Owner's Manual

ZV420MW8

IGITAL

IDEO

ISC

ECORDER

WITH

IDEO

ASSETTE

ECORDER

THANK YOU FOR CHOOSING MAGNAVOX.

NEED HELP FAST?

READ YOUR QUICK GUIDE AND/OR OWNER'S MANUAL FIRST FOR QUICK TIPS THAT MAKE USING

YOUR MAGNAVOX PRODUCT MORE ENJOYABLE.

IF YOU HAVE READ YOUR INSTRUCTIONS AND STILL NEED ASSISTANCE,

YOU MAY ACCESS OUR ONLINE HELP AT HTTP://WWW.FUNAI-CORP.COM

OR CALL 1-800-605-8610 WHILE WITH YOUR PRODUCT.

INSTRUCCIONES EN ESPAÑOL INCLUIDAS.

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

2EN2EN

PRECAUTIONS

This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device,

due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS

RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE INTO BEAM.

LOCATION: INSIDE, NEAR THE DECK MECHANISM.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE.

The lightning flash with arrowhead symbol, within an

equilateral triangle, is intended to alert the user to the

presence of uninsulated “dangerous voltage” within the

product’s enclosure that may be of sufficient magnitude

to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in the

literature accompanying the appliance.

3EN 3EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

PRECAUTIONS

Important Safeguards

1. Read Instructions - All the safety and operating

instructions should be read before the appliance is

operated.

2. Retain Instructions- The safety and operating instructions

should be retained for future reference.

3. Heed Warnings - All warnings on the appliance and in

the operating instructions should be adhered to.

4. Follow Instructions - All operating and use instructions

should be followed.

5. Cleaning - Unplug this product from the wall outlet

before cleaning. Do not use liquid cleaners or aerosol

cleaners. Use a damp cloth for cleaning.

EXCEPTION: A product that is meant for uninterrupted

service and, that for some specific reason, such as the

possibility of the loss of an authorization code for a

CATV converter, is not intended to be unplugged by the

user for cleaning or any other purpose, may exclude the

reference to unplugging the appliance in the cleaning

description otherwise required in item 5.

6. Attachments - Do not use attachments not

recommended by the product manufacturer as they may

cause hazards.

7. Water and Moisture- Do not use this product near water,

for example, near a bath tub, wash bowl, kitchen sink,

or laundry tub, in a wet basement, or near a swimming

pool, and the like.

8. Accessories - Do not place this product on an unstable

cart, stand, tripod, bracket, or table. The product may

fall, causing serious injury to a child or adult, and

serious damage to the appliance. Use only with a cart,

stand, tripod, bracket, or table recommended by the

manufacturer, or sold with the product. Any mounting

of the appliance should follow the manufacturer's

instructions and should use a

mounting accessory recommended

by the manufacturer. An appliance

and cart combination should be

moved with care. Quick stops,

excessive force, and uneven surfaces

may cause the appliance and cart

combination to overturn.

9. Ventilation - Slots and openings in the cabinet are

provided for ventilation and to ensure reliable operation

of the product and to protect it from overheating,

and these openings must not be blocked or covered.

The openings should never be blocked by placing the

product on a bed, sofa, rug, or other similar surface. This

product should not be placed in a built-in installation

such as a bookcase or rack unless proper ventilation is

provided or the manufacturer's instructions have been

adhered to.

10. Power Sources - This product should be operated only

from the type of power source indicated on the marking

label. If you are not sure of the type of power supply

to your home, consult your appliance dealer or local

power company. For products intended to operate from

battery power, or other sources, refer to the operating

instructions.

11. Grounding or Polarization - This product is equipped

with a polarized alternating-current line plug (a plug

having one blade wider than the other). This plug will

fit into the power outlet only one way. This is a safety

feature. If you are unable to insert the plug fully into the

outlet, try reversing the plug. If the plug should still fail

to fit, contact your electrician to replace your obsolete

outlet. Do not defeat the safety purpose of the polarized

plug.

12. Power Cord Protection - Power supply cords should be

routed so that they are not likely to be walked on or

pinched by items placed upon or against them, paying

particular attention to cords at plugs, convenience

receptacles, and the point where they exit from the

appliance.

13. Lightning - For added protection for this product during

a lightning storm, or when it is left unattended and

unused for long periods of time, unplug it from the wall

outlet. This will prevent damage to the product due to

lightning and power-line surges.

14. Power Lines - An outside antenna system should not be

located in the vicinity of overhead power lines or other

electric light or power circuits, or where it can fall into

such power lines or circuits. When installing an outside

antenna system, extreme care should be taken to keep

from touching such power lines or circuits as contact

with them might be fatal.

15. Overloading - Do not overload wall outlets and extension

cords as this can result in a risk of fire or electric shock.

16. Object and Liquid Entry - Never push objects of any kind

into this product through any openings as they may

touch dangerous voltage points or short-out parts that

could result in a fire or electric shock. Never spill liquid of

any kind on the product.

17. Servicing - Do not attempt to service this product yourself

as opening or removing covers may expose you to

dangerous voltage or other hazards. Refer all servicing to

qualified service personnel.

18. Damage Requiring Service - Unplug this product from

the wall outlet and refer servicing to qualified service

personnel under the following conditions:

a. When the power-supply cord or plug is damaged.

b. If liquid has been spilled, or objects have fallen into the

product.

c. If the product has been exposed to rain or water.

d. If the product does not operate normally by following

the operating instructions. Adjust only those controls

that are covered by the operating instructions as an

improper adjustment of other controls may result in

damage and will often require extensive work by a

qualified technician to restore the product to its normal

operation.

e. If the product has been dropped or damaged in any way.

f. When the product exhibits a distinct change in

performance this indicates a need for service.

19. Replacement Parts - When replacement parts are

required, be sure the service technician has used

replacement parts specified by the manufacturer or

have the same characteristics as the original part.

Unauthorized substitutions may result in fire, electric

shock or other hazards.

20. Safety Check - Upon completion of any service or repairs

to this product, ask the service technician to perform

safety checks to determine that the product is in proper

operating condition.

21. Heat - This product should be situated away from heat

sources such as radiators, heat registers, stoves, or other

products (including amplifiers) that produce heat.

4EN4EN

PRECAUTIONS

Unauthorized copying, broadcasting, public performance

and lending of discs are prohibited.

This product incorporates copyright protection

technology that is protected by U.S. patents and other

intellectual property rights. Use of this copyright

protection technology must be authorized by

Macrovision, and is intended for home and other

limited viewing uses only unless otherwise authorized

by Macrovision. Reverse engineering or disassembly is

prohibited.

Moisture condensation may occur inside the unit

when it is moved from a cold place to a warm place or

after heating a cold room or under conditions of high

humidity. Do not use this unit at least for 2 hours until its

inside gets dry.

Consumers should note that not all high definition

television sets are fully compatible with this product

and may cause artifacts to be displayed in the picture.

In case of picture problems with 525 (480) progressive

scan output, it is recommended that the user switch the

connection to the ‘standard definition’ output. If there

are questions regarding your TV set compatibility with

this 525p (480p) DVD player, please contact our customer

service center.

For safety and optimum performance of this unit:

• Install the unit in a horizontal and stable position. Do

not place anything directly on top of the unit. Do not

place the unit directly on top of the TV.

• Shield it from direct sunlight and keep it away from

devices of intense heat. Avoid dusty or humid places.

Avoid places with insufficient ventilation for proper

heat dissipation. Do not block the ventilation holes on

the sides of the unit. Avoid locations subject to strong

vibration or strong magnetic fields.

• Do not handle the power cord with wet hands.

• Do not pull on the power cord when disconnecting it

from AC outlet. Grasp it by the plug.

• If, by accident, water is spilled on this unit, unplug

the power cord immediately and take the unit to our

Authorized Service Center for servicing.

Supplied Accessories

remote control (NB552UD) with batteries (AAAx2)

RCA audio/video cables (WPZ0102TM015/WPZ0102LTE01)

owner's manual (1VMN23495)

quick guide (1VMN23496)

Installation Location

Avoid the Hazards of Electrical Shock and Fire

Moisture Condensation Warning

About Copyright

Notice for Progressive Scan Output

5EN 5EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

PRECAUTIONS

Servicing

• Please refer to relevant topics on “TROUBLESHOOTING”

on pages 82-86 before returning the product.

• If this unit becomes inoperative, do not try to correct

the problem by yourself. There are no user-serviceable

parts inside. Turn off, unplug the power plug and

please call our help line mentioned on the front page

to locate an Authorized Service Center.

Cleaning the cabinet

• Use a soft cloth slightly moistened with a mild

detergent solution. Do not use a solution containing

alcohol, spirits, ammonia or abrasive.

Cleaning discs

• When a disc becomes dirty, clean it with a cleaning

cloth. Wipe the disc from the center to out. Do not

wipe in a circular motion.

• Do not use solvents such as benzine, thinner,

commercially available cleaners, detergent, abrasive

cleaning agents or antistatic spray intended for analog

records.

Cleaning the disc lens

• If this unit still does not perform properly

although you refer to the relevant sections and to

“TROUBLESHOOTING” in this owner's manual, the laser

optical pickup unit may be dirty. Consult your dealer

or an Authorized Service Center for inspection and

cleaning of the laser optical pickup unit.

Disc handling

• Handle the discs so that fingerprints and dust do not

adhere to the surfaces of the discs.

• Always store the disc in its protective case when it is

not used.

Auto head cleaning

• Automatically cleans video heads as you insert or

remove a cassette, so you can see a clear picture.

• Playback picture may become blurred or interrupted

while the TV program reception is clear. Dirt

accumulated on the video heads after a long period of

use, or the usage of rental or worn tapes can cause this

problem. If a streaky or snowy picture appears during

playback, the video heads in your unit may need to be

cleaned.

Maintenance

1. Please visit your local Audio/Video store and purchase a

good quality VHS video head cleaner.

2. If a video head cleaner does not solve the problem,

please consult your dealer or an Authorized Service

Center.

Note

• Remember to read the instructions along with the video

head cleaner before use.

• Clean video heads only when problems occur.

IR signal check

If the remote control does not work properly, you can test

if the remote control sends out the infrared signal with

AM radio or a digital camera (including built-in camera

of cellular phone). It will help to define the cause of

malfunction.

• With an AM radio:

Tune an AM radio to a station with no

broadcasting. Press a button on remote

control toward the radio. Sound will be

fluttering when you press any key and the

radio receives the signal. This means the

remote control is working.

• With a digital camera (including built-in

camera of cellular phone):

Direct a digital camera to remote control,

press and hold a button on remote control. If

infrared light appears through digital camera,

the remote control is working.

6EN6EN

CONTENTS

Introduction

PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Symbols Used in this Owner's Manual . . . . . . . . . . . . . . .7

FUNCTIONAL OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . 8

Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Front Panel Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Connections

CONNECTION TO AN EXTERNAL TUNER. . . . . . . . . . . 13

SETTINGS FOR THE VIDEO INPUT. . . . . . . . . . . . . . . . . 14

CONNECTION TO A TV. . . . . . . . . . . . . . . . . . . . . . . . . . . 15

CONNECTION TO AN AUDIO SYSTEM . . . . . . . . . . . . . 16

Basic Setup

THE VCR / DVD RECORDER SWITCHING . . . . . . . . . . . 17

GUIDE TO ON-SCREEN DISPLAYS AND MENUS . . . . 18

On-Screen Display / Menu . . . . . . . . . . . . . . . . . . . . . . . . . 18

Main Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

INITIAL SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

SETTING THE CLOCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Clock Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Recording

INFORMATION ON DVD RECORDING . . . . . . . . . . . . . 22

BEFORE RECORDING . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Make Recording Compatible . . . . . . . . . . . . . . . . . . . . . . 23

Setting for Auto Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . 23

BASIC RECORDING &

ONE-TOUCH TIMER RECORDING . . . . . . . . . . . . . . . . . 24

TIMER RECORDING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Hints for Timer Recording . . . . . . . . . . . . . . . . . . . . . . . . . 29

SATELLITE LINK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

OVERWRITING UNNECESSARY TITLE . . . . . . . . . . . . . 32

Overwriting from the Beginning of the Title. . . . . . . . 32

Overwriting in the Middle of the Title . . . . . . . . . . . . . . 32

Hints for Overwriting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

EXTERNAL DEVICE RECORDING . . . . . . . . . . . . . . . . . . 34

Connection to an External Device. . . . . . . . . . . . . . . . . . 34

Recording from an External Device . . . . . . . . . . . . . . . . 35

SETTING A DISC TO PROTECT . . . . . . . . . . . . . . . . . . . . 36

PLAYING THE DISCS IN OTHER DVD PLAYERS . . . . . 37

Finalizing a Disc. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Auto Finalizing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

DUBBING MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Playback

INFORMATION ON PLAYBACK . . . . . . . . . . . . . . . . . . . 41

BASIC PLAYBACK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Direct Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Playback from the Title List . . . . . . . . . . . . . . . . . . . . . . . . 43

Playing Back an Audio CD and

a CD-RW/-R with MP3 Files . . . . . . . . . . . . . . . . . . . . . . . . 45

Using the Title / Disc Menu . . . . . . . . . . . . . . . . . . . . . . . . 46

Pause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

SPECIAL PLAYBACK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Resume Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Fast Forward / Fast Reverse Playback . . . . . . . . . . . . . . 47

Skipping TV Commercials During Playback. . . . . . . . . 47

Rapid Playback. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Step by Step Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Slow Forward / Slow Reverse Playback. . . . . . . . . . . . . 48

Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Marker Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

SEARCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Title / Chapter Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Track Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Time Search. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

REPEAT / RANDOM / PROGRAM PLAYBACK . . . . . . . 52

Repeat Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Random Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Program Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

SELECTING THE FORMAT OF AUDIO AND VIDEO . . 54

Switching Subtitles. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Switching Audio Soundtrack . . . . . . . . . . . . . . . . . . . . . . 54

Switching Virtual Surround System . . . . . . . . . . . . . . . . 55

Switching Camera Angles . . . . . . . . . . . . . . . . . . . . . . . . . 55

Reducing Block Noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Editing

INFORMATION ON DISC EDITING. . . . . . . . . . . . . . . . . 56

Guide to a Title List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Editing Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

EDITING DISCS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Deleting Titles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Putting Names on Titles . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Setting Chapter Marks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Clearing Chapter Marks . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Hiding Chapters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Setting Pictures for Thumbnails. . . . . . . . . . . . . . . . . . . . 63

Dividing a Title. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Putting Name on Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Setting or Releasing Disc Protect . . . . . . . . . . . . . . . . . . 66

Erasing Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Making Edits Compatible. . . . . . . . . . . . . . . . . . . . . . . . . . 68

Function Setup

LIST OF SETTINGS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

SETUPS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Reset All . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

VCR Functions

VCR FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Recording. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

One-touch Timer Recording (OTR) . . . . . . . . . . . . . . . . . 80

Index Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Time Search. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Other Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Others

TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Frequently Asked Questions. . . . . . . . . . . . . . . . . . . . . . . 86

LANGUAGE CODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

GLOSSARY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Español

ESPAÑOL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . Back cover

7EN 7EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

FEATURES

Symbol

For Recording, Playing Back, and Editing

For Playback only

Description

Description refers to DVD+RW

Description refers to DVD+R

Description refers to audio CD

Description refers to video CD with PBC function

Description refers to video CD without PBC

function

Description refers to CD-RW/-R with MP3 les

8EN8EN

FUNCTIONAL OVERVIEW

1 2* 3

6 5 422 21 13 11 1012 9 8* 72019 18 17 16 15 14

Front Panel

(*) The unit can also be turned on by pressing these buttons or insert a cassette tape.

1. Cassette compartment (VCR)

Insert a cassette tape here.

2. OPEN/CLOSE A button (DVD)*

Press to open or close the disc tray.

3. Disc tray (DVD)

Place a disc when it is open.

4. AUDIO input jacks (E2) (DVD/VCR)

Use to connect external device with a RCA audio

cable.

5. VIDEO input jack (E2) (DVD/VCR)

Use to connect external device with a RCA video

cable.

6. S-VIDEO input jack (E2) (DVD/VCR)

Use to connect the S-video output of external device

with an S-video cable.

7. RECORD I button (DVD)

Press once to start recording.

Press repeatedly to start the one-touch timer

recording.

8. PLAY B button (DVD)*

Press to start or resume playback.

9. STOP C button (DVD)

Press to stop playback or recording.

Press to stop the proceeding timer recording in DVD.

10. DVD indicator

Lights up when the DVD output mode is selected.

11. SOURCE button (DVD/VCR)

Press to select the component you wish to operate.

12. VCR indicator

Lights up when the VCR output mode is selected.

13. D.DUBBING button (DVD/VCR)

Press to start VCR to DVD (DVD to VCR) duplication

which you set in the main menu.

14. TRACKING L / K buttons (VCR)

Press to adjust the tracking during playback or in slow

motion of the cassette tape.

While playback is in still mode, you can adjust the

picture blurred vertically.

15. Display

Refer to “Front Panel Display” on page 12.

16. Infrared sensor window (DVD/VCR)

Receive signals from your remote control so that you

can control the unit from a distance.

17. RECORD I button (VCR)

Press once to start a recording. Press repeatedly to

start the one-touch timer recording.

18. PLAY B button (VCR)

Press to start playback.

19. STOP C / EJECT A button (VCR)

EJECT A button

When the unit is in stop mode, press to remove the

cassette tape from the cassette compartment.

STOP C button

Press to stop cassette tape playback or recording.

Press to stop the proceeding timer recording in VCR.

20. F.FWD D button (VCR)

Press to rapidly advance the cassette tape, or view the

picture rapidly in forward during playback (forward

search).

21. REW E button (VCR)

Press to rewind the cassette tape, or to view the

picture rapidly in reverse during playback (rewind

search).

22. STANDBY-ON

button (DVD/VCR)

Press to turn on and off the unit.

23. POWER ON indicator (DVD/VCR)

Red LED lights up when power is on.

9EN 9EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

Note

• Do not touch the inner pins of the jacks on the rear

panel. Electrostatic discharge may cause permanent

damage to the unit.

DVD

DIGITAL

AUDIO OUT

AUDIO

OUT

S-VIDEO

OUT IN

COAXIAL

/CB

/CR

S-VIDEO IN --- AUDI O --- OU T

I N --- VIDEO --- OUT

COMPONENT

VIDEO OUT

DVD/VCR

26810 7 5 349

FUNCTIONAL OVERVIEW

Rear Panel

1. AC Power Cord (DVD/VCR)

Connect to a standard AC outlet to supply power to this

unit.

2. AUDIO OUT jacks (DVD/VCR)

Use to connect a TV monitor, AV receiver or other

device with a RCA audio cable.

3. VIDEO OUT jack (DVD/VCR)

Use to connect a TV monitor, AV receiver or other

device with a RCA video cable.

4. VIDEO IN jack (E1) (DVD/VCR)

Use to connect external device with a RCA video

cable.

5. AUDIO IN jacks (E1) (DVD/VCR)

Use to connect external device with a RCA audio

cable.

6. S-VIDEO IN jack (E1) (DVD/VCR)

Use to connect the S-video output of external device

with an S-video cable.

7. COMPONENT VIDEO OUT jacks (DVD only)

Use to connect a TV monitor with component video

inputs with a component video cable.

8. S-VIDEO OUT jack (DVD only)

Use to connect the S-video input of a TV monitor, AV

receiver or other device with an S-video cable.

9. AUDIO OUT jacks (DVD only)

Use to connect a TV monitor, AV receiver or other

device with a RCA audio cable.

10. COAXIAL DIGITAL AUDIO OUT jack (DVD only)

Use to connect an AV receiver, Dolby Digital decoder

or other device with a coaxial digital input jack with a

digital coaxial cable.

