MOVON MC710 SMART CONTROLLER User Manual MC710 manual indd
MOVON Corporation SMART CONTROLLER MC710 manual indd
MOVON >
Users Manual
MC710
User Manual
SMART
CONTROLLER
ENCLOSURE
1. SMART CONTROLLER 2. Micro USB charger 3. Manual
PRODUCT COMPONENTS OF SMART CONTROLLER UNIT
Indication LED
Power On / O
3.5 audio jack
Charging port
Navigation button
Play/Pause/OK button
Up / Volume Up
Down / Volume Down
Left / Previous/ REW
Right / Next/ FF
Home button
Option button
Microphone
Call End button
Mode Switching
button
Speaker
Call button
Previous (Cancel) button
-1-
CHARGING
Connect a micro USB charger to the charging port and plug it into USB
port of PC. Before using the unit, charge the battery completely.
The LED blinks in RED while charging and will be o when charging
is completed.
Low battery alarm : When the battery is low, the LED will blink in RED
three time and beep sound every 30 seconds. Once MC710 alerts, please charge
immediately, otherwise MC710 will be powered o within approx. 10 minutes.
PAIRING WITH YOUR BLUETOOTH DEVICES
TURN ON/OFF
Turning On: LED blinks in Blue
PAIRING
1) Put your device in pairing mode.
2) Press the OK button and slide power button up simultaneously, the LED blinks in BLUE rapidly.
3) Your device will nd the “Smart Controller”.
4) Accepting by pressing “Yes” or “Okay” . (PIN or passkey: 0000)
[Note] In case of unsuccessful pairing, please repeat the step 1 ~ 4.
-2-
Turning On Turning O
Auto Reconnection : MC710 will try to re-connect to the last connected devices when you turn on the MC710.
HOW TO UES
MULTIMEDIA MODE
Play/Pause: press [ ] button
Next / FF : Press [ ] button / Hold [ ] Button
Previous / REW: press [ ] button / Hold [ ] Button
Volume Up / Down: press [ ] / [ ] button
NAVIGATION MODE
Direction Key: Up / Down / Left / Right & Selection
Home button
Option button
Previous button
KEYPAD
US QWETRY Keyboard with backlighting
[Note] To convert from English to your own language, please press button or button+ button
[Note] To using the Keyboard function, your device should support Bluetooth HID pro le.
-3-
HANDS-FREE CALL
Making a call: Press button for 2 seconds
Receiving a call: Press button
Rejecting a incoming call: Press button
Ending a call: Press button
Call waiting : press two seconds and you will be connected to the waiting call.
Transferring a call : To transfer a call from your device to MC710 and vice versa, press button for 2 seconds
HOW TO SWITCH THE MODE
You can switch from Navigation Mode to Multimedia mode and vice versa by pressing button on Keypad.
-4-
STATUS INDICATION
STATUS LED STATUS BEEP
ON Blue LED light blinks twice
Pairing mode Blue LED light blinks quickly. Beeps twice continuously
Connectable mode Blue LED light blinks every 5 seconds
Connected mode Blue LED light blinks twice every 5 seconds
Active on a call Blue LED light blinks three times every 5 seconds
Receiving a call Blue LED light blinks twice every 2 seconds
Backlight on
Melody
Charging Red LED light on
Fully charged Red LED light o
Require charging Red LED light blinks three times every 30 seconds Beeps every 30 seconds
SPECIFICATIONS
Model MC710
Bluetooth version Bluetooth 2.1 + EDR
Pro le HSP, HFP, A2DP, AVRCP, HID
Coverage range 10 m
Talk time 20 Hours
Playback time 15 Hours
Stand-by Time 400 Hours
Size 44.1(W) x 106.1(H) x 11.99(D) mm
Weight 45 g
Charging time 3 Hours(MAX)
Battery Lithium polymer 3.7V 500mAh
Operating temperature -20°C ~ +55°C
Storage temperature -20°C ~ +80°C
-5-
SAFETY AND GENERAL INFORMATION
1. Please read this guidebook carefully and follow the instruction.
2. To avoid any damage or malfunction of the unit, do not drop it from high place.
3. Keep away unit from humidity, water and any other liquid. And if the unit is exposed by water, moisture and other liquid directly, then do not operate it
normally to avoid any electrical shock, explosion and damage of the unit.
4. Do not place or keep the unit near the heat sources such as direct sun light, radiators, stoves or other apparatus which produce heat. It may cause explosion,
degrade of performance and reduce battery life.
5. Do not modify, repair & disassemble unit at discretion (especially battery: it may cause an explosion.
6. Do not place the heavy objects on the unit.
7. Use only supplied and approved charger.
8. Replacement or service must be done at a quali ed service center or manufacturer.
9. Unplug this unit when unused for long period of time or during lightening storms.
[CAUTIONS] ELECTRIC SHOCK HAZARD :
The battery used in this device may present a risk of re or chemical burn if mis-treated.
FCC STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received , including interference that may cause undesired operation.
[NOTE] The manufacturer is not responsible for AzNY interference, for example RADIO or TV interference, caused by unauthorized modi cations to this equipment.
Such modi cations could void the user’s authority to operate the equipment.
FCC WARNING
This equipment may generate or use radio frequency energy. Changes or modi cations to this equipment may cause harmful interference unless the
modi cations are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or
modi cation is made.
[NOTE] This equipment has been tested and found to comply with the limits for a Class B digital device, purchant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
-6-
If this equipment does cause harmful interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit di erent from that to which the receiver is connected.
Consult the dealer or an experiencedradio/TV technician for help.”
FCC RF Radiation Exposure Statement
1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
EU
This product is CE marked according to the provision of the R&TTE Directive (99/5/EC).
Here by MOVON Corporation, declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/
EC. Please note that this product uses radio frequency bands not harmonized within EU. Within the EU this product is intended to be used in Austria, Belgium,
Denmark, Finland, France,Germany, Greece, Ireland, Italy, Luxembourg, The Netherlands, Portugal, Spain, Sweden, United Kingdom and within EFTA in Iceland,
Norway and Switzerland. Bluetooth is a trademark owned by the Bluetooth SIG, Inc.
WARRANTY
The condition of this warranty and our responsibilities under this warranty are as follows: Supplier’s warranty is non-transferable. And this warranty is limited to
the original purchaser only.
You must be able to prove the date of original purchase of the unit with a dated receipt.
The warranty is not applicable if the product has been subject to physical abuse, improper installation, modi cation or repair by unauthorized third party.
The responsibility of supplier’s products shall be limited to the repair or replacement of the product at it’s sole discretion.
Speci cally exempt from any warranty are limited-life consumable components subject to normal wear and tear such as batteries, decorates and other
accessories.
A supplier will not take any responsibility if the failure of the unit has resulted from accident, abuse,misuse or any unauthorized repair, modi cation or
disassemble.
Modi cation and repair of the unit should be done by authorized and quali ed service personnel, center or returned to the manufacturer.
This warranty gives you speci c legal rights and you may also have other rights which vary under local laws.
-7-
WEEE SYMBOL INFORMATION
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates
that it should not be disposed with other household wastes at the end of its working life.
To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it
responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product or their local government o ce, for details of where and how they can take
this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial
wastes for disposal.
[IMPORTANT NOTE] To comply with RF exposure requirements, this device may not be co-located
with any other transmitter or antenna.
