LIVALL Tech BH6X Bling Helmet User Manual 15 BH60 UserMan
Shenzhen Qianhai Livall LOT Technology Co., Ltd. Bling Helmet 15 BH60 UserMan
15_BH60 UserMan
Smart Safety Helmet
I. Introduction
This smart safe-riding helmet (hereinafter referred to as “Bling
Helmet”) is made of the lightest and safest materials, which
makes it more comfortable and safer. Its fine ventilating
structure inside enables air to flow smoothly through so as to
achieve the best cooling effect. It also has Bluetooth speakers,
and warning tail light.
II. Packing list
One helmet One hag tag
One USB charging cable One warranty card
One product instruction
III. Wearing instruction
Usage:
This safety helmet adopts a fixed setting, easy to operate,
putting on or taking off the helmet only with the buckle.
Flatten the drawstrings on both sides and make them
clinging to your face, buckle up it when the helmet is tightly
put on. If the drawstrings become loose, please take off the
helmet and adjust them properly. When adjusting the
drawstrings, please use one hand to fix the buckle and then
adjust the drawstrings with proper tightness. If you want to
strengthen the rear drawstring, pull it tight from its back, use
one hand to fix the helmet and another one to fix the
drawstring under the chin and adjust the four drawstrings to
a most appropriate position.
Proper wearing
The helmet must be worn closely to your head. If you want
to lower the front to cover your forehead, you could make
the drawstring close to your chin and loose the rear
drawstring; if you want to heighten the front of the helmet,
loose the drawstring and tighten the rear drawstring.
Comfort adjustment:
In order to check the tightness of the helmet, you could put
on the helmet and buckle up it, open your mouth to feel
whether the drawstrings are closely attached to your chin,
and then move your helmet forward and backward, if the
helmet becomes loose, then the tightness of the drawstring
must be strengthened and make sure that the thickness of
the pad is proper. The helmet could not be able to move
forth and back much distance; the helmet could not be taken
off if the buckle is not opened. Note: It is necessary to
reaffirm whether the helmet is in a good condition every time
you wear.
Connecting to Bluetooth earphone:
Connect the bluetooth with your smart phone when first-use
or when change to another smart phone;When the device is
power off, long press “” till you hear the “ready to pair”
sounds, means the device starts matching; scan the device
with your phone which the Bluetooth is available. and click it
to connect when spotting the equipment of “BH60”. The
speakers on both sides will make the noise of “matching
completed” when the connection is completed;The bluetooth
will be connected automatically next time.
Answer and hang up calls:
When there’s an incoming call, the device would give out
notification voice, press “” to answer the call and long press
for 1S to reject; during calls, press “” to hang up.
Redial calls:
When the device is powered, quick press “” twice to dial the
last number.
helmet is suitable for you and could be tightly wore. Check
the adjustment again every time you wear to ensure that the
helmet could be closely put on your head.
IV. Operating Instruction
Start up:
Long press “” for 2s till you hear the “power on” sounds,
meanwhile the outline light and tail light will flash twice in orange.
Power off:
When the device is in a state of working, long press “” till
you hear the “power off” sounds, meanwhile the outline light
and tail light would flash once in orange.
Checking
Make sure that the helmet must be put on your head
correctly and firmly . Readjust the tightness of the
drawstrings to a proper position if the helmet still shakes.
For the best protection effect, please make sure that the
Back
Rear drawstring
Adjustment buckle
Buckle
Front drawstring
Brim
Button”
Button “+”
Button“-”
Warning tail light
Bluetooth speaker
Charging port
Front
V. Precautions
Temperature
The safety helmet would be damaged under/over 150 0F
(65.6 0C). Under hot weather, if the helmet is put in dark
vehicle or storage bag, its temperature would be even
higher. Heat would incur irregular misshaping to the surface
of the helmet, like bubbling or pits. If this happens, please
discard this helmet immediately and replace it with a new
one. To insure a proper use of this helmet, please carefully
read this Instruction before use so as to get to know the
features, performance, wearing, maintenance and other
aspects of the product.
Safety precautions
This helmet is designed to burden damages and injuries
from external impact. Although such injury may seem minor,
it could damage the helmet. If the helmet is damaged from
falling or other causes, please discard the helmet and
replace it with a new one. Some accidents are unavoidable
for whatever safety helmet and the damaging degree may
differ from the impacting; even at a slow speed, severe head
injuries or life threatening damages may occur. So please
make sure that you’ve completely and carefully read this
Instruction and have arranged all possible protections
before riding the bike, scooter or wearing the roller skates.
