User Manual

Draft: 10/25/2010

MINOHD WiFi (Jenner) USER GUIDE – ENGLISH SOURCE TEXT FOR USA

PANEL 1

MINOHD WIRELESS QUICK START GUIDE VISUALS

Set Up Wireless

1. Plug your video camera into your computer to install FlipShare

software and setup wireless sharing features. (For instructions on

installing FlipShare, see User Guide.)

2. Follow prompts in the FlipShare installation to:

a. Add your email and phone contacts

b. Link to your social networking accounts (e.g. Facebook)

c. Authenticate your Flipshare.com sharing account

d. Setup your wireless network(s)

PANEL 2

LIVE STREAMING

(Note: if you have not yet setup your wireless network in FlipShare, please do so

before attempting Live Streaming.)

Connect

• Press (sharing button image) to enable wireless sharing

• Press + and – to choose a wireless network, if one is not automatically

selected follow steps from “Network Setup”

Select

• Press < and > to select Live Streaming

• Press + and – to select a sharing recipient such as email address, social

media site, or FlipShare.com

• Press (red record button) to begin recording video and streaming live

to your video recipient

• Press (red record button) to stop recording and end live streaming

session

PANEL 3

INSTANT SHARE

(Note: if you have not yet setup your wireless network in FlipShare, please do so

before attempting Instant Share.)

Connect

• Press (sharing button image) to enable wireless instant share

• Press + and – to choose a wireless network, if one is not automatically

selected follow steps from “Network Setup”

Select

• Press < and > to select Instant Share

• Press < and > to view previous/next video to select which video you

would like to share

•

Press + and

–

to select a sharing recipient such as an email address,

Draft: 10/25/2010

social media site or Flipshare.com

• Press (play button) to begin the Instant Share upload

PANEL 4

NETWORK SETUP

Press and hold the (share button) and (red record button) at the same time to

enter network setup.

To add a new network (network name is visible): Press + or – to select the

network name from the list

• Press the <, >, +, - to select letters from the onscreen keyboard, if a

network password is required

• Press (play button) to log onto the network

To add a new network (network name does not appear):

• Press the (share button) to enter the network name

• Press the <, >, +, - to select letters from the onscreen keyboard to

enter the network name

• Press + or – to select the type of network password required

• Press the <, >, +, - to select letters from the onscreen keyboard, if a

network password is required

• Press (play button) to log onto the network

PANEL 1

MINOHD USER GUIDE

PANEL 2

Get Started

Welcome to Flip MinoHD

™

1 Press power button to turn on. Video camera settings appear automatically

when you first power on.

Note: Video camera is shipped with a partially charged battery. If battery is not

charged, simply follow the steps in the Recharge Battery section.

Set Language

• Use

+ -

to select your language.

Set Date

• Use

+ -

to adjust the current setting.

• Use

< >

to select month/day/year.

Set Time

• Use

+ -

to adjust the current setting.

• Use

< >

to select hour/minute/am/pm.

Tones

• Use

< >

to turn the tones on and off.

Draft: 10/25/2010

Recording Light

• Use

< >

to turn the recording light on and off.

To Return to Video Camera Setup Later

Starting with the video camera OFF:

1 Press power button to turn on.

2 When Flip Video logo appears, press and hold record button until Select a

Language appears.

PANEL 3

Record and Play

Touch-Sensitive Buttons

Gently touch lighted icons with your finger to activate the controls on the back

panel.

Record Videos

1 Press to start/stop recording.

2 Press and hold

+ -

to zoom in/out during recording.

Play Videos

1 Press to play/pause. Press and hold to play all videos.

2 Press and hold

+ -

to increase/decrease volume.

3 Press

< >

to view previous/next video.

Note: Press and hold

< >

during playback to rewind/fast-forward.

Deleting Videos

1 Press button. Select YES to confirm.

Note: Delete button is locked when you first power on. To unlock, press and hold

delete button.

PANEL 4

Connect to Computer

1 Slide USB latch down. USB arm flips up automatically.

2 Connect USB arm to computer’s USB port.

3 The battery pack will begin recharging and you can install FlipShare™ software

on your computer.

Recharge Battery

1 Slide USB latch down. USB arm flips up automatically.

2 Connect USB arm to computer’s USB port.

3 Recording light turns on to indicate charging.

When charged, the recording light turns off.

• The video camera uses a sealed, rechargeable battery.

