CY920
Regulatory Compliance Information
Revision 0.0
Oct’ 2014
CY920 Regulatory Compliance Information
Revision 0.0 (10/2014)
Preliminary
1
This document covers the Regulatory Compliance information which
will be part of the datasheet and related documents shared with
customers.
CY920 Regulatory Compliance Information
Revision 0.0 (10/2014)
Preliminary
2
1.1 Antenna Considerations:
Table 1-1 provides the list of antennas along with the manufacturer and part number details.
-
1:
ANTENNA LIST
Sl
No Manufacturer Part Number
Antenna
Type Peak Gain
(2)
1 WALSIN PI_RFDPA870920IMLB301_V01
Dipole
Antenna 1.84 dBi/ 2.4 GHz
2 WALSIN PI_RFDPA870920IMLB301_V01
Dipole
Antenna
3.26 dBi/LB, 2.13dBi/ MB
-
Ext,
1.55 dBi/ UB 5GHz
3 WALSIN PI_RFDPA870930IMLB301_V01
Dipole
Antenna 1.10 dBi/ 2.4 GHz
4 WALSIN PI_RFDPA870930IMLB301_V01
Dipole
Antenna
1.88 dBi/LB, 2.41 dBi
/ MB
-
Ext,
2.77 dBi/ UB 5GHz
5 WALSIN RFDPA870930IMAB301
Dipole
Antenna 1.2 dBi/ 2.4 GHz
6 WALSIN RFDPA870945IMAB301
Dipole
Antenna 1.16 dBi/ 2.4 GHz
7 WALSIN
RFDPA870900SBAB801* +
RFCBA100630SA6B301
Dipole
Antenna 0.7 dBi/ 2.4GHz
8 WALSIN
RFDPA870900SBAB801* +
RFCBA100645SA6B301
Dipole
Antenna 0.1 dBi/2.4GHz
9 WALSIN RFDPA870933IMLB301
Dipole
Antenna 1.32 dBi/ 2.4 GHz
10 WALSIN RFDPA870933IMLB301
Dipole
Antenna
1.53 dBi/LB, 1.92dBi/ MB
-
Ext,
2.64 dBi/ UB 5GHz
Note 1: * The antenna connector is reverse SMA type.
Note 2: LB = Lower Band; MB
-
Ext = Middle Band Extended; UB =
Upper band [5GHz bands]
Table 1-2 provides the antennas to be used for the various SKUs as per Table 1-1.
-
2: ANTENNAS FOR VARIOUS SKUs
Configuration
Code
Antenna List (Sl No.)
CY920
-
A
1, 2, 3, 4, 5, 6, 7, 8, 9, 10
CY920
-
B
—
CY920
-
C
1, 2, 3, 4, 5, 6, 7, 8, 9, 10
Note 1: The antenna list for CY920
-
B SKU will be
provided in the future revisions of this
document.
CY920 Regulatory Compliance Information
Revision 0.0 (10/2014)
Preliminary
3
1.2 CY920 Usage Guidelines under Modular Approval
The CY module has received Limited Module Approval (LMA) from FCC and IC. This is because the CY module does
not have complete built-in Power regulator circuit. Microchip recommends that customers follow the supply voltage
requirements provided in the data sheet, and follow the Power supply design provided in the “CY Module Power
Supply V1.1” document. It is the product manufacturer responsibility to ensure that the power supply
recommendations are followed, and the RF behaviour adheres the FCC or TCB certification requirements
when the module is installed in the final Host product. The product manufacturer should work with their test
house for confirming the RF behavior with FCC or TCB.
CY920 Regulatory Compliance Information
Revision 0.0 (10/2014)
Preliminary
1
APPENDIX A: CERTIFICATION
NOTICES
The CY920 module is not tested for Federal
Communications Commission (FCC). The following
statements are not valid until the production version
modules are tested. It is planned to certify the
production version of the CY920 module as soon as
possible after production versions are made.
Federal Communications Commission
Interference Statement
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and radiates radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/ TV
technician for help.
Caution:
Any changes or modifications not
expressly approved by the grantee of this
device could void the user's authority to
operate the equipment.
Applicable to UNII device only: The
device is restricted to indoor use when
operating in the 5.15 GHz to 5.25 GHz
frequency band. FCC requires this
product to be used indoors for frequency
range 5.15 GHz to 5.25 GHz to reduce
the potential for harmful interference to
co-channel mobile satellite systems.
Labeling Requirements
This device complies with Part 15 of the FCC Rules. The
operation is subject to the following two conditions: the
device may not cause harmful interference, and the
device must accept any interference received, including
interferences that may cause undesired operations.
RF Exposure Warning
This equipment must be installed and operated in
accordance with provided instructions. The antennas
used for this transmitter must be installed to provide a
separation distance of at least 20 cm from all persons
and must not be co-located or operating in conjunction
with any other antenna or transmitter. End users and
installers must be provide with antenna installation
instructions and transmitter operating
conditions for satisfying RF exposure compliance.
Information for the OEMs or Integrators
The following statement must be included in all
versions of this document supplied to OEMs or
integrators, but should not be distributed to the end
user.
“This device is intended for OEM or integrators only.
Please see the full Grant of Equipment document for
other restrictions. This device must be operated and
used with a locally approved Access “.
Information to be Supplied to the End
User by the OEM or Integrator
The following regulatory and safety notices must be
published in all documentation supplied to the end user
of the product or system, incorporating an adapter in
compliance with local regulations.
