LG Electronics USA S147ZHA Microwave Oven User Manual
LG Electronics USA Microwave Oven Users Manual
Users Manual
Microwave Oven
3828W5A3666 164D3370P318 49-40388 06-03 JR
JES1339
Owner’s
Manual
Safety Information
Adapter Plugs . . . . . . . . .9
Arcing . . . . . . . . . . . . . . .4
Extension Cords . . . . .10
Foods . . . . . . . . . . . . .4, 5
Grounding
Instructions . . . . . . . . . .8
Microwave-Safe
Cookware . . . . . . . . . .6, 7
Precautions to Avoid
Possible Exposure to
Excessive Microwave
Energy . . . . . . . . . . . . . .2
Safety Precautions . . .2, 3
Operating Instructions
Convenience
Features . . . . . . . . .23–26
Microwave Terms . . . . .30
Other Features . . . .27–29
Oven Features . . . .14, 15
Power Levels . . . . . . . . .16
Time Features . . . .17–22
Care and Cleaning
Inside . . . . . . . . . . . . . .31
Outside . . . . . . . . . . . . .32
Turntable . . . . . . . . . . .31
Troubleshooting
Tips . . . . . . . . . . . . .33, 34
Things That Are
Normal With Your
Microwave Oven . . . . .34
Consumer Support
Consumer
Support . . . . .Back Cover
Product Registration . .12
Warranty . . . . . . . . . . . .35
www.GEAppliances.com
49-40388 v07 6/18/03 11:07 AM Page 1
■Read and follow the specific
precautions in the Precautions
to Avoid Possible Exposure to
Excessive Microwave Energy
section above.
■This appliance must be
grounded. Connect only to
a properly grounded outlet.
See the Grounding Instructions
section on page 8.
■Install or locate this
appliance only in accordance
with the provided Installation
Instructions.
■Be certain to place the front
surface of the door three
inches or more back from
the countertop edge to avoid
accidental tipping of the
appliance in normal usage.
■Do Not Attempt to operate
this oven with the door open
since open-door operation
can result in harmful
exposure to microwave
energy. It is important not
to defeat or tamper with
the safety interlocks.
■Do Not Place any object
between the oven front
face and the door or allow
soil or cleaner residue to
accumulate on sealing
surfaces.
■
Do Not Operate the oven if it
is damaged. It is particularly
important that the oven door
close properly and that there
is no damage to the:
door (bent)
hinges and latches
(broken or loosened)
door seals and sealing
surfaces.
■The Oven Should Not
be adjusted or repaired by
anyone except properly
qualified service personnel.
3
2
1
PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
Safety InformationOperating Instructions
Troubleshooting Tips
Consumer Support
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
2
For your safety, the information in this manual must be
followed to minimize the risk of fire or explosion, electric
shock, or to prevent property damage, personal injury, or
loss of life.
When using electrical appliances basic safety
precautions should be followed, including the following:
SAFETY PRECAUTIONS
WARNING!
49-40388 v07 6/18/03 11:07 AM Page 2
3
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
Use this appliance only for its intended purpose as described in this
Owner’s Manual.
■This microwave oven is not approved
or tested for marine use.
■Do not mount this appliance over
a sink.
■Do not mount the microwave oven
over or near any portion of a heating
or cooking appliance.
■Do not store anything directly on top
of the microwave oven surface when
the microwave oven is in operation.
■Do not operate this appliance if it
has a damaged power cord or plug,
if it is not working properly, or if
it has been damaged or dropped.
If the power cord is damaged, it
must be replaced by General Electric
Service or an authorized service agent
using a power cord available from
General Electric.
■Do not cover or block any openings
on the appliance.
■Use this appliance only for its
intended use as described in this
manual. Do not use corrosive
chemicals or vapors in this appliance.
This microwave oven is specifically
designed to heat, dry or cook food,
and is not intended for laboratory
or industrial use.
■Do not store this appliance outdoors.
Do not use this product near water—
for example, in a wet basement, near
a swimming pool, near a sink or in
similar locations.
■Keep power cord away from heated
surfaces.
■Do not immerse power cord or
plug in water.
■Do not let power cord hang over
edge of table or counter.
■To reduce the risk of fire in the
oven cavity:
— Do not overcook food. Carefully
attend appliance when paper, plastic
or other combustible materials are
placed inside the oven while cooking.
— Remove wire twist-ties and metal
handles from paper or plastic
containers before placing them
in the oven.
— Do not use the oven for storage
purposes. Do not leave paper
products, cooking utensils or food
in the oven when not in use.
— If materials inside the oven ignite,
keep the oven door closed, turn the
oven off and disconnect the power
cord, or shut off power at the fuse or
circuit breaker panel. If the door is
opened, the fire may spread.
■See door surface cleaning instructions
in the Care and cleaning of the
microwave oven
section of this manual.
■This appliance must only be serviced
by qualified service personnel.
Contact nearest authorized service
facility for examination, repair or
adjustment.
■As with any appliance, close
supervision is necessary when
used by children.
49-40388 v07 6/18/03 11:07 AM Page 3
Arcing is the microwave term
for sparks in the oven. Arcing
is caused by:
■Metal or foil touching the
side of the oven.
■Foil not molded to food
(upturned edges act like
antennas).
■Metal, such as twist-ties,
poultry pins, or gold-rimmed
dishes, in the microwave.
■Recycled paper towels
containing small metal pieces
being used in the microwave.
■Do not pop popcorn in your
microwave oven unless in a
special microwave popcorn
accessory or unless you use
popcorn labeled for use in
microwave ovens.
■Some products such as
whole eggs and sealed
containers—for example,
closed jars—are able to
explode and should not be
heated in this microwave
oven. Such use of the
microwave oven could
result in injury.
■Do not boil eggs in a
microwave oven. Pressure
will build up inside egg yolk
and will cause it to burst,
possibly resulting in injury.
■Operating the microwave
with no food inside for more
than a minute or two may
cause damage to the oven
and could start a fire.
