MeiDong Acoustics MD-6110 Bluetooth speaker User Manual

Shenzhen MeiDong Acoustics Co., LTD Bluetooth speaker

User Manual

MD-6110
S/N:
Frequency range:
Power supply:
Audio source:
Function spec:
Size:
>75dB
Lithium battery or USB cable
iPhone, iPad, Smartphone, Notebook, MP3, MP4, etc
Bluetooth, Microphone, Line-in
180mm x 55.2mm x 55.8mm
1. Introduction
Thank you for purchasing MD-6110 This device can be easily
connected with audio or video devices for your daily needs.
The MD-6110 speaker supports both Bluetooth and Aux-in function.
Specification
2. Battery Precautions
The device is power by a built-in rechargeable lithium battery. Please charge
the battery at least 8 hours before your first use of device.
If the device is not used for a long period of time, the battery may be out of
power. please charge the battery.
Rechargeable batteries are only to be charged under adult supervision.
Do not attempt to open the rechargeable battery or battery pack. There are
no serviceable parts inside.
Should a battery leak, the device may become damaged. Clean the battery
compartment immediately, avoiding contact with your skin.
Keep the battery out of reach of children. If swallowed, consult a physician
immediately.
Avoid storing the battery in extremely hot or cold environment. A device
with a hot or cold battery may not work temporarily, even when the battery
is fully charged.
3. Getting Started
4. Cable Connection
3.5mm stereo jack
AUX
TF
USBAUX
Micro USB
5. Bluetooth Connection
Pairing MD-6110 to your devise (devise should be within 10 meters of
your speaker)
Activate pairing mode on MD-6110 by pressing “ON/OFF” button.
After prompt voice, the device is in pairing mode and can be searched.
Navigate to the Bluetooth function (refer to the tablet owner’s manual to
locate Bluetooth function).
Select “Set Up” Bluetooth or turn “ON” Bluetooth.
Select “Search” or “Discover” devices.
Select “MD-6110”
If requested, type the password or PIN 0000
Press the enter key.
After completing the steps above, a message on your devise will appear
confirming that your device is now paired/connected.
In case of unsuccessful pairing, turn off the speaker by long pressing “
ON/OFF” button and restart it.
If you turn off the device, but the Bluetooth on your devise remains open,
when you restart the device, the Bluetooth will be connected automatically.
1.
2.
3.
4.
5.
6.
7.
Notice:
1. If you turn off the device, but the Bluetooth on your devise remains
open, when you restart the device, the Bluetooth will be connected
automatically.
2. When your smartphone and this speaker are apart beyond bluetooth
receiving range, after 10 minutes, this speaker will disconnect with your
smartphone and turn into pairing mode. If within 10 minutes your
smartphone is back, will connect with this speaker automatically.
6. Microphone Usage 8. FAQ&Customer Support
When a phone call comes in, you could talk through the microphone on
speaker.
Tips:
When you make a call from your mobile phone the call will (subject to
phone settings) automatically transfer to your MD-6110.
Flash slow
Stay solid
Stay solid
Flash fast Low battery
Charging in process
Fully charged
OFF
Green
Light
Red
Light
The indicator light status display as below:
LED Display Light Indication
Ready to pair
Paired
Built-in lithium battery，can be charged through micro USB cable,
see below picture:
7. Charging and LED Indicator Light
Charging by USB
PC
Notebook
Volume Down Volume UP
Play/Pause
Next Previous
Microphone OFF/ON
Bluetooth
For Apple Mac
.Please go to the bluetooth device list and if the MD-6110 is lited
please remove it. With the MD-6110 removed or if was not listed,
restart your Apple Mac and try again to pair and connect.
For windows systems
.Please go to the bluetooth device list and if the MD-6110 is lited
please remove it. With the MD-6110 removed or if was not listed,
restart your Apple Mac and try again to pair and connect.
.If your windows system displays an error message requesting a
driver. You need to update your computer’s bluetooth driver. The
MD-6110 does not require a special driver itself and there is no driver
for it. Go to the support site for your system manufacture and specific
model and select the bluetooth driver. Download and install the
bluetooth driver, restart your system and try again to pair and connect
to your MD-6110 speaker.
3-No audo playing from the MD-6110 when connect over bluetooth
.Remove the MD-6110 from the bluetooth device list on your device,
restart your device, and then re-pair and connect to the speaker.
.Make sure the volume is up on your MD-6110 and your device.
.Make sure your bluetooth device is playing audio, and is not paused
and volume is up.
.Your bluetooth device may be out of range, move closer within 30
unobstructed feet.
.Turn your MD-6110 off and back on.
Some apps have their own volume setting. Please check the app to
make sure the volume is not on mute and the volume is up.
4-Poor sound quality when connect over bluetooth
.Your bluetooth device may be out of range, move closer within 30
unobstructed feet.
.Remove the MD-6110 from the bluetooth device list on your souce
device, restart your source device, and then re-pair and connectto the
speaker.
5-No audio playing from the MD-6110 when connected with the
3.5mm audio cable
.Make sure the 3.5mm audio cable is fully inserted into the MD-6110
and device. Some devices have cases that prevent a proper fit and
need to be removed to connect. Make sure your device is on and
playing and music.
.Increase the volume level on the MD-6110 and the device.
6-Poor soundquality when connected with the 3.5mm audio cable
.Reduce the volume level on the AUX source.
.Remove the charging cable while playing.
1- MD-6110 will not turn on
.The battery may have become fully drained. Charge the MD-6110
using a USB wall charger from a smartphone/iPhone or table for at
least 15 minutes, then press the power button to turn the speaker on.
Then continue charging the battery.
2-Cannot pair or connect to the MD-6110
.Check that your MD-6110 has a sufficient battery charge, the
speaker may not connect when the battery has a low charge.
Connect the speakerto a charging source and try again to pair and
connect.
.Your soure device may be out of range. Move it closer to within 30
unobstructed feet of your speaker.
.Check the bluetooth LED light to make sure it is flashing. If it is solid
blue that MD-6110 is already connected to another device. The
MD-6110 can be connected to one device at a time. You need to
disconnect the connected device then you can connect to the next
device.
.Your device may have a temporary bluetooth connection issue
please try the following steps which can resolve this:
For iPhone, iPad, iPod, smartphone and tablets
.Turn off the MD-6110 speaker, go to the bluetooth device list on your
iPhone, iPad or iPod, smartphone or table and check if the MD-6110
is listed. If it listed press the bluetooth icon and then press unpair this
device. With the MD-6110 unpaired or if it was not listed, do a hard
restart on your smartphone or tablet. When it restarts turn on the
MD-6110 and then try again to pair and connect. Please see
instructions 5.
.Turn your MD-6110 off and back on.
.Some devices need to have their WIFI turned off to improve audio
quality over bluetooth.
Manual
User
Model:MD-6110,MD-6110A
Brand:COWIN
Manufacture:Shenzhen MeiDong Acoustics Co., LTD
2402-2480MHz
FCC Caution.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used
in portable exposure condition without restriction.
