Users Manual

LG P930

User Manual

Your Phone

To turn on the phone, press and hold the Power/Lock Key for 3 seconds.

To turn off the phone, press the Power/Lock Key for 3 seconds and touch Power off and OK to

confirm.

Front View

TIPS

- Press the Menu Key whenever you open an application to check what options are available.

- This phone does not support video calls.

- If your phone has errors when you use it or you cannot turn it on, remove the battery, install it

again and turn it on after 5 seconds.

Home Key

- Returns to the Home screen

from any screen.

Menu Key

- Displays available options for

the current screen.

Earpiece

Back Key

- Returns to the previous screen.

Search Key

- Search the web and contents

in your phone.

Power/Lock Key

- Powers your phone on/off by

pressing and holding the key.

- Turns your screen on and off

and locks it.

Proximity Sensor

Warning

Placing a heavy object on the phone or sitting on it can damage its LCD and touch screen

functionalities. Do not cover the LCD’s proximity sensor with a protective ﬁlm.

This can cause the sensor to malfunction.

Front Camera Lens

Your Phone

Rear View

Side View

SIM Card Slot

Back Camera Lens

microSD

Card Slot

Battery

3.5mm Headset Jack

HDMI Slot

- Connect an HDMI cable from

the HDMI port on your phone

to an HDMI port on your TV.

Power/Lock Key

3D Key

- Easy to access 3D Space

directly.

Volume Keys

- From the Home screen:

Controls ringer volume.

- During a call: Controls your

earpiece volume.

- When playing a track:

Controls volume

continuously.

USB

Installing the SIM card and

battery

Before you can start exploring your new phone,

you’ll need to set it up. To insert the SIM card

and battery:

Hold the phone on your hand firmly. With the 1

other hand, firmly press your thumb on the

back and lift off the battery cover with your

forefinger using the fingertip cutout at the

top of the phone.

Slide the SIM card into the SIM card slot. 2

Make sure the gold contact area on the card

is facing downwards.

Insert the battery into place by aligning the 3

gold contacts on the phone and the battery.

Replace the back cover of the phone (as 4

demonstrated below). Apply a steady

downward pressure until the battery cover

clicks into place.

Getting Started

Charging your phone

Plug the USB cable (as shown below) into the

phone's accessory/charger port. Make sure the

‘B’ side is facing upwards.

NOTE

The battery must be fully charged initially

to improve battery lifetime.

NOTE

Your phone has an internal antenna. Be

careful not to scratch or damage this

rear area, as that will cause loss of

performance.

Installing the microSD card

To store multimedia files, such as images

taken using the camera, you must insert a

microSD card into your phone.

To insert a microSD card:

NOTE

This device supports up to a 32GB microSD

card.

Turn the phone off before inserting or 1

removing the microSD card. Remove the

battery cover.

Getting Started

Slide the slot protector upwards to unlock 2

it and flip it open. Then insert the microSD

card into the slot. Make sure the gold

contact area is facing downwards.

Flip the slot protection down to close it. 3

Then slide the slot protection downwards to

lock it and replace the battery cover.

Getting Started

Warning

Do not insert or remove the microSD card

when the phone is on. Otherwise, it may

damage the microSD card as well as your

phone, and the data stored on the microSD

card may be corrupted.

Formatting the microSD card

Your microSD card may already be formatted.

If it isn’t, you must format it before you can

use it.

NOTE

All ﬁles on the card are deleted when you

format the microSD card.

From the Home screen, press the 1

Key

Touch 2

Settings

Touch 3

SD card & phone storage

Touch 4

Unmount SD card

and

confirm.

Touch 5

Format SD card

(twice).

If you set an unlock pattern, enter it and 6

touch

Erase Everything.

The card will

then be formatted and ready to use.

NOTE

If there is content on your microSD card,

the folder structure may be different after

formatting since all the ﬁles will have been

deleted.

Getting Started

Switching between and

Exiting Applications

Multi-tasking is easy with Android because

open applications keep running even when you

open another application. There is no need to

quit an application before opening another. Use

and switch among several open applications.

Android manages each application, stopping

and starting them as needed, to ensure that

idle applications don’t consume resources

unnecessarily.

Switching between applications

- Press and hold the Home Key. A list of

recently used applications will be displayed.

Then touch the application you want to

access.

To stop/exit an application

From the Home screen, press the 1

Key

and touch

Settings

Applications

Manage applications

Touch the desired application and touch 2

Force stop

to exit.

Touch-screen tips

Here are some tips on how to navigate around

your phone.

Touch -

To choose a menu/option or open an

application, touch it.

Touch and hold -

To open an options menu

or grab an object you want to move, touch

and hold it.

Drag -

To scroll through a list or move slowly,

drag across the touch screen.

Flick -

To scroll through a list or move quickly,

flick across the touch screen (drag quickly and

release).

NOTE

• To select an item, touch the center of the

icon.

• Do not to press too hard; the touch screen

is sensitive enough to pick up a light, firm

touch.

• Use the tip of your finger to touch the option

you want. Be careful not to touch any other

keys or icons.

Proximity sensor

When receiving and making calls, this sensor

automatically turns the backlight off and locks

the touch keypad by sensing when the phone

is near your ear. This extends battery life and

prevents the touch keypad from activating

unintentionally during calls.

Lock your phone

When you are not using the LG P930, press

the Power/Lock Key to lock your phone. This

helps prevent accidental presses and saves

battery power.

Also, if you do not use the phone for a while,

the Home screen or other screen you are

viewing, is automatically replaced with the

lock screen after 30 seconds of inactivity

to conserve the battery and prevent pocket

dialing.

To wake up your phone, press the

Home

Back

Power Keys

. The

lock screen will appear. Touch the lock icon

and drag your finger to the right to unlock

your Home screen. The last screen you were

working on opens.

NOTE

- The automatic screen timeout can be

configured manually in Settings.

- If there are any programs running when you

lock the phone, they may still be running in

Your Home screen

lock mode. It is recommended that you exit

all programs before entering the lock mode to

avoid unnecessary charges. (e.g., phone call,

web access and data communications)

Setting an unlock pattern:

You can draw

your own unlock pattern by connecting four or

more dots.

To unlock the phone, draw the pattern you set

on the screen.

Caution

If there are more than 5 pattern drawing errors

in a row, you will be required to wait for 30

seconds to retry.

Unlock screen

Whenever your phone is not in use, it will

return to the lock screen. Slide your finger from

left to right to unlock the screen.

When the screen is locked, you can quickly

turn off your ringer and put the phone in silent

mode, by sliding finger from right to left.

Silent Mode

To set phone to silent when screen is unlocked,

open the Notifications panel and touch .

The icon will change to . To take it off

Silent, touch button again or, if the lock screen

is displayed, simply drag to the left.

Home

Simply swipe your finger to the left or right to

view the different panels.

You can also customize each panel with

shortcuts, folders, and wallpapers. You can

also customize each panel with widgets, which

are shortcuts to your favorite applications.

NOTE

On your LG Home screen, you can view quick

keys at the bottom of the screen. The quick

Your Home screen

keys provide easy, one-touch access to the

functions you use the most.

Quick Keys

Touch the

Phone

icon to bring up the

keypad to make a call.

Touch to open your Contacts list.

Touch the

Applications Launcher Key

to view all your installed applications.

Touch the

Messaging

icon to access the

messaging application.

Touch to open your phone's web browser.

Adding shortcuts and widgets

to your Home screen

You can customize your Home screen by adding

quick access elements, such as shortcuts,

widgets, or folders to it.

•

Shortcuts

: Add application, web

bookmark, contact, email, and music playlist

shortcuts to the Home screen.

•

Widgets

: Add dynamically updating

widgets to your Home screen to allow quick

access to applications without opening the

full application.

•

Folders

: Add folders to organize contacts

and shortcuts.

To do so, use the following steps:

From the Home screen, press the 1

Key

and touch

Add

. Or touch and hold an

empty part of the Home screen.

On the 2

Add to Home screen

menu,

touch the type of item you want to add.

For example, touch

Folders

from the list

and touch the folder you wish to add to the

Home screen.

You will see a new icon on the Home 3

screen. Drag it to the desired location on the

desired panel and release your finger from

the screen.

TIP

To add a preloaded application or an

application you have downloaded from the

Android Marketplace to the Home screen,

simply touch and hold the icon you want in

the Application Launcher to add to the Home

screen.

TIP

To delete an application icon from the Home

screen, touch and hold the shortcut icon you

want to delete and drag to at the bottom

of the screen.

Your Home screen

TIP

You cannot delete the preloaded applications.

(Only their icons can be deleted from the

screen).

Getting back to a recently

used application

Press and hold the 1

Home Key.

The screen

will display the icons of applications that

you have used recently.

Touch an icon to open its application or 2

press the

Back Key

to return to the current

application.

Notifications panel

The Notifications panel runs across the top of

your screen.

Ring

Airplane

Mode

GPS

Bluetooth

Wi-Fi

Touch and slide the Notifications panel

down with your finger. Or, from the Home

screen, press the

Menu Key

and touch

Notifications

. From here, you can check and

manage Wi-Fi, Bluetooth, GPS, Airplane mode,

Ringer and view other notifications.

