Lenovo Mobile Communication Technology S90L Lenovo Mobile Phone User Manual
Lenovo Mobile Communication Technology Ltd. Lenovo Mobile Phone
User manual
Quick Start Guide
Read this guide carefully before using your smartphone.
Lenovo S90-L
First glance
Front-facing camera
3
Fill Light
1Receiver
2
On/Off button
6
Light/Proximity sensor
4Volume buttons
5
Home button
9
Touch screen
7Back button
8
Flashlight
12
Menu button
10 Rear-facing camera
11
Speaker
15
Headset connector
13 Micro-SIM-card tray
14
16 17 Micro USB connector
Microphone
8
10 1713 16
9
2
3
4
1
5
6
7
11 12 13 14
15
Installing the Micro SIM card
SIM
SIM2
SIM
A Micro SIM card provided by your carrier is required in order to use
cellular services. Install the Micro SIM card as shown.
Step 1.
Step 2.
Step 3.
Insert the SIM eject tool that comes with your smartphone
into the hole in the Micro-SIM-card tray.
Pull out the Micro-SIM-card tray and position the Micro SIM
card into the tray in correct orientation.
Carefully insert the tray with the installed Micro SIM card
back into the slot.
Only Micro SIM cards work with your smartphone.
Always turn off your smartphone first before you insert or remove a
Micro SIM card. Insert or remove a Micro SIM card with your
smartphone on may damage your Micro SIM card or smartphone
permanently.
Charging the battery
Low battery power Fully charged Charging
Your smartphone has a built-in rechargeable battery. For more
information about battery safety, see the “Built-in rechargeable
battery notice” section. The battery in this product cannot be easily
replaced by users themselves.
Charge the battery as shown.
Turning on or turning off your smartphone
Turn on: Press and hold the On/Off button until
the Lenovo logo appears.
Tur n of f: Press and hold the On/Off button for a
few seconds, then tap Power off.
Restart: Press and hold the On/Off button for
about 10 seconds.
Method 1.
Method 2.
Connect your smartphone to a power outlet using the
cable and USB power adapter that come with your
smartphone.
Connect your smartphone to a computer using the cable
that comes with your smartphone.
2
1
① Depending on the measuring method, the dimensions and weight
might vary slightly.
② In some countries, LTE is not supported. To know if your
smartphone works with LTE networks in your country, contact
your carrier.
Type: CMOS
Pixels: 13 megapixels (back) + 8 megapixels (front)
Processor: Qualcom 8916
,
quad-core
,
1.2 GHz
Size: 5.0 inches
Resolution: 1280 × 720 pixels
Model: Lenovo S90-L
Bluetooth 4.0; WLAN 802.11 b/g/n;
②FDD-LTE/WCDMA/GSM; GPS
Battery: 2300 mAh
Height: 146 mm (5.75 inches)
Depth: 6.9 mm (0.27 inch)
Model and system
Display
Battery
Processor
①Dimensions and weight
Camera
Wireless communication
Technical specifications
System: Android
Width: 71.7 mm (2.82 inches)
Weight: 129 g (0.28 lb)
Screen: multi-touch
LCD type: S-AMOLED
Important regulatory, safety, and handling
information
This section contains important regulatory, safety, and handling
information for Lenovo smartphones. Additional safety and handling
information is provided in the User Guide. See the “Accessing your
User Guide” section for details.
Read rst — regulatory information
Be sure to read the Regulatory Notice for your country or region
before using the wireless devices contained in your Lenovo Mobile
Phone. To obtain a PDF version of the Regulatory Notice, see the
“Downloading publications” section.
General battery notice
Batteries supplied by Lenovo for use with your product have been
tested for compatibility and should only be replaced with approved
parts. Risk of explosion if the battery is replaced with an incorrect
type. Dispose of used batteries according to the instructions.
Rechargeable battery notice
CAUTION: Risk of explosion if the battery is replaced with an incorrect
type.
When replacing the lithium battery, use only the same or an equivalent
type that is recommended by the manufacturer. The battery contains
lithium and can explode if not properly used, handled, or disposed of.
Dispose of used batteries according to the instructions.
Do not:
Throw or immerse into water
Heat to more than 100°C (212°F)
Repair or disassemble
Built-in rechargeable battery notice
CAUTION: Do not attempt to replace the internal rechargeable lithium
ion battery. Contact Lenovo Support for factory replacement.
