Advantium® Oven
MFL38211610 49-40620 12-09 GE
PSA2200
PSA2201
Owner’s Manual
GEAppliances.com
Advantium
Cooking controls .....................................12
Getting to know the Advantium .........10
Oven features ...........................................11
Safety ........................................................ 2–9
Speedcooking
Cooking tips ..............................................14
Custom speedcook ................................17
My Recipes ......................................... 18, 19
Power level ................................................16
Repeat last .................................................17
Resume feature .......................................17
Speedcook cookware ...........................14
Speedcook-safe cookware ...................7
Things that are normal ........................13
Using the pre-set
speedcook menu ....................................15
Other Cooking Functions
Broiling and toasting ............................21
Convection baking .................................20
Warming and proofing ........................22
Microwaving
Cook by time .............................................24
Cooking tips ..............................................23
Defrost by food type .............................26
Defrost by time ........................................25
Defrosting tips ..........................................25
Micro 30 Secs ...........................................25
My Recipes .................................................25
Microwave power level(s) ...................24
Microwave-safe cookware ...................8
Precautions to avoid possible
exposure to excessive
microwave energy ....................................2
Sensor cooking ................................27, 28
Things that are normal ........................23
Using pre-set
microwave selections ...........................24
Other Features
Automatic fan ..........................................31
Automatic Night Light ..........................30
Auto Conversion......................................29
Beeper volume.........................................29
Control lockout ........................................31
Clock .............................................................29
Cook time completed ...........................28
Delay Start .................................................30
Display ON/OFF .......................................29
Help ...............................................................31
Reminder ....................................................29
Surface Light ............................................32
Timer .............................................................31
Turntable On/Off .....................................29
Vent Fan ......................................................32
Care and Cleaning
Cleaning the inside ................................32
Cleaning the outside .............................34
Cooking trays and baking sheet .....33
Removable turntable ............................33
Replacing the cavity light ...................35
Replacing the surface light ................35
Troubleshooting
Problem Solver ................................. 37, 38
Consumer Support
Consumer Support .............. Back Cover
Warranty ....................................................39
GE Profile
Write the model and serial numbers here:
Model # ___________________________
Serial # ___________________________
Find these numbers on a label inside
the oven.
2
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
(a) Do Not Attempt to operate this oven with
the door open since open-door operation
can result in harmful exposure to microwave
energy. It is important not to defeat or
tamper with the safety interlocks.
(b) Do Not Place any object between the oven
front face and the door or allow soil or
cleaner residue to accumulate on sealing
surfaces.
(c) Do Not Operate the oven if it is damaged.
It is particularly important that the oven
door close properly and that there is no
damage to the:
(1) door (bent),
(2) hinges and latches (broken or loosened),
(3) door seals and sealing surfaces.
(d) The Oven Should Not be adjusted or
repaired by anyone except properly qualified
service personnel.
Advantium Oven
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING
SAVE THESE INSTRUCTIONS
WARNING: To reduce the risk of burns, electric shock, fire, injury to persons, or exposure to excessive
microwave energy:
When using electrical appliances basic safety precautions should be followed, including the following:
nRead all instructions before using
this appliance. When using electrical
appliances, basic safety precautions should be
followed, including the following:
n Read and follow the specific precautions in the
Precautions to Avoid Possible Exposure to Excessive
Microwave Energy section above.
n This appliance must be grounded. Connect only
to a properly grounded outlet. See the Grounding
Instructions section on page 8.
n This microwave oven is UL listed for installation over
both gas (less than 60,000BTU) and electric ranges.
n This over-the-range oven is designed for use over
ranges no wider than 36.″ It may be installed over
both gas and electric cooking equipment.
n Do not operate this appliance if it has a damaged
power cord or plug, if it is not working properly, or if
it has been damaged or dropped. If the power cord
is damaged, it must be replaced by General Electric
Service or an authorized service agent using a power
cord available from General Electric.
n To reduce the risk of fire in the oven cavity:
—Donotovercookfood.Carefullyattendappliance
when paper, plastic or other combustible materials
are placed inside the oven while cooking.
—Removewiretwist-tiesandmetalhandlesfrom
paper or plastic containers before placing them in
the oven.
—Donotusetheovenforstoragepurposes.Donot
leave paper products, cooking utensils or food in the
oven when not in use.
—Donotpoppopcorninyourmicrowaveovenunless
in a special microwave popcorn accessory or unless
you use popcorn labeled for use in microwave ovens.
—Ifmaterialsinsidetheovenignite,keeptheovendoor
closed, turn the oven off and disconnect the power
cord, or shut off power at the fuse or circuit breaker
panel. If the door is opened, the fire may spread.
—DonotusetheSensorFeaturestwiceinsuccession
on the same food portion. If food is undercooked
after the first countdown, use COOK BY TIME for
additional cooking time.
—Donotusetheoventodrynewspaper.
n Be sure your appliance is properly installed
and grounded by a qualified technician in
accordance with the provided installation
instructions.
n Install or locate this appliance only
in accordance with the provided installation
instructions.
n Some products such as whole eggs and
sealedcontainers—forexample,closed
jars—areabletoexplodeandshouldnotbe
heated in this oven. Such use of the oven
could result in injury.
n Do not mount this appliance over a sink.
nThis oven is not approved or tested for
marine use.
nThis oven is UL listed for standard wall
installation above 36 inches.
n Do not operate this appliance if it has
been damaged or dropped.
n As with any appliance, close supervision
is necessary when used by children.
n Use this appliance only for its intended use
as described in this manual.
n Do not use corrosive chemicals or vapors
in this appliance.
nThis oven is specifically designed to heat,
dry or cook food, and is not intended for
laboratory or industrial use.
n This appliance must only be serviced by
qualified service personnel. Contact nearest
authorized service facility for examination,
repair or adjustment.
n Do not cover or block any openings on the
appliance.
n Do not store this appliance outdoors.
Donotusethisproductnearwater—
for example, in a wet basement, near a
swimming pool, near a sink or in similar
locations.
n See door surface cleaning instructions in the
Care and Cleaning of the Oven section
of this manual.
n If materials inside the oven ignite, keep the
oven door closed, turn the oven off and
shut off power at the fuse or circuit breaker
panel. If the door is opened, the fire may
spread.
n The wire oven rack should not be used for
speedcook or microwave cooking to prevent
arcing.
n Do not cover racks or any other part of
the oven with metal foil. This will cause
overheating of the oven.
n Oversized foods or oversized metal utensils
should not be used in oven as they may
create a fire or risk of electric shock.
n Do not use paper products when appliances
is operated in modes other than microwave.
3
IMPORTANT SAFETY INSTRUCTIONS
Advantium Oven
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING
4
nThermometer—Donotuseregularcooking
or oven thermometers when cooking by
microwave. The metal and mercury in these
thermometers could cause arcing and
possible damage to the oven. Do not use a
thermometer in food you are microwaving
unless the thermometer is designed or
recommended for use in the microwave
oven.
n Do not clean with metal scouring pads.
Pieces can burn off the pad and touch
electrical parts involving risk of electric
shock.
n Do not store any materials, other than our
recommended accessories, in this oven
when not in use.
n Do not let cord hang over edge of table or
counter.
n Keep power cord away from heated
surfaces.
n Do not immerse power cord or plug in
water.
n Do not operate the oven without
the turntable in place. The turntable must
be unrestricted so it can turn.
n During and after use, do not touch, or
let clothing or other flammable materials
contact any interior area of the oven;
allow sufficient time for cooling first.
n Potentially hot surfaces include the
oven door, floor, walls, oven rack and
turntable.
n It is important to keep the area clean where
the door seals against the microwave. Use
only mild, non-abrasive detergents applied
with a clean sponge or soft cloth. Rinse well.
n Do not store anything directly on top of
the microwave oven surface when the
microwave oven is in operation.
n Keep the oven free from grease buildup.
n Per USDA, cook meat to an INTERNAL
temperature of at least 160°F, and
poultry to an INTERNAL temperature
of at least 180°F. Cooking to these
temperatures usually protects against
foodborne illness. For more information,
see www.foodsafety.gov.
Arcing is the microwave term for sparks
in the oven. Arcing is caused by:
n Metal or foil touching the side of
the oven.
n Foil not molded to food (upturned edges
act like antennas).
n Use foil only as recommended in
this manual.
n Metal, such as twist-ties, poultry pins,
or gold-rimmed dishes, in the oven.
n Metal cookware or the wire oven
rack used during either speedcook or
microwave cooking (except for the pans
provided with the oven).
n Recycled paper towels containing small
metal pieces being used in the oven.
ARCING
Arcing can occur during both speedcooking and microwave cooking. If you see arcing,
press the CLEAR/OFF pad and correct the problem.
SAVE THESE INSTRUCTIONS
Do not store rack in
microwave. Rack is
ONLY to be used for
Convection Bake,
Warm and Proof.
IMPORTANT SAFETY INSTRUCTIONS
Advantium Oven
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING
5
SAVE THESE INSTRUCTIONS
Advantium Oven
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING
nWhen microwaving, place all foods and
containers on the clear glass tray.
nDo not pop popcorn in your oven unless in
a special microwave popcorn accessory or
unless you use popcorn labeled for use in
microwave ovens.
n Do not boil eggs in this oven. Pressure will
build up inside egg yolk and will cause it to
burst, possibly resulting in injury.
n Do not operate oven without food inside.
This may cause damage to the oven. It
increases the heat around the magnetron
and can shorten the life of the oven.
n Foods with unbroken outer “skin”
such as potatoes, hot dogs, sausages,
tomatoes, apples, chicken livers and other
giblets, and egg yolks should be pierced to
allow steam to escape during cooking.
n Don’t defrost frozen beverages in
narrow-necked bottles (especially
carbonated beverages). Even if the
container is open, pressure can build up.
This can cause the container to burst,
possibly resulting in injury.
n Foods cooked in liquids (such as
pasta) may tend to boil more rapidly
than foods containing less moisture.