Viewing the Status Bar

The Status Bar uses different icons to display

phone information, such as signal strength,

new messages, battery life, and active

Bluetooth and data connections.

Below is a table explaining the meaning of

icons you are likely to see in the Status Bar.

[Status Bar]

Icon Description

No SIM card is installed

No signal

Your Home screen

Icon Description

Connected to a Wi-Fi network

A wired headset is connected

Call forwarded

Call on hold

Speakerphone is on

Phone microphone is muted

Missed call

Bluetooth is on

Connected to a Bluetooth device

System warning

Alarm is set

New voicemail

Airplane mode is set

Silent mode is set

Vibrate mode is set

Icon Description

No microSD card installed

Battery is fully charged

Battery is charging

Data in

Data out

Data in and out

The phone is connected to a PC via

USB cable

Downloading data

Uploading data

GPS is on

GPS is receiving location data

USB tethering is active

Mobile Hotspot is active

Your Home screen

Onscreen Keyboard

You can also enter text using the onscreen

keyboard. The onscreen keyboard displays

automatically on the screen when you need to

enter text. To manually display the keyboard,

simply touch a text field where you want to

enter text.

There are two types of keypad that you can

use, the Phone keypad and the QWERTY

keypad.

TIP

To switch between the Qwerty Keypad and

Phone Keypad, touch and Keypad types.

Then touch the keypad you wish to use.

The Phone keypad allows you to enter

letters by touching the key labeled with the

desired letters, similar to how you would on

a traditional 12 key phone. You may have to

touch a key up to four times to type the desired

letter or number.

The QWERTY keypad shows a letter for each

key, similar to on a computer keyboard.

You can also use this keypad in landscape

mode. Turn phone to a horizontal position to

use the landscape QWERTY keypad.

Your Home screen

Entering text

Shift Key -

Touch once to capitalize the

next letter you type. Double-tap for all

caps.The colored circle on the button tells

you if uppercase is locked on or if it is

just on for one character .

Setting Key-

Allows you to set the

keyboard settings.

Number and Symbols Key -

Touch to

change to 123 Mode and enter numbers

and symbols.

Enter Key-

Adds another line when

entering text.

Hide Keypad Key -

Removes the

keypad from the screen.

Delete Key-

Deletes any text you have

entered.

To enter a space, touch .

123 Mode

This mode allows you to enter numbers

in a text message (a telephone number,

for example) more quickly. Touch the keys

corresponding to the required digits before

manually switching back to the appropriate

text entry mode by touching the key.

TIP

You can also change your input method when

typing between LG keyboard and Android

Keyboard. To do so, press and hold a text

field. Select

Input Method

from the menu

and make your selection.

Entering accented letters

When you select French or Spanish as the text

entry language, you can enter special French or

Spanish characters (e.g., “á”).

From Phone Keypad

After the corresponding letter character

disappears, press the same key repeatedly

until you see the special character you want.

From Qwerty keyboard

To input the accent, press and hold the “á” key.

After the accented character appears, touch

it to enter it.

Your Home screen

The first time you open a Google application on

your phone, you will be required to sign in with

your existing Google account. If you do not

have a Google account, you will be prompted

to create one.

Creating your Google account

From the Home screen, touch the 1

Applications Launcher Key

Touch2

Gmail

Create

to start the

Gmail™ setup wizard.

Touch a text field to open the keyboard and 3

enter your name and username for your

Google account. When you finish entering

the text, you can move to the next text field

by touching

on the keyboard.

When you’re finished entering your name 4

and username, touch

. Your phone

will communicate with Google servers and

check for username availability.

Enter and re-enter your password. Then 5

follow the instructions and enter the

required and optional information about

the account. Wait while the server creates

your account.

Signing into your Google

account

Enter your email address and password, 1

then touch

After signing in, you can use Gmail™ and 2

take advantages of Google services on your

phone.

Once you have set up your Google 3

account, your phone will be automatically

synchronized with your Google account on

the web. (Depending on your synchronization

settings.)

After signing in, your phone will sync with your

Google services, such as Gmail

, Contacts,

Google Calendar, and Picasa photo albums.

You can also use Google Maps

, download

applications from Android Market™, back

up your settings to Google servers, and take

advantage of other Google services on your

phone.

Google Account Set-up

IMPORTANT

• Some applications, such as Calendar,

work only with the first Google Account

you add. If you plan to use more than one

Google Account with your phone, be sure

to sign into the one you want to use with

such applications first. When you sign in,

your contacts, Gmail messages, Calendar

events, and other information from these

applications and services on the web are

synchronized with your phone. If you don’t

sign into a Google Account during setup,

you will be prompted to sign in or to create

a Google Account the first time you start an

application that requires one, such as Gmail

or Android Market™.

• If you want to use the backup feature to

restore your settings to this phone from

another phone that was running Android

release 2.0 or later, you must sign into your

Google Account, during setup. If you wait

until after setup is complete, your settings

will not be restored.

• If you have an enterprise account through

your company or other organization, your IT

department may have special instructions on

how to sign into that account.

Google Account Set-up

Making a call

Touch 1 to open the keypad.

Enter the number on the keypad. To delete a 2

digit, touch the

Clear

icon .

Touch the 3

Call

icon to make a call.

To end a call, touch the 4

End

icon .

TIP

To enter “+” to make international calls,

touch and hold down .

Calling your contacts

Touch 1 to open your contacts.

Scroll through the contact list or touch the2

box and enter the first letter(s) of

the contact you want to call.

In the list that is displayed, touch the contact 3

you want to call.

In the Contact Info screen, touch the phone 4

number you wish to call.

Answering and rejecting a

call

When the screen is locked

When your phone rings, drag the

Answer

icon

to the right.

Drag the

Decline

icon to the left to reject

an incoming call. Drag the Send msg bar

upwards if you want to send a message to the

caller. If the caller is unknown, this Send msg

bar is not available.

When the screen is unlocked

When your phone rings, touch the

Answer

icon . Touch

Decline

icon to reject

an incoming call.

Touch the Send msg bar upwards if you want

to send a message to the caller. If the caller is

unknown, the Send msg bar is not available.

Adjusting the In-call volume

To adjust the In-call volume during a call, use

the volume up and down keys on the right side

of the phone.

Calls

Making a second call

During your initial call, touch 1 .

Then enter the number you want to call.

Dial the number or search your contacts.2

Touch the 3

Call

icon to connect the call.

Both calls will be displayed on the call 4

screen. Your initial call will be locked and

put on hold.

Touch 5 to toggle between calls or touch

to make a conference call.

To end active calls, touch 6

End

. If there is

no active call, it will end the call on Hold.

To end all calls at the same time, press the

Menu Key

and touch

End all calls.

NOTE

You will be charged for each call you make.

Viewing your call logs

From the Home screen, touch and the

Call log tab.

View a complete list of all dialed, received,

and missed voice calls.

TIP

Touch any single call log entry to view the

date, time, and duration of the call.

TIP

Press the Menu Key, then touch Clear call

log to delete all the recorded items.

Call settings

You can configure phone call settings, such

as call forwarding, and other special features

offered by your carrier.

From the Home screen, press the 1

Key

and touch

Settings

Touch 2

Call settings

Calls

You can add contacts on your phone and

synchronize them with the contacts in your

Google Account or other accounts that

support syncing contacts.

Searching for a contact

Touch 1 to open your contacts.

Press the 2 Search Key and enter the

contact name using the keypad.

Adding a new contact

Touch 1 and enter the new contact’s

number. Press the Menu Key, touch

Add to contacts and then Create new

contact.

If you want to add a picture to the new 2

contact, touch . Choose from Take

photo or Select photo from gallery.

Select the contact type by touching 3 .

Touch a category of contact information 4

and enter the details about your contact.

Touch 5 Done to save the contact entry.

Favorite Contacts

You can classify frequently called contacts

as favorites.

To add a contact to your favorites

From the Home screen, touch1 to open

your contacts.

Touch a contact to view its details.2

Touch the star to the right of the contact’s 3

name. The star turns gold.

To remove a contact from your

favorites list

From the Home screen, touch 1 to open

your contacts.

Touch the 2 Groups tab and touch

Favorites.

Touch a contact to view its details.3

Touch the gold star to the right of the 4

contact’s name. The star turns grey

and the contact is removed from your

favorites.

Contacts

AT&T Address Book (AAB)

AT&T Address Book (AAB) is an application

that automatically syncs your contacts to

an online address book for safekeeping!

When you first turn on the phone or change

your SIM card and touch Contacts, the AAB

application is displayed after copying the

SIM card information to your phone.

After signing up for this service, your

information is synced on a regular basis.

You can find more information on this

service and access your online address book

at www.att.com/addressbook. You can find

the synchronization menu for the service

by pressing the Menu Key and touching

Settings > Accounts & sync > AT&T

Address Book.

Contacts

Messaging/Email

Messaging

Your phone combines SMS and MMS into one

intuitive, easy-to-use menu.

Threaded box

Messages (SMS and MMS) exchanged with

another party can be displayed in chronological

order so that you can conveniently see an

overview of your conversation.

Sending a message

Touch the 1 icon on the Home screen,

then touch

New message

to create a new

message.

Enter a contact name or phone number in 2

the

field. As you enter the contact name,

matching contacts appear. You can touch

a suggested recipient. You can also add

multiple contacts.

