Shenzhen Minew Technologies Co.,Ltd. i3 MiniBeacon

Datasheet V1.2

TheMiniBeaconi3isdevelopedandproducedincludinghardwareandfirmwareallbyMINEWTechnologies.

i3isdesignedonCC2540/CC2541BLE4.0corechipsetwithhighperformanceonboardantenna,themax.

advertisingrangeis180metersintheopenspace.Moreover,i3haspacked2pcsAAbatteries,thebattery

lifetimehas5years.

‐Built‐inMiniBeaconfirmware

‐Built‐in2pcsAAbatteries,5yearslifetime

‐Bluetoothlowenergytechnologycompatible

‐Excellentlinkbudget(upto97dB)

‐Themax.180metersadvertisingdistance

‐AccuratedigitalRSSI

‐Highperformanceandlowpower8051coreMCU

‐AESsecuritycoprocessor



‐iBeaconLicense

‐FCCRegulation(FCCPart15C)

‐CERegulations(IncludedEN300328,EN301489,EN60950,EN62479)



‐Applicationforadvertisementandproximitylocation

‐SupportsbothiOS7.0+andAndroid4.3+system

‐Built‐inpairingpasswordtopreventotherschangingthesettings

‐MiniBeaconname,UUID,Major,Minorvaluesandbroadcastingintervalcanbechangedbycustomer

‐Batterycapacityintelligentdetectingandnotificationfeature

‐Supportssoftrebootfunction,nolongerrequiredtotakeoutthebatterytorebootthedevice

‐MiniBeaconserialIDcanbecustomized,itwillhelpcustomertoeasilydistinguishwhichoneiswhich

‐Placedapowerbuttonontheboardusedtoactivate/shutdownbeacondevice

‐Supportstheconnectableandnon‐connectablebroadcastingmode

‐SupportstheOADfunction

‐Publishesthefreeupgradedfirmwareregularly

‐Built‐inJTAGportforothercustomizedapplicationfirmwareasastandalonesystem

‐Thecustomer’slogocanbeprintedonthehousingifrequired

‐Customizedhousingandfirmwareserviceswillbewelcomed



Image1

TEL: +86-755-8886 8480 FAX: +86-755-2982 5342 EMAIL: sales@minewtech.com URL: www.minewtech.com

Page 3

Shenzhen Minew Technologies Co.,Ltd.

i3 MiniBeacon

Datasheet V1.2

1.ActivateMiniBeaconasbelowmethodbeforeusingdevice

1.1Usethetooltoopenthecase,takeoutthemoduleandfoundouttheBUTTON(Image2);

1.2PresstheBUTTONandkeepholding5seconds,theBlueLEDwillLighton5secondsandthenoff;

itmeansthatMiniBeaconwaswakeningupandstartstobroadcasting.



2.ShutdownMiniBeaconasbelowmethod

2.1Usethetooltoopenthecase,takeoutthemodule;

2.2PresstheBUTTONandkeepholding5seconds,theBlueLEDwillflash5timesandthenoff;

itmeansthatMiniBeaconwasonsleepingmodeandstopbroadcasting.







Ifthebatterylevellowerthan2.3V,theRedLEDwillflashatimeevery5seconds;MiniBeaconwillstop

broadcastingautomaticallyoncethebatterylevellowerto2.1volts.(Image3)



  

Image2Image3



ParametersItemDefaultValue

0xFFF1ProximityUUIDE2C56DB5‐DFFB‐48D2‐B060‐D0F5A71096E0

0xFFF2Major0x0000

0xFFF3Minor0x0000

0xFFF4MeasuredPower0xC5

0xFFF5TransmissionPower0x00(0dBm)

0xFFF6PairingPassword0x0F0FF3(thecorrespondingdecimalis987123)

0xFFF7Broadcastinginterval0x03(300mS)

0xFFF8BeaconSerialIDRandom(UniqueserialIDforbeacon)

0xFFFEConnectionMode0x00(connectablemode)

0xFFFFSoftReboot 0x0F0FF3(thecorrespondingdecimalis987123)

0x180FBatteryService0x64(100%fullcapacityofbattery)

Federal Communications Commission (FCC) Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

●Reorient or relocate the receiving antenna.

●Increase the separation between the equipment and receiver.

●Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

●Consult the dealer or an experienced radio/TV technician for help.

Warning: Changes or modifications made to this device not expressly approved by Shenzhen

Minew Technologies Co., Ltd. may void the FCC authorization to operate this device.

Note: The manufacturer is not responsible for any radio or tv interference caused by

unauthorized modifications to this equipment. Such modifications could void the user’s

authority to operate the equipment.
