Tamper proof process for Wireless card
Dell TJ860 and Lexmark 30B0520
Part 1: Add epoxy glue to fix the metal shield and cover
EPROM.
View #1:
Epoxy glue
View #2:
Epoxy glue
Part 2: Additional solder added to assembly.
Solder added to clasp in two locations to keep
the mini card from bein
g
removed.
Solder added to antenna connection.