Should this occur, refer to the Care
and Cleaning of the oven section for
instructions on how to clean the
inside of the oven.
n Hot foods and steam can cause
burns. Be careful when opening any
containers of hot food, including popcorn
bags, cooking pouches and boxes.
To prevent possible injury, direct steam
away from hands and face.
n Do not overcook potatoes. They could
dehydrate and catch fire, causing
damage to your oven.
n Avoid heating baby food in glass jars,
even with the lid off. Make sure all infant
food is thoroughly cooked. Stir food to
distribute the heat evenly. Be careful to
prevent scalding when warming formula.
The container may feel cooler than the
formula really is. Always test the formula
before feeding the baby.
n Do not attempt to deep fry in the oven.
n SUPERHEATED WATER
Liquids, such as water, coffee or tea, are able to
be overheated beyond the boiling point without
appearing to be boiling. Visible bubbling or
boiling when the container is removed from
the microwave oven is not always present.
THIS COULD RESULT IN VERY HOT LIQUIDS
SUDDENLY BOILING OVER WHEN THE
CONTAINER IS DISTURBED OR A SPOON OR
OTHER UTENSIL IS INSERTED INTO THE LIQUID.
To reduce the risk of injury to persons:
—Donotoverheattheliquid.
—Stirtheliquidbothbeforeandhalfway
through heating it.
—Donotusestraight-sidedcontainers
with narrow necks.
—Afterheating,allowthecontainer
to stand in the microwave oven for
a short time before removing the
container.
—Useextremecarewheninserting
a spoon or other utensil into the
container.
FOODS
6
WARNING!
n Do not use the wire oven rack for
microwave.
n Place food or microwavable container
directly on the clear glass tray to cook
your food.
n Use of a metal tray during microwave
cooking will result in inferior cooking
performance.
n If you are not
sure if a dish
is microwave-
safe, use this
test: Place both
the dish you are
testing and a
glass measuring
cup filled with 1
cup of water in
the oven. Set the measuring cup either
in or next to the dish. Microwave 30-45
seconds at high. If the dish heats, it
should not be used for microwaving.
If the dish remains cool and only the
water in the cup heats, then the dish
is microwave-safe.
CAUTION: Burn Risk
n Cookware may become hot because
of heat transferred from the heated food.
Oven mitts may be needed to handle the
cookware.
n Use foil only as directed in this manual.
When using foil in the oven, keep the foil
at least 1” away from the sides of the
oven.
n If you use a meat thermometer while
cooking, make sure it is safe for use
in microwave ovens.
n Some foam trays (like those that meat
is packaged on) have a thin strip of
metal embedded in the bottom. When
microwaved, the metal can burn the floor
of the oven or ignite a paper towel.
n Do not use recycled paper products.
Recycled paper towels, napkins and
waxed paper can contain metal flecks
which may cause arcing or ignite.
Paper products containing nylon or nylon
filaments should be avoided,
as they may also ignite.
n Paper towels, waxed paper and plastic
wrap can be used to cover dishes in
order to retain moisture and prevent
spattering. Be sure to vent plastic wrap
so steam can escape.
n Not all plastic wrap is suitable for use
in microwave ovens. Check the package
for proper use.
n “Boilable” cooking pouches and tightly
closed plastic bags should be slit, pierced
or vented as directed by package
instructions. If they are not, plastic
could burst during or immediately after
cooking, possibly resulting in injury. Also,
plastic storage containers should be at
least partially uncovered because they
form a tight seal. When cooking with
containers tightly covered with plastic
wrap, remove covering carefully and
direct steam away from hands and face.
nPlasticcookware—Plasticcookware
designed for microwave cooking is very
useful, but should be used carefully. Even
microwave-safe plastic may not be as
tolerant of overcooking conditions
as glass or ceramic materials. Plastic
may soften or char if subjected to
short periods of overcooking. In longer
exposures to overcooking, the food
and cookware could ignite.
Follow these guidelines:
1. Use microwave-safe plastics only,
and use them in strict compliance
with the cookware manufacturer’s
recommendations.
2. Do not microwave empty containers.
3. Do not permit children to use plastic
cookware without adult supervision.
Microwave-
safe
cookware
The turntable must
always be in place when
using the oven.
The clear glass tray
should always be in place
when microwaving.
Make sure to use suitable cookware during microwave cooking. Most glass casseroles,
cooking dishes, measuring cups, custard cups, pottery or china dinnerware which does not
have metallic trim or glaze with a metallic sheen can be used. Some cookware is labeled
“suitable for microwaving.”
How to test for a
microwave-safe dish.
SAVE THESE INSTRUCTIONS
Advantium Oven
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING
7
SAVE THESE INSTRUCTIONS
CAUTION: Burn Risk
n The oven and door will get very hot when
convection baking, broiling, warming or
toasting.
n Cookware will become hot. Oven mitts
will be needed to handle the cookware.
WARNING: Fire Risk
n Do not cover dishes or use plastic
containers, plastic cooking/roasting
bags, plastic wrap, wax paper or paper
when broiling or toasting.
n Use the metal tray in the same way
you would use a shallow baking pan
or baking tray.
n Use the wire oven rack when convection
baking or warming.
n Place food directly on the metal trays
when cooking unless the recipe requires
a dish.
n Any oven-safe dish can be used in
your oven. Place them directly
on the trays.
n Use of the clear glass tray when
convection baking, broiling, warming
or toasting will result in inferior cooking
performance.
Oven-safe
cookware
for
Convection
Baking,
Broiling,
Warming,
Proofing &
Toasting
The turntable must
always be in place when
using the oven.
Put food or oven-safe
cookware directly on the
metal tray to convection
bake, warm or toast.
Put food directly on the metal tray or in the
appropriate dish and place on wire oven
rack when baking or warming.
Put food directly on the
metal grill tray as required
to broil.
CAUTION: Burn Risk
n The oven and door will get very hot
when speedcooking.
nCookware will become hot. Oven mitts
will be needed to handle the cookware.
WARNING: Fire Risk
nDo not use coverings, containers
or cooking/roasting bags made
of foil, plastic, wax or paper when
speedcooking.
n Do not cover the turntable, metal trays or
any part of the oven with metal foil. This
will cause arcing in the oven.
n Use the metal tray in the same way
you would use a shallow baking pan or
baking tray.
n Do not use the wire oven rack for
speedcook.
n Place food directly on the metal trays
when cooking unless prompted by the
oven to do otherwise.
n Any non-metal oven-safe dish can be
used in your oven. Place them directly
on the trays.
n Use of the clear glass tray when
speedcooking will result in inferior
cooking performance and possible
cracking of the glass tray.
n Use only the metal trays specified for use
with this oven. Other metal trays are not
designed for use with this oven and will
result in inferior cooking performance.
Oven-safe
cookware for
Speedcooking
The turntable must
always be in place
when using the oven.
Put food directly on
the metal grill tray to
speedcook.
Put food directly on the
metal tray to speedcook,
convection bake, warm or
toast.
Advantium Oven
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING
Advantium Oven
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING
SAVE THESE INSTRUCTIONS
This appliance
must be grounded.
In the event of an
electrical short circuit,
grounding reduces
the risk of electric
shock by providing
an escape wire for
the electric current.
This appliance is equipped with a power cord
having a grounding wire with a grounding plug.
The plug must be plugged into an outlet that is
properly installed and grounded.
Consult a qualified electrician or service
technician if the grounding instructions are not
completely understood, or if doubt exists as to
whether the appliance is properly grounded.
If the outlet is a standard 3-prong wall outlet,
it is your personal responsibility and obligation
to have it replaced with a properly grounded
30 ampere, 4-prong wall outlet.
Do not under any circumstances cut or remove
the ground prong from the power cord.
Do not use an adapter plug with this appliance.
Do not use an extension cord with this
appliance. If the power cord is too short, have
a qualified electrician or service technician
install an outlet near the appliance.
For best operation, plug this appliance into its
own electrical circuit to prevent flickering of
lights, blowing of fuse or tripping of circuit
breaker.
The fan will operate automatically under
certain conditions (see Vent Fan section). Take
care to prevent the starting and spreading of
accidental cooking fires while the vent fan is in
use.
n Clean the underside of the Advantium often.
Do not allow grease to build up on the
Advantium or the fan filters.
n In the event of a grease fire on the surface
units below the Advantium, smother a
flaming pan on the surface unit by covering
the pan completely with a lid, a cookie sheet
or a flat tray.
n Use care when cleaning the vent fan filters.
Corrosive cleaning agents, such as lye-
based oven cleaners, may damage the
filters.
n When preparing flaming foods under the
Advantium, turn the fan on.
n Never leave surface units beneath your
Advantium unattended at high heat
settings. Boilovers cause smoking and
greasy spillovers that may ignite and spread
if the Advantium vent fan is operating. To
minimize automatic fan operation, use
adequate sized cookware and use high heat
on surface units only when necessary.
Ensure proper ground exists
before use.
WARNING!
Improper use of the grounding plug can result in a risk of electric shock.
Grounding
Instructions
The Vent Fan
8
Advantium Oven
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
WARNING
Most pacemakers are shielded from interference from electronic products, including microwaves.
However, patients with pacemakers may wish to consult their physicians if they have concerns.
PACEMAKERS
Filler Panel Kits
nJX52WH—White
n JX52BL—Black
When replacing a 36” range hood, filler
panel kits fill in the additional width to
provide a custom built-in appearance.
For installation between cabinets only;
not for end-of-cabinet installation.
Each kit contains two 3” wide filler
panels.
Filter Kits
nJX81D—Recirculating Charcoal
Filter Kit
Filter kits are used when the oven
cannot be vented to
the outside.
See back cover to order by phone or
at ge.com.
Available at extra cost from your GE supplier.
Optional kits
9
Getting to Know the Advantium
Advantium Oven
The Advantium oven uses
breakthrough Speedcook technology
to harness the power of light. The
Advantium oven cooks the outside
of foods much like conventional
radiant heat, while also penetrating
the surface so the inside cooks
simultaneously.
