Medtronic M333688D001 RFID MODULE FOR USE WITH A RF GENERATOR FOR IDENTIFICATION OF COMPATIBILITY PURPOSES User Manual 10116967DOC Rev1A
Medtronic, Inc. RFID MODULE FOR USE WITH A RF GENERATOR FOR IDENTIFICATION OF COMPATIBILITY PURPOSES 10116967DOC Rev1A
User Manual
Medtronic Confidential
CS0049
RFID_User_Manual_FCV.fm 10/1/13 10:18 am
8.5 in x 11 in (215.9 mm x 279.4 mm)
10116967DOC Rev. 1A
RFID Module
MODEL NUMBER: M333688D001
Medtronic Confidential
CS0049
RFID_User_Manual_FCV.fm 10/1/13 10:18 am
8.5 in x 11 in (215.9 mm x 279.4 mm)
10116967DOC Rev. 1A
FEDERAL COMMUNICATIONS COMMISSION (FCC) COMPLIANCE:
FCC ID: LF5-M333688D001
■This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
■The FCC regulates marketing, sale and importation of radio frequency (RF) devices. When
importing an RF device the importer or ultimate consignee, or their designated broker, may be
required to declare that the RF device meets the FCC importation conditions under Title 47 of the
Code of Federal Regulation (CFR) Section 2.1204. See KDB 997198 Importation Guidelines for
more details.
■The host product manufacturer is responsible for ensuring that the final product with the module
installed and fully operational complies with all applicable FCC equipment authorizations
regulations, requirements and equipment functions. Refer to CFR Title 47 Part 2 Subpart J
Equipment Authorization Procedures, and KDB 784748 D01 V07 Labeling Guidelines.
■The antenna must not transmit simultaneously with any other antenna or transmitter, except in
accordance with FCC multi transmitter product codes.
■Separate approval is required for all other operating configurations, including portable
configurations with respect to CFR Title 47 Part 2.1093 and different antenna configuration.
■Any changes or modifications of this product, not approved by manufacturer will void the user's
authority to operate the equipment.
■The antenna must be installed such that it is a distance of at least 20 cm (7.9 in) between the
antenna and users.
■The module will only be installed in mobile applications as defined by part 2.1091(b).
INDUSTRY CANADA COMPLIANCE:
IC: 3408D-M333688D001
■This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
■Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne
doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Medtronic Confidential
CS0049
RFID_User_Manual_EN_CH.fm 10/1/13 10:18 am
8.5 in x 11 in (215.9 mm x 279.4 mm)
10116967DOC Rev. 1A
The following statements must be on the label or the manual of the host device:
■“This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a distance of at least 20 cm
between the radiator and your body. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.”
■“This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.”
■“Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne
doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.”
The following statements must be on the label of the host device:
■“Contains FCC ID: LF5-M333688D001”
■“Contains IC: 3408D-M333688D001”
Medtronic Confidential
CS0049
RFID_User_Manual_CST_bcv.fm 10/1/13 10:18 am
8.5 in x 11 in (215.9 mm x 279.4 mm)
10116967DOC Rev. 1A
*10116967DOC* © Medtronic, Inc. 2013
All Rights Reserved
10116967DOC Rev. 1A
Manufacturer:
Medtronic, Inc.
710 Medtronic Parkway
Minneapolis, MN 55432
USA
Tel. +1 763 514 4000
Fax +1 763 514 4879
www.medtronic.com
