Super Audio CD player

SA8003

SA7003

www.marantz.com

You can find your nearest authorized distributor or dealer on our website.

is a registered trademark.

ENGLISHFRANÇAISDEUTSCHNEDERLANDSITALIANOSVENSKA ESPAÑOL

ENGLISH

WARRANTY

For warranty information, contact your local Marantz

distributor.

RETAIN YOUR PURCHASE RECEIPT

Your purchase receipt is your permanent record of a

valuable purchase. It should be kept in a safe place

to be referred to as necessary for insurance purposes

or when corresponding with Marantz.

IMPORTANT

When seeking warranty service, it is the responsibility of

the consumer to establish proof and date of purchase.

Your purchase receipt or invoice is adequate for such

proof.

FOR U.K. ONLY

This undertaking is in addition to a consumer’s

statutory rights and does not affect those rights in

any way.

FRANÇAIS

GARANTIE

Pour des informations sur la garantie, contacter le

distributeur local Marantz.

CONSERVER L’ATTESTATION D’ACHAT

L’attestation d’achat est la preuve permanente

d’un achat de valeur. La conserver en lieu sur pour

s’y reporter aux ﬁns d’obtention d’une couverture

d’assurance ou dans le cadre de correspondances

avec Marantz.

IMPORTANT

Pour l’obtention d’un service couvert par la garantie,

il incombe au client d’établir la preuve de l’achat

et d’en corroborer la date. Le reçu ou la facture

constituent des preuves sufﬁsantes.

DEUTSCH

GARANTIE

Bei Garantiefragen wenden Sie sich bitte an Ihren

Marantz-Händler.

HEBEN SIE IHRE QUITTING GUT AUF

Die Quittung dient Ihnen als bleibende Unterlage

für Ihren wertvollen Einkauf Das Aufbewahren der

Quittung ist wichtig, da die darin enthaltenen Angaben

für Versicherungswecke oder bei Korrespondenz mit

Marantz angeführt werden müssen.

WICHTIG!

Bei Garantiefragen muß der Kunde eine Kaufunterlage

mit Kaufdatum vorlegen. Ihren Quittung oder

Rechnung ist als Unterlage ausreichend.

NEDERLANDS

GARANTIE

Voor inlichtingen omtrent garantie dient u zich tot uw

plaatselijke Marantz.

UW KWITANTIE, KASSABON E.D. BEWAREN

Uw kwitantie, kassabon e.d. vormen uw bewijs van

aankoop van een waardevol artikel en dienen op een

veilige plaats bewaard te worden voor evt, verwijzing

bijv, in verbend met verzekering of bij correspondentie

met Marantz.

BELANGRIJK

Bij een evt, beroep op de garantie is het de

verantwoordelijkheid van de consument een

gedateerd bewijs van aankoop te tonen. Uw

kassabon of factuurzijn voldoende bewijs.

ESPAÑOL

GARANTIA

Para obtener información acerca de la garantia

póngase en contacto con su distribuidor Marantz.

GUARDE SU RECIBO DE COMPRA

Su recibo de compra es su prueba permanente de

haber adquirido un aparato de valor, Este recibo

deberá guardarlo en un lugar seguro y utilizarlo

como referencia cuando tenga que hacer uso del

seguro o se ponga en contacto con Marantz.

IMPORTANTE

Cuando solicite el servicio otorgado por la garantia

el usuario tiene la responsabilidad de demonstrar

cuándo efectuó la compra. En este caso, su recibo

de compra será la prueba apropiada.

ITALIANO

GARANZIA

L’apparecchio è coperto da una garanzia di buon

funzionamento della durata di un anno, o del periodo

previsto dalla legge, a partire dalla data di acquisto

comprovata da un documento attestante il nominativo

del Rivenditore e la data di vendita. La garanzia sarà

prestata con la sostituzione o la riparazione gratuita

delle parti difettose.

Non sono coperti da garanzia difetti derivanti da

uso improprio, errata installazione, manutenzione

effettuata da personale non autorizzato o, comunque,

da circostanze che non possano riferirsi a difetti di

funzionamento dell’apparecchio. Sono inoltre esclusi

dalla garanzia gli interventi inerenti l’installazione e

l’allacciamento agli impianti di alimentazione.

Gli apparecchi verranno riparati presso i nostri Centri

di Assistenza Autorizzati. Le spese ed i rischi di

trasporto sono a carico del cliente.

La casa costruttrice declina ogni responsabilità per

danni diretti o indiretti provocati dalla inosservanza

delle prescrizioni di installazione, uso e manutenzione

dettagliate nel presente manuale o per guasti dovuti ad

uso continuato a ﬁni professionali.

SVENSKA

GARANTI

För information om garantin, kontakta Marantz

lokalagent.

SPAR KVITTOT

Kvittot är ett inköpsbevis på en värdefull vara. Det skall

förvaras säkert och hänvisas till vid försäkringsfall

eller vidkorrespondens mod Marantz.

VIKTIGT

Fö att garantin skall gälla är det kundens sak att

framställa bevis och datum om köpet. Kvitto eller

faktura är tillräokligt bevis fö detta.

CE MARKING

English

The SA8003/SA7003 is in conformity with

the EMC directive and low-voltage direc-

tive.

Français

SA8003/SA7003

est conforme à la di-

rective EMC et à la directive sur les basses

tensions.

Deutsch

Das Modell SA8003/SA7003 entspricht

den EMC-Richtlinien und den Richtlinien

für Niederspannungsgeräte.

Nederlands

De SA8003/SA7003 voldoet aan de EMC

eisen en de vereisten voor laag-voltage.

Español

SA8003/SA7003

está de acuerdo con

las normas EMC y las relacionadas con

baja tensión.

Italiano

Il SA8003/SA7003 è conforme alle direttive

CEE ed a quelle per i bassi voltaggi.

Svenska

SA8003/SA7003

är tillverkad i enlighet med

EMC direktiven och direktiven för lågvolt-

sutrusning.

English

WARNINGS

- Do not expose the equipment to rain, moisture,

dripping or splashing.

- Do not remove the cover from the equipment.

- Do not insert anything into the equipment through the

ventilation holes.

- Do not handle the mains cord with wet hands.

- Do not cover the ventilation with any items such as

tablecloths, newspapers, curtains, etc.

- No naked ﬂame sources, such as lighted candles,

should be placed on the equipment.

- When disposing of used batteries, please comply

with governmental regulations or environmental

public instruction’s rules that apply in your country or

area.

- Make a space of about 0.1 meter around the unit.

- No objects ﬁlled with liquids, such as vases, shall be

placed on the equipment.

- When the switch is in the OFF position, the equipment

is not completely switched off from MAINS.

- The equipment shall be installed near the power

supply so that the power supply is easily accessible.

- Do not expose the unit and batteries to excessive

heat such as direct sunlight, ﬁre or the like.

Français

AVERTISSEMENTS

- Ne pas exposer l’appareil à la pluie, à l’humidité, à

l’égouttement ou aux éclaboussures.

- Ne pas essayer de retirer le boîtier de l’appareil.

- Ne rien insérer dans l’appareil par les oriﬁ ces de

ventilation.

- Ne pas manipuler le cordon d’alimentation avec les

mains mouillées.

- Ne pas recouvrir les ouïes de ventilation avec un

objet quelconque comme une nappe, un journal, un

rideau, etc.

- Ne placer aucune source de ﬂ amme nue, comme

une bougie allumée, sur l’appareil.

- Pour mettre au rebut les piles usées, respecter les

lois gouvernementales ou les règlements ofﬁ ciels

concernant l’environnement qui s’appliquent à votre

pays ou région.

- Veiller à ce qu’aucun objet ne soit à moins de 0,1

mètre des côtés de l’appareil.

- Aucun objet rempli de liquide, un vase par exemple,

ne doit être placé sur l’appareil.

- Lorsque l’interrupteur est sur la position OFF,

l’appareil n’est pas complètement déconnecté du

SECTEUR (MAINS).

- L’appareil sera installé près de la source

d’alimentation, de sorte que cette dernière soit

facilement accessible.

- N’exposez pas l’appareil et les piles à une chaleur

excessive, comme par exemple aux rayons directs

du soleil, au feu, etc.

Deutsch

WARNHINWEISE

- Das Gerät nicht Regen, Feuchtigkeit, Tropf- oder

Spritzwasser aussetzen.

- Die Abdeckung nicht vom Gerät abnehmen.

- Keine Gegenstände durch die Belüftungsschlitze

stecken.

- Das Netzkabel nicht mit feuchten oder nassen

Händen anfassen.

- Decken Sie die Lüftungsöffnungen nicht mit einem

Tischtuch, einer Zeitung, einem Vorhang usw. ab.

- Es dürfen keine Gegenstände mit offener Flamme,

wie etwa brennende Kerzen, auf dem Gerät

aufgestellt werden.

- Beachten Sie bei der Entsorgung der verbrauchten

Batterien alle geltenden lokalen und überregionalen

Regelungen.

- Auf allen Geräteseiten muß ein Zwischenraum von

ungefähr 0,1 meter vorhanden sein.

Auf das Gerät dürfen keine mit Flüssigkeiten

gefüllte Behälter, wie etwa eine Vase, gestellt

werden.

- Wenn der Schalter ausgeschaltet ist (OFF-Position),

ist das Gerät nicht vollständig vom Stromnetz

(MAINS) abgetrennt.

- Das Gerät sollte in der Nähe einer Netzsteckdose

aufgestellt werden, damit es leicht an das Stromnetz

angeschlossen werden kann.

- Setzen Sie das Gerät und die Batterien keiner

übermäßigen Wärme aus, z.B. durch Aufstellung

in direkter Sonneneinstrahlung, in der Nähe eines

offenen Feuers usw.

Español

ADVERTENCIAS

- No exponga el equipo a la lluvia, la humedad, goteos

o salpicaduras.

- No extraiga la tapa del equipo.

- No introduzca nada en el interior del equipo a través

de los oriﬁ cios de ventilación.

- No maneje el cable de alimentación con las manos

mojadas.

- No cubra la ventilación con objetos como manteles,

periódicos, cortinas, etc.

- No deben colocarse sobre el equipo elementos con

fuego, por ejemplo velas encendidas.

- Cuando se eliminen baterías usadas, deben

cumplirse las reglamentaciones oficiales o las

normas de protección medioambiental aplicables en

su país o en su zona.

- Deje un espacio de unos 0,1 metro alrededor de la

unidad.

- No se deben colocar sobre el aparato recipientes

que contengan líquidos, como por ejemplo jarrones.

- Cuando el interruptor está en la posición OFF, el

equipo no está completamente desconectado de la

alimentación MAINS.

- El equipo se instalará cerca de la fuente de

alimentación de manera que resulte fácil acceder a

ella.

- No exponga la unidad y las pilas a un calor excesivo,

tal como el derivado de la luz directa del sol, el fuego,

o alguna fuente térmica similar.

Nederlands

WAARSCHUWINGEN

- Stel het apparaat niet bloot aan regen, vocht,

druppels of spetters.

- Verwijder de afdekplaat van het apparaat niet.

- Duw niets door de ventilatieopeningen in het

apparaat.

- Raak het netsnoer niet met natte handen aan.

Bedek de ventilatieopeningen niet met enige

voorwerpen, zoals tafelkleden, kranten, gordijnen,

enz.

- Plaats geen brandende voorwerpen, zoals kaarsen,

op het apparaat.

- Volg bij het weggooien van verbruikte batterijen de

overheidswetgeving of milieuvoorschriften op die

van kracht zijn in het land of de regio waarin u zich

bevindt.

