Maytel MTT-T Multi Tour Guide (Digital Intercom) User Manual
Maytel Co., Ltd Multi Tour Guide (Digital Intercom) Users Manual
Maytel >
Users Manual
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC
RULES.
Operation is subject to the following two conditions; (1) this
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
CAUTION : Changes or modifications not expressly approved
bythe party responsible for compliance could void the user’s
authority to operate the equipment.
CE
Radio Frequency Type
ISM 2405~2477MHz
Type
Wireless Microphone/Receiver Unit
Radio Interface
ISM 2.4GHz FSK Modulation with
Frequency Hopping
Voice Codec
16bit/24KHz
RX Sensitivity
-95dBm
Voice Latency
<35ms
Number of Frequency Channel
145ch
Channel Spacing
500KHz
Data Rate
2Mbps
Frequency Bandwidth
2MHz
Battery
Li-ion Battery @3.7V/TBD 1100mA
Antenna
Helical Antenna (Gain: 0dBi)
Talk Time for Microphone
10hr Typ.
Power Consumption
Avg. 100mA
Distance Range(LOS)
100M
Frequency Response
50Hz~7KHz
Max. Operation Users
5 persons
Dimension/Weight
98(H)X49(W)X17(D) / 88g
Audio In
TBD
Audio Out
TBD
LED Display
Status/Talk/Charging LED
Low Battery Alert
Audible signal (Beep)
Water Proof
TBD
FCC Information to User
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
con-nected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution
Modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC Compliance Information : This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation
IMPORTANT NOTE:
FCC RF Radiation Exposure Statement:
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment.
The antennas used for this transmitter must be installed to provide a separation distance of at
least 5mm from all persons and must not be co-located or operating in conjunction with any
other antenna or transmitter.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this equipment near water.
6) Do not using near any heat sources such as radiators, heat resisters, stove, or other
equipment that produce heat.
European CE notice to users and product statements
This product is CE marked according to the provisions of the R&TTE
Directive(2014/53/EU). Hereby, Maytel Co., Ltd declares that this product
is in compliance with the essential requirements and other relevant
provisions of Directive 2014/53/EU.
For further information, please contact http:// www.maytel.com
Maytel Co., Ltd
#417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si,
Gyeonggi-do, Republic of Korea
Tel: +82-31-478-5508
Fax: +82-31-440-9331
URL: www.maytel.com
CONTACT INFORMATION
Manufacturer Address #417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si,
Gyeonggi-do, Republic of Korea
To locate in-country MAYTEL CO., LTD., distributors of the MULTI TOUR GUIDE (DIGITAL INTERCOM)
please refer to the MAYTEL CO., LTD. Website http:// www.maytel.com
These distributor(s) represent local contacts for this product.
CORPORATE HEADQUARTERS:
MAYTEL CO., LTD.
#417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Republic of Korea
Tel: +82-31-478-5508
Fax: +82-31-440-9331
Web: http:// www.maytel.com
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is Subject to the following two condition: (1) this device may not cause interference
,and (2) this device must accept any interference, including interference that may cause undesired
operation of the device.
EUROPEAN UNION “DECLARATION OF CONFORMITY”
DECLARATION OF CONFORMITY
MAYTEL CO., LTD.
#417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Republic of Korea
declare under our sole responsibility that the product(s)
MULTI TOUR GUIDE (DIGITAL INTERCOM) – MTT-T
to which this declaration relate(s) is in conformance with the following standards:
EN 301 489-1 V1.9.2:2011
EN 301 489-17 V2.2.1:2012
EN 60950-1:2006/A2:2013
EN 300 328 V1.9.1:2015
following the provisions of the 2014/53/EU Directives.
