Mattel asia Pacific Sourcing Ltd. RC HW GYMKHANA CAR Users Manual
Users Manual
Keep these instructions for future reference as they contain
important information. IMPORTANT: Please read all
“Consumer Information” before operating your vehicle.
CAUTION:
Surfaces may become hot and
cause burns if electronics get wet. Do not
operate vehicle through water or snow.
CAUTION:
To prevent entanglement, keep all
hair away from the wheels.
I. CONTENTS/ FEATURES
Vehicle
Transmitter
Steering wheel
Battery cover
ON (I) / OFF (0)
Steering adjuster
Tight Drift Button
8+
®
1
2
3
4
5
V0098-0920
I O
2
4
3
5
1
2
V0098-0920 .indd 1 3/28/11 7:43:38 PM
II. BATTERY INSTALLATION
(Transmitter & Vehicle)
Requires 6 AA alkaline batteries for the vehicle and 2 AA
alkaline batteries for the transmitter. Batteries not included.
Vehicle
1. Unscrew the battery cover with a Phillips head
screwdriver (not included).
2. Your vehicle requires 6 AA alkaline batteries. Install with
polarity (+/-) as shown inside the battery compartment.
3. Replace battery cover and tighten screw.
Transmitter
1. Unscrew the battery cover with a Phillips head
screwdriver (not included).
2. Transmitter requires 2 AA alkaline batteries. Install with
polarity (+/-) as shown inside the battery compartment.
3. Replace battery cover and tighten screw.
NOTE: Once the batteries are installed the transmitter
will always be “ON” and will work automatically the
moment you use it.
III. OPERATION
WIDE DRIFT RIGHTFORWARD
REVERSE TIGHT DRIFT RIGHT
2 X AA
6 X AA
One-touch tight drifts!
One-touch tight drifts!
WIDE DRIFT LEFT
TIGHT DRIFT LEFT
V0098-0920 .indd 2 3/28/11 7:43:39 PM
IV. QUICK TIPS
1 When your vehicle starts to lose power, it may lose
functionality or performance. It’s time for fresh
batteries. Your vehicle’s running time may change
depending on your driving style.
2 Radio interference can affect your vehicle's
performance. Interference can be caused by other
R/C vehicles running on the same frequency,
electrical wires, large buildings or CB radios. Try to
stay away from these!
3 Point your transmitter up - not down toward your
vehicle. If your vehicle gets too far away, it won’t
work properly.
4 Don't drive your vehicle in sand or through water
or snow. If your vehicle does get wet, wipe it with a
towel and allow to dry completely overnight.
5 Don’t store your vehicle near heat or in direct
sunlight. Always turn switches OFF and remove all
batteries for storage.
6 If the vehicle malfunctions, please turn the power
OFF and ON again. This should reset your vehicle
and let you resume normal operation.
V. BATTERY SAFETY INFORMATION
In exceptional circumstances batteries may leak fluids that
can cause a chemical burn injury or ruin your product.
To avoid battery leakage:
• Non-rechargeable batteries are not to be recharged.
• Rechargeable batteries are to be removed from the
product before being charged (if designed to be
removable).
• Rechargeable batteries are only to be charged under
adult supervision (if designed to be removable).
• Do not mix alkaline, standard (carbon-zinc), or
rechargeable (nickel-cadmium) batteries.
• Do not mix old and new batteries.
• Only batteries of the same or equivalent type as
recommended are to be used.
• Batteries are to be inserted with the correct polarity.
• Exhausted batteries are to be removed from the
product.
• The supply terminals are not to be short-circuited.
• Dispose of battery(ies) safely.
• Do not dispose of this product in a fire. The batteries
inside may explode or leak.
Battery Performance Note:
For best performance use regular or high-performance
alkaline batteries (where disposable batteries are called
for). If your vehicle is supplied with standard (carbon-
zinc) batteries for initial use and/or demonstration
purposes, we recommend replacing them with alkaline
batteries when necessary. Battery life may vary
depending on battery brand.
VI. CONSUMER INFORMATION
Note to Adults: To ensure that the child’s play is both
safe and fun, please review all operating instructions
and safety rules with your child.
Safety Tips
• NEVER drive your vehicle on streets!
They’re for real cars!
• DO NOT pick up the vehicle while in motion.
• Keep fingers, hair and loose clothing away from
the tires and the wheel hubs while the vehicle is
switched ON.
• Adult supervision is recommended when this vehicle
is being operated.
• To avoid accidental operation, remove all batteries
when not in use.
Protect the environment by not disposing
of this product with household waste
(2002/96/EC). Check your local authority
for recycling advice and facilities.
V0098-0920 .indd 3 3/28/11 7:43:43 PM
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
• This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
NOTE: Changes or modications not expressly approved
by the manufacturer responsible for compliance could
void the user’s authority to operate the equipment.
RSS - 310 (Canada) (VALID FOR
CANADA ONLY - VALABLE AU CANADA
SEULEMENT)
This Category II radiocommunication
device complies with Industry Canada
Standard RSS-310. Operation is subject
to the following two conditions: (1) this
device may not cause interference, and (2)
this device must accept any interference,
including interference that may cause
undesired operation of the device.
Ce dispositif de radiocommunication de
catégorie II respecte la norme CNR-310
d’Industrie Canada. L'utilisation de ce
dispositif est autorisée seulement aux deux
conditions suivantes : (1) il ne doit pas
produire de brouillage, et (2) l'utilisateur
du dispositif doit être prêt à accepter tout
brouillage radioélectrique reçu, même si ce
brouillage est susceptible de compromettre
le fonctionnement du dispositif.
CNR-310 d’Industrie Canada (CANADA SEULEMENT)
27.145MHz is 71.1 dBuV/m @ 3m.
© 2011 Mattel, Inc. All Rights Reserved.
Mattel, Inc., 636 Girard Avenue, East Aurora, NY
14052, U.S.A. Consumer Relations 1-888-557-8926.
• Mattel U.K. Ltd., Vanwall Business Park, Maidenhead
SL6 4UB. Helpline 01628 500303. • Mattel Australia
Pty., Ltd., Richmond, Victoria. 3121.Consumer
Advisory Service - 1300 135 312. • Mattel East Asia
Ltd., Room 1106, South Tower, World Finance Centre,
Harbour City, Tsimshatsui, HK, China. • Diimport &
Diedarkan Oleh: Mattel SEA Ptd Ltd.(993532-P) Lot
13.5, 13th Floor, Menara Lien Hoe, Persiaran Tropicana
Golf Country Resort, 47410 PJ. Tel:03-78803817,
Fax:03-78803867.
service.mattel.com
Ford Oval and nameplates are registered
trademarks owned and licensed by Ford Motor
Company. www.ford.com
All commercial and publicity rights to use or
market the name and likeness of ‘Ken Block’ are
licensed exclusively through the Wasserman
Media Group, LLC.
