MINEW TECHNOLOGIES E4 Digital Broadcasting Device (iBeacon/Eddystone) User Manual
SHENZHEN MINEW TECHNOLOGIES CO., LTD. Digital Broadcasting Device (iBeacon/Eddystone)
User Manual
RADBEACON E4
For more information, contact
hello@radiusnetworks.com or call 202-681-9434
© 2018 Radius Networks, Inc.
Radius
Networks
Congurable Advertisements:
iBeacon
AltBeacon (Beacon ID | Reference RSSI)
Eddystone-UID
Eddystone-URL (Physical Web)
Advertisement Rate: 1Hz - 10Hz
Transmit Power: +4dBm to -20dBm
SETTINGS
Ruggedized, weatherproof beacon technology.
The RadBeacon E4 is a fully stand-alone Bluetooth 5 proximity beacon
that supports iBeaconTM, AltBeaconTM, and EddystoneTM technology. It
replaces the X4 in the Radius Networks product line. The RadBeacon
E4 is a rugged, weatherproof, and temperature-resistant proximity
beacon powered by four AA batteries. It can be installed in any location,
regardless of available power and provides proximity advertisements for
mobile applications that are compatible with iBeacon, AltBeacon, and
Eddystone standards, including the Physical WebTM.
CUSTOMER LOCATION PLATFORM
Size: 72 x 72 x 23mm
Weight: 65g
Colors: White
Form Factor: Waterproof IP65
Electrical Interface: Quad AA-battery clips
Operating Temperature: -40°C to 60°C (-40°F to 140°F)
Mounting: High-strength, durable adhesive
HARDWARE
Apple iBeaconTM: iBeacon Licensed Product
EddystoneTM: Eddystone Licensed Product
Bluetooth: Bluetooth controller subsystem
FCC: FCC Part 15
CE: EN300328, EN60950, EN62479
IC: Industry Canada
CERTIFICATIONS
Advertising Rate Battery Life
High - 100ms 18 months
Medium - 200ms 36 months
Low - 1,000ms 184 months
BATTERY LIFE
Version: Bluetooth 5
Frequency: 2.402 GHz to 2480 GHz
Transmit Power: +4dBm to -30dBm
Typical Line-of-Sight Range: 5m to 50m
Antenna: Omnidirectional PCB antenna
BLUETOOTH RADIOS
FCC WARNING
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be
installed and operated with minimum 20cm distance between the radiator your body: Use
only the supplied antenna.
IC Caution:
RSS-Gen Issue 5 March 2015"&"CNR-Gen 5e March 2015:
- English:
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) This device may not cause
interference, and (2) This device must accept any interference, including interference that
may cause undesired operation of the device.
- French:
Le présentappareilestconf orme aux CNR d' Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitationestautorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l' utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le
brouillageest susceptible d'encompromettre le fonctionnement.
Pour rester en conformité avec les lignes directrices pour l’exposition aux radiations de la ISED,
le dispositif doit être installé et opérationnel à une distance minimale de 20cm entre le radiateur et
votre corps: uniquement avec l’antenne fournie.