Zorg dat er 0,1 meter vrije ruimte rond het toestel is.

- Plaats geen voorwerpen met een vloeistof erin, zoals

een bloemenvaas, op het apparaat.

- Als de schakelaar op OFF staat, is het apparaat niet

volledig losgekoppeld van de netspanning (MAINS).

- De apparatuur wordt in de buurt van het stopcontact

geïnstalleerd, zodat dit altijd gemakkelijk toegankelijk

is.

- Stel het apparaat en de batterijen niet bloot aan grote

warmte, zoals direct zonlicht, vuur en dergelijke.

Italiano

AVVERTENZE

- Non esporre l’apparecchio alla pioggia, all’umidità, al

gocciolamento o agli spruzzi.

- Non rimuovere il coperchio dell’apparecchio.

- Non introdurre oggetti all’interno dell’apparecchio

attraverso i fori di ventilazione.

- Non toccare il cavo di alimentazione con le mani

bagnate.

- Non coprire le fessure di ventilazione con tovaglie,

giornali, tende od oggetti analoghi.

- Non posare sull’apparecchio sorgenti di ﬁ amme

scoperte quali candele accese.

- Smaltire le pile usate in conformità alle norme

governative o disposizioni ambientali vigenti nel

proprio paese o zona.

- Lasciare 0,1 metro liberi tutto intorno l’unità.

- Non mettere sull’apparecchiatura alcun contenitore

di liquido, come ad esempio dei vasi.

- Quando l’interruttore è nella posizione OFF,

l’apparecchiatura non è completamente scollegata

da MAINS.

- L’apparecchio va installato in prossimità della fonte

di alimentazione, in modo che quest’ultima sia

facilmente accessibile.

- Non esporre l’unità e le batterie a calore eccessivo

come la luce diretta del sole, il fuoco o così via.

Svenska

VARNINGAR

- Utsätt inte utrustningen för regn, fukt, droppande

vatten eller vattenstänk.

- Ta inte bort utrustningens hölje.

- För inte in föremål i utrustningen genom

ventilationshålen.

- Hantera inte nätsladden med våta händer.

- Täck inte för ventilationsöppningarna med några

föremål som till exempel bordsdukar, dagstidningar,

gardiner e.d.

- Inga föremål med öppen låga, som till exempel tända

stearinljus, bör placeras på utrustningen.

- Följ de lagar och miljöskyddsråd som gäller i det

land eller område där du bor när du gör dig av med

batterier.

- Se till att det ﬁ nns omkring 0,1 meter fri plats runt

omkring enheten.

- Inga objekt som är fyllda med någon vätska, till

exempel blomstervaser, bör placeras på apparaten.

- Även om strömbrytaren står i det avstängda läget

OFF, så är utrustningen inte helt bortkopplad från det

elektriska nätet (MAINS).

- Utrustningen ska vara installerad nära strömuttaget

så att strömförsörjningen är lätt att tillgå.

- Utsätt inte enheten och batterierna för kraftig värme,

såsom direkt solljus, eld eller liknande.

OPT_080602N1

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

APPLICATION

OPERATION

TROUBLESHOOTING

OTHERS

ENGLISH

• Audio connecting cord

• Remote control connecting cord

• User Guide

INTRODUCTION

Thank you for selecting the Marantz Super Audio CD Player for your Audio system.

This Player incorporates a number of features designed to enhance the listening of your favorite audio

sources.

Please read these operating instructions carefully. We recommend that you read the entire user guide before

you attempt to connect or operate the player.

After you have reviewed the contents of this manual, we suggest that you make all system connections

before you attempt to operate the unit.

CHECKING THE ACCESSORIES

After opening the cover of the packing box, check

that the following accessories are included.

• Remote controller

• Size “AAA” batteries x 2

• AC Power cord

CONTENTS

A NOTE ABOUT RECYCLING

This product’s packaging materials are

recyclable and can be reused. This product

and the accessories packed together are the

applicable product to the WEEE directive

except batteries.

Please dispose of any materials in accordance

with your local recycling regulations.

When discarding the unit, comply with your

local rules or regulations.

Batteries should never be thrown away or

incinerated but disposed of in accordance with

your local regulations concerning chemical

wastes.

FEATURES ........................................................2

SA8003/SA7003 COMMON FEATURES ..................... 2

SA8003 FEATURES ........................................................ 2

APPLICABLE DISCS TO THE UNIT ............................ 2

BEFORE USING ...............................................3

USAGE OF REMOTE CONTROLLER ........................... 4

NAMES AND FUNCTIONS ............................ 5

FRONT PANEL ................................................................ 5

DISPLAY .......................................................................... 6

REMOTE CONTROLLER ................................................ 7

REAR PANEL .................................................................. 8

BASIC CONNECTIONS ..................................9

CONNECTING TO AN AMPLIFIER ............................. 9

USB MEDIA/iPod CONNECTION

(SA8003 ONLY) ............................................................... 9

CONNECTING THE POWER SUPPLY ......................... 9

BASIC OPERATION ......................................10

NORMAL PLAYBACK .................................................. 10

PLAYING YOUR FAVORITE TRACKS OF A DISC .... 10

PLAYING YOUR FAVORITE PARTS OF A DISC

(SEARCH) ...................................................................... 10

ADVANCED CONNECTIONS .......................11

CONNECTING TO A DIGITAL AUDIO

COMPONENT ............................................................... 11

REMOTE CONTROL CONNECTION .......................... 12

TIMER PLAY ................................................................. 12

APPLICATION OPERATION (CD OPERATION)

..... 14

TO CHANGE TIME DISPLAY ...................................... 14

REPEATED DISC PLAY (REPEATPLAY) .................... 14

PLAYING TRACKS IN A RANDOM SEQUENCE

(RANDOM PLAY) ......................................................... 14

PLAYING TRACKS IN A SPECIFIC SEQUENCE

(PROGRAM PLAY) ....................................................... 14

TO CHECK THE PROGRAMMED TRACKS .............. 15

SEARCHING YOUR FAVORITE TRACKS

(AMS (AUTOMATIC MUSIC SCAN) PLAY) ............. 15

SWITCHING SOUND MODE

(SUPER AUDIO CD) ..................................................... 15

SETTING THE DIGITAL OUTPUT .............................. 16

APPLICATION OPERATION

(USB/iPod OPERATION) - SA8003 .............17

NORMAL PLAYBACK .................................................. 17

PLAYING YOUR FAVORITE TRACKS ........................ 18

PLAYING YOUR FAVORITE PARTS OF A

TRACK (SEARCH) ........................................................ 18

USB MEDIUM OPERATION ....................................... 19

iPod OPERATION ......................................................... 21

TROUBLESHOOTING....................................23

OTHERS ..........................................................25

SPECIFICATIONS & DIMENSIONAL

DRAWINGS .................................................................. 27

NOTES ABOUT THE DISCS ....................................... 28

ABOUT USB MEDIA ................................................... 28

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

APPLICATION

OPERATION

TROUBLESHOOTING

OTHERS

ENGLISH

FEATURES

SA8003/SA7003 COMMON

FEATURES

This unit can play back the outstanding sound

performance of Super Audio CDs. This unit has the

following major features.

• Low-noise low-distortion filter circuit and

high-speed HDAMSA2-type output ampliﬁer

with the differential input type HDAM

• Playback of CD-R/CD-RW discs

• Playback of CD-R/CD-RW/CD-ROM discs

containing WMA and MP3 ﬁles

SA8003 FEATURES

The SA8003 has been upgraded from SA7003 as in

the following.

• Toroidal transformer

The SA8003 features a toroidal transformer that

produces less vibration and magnetic leakage ﬂux

compared to conventional power transformers.

The materials and manufacturing process of the

ring-shaped core are strictly controlled to reduce

vibration, while the short-ring attached to the

perimeter of the transformer reduce magnetic

leakage ﬂux.

• Large-capacitance block capacitor

A large capacitance 3300 µF capacitor carefully

selected for its acoustic characteristics is

incorporated into the power supply circuit.

• Audiophile-grade film capacitors and

electrolytic capacitors

The SA8003 features the same audiophile-

grade ﬁlm capacitors and electrolytic capacitors

speciﬁcally used in top-range models.

• Double-layered chassis

• High-grade machined analog audio output

connectors

• Playback of USB audio (MP3/WMA/WAV)/

iPod

This unit can play back MP3, WMA, WAV, and

AAC ﬁles by connecting an USB device or iPod to

its USB connector.

• Copper-plated chassis

APPLICABLE DISCS TO THE UNIT

1. Super Audio CD

The Super Audio standard is based on Direct Stream

Digital (DSD) technology. This new direct-stream

digital format comprises a 1-bit system that has a

digital sampling frequency that is 64 times higher

than that of conventional audio CD. The results are

spectacular: a frequency response of over 100k Hz

and a 120 dB dynamic range over the entire audible

spectrum. Mixed with as many of the original

frequencies as possible, the audio information

audible for human ears sounds much more natural.

All audible frequencies are, after all, embedded

in the frequency range as emitted by the sound

source. A better reproduction does not exist! For

the ﬁrst time your ears will relive reality.

There are three types of Super Audio CDs.

• Single-layer Disc

• Dual-layer Disc

• Hybrid-layer Disc

Disc Types

Single-layer Disc

Dual-layer Disc Hybrid-layer Disc

HD layer HD layer CD layer HD layer

And each type may contain two areas of recorded

information.

• High quality stereo area

• High quality multi-channel area**

• Single Layer Disc

It can contain both high quality stereo area and

high quality multi-channel area** information.

• Dual Layer Disc

It can contain both high quality stereo area and

high quality multi-channel area** information.

And a double amount of information can be

stored on the disc thanks to the second layer.

• Hybrid Layer Disc

Not only does this disc contain both high sound

quality stereo area and high sound quality multi-

channel area** information, it also has a CD layer

in the second layer, so it can be played on a CD

player.

Hybrid Super Audio CD Disc

1 CD layer that plays on any of your

existing CD players

High-Density layer containing:

2 - High sound quality stereo

3 - High sound quality multi-channel**

The number of tracks recorded may vary per layer. It

will be shown on the display window of the unit.

**This unit is a stereo-only player, and so it

cannot play high-quality multi-channel audio

areas. (It does not recognize multi-channel

areas.)

2. Audio CD (CDDA)

Audio CDs contain music tracks only.

3. CD-R / CD-RW

This unit can play back the CD-RW (ReWritable)

discs as well as ordinary Audio CD and CD-R

(Recordable) discs.

• The CD-R and CD-RW discs should contain

properly-recorded TOC* information so that they

can be played back. In CD recorders, the task of

writing TOC information is referred to as ﬁnalizing

the disc. Discs that are not ﬁnalized cannot be

properly recognized as an Audio CD and played

back by regular CD players and Super Audio CD

players. For details, please read the instruction

manual provided with a CD recorder.

* TOC stands for Table Of Contents and contains

information such as the total number of tracks

and total playing time of the disc.

• As the playback of a CD-RW disc necessitates

partial change of the player setup, it may take

longer time for reading the TOC information than

when an Audio CD or CD-R disc is played.

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

APPLICATION

OPERATION

TROUBLESHOOTING

OTHERS

ENGLISH

This section must be read before any connection is

made to the mains supply.

EQUIPMENT MAINS WORKING SETTING

Your Marantz product complies with the household

power and safety requirements in your area.

This product can be powered by 230 V AC only.