NOTE

You will be charged for a text message for

every person you send the message to.

Touch the text field to start entering your 3

message.

Press the 4

Menu Key

to open the options

menu. Choose from

Call

Attach

Insert

Smiley

Discard

Templates

All

threads

Touch 5

Send

to send your message.

The message screen opens, with your 6

message after your name. Responses

appear on the screen. As you view and send

additional messages, a message thread is

created.

Warning

The 70-character limit may vary from

country to country depending on how the

SMS is coded and the language used in the

message.

Warning

If an image, video, or audio ﬁle is added to

an SMS message, it will be automatically

converted into an MMS message and you

will be charged accordingly.

NOTE

When you get an SMS message during a

call, there will be an audible notiﬁcation.

Using smilies

Liven up your messages using smilies.

When writing a new message, press the

Menu Key,

then touch

Insert Smiley

Changing your message

settings

Your phone's message settings are predefined,

so you can send messages immediately.

You can change the settings based on your

preferences.

You can use the

application to read

Email from providers other than Gmail. The

Email application supports the following

account types: POP3, IMAP and Microsoft

Exchange ActiveSync (for Enterprise users).

To open the Email application

] From the Home screen, touch

The first time you open the

application,

a setup wizard opens to help you add an Email

account.

Email Accounts screen

The Accounts screen

The Accounts screen lists your Combined Inbox

and each of your Email accounts.

Open the Email application. If you’re not on 1

the Account screen, press the

Menu Key

and touch

Accounts

- Touch to open your Combined Inbox,

with messages sent to all of your accounts.

- Touch to open a list of just your starred

messages.

- Touch the folder icon to open a specific

account’s folders.

You can touch an account to view its Inbox. The

account from which you send Email by default

is indicated with a checkmark.

Your Combined Inbox

If you have configured Email to send and

receive Email from more than one account, you

can view all messages sent to all accounts in

your Combined Inbox.

Touch 1

From the Inbox, press the 2

Menu Key

and

touch

Accounts

Messaging/Email

Touch 3

Combined Inbox

(on the Accounts

screen). Messages in the Combined Inbox

are color coded along their left sides, by

account, using the same colors that are used

for your accounts on the Accounts screen.

Only your account’s most recent Email are

downloaded to your phone. To download more

(earlier) Email messages, touch

messages

at the bottom of the Email list.

Reading Your Messages

Touch the message you want to read. The

message opens in a screen that includes

information about who sent it, the date it was

sent, and other related information.

Responding to a Message

You can reply to it, forward it or even just

delete it.

To delete a message

] While reading a message, touch the

Delete

button.

] While reading a message, press the

Key

and touch

Delete

For many types of accounts, deleted messages

are moved to a Trash folder, so you can retrieve

them in case they were deleted by mistake.

Other options

] To reply the message, touch the message

you received from the Inbox and touch the

Reply button.

] Touch and hold the recieved message until

the pop-up appears. From the pop-up,

you can reply, forward, delete and mark

messages as read or unread.

Composing and Sending Email

To compose and send a message

While in the 1

application, press the

Menu Key

and touch

Compose

Enter an address for the message’s intended 2

recipient. As you enter text, matching

addresses are offered from your Contacts.

Separate multiple addresses with commas.

Press the 3

Menu Key

and touch

Add

Cc/Bcc

to copy other contacts or Email

addresses.

Enter the text of the message. 4

Press the 5

Menu Key

and touch

Attach

send a photo with the message.

Touch the 6

Send

button.

Saving and Accessing Draft Messages

If you’re not ready to send the message, touch

the

Save as draft

button to save it in the

Drafts folder. Touch a draft message in the

Drafts folder to resume working on it. Your

message will also be saved as a draft if you

touch the

Back Key

before sending

it. Touch the Discard button to abandon and

delete a message, including any saved drafts.

If you are not connected to a network (for

example, if you are working in airplane mode)

the messages that you send are stored in

your Outbox folder until you are connected to

a network again. If it contains any pending

messages, the Outbox is displayed on the

Accounts screen.

NOTE

Please note that messages sent using a

Microsoft Exchange account will not be saved

on the phone; they will, however, be saved on

the Exchange server itself.

If you want to see your sent messages in

the Sent folder, you will often need to open

the Sent folder and touch Refresh from the

options menu.

Working with Account Folders

Each account has Inbox, Outbox, Sent, and

Drafts folders. Depending on the features

supported by your account’s service provider,

you may have additional folders.

Adding and Editing Email

Accounts

To add an Email account

From the Accounts screen, press the 1

Key

and touch

Add account

Touch the type of account you would like to 2

add and enter your Email account settings.

Enter a name for the account, confirm how 3

you want your name to appear in outgoing

mail, then touch the

Done

button.

To change an account’s settings

Open the Accounts screen. 1

Touch and hold the account you want to edit. 2

In the menu that opens, touch

Account

settings

To delete an Email account

Open the Accounts screen. 1

Touch and hold the account you want to 2

delete.

Messaging/Email

Touch 3

Remove account

in the menu

that opens.

Touch the 4

button in the dialog box to

confirm that you want to delete the account.

Social Networking

With your phone, you can enjoy social

networking and manage your micro-blog in

on-line communities. You can update your

current status, upload photos, and view your

friends’ status updates in real-time.

You can add your Facebook and Twitter

accounts to your phone. If you don’t have an

account, you can visit their sites to set one up.

NOTE

Additional costs may be incurred when

connecting and using online services.

Check your data charges with your network

provider.

Adding an account to your

phone

From the Home screen, touch the 1

Applications Launcher Key to view your

installed applications and choose any social

networking application you want to use. If

you don't have an account yet, touch Sign

up now and create an account.

Enter your email address and password 2

that you set up for your social networking

account, then touch

NOTE

If you add a social networking widget on

your Home screen, the widget will show

your status when your phone receives

updates from the network.

You can also access the social community

directly by touching the widget.

Viewing and updating your

status

Open the social networking application you 1

want to update.

You can see the current status of your social 2

application, such as Twitter or Facebook.

You can update your status with comments 3

or upload photos.

TIP

You can use information about friends only

in your social network(s) or sync all data

to Contacts.

Syncing accounts on your

phone

You can sync information from your social

networking accounts with your Contacts and

other functions on your phone, if applicable.

From the Home screen, press the

Menu Key

and touch

Settings

Accounts & sync

Add account

. Choose the account you

want to synchronize and enter the necessary

information.

Removing accounts on your

phone

From the Home screen, press the

Menu Key

and touch

Settings

Accounts & sync

Touch the account(s) you want to delete, then

touch

Remove account

(twice).

Messaging/Email

Camera

Getting to know the viewfinder

NOTE

You need to insert a microSD card ﬁrst to take a picture. Without inserting a microSD card, you

will not be able to take a picture nor save the picture you had taken.

NOTE

You can close all the shortcut options to give a clearer viewﬁnder screen. Just touch the center

of the screen once. To recall the options, touch the screen again.

Camera Lens Switch

- Allows you to switch the camera lens between front one and

back one.

3D Camera -

Touch to switch to 3D camera shoot

mode.

Video mode

– Slide this icon down to switch to

video mode.

Capture

– Allows you to take a photo.

Gallery

– This enables you to access your saved

photos and videos within the camera

mode. Simply touch and your gallery will

appear on the screen.

Flash

– Allows you turn on the flash when taking a photo in a dark place.

Settings

– Touch this icon

to open the settings menu. See

Using the advanced settings

Brightness

– This defines and controls of the amount of sunlight entering the image.

Slide the brightness indicator along the bar, towards “-” for a lower brightness image, or

towards “+” for a higher brightness image.

Zoom

– Zoom in or zoom out. Alternatively you can use the Volume Keys.

Camera

Using the focus mode

You can select the following focus mode

options:

Auto Focus

– Set the camera to focus

automatically.

Macro

– Macro mode allows you to take

extreme close-ups. If you are trying to take a

close-up shot but the focus box remains red,

try turning the macro mode on.

Face tracking

– If you set Face tracking and

take a photo, your camera detects and focuses

on human faces automatically.

Manual

– Set the camera to focus manually.

Taking a photo

From the Home screen, touch 1

Camera

Holding the phone horizontally, point the 2

lens towards the subject you want to

photograph.

Touch and hold the capture button lightly, 3

and a focus box will appear in the center of

the viewfinder screen.

Position the phone so you can see the 4

subject in the focus box.

When the focus box turns green, the camera 5

has focused on your subject.

Release the capture button.6

Once you’ve taken the photo

Your captured photo will appear on the screen.

Touch to share your photo as

Bluetooth

Facebook,

Gmail

Messaging, Picasa

Twitter

NOTE

Additional charges may apply when MMS

messages are sent while roaming.

Set as

Touch to use the image as

Contact

icon

Wallpaper

Rename

Touch to edit the name of the

selected picture.

Touch to delete the image.

Touch to take another photo immediately.

Your current photo will be saved.

Touch to view the Gallery of your saved

photos.

Using the advanced settings

In the viewfinder, touch to open the

advanced options.

You can change the camera settings by

scrolling the list. After selecting the option,

touch the

Back key

Image size

– Touch to set the size (in

pixels) of the picture you take. Select a pixel

value from the following options:

3.2M

(2048x1536), 2M (1600x1200), 1M

(1280x960), VGA (640x480),

QVGA (320x240)

ISO

– The ISO rating determines the sensitivity

of the camera’s light sensor. The higher the

ISO, the more sensitive the camera will be.