It increases the heat around
the magnetron and can
shorten the life of the oven.
■Foods with unbroken outer
“skin” such as potatoes, hot
dogs, sausages, tomatoes,
apples, chicken livers and
other giblets, and egg yolks
should be pierced to allow
steam to escape during
cooking.
FOODS
Safety InformationOperating Instructions
Troubleshooting Tips
Consumer Support
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
4
WARNING!
If you see arcing, press the CLEAR/OFF pad and correct
the problem.
ARCING
49-40388 v07 6/18/03 11:07 AM Page 4
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
■SUPERHEATED WATER
Liquids, such as water,
coffee or tea are able to be
overheated beyond the boiling
point without appearing to
be boiling. Visible bubbling or
boiling when the container is
removed from the microwave
oven is not always present.
THIS COULD RESULT IN VERY
HOT LIQUIDS SUDDENLY
BOILING OVER WHEN THE
CONTAINER IS DISTURBED OR
A SPOON OR OTHER UTENSIL
IS INSERTED INTO THE LIQUID.
To reduce the risk of injury
to persons:
— Do not overheat the liquid.
— Stir the liquid both before
and halfway through
heating it.
— Do not use straight-sided
containers with narrow
necks.
— After heating, allow the
container to stand in the
microwave oven for a short
time before removing the
container.
— Use extreme care when
inserting a spoon or other
utensil into the container.
■Avoid heating baby food in
glass jars, even with the lid
off. Make sure all infant food
is thoroughly cooked. Stir
food to distribute the heat
evenly. Be careful to prevent
scalding when warming
formula. The container may
feel cooler than the formula
really is. Always test the
formula before feeding
the baby.
■Don’t defrost frozen
beverages in narrow-
necked bottles (especially
carbonated beverages).
Even if the container is
opened, pressure can build
up. This can cause the
container to burst, possibly
resulting in injury.
■Hot foods and steam can
cause burns. Be careful when
opening any containers of
hot food, including popcorn
bags, cooking pouches and
boxes. To prevent possible
injury, direct steam away
from hands and face.
■Do not overcook potatoes.
They could dehydrate and
catch fire, causing damage
to your oven.
■Cook meat and poultry
thoroughly—meat to
at least an INTERNAL
temperature of 160°F.
and poultry to at least an
INTERNAL temperature
of 180°F. Cooking to these
temperatures usually protects
against foodborne illness.
5
49-40388 v07 6/18/03 11:07 AM Page 5
Make sure all cookware used in
your microwave oven is suitable
for microwaving. Most glass
casseroles, cooking dishes,
measuring cups, custard cups,
pottery or china dinnerware
which does not have metallic
trim or glaze with a metallic
sheen can be used. Some
cookware is labeled “suitable
for microwaving.”
■If you are not sure if a dish is
microwave-safe, use this test:
Place in the oven both the
dish you are testing and a
glass measuring cup filled
with 1 cup of water—set the
measuring cup either in or
next to the dish. Microwave
30–45 seconds at high. If the
dish heats, it should not be
used for microwaving.
If the dish remains cool
and only the water in the
cup heats, then the dish
is microwave-safe.
■If you use a meat
thermometer while cooking,
make sure it is safe for use
in microwave ovens.
■Do not use recycled paper
products. Recycled paper
towels, napkins and waxed
paper can contain metal
flecks which may cause arcing
or ignite. Paper products
containing nylon or nylon
filaments should be avoided,
as they may also ignite.
■Some styrofoam trays (like
those that meat is packaged
on) have a thin strip of metal
embedded in the bottom.
When microwaved, the metal
can burn the floor of the
oven or ignite a paper towel.
■Do not use the microwave to
dry newspapers.
■Not all plastic wrap is suitable
for use in microwave ovens.
Check the package for
proper use.
■Paper towels, waxed paper
and plastic wrap can be used
to cover dishes in order to
retain moisture and prevent
spattering. Be sure to vent
plastic wrap so steam can
escape.
■Cookware may become hot
because of heat transferred
from the heated food. Pot
holders may be needed to
handle the cookware.
MICROWAVE-SAFE COOKWARE
Safety InformationOperating Instructions
Troubleshooting Tips
Consumer Support
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
6
WARNING!
49-40388 v07 6/18/03 11:07 AM Page 6
7
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
■“Boilable” cooking pouches
and tightly closed plastic bags
should be slit, pierced or
vented as directed by
package. If they are not,
plastic could burst during or
immediately after cooking,
possibly resulting in injury.
Also, plastic storage
containers should be at least
partially uncovered because
they form a tight seal. When
cooking with containers
tightly covered with plastic
wrap, remove covering
carefully and direct steam
away from hands and face.
■Use foil only as directed in
this guide. TV dinners may
be microwaved in foil trays
less than 3/4″high; remove
the top foil cover and return
the tray to the box. When
using foil in the microwave
oven, keep the foil at least
1″away from the sides of
the oven.
■Plastic cookware—Plastic
cookware designed for
microwave cooking is very
useful, but should be used
carefully. Even microwave-
safe plastic may not be as
tolerant of overcooking
conditions as are glass or
ceramic materials and may
soften or char if subjected
to short periods of
overcooking. In longer
exposures to overcooking,
the food and cookware
could ignite.
Follow these guidelines:
Use microwave-safe
plastics only and
use
them in strict
compliance
with
the cookware
manufacturer’s
recommendations.
Do not microwave empty
containers.
Do not permit children
to use plastic cookware
without complete
supervision.
3
2
1
49-40388 v07 6/18/03 11:07 AM Page 7
This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electric current.
This appliance is equipped with a power cord having a grounding
wire with a grounding plug. The plug must be plugged into an
outlet that is properly installed and grounded.
Consult a qualified electrician or service technician if the grounding
instructions are not completely understood, or if doubt exists as to
whether the appliance is properly grounded.
If the outlet is a standard 2-prong wall outlet, it is your personal
responsibility and obligation to have it replaced with a properly
grounded 3-prong wall outlet.