Charging
Charge Lenovo Phone in the temperature range of 0°C (32 °F)—45°C
(113°F). You can use any of the following charging methods to safely
recharge the internal battery of Lenovo Phone:
Supported
Charging method Display off
ac adapter
USB connection between
the dc-in connector on
Lenovo Phone and a USB
connector on a personal
computer or other
devices that comply with
the USB 2.0 standards.
Display on
Supported, but the
battery will charge
slowly.
Supported, but the
battery will charge
slowly.
Supported, but will
compensate power
consumption and the
battery will charge
more slowly than usual.
Notes:
Display on: Lenovo Phone on
Display off: Lenovo Phone off or in screen lock mode
Charging devices might become warm during normal use. Ensure
that you have adequate ventilation around the charging device.
Unplug the charging device if any of the following occurs:
The charging device has been exposed to rain, liquid, or
excessive moisture.
The charging device shows signs of physical damage.
You want to clean the charging device.
Lenovo is not responsible for the performance or safety of products
not manufactured or approved by Lenovo. Use only approved Lenovo
ac adapters and batteries.
NOTE: Adapter shall be installed near the equipment and shall be
easily accessible. Users have to use the connection to USB interfaces
with USB 2.0 version or higher.
Distraction
Take care when using Lenovo Phone in a motor vehicle or on a
bicycle. Always prioritize your safety and the safety of others. Follow
the law. Local laws and regulations might govern how you can use
mobile electronic devices, such as Lenovo Phone, while you drive a
motor vehicle or ride a bicycle.
Handling
Handle Lenovo Phone with care
Do not drop, bend, or puncture Lenovo Phone; do not insert foreign
objects into or place heavy objects on Lenovo Phone. Sensitive
components inside might become damaged.
Prevent Lenovo Phone and adapter from getting wet
Do not immerse Lenovo Phone in water or leave Lenovo Phone in a
location where it can get saturated with water or other liquids.
Repairing
Do not disassemble or modify Lenovo Phone. Lenovo Phone is a
sealed unit. There are no end-user serviceable parts inside. All
internal repairs must be done by a Lenovo-authorized repair facility or
a Lenovo-authorized technician. Attempting to open or modify
Lenovo Phone will void the warranty.
Lenovo Phone screen is made of glass. The glass might break if
Lenovo Phone is dropped on a hard surface, is the subject of a high
impact, or is crushed by a heavy object. If the glass chips or cracks,
do not touch the broken glass or attempt to remove it from Lenovo
Phone. Stop using Lenovo Phone immediately and contact Lenovo
technical support for repair, replacement, or disposal information.
Polyvinyl Chloride (PVC) cable and cord notice
WARNING: Handling the cord on this product or cords associated
with accessories sold with this product will expose you to lead, a
chemical known to the State of California to cause cancer, and birth
defects or other reproductive harm. Wash hands after handling.
Disposing according to local laws and regulations
When Lenovo Phone reaches the end of its useful life, do not crush,
incinerate, immerse in water, or dispose of Lenovo Phone in any
manner contrary to local laws and regulations. Some internal parts
contain substances that can explode, leak, or have an adverse
environmental effect if disposed of incorrectly. See “Recycling and
environmental information” for additional information.
Plastic bag notice
DANGER: Plastic bags can be dangerous. Keep plastic bags away
from babies and children to avoid danger of suffocation.
Choking hazard
Keep Lenovo Phone and accessories away from small children.
Lenovo Phone contains small parts that can be a choking hazard to
small children. Additionally, the glass screen can break or crack if
dropped on or thrown against a hard surface.
motor vehicle or ride a bicycle.
Prevent hearing damage
Lenovo Phone has a headphone connector. Always use the
headphone connector for headphones (also called a headset) or
earphones.
CAUTION: Excessive sound pressure from earphones and
headphones can cause hearing loss. Adjustment of the equalizer to
maximum increases the earphone and headphone output voltage and
the sound pressure level. Therefore, to protect your hearing, adjust
the equalizer to an appropriate level.
Excessive use of headphones or earphones for a long period of time
at high volume can be dangerous if the output of the headphone or
earphone connectors do not comply with specifications of EN
50332-2.
The headphone output connector of Lenovo Phone complies with EN
50332-2 Sub clause 7. This specification limits Lenovo Phone's
maximum wide band true RMS output voltage to 150 mV. To help
protect against hearing loss, ensure that the headphones or
earphones you use also comply with EN 50332-2 (Clause 7 limits) for
a wide band characteristic voltage of 75 mV. Using headphones that
do not comply with EN 50332-2 can be dangerous due to excessive
sound pressure levels.
