Lenovo A7600H PORTABLE TABLET COMPUTER User Manual Lenovo LVP9 QSG EN 125 85mm

Lenovo (Shanghai) Electronics Technology Co., Ltd PORTABLE TABLET COMPUTER Lenovo LVP9 QSG EN 125 85mm

Contents

User Manual

Lenovo A7600
Quick Start Guide v1.0
Read this guide carefully before using your tablet.
All information labeled with * in this guide refers only to the
WLAN + 3G model (Lenovo A7600-HV).
Technical specifications
Type: CMOS
Pixels: 5 MP (back)+ 2 MP (front)
GPS
Height: 264.1 mm Width: 176.54 mm Depth: 8.9 mm
Weight: 550 g
CPU: MTK 8121
*MTK 8382
Size: 10.1 inches (diagonal) Screen: Multi-touch display
Resolution: 1280 × 800 LCD type: IPS
Model: Lenovo A7600-F; *Lenovo A7600-HV;
②Bluetooth 4.0 WLAN 802.11b/g/n *WCDMA, GSM
① Actual product may differ.
② Launch with Android 4.2 which only supports BT 4.0 PXP profile.
Battery: 6340 mAh
Wireless communication
Display
Model and system
Power and battery
CPU
① Size and weight
Camera
Version: WLAN *WLAN + 3G
First glance
Micro USB port
Microphone
Receiver / Speaker Back camera
On/Off button
5
10
Front camera
2
6
3
789
4
1
Volume key
*SIM card slot
microSD card slot
* The WLAN model (Lenovo A7600-F) does not have a SIM card slot.
Earphone jack
SIM
4
3
2
1
4
6
5
8
9
10
7
Installing the SIM card & microSD card
Step 1. Open the card slot cover as shown.
Step 2. Insert the SIM card into the SIM card slot and the microSD card
into the microSD card slot.
Step 3. Carefully replace the card slot cover.
You can use cellular services with the WLAN + 3G model (Lenovo
A7600-HV) by inserting the SIM card provided by your carrier services.
Install the SIM card as shown.
Only SIM cards work with your tablet and SIM cards are for mobile data only.
Do not insert or remove the SIM card while your tablet is turned on. Doing so
may permanently damage your SIM card or tablet.
SIM
SIM
SIM
SIM
Reset
For more information about battery safety, see the Important
Product Information Guide.
Charging and turning on/off your tablet
Method Connect your tablet to a power outlet using the included cable
and USB power adapter.
Low battery Fully charged Charging
Before using your tablet, you might need to charge the battery.
Charge the battery as shown.
8306LVP502W
Printed in China
Learn more
Legal notices
Lenovo and the Lenovo logo are trademarks of Lenovo in the United States,
other countries, or both.
Other company, product, or service names may be trademarks or service
marks of others.
* Manufactured under license from Dolby Laboratories. Dolby and the
double-D symbol are trademarks of Dolby Laboratories.
First Edition (January 2014) © Copyright Lenovo 2014.
For other useful manuals, please access “User Guide” from the Browser
favorites in your tablet.
For “Regulatory Notices”, please go to http://support.lenovo.com/.
Getting support
For support on network service and billing, please contact your wireless
network operator. For instructions on how to use your tablet, go to
http://support.lenovo.com/.
Radio and Telecommunications Terminal Equipment Directive
This product is in compliance with the essential requirements and other
relevant provisions of the Radio and Telecommunications Terminal
Equipment Directive, 1999/5/EC.
European Union conformity
