Leedarson Lighting RC4X1WN-A9 Remote control User Manual
LEEDARSON LIGHTING CO., LTD. Remote control Users Manual
Users Manual
Dim/CCT+
Status Indicator:
Program Button
Remote is in Standby mode
or Selected Group is OFF
(slow)
(fast)
Selected Group is ON
Finding Network Channel
(when batteries are inserted)
Commisioning a bulb
Re
m
o
t
e
C
on
t
r
ol
&
Connected Bulb
U
se
r
G
uid
e
1.Commissioning (Pairing) Light(s)
Commissioning (Pairing) Light(s): Follow instruction below to commission new smart light(s). In case you buy new smart light(s)
or the current smart light(s) are set to Factory Default.
Light(s) (Factory Default) must start On
With your Remote
Restarted by wall switch
Successfully paired
to Remote
Light(s) blinks twiceOnce commissioned to a
remote, it’s no longer visible to other remotes
In case of a time-out,the light(s) will turn
off the radio and become a standard
non-controllable light(s)
Fail
Press and hold one of the group
button for 3s that you want the
light(s) to join.
Remote control gets close to light
about 10 cm distance for touch link.
3.Group Selection
2.Unpairing light(s)
Press the group selection button to select the group(s) you want to control.
Press group all key “1-2” + red program button for 3 seconds that you want the light(s) to unpair. Remote control gets close to light
about 10 cm distance for touch link.
Bulb(s) could be restored to factory default status either by remote or by wall switch. Factory default by remote is same as un -pairing
Bulb(s), while by wall switch is as following.
R
es
e
t
i
n
g
Bulb
(
s
)
Starting from
wall switch OFF
Light(s) finishes On
on 1 second
off 2 seconds
on 1 second
off 2 seconds
on 1 second
off 2 seconds
n 1 second
ff 2 seconds
n 1 second
ff 2 seconds
o
o
o
o
on
User flips the wall switch off and
on 5x over between 1-2 seconds
Factory Default
User connects light(s)
to new network(remote)
Or after 5 min
Light(s) added to
device list as new
Blinks twice
Network close
Restored to factory default by switch
Restarted by wall switch
4.ON/OFF
ON/OFF: Every single press turns all the lights in selected group(s) ON or OFF gradually.
5.Dimming
6.Reset remote control to factory default
Dimming: Dim the light(s) in selected group(s).
UP/DOWN button:
Every press: dims the lumen step by step until max./min.
Keep pressing: dims until max./min. in one time.
Remark: There are totally 13 brighness diming level
CCT button:
Every press: adjusts the CCT step by step until max./min(for RGBW ver. remote)
Keep pressing: adjusts the CCT until max./min. in one time(for RGBW ver. remote)
Press “ON/OFF” key + red program button for 3 seconds. The remote control will be reset to factory default.
Group 1 Group 2
All Groups
CCTW / DIM
On/off
RGBW
Dim+
On/off
shift function between
dim and CCT
Dim/CCT-
RGB-
Quick Dim
Dim-
CCT- CCT+
Group 2
Group 1
Group All
Group 1
RGB+
Group 2
Group All
Dim up
Dim down
Quick toggling between highest
and lowest dimming level &
toggling CCT (for RGBW version)
10s
2s 2s
1s 1s 1s 1s 1s 10s
2s 2s 2s 2s
ON
OFF
