Quick Installation Guide

Model: LP-8617N

NOTE: Do not insert the USB adapter until the software/driver has been installed.

High Power Wireless-150N Compact USB Adapter

Insert the Setup CD Install Software

The menu page should appear.

Select the instruction for your operating system and

install the driver for the USB adapter.

Follow the Instructions for Driver Installation

A. From the Menu page, select Driver Installation B. Start the Driver Installation

If the Menu page does not appear, browse the if prompted, click Next to begin the installation

CD drive and double-click the autorun.exe file

C. Continue the Driver Installation D. Restart your Computer

Follow the instructions that appear for installation A prompt will appear asking you to restart your

computer. Select Yes and click Finish to restart.

E. Insert the High Power USB Adapter

After the computer has fully rebooted, locate a USB port and insert the

USB Adapter. Windows should automatically begin to install the driver

for using the USB Adapter.

Quick Installation Guide

Model: LP-8617N

Windows 7

1. Connect to a Wireless Network 2. Connect to a Wireless Network

Locate the Wireless Icon in the Windows If the network you are trying to connect to has

System tray (bottom right corner) and click it to security enabled you will need to enter it here.

view available wireless Networks. Highlight your

desired network and click Connect.

Windows 8.1

1. Connect to a Wireless Network 2. Connect to a Wireless Network

Click it to view available wireless Networks. Enter the Security Key then click “Next ”.

Select the Wireless Network and tick mark the

button to connect automatically & press “Connect”.

3. The Wi-Fi Network is connected successfully.

QuickInstallationGuide

Model:LP‐8617N



REGULATORYINFORMATION

FederalCommunicationCommissionInterferenceStatement

ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttoPart15

oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferenceina

residentialinstallation.Thisequipmentgenerates,uses,andcanradiateradiofrequencyenergyand,ifnotinstalled

andusedinaccordancewiththeinstructions,maycauseharmfulinterferencetoradiocommunications.However,

thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescause

harmfulinterferencetoradioortelevisionreception,whichcanbedeterminedbyturningtheequipmentoffand

on,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:

•Reorientorrelocatethereceivingantenna.

•Increasetheseparationbetweentheequipmentandreceiver.

•Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.

•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.



FCCCaution:

ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:(1)This

devicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptanyinterferencereceived,including

interferencethatmaycauseundesiredoperation.



RFRadiationExposureandHazardStatement:

ToensurecompliancewithFCCRFexposurerequirements,thisdevicemustbeinstalledinalocationsuchthatthe

antennaofthedevicewillbegreaterthan0.25mawayfromallpersons.Usinghighergainantennasandtypesof

antennasnotcoveredundertheFCCcertificationofthisproductisnotallowed.Installersoftheradioandend

usersoftheproductmustadheretotheinstallationinstructionsprovidedinthismanual.Thistransmittermustnot

beco‐locatedoroperatinginconjunctionwithanyotherantennaortransmitter.



SARwarningstatement

ThisEUTiscompliancewithSARforgeneralpopulation/uncontrolledexposurelimitsinANSI/IEEEC95.1‐1999and

hadbeentestedinaccordancewiththemeasurementmethods.Thisequipmentshouldbeinstalledandoperated

withminimumdistance5mmbetweentheradiator&yourbody.



Non‐modificationStatement:

Useonlytheintegralantennasuppliedbythemanufacturerwhenoperatingthisdevice.Unauthorizedantennas,

modifications,orattachmentscoulddamagetheTINavigatoraccesspointandviolateFCCregulations.Any

changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoidtheuser's

authoritytooperatethisequipment.


