Mercury Innovations Science and Technology MIFAM1 bluetooth speaker User Manual
Shenzhen Mercury Innovations Science and Technology Ltd bluetooth speaker
User manual
19 English
18 English
Hold for 2 seconds to power on/off
Short press to skip to the previous
song, long press to decrease the
volume
Short press mode key, change
between Bluetooth mode, SD card
mode(SD card music mode requires
a SD card inserting first) and USB
sound card mode(connecting with
computer with the cable)in turn.
Short press to skip to the next song,
long press to increase the volume
Keys Function
M
Bluetooth disconnected or reconnect:
Hands-free call
Short press to answer or hang up
the call, long press to reject the call
Short press to play/pause music play
In the Bluetooth connection mode,
long press to disconnect , short press
again to reconnect the previous device
JU S T EN J OY
M
Bluetooth speaker
User manual
17 English
Us er Ma nual
Warranty Car d
Speaker 1pc
USB cable/data cable 1pc
What's in the box
规格40x100MM 105克铜版纸
封面
专⾊Y012C
Power on: Blue light flashing fast, ready for
Bluetooth pairing, paired continuous blue
Pause: Blue light slow flashing
Charging: Continuous red, die out while
fully charged, while out of power, the red
light flashing fast
Max. volume: Blue LED light flashing fast
Playing mode: Blue LED light flickering
LED indicator
20 English 21 English
Charge
Charging with a DC5V~500mA USB
adaptor
Data transfer
When the speaker power off, insert
micro SD card, connect the speaker
to computer,short press key,
voice prompt “Card Reader enabled”
and then can copy or delete files from
the micro SD card.
Press the power button and insert the
micro SD card, the speaker will say”SD
card enabled”, and then the speaker will
play the music in the SD card.
Micro SD Music play
Reset button:
Press to reset the device
USB sound card
Play music stored in the computer
through the speaker with the supplied
cable by shorting press key until
you hear” Auxliary enabled”.
Built-in
microphone
M
22 English
Power on the speaker after “Ding-dong”
sound and “Bluetooth enabled”, blue
light flickering ,allow pairing a Bluetooth
device.
If requires to connect other devices, press
and hold key to disconnect first and
then the speaker is discoverable and
ready to pair a new device.
Turn on the Bluetooth device, set it to
discover the “Mifa_M1”, once connected
successfully, you will hear a sound and the
LED light remains steadily on.
The speaker will auto-connect the last
paired device when it powers on.
Bluetooth Connection
23 English
Technical parameters
Product size: W105×D64×H40mm
Product weight: 225g
lithium battery included
Output Power 4Ω 3W x 2 THD=10%
Frequency Response 60Hz~20KHz
Loudspeaker
Bluetooth Version
USB Specification
Storage Type
Power Supply
File Format
APE / FLAC / WAV / WMA / MP3
Features
·Bluetooth wireless music playing,
hands-free function
·One button Bluetooth reconnection,
Micro SD card music playing
·USB sound card and card reader function
M
1.5 inch + passive radiator
Bluetooth 4.0
Built-in 950 mAh Polymer battery
DC5V-500mA USB adaptor
Max. 32GB micro SD card
USB 2.0 compatible with USB 1.1
MI CR O
SD
24 English
© MIFA all rights reserved .The product and the
packaging trademarks or registered trademarks of
MIFA INNOVATIONS LLC in the united states or other
countries .All rights reserved . Other trademarks and
trade names are registered mark of their respective
owners . MIFA INNOVATIONS LLC for any errors that
may occur in this manual does not undertake any
responsibility. The information contained in this
manual are subject to change no prior notice.
MIFA INNOVATIONS LLC
Hotline：4007-881-899
www.mifa.net Designed in US
Made in China
Warnings
◆Please use and store this product at
room temperature
Do not expose this product to rain or ◆
wet conditions
Do not throw and drop this product to ◆
avoid product damage
Do not self-dismantling ,repair and ◆
transform the product
Do not use chemical solvent cleaning ◆
the product
Please don’t arbitrarily discarded or ◆
placed the lithium battery in the fire in
order to avoid the risk of explosion
M
This device complies with part 15 of the FCC
Rules. Operation is subject to the condition
that this device does not cause harmful
interference (1) this device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
Changes or modifications not expressly
approved by the party responsible for
compliance
could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged
to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the
equipment and receiver.
-- Connect the equipment into an outlet on a
circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced
radio/TV technician for help.
The device has been evaluated to meet gener
al RF exposure requirement. The device can be
used in portable
exposure condition without restriction.
FCC ID: 2AF7A-MIFAM1