This is useful under darker conditions. Select

from ISO values of

Auto

400,200

and

100

White balance

– Choose from

Auto

Incandescent

Sunny

Fluorescent

, and

Cloudy

Color effect

– Choose a color tone for your

new photo.

NOTE

You can change a color picture to black and

white or sepia, but you cannot change a black-

and-white or sepia picture to color.

Timer

– The self-timer allows you to set a

delay after the shutter is pressed. Select

Off

3 secs.

5 secs.

, or

10 secs.

This is ideal if

you want to be included in a photo.

Shot mode

– Choose from

Normal,

Continuous shot, Smile shot, Beauty

shot, Art shot, Panorama, Face effect

and

Cartoon.

Image Quality

– Choose from

Super fine

Fine

, and

Normal

. The finer the quality, the

sharper the photo. However, the file size will

increase as a result, which means you’ll be

able to store fewer photos in the memory.

Auto review

– If you set Auto review on,

it will display the picture that was just taken

automatically.

Shutter sound

– Select one of the four

shutter sounds.

Tag location

– Activate to use your phone’s

location-based services. Take pictures

wherever you are and tag them with the

location. If you upload tagged pictures to a

blog that supports geotagging, you can see the

pictures displayed on a map.

NOTE

This function is only available when GPS

is active.

Camera

Reset

– Restore all camera default

settings.

– Touch whenever you want to know how

a function operates. This will provide you a

quick guide.

TIP

When you exit the camera, all settings

will return to their defaults, except image

size and image quality. Any non-default

settings must be reset, such as color tone

and ISO. Check these before you take your

next photo.

TIP

The settings menu is superimposed over the

viewﬁnder, so when you change elements

of the image color or quality, you will see

a preview of the image change behind the

settings menu.

Viewing your saved photos

You can access your saved photos from within

the camera mode. Just touch and your

Gallery will be displayed.

TIP

Flick left or right to view other photos or

videos.

– Touch to see slide show.

– Touch to share the contents or delete.

Touch

for the following options below.

Details

- View information about the

photo.

Set as

- Set the photo as a

Contact

icon

Wallpaper

Crop

-Crop your photo. Move your

finger across the screen to select the

area.

Rotate

- You can rotate the photo left

or right.

Adjusting the volume when

viewing a video

To adjust the volume of a video while it is

playing, use the Volume Keys on the right side

of the phone.

Setting a photo as wallpaper

Touch the photo you want to set as 1

wallpaper to open it.

Touch the screen to open the options menu.2

Touch 3

Set as

Wallpaper

Camera

Zoom

– Zoom in or zoom out. Alternatively you can use the Volume Keys.

Brightness

– This defines and controls of the amount of sunlight entering the

image. Slide the brightness indicator along the bar, towards “-” for

a lower brightness image, or towards “+” for a higher brightness

image.

Settings

– Touch this icon to open the settings menu. See

Using the advanced

settings

3D Camera -

Touch to switch to 3D video

camera recording mode.

Camera mode

– Slide this icon up to

switch to camera mode.

Record

– Allows you to start recording.

Gallery

– This enables you to access your

saved photos and videos from

within the video camera mode.

Simply touch and your Gallery will

appear on the screen.

Getting to know the viewfinder

Video camera

Flash

– Allows you turn on the flash when taking a photo in a dark place.

Camera Lens Switch

- Allows you to switch the camera lens between front

one and back one.

Shooting a video

From the Home screen, touch 1

Camera

and

slide the camera mode button to change to

Video mode. The icon will change to .

The video camera’s viewfinder will appear 2

on the screen.

Holding the phone horizontally, point the 3

lens towards the subject of the video.

Touch the record button once to start 4

recording.

REC will appear at the bottom of the 5

viewfinder with a timer showing the

length of the video.

Touch 6 on the screen to stop recording.

After recording a video

A still image representing your video will

appear on the screen.

Play

Touch to play the video.

Touch to share your video via

Bluetooth

Gmail

Messaging,

YouTube.

NOTE

Additional charges may apply when MMS

messages are downloaded while roaming.

Rename

Touch to edit the name of the

selected video.

Touch to record another video right away.

Your current video will be saved.

Touch to delete the video you just

recorded. Confirm by touching

. The

viewfinder will reappear.

Touch to view the Gallery of your saved

videos.

Using the advanced settings

Using the viewfinder, touch to open the

advanced options.

Adjust the video camera settings by scrolling

the list. After selecting the option, touch the

Back

key

White balance

– The white balance ensures

any the white areas in your video are realistic.

To enable your camera to adjust the white

balance correctly, you may need to determine

the light conditions. Choose from

Auto

Incandescent

Sunny

Fluorescent

, and

Cloudy

Color effect

– Choose a color tone to use for

your new view.

Video camera

Duration

– Set a duration limit for your video.

Choose between

Normal

and

MMS

to limit

the recording time and share the video as

an MMS.

If you set Video Duration as MMS, the video

size will be set as 176x144 automatically and

you cannot change the size. You can change

the size only if you choose Normal.

Video Quality

– Choose from

Super fine

Fine

and

Normal.

Audio recording

– Choose

Mute

to record a

video without sound.

Auto review

– If you turn Auto review on,

it will play back the video you just recorded

automatically.

Reset

– Restore all video camera default

settings.

– Touch whenever you want to know how

a function operates. This will provide you a

quick guide.

TIP

You can change a video shot in color to

black and white or sepia, but you cannot

change a black-and-white or sepia video

to color.

Watching your saved videos

In the viewfinder, touch 1 .

Your Gallery will appear on the screen.2

Touch a video to play it automatically.3

Video camera

You can store multimedia files to a microSD

card to have easy access to all your image

and video files.

Touch the Applications Launcher Key,

then touch Gallery.

n NOTE

Make sure you install a microSD card into

the phone to save photos and access all your

pictures. Without a microSD card, the phone

will not display any photos or videos unless

you have them stored in a Picasa album.

View mode

When you open the Gallery, your photos

will be presented in Folder view. Once you

open a folder, your photos will be in Grid

view. When you touch a photo from Grid

view, it will be displayed in Full view.

Timeline view

The phone's Gallery provides a timeline

view of your photos and videos. From the

Grid view mode,drag to the right.

The date you took your photos will be

displayed starting with the most recent.

If you select a specific date, all the photos

you took on that day will be grouped over

a white background.

My Images options menu

Touch a photo and press the Menu Key

twice to see the following available

options: Share, Delete, Details, Set as,

Crop and Rotate Right/Left.

Sending a photo

To send a photo, touch and hold the 1

photo you want.

Touch 2 Share and choose from

Bluetooth, Email, Gmail, Messaging,

Twitter, Facebook or Picasa.

When you choose 3 Email, Gmail or

Messaging, your photo will be attached

to a message, which you can then write

and send normally.

n TIP

If you have a social networking account

set up on your phone, you can share

your photo with that social networking

community.

Multimedia

Sending a video

To send a video, touch and hold the 1

video you want.

Touch 2 Share and choose from

Bluetooth, Email, Gmail, Messaging,

or YouTube.

When you choose 3 Email, Gmail or

Messaging, your video will be attached

to a message, which you can then write

and send normally.

Using an image

Choose images to use as wallpaper or

identify callers.

Touch and hold a photo, then touch 1

More >

Set as.

Choose from2 Contact icon or

Wallpaper.

Viewing a slideshow

To view a slideshow of your photos, open

the Gallery and touch a photo. Once the

photo is displayed, touch the screen to see

the menu. Touch

Slideshow

to begin the

slideshow of all your photos.

View photo details

You can view a photo’s detailed

information, such as the name, date, time,

size, and type.

While viewing a photo, touch Menu >

More > Details.

Transferring files using USB

mass storage devices

To transfer files using a USB device:

Connect the phone to a PC using a USB 1

cable.

If you haven't installed the LG Android 2

Platform Driver on your PC, you need to

change the settings manually. From the

Home screen, press the

Menu Key

and

touch Settings > SD card & phone

storage > Mass storage only.

Touch 3 Turn on USB storage.

You can view the mass storage content 4

on your PC and transfer the files.

n NOTE

You need to insert the microSD card ﬁrst.

Without an microSD card, you cannot use

USB mass storage.

Multimedia

n NOTE

If you installed the LG Android Platform

Driver, you will see a pop up saying,

'Turn on USB storage' immediately after

connecting the phone to the PC.

Music

Your phone has a music player that lets

you play all your favorite tracks. To access

the music player from the Home screen,

touch the

Applications Launcher Key

and touch

Music

How to save music/video files

to the phone

Connect your phone to the PC using

the USB cable.

You'll receive a notification that the USB is

connected. Touch

Turn on USB storage

. Then open the folder you wish to view

from your computer.

If you did not install the LG Android Platform

Driver on your PC, you need set it manually.

For more information, refer to 'Transferring

files using mass storage devices' .

Save music or video files from the PC

to the phone's removable storage.

- You may copy or move files from the PC to

the phone's removable storage using a card

reader.

- If there is a video file with a subtitle file

(.smi file with the same name as the video

file), place them in the same folder to display

the subtitle automatically when playing the

video file.