Recording and playback of any material may

require consent. For further information refer to the

following:

— Copyright Act 1956

— Dramatic and Musical Performers Act 1958

— Performers Protection Acts 1963 and 1972

— any subsequent statutory enactments and

orders

INAPPROPRIATE PLACES FOR

INSTALLATION

To keep your player in perfect working order for the

longest possible time, avoid installing the player in

the following locations.

• Wherever it will be exposed to direct sunlight

• Wherever it will be close to a heater or other heat-

radiating appliance

• Wherever the humidity is high or ventilation is

poor

• Wherever it is very dusty

• Wherever it will be subject to vibration

• On top of a rickety stand or in an unstable location

which is tilted at an angle

• On top of an ampliﬁer or other component which

dissipates a great deal of heat

• In an audio rack with little space at the top

and bottom or other location where the heat

dissipation will be obstructed

To ensure proper heat dissipation, install the

player while leaving clearances between the

player and wall or other components, as shown

in the ﬁgure below.

0.1 m or more

0.1 m

or more

0.1 m

or more

0.1 m

or more

BEFORE USING

DO NOT PLACE OBJECTS ON TOP

• Refrain from placing any objects on top of the

player.

CAUTIONS ON HANDLING MAINS CORD

• Do not touch the mains cord with wet hands.

• When disconnecting the mains cord, always

make sure that you take hold of the plug. Yanking

out or bending the cord can damage it and/or

cause electric shocks or a ﬁre.

• Get into the habit of disconnecting the power

plug before leaving home.

DO NOT ATTEMPT REPAIRS YOURSELF

• Refrain from lubricating the player: doing so can

cause malfunctioning.

• Only qualified engineers with specialized

expertise are authorized to repair the pick-up and

parts inside the player.

PRECAUTIONS

• In winter, droplets of water form on the insides

of the windows of a heated room: this is called

condensation. This CD player uses an optical

lens, so the condensation may form in the

following cases.

- In a room immediately after the heating has

been turned on

- In a room where the humidity level is high

- When the player has been suddenly brought

from a cold location into a warm room

Since, in cases like this, the track numbers may

not be read and the player is prevented from

operating properly, wait about 30 minutes, and

then operate the player.

• This player may cause interference on a tuner or

TV set. If this is the case, place it further away

from the tuner or TV set.

• Compact discs have much less noise than analog

records and hardly any noise is heard before play

starts. Bear in mind, therefore, that if the volume

control on the ampliﬁer is set too high, you will

risk damaging other audio components.

• This audio player is for the exclusive playing of

Audio CDs (Compact Discs) and MP3/WMA

compressed data ﬁles.

It cannot play CD-ROMs used with personal

computers, game CDs, video CDs, DVDs (video/

audio) or DTS-CDs.

• We do not recommend the use of lens cleaners.

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

APPLICATION

OPERATION

TROUBLESHOOTING

OTHERS

ENGLISH

BEFORE USING

USAGE OF REMOTE CONTROLLER

LOADING BATTERIES

Before using the remote controller for the ﬁrst time,

load the batteries in the remote controller. The

batteries provided are used to verify the operations

of the remote controller only.

1. Remove the battery cover.

2. Insert the batteries with correct ª/·

orientation.

3. Close the battery cover until it clicks shut.

CAUTIONS ON HANDLING BATTERIES

Misuse of the batteries can result in electrolyte

leakage, rupturing, corrosion, etc.

Bear in mind the following points when using

batteries.

• Remove the batteries from the remote control

unit if the unit is not going to be used for a

prolonged period (a month or more).

• Do not use an old battery together with a new

one.

• Insert the batteries while ensuring that their

ª and · poles are properly aligned with the

corresponding markings on the remote control

unit.

• Batteries with the same shape may have different

voltages. Do not use different types of batteries

together.

• If electrolyte has leaked, thoroughly wipe the

inside of the battery compartment, and then

insert new batteries.

• When batteries which are no longer required are

to be discarded, follow the directions (regulations)

laid down by the local authorities in the area

concerned for their disposal.

OPERATIONAL RANGE

Operate the unit with the remote controller within

the range of the illustration below.

60°

Precautions

• Do not allow direct sunlight, an inverter ﬂuorescent

light or other strong source of light to shine onto

the player’s infrared signal reception window

(remote sensor). Otherwise, the operation of the

remote control unit may be disabled.

• Bear in mind that operating the remote control

unit may cause other devices operated by infrared

rays to be operated by mistake.

• The remote control unit cannot be operated if

the space between the controller and the player’s

remote sensor is obstructed.

• Do not place any objects on top of the remote

control unit. Doing so may cause one or more

buttons to be held down which will cause the

batteries to run down.

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

TROUBLESHOOTING

OTHERS NAMES AND

FUNCTIONS

ENGLISH

APPLICATION

OPERATION

NAMES AND FUNCTIONS

q POWER ON/STANDBY switch

STANDBY indicator

This switch is used to turn the power ON and OFF

(see page 10).

w 4/1 (Track Skip/Search)

button

See page 10.

e ¡/¢ (Search/Track Skip)

button

See page 10.

r 0 (Open/Close) button

See page 10.

t Disc tray

The disk to be played is placed on the tray (see

page 10).

y 2 (Play) button

See page 10.

u 7 (Stop) button

See page 10.

i 8 (Pause) button

See page 10.

o LEVEL (headphones level) control

This is used to adjust the headphones volume level.

The level increases when turned clockwise.

!0 PHONES (headphones) jack

The headphones are connected to this jack. Use

headphones that come with a standard plug.

!1 Remote sensor

This sensor senses the infrared control signals sent

from the remote control unit.

!2 FL display

See page 6.

!3 DISPLAY OFF indicator

See page 7.

!4 DISC MEDIA / USB button (SA8003

only)

See page 17.

!5 USB connector (SA8003 only)

See page 17.

FRONT PANEL

DISPLAY

OFF

SUPER AUDIO CD PLAYER SA8003

DISC MEDIA/USBUSB

PHONES LEVEL

–+

STANDBY

ON/STANDBY

POWER

SUPER AUDIO CD PLAYER SA7003

PHONES LEVEL

–+

STANDBY

ON/STANDBY

POWER

DISPLAY

OFF

qwer tyui

!4 !0 o!3 !2 !1

qwer tyui

!0 o!3 !2 !1

SA8003 SA7003

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

TROUBLESHOOTING

OTHERS

NAMES AND

FUNCTIONS

ENGLISH

APPLICATION

OPERATION

NAMES AND FUNCTIONS

a 1 (repeat) indicator

This indicator lights up during repeat play of one

track.

s RPT (repeat) indicator

This indicator lights up during repeat play.

d RNDM (random) indicator

This indicator lights up during random play.

f PROG (program) indicator

This indicator lights up during program play.

g TRK (track) indicator

This indicator lights up above the display of the track

number currently being played.

h SA-CD indicator

This indicator indicates the type of disc on the disc

tray (Super Audio CD).

j CD indicator

This indicator indicates the type of disc on the disc

tray (CD).

k M FILE indicator

This indicator indicates the type of disc on the disc

tray (WMA/MP3).

l USB indicator

This indicator lights up during operation in the USB/

iPod mode.

¡0 D OFF (digital output OFF)

indicator

This indicator lights up when the digital output

setting of the audio CD signal is set to OFF (see

page 16).

¡1 REMAIN (remaining time) indicator

This indicator lights up above the remaining playback

time of a track, when it is displayed.

¡2 TTL (total time) indicator

This indicator lights up above the total remaining time

or the total program time, when it is displayed.

¡3 Main display area

This area displays the time display and text

information of the disc to be played, as well as the

setting menu items, etc.

¡4 8 (pause) indicator

This indicator lights up when play is paused.

¡5 3 (play) indicator

This indicator lights up during disc play.

DISPLAY

RPT RNDM PROG TRKCD CD FILE USB DOFF REMAIN TTLM

a s d f g h j

¡3¡4¡5

k l ¡0 ¡1 ¡2

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

TROUBLESHOOTING

OTHERS NAMES AND

FUNCTIONS

ENGLISH

APPLICATION

OPERATION

NAMES AND FUNCTIONS

z POWER button

Switches the power of the unit ON and OFF (see

page 10).

x USB button (SA8003 only)

Press this button when using a USB connection

(see page 17).

c DISC button (SA8003 only)

Press this button when using a disc media.

v FILTER button

This button cannot be used on this unit.

b PROGRAM button

See page 14.

n RANDOM button

See page 14.

m CLEAR button

See page 15.

, REPEAT button

See page 14.

. AMS (Automatic Music Scan)

button

See page 15.

⁄0 MUTE button

This button can activate the mute function of devices

compatible with Marantz pre-main ampliﬁers.

⁄1 VOLUME button

This button can be used to adjust the volume of

devices compatible with Marantz ampliﬁers that

come with a remote controller.

⁄2 ENTER button

This button is used to enter settings done via MENU

or decide ﬁles for USB ﬁle search.

⁄3 8 (pause) button

See page 10.

⁄4 7 (stop) button

See page 10.

⁄5 MENU (menu setting) button

Press this button when conducting Timer Play, SA-

CD, USB setup or iPod setup.

⁄6 0-9 (numeric) buttons

See page 10.

⁄7 1, ¡ (search) buttons

See page 10.

⁄8 4, ¢ (track skip) buttons

See page 10.

⁄9 3 (play) button

See page 10.

¤0 FOLDER 5/∞ buttons

(SA8003 only)

These buttons are used for USB folder search and

iPod album selection.

¤1 INPUT 5/∞ buttons

These buttons are used to switch the input when

using one of the supported Marantz amplifiers.

However, this function may not work with some of

the older models.

¤2 TEXT button

Press this button when switching the main display

area from time display to text display when using a

data disc containing MP3, WMA ﬁles, etc., or during

USB/iPod use (see page 20).

However, this feature does not support the display

of Super Audio CD or Audio CD TEXT.

¤3 TIME button

Press this button when switching the main display

area from text display to time display (see page

14).

¤4 DISPLAY button

Press this button when switching the display ON

and OFF.

The display becomes dimmer each time the button

is pressed. When the button is pressed for the third

time, the display turns off and the DISPLAY OFF

indicator lights up. The last setting is retained even

if the power is turned off.

¤5 S.MODE (sound mode) button

See page 15.

¤6 DIG.OUT (digital out on/off) button

Press this button when switching the digital output

of an audio CD signal on/off (see page 16).

¤7 0 (OPEN/CLOSE) button

See page 10.

REMOTE CONTROLLER

⁄3

⁄4

⁄5

⁄6

⁄7

⁄9

⁄8

¤0

⁄1

⁄2

⁄0

¤1

¤2

¤3

¤4

¤5

¤6

¤7

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

TROUBLESHOOTING

OTHERS

NAMES AND

FUNCTIONS

ENGLISH

APPLICATION

OPERATION

NAMES AND FUNCTIONS

q Power cord connector socket

Use the supplied power cord to connect the unit to

a standard household power supply outlet.

Connect the player so that the power cord

can be removed easily as a precaution against

possible accidents.

w DIGITAL AUDIO OUT OPTICAL

(optical digital output) connector

This optical output connector performs digital

output of the music signal of the audio CD during

playback (see page 11).

e DIGITAL AUDIO OUT COAXIAL

(coaxial digital output) connector

This coaxial digital output connector performs digital

output of the music CD of the audio CD during

playback (see page 11).

r REMOTE CONTROL IN / OUT

(remote control IN and OUT)

connectors

These connectors are used to connect the player to

a Marantz audio component equipped with remote

control connectors using the supplied remote

control connecting cable (see page 12).

t EXTERNAL / INTERNAL

(external/internal) switch

The switch is set to INTERNAL at factory shipping,

enabling use of the player’s built-in remote sensor.