While halogen light is the primary
source of power, a convection system
and ceramic heater assist in the
cooking, with a “microwave boost”
added in some cooking algorithms.
Food cooks evenly and fast, retaining
its natural moisture.
Getting to know
the Advantium
10
The Advantium oven is capable of
speedcooking, convection baking,
broiling, toasting, warming, proofing
and microwaving. The Speedcook
feature is the biggest benefit of the
Advantium oven.
No preheating is required to
speedcook. Place the food in the
oven and start cooking immediately.
Time is saved because there is no
preheat and because speedcook
cooks faster.
Oven Features
Advantium Oven
Oven
features
Throughout this manual, features and appearance may vary from your model.
Turntable
The turntable must always be
in place, on the oven floor, for all
cooking. Be sure the turntable is
seated securely over the spindle
in the center of the oven.
Metal Tray or Metal Grill Tray
Put food directly on the metal tray
or metal grill tray and place on the
turntable when using the speedcook,
broil, and toast.
Wire Oven Rack
Put food directly on a metal tray or
in an oven-safe dish on the wire oven
rack only when convection baking or
warming.
Clear Glass Tray
Place on turntable when using microwave
features. Place food or microwave-safe
cookware directly on tray.
Upper Halogen Lamps
Two 1200W halogen lamps cook food
from above in speedcook, broil and toast.
Window
Allows cooking to be viewed while
keeping microwaves confined in
the oven.
Door Handle
Pull to open the door.
Door Latches
The door must be securely latched for
the oven to operate.
Lower Ceramic Heater
One 500W ceramic heater cooks food
from the bottom in speedcook, broil
and toast.
Control Panel
The pads used to operate the oven
are located on the control panel.
Convection System
One 1550W heating element cooks
food with a convection fan circulating
the hot air throughout the cavity in
speedcook, broil, convection bake,
toast and warm.
11
12
Controls
Advantium Oven
Cooking
controls
With your Advantium oven, you can cook with high-intensity halogen lights, ceramic heaters, convection heating
element, and/or conventional microwave energy.
SELECTOR DIAL
Turn to select. Press to enter.
Turn to select food, power level, or
temperature selections. Also use the dial to
increase (turn clockwise) or decrease (turn
counterclockwise) time. Simply press the
button to enter the selection.
BACK
Press this pad to step back one or more
levels in the programming process.
HELP
Press this pad to find out more about your
oven’s features.
DISPLAY
Shows feature selections and information
about the oven when in use.
START/PAUSE
Press this pad to start or pause any cooking
function.
CLEAR/OFF
Press this pad to cancel ALL oven programs
except clock, auto night light, timer, vent fan,
and surface light.
SPEEDCOOK
Press this pad to access the pre-set
speedcook menu or to set your own
speedcook program.
CONV BAKE
Press this pad to use convection bake.
MICROWAVE
Press this pad to access the microwave
menu or to set your own microwave
program.
SETTINGS
Press this pad to set the clock and access
Turntable On/Off, Auto Conversion, Auto
Nightlight, Beeper Volume, Display On/Off,
Reminder, and Temperature Units.
COOKING OPTIONS
Press this pad to access Repeat Last, Broil,
Proof, Toast, Warm and Delay Start.
MICRO 30 SEC
Starts the microwave for 30 seconds of
cooking time. An additional 30 seconds is
added to the remaining cooking time each
time the pad is pressed.
TIMER ON/OFF
Press this pad to set a minute and seconds
timer.
SURFACE LIGHT
Press this pad to turn the cooktop light on
and off.
VENT FAN
Press this pad to turn the vent fan on and
off.
13
Speedcooking
Advantium Oven
Using
speedcook
features
CAUTION: Burn Risk
When using speedcook programs, remember that the oven, door and dishes
will be very hot!
Prior to the first use of your oven, the clock must be set. See the Clock section.
Before you begin, make sure the turntable is in place. Use the metal tray or metal grill tray
and your own glass or ceramic cookware, if needed.
The turntable must always be in
place when using the oven. Put food directly on the metal tray or metal grill tray to speedcook.
n If the door is opened during cooking, the
oven will stop and PAUSE will appear in the
display. Close the door and press the START/
PAUSE pad to resume cooking.
n At any time during cooking you can change
time or power levels by selecting EDIT.
n Speedcooking meats in the oven may
produce smoke.
n To cook for additional time after a cooking
cycle has been completed, use the Resume
feature as instructed on the display.
Things that
are normal
Cooking Times
n When speedcooking pre-set menu foods,
you may see OPTIMIZING COOK TIME in the
display several seconds after you press
START/PAUSE. The oven automatically
senses the electrical voltage level in your
home and adjusts the cooking time up or
down for proper cooking.
Cooling Fans
nThe fans will be on during cooking. At the
end of cooking, the fans may continue
to run for a short time to cool internal
components. The fans will automatically
shut off when the internal parts of the oven
have cooled. The screen will display “Oven
is Cooling”.
n The oven vent will emit warm air while
the oven is on.
nThe exhaust fan may come on
automatically if the oven becomes hot. See
Automatic fan section.
Lights
nWhen the oven is on, light may be visible
around the door or outer case.
n The halogen lights will dim and cycle
on and off during a speedcook cycle,
sometimes even at full power levels.
This is normal. The oven senses the
heat level and adjusts automatically.
Oven Heat
n No preheating time is required during
speedcook cycles. The oven begins cooking
immediately.
n The door and inside of the oven will be very
hot. Use caution when opening the door
and removing food. Be cautious of steam
or vapor that may escape from around the
door.
n Do not use cookware or coverings made
of paper, plastic, or foil when speedcooking.
n When cooking for an extended period
of time, the oven may automatically
reduce the power levels to maintain
the appropriate level of oven heat.
Sounds
n Clicks and a fan blowing are normal
sounds during cooking. The electronic
control is turning components on and off.
Interference
n TV/radio interference might be noticed
while using the microwave, similar to
the interference caused by other small
appliances. It does not indicate a problem
with the microwave. Move the radio or TV as
far away from the microwave as possible, or
check the position of the TV/radio antenna.
Advantium Oven
Speedcooking
14
Cooking
tips for best
results
Arrange food on the metal trays as shown to
ensure consistent and even browning. Foods can touch but should not overlap.
Circular pattern
(Example: biscuits, cookies)
Spoke pattern
(Example: crescent rolls, breadsticks)
Single layer
(Example: appetizers)
Side by side pattern
(Example: meats and poultry)
Fresh meat, chicken, fish or seafood that has been frozen should be thawed before cooking.
(The microwave defrost feature can be used.) For other frozen prepackaged foods, follow
package directions.
Speedcook
cookware
CAUTION: Burn Risk
n Cookware will become hot. Oven mitts will
be needed to handle the cookware.
n Follow cookware suggestions on the oven
display or in the cookbook.
n Place food directly on the metal tray or
metal grill tray when cooking, unless
prompted by the oven to do otherwise.
n Use the metal tray in the same way you
would use a shallow baking pan or baking
tray.
n In addition to the cookware provided, you
can use non-metal casserole dishes, pie
plates and other heat-safe cookware.
Place them directly on the metal tray.
n Be sure to select a size that will rotate
easily.
n Place the metal tray or metal grill tray
on the turntable. Place glass or ceramic
cookware on the tray.
n Do not use cookware or coverings made
of paper, plastic, or foil when cooking
during a speedcook cycle.
Speedcooking
Advantium Oven
15
Pre-set
speedcook
menu selections
The Advantium is already pre-set to
cook over 175 popular foods.
1. Press the SPEEDCOOK pad.
If no selection is made within
15 seconds, the display will revert
back to the time of day.
2. Turn the selector dial to select
the type of food category you
want. Press the dial to enter.
3. Turn the selector dial to select the
specific food (menu selection).
Press the dial to enter.
4. Turn the selector dial to select
amount, size and/or doneness (if
required, the oven will prompt you).
Press the dial after each selection.
5. Once the display shows:
EDIT, SAVE or START press the
START/PAUSE pad or the selector
dial to start cooking.
Turn the food over when the oven
signals TURN FOOD OVER (for certain
foods).
When the oven signals CHECK for
DONENESS, check to see if your food is
done to your liking (for certain foods).
To review settings during cooking,
press the selector dial.
If you enter an undesired selection at
any time, simply press the BACK pad
and re-enter the desired selections.
Speedcooking meats in the oven may
produce smoke.
Using the
pre-set
speedcook
menu
Food Category Menu Selection
Appetizers Bagel Bites
Cheese Sticks
Egg Rolls (Frozen)
Jalapeño Poppers
Meat Balls (Frozen)
Nachos
Nuts, Roasted
Onion Rings
Pizza Rolls
Soft Pretzels (frozen)
Taquitos (frozen)
Breads Biscuits
Bread Sticks
Cheese Bread
Crescent Rolls
Dinner Rolls
Garlic Bread
Texas Toast
Breakfast Belgian Waffles
Breakfast Pizza
French Toast
Hashbrown Patties
Pancakes (frozen)
Rolls (refrigerated)
Sausage Biscuit
Sausage Links
Sausage Patties
Strudel (frozen)
Turnovers
Waffles (frozen)
Food Category Menu Selection
Chicken Bone-In
Boneless
Fillet (frozen)
Finger (frozen)
Fried (frozen)
Nugget (frozen)
Patty (frozen)
Tender (frozen)
Wings (frozen)
Whole
Desserts Brownie Mix
Cookies
Pie (fresh fruit)
Pie Crust
Rolls (refrigerated)
Turnovers
Entree Egg Rolls (frozen)
Meatloaf (9x5)
Taquitos (frozen)
Meats Filet Mignon
Hamburger
Lamb Chops
Pork Chops
Ribeye Steak
Sirloin Steak
Strip Steak
T-Bone Steak
Tenderloin
Pizza Deli/Fresh
Frozen Pizza
Use Precooked Crust
Potatoes Baked Potato
Hashbrown Patties
Frozen Fries
Frozen Nugget
Sweet Potato/Yam
Food Category Menu Selection
Sandwich Corn Dog (frozen)
Crescent Roll Hot Dog
Grilled Sandwich
Pocket Sandwich
Seafood Cod Fillets
Fish Sticks (frozen)
Frozen Breaded
Orange Roughy Fillet
Salmon
Shellfish
Swordfish Steak (1”)
Talapia
Tuna Steaks
Whitefish/Cod
Side Dish Casserole
Refried Beans (16 oz)
Roasted Asparagus
Roasted Bell Pepper
Roasted Chilies (3-6)
Roasted Corn (1-4)
Roasted Garlic
Roasted Mixed Vegetables
Scalloped Potatoes
Per USDA Guidelines, cook meat to an INTERNAL temperature of at least 160°F,
and poultry to an INTERNAL temperature of at least 180°F. Cooking to these
temperatures usually protects against foodborne illness. For more information,
see www.foodsafety.gov.
