RollRiteRADIOFREQUENCYRECEIVER/RADIOFREQUENCYTRANSMITTERInstruction Page1
RollRiteAutomatedTarpSystem
RemoteControlOwner’sGuide
ComponentPhotos
RadioFrequencyTransmitter(figure)
RadioFrequencyReceiver(figure)
ConnectingRFReceivertoMotorController
InstallationRequirements
Allelectricalterminalsshallbecoatedwithdielectricgrease,SyntheticNLGIGrade2or
equivalent
RemovenegativeelectricalterminalsofallchassisbatteriespriortoinstallationofRollRite
components
RollRitemotorrelayandRadioFrequencyReceivershallbeinstalledonaverticalplanewiththe
wiresfromterminalsfacingdown.ThisistheonlyapprovedinstallationorientationforRollRite
electricalcomponents
TorqueMotorRelayTerminal7/16”fastenersto8ft.lb(11Nm)
InstallationProcedure
1. DisconnectallMainNegativeBatteryTerminalsfromtheVehicleBatterySystem,thereby
isolatingstoredelectricalenergyfromRollRitetarpsystemcomponents
2. ConnectRollRiteMotorController
a. ConnectPositivePowertoBat+Terminal,SlideRedBootoverTerminalconnection
b. ConnectNegativePowertoGNDTerminal,SlideBlackBootoverTerminalconnection
c. ConnectBlueMotorCabletoM1Terminal,SlideBlueBootoverTerminalconnection
RollRiteRADIOFREQUENCYRECEIVER/RADIOFREQUENCYTRANSMITTERInstruction Page2
d. ConnectYellowMotorCabletoM2Terminal,SlideYellowBootoverTerminal
connection
3. ConnectRadioFrequencyReceivertoRollRiteMotorController
a. Adddielectricgreasetoall¼”terminalsoftheRadioFrequencyReceiverandMotor
Controller
b. Connect¼”FlagTerminalofRedWiretoBAT+Terminal
c. Connect¼”FlagTerminalofBlackWiretoGNDTerminal
d. Connect¼”FlagTerminalofYellowWiretoFWDTerminal
e. Connect¼”FlagTerminalofBlueWiretoREVTerminal
4. InstallMotorRelayandRFReceiveronvehiclechassis,followinginstallationrequirementsinthis
document
5. ConnectMainNegativeBatteryTerminalstoMainNegativeWiresonChassisWiringHarness
WiringDiagram(figure)

PairingtheSingleFunctionTransmitterwithOneReceiver
1. CompleteallelectricalconnectionsbetweenRadioFrequencyReceiverand
2. InstallRadioFrequencyReceiveronvehiclebody
3. Onthereceiver,pressUncoverandPairatthesametime,theReceiverLEDwillflashindicating
pairinghasstarted(figure)
4. Pressthepairbuttonthetransmitter,theReceiverLEDwillilluminatesolid,indicatingthereceiver
haspairedwiththetransmitter(figure)
5. Onthetransmitter,PresstheCoverandUncoverbuttonssimultaneouslytosetthereceiverasthe
primarymotorcontroller.ThereceiverLEDwillilluminateonceindicatingthepairinghas
completed.(figure)
PairingtheMultiFunctionTransmitterWithMoreThanOneReceiver
TheRollRiteTransmittercanbeconfiguredtodrivebetween1and3receivers.Thisisimplemented
whenmorethanonemotorisworkingonatruckortrailer.Forexample,atypicalgraintrailerwillhave
onemotoroperatingthetarpandonemotorperautomatedhopperdoor.Thetotalmotorsand
receiversisthreeinthisexample.