When connecting the remote control connector

of this player to a Marantz unit using the supplied

connecting cable, set this switch to EXTERNAL

(see page 12).

y ANALOG OUT (analog output)

connector

This connector outputs the music signal during

playback (see page 9).

REAR PANEL

AC IN

DIGITAL AUDIO OUT

R L IN

OUT

REMOTE CONTROLANALOG OUTPUT

OPTICALCOAXIAL

INTERNAL

EXTERNAL

AC IN

DIGITAL AUDIO OUT

OUT

REMOTE CONTROL

ANALOG OUTPUT

R L

OPTICALCOAXIAL

INTERNAL

EXTERNAL

qwety r

SA8003 SA7003

qwety r

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

TROUBLESHOOTING

OTHERS BASIC

CONNECTION

ENGLISH

APPLICATION

OPERATION

BASIC CONNECTIONS

This CD player is connected to an ampliﬁer, CD recorder and other components for use. To ensure that the

components are connected properly, refer to the instruction manuals that come with the components to be

connected.

Before connecting the components, be absolutely sure to turn off their power.

CONNECTING TO AN AMPLIFIER

Use the audio connecting cord to connect the player with a stereo ampliﬁer or AV ampliﬁer.

When making the connections, insert the plugs securely into the connectors. Failure to insert the plugs

securely may result in noise.

GND

CD AUX

DVD

TUNER

OUTIN

RECORDER 1

OUTIN

RECORDER 2

PHONO

AC IN

AC OUTLET

UNSWITCHED

100W 1A MAX

100V 50/60Hz

OUT

REMOTE

CONTROL

POWER AMP

DIRECT IN

PRE OUT

AC IN

DIGITAL AUDIO OUT

OUT

REMOTE CONTROL

ANALOG OUTPUT

R L

OPTICALCOAXIAL

INTERNAL

EXTERNAL

SPEAKERS

SYSTEM A

R L

(White)

Ampliﬁer

(Red)

: Signal ﬂow

(Red)

Audio connecting cord (supplied)

Caution:

Do not connect the player to the PHONO input connectors on the ampliﬁer.

USB MEDIA/iPod CONNECTION

(SA8003 ONLY)

Connect the SA8003 to USB media/iPod.

DISPLAY

OFF

SUPER AUDIO CD PLAY

DISC MEDIA/USBUSB

Supplied iPod cable

Caution:

• Connect the USB media/iPod while in power off

or when the input source is something other than

USB. Connecting/disconnecting USB memory

when the input source is USB and the power is on

may damage the USB memory.

• When using an USB device, do not use an USB

extension cable.

CONNECTING THE POWER

SUPPLY

1. Plug the power cable into AC IN jack on the

back panel.

AC IN

UDIO OUT

OPTICAL

2. Plug the power cable into an AC outlet.

3. Turn on the power switch of the audio unit

(ampliﬁer, etc.) that is connected with this

unit. Set the selector on the connected unit

to this unit.

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

TROUBLESHOOTING

OTHERS

BASIC

OPERATION

ENGLISH

APPLICATION

OPERATION

BASIC OPERATION

NORMAL PLAYBACK

SUPER AUDIO CD PLAYER PLAYBACK

1. 4.2. 3.

1. Keep pressing the POWER Switch for about

a second to turn on the system.

Display

The display cycles from TOC Reading →

No Disc (when no disc is loaded) → Super

Audio CD (when the start sound mode

setting is Super Audio CD).

2. Press the 0 button.

The disc tray comes out. Place the disc with

label side up on the tray.

To play a single (8cm) CD, place the disc

with the indentation at the center of the

tray.

3. Press 0 button.

Caution:

Do not close the disc tray by pressing it in with your

hand, as this will damage it.

4 . Press 2 button.

Disc type is automatically detected and

playback is started. Track number and track

elapsed time (minute, second) appear on

the display.

• For Super Audio CD/CD hybrid-layer

discs (see page 2), the layer that is set

in the start sound mode (see page 16)

is played. To change the layer, use the

S.MODE button (see page 15).

(Exp.:Track 6, Elapsed time 2 min 8 sec)

Number of current track Minutes Seconds

Playback automatically stops at the end of the ﬁnal

track.

TO STOP PLAYBACK

Press 7 button.

TO EJECT DISC

Press 0 button to open the disc tray and take the

disc off. Press the button again to close the tray.

Disc tray must be closed when the unit is not be

used.

TO PAUSE PLAYBACK

Press 8 button.

PAUSE indicator will light and playback is paused

at the point that the button is pressed. To restart

playback, press 8 button again or press 2 button.

PLAYING YOUR FAVORITE

TRACKS OF A DISC

0-9

¢4

SPECIFY TRACK NUMBER TO PLAY

(DIRECT SEARCH)

Specify track number with numerical buttons (0-9)

on the remote controller.

(example)

3rd track : Press 3.

12th track : Press 1 and then press 2 (within

approximately 1.5 seconds).

IF A WRONG NUMBER IS PRESSED

If a track number that is not in the disc is speciﬁed,

“No Track” will be shown on the main display.

Press correct number again.

SKIPPING TO THE PREVIOUS OR NEXT

TRACK (TRACK SKIP)

TO LISTEN TO A TRACK POSTERIOR TO THE

CURRENT TRACK

Press the ¢ button on the remote controller or

the unit the same number of times as the number

of tracks you want to advance.

TO LISTEN TO A TRACK PRIOR TO THE CURRENT

TRACK

If the 4 button is pressed on the unit or the

remote controller while playing a track, playback

starts again from the start of the current track.

Continue to press the 4 button for the same

number of times as the number of tracks you want

to return.

PLAYING YOUR FAVORITE

PARTS OF A DISC (SEARCH)

¢4

The search is started by holding down the 4, ¢

buttons on the player or the 1, ¡ buttons on the

remote control unit during playback.

The search speed can be changed by pressing the

4, ¢ buttons on the player or the 1, ¡

buttons on the remote control unit.

The search speed changes in 4 steps: 1 → 2 → 3

→ 4 → 1.

4 is the fastest search speed.

When the speciﬁc part you wish to hear is near,

press the 2 button.

Note:

No sound is output during the search operation.

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

TROUBLESHOOTING

OTHERS ADVANCED

CONNECTIONS

ENGLISH

APPLICATION

OPERATION

ADVANCED CONNECTIONS

CONNECTING THE OPTICAL OUTPUT CONNECTOR

Use an optical digital connecting cable available on the market. Insert the plug ﬁrmly in until it clicks into

place. Do not bend or bundle the optical digital connecting cable.

CONNECTING TO A DIGITAL AUDIO COMPONENT

The player has one digital optical output connector and one digital coaxial output connector.

You can enjoy digital recording when the player is connected to a CD recorder or other digital recording component.

Caution:

Signals come of the Digital Audio Output (Optical and Coaxial) terminals only at the time of audio CD playback. There are no signals when other media are being played back.

CONNECTING THE COAXIAL OUTPUT CONNECTOR

Use a coaxial digital connecting cable available on the market.

INPUT OUTPUT

MD/CDMD

DIGITAL IN/OUT

INPUT

ANALOG IN/OUT

OUTPUT

MD MD COMMON

OPTICAL

AC IN

DIGITAL AUDIO OUT

OUT

REMOTE CONTROL

ANALOG OUTPUT

R L

OPTICALCOAXIAL

INTERNAL

EXTERNAL

Optical digital connecting cable (available on market)

: Signal ﬂow

CD recorder, MD deck, AV ampliﬁer, etc.

INTERNAL

EXTERNAL

INPUT

ANALOG IN/OUT

OUTPUT OUTPUT

DIGITAL IN/OUT

INPUT

OPTICAL COAXIAL CONTROL

REMOTE

INPUT OUTPUT

OUT

AC IN

DIGITAL AUDIO OUT

OUT

REMOTE CONTROL

ANALOG OUTPUT

R L

OPTICALCOAXIAL

INTERNAL

EXTERNAL

Coaxial digital connecting cable (available on market)

: Signal ﬂow

CD recorder, MD deck, AV ampliﬁer, etc.

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

TROUBLESHOOTING

OTHERS

ADVANCED

CONNECTIONS

ENGLISH

APPLICATION

OPERATION

ADVANCED CONNECTIONS

REMOTE CONTROL CONNECTION

Connecting this player to additional Marantz audio equipment using the supplied remote control cable

enables remote control of the connected equipment as a single audio system.

• When connecting equipment incorporating a remote sensor, connect the “remote control out” connector

of the equipment to the “remote control in” jack of the CD player.

When doing this, set this player’s switch to “EXTERNAL.” This will stop its remote control IR receiver

from operating and the player can now be controlled via the remote control IR receiver of the attached

equipment.

GND

CD AUX

DVD

TUNER

OUTIN

RECORDER 1

OUTIN

RECORDER 2

PHONO

AC IN

AC OUTLET

UNSWITCHED

100W 1A MAX

100V 50/60Hz

OUT

REMOTE

CONTROL

POWER AMP

DIRECT IN

PRE OUT

SPEAKERS

SYSTEM A

R L

AC IN

DIGITAL AUDIO OUT

OUT

REMOTE CONTROL

ANALOG OUTPUT

R L

OPTICALCOAXIAL

INTERNAL

EXTERNAL

Set to “EXTERNAL.”

Remote connector cable (supplied)

: Signal ﬂow

Ampliﬁer

TIMER PLAY

This unit can perform timer play by cooperating with your audio timer.

Connect this unit’s power cord to the audio timer’s power socket and the timer’s power cord to power

outlet.

• For connection to audio timer and it’s operation, please refer to the instruction manual of your audio

timer.

AC IN

DIGITAL AUDIO OUT

OPTICALCOAXIAL

Audio Timer

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

TROUBLESHOOTING

OTHERS ADVANCED

CONNECTIONS

ENGLISH

APPLICATION

OPERATION

TIMER PLAY SETTING

Time Play is set in the following hierarchical logic.

Timer Play

CD/SA-CD

USB

Off

File Sel

(SA8003)

SA7003

1. Keep pressing the POWER Switch for about

a second to turn on the system.

2. Press the MENU button on the remote

control unit.

3. Display “TIMER PLAY=>” in the display

area and then press ENTER button on the

remote control unit.

4. Display “2 ON” with the 4, ¢ buttons,

and then press ENTER button on the remote

control unit.

5. Press the MENU button on the remote

control unit to complete the setting.

6. Insert the disc to be played.

7. Set the audio timer.

SA8003

1. Keep pressing the POWER Switch for about

a second to turn on the system.

2. Press the MENU button on the remote

control unit.

3. Display “TIMER PLAY=>” in the display

area and then press ENTER button on the

remote control unit.

4. Display “2 ON” with the 4, ¢ buttons,

and then press ENTER button on the remote

control unit.

5. To play a CD/SA-CD disc with timer play,

display “1 CD/SACD” with the 4, ¢

buttons and then press ENTER button on

the remote control unit.

6. For USB playback with timer play, display

“2 USB” with the 4, ¢ buttons, and

then press ENTER button on the remote

control unit.

If USB is selected, the track to be played

during timer play can be selected. For the

selection method, refer to USB selection

method.

7. Press the MENU button on the remote

control unit to complete the setting.

8. If CD/SA-CD is selected, insert the disc to be

played.

ADVANCED CONNECTIONS

9. Set the audio timer.

Caution:

Insert a USB medium in advance when selecting

USB for Timer Play.

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

REMOTE CONTROLLER

OPERATION

TROUBLESHOOTING

OTHERS

APPLICATION

OPERATION

ENGLISH

TO CHANGE TIME DISPLAY

TIME

Press the TIME button on the remote control.

