to the server with the selected server profile
and the synchronization animation is displayed while
the synchronization is performed.
• Server settings
This menu allows you to configure the profile for a
Sync Server.
] Adding a new profile
- Input and choose the Profile name, Host address,
Username, Password, Contacts, Contact name,
Calendar, Calendar name, To do, To do name and
Access point.
- Press the key to save the new profile.
- In the Settings screen, press the left soft key
[Options] key and select Add new to add a new
profile.
] Editing a profile
- Select a profile to edit.
- Press the left soft key [Options], select Edit, and
edit the selected profile.
] Deleting profiles
- Press the left soft key [Options] and select Delete.
- Select Yes to delete the selected profile.
] Selecting a server
- Select a desired server profile to synchronise in the
Settings screen and then press the key.
• Logs
Select a Server sync item in the Connectivity menu and
then press the key.
Select Log item and then press the key to view the
log for the last synchronisation operation performed.
Settings
M4300 <71>
Network (Menu-9-7-3)
You can set a list of preferred networks the handset
should attempt to register with first, before attempting
to register to any other networks. This list is created
from the handset’s predefined list of known networks.
GPRS (Menu-9-7-4)
Internet Menu-9-8
You can access various WAP (Wireless Application
Protocol) services such as banking, news, weather
reports and flight information. These services are spe-
cially designed for mobile phones and they are main-
tained by WAP service providers.
Check the availability of WAP services, pricing and
tariffs with your network operator and/or the service
provider whose service you wish to use. Service pro-
viders will also give you instructions on how to use
their services.
To launch the browser in standby mode, press either
the t-zone key ( ) or press and hold the key.
Once connected, the homepage is displayed. The con-
tent depends on the service provider.
To exit the browser at any time, press the ( ) key.
The phone will return to the standby mode.
Navigating with the WAP browser
You can surf the Internet using either the phone keys
or the WAP browser menu.
Using the phone keys
When surfing the Internet, the phone keys function dif-
ferently to phone mode.
Using the WAP browser menu
There are various menu options available when surfing
the Mobile Web.
n Note You can select a network other than your home
network only if it has a valid roaming agreement
with your home network.
Key Description
Scrolls each line of the con-
tent area
up/down navigation
keys
C key
OK key
Returns to the previous page
Selects options and confirms
actions
Settings
<72> M4300
Home (Menu-9-8-1)
Connects to a homepage. The homepage will be the
site which is defined in the activated profile. It will be
defined by the service provider if you have not defined
it in the activated profile.
My bookmarks (Menu-9-8-2)
This menu allows you to store the URL of favourite web
pages for easy access at a later time.
To create a bookmark
1. Press the left soft key [Options].
2. Select Add new and press the OK key.
3. After entering the desired URL and title, press the
OK key.
✽
Tip: Use the key and key to enter symbols.
To enter “.”, press .
After selecting a desired bookmark, the following
options are available.
] Connect: Connects to the selected bookmark.
] Add new: Select this to create a new bookmark.
] Edit: You can edit the URL and/or the title of the
selected bookmark.
Go to URL (Menu-9-8-3)
You can connect directly to the site you want. After
entering a specific URL, press the OK key.
Security settings (Menu-9-8-4)
A list of the available certification is shown.
] Authority: You can see the list of authority certifi-
cates that have been stored in your phone.
] Personal: You can see the list of personal certifi-
cates that have been stored in your phone.
Settings (Menu-9-8-5)
• Profiles
A profile is the network information used to connect to
the Internet.
T-mobile supports three kinds of profile.
1. t-zones
If you want to connect the server via WAP 2.0, acti-
vate this profile.
2. t-zones business
3. t-zones GPRS
If you want to connect the WAP server over GPRS,
activate this profile.
Settings
M4300 <73>
4. t-zones CSD
If you want to connect the WAP server over CSD,
activate this profile. For more information, consult
T-mobile.
Each profile has submenus as follows:
] Activate: Activates the selected profile.
] Settings: Use this to edit and change WAP settings
for the selected profile.
- Homepage: This setting allows you to enter
the address (URL) of a site you want to use as
homepage. You do not need to type http:// at the
front of each URL as the WAP Browser will auto-
matically add it.
- Bearer: You can set the bearer data service.