Advantium Oven
Speedcooking
16
Speedcook
power level
The Advantium uses power from high
intensity halogen lamps, a ceramic
heater, a convection system and
microwaves to cook food from the top,
bottom and interior simultaneously to
seal in moisture and flavor.
When using the pre-set menu foods,
the power levels are already selected
for you. However, power levels can
be adjusted when using pre-set menu
foods and MY RECIPE.
Each power level gives you halogen
lamp or ceramic heater power and
microwave energy for a certain
percentage of the time or provides
heating from the convection system.
For example:
U–07 Upper halogen lamp on
70% of the time.
L–07 Lower ceramic heater on
70% of the time.
M–05 Microwave on 50% of the
time.
C–06 Convection element heats
oven to 350ºF.
NOTE: Be careful when adjusting
power levels so that you do not
overcook or undercook food.
1. Press the SPEEDCOOK pad and
select your food (follow instructions
from Using the pre-set speedcook
menu).
2. When display shows EDIT, SAVE or
START, turn the dial to select EDIT.
If you do not want to change one
of the settings, just press the dial to
move to the next selection.
3. Press the dial if you do not want to
adjust cooking time.
4. Turn the dial clockwise to increase
or counterclockwise to decrease
the upper power level. Press the
dial to enter.
5. Turn the dial to change the lower
power level. Press the dial to enter.
6. Turn the dial to change the
microwave power level. Press the
dial to enter.
7. Turn the dial to change the
convection power level. Press the
dial to enter.
8.
Press the START/PAUSE
pad
or the
selector dial to start cooking.
U = Select a higher setting for thin
foods requiring a golden brown
top (example: fish fillets, toast,
boneless chicken breasts). Select
a lower setting for thicker foods
and foods with high sugar or fat
content (example: muffins, roasts,
casseroles) or that require a longer
cook time.
L = Select a higher setting for thick or
dense foods that may not cook
quickly in the center (example:
steaks, casseroles). Select a lower
setting for thin foods (example:
cookies).
M = Select a higher setting to shorten
cooking time for dense or heavy
foods (example: casseroles, whole
chicken). Select a lower setting for
delicate foods (example: breads)
or foods requiring longer cook
times for tender results (example:
stew, pot roast).
C = Select a lower setting for more
delicate foods that cook at lower
temperatures. Select a higher
setting (6 or above) for more
robust foods or foods that cook at
temperatures above 350ºF.
Follow these general guidelines when selecting the best U=, L=, M= and C=
settings for your favorite recipes:
17
Speedcooking
Advantium Oven
My Recipe -
Custom
speedcooking
The Advantium gives you the flexibility
to cook your favorite dishes.
If you want to cook a food item that is
not among the pre-set selections, use
My Recipe to custom speedcook.
1. Press the SPEEDCOOK pad and
select MY RECIPE. Press the dial to
enter. Select NEW RECIPE.
If no entries are made within 15
seconds, the display will revert
back to the time of day.
2. Turn the selector dial to select
the cooking time. Press the dial
to enter.
The display will prompt you to
select the power level(s).
3. Turn the dial to select the upper
power level. Turn the dial clockwise
to increase or counterclockwise to
decrease the upper power level.
Press the dial to enter.
4. Turn the dial to select the
lower power level. Press the
dial to enter.
5. Turn the dial to select the
microwave power level. Press the
dial to enter.
6. Turn the dial to select the
convection power level. Press the
dial to enter.
7. Press the START/PAUSE
pad or press the selector
dial to start cooking.
For power level and cooking time
suggestions, use your cooking guide,
cookbook and the pre-set speedcook
menu selections.
Repeat last
1. Press COOKING OPTIONS and select
REPEAT LAST.
2. The last pre-set food will be
displayed.
3. Press the START/PAUSE pad or the
selector dial to start cooking.
Use this time saving feature for
cooking repetitive items like cookies or
appetizers.
NOTE: The last program used is stored
for two hours.
Resume
feature
1. If your food needs to cook a bit
longer, you can restart the oven
by pressing the START/PAUSE pad
or selector dial.
2. RESUME COOKING will be
displayed and the oven will
restart immediately at 10%
of the original time.
The program stays in memory for
5 minutes. After that you will
need to begin the program again.
See Using the pre-set speedcook
menu section.
Speedcooking
Advantium Oven
18
MyRecipe—
to enter
and save
Add and save up to 30 of your own
Speedcook or microwave recipes, or
pre-set Speedcook menu recipes as
a favorite recipe. Once it’s done, you
can quickly recall your favorite so
that your food cooks just the way you
want it every time!
1. Press the SPEEDCOOK or
MICROWAVE pad.
2. Turn the dial to select MY RECIPE.
Press the dial to enter.
3. Turn the dial until NEW RECIPE
appears. Press the dial to enter.
4. ENTER COOK TIME appears. Turn
the dial to select the cooking time.
Press the dial to enter.
The display will prompt you to
select the power level(s).
5. Turn the dial clockwise to increase
or counterclockwise to decrease
the power level(s). Press the dial to
enter.
For power level and cooking time
suggestions, use your cooking guide
or cookbook.
6. Select SAVE from the summary
screen.
7. SPELL THE FOOD NAME
appears. Turn the dial to
the first letter of your food
description and press the dial to
enter. Continue this process to spell
the rest of the food name. Press
the START/PAUSE pad to save the
recipe and its name.
To find and use stored recipes:
1. Press the SPEEDCOOK or
MICROWAVE pad.
2. Turn the dial to select MY RECIPE.
3. The recipe names you entered will
appear.
4. Turn dial until the recipe you want
is displayed and press the dial to
enter.
5. Press the START/PAUSE pad or
press the selector dial to start
cooking.
MyRecipe—
to find
and use
19
Speedcooking
Advantium Oven
MyRecipe—
to adjust
or change
To adjust or change stored recipes:
1. Press the SPEEDCOOK or
MICROWAVE pad.
2. Turn the dial to select MY RECIPE.
3. Turn the dial to the recipe you
want to change. Press the dial
to enter. Current settings appear.
4. Select EDIT.
5. Turn the dial to adjust the cooking
time and press the dial to enter.
6. Turn the dial to change the power
level(s) and press the dial to enter
each power level.
7. Turn the dial to change the recipe
name. Press the dial to enter
each letter change.
8. Press the START/PAUSE pad to
save the revised recipe.
For power level and cooking time
suggestions, use your cooking guide
or cookbook.
To delete stored recipes:
1. Press the SPEEDCOOK or
MICROWAVE pad.
2. Turn the dial to select MY RECIPE.
3. Select the recipe you would like to
delete.
4. Turn the dial to select DELETE.
MyRecipe—
to delete
Convection baking
Advantium Oven
20
1. Press CONV BAKE pad.
2. Turn the dial to set the temperature
and press the dial to enter.
3. Press the dial to enter and confirm
the selection.
To start immediately without setting
a cook time, select START or press the
START/PAUSE pad:
To set a cook time:
1. Turn the dial and select COOK TIME.
2. Turn the dial to set the cook time
and press the dial to enter.
3. To start the cook time immediately,
place the food in the oven and select
START COOK TIME. Then press the
dial or the START/PAUSE pad to start.
The cook time will immediately start
to count down.
To start cook time after preheat, select
START PREHEAT. The oven will signal
once the oven reaches the cooking
temperature. Place the food in the oven
and press the START/PAUSE pad. The
cook time will begin to count down.
If the oven door is opened during
cooking, “Pause” or “Oven is Hot” will
appear in the display. Close the door and
press START/PAUSE pad.
Cook times are shown in hours and
minutes and can be set to a maximum
of 2 hours 59 minutes. Time can be
changed during cooking by turning the
dial.
How to
Convection
Bake
nMetal pans are recommended
for all types of baked products,
but especially where browning is
important.
nDark or dull finish metal pans are
best for breads and pies because
they absorb heat and produce
crisper crust.
n Shiny aluminum pans are better
for cakes, cookies or muffins
because they reflect heat and help
produce a light tender crust.
n Glass or glass-ceramic casserole
or baking dishes are best suited
for egg and cheese recipes due to
the cleanability of glass.
n When baking on one level, use the
lower level. The top clips are to
only be used in two level baking.
Cooking Tips
for Convection
Baking
Convection
Baking
Convection baking allows you to cook foods
the same way as a conventional oven, using an
element to heat the air inside the oven. Any oven
temperature from 250°F to 450°F may be set.
A fan gently circulates heated air throughout the
oven, over and around the food. Because the
heated air is kept constantly moving, some foods
cook slightly faster than in regular oven cooking.
Before you begin, make sure the metal rack is
in place. Both racks may be used for two level
cooking.
CAUTION: Burn Risk
When baking, remember that the oven, door and
dishes will be very hot!
Per USDA Guidelines, cook meat to an INTERNAL
temperature of at least 160°F, and poultry to an
INTERNAL temperature of at least 180°F. Cooking to
these temperatures usually protects against foodborne
illness. For more information, see www.foodsafety.gov.