- When downloading music or video files,

corrupted file or file with a wrong extension

may cause damage to the phone.

How to play music/video files

on the phone

Playing music/video files

Locate the file you want in the Gallery and

touch it to play it.

Playing a song

From the Home screen, touch the 1

Applications Launcher Key and touch

Music.

Touch the 2 Songs tab.

Multimedia

Touch the song you want to play.3

Touch 4 to pause the song.

Touch 5 to skip to the next song.

Touch 6 to go back to the beginning

of the song. Touch twice to go

back to the previous song.

To change the volume while listening to

music, press the up and down Volume

Keys on the right side of the phone.

To display the options for a song, touch

and hold any song in the list. You will

see the following options: Play, Add

to playlist, Use as phone ringtone,

Delete, Details, and Search.

Working with Playlists

You can create playlists to organize your

music files into sets of songs, which

you can play in the order you set or in a

shuffle.

To create a playlist

When viewing a list of songs in the 1

library, touch and hold the first song you

want to add to the new playlist.

Touch 2

Add to playlist

Touch3 New.

Enter a name for the playlist, then touch 4

Save

The new playlist is added to the

Playlists library.

You can also add the song that is

playing in the Playback screen as the

first song in a playlist by pressing the

Menu Key, then touching Add to

playlist or touching

Save as playlist

to save all the songs in an album that

you're playing as a playlist.

To remove a song from a

playlist

Open a playlist.1

Touch and hold the song you want to 2

remove, then touch Remove from

playlist or when viewing the currently

playing playlist, press the Menu Key,

then touch

Clear playlist

to remove all

the songs from the current playlist.

Multimedia

To rename or delete a

playlist

Open the 1

Playlist

library.

Touch and hold the playlist to display 2

the options menu, then touch

Delete

Rename

n NOTE

Music file copyrights may be protected

by international treaties and national

necessary to obtain permission or a

licence to reproduce or copy music. In

some countries, national laws prohibit

private copying of copyrighted material.

Before downloading or copying the file,

please check the national laws of the

relevant country concerning the use of

such material.

Multimedia

About Google applications

Google applications, including mobile

versions of Gmail, Google Talk, Google

Calendar, and Google Maps, are loaded on

your phone.

First, set up a Google account. Then enter 1

your user name and password and sign in.

After signing in, your contacts, email, 2

and calendar in your Google account will

automatically synchronize with your phone.

Google Maps™

To open Google Maps and view

your location

Touch 1

Maps

on the Home screen or in the

Launch screen.

Touch the My location 2

icon

the map.

The map centers on a blue dot that

indicates your location. A blue circle around

the dot indicates that your actual location is

within the circle.

To get an address and additional

information for a location

] Touch and hold a location on the map. A

balloon with the address and a thumbnail

from Street View (if available) opens over

the location.

] Touch the balloon to access additional

options.

To view map, satellite, or traffic

layers

] Touch the Layers icon on the map

and select a layer option. You can choose

from Traffic, Satellite, Terrain, Latitude, or

More Layers.

Searching For Locations and

Places

You can search for a location and view it on

a map. You can also search for places on

the map that you're viewing.

To search for a location

While viewing a map, press the 1 Menu Key

and touch Search or press the Search Key.

In the search box, enter the place 2

you're looking for. You can enter an

address, a city, or a type of business or

establishment. For example, “theater in

New York”.

Touch the Search icon. 3

Markers with letter labels indicate

search matches on the map.

Google applications

Getting Directions

To get directions

While viewing a map, press the 1 Menu Key

and touch

Directions

Enter a starting point in the first text box and 2

your destination in the second text box.

To reverse directions, press the

Menu Key

and touch Reverse Start & End.

Touch the icon for car, public transit, bicycling, 3

or walking directions.

Touch 4

The directions to your

destination appear in a list.

To view turn-by-turn directions in a list

You can view each turn in your route as a

list of written directions.

When viewing a list of directions, touch

the

Navigate icon to view turn-by-turn

directions in Navigation View.

To search for locations along your route

You can search for businesses, points of

interest, and other features along your

route. When you search while navigating,

your results include locations along your

route, rather than locations that are near

your current location.

]

Press the Search Key and search for

locations of interest.

The results are displayed as markers

along your route; the ﬁrst result is

labeled. You can use the left and right

arrow buttons to move from result to

result, zoom in and out, or touch a label

for more information about the marker.

]

When you're ﬁnished, touch the

Navigation icon to return to Navigation

View.

Starred Places

Starred Places bookmarks your favorite

places, such as addresses or local businesses,

to be able to find them quickly later.

To view Starred Places

While viewing a map, press the

Menu Key

and

touch Starred Places.

Clear Map

Clear any information, such as routes and

search results, from the map.

To clear a map

While viewing a map, press the

Menu Key

and

touch Clear Map.

Google applications

Latitude

Finding Your Friends with Google

LatitudeTM

Google Latitude lets you and your friends

view each others' locations on maps and get

directions to your friends' locations using

Google Latitude. Your location is not shared

automatically. It is by invitation only.

You must join Latitude and then invite your

friends to view your location or accept

invitations from your friends.

To join Latitude

] While viewing a map, press the

Menu Key

and touch

Join Latitude

The first time you join Latitude, you're

prompted to accept or reject the Google

the Join Latitude item changes to

Latitude

To open Latitude

After you join Latitude, you can open it to find

your friends and view their updates.

] While viewing a map, press the

Menu Key

and touch

Latitude

To invite friends to share their

locations

After you join Latitude, you can start sharing

your location with your friends. Only friends

whom you have explicitly invited or accepted

can see your location.

Open Latitude, press the 1 Menu Key and touch

Add friends

Touch 2

Select from Contacts

Add via

email address

in the menu that opens.

Touch 3

Add friends

at the bottom of the

screen. If your friends already use Latitude,

they receive an email request and a notification

on Latitude. If they have not yet joined

Latitude, they receive an email inviting them to

Places

To ﬁnd places

Touch the

Places

icon while in Google Maps

to find different venues, such as gas stations,

coffee shops, bars, restaurants, etc.

Once you select a category, you will see a list

of closest matches, including their distance,

compass bearing, description and even user

reviews. You can customize your own location

search categories, and even add the Places

icon to your Home screen.

Google applications

Tip

While viewing a map, press the Menu Key

and touch More for the following options:

Labs, Cache Settings, Help, Terms,

Privacy & Notices and About.

Market™

Android Market™ lets you browse through

and download thousands of fun and useful

applications and games. You can check other

users' comment regarding an application

or you can post your own comments. If you

install applications and games from Android

Market™, they appear in the phone's menu

below the preloaded applications, and you can

find them by scrolling down with your finger.

You can open downloaded applications from

the Market by pressing the

Menu Key

and

touching

My apps

To download applications and games

From the Android Market home page, touch 1

a category near the top of the screen.

Scroll to view subcategories and touch the 2

one you want to explore.

Touch an application to open its details 3

screen, or further sort the subcategory by

touching

Top paid, Top free,

Just in

Touch the application you desire to install. 4

The descriptions and the prices of the

application will be displayed.

Touch the 5

price

button at the top right of

the screen for paid applications. For free

applications, touch the

FREE

button. The

applications will then be downloaded and

installed.

n NOTE

To purchase a paid app, you’ll need to set up a

payment method with Google Checkout™. You

have the option to use a credit card or charge

to your carrier bill.

n NOTE

When you want to exit a game or application,

use the Home or Back Key, which will return

you to the Home screen. Or select Menu (or

Options) within the game or application and

select Exit. (Exit option may vary by game/

application). Ending applications that continue

to run in the background (after going back to

the Home screen) will help conserve battery

life and reduce unwanted data usage.

Google applications

Gmail™

Gmail™ can be configured when you first

set up your phone. Depending on your

synchronization settings, Gmail™ on your

phone is automatically synchronized with

your Gmail™ account on the web.The inbox

conversations list is your default Gmail™ view.

Press the

Menu Key,

then touch

Refresh

send or receive new email and to synchronize

your email with your Gmail™ account on the

web. Press the

Menu Key

for the following

additional options:

Compose, Accounts,

to labels

and

Press the

Menu Key

and touch

Accounts

Add account

to add another Gmail

account. You can also change the settings by

pressing the

Menu Key

and touching

Settings

from any screen within an account.

Google Talk™

Google Talk™ is Google’s instant messaging

program. It lets you communicate with other

people who also use Google Talk™.

Press the

Menu Key

for the following

available options.

All friends

– Displays all friends you can

communicate with.

Add friend

– Send invitations to chat.

– It searches for contacts to

chat with or any chat records that contain the

word(s) you entered.

Sign Out

– Sign out from chat. When

you touch the Talk icon from the Home screen,

you will be signed in automatically if you

activate

Automatically sign in

Settings

– Allows you to adjust various

settings.

– Choose from

Close all chats

close all the current chats,

Invites

to see a list

of friends you have invited to chat, or

Blocked

to view a list of friends you have blocked.

Changing Google Talk Settings

You can configure Google Talk to send you a

notification of each message that you receive

in a chat and also to sound a ringtone or

vibrate the phone.

You can also configure Google Talk to sign you

in automatically when you turn on your phone,

and you can set whether the mobile indicator

is displayed next to your name in other

people's Friends lists.