If Lenovo Phone came with headphones or earphones in the
package, as a set, the combination of the headphones or earphones
and Lenovo Phone already complies with the specifications of EN
50332-1. If different headphones or earphones are used, ensure that
they comply with EN 50332-1 (Clause 6.5 Limitation Values). Using
headphones that do not comply with EN 50332-1 can be dangerous
due to excessive sound pressure levels.
Sound pressure warning statement
For the device that is tested in accordance with EN 60950-1:
2006+A11:2009:+A1:2010+A12:2011, it is mandatory to perform
audio tests for EN50332.
This device has been tested to comply with the Sound Pressure Level
requirement in the applicable EN 50332-1 and/or EN 50332-2
standards. Permanent hearing loss may occur if earphones or
headphones are used at high volume for prolonged periods of time.
Warning statement: To prevent possible hearing damage, do not listen
at high volume levels for long periods.
Explosive atmospheres
Do not charge or use Lenovo Phone in any area with a potentially
explosive atmosphere, such as at a fueling area, or in areas where
the air contains chemicals or particles (such as grain, dust, or metal
powders). Obey all signs and instructions.
Radio frequency interference
Observe signs and notices that prohibit or restrict the use of mobile
phones (for example, in healthcare facilities or blasting areas).
Although Lenovo Phone is designed, tested, and manufactured to
comply with regulations governing radio frequency emissions, such
emissions from Lenovo Phone can negatively affect the operation of
other electronic equipment, causing them to malfunction. Turn off
Lenovo Phone or use Airplane Mode to turn off Lenovo Phone
wireless transmitters when use is prohibited, such as while traveling
in aircraft, or when asked to do so by authorities.
Medical devices
Lenovo Phone contains radios that emit electromagnetic fields.
These electromagnetic fields may interfere with pacemakers or other
medical devices. If you wear a pacemaker, maintain at least 15 cm (6
inches) of separation between your pacemaker and Lenovo Phone. If
you suspect Lenovo Phone is interfering with your pacemaker or any
other medical device, stop using Lenovo Phone and consult your
physician for information specific to your medical device.
Cleaning
Clean Lenovo Phone immediately if it comes in contact with anything
that may cause stains, such as dirt, ink, makeup, or lotions. To clean:
Disconnect all cables and turn off Lenovo Phone (press and hold
the Sleep/Wake button, then slide the on-screen slider).
Use a soft, lint-free cloth.
Avoid getting moisture in openings.
Do not use cleaning products or compressed air.
Operating temperature
Be aware of heat generated by Lenovo Phone. When using Lenovo
Phone, keep it away from hot or high-voltage environments, such as
electric appliances, electric heating equipment, or electric cooking
equipment. Use Lenovo Phone only in the temperature range of
-10°C (14°F)—45°C (113°F) to avoid damage.
When Lenovo Phone is turned on or the battery is charging, some
parts might become hot. The temperature that they reach depends
on the amount of system activity and the battery charge level.
Extended contact with your body, even through clothing, could cause
discomfort or even a skin burn. Avoid keeping your hands, your lap,
or any other part of your body in contact with a hot section of Lenovo
Phone for any extended time.
Protecting your data and software
Do not delete unknown files or change the name of files or directories
that were not created by you; otherwise, Lenovo Phone software
might fail to work.
Be aware that accessing network resources can leave Lenovo Phone
vulnerable to computer viruses, hackers, spyware, and other
malicious activities that might damage Lenovo Phone, software, or
data. It is your responsibility to ensure that you have adequate
protection in the form of firewalls, antivirus software, and
anti-spyware software and keep such software up to date.
Keep electrical appliances away from Lenovo Phone, such as an
electric fan, a radio, high-powered speakers, an air conditioner, and a
microwave oven. The strong magnetic fields generated by electrical
appliances can damage the screen and the data on Lenovo Phone.
FCC Compliance Statement
FCC Regulations:
This mobile phone complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
This mobile phone has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiated radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Note:
Caution: Changes or modifications not expressly approved by the
party responsible for compliance could void the user‘s authority to
operate the equipment.
Lenovo is not responsible for any radio or television interference
caused by unauthorized changes or modifications to this equipment.
Unauthorized changes or modifications could void the user’s
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Responsible Party:
Lenovo (United States) Incorporated
1009 Think Place - Building One
Morrisville, NC 27560
Telephone: 1-919-294-5900
FCC Caution
Any Changes or modifications not expressly approved by the party
responsible for compliance void the user’s authority to operate the
equipment.