Put food directly on the metal tray or in the
appropriate dish and place on wire oven rack
when baking or warming.
Broil and toast use the upper lamps, lower heater and
convection system to broil or toast food similar to a
conventional oven.
Before you begin, make sure the turntable is in place.
Use the metal tray when toasting and the metal tray
or metal grill tray when broiling.
CAUTION: Burn Risk
When broiling or toasting, remember that the oven
cavity, the oven door and dishes will be very hot!
Broiling and Toasting
Advantium Oven
21
1. Press the COOKING OPTIONS pad.
2. Turn the dial to BROIL and press to
enter.
3. Place the food in the oven and select
START or press the START/PAUSE pad
to start.
If the oven door is opened during cooking,
“Pause” or “Oven is Hot” will appear in
the display. Close the door and press the
START/PAUSE pad.
How to
Broil
Broiling
and
Toasting
The turntable must
always be in place when
using the oven.
Put food directly on the metal
tray or the metal grill tray.
nBroiling times may be shorter in
the Advantium oven because of
the use of halogen lamps. Make
sure to monitor food closely to get
the desired results.
nFor best results when broiling,
place food directly on the metal
grill tray.
nBroiling meats in the oven may
produce smoke.
nIf preheating the oven to broil
meat, preheat with the metal grill
tray in the oven and place food on
the hot metal tray for best searing
of meat.
nFor best performance, preheat the
oven for 5 minutes when broiling
meat. Chicken performs best with
no preheating.
nFoods should be turned halfway
through broiling time.
nRemove thinner pieces as needed
to prevent overcooking and drying.
Cooking
Tips for
Broiling
nFor best results when toasting, use
the metal tray.
nNo turning is necessary for most
foods.
nWhen toasting nuts, stir halfway
through the cooking time.
nToast thicker pieces a longer time,
thinner pieces a shorter time.
Cooking
Tips for
Toasting
How to
Toast
1. Press the COOKING OPTIONS pad.
2. Turn the dial to TOAST and press to
enter.
3. Turn the dial to set the toast time,
place the food in the oven and select
START or press the START/PAUSE pad
to start.
If the oven door is opened during cooking,
“Pause” or “Oven is Hot” will appear in
the display. Close the door and press the
START/PAUSE pad.
22
Warming and Proofing
Advantium Oven
Tips for Crisp Foods:
n Leave food uncovered.
n Do not use plastic containers
or plastic wrap.
n Preheating is not necessary
except for crisping stale items.
(See To Crisp Stale Items.)
Food Type Moisture Setting
Casseroles MOIST
Chili/Soup MOIST
Pancakes, waffles MOIST
Pizza CRISP
Potatoes, baked CRISP
Chips/Crackers CRISP
Temperature and Moisture Selection Chart
Warming
The WARM feature will keep hot,
cooked foods at serving temperature.
Always start with hot food. Use
cookware and utensils that can
withstand temperatures up to 230°F.
1. Press the COOKING OPTIONS pad.
2. Turn the dial to select WARM. Press
the dial to enter.
3. Turn the dial to select the level of
moisture you want. See the chart
and tips below. Press the dial to
enter.
4. Select START or press the START/
PAUSE pad to start. The oven
starts warming immediately and
shows the amount of warming
time to complete.
If the oven door is opened during
warming, “Pause” or “Oven is Hot” will
appear in the display. Close the door
and press the START/PAUSE pad.
To Crisp Stale Items:
nSelect the CRISP setting. Preheat
the oven for 10 minutes.
NOTE: Only preheat when crisping
stale items.
nPlace food or dishes directly on the
metal tray.
nCheck crispness after 45 minutes.
Add time as needed.
The proofing feature automatically
provides an appropriate temperature
for the proofing process, and therefore
does not have a temperature
adjustment.
1.
Press the COOKING OPTIONS pad.
2. Turn the dial to select PROOF and
press to enter.
3. Select START or press the START/
PAUSE pad to start. The oven
starts proofing immediately and
shows the amount of proofing
time to complete.
nCheck bread products early to
avoid over-proofing.
nTo avoid lowering the oven
temperature and lengthening
proofing time, do not open the
oven door unnecessarily.
NOTES:
nDo not use the proofing mode
for warming food or keeping
food hot. The proofing oven
temperature is not hot enough to
hold foods at safe temperatures.
Use the WARM feature to keep
food warm.
nProofing will not operate if the oven
is too hot. Allow the oven to cool
before proofing.
Proofing
Put bread dough in a bowl/bread pan
and place on the metal tray to proof.
The turntable must always be
in place when using the oven.
Put food or oven-safe cookware directly
on the metal tray to warm.
The turntable must always be
in place when using the oven.
Tips for Moist Foods:
n Cover food with lid or aluminum
foil.
n Do not use plastic containers
or plastic wrap.
n Preheating is not necessary.
Microwaving
Advantium Oven
Using the
microwave
features
Make sure the turntable is in place. Use the clear glass tray.
Place food or microwavable container directly on the clear glass tray to cook your
food.
n Cook
–By Food Type
–By Time
–By Time 1 & 2
nDefrost
-1.0 lb Quick
-By Time
-By Food Type
-By Weight
-Melt
-Soften
nBeverage
-Water (8 oz)
-Coffee (8 oz)
-Tea (8 oz)
-Milk (8 oz)
-Hot Cocoa (8 oz)
nPopcorn
(2.9 or 3.5 oz)
nMelt
-Butter
-Caramel
-Cheese
-Chocolate Chips
-Marshmallow
nSimmer
nSoft
-Butter
-Cream Cheese
-Frosting (16 oz)
-Ice Cream
nReheat
–Beverage
–Casserole
–Chicken
–Pasta
–Pizza
–Plate of Food
–Rice
–Soup
–Steaks/Chops
–Vegetables
MICROWAVE PRE-SET SELECTIONS
The turntable must always
be in place when using the oven. The clear glass tray should always be
in place when microwaving.
Cookware
n Make sure that cookware is suitable for
microwaving.
Things that
are normal
Interference
n TV/radio interference might be
noticed while using the microwave,
similar to the interference caused by
other small appliances. It does not indicate
a problem with the microwave. Move
the radio or TV as far away from the
microwave as possible, or check the
position of the TV/radio antenna.
Oven Heat
n Cookware may become hot because of
heat transferred from the heated food.
Oven mitts may be needed to handle
the cookware.
n Steam or vapor may escape from around
the door.
n When cooking bacon, layer strips on a
plate. Cover each layer with a paper towel.
n When cooking vegetables, use a
microwave-safe casserole or bowl. Cover
with a microwave-safe lid or vented plastic
wrap.
n For frozen vegetables, follow the package
instructions for adding water.
n For fresh vegetables, add 2 tablespoons of
water for each serving.
Cooking
tips
23
Cook By Time
Use COOK BY TIME to microwave food
that is not in the pre-set microwave
selections.
1. Press the MICROWAVE pad.
2. Turn the dial to select COOK BY
TIME and press the dial to enter.
3. Turn the dial to set the cook time
and press the dial to enter.
4. Turn the dial to set the power level
and press the dial to enter.
5. Press the dial or the START/ PAUSE
pad to start cooking.
You may open the door during COOK
BY TIME to check the food. Close the
door and press START/PAUSE to
resume cooking.
Microwave
power
level(s)
The microwave power level is
automatically set on all microwave
features but you can change it for
COOK BY TIME, COOK BY TIME 1&2,
MICRO 30 SEC, and DEFROST BY TIME.
1. First, follow directions for COOK BY
TIME, COOK BY TIME 1 & 2, MICRO
30, or DEFROST BY TIME.
2. Select START or press the START/
PAUSE pad to start.
3. Press EDIT to change the cooking
time and then the microwave
power level Press the dial to enter
cooking time and power level
changes.
Here are some examples of uses for
various power levels:
High 10: Fish, bacon, vegetables,
boiling liquids.
Med-High 7: Gentle cooking of meat
and poultry; baking casseroles and
reheating.
Medium 5: Slow cooking and
tenderizing for stews and less
tender cuts of meat.
Low 2 or 3: Defrosting; simmering;
delicate sauces.
Warm 1: Keeping food warm;
softening butter.
Microwaving
Advantium Oven
24
How to
use pre-set
microwave
selections
1. Press the MICROWAVE pad.
If no selection is made within 15
seconds, the display will revert back to
the time of day.
2. Turn the dial to select COOK,
DEFROST, BEVERAGE, POPCORN,
MELT, REHEAT, SIMMER and
SOFTEN.
3. Turn the dial to find the food you
want to cook, defrost or reheat.
Press the dial to enter.
4. Turn the selector dial to select the
type, amount, weight and/or size
as prompted by the oven. Press the
dial after each selection.
5. Press the dial or the START/PAUSE
pad to start cooking.
To review settings during cooking,
press the selector dial.
If the door is opened during cooking,
the oven will stop and PAUSE will
appear in the display. Close the door
and press START/ PAUSE to resume
cooking.
If you enter an undesired selection at
any time, simply press the BACK pad
and re-enter the desired selections.
Cook By Time
1 & 2
Use COOK BY TIME 1 & 2 to microwave
food that requires two different times
and power levels.
1. Press the MICROWAVE pad.
2. Turn the dial to select COOK and
press the dial to enter.
3. Turn the dial to select COOK BY
TIME 1 & 2 and press the dial to
enter.
4. Turn the dial to set the first time
and press the dial to enter. Repeat
for the first power level, the second
time, and the second power level.
5. Press the dial or the START/PAUSE
pad to start cooking.
Microwaving
Advantium Oven
25
Press MICRO 30 SECS repeatedly for
30 second increments of microwave
cooking time. Oven starts immediately.
The power level is automatically set at
high, but you can change it for more
flexibility. See Microwave power levels
section for instructions.