10 EN10 EN

FUNCTIONAL OVERVIEW

Installing the Batteries in the Remote Control

Keep in mind the following when using the remote

control:

• Make sure that there are no obstacles between the remote

control and the infrared sensor window on the unit.

• Remote operation may become unreliable if strong

sunlight or fluorescent light is shining on the infrared

sensor window of the unit.

• Remote control for different devices can interfere with

each other. Avoid using remote control for other device

located close to the unit.

• Replace the batteries when you notice a fall off in the

operating range of the remote control.

• The maximum operable ranges from the unit are as

follows.

- Line of sight: approx. 23 feet (7m)

- Either side of the center:

approx. 16 feet (5m) within 30°

- Above: approx. 16 feet (5m) within 15°

- Below: approx. 10 feet (3m) within 30°

Install the batteries (AAAx2) matching the polarity

indicated inside battery compartment of the remote

control.

Note

Incorrect use of batteries can result in hazards such as

leakage and bursting. Please observe the following:

• Do not mix new and old batteries together.

• Do not use different kinds of batteries together.

Although they may look similar, different batteries

may have different voltages.

• Make sure that the + and - ends of each battery

match the indications in the battery compartment.

• Remove batteries from battery compartment that is

not going to be used for a month or more.

• When disposing of used batteries, please comply

with governmental regulations or environmental

public instruction’s rules that apply in your country

or area.

• Do not recharge, short-circuit, heat, burn or

disassemble batteries.

16feet (5m)

30˚

16feet (5m)

30˚

23feet (7m)

Remote Control

Using a Remote Control

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

NB552

11EN 11EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

FUNCTIONAL OVERVIEW

1. DISPLAY button (DVD/VCR)

Press to display the display menu on or off.

2. TIMER SET button (DVD/VCR)

Press to set the unit in the timer standby mode. In

the timer standby mode, press to cancel the mode

and to turn the unit on.

3. SOURCE button (DVD/VCR)

Press to select the appropriate input.

4. Number/Character buttons (DVD/VCR)

• Press to select a title/chapter/track/file on display.

• Press to enter values for the settings in the main menu.

• Press to enter title names.

• Press to start the index/time search in VCR mode.

5. TIMER button (DVD/VCR)

Press to display the timer programming list.

6. DISC MENU button (DVD)

Press to display the disc menu.

7. OK button (DVD/VCR)

Press to confirm or select menu items.

8. TITLE button (DVD)

Press to display the title list.

9. PREV H button (DVD)

• During playback, press to return to the beginning of

the current chapter, track or file.

• When playback is paused, press to play back reverse

step by step.

10. REW E button (DVD/VCR)

DVD mode:

• During playback, press to fast reverse.

• When playback is paused, press to play back slow

reverse.

VCR mode:

• During playback, press to rewind the cassette tape

or to view the picture rapidly in reverse.

11. PAUSE F button (DVD/VCR)

Press to pause playback or recording.

12. TRACKING / buttons (VCR)

• Press to adjust the tracking during playback or in

slow motion of the cassette tape.

• While playback is in still mode, you can adjust the

picture blurred vertically.

13. VCR button

• Press to select the VCR output mode.

14. REC MODE button (DVD/VCR)

Press to switch the recording mode.

15. REC I button (DVD/VCR)

• Press once to start a recording.

• Press repeatedly to start the one-touch timer recording.

16. CM SKIP button (DVD)

During playback, press to skip 30 seconds.

17. SEARCH button (VCR)

Press to call up the index or time search menu.

18. STANDBY-ON

y button (DVD/VCR)

Press to turn the unit on and off.

19. OPEN/CLOSE A button (DVD/VCR)

DVD mode:

Press to open or close the disc tray.

VCR mode:

Press to remove the cassette tape from the cassette

compartment.

20. CLEAR button (DVD/VCR)

DVD mode:

Press to clear the password once entered or to cancel

the programming for CD or to clear the selecting

marker number in the edit menu, etc.

VCR mode:

Press to reset the tape counter.

21. SETUP button (DVD/VCR)

• Press to display the main menu.

• During DVD playback, press and hold for more than

3 seconds to switch the progressive scanning mode

to the interlace mode.

22. Cursor K / L / { / B buttons (DVD/VCR)

Press to select items or settings.

23. RETURN button (DVD/VCR)

Press to return to the previously displayed menu screen.

24. PLAY B button (DVD/VCR)

Press to start or resume playback.

25. NEXT G button (DVD)

• During playback, press to skip to the next chapter,

track or file.

• When playback is paused, press to play back for-

ward step by step.

26. FFW D button (DVD/VCR)

DVD mode:

• During playback, press to play back fast forward.

• When playback is paused, press to play back slow

forward.

VCR mode:

• During playback, press to rapidly advance the

cassette tape or view the picture rapidly in forward.

• When playback is paused, press to view the cassette

tape in slow motion.

27. STOP C button (DVD/VCR)

• Press to stop playback or recording.

• Press to exit from the title list.

28. DVD button

• Press to select the DVD output mode.

29. AUDIO button (DVD/VCR)

DVD mode:

• During playback, press to display the audio menu.

VCR mode:

• During playback a HiFi video tape, press to change

the audio out setting HiFi and mono.

30. D.DUBBING button (DVD/VCR)

Press to start VCR to DVD (DVD to VCR) duplication

which you set in the main menu.

31. RAPID PLAY button (DVD)

During playback, press to playback in a slightly fast-

er/slower mode with keeping the audio quality.

Note

• If you turn off this unit, [OPEN/CLOSE A] on the remote

control is not available.

Be sure to use [OPEN/CLOSE A] or [STOP C / EJECT A]

on the unit.

12 EN12 EN

Appears when data is being

written on a disc.

Appears when a disc is loaded

on the disc tray.

Appears when the PBC function

is activated. (Video CD playback

only. Refer to page 41.)

Appears when the disc tray is

closing.

Appears when the disc tray is

opening.

Display Message

FUNCTIONAL OVERVIEW

BS CS DR CD

VCR

HDDDB

DVD

Front Panel Display

: Appears in the afternoon with

the clock display.

2. Title / track / file and chapter mark

: Appears when indicating a

title / track / file number.

: Appears when indicating a

chapter number.

3. Current status of the unit

: Appears when playback is

paused.

: Appears when playing back a

disc.

: Appears when the timer

programming or OTR has

been set and is proceeding.

: Flashes when all timer

recordings have been

finished.

: Appears during recording

process.

: Flashes when a recording

pauses.

: Appears when this unit is in

DVD output mode and a disc

is in the unit.

: Appears during duplication

process.

: Appears when this unit is in

VCR output mode and a

cassette tape is in the unit.

: Appears during duplication

process.

VCR

: Appears when this unit is in

VCR output mode.

: Appears when the timer

recording is proceeding in VCR.

: Appears when VCR is in the

timer recording standby mode.

: Flashes when a program

cannot be performed for

some reasons.

DVD

: Appears when this unit is in

DVD output mode.

: Appears when the timer

recording is proceeding in

DVD.

: Appears when DVD is in the

timer recording standby

mode.

: Flashes when a program

cannot be performed for

some reasons.

: Appears during VCR to DVD

duplication process.

: Appears during DVD to VCR

duplication process.

4. Displays the following

• Elapsed playback time

• Current title / chapter / track /file

number

• Recording time / remaining time

• Clock

• Selected external input position

• Remaining time for one-touch

timer recording

13EN 13EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

rear of your TV

rear of this unit

connect

CONNECTION TO AN EXTERNAL TUNER

Supplied cables used in this connection are as follows:

• RCA audio cable (L/R) x 1

• RCA video cable x 1

Please purchase the rest of the necessary cables at your local store.

Note to CATV system installer

• This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the National Electrical

Code, which provides guidelines for proper grounding - in particular, specifying that the cable ground shall be

connected to the grounding system of the building, as close to the point of cable entry as possible.

OUT IN

14 EN14 EN

SETTINGS FOR THE VIDEO INPUT

You must let the unit know which video input jack you are using before making a recording.

1 Press [SETUP] and use [K / L] to

select “General Setting”, then press

[OK].

“General Setting” menu will appear.

2 Use [K / L] to select “Video”, then

press [OK].

Submenu will appear.

3 Use [K / L] to select “Video Input”,

then press [OK].

4 Use [K / L] to select desired external

input position, then press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Progressive Scan

TV Aspect

Video Input

E1 (Rear)

E2 (Front)

5 Use [K / L] to select the input jack

type to connect, then press [OK].

If you want to use VIDEO IN jack, select “Video

In”.

If you want to use S-VIDEO IN jack, select

“S-Video In”.

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Progressive Scan

TV Aspect

Video Input

E1 (Rear)

E2 (Front)

E1 (Rear)

Video In

S-Video In

6 Press [SETUP] to exit.

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

NB552

SETUP

15EN 15EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

CONNECTION TO A TV

S-VIDEO IN

DVD

DIGITAL

AUDIO OUT

AUDIO

OUT

S-VIDEO

OUT

COAXIAL

/CB

/CR

COMPONENT

VIDEO OUT

16 EN16 EN

CONNECTION TO AN AUDIO SYSTEM

Note

• The DVD AUDIO OUT and DIGITAL AUDIO OUT jacks are only useful in DVD mode.

• The audio source on a disc in a Dolby Digital multi channel surround format cannot be recorded as digital sound

by an MD or DAT deck.

• By connecting this unit to a Dolby Digital decoder, you can enjoy high-quality Dolby Digital multi channel

surround sound as heard in the movie theaters.

• Playing back a DVD using incorrect settings may generate noise distortion and may also damage the speakers.

Setting Setup >General Setting >Playback >Disc Audio >

Dolby Digital

Connection

If output is Dolby Digital encoded audio, connect to a Dolby

Digital decoder. Stream

Connecting to an MD deck or DAT deck. PCM

If not connected to any external devices. PCM

* To complete these settings, refer to page 73.

Supplied cables used in this connection are as follows:

• RCA audio cable (L/R) x 1

Please purchase the rest of the necessary cables at your local store.

DVD

DIGITAL

AUDIO OUT

AUDIO

OUT

S-VIDEO

OUT IN

COAXIAL

/CB

/CR

S-VIDEO IN --- AUDIO --- OU T

IN --- VI D EO --- OU T

COMPONENT

VIDEO OUT

DVD/VCR

AUDIO IN

S-VIDEO IN --- AUD IO --- OUT

I N --- V ID EO --- OU T

DVD/VCR

DVD

DIGITAL

AUDIO OUT

AUDIO

OUT

S-VIDEO

OUT

COAXIAL

/CB

/CR

COMPONENT

VIDEO OUT

stereo system audio

analog audio

input jacks

RCA audio cable

AUDIO OUT

2 Channel Analog Audio Connection

Digital Audio Connection

Dolby Digital decoder,

MD deck or DAT deck

DVD

DIGITAL

AUDIO OUT

AUDIO

OUT

S-VIDEO

OUT IN

COAXIAL

/CB

/CR

S-VIDEO IN --- AUDIO --- OUT

IN --- VID E O --- OUT

COMPONENT

VIDEO OUT

DVD/VCR

DIGITAL

AUDIO OUT

AUDIO

OUT

S-VIDEO

OUT

COAXIAL

/CB

/CR

COMPONENT

VIDEO OUT

17EN 17EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

Because this product is a combination of a VCR and a DVD recorder, you must select first which component you wish

to operate with [SOURCE].

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDI OREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

iji

DIS PLAY OPEN/CLOSE

NB552

DVD indicator

VCR indicator

SOURCE button VCR button

DVD button

DVD mode

Press [DVD] on the remote control.

(Verify that the DVD indicator is lit.)

VCR mode

Press [VCR] on the remote control.

(Verify that the VCR indicator is lit.)

Note

• You cannot switch to another mode (DVD or VCR) during in the timer-standby mode.

THE VCR / DVD RECORDER SWITCHING

18 EN18 EN

SP(2Hr) 1:53

5 15122

* This is an example screen only for explanation.

1. Indicates a disc type and format mode.

2. Indicates the selected external input position.

3. Indicates a recording mode and possible recording

time left.

4. Indicates an operation status.

5. Each icon means:

: Search

: Audio

: Subtitle

: Angle

: Repeat

: Marker

: Noise Reduction

: Zoom

: Surround

6. Indicates the current title number/total number of

titles, the current chapter number/total number of

chapters, and time lapse of the current title playback/

total duration of the title.

This unit uses the following on-screen displays and menus to guide you to the easy operations.

The on-screen displays give you the information on the loaded disc, the disc/file in playback, etc.

The menus allow you to change the various kinds of settings for playing back, recording, or editing to suite your preference.

On-Screen Display / Menu

GUIDE TO ON-SCREEN DISPLAYS AND MENUS

Disc Information / Menu

The on-screen display changes in the following order

as you press [DISPLAY].

OFF

Disc Information/Menu

Title Name Information

(only when DVD+RW/DVD+R/DVD-RW/DVD-R

is in playback)

File Name Information

(only when a CD with MP3 files is in playback)

Title Name Information

Title Name

My Title

File Name Information

File Name

My File

1. Displays title/file name.

Title/File Name Information

DVD mode

0:00:00 HIFISP

12:00AM

4 53

1. Indicates current video status.

2. Indicates the current time.

3. Indicates a recording or playing back mode.

4. Indicates a tape counter.

5. Audio status of the current cassette tape.

VCR mode

Note

• This is an example screen only for explanation.

Displayed items are depending on the disc you

inserted.

19EN 19EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

1. Edit Disc Name:

Allows you to rename the disc.

2. Erase Disc: (DVD+RW/DVD-RW only)

Allows you to erase all contents in the disc and format it.

3. Make Edits Compatible: (DVD+RW only)

Allows you to memorize the editing status on the disc if

you have added or deleted chapters, or made chapters

hidden on this unit, and to effect it when playing back

on the other unit.

Finalize: (DVD+R/DVD-RW/-R only)

Allows you to finalize a disc containing recorded titles.

4. Disc Protect :

Allows you to protect a disc from accidental editing or

recording.

5. Random Play:

Allows you to activate the random playback feature.

6. Program Play: (audio CD/video CD only)

Allows you to activate the program playback feature.

7. PBC (Video CD only):

Allows you to select images or information on the menu

screen by activating PBC (playback control) function.

Disc Edit

Edit Disc Name

Erase Disc

Make Edits Compatible

Disc Protect OFF ON

CD Playback Mode

Random Play

Program Play

PBC (Video CD only)

Disc Edit

Edit Disc Name

Finalize

Disc Protect OFF ON

GUIDE TO ON-SCREEN DISPLAYS AND MENUS

Main Menu

Press [SETUP] to display the main menu. Then use

[K / L] to select a menu and press [OK] to display the

menu. These menus provide entries to all main functions

of the unit.

Disc Edit / CD Playback Mode

Disc Edit

Edit Disc Name

Erase Disc

Finalize

Disc Protect OFF ON

1. General Setting:

To go to general setting menu.

2. Timer Programming:

To program a timer recording.

3. Title List:

To call up the title list.

4. Disc Edit:

To set up the DVD disc setting.

5. CD Playback Mode:

To set up the CD playback setting.

• “CD Playback Mode” is available only when an audio

CD, a video CD, a CD-RW/-R with MP3 files is inserted

into the unit.

Setup

Timer Programming

Title List

Disc Edit

CD Playback Mode

General Setting

General Setting Menu

General Setting

Playback

Display

Video

Recording

Clock

Reset All

1. Playback:

To set up the unit to play back discs as you prefer.

2. Display:

To set up the OSD screen as you prefer.

3. Video:

To set up the video setting.

4. Recording:

To set up the unit to record to discs as you prefer.

5. Clock:

To set up the clock of the unit as you need.

6. Reset All:

To reset the setting to the factory default.

20 EN20 EN

INITIAL SETTING

You need to follow these steps when you turn on this unit for the first time.

1 Press [STANDBY-ON

y].

Turn the TV on. Select the input to

which the unit is connected.

2 Use [K / L] to select your desired

language, then press [OK] to set

language.

Initial Setup

OSD Language

English

Français

Español

3 Press [OK] to activate “Clock Setting”.

Initial Setup

Clock Setting

- - - / - - / - - - - ( - - - )

- - : - - - -

4 Proceed to step 4 in “Clock Setting”

on page 21.

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

NB552

STANDBY-ON

21EN 21EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

SETTING THE CLOCK

Set the clock before you try the timer programming.

Clock Setting

1 Press [SETUP] and use [K / L] to

select “General Setting”, then press

[OK].

“General Setting” menu will appear.

2 Use [K / L] to select “Clock”, then

press [OK].

3 Use [K / L] to select calendar or time,

then press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Clock Setting

JAN / 01 / 2007 ( MON )

12 : 00 AM

4 Use [{ / B] to select an item to set,

and use [K / L] to select the contents

to suit your preference, then press

[OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Clock Setting

JAN / 01 / 2007 ( MON )

12 : 00 AM

Your setting will be activated.

The clock start counting when you press [OK].

5 Press [SETUP] to exit.

Note

• Your clock setting will be lost if either there is a power

failure or this unit has been unplugged for more than

30 seconds.

• For setting the day, year, hour, and minute,

[the Number buttons] can also be used.

• You can set the built-in calendar from the year 2007

up to 2056.

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

NB552

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACE

PQRS

123

456

SETUP

OK Bs

22 EN22 EN

INFORMATION ON DVD RECORDING

Logo Attributes

8cm/12cm, single-sided,

single layer disc

Approx. max. recording time

(SLP mode):

360 minutes (4.7GB) (for 12cm)

108 minutes (1.4GB) (for 8cm)

DVD+RW DVD+R

DVD-RW DVD-R

This unit can record to DVD+RW, DVD+R, DVD-RW and

DVD-R.

DVD+R/DVD-R can only be recorded to once. DVD+RW/

DVD-RW can be recorded to and erased many times.

DVD-RW/-R will be recorded in the DVD+VR mode

automatically in this unit.

You can select a recording mode among 6 options, and

the recording time will depend on the recording mode

you select as follows.

Recording

mode Recording

time Video/sound

quality

Disc size

8cm Disc

60 min

120 min

150 min

180 min

240 min

360 min

12cm Disc

(poor)

(good)

HQ (1Hr)

SP (2Hr)

SPP (2.5Hr)

LP (3Hr)

EP (4Hr)

SLP (6Hr)

18 min

36 min

45 min

54 min

72 min

108 min

HQ (1Hr)

SP (2Hr)

SPP (2.5Hr)

LP (3Hr)

EP (4Hr)

SLP (6Hr)

• The recording time is only an estimate. The actual

recording time may differ.

• The audio and video quality gets poorer as the recording

time becomes longer.

• Each time [REC MODE] is pressed, recording mode and

its allowed recording time will be displayed.

• Following discs are recommended for good recording

quality and are proven to be compatible with this unit.

However, depending on the media condition the unit

may not read the disc properly.

Verbatim DVD+R 8x, DVD+RW 4x,

DVD-R 8x, DVD-RW 2x

JVC DVD-RW 4x

Maxell DVD+R 4x/8x/16x, DVD-R 8x/16x

SONY DVD+R 4x/8x/16x, DVD+RW 4x

TDK DVD+R 4x/8x/16x

Performance of any other discs are not guaranteed.

• You can play back DVD+RW on most DVD players

without finalizing. However, if you have added or

deleted chapters, or made chapters hidden, you

must perform “Make Edits Compatible” before being

able to see those effects on other units. (Refer to

page 68 for more details.) To play back discs other

than DVD+RW on other DVD players, you will need

to finalize.

Note

• This unit cannot record to CD-RW or CD-R.

• DVD+RW/+R, DVD-RW/-R and CD-RW/-R recorded on

a personal computer or a DVD or CD recorder may

not be played back if the disc is damaged or dirty or

if there is condensation on the player’s lens.

• If you record a disc using a personal computer, even

if it is recorded in a compatible format it may not be

played back because of the settings of the

application software used to create the disc. (Check

with the software publisher for more detailed

information.)