Do not under any circumstances cut or remove the third (ground)
prong from the power cord.
We do not recommend using an extension cord with this appliance.
If the power cord is too short, have a qualified electrician or service
technician install an outlet near the appliance. (See WARNING—
EXTENSION CORDS section.)
For best operation, plug this appliance into its own electrical
outlet to prevent flickering of lights, blowing of fuse or tripping
of circuit breaker.
GROUNDING INSTRUCTIONS
Safety InformationOperating Instructions
Troubleshooting Tips
Consumer Support
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
8
WARNING!
Improper use of the grounding plug can result in a risk of
electric shock.
49-40388 v07 6/18/03 11:07 AM Page 8
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
Usage situations where appliance’s power cord will be disconnected
infrequently.
Because of potential safety
hazards under certain conditions,
we strongly recommend against the
use of an adapter plug. However,
if you still elect to use an adapter,
where local codes permit,
a TEMPORARY CONNECTION may
be made to a properly grounded
2-prong wall receptacle by the use of
a UL listed adapter which is available
at most local hardware stores.
The larger slot in the adapter must be aligned with the larger slot
in the wall receptacle to provide proper polarity in the connection
of the power cord.
CAUTION: Attaching the adapter ground terminal to the wall receptacle
cover screw does not ground the appliance unless the cover screw is
metal, and not insulated, and the wall receptacle is grounded through
the house wiring.
You should have the circuit checked by a qualified electrician to
make sure the receptacle is properly grounded.
When disconnecting the power cord from the adapter, always hold
the adapter with one hand. If this is not done, the adapter ground
terminal is very likely to break with repeated use. Should this
happen, DO NOT USE the appliance until a proper ground has again
been established.
Usage situations where appliance’s power cord will be disconnected
frequently.
Do not use an adapter plug in these situations because frequent
disconnection of the power cord places undue strain on the
adapter and leads to eventual failure of the adapter ground
terminal. You should have the 2-prong wall receptacle replaced
with a 3-prong (grounding) receptacle by a qualified electrician
before using the appliance.
ADAPTER PLUGS
9
Ensure proper ground
and firm connection
before use.
TEMPORARY
METHOD
Align large
prongs/slots
(Adapter plugs not
permitted in Canada)
49-40388 v07 6/18/03 11:07 AM Page 9
Safety InformationOperating Instructions
Troubleshooting Tips
Consumer Support
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
10
WARNING!
A short power supply cord is provided to reduce the risks resulting
from becoming entangled in or tripping over a longer cord.
Extension cords may be used if you are careful in using them.
If an extension cord is used—
The marked electrical rating of the extension cord should be
at least as great as the electrical rating of the appliance;
The extension cord must be a grounding-type 3-wire cord and
it must be plugged into a 3-slot outlet;
The extension cord should be arranged so that it will not
drape over the countertop or tabletop where it can be pulled
on by children or tripped over unintentionally.
If you use an extension cord, the interior light may flicker and the
blower sound may vary when the microwave oven is on. Cooking
times may be longer, too.
3
2
1
EXTENSION CORDS
49-40388 v07 6/18/03 11:07 AM Page 10
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
11
READ AND FOLLOW THIS SAFETY
INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
49-40388 v07 6/18/03 11:07 AM Page 11
12
IMPORTANT!
Fill out the Consumer Product Registration Card.
Two easy ways to register your appliance!
■Through the internet at www.geappliances.com
■Complete and mail the enclosed Product Registration Card
FOR YOUR RECORDS
Write the model and serial numbers here:
#
#
You can find them on a label inside the oven.
Staple sales slip or cancelled check here.
Proof of the original purchase date is needed to obtain service
under the warranty.
Safety InformationOperating Instructions
Troubleshooting Tips
Consumer Support
A service partnership.
49-40388 v07 6/18/03 11:07 AM Page 12
13
Consumer Support
Troubleshooting Tips
Operating InstructionsSafety Information
Inside you will find many helpful hints on how to use and maintain
your microwave oven properly. Just a little preventive care on your
part can save you a great deal of time and money over the life of
your microwave oven.
READ THIS MANUAL
You’ll find many answers to common problems in the Before You
Call for Service section. If you review our chart of Troubleshooting Tips
first, you may not need to call for service at all.
If you do need service, you can relax knowing help is only a phone
call away. A list of toll-free customer service numbers is included in
the back section.
IF YOU NEED SERVICE
49-40388 v07 6/18/03 11:07 AM Page 13
Safety InformationOperating Instructions
Troubleshooting Tips
Consumer Support
About the features of your microwave oven.
Throughout this manual, features and appearance may vary from your model.
14
1150 Watts
Features of the Oven
Door Latches.
Window with Metal Shield. Screen allows cooking to be
viewed while keeping microwaves confined in the oven.
Convenience Guide.
Touch Control Panel and Display.
Door Latch Release. Press latch release to open door.
Removable Turntable. Turntable and support must be
in place when using the oven. The turntable may be
removed for cleaning.
NOTE: Rating plate, oven vent(s) and oven light are located on
the inside walls of the microwave oven.
49-40388 v07 6/18/03 11:07 AM Page 14
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
You can microwave by time or with the convenience features.
Cooking Controls
Check the Convenience Guide before you begin.
Time Features
Press Enter
TIME COOK Amount of cooking time
Press once or twice
TIME DEFROST Amount of defrosting time
EXPRESS COOK Starts immediately!
POWER LEVEL Power level 1–10
30 SEC. Starts immediately!
Convenience Features
Press Enter Option
POPCORN Starts immediately!
3.5 oz., 3 oz. or
1.75 oz.
Press once, twice or more/less time
three times
BEVERAGE
Starts immediately! 4 oz., 8 oz. or 12 oz.
Press once, twice or
three times
REHEAT Food type 1–6 1–3 servings
SNACKS Snack type 1–6 number/weight
COOK
Food type 1–9 + weight
AUTO DEFROST Food weight
15
49-40388 v07 6/18/03 11:08 AM Page 15
Safety InformationOperating Instructions
Troubleshooting Tips
Consumer Support
About changing the power level.