Each time TIME button is pressed, display will

change in the following order.

Track elapsed

time

Track remaining

time

Total remaining

time

• Track remaining time

(The remaining playing time from the playing

point to the end of the current track)

“REMAIN” is displayed

• Total remaining time

(The remaining playing time from the playing

point to the end of the last track)

“REMAIN TTL” is displayed

Track information does not appear when “Total

remaining time” is displayed.

APPLICATION OPERATION (CD OPERATION)

REPEATED DISC PLAY

(REPEATPLAY)

REPEAT

Each time the REPEAT button on the remote control

is pressed, the repeat mode cycles in the following

order.

OFF 1

ALL

ONE TRACK REPEAT

Press REPEAT button on the remote two times.

“1”, “RPT” indicators will light and the track will be

played repeatedly.

TO EXIT FROM ONE TRACK REPEAT

Press the REPEAT button on the remote control

twice. “1” “RPT” indicator will disappear, repeat

mode will be off and it returns to normal play

mode.

ALL TRACK REPEAT

When “Repeat” mode is off, press the REPEAT

button on the remote control twice. The “RPT”

indicator will light up and all track repeat play

begins.

TO RETURN TO NORMAL PLAY

Press the REPEAT button on the remote control

once. “RPT” indicator will disappear, repeat mode

will be off and it returns to normal play mode.

Note:

Random Play and AMS Play cannot be conducted

when the unit is in Repeat Mode.

PLAYING TRACKS IN A RANDOM

SEQUENCE (RANDOM PLAY)

RANDOM

When the RANDOM button on the remote

control is pressed in stop mode, and then the 2

button is pressed, the unit shufﬂes the track order

automatically and plays all tracks randomly in the

shufﬂed order.

The display’s “RNDM” (random) indicator will

light-up.

Note:

Repeat Play and AMS Play cannot be conducted

when the unit is in Random Mode.

• If the ¢ button on the main unit, or the ¢

button on the remote control are pressed during

Random Play, the player jumps to the next track

of the shufﬂed order.

• To search through the current track during random

play, press and continue holding the 4/1,

¡/¢ buttons on the main unit or press the

1, ¡ buttons on the remote control.

TO EXIT FROM RANDOM PLAY AND RETURN TO

NORMAL PLAY

Press the 7 button, and then press the RANDOM

button while playback is stopped.

The RNDM (random) indicator goes off, and random

play is released.

PLAYING TRACKS IN A SPECIFIC

SEQUENCE (PROGRAM PLAY)

You can arrange and play tracks in a specific

sequence. Up to 24 tracks to be played can be

programmed.

1. Press PROGRAM button on the remote in

stop mode. “PROG” indicator will blink and

it goes to program mode.

Lights up

2. Choose a track to be programmed with

numeric buttons on the remote.

(Example: The 15th track is chosen and it’s

length is 4min30sec)

Lights up

1st track programmed

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

REMOTE CONTROLLER

OPERATION

TROUBLESHOOTING

OTHERS APPLICATION

OPERATION

ENGLISH

APPLICATION OPERATION (CD OPERATION)

3. With the sequence described in step 2

above, program another track. Repeat that

sequence to program all the tracks you

want. You can program up to 30 tracks.

(Example: The 7th track is chosen and total

length of 7th and 15th is 7min50sec)

Total programmed

number

Total playing time of

programmed tracks

4. Press 2 button to starts playback in

programmed order.

Note:

Repeat Play, Random Play, and AMS Play cannot

be conducted while the unit is in PROGRAM mode

(i.e. when the PROG indicator is lit).

TO CHECK THE PROGRAMMED

TRACKS

CLEAR

TO DELETE A PROGRAMMED TRACK

1. Press CLEAR button in stop mode when

program has been made (When “PROG”

indicator is lighting up).

2. Every time press CLEAR button, the

programmed tracks are deleted in order

from the last track programmed.

TO CLEAR WHOLE PROGRAM

Press 7 STOP button two times while in program

play. In the stop mode, press 7 STOP button once.

Program can also be cleared by pressing 0 OPEN/

CLOSE button to open the disc tray.

TO ADD TRACKS TO PROGRAM

Tracks can be added to the end of program when

program is remaining (“PROG” indicator is lighting

up) and in stop mode.

PLEASE BE CAREFUL ABOUT THE FOLLOWING

MATTERS

• When programming 1st through 9th tracks in a

disc that has over 10 tracks by using numeric

buttons. For instance, programming the 3rd track

after programming the 1st track, press 3 button

more than approximately 1.5 seconds after 1

button is pressed. When a program is ﬁnalized,

the time is updated.

• Likewise, when programming a track at 10th or

after. For example, to program 13th track, press 3

button within approximately 1.5 seconds after 1

button is pressed.

• When programming a track in a disc that has less

than 9 tracks. For instance, to program the 5th

track after 4th track has been programmed, press

5 button more than approximately 0.5 second

after 4 button is pressed.

SEARCHING YOUR FAVORITE

TRACKS (AMS (AUTOMATIC

MUSIC SCAN) PLAY)

AMS

This feature is convenient for searching where your

favorite track is.

If the AMS button is pressed while a track is

stopped, the PLAY indicator “2” ﬂashes, and the

ﬁrst ten seconds of each track on the disk will be

played starting from the ﬁrst track.

Also, if the AMS button is pressed during playback,

the PLAY indicator “2” ﬂashes, and the program

jumps to the next track after approximately

10 seconds elapses on the display time.

Once you ﬁnd a song that you want to listen to,

press the AMS button again or press the 2 button.

The PLAY indicator lights up and normal playback

resumes from the current track.

Note:

AMS Play cannot be conducted while the unit is in

PROGRAM mode.

SWITCHING SOUND MODE

(SUPER AUDIO CD)

Please set Start Sound Mode to “SA-CD” (see

page 16).

S.MODE

1. Press S.MODE button in stop mode (not

playing).

The currently selected layer or area is

shown on the display. (CD or Super Audio

CD)

If S.MODE button is pressed again, a

playable layer or area will be shown, and

the layer or area will be switched to new

one.

• When layer or area is switched, TOC will

be read again.

• The sound mode cannot be changed for

Audio CDs and discs with only a Super

Audio CD area.

• The sound mode on hybrid layer discs

will be changed in the following order.

Super Audio CD stereo area

CD layer

2 . Press the S.MODE button during playback.

The currently selected layer or area is

shown on the display. (CD or Super Audio

CD)

If S.MODE button is pressed again, the

playback is stopped, and the layer or area

will be switched to new one.

When you want to listen at that area,

press 2 button again. The playback will be

started.

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

REMOTE CONTROLLER

OPERATION

TROUBLESHOOTING

OTHERS

APPLICATION

OPERATION

ENGLISH

APPLICATION OPERATION (CD OPERATION)

SWITCHING “START SOUND MODE”

The Start Sound Mode can be switched over in the

following hierarchical scheme.

SA-CD Mode SA-CD*

1. Press the MENU button on the remote

control.

2. Use the 4, ¢ buttons to display “SA-CD

Mode=>” and press ENTER button on the

remote control.

3. To load the SA-CD layer, use the 4, ¢

buttons to display “1 SA-CD” and press

ENTER button on the remote control.

4. To load the CD layer, use the 4, ¢

button to display “2 CD” and press ENTER

button on the remote control.

5. Press the MENU button on the remote

control unit to complete the setting.

WHEN START SOUND MODE IS SWITCHED TO

• At this time, if a Super Audio CD hybrid layer disk

is inserted, the CD layer is read.

• Sound Mode cannot be switched even if the

S.MODE button on the remote control is

pressed.

• If a disk with only a Super Audio CD area is

inserted, the Super Audio CD layer is read.

WHEN START SOUND MODE IS SWITCHED TO

SA-CD (DEFAULT MODE)

• At this time, if a Super Audio CD hybrid layer disk

is inserted, the Super Audio CD layer is read.

• Switch to the CD layer by pressing the S.MODE

button on the remote control.

• Switch back to the Super Audio CD layer by

pressing the S.MODE button on the remote

control once again.

SETTING THE DIGITAL OUTPUT

The settings can be made using the remote

control.

The settings are retained even if the power is turned

off so that you can always hear tracks played the

way you want.

Use the same procedures to change the settings

again.

The settings can be changed when the track is

stopped.

DURING THE PLAYBACK OF THE CD LAYER

OF AN AUDIO CD OR SUPER AUDIO CD

DIG.OUT

“DIGITAL OUTPUT OFF” OPERATION

The digital output function is turned ON and OFF

by pressing the DIG.OUT button while the track

is stopped. When digital output is turned off, the

“D OFF” indicator lights up on the display.

• When digital output is not used, turn off the digital

output to enjoy better sound quality.

Note:

Digital signals are only output when playing Audio

CDs.

They are not output when playing other media.

The “digital output off” has a memory retention

function where the settings remain stored and

unchanged even when the disk is changed or the

power is turned off.

* Default setting

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

REMOTE CONTROLLER

OPERATION

TROUBLESHOOTING

OTHERS APPLICATION

OPERATION

ENGLISH

NORMAL PLAYBACK

1. 3. 2. 4.

1 . Connect the USB medium to the USB port

on the front panel.

2 . Keep pressing the POWER Switch for about

a second to turn on the system.

The display cycles from “TOC Reading”

→ “No Disk” (when no disk is loaded) →

“SuperAudioCD” (when the Start Sound

Mode setting is Super Audio CD).

3. Press the DISC MEDIA/USB button on

the front panel, or the USB button on the

remote control.

APPLICATION OPERATION (USB/iPod OPERATION) - SA8003

4 . While the unit searches for USB media, the

display will read as follows.

When the unit finishes getting the USB

medium file information, the display

changes to the following.

Folder No. File No. File Name

Note:

When no USB medium is connected, the display

cycles from “USB Reading” → “USB”.

5. Press the 2 button.

Selected ﬁle information within the menu

and time information are displayed.

Folder No. File No. Time Information

When there are more than 1000 songs, the

display changes to appear as follows.

File Volume Time Information

TO STOP PLAYBACK

Press the 7 button.

TO PAUSE PLAYBACK

Press the 8 button.

Pause indicator will light and playback is paused at

the point that the button is pressed.

To resume playback, press the 8 button again or

press the 2 button.

Tip

• When playing USB media/iPod files, the unit

can play up to 65,535 ﬁles, 700 folders, and a

maximum of 8 levels.

• The iPod’s equalizer cannot be operated from

the Marantz player. We recommend that you turn

“off” the iPod’s equalizer before connecting the

iPod to the main unit.

• Some operations may differ depending on the

iPod model.

USING “REPEAT PLAY” MODE

You can repeatedly play a single song or all songs.

REPEAT

Each time the REPEAT button on the remote

control is pressed, Repeat Play mode cycles in the

following order.

OFF

ALL

Press the 2 button to begin playback in the selected

repeat mode (see page 14).

PLAYING TRACKS IN A RANDOM

SEQUENCE (RANDOM PLAY)

You can randomly play songs.

RANDOM

Press the RANDOM button on the remote control

while the player is stopped to turn random mode

ON or OFF.

Press the 2 button when random mode is turned

ON to start Random Play (see page 14).

SEARCHING YOUR FAVORITE TRACKS

(AMS (AUTOMATED MUSIC SCAN) PLAY)

You can play the ﬁrst 10 seconds of each track

starting from the ﬁrst track.

Press the AMS button on the remote control to

automatically begin AMS play (see page 15).

