The iBeacon&Eddystone (digital broadcasting device) C6 is designed based on the Low Energy Bluetooth
4.0 technology; it is a wearable tag that supports to attach it to somebody by neck-string or keychain.
C6 broadcasts the data at regular and adjustable intervals according to Apple’ standard iBeacon protocol, it
can be heard and interpreted by iOS and Android BLE-enabled devices that are equipped with many mobile
apps. It widely used for the trade shows, conferences, events and so on.
FEATURES
- Programmed MiniBeacon standard firmware
- The max. 80 meters advertising distance
- Easy to print the logo on the case
- Wearable optional: neck-string and keychain
- Ultra-low power consumption chipset nRF51822 with ARM core
- Powered by a small coin battery CR2032, battery replaceable
CERTIFICATIONS
- iBeacon MFi License (iBC-14-00582)
- FCC Regulation (FCC Part 15.)
- CE Regulations (Included EN300328/301489/60950/62479)
SPECIFICATION
iBeacon & Eddystone C6
Image 1
Compatibility
- Supported iOS 7.0+ and Android 4.3+ system;
- Compatible with Apple iBeaconTM standard;
- Compatible with all Bluetooth 4.0 (BLE) devices;
Long Battery Lifetime and Battery Level
- 6 months @ default settings;
- Easy to get the real-time battery level notification;
Soft-reboot
- Reboot the device via command without any tools;
Connection Mode
- Advertising mode, non-connectable;
- Configuration mode, connectable;
Programming Ports J-Link
- Reserved the J-Link port on the board;
- Re-programming the FW into board via J-Link;
Configurable Parameters
- UUID, Major, Minor, Device Name, Password etc.
- Special Configuration APP;
Transmission Power Levels
- Default setting: 0dBm
- 8 adjustable levels, range from 0 to 7
- Transmission power range: -30dBm to +4dBm;
Long Range
- The max. Range 100 meters in the open space;
- The range depends on the physical environment;
Security
- 8 characters password (Lock/Unlock parameters);
- Broadcast the encrypted data if needed;
- AES HW encryption
TEL: +86-755-8886 8480 FAX: +86-755-2982 5342 EMAIL: sales@minewtech.com URL: www.minewtech.com
Page 3
Minew Technologies C6 iBeacon & Eddystone
Datasheet V1.0
TURN ON C6
Please DO take out the battery sheet from the beacon device before using.
CONFIGURABLE PARAMETERS
Characteristic
Item Default Settings
0xFFF1 UUID E2C56DB5-DFFB-48D2-B060-D0F5A71096E0 (Proximity)
0xFFF2 Major 0
0xFFF3 Minor 0
0xFFF4 Measured Power -59 (0xC5)
0xFFF5 Transmission Power 6 (0dBm)
0xFFF6 Change Password minew123 (Must be 8 characters)
0xFFF7 Broadcasting Interval 9(900mS)
0xFFF8 Serial ID Random (Unique serial ID for beacon)
0xFFF9 iBeacon Name MiniBeacon_ (the maximum 14 characters)
0xFFFE Connection Mode 0 (connectable, configuration mode)
0xFFFF Soft Reboot minew123 (it is same as the value of Change Password)
ELECTRONIC PARAMETERS
Item Value Remarks
Case Color white Other colors can be customized
Battery Model 1pc x CR2032 Coin battery, 1pc x 3.0V
Operation Voltage 1.8-3.6V DC
Transmission Circuit 10.5mA (Max.) Tested at 0dBm transmission power
Transmission Range 80 meters Maximum
Antenna 50ohm On board / PCB Antenna
Accessories Double adhesive 1pc, high-strength, 3M brand;
Net Weight 16.0g With battery
Size 42 x 31 x 11 mm Null
TECHNICAL SUPPORT
Item Version File Name Updated Date
Datasheet V1.0 C6_MiniBeacon Datasheet_1.0.pdf 10
th
August, 2015
Instruction V2.03 Instructions_MiniBeacon_V2.03.pdf 25
th
May, 2015
SDK V1.0 Android Reference Source Code;
iOS Reference Source Code; 28th February, 2015
APP Tools V2.0 iBeaconCFG; iBeaconDFU; 3rd March, 2015
* Minew sales team will send you these documents after the sample arrived.