• Since the recording is made by the VBR (variable bit

rate) method, depending on the picture you are

recording, the actual remaining time for recording

may be a little shorter than the remaining time

displayed on the TV screen.

• You cannot record copy-protected program using

this unit. (Copy-protected signal is included in DVD-

video or some satellite broadcasts.)

• You cannot record “copy-once only” program on

DVD.

Recordable Discs

Before you make a recording, read the following information.

Recording Mode

• DVD-RW recorded in the mode other than +VR is not

recordable on this unit unless you erase all contents in

the disc (refer to page 67).

• DVD-R recorded in the mode other than +VR is not

recordable on this unit.

Unrecordable Discs

23EN 23EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

BEFORE RECORDING

Use this feature to make the unfinalized +VR mode discs

recorded on other unit recordable on this unit. When you

make an additional recording on this unit with “Make

Recording Compatible” set to “ON”, the title menu is

automatically converted to our style.

1) Press [SETUP] and use [K / L] to select “General

Setting”, then press [OK].

“General Setting” menu will appear.

2) Use [K / L] to select “Recording”, then press [OK].

“Recording” menu will appear.

3) Use [K / L] to select “Make Recording Compatible”,

then press [OK].

4) Use [K / L] to select “ON” or “OFF”, then press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Auto Chapter

Auto Finalize

Dubbing Mode

Make Recording Compatible

OFF

ON: Title list will be replaced when you make

additional recordings to the discs recorded by

other units.

OFF: Prohibiting additional record to the disc that

has a title list created by other units.

5) Press [SETUP] to exit.

Make Recording Compatible Setting for Auto Chapter

You can set a specified time for chapter marks.

1) Press [SETUP] and use [K / L] to select “General

Setting”, then press [OK].

“General Setting” menu will appear.

2) Use [K / L] to select “Recording”, then press [OK].

“Recording” menu will appear.

3) Use [K / L] to select “Auto Chapter”, then press [OK].

4) Use [K / L] to select a desired time option, then

press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Auto Chapter

Auto Finalize

Dubbing Mode

Make Recording Compatible

Auto Chapter

OFF

5 minutes

10 minutes

15 minutes

30 minutes

60 minutes

5) Press [SETUP] to exit.

Note

• The interval for auto chapter marks may slightly

differ.

• A blank chapter may be created depending on the

remaining time of the disc.

24 EN24 EN

BASIC RECORDING & ONE-TOUCH TIMER RECORDING

1 Press [STANDBY-ON

y].

Turn on the TV and be sure to select the input to

which the unit is connected.

Press [DVD].

2 Press [OPEN/CLOSE A] to open the

disc tray and insert your disc with its

label facing up.

Align the disc to

the disc tray guide.

* Make sure the disc is compatible with this unit.

(Refer to page 22 for the list of compatible discs.)

3 Press [OPEN/CLOSE A] to close the

disc tray.

It may take a while to load

the disc completely.

• When inserting a brand-new DVD+RW/DVD-

RW, the unit automatically starts to format.

• If titles have been recorded on the disc, the

title list is displayed. Press [STOP C] to exit the

title list.

4 Press [REC MODE] to select a

recording mode.

Refer to “Recording Mode” on page 22 for DVD.

SP(2Hr) 0:58

5 Press [SOURCE] to select the

appropriate external input position

(E1/E2) to which your external tuner

is connected. Then select the desired

channel to record on the external

tuner.

Follow the steps to record TV programs from an external

tuner.

This unit has no tuner system so cannot receive TV

broadcasts without external tuner or such devices.

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

NB552

STANDBY-ON

SOURCE OPEN/CLOSE

REC MODE

REC

TIMER SET

DVD

25EN 25EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

BASIC RECORDING & ONE-TOUCH TIMER RECORDING

7 Press [STOP C] to stop recording.

The recorded title will appear in the title list.

(Refer to “Guide to a Title List” on page 56.)

e.g.) DVD+R

Writing to Disc 90%

1SP(2Hr)

EMPTY TITLE

1:41:17

SP(2Hr)

NOV/21/07 11:00

E1 SP

NOV/21/07 0:20:44

• Press [STOP C] to exit the title list.

6 Press [REC I] to start recording.

“I” will be displayed for 5 seconds.

Press [PAUSE F] to pause recording.

Press [PAUSE F]] or [REC I] again to restart

recording.

To set one-touch timer recording (OTR)...

This is a simple way to set the recording time in blocks

of 30 minutes.

Press [REC I] repeatedly until the desired recording

time (30 minutes to 6 hours) appears on the TV screen.

One-touch timer recording will start.

0:30

(normal recording)

6:00 5:30

1:00

I 0:30

• To cancel one-touch timer recording within the

specified time, press [STOP C].

Note

• When you press [REC I], recording starts immediately and continues until the disc is full or you stop recording.

• This unit cannot record images as aspect ratio of 16:9. The 16:9 images will be recorded as 4:3.

• When the unit clock has not been set, the space for a date and time of title names will be blank.

• You cannot change the recording mode during the recording pause mode.

• You can change a channel to be recorded during the recording pause mode.

Note for one-touch timer recording

• Press [DISPLAY] to see the remaining recording time on the TV screen.

• Unlike the timer recording, you can perform the following operations during one-touch timer recording.

- Turning off the power to stop one-touch timer recording.

- Using [REC I] or [STOP C] on the remote control.

• You cannot use the pause function during one-touch timer recording.

• If DVD one-touch timer recording is completed during VCR playback or recording, the DVD will be in stop mode

and the VCR keeps the current mode.

• When one-touch timer recording is finished and the power is turned off, the unit will switch to the timer-standby

mode automatically if a timer recording has been programmed. Press [TIMER SET] to cancel the timer-standby

mode to use the unit continuously.

26 EN26 EN

TIMER RECORDING

1 Press [TIMER].

2 Use [K / L] to select “New Program”,

then press [OK].

Timer Programming

1/1

MON JAN/01 11:00AM

Date Start End E1/E2

New Program

3 Use [K / L] to enter the date, then

press [B].

Timer Programming

1/1

MON JAN/01 11:00AM

Date Start End E1/E2

New Program

Date

JAN/02

E1/E2

REC To Mode

DVD SP

SP 2 : 00

Start

- - : - -

End

- - : - -

Daily

MON-SAT

JAN/01

JAN/31

MON-FRI

SAT

FRI

SUN

Guide to Timer Programming Display

Timer Programming

1/1

MON JAN/01 11:00AMSP (1:00)

JAN/ 2/07 12:00 AM E1 SP

Date Start End E1/E2

JAN/02 12:00AM 1:00AM E1

New Program

1 Title of a timer program (Contains date, time, selected

external input position, recording mode of the program)

2 Current date and time

3 Recording mode, and length of the recording

4 Timer program list

5 Total number of pages and current page (2 pages

maximum)

When pressing [L] at

the current date, the

date will change as

follows.

e.g.) January 1st

You can program the unit to record up to 12 programs

within a month in advance. Daily or weekly program

recordings are also available.

Before recording, make sure

• Connect the external tuner to either E1 or E2 and set it

to output audio/video signals when it comes to the time

you want to start recording.

• Do not change the external tuner’s channel while you

are recording. You cannot watch one channel and

record another at the same time.

• Set the clock before setting a timer programming.

• Insert a recordable disc with enough recordable space or

a cassette tape with a erase-protection tab.

27EN 27EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

Note

• If you have not set the clock yet:

“Clock Setting” menu will appear instead of the timer

programming list at step 1. Continue with the step 4

in “Clock Setting” on page 21 before setting a timer

programming.

• Use [s / B] to move the cursor to the left and the

right in “Timer Programming” menu.

• If a basic recording or one-touch timer recording is in

progress on one component (e.g., VCR) and the timer

recording set for the other component (e.g., DVD) is

about to begin, the unit automatically switches to the

programmed channel for timer recording 2 minutes

before the programmed starting time, and the

recording in progress (for VCR) will be canceled

UNLESS their recording channels are the same. If their

recording channels are the same, the timer recording

will start without canceling the recording currently in

progress. In this case, the recording of the same

channel will be made on both DVD and VCR.

• Cancel the timer-standby mode by pressing

[TIMER SET] before operation for either DVD or VCR.

When finished operating, press [TIMER SET] to

resume the timer-standby mode.

• In the timer-standby mode, you can turn on the

power and use the component (VCR or DVD) which is

not currently timer-programmed.

4 Use [K / L] or [the Number buttons]

to enter the start and end time, then

press [B].

Timer Programming

1/1

MON JAN/01 11:00AM

Date Start End E1/E2

New Program

Date

JAN/02

E1/E2

REC To Mode

DVD SP

SP 2 : 00

Start

12 : 00AM

End

- - : - -

5 Use [K / L] to select the appropriate

external input position (E1/E2) to

which your external tuner is

connected, then press [B].

Timer Programming

1/1

MON JAN/01 11:00AM

Date Start End E1/E2

New Program

Date

JAN/02

E1/E2

REC To Mode

DVD SP

SP 1 : 00

Start

12 : 00AM

End

1 : 00AM

6 Use [K / L] to select a recording

media (“DVD” or “VCR”), then press

[B].

1/1

Date Start End E1/E2

New Program

Date

JAN/02

E1/E2

REC To Mode

DVD SP

SP 1 : 00

Start

12 : 00AM

End

1 : 00AM

7 Use [K / L] to select a recording

mode.

1/1

Date Start End E1/E2

New Program

Date

JAN/02

E1/E2

REC To Mode

DVD SP

SP 1 : 00

Start

12 : 00AM

End

1 : 00AM

Refer to “Recording Mode” on page 22 for DVD

or “Recording” on page 79 for VCR.

• You can check the remaining recordable space

of the disc when you select the recording mode.

Date

JAN/02

E1/E2

REC To Mode

DVD SP

SP 1 : 00

Start

12 : 00AM

End

1 : 00AM

8 Press [OK] when all items are entered.

Your program setting is now stored.

• To set another program, repeat steps 2 to 7.

• To exit, press [TIMER] or [SETUP].

• When 2 or more programs are overlapped,

“Timer program overlapped” appears, and the

overlapped program will be displayed in blue.

• To correct the timer program refer to

“Checking, canceling, or correcting the timer

programming information” on page 28.

9 Press [TIMER SET] to set a timer

programming.

will appear on the front panel display.

BS CS DR CD

HDD

DVD

"VCR” will appear if VCR timer recording have

been set.

TIMER RECORDING

Auto recording mode select...

When “Auto” is selected as a recording mode, the unit

calculates how much time is available on the disc and

determines the appropriate recording mode to

complete recording the program.

Date

JAN/02

E1/E2

REC To Mode

DVD Auto

Auto 0 : 00

Start

12 : 00AM

End

1 : 00AM

• “Auto” is only available for one program in the timer

program list.

• The recording may be cut short when the available

recording space of the disc is too limited.

28 EN28 EN

TIMER RECORDING

Checking, canceling, or correcting the timer

programming information If the timer program did not complete correctly,

the error number appears in the timer pro-

gramming list.

1) Press [TIMER SET].

will disappear on the front panel display.

2) Press [TIMER].

3) Check the information on the list you will need.

Timer Programming

1/1

MON JAN/01 11:00AMSP (1:00)

JAN/ 2/07 12:00 AM E1 SP

Date Start End E1/E2

JAN/02 12:00AM 1:00AM E1

New Program

4-A) To delete the timer program:

1 Use [K / L] to select the program you want to

delete, then press [OK].

2 Use [K / L] to select “Delete”, then press [OK].

Confirmation window will appear.

3 Use [K / L] to select “Yes”, then press [OK].

4-B) To correct the timer program:

1 Use [K / L] to select the program you want to

correct, then press [OK].

2 Use [K / L] to select “Program Change”, then

press [OK].

3 Correct the timer program by using

[K / L / { / B], then press [OK].

5) Press [TIMER] to exit.

6) Press [TIMER SET] to return to the timer standby

mode.

Note

• Press [TIMER] to check the timer recording in progress.

When the timer recording is proceeding, that

program will be highlighted with red. In this case,

you cannot select any other program.

Timer Programming

1/1

TUE JAN/02 11:00AM

Date Start End E1/E2

E41 JAN/02 12:00AM 1:00AM E1

New Program

Each error number means:

E1-22

E37-39 Recording error other

than below E41 Power failed

E24 Unrecordable disc E42 No disc when

recording

E25-26 Copy prohibited

program E43 Already 49 titles

recorded

E29 Disc protected E44 Already 254 chapters

recorded

E30 Disc full E45 Copy prohibited

program

E35 PCA full *1 E46 It is impossible to

record additionally

on a disc recorded

by other units

when setting “

Make Recording

Compatible” to “OFF”.

E36 Already finalized

video format disc

E40 Some portion has

not been recorded

because of program

overlapping.

Recording did not

start at the start time.

• E23, E27, E28, E31, E32, E33 and E34 are not displayed.

• A program with the error number is grayed in the timer

programming list.

• Once the timer programming list with error line(s) is

displayed, or after canceling and setting again the timer

standby mode, the program line(s) with error will be

cleared.

*1 PCA is a disc's space reserved for recording test.

Press [STOP C] to stop the disc recording or

[STOP C/EJECT A] to stop the cassette tape recording

on the front panel of the unit.

[STOP C] on the remote control is not effective.

To stop the timer recording in process

29EN 29EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

TIMER RECORDING

Hints for Timer Recording

When the starting time is the same:

A program set previously (PROG. A) has priority.

PROG. A

PROG. B

actual

recording PROG. A PROG. B

The rst 2 minutes (at the longest) will be cut o.

PROG. A

The Priority of Overlapped Settings

Note for DVD recording

• When the recording time of 2 programs are overlapped, or

the end time of a program and the start time of another

program is the same, the first 2 minutes (at the longest) of

the subsequent program will be cut off.

• If the cut-off portion comes up to 3 minute or more, this

program will be displayed with error number E40 in the

timer programming list.

PROG. A

PROG. B

actual

recording

The rst 2 minutes (at the longest) will be cut o.

PROG. BPROG. A

When the end time of the programming

currently being recorded and the start time

of the subsequent program are same:

The beginning of the PROG. B may be cut o.

• If there is a power failure or this unit has been

unplugged for more than 30 seconds, the clock setting

and all timer programming will be lost.

• If a disc is not inserted, "DVD" on the front panel display

flashes and timer recording cannot be performed. In some

cases, will appear momentarily around the start point as

the unit attempts to record. Please insert a recordable disc.

• If a cassette tape with a erase-protection tab is not in the

cassette compartment or there is no cassette tape in the

cassette compartment, “VCR” on the front panel display

flashes and timer recording cannot be performed. Please

insert a recordable cassette tape.

• If you press [TIMER SET] and turn on the unit while

either DVD or VCR is in timer standby mode,

disappears. In this case, you cannot change the mode

between DVD and VCR. You cannot change any settings

using [SETUP] or edit discs.

• When all the timer recording is completed, flashes. To

play back or eject the recorded disc, press [TIMER SET]

first, then select the recorded title and press [PLAY B],

or [OPEN/CLOSE A] to remove the disc.

• If both DVD and VCR are timer programmed, you cannot

use any functions for either unit during timer standby or

timer recording. If you want to use functions other than

recording under such condition, cancel timer recording

by pressing [TIMER SET] during timer standby or stop

recording by pressing [STOP C] on the front panel

during timer recording.

• To cancel the timer standby mode, press [TIMER SET].

• When the starting and the ending time are the same, the

length of the recording will be set for 24 hours. When

the disc or cassette tape becomes full during the

recording, the unit turns itself off.

• When the programmed starting and ending time are

earlier than the current time, the setting will not be

accepted and be cleared for redoing.

• If the starting time is earlier and the ending time is later

than the current time, the recording will start right after

you turn the power off.

• The timer recording for digital TV cannot record any

audio language other than English.

• The timer recording cannot be performed in DVD and

VCR at the same time. If you set 2 programming with the

same channel and time in both devices, the program

with a lower program number will be recorded.

• Timer program which has the earlier start time will be placed first in the timer program list, and be given priority over

the programs with the later start time when timer programs overlap.

• When timer programs overlap, the first 2 minutes (at the longest) of the later recording will be cut off.

• When two or more timer programs have the same start time, the program set first will be given priority.

• A timer recording of lower priority will be canceled or start from the middle.

• Check the overlapped timer programmings and change the priority if necessary.

30 EN30 EN

SATELLITE LINK

You can set the unit to start recording whenever it

detects the video signal from the external tuner.

Preparing for the satellite link timer recording:

Preparation on the tuner

• Satellite link accepts only the connection from E1 (rear)

with the external tuner. (The connection from E2 cannot

read any signals from the external tuner.)

• The external tuner should be equipped with some kind

of timer function. Using timer function of the tuner, set

it to output audio/video signals when it comes to the

time you want to start recording, and stop output audio/

video signals when it comes to the time you want to

finish recording. Refer to the tuner’s manual on how to

set the timer.

• Make sure to set the satellite link standby mode when

you finish setting.

1 Press [SETUP].

2 Use [K / L] to select “Timer

Programming”, then press [OK].

3 Use [K / L] to select “Satellite Link”,

then press [OK].

Timer Programming

Satellite Link

Timer Programming

4 Use [K / L] to select the time, media

and recording mode, then press [OK].

Satellite Link

To Standby Mode

5:00PM DVD SP (2Hr)

Start Mode

DVD

VCR

5 Use [K / L] to set the desired starting

time, then press [B].

• The hour can be selected from 1 to 12 with AM

or PM.

• Repeat procedures in step 5 to set the desired

minutes.

• If you wish to go back to the left, press [{].

6 Use [K / L] to select a recording

media (“DVD” or “VCR”), then press

[B].

7 Use [K / L] to select the recording

mode.

Refer to page 22 for details.

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

31EN 31EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

SATELLITE LINK

8 Press [OK].

“To Standby Mode” is highlighted.

9 Press [OK] again.

Satellite Link

To Standby Mode

5:00PM DVD SP (2Hr)

Start Mode

DVD

VCR

In a second, the unit will be turned off

automatically as it goes into the satellite link

standby mode.

To cancel the satellite link function while in

the satellite link standby mode:

Press [TIMER SET] to turn on the unit.

To cancel the satellite link function while the

satellite link recording is in progress:

Press [STOP C] on the front panel of the unit.

Notes

• If the signal of external input breaks up over 5 seconds, satellite link function will be canceled.

• If you have not set the clock, “Clock Setting” menu will appear at step 3. Follow to step 3 in “Clock Setting” on

page 21.

• You cannot set the end time for the satellite link timer recording on this unit.

• Recording picture will be distorted if the copy protection signal is being detected during satellite link timer

recording.

• You can record the satellite link by using S-video input jacks on the rear panel. Refer to page 13 for more

information.

• When a regular timer recording and the satellite link timer recording are overlapped, those recordings are

recorded as illustrated below.

• Press [TIMER] during the satellite link timer recording to check the satellite link timer recording in progress.

example 2

actual

recording

timer

recording

satellite link

example 3

actual

recording

timer

recording

satellite link

The rst 2 minutes (at the longest) will be cut o.

example 1

timer

recording

actual

recording

satellite link

The rst 2 minutes (at the longest) will be cut o.

32 EN32 EN

OVERWRITING UNNECESSARY TITLE

You can overwrite the existing title from the beginning.

1) Press [STANDBY-ON

y].

Make sure that the TV input is set on the unit.

2) Load the disc that includes a title to be overwritten.

It takes a while to display

the title list.

Title list will appear.

If the title list does not appear, press [TITLE].

3) Press [REC MODE] to select a recording mode.

Refer to “Recording Mode” on page 22.

4) Use [K / L] to select a title to be overwritten, then

press [OK].