AMS

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

REMOTE CONTROLLER

OPERATION

TROUBLESHOOTING

OTHERS

APPLICATION

OPERATION

ENGLISH

CHOOSING FILES FROM A DIFFERENT

FOLDER

1. Press the FOLDER 5/∞ button to display

the current folder’s name and number.

Search for the folder that contains your

desired track.

2. When the name of the folder that contains

your desired track is displayed, press the

ENTER button on the remote control. The

title of the ﬁrst track in the folder will be

displayed.

3. Use the 4, ¢ buttons to select your

desired track. Press PLAY button to register

the selection and play.

PLAYING YOUR FAVORITE

TRACKS

¢4

0-9

SPECIFY RACK NUMBER TO PLAY

(DIRECT SEARCH)

Specify track number with numerical buttons (0-9)

on the remote.

(example)

3rd track : Press “3”.

12th track : Press

“1” and then press

“2” (within

approximately 1.5 seconds).

IF A WRONG NUMBER IS PRESSED

If a track number that is not in the folder is speciﬁed,

the screen will return to its previous display.

Press correct number again.

SKIPPING TO THE PREVIOUS OR NEXT

TRACK (TRACK SKIP)

TO LISTEN TO A TRACK POSTERIOR THE

CURRENT TRACK

Press the ¢ button on the main unit or the remote

control the same number of times as the number of

tracks you want to advance.

TO LISTEN TO A TRACK PRIOR TO THE CURRENT

TRACK

Press the 4 button on the main unit or remote

control once and the current track will start playing

again from the beginning.

Continue to press the 4 button on the main unit

or the remote control the same number of times as

the number of tracks you want to return.

APPLICATION OPERATION (USB/iPod OPERATION) - SA8003

PLAYING YOUR FAVORITE

PARTS OF A TRACK (SEARCH)

¢4

While playing a track, press and continue holding

the 4, ¢ buttons on the main unit or press the

1, ¡ buttons on the remote control to begin

track search.

You can change the search speed by pressing the

4, ¢ buttons on the main unit or the remote

control 4, ¢ buttons again.

For USB media, the player has 4 levels of search

speed with 4 being the fastest. It changes from 1

→ 2 → 3 → 4 → 1.

For iPods, there is only 1 level of search speed.

Release the 2 button when the point you want to

listen to gets close.

Note:

Sounds do not come out during search operations.

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

REMOTE CONTROLLER

OPERATION

TROUBLESHOOTING

OTHERS APPLICATION

OPERATION

ENGLISH

APPLICATION OPERATION (USB/iPod OPERATION) - SA8003

USB MEDIUM OPERATION

Sounds do not come out during search operations.

USB Setup1 File Name*

2 Title

1 Off*

2 On

1 Off*

2 On

3 Artist

4 Album

5 Time

File Info

Play

AMS

1 All*

2 Folder

1 All*

2 Folder

1 All*

2 Folder

1 All*

2 Folder

1 All*

2 Folder

Random

Repeat

Direct Sel

Range Spec

Resume

iPod Setup Database

File Info

Resume

PLAYING TRACKS FROM WHERE THEY

WERE PREVIOUSLY STOPPED (RESUME

PLAY)

1. Press the MENU button on the remote

control.

2. Use the 4, ¢ buttons to display “USB

Setup=>” or

“iPod Setup” and press ENTER

button on the remote control.

3. Use the 4, ¢ buttons to display

“Resume=>” and press ENTER button on

the remote control.

4. To enable Resume Play, use the 4, ¢

buttons to display “2 On” and press ENTER

button on the remote control.

To disable Resume Play, use the 4, ¢

buttons to display “1 Off” and press ENTER

button on the remote control.

5. Press the MENU button on the remote

control unit to complete the setting.

Note:

• Resume Play only works when an identical USB

medium is inserted. If another USB medium is

inserted, the unit will start playing from the ﬁrst

ﬁle.

• The unit may not play your desired track if ﬁles

have been added to or deleted from the identical

USB medium.

• In the case of the iPod, tracks will resume play

starting from the beginning of the track.

PLAYING YOUR FAVORITE TRACKS

You can specify whether tracks you want to hear

are selected using track numbers within a folder

or selected directly from all tracks on the USB

medium.

1. Press the MENU button on the remote

control.

2. Use the 4, ¢ buttons to display “USB

Setup=>” and press ENTER button on the

remote control.

3. Use the 4, ¢ buttons to display “Range

Spec=>” and press ENTER button on the

remote control.

4. Use the 4, ¢ buttons to display “Direct

Sel=>” and press ENTER button on the

remote control.

5. To select tracks using track numbers within

a folder, use the 4, ¢ buttons to display

“2 Folder” and press ENTER button on the

remote control.

To select tracks from all tracks on the

USB medium, use the 4, ¢ buttons to

display “1 All” and press ENTER button on

the remote control.

6. Press the MENU button on the remote

control unit to complete the setting.

REPEAT PLAY

You can specify whether to “repeat play” tracks

within a folder or to “repeat play” all tracks on the

USB medium.

1. Press the MENU button on the remote

control.

2. Use the 4, ¢ buttons to display “USB

Setup=>” and press ENTER button on the

remote control.

3. Use the 4, ¢ buttons to display “Range

Spec=>” and press ENTER button on the

remote control.

4. Use the 4, ¢ buttons to display

“Repeat=>” and press ENTER button on

the remote control.

5. To “repeat play” tracks within a folder, use

the 4, ¢ buttons to display “2 Folder”

and press ENTER button on the remote

control.

To “repeat play” all tracks on the USB

medium, use the 4, ¢ buttons to

display “1 All” and press ENTER button on

the remote control.

6. Press the MENU button on the remote

control unit to complete the setting.

* Default setting

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

REMOTE CONTROLLER

OPERATION

TROUBLESHOOTING

OTHERS

APPLICATION

OPERATION

ENGLISH

APPLICATION OPERATION (USB/iPod OPERATION) - SA8003

PLAYING TRACKS IN A RANDOM

SEQUENCE (RANDOM PLAY)

You can specify whether to “random play” tracks

within a folder or to “random play” all tracks on the

USB medium.

1. Press the MENU button on the remote

control.

2. Use the 4, ¢ buttons to display “USB

Setup=>” and press ENTER button on the

remote control.

3. Use the 4, ¢ buttons to display “Range

Spec=>” and press ENTER button on the

remote control.

4. Use the 4, ¢ buttons to display

“Random=>” and press ENTER button on

the remote control.

5. To “random play” tracks within a folder,

use the 4, ¢ buttons to display “2

Folder” and press ENTER button on the

remote control.

To “random play” all tracks on the USB

medium, use the 4, ¢ buttons to

display “1 All” and press ENTER button on

the remote control.

6. Press the MENU button on the remote

control unit to complete the setting.

SEARCHING YOUR FAVORITE TRACKS

(AMS (AUTOMATED MUSIC SCAN) PLAY)

You can specify whether to “AMS play” tracks

within a folder or to “AMS play” all tracks on the

USB medium.

1. Press the MENU button on the remote

control.

2. Use the 4, ¢ buttons to display “USB

Setup=>” and press ENTER button on the

remote control.

3. Use the 4, ¢ buttons to display “Range

Spec=>” and press ENTER button on the

remote control.

4. Use the 4, ¢ buttons to display

“AMS=>” and press ENTER button on the

remote control.

5. To “AMS play” tracks within a folder, use

the 4, ¢ buttons to display “2 Folder”

and press ENTER button on the remote

control.

To “AMS play” all tracks on the USB

medium, use the 4, ¢ buttons to

display “1 ALL” and press ENTER button

on the remote control.

6. Press the MENU button on the remote

control unit to complete the setting.

FILE INFORMATION DISPLAY SELECTION

You can view MP3 tags and other ﬁle information

when playing a USB medium.

1. Press the MENU button on the remote

control.

2. Use the 4, ¢ buttons to display “USB

Setup=>” and press ENTER button on the

remote control.

3. Use the 4, ¢ buttons to display “File

Info=>” and press ENTER button on the

remote control.

4. To view file names, use the 4, ¢

buttons to display “1 File Name” and press

ENTER button on the remote control.

To view track titles, use the 4, ¢ buttons

to display “2 Title” and press ENTER button

on the remote control.

To view artist names, use the 4, ¢

buttons to display “3 Artist” and press

ENTER button on the remote control.

To view album names, use the 4, ¢

buttons to display “4 Album” and press

ENTER button on the remote control.

To always view time information without

viewing ﬁle information, use the 4, ¢

buttons to display “5 Time” and press

ENTER button on the remote control.

5. Press the MENU button on the remote

control unit to complete the setting.

• Press the TEXT button on the remote

control during normal playback to view

selected ﬁle information.

• Press the TEXT button again to view the

track title. If “track title” was the selected

ﬁle information option, then the artist

name will be displayed.

• Each time the TEXT button on the remote

control is pressed, the display changes in

the following order: Track Title → Artist

Name → Album Name →Track Title.

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

REMOTE CONTROLLER

OPERATION

TROUBLESHOOTING

OTHERS APPLICATION

OPERATION

ENGLISH

iPod OPERATION

The iPod works in the following hierarchical logic.

iPod Setup 1 Album*

2 Artist

3 Genre

4 Track

1 Title*

2 Artist

3 Album

4 Time

Database

File Info

1 Off*

2 On

Resume

iPod DATABASE SELECTION

1. Press the MENU button on the remote

control.

2. Use the 4, ¢ buttons to display “iPod

Setup=>” and press ENTER button on the

remote control.

3. Use the 4, ¢ buttons to display

“Database=>” and press ENTER button on

the remote control.

4. To select albums by album name, use the

4, ¢ buttons to display “1 Album”

and press ENTER button on the remote

control.

To select albums by artist name, or if you

would like to play all tracks for a selected

artist, use the 4, ¢ buttons to display

“2 Artist” and press ENTER button on the

remote control.

To select artists by genre, use the 4, ¢

buttons to display “3 Genre” and press

ENTER button on the remote control.

To play tracks without using the database,

use the 4, ¢ buttons to display “4

Track” and press ENTER button on the

remote control.

5. Press the MENU button on the remote

control unit to complete the setting.

Note:

Please refer to your iPod instructions for information

on how to use with each database.

SELECTING TRACKS BY ANOTHER ARTIST

CLEAR

ENTER

FOLDERFOLDER

CLEAR

ENTER

FOLDERFOLDER

When the iPod database is set to “Artist”

1. Press the FOLDER 5/∞ button and either

“ALL” or the current artist will be displayed.

Press the CLEAR button on the remote

control and the currently selected artist will

be cancelled.

2. Press the FOLDER 5/∞ button and search

for your desired artist.

3. When your desired artist is displayed, press

ENTER button on the remote control and

either “All Album”, album name, or track

title will be displayed.

(Selecting from All Album)

4. When selecting from “All Album”, press

ENTER button on the remote control and

the title of the ﬁrst track by the artist will be

displayed.

5. Use the 4, ¢ buttons to select your

desired track. Press PLAY button to register

the selection and play.

(Selecting from Album)

4. When selecting from “Album”, press the

FOLDER 5/∞ button on the remote control

and the names of albums by the artist will

be displayed.

5. Press the FOLDER 5/∞ button and search

for your desired album.

6. When your desired album is displayed,

press ENTER button on the remote control

and the title of the ﬁrst track from the album

will be displayed.

7. Use the 4, ¢ buttons to select your

desired track. Press PLAY button to register

the selection and play.

Tip:

You can also use the remote control’s numeric keys

0-9 to select albums and tracks. Please refer to your

iPod instructions for information on how to use

with each database.