Micro 30
Secs
See the MY RECIPE sections in the
Speedcook section of this book for
instructions on how to save, use,
change or delete a microwave custom
recipe.
My
Recipes
Defrosting
tips
Use DEFROST BY FOOD TYPE for meat,
poultry, fish, and bread.
Use DEFROST
BY TIME for most other frozen foods.
n Foods frozen in paper or plastic
can be defrosted in the
package
when using DEFROST BY TIME. Meats
should be taken out of the package
when using
DEFROST BY FOOD
TYPE
. Closed packages should be
slit, pierced or vented after food has
partially defrosted. Plastic storage
containers should be partially
uncovered.
n Family-size, prepackaged frozen
dinners can be defrosted and
microwaved. If the food is in a
foil container, transfer it to a
microwave-safe dish.
n Foods that spoil easily should not
be allowed to sit out for more than
one hour after defrosting. Room
temperature promotes the growth
of harmful bacteria.
n When defrosted, food should be
cool but softened in all areas.
If still slightly icy, return to the
microwave very briefly, or let
it stand a few minutes.
n When defrosting 3 or more pounds
of ground or cubed meat, remove
defrosted portions at the turn
signals.
Use DEFROST BY TIME to defrost for a
selected length of time.
1. Press the MICROWAVE pad.
2. Turn the selector dial to DEFROST.
Press the dial to enter.
3. Turn the dial to DEFROST BY TIME.
Press the dial to enter.
4. Turn the dial to select the time you
want. Press the dial to enter.
5. Press the dial or START/PAUSE pad
to start defrosting.
6. Turn the food over when the oven
signals TURN FOOD OVER.
Power level is automatically set
at 3, but can be changed. To change
the power levels, see Microwave
power levels for instructions.
You can defrost small items quickly by
raising the power level after entering
the time. Power level 7 cuts the total
defrosting time in about half; power
level 10 cuts the total time to about
1/3. When defrosting at high power
levels, food will need more frequent
attention than usual and may have
some cooking.
Defrost by
time
Microwaving
Advantium Oven
Defrost by
food type
DEFROST BY FOOD TYPE automatically
sets the defrosting times and power
levels to give even defrosting results
for meats, poultry and fish weighing
up to 6 pounds.
1. Remove meat from the package
and place it on a microwave-safe
dish. Bread should be left in the
package with any metal twist-ties
removed.
2. Press the MICROWAVE pad.
3. Turn the dial to DEFROST. Press the
dial to enter.
4. Turn the dial to DEFROST BY FOOD
TYPE. Press the dial to enter.
5. Turn the dial to select food type.
Press the dial to enter.
6. Turn the dial to the food weight,
using the Conversion Guide
at right. For example, dial 1.2 for
1.2 pounds (1 pound, 3 oz.)
Press the dial to enter.
7. Press the dial or START/PAUSE pad
to start defrosting.
8. Turn the food over when the oven
signals TURN FOOD OVER.
n Remove defrosted meat or shield
warm areas with small pieces of
foil for even defrosting.
n After defrosting, most meats need
to stand 5 minutes to complete
defrosting. Large roasts should
stand for about 30 minutes.
Conversion Guide
If the weight of food is stated in pounds
and ounces, the ounces must be
converted to tenths (.1) of a pound.
Weight of Food Enter Food Weight
in Ounces (tenths of a pound)
1–2 .1
3 .2
4–5 .3
6–7 .4
8 .5
9–10 .6
11 .7
12–13 .8
14–15 .9
26
Microwaving
Advantium Oven
27
The Advantium’s microwave mode
features sensor cooking and
reheating. The oven automatically
senses when food is done and shuts
itselfoff—eliminatingtheneedto
program cook times and power levels.
The sensor feature detects the
increasing humidity released during
cooking. The oven automatically
adjusts the cooking time to various
types and amounts of food.
WARNING:
Fire Risk
Do not use the sensor features twice in
succession on the same food portion—
it may result in severely overcooked or
burnt food. If food is undercooked after
the first countdown, use COOK BY TIME
for additional cooking time.
The proper containers and covers are
essential for best sensor cooking.
n Always use microwave-safe
containers and cover them with lids
or vented plastic wrap.
Never use tight sealing plastic
containers—theycanprevent
steam from escaping and cause
food to overcook.
n Be sure the outside of the cooking
containers and the inside of the
oven are dry before placing food
in the oven. Beads of moisture
turning into steam can mislead
the sensor.
n Popcorn and Potatoes are best
heated uncovered.
Microwave
sensor
cooking tips
Covered
Vented
Dry off dishes so they don’t
mislead the sensor.
n Ground Meat
n Popcorn
(Prepackaged microwave
popcorn, 2.9 oz. to 3.5 oz.)
n Potato
n Rice
n Soup
n Vegetables (Canned, Fresh,
Frozen)
n Chicken Reheat
n Pasta Reheat
n Plate of Food Reheat
n Soup Reheat
n Vegetable Reheat
n Simmer
MICROWAVE SENSOR PROGRAMS
To use all
sensor
programs
To use the sensor features:
1. Press the MICROWAVE pad.
2. Turn the dial to select COOK BY FOOD
(located under COOK), REHEAT, or SIMMER.
3. For COOK BY FOOD and REHEAT, select
a food and press the dial to enter. For
SIMMER, set the time to simmer after the
soup, sauce or stew has come to a boil.
4. Press the dial or press the START/ PAUSE
pad to start cooking.
Do not open the oven door until time is
counting down on the display. If you open
the door while sensor cooking, “Sensor Error
- Close door and press START” will appear.
Close the door immediately and press the
START/PAUSE pad to begin again.
WARNING:
Fire Risk
Do not use a sensor feature twice in
successiononthesamefoodportion—itmay
result in severely overcooked or burnt food. If
the food is not done enough at the end of the
sensor cook time, use COOK BY TIME in the
microwave selector to cook for more time.
nIf you have been cooking and the oven is
hot, it may indicate that it is too hot for
sensor cooking. In that case, the oven will
automatically change to time cooking and
may prompt for weights or amounts of
food.
n To shorten or lengthen the
cook time, wait until the time countdown
shows in the display. Then turn the dial to
add or subtract time.
Notes about the Reheat program:
Reheated foods may have wide variations in
temperature. Some areas may be extremely
hot.
It is best to use COOK BY TIME and
not REHEAT for these foods:
n Bread products
n Food that must be reheated uncovered
n Foods that need to be stirred
or turned
n Foods calling for a dry look or crisp
surface after reheating
How to adjust the oven’s automatic COOK
BY FOOD and REHEAT settings for a shorter
or longer cook time (not available for all food
types):
To reduce the automatic cooking times:
Right after the oven starts, turn the dial
counterclockwise until a minus (“-“) sign
or a double minus (“--“) sign appears and
press the dial to enter. A minus (“-“) sign
is a 10% reduction of cooking time and a
double minus (“--“) sign is a 20% reduction of
cooking time.
To increase the automatic cooking times:
Right after the oven starts, turn the dial
clockwise until a plus (“+“) sign or a double
plus (“++“) sign appears and press the dial to
enter. A plus (“+“) sign is a 10% increase of
cooking time and a double plus (“++“) sign is
a 20% increase of cooking time.
Microwaving and Other Advantium Features
Advantium Oven
28
Cooking
Complete
To remind you that you have food
in the oven, the oven will display the cooking
mode and COOKING COMPLETE and beep
once a minute until you either open the oven
door or press the CLEAR/OFF pad.
Other Advantium Features
Advantium Oven
29
Use this feature to adjust the volume of the
beeper. You can even turn it off. Press the SETTINGS pad, turn the dial to
select BEEPER VOLUME, press the dial to
enter. Select the beeper volume, press the
dial to enter.
Beeper
Volume
Reminder Use this feature to set an alarm beep to
sound at a specific time of day.
1. Press the SETTINGS pad, turn the dial to
select REMINDER and press the dial to enter.
2. Select SET REMINDER and press the dial to
enter.
3. Turn the dial to set the time hour and
minutes, press the dial to enter. NOTE:
Setting the hours set AM/PM.
To turn off the Reminder, press the SETTINGS
pad, turn the dial to select REMINDER and
press the dial to enter. Turn the dial to select
CLEAR REMINDER and press the dial to enter.
To check the Reminder time, press the
SETTINGS pad, turn the dial to select
REMINDER and press the dial to enter. Turn
the dial to select REVIEW REMINDER and
press the dial to enter. The display will show
the Reminder time.
Turntable
On/OFF
Use this feature to keep the turntable from
turning when using a dish is too large to
rotate in the cavity.
Press the SETTINGS pad, turn the dial to
select TURNTABLE ON/OFF and press the dial
to enter. Turn the dial to select TURNTABLE
ON or TURNTABLE OFF, press the dial to
enter.
Note:
•TheturntablewillnotturnoffinSpeedcook,
Broil, Toast, or Microwave Sensor modes.
•IfTURNTABLEOFFisselectedwhilecooking,
the turntable will be shut off until the end
of the cooking time. The turntable will turn
back on the next cooking cycle and if the
RESUME feature is used.
•IfTURNTABLEOFFisselectedbefore
starting cooking, the turntable will remain
off for any cooking that starts within
the next 5 minutes. After 5 minutes, the
turntable will automatically return to
TURNTABLE ON.
The clock must be set before you can use
your oven for the first time. When setting the
clock time for the first time go directly to step
two.
1. To change the clock time, press the
SETTINGS pad and turn the dial to CLOCK
SETTINGS. Select SET TIME.
2. Turn the dial to set hours. Press the dial to
enter. Note: Setting hours sets AM/PM.
3. Turn the dial to set minutes. Press the dial
to enter.
Clock
Auto
Conversion Auto conversion automatically reduces the
convection baking temperature. You still
input the recipe temperature and the oven
control does the rest.
To change the setting, press the SETTINGS
pad and turn the dial to AUTO CONVERSION.
Press the dial to enter. Turn the dial to
change the setting to CONVERSION ON or
CONVERSION OFF. Press the dial to enter.