1SP (2Hr)

NOV/21/07 11:00

E1 SP

NOV/21/07 0:20:44

NOV/22/07 11:35

E1 EP

NOV/22/07 0:10:33

5) Use [K / L] to select “Overwrite”, then press [OK].

1SP (2Hr)

NOV/21/07 11:00

E1 SP

NOV/21/07 0:20:44

Edit

Overwrite

Play

6) Press [SOURCE] to select the appropriate external

input position (E1/E2) to which your external tuner

is connected. Then select the desired channel to

record on the external tuner.

e.g.) DVD+RW

E1 (Rear)

+RW

0:01:00

SP(2Hr) 2:00

F I

33EN 33EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

OVERWRITING UNNECESSARY TITLE

When you overwrite on the unnecessary title, there were various circumstances such as follows. Please note that

following cases only describe the overwriting without any recording mode discrepancy. To avoid accidental deletion

please check if there is no important title after the overwriting point.

When overwriting title is shorter than the existing title:

(overwriting from the beginning of the title)

overwrite

recording : A

existing title : B

after

overwriting

34 EN34 EN

DVD

DIGITAL

AUDIO OUT

AUDIO

OUT

S-VIDEO

COAXIAL

S-VIDEO IN --- AUDIO --- OU T

IN --- VIDEO --- OUT

COMPONENT

VIDEO OUT

DVD/VCR

35EN 35EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

EXTERNAL DEVICE RECORDING

Recording from an External Device

Before recording from an external device, refer to the

instructions for the connection on page 34.

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

STANDBY-ON

SOURCE OPEN/CLOSE

REC MODE

VCR DVD

1 Turn on the TV and press

[STANDBY-ON

y], and be sure to

select the input of the TV to which

the unit is connected.

2 When you want to record to the disc:

Press [DVD].

Press [OPEN/CLOSE A] to open the disc

tray. Place the disc to record properly.

Press [OPEN/CLOSE A] again to close

the disc tray.

It takes a while to load

the disc.

When you want to record to a

cassette tape:

Press [VCR].

Insert the cassette tape with a erase-

protection tab into the cassette

compartment.

Select the input of the unit which the

external device is connected. (E2 or

E1)

• To use the input jacks on the rear of this unit;

Select “E1 (Rear)” position by using [SOURCE].

• To use the input jacks on the front of this unit;

Select “E2 (Front)” position by using [SOURCE].

4 Press [REC MODE] to select a

recording mode.

Refer to “Recording Mode” on page 22 for DVD

or “Recording” on page 79 for VCR.

5 Press [RECORD I] (DVD or VCR) on

the unit to start recording.

6 Start playback on the external device

to record from.

7 For disc:

Press [STOP C] on the unit to stop

recording.

For cassette tape:

Press [STOP C/EJECT A] on the unit

to stop recording.

This operation may take a

while to be completed.

36 EN36 EN

SETTING A DISC TO PROTECT

1 Press [SETUP].

2 Use [K / L] to select “Disc Edit”, then

press [OK].

3 Use [K / L] to select “Disc Protect

OFF ON”, then press [OK].

e.g.) DVD+RW

Disc Edit

Edit Disc Name

Erase Disc

Make Edits Compatible

Disc Protect OFF ON

4 Use [K / L] to select “Yes”, then press

[OK].

Disc Edit

Edit Disc Name

Erase Disc

Make Edits Compatible

Disc Protect OFF ON

Protect this disc?

Yes

A disc will be protected.

This operation may take a

while to be completed.

To prevent accidental recording, editing or erasing the

titles, you can protect them from “Disc Edit” menu.

Note

To cancel the disc protect:

• When you insert a disc protected with this unit,

“Disc Protect ON OFF” will appear instead of “OFF

ON” at step 3.

Disc Edit

Edit Disc Name

Erase Disc

Make Edits Compatible

Disc Protect ON OFF

To release the protect for the disc, select “Yes” at step 4.

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

NB552

SETUP

37EN 37EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

PLAYING THE DISCS IN OTHER DVD PLAYERS

Finalizing a Disc

1 Press [SETUP].

2 Use [K / L] to select “Disc Edit”, then

press [OK].

“Disc Edit” menu will appear.

3 Use [K / L] to select “Finalize”, then

press [OK].

4 Use [K / L] to select “Yes”, then press

[OK].

e.g.) DVD+R, DVD-R

Disc Edit

Edit Disc Name

Finalize

Disc Protect OFF ON

Finalize disc?

Yes

Finalizing will start.

Finalizing 90%

To cancel finalizing...

(DVD-RW only)

• To cancel finalizing at step 4, press [STOP C], select

“Yes” with [K / L], then press [OK]. Finalizing is

canceled and the unit will be in stop mode.

Finalizing 5%

Yes

Do you want to cancel ?

• If appears when pressing [STOP C], you cannot

cancel finalizing because the finalizing has been in

certain progress.

• When selecting “No” and press [OK] or [RETURN],

finalizing will be continued.

• You cannot cancel finalizing the DVD+R/DVD-R once

it has started.

This operation may take a

while to be completed.

5 Finalizing is completed.

You will need to finalize discs to play back in other DVD

players.

Finalizing may take several minutes up to an hour.

A shorter recording period on the disc will require a

longer time period for finalization. Do not unplug the

power cord during finalization.

Note

• Once you have finalized a DVD+R/ DVD-R, you

cannot edit or record anything on that disc.

• There is no need to finalize DVD+RW.

• When you insert a DVD-RW finalized with this unit,

“Undo Finalize” will appear instead of “Finalize”.

Disc Edit

Edit Disc Name

Erase Disc

Undo Finalize

Disc Protect ON OFF

To release the finalizing for the disc, select “Undo

Finalize” at step 3.

* DO NOT power off during finalization, this will result

in malfunction.

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

SETUP

RETURN

38 EN38 EN

PLAYING THE DISCS IN OTHER DVD PLAYERS

1 Press [SETUP] and use [K / L] to

select “General Setting”, then press

[OK].

“General Setting” menu will appear.

2 Use [K / L] to select “Recording”,

then press [OK].

“Recording” menu will appear.

3 Use [K / L] to select “Auto Finalize”,

then press [OK].

4 Use [K / L] to select “Disc Full” or

“End of Timer Rec”, then press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Auto Chapter

Auto Finalize

Dubbing Mode

Make Recording Compatible

Auto Finalize

Disc Full

End of Timer Rec

5 Use [K / L] to select “ON”, then press

[OK].

e.g.) “Disc Full”

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Auto Chapter

Auto Finalize

Dubbing Mode

Make Recording Compatible

Auto Finalize

Disc Full

End of Timer Rec

Disc Full

OFF

Your setting will be activated.

6 Press [SETUP] to exit.

You can finalize discs automatically using this function.

You can use this function to finalize discs after finishing

all timer recordings and at the end of the disc space.

Auto Finalizing

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

NB552

SETUP

39EN 39EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

DUBBING MODE

1 Press [SETUP] and use [K / L

40 EN40 EN

4 Use [K / L] to select “VCR DVD”,

then press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Auto Chapter

Auto Finalize

Dubbing Mode

Make Recording Compatible

Dubbing Mode

VCR DVD

DVD VCR

5 Press [SETUP] to exit.

Press [VCR].

6 Press [PLAY B]. Then press

[PAUSE F] at the point you wish to

start recording.

• Since it takes about a few seconds before the

actual dubbing begins, please allow extra 5

seconds when selecting the starting point.

7 Press [DVD].

Make sure to select a recording mode using

[REC MODE].

8 Press [D.DUBBING].

VCR to DVD duplication will start.

9 Press [STOP C] to stop the recording.

Title list will automatically appear.

• If you want to watch the duplicated material

after the VCR to DVD duplication, press [OK]

and then select “Play” in the title.

DUBBING MODE

4 Use [K / L] to select “DVD VCR”,

then press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Auto Chapter

Auto Finalize

Dubbing Mode

Make Recording Compatible

Dubbing Mode

VCR DVD

DVD VCR

5 Press [SETUP] to exit.

Press [DVD].

6 Press [PLAY B]. Then press

[PAUSE F] at the point you wish to

start recording.

7 Press [VCR].

Make sure to select a recording mode using

[REC MODE].

8 Press [D.DUBBING].

DVD to VCR duplication will start.

9 Press [STOP C] to stop the recording.

VCR to DVD DVD to VCR

Note

• When you turn off the unit after setting the dubbing mode to DVD VCR, the setting will be set to VCR DVD

automatically.

• You cannot change the output mode during VCR to DVD or DVD to VCR duplication.

For Audio CD to VCR duplication:

• This function is available on Audio CD, not MP3 files.

For VCR to DVD duplication:

• The playback sound mode is followed by the setting of VCR playback sound mode on page 81. Set the playback

sound mode to which you wish to record to the DVD.

• This unit will automatically stop the duplication if playback with no image is for more than 3 minutes during VCR

to DVD duplication.

• Dubbing indicator will appear on the front panel display during dubbing.

41EN 41EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

INFORMATION ON PLAYBACK

Before you play back DVD, read the following information.

This unit is compatible to play back the following discs.

To play back a DVD, make sure that it meets the requirements

for region codes and color systems as described below. You

can play back discs that have the following logos will play back

on the unit. Other disc types are not guaranteed to play back.

Playable Discs and Files DVD is recorded in different color systems throughout the

world. The most common color system is NTSC (which is

used primarily in the United States and Canada).

This unit uses NTSC, so DVD you play back must be recorded

in the NTSC system. You cannot play back DVD recorded in

other color systems.

Color Systems

Region Codes

The contents of DVD are generally divided into titles. Titles

may be further subdivided into chapters.

Hint for DVD Playback

You can select images or information on the menu screen by

activating the PBC (playback control) function of the video CD.

This unit conforms to ver.1.1 and ver. 2.0 of video CD

standard with PBC function.

Ver.1.1 (without PBC function): You can enjoy playback

picture as well as music CD.

Ver.2.0 (with PBC function): While using a video CD with PBC

function, “PBC” appears on the TV screen.

Note

• PBC setting turns to “ON” when loading video CD with

PBC function, thus, even after setting PBC to “OFF” and

ejecting the video CD then reloading the video CD, this

setting turns to “ON” automatically.

• Some operations cannot be performed while PBC function

is on. Cancel PBC function temporarily to perform those

operations by following the instruction below.

1) Press [SETUP].

2) Use [K / L] to select “CD Playback Mode”, then press [OK].

“CD Playback Mode” menu will appear.

3) Use [K / L] to select “PBC (Video CD only)”, then press [OK].

4) Use [K / L] to select “ON” or “OFF”, then press [OK].

Your setting will be activated.

You can play back interactive software using menu screens.

Refer to instructions in the video CD.

PBC (playback control) for Video CD

LogosPlayable discs

MediaPlayable les

CD-DA

MP3

CD-RW/-R

CD-DA (audio CD)

video CD

CD-RW

CD-R

DVD-video

DVD+RW

DVD+R

DVD-RW

(Finalized video mode discs only)

DVD-R

(Finalized video mode discs only)

42 EN42 EN

BASIC PLAYBACK

Direct Playback

1 Press [STANDBY-ON

y].

Turn on the TV and be sure to select the input to

which the unit is connected.

Press [DVD].

2 Press [OPEN/CLOSE A] to open the

disc tray and insert your disc with its

label facing up.

Align the disc to

the disc tray guide.

* Make sure the disc is compatible with this unit.

(Refer to page 41 for the list of compatible discs.)

3 Press [OPEN/CLOSE A] to close the

disc tray.

It may take a while to load

the disc completely.

4 Press [PLAY B] to start playback.

If you are playing back a DVD-video or video CD

with PBC function, a menu may appear.

Refer to “Using the Title / Disc Menu” on page

46.

5 Press [STOP C] once to stop playback

temporarily.

• Refer to “Resume Playback” on page 47.

Note

• Some discs may start playback automatically.

• You can select images or information on the menu

screen by activating PBC (playback control) function

(page 41).

43EN 43EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

BASIC PLAYBACK

1 Press [STANDBY-ON

y].

Turn on the TV and be sure to select the input to

which the unit is connected.

Press [DVD].

2 Press [OPEN/CLOSE A] to open the

disc tray and insert your disc with its

label facing up.

Align the disc to

the disc tray guide.

* Make sure the disc is compatible with this unit.

(Refer to page 41 for the list of compatible discs.)

3 Press [OPEN/CLOSE A] to close the

disc tray.

It may take a while to load

the disc completely.

• To exit the title list, press [STOP C].

• To resume the title list, press [TITLE].

Note

• Some discs may start playback automatically.

• You can also start playback by pressing [PLAY B]

instead of [OK] at step 4.

Playback from the Title List

Instructions continue on the next page.

44 EN44 EN

4 Use [K / L] to select a desired title,

then press [OK].

1SP (2Hr)

NOV/21/07 11:00

E1 SP

NOV/21/07 0:20:44

NOV/22/07 11:35

E1 EP

NOV/22/07 0:10:33

EMPTY TITLE

1:37:52 SP(2Hr)

• For Video CD, when “PBC (Video CD only)” in

“CD playback Mode” menu is set to “ON”, the

video CD main menu will appear when

inserting a disc. In such case, select a numbered

menu with [the Number buttons].

• Press [B] to display the next page, and press

[{] to display the previous page.

If you want to see disc information, press [{ ] when the

first page of the title list is displayed or press [ K ] when

the first title is selected but not when “Play”, “Edit” or

“Overwrite” is highlighted.

e.g.) DVD+RW

No Disc Name

Disc DVD+RW

Total Titles 3

Disc Space Used 0:30:48

Disc Protect OFF

Make Edits Compatible Needed

e.g.) DVD+R

No Disc Name

Disc DVD+R

Total Titles 5

Disc Space Used 1:30:48

Disc Protect OFF

Finalize Finalized

1. Disc name

(Default “No Disc Name”)

2. Disc type

(DVD+RW/DVD+R/ DVD-RW/DVD-R)

3. Total number of title

(include “EMPTY TITLE”)

4. Total time of recorded disc space

5. Status of disc protection

(“ON” is protected disc.)

6. Making edits compatible/finalize

• When DVD+RW is inserted:

If the disc needs to be set “Make Edits Compatible”,

“Needed” is displayed. Otherwise, “Not Needed” is

displayed. (Refer to page 68.)

• When DVD+R, DVD-RW or DVD-R is inserted:

If “Finalize” is done, “Finalized” is displayed.

Otherwise, “Unfinalized” is displayed.

5 Use [K / L] to select “Play”, then

press [OK].

1SP (2Hr)

NOV/21/07 11:00

E1 SP

NOV/21/07 0:20:44

NOV/22/07 11:35

E1 EP

NOV/22/07 0:10:33

EMPTY TITLE

1:37:52 SP(2Hr)

Edit

Overwrite

Play

Playback will start.

6 Press [STOP C] once to stop playback

temporarily.

• Refer to “Resume Playback” on page 47.

To eject the disc, press [OPEN/CLOSE A] to

open the disc tray, then remove the disc before

turning off the unit.

BASIC PLAYBACK

45EN 45EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

BASIC PLAYBACK

Playing Back an Audio CD and a CD-RW/-R with MP3 Files

Note

• The audio source of MP3 files cannot be recorded as

digital sound by an MD or DAT deck.

• Files whose extension is other than “.mp3(MP3)” will

not be listed.

• Some unplayable folders or files may be listed due to

the recording status.

1 Follow steps 1 to 2 in “Direct

Playback” on page 42.

2 Press [OPEN/CLOSE A] to close the

disc tray.

It may take a while to load

the disc completely.

When an audio CD is inserted, track list will

appear.

When a CD-RW/-R with MP3 files is inserted, file

list will appear.

• To exit the track/file list, press [STOP C].

• To resume the track/file list, press [TITLE].

3 Use [K / L] to select a desired folder

or track/file, then press [OK].

e.g.) File list

File List

DISC NAME

1/ 2

1 MP3 file1

2 MP3 file2

3 MP3 file3

4 MP3 file4

When selecting track/file:

Playback will start.

When selecting the folder (Not available for audio CD):

The files in the folder will appear.

Use [K / L] to select the file or folder you want to play

back, then press [OK].

• Press [PLAY B], [OK] or [B] to move to any lower

hierarchies.

• Press [s] or [RETURN] to move back to the previous

hierarchy.

Hints for audio CD tracks and MP3 files:

• Folders are shown by .

• Audio CD tracks are shown by .

• MP3 files are shown by

• The system can recognize up to 255 folders, up to 99

tracks/999 files.

• Letters of a file/folder name overflowing the given space

will be displayed as “...”. Unrecognizable characters will

be replaced with asterisks.

• If there are no files in the folder, “No Files” will be displayed.

It is recommended that files to be played back in this

unit are recorded under the following specifications:

<MP3>

• Sampling frequency : 44.1 kHz or 48 kHz.

• Constant bit rate : 112 kbps - 320 kbps

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

NB552

OPEN/CLOSE

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACE

PQRS

123

456

DISC MENU

TITLE RETURN

OK B

46 EN46 EN

BASIC PLAYBACK

Using the Title / Disc Menu

DVD or video CD with PBC function may contain a title

list, which describes the contents of the disc, or a disc

menu, which guides you through the available functions

in the disc.

Press [DVD] first.

1) Press [TITLE] or [DISC MENU] to call up the title list

or disc menu.

2) Use [K / L / { / B] to make a selection, and then

press [OK] to enable your selection.

3) Press [STOP C] to exit.

Press [DVD] first.

1) During playback, press [PAUSE F].

Playback will be paused and sound will be muted.

2) Press [PLAY B] to return to the normal playback.

Note

• You can select a numbered menu with [the Number

buttons] also.

• Menus vary among discs. Refer to the information

accompanying the disc for details.

• [TITLE] or [DISC MENU] will not always be active

with all DVD.

• For video CD, when “PBC (Video CD only)” in “CD

Playback Mode” menu is “ON”, the video CD main

menu will appear when inserting a disc.

Note

• On DVD, set “Still Mode” to “Field” in “Playback”

menu if pictures in the pause mode are blurred.

(Refer to page 74.)

Pause

47EN 47EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

SPECIAL PLAYBACK

You can skip TV commercials to enjoy the recorded

programs without interrupting.

Press [DVD] first.

During playback, press [CM SKIP].

Normal playback will start at 30 seconds ahead from the

point you press [CM SKIP].

Every time you press [CM SKIP], the searching point will

be extended by 30 seconds ahead.

You can press [CM SKIP] up to 6 times (180 seconds).

e.g.) Press [CM SKIP] once.

CM Skip 30 sec.

(forwarding 30 seconds)

Playback will return to the normal playback.

You can play back from where you stopped playing back

the disc last.

Press [DVD] first.

1) During playback, press [STOP C].

The resume message will appear.

Resume ON

2) Press [PLAY B].

In a few seconds, playback will resume from the point

at which it stopped last. You can resume playback at

the same point even if you turn off the unit.

To cancel the resume playback and start playing back

the disc from the beginning, press [STOP C] again

while the playback is stopped.

Resume Playback

Note

• For MP3 files, playback will resume from the

beginning of the file at which playback was stopped.

• Some video CD with the PBC function resume

playback from the beginning of the track.

Note

• Forward/reverse speed will be indicated with icons

as follows.

forward (approx. speed)

2x:

20x:

40x:

reverse (approx. speed)

5x:

20x:

40x:

Press [DVD] first.

1) During playback, press [D] or [E].

Every time you press [D] or [E], approximate speed

will be changed as follows.

Fast forward or fast reverse playback across titles (for

DVD) or files (for MP3 files) is not possible.

20x

normal

speed

playback

2x 20x5x 40x40x

For video CD, approximate forward/reverse speeds are

2x, 8x, 16x.

For audio CD, MP3 files, approximate speed is fixed at

8x with sound (indicated with / ).

2) Press [PLAY B] to return to the normal playback.

