LINAK A S HBGL Remote Control User Manual
LINAK A/S Remote Control
user manual
FLAT BUTTON
Press and hold to lower the base to
flat position. This will also turn off
massage motors
LOCK BUTTON
Press and hold for 3 seconds to lock
or unlock remote. Backlight will flash
3 times confirming the change.
HEAD UP/DOWN BUTTONS
Press and hold to adjust the head
section
FOOT UP/DOWN BUTTONS
Press and hold to adjust the foot section
UNDERBED LIGHT BUTTON
Press and release to toggle underbed
light
SET BUTTON
Simultaneously press and hold this
button AND “MEM1” or “MEM2” or
“SNORE” or “ZGRAV” to program a
new memory position. The massage
motors will chirp once to confirm a
new position has been set.
SNORE BUTTON
Press and hold to adjust the head
section of your partner’s side to a 15°
angle. This will go down to flat after
15 minutes
ZERO GRAVITY BUTTON
Press and hold to adjust the base to
the “Zero Gravity” position. Massage
setting can also be saved in this
position.
MEM 1 / MEM 2 BUTTONS
Press and hold to adjust the base to
the programmed position. Massage
settings can also be saved in these
positions.
WAVE BUTTON
Press and release to turn on the
massage motors in wave mode. If
already in wave mode, the massage
motors will go back to constant mode.
HEAD MASSAGE UP/DOWN BUTTONS
Press and release adjust the intensity of
the head massage motor up or down.
There are 3 levels: low, medium, and
high. Pushing the DOWN button when
in low level will turn the massage off.
Massage will automatically shut off
after 30 minutes.
FOOT MASSAGE UP/DOWN BUTTONS
Press and release adjust the intensity of
the foot massage motor up or down.
There are 3 levels: low, medium, and
high. Pushing the DOWN button when
in low level will turn the massage off.
Massage will automatically shut off
after 30 minutes.
PRESS & HOLD TO ONE TOUCH.
To change the remote from “press & hold” mode to “one touch” mode, simultaneously press the FLAT and
HEADUP buttons for 3 seconds. The massage motors will chirp once to confirm the change. Use the same
process to switch from “one touch” mode back to “press & hold” mode.
When in “one touch” mode:
- Press & release Mem 1, Mem 2, or Z-GRAVand the base will automatically adjust to the programmed
memory position (including massage settings). Press any other button to stop the base during movement.
- Press & release FLAT and the base will turn off massage motors and automatically adjust the base to the
flat position. Press any other button to stop the base during movement.
To revert back to factory settings, simultaneously press and hold the FLAT and HEADDOWN buttons for 3
seconds. The massage motors will chirp confirming the change and your base is now back to factory settings.
SCAPE + REMOTE CONTROL FUNCTIONALITY
HBGL-U001-XX
Gladiator
remote
FCC ID: XBE-HBGL
IC: 12338B-HBGL
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
Changes or modifications to this unit not expressly approved by the party responsible forcompliance could void the
user's authority to operate the equipment.
Statement for digital devices for class B:
NOTE: This equipment has been tested and found to comply with the limits for a Class B digitaldevice, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protectionagainst harmful interference in a
residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and
used in accordance with the instructions, may causeharmful interference to radio communications. However, there is no
guarantee that interference will notoccur in a particular installation. If this equipment does cause harmful interference
to radio or televisionreception, which can be determined by turning the equipment off and on, the user is encouraged to
try tocorrect the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiverisconnected.
—Consult the dealer or an experienced radio/TV technician for help.
This device complies with Industry Canada license-exempt RSS standard(s).
Operation issubject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