16
The power level may be entered or changed
immediately after entering the feature time for
Time Cook, Time Defrost or Express Cook. The power
level may also be changed during time countdown.
Press TIME COOK or TIME DEFROST.
Enter cooking or defrosting time.
Press POWER LEVEL.
Select desired power level 1–10.
Press START.
Variable power levels add flexibility to microwave
cooking. The power levels on the microwave oven
can be compared to the surface units on a range.
Each power level gives you microwave energy a certain
percent of the time. Power level 7 is microwave energy
70% of the time. Power level 3 is energy 30% of the
time. Most cooking will be done on High (power level 10)
which gives you 100% power. Power level 10 will cook
faster but food may need more frequent stirring,
rotating or turning over. A lower setting will cook more
evenly and need less stirring or rotating of the food.
Some foods may have better flavor, texture or
appearance if one of the lower settings is used. Use
a lower power level when cooking foods that have a
tendency to boil over, such as scalloped potatoes.
Rest periods (when the microwave energy cycles off)
give time for the food to “equalize” or transfer heat to
the inside of the food. An example of this is shown with
power level 3—the defrost cycle. If microwave energy
did not cycle off, the outside of the food would cook
before the inside was defrosted.
Here are some examples of uses for various power levels:
High 10: Fish, bacon, vegetables, boiling liquids.
Med-High 7: Gentle cooking of meat and poultry;
baking casseroles and reheating.
Medium 5: Slow cooking and tenderizing for stews and
less tender cuts of meat.
Low 2 or 3: Defrosting; simmering; delicate sauces.
Warm 1: Keeping food warm; softening butter.
5
4
3
2
1
49-40388 v07 6/18/03 11:08 AM Page 16
About the time features.
Time Cook
Time Cook I
Allows you to microwave for any time up to 99 minutes
and 99 seconds.
Power level 10 (High) is automatically set, but you may
change it for more flexibility.
Press TIME COOK.
Enter cooking time.
Change power level if you don’t want full power.
(Press POWER LEVEL. Select a desired power level
1–10.)
Press START.
You may open the door during Time Cook to check
the food. Close the door and press START to resume
cooking.
Time Cook II
Lets you change power levels automatically during
cooking. Here’s how to do it:
Press TIME COOK.
Enter the first cook time.
Change the power level if you don’t want full
power. (Press POWER LEVEL. Select a desired
power level 1–10.)
Press TIME COOK again.
Enter the second cook time.
Change the power level if you don’t want full
power. (Press POWER LEVEL. Select a desired
power level 1–10.)
Press START.
At the end of Time Cook I, Time Cook II counts down.
7
6
5
4
3
2
1
4
3
2
1
17
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
49-40388 v07 6/18/03 11:08 AM Page 17
Safety InformationOperating Instructions
Troubleshooting Tips
Consumer Support
About the time features.
Cooking Guide for Time Cook
NOTE: Use power level High (10) unless otherwise noted.
18
Vegetable Amount Time Comments
Asparagus
(fresh spears) 1 lb. 5 to 8 min., In 1
1
⁄
2
-qt. casserole, place 1/4 cup
Med-High (7) water.
(frozen spears) 10-oz. package 4 to 7 min. In 1-qt. casserole.
Beans
(fresh green) 1 lb. cut in half 10 to 15 min. In 1
1
⁄
2
-qt. casserole, place 1/2 cup
water.
(frozen green) 10-oz. package 4 to 8 min. In 1-qt. casserole, place
2 tablespoons water.
(frozen lima) 10-oz. package 4 to 8 min. In 1-qt. casserole, place 1/4 cup
water.
Beets
(fresh, whole) 1 bunch 16 to 22 min. In 2-qt. casserole, place 1/2 cup
water.
Broccoli
(fresh cut) 1 bunch 5 to 9 min. In 2-qt. casserole, place 1/2 cup
(1
1
⁄
4
to 1
1
⁄
2
lbs.) water.
(fresh spears) 1 bunch 7 to 11 min. In 2-qt. casserole, place 1/4 cup
(1
1
⁄
4
to 1
1
⁄
2
lbs.) water.
(
frozen,
10-oz. package 4 to 7 min. In 1-qt. casserole.
chopped)
(frozen spears) 10-oz. package 4 to 7 min. In 1-qt. casserole, place
3 tablespoons water.
Cabbage
(fresh) 1 medium head 6 to 10 min. In 1
1
⁄
2
- or 2-qt. casserole, place
(about 2 lbs.) 1/4 cup water.
(wedges) 5 to 9 min. In 2- or 3-qt. casserole, place
1/4 cup water.
Carrots
(fresh, sliced) 1 lb. 4 to 8 min. In 1
1
⁄
2
-qt. casserole, place 1/4 cup
water.
(frozen) 10-oz. package 3 to 7 min. In 1-qt. casserole, place
2 tablespoons water.
Cauliflower
(flowerets) 1 medium head 7 to 11 min. In 2-qt. casserole, place 1/2 cup
water.
(fresh, whole) 1 medium head 7 to 15 min. In 2-qt. casserole, place 1/2 cup
water.
(frozen) 10-oz. package 3 to 7 min. In 1-qt. casserole, place
2 tablespoons water.
49-40388 v07 6/18/03 11:08 AM Page 18
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
Vegetable Amount Time Comments
Corn
(frozen kernel) 10-oz. package 2 to 6 min. In 1-qt. casserole, place
2 tablespoons water.
Corn on the cob
(fresh) 1 to 5 ears 11⁄4to 4 min. In 2-qt. glass baking dish, place
per ear corn. If corn is in husk, use no
water; if corn has been husked,
add 1/4 cup water. Rearrange
after half of time.
(frozen) 1 ear 3 to 6 min. Place in 2-qt. oblong glass
baking dish. Cover with vented
2 to 6 ears 1 to 3 min. plastic wrap. Rearrange after
per ear half of time.