Fast Forward / Fast Reverse Playback

Skipping TV Commercials During

Playback

48 EN48 EN

SPECIAL PLAYBACK

Rapid playback function is available only during

playback.

This function is available only on discs recorded in the

Dolby Digital format, and plays back in a slightly faster/

slower speed while keeping the sound quality just as

normal playback.

Press [DVD] first.

1) During playback, press [RAPID PLAY].

B :Press [RAPID PLAY] once during playback.

Plays back approximately at 0.8 times of normal

playback.

B :Press [RAPID PLAY] twice during playback.

Plays back approximately at 1.3 times of normal

playback.

B :Press [RAPID PLAY] 3 times to play back in

normal speed.

No effects.

2) Press [PLAY B] to continue the normal playback.

Rapid Playback

49EN 49EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

SPECIAL PLAYBACK

Zoom

Note

• When selecting a smaller factor than the current one,

the zoom area will not be displayed.

• To exit the zoom menu, press [DISPLAY] again at

step 1.

• To cancel the zoom function, select “x1.0” using

[K / L], then press [OK].

Press [DVD] first.

1) During playback, press [DISPLAY].

2) Use [{ / B] to select , then press [OK] within 1

second or wait for 1 second to display the selection

menu.

e.g.) DVD-video

1/ 5 1/ 5

DVD

0:01:00 / 1:23:45

Video

3) Use [K / L] to select a desired zoom factor to zoom,

then press [OK].

1/ 5 1/ 5

DVD

× 1.2

× 1.5

× 2.0

0:01:00 / 1:23:45

Video

Zoom menu will appear.

There are four options

(x1.0, x1.2, x1.5 and x2.0), these are displayed

excluding the current zoom rate.

Zoom area will be displayed.

4) Use [K / L / { / B] to select a desired zoom

position, then press [OK].

Zoom playback will start.

This feature allows you to assign a specific point on a disc

to be called back later.

Press [DVD] first.

1) During playback, press [DISPLAY].

2) Use [{ / B] to select , then press [OK] within 1

second or wait for 1 second to display the marker

list.

e.g.) DVD-video

1/ 5 1/ 5

DVD

0:01:00 / 1:23:45

Video

3) Use [K / L] to select a desired marker number.

When it reaches the desired point, press [OK].

1/ 5 1/ 5

DVD

---

0:01:00 / 1:23:45

Video

The title (track) number and the time will be displayed.

4) To return to the marker later:

Use [K / L] to select the desired marker number,

then press [OK].

Marker Setting

Note

• To clear a marker, select the marker number to be

cleared, then press [CLEAR].

• All markers will be erased when you operate these

operations listed below.

– Opening the disc tray

– Turning off the power

– Record on a recordable disc

• You can mark up to 6 points.

• Marker setting is not available when you play back

the video CD with PBC function.

50 EN50 EN

Using [PREV H] / [NEXT G]

Press [DVD] first.

1) During playback, press [NEXT G] to skip the

current title or chapter and move to the next.

The title or chapter will move forward by one at a time.

• If there is no chapter in one title, the current title will

be skipped.

To go back to the beginning of the current title or

chapter, press [PREV H].

Press it repeatedly to go to the previous title or

chapter. The title or chapter will move backward one

at a time.

Using [DISPLAY]

Press [DVD] first.

1) During playback, press [DISPLAY].

2) Use [{ / B] to select , then press [OK].

e.g.) DVD-video

1/ 5 1/ 5

DVD

0:01:00 / 1:23:45

Video

The number next to will be highlighted.

3) Title:

Use [K / L] or [the Number buttons] to enter a

desired title number to search, then press [OK].

Title search will start.

Chapter:

Press [B] to move to the number next to for

chapter.

Use [K / L] or [the Number buttons] to enter a

desired chapter number to search, then press [OK].

After the search, playback will start automatically.

Title / Chapter Search

Using [PREV H] / [NEXT G]

Press [DVD] first.

1) During playback, press [NEXT G] to skip the

current track/file and move to the next.

The track/file will move forward one at a time.

To go back to the beginning of the current track/file,

press [PREV H].

Press it repeatedly to go to the previous track/file. The

track/file will move backward one at a time.

Track Search

Note

• During CD playback you can enter a track number

directly using [the Number buttons] for track search

without displaying the menu.

• Track search is not available when you play back the

video CD with PBC function.

Using [DISPLAY]

Press [DVD] first.

1) During playback, press [DISPLAY].

2) Use [{ / B] to select , then press [OK].

e.g.) audio CD

1/ 5

0:00:15 / 0:05:00

e.g.) MP3 files

1/ 5 0:00:15

MP3

The number next to will be highlighted.

3) Use [K / L] or [the Number buttons] to enter a

desired track/file number to search, then press

[OK].

After the search, playback will start automatically.

Note

• In search mode display, total numbers of each search

contents (title/chapter/time) are shown as a

denominator.

1/ 5 1/ 5 0:01:00 / 1:23:45

DVD

Video

total number

of titles total number

of chapters

total time

of the title

51EN 51EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

Press [DVD] first.

1) During playback, press [DISPLAY].

2) Use [{ / B] to select , then press [OK].

e.g.) DVD-video

1/ 5 1/ 5 0:01:00 / 1:23:45

DVD

Video

e.g.) audio CD

1/ 5

0:00:15 / 0:05:00

The number next to will be highlighted.

To move to the number next to , press [B].

When time search is not available, and time

counter are not displayed.

3) Use [K / L / { / B] or [the Number buttons] to

enter a desired time to search, then press [OK].

After the search, playback will start automatically.

Note

• Time search is available only in the same track, file or

title.

• Time search is not available when you play back the

video CD with PBC function.

Time Search

52 EN52 EN

REPEAT / RANDOM / PROGRAM PLAYBACK

Repeat Playback

Random Playback

Available repeat function may vary depending the discs.

Press [DVD] first.

1) During playback press [DISPLAY].

2) Use [{ / B] to select , then press [OK] within 1

second or wait for 1 second to display the selection

menu.

1/ 5 1/ 5

DVD

0:01:00 / 1:23:45

Video

3) Use [K / L] to select a desired option to repeat,

then press [OK].

e.g.) DVD-video

1/ 5 1/ 5

DVD

OFF

Title

Chapter

A – B

0:01:00 / 1:23:45

Video

e.g.) audio CD, video CD

1/ 5

0:00:15 / 0:05:00

OFF

Track

All

A – B

e.g.) MP3 files

1/ 5 0:00:15

MP3

53EN 53EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

Program Playback

Note

• To erase tracks you selected, press [CLEAR] at step 4.

• You can make program settings up to 50 tracks.

• To cancel program playback, press [STOP C] twice

during program playback. “OFF” appears on the TV

screen.

• You may also select a desired track using [the

Number buttons] at step 4.

• For video CD with PBC function, the PBC setting will

be switched to off automatically when you start

program playback.

REPEAT / RANDOM / PROGRAM PLAYBACK

You can program the disc to play back in your desired

order.

Press [DVD] first.

1) Press [SETUP].

2) Use [K / L] to select “CD Playback Mode”, then press

[OK].

“CD Playback Mode” menu will appear.

3) Use [K / L] to select “Program Play”, then press

[OK].

4) Use [K / L] to select a desired track, then press [OK]

or [B].

CD Playback Mode

Program Play

0:00:00Total

-- -- -- -- -- -- -- -- -- --

Repeat this step until you program all the desired

tracks.

5) Press [PLAY B].

CD Playback Mode

Program Play

0:31:07Total

09 04 10 06 -- -- -- -- -- --

-- -- -- -- -- -- -- -- -- --

Program playback will start.

54 EN54 EN

DVD-video may have subtitles in 1 or more languages.

Available subtitle languages can be found on the disc

case. You can switch subtitle languages anytime during

playback.

Press [DVD] first.

1) During playback, press [DISPLAY].

2) Use [{ / B] to select , then press [OK] within 1

second or wait for 1 second to display the selection

menu.

e.g.) DVD-video

1/ 5 1/ 5

DVD

0:01:00 / 1:23:45

Video

3) Use [K / L] to select a desired subtitle language,

then press [OK].

1/ 5 1/ 5

DVD

0:01:00 / 1:23:45

OFF

1.English

Video

Subtitle will be displayed in the selected language.

When selecting “OFF”, subtitle will disappear.

SELECTING THE FORMAT OF AUDIO AND VIDEO

Switching Subtitles

Note

• Some discs will only allow you to change the subtitle

from the disc menu. Press [TITLE] or [DISC MENU] to

display the disc menu.

• If a 4-digit language code appears in the subtitle

menu, refer to the “LANGUAGE CODE” on page 87.

You can select the format of audio and video as you prefer depending on the contents of the disc you are playing back.

When playing back a DVD-video recorded with 2 or more

soundtracks (these are often in different languages), you

can switch them during playback.

When playing back video CD, audio CD you can switch

“L/R”(stereo), “L”(left) or “R”(right).

Press [DVD] first.

1) During playback, press [DISPLAY].

2) Use [{ / B] to select , then press [OK] within 1

second or wait for 1 second to display the selection

menu.

3) Use [K / L] to select a desired audio soundtrack or

audio channel, then press [OK].

For DVD-video

• Audio soundtrack will switch.

1/ 5 1/ 5

DVD

0:01:00 / 1:23:45

1.Dolby Digital 5.1ch English

2.Dolby Digital 2ch English

Video

• If the title contains both main and sub audio, you can

further select “L” (main), “R” (sub), or “L/R” (mixed of

main and sub).

For audio CD, video CD

• Audio channel will switch.

e.g.) audio CD

1/ 5

0:00:15 / 0:05:00

1. L/R

2. L

3. R

Switching Audio Soundtrack

Note

• Some discs will only allow you to change the

soundtrack from the disc menu. Press [TITLE] or

[DISC MENU] to display the disc menu.

55EN 55EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

You can enjoy stereophonic virtual space through your

existing 2 channel stereo system.

Press [DVD] first.

1) During playback, press [DISPLAY].

2) Use [{ / B] to select , then press [OK] within 1

second or wait for 1 second to display the selection

menu.

e.g.) DVD-video

1/ 5 1/ 5

DVD

0:01:00 / 1:23:45

Video

3) Use [K / L] to select “OFF”, “Type 1” or “Type 2”,

then press [OK].

e.g.) DVD-video

1/ 5 1/ 5

DVD

0:01:00 / 1:23:45

OFF

Type 1

Type 2

Video

OFF : no effect

Type 1 : natural effect

Type 2 : emphasized effect

Note

• Select “OFF” in a case sound is distorted.

• The setting will be kept even when the unit is turned

off.

Switching Virtual Surround System

SELECTING THE FORMAT OF AUDIO AND VIDEO

Switching Camera Angles

Reducing Block Noise

Some DVD-video have scenes shot from 2 or more

angles. Angle information should be on the disc case if

the disc contains multi-angle scenes.

Press [DVD] first.

1) During playback, press [DISPLAY].

2) Use [{ / B] to select , then press [OK].

e.g.) DVD-video

1/ 5 1/ 5

DVD

0:01:00 / 1:23:45

Video

Angle icon appears when a switching camera angle is

available.

Angle will switch each time you press [OK].

Press [DVD] first.

1) During playback, press [DISPLAY].

2) Use [{ / B] to select , then press [OK] within 1

second or wait for 1 second to display the selection

menu.

e.g.) DVD-video

1/ 5 1/ 5

DVD

0:01:00 / 1:23:45

Video

3) Use [K / L] to select a desired option, then press

[OK]. 1/ 5 1/ 5

DVD

0:01:00 / 1:23:45

Video

OFF

Type 1

Type 2

Your setting will be activated.

This function reduces noise in the playback picture. If

noises appear on the TV screen during playing back

discs recorded in long time recording mode such as EP

or SLP, select “Type 1” or “Type 2”.

(“Type 2” is more effective.)

When playing back discs with a few noises such as

DVD-video, select “OFF”.

Note

• Angle icon does not appear on the TV screen in a

case you set “Angle Icon” to “OFF” in “Playback”

menu. Refer to page 74.

56 EN56 EN

INFORMATION ON DISC EDITING

Guide to a Title List Editing Discs

Title list allows you to check the titles recorded on the

disc easily. You can choose a title to play back from this

list and easily edit the titles as you prefer.

Press [TITLE].

Chapter Mark

Hide Chapter

Index Picture

Title Dividing

Edit Title Name

Title Delete

Edit

NOV/22/07 11:35AM E1 EP

0:00:59

NOV/21/07 11:00

E1 SP

NOV/21/07 0:20:44

Overwrite NOV/22/07 11:35

E1 EP

NOV/22/07 0:10:33

EMPTY TITLE

1:37:52 SP(2Hr)

Play

Edit

SP (2Hr)

789

1. Title list: List of the titles recorded on the disc, and

their information.

2. Arrow: Indicating there is a previous / next page.

3. Title information: On the first line, title name

(editable) is displayed. On the second line, the length

of the title is displayed.

Empty title: The portion of the disc where there is no

recordings are made. As for the empty title, available

recording time by the selected recording mode is

displayed on the second line.

4. Recording mode: Currently selected recording mode

is displayed here.

5. Capacity indicator: Indicating the position and the

amount of each title in the disc. The portion for the

selected title is highlighted.

6. Thumbnails: A cut from the recorded content is

displayed here.

7. Submenu: Submenus for the selected menu are

displayed here.

8. Title name (editable): If you do not name the title,

the recorded date, time, selected external input

position, and the recording mode are displayed here.

9. Progress bar: Indicating the progress of the

playback.

10. Preview window: Preview of the selected title is

displayed here.

11. Playback status: Indicating the current playback

status of the selected title.

Press [STOP C] to exit the title list.

Note

• When selecting “Edit” on pop-up menu of the title

list and edit the title, the title list is displayed after

writing the edited contents onto the disc.

• The capacity indicator in the right side of the title list

may not indicate the precise capacity in the disc.

• The capacity indicator may not indicate the capacity

for the titles of which recording time is short.

• Once you have finalized a DVD+R/DVD-R, you cannot

edit or record anything on that disc.

You can edit discs for the following items. Be sure that

once you edit titles, they will not remain as original.

• Deleting Titles (Refer to page 57.)

• Putting Names on Titles (Refer to page 58.)

• Setting Chapter Marks (Refer to page 59.)

• Clearing Chapter Marks (Refer to pages 60-61.)

• Hiding Chapters (Refer to page 62.)

• Setting Pictures for Thumbnails (Refer to page 63.)

• Dividing a Title (DVD+RW/DVD-RW only)

(Refer to page 64.)

• Putting Name on Disc (Refer to page 65.)

• Setting or Releasing Disc Protect (Refer to page 66.)

• Erasing Disc (Refer to page 67.)

• Making Edits Compatible (Refer to page 68.)

57EN 57EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

EDITING DISCS

3 Use [K / L] to select “Edit”, then

press [OK].

NOV/21/07 11:00

E1 SP

NOV/21/07 0:20:44

Overwrite

NOV/22/07 11:35

E1 EP

NOV/22/07 0:10:33

EMPTY TITLE

1:37:52 SP(2Hr)

SP (2Hr)

Edit

Play

4 Use [K / L] to select “Title Delete”,

then press [OK].

Edit

Title Delete

Edit Title Name

Chapter Mark

Index Picture

Title Dividing

Hide Chapter

NOV/21/07 11:00AM E1 SP

0:00:59

5 Use [K / L] to select “Yes”, then press

[OK].

Edit - Title Delete

Yes

0:00:59

NOV/21/07 11:00AM E1 SP

After that, “Are you sure?” will appear, select

“Yes” and then press [OK].

Title will be deleted.

Data will be written onto the disc momentarily.

Writing to Disc 90%

This operation may take a

while to be completed.

After editing is complete, the title list will appear.

e.g.) DVD+RW/DVD-RW

EMPTY TITLE

0:21:14 SP(2Hr)

NOV/22/07 11:35

E1 EP

NOV/22/07 0:10:33

EMPTY TITLE

1:37:52 SP(2Hr)

SP (2Hr)

You can delete titles which you do not need anymore.

Please be advised that the titles once deleted cannot be

brought back to the disc.

For DVD+RW/DVD-RW, when the last recorded title in the

title list is deleted, the available disc space to record on

will be increased. For DVD+R/DVD-R, the disc space to

record on will not be changed.

Note

• Deleted part of the titles in the capacity indicator

changes in color.

• As for DVD+RW/DVD-RW if you delete the title, deleted

title will be displayed as “EMPTY TITLE”.

Deleting Titles

1 Press [DVD] first.

Press [TITLE].

2 Use [K / L] to select a desired title,

then press [OK].

NOV/21/07 11:00

E1 SP

NOV/21/07 0:20:44

NOV/22/07 11:35

E1 EP

NOV/22/07 0:10:33

EMPTY TITLE

1:37:52 SP(2Hr)

SP (2Hr)

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

PQRS

SOURCE

123

456

Biji

DISPLAY OPEN/CLOSE

TITLE

58 EN58 EN

EDITING DISCS

Putting Names on Titles

4 Use [K / L] to select “Yes”, then press

[OK].

Edit - Edit Title Name

Yes

MY FAVORITE

0:00:59

The name you entered will be activated for the title.

5 After this operation is completed,

press [RETURN] to exit.

Data will be written onto the disc momentarily.

This operation may take a

while to be completed.

You can put title names on the titles and change the

names from this menu.

1) Use [K / L] to select a desired character set, then

press [OK].

2) Follow the list below, use [the Number buttons]

repeatedly until the desired letter appears.

ABC

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

abc

def

ghi

jkl

mno

pqrs

tuv

wxyz

! ” # $ % & ’ ( )

* + , - . / : ; < = >

? @ [ ] ^ _ { | }

ABC abc @ ! ?

123

(*1) (*1)

(*2)

Select

Press

*1 Press

, character set will be changed to the “ @!? ”

mode automatically.

*2 Press

, character set will be changed to the

previous input mode automatically.

• To delete letters, press [CLEAR] repeatedly.

Holding [CLEAR] to delete all letters.

• Use [s / B] to move the cursor to the left and right.

• You can enter up to 30 letters.

Note

• Undefined letters in a title name are shown by “*”. If

you delete them, adjoining letters may change to “*”

or other.

Guide to Edit Title Name

1 Follow steps 1 to 3 in “Deleting

Titles” on page 57 to display “Edit”

menu.

2 Use [K / L] to select “Edit Title

Name”, then press [OK].

Edit

Title Delete

Edit Title Name

Chapter Mark

Index Picture

Title Dividing

Hide Chapter

NOV/21/07 11:00AM E1 SP

0:00:59

3 To enter a title name, follow the

steps of “Guide to Edit Title Name”

on this page.

Edit - Edit Title Name

abc

ABC

123

@! ?

0:00:59

1character set

area for entering title names

When you finish entering a title name, press [OK].

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

PQRS

SOURCE

123

456

Biji

DISPLAY OPEN/CLOSE

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACE

PQRS

123

456

CLEAR

RETURN

OK Bs

59EN 59EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

EDITING DISCS

Setting Chapter Marks

1 Follow steps 1 to 3 in “Deleting

Titles” on page 57 to display “Edit”

menu.

2 Use [K / L] to select “Chapter Mark”,

then press [OK].

Submenu will appear.

3 Press [PLAY B] and then [PAUSE F]

to decide the point at which you will

create a new chapter mark.

• It is convenient to use [PREV H], [NEXT G],

[E] and [D] for finding the point to add a

new chapter mark.

4 Use [K / L] to select “Add”, then press

[OK].

Delete

Delete All

Add

NOV/21/07 11:00AM E1 SP

0:00:59

Chapter 2/ 2

Edit - Chapter Mark

5 Use [K / L] to select “Yes”, then press

[OK].

Edit - Chapter Mark - Add

Yes

NOV/21/07 11:00AM E1 SP

0:00:59

Chapter 2/ 2

A new chapter mark will be added.

