MINEW TECHNOLOGIES E9 Digital Broadcasting Device (iBeacon/Eddystone) User Manual

SHENZHEN MINEW TECHNOLOGIES CO., LTD. Digital Broadcasting Device (iBeacon/Eddystone) Users Manual

User Manual

TEL: +86-755-2103 8160 EMAIL: sales@minewtech.com URL: www.minewtech.com 1
E8 TagBeacon
DearBeacon_E9
D
De
ea
ar
rB
Be
ea
ac
co
on
n
M
Mo
od
de
el
l:
:
E
E9
9
D
Da
at
ta
as
sh
he
ee
et
t
V
V1
1.
.0
0
Part #
Description
E9-6001A
204860001, DearBeacon, Bluetooth 5.0, IP67 waterproof, screw fixing, pre-flashed
MiniBeacon Plus software supports broadcasting iBeacon and Eddystone
simultaneously
TEL: +86-755-2103 8160 EMAIL: sales@minewtech.com URL: www.minewtech.com 2
E8 TagBeacon
DearBeacon_E9
The DearBeacon E9 is a new generation beacon that loaded Bluetooth 5.0 hardware platform and
MiniBeacon Plus intelligence software. E9 has a smart rotatable mechanical design for the housing that
makes the coin battery replaceable and IP67 waterproof grade combination perfectly. Moreover, E9 can be
fixed by the screw and 3M adhesive.
E9 DearBeacon advertises standard iBeacon and Eddystone (UID,URL,TLM) data packet simultaneously. The
user can configure the E9 DearBeacon via configuration app BeaconSET+ as well.
FEATURE
- IP67 waterproof;
- Replaceable coin battery 1000mAh
- Advertising iBeacon & Eddystone
- Unique MAC address (ITU)
- Bluetooth 5.0 chipset nRF52 series
- The max. 100 meters advertising distance
- Internal power ON/OFF push button
- Tough enclosure and screw fixing
APPLICATION
- Indoor location
- Retail promotion
- Activity monitoring
- Inventory tracking
ACCESSORY
- 2 pcs screw
CONFIGURATION TOOL
- BeaconSET+ (IOS & Android)
ACTIVATE E9
- Open the rotatable housing, pressing “push button” and keep holding on 3 seconds;
- The LED lights on 5 seconds and then off, the DearBeacon E9 has been activated on;
CERTIFICATION
- iBeacon MFi License (iBC-14-00582)
- FCC Regulation (FCC Part 15.)
- CE Regulations (Included EN300328/301489/60950/62479)
DearBeacon E9
TEL: +86-755-2103 8160 EMAIL: sales@minewtech.com URL: www.minewtech.com 3
E8 TagBeacon
DearBeacon_E9
ELECTRONIC PARAMETER
Item
Value
Case Color
Black
Battery Model
1 x CR2477
Operation Voltage
1.8-3.9V
Transmission Current
5.3mA (peak current)
Transmission Range
100 meters
Waterproof level
IP67
Antenna
50ohm
Size
Φ49 x 66 x 17.5mm
PARAMETER SETTING
Each E9 DearBeacon has been pre-configured in the factory before the shipment. Here below is given the
main parameters and default settings.
Type
Item
Default Settings
iBeacon
UUID (16 bytes)
E2C56DB5-DFFB-48D2-B060-D0F5A71096E0 (Proximity)
Major (2 bytes)
0
Minor (2 bytes)
0
Eddystone
Instance ID @UID
random (6 bytes)
Namespace ID @UID
random (10 bytes)
URL
https://www.minewtech.com
Base
Parameters
Measured Power
-59 (0xC5)
Radio Tx power
6 (0dBm)
Adv. Interval
9 (900mS)
Beacon ID
random, it is MAC address of beacon actually.
Beacon Name
PLUS
Connectable
yes (it is configuration mode)
Password
minew123 (Allowing only 8 characters)
Extra
Function
Reset factory
available
Power off
available
Modify password
available
Remove password
available
Update firmware
available
TEL: +86-755-2103 8160 EMAIL: sales@minewtech.com URL: www.minewtech.com 4
E8 TagBeacon
DearBeacon_E9
TECHNICAL DOCUMENT
Item
Version
File Name
Date
Datasheet
V1.0
E9 DearBeacon Datasheet
8th May, 2018
Instruction
V2.0
MiniBeaconPlus Configuration Instruction
8th May, 2018
SDK
V1.0
Both iOS and Android
28th December, 2017
PACKING INFORMATION
Details
Box
Carton
Quantity (E9)
20 pcs
200 pcs
Net Weight
0.45 Kg
4.5 Kg
Gross Weight
0.55 Kg
6.2 Kg
Size
31 x 11 x 8 cm
32 x 23 x 40 cm
Firmware Flash
1. J-LINK Programmer Kit;
2. Programming ports definition;
Please contact MINEW sales team to ask more related information if needed.
DECLARATION
The contents of this datasheet are subject to change without prior notice for further improvement. Minew
team reserves the right to explain all the terms of this datasheet.