Mixed
vegetables
(frozen) 10-oz. package 2 to 6 min. In 1-qt. casserole, place
3 tablespoons water.
Peas
(fresh, shelled) 2 lbs. unshelled 7 to 10 min. In 1-qt. casserole, place 1/4 cup
water.
(frozen) 10-oz. package 2 to 6 min. In 1-qt. casserole, place
2 tablespoons water.
Potatoes
(fresh, cubed, 4 potatoes 9 to 12 min. Peel and cut into 1-inch cubes.
white) (6 to 8 oz. each) Place in 2-qt.casserole with 1/2
cup water. Stir after half of time.
(fresh, whole, 1 (6 to 8 oz.) 2 to 4 min. Pierce with cooking fork. Place
sweet or white) in center of the oven. Let stand
5 minutes.
Spinach
(fresh) 10 to 16 oz. 3 to 6 min. In 2-qt. casserole, place washed
spinach.
(frozen, chopped
10-oz. package 3 to 6 min. In 1-qt. casserole, place
and leaf) 3 tablespoons water.
Squash
(fresh, summer
1 lb. sliced 3 to 5 min. In 11⁄2-qt. casserole, place 1/4
and yellow) cup water.
(winter, acorn, 1 or 2 squash 5 to 9 min. Cut in half and remove fibrous
or butternut)
(about 1 lb. each)
membranes. In 2-qt. glass
baking dish, place squash cut-
side-down. Turn cut-side-up
after 4 minutes.
19
49-40388 v07 6/18/03 11:08 AM Page 19
Safety InformationOperating Instructions
Troubleshooting Tips
Consumer Support
About the time features.
Time Defrost
Allows you to defrost for a selected length of time.
See the Defrosting Guide for suggested times.
Press TIME DEFROST.
Enter defrosting time.
Press START.
Power level is automatically set at 3, but can be changed.
You can defrost small items quickly by raising the power
level after entering the time. Power level 7 cuts the total
defrosting time in about half; power level 10 cuts the
total time to approximately 1/3. However, food will
need more frequent attention than usual.
A dull thumping noise may be heard during defrosting.
This is normal when oven is not operating at High power.
Defrosting Tips
■Foods frozen in paper or plastic can be defrosted in
the package. Closed packages should be slit, pierced
or vented AFTER food has partially defrosted. Plastic
storage containers should be partially uncovered.
■Family-size, prepackaged frozen dinners can be
defrosted and microwaved. If the food is in a foil
container, transfer it to a microwave-safe dish.
■Foods that spoil easily should not be allowed to
sit out for more than one hour after defrosting.
Room temperature promotes the growth of
harmful bacteria.
■For more even defrosting of larger foods, such as
roasts, use Auto Defrost. Be sure large meats are
completely defrosted before cooking.
■When defrosted, food should be cool but softened
in all areas. If still slightly icy, return to the microwave
very briefly, or let it stand a few minutes.
3
2
1
20
49-40388 v07 6/18/03 11:08 AM Page 20
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
Food Time Comments
Breads, Cakes
Bread, buns or rolls (1 piece) 1/4 min.
Sweet rolls (approx. 12 oz.) 2 to 4 min. Rearrange after half the time.
Fish and Seafood
Fillets, frozen (1 lb.) 6 to 9 min.
Shellfish, small pieces
(1 lb.)
3 to 7 min. Place block in casserole. Turn over and
break up after half the time.
Fruit
Plastic pouch—1 or 2 1 to 5 min.
(10-oz. package)
Meat
Bacon (1 lb.) 2 to 5 min. Place unopened package in oven.
Let stand 5 minutes after defrosting.
Franks (1 lb.) 2 to 5 min. Place unopened package in oven.
Microwave just until franks can be
separated. Let stand 5 minutes, if
necessary, to complete defrosting.
Ground meat (1 lb.) 4 to 6 min. Turn meat over after first half of time.
Roast: beef, lamb, veal, pork
9 to 13 min.
Use power level 1.
per lb.
Steaks, chops and cutlets 4 to 8 min. Place unwrapped meat in cooking
per lb. dish. Turn over after first half of time
and shield warm areas with foil.
After second half of time, separate
pieces with table knife. Let stand to
complete defrosting.
Poultry
Chicken, broiler-fryer
14 to 20 min.
Place wrapped chicken in dish. Unwrap
cut up (21⁄2to 3 lbs.)
and turn over after first half of time.
After second half of time, separate pieces
and place in cooking dish. Microwave
2– 4 minutes more, if necessary. Let stand
a few minutes to finish defrosting.
Chicken, whole
20 to 25 min.
Place wrapped chicken in dish. After half
(21⁄2to 3 lbs.) the time, unwrap and turn chicken over.
Shield warm areas with foil. To complete
defrosting, run cold water in the cavity
until giblets can be removed.
Cornish hen 7 to 13 min. Place unwrapped hen in the oven
per lb. breast-side-up. Turn over after first half
of time. Run cool water in the cavity until
giblets can be removed.
Turkey breast (4 to 6 lbs.) 3 to 8 min. Place unwrapped breast in microwave-safe
per lb. dish breast-side-down. After half of time,
turn breast-side-up and shield warm areas
with foil. Defrost for second half of time.
Let stand 1–2 hours in refrigerator to
complete defrosting.
Defrosting Guide
21
49-40388 v07 6/18/03 11:08 AM Page 21
Safety InformationOperating Instructions
Troubleshooting Tips
Consumer Support
22
About the time features.
Express Cook
This is a quick way to set cooking time for 1–6 minutes.
Press one of the Express Cook pads (from 1 to 6)
for 1 to 6 minutes of cooking at power level 10.
For example, press the 2pad for 2 minutes of
cooking time.
The power level can be changed as time is counting
down. Press POWER LEVEL and enter 1–10.
Add 30 Seconds
You can use this feature two ways:
■It will add 30 seconds to the time counting down
each time the pad is pressed.