6 Press [RETURN] twice to exit.

Data will be written onto the disc momentarily.

This operation may take a

while to be completed.

You can put chapter marks in each title. Once a chapter is

marked, you can use it for the chapter search feature.

Note

• When the number of chapter marks in a title is 99

and the number of chapter marks in a disc is 254,

chapter marks cannot be added.

• Besides the above-mentioned, it is not likely to be

able to add according to recorded time and number

of chapters.

• Remaining time of the disc may decrease when

adding chapter marks or increase when clearing

chapter marks depending on the recording time or

edited contents.

60 EN60 EN

EDITING DISCS

Clearing Chapter Marks

1 Follow steps 1 to 3 in “Deleting

Titles” on page 57 to display “Edit”

menu.

2 Use [K / L] to select “Chapter Mark”,

then press [OK].

Submenu will appear.

3 Use [PREV H] / [NEXT G] to select

a chapter mark to be deleted.

4 Use [K / L] to select “Delete”, then

press [OK].

5 Use [K / L] to select “Yes”, then press

[OK].

Edit - Chapter Mark - Delete

Yes

NOV/21/07 11:00AM E1 SP

0:00:59

Chapter 2/ 2

The selected chapter mark will be deleted.

6 Press [RETURN] twice to exit.

Data will be written onto the disc momentarily.

This operation may take a

while to be completed.

Note

• Remaining time of the disc may decrease when

adding chapter marks or increase when clearing

chapter marks depending on the recording time or

edited contents.

61EN 61EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

EDITING DISCS

Clearing Chapter Marks (cont’d)

To delete all chapter marks:

1 Follow steps 1 to 3 in “Deleting

Titles” on page 57 to display “Edit”

menu.

2 Use [K / L] to select “Chapter Mark”,

then press [OK].

Submenu will appear.

3 Use [K / L] to select “Delete All”,

then press [OK].

4 Use [K / L] to select “Yes”, then press

[OK].

Edit - Chapter Mark - Delete All

Yes

NOV/21/07 11:00AM E1 SP

0:00:59

Chapter 2/ 2

5 Use [K / L] to select “Yes”, then press

[OK].

Chapter 2/ 2

Edit - Chapter Mark - Delete All

Yes

Are you sure?

NOV/21/07 11:00AM E1 SP

0:00:59

All chapter marks will be deleted.

6 Press [RETURN] twice to exit.

Data will be written onto the disc momentarily.

This operation may take a

while to be completed.

Note

• Remaining time of the disc may decrease when

adding chapter marks or increase when clearing

chapter marks depending on the recording time or

edited contents.

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

NB552

RETURN

62 EN62 EN

EDITING DISCS

Hiding Chapters

1 Follow steps 1 to 3 in “Deleting

Titles” on page 57 to display “Edit”

menu.

2 Use [K / L] to select “Hide Chapter”,

then press [OK].

Submenu will appear.

3 Use [PREV H] / [NEXT G] to decide

the chapter to be hidden.

4 Use [K / L] to select “Hidden”, then

press [OK].

Edit - Hide Chapter

Hidden

Visible

0:00:59

NOV/21/07 11:00AM E1 SP

Chapter 2/ 2 Visible

5 After this operation is completed,

press [RETURN] twice to exit.

Data will be written onto the disc momentarily.

This operation may take a

while to be completed.

If you want hidden chapters to be “Visible”,

select the chapter to be shown. Then use

[K / L] to select “Visible” at the step 4 on this

page.

Data will be written onto the disc momentarily.

After that, title list is displayed.

Note

• ”Hidden” will be displayed in the preview window

while previewing the hidden chapter.

• When you make all chapters in the title “Hidden”,

“Hidden” is displayed in a thumbnail of the title list.

NOV/22/07 11:35

E1 EP

NOV/22/07 0:10:33

NOV/21/07 11:00

E1 SP

NOV/21/07 0:20:44

Hidden

EMPTY TITLE

1:37:52 SP(2Hr)

SP (2Hr)

You can hide chapters from the title list.

Hidden chapters are skipped during playback.

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

NB552

RETURN

iij

63EN 63EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

EDITING DISCS

Setting Pictures for Thumbnails

1 Follow steps 1 to 3 in “Deleting

Titles” on page 57 to display “Edit”

menu.

2 Use [PREV H], [NEXT G], [E],

[D], [PAUSE F] and [PLAY B] to

decide the picture you want to select

as a thumbnail.

3 Use [K / L] to select “Index Picture”,

then press [OK].

4 Use [K / L] to select “Yes”, then press

[OK].

Yes

64 EN64 EN

EDITING DISCS

Dividing a Title

1 Follow steps 1 to 3 in “Deleting

Titles” on page 57 to display “Edit”

menu.

2 Use [PREV H], [NEXT G], [E],

[D], [PAUSE F] and [PLAY B] to

decide the point at which you will

divide the title.

3 Use [K / L] to select “Title Dividing”,

then press [OK].

4 Use [K / L] to select “Yes”, then press

[OK].

Yes

Edit - Title Dividing

NOV/21/07 11:00AM E1 SP

0:00:59

The title will be divided into 2 new titles.

Both title names are identical, and index pictures

are reset to the first scene at this point.

Data will be written onto the disc momentarily.

This operation may take a

while to be completed.

You can divide one title into 2 new titles.

Note

• You cannot divide a title of the disc when the

number of recording titles reaches the maximum of

49, and the number of recording chapters reaches

the maximum of 254.

65EN 65EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

Putting Name on Disc

Press [STOP C] if you are playing back a disc.

1 Press [DVD] first.

Press [SETUP].

2 Use [K / L] to select “Disc Edit”, then

press [OK].

3 Use [K / L] to select “Edit Disc

Name”, then press [OK].

e.g.) DVD+RW

Disc Edit

Edit Disc Name

Erase Disc

Make Edits Compatible

Disc Protect OFF ON

A window for entering a title name will appear.

Edit Disc Name

abc

ABC

123

@! ?

0:00:00

No Disc Name

Disc DVD+RW

Total Titles 3

Disc Space Used 0:30:48

Disc Protect OFF

Make Edits Compatible Needed

4 To enter a disc name, follow the steps

of “Guide to Edit Title Name” on page

58.

When you finish entering a title name, press

[OK].

5 Use [K / L] to select “Yes”, then press

[OK].

Edit Disc Name

0:00:00

MY FAVORITE DISC

Yes

No Disc Name

Disc DVD+RW

Total Titles 3

Disc Space Used 0:30:48

Disc Protect OFF

Make Edits Compatible Needed

The name you entered will be activated for the title.

Data will be written onto the disc momentarily.

This operation may take a

while to be completed.

Note

• You cannot select “Disc Edit” when finalized DVD+R

or DVD-R is inserted.

You can put a name on the disc and change it from this

menu.

EDITING DISCS

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

NB552

SETUP

DVD

66 EN66 EN

EDITING DISCS

Setting or Releasing Disc Protect

1 Follow steps 1 to 2 in “Putting Name

on Disc” on page 65 to display “Disc

Edit” menu.

2 Use [K / L] to select “Disc Protect

OFF ON”, then press [OK].

e.g.) DVD+RW

Disc Edit

Edit Disc Name

Erase Disc

Make Edits Compatible

Disc Protect OFF ON

• If the disc is already protected, “Disc Protect ON

OFF” will appear instead of “Disc Protect OFF

ON”.

3 Use [K / L] to select “Yes”, then press

[OK].

Disc Edit

Edit Disc Name

Erase Disc

Make Edits Compatible

Disc Protect OFF ON

Protect this disc?

Yes

Data will be written onto the disc momentarily.

This operation may take a

while to be completed.

To prevent accidental editing, or erasing the titles, you

can protect them.

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

NB552

67EN 67EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

EDITING DISCS

Erasing Disc

Press [STOP C] if you are playing back a disc.

1 Follow steps 1 to 2 in “Putting Name

on Disc” on page 65 to display “Disc

Edit” menu.

2 Use [K / L] to select “Erase Disc”,

then press [OK].

e.g.) DVD+RW

Disc Edit

Edit Disc Name

Erase Disc

Make Edits Compatible

Disc Protect OFF ON

3 Use [K / L] to select “Yes”, then press

[OK].

Disc Edit

Edit Disc Name

Erase Disc

Make Edits Compatible

Disc Protect OFF ON

When you press “Yes”, all the

contents in the disc will be erased.

Are you sure to erase the disc?

Yes

Data will be written onto the disc momentarily.

This operation may take a

while to be completed.

You can erase all titles on a disc.

Note

• When you select “Yes” at step 3, all contents of the

disc will be erased.

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

NB552

68 EN68 EN

EDITING DISCS

Making Edits Compatible

Press [STOP C] if you are playing back a disc.

1 Follow steps 1 to 2 in “Putting Name

on Disc” on page 65 to display “Disc

Edit” menu.

2 Use [K / L] to select “Make Edits

Compatible”, then press [OK].

Disc Edit

Edit Disc Name

Erase Disc

Make Edits Compatible

Disc Protect OFF ON

3 Use [K / L] to select “Yes”, then press

[OK].

Disc Edit

Edit Disc Name

Erase Disc

Make Edits Compatible

Disc Protect OFF ON

Activate the Make Edits Compatible?

Yes

Data will be written onto the disc momentarily.

This operation may take a

while to be completed.

If you have added or deleted chapters, or made chapters

hidden, you must perform “Make Edits Compatible” to

see those effects on other unit.

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

NB552

69EN 69EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

LIST OF SETTINGS

The following table is the contents which you can set and the default setting. Refer to the following table for useful operation.

Setup Items (highlight is the default) Contents

General Setting

Playback

Pages 71-74

Parental Lock OFF

level 8 [Adult] to 1 [Kid Safe]

Set the parental level for DVD playback.

Disc Audio Dynamic Range

Control ON

OFF

Compressing the range of sound volume.

PCM 48kHz

96kHz

Set whether the sound recorded in 96kHz will

be down sampled in 48kHz.

Dolby Digital PCM

Stream

Set the type of sound signal which outputs

from the digital audio output jack.

Disc Menu Language English

French

Spanish

Other

Set the language for disc menu language.

Audio Language Original

English

French

Spanish

Other

Set the language for audio.

Subtitle Language OFF

English

French

Spanish

Other

Set the language for subtitles.

Angle Icon ON

OFF

Set whether or not to display the angle icon.

Still Mode Auto

Field

Frame

Set the type of still image in pausing playback.

Display

Page 75

OSD Language English

Français

Español

Set the language for OSD (on-screen display).

Screen Saver OFF

5minutes

10minutes

15minutes

30miniutes

Set the idling time before the screen saver

starts.

FL Dimmer Auto

Bright

Dark

Set the brightness of the front panel display.

Video

Pages 76-77

Progressive Scan ON

OFF

Set to the progressive scan mode (set to "ON")

or to the interlace scan mode(set to "OFF").

TV Aspect 4:3 Letter Box

4:3 Pan & Scan

16:9 Wide

Set a picture size according to aspect ratio of

your TV.

Video Input

Page 14

E1(Rear) Video In

S-Video In

Set the video input type for the external input.

E2(Front) Video In

S-Video In

70 EN70 EN

LIST OF SETTINGS

Note

• Your change to each settings stays on even when the power is off.

• An item which is not currently available is grayed in the settings.

Setup Items (highlight is the default) Contents

General Setting

Recording Auto Chapter

Page 23

OFF

5 minutes

10 minutes

15 minutes

30 minutes

60 minutes

Insert chapter marks at even time interval.

Auto Finalize

Page 38

Disc Full ON

OFF

Set the unit to finalize the disc automatically.

End of Timer Rec ON

OFF

Dubbing Mode Pages 39-40 VCR DVD

DVD VCR

Set the VCR to DVD (DVD to VCR) duplication.

Make Recording Compatible

Page 23

OFF

Set to prohibiting additional recording (OFF)

or to replace the title list after recording (ON).

Clock

Page 21

Clock Setting Set the clock.

Reset All Page 78 Yes

Set to the default setting.

71EN 71EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

SETUPS

Press [STOP C] if you are playing back a disc.

1 Press [SETUP] and use [K / L] to

select “General Setting”, then press

[OK].

“General Setting” menu will appear.

2 Use [K / L] to select “Playback”, then

press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

3 Use [K / L] to select a desired item,

then press [OK].

Parental Lock

Disc Audio

Disc Menu Language

Audio Language

Subtitle Language

Angle Icon

Still Mode

Submenu will appear.

4 Refer to 1 to 7 on pages 72-74 and

set the selected item.

5 When you finish with setting, press

[SETUP] to exit.

Playback

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

NB552

OPEN/CLOSE

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACE

PQRS

123

456

SETUP

CLEAR

72 EN72 EN

SETUPS

1Parental Lock (Default: OFF)

Some DVD-video feature a parental lock level. Playback

will stop if the ratings exceed the levels you set, it will

require you to enter a password before the disc will

playback. This feature prevents your children from

viewing inappropriate material.

Use [K / L] to select the desired level, then press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Parental Lock

Audio Out

Disc Menu Language

Audio Language

Subtitle Language

Angle Icon

Still Mode

Parental Lock

OFF

8 [Adult]

7 [NC 17]

6 [R]

5 [PG R]

4 [PG 13]

3 [PG]

2 [G]

1 [Kid Safe]

If a password has not been set yet, proceed to A.

If a password has been set already, proceed to B.

Note

• Parental lock function may not be available to some

discs.

• With some DVD, it may be difficult to find if they are

compatible with parental lock. Be sure to check if the

parental lock function operates in the way that you

have set.

• Record the password in case you forget it.

• If there is a DVD in the unit when you set up the

parental lock, press [OPEN/CLOSE A] to activate the

parental lock level.

A A password has not been set yet.

Use [K / L] to select “Yes”. Use [the Number buttons]

to enter a new password except for 4737, then press

[OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Parental Lock

Audio Out

Disc Menu Language

Audio Language

Subtitle Language

Angle Icon

Still Mode

Parental Lock

OFF

8 [Adult]

7 [NC 17]

6 [R]

5 [PG R]

4 [PG 13]

3 [PG]

2 [G]

1 [Kid Safe]

Change Password?

Yes

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Parental Lock

Audio Out

Disc Menu Language

Audio Language

Subtitle Language

Angle Icon

Still Mode

Parental Lock

OFF

8 [Adult]

7 [NC 17]

6 [R]

5 [PG R]

4 [PG 13]

3 [PG]

2 [G]

1 [Kid Safe]

Change Password?

Yes

Password Input

Yes

Your setting will be activated.

B A password has been set already.

• Use [the Number buttons] to enter the current

password.

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Parental Lock

Audio Out

Disc Menu Language

Audio Language

Subtitle Language

Angle Icon

Still Mode

Parental Lock

OFF

8 [Adult]

7 [NC 17]

6 [R]

5 [PG R]

4 [PG 13]

3 [PG]

2 [G]

1 [Kid Safe]

Password Input

Your setting will be activated.

• If you want to change password, use [K / L] to select

“Yes”. Use [the Number buttons] to enter a new

password, then press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Parental Lock

Audio Out

Disc Menu Language

Audio Language

Subtitle Language

Angle Icon

Still Mode

Parental Lock

OFF

8 [Adult]

7 [NC 17]

6 [R]

5 [PG R]

4 [PG 13]

3 [PG]

2 [G]

1 [Kid Safe]

Change Password?

Yes

Password Input

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Parental Lock

Audio Out

Disc Menu Language

Audio Language

Subtitle Language

Angle Icon

Still Mode

Parental Lock

OFF

8 [Adult]

7 [NC 17]

6 [R]

5 [PG R]

4 [PG 13]

3 [PG]

2 [G]

1 [Kid Safe]

Change Password?

Yes

Your setting will be activated.

Note

• Press [CLEAR] to erase numbers entered incorrectly.

• When you forget the password or you want to clear

all settings in “Parental Lock” menu, enter 4,7,3,7

using [the Number buttons] in password input

window. Password will be cleared and parental levels

will be set to “OFF”.

Playback (cont’d)

73EN 73EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

SETUPS

2Disc Audio

Choose the appropriate audio setting for your external device.

It will only affect a disc playback.

Use [

] to select a desired item, then press

[OK]

General Setting

Playback

Display

Video

Recording

Clock

Reset All

74 EN74 EN

SETUPS

3Disc Menu Language (Default : English)

Set the language for disc menu.

Use [K / L] to select a setting, then press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Parental Lock

Audio Out

Disc Menu Language

Audio Language

Subtitle Language

Angle Icon

Still Mode

Disc Menu Language

English

French

Spanish

Other

Your setting will be activated.

4Audio Language (Default : Original)

Set the audio language.

Use [K / L] to select a setting, then press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Parental Lock

Audio Out

Disc Menu Language

Audio Language

Subtitle Language

Angle Icon

Still Mode

Audio Language

Original

English

French

Spanish

Other

Your setting will be activated.

• When “Original” is selected, the audio language will be

in the disc’s default language.

5Subtitle Language (Default : OFF)

Set the subtitle language.

Use [K / L] to select a setting, then press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Parental Lock

Audio Out

Disc Menu Language

Audio Language

Subtitle Language

Angle Icon

Still Mode

Subtitle Language

OFF

English

French

Spanish

Other

Your setting will be activated.

If “Other” is selected for 3 to 5, press 4-digit code

using [the Number buttons].

Code Input

----

• When you finish entering the code, press [OK]. Refer

to the language code table on page 87.

Note

• Only the languages supported by the disc can be

selected.

• Audio language setting may not be available to

some discs.

• You can change or switch off the subtitles on a DVD

also from the disc menu if it is available.

• Press [CLEAR] or [s] to erase numbers entered

incorrectly.

6Angle Icon (Default : ON)

Set to “ON” to show the angle icon during the playback.

Use [K / L] to select a setting, then press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Parental Lock

Disc Audio

Disc Menu Language

Audio Language

Subtitle Language

Angle Icon

Still Mode

Angle Icon

OFF

Your setting will be activated.

7Still Mode (Default : Auto)

Select “Auto” usually.

Use [K / L] to select a setting, then press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Parental Lock

Audio Out

Disc Menu Language

Audio Language

Subtitle Language

Angle Icon

Still Mode

Auto

Field

Frame

Your setting will be activated.

Auto : Optimum resolution setting (“Field” or

“Frame”) will be selected.

Field : Images in the still mode will be stabilized.

Frame : Images in the still mode will be highly defined.

Note

•

Frame is 1 completed video image made up of 2

fields (There are 30 frames per second of NTSC video).

Playback (cont’d)

75EN 75EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

SETUPS

Display

Press [STOP C] if you are playing back a disc.

1 Press [SETUP] and use [K / L] to

select “General Setting”, then press

[OK].

2 Use [K / L] to select “Display”, then

press [OK].

3 Use [K / L] to select a desired item,

then press [OK].

OSD Language

Screen Saver

FL Dimmer

Selection menu will appear.

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

NB552

SETUP

4 Refer to 1 to 3 on this page and set

the selected item.

5 When you finish with setting, press

[SETUP] to exit.

1OSD Language (Default : English)

Set the language for the on-screen display.

Use [K / L] to select a setting, then press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

OSD Language

Screen Saver

FL Dimmer

OSD Language

English

Français

Español

Your setting will be activated.

2Screen Saver (Default : 10 minutes)

Set the time to activate the screen saver function on the

TV screen.

Use [K / L] to select a setting, then press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

OSD Language

Screen Saver

FL Dimmer

Screen Saver

OFF

5 minutes

10 minutes

15 minutes

30 minutes

Your setting will be activated.

3FL Dimmer (Default: Bright)

Set the front panel display brightness.

Use [K / L] to select a setting, then press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Channel

Reset All

OSD Language

Screen Saver

FL Dimmer

Auto

Bright

Dark

You can choose one from “Auto”, “Bright” and “Dark”.