“The host system must be labelled with: Contains FCC
ID:ZQO-CY920‘X’ and IC: 2581A-CY920‘X’, FCC ID
displayed on the label.
The letter shown in Ordering Guide Part Number
column should be substituted for ‘X’. For example, for
the CY920-C module, the label text should be
"Contains FCC ID:ZQO-CY920C"and "IC:
2581A-CY920C. The label text should be updated
according to the table shown in the “Ordering Guide”
section of the datasheet.
CY920 Regulatory Compliance Information
Revision 0.0 (10/2014)
Preliminary
2
Japan
This device operation in the 5.15 GHz to 5.35 GHz
frequency range is restricted to indoor use. Final
product shall be labelled "For Indoor use only."
Canada, Industry Canada (IC) Notices
This Class B digital apparatus complies with Canadian
ICES-003 and RSS-210.
Operation is subject to the following two conditions: the
device may not cause interference, and the device
must accept any interference, including interference
that may cause undesired operation of the device.
This radio transmitter "IC: 2581A-CY920‘X’ has been
approved by Industry Canada to operate with the
antenna types listed in Table with the maximum
permissible gain and required antenna impedance for
each antenna type indicated. Antenna types not
included in this list, having a gain greater than the
maximum gain indicated for that type, are strictly
prohibited for use with this device.
RF Exposure Information
The radiated output power of the wireless device is
below the Industry Canada (IC) radio frequency
exposure limits. The Wireless Device should be used in
such a manner that the potential for human contact
during normal operation is minimized.
This device has been evaluated and shown compliant
with the IC radio frequency exposure limits under
mobile exposure conditions. (antennas are greater
than 20cm from a person's body).
This device has been certified for use in Canada.
Status of the listing in the Industry Canada's Radio
Equipment List (REL) can be found at the following
locations:
http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.do?la
ng=eng
Additional Canadian information on RF exposure can
be found at the following location:
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.ht
ml
Caution:
Applicable to LE-LAN device only: This
device is restricted to indoor use when operating in the
5.15 GHz to 5.25 GHz frequency band. Industry Canada
requires this product to be used indoors for frequency
range 5.15 to 5.25 GHz to reduce the potential for
harmful interference to co-channel Mobile Satellite
systems.
Canada, avis d'Industry Canada (IC)
Cet appareil numérique de classe B est conforme aux
normes canadiennes ICES-003 et RSS-210.
Son fonctionnement est soumis aux deux conditions
suivantes: (1) cet appareil ne doit pas causer
d'interférence et (2) cet appareil doit accepter toute
interférence, notamment les interférences qui peuvent
affecter son fonctionnement.
Cet émetteur radio "IC: 2581A-CY920‘X’ a été
approuvé par Industrie Canada pour fonctionner avec
les types d'antennes énumérés dans le tableau 7-2
avec le gain maximal admissible et impédance
d'antenne requise pour chaque type d'antenne indiqué.
Types d'antennes n'est pas inclus dans cette liste,
ayant un gain supérieur au gain maximal indiqué pour
ce type, sont strictement interdits pour une utilisation
avec cet appareil.
Informations concernant l'exposition aux
fréquences radio (RF)
La puissance de sortie émise par l'appareil de sans fil
Dell est inférieure à la limite d'exposition aux
fréquences radio d'Industry Canada (IC). Utilisez
l'appareil de sans fil Dell de façon à minimiser les
contacts humains lors du fonctionnement normal.
Ce périphérique a également été évalué et démontré
conforme aux limites d'exposition aux RF d'IC dans des
conditions d'exposition à des appareils mobiles (les
antennes se situent à moins de 20 cm du corps d'une
personne).
Ce périphérique est homologué pour l'utilisation au
Canada. Pour consulter l'entrée correspondant à
l'appareil dans la liste d'équipement radio (REL - Radio
Equipment List) d'Industry Canada rendez-vous sur:
http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.do?la
ng=eng
Pour des informations supplémentaires concernant
l'exposition aux RF au Canada rendez-vous sur:
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.ht
ml
Caution:
Prudence (ce n'est applicable qu'aux dispositif LE-LAN):
Ce dispositif est limité à une utilisation en intérieur à
cause de son fonctionnement dans la gamme 5.15
GHz à 5.25 GHz. Industrie Canada exige que ce produit
est utilisé à l'intérieur pour la gamme de fréquence de
5,15 à 5,25 GHz pour réduire les risques d'interférence
nuisible à la co-canal systèmes mobiles par satellite.
CY920 Regulatory Compliance Information
Revision 0.0 (10/2014)
Preliminary
3
Taiwan – NCC Statement:
The low-power radio-frequency devices must not be
altered by changing the frequency, enhancing
emission power, adding external antenna, and
modification of original design characteristic as well as
function.
The operation of the low-power radio-frequency devices
is subject to the conditions that no harmful
interference is caused. The user must stop operating the
device immediately should harmful
interference is caused and shall not resume until the
condition causing the harmful interference has
been corrected.
Moreover, the interference must be accepted that may
be caused by the operation of an authorised
communications, or ISM equipment.
End Product Labeling:
This transmitter module is authorized only for use in
device where the antenna may be installed such that
20cm may be maintained between the antenna and
users. The final end product must be labeled in a visible
area with the following:
"Contains CCXXxxYYyyyZzW“
Device operation, if available in 5.25 – 5.35GHz
frequency range, is restricted to indoor use only,
Outdoor operations in the 5250~5350MHz is prohibited.

Navigation menu