To configure notifications for

new Google Talk messages

From the Friends list, press the 1

Menu Key,

then touch

Settings

Checkmark 2

IM notifications

to receive a

notification in the Status Bar when a new

chat message arrives.

Touch 3

Select ringtone

to choose a

ringtone that will ring to notify you of a

new chat.

Touch 4

Vibrate

to choose the vibration

setting when you receive a notification of

a new chat.

To show or hide the mobile

indicator to friends

From the Friends list, press the 1

Menu Key,

then touch

Settings

Checkmark or uncheck 2

Mobile indicator

If Mobile indicator is checkmarked, your

friends see an outline of an Android

to your name in their Friends list when you

are signed into Google Talk on an Android

phone.

To set whether you sign into

Google Talk automatically

From the Friends list, press the 1

Menu Key,

then touch

Settings

Checkmark or uncheck 2

Automatically

sign

. When Automatically sign in is checked,

you are signed into Google Talk when you

turn on your phone.

To set Google Talk to change

your status

From the Friends list, press the 1

Menu Key

then touch

Settings

Checkmark or uncheckmark 2

Automatic

away-status

When Automatic away-status is

checkmarked, your status will automatically

be changed to Away when the screen is

turned off.

Google applications

Setting the alarm

From the Home screen, touch the 1

Applications Launcher Key

and touch

Clock

To add a new alarm, touch 2 .

Touch 3

Add alarm

and set the alarm time.

After you set the time, the phone will let

you know how much time is left before the

alarm sounds.

Set 4

Repeat

Ringtone

Vibrate

and add

Label

to name the alarm. Touch

Done

Press the 5

Menu Key

to add another alarm

or adjust the alarm settings.

Using the calculator

From the Home screen, touch the 1

Applications Launcher Key

and touch

Calculator

Touch the number keys to enter numbers.2

For simple calculations, touch the function 3

you want (+, –, x, or ÷), followed by =.

For more complex calculations, press the 4

Menu Key,

touch the

Advanced panel

then choose an option.

Adding an event to your

calendar

NOTE

You must create a Google account to use

Calendar.

From the Home screen, touch the 1

Applications Launcher Key

and touch

Calendar

To view an event, touch the date. If you 2

want to add an event, touch and hold a date,

then touch

New event

Touch the3

What

field and enter the event

name. Check the date and enter the start

and end time you want your event to begin

and finish.

Touch the 4

Where

field to enter the location.

To add a note to your event, touch the 5

Description

field and enter the details.

To repeat the event, set 6

Repetition

, and set

Reminders

, if necessary.

Touch 7

Done

to save the event in the

calendar. A colored square in the calendar

will mark all days that have saved events.

An alarm will sound at the event start time

if you set it.

Utilities

Changing your calendar view

From the Home screen, touch the 1

Applications Launcher Key

and touch

Calendar

Press the 2

Menu Key

and touch

Day,

Week, Agenda,

Month

ThinkFree Office

With ThinkFree Office, you can create, view

and edit document files in an email or on a

microSD card inserted in your device. The

ThinkFree Office application supports the

following file formats: txt, doc, docx, xls, xlsx,

ppt, pptx, pdf.

Create a New Document

From the Home screen, touch the1

Applications Launcher Key

ThinkFree Office

Touch 2

Activate now

(This is necessary only when you launch this

application for the first time.)

Touch the 3

My Docs

tab for folders and

documents on your microSD card.

Press the 4

Menu Key

, then touch

New

start a new document.

Touch the type of document and enter a 5

name for the document, then touch

Enter contents in the document using the 6

tools at the bottom of the screen.

When you're done working on the document, 7

press the

Menu Key

, touch

File

Save

(or

Save as

and enter a new document name),

then press the

Back Key

to exit.

NOTE

To save without exiting, simply touch

Save

the bottom of the screen and continue working

on the document.

View and edit a document on your

device

From the Home screen, touch the 1

Applications Launcher Key

ThinkFree Office

Touch the 2

My Docs

tab for folders and

documents on your microSD card.

Touch the document you want to view or edit. 3

If it's not in the root directory, touch the folder

where it's stored, then touch the document

name to open it.

NOTE

You can also open an attachment in an email

by touching the attachment in the message.

The document opens for you to view. If you 4

want to edit it, press the

Menu Key

then

touch

Edit

Utilities

] To move between pages or pan through

the document, scroll in the corresponding

direction.

] To change the zoom level, press the

Key

, touch

Zoom

, then touch the zoom

level you want.

] Use the toolbar at the bottom of the screen

to make edits to the document (Word, text,

or Excel file).

] Press the

Menu Key

for additional menu

options such as search, preferences, and

more.

When you're finished editing, touch 5

Save

then press the

Back Key

to exit.

ThinkFree Ofﬁce document tools

The ThinkFree Office application has a toolbar

that appears automatically when you create a

document. To display the toolbar in an existing

document, press the

Menu Key

, then touch

Edit

. Touch a toolbar icon and corresponding

tools display in a bar beneath it for you to

touch and use. Left and right arrows on the

toolbar indicate that you can scroll horizontally

for more icons. Scrolling works independently.

While a tool is selected (for example the

Select text tool ), you can scroll the toolbar

to touch an other toolbar icon (for example

the clipboard tool to copy the text you just

selected). Touch the toolbar icon again to close

tool options.

The tools in the toolbar vary depending on the

document type.

Manage documents online

From the Home screen, touch the 1

Applications Launcher Key

ThinkFree Office

Touch the 2

Online tab

for access to your

ThinkFree Office online account.

Enter your user name and password to 3

access your account, then touch

View and manage your documents on the 4

server as desired.

Voice Search

You can search by voice and complete other

voice actions, such as calling or texting a

contact, sending an email, creating a note or

getting directions with just a simple touch of

the Voice Search icon.

From the Home screen, touch the 1

Applications Launcher Key

Voice

Wait for the "2

Speak now

" prompt, then

say your query.

Available commands include:

- Send text

- Navigate to

- Call

- Send email

- Map of

- Go to

- Note to self

- Directions to

For a "Go to" web query, the search results 3

will be displayed in the web browser. Touch

the result you want or continue searching.

Voice Dialer

You can search for and dial a contact by

speaking, rather than by manually dialing

a contact.

]

This feature may be unavailable

depending on your region.

]

Your device can recognize only American

English commands.

]

Recognized languages may vary

depending on your region.

To place a call by speaking

From the Home screen, touch the 1

Applications Launcher Key

Voice

Dialer

Say "2

Call

" or "

Dial

" followed followed by

the name of the contact to call.

If Voice Dialer finds a match, it dials the

contact's default number.

Voice recorder

Use the voice recorder to record voice memos

or other audio files.

Recording a sound or voice

From the Home screen, touch the 1

Applications Launcher Key

and touch

Voice Recorder

Touch 2 to begin recording.

Touch 3 to end recording.

NOTE

Touch Go to list to access your voice

recordings. You can listen to the saved

recordings.

Sending the voice recording

Once you have finished recording, you can 1

send the audio clip by pressing the

Key

and touching

Choose from 2

Bluetooth, Email, Gmail

and

Messaging

. When you select

Email,

Gmail

Messaging,

the voice recording

will be added to a message that you can

write and send normally.

Utilities

Using Car Home

You can use the Car Home application whether

or not you have a phone car dock (the optional

accessory.)

] Insert the phone into the car dock.

] Touch the

Car Home

icon in the

Launch screen.

From the Car Home application, you can

access Navigate, Voice Search, Music, Phone,

Contacts, Map, Settings, and the Brightness

settings.

Utilities

Browser

The Browser gives you a fast, full-color world

of games, music, news, sports, entertainment,

and much more, right on your mobile phone.

n NOTE

Additional charges apply when connecting

to these services and downloading content.

Check data charges with your network

provider.

Using the Web browser

You phone comes with a full HTML web

browser that allows you to look at webpages

similarly to how you would on a computer.

From the Home screen, touch 1 .

Scroll up and down the screen to navigate 2

and touch links to open them. Double-tap on

the screen to zoom in; double-tap again to

zoom back out.

To visit another website, touch the web

address bar at the top of

the page, enter an address, and touch .

Using options

Press the Menu Key to view the following

options:

New window – Open a new window.

Bookmarks – Displays your bookmarks

and allows you to add new ones. You can

also view a list of your most visited sites

and your web browsing history.

Windows – Displays all your open

windows.

Refresh – Touch to refresh the web

page.

Forward – Used in conjunction with

the Back Key. This allows you to go back

and forth between web pages without

opening multiple windows.

• Add bookmark – Add the current

web page as bookmarks.

• Find on page – Use this feature to

find a specific word or phrase on a

web page.

• Select text – Allows you to copy text

from the web page.

• Page info – Displays information for

the current web page.

• Share page – Allows you to share the

web page with your friends and family.

• Downloads – Displays your download

history.

• Settings – Allows you to configure

browser settings.

The Web

n TIP

To return to the previous web page, press the

Back key.

Accessing bookmarks

Press the 1 Menu Key and touch

Bookmarks.

To access the bookmark, simply touch the 2

bookmark.