■It can be used as a quick way to set 30 seconds of
cooking time.
49-40388 v07 6/18/03 11:08 AM Page 22
About the convenience features.
23
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
Popcorn
To use the Popcorn feature:
Follow package instructions, using Time Cook
if the package is less than 1.75 ounces or larger
than 3.5 ounces. Place the package of popcorn
in the center of the microwave.
Press POPCORN once for a 3.5 ounce package of
popcorn, twice for a 3.0 ounce package, or three
times for a 1.75 ounce package. The oven starts
immediately.
How to Adjust the Popcorn Program to Provide a Shorter
or Longer Cook Time
If you find that the brand of popcorn you use
underpops or overcooks consistently, you can add or
subtract 20 seconds to the automatic popping time.
To add time:
After pressing POPCORN, press 9immediately after the
oven starts for an extra 20 seconds.
To subtract time:
After pressing POPCORN, press 1immediately after the
oven starts for 20 seconds less cooking time.
2
1
(less time) (more time)
Use only with prepackaged
microwave popcorn weighing
1.75 to 3.5 ounces.
Beverage
To use the Beverage feature:
Press BEVERAGE once for a 4 oz. beverage, twice for
an 8 oz. beverage or three times for a 12 oz. beverage.
Drinks heated with the Beverage feature may be very hot.
Remove the container with care.
49-40388 v07 6/18/03 11:08 AM Page 23
Safety InformationOperating Instructions
Troubleshooting Tips
Consumer Support
About the convenience features.
Snacks
The Snacks feature automatically sets the microwaving
times and power levels to warm a variety of snack foods.
Press SNACKS.
Select snack type 1–6 (see Snacks Guide below).
Enter the number of items or the food weight
in ounces.
Press START.
HINT: You can press and hold the SNACKS pad during
cooking to display the remaining microwaving time.
4
3
2
1
24
1 Pasta Cover with lid or vented plastic wrap.
2 Meats, casseroles, pizza Cover with lid or vented plastic wrap.
3 Fruits and vegetables Cover with lid or vented plastic wrap.
4 Beverages, 8–10 oz. Use wide mouth mug.
5 Sauces and gravies Cover with lid or vented plastic wrap.
6 Plate of leftovers (2 to 3 foods, 4 oz. each) Cover with vented plastic wrap.
Food Type Comments
Reheat Guide
1 Bread, rolls, muffins 1 to 4
2 Sandwiches 1 to 2
3 Pizza (leftover slices) 1 to 4
4 Dessert toppings 1 to 4
5 Soup 8 to 40 oz.
6 Cheese dip 4 to 16 oz.
Food Type Quantity or Weight
Snacks Guide
Reheat
The Reheat feature reheats 1 to 3 servings of many
previously cooked foods.
Press REHEAT.
Select food type 1–6 for one serving (see Reheat
Guide below).
Press 2or 3to reheat 2 or 3 servings.
Press START.
NOTE: The serving size may be changed or added after
pressing START. Press number pad 2or 3.
4
3
2
1
49-40388 v07 6/18/03 11:08 AM Page 24
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
Cook
The Cook feature automatically sets the cooking times
and power levels for a variety of foods.
Press COOK.
Select food type 1–9 (see the Cook Guide below).
Enter weight in ounces.
Press START.
HINT: Press and hold the COOK pad during cooking to
display the remaining cook time.
4
3
2
1
1 Canned Vegetables 4 to 20 oz. Use microwave-safe casserole or bowl.
Cover with lid or vented plastic wrap.
2 Frozen Vegetables 4 to 16 oz. Use microwave-safe casserole or
bowl. Follow package instructions
for adding water. Cover with lid or
vented plastic wrap.
3 Fresh Vegetables 4 to 16 oz. Use microwave-safe casserole or bowl.
Add 2 tablespoons water for each
serving. Cover with lid or vented
plastic wrap.
4 Potatoes 8 to 40 oz. Pierce skin with fork. Place potatoes
on the turntable.
5 Fish 4 to 16 oz. Use oblong, square or round dish.
Cover with vented plastic wrap.
6 Chicken Pieces 4 to 40 oz. Use oblong, square or round dish.
Cover with vented plastic wrap or
wax paper.
7 Ground Meat 8 to 48 oz. Use round casserole dish. Crumble
(beef, pork, turkey)
meat into dish. Cover with lid or
vented plastic wrap.
8 Bacon 2 to 10 oz. Layer strips on a plate, 4 to a layer.
Cover each layer with a paper towel.
9 Pizza 4 to 16 oz. Follow package instructions to
(frozen, microwaveable) prepare pizza for microwaving.
Food Type Weight Comments
25
Cook Guide
49-40388 v07 6/18/03 11:08 AM Page 25
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
About the convenience features.
26
Auto Defrost
Use Auto Defrost for meat, poultry and fish. Use Time
Defrost for most other frozen foods.
Auto Defrost automatically sets the defrosting times and
power levels to give even defrosting results for meats,
poultry and fish.
Press AUTO DEFROST.
Using the Conversion Guide below, enter food
weight. For example, press pads 1and 2for
1.2 pounds (1 pound, 3 ounces).
Press START.
There is a handy guide located on the inside front of the oven.
■Remove meat from package and place on microwave-
safe dish.
■Twice during defrost, the oven signals “TURn.”
At each “TURn” signal, turn the food over.
Remove defrosted meat or shield warm areas
with small pieces of foil.
■After defrosting, most meats need to stand 5 minutes
to complete defrosting. Large roasts should stand for
about 30 minutes.
Conversion Guide
If the weight of food is stated in pounds and ounces, the ounces
must be converted to tenths (.1) of a pound.
3
2
1
Guide
Weight of Food in Ounces Enter Food Weight
(tenths of a pound)
1–2 .1
3.2
4–5 .3
6–7 .4
8.5
9–10 .6
11 .7
12–13 .8
14–15 .9
49-40388 v07 6/18/03 11:08 AM Page 26
About the other features.