• Fully recharging the battery takes about three hours.

• The video camera may remain connected to your computer after it is fully

Draft: 10/25/2010

charged, but disconnecting it will help preserve the battery pack’s lifespan and

performance.

• The optional Flip Video Power Adapter can charge the battery in about two

hours.

Note: Your computer must be powered on for your video camera to charge.

PANEL 5

Organize, Create and Share

FLIPSHARE

logo

Pre-loaded FlipShare software makes editing and sharing your videos easy. Just

plug in your video camera, open FLIPVIDEO and launch Setup FlipShare (PC) or

Start FlipShare (Mac).

FlipShare Features

• Save videos to your computer.

• Organize your videos.

• Create custom movies

• Capture snapshots

• Share your videos via email or Flip Channels, or upload directly to:

Facebook™ (logo) MySpace™ (logo) Twitter™ (logo) YouTube™ (logo)

Visit the FlipShare software HELP section for detailed instructions on all features.

PANEL 6

View On HD Television

1 Power off video camera and television.

2 Connect video camera to television with optional HDMI™ Cable from Flip Video

(available at www.theflip.com/accessories).

3 Power on video camera and television.

• Video camera screen turns off when connected to television.

4 Switch your television to the appropriate VIDEO input.

• See television manual for instructions.

5 Touch play button to start/pause playback.

HDMI Cable

Note: You can use any brand of HDMI Cable that has an HDMI Connector (for the

TV) on one end and an HDMI Mini Connector (for the video camera) on the other

end.

PANEL 7,8

Video Camera Features

1 Power Button

2 Wrist Strap Hook

3 Tripod Mount

4 Recording Light

5 USB Latch

6 USB Arm

7 HDMI Mini Port

1 Press to turn on/off.

2 Attach wrist strap (included in box).

3 Attach a tripod or a Flip

Video Tripod

accessory.

4 Red light turns on during recording or charging. Built-in wide-range microphone is also located here.

5 Slide down to release USB arm.

6 Connect to a PC or Mac USB port.

7 Connect HDMI cable accessory to your HDTV.

Draft: 10/25/2010

8 Screen

9 Recording Controls

Record Button

Play Button

Delete Button

+ -

Up/Down Buttons

< >

Left/Right Buttons

8 Recording viewfinder/playback screen.

9 Touch buttons to record and preview videos.

Press and release to start/stop recording. During Power On: Hold to return to video camera setup.

Touch to play/pause recording. Touch and hold to play all videos.

Touch to delete. Touch and hold to lock/unlock the delete button.

While Recording: Press and hold to zoom in/out. During Playback: Press and hold to increase/decrease volume.

While Paused: Press to skip to previous/next video. During Playback: Press and hold to rewind/fast-forward.

Flip Video offers a variety of accessories for your video camera. Learn more at www.theflip.com/accessories.

PANEL 9

top bubble

Included In This Box

• Flip MinoHD Video Camera

• Wrist Strap

• Soft Case

• User Guide

• Safety Instructions

• Warranty Information

PANEL 9

middle

bubble

Flip Video Support : Go to www.theflip.com/support

Panel 9

Declaration

conformity

Declaration of Conformity:

Responsible Party: Cisco Consumer Products LLC, 185 Berry Street, Suite 6500,

San Francisco, CA 94107 USA

FCC Compliance Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference,

and (2) this device must accept any interference received, including interference

that may cause undesired operation.

Radio and TV Interference

This equipment has been tested and found to comply with the limits for a Class

B digital device in accordance with the specifications in Part 15

of FCC rules. These specifications are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the manufacturer’s instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

Draft:10/25/2010

•Increasetheseparationbetweentheequipmentandthereceiver.

•Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhich

thereceiverisconnected.

•Consultthedealeroranexperiencedradio/televisiontechnicianforhelp.

CAUTION:ChangesormodificationstothisdevicenotauthorizedbyCisco

ConsumerProductsLLCmayvoidtheuser’sauthoritytooperatethisdevice.



Foroperationwithin5.15~5.25GHzfrequencyrange,itisrestrictedtoindoor

environment.



ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothe

followingtwoconditions:(1)Thisdevicemaynotcauseharmfulinterference,and

(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethat

maycauseundesiredoperation.