The antenna(s) used for this transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
NOTE:
The country code selection is for non-US model only and is not
available to all US model. Per FCC regulation, all Wi-Fi product
marketed in US must fixed to US operation channels only.
Service, support, and warranty information
The following information describes the technical support that is
available for your product, during the warranty period or throughout
the life of your product. Refer to the Lenovo Limited Warranty for a full
explanation of Lenovo warranty terms.
Online technical support
Online technical support is available during the lifetime of a product at
http://www.lenovo.com/support.
Telephone technical support
Where applicable, you can get help and information from the
Customer Support Center by telephone. Before contacting a Lenovo
technical support representative, please have the following
information available: model and serial number, the exact wording of
any error message, and a description of the problem.
Your technical support representative might want to walk you through
the problem while you are at your phone during the call.
Worldwide Lenovo Support telephone list
IMPORTANT: Telephone numbers are subject to change without
notice. The most up-to-date telephone list for the Customer Support
Center is always available at
http://support.lenovo.com/serviceproviders
.
The Customer Support Center phone number is subjected to be
change, and please go to the e-support website for the latest phone
number. If the telephone number for your country or region is not
listed, contact your Lenovo reseller or Lenovo marketing
representative.
Lenovo Limited Warranty notice
Read the full Lenovo Limited Warranty (LLW) at
http://support.lenovo.com/smartphone-llw. You can view the LLW in
a number of languages from this Web site. If you cannot view the
LLW either from the Web site or from your phone, contact your local
Lenovo office or reseller to obtain a printed version of the full LLW.
IMPORTANT: Lenovo Smartphone Products do not have International
Warranty Services.
Suplemento de Garantía para México
Este Suplemento se considera parte integrante de la Garantía
Limitada de Lenovo y será efectivo única y exclusivamente para los
productos distribuidos y comercializados dentro del Territorio de los
Estados Unidos Mexicanos. En caso de conflicto, se aplicarán los
términos de este Suplemento.
El comercializador responsable del producto es Lenovo México S de
R L de CV y para efectos de esta garantía su domicilio es Paseo de
Tamarindos No.400-A Piso 27 Arcos Torre Poniente Bosques de Las
Lomas C.P. 05120 México, D.F. En el caso de que se precise una
reparación cubierta por la garantía o precise de partes, componen-
tes, consumibles o accesorios diríjase a este domicilio.
Otra opción es llamar al Centro de soporte al cliente al
01-800-9253-6686, donde le dirigirán al Centro de servicio
autorizado más cercano. Si no existiese ningún Centro de servicio
autorizado en su ciudad, población o en un radio de 70 kilómetros de
su ciudad o población, la garantía incluirá cualquier gasto de entrega
razonable relacionado con el transporte del producto a su Centro de
servicio autorizado más cercano. Por favor, llame al Centro de
servicio autorizado más cercano para obtener las aprobaciones
necesarias o la información relacionada con el envío del producto y
la dirección de envío.
Esta garantía ampara todas las piezas de hardware del producto e
incluye mano de obra.
El procedimiento para hacer efectiva la garantía consiste en la
presentación del producto, acompañado de la póliza correspondi-
ente, debidamente sellada por el establecimiento que lo vendió, o la
factura, o recibo o comprobante, en el que consten los datos
específicos del producto objeto de la compraventa.
Lenovo sólo pueden eximirse de hacer efectiva la garantía en los
siguientes casos: a) Cuando el producto se hubiese utilizado en
condiciones distintas a las normales. b) Cuando el producto no
hubiese sido operado de acuerdo con el instructivo de uso que se le
acompaña. c) Cuando el producto hubiese sido alterado o reparado
por personas no autorizadas por el fabricante nacional, importador o
comercializador responsable respectivo.
Todos los programas de software precargados en el equipo sólo
tendrán una garantía dentro de noventa (90) días por defectos de
instalación desde la fecha de compra. Lenovo no es responsable de
la información incluida en dichos programas de software y /o
cualquier programa de software adicional instalado por Usted o
instalado después de la compra del producto.
La garantía cubre la atención, revisión y corrección de errores,
defectos o inconsistencias que impidan el desempeño normal de un
equipo en cuanto a su hardware y software. Los servicios no
cubiertos por la garantía se cargarán al usuario final, previa
obtención de una autorización.