TarpMotorPairing:
1. Onthereceiver/relayconnectedtothetarpmotor,pressUncoverandPairatthesame
time,theReceiverLEDwillflashindicatingpairinghasstarted(figure)
2. Pressthepairbuttonthetransmitter,theReceiverLEDwillilluminatesolid,indicatingthe
receiverhaspairedwiththetransmitter(figure)
RollRiteRADIOFREQUENCYRECEIVER/RADIOFREQUENCYTRANSMITTERInstruction Page3
3. Onthetransmitterselectthe“Tarp”CoverandUncoverbuttonsimultaneously(figure)
4. ThereceiverLEDwillflash1time,indicatingthetransmitterhaspairedwiththeTarpMotor
Receiver
FrontHopperMotorPairing:
1. Onthereceiver/relayconnectedtothehoppermotoratthefrontofthetrailer,press
UncoverandPairatthesametime,theReceiverLEDwillflashindicatingpairinghasstarted
(figure)
2. Pressthepairbuttonthetransmitter,theReceiverLEDwillilluminatesolid,indicatingthe
receiverhaspairedwiththetransmitter(figure)
3. Onthetransmitterselectthe“FrontHopper”CoverandUncoverbuttonsimultaneously
(figure)
4. ThereceiverLEDwillflash2times,indicatingthetransmitterhaspairedwiththereceiver
operatingwiththeFrontHopperDoor
RearHopperMotorPairing:
1. Onthereceiver/relayconnectedtotherearhoppermotorattherearofthetrailer,press
UncoverandPairatthesametime,theReceiverLEDwillflashindicatingpairinghasstarted
(figure)
2. Pressthepairbuttonthetransmitter,theReceiverLEDwillilluminatesolid,indicatingthe
receiverhaspairedwiththetransmitter(figure)
3. Onthetransmitterselectthe“RearHopper”CoverandUncoverbuttonsimultaneously
(figure)
4. ThereceiverLEDwillflash3times,indicatingthetransmitterhaspairedwiththisreceiver
OperatingtheSystem
TurningtheReceiverOn(figure)
UncoveringtheTarp(figure)
UsingtheReceiverButtonstoUncover(figure)
UsingtheTransmittertoUncover(figure)
CoveringtheTarp(figure)
TurningtheReceiverOff(figure)
RollRiteRADIOFREQUENCYRECEIVER/RADIOFREQUENCYTRANSMITTERInstruction Page4
Specifications
FCCStatementofCompliance
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaclassBdigitaldevice,pursuant
topart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmful
interferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofrequency
energyandifnotinstalledandusedinaccordancewiththeinstructions,maycauseharmfulinterference
toradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticular
installation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,which
canbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotrytocorrectthe
interferencebyoneormoreofthefollowingmeasures:
*Reorientorrelocatethereceivingantenna.
*Increasetheseparationbetweentheequipmentandreceiver.
*Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris
connected.
*Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
InordertomaintaincompliancewithFCCregulations,shieldedcablesmustbeusedwiththis
equipment.Operationwithnonapprovedequipmentorunshieldedcablesislikelytoresultin
interferencetoradioandTVreception.Theuseriscautionedthatchangesandmodificationsmadeto
theequipmentwithouttheapprovalofmanufacturercouldvoidtheuser'sauthoritytooperatethis
equipment.
ICStatementofCompliance‐English
UnderIndustryCanadaregulations,thisradiotransmittermayonlyoperateusinganantennaofatype
andmaximum(orlesser)gainapprovedforthetransmitterbyIndustryCanada.Toreducepotential
radiointerferencetootherusers,theantennatypeanditsgainshouldbesochosenthattheequivalent
isotropicallyradiatedpower(e.i.r.p.)isnotmorethanthatnecessaryforsuccessfulcommunication.
Thisradiotransmitter(IC:[ICCompanynumberofyourproduct])hasbeenapprovedbyIndustryCanada
tooperatewiththeantennatypeslistedbelowwiththemaximumpermissiblegainandrequired
antennaimpedanceforeachantennatypeindicated.Antennatypesnotincludedinthislist,havinga
gaingreaterthanthemaximumgainindicatedforthattype,arestrictlyprohibitedforusewiththis
device.
ICDéclarationdeConformité
Conformémentàlaréglementationd'IndustrieCanada,leprésentémetteurradiopeut
fonctionneravecuneantenned'untypeetd'ungainmaximal(ouinférieur)approuvépour
l'émetteurparIndustrieCanada.Danslebutderéduirelesrisquesdebrouillageradioélectrique
àl'intentiondesautresutilisateurs,ilfautchoisirletyped'antenneetsongaindesortequela
RollRiteRADIOFREQUENCYRECEIVER/RADIOFREQUENCYTRANSMITTERInstruction Page5
puissanceisotroperayonnéeéquivalente(p.i.r.e.)nedépassepasl'intensiténécessaireà
l'établissementd'unecommunicationsatisfaisante.
Leprésentémetteurradio(IC:[ICCompanynumberofyourproduct])demodèles'ilfaitpartiedu
matérieldecatégorieI)aétéapprouvéparIndustrieCanadapourfonctionneraveclestypesd'antenne
énuméréscidessousetayantungainadmissiblemaximaletl'impédancerequisepourchaquetype
d'antenne.Lestypesd'antennenoninclusdanscetteliste,oudontlegainestsupérieuraugainmaximal
indiqué,sontstrictementinterditspourl'exploitationdel'émetteur.