SELECTING TRACKS FROM A DIFFERENT

GENRE

CLEAR

ENTER

FOLDERFOLDER

CLEAR

ENTER

FOLDERFOLDER

When the iPod database is set to “Genre”

1. Press the FOLDER 5/∞ button and either

“ALL” or the name of the album currently

playing will be displayed.

2. Press the CLEAR button on the remote

control to cancel the currently selected

artist or genre. If artist is canceled, “ALL”

will be displayed.

3. Press the FOLDER 5/∞ button and search

for your desired genre.

4. When your desired genre is displayed,

press ENTER button on the remote control

and either “All Artist” or artist name will be

displayed.

APPLICATION OPERATION (USB/iPod OPERATION) - SA8003

* Default setting

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

REMOTE CONTROLLER

OPERATION

TROUBLESHOOTING

OTHERS

APPLICATION

OPERATION

ENGLISH

(Selecting from All Artist)

5. When selecting from “All Artist”, press

ENTER button on the remote control and

the title of the ﬁrst track within the genre

will be displayed.

6. Use the 4, ¢ buttons to select your

desired track. Press PLAY button to register

the selection and play.

(Selecting from Artist)

5. When selecting from “Artist”, press the

FOLDER 5/∞ button on the remote control

and search for your desired artist.

6. When your desired artist is displayed, press

ENTER button on the remote control and

either “All Album”, album name, or track

title will be displayed.

7. Push ENTER button again and the title of the

ﬁrst track by the artist will be displayed.

8. Use the 4, ¢ buttons to select your

desired track. Press PLAY button to register

selection and play.

(Selecting from the Album)

5. When selecting from “Album”, press the

FOLDER 5/∞ button on the remote control

and the names of albums by the artist will

be displayed.

6. Press the FOLDER 5/∞ button and search

for your desired album.

7. When your desired album is displayed,

press ENTER button on the remote control

and the title of the ﬁrst track from the album

will be displayed.

8. Use the 4, ¢ buttons to select your

desired track. Press PLAY button to register

selection and play.

SELECTING TRACKS FROM A DIFFERENT

ALBUM

When the iPod database is set to “Album”

1. Press the FOLDER 5/∞ button on the

remote control to display the name of the

current album. Press the FOLDER 5/∞

button and search for your desired album.

2. When your desired album is displayed,

press ENTER button on the remote control

and the title of the ﬁrst track from the album

will be displayed.

3. Use the 4, ¢ buttons to select your

desired track. Press PLAY button to register

selection and play.

Tip:

You can also use the remote control’s numeric keys

0-9 to select albums and tracks.

FILE INFORMATION DISPLAY SELECTION

TEXT

You can view ﬁle information when playing iPod

ﬁles.

1. Press the MENU button on the remote

control.

2. Use the 4, ¢ buttons to display “iPod

Setup=>” and press ENTER button on the

remote control.

3. Use the 4, ¢ buttons to display “File

Info=>” and press ENTER button on the

remote control.

4. To view track titles, use the 4, ¢ buttons

to display “1 Title” and press ENTER button

on the remote control.

To view artist names, use the 4, ¢

buttons to display “2 Artist” and press

ENTER button on the remote control.

To view album names, use the 4, ¢

buttons to display “3 Album” and press

ENTER button on the remote control.

To always view time information without

viewing ﬁle information, use the 4, ¢

buttons to display “4 Time” and press

ENTER button on the remote control.

5. Press the MENU button on the remote

control unit to complete the setting.

• Press the TEXT button on the remote

control during normal playback to view

selected ﬁle information.

• Press the TEXT button again to view the

track title. If “track title” was the selected

ﬁle information option, then the artist

name will be displayed.

• Each time the TEXT button on the

remote control is pressed, the displayed

information changes in the following

order: Track Title→Artist Name→Album

Name→Track Title.

APPLICATION OPERATION (USB/iPod OPERATION) - SA8003

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

TROUBLESHOOTING

OTHERS

TROUBLESHOOTING

ENGLISH

APPLICATION

OPERATION

TROUBLESHOOTING

If you think that something is wrong with your player, ﬁrst check the points listed below. Incorrect operations

can sometimes be taken for trouble and malfunctions. If the trouble persists even after the following points

have been checked, consult your dealer or nearest Marantz sales ofﬁce or service center.

Problem Cause Corrective action

The disc fails to rotate.

The power cord is pulled out of the

socket.

Insert the power cord plug into the

socket. (→ Page 9)

Power to this unit is not ON. Turn the power to this unit ON.

(→ Page 10)

The disc is not placed in the correct

position on the disc tray.

Place the disc in the disc tray correctly.

(→ Page 10)

The disc is placed in upside down. (The

disc is placed in with the label facing

down).

Place the disc in the disc tray correctly.

(→ Page 10)

The disc stops rotating in

mid-operation.

The disc is dirty. Clean the disc’s surface. (→ Page 28)

The disc is scratched. The disc may be unable to be played if

it has a lot of scratches.

The disc is warped. The disc may be unable to be played if

it is badly warped.

The disc is rotating but no

sound is heard.

The ampliﬁer and speakers are not

connected correctly.

Connect the cables correctly.

(See the instruction manual for the

ampliﬁer.)

The ampliﬁer power is not ON.

Turn ON the power to the ampliﬁer.

(See the instruction manual for the

ampliﬁer.)

The ampliﬁer’s function or selector

switch is not set to “CD” or “AUX” or

such (to whatever you have connected

this unit to).

Switch the ampliﬁer’s function or

selector switch to “CD” or “AUX” or

such (to whatever you have connected

this unit to).

(See the instruction manual for the

ampliﬁer.)

The ampliﬁer’s volume control is set at

the minimum level.

Adjust the ampliﬁer volume.

(See the instruction manual for the

ampliﬁer.)

Problem Cause Corrective action

Remote control operation is

not possible.

The distance between this unit and the

remote control is too great.

Move closer to this unit, and operate

the remote control within the

operating range. (→ Page 4)

There is an obstacle between this unit

and the remote control. Remove the obstacle. (→ Page 4)

The remote control’s batteries are dead. Replace all batteries with new ones.

(→ Page 4)

A strong light is hitting the unit’s sensor

window.

Do not let strong light hit the sensor

window. (→ page 4)

The switch on the back of the REMOTE

CONTROL is on EXTERNAL.

When using this unit independently,

set the switch to INTERNAL. (→ Page

12)

CD-R/CD-RW disc cannot be

played.

The disc is placed in upside down. Place the disc in the tray correctly.

(→ Page 10)

The information recorded is not in an

audio (CD-DA) format. Or the MP3/

WMA ﬁle was not properly recorded.

Record correct information that is

compatible with to this unit. (→ Page

28)

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

TROUBLESHOOTING

OTHERS

TROUBLESHOOTING

ENGLISH

APPLICATION

OPERATION

TROUBLESHOOTING

USB/iPod(SA8003)

Problem Cause Corrective action

“OverCurrent” appears on

the display.

The voltage able to be supplied from this

unit via the USB has been exceeded.

The USB media is not supported.

Please use a USB device with an

operating current that is less than

500 mA.

“FAT Error” or “Cluster Err”

appear on the display.

An unsupported ﬁle system is being

used. USB memory below 128 MB

cannot be supported.

Please use a USB device formatted

with a compatible file system (FAT32

or FAT) and that has at least 256 MB

of memory.

“No File” appears on the

display.

No ﬁle able to be played on this unit

exists.

Check supported formats. (→ Page

25, 26)

“DRM Stream” appears on

the display.

This is a ﬁle subject to digital rights

management.

Cannot play on this unit because of

unsupported DRM. (→ Page 25)

The sound of the USB being

connected is not heard.

The ampliﬁer and speakers are not

connected properly.

Connect the cables correctly.

(→See the instruction manual for the

ampliﬁer.)

The ampliﬁer power is not ON.

Turn the amplifier power ON.

(→See the instruction manual for the

amplifier.)

The ampliﬁer’s function or selector

switch is not set to “CD” or “AUX” or

such (to whatever you have connected

this unit to).

Switch the amplifier’s function or

selector switch to “CD” or “AUX” or

such (to whatever you have connected

this unit to).

(→See the instruction manual for the

amplifier.)

The ampliﬁer’s volume control is set at

the minimum level.

Adjust the ampliﬁer volume.

(→See the instruction manual for the

ampliﬁer.)

The sound of the iPod being

connected is not heard.

3rd generation or earlier iPods are

unsupported.

Refer to “ABOUT iPod PLAYBACK”.

(→ Page 26)

The amplifier and speakers are not

connected correctly.

Connect the cables correctly.

(→See the instruction manual for the

amplifier.)

The amplifier power is not ON.

Turn ON the power to the amplifier.

(→ See the instruction manual for the

amplifier.)

The ampliﬁer’s function or selector

switch is not set to “CD” or “AUX” or

such (to whatever you have connected

this unit to).

Switch the ampliﬁer’s function or

selector switch to “CD” or “AUX” or

such (to whatever you have connected

this unit to).

(See the instruction manual for the

ampliﬁer.)

The ampliﬁer’s volume control is set at

the minimum level.

Adjust the ampliﬁer volume.

(See the instruction manual for the

ampliﬁer.)

Reading of USB device

takes time.

When connecting a high-capacity

USB device, it will take time to read

depending on its capacity. Several

minutes may be required for reading

when using a high-capacity device.

Wait until reading is completed.

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

TROUBLESHOOTING

OTHERSOTHERS

ENGLISH

APPLICATION

OPERATION

OTHERS

ABOUT WMA PLAYBACK

• Windows Media is a trademark of the Microsoft

Corporation in the US and other countries.

• WMA is an abbreviation for “Windows Media

Audio” and is an audio compression technology

developed by the Microsoft Corporation. WMA

data may be encoded using Windows Media®

Player Ver. 7, 7.1, Windows Media® Player for

Windows® XP, or Windows Media® Player 9

Series.

• Use discs recorded conforming to the ISO

9660 Level 1/Level 2 CD-ROM ﬁle system and

extended format (Joliet, Romeo).

• Multi-session recording is not supported.

• WMA ﬁles having DRM copy protection cannot

be played.

• Encode WMA ﬁles using applications that have

received Microsoft Corporation certiﬁcation. If an

uncertiﬁed application is used, it may not operate

normally.

WMA FILES

Standard

Conforming to Microsoft Windows

Media Audio 9.2

The following are unsupported

• WMA9 Series Professional

• WMA9 Series Voice

• WMA9 Series Lossless

• WMA with Video

Extension .wma

Bit rate

[kbps]

CBR: 48~320

VBR: Peak 384 (display corresponds

to average bit rate value)

Sampling

frequency

[kHz]

32/44.1/48

Channels 2ch (Stereo)

Textual

information

Title: 128 Byte

Composer (Name of artist): 128 Byte

Name of album: 128 Byte

ABOUT WINDOWS MEDIA DRM

Windows Media Digital Rights Management (DRM)

(referred to below as WMDRM) is a platform

to prevent playback on computers, digital audio

players, network devices and the like in order to

securely distribute digital content.

Content protected by WMDRM may be played back

only when connected to a media server that has

WMDRM functionality.

This system does no comply with any contents

protected by WMDRM.

ABOUT MP3 PLAY BACK

• Use discs recorded conforming to the ISO

9660 Level 1/Level 2 CD-ROM ﬁle system and

extended format (Joliet, Romeo).

• MPEG1 Audio Layer-3 ﬁles recorded at sampling

frequencies of 32 kHz, 44.1 kHz, or 48 kHz are

supported. For ﬁles recorded with a frequency

other than this, “No File” will be displayed, and

these ﬁles cannot be played.