IMPORTANTNOTE:

RadiationExposureStatement:

TheproductcomplywiththeUS/CanadaportableRFexposurelimitsetforthforan

uncontrolledenvironmentandaresafeforintendedoperationasdescribedinthis

manual.ThefurtherRFexposurereductioncanbeachievediftheproductcanbe

keptasfaraspossiblefromtheuserbodyorsetthedevicetoloweroutputpower

ifsuchfunctionisavailable.



Thistransmittermustnotbeco‐locatedoroperatinginconjunctionwithanyother

antennaortransmitter.



CANADIANICES‐003STATEMENT:ThisClassBdigitalapparatuscomplieswith

CanadianICES‐003.‘



ICStatement

ThisdevicecomplieswithRSS‐210oftheIndustryCanadaRules.Operationis

subjecttothefollowingtwoconditions:(1)Thisdevicemaynotcauseharmful

interference,and(2)thisdevicemustacceptanyinterferencereceived,including

interferencethatmaycauseundesiredoperation.



IMPORTANTNOTE:

RadiationExposureStatement:

TheproductcomplywiththeUS/CanadaportableRFexposurelimitsetforthforan

uncontrolledenvironmentandaresafeforintendedoperationasdescribedinthis

manual.ThefurtherRFexposurereductioncanbeachievediftheproductcanbe

keptasfaraspossiblefromtheuserbodyorsetthedevicetoloweroutputpower

ifsuchfunctionisavailable.



Intheeventthattheseconditionscannotbemet(forexamplecertainlaptop

configurationsorco‐locationwithanothertransmitter),thentheCanada

authorizationisnolongerconsideredvalidandtheICIDcannotbeusedonthe

finalproduct.Inthesecircumstances,theOEMintegratorwillberesponsiblefor

re‐evaluatingtheendproduct(includingthetransmitter)andobtainingaseparate

Canadaauthorization.

CedispositifestconformeàlanormeCNR‐210d'IndustrieCanadaapplicableaux

appareilsradioexemptsdelicence.Sonfonctionnementestsujetauxdeux

conditionssuivantes:(1)ledispositifnedoitpasproduiredebrouillage

préjudiciable,et(2)cedispositifdoitacceptertoutbrouillagereçu,ycomprisun

brouillagesusceptibledeprovoquerunfonctionnementindésirable.



NOTEIMPORTANTE:(Pourl'utilisationdesappareilsportables)

Déclarationd'expositionauxradiations:

Leproduitestconformeauxlimitesd'expositionpourlesappareilsportablesRF

pourlesEtats‐UnisetleCanadaétabliespourunenvironnementnoncontrôlé.

Leproduitestsûrpourunfonctionnementtelquedécritdanscemanuel.La

réductionauxexpositionsRFpeutêtreaugmentéesil'appareilpeutêtreconservé

aussiloinquepossibleducorpsdel'utilisateurouqueledispositifestréglésurla

puissancedesortielaplusfaiblesiunetellefonctionestdisponible.



Danslecasoùcesconditionsnepeuventêtresatisfaites(parexemplepour

certainesconfigurationsd'ordinateurportableoudecertainesco‐localisationavec

unautreémetteur),l'autorisationduCanadan'estplusconsidérécommevalideet

l'IDICnepeutpasêtreutilisésurleproduitfinal.Danscescirconstances,

l'intégrateurOEMserachargéderéévaluerleproduitfinal(ycomprisl'émetteur)

etl'obtentiond'uneautorisationdistincteauCanada.



PANEL9

Trademark

Cisco,theCiscologo,FlipMinoHD,FlipShare,FlipVideo,andtheFlipVideologoare

trademarksorregisteredtrademarksofCiscoand/oritsaffiliatesintheUnited

Statesandcertainothercountries.Allothertrademarksmentionedinthis

documentorwebsitearethepropertyoftheirrespectiveowners.Formore

information,pleasevisitwww.theflip.com.

FacebookTM,MySpaceTM, TwitterTM,andYouTubeTMaretrademarksoftheir

respectiveowners.



HDMI,theHDMILogoandHigh‐DefinitionMultimediaInterfacearetrademarksor

registeredtrademarksofHDMILicensingLLC.



MacisaregisteredtrademarkofAppleInc.



LINKSYS M3260 Digital Video Recorder User Manual User Guide MINOHD WiFi Source Text 10 25 10

LINKSYS LLC Digital Video Recorder User Guide MINOHD WiFi Source Text 10 25 10

User Manual

Navigation menu

Namespaces

Views

Navigation