Adding bookmarks

Press the 1

Menu Key

and touch

Bookmarks

• From

Thumbnail view

, touch

Add

enter a name and URL, and touch

• From

List view

, touch

Add bookmark

enter a name and URL, and touch

Changing the Browser settings

Press the Menu Key and touch More >

Settings.

The web

Wireless & networks

This menu allows you to manage Wi-Fi and

Bluetooth connections, portable hotspot

and data tethering ,airplane mode and VPN

connections.To access this menu, from the

Home Screen, press

Menu Key

and touch

Settings > Wireless and networks

Airplane mode

Airplane mode allows you to quickly turn off all

wireless connections.

From the 1

Wireless & networks

screen,

touch the

Airplane mode

checkbox to turn

it on (a green checkmark will appear).

Touch again to turn it off.2

From the Home Screen, swipe the Status Bar 1

down to open the Notifications panel.

Touch 2 to turn on Airplane mode.

Touch again to turn it off.3

Bluetooth

Using Bluetooth

From the 1

Wireless & networks

screen,

touch

Bluetooth

to turn on the Bluetooth

setting.

Touch 2

Bluetooth settings

Scan for

devices

Touch the name of the device you wish to 3

pair with, and then touch

Pair

to pair and

connect.

n TIP

Please consult documentation included with

Bluetooth device for information on pairing

mode and passcode (typically 0 0 0 0 – four

zeroes).

How to send data from your phone via

Bluetooth

You can send data via Bluetooth by running a

corresponding application, not from Bluetooth

menu, unlike regular mobile phones.

Sending pictures:

Open the Gallery

application and touch a picture. Then touch

Bluetooth

. Check if

Bluetooth is turned on and touch

Scan for

devices

. Then touch the device you want to

send data to from the list.

Settings

Exporting contacts:

Open the Contacts

application. Touch the contact you want

to share, press the

Menu Key

and touch

Bluetooth

. Check if Bluetooth is

turned on and touch

Scan for devices

Then touch the device you want to send data

to from the list.

Sending multi-selected contacts:

Open

the Contacts application. To select more

than one contact, press the

Menu Key

and

touch

Multiselect

. Touch the contacts you

want to send or press the

Menu Key

and

touch

Select all.

Then touch

Share >

Bluetooth.

Check if Bluetooth is turned on

and touch

Scan for devices

. Then touch

the device you want to send data to from

the list.

Connecting to FTP (Only the FTP

server is supported on this handset):

From the Home screen, press the Menu

Key and touch Settings > Wireless &

networks > Bluetooth settings. Make sure

Bluetooth is turned on. Touch Discoverable

to place a checkmark and make the phone

visible to other Bluetooth devices. Then

search for other devices. Find the service you

want and connect to the FTP server.

TIP

The supported Bluetooth version is Bluetooth

2.1 EDR and certified by Bluetooth SIG. It is

compatible with other Bluetooth SIG certified

devices.

- If you want to search for this phone from

other devices,from the Home screen,

press the Menu Key and touch Settings

> Wireless & networks > Bluetooth

settings. Make sure Bluetooth is turned on.

Touch Discoverable to place a checkmark

and make the phone visible to other

Bluetooth devices for 120 seconds.

- Supported profiles are SDAP, HFP, HSP, OPP,

PBAP (server), FTP (server), A2DP, AVRCP,

and DUN.

Wi-Fi

To use Wi-Fi on your phone, you need

access to a wireless access point, or

"hotspot." Some access points are open

and you can simply connect to them.

Others are hidden or implement other

security features, so you must configure

your phone in order to connect to them.

You get free access to AT&T WiFi Hot

Spots at thousands of locations across

Settings

the country with Wi-Fi, without wireless

data charges.

To locate AT&T WiFi hotspots nearby,

open the AT&T Hot Spots application in

the Application Launcher or visit

www.attwifi.com

Turn on Wi-Fi

From the Home Screen , open the

Notifications panel and touch to turn

Wi-Fi on.

Press the Menu Key and touch Settings

> Wireless & networks > Wi-Fi .

To connect to a Wi-Fi

Network

Turn off Wi-Fi when you're not using it to

extend the life of your battery.

To turn Wi-Fi on and connect to a Wi-Fi

network

From the Home screen, press the 1

Key

and touch

Settings

Wireless &

networks

Wi-Fi settings

Touch 2

Wi-Fi

to turn it on and begin scanning

for available Wi-Fi networks.

A list of available Wi-Fi networks will

be displayed. Secured networks are

indicated by a lock icon.

Touch a network to connect to it.3

- If the network is open, you are prompted

to confirm that you want to connect to

that network by touching

Connect

- If the network is secured, you are

prompted to enter a password or

other credentials. (Ask your network

administrator for details).

The Status Bar at the top of your screen 4

will display an icon that indicates your

Wi-Fi status.

n TIP

If you are not in range of a Wi-Fi network

and use a 3G connection, additional data

charges may apply.

n NOTE

Access to the Internet and a wireless

router required. As an added

convenience, AT&T has shipped certain

smartphones with Wi-Fi enabled as a

default setting. Leaving Wi-Fi enabled

when not connected to a Wi-Fi network

may affect battery charge. Qualifying

data plan required.

Settings

n NOTE

This device supports WEP, WPA/

WPA2-PSK and 802.1x EAP. security. If

your Wi-Fi service provider or network

administrator sets encryption for network

security, enter the key in the pop-up

window. If encryption is not set, this pop-

up window will not be shown. You can

obtain the key from your Wi-Fi service

provider or network administrator.

Data Tethering

You can use your phone to provide a data

connection to a computer by activating

data tethering and connecting them with

a USB cable.

To tether your phone with your computer

using the USB

Connect your phone to your computer with 1

a USB cable.

From the Home screen, press the 2

Key

and touch

Settings

Wireless &

networks

Tethering & portable

hotspot > USB tethering

A green check mark will appear, indicating 3

that the function is activated.

n NOTE

- Data Tethering requires an appropriate

DataPro data plan. Devices connected by

tethering use data from your DataPro plan.

Plans are not unlimited and significant

charges may be incurred if the included

data allowance is exceeded. Performance

may vary depending on the number of

devices connected and other factors.

- You cannot access your phone's microSD

card on your computer when using USB

tethering.

Mobile Hotspots

You can also use your smartphone to

provide a mobile broadband connection

for up to 4 other devices. Create a hotspot

and share your connection.

To use tethering, attach the device you 1

want to tether to your phone with a USB

cable and touch

Tethering & portable

hotspot

USB tethering

in the Wireless

& networks screen.

To create a portable hotspot, touch 2

Tethering & portable hotspot

Portable Wi-Fi hotspot

in the Wireless

& networks screen. Set a password upon

first use.

n NOTE

Mobile Hotspots requires an appropriate

DataPro data plan. Devices connected to

your Mobile Hotspot use data from your

DataPro plan. Plans are not unlimited and

signiﬁcant charges may be incurred if the

included data allowance is exceeded.

Performance may vary depending on the

number of devices connected and other

factors. If you do not use a password,

others will be able to use your Mobile

Hotspot connection.

Call settings

You can set Fixed Dialing Numbers,

Voicemail

and

Other call settings

including

TTY mode

Send Messages

Call forwarding

Call duration

and

Additional settings

Sound

Adjust sound, notification default settings and

vibrate mode. You can also manage audible

and Haptic feedback.

Haptic feedback

– Vibrate when pressing

soft keys and on certain user interface

interactions.

Display

Brightness

– Adjust the brightness of the

screen.

Auto-rotate screen

– Set to switch

orientation automatically when you rotate

the phone.

Animation

– Set to allow animations.

Screen timeout

– Set the time delay before

the screen automatically turns off.

Location & security

Use wireless networks

– If you check Use

wireless networks, your phone will determine

your approximate location by using Wi-Fi and

mobile networks. When you check this option,

you’re asked whether you consent to allowing

Google to use your location when providing

these services.

Use GPS satellites

– If you check Use GPS

satellites, your phone will be determine your

location to street-level accuracy.

Set up screen lock

– Set an unlock pattern

to secure your phone. Opens a set of screens

that guide you through drawing a screen

unlock pattern. You can set a PIN or Password

instead of a Pattern or leave it as None.

Settings

When you turn on your phone or wake up the

screen, you're prompted to draw your unlock

pattern to unlock the screen.

Screen lock timer

- Set the amount of idle

time before the screen lock is enabled.

Set up Sim card lock

– Set up SIM card

lock or change SIM PIN.

Visible passwords

– Select to show

passwords as you type them or deselect to

hide passwords as you type them.

Select device administrators

– Add or

remove administrators.

Use secure credentials

– Allows you to

access secure certificates

Install from SD card

– Choose to install

encrypted certificates from your microSD card.

Set password

– Set or change the credential

storage password.

Clear storage

- Clear credential storage of

all contents and reset its password

Using the Unlock Pattern, PIN,

or Password

Set an unlock Pattern, PIN, or Password to

secure your phone. To set the screen lock,

follow the process below.

Press the

Menu Key

, touch

Settings

Location & security

Set up screen

lock

and select between

Pattern, PIN or

Password

Warning

Take precautions when using an Unlock

Pattern, PIN, or Password. It is very

important that you remember the screen

unlock information you set. You are

allowed 5 attempts to enter your screen

unlock information. If you used up all 5

opportunities, you will have to wait 30

seconds to attempt unlocking the phone

again.