Speaker usage instructions
This product is equipped with Bluetooth speakers, and
taking calls during riding may distract the user’s attention, so
it is suggested that distracting functions like calls and voices
be used after the bike is stopped; listening to music during
riding may affect user’s attention to surrounding sounds,
which may bring potential safety hazards, so it is suggested
that the volume be lowered.
Warnings
This safety helmet is specially designed for bikes, so please
don’t use it on other mobile vehicles, like motor cars or
motor bikes. No safety helmet could completely avoid all
unpredicted impacting, but for the best protection effect, the
size of the helmet must be proper and the buckle must be
tightly buckled. Unless advised by the manufacturer, please
refrain from modify or remove any part of the helmet.
Children should refrain from using during climbing or other
activities, in case of getting trapped or entangled from
wearing this helmet.
Water warnings
This product is only resistant to short period rainfall, so to
avoid any malfunctions, please try to avoid riding during
raining.
VI. Trouble-shooting of electronic functions
During use or after impact (without misshaping or
cracking), if the following functions go wrong, please follow
the steps to fix them; If failed, please contact the after-sale
service center.
Malfunctions
1. Unable to get started up
2. When starting up, only heard the start up notification
sound but no indication of flashing outline lights
3. After start up, it automatically powers off after a short
period of use (maybe the battery is low)
4. After unplugging the charging cable, the charging light is
still on and rebooting could not fix it.
5. Start up is normal, but the speaker has no notification
sound or has just single tone or noises.
Trouble shooting steps
1. Charging for 1 to 2 hours
2. Check the tail light, main control (within the brim) and the
inner side of two speakers to see whether there’re clear
cracks, if does, please manually push it in.
3. Factory reset, hold “” till the outline light shows white,
and about 20 seconds later, the white light would
automatically fade away and the product is reset. And then
start it up, if the trouble is not fixed, please contact the after
sales center.
VII. Appendix Technical specifications:
Bluetooth:
Bluetooth distance: Max 10m
Speaker: Stereo 2*0.5W
Mic: -39dB microphone
Tail light: 8 +6 color LED
Buttons: three buttons,
start up (play, pause, power off),
volume + (next song),
volume – (previous song)
Charging port: MicroUSB
Electricity parameter: DC 5V/0.5A
Battery capacity: 380mAH (1.4WH)
Charging time: 1.5h
Battery life: >10h
Standby duration: >180 days
Product size: 285*230*150
Product weight: 279g±5%
Music player:
When the device is powered, press “” to play music (need
to open the music player APP in your phone before this
operation). Long press “-” to play the previous song and “+”
the next song.
Volume adjustment:
During music playing or taking calls, press “+” to increase
volume while “-” to decrease
Notification voice switches of Bluetooth speaker:
The default setting is English. When the product is powered,
first hold “-” and then press “+” to cycle switch languages,
from EnglishChineseFrenchSpanish; when the
language is selected, loose “-”.
Charging:
Use the USB cable to connect the USB port beneath the tail
light to the charger with USB (DC 5V) port. When it’s
connected, the two indicator lights in the middle of the tail
light would flash red (no such indicator under normal
standby state) and green when the charging is done. The
electricity of the charger is suggested to be > 1A and the
charging time about 3.5h.
Factory Reset:
Hold “” till the outline light shows white, and about 20
seconds later, the white light would automatically fade away
and the product is reset.
After-Sales Information:
Thank you for purchasing LIVALL product, please read the following
instructions for better service
1. The warranty time is 1 year after purchase. Any quality problem can
be maintained free or it can be replaced within 3 months after
purchase if re-sale is available.
2. Damages caused by the following reasons are not included in the
scope of free warranty:
Exceeding the specified warranty period;
Damages caused by unsuitable operation;
Damages caused by user removing or repairing it by themselves as
well as other man-made damages.
3. This warranty card is the important certificate for the warranty
service provided to the end user, please keep it well. The card should
be taken along with the product to the manufacturer when the
maintenance is required.
4. Our company reserves the rights to modification and explanation for
above terms and conditions.
Please visit www.livall.com for more information.
User Name: ____________________________________________
Tel.:___________________________________________________
ID No.: ________________________________________________
Home Address: _________________________________________
Seller:_________________________________________________
Purchase Date: _________________________________________
Maintenance Record:
______________________________________________________
Note: This form should be completed in real details, otherwise, it
would be invalid.
After-Sales Service Warranty Card
Smart Safety Helmet
Designed and Assembled in Shenzhen China
Model:BH60
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
