MINEW TECHNOLOGIES D15N Digital Broadcasting Device (iBeacon/Eddystone) User Manual
SHENZHEN MINEW TECHNOLOGIES CO., LTD. Digital Broadcasting Device (iBeacon/Eddystone) Users Manual
User Manual
TEL: +86-755-2103 8160 EMAIL: sales@minewtech.com URL: www.minewtech.com 1
E8 TagBeacon
UFO Beacon_D15N
U
UF
FO
O
B
Be
ea
ac
co
on
n
M
Mo
od
de
el
l:
:
D
D1
15
5N
N
D
Da
at
ta
as
sh
he
ee
et
t
V
V3
3.
.0
0
Part #
Description
D15N-6001A
204780001, UFO beacon with hidden push button, Bluetooth 5.0, pre-flashed
MiniBeacon Plus software supports broadcasting iBeacon and Eddystone
simultaneously
TEL: +86-755-2103 8160 EMAIL: sales@minewtech.com URL: www.minewtech.com 2
E8 TagBeacon
UFO Beacon_D15N
The UFO beacon D15N is a new generation beacon that loaded Bluetooth 5.0 hardware platform, hidden
push button and MiniBeacon Plus intelligence software.
D15N UFO beacon advertises standard iBeacon and Eddystone (UID,URL,TLM) simultaneously. The user can
configure D15N UFO beacon via configuration app BeaconSET+ as well.
Moreover, the push button can be defined to advertise different data to meet different application by click,
double-click and triple-click. For example, the single click can be used to the panic / emergency / SOS
button. For more functions, please refer to the configuration instruction.
FEATURE
- Advertise iBeacon & Eddystone simultaneously
- Unique MAC address (ITU)
- Bluetooth 5.0 chipset nRF52 series
- The max. 50 meters advertising distance
- Weatherproof housing with key-chain hole
- Push button for emergency using
APPLICATION
- Asset tracking and location
- Personnel tracking
- Activity monitoring
- Inventory tracking
CONFIGURATION TOOL
- BeaconSET+ (IOS & Android);
- The UFO beacon D15N can be turned off by app BeaconSET+;
ACTIVATE D15N
- Pressing the push button with power icon and keeping on 3 seconds;
- The UFO beacon D15N has been activated on after LED lights on 5 seconds then off, t
CERTIFICATION
- iBeacon MFi License (iBC-14-00582)
- FCC Regulation (FCC Part 15.)
- CE Regulations (Included EN300328/301489/60950/62479)
D15N UFO Beacon
TEL: +86-755-2103 8160 EMAIL: sales@minewtech.com URL: www.minewtech.com 3
E8 TagBeacon
UFO Beacon_D15N
ELECTRONIC PARAMETER
Item
Value
Remarks
Case Color
white
Other colors can be customized
Battery Model
1 x CR2025
1pc CR2025 coin battery, 85mAh, 3.0V
Operation Voltage
1.8-3.9V
DC
Transmission Circuit
5.3mA (Max.)
Tested at 0dBm transmission power
Transmission Range
50 meters
Maximum
Antenna
50ohm
On board / PCB Antenna
Net Weight
7.0g
With battery
Size
Ø35 x 8.2 mm
Null
PARAMETER SETTING
Each D15N UFO beacon has been pre-configured in the factory before the shipment. Here below is given
the main parameters and default settings.
Type
Item
Default Settings
iBeacon
UUID (16 bytes)
E2C56DB5-DFFB-48D2-B060-D0F5A71096E0 (Proximity)
Major (2 bytes)
0
Minor (2 bytes)
0
Eddystone
Instance ID @UID
random (10 bytes)
Namespace ID @UID
random (6 bytes)
URL
https://www.minewtech.com
Base
Parameters
Measured Power
-59 (0xC5)
Radio Tx power
6 (0dBm)
Adv. Interval
9(900mS)
Beacon ID
random, it is MAC address of beacon actually.
Beacon Name
PLUS
Connectable
yes (it is configuration mode)
Password
minew123 (Allowing only 8 characters)
Extra
Function
Reset factory
available
Power off
available
Modify password
available
Remove password
available
Update firmware
available
TEL: +86-755-2103 8160 EMAIL: sales@minewtech.com URL: www.minewtech.com 4
E8 TagBeacon
UFO Beacon_D15N
TECHNICAL DOCUMENT
Item
Version
File Name
Date
Datasheet
V3.0
UFO Beacon Datasheet
8th May, 2018
Instruction
V3.0
UFO Beacon Configuration Instruction
9th May, 2018
SDK
V1.0
Both iOS and Android
28th December, 2017
PACKING INFORMATION
Gift Package:
Details
Gift Box
Package Box
Carton
Quantity (D15N)
1pc per gift box
16pcs per package box
160pcs per carton
Net Weight
0.007kg
0.112kg
1.12Kg
Gross Weight
0.39Kg
0.65Kg
7.5Kg
Size
30.5 x 11 x 7.5 cm
30.5 x 11 x 7.5 cm
32 x 23 x 40 cm
Firmware Flash
1. J-LINK Programmer Kit;
2. Programming ports definition;
Please contact MINEW sales team to ask more related information if needed.
DECLARATION
The contents of this datasheet are subject to change without prior notice for further improvement.
Minew team reserves the right to explain all the terms of this datasheet.
<END>
FCC Caution：
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