Display
On/Off
Use this feature to turn your clock display on
or off. Press the SETTINGS pad, turn the dial to
select DISPLAY ON/OFF. Turn the dial to
select CLOCK DISPLAY ON or CLOCK DISPLAY
OFF. Press the dial to enter.
30
Other Advantium Features
Advantium Oven
Auto Night
Light
Use this feature to set the surface light to
come on and go off at a certain time.
1. Press the SETTINGS pad, turn the dial to
select AUTO NIGHT LIGHT and press the
dial to enter.
2. Select SET ON TIME and press the dial to
enter.
3. Turn the dial to set on time hour and
minutes, press the dial to enter. Turn the
dial to set off time hour and minutes, press
the dial to enter. Note: Setting the hours
sets AM/PM.
To permanently turn off the Auto Night Light,
press the SETTINGS pad, turn the dial to
select AUTO NIGHT LIGHT and press the dial
to enter. Turn the dial to select DEACTIVATE
and press the dial to enter.
To check the Auto Night Light on and off
times, press the SETTINGS pad, turn the dial
to select AUTO NIGHT LIGHT and press the
dial to enter. Turn the dial to select REVIEW
ON/OFF TIMES and press the dial to enter.
The display will show the on and off time for
the Auto Night light.
Note:
If the SURFACE LIGHT pad is pressed while
the Auto Night Light is on, the surface light
is taken out of Auto Night Light for that one
time. The SURFACE LIGHT pad must be
pressed to turn off the surface light. Auto
Night Light will turn on again at the next
scheduled time.
If the surface light is already on when Auto
Night Light is scheduled to turn on, the
surface light will not use the Auto Night Light
settings. The SURFACE LIGHT pad must be
pressed to turn off the surface light. Auto
Night Light will turn on again at the next
scheduled time.
Temperature
Units
To change temperature units, press the
SETTINGS pad and select TEMPERATURE
UNITS. Turn the dial to select F or C and press
the dial to enter.
Delay Start Use this feature to delay when the oven will
start cooking in CONV BAKE, COOK BY TIME,
COOK BY TIME 1&2, DEFROST BY TIME, or
DEFROST BY WEIGHT.
1. Press the COOKING OPTIONS pad.
2. Turn the dial to select DELAY START and
press the dial to enter.
3. Turn the dial to set the start time hour
and minutes, press the dial to enter.
NOTE: Setting the hours sets AM/PM.
4. Set the cooking mode.
The oven will start the programmed cooking
mode when the clock time and the delay
start time are the same.
Help
Use this feature to find out more about
your oven and its features.
1. Press the HELP pad.
2. Turn the dial to select the feature
name. Press the dial to enter.
The display will show a description
for the program you have chosen.
Use the dial to scroll up or down to
read the description.
Adding Time
Auto Conversion
Auto Night Light
Back
Beeper Volume
Beverage
Broil
Clear/Off
Clock
Control Lockout
Conv Bake
Cook
Cook by Food Type
Cook by Time
Cook by Time 1 & 2
Cooking Options
Defrost
Defrost by Food
Defrost by Time
Defrost by Weight
Delay Start
Display ON/OFF
Edit
Help
Melt
Micro 30 Secs
Microwave
My Recipes
Proof
Reheat
Reminder
Repeat Last
Resume
Sensor Cooking
Simmer
Soften
Speed Cook
Start/PAUSE
Temperature Units
Timer On/Off
Turntable ON/OFF
Toast
Warm
Features found in the HELP function.
Other Advantium Features
Advantium Oven
Use this feature anytime you need a
general purpose timer. It can even be
used while cooking in the oven.
1. Press the TIMER pad.
2. Turn the dial to select the minutes.
Press the dial to enter.
3. Turn the dial to select the seconds.
Press the dial to enter.
To cancel, press the TIMER pad.
Timer
Cooling fans automatically turn on
as required to keep the internal
oven components and control from
overheating.
The fans will automatically turn off
when the internal parts are cool. One
or more may stay on for 5 minutes or
more after the oven control is turned
off.
The vent fan may come on
automatically if the oven gets too hot,
even if the oven isn’t running. The
screen will display: “Normal Operation.
Fan is on due to high heat. Fan will
shut off automatically.”
Automatic
fans
You may lock the control panel
to prevent the oven from being
accidentally started during cleaning or
being used by children.
Press and hold CLEAR/OFF for
3 seconds to lock and unlock.
When the control panel is locked,
CONTROL IS LOCKED will be displayed
briefly anytime a pad or dial is
pressed.
Control
lock-out
31
Care and Cleaning
Advantium Oven
32
Clean the inside of the oven often for
proper heating performance.
Some spatters can be removed with
a paper towel, others may require
a warm soapy cloth. Remove greasy
spatters with a sudsy cloth, then
rinse with a damp cloth.
If the dirt and spatter do not come off
easily with a warm sudsy cloth, place
a medium sized bowl full of water in
the unit on the metal tray and press the
SPEEDCOOK pad. Select MY RECIPE and
set for 10 minutes at U=10, L=10, M=7,
C=10. This should loosen the dirt in the
oven so that it can be removed with a
warm sudsy cloth.
If you notice yellowing on the metal
inside the oven that cannot be
removed with a warm sudsy cloth, use
a stainless steel cleaner that removes
heat discoloration and/or tarnishing.
You can then clean the inside of the
oven as you normally do.
Do not use abrasive cleaners or sharp
utensils on oven walls.
Never use a commercial oven cleaner
on any part of your oven.
Do not clean the inside of the oven
with metal scouring pads. Pieces can
break off the pad inside the oven,
causing electrical shock as well as
damaging the inside surface finish of
the oven.
Be certain the oven control is turned
off and the oven is warm or cool to
the touch before cleaning any part of
this oven.
How to clean
the inside of
the oven
Use to light your cooktop.
Press the SURFACE LIGHT pad to
change from bright to night to off.
Surface
Light
The vent fan removes steam and
other vapors from surface cooking.
Press the VENT FAN pad to change
from high to medium to low to off.
The vent fan may come on
automatically if the oven gets too hot,
even if the oven isn’t running. The
screen will display: “Normal Operation.
Fan is on due to high heat. Fan will
shut off automatically.”
Vent Fan
Cooking trays
and wire
oven rack
To prevent breakage, allow the trays to
cool completely before cleaning. Wash
carefully in hot, sudsy water or in the
dishwasher.
Do not use abrasives to clean the glass
tray or wire oven rack, as they may
damage the finish.
A plastic scrubbing pad may be used
to clean the metal trays.
Metal tray
Wire oven rack
Metal grill tray
Clear glass tray
Care and Cleaning
Advantium Oven
33
The area underneath the turntable should
be cleaned frequently to avoid odors and
smoking during a cooking cycle.
The turntable can be broken if dropped.
Wash carefully in warm, sudsy water.
Dry completely and replace.
To replace the turntable, place its
center over the spindle in the center of
the oven and turn it until it seats into
place.
Do not use the oven without the
turntable in place.
Removable
turntable
Turntable
We recommend against using
cleaners with ammonia or alcohol,
as they can damage the appearance
of the oven. If you choose to use a
common household cleaner, first
apply the cleaner directly to a clean
cloth, then wipe the soiled area.
Case
Clean the outside of the microwave
with a sudsy cloth. Rinse and then dry.
Wipe the window clean with a damp
cloth.
Control Panel
Wipe with a damp cloth. Dry
thoroughly. Do not use cleaning
sprays, large amounts of soap and
water, abrasives or sharp objects on
the panel - they can damage it. Some
paper towels can also scratch the
control panel.
Stainless Steel Surfaces
(on some models)
The stainless steel panel can be
cleaned with Stainless Steel Magic or
a similar product using a clean, soft
cloth. Apply stainless cleaner carefully,
avoiding the surrounding plastic or
glass parts. Do not use appliance wax,
polish, bleach or products containing
chlorine on stainless steel.
Plastic Color Panels
(on some models)
Use a clean, soft, lightly dampened
cloth, then dry thoroughly.
Door Seal
It’s important to keep the area
clean where the door seals against
the oven. Use only mild, non-abrasive
detergents applied with a clean
sponge or soft cloth. Rinse well.
Bottom
Clean off the grease and dust on the
bottom often. Use a solution of warm
water and detergent.
How to clean
the outside of
the oven
Care and Cleaning
Advantium Oven
Do not remove the halogen lamp
glass cover or the mica sheet.
The upper halogen lamp cover
must be kept free of grease and
food spatterings in order to operate
effectively.
Clean the lamp glass cover and mica
sheet often to avoid excess smoking
and decreased cooking power.
To clean the upper lamp cover: Allow
the oven and glass cover to cool
completely. Wipe clean with a warm
soapy cloth or plastic scrubbie.
For heavy burned on soil, a cleaning
scraper may be used to clean the
halogen lamp cover. Hold the cleaning
scraper at a 30° angle. Scrape the
glass clean and wipe up excess soil.
To clean the mica sheet: Allow the
oven to cool completely. Wipe clean
with a warm soapy cloth.
For heavy or burned on soil
Halogen
lamp cover
and mica
sheet
34
Upper halogen
lamp cover Mica Sheet
Care and Cleaning
Advantium Oven
35
Surface light
1. To replace the surface light, first
disconnect the power at the main fuse
or circuit breaker panel.
2. Remove the screw from the side of
the light compartment cover and lower
the cover until it stops.
3. Be sure the bulb to be replaced is
cool before removing. Gently pull the
bulb from the receptacle.
Replace with a 120 volt, 50-watt
halogen bulb. Order WB08X10051
from your GE supplier.
4. Raise the light cover and replace
the screw. Connect electrical power to
the oven.
1. The metal filters trap grease
released by foods on the cooktop.
They also prevent flames from
foods on the cooktop from
damaging the inside of the oven.
2. For this reason, the filters must
always be in place when the hood
is used. The vent filters should
be cleaned once a month, or as
needed.