• Variable Bit Rate (VBR) is not supported (when

playback is possible, the time display in the

display window will speed up and slow down).

• Multi-session recording is not supported.

• For audio quality, a recording rate of 128 kbps or

higher is recommended.

MP3 FILES

Standard MPEG-1 Audio Layer3

Extension .mp3

Bit rate

[kbps]

For MPEG-1 Audio Layer3,

32/40/48/56/64/80/96/112/128/160/

192/224/256/320

Sampling

frequency

[kHz]

For MPEG-1 Audio Layer3,

32/44.1/48

Channels 2 ch (Stereo)

Emphasis OFF

Textual

information

[ID3v2 (v2.2/v2.3/v2.4)]

Title: 128 Byte

Name of artist: 128 Byte

Name of album: 128 Byte

Comment: 128 Byte

[ID3v1 (v1.0/v1.1)]

Title: 30 Byte

Name of artist: 30 Byte

Name of album: 30 Byte

Comment: 30 Byte

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

TROUBLESHOOTING

OTHERSOTHERS

ENGLISH

APPLICATION

OPERATION

OTHERS

ABOUT AAC PLAYBACK

• AAC is an abbreviation for “Advanced Audio

Coding”. It is the basic format related to the audio

compression technology used in MPEG-2 and

MPEG-4.

• Playing of AAC files that have the extension

“.m4a” encoded using iTunes® is supported

with this device. However, ﬁles may be unable

to be played due to having DRM copy protection

(copyright protection) or because of the version of

iTunes they have been encoded with.

• iTunes is a trademark of Apple Inc. that is

registered in the US and other countries.

• This applies to ﬁles created with iTunes.

Standard MPEG-4/AAC LC (Low Complexity)

MPEG-2/AAC LC (Low Complexity)

Extension .m4a

Bit rate

[kbps] 8~320

Sampling

frequency

[kHz]

32/44.1/48

Channels 2 ch (Stereo)

Textual

information

[MPEG-4 header (iTunes content

information)]

Name (Title): 128 Byte

Name of artist: 128 Byte

Name of album: 128 Byte

Comment: 128 Byte

ABOUT iPod PLAYBACK

• If a 5th generation or later iPod, iPod nano, iPod

classic or iPod touch is connected, it can be

played with even higher sound quality because

the audio from the iPod is transmitted digitally

(LPCM).

• Some operations may differ depending on the

iPod model.

• If the iPod’s software is old, it may not operate

properly. Please be sure to use up-to-date iPod

software.

• The TEXT display is alphanumeric only. If non-

alphanumeric characters have been recorded in

the iPod, the characters will be displayed as “*”.

• The iPod is a device licensed for the private

duplication and playback of uncopyrighted material

or material for which duplication and playback are

legally permitted. Violation of copyright is legally

prohibited.

• The iPod equalizer cannot be operated from the

SA8003. Before connecting an iPod to this unit, it

is recommended that the iPod equalizer be set to

“OFF”.

• Please note that we offer no compensation if

problems occur in the iPod data when using this

unit with an iPod.

iPod is a trademark of Apple Inc. registered in the

US and other countries.

ABOUT WAV PLAYBACK

Standard RIFF Waveform Audio Format

Format Linear PCM

Extension .wav

Sampling

frequency

[kHz]

Linear PCM: PCM 32/44.1/48

Those other than the above, not

supported.

Number of

bits [bit] Linear PCM: 16

Channels 2 ch (Stereo)

Textual

information None

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

TROUBLESHOOTING

OTHERSOTHERS

ENGLISH

APPLICATION

OPERATION

OTHERS

SPECIFICATIONS & DIMENSIONAL DRAWINGS

POWER SUPPLY

Power Supply ................................ AC 230V 50Hz

Power Consumption ..................................... 25W

Power consumption in standby mode ....... 0.5W

CABINET, ETC.

Dimensions (Width × Height × Depth)

........ (SA8003) 440 × 108.5 × 343.5mm

........... (SA7003) 440 × 107 × 339.5mm

Net weight

......................................... (SA8003) 7.8kg

......................................... (SA7003) 5.9kg

Operating temperatures ................. +5˚C ~ +35˚C

Operating humidity ........5 ~ 90% (without dew)

ACCESSORIES

• Remote control unit ...............................1

Net weight ....................................... 110g

• AAA (R03) Batteries ...............................2

• AC Power cord ........................................1

• Audio cable .............................................1

• Remote control connecting cord ..........1

• User’s Guide ...........................................1

Specifications subject to change without prior

notice.

107

90.516.5

440

339.5 6

33.5

108.5

9216.5

440

343.5 10

33.5

SA7003SA8003

Super Audio CD Audio CD

Audio Characteristics

Analog output

Channels

Frequency range

Frequency characteristics

Dynamic range

S/N Ratio (A-weighted)

THD (1kHz)

wow & ﬂutter

Output level

Unbalanced

Digital output

output level (cinch JACK)

output level (optical)

2channels

2Hz — 100kHz

2Hz — 50kHz (-3dB)

112dB

110dB

0.0020%

Precision of quartz

2.3V RMS stereo

—

2channels

2Hz — 20kHz

100dB

110dB

0.0020%

Precision of quartz

2.3V RMS stereo

0.5Vp-p (75W)

-19dBm

Optical Readout System

Laser

Wave length

AlGaAs

650nm

AlGaAs

780nm

Signal format

Sampling frequency

1-bit DSD

2.8224MHz

16-bit linear PCM

44.1kHz

DIMENSIONS (UNIT: MM)

CLASS 1 LASER PRODUCT

LUOKAN 1 LASERLAITE

KLASS 1 LASERAPPARAT

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

TROUBLESHOOTING

OTHERSOTHERS

ENGLISH

APPLICATION

OPERATION

NOTES ABOUT THE DISCS

* Handle the discs carefully so as not to scratch

their surfaces.

* Keep the surfaces of the discs clean at all

times.

When cleaning the surfaces of discs, always

be sure to use the special cleaner and wipe the

surfaces in the directions shown in the ﬁgure

below.

• Wipe the surface

radially from the

center.

• Do not wipe the surface

in the circumferential

direction.

* Do not attach pieces of paper or stickers to

the label surfaces of the discs.

When a disc has a piece of plastic tape or rental

CD label with paste protruding from the edge or

when a disc still bears traces of sticky tape or

adhesive labels, do not attempt to play it. If such a

disc is played on the CD player, you may ﬁnd that

you cannot remove it or that some other kind of

malfunctioning may occur.

* Do not use discs which come in special

shapes.

Do not attempt to play heart-shaped or octagonal

discs or discs with any other special shapes. You

may find that you cannot remove them or that

some other kind of malfunctioning may occur in

the player.

* Use discs which satisfy the CD standards such

as those with the “CD logo”, “ ” or “

TEXT

”

mark on their disc label surfaces.

No guarantees are made for playback if discs

which do not satisfy the appropriate CD standards

are used.

Similarly, no guarantees are made for their sound

quality even if it is possible to play such discs.

* To protect your discs from damage, avoid

placing them in the following locations.

• Where they will be exposed to direct sunlight or

where they will be close to a heater or other heat-

radiating appliance

• Where the humidity level is high or it is very

dusty

• Near a window or other such location where they

may be exposed to rain

* Get into the habit of putting the discs back in

their cases after use.

OTHERS

ABOUT PLAYING COPY-CONTROLLED CDS

Some copy-controlled CDs may not conform to

ofﬁcial CD standards. They are special discs and

may not play on the unit.

PLAYING CD-R/CD-RW DISCS

This unit can play back the CD-RW (ReWritable)

discs as well as ordinary Audio CD and CD-R

(Recordable) discs.

• The CD-R and CD-RW discs should contain

properly-recorded TOC* information so that they

can be played back. In CD recorders, the task of

writing TOC information is referred to as ﬁnalizing

the disc. Discs that are not ﬁnalized cannot be

properly recognized as an Audio CD and played

back by regular CD players and Super Audio CD

players. For details, please read the instruction

manual provided with a CD recorder.

* TOC stands for Table Of Contents and contains

information such as the total number of tracks

and total playing time of the disc.

• This unit can play CD format, video CD format,

and CD-R/CD-RW discs which contain WMA/

MP3 music data. However, some discs may have

problems such as unable to play, noise or sound

distortion.

• This device is exclusively a playback device. It

cannot record CD-R/CD-RW discs.

• As the playback of a CD-RW disc necessitates

partial change of the player setup, it may take

longer time for reading the TOC information than

when an Audio CD or CD-R disc is played.

• Depending on the application settings and

environment, discs recorded with a personal

computer may not be able to be played. Please

record with the correct format. (For details,

please inquire at your application sales agent.)

• Discs recorded with the packet writing system

cannot be played.

• Mixed mode CD/enhanced CD and DTS CD discs

cannot be played.

• CD-G, video CD and DVD discs cannot be

played.

ABOUT DUALDISC PLAYBACK

• “DualDisc” contains DVD-standard-compliant

video and audio on one side and audio for playing

on a CD player on the other side, respectively.

• Since the non-DVD audio side does not conform

to common CD physical standards, it may not be

able to be played.

• In regard to details such as “DualDisc”

speciﬁcations and standards, please inquire at

your selling agent or distributor.

ABOUT USB MEDIA

• Music files cannot be played by connecting

this unit to a personal computer with a USB

cable. This is a device that belongs to a class

of USB mass storage such as USB memory

(FAT16, FAT32 format supported), which this unit

supports.

• There are cases where playback of all USB

memory or supplying electrical power cannot

be guaranteed. In addition, please note that we

cannot assume any responsibility in the unlikely

event of loss of USB memory ﬁles.

NAMES AND

FUNCTIONS

BASIC

CONNECTION

BASIC

OPERATION

ADVANCED

CONNECTIONS

TROUBLESHOOTING

OTHERSOTHERS

ENGLISH

APPLICATION

OPERATION

OTHERS

The section describes the care and maintenance

tasks that must be performed to optimize the

operation of your Marantz equipment.

CLEANING OF EQUIPMENT EXTERNAL

SURFACES

The exterior ﬁnish of your unit will last indeﬁnitely

with proper care and cleaning, Never use scouring

pads, steel wool, scourging powders or harsh

chemical agents (e.g., lye solution), alcohol, thinner,

benzine, insecticide or other volatile substances as

these wil mar the ﬁnish of the equipment. Likewise,

never use cloths containing chemical substances. If

the equipment get dirty, wipe the external surfaces

with a soft, lint-free cloth.

If the equipment becomes heavily soiled:

• dilute some washing up liquid in water, in a ratio

of one part detergent to six parts water.

• dip a soft, lint free in the solution and wring the it

is damp.

• wipe the equipment with the damp cloth.

• dry the equipment by wiping it with a dry cloth.

REPAIRS

Only the most competent and qualified service

technicians should be allowed to service the

factory-trained warranty station personnel have

the knowledge and special facilities needed for

repair and calibration of this precision equipment.

After the warranty period has expired, repairs will

be performed for a charge if the equipment can be

returned to normal operation.

In the event of difﬁculty, refer to your dealer or write

directly to the nearest location to you that is listed

on the Marantz Authorized Service Station list. If

writing, please include the model and serial number

of the equipment together with a full description of

what you think is abnormal about the equipment’s

behaviour.

www.marantz.com

You can find your nearest authorized distributor or dealer on our website.

is a registered trademark.

Printed in China 07/2008 541110093134M mzh-d

Marantz Sa7003 Users Manual

Navigation menu

Versions of this User Manual:

Views

Navigation