1 Data
2 GPRS
- Data settings: Appears only if you select Data
Settings as a Bearer / service.
IP address: Enter the IP address of the WAP gate-
way you want.
Dial number: Enter the telephone number to dial to
access your WAP gateway.
User ID: The users identity for your dial-up server
(and NOT the WAP gateway).
Password: The password required by your dial-up
server (and NOT the WAP gateway) to identify you.
Call type: Select the type of data call : Analogue of
Digital (ISDN)
Call speed: The speed of your data connection ;
9600 or 14400
Linger time: You need to enter timeout period. After
entering that, the WAP navigation service will be
unavailable if any data is not input or transferred.
- GPRS settings: The service settings are only avail-
able when GPRS is chosen as a bearer service.
IP address: Input the IP address of the WAP gate-
way you access.
APN: Input the APN of the GPRS.
User ID: The users identify for your APN server.
Password: The password required by your APN
server.
- Connection Type: The options for connection type
are Temporary or Continuous and depend on the
gateway you are using.
Continuous
A confirmed delivery mechanism but generates
more network traffic.
Settings
<74> M4300
Temporary
A non-confirmed (connectionless) service.
HTTP
Connecting Clients to Server directly in HTTP
- Proxy settings
IP address: Input the IP address of the Proxy server
you access.
Port: Input the Proxy Port
- DNS settings
Primary server: Input the IP address of the primary
DNS server you access
Secondary server: Input the IP address of the sec-
ondary DNS server you access
- Secure settings: According to the used gateway
port, you can choose this option as On or Off.
- Display image: You can select whether images on
WAP cards are displayed or not.
] Rename: You can change the profile name.
] Add new: You can add a new profile.
• Cache
The information or services you have accessed are
saved in the cache memory of the phone.
n Note A cache is a buffer memory, which is used to
save data temporarily.
• Cookie
The information or services you have accessed are
saved in the cache memory of the phone.
• Clear cache
Removes all context saved in cache.
• Clear cookie
Removes all context saved in Cookies.
Reset settings Menu-9-9
You can reset your phone to its default configuration.
To do so, proceed, as follows.
1. Select the Reset settings menu option.
2. You are requested to enter the 4-digit security
code.
n Note The security code is preset to 0000. To change
this, refer to page 86.
Settings
M4300 <75>
Q&A
Please check to see if any problem which you may
have with your phone is described here before taking
it for service or calling a service engineer.
Q How do I view the list of outgoing calls, incoming
calls and missed calls?
A Press .
Q How do I clear all call history?
A Press the left soft key and then .
Q How do I view all numbers saved in the memory?
A Press the up navigation key .
Q does not disappear from the screen.
A Check whether you are in a service area. If you
continue to see , turn off the power and wait
for approximately 2 minutes before turning it back
on. If there is no change, relocate to another area
and check again.
Q Connection is poor or is not audible in certain
areas.
A In certain areas, signal strength can vary dramati-
cally.
Try moving to a different location. Heavy network
traffic may affect the ability to connect, or the sta-
bility of the call.
Q Connection is poor even when established.
A In certain areas, signal strength can vary dramati-
cally.
Try moving to a different location. Heavy network
traffic my affect the ability to connect, or the stabil-
ity of the call.
Q LCD does not turn on.
A Remove and replace the battery and turn on the
power.
If the phone still does not turn on, charge the bat-
tery and try again.
Q An echo can be heard during connection with a
certain telephone in a certain area.
A It is called ‘Echo Phenomenon’. It occurs if the
volume is too high or caused by special proper-
ties (semi electronic telephone exchange) of the
machine on the other end.
<76> M4300
Q The phone gets warm.
A During long calls, or if games/Internet are used
for a long time, the phone may become hot. This is
perfectly normal and has no effect upon the life of
the product or performance.
Q The bell does not ring, or lamp or LCD blinks only.
A The phone is set to ‘Vibrate only’ or ‘Silent’ in the
Profiles menu. Please select ‘General’ or ‘Loud’
Q Standby duration of the phone gradually becomes
shorter.
A Batteries have a limited life. When the battery lasts
for half its original time, it requires replacement.
Only use authorised replacement parts.
Q Usage time of battery becomes shorter.
A If the battery time is short, it may be due to the
user environment, or large volume of calls, or weak
signals.