3. To remove, slide them to the rear
using the tabs. Pull down and out.
4. To clean the vent filters, soak them
and then swish around in hot water
and detergent. Don’t use ammonia
or ammonia products because
they will darken the metal. Light
brushing can be used to remove
embedded dirt.
5. Rinse, shake and let dry before
replacing.
6. To replace, slide the filters into the
frame slots on the back of each
opening. Press up and to the front
to lock into place.
Removing
and cleaning
the filters
To replace
oven cavity
lamp
1. Disconnect power at the main fuse
or circuit breaker panel.
2. Remove the top grill by removing
the two screws that hold it in place.
3. Remove charcoal filter if present.
Slide the filter toward the left and
pull toward the front to remove.
NOTE: Charcoal filter is an optional
kit, you may not have one.
4. Remove the screw holding the lamp
shield in place.
5. Pull the lamp shield out. Pull the
light bulb out and replace with the
120V-130V, 20W halogen bulb.
Order WB25X10019 from your GE
supplier.
6. Return the lamp and lamp shield to
original position and replace screw
and charcoal filter.
7. Replace the grill and 2 screws.
Reconnect power to the oven
Remove screw
36
Care and Cleaning
Advantium Oven
To install a new filter:
1. Remove plastic and other outer
wrapping from the new filter.
2. Remove the top grill by removing
the two screws that hold it in place.
3. Insert the filter into the top opening
of the oven as shown.
4. It will rest at an angle on two back
support tabs and in front by two tabs.
5. Replace the grill and two screws.
To remove the filter, repeat step 2
above, remove the filter and repeat
step 5.
If the model is not vented to the
outside, the air will be recirculated
through a disposable charcoal filter
that helps remove smoke and odors.
The charcoal filter cannot be cleaned.
It must be replaced. Order Part No.
WB2X9883 from your GE supplier.
The charcoal filter should be replaced
when it is noticeably dirty
or discolored (usually after 6 to
12 months, depending on usage).
Charcoal
filter (JX81D -
optional kit)
To install
the charcoal
filter
Troubleshooting
Advantium Oven
37
Problem Possible Causes What To Do/Explanation
LIGHTS
Lightduringa Thisisnormal. •Thisisnormal.Theovensensesthe
speedcook cycle Power level has been heat level and adjusts automatically.
dims and cycles on automatically reduced
and off, even at full because the oven is hot.
power levels.
Lightvisiblearound Thisisnormal. •Whentheovenison,lightmay
the door and outer be visible around the door and
case while outer case.
speedcooking.
FAN
Fancontinuestorun Theoveniscooling. •Thefanwillautomaticallyshutoff
after cooking stops. when the internal parts of the oven
have cooled.
Oven vent emits warm This is normal.
air while oven is on.
Ventfancomeson Thisisnormal. • Ifthecooktoporovengetshot
automatically when enough the vent fan comes on.
oven not in use. (see Automatic Fan section.)
Fancomeson Thisisnormal. • Ifthemicrowaveisusedafter
automatically when speedcook and the oven senses
using the microwave. that it is too hot, the vent fan comes
on to cool the oven.
Theovenmakes Clicksandfansblowing • Thesesoundsarenormal.
unusual sounds are normal. The relay
while cooking. board is turning the
components on and off.
Fansoundchanges Thisisnormal. • Fanmayturnonoroffduring
while cooking. cooking to maintain cooking
temperature.
COOKING
Smokecomesoutof Foodishighinfat •Smokeisnormalwhencookinghigh-
the oven when content. Aerosol spray fat foods. Use vegetable oil or olive
the door is opened. used on the pans. oil on the meat itself instead of
coating the entire pan.
Foodisnotfully Programmedtimes •Increaseordecreasetimefor
cooked or browned may not match the size doneness or adjust the upper or
at the end of a or amount of food you lower lamps for browning.
cooking program. are cooking.
Questions?
Use this
problem
solver
Questions?
Use this
problem
solver
Advantium Oven
Troubleshooting
38
Problem Possible Causes What To Do/Explanation
DISPLAY
Thedisplayisblank. Thedisplayhas •ChecktheSETTINGSmenuforclock
been turned off. display settings. Turn the display on.
“ControlPanel Thecontrolhas •PressandholdCLEAR/OFFforabout
LOCKED” appears been locked. 3 seconds to unlock the control.
in display. See Other Features Section.
Controldisplayis Clockisnotset. •Followpromptstosettheclock.
lighted yet oven Doornotsecurelyclosed. • Openthedoorandclosesecurely.
will not start.
START/PAUSEpad • Followprompts
not pressed after entering
cooking selection.
DelayStartwas • PressCLEAR/OFFandreset.
accidentally set.
OvenisinDEMOMode • Unplugtheovenfor1minute,plug
the oven back into the wall DO NOT set
the oven clock, press and hold the HELP
and START/PAUSE pads for 3 seconds.
The control should exit DEMO mode.
Set clock and continue.
CLEAR/OFFwaspressed • Resetcookingprogramandpress
accidentally. START/PAUSE.
OTHER PROBLEMS
Thedoorandinside Theoven •Thisisnormal.
oftheovenfeelshot. producesintenseheat •Useovenmittstoremovefoodwhen 
in a small space. when ready.
Flooroftheovenis Thecooktoplightis •Thisisnormal.
warm, even when located below the oven
the oven has not floor. When the light
been used. is on, the heat it produces
may make the oven floor
get warm.
Ovenwillnotstart. Afuseinyourhome •Replacefuseorresetcircuitbreaker.
may be blown or the
circuit breaker tripped.
Powersurge. •Unplugtheoven,thenplugitbackin.
Plugnotfullyinserted •Makesuretheplugontheovenis 
into wall outlet. fully inserted into wall outlet.
Glassmicrowave  •Aligntheprotrusionsonthebottomof
tray does not lock the glass microwave tray with the
into center hub. indentation in the turntable. This fit is
not tight, some movement is normal.
39
Advantium Oven Warranty
Advantium Oven
All warranty service provided by our Factory Service Centers,
or an authorized Customer Care® technician.
To schedule service, online, contact us at GEAppliances.com,
or call 800.GE.CARES (800.432.2737). Please have serial and
model numbers availa ble when calling for service.
What GE Will Not Cover:
n Service trips to your home to teach you how
to use the product.
n Improper installation, delivery or
maintenance.
n Product not accessible to provide required
service.
n Failure of the product or damage to
the product if it is abused, misused (for
example, cavity arcing from wire rack
or metal/foil), or used for other than the
intended purpose or used commercially.
n Replacement of house fuses or resetting
of circuit breakers.
n Replacement of the cooktop light bulbs.
n Damage to the product caused by
accident, fire, floods or acts of God.
n Incidental or consequential damage
caused by possible defects with this
appliance.
n Damage caused after delivery.
This warranty is extended to the original purchaser and any succeeding owner for products
purchased for home use within the USA. If the product is located in an area where service by
a GE Authorized Servicer is not available, you may be responsible for a trip charge or you may
be required to bring the product to an Authorized GE Service Location for service. In Alaska,
the warranty excludes the service calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages.
This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state. To know what your legal rights are, consult your local or state consumer
affairs office or your state’s Attorney General.
Warrantor: General Electric Company. Louisville, KY 40225
For The Period Of: GE Will Replace:
One Year Any part of the oven which fails due to a defect in materials or
From the date of the workmanship. During this limited one-year warranty, GE will also
original purchase provide, free of charge, all labor and related service costs to
replace the defective part.
Five Years The magnetron tube, if the magnetron tube fails due to a
From the date of the
defect in materials or workmanship. During this five-year limited
original purchase
warranty, you will be responsible for any labor or in-home service costs.
Staple your receipt here.
Proof of the original
purchase date is needed
to obtain service under
the warranty.
EXCLUSION OF IMPLIED WARRANTIES—Your sole and exclusive remedy is product
repair as provided in this Limited Warranty. Any implied warranties, including the
implied warranties of merchantability or fitness for a particular purpose, are limited
to one year or the shortest period allowed by law.
Printed in Korea
Consumer Support
GE Appliances Web site GEAppliances.com
Have a question or need assistance with your appliance? Try the GE Appliances Web site any day of the year!
For greater convenience and faster service, you can now download Owner’s Manuals, order parts or even
schedule service on-line.
Schedule Service GEAppliances.com
Expert GE repair service is only one step away from your door. Get on-line and schedule your service at
your convenience any day of the year! Or call 800.GE.CARES (800.432.2737) during normal business hours.
Real Life Design Studio GEAppliances.com
GEsupportstheUniversalDesignconcept—products,services,andenvironmentsthatcanbeusedby
people of all ages, sizes, and capabilities. We recognize the need to design for a wide range of physical and
mental abilities and impairments. For details of GE’s Universal Design applications, including kitchen design
ideas for people with disabilities, check out our Web site today. For the hearing impaired, please
call 800.TDD.GEAC (800.833.4322).
Extended Warranties GEAppliances.com
Purchase a GE extended warranty and learn about special discounts that are available while your warranty
is still in effect. You can purchase it on-line anytime or call 800.626.2224 during normal business hours.
GE Consumer Home Services will still be there after your warranty expires.
Parts and Accessories GEAppliances.com
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
(VISA, MasterCard, and Discover cards are accepted). Order on-line today, 24 hours every day, or by phone at
800.626.2002 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing
generally should be referred to qualified service personnel. Caution must be exercised, since improper
servicing may cause unsafe operation.
Contact Us GEAppliances.com
If you are not satisfied with the service you receive from GE, contact us on our Web site with all the details,
including your phone number, or write to: General Manager, Customer Relations
GE Appliances, Appliance Park
Louisville, KY 40225
Register Your Appliance GEAppliances.com
Registeryournewapplianceon-line—atyourconvenience!Timelyproductregistrationwillallowforenhanced
communication and prompt service under the terms of your warranty, should the need arise. You may also mail
in the preprinted registration card included in the packing material.

Navigation menu
