Lee Technology Korea Co., Ltd. Mini RCL Charger Transmitter Users Manual
Users Manual
MINI RCL CHARGER TRANSMITTER
Manual
LEE TECHNOLOGY KOREA CO., LTD.
email sales@leetek.org
website www.leetekorea.com
KOREA HEADQUARTER US OFFICE
3rd Fl. 499-2, Sang3-dong, 530 Highland Station Drive, Suite 2004,
Wonmi-gu, Bucheon City, Suwanee, GA 30024, U.S.A.
Kyunggi-do, Korea
Tel +82-32-324-9838 Tel +1-678-714-2161
Fax +82-32-324-9840 Fax +1-678-714-2162
Alpha Paging System User Manual
NOTICE
This manual, software and electronic circuitry are copyrighted. All rights reserved. Under the
copyright laws, this manual, software and electronic circuitry may not be copied, in whole or in
part without written prior consent of Lee Technology.
All information provided in this document is carefully prepared and offered in good faith as a
guide in the installation, use and servicing of our products. Installers must ensure that the final
installation operates satisfactorily within the relevant regulatory requirements. Lee Technology
accepts no responsibility for incorrect installation. Lee Technology reserves the right to change
products, specifications and installation data at any time without notice.
Lee Technology makes certain limited warranties with respect to defective diskettes,
documentation and electronic circuitry. Please see the associated information contained on this
page.
LIMITED WARRANTY
With respect to the physical documentation and physical electronic circuitry enclosed herein, Lee
Technology warrants the same to be free of defects in materials and workmanship for a period of
one year from the date of purchase. In the event of notification within the warranty period of
defects in material or workmanship, Lee Technology will replace the defective diskettes,
documentation and electronic circuitry. The remedy for breach of this warranty shall be limited to
replacement and shall not encompass any other damages including but not limited to loss of
profit and special incidental, consequential, or other similar claims.
Lee Technology Korea specifically disclaims all other warranties, expressed or implied, including
but not limited to implied warranties of merchantability and fitness for a particular purpose with
respect to defects in the documentation and electronic circuitry and the program license granted
herein, in particular, and without limiting operation of the program license with respect to any
particular application, use or purpose.
IMPORTANT SAFETY INFORMATION
NOTE : The manufacturer is not responsible for any radio or TV interference
caused by unauthorized modifications to this equipment. Such modifications could
void the user's authority to operate the equipment.
RF EXPOSURE STATEMENT
Your Pager Transmitter contains a radio frequency
transmitter. When the button is pushed the transmitter
sends our RF signals.
CAUTION: To comply with FCC RF exposure
compliance requirements, a separation distance of at
least 8 inches (20 cm) must be maintained between the
antenna of this trasmitter and all persons, during normal
operation.
The antenna uesd for this transmitter must not be colocated
or operating in conjunction with any other
antenna of transmitter.
Unauthorized antennas, modifications, of attachments
could damage the transceiver and may violate FCC
regulations.
Any changes or modifications (including the antenna) made to
this device that are not expressly approved by the manufacturer
may void the user’s authority to operate the equipment.
TABLE OF CONTENTS
1. SYSTEM INTRODUCTION
1) SYSTEM SUMMARY
2) SPECIFICATION
2. INSTALLATION
1) EQUIPMENT SETUP
2) PLACEMENT
3) EASY INSTALLATION INSTRUCTION
3. SYSTEM SETTING
4. OPERATION
5. HOW TO USE
1. SYSTEM INTRODUCTION
1) SYSTEM SUMMARY
RCL Paging System was designed to help restaurants manage incoming customers
efficiently and distinctively. Customers receive instant notification when their table is ready,
making them feel special and welcome. Freed from long lines, your restaurant looks more
inviting to people walking in, customers are encouraged to wait without fears of missing
their table, resulting in higher traffic, while overall restaurant traffic flows more smoothly,
leading to faster table turns. By offering perfect customer service the instant a customer
appears, you will enjoy greater competitiveness, revenues and profits.
2) SPECIFICATION
FEATURE
BENEFIT
TECHNOLOGY
° UHF Technology
° Perfect for large restaurant and multiple levels
TRANSMITTER
° Built-in Clock
° Wireless Pager Programmability
° Durable and Sturdy to withstand industry conditions
° Selectable Frequency, Pager Alert Type, and Alert Time
° Out of Range
° Field Test
° Powered by power supply
PAGER
° POCSAG Code
° All Pagers work on Single Transmitter Platform
° Smart Charging System with own Charger Base
° Advertise with Paddle insert sheet
RESTAURANT SYSTEM ID
° Unique Base ID to eliminate overlapping message
RECHARGEABLE BATTERY
° Smart Charging eliminates over-charging and extend battery
life
APPLICATION
° Restaurant, Café, Hotel, Pharmacy, Church, Super market,
Car Wash and Auto Dealer shop
3) MODEL SPEC
1)MODEL : LTA-6465
2) Frequency Range : 450Mhz ~ 470Mhz
3) Data Rate : 1200&512
4) Standard Deviation : +- 3.5Khz below
5) Modulation : GFSK
6) Channel Spacing : 12.5Khz
7) Output Power : 32dBm below
8) Code Format : POCSAG
9) Dimension : 138mm x 160mm x 30mm
10) Weight : 300g , (pager : 92g)
2. INSTALLATION
1) EQUIPMENT SETUP
(1) Transmitter
Unwrap all sending unit components. Lock the antenna into the hope in the upper right
hand corner of the transmitter. Plug the power supply with the large tip into a standard
outlet and plug it into the back of the transmitter. We recommend some type of surge
suppressor on the power supply for protection. Power surges are not covered under
system warranty.