If “Auto” is selected, the display gets dark when the

power is off.

76 EN76 EN

SETUPS

Press [STOP C] if you are playing back a disc.

1 Press [SETUP] and use [K / L] to

select “General Setting”, then press

[OK].

2 Use [K / L] to select “Video”, then

press [OK].

3 Use [K / L] to select a desired item,

then press [OK].

Progressive Scan

TV Aspect

Video Input

Submenu will appear.

4 Refer to 1 to 2 on page 77 and set

the selected item.

• For 3 refer to page 14.

5 When you finish with setting, press

[SETUP] to exit.

Video

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

NB552

SETUP

OK B

77EN 77EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

1Progressive Scan (Default : OFF)

This unit is compatible with the progressive scan system.

The feature provides you with the higher definition

images than the traditional output system does. To utilize

this feature, you must set progressive scan mode to “ON”.

1) Use [K / L] to select “ON“, then press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Progressive Scan

TV Aspect

Video Input

Progressive Scan

OFF

2) Use [{ / B] to select “Yes“, then press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Progressive Scan

TV Aspect

Select Video

Progressive Scan

OFF

Activating progressive scan:

Check your TV has progressive scan

and connect with component video cable.

NOTE :

Activate? Yes No

If there is no picture or picture is

distorted after selecting “Yes”,

Wait about 15 seconds for auto recovery.

3) Use [K / L] to select “Yes“ within 15 seconds, then

press [OK].

Your setting will be activated.

Note

• If your TV is compatible with progressive scan (525p /

480p), you are recommended to use the component

video cable (commercially available) to connect this

unit to the TV. (Refer to “Method 2” on page 15.) If

not, use the RCA video cable and set the progressive

scan to “OFF” or press and hold [SETUP] for more

than 3 seconds during DVD playback.

• When selecting “No” or not pressing any buttons on

the unit or remote control within 15 seconds at step 3,

progressive scan remains to be “OFF” (interlace scan).

2TV Aspect (Default: 4:3 Letter Box)

You can select the TV aspect ratio to match the formats of

what you are playing back with the unit and your TV

screen (4:3 standard or 16:9 widescreen TV).

Use [K / L] to select a setting, then press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Progressive Scan

TV Aspect

Video Input

TV Aspect

4:3 Letter Box

4:3 Pan & Scan

16:9 Wide

If you have a standard TV:

Select “4:3 Letter Box”, so that black bars appear on the

top and bottom of the TV screen when playing back a

wide-screen picture. Select “4:3 Pan & Scan” for a full

height picture with both sides trimmed when playing

back wide-screen picture.

If you have a widescreen TV:

Select “16:9 Wide”.

Video (cont’d)

SETUPS

78 EN78 EN

Reset the setting to default. 1 Press [SETUP] and use [K / L] to

select “General Setting”, then press

[OK].

“General Setting” menu will appear.

2 Use [K / L] to select “Reset All”, then

press [OK].

3 Select “Yes” using [K / L] , then press

[OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Reset to factory default?

Yes

4 Select “Yes” again using [K / L] ,

then press [OK].

General Setting

Playback

Display

Video

Recording

Clock

Reset All

Reset to factory defauit?

Yes

Are you sure?

Yes

Your setting in recording will be initialized.

Reset All

SETUPS

Note

• The settings listed below will remain unchanged

even after resetting to the factory default.

– OSD language setting

– Clock setting

– Parental lock setting

– Timer programming information

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

NB552

SETUP

79EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

VCR FUNCTIONS

Playback Recording

1) Press [STANDBY-ON

] on the remote control or

the front panel of the unit.

When you are playing back a cassette tape, turn the TV

on and be sure to select the input to which the unit is

connected.

Press [VCR].

2) Insert a prerecorded cassette tape. Press [PLAY B]

to begin playback.

3) During playback, press [PAUSE F].

Playback will pause and sound will be muted.

4) Press [PLAY B] to resume playback.

5) Press [STOP C] to stop playback.

6) Press [STOP C / EJECT A] on the front panel of the

unit to eject the cassette tape.

Note

• When a cassette tape without erase-protection tab is

inserted, the unit will start playback automatically.

• Tracking will be automatically adjusted upon

playback. To adjust the tracking manually, press

[TRACKING / ].

Press [VCR] first.

Before recording, make sure:

• The appropriate external input position (E1/E2) to which

your external tuner is connected is selected by pressing

[SOURCE].

• There is a cassette tape with a erase-protection tab in

the unit.

• The desired recording mode is selected in SP (standard

playback) or SLP (super long playback) mode by

pressing [REC MODE].

Recording mode:

Tape speed Recording / playback time

Type of tape T60 T120 T160

SP mode 1hour 2hours 2-2/3hours

SLP mode 3hours 6hours 8hours

• Refer to pages 26-29 for instructions on timer recording.

1) Press [REC I] to begin the recording.

To temporarily stop recording or to resume it, press

[PAUSE F]. After the unit has been in pause mode for

5 minutes, it will stop automatically to protect the

cassette tape and the video head from damage.

2) Press [STOP C] when the recording is completed.

Accidental erasure prevention

To prevent accidental recording on a

recorded cassette tape, remove its erase-

protection tab. To record on it later, cover

the hole with cellophane tape. erase-protection tab

80 EN

VCR FUNCTIONS

One-touch Timer Recording (OTR) Index Search

This feature allows you to set the recording length simply

by pressing [REC I] on the remote control.

Press [VCR] first.

1) During normal recording, press [REC I] to begin

the one-touch timer recording.

You can select a fixed recording time by pressing

[REC I] repeatedly.

(0:30) (1:00)

(Normal recording)

(7:30)(8:00)

When the one-touch timer recording is finished, the

unit will turn off automatically.

To change the recording length during the one-touch

timer recording, press [REC I] repeatedly until the

desired length appear.

To cancel the one-touch timer recording within the

specified time, press [STOP C].

Note

• To see the remaining recording time on the TV

screen during the one-touch timer recording, press

[DISPLAY].

• You cannot pause the one-touch timer recording.

• If VCR the one-touch timer recording is completed

during DVD playback or recording, the VCR will be in

stop mode and the DVD keeps the current mode.

• Unlike a timer recording, you can perform the

following operations during the one-touch timer

recording.

- Turning off the power to stop one-touch timer

recording.

- Using [REC I] or [STOP C].

• When the one-touch timer recording is finished and

the power is turned off, the unit will switch to the

standby mode automatically if a timer recording has

been programmed. Press [TIMER SET] to cancel the

standby mode for using the unit continuously.

An index mark will be assigned at the beginning of each

recording you make. You may skip to a specific marked

point by following the steps below.

Press [VCR] first.

1) Press [SEARCH] so that “INDEX SEARCH” menu

appears.

2) Using [the Number buttons], enter the number of

recordings you wish to skip within 30 seconds.

INDEX SEARCH

3) Press [E], [D] to start index search.

If you want to go in the forward direction, press [ D].

If you want to go in the reverse direction, press [E].

After index search, the VCR will play back the cassette

tape automatically.

Pro.1 Pro.2 Pro.3 Pro.4 Pro.5

02 01 01 02 03

Beginning

of tape End

of tape

CURRENT PROGRAM

INDEX MARK

Note

• You can make the index mark up to 20.

81EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

VCR FUNCTIONS

Time Search Other Operations

This feature allows you to go to a specific point on a

cassette tape by entering the exact amount of time you

wish to skip in order to reach the point.

Press [VCR] first.

1) Press [SEARCH] repeatedly so that “TIME SEARCH”

menu appears.

2) Using [the Number buttons], enter your desired

time to skip within 30 seconds.

You can set the time up to 9:59.

TIME SEARCH

2:50

3) Press [E], [D] to start time search.

If you want to go in the forward direction, press [D].

If you want to go in the reverse direction, press [E].

After time search, the unit will play back the cassette

tape automatically.

Note

• Index search and time search are not available

during recording.

• Press [STOP C] to stop the search.

• If the end of the cassette tape is reached during

search, this unit will cancel the search and rewind the

cassette tape.

82 EN82 EN

TROUBLESHOOTING

Before requesting service for this unit, check the table below for a possible cause of the problem you are experiencing.

Some simple checks or a minor adjustment on your part may eliminate the problem and restore proper operation.

Symptom Remedy

•

The power does not turn on. • Check that the AC power cord is connected securely.

• Check the breaker (in case of power failure).

• Press [TIMER SET] to cancel the timer standby mode.

There is no picture. • Re-connect the connecting cords securely.

• Check if the connecting cords are damaged.

• Check the connection to your TV (page 15).

• Switch the input selector on your TV (such as to “E1”) so that the signal

from the unit appears on the TV screen.

Cannot record a TV program. • This unit does not have a tuner to receive TV broadcasting.

• You must connect this unit to an external tuner to record TV programs

(page 13).

TV program pictures are distorted. • Check if all the connections are made correctly.

Playback picture is distorted. • Keep the device which may cause electrical disturbances, such as a

cellular phone, away.

There is no sound. • Re-connect all connections securely.

• Check if the connecting cord is damaged.

• Check the connections to the amplifier input.

• Check if the input device setting on the amplifier is correct.

• When the unit is in pause mode or in slow-motion playback mode,

sound is not output. This is not a malfunction.

• When the unit is in fast forward or fast reverse mode, sound is not

output. This is not a malfunction.

Nothing was recorded even though

you set the timer setting correctly.

• There was a power failure during recording.

• The unit’s internal clock stopped due to a power failure that lasted for

more than 30 seconds. Reset the clock (page 21).

• The program contains copy protection signals that restricts copying.

• The timer setting overlapped with another setting that has priority.

Timer recording is not complete or

did not start from the beginning.

• The timer setting overlapped with another setting that has priority (page 29).

• Disc space was not enough.

Timer recording is impossible. • Make sure appears on the front panel display of this unit. If not, press

[TIMER SET].

The remote control does not function. • Batteries are weak.

• There are obstacles between the remote control and the unit.

• The remote control is far from the unit.

• There are no batteries in the remote control.

• Check if the unit is turned on.

• Check if you are pointing the remote control at the recorder and NOT

the TV.

If you have a plasma TV, it may interfere with the IR signal. Try the

remote with the plasma off. If the remote works, you may need to move

the unit away from the plasma TV.

• Press [DVD] or [VCR], whichever you need. Then, try again.

• Press [TIMER SET] to cancel the timer standby mode.

The unit does not operate properly. • When static electricity, etc., causes the unit to operate abnormally,

unplug the unit and then plug it in again.

83EN 83EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

TROUBLESHOOTING

Symptom Remedy

There is no picture. • If the main menu appears on the TV screen, press [RETURN] to exit.

• Check if the progressive scan mode is set correctly according to your TV

(page 77).

Picture noise appears. • Clean the disc with a cleaning cloth.

Playback picture from the external

devices connected to this unit is

distorted.

• If the picture output signal from the external devices passes through

this unit to get to your TV, the copy protection signal applied to some

DVD could affect the picture quality. Disconnect the playback device in

question and connect it directly to your TV.

There is no sound. • If you are using DIGITAL AUDIO OUTPUT (COAXIAL) jack, check the setting

in “Disc Audio” (page 73).

• Clean the disc with a cleaning cloth.

Sound is noisy. • Clean the disc with a cleaning cloth.

No DTS sound is output. • This unit is not compatible with DTS sound.

The disc does not play back. • No disc is inserted.

• A blank disc is inserted.

• The disc is upside down. Insert the disc with the labeled side facing up.

• The disc is not correctly inserted.

• The unit cannot play back certain discs (such as a CD-ROM) (page 41).

• The region code on the DVD-video does not match the unit (page 41).

• Moisture has condensed inside the unit. Remove the disc and leave the

unit turned on for about 2 hours until the moisture evaporates (page 4).

• If the disc was recorded on another recorder, the unit cannot play back

the disc if it was not finalized.

Discs recorded on this unit cannot be

played back on other DVD players.

• If you are using DVD+R, DVD-RW/-R disc, please ensure you finalized the

disc after recording (page 37).

The disc does not start playback from

the beginning.

• Resume playback was activated (page 47). Press [STOP C] twice.

• You have inserted a disc whose title menu or DVD menu automatically

appears on the TV screen when it is first insert.

The unit starts playing back the disc

automatically.

• The DVD-video features an auto playback function.

Some functions such as stop, search,

or slow-motion playback cannot be

performed.

• Depending on the disc, you may not be able to do some of the

operations. Refer to the manual supplied with the disc.

The language for the sound track

cannot be changed.

• The title does not have the multilingual audio tracks.

• The DVD-video prohibits the changing of the language for the sound

track.

The subtitle language cannot be

changed or turned off.

• Multilingual subtitle are not recorded on the DVD-video.

The angles cannot be changed. • Multi-angles are not recorded on the DVD-video being played back.

• The angle-change operation is whenever possible as long as the disc

contains a multi-angle portion. Actual change will be performed when

the portion has come up.

• The DVD-video prohibits changing angles.

• Try changing the angle using the DVD-video’s menu.

Recording does not stop immediately

after you press [STOP C].

• It may take a few seconds for the unit to input disc data before

recording stops.

The disc tray does not open when you

press [OPEN/CLOSE A].

• It may take a few seconds for the disc tray to open after you have

recorded or edited a disc. This is because the unit is adding disc data to

the disc.

84 EN84 EN

TROUBLESHOOTING

Symptom Remedy

“Repairing” appears on the TV screen.

Repairing

• If there is a power failure or unplugging during recording, finalizing,

formatting or editing (even after “Repairing” disappears), a repairing

process will begin automatically just after turning the unit on again.

It may take several minutes up to about several hours.

In a case you intend to cancel the

repairing process.

Repairing

Do you want to cancel a repairing process ?

When selecting “Yes”, the disc may not be

usable.

Yes

• If you intend to cancel the repairing process, press [OPEN/CLOSE A]

on the front panel, then select “Yes” and press [OK]. After that, press

[OPEN/CLOSE A] to take out the disc. The disc canceled during the

repairing process MAY NOT work.

Picture noise appears. • Head cleaning for VCR may be necessary. Refer to “Auto head cleaning”

(page 5).

• Adjust tracking control for better picture by pressing [TRACKING / ]

while you are playing back a cassette tape.

The cassette tape does not play back. • No cassette tape is inserted.

Recording does not start after you

press [REC I].

• Make sure the cassette tape has a erase-protection tab when you record

to a cassette tape. If needed, cover the hole with cellophane tape.

The remote control does not function. • Check if a cassette tape is in this unit.

The motor rotates even when

playback / recording is stopped.

• The motor may rotate for the duration of approximately 5 minutes for

efficient operation. This is not a malfunction.

85EN 85EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

TROUBLESHOOTING

Error message Cause Solution

Disc Error

— Please eject the disc. —

Playback feature may not be available on

this Disc.

• Unplayable disc is inserted in the unit.

• The disc is upside down.

• Insert the standardized disc which bear

the marks on page 41.

• Insert the disc with the labeled side

facing up.

Region Error

— Please eject the disc. —

Playback is not authorized in your region.

• Playback is not authorized in the region

of the DVD-video which you inserted in

the unit.

• Insert the DVD-video with region codes

1 or ALL.

Parental Lock On

The current selected parental level

prohibits playback.

• The current selected parental level

prohibits playback.

• Check “Parental Lock” setting in

“Playback” menu (page 72).

Recording Error

This program is not allowed to be

recorded.

• The recording function encountered

the copy prohibited program.

• You cannot record copy prohibited

programs.

Recording Error

This program is not recordable in +VR

mode.

• You are trying to record the copy-once

program.

• You cannot record the copy-once

program.

Recording Error

Can not record on this disc.

• You are trying to record onto the disc

which is unrecordable, or the disc status

is unable to record.

• The disc is dirty.

• The disc is damaged.

• Insert the recordable disc, and ensure

the disc status satisfies the recording

requirements (page 22).

• Clean the disc with a cleaning cloth.

• Replace the disc.

Recording Error

This disc is protected and not recordable.

• You are trying to record on to the

protected disc which is set in “Disc Edit”

menu.

• Release the disc protect setting in “Disc

Edit” menu (page 36).

Recording Error

Disc is full.

(No area for new recording)

• You are trying to record onto the disc

which has no space for recording.

• Insert the recordable disc with enough

recording space.

Recording Error

You cannot record more than 49 titles on

one disc.

(The maximum is 49)

• You are trying to record onto the disc

on which the number of recording titles

comes up to the maximum (49).

• Delete unnecessary titles (page 57).

Recording Error

You cannot record more than 254 chapters

on one disc.

(The maximum is 254)

• You are trying to record onto the

DVD+RW or DVD-RW on which the

number of recording chapters comes

up to the maximum (254).

• Delete unnecessary chapter marks

(pages 60-61).

Recording Error

You cannot record on this disc as Power

Calibration Area is full.

• When recordings are performed

repeatedly onto an unstable disc, this

area may come up to be full.

• Every time you insert a disc for

recording, the disc’s working area will

be taken up. And if you repeat this

frequently, it will be used up sooner

and you may not be able to record full

49 titles.

• Insert a new disc.

Recording Error

This disc is already finalized.

• You are trying to record onto the disc

already finalized.

• Release the finalizing for this disc

(page 37).

Recording Error

The disc has no recording compatibility.

Set “Make Recording Compatible” to

“ON” to convert the disc.

• You are trying to record onto the

disc that had been recorded by other

recorders.

• Set “Make Recording Compatible” to

“ON” to rewrite the menu, after that you

will record to disc (page 23).

* If you are still having trouble with the unit after checking “TROUBLESHOOTING”, write down the error code and the

error description for calling our help line mentioned on the front page to locate an Authorized Service Center.

86 EN86 EN

Frequently Asked Questions

TROUBLESHOOTING

– Can I record to CD-RW/-R? No, this unit records only DVD.

– Can I play back DVD-video that is bought in another

country?

Possible when the region code of the disc is 1 and All.

– Can I connect the unit to my PC? No, you cannot control the unit by PC.

– Can I program a timer recording with external tuner? Yes, you can. Select “E1” or “E2” as your recording

channel, and leave the external tuner on (pages 13, 26-

29).

– Can I record one channel while watching another

channel using an external tuner?

It depends on your connection configurations. For more

details, please kindly contact at your local store.

– Can I change the channels on the external tuner using

the remote control of this unit?

No. Changing the channels on the external tuner using

this unit’s remote control is not possible. You need to use

the remote control supplied with the external tuner to

change the channels on the external tuner.