Esta garantía tiene una duración de un año a partir del momento de
la compra e incluye la mano de obra, por lo que en caso de aplicarse
la garantía, esta no causara ningún gasto o costo para el cliente.
Para obtener una lista de los Centros de servicio autorizados, por
favor, visite:
http://support.lenovo.com/serviceproviders.
Fabricado por: Lenovo PC HK Limited
23/F, Lincoln House, Taikoo Place 979 King's Road, Quarry Bay,
Hong Kong
Modelo del producto: __________________
Fecha en que el consumidor recibió el producto:
__________________
Recycling and environmental information
General recycling statement
Lenovo encourages owners of information technology (IT) equipment
to responsibly recycle their equipment when it is no longer needed.
Lenovo offers a variety of programs and services to assist equipment
owners in recycling their IT products. For information on recycling
Lenovo products, go to: http://www.lenovo.com/recycling.
Recycling information for India
Recycling and disposal information for India is available at:
http://www.lenovo.com/social_responsibility/us/en/sustainability/ptb_india.html
Important WEEE information
Electrical and electronic equipment marked with the
symbol of a crossed-out wheeled bin may not be disposed
as unsorted municipal waste. Waste of electrical and
electronic equipment (WEEE) shall be treated separately
using the collection framework available to customers for
the return, recycling, and treatment of WEEE.
Country-specific information is available at:
http://www.lenovo.com/recycling
Restriction of Hazardous Substances Directive (RoHS)
Turkish
The Lenovo product meets the requirements of the Republic of
Turkey Directive on the Restriction of the Use of Certain Hazardous
Substances in Waste Electrical and Electronic Equipment (WEEE).
India
RoHS compliant as per E-Waste (Management & Handling) Rules, 2011.
Ukraine
Atık Elektrikli ve
AEEE
AEEE
AEEE
Elektronik Eşya
Specic Absorption Rate information
This mobile device meets the government’s requirements for
exposure to radio waves.
Your mobile device is a radio transmitter and receiver. It is designed
and manufactured not to exceed the limits for exposure to radio
waves set by the Federal Communications Commission (FCC) of the
U.S. Government, Industry Canada of the Canadian Government(IC),
recommended by The Council of the European Union when used as
directed in the previous section.
The exposure standard for mobile devices employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The
SAR limit set by the FCC/IC is 1.6W/kg averaged over 1 grams of
tissue. The India SAR limit for mobile devices is 1.6 W/kg averaged
over 1 grams of tissue. Tests for SAR are conducted using standard
operating positions with the device transmitting at its highest certified
power level in all tested frequency bands.
Before a mobile device is available for sale to the public, it must be
tested and certified to the FCC, IC, and the Council of the European
Union that it does not exceed the limit established by government-ad-
opted requirement for safe exposure under the recommendations of
the international Commission on Non-lonizing Radiation Protection
(ICNIRP). The tests are performed in positions and locations (for
example, at the head and worn on the body) as required by the FCC,
IC, and the Council of the European Union for each model.
The highest SAR value for your Lenovo device when tested for use at
the head and body is outlined as follows:
FCC 1g SAR Limit(1.6W/kg)
Position Regulation
Head
Body-worn
The highest SAR value
1.25
1.34
During use, the actual SAR values for this device are usually well
below the values stated above. This is because, for purposes of
system efficiency and to minimize interference on the network, the
operating power of your mobile devices is automatically decreased
when full power is not needed for the call. The lower the power
output of the device, the lower its SAR value.
During SAR testing, this device was set to transmit at its highest
certified power level in all tested frequency bands, and placed in
positions that simulate RF exposure in usage against the head
with no separation, and near the body with the separation of 10 mm.
XXXXXXXXXX
Printed in China
First Edition (December 2014) © Copyright Lenovo 2014.
Learning more
Getting support
For support on network service and billing, contact your
wireless network operator. For instructions on how to use
Lenovo smartphone, go to: http://support.lenovo.com/.
Downloading publications
To obtain the latest smartphone manuals, go to:
http://support.lenovo.com/
Advertensia para Mexico
La operación de este equipo está sujeta a las siguientes
dos condiciones: (1) es posible que este equipo o
dispositivo no cause interferencia perjudicial y (2) este
equipo o dispositivo debe aceptar cualquier interferencia,
incluyendo la que pueda causar su operación no deseada.
Legal notices
Lenovo and the Lenovo logo are trademarks of Lenovo in
the United States, other countries, or both.
Other company, product, or service names may be
trademarks or service marks of others.