Q No number is dialled when you recall a contact
entry.
A Check that the numbers have been saved correctly,
by using the Contact Search feature. Resave them,
if necessary.
Q You cannot be contacted.
A Is your phone switched on ( pressed for
more than three seconds)? Are you accessing the
right cellular network?
Have you set an incoming call barring option?
Q I cannot find the lock, PIN, or PUK code, or pass-
word?
A The default lock code is ‘0000’. If you forget or lose
the lock code, contact your phone dealer. If you
forget or lose a PIN or PUK code, or if you have not
received such a code, contact your network serv-
ice provider.
Q&A
M4300 <77>
Accessories
There are a variety of accessories available for your
mobile phone. You can select these according to your
personal communication requirements. Consult your
local dealer for availability.
Supplied adapter
This adapter lets you
charge the battery while
at home or in the office.
Battery
Standard battery is
available.
Headset
Allows hands-free oper-
ation. Includes earpiece
and microphone.
n Note • Always use genuine LG accessories. Failure to
do this may invalidate your warranty.
• Accessories may be different in different
regions; please check with our regional service
company or agent for further enquiries.
<78> M4300
Technical data
Technical data
General
Product name : M4300
System : GSM900 / DCS1800
Ambient temperatures
Max : +55°C
Min : -10°C
M4300 <79>
Appendix. RF Exposure Statement
WARNING! Read this information before operating the phone.
In August 1996, the Federal Communications (FCC) of the United States, with its action in Report
and Order FCC 96-326, adopted an updated safety standard for human exposure to radio
frequency(RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines
are consistent with the safety standard previously set by both U.S. and international standards
bodies.
The design of this phone complies with the FCC guidelines and these international standards.
CAUTION
Use only the supplied and approved antenna. Use of unauthorized antennas or modifications could
impair call quality, damage the phone, void your warranty and/or result in violation of FCC
regulations.
Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with skin,
a minor burn may result. Contact your local dealer for a replacement of antenna.
Body Worn Operation
This device was tested for typical body-worn operations with the back of the phone kept 1.5
cm from the body. To comply with FCC RF exposure requirements, a minimum separation
distance of 1.5 cm must be maintained between the user’s body and the back of the phone,
including the antenna, whether extended or retracted. The use of belt-clips, holsters, and
similar accessories should not containing metallic components in its assembly. The use of
accessories that do not satisfy these requirements may not comply with FCC RF exposure
requirements, and should be avoided.
For Your Safety FCC Part 15 Class B Compliance
This device and its accessories comply with part 15 of FCC rules. Operation is subject to the
following two conditions: (1) This device and its accessories may not cause harmful
interference, and (2) this device and its accessories must accept any interference received,
including interference that may cause undesired operation.
Appendix 2. Consumer Information on SAR
(Specific Absorption Rate)
This Model Phone Meets the Government’s Requirements for Exposure to Radio Waves. Your
wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed
the emission limits for exposure to radio frequency (RF) energy set by the Federal
Communications Commission of the U.S. Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for the general population. The guidelines
are based on standards that were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The standards include a substantial safety
margin designed to assure the safety of all persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of measurement known as the
Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are
conducted using standard operating positions specified by the FCC with the phone transmitting at
its highest certified power level in all tested frequency bands. Although SAR is determined at the
highest certified power level, the actual SAR level of the phone while operating can be well below
the maximum value. Because the phone is designed to operate at multiple power levels to use only
the power required to reach the network, in general, the closer you are to a wireless base station
antenna, the lower the power output.
Before a phone model is available for sale to the public, it must be tested and certified to the FCC
that it does not exceed the limit established by the government-adopted requirement for safe
exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the
body) as required by the FCC for each model.
The highest SAR value for this model phone when tested for use at the ear is 0.359 W/kg and
when worn on the body, as described in this user guide, is 0.231 W/kg (body-worn measurements
differ among phone models, depending upon available accessories and FCC requirements). While
there may be differences between SAR levels of various phones and at various positions, they all
meet the government requirement for safe exposure.
The FCC has granted an Equipment Authorization for this model phone with all reported SAR
levels evaluated as in compliance with the FCC RF emission guidelines. SAR information on this
model phone is on file with the FCC and can be found under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on FCC ID BEJM4300.

Navigation menu