87EN 87EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

LANGUAGE CODE

Language Code

Abkhazian 4748

Afar 4747

Afrikaans 4752

Albanian 6563

Amharic 4759

Arabic 4764

Armenian 5471

Assamese 4765

Aymara 4771

Azerbaijani 4772

Bashkir 4847

Basque 5167

Bengali;Bangla 4860

Bhutani 5072

Bihari 4854

Bislama 4855

Breton 4864

Bulgarian 4853

Burmese 5971

Byelorussian 4851

Cambodian 5759

Catalan 4947

Chinese 7254

Corsican 4961

Croatian 5464

Czech 4965

Danish 5047

Dutch 6058

English 5160

Esperanto 5161

Estonian 5166

Faroese 5261

Fiji 5256

Finnish 5255

French 5264

Frisian 5271

Galician 5358

Georgian 5747

German 5051

Greek 5158

Greenlandic 5758

Guarani 5360

Gujarati 5367

Hausa 5447

Hebrew 5569

Hindi 5455

Language Code

Hungarian 5467

Icelandic 5565

Indonesian 5560

Interlingua 5547

Interlingue 5551

Inupiak 5557

Irish 5347

Italian 5566

Japanese 5647

Javanese 5669

Kannada 5760

Kashmiri 5765

Kazakh 5757

Kinyarwanda 6469

Kirghiz 5771

Kirundi 6460

Korean 5761

Kurdish 5767

Laothian 5861

Latin 5847

Latvian; Lettish 5868

Lingala 5860

Lithuanian 5866

Macedonian 5957

Malagasy 5953

Malay 5965

Malayalam 5958

Maltese 5966

Maori 5955

Marathi 5964

Moldavian 5961

Mongolian 5960

Nauru 6047

Nepali 6051

Norwegian 6061

Occitan 6149

Oriya 6164

Oromo (Afan) 6159

Panjabi 6247

Pashto; Pushto 6265

Persian 5247

Polish 6258

Portuguese 6266

Quechua 6367

Rhaeto-Romance 6459

Romanian 6461

Language Code

Russian 6467

Samoan 6559

Sangho 6553

Sanskrit 6547

Scots Gaelic 5350

Serbian 6564

Serbo-Croatian 6554

Sesotho 6566

Setswana 6660

Shona 6560

Sindhi 6550

Singhalese 6555

Siswat 6565

Slovak 6557

Slovenian 6558

Somali 6561

Spanish 5165

Sundanese 6567

Swahili 6569

Swedish 6568

Tagalog 6658

Tajik 6653

Tamil 6647

Tatar 6666

Telugu 6651

Thai 6654

Tibetan 4861

Tigrinya 6655

Tonga 6661

Tsonga 6665

Turkish 6664

Turkmen 6657

Twi 6669

Ukrainian 6757

Urdu 6764

Uzbek 6772

Vietnamese 6855

Volapuk 6861

Welsh 4971

Wolof 6961

Xhosa 7054

Yiddish 5655

Yoruba 7161

Zulu 7267

88 EN88 EN

Analog Audio

An electrical signal that directly represents sound.

Compare this to digital audio which can be an electrical

signal, but is an indirect representation of sound. See also

“Digital Audio”.

Aspect Ratio

The width of a TV screen relative to its height.

Conventional TVs are 4:3 (in other words, the TV screen

is almost square); widescreen models are 16:9 (the TV

screen is almost twice as wide as it is high).

Chapter

Just as a book is split up into several chapters, a title on a

DVD is usually divided into chapters. See also “Title”.

Component Video Output

Each signal of luminance (Y) and component (PB/CB, PR/

CR) is independent to output so that you can experience

picture color as it is.

Also, due to compatibility with progressive video

(525p/480p), you can experience higher-density picture

than that in interlace (525i/480i).

Digital Audio

An indirect representation of sound by numbers. During

recording, the sound is measured at discrete intervals

(44,100 times a second for CD audio) by an analog-

to-digital converter, generating a stream of numbers.

On playback, a digital-to-analog converter generates

an analog signal based on these numbers. See also

“Sampling Frequency” and “Analog Audio”.

Dolby Digital

The system to compress digital sound developed by

Dolby Laboratories. It offers you sound of stereo(2ch) or

multi channel audio.

Finalize

To make DVD, which have been recorded on, possible to

play back in DVD players. With this unit, it is possible to

finalize DVD+R, DVD-RW, and DVD-R.

MP3 (MPEG audio layer 3)

MP3 is a method of compressing files. You can copy MP3

files on CD-RW/-R from the computer and play back the

files on this unit.

PBC (playback control) (video CD only)

This function enables you to play back interactive

software using a menu screen. See also “Video CD”.

PCM (pulse code modulation)

The most common system of encoding digital audio,

found on CD and DAT. Excellent quality, but requires a

lot of data compared to formats such as Dolby Digital

and MPEG audio. For compatibility with digital audio

recorders (CD, MD and DAT) and AV amplifiers with

digital inputs, this unit can convert Dolby Digital and

MPEG audio to PCM. See also “Digital Audio”.

Progressive Scan (525p/480p)

A type of display that does not split each frame into

fields, and instead scans directly through all the scanlines

of each frame in order. Progressive scan provides less

flickering and higher image resolution than traditional

(525i/480i) TV signals. Refer to page 77 for instructions on

selective progressive scan mode.

Region Code

Regions associate discs and players with particular areas

of the world. This unit will only play back discs that have

compatible region codes. You can find the region code

of your unit by looking on the rear panel. Some discs are

compatible with more than one region (or all regions).

Sampling Frequency

The rate which sound is measured by a specified interval

to turn into digital audio data. The numbers of sampling

in one second defines as sampling frequency. The higher

the rate, the better the sound quality.

S-Video Output

It delivers independently each signal of color(C) and

luminance(Y) to TV as video signals, so that higher-quality

picture will be gained.

Title (DVD only)

A collection of chapters on DVD. See also “Chapter”.

Track

Audio CD use tracks to divide up the content of a

disc. The DVD equivalent is called a chapter. See also

“Chapter”.

Video CD

A digital format for store video data in compact disc.

GLOSSARY

89EN 89EN

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

SPECIFICATIONS

Note

• The specifications and design of this product are subject to change without notice.

General

System DVD+RW/+R, DVD-RW/-R, DVD-video, CD-DA, Video CD, CD-RW/-R

VHS cassette tape

VCR video heads Four heads

Power requirements 120V AC +/-10%, 60Hz +/-5%

Power consumption 30W (standby: 3.3W)

Dimensions (width x height x depth) 17 3/16 x 3 15/16 x 10 1/4 inches (435 x 99.5 x 260mm)

Weight 9.5 lbs. ( 4.3kg )

Operating temperature 41°F (5°C) to 104°F (40°C)

Operating humidity Less than 80% (no condensation)

Recording

Recording format +VR (video recording) format

Recording discs DVD+Rewritable, DVD+Recordable

DVD-Rewritable, DVD-Recordable (+VR mode only)

Video recording format

Sampling frequency

Compression format

13.5 MHz

MPEG

Audio recording format

Sampling frequency

Compression format

48 kHz

Dolby Digital

Terminals

Front

Audio input

RCA jack x 2 2V rms (input impedance: more than 22kΩ)

Video input

RCA jack x 1 1Vp-p (75Ω)

S-video input

Mini DIN 4-pin x 1 Y: 1Vp-p (75Ω) C: 286mVp-p (75Ω)

Rear

Audio input

RCA jack x 2 2V rms (input impedance: more than 22kΩ)

Audio output

RCA jack x 4 2V rms (output impedance: more than 1kΩ)

Video input

RCA jack x 1 1Vp-p (75Ω)

Video output

RCA jack x 1 1Vp-p (75Ω)

S-video input

Mini DIN 4-pin x 1 Y: 1Vp-p (75Ω) C: 286mVp-p (75Ω)

S-video output

Mini DIN 4-pin x 1 Y: 1Vp-p (75Ω) C: 286mVp-p (75Ω)

Component video output

RCA jack x 3 Y: 1Vp-p (75Ω) PB/CB: 700mVp-p (75Ω) PR/CR: 700mVp-p (75Ω)

Coaxial digital audio output

RCA jack x 1 500mVp-p (75Ω)

90 ES

ESPAÑOL

Logotipo Atributos

Disco de 8 cm / 12 cm, un solo lado,

una sola capa

Tiempo de grabación máx. aprox.

(modo SLP):

360 minutos (4,7 GB) (para 12 cm)

108 minutos (1,4 GB) (para 8 cm)

DVD+RW DVD+R

DVD-RW DVD-R

LogotiposDiscos reproducibles

Medio Archivos reproducibles

CD-DA

MP3

CD-RW/-R

CD-DA (CD de audio)

CD de video

CD-RW

CD-R

DVD-video

DVD+RW

DVD+R

DVD-RW

(Sólo discos en modo de video nalizados)

DVD-R

(Sólo discos en modo de video nalizados)

es una marca registrada de

DVD Format/Logo Licensing Corporation.

Discos Reproducibles

Este aparato es compatible con la reproducción de los

siguientes discos y archivos.

Códigos de Región

Disco Grabable

Este aparato puede grabar a DVD+RW, DVD+R, DVD-RW y

DVD-R.

Los discos DVD+R/DVD-R pueden ser grabados sólo una

vez. Los discos DVD+RW/DVD-RW pueden ser grabados y

borrados muchas veces.

En este aparato los discos DVD-RW/-R serán grabados

automáticamente en el modo DVD+VR.

• Los siguientes discos se recomiendan para obtener una

buena calidad de grabación y han sido comprobados

como compatibles con este aparato. Sin embargo, según

sea la condición del medio el equipo podría no leer el

disco correctamente.

Verbatim DVD+R 8x, DVD+RW 4x,

DVD-R 8x, DVD-RW 2x

JVC DVD-RW 4x

Maxell DVD+R 4x/8x/16x, DVD-R 8x/16x

SONY DVD+R 4x/8x/16x, DVD+RW 4x

TDK DVD+R 4x/8x/16x

El comportamiento de cualquier otro disco no está

garantizado.

• Usted puede reproducir discos DVD+RW en la

mayoría de los reproductores de DVD sin finalizarlos.

Sin embargo, si usted ha añadido o eliminado

capítulos, u ocultado capítulos, debe ejecutar

“Compatibilizar edic.” antes de poder ver dichos

efectos en otros equipos. (Consulte la página 68.)

Para reproducir discos que no sean DVD+RW en

otros reproductores de DVD, usted necesitará

finalizarlos.

El número presente en el interior

el globo se refiere a una región

del mundo.Este aparato puede

reproducir discos DVD que estén

rotulados para ALL las regiones o

para la región 1.

Disco no Grabable

• Un DVD-RW grabado en un modo distinto de +VR no

será grabable en este aparato a menos que usted borre

todo el contenido del disco. (Consulte la página 67.)

• Un DVD-R grabado en un modo distinto de +VR no será

grabable en este aparato.

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

91ES

OUT IN

DVD

DIGITAL

AUDIO OUT

AUDIO

OUT

S-VIDEO

/CB

/CR

S-VIDEO I N --- AUDIO --- OUT

IN --- VI D E O --- OUT

COMPONENT

VIDEO OUT

DVD/VCR

parte trasera de su televisor

sintonizador externo

parte trasera de este aparato

cable coaxial

de RF

ej.)

ANT. IN

AUDIO IN

VIDEO IN

AUDIO OUT

VIDEO

OUT

S-VIDEO

OUT

S-VIDEO IN --- AUDIO --- OUT

IN --- VIDEO --- OUT

DVD/VCR

señal de TV

cable de audio RCA

cable de video RCA

cable de

video RCA

cable de S-video

cable coaxial de RF

cable de

audio RCA

92 ES

Cuando usted encienda este aparato por primera vez

necesita seguir estos pasos.

1 Presione [STANDBY-ON

y].

Encienda el televisor. Seleccione la entrada a

la cual está conectado el aparato.

2 Utilice [K / L] para seleccionar su

idioma deseado, y luego presione

[OK] para establecerlo.

Initial Setup

OSD Language

English

Français

Español

Presione [OK] para activar “Ajste

Manual de Reloj”.

Ajuste inicial

Ajste Manual de Reloj

- - - / - - / - - - - ( - - - )

- - : - - - -

Utilice [{ / B] para seleccionar un

elemento a configurar, y utilice [

K / L

]

para seleccionar el contenido de su

preferencia, y luego presione [OK].

Ajuste inicial

Ajste Manual de Reloj

ENE / 01 / 2007 ( LUN )

12 : 00 AM

ESPAÑOL

Configuración Inicial 1 Presione [DVD].

Presione [OPEN/CLOSE A] para abrir

la bandeja de discos e insertar su

disco con el rótulo aupntando hacia

arriba.

* Asegúrese de que el disco

sea compatible con este

aparato.(Para obtener la

lista de discos compatibles

consulte la página 22.)

2 Para seleccionar un modo de

grabación presione [REC MODE].

SP(2Hr) 0:58

Buena

Deciente

18 min

36 min

45 min

54 min

72 min

108 min

60 min

120 min

150 min

180 min

240 min

360 min

Disco de 8 cm Disco de 12 cm

HQ (1Hr)

SP (2Hr)

SPP (2.5Hr)

LP (3Hr)

EP (4Hr)

SLP (6Hr)

Calidad del video

y el sonido

Modo de

grabación Tiempo de

grabación

3 Presione [SOURCE] para seleccionar

la posición adecuada de la entrada

externa (E1/E2) a la cual está

conectado su sintonizador externo.

Luego seleccione en el sintonizador

externo el canal que desea grabar.

4 Presione [REC I] para iniciar la

grabación.

Para configurar la grabación a un toque

con temporizador (OTR)...

Esta es una manera sencilla de configurar el tiempo de

grabación en bloques de 30 minutos.

Presione [REC I] repetidamente hasta que aparezca

en la pantalla del televisor la longitud deseada de

grabación (30 minutos a 6 horas).

Comenzará la grabación a un toque con temporizador.

0:30

(grabación normal)

6:00 5:30

1:00

I 0:30

• Para cancelar la grabación a un toque con

temporizador dentro del tiempo especificado,

presione [STOP C].

5 Para de tener la grabación presione

[STOP C].

Grabación Básica

Recording Playback Editing

Introduction Connections Basic Setup Function Setup VCR Functions Others Español

93ES

1 Abra la bandeja

de discos. 2

Inserte un disco.

3 Comience a

reproducir. 4 Detenga la

reproducción.

1 Presione [TIMER].

2 Utilice [K / L] para seleccionar “Prog.

nuevo”, y luego presione [OK].

Programaci. con Reloj

LUN ENE/01 11:00AM

Fcha Empieza Termina E1/E2

Prog. nuevo

3 Configure una programación del

temporizador.

4 Presione [OK].

5 Presione [TIMER SET] para configurar

una programación del temporizador.

Aparecerá en el pantalla del panel frontal.

Usted puede programar el equipo para que grabe hasta 12

programas, con un mes de anticipación. También hay

disponibles grabaciones de programas diarias o semanales.

Antes de grabar, asegúrese de que

• Cuando llegue el momento en que desea empezar a

grabar, conecte el sintonizador externo a ya sea E1 o E2 y

configúrelo para dar salida a las señales de audio/video.

• No cambie el canal del sintonizador externo cuando esté

grabando. Usted no puede mirar un canal y grabar otro

al mismo tiempo.

• Antes de establecer una programación del temporizador

configure el reloj.

• Inserte un disco grabable con suficiente espacio libre.

ESPAÑOL

Reproducción

Grabación con Temporizador

SP 2 : 00

Fcha

ENE/02

E1/E2

E1 DVD

Empieza

- - : - -

Termina

- - : - -

GRAB a Modo

DVD SP

SP 2 : 00

Fcha

ENE/02

E1/E2

Termina

- - : - -

Empieza

12 : 00AM

GRAB a Modo

DVD SP

SP 1 : 00

Fcha

ENE/02

E1/E2

Termina

Empieza

12 : 00AM 1 : 00AM

GRAB a Modo

SP 1 : 00

Fcha

ENE/02

E1/E2

Termina

Empieza

12 : 00AM 1 : 00AM

DVD SP

Configure la fecha.

Configure las horas de inicio y finalización.

Seleccione un modo de grabación.

Seleccione la posición adecuada de la entrada

externa (E1/E2) a la cual está conectado su

sintonizador externo.

GRAB a Modo

SP 1 : 00

Fcha

ENE/02

E1/E2

Termina

Empieza

12 : 00AM 1 : 00AM

DVD

Seleccione un medio de grabación (“DVD” o “VCR”).

OPEN/CLOSE

STANDBY-ON

TIMER SET

ABC DEF.@/:

JKL MNOGHI

TUV WXYZ

SPACETIMER CLEAR

SETUPDISC MENU

RETURNTITLE

TRACKING

VCR DVD

AUDIOREC

REC MODE D.DUBBING

CM SKIP

SEARCH RAPID PLAY

PQRS

SOURCE

123

456

+--

Biji

DISPLAY OPEN/CLOSE

NB552

TIMER

TIMER SET

94 ES

MEMO

95ES

MEMO

Printed in China E9E8AUD

1VMN23495 ★★★★★

LIMITED WARRANTY

FUNAI CORP. will repair this product, free of charge in the USA in the event of defect in materials or workmanship

as follows:

DURATION:

PARTS: FUNAI CORP. will provide parts to replace defective parts without charge for one (1) year from the date

of original retail purchase. Certain parts are excluded from this warranty.

LABOR: FUNAI CORP. will provide the labor without charge for a period of ninety (90) days from the date of

original retail purchase.

LIMITS AND EXCLUSIONS:

THIS WARRANTY IS EXTENDED ONLY TO THE ORIGINAL RETAIL PURCHASER. A PURCHASE RECEIPT OR OTHER

PROOF OF ORIGINAL RETAIL PURCHASE WILL BE REQUIRED TOGETHER WITH THE PRODUCT TO OBTAIN SERVICE

UNDER THIS WARRANTY.

This warranty shall not be extended to any other person or transferee.

This warranty is void and of no effect if any serial numbers on the product are altered, replaced, defaced, missing

or if service was attempted by an unauthorized service center. This limited warranty does not apply to any

product not purchased and used in the United States.

This warranty only covers failures due to defects in material or workmanship which occur during normal use. It

does not cover damage which occurs in shipment, or failures which are caused by repairs, alterations or products

not supplied by FUNAI CORP., or damage, which results from accident, misuse, abuse, mishandling,

misapplication, alteration, faulty installation, improper maintenance, commercial use such as hotel, rental or

office use of this product, or damage which results from fire, flood, lightning or other acts of God.

THIS WARRANTY DOES NOT COVER PACKING MATERIALS, ANY ACCESSORIES (EXCEPT REMOTE CONTROL), ANY

COSMETIC PARTS, COMPLETE ASSEMBLY PARTS, DEMO OR FLOOR MODELS.

FUNAI CORP. AND ITS REPRESENTATIVES OR AGENTS SHALL IN NO EVENT BE LIABLE FOR ANY GENERAL, INDIRECT

OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR OCCASIONED BY THE USE OF OR THE INABILITY TO USE THIS

PRODUCT. THIS WARRANTY IS MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, AND OF ALL

OTHER LIABILITIES ON THE PART OF FUNAI, ALL OTHER WARRANTIES INCLUDING THE WARRANTY OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED BY FUNAI AND ITS

REPRESENTATIVES IN THE UNITED STATES.

ALL WARRANTY INSPECTIONS AND REPAIRS MUST BE PERFORMED BY AN AUTHORIZED SERVICE CENTER.

THIS WARRANTY IS ONLY VALID WHEN THE UNIT IS CARRIED-IN TO AN AUTHORIZED SERVICE CENTER.

THE PRODUCT MUST BE ACCOMPANIED BY A COPY OF THE ORIGINAL RETAIL PURCHASE RECEIPT. IF NO PROOF

OF PURCHASE IS ATTACHED, THE WARRANTY WILL NOT BE HONORED AND REPAIR COSTS WILL BE CHARGED.

IMPORTANT:

THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHER RIGHTS THAT VARY FROM

STATE TO STATE. IF, AT ANY TIME DURING THE WARRANTY PERIOD, YOU ARE UNABLE TO OBTAIN SATISFACTION

WITH THE REPAIR OF THIS PRODUCT, PLEASE CONTACT FUNAI CORP.

ATTENTION:

FUNAI CORP. RESERVES THE RIGHT TO MODIFY ANY DESIGN OF THIS PRODUCT WITHOUT

PRIOR NOTICE.

WARRANTY STATEMENT REGARDING NON AUTHORIZED REPAIRS:

To obtain warranty service, you must take the product, or deliver the product freight prepaid, in either its original

packaging or packaging affording an equal degree of protection, to any AUTHORIZED SERVICE CENTER. FUNAI

CORP. will not reimburse you for any service done by unauthorized service providers without prior written

approval.

To locate your nearest AUTHORIZED SERVICE CENTER or for general service inquiries, please

Customer Service

Tel: 1-800-605-8610

http://www.funai-corp.com

19900 Van Ness Avenue, Torrance, CA 90501