(2) Pager
Locate the charger base in a sturdy, out of the way location. Connect the charger bases
together using included jump wires. Use the power supply with the small tip and plug it
into a standard outlet and into either open plug on the charger base. Be sure to plug the
jump wires & power supply jack in all the way.
Insert the pagers into the charger base. The flash of charging indicator next to the
number label will be lighted.
You should check a charging indicator appear on each pagers. This light indicates proper
charging is taking place.
2) Installation of transmitter
Stepu Lock the antenna to the right corner of the Mini Transmitter.
(Fit over plug and twist left to lock antenna in place)
Stepv Plug the Mini Transmitter A/C adaptor into the Mini Transmitter and then into a
standard outlet. A surge protector is recommended.
Step w Mini Transmitter will be fully charged in 4 hours.
3. SYSTEM SETTING
Using SETUP MODE
(1) Setup Mode How to Enter: ↑ Key Press and hold 3 seconds.
(2) Key Operation details
Menu Up - ↑ , Menu Down - ↓, Enter - Send, Cancel - Send Press and hold 3 seconds,
number - 0 ~ 9
NO.
SETUP
MODE
Function
Remarks
1
bASE
Available only when using the same
ADDRESS (0~200)
Base ID
2
g-Id
Ability to set the Group ID
Group ID
3
A-Id
Ability to set the All Page ID
All Page
ID
4
bPS
The transmission rate of the signal to
display.(512 / 1200)
Baud
Rate
5
FrEq
450.000Mhz~ 470.000Mhz
Frequency
6
tyPE
System Mode settings (nor / 10b / 06b)
TYPE
7
Alt
ALERT behavior can be changed (A-00 ~
A-06)
ALERT
8
Altt
ALERT TIME can be changed (t-00 ~ t-06)
ALERT
TIME
9
tESt
RANGE TEST MODE
TEST
10
V-XX
model VERSION
VERSION
4. OPERATION
l When you need to alert the pagers, just press “Pager Number” + “SEND” key.
l The corresponding pager will be alerted.
l When you return the alerted pager back to the charger base, it’ll stop alerting.
5. HOW TO USE
1) Franchise Restaurant, Hotel Restaurant
(1) Direction for Use
- For calling waiting guests
(2) Process
- If the guests are too many to provide enough seats to them, the staff located in front
of the door, hands out the pagers to the waiting guests.
- The waiting guests do shopping, drinking in the café, seating on a seat in the park
and waiting for their turns with pager.
- When their turn comes, the waiter will page corresponding pager number.
- If his/her pager is paged, the guest immediately moves to the restaurant and guided
his/hers seat.
(3) Merits
- It’ll keep the restaurant from confusing their entrance.
- The waiter don’t need to use the microphone, the mood will be more quiet and high-
quality.
- The waiting guest can utilize their waiting time usefully.
2) Café
(1) Direction for Use
- For calling waiting guests
(2) Process
- When the guest comes to the café and order, the waiter will provide the receipt and
pager to him.
- The guest will take his seat and wait for his turn.
- When the drink is ready, the waiter will call the pager number.
- The guest goes to the pick up place and receives his drink and goes back to his seat.
(3) Merits
- It’ll eliminate the discomfort for waiting in front of the pick up place.
- The waiter doesn’t need to hurry and prepare the drink in turn.
- If utilizing multiple levels, it’ll eliminate the confusion in front of the store
3) Hospital
(1) Direction for Use
- For calling waiting patient or families
(2) Process
- When outpatient goes to the post after registering, the nurse will hand out the pager
to the patient.
- When turn is coming, the nurse will page the patient and the patient will enter the
medical office.
(3) Merits
- It’s needless to wait in front of the busy medical office and even there are not enough
seats to sit on.
- It’ll speed up the entrance and reduce the waste time.
4) Pharmacy
(1) Direction for Use
- For calling waiting patient
(2) Process
- After finishing their medical treatment, the patient will go to the pharmacy to receive
their medicine.
- It may take lots of time to receive the medicine because of many waiting patients.
- At this time, the staff will hand out the pager to the patient.
- When turn is coming, the staff will page the patient and the patient will receive their
medicine.
(3) Merits
- While waiting their turn, the patients do not need to wait in the tiny waiting area.
- Instead of waiting in the pharmacy, the patient will go shopping, waiting in the café or
park and it’ll serve the patient more comfortable.
5) Church
(1) Direction for Use
- For calling guardian
(2) Process
- When they go to worship, the parent will leave their children to the playroom.
- They receive the pager and enter to the chapel.
- If something is happened to the children during the worship, the playroom manager
will page their parent.
- Corresponding parents will move to the playroom immediately, and check whether
their children are in trouble or not.
(3) Merits
- It’ll keep the chapel quiet and solemn.
- During the worship, the parents have no worries about their children and concentrate
on their worship.
- The children can play in the playroom instead of their boring worship.
6) Car Wash
(1) Direction for Use
- For calling waiting guests
(2) Process
- When the guest comes to the Car Wash Center to wash their car, sometimes they
need some time to wait their turn.
- Then, the staff in the Car Wash will hand out the pager to the waiting guest.
- After finishing Car Wash, the staff will page corresponding car owner.
- The guest who is paged will come to the Car Wash and return back his car.
(3) Merits
- It’ll reduce the time to waste in front of the Car Wash.
- The guest can do his business instead of waiting.
- It’ll keep the entrance of Car Wash not crowded.