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
Clock
Press to enter the time of day or to check the time of
day while microwaving.
Press CLOCK.
Enter time of day.
Press START or CLOCK.
3
2
1
Delay Start
Delay Start allows you to set the microwave to delay
cooking up to 12 hours.
Press DELAY START.
Enter the time you want the oven to start. (Be sure
the microwave clock shows the correct time of day.)
Select your desired cooking program.
Press START.
The Delay Start time will be displayed. The oven will
automatically start at the delayed time.
The time of day may be displayed by pressing CLOCK.
4
3
2
1
27
Cooking Complete Reminder
To remind you that you have food in the oven, the oven
will beep once a minute until you either open the oven
door or press CLEAR/OFF.
49-40388 v07 6/18/03 11:08 AM Page 27
Safety InformationOperating Instructions
Troubleshooting Tips
Consumer Support
About the other features.
28
Reminder
The Reminder feature can be used like an alarm clock,
without starting the oven. The Reminder time can be
set up to 12 hours later.
Press DELAY START.
Enter the time you want the oven to remind you.
(Be sure the microwave clock shows the correct
time of day.)
Press START. The Reminder time may be displayed
by pressing DELAY START.
NOTE: REM will remain on the display to show that the
Reminder is set until the Reminder time is reached and
the door is opened or CLEAR/OFF is pressed.
3
2
1
Child Lock-Out
You may lock the control panel to prevent the microwave
from being accidentally started or used by children.
To lock or unlock the controls, press and hold CLEAR/OFF
for about three seconds. When the control panel is
locked, an Lwill be displayed.
Sound
Press SOUND to turn the oven beeper on or off.
49-40388 v07 6/18/03 11:08 AM Page 28
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
Kitchen Timer
This pad performs three functions:
■It operates as a minute timer.
■It can be set to delay cooking.
■It can be used as a hold setting after defrosting.
The Kitchen Timer operates without microwave energy.
How to Use as a Minute Timer
Press KITCHEN TIMER.
Enter the amount of time you want to count down.
Press START. When the time is up, the timer will
signal.
How to Use to Delay the Start of Cooking
You can set the microwave to delay cooking up to
99 minutes and 99 seconds.
Press TIME COOK and enter the amount of
cooking time.
Press KITCHEN TIMER and enter the amount of
time to delay the start of cooking.
Press START. The timer will begin counting down
to zero and cooking will then begin.
How to Use to Set a Holding Time
You can set a holding time between Defrost and
Time Cook, from one second to 99 minutes.
Press TIME DEFROST.
Enter defrosting time.
Press KITCHEN TIMER.
Enter the amount of time you want the oven
to hold.
Press TIME COOK.
Enter cooking time.
Press START.
7
6
5
4
3
2
1
3
2
1
3
2
1
29
49-40388 v07 6/18/03 11:08 AM Page 29
Safety InformationOperating Instructions
Troubleshooting Tips
Consumer Support
Microwave terms.
Arcing Arcing is the microwave term for sparks in the oven. Arcing is
caused by:
■metal or foil touching the side of the oven.
■foil that is not molded to food (upturned edges act
like antennas).
■metal such as twist-ties, poultry pins, gold-rimmed dishes.
■recycled paper towels containing small metal pieces.
Covering Covers hold in moisture, allow for more even heating and reduce
cooking time. Venting plastic wrap or covering with wax paper
allows excess steam to escape.
Shielding In a regular oven, you shield chicken breasts or baked foods to
prevent over-browning. When microwaving, you use small strips
of foil to shield thin parts, such as the tips of wings and legs on
poultry, which would cook before larger parts.
Standing Time When you cook with regular ovens, foods such as roasts or
cakes are allowed to stand to finish cooking or to set. Standing
time is especially important in microwave cooking. Note that a
microwaved cake is not placed on a cooling rack.
Venting After covering a dish with plastic wrap, you vent the plastic wrap by
turning back one corner so excess steam can escape.
Term Definition
30
49-40388 v07 6/18/03 11:08 AM Page 30
Care and cleaning of the microwave oven.
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
31
Helpful Hints
An occasional thorough wiping with a solution of
baking soda and water keeps the inside fresh.
Unplug the cord before cleaning any part of this oven.
How to Clean the Inside
Walls, Floor, Inside Window, Metal and Plastic Parts on
the Door
Some spatters can be removed with a paper towel, others
may require a damp cloth. Remove greasy spatters with
a sudsy cloth, then rinse with a damp cloth. Do not use
abrasive cleaners or sharp utensils on oven walls.
To clean the surface of the door and the surface of the oven that
come together upon closing, use only mild, nonabrasive soaps
or detergents using a sponge or soft cloth. Rinse with a damp
cloth and dry.
Never use a commercial oven cleaner on any part of
your microwave.
Removable Turntable and Turntable Support
To prevent breakage, do not place the turntable into
water just after cooking. Wash it carefully in warm, sudsy
water or in the dishwasher. The turntable and support
can be broken if dropped. Remember, do not operate
the oven without the turntable and support in place.
49-40388 v07 6/18/03 11:08 AM Page 31
Safety InformationOperating Instructions
Troubleshooting Tips
Consumer Support
Care and cleaning of the microwave oven.
32
How to Clean the Outside
Do not use cleaners containing ammonia or alcohol on
the microwave oven. Ammonia or alcohol can damage
the appearance of the microwave.
Case
Clean the outside of the microwave with a sudsy cloth.
Rinse and then dry. Wipe the window clean with a
damp cloth.
Control Panel and Door
Wipe with a damp cloth. Dry thoroughly. Do not use
cleaning sprays, large amounts of soap and water,
abrasives or sharp objects on the panel—they can
damage it. Some paper towels can also scratch the
control panel.
Door Surface
It’s important to keep the area clean where the door
seals against the microwave. Use only mild, non-abrasive
detergents applied with a clean sponge or soft cloth.
Rinse well.
49-40388 v07 6/18/03 11:08 AM Page 32
Before you call for service…
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
33
Troubleshooting Tips
Save time and money! Review the chart below first and you may
not need to call for service.
