SIMPLE MANUAL
Wireless
Sound Bar
To view the instructions of advanced features,
visit http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from your unit.
MODELS
LAS465B SH3K
www.lg.com
ENGLISH
*MFL69596802*
Printed in China
WARNING: This product contains chemicals known to the
State of California to cause cancer and birth defects or other
reproductive harm. Wash hands after handling.
FCC Compliance Statement
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the
following measures:
yReorient or relocate the receiving antenna.
yIncrease the separation between the equipment and
the receiver.
yConnect the equipment to an outlet on a circuit
different from that to which the receiver is connected.
yConsult the dealer or an experienced radio/TV
technician for help.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received,
including interference that may cause undesired
operation of the device. Any changes or modications
in construction of this device which are not expressly
approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
FCC RF Radiation Exposure Statement : This
equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. This
transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
This equipment should be installed and operated with
minimum distance 20 cm (7.8 inches) between the
antenna and your body. Users must follow the specic
operating instructions for satisfying RF exposure
compliance.
FCC Radio Frequency Interference Requirements :
High power radars are allocated as primary users of the 5.25 to
5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can
cause interference with and/or damage this device. This device
cannot be co-located with any other transmitter.
Responsible Party :
LG Electronics USA, Inc.
1000 Sylvan Ave
Englewood Cliffs, NJ 07632
Tel: 1-800-243-0000
LG Customer Information Center
1-800-243-0000 USA, Consumer
1-888-865-3026 USA, Commercial
Register your product Online!
www.lg.com
Front Panel
Rear Panel
·································Standby /On
····························· Selects Function
·························Adjusts Volume
PORT. IN ············ Connect to a Portable device
OPTICAL IN ·········· Connect to an Optical device
Subwoofer Connection
1
Place the wireless subwoofer near the sound bar and
follow steps below.
a Connect the power cord of wireless
subwoofer to the outlet.
b Turn on the sound bar :
The sound bar and wireless subwoofer will be
automatically connected. The subwoofer's
yellow - green LED turns on.
Subwoofer Connection Manually
a Reset the Subwoofer
If the yellow - green LED on the subwoofer
blinks rapidly, skip this step and go to b
yPress and hold PAIRING button for 5 seconds.
yThe LED lights up alternately in red and
yellow - green.
yUnplug the power cord. After the LED turns off
completely, plug in the power cord again.
When the reset is completed, the subwoofer's
yellow - green LED blinks rapidly.
b Reset the sound bar
yAdjust volume to minimum until the red LED on
the sound bar lights up for a while.
yPress and hold (Mute) button on the remote
control for 3 seconds.
yThe red LED on the sound bar blinks rapidly.
yTurn the sound bar’s power off and on while the
subwoofer’s yellow - green LED blinks.
When the connection is completed, you can see the
yellow - green LED on the subwoofer.
Keep the sound bar and the subwoofer
away from the following (ex. wireless router,
microwave oven, etc.) over 1m (3.3 ft) to
prevent wireless interference.
!P
a Connect the the sound bar to the TV using
Optical cable.
b Set up [External Speaker (Optical)] on your TV
setting menu.
TV
TV Connection
2Remote control
Addtional Device Connection
a Connect to the external device as follows.
TV
(Set-top
Box, Player
etc.)
b Set the input source by pressing F on the
remote control or unit repeatedly.
Additional Information
STANDARD/VOICE/CINEMA : Selects sound effect.
DRC ON/OFF: Makes comfortable sound at Dolby Digital.
WOOFER LEVEL +/-: Adjusts the volume level of subwoofer.
AUTO POWER ON/OFF: Automatically turns on by an input
source.
Replacement of battery
Specication
Power
requirements Refer to the main label.
Power
consumption
Refer to the main label.
Networked standby : 0.5 W
(If all network ports are
activated.)
Dimensions
(W x H x D)
Approx.
950 mm x 71 mm x 47 mm
(37.4 inch x 2.8 inch x 1.9 inch)
Net Weight Approx. 2.47 kg (5.4 lb)
Amplier
(Total RMS
Output power)
300 W
Design and specications are subject to change
without notice.
How to disconnect the wireless network
connection or the wireless device
Set up the AUTO POWER ON/OFF function to off and
turn off the unit.