Settings

When you can’t recall your Unlock

Pattern, PIN, or Password:

If you logged into a Google account on the

phone and failed to use the correct pattern

5 times, touch Forgot Pattern? You will

be required to sign in with your Google

account and prompted to create a new

unlock pattern.

If you haven’t created a Google account

on the phone or you forgot your PIN or

Password, you need to perform a hard

reset.

Caution

If you perform a hard reset, all user

applications and user data will be deleted.

Please remember to back up any important

data before performing a hard reset.

Turn the power off.1

Press and hold the following keys at the 2

same time for 10 seconds: Power/Lock Key +

Home Key + Up Volume Key.

When the power turns on, release the keys.3

Applications

You can manage applications.

Manage Applications

– Manage and

remove installed applications.

Running services

- Check currently running

services

Development

– Set options for application

development.

Accounts & sync

Allows you to enable Background data, Auto-

sync and synchronize or add new accounts.

Privacy

Allows you to perform a Factory data reset. Be

careful as this will erase all your data.

SD card & phone storage

Allows you to check total available microSD

card and internal phone storage space. You

can also unmount the microSD card to safely

remove it or format it.

Settings

Touch

Google search

and you can adjust

Google search settings.

Adjust Searchable items so you can get

necessary information effectively . Choose

from

Web

Apps, Contacts, Messaging

Search, Music

Twitter

Voice Search

You can also clear shortcuts to recently chosen

search suggestions.

Language & keyboard

Select language and customize the input

method and keyboard settings.

Voice input & output

Set Voice recognizer settings and use the Text-

to-Speech settings to configure the Android

text-to-speech synthesiser, for applications that

can take advantage of it.

Accessibility

Use the Accessibility settings to configure any

accessibility plug-ins you have installed on

your phone.

NOTE

Requires additional plug-ins to become

selectable.

Date and time

Set date, time, time zone and date and time

formats.

About phone

View legal information, and check phone

status and software versions.

Settings

Phone Software update

This feature allows you to update the

firmware of your phone to the latest version

conveniently from the internet without the

need to visit a service center.

For more information on how to use this

function, please visit:

http://update.lgmobile.com or

http://www.lg.com/common/ index.jsp.

As the mobile phone firmware update requires

the user’s full attention for the duration of the

update process, please make sure to check all

instructions and notes that appear at each step

before proceeding. Please note that removing

the USB cable or battery during the upgrade

may seriously damage your mobile phone.

DivX Mobile

ABOUT DIVX VIDEO: DivX

is a digital video

format created by DivX, Inc. This is an official

DivX Certified

device that plays DivX video.

Visit www.divx.com for more information and

software tools to convert your files into DivX

video.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX

Certified

device must be registered in order to

play purchased DivX Video-on-Demand (VOD)

movies. To obtain your registration code, locate

the DivX VOD section in your device Settings

menu. Go to vod.divx.com for more information

on how to complete your registration.

DivX Certified® to play DivX® video up

to 320 x 240.

DivX

, DivX Certified

and associated logos

are trademarks of DivX, Inc. and are used

under license.

Software update

For Your Safety

Important Information

This user guide contains important information

on the use and operation of this phone. Please

read all the information carefully for optimal

performance and to prevent any damage

to or misuse of the phone. Any changes or

modifications not expressly approved in this

user guide could void your warranty for this

equipment. Any changes or modifications

not expressly approved by the manufacturer

could void the user’s authority to operate the

equipment.

Before You Start

Safety Instructions

WARNING! To reduce the possibility of

electric shock, do not expose your phone to

high humidity areas, such as the bathroom,

swimming pool, etc.

Always store your phone away from heat.

Never store your phone in settings that may

expose it to temperatures less than 32°F or

greater than 104°F, such as outside during

extreme weather conditions or in your car on

a hot day. Exposure to excessive cold or heat

will result in malfunction, damage and/or

catastrophic failure.

Be careful when using your phone near

other electronic devices. RF emissions

from your mobile phone may affect nearby

in adequately shielded electronic equipment.

You should consult with manufacturers of any

personal medical devices such as pacemakers

and hearing aides to determine if they are

susceptible to interference from your mobile

phone. Turn off your phone in a medical facility

or at a gas station. Never place your phone

in a microwave oven as this will cause the

battery to explode.

IMPORTANT! Please read the TIA SAFETY

INFORMATION before using your phone.

Safety Information

Read these simple guidelines. Breaking the

rules may be dangerous or illegal. Further

detailed information is given in this user guide.

]

For Your Safety

The design of this phone complies with

the FCC guidelines and these international

standards.

CAUTION

Use only the supplied and approved antenna.

Use of unauthorized antennas or modifications

could impair call quality, damage the phone,

void your warranty and/or result in violation

of FCC regulations. Do not use the phone with

a damaged antenna. If a damaged antenna

comes into contact with skin, a minor burn

may result. Contact your local dealer for a

replacement antenna.

Body-worn Operation

This device was tested for typical body-worn

operations with the back of the phone kept

0.79 inches (2cm) between the user’s body

and the back of the phone. To comply with

FCC RF exposure requirements, a minimum

separation distance of 0.79 inches (2cm) must

be maintained between the user’s body and

the back of the phone. Third-party belt-clips,

holsters, and similar accessories containing

metallic components should not be used.

Body-worn accessories that cannot maintain

0.79 inches (2cm) separation distance between

the user's body and the back of the phone,

and have not been tested for typical body-

worn operations may not comply with FCC RF

exposure limits and should be avoided.

FCC Part 15 Class B Compliance

This device and its accessories comply with

part 15 of FCC rules. Operation is subject

to the following two conditions: (1) This

device and its accessories may not cause

harmful interference, and (2) this device and

its accessories must accept any interference

received, including interference that may

cause undesired operation.

Part 15.105 statement

This equipment has been tested and found

to comply with the limits for a class B

digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide

reasonable protection against harmful

interference in a residential installation.

This equipment generates uses and can

radiate radio frequency energy and, if not

installed and used in accordance with the

instructions, may cause harmful interference

to radio communications. However, there is no

guarantee that interference will not occur in a

particular installation.

For Your Safety

If this equipment does cause harmful

interference or television reception, which

can be determined by turning the equipment

off and on, the user is encouraged to try to

correct the interference by one or more of the

following measures:

] Reorient or relocate the receiving antenna.

] Increase the separation between the

equipment and receiver.

] Connect the equipment into an outlet on

a circuit different from that to which the

receiver is connected.

] Consult the dealer or an experienced radio/

TV technician for help.

Cautions for Battery

]

Safety Guidelines

123

Hearing Aid Compatibility

(HAC) with Mobile Phones

When some mobile phones are used near

some hearing devices (hearing aids and

cochlear implants),users may detect a buzzing,

humming, or whining noise. Some hearing

devices are more immune than others to this

interference noise, and phones also vary in

the amount of interference they generate. The

wireless telephone industry has developed

ratings for some of their mobile phones, to

assist hearing device users in finding phones

that may be compatible with their hearing

devices. Not all phones have been rated.

Phones that are rated have the rating on their

box or a label on the box. The ratings are not

guarantees. Results will vary depending on

the user’s hearing device and hearing loss. If

your hearing device happens to be vulnerable

to interference, you may not be able to use a

rated phone successfully. Trying out the phone

with your hearing device is the best way to

evaluate it for your personal needs.

M-Ratings: Phones rated M3 or M4 meet FCC

requirements and are likely to generate less

interference to hearing devices than phones

that are not labeled. M4 is the better/higher of

the two ratings.

T-Ratings:

Phones rated T3 or T4 meet FCC

requirements and are likely to be more usable

with a hearing device’s telecoil (“T Switch” or

“Telephone Switch”) than unrated phones. T4 is

the better/higher of the two ratings. (Note that

not all hearing devices have telecoils in them.)

T-coil statement for CF360

Achieve optimal antenna performance of the

phone by sliding the phone open to make or

receive a call.

Hearing devices may also be measured for

immunity to this type of interference. Your

hearing device manufacturer or hearing health

professional may help you find results for your

hearing device. The more immune your hearing

aid is, the less likely you are to experience

interference noise from mobile phones.

To ensure that the Hearing Aid Compatibility

rating for your phone is maintained, secondary

transmitters such as Bluetooth and WLAN

components must be disabled during a call.

See Page 73 for instructions to disable these

components.

※ HAC statement regarding Multiband

This phone has been tested and rated for use with

hearing aids for some of the wireless technologies

that it uses.

However, there may be some newer wireless

technologies used in this phone that have not been

tested yet for use with hearing aids.

It is important to try the different features of this phone

thoroughly and in different locations, using your hearing

aid or cochlear implant, to determine if you hear any

interfering noise.

Consult your service provider or the manufacturer of this

phone for information on hearing aid compatibility.

If you have questions about return or exchange policies,

consult your service provider or phone retailer.

LG Electronics USA P930 GSM/WCDMA AND LTE PHONE WITH BLUETOOTH AND WLAN User Manual LG P30 ATT EN 110405 indd

LG Electronics USA GSM/WCDMA AND LTE PHONE WITH BLUETOOTH AND WLAN LG P30 ATT EN 110405 indd

Users Manual

Navigation menu

Namespaces

Views

Navigation