Problem Possible Causes What To Do
Oven will not start A fuse in your home •Replace fuse or reset
may be blown or the circuit breaker.
circuit breaker tripped.
Power surge. •Unplug the microwave
oven, then plug it back in.
Plug not fully inserted •Make sure the 3-prong
into wall outlet. plug on the oven is fully
inserted into wall outlet.
Door not securely closed. •Open the door and close
securely.
Control panel lighted, Door not securely closed. •Open the door and close
yet oven will not start securely.
START pad not pressed •Press START.
after entering cooking
selection.
Another selection entered •Press CLEAR/OFF.
already in oven and
CLEAR/OFF pad not
pressed to cancel it.
Cooking time not entered •Make sure you have
after pressing TIME
COOK. entered cooking time
after pressing TIME COOK.
CLEAR/OFF was pressed •Reset cooking program
accidentally. and press START.
Food weight not entered •Make sure you have
after pressing AUTO entered food weight
DEFROST.
after pressing AUTO
DEFROST.
Food type not entered •Make sure you have
after pressing REHEAT entered a food type.
or COOK.
49-40388 v07 6/18/03 11:08 AM Page 33
Safety InformationOperating Instructions
Troubleshooting Tips
Consumer Support
Before you call for service…
Things That Are Normal With Your Microwave Oven
■Steam or vapor escaping from around the door.
■Light reflection around door or outer case.
■Dimming oven light and change in the blower sound
at power levels other than high.
■Dull thumping sound while oven is operating.
■TV/radio interference might be noticed while using the
microwave. Similar to the interference caused by other
small appliances, it does not indicate a problem with the
microwave. Plug the microwave into a different electrical
circuit, move the radio or TV as far away from the
microwave as possible, or check the position and signal
of the TV/radio antenna.
34
49-40388 v07 6/18/03 11:08 AM Page 34
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
35
GE Microwave Oven Warranty.
All warranty service provided by our Factory Service Centers,
or an authorized Customer Care®technician. To schedule service,
on-line, 24 hours a day, contact us at www.GEAppliances.com,
or call 800.GE.CARES.
This warranty is extended to the original purchaser and any succeeding owner for products purchased
for home use within the USA.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This
warranty gives you specific legal rights, and you may also have other rights which vary from state to
state. To know what your legal rights are, consult your local or state consumer affairs office or your
state’s Attorney General.
Warrantor: General Electric Company. Louisville, KY 40225
For The Period Of: GE Will Replace:
One Year Any part of the microwave oven which fails due to
From the date of the a defect in materials or workmanship. During this
original purchase one-year limited warranty, GE will also provide, free
of charge, all labor to repair or replace the defective part.
Four Years The magnetron tube, if the magnetron tube fails due to
For the second through a defect in materials or workmanship. During this
fifth year from the date four-year limited warranty, you will be responsible for
of the original purchase any labor or in-home service costs.
For each of the above warranties: To avoid any trip charges, you must take the microwave oven to
a General Electric Customer Care®servicer and pick it up following service. In-home service is also
available, but you must pay for the service technician’s travel costs to your home.
■Service trips to your home to teach
you how to use the product.
■Improper installation, delivery or
maintenance.
■
■ Replacement of house fuses or
resetting of circuit breakers.
■ Damage to the product caused by
accident, fire, floods or acts of God.
■ Incidental or consequential damage
caused by possible defects with this
appliance.
■ Damage caused after delivery.
What GE Will Not Cover:
49-40388 v07 6/18/03 11:08 AM Page 35
■ Failure of the product or damage to the
product if it is abused,misused (for example,
cavity arcing from wire rack or metal/foil),
or used for other than the intended purpose
or used commercially.
Printed in China
Consumer Support.
GE Appliances Website www.GEAppliances.com
Have a question or need assistance with your appliance? Try the GE Appliances Website
24 hours a day, any day of the year! For greater convenience and faster service, you can
now download Owner’s Manuals, order parts, catalogs, or even schedule service on-line.
You can also “Ask Our Team of Experts
™
” your questions, and so much more…
Schedule Service www.GEAppliances.com
Expert GE repair service is only one step away from your door. Get on-line and
schedule your service at your convenience 24 hours any day of the year! Or call
800.GE.CARES (800.432.2737) during normal business hours.
Real Life Design Studio www.GEAppliances.com
GE supports the Universal Design concept—products, services and environments that
can be used by people of all ages, sizes and capabilities. We recognize the need to
design for a wide range of physical and mental abilities and impairments. For details
of GE’s Universal Design applications, including kitchen design ideas for people with
disabilities, check out our Website today. For the hearing impaired, please call
800.TDD.GEAC (800.833.4322).
Extended Warranties www.GEAppliances.com
Purchase a GE extended warranty and learn about special discounts that are available
while your warranty is still in effect. You can purchase it on-line anytime, or call
800.626.2224 during normal business hours. GE Consumer Home Services will
still be there after your warranty expires.
Parts and Accessories www.GEAppliances.com
Individuals qualified to service their own appliances can have parts or accessories
sent directly to their homes (VISA, MasterCard and Discover cards are accepted).
Order on-line today, 24 hours every day or by phone at 800.626.2002 during normal
business hours.
Instructions contained in this manual cover procedures to be performed by any user.
Other servicing generally should be referred to qualified service personnel. Caution
must be exercised, since improper servicing may cause unsafe operation.
Contact Us www.GEAppliances.com
If you are not satisfied with the service you receive from GE, contact us on our Website
with all the details including your phone number, or write to:
General Manager, Customer Relations
GE Appliances, Appliance Park
Louisville, KY 40225
Register Your Appliance www.GEAppliances.com
Register your new appliance on-line—at your convenience! Timely product registration
will allow for enhanced communication and prompt service under the terms of your
warranty, should the need arise. You may also mail in the pre-printed registration card
included in the packing material.
49-40388 v07 6/18/03 11:08 AM Page 36
